Sony ILCE-7RM3 Users guide

Main specifications of

General Camera Type Interchangeable-lens digital camera

Image sensor Type 35mm full frame (35.9×24.0mm), Exmor R CMOS sensor

Recording System
(still image)

Recording System
(movie)

Recording System Location Information Link From

Noise reduction Noise Reduction Long exposure NR: On/Off, available at shutter speeds longer than 1 sec.

White Balance Modes Auto / Daylight / Shade / Cloudy / Incandescent / Fluorescent <;Warm White / Cool White

Focus Focus Type

Exposure Metering Type 1200-zone evaluative metering

Viewfinder Viewfinder Type 1.3 cm (0.5-type) electronic viewfinder (color), Quad-VGA OLED Tru-Finder

*1 Phase-detection AF may not work with certain lenses or may require software update. See Sony support page for details. *2 With compatible Sony external flash. *3 With compatible external flash. *4 Varies according to shooting conditions or memory card used. *5 Images shot in Pixel Shit Multi Shooting mode
can be processed using a dedicated imaging software by Sony. Maximum flash-sync speed is limited to 1/13 second. *6 Supports Micro USB compatible device. *7 (Configuration method/Access method) WPS or manually /infrastructure mode. When connecting to smartphones, the camera can always work as a base
without a wireless access point. (Security: WEP/WPA-PSK/WPA2-PSK) *8 Sony accessories for the Accessory Shoe can be attached. *9 The LCD screen is turned on, shot once every 30 seconds, operate zoom alternately between W and T ends, flash strobe once every two times, turn power off and on once every ten
times. *10 Continuous movie recording is possible for approximately 29 minutes (limited by product specifications). *11 Indication recording time, which is defined by repeating the cycle: Power on, start recording, zoom , stand-by and power off. *12 The total movie recording time. When the limit of the continuous
movie recording time (29 minutes) is reached, let the camera continue movie recording by pressing the MOVIE button again. No other operation such as zoom is performed.

Lens mount E-mount

Number of Pixels Approx. 42.4 megapixels (effective), Approx. 43.6 (Total)
Image sensor Aspect Ratio 3:2
Anti-Dust System Charge protection coating on optical filter and image sensor shift mechanism
Recording Format JPEG (DCF Ver. 2.0, Exif Ver.2.31, MPF Baseline compliant), RAW (Sony ARW 2.3 format)
Image Size (pixels) [3:2] [35mm full frame] L: 7952 x 5304 (42M), M: 5168 x 3448 (18M), S: 3984 x 2656 (11M)

Image Size (pixels) [16:9] [35mm full frame] L: 7952 x 4472 (36M), M: 5168 x 2912 (15M), S: 3984 x 2240 (8.9M)

Image Quality modes RAW, RAW & JPEG (Extra fine, Fine, Standard), JPEG (Extra fine, Fine, Standard)
Picture Effect 8 types: Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/

Creative Style Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn

Picture Profile Yes (Off / PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709

Dynamic Range Functions Off, Dynamic Range Optimizer (Auto/Level (1-5)), Auto High Dynamic Range (Auto Exposure

Color Space
14bit RAW Yes
Uncompressed RAW Yes
Recording Format XAVC S, AVCHD format Ver. 2.0 compliant
Video Compression XAVC S: MPEG-4 AVC/H.264, AVCHD: MPEG-4 AVC/H.264
Audio Recording Format XAVC S: LPCM 2ch, AVCHD: Dolby Digital (AC-3) 2ch, Dolby Digital Stereo Creator
Color Space xvYCC standard (x.v.Color when connected via HDMI cable) compatible with TRILUMINOS

Picture Effect

Creative Style Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn

Picture Profile Yes (Off / PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709

Image Size (Pixels), NTSC XAVC S 4K: 3840 x 2160 (30p, 100M), 3840 x 2160 (24p, 100M), 3840 x 2160 (30p, 60M), 3840

Image Size (pixels), PAL XAVC S 4K: 3840 x 2160 (25p, 100M), 3840 x 2160 (25p, 60M)

Slow & Quick Motion (S&Q) /
Image size

Slow & Quick Motion (S&Q) /
Image frame rate

Movie Functions Audio Level Display, Audio Rec Level, PAL/NTSC Selector, Proxy Recording (1280 x 720,

HDMI Output 3840 x 2160 (25p), 1920 x 1080 (50p), 1920 x 1080 (50i), 1920 x 1080 (24p), 1920 x 1080 (60p),

Smartphone
Media Memory Stick PRO Duo, Memory Stick PRO-HG Duo, Memory Stick Micro (M2), SD memory

Memory Card Slot SLOT1: Slot for SD (UHS-I/II compliant) memory card

Recording mode on 2 memory
cards

Multi Frame NR -

AWB Micro Adjustment Yes <G7 to M7,57-step><A7 to B7,29-step>
Priority Set in AWB Yes
Bracketing 3 frames, H/L selectable

*1

Focus Sensor Exmor R CMOS sensor
Focus Point 35mm full frame: 399 points (phase-detection AF), APS-C mode with FE lens: 323 points

Focus Sensitivity Range EV-3 to EV20 (ISO100 equivalent with F2.0 lens attached)
Focus Mode AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus),

Focus Area Wide (399 points (phase-detection AF), 425 points(contrast-detection AF)) / Zone / Center

Other Features Eye-start AF (only with separately sold LA-EA2 or LA-EA4 attached), Lock-on AF, Eye AF, AF

AF Illuminator Yes (with Built-in LED type)
AF Illuminator Range Approx. 0.3m - approx. 3.0m (with FE 28-70mm F3.5-5.6 OSS attached)
Focus Type With LA-EA3

(Sold separately)

Metering Sensor Exmor R CMOS sensor
Metering Sensitivity EV-3 to EV20 (at ISO100 equivalent with F2.0 lens attached)
Metering Mode Multi-segment, Center-weighted, Spot, Spot Standard/Large, Entire Screen Avg., Highlight
Exposure Compensation +/- 5.0EV(1/3 EV, 1/2 EV steps selectable) (with exposure compensation dial : +/- 3EV (1/3

Exposure Bracketing Bracket: Cont., Bracket: Single, 3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3,

AE Lock
Exposure Modes AUTO (iAuto), Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual

ISO sensitivity
(Recommended Exposure
Index)

Anti-flicker Shoot. Yes

Number of Dots 3,686,400 dots
Brightness Control (Viewfinder) Auto/Manual (5 steps between -2 and +2)
Color Temperature Control Manual (5 steps)

[APS-C] L: 5168 x 3448 (18M), M: 3984 x 2656 (11M), S: 2592 x 1728 (4.5M)

[APS-C] L: 5168 x 2912 (15M), M: 3984 x 2240 (8.9M), S: 2592 x 1456 (3.8M)

G/B/Y), High Contrast Monochrome, Toy Camera(Normal/Cool/Warm/Green/Magenta),
Soft High-key, Rich-tone Monochrome

leaves, Black & White, Sepia, Style Box (1-6), (Contrast (-3 to +3 steps), Saturation (-3 to +3
steps), Sharpness (-3 to +3 steps))

[800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color
Phase, Color Depth, Detail, Copy, Reset

Difference, Exposure Difference Level (1-6 EV, 1.0 EV step))
sRGB standard (with sYCC gamut) and Adobe RGB standard compatible with TRILUMINOS Color

Color
Posterization (Color), Posterization (B/W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High

Contrast Monochrome, Toy Camera(Normal/Cool/Warm/Green/Magenta), Soft High-key

leaves, Black & White, Sepia,Style Box(1-6) (Contrast (-3 to +3 steps), Saturation (-3 to +3
steps), Sharpness (-3 to +3 steps))

[800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Color Mode, Saturation, Color
Phase, Color Depth, Detail, Copy, Reset

x 2160 (24p, 60M)
XAVC S HD: 1920 x 1080 (120p, 100M), 1920 x 1080 (120p, 60M), 1920 x 1080 (60p, 50M), 1920

x 1080 (30p, 50M), 1920 x 1080 (24p, 50M), 1920 x 1080 (60p, 25M), 1920 x 1080 (30p, 16M)
AVCHD: 1920 x 1080 (60i, 24M, FX), 1920 x 1080(60i, 17M, FH)

XAVC S HD: 1920 x 1080 (100p, 100M), 1920 x 1080 (100p, 60M), 1920 x 1080 (50p, 50M), 1920
x 1080 (25p, 50M), 1920 x 1080 (50p, 25M), 1920 x 1080 (25p, 16M)

AVCHD: 1920 x 1080 (50i, 24M, FX), 1920 x 1080 (50i, 17M, FH)
NTSC mode: 1920x1080 (60p, 30p, 24p)
PAL mode: 1920x1080 (50p, 25p)
NTSC mode: 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps
PAL mode: 1fps, 2fps, 3fps, 6fps, 12fps, 25fps ,50fps,100fps

9Mbps), TC/UB (TC Preset/UB Preset/TC Format/TC Run/TC Make/UB Time Rec), Auto Slow
Shutter, REC Control, Clean HDMI Info.(ON/OFF selectable), Gamma Disp. Assist

1920 x 1080 (60i), 3840 x 2160 (30p), 3840 x 2160 (24p), YCbCr 4:2:2 8bit / RGB 8bit
Yes

card, SDHC memory card (UHS-I/II compliant), SDXC memory card (UHS-I/II compliant),
microSD memory card, microSDHC memory card, microSDXC memory card

SLOT2: Multi slot for Memory Stick Duo/SD (UHS-I compliant) memory card

Simult. Rec (Still), Simult. Rec (Movie), Simult. Rec (Still/Movie), Sort (JPEG/RAW), Sort (Still/

Movie), Auto Switch Media (On/Off), Copy

High ISO NR: Normal/Low/Off

/ Day White / Daylight> / Flash /Underwater/ Color Temperature <2500 to 9900K> & color
filter <G7 to M7(57-step), A7 to B7(29-step)> / Custom

Fast Hybrid AF (phase-detection AF/contrast-detection AF)

(phase-detection AF), with APS-C lens: 255 points (phase-detection AF) / 425 points
(contrast-detection AF)

Manual Focus

/ Flexible Spot (S/M/L) /Expanded Flexible Spot/ Lock-on AF ( Wide / Zone / Center /
Flexible Spot (S/M/L)/Expanded Flexible Spot)

micro adjustment (only with separately sold LA-EA2 or LA-EA4 attached), Predictive control,
Focus lock, AF Track Sensitivity, Swt.V/H AF Area, AF Area Registration

Selectable (phase-detection, contrast-detection)

EV steps))

1.0, 2.0, or 3.0 EV increments, with 9 frames, in 1/3, 1/2, 2/3, or 1.0 EV increments.
Locked when shutter button is pressed halfway. Available with AE lock button. (On/Off/Auto)

(M), Movie (Programmed AE (P) / Aperture priority (A) / Shutter-speed priority (S) / Manual
(M) ), Slow & Quick Motion (Programmed AE (P) / Aperture priority (A) / Shutter-speed
priority (S) / Manual (M) )

Still images: ISO 100-32000 (ISO numbers up from ISO 50 to ISO 102400 can be set as
expanded ISO range.),

AUTO (ISO 100-12800, selectable lower limit and upper limit)
Movies: ISO 100-32000 equivalent, AUTO (ISO 100-12800, selectable lower limit and upper limit)

Trademarks & Remarks

"

", "Exmor", "Exmor R", "BIONZ X", "BRAVIA", "SteadyShot", "InfoLithium", "Translucent Mirror Technology", "Tru-Finder", "Memory Stick", "Memory Stick PRO Duo", "Memory Stick PRO-HG Duo", "PlayMemories Home", "PlayMemories Mobile", "PlayMemories Camera Apps", "x.v.Color", "TRILUMINOS", "TRILUMINOS

•

Color", "TRILUMINOS Display" and "XAVC S" are trademarks or registered trademarks of Sony Corporation. • "Xperia" is a trademark or registered trademark of Sony Mobile Communications AB. • "AVCHD" and "AVCHD Progressive" are trademarks of Panasonic Corporation and Sony Corporation. • The SD Logo, SDHC
Logo and SDXC Logo are trademarks of SD-3C, LLC. • The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. • The Wi-Fi Protected Setup Identifier Mark is a mark of the Wi-Fi Alliance.

• N-Mark is a registered trademark of the NFC Forum. • Dolby is a trademark of Dolby Laboratories. • WhiteMagic is a trademark of Japan Display Inc. • App Store is a service mark of Apple Inc. • Android, Google Play and Google Play logo are trademarks or registered trademarks of Google Inc. • iPad is a trademark
of Apple Inc., registered in the U.S. and other countries. • All other company and product names mentioned herein are used for identification purposes only and may be the trademarks or registered trademarks of their respective owners. • "InfoLithium" is a lithium battery pack which can exchange data with
compatible electronic equipment about its energy consumption. • Sony recommends that you use the battery pack with electronic equipment bearing the "InfoLithium" mark. • Screen displays and effects used to illustrate some functions are simulated. • For use of other companies’ services and software, 1) other

conditions for use may be applied. 2) updating of services and software may be stopped/terminated without prior notice. 3) the contents of services and software may be changed without prior notice. 4) other registrations or payments of other fees may be required.

Specifications and features are subject to change without notice.

Viewfinder (Cont.) Field Coverage 100%

LCD Screen Type 7.5cm (3.0-type) type TFT

Other Features PlayMemories Camera Apps™ -

Shutter Type Electronically-controlled, vertical-traverse, focal-plane type

Image Stabilization Type Image Sensor-Shift mechanism with 5-axis compensation (Compensation depends on lens

Flash Control Control Pre-flash TTL

Drive Drive Modes Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), Self-timer, Self-timer

Playback Photo Capture Yes

Interface PC Interface Mass-storage, MTP, PC remote

Audio Microphone Built-in stereo microphone or XLR-K2M/XLR-K1M/ECM-XYST1M (sold separately)

Print Compatible Standards Exif Print, Print Image Matching III, DPOF setting
Custom function Type Custom key settings, Programmable Setting (Body 3 sets /memory card 4 sets), My Menu,

Lens Compensation Setting Peripheral Shading, Chromatic Aberration, Distortion
Power Supplied Battery One rechargeable battery pack NP-FZ100

Others Operating Temperature 32 - 104 degrees F / 0 - 40 degrees C
Size & Weight Dimensions (W x H x D) Approx. 126.9mm x 95.6mm x 73.7mm, Approx. 126.9mm x 95.6mm x 62.7mm (from grip to

What's In The Box Power cord, Rechargeable Battery NP-FZ100, Cable Protector, Battery Charger BC-QZ1,

Magnification Aapprox. 0.78 x (with 50mm lens at infinity, -1m
Dioptre Adjustment - 4.0 to +3.0m
Eye Point Approx. 23mm from the eyepiece lens, 18.5mm from the eyepiece frame at -1m-1 (CIPA

Finder Frame Rate Selection NTSC mode: STD 60fps / HI 120fps

Display Content Graphic Display, Display All Info., No Disp. Info., Digital Level Gauge, Histogram

Number of Dots 1,440,000 dots
Touch Panel Yes
Brightness Control Manual (5 steps between -2 and +2), Sunny Weather mode
Adjustable Angle Up by approx. 107 degrees, Down by approx. 41 degrees
Display Selecter (Finder/LCD) Yes (Auto/Manual)
Real-time Image Adjustment

Display (LCD)
Quick Navi Yes
Focus Magnifier Yes (35mm full frame: 6.2x, 12.4x APS-C: 4.0x, 8.0x)
Zebra Yes (Selectable level + range or lower limit as custom setting)
Peaking MF Yes (Level setting: High/Mid/Low/Off, Color: White/Red/Yellow)
Others WhiteMagic™, Grid Line (Rule of 3rds Grid/Square Grid/Diag. + Square Grid/Off), Movie

Display Contents

Clear Image Zoom Still images:Approx. 2x

Digital Zoom Smart zoom (Still images) [35mm full frame] M: approx 1.5x, S: approx 2x [APS-C] M: approx

Face Detection [Modes] Face Priority inAF (On/Off), Face Priority in Multi Metering (On/Off), Regist. Faces

Others Touch Focus (Available with LCD monitor or Viewfinder operation), ISO AUTO Min. SS, Bright

Eye-Fi ready -

Shutter Speed [Still images] 1/8000 to 30 sec, Bulb, [Movies] 1/8000 to 1/4 (1/3 steps) up to 1/60 in AUTO

Flash Sync. Speed
Electronic Front Curtain Shutter Yes (ON/OFF)
Silent Shooting Yes (ON/OFF)

*2

Compensation Effect 5.5 stops (based on CIPA standard. Pitch/yaw shake only. With Planar T* FE 50mm F1.4 ZA

Flash Compensation +/- 3.0 EV (switchable between 1/3 and 1/2 EV steps)
Flash Bracketing 3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, 3.0 EV increments, with

Flash Modes Flash off, Autoflash, Fill-flash, Slow Sync., Rear Sync., Red-eye reduction (on/off selectable),

External Flash Compatibility Sony α System Flash compatible with Multi Interface Shoe, attach the shoe adaptor for flash

FE Level Lock Yes
Wireless Control Yes (Light signal: Available with Fill-flash, Slow Sync., Hi-speed sync. /Radio signal: Available

Continuous Drive Speed

*4

(approx. max.)
No. of Recordable Frames

*4

(approx.)

Self-Timer 10 sec. delay/5 sec. delay/2 sec. delay/Continuous self-timer (3 frames after 10 sec. delay/5

Pixel Shift Multi Shooting Yes

Modes Single (with or without shooting information Y RGB histogram & highlight/shadow

Multi / Micro USB Terminal
USB Type-C™ Terminal Yes (SuperSpeed USB (USB 3.1 Gen 1) compatible)
NFC™ Yes (NFC forum Type 3 Tag compatible), One-touch remote, One-touch sharing
Wireless LAN (Built-In) Wi-Fi Compatible, IEEE 802.11b/g/n (2.4GHz band), View on Smartphone, Send to Computer,

Bluetooth Yes (Bluetooth Standard Ver. 4.1 (2.4GHz band))
HD Output HDMI micro connector (Type-D), BRAVIA Sync(Control for HDMI), PhotoTV HD, 4K movie

Multi Interface Shoe
Mic Terminal Yes (3.5 mm Stereo minijack)
Sync Terminal Yes
Headphone Terminal Yes (3.5 mm Stereo minijack)
Vertical Grip Connector Ye s
PC Remote Yes
LAN Terminal -

*6

*8

-1

standard)

PAL mode: STD 50fps / HI 100fps

On/Off

Marker (Center/Aspect/Safety Zone/Guideframe)
Graphic Display, Display All Info, No Disp. Info, Digital Level Gauge, Histgram, For viewfinder, Monitor Off

Movies:Approx. 1.5x (4K), Approx. 2x (HD)

1.3x, S: approx 2x
Digital zoom (Still images) [35mm full frame] L: approx 4x, M: approx 6.2x, S: approx 8x

[APS-C] L: approx 4x, M: approx 5.2x, S: approx 8x
Digital zoom (Movie) [35mm full frame] approx 4x [APS-C] approx 4x

Priority (On/Off)
[Face registration] Max. number of detectable: 8

Monitoring, Copyright Info, Set File Name, FTP Transfer Func., Help guide, Area Setting, Shop
Front Mode, Video Light Mode, Zoom Ring Rotate

mode (up to 1/30 in Auto slow shutter mode);
1/250 sec.

specifications)

lens mounted. Long exposure NR off.)

9 frames, in 1/3, 1/2, 2/3, 1.0 EV increments.

Wireless

*3

, Hi-speed sync.

*3

compatible with Auto-lock accessory shoe

with Fill-flash, Rear Sync., Slow Sync., Hi-speed sync.)

(Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket
Continuous shooting: Hi+: max. 10 fps, Hi: max. 8 fps, Mid: max. 6fps, Lo: max. 3 fps

JPEG Extra fine L: 76 frames, JPEG Fine L: 76 frames, JPEG Standard L: 76 frames, RAW: 76
frames, RAW&JPG: 76 frames, RAW (Uncompressed): 28 frames, RAW (Uncompressed)&JPG:

28 frames

frames after 10 sec. delay/3 frames after 5 sec. delay/5 frames after 5 sec. delay/3 frames
after 2 sec. delay/5 frames after 2 sec. delay)/Bracketing self-timer

*5

warning), 9/25-frame index view, Enlarged display mode (L: 19.9x, M: 12.9x, S: 10.0x), Auto
Review (10/5/2 sec,Off), Image orientation (Auto/Manual/Off selectable), Slideshow, Folder
selection (Date/ Still/ AVCHD/XAVC S HD/XAVC S 4K), Forward/Rewind (movie), Delete,
Protect, Rating, Disp Cont Shoot Grp

Yes

*7

View on TV

output/4K still image PB
Yes

Speaker Built-in, monaural

Reg Cust Shoot Set

Battery Life

(Still Images) *9Approx. 530 shots (Viewfinder) / approx. 650 shots (LCD monitor) (CIPA standard)

(Movie, actual recording)

(Movie, continuous recording)

*10 *11

Approx. 100 min (Viewfinder) / Approx. 115 min (LCD monitor) (CIPA standard)

*10 *12

Approx. 180 min (Viewfinder) / Approx. 190 min (LCD monitor) (CIPA standard)

Still images: approx. 3.7W (with FE 28-70mm F3.5-5.6 OSS lens attached),
Movies: approx. 5.5W (with FE 28-70mm F3.5-5.6 OSS lens attached)

Still images: approx. 3.0W(with FE 28-70mm F3.5-5.6 OSS lens attached),
Movies: approx. 5.2W (with FE 28-70mm F3.5-5.6 OSS lens attached)

monitor) /Approx. 5 x 3 7/8 x 3 inches, Approx. 5 x 3 7/8 x 2 1/2 inches (from grip to monitor)

Battery Life
Battery Life
Internal Battery Charge Yes (Available via Multi/Micro USB Terminal or USB Type-C™ Terminal)
Power Consumption With

Viewfinder
Power Consumption With LCD

Screen
USB Power Supply Yes (Available via Multi/Micro USB Terminal or USB Type-C™ Terminal)

Weight Approx. 657 g / approx. 1lb 7.2 oz (with battery and memory card included)

Shoulder strap, Body cap, Accessory shoe cap, Eyepiece cup, USB Type-C™ cable

-1

)

Printed in Japan©October 2017 Sony Corp.

Interchangeable-lens

digital camera

Reality realized. New worlds.

The art of bringing the world to life in photographic form hinges on a sublime blend of technical
capability and creative vision. With a new system that achieves outstanding resolution, sensitivity,
dynamic range, and speed, the 7R III provides the technical capability you need to let your
imagination soar and fulfill your vision with breathtaking reality. All of this comes in a compact,
mobile package that is easy and intuitive to use while seamlessly supporting professional workflows.
The 7R III offers the potential you need to realize concepts and explore worlds that have previously been beyond reach.

*

* Connect to an HDR (HLG) compatible Sony TV via a USB cable when displaying HDR (HLG) movies.
** Up to 10 fps in continuous “Hi+” mode, and up to 8 fps in continuous “Hi” mode. Maximum fps will depend on camera settings.

**

No.1 image sensor manufac­turer for digital cameras and
video recorders. Based on
Sony research – April 2016 to
March 2017
(over 50% market share).

NEW

in this guide marks an a dvan cemen t over th e

7R II .

FE 85mm F1.4 GM (SEL85F14GM), 1/250sec., F8, ISO 100

54

FE 24-70mm F2.8 GM (SEL2470GM), 1/640sec., F8, ISO 200

FE 100-400mm F4.5-5.6 GM OSS (SEL100400GM), 1/4000 sec., F5.6, ISO 400

FE 12-24mm F4 G (SEL1224G), 2 sec., F8, ISO 100, Pixel Shift Multi Shooting mode, composited using dedicated software

Planar T* FE 50mm F1.4 ZA (SEL50F14Z), 1/250 sec., F1.4, ISO 100

A portal to unseen worlds

Technology both frees and confines art. As it evolves restraints
diminish and art comes to the fore. The
an evolutionary leap, freeing the user to explore previously
unseen worlds of detail, color, dimension, and time.

7R III makes

Versatile viewingSpectacular Rendering

Back illumination for high sensitiv­ity, gapless on-chip lenses, anti­reflective seal glass coating, no
optical low-pass filter, and other
advanced features contribute to un-

* Approximately.

Faster, more detailed image processing

The latest high-speed front-end
LSI and updated BIONZ X™ image­processing engine provide a dramatic
increase in system speed, plus an
impressive 15-stop dynamic range*
at low-sensitivity settings. Advances
have also been made in Sony’s Detail
Reproduction Technology and Area­specific Noise Reduction features,

precedented imaging performance.
High resolution, high sensitivity with
low noise, and wide dynamic range
add up to vastly expanded shooting
potential.

NEW

reducing noise by as much as a full
stop** in the mid sensitivity range.
A sublime blend of high resolution
and low noise is ensured over a wide
sensitivity range, for outstanding
image quality and color accuracy that
are ideal for portraits and landscape
photography.

* Sony test cond itions for stills * * Compa red to th e

Standard 100 ~ 32000 ISO expandable up to 102400*

The standard ISO range has been ex­tended to ISO 100 ~ 32000, expand­able* to ISO 50 at the low end and ISO

102400 at the high end for wide cover­age that can capture low-light scenes
with high quality and low noise.

NEW

* Exp anded ISO available

for still images onl y.

FE 24-70mm
F2.8 G M (SEL2470GM),
1/320sec., F11, ISO 3200

7R II .

16-bit processing and
14-bit RAW output

The digital output from the image
sensor’s AD converter is processed
in 16-bit form by the front-end LSI
and BIONZ X processor before being
output as compressed or uncom­pressed 14-bit RAW files. The result
is smoother, more natural gradations
that contribute to higher overall im­age quality. The enhanced image
processing system makes 14-bit RAW
output available even when shooting
in silent or continuous mode.*

* Limited to 12 bits dur ing com press ed RAW contin uous

shooting, BU LB ex posure, or whe n Long E xposure NR
is ON.

16-bit image processing

Image Sensor

14bits

Newly developed

high-speed front-end LSI

NEW

8bits

14bits

JPEG

RAW

3.69 million dot Quad-VGA OLED Tru-Finder™42.4* effective megapixel full-frame Exmor R™ CMOS sensor

NEW

This high-resolution Quad-VGA OLED
Tru-Finder has approximately 3.69
million dots for fine detail and high
contrast for accurate black reproduc­tion. High luminance brings view­finder brightness closer to that of the
actual scene. The high quality of the
viewfinder image and features like
focus magnification make it easier to
achieve perfect focus with just about
any subject in any situation.

High quality mode

“Standard” and “High” quality settings
are available for the viewfinder and
monitor. “High” takes advantage of the
large amount of data read from the

42.4 effective megapixel sensor to pro­vide extra fine viewfinder and monitor

Conventional XGA Finder

AF in Focus Magnifier

By magnif ying the selected focus
area while using autofocus to shoot
stills this function makes it easier to
achieve perfect focus, especially for
macro photography and other criti­cal applications.

displays for a more natural view.

Compact, lightweight, and durable

Lightweight, durable magnesium body

To ensure maximum reliability in
harsh conditions, body durability
has been enhanced by the use of a

Increased mount and grip rigidity

NEW NEW

Increased lens mount rigidity maxi­mizes durability when using heav y
optics, and the grip has been rede­signed and unified with the front
cover using magnesium alloy for
higher overall rigidity.

lightweight, high-rigidity magne­sium alloy for the top cover, front
cover, internal frame, and rear cover.

Durable low-vibration shutter

A new shutter unit features a fast­response coreless motor and brake
system that effectively subdues me­chanical vibration. The shutter has
been tested for durability in excess
of 500,000 shutter cycles.*

* Sony in terna l test s with elec tronic front cur tain s hut ter.

Quad-VGA Finder (High quality mode)

NEWNEW

Improved peaking

NEW

The evolved BIONZ X processing
engine improves the accuracy of
“peaking” display that highlights
in-focus areas when focusing manu­ally, making it easier to achieve
precise focus.

Dust and moisture resistant*

Sealing is provided at critical loca­tions to minimize dust and moisture
ingress, ensuring reliable operation
in challenging environments.

* Not guaranteed to be 10 0% dust and moisture proof.

1514

Speed and precision capture perfect moments

Breakthroughs in continuous shooting and autofocus performance
make it easier than ever to capture those elusive natural moments
that define the photographer’s art. Enhanced operability and
reliability further ensure that not a moment is lost.

High-speed continuous shooting

Up to 10 fps* continuous shooting with AF/AE tracking

Continuous shooting at up to 10 fps*
with accurate AF/AE tracking makes it
possible to capture moving subjects
in their most photogenic moments
while taking full advantage of the

camera’s 42.4 megapixel resolution
and 14-bit output. The image files
produced contain ample data for
flexible trimming and retouching
without losing image quality. It is

42.4

megapixels

10fps

NEW

also possible to shoot continuously
at up to 8 fps* in live view mode,
with minimal viewfinder/monitor
display lag.

Unprecedented AF performance

Updated algorithms enhance AF response

Evolved image processing plus AF algorithms from the 9
refined and optimized for the
provements in AF speed, precision, and tracking performance.
Even the wildest motion can be tracked reliably.

Wide: 399 phase-detection +
425 contrast AF points

399 focal plane phase-detection AF
points cover approximately 68% of
the image area in the horizontal and
vertical directions, complementing
425 contrast AF points for consis­tently reliable focus.

7R III provide significant im-

NEW

Fast:
Up to 2x* AF speed

Enhanced Fast Hybrid AF System
performance achieves low-light AF
response that is up to twice as fast*
as the
able even in dim lighting.

* Compared to the 7R II. Sony tes t condi tions.

7R II. Focus is fast and reli-

Steadfast: Subject tracking performance
approximately doubled

Tracking performance during continu­ous shooting has been improved by
approximately 2x.* Complex, unpre­dictable motion is reliably tracked with
greater precision than ever before.

NEWNEWNEW

42.4 meg apixe l resolution prov ides plent y of margin
for cropping.

10 fps co ntinu os shooting c aptur es the decisi ve moment

Silent continuous shooting**

Silent, vibration-free shooting at up
to 10 fps** with AF/AE tracking and no
cropping is also available when shoot­ing in silent mode. Silent shooting

* Up to 10 fps in continu ous “Hi +” mode, and up to 8 fps in cont inuou s “Hi” mode. Ma ximum fps will depe nd on camera settings.
** So me dis tortion ma y occur w ith fast-mo ving s ubjects o r if the c amera is move d sideways ra pidl y while shooting.

NEW

is critical for wildlife photography
where even the slightest shutter
noise can mean missing the mo­ment.

Focal plane phase-detection AF
with A-mount lenses*

Focal plane phase-detection AF also
functions with A-mount lenses* mount­ed via the LA-EA3 adaptor, providing
wide-area coverage, fast response, and
high tracking performance. Eye AF is
now supported with A-mount lenses*.

* With SS M or SA M lense s only. With the LA- EA 3 mount adapter. Focal pl ane pha se-detec tion AF not sup por ted fo r

movie recording. AF-C ca n only b e used w hen the “Phase detec tion” AF sys tem is se lec ted, but focus is fi xed at t he
first frame dur ing con tinuous shooting in any mod e other than “Continu ous: Lo” (Hi +, Hi, Mid).

Reliable AF down to
EV-3 brightness

Advanced AF algorithms contribute
to high AF precision down to light
levels as low as EV-3 (ISO 100 equiv­alent, F2.0 lens) in the AF-S mode.
AF is more precise and reliable in
dark scenes.

NEWNEW

1716

Efficient focus control

More continuous shooting support

AF-ON button

NEW

Press the AF-ON button to activate
autofocus when shooting stills or mov­ies. This makes it possible to release
the shutter instantly to capture fleeting
moments without having to go through
the normal half-press focus sequence.

Multi-selector

NEW

The multi-selector provides a fast,
efficient way to shift focus points.
Simply press the up, down, left, or
right button when using the Zone,
Flexible Spot, or Expand Flexible
Spot focus area mode.

3.0 type 1.44 million dot
tilting LCD monitor

NEW

This 3.0 type LCD monitor with 1.44
million dots features high resolution
for detailed viewing. WhiteMagic™
technology is included to ensure that
LCD viewing is bright and clear even
in outdoor conditions. The monitor
tilts upwards by a maximum of 107°,
and downwards by a maximum of 41°
for flexible hold and framing.

AF-ON Multi-selector

Touchpad Function
Touch Focus

Touch focus Touchpad focus point control

Simply touch the monitor screen to
specify the desired focus point for
stills or movies. Even subjects near
the frame edges can be instantly
selected without having to reframe
or manually shift the focus point.
Double-tap any point for a magni­fied view of that area when focusing
manually.

NEW

The monitor touchpad function al­lows the focus frame to be dragged
to any desired point with a fingertip
while viewing through the view­finder. Relative and absolute modes
are available, and nine area patterns
provide easy operation when view­ing with either eye, and when posi­tioning with either hand.

NEW

NEW

NEW

Separate media slots for SD card
(UHS-II compatible) and SD/MS card
allow data to be simultaneously or se­quentially recorded to two cards (Auto
Switch Media), or separate cards can
be assigned to save RAW and JPEG
files, or stills and movies. Data can
also be copied between media cards.

Rating and protect functions
facilitate on-location sorting

NEW NEW

Ratings of from 1 to 5 stars can be
applied to still images right from
the camera controls. The rating and
protect functions can be set via as­signed custom buttons while view­ing the review playback display on
location or while traveling to save
time.

Up to 76* images per burst Dual media slots, UHS-II support

A larger buffer memory, increased
overall system speed, UHS-II sup­port, and other refinements allow
up to 76* JPEG or compressed RAW
images, or up to 28* uncompressed
RAW images to be captured in one
continuous burst.

* “Hi+” continuo us mode with U HS-I I compa tible SDXC

memor y card. Sony te st conditio ns.

Improved operability while
writing to memory card

The Fn menu can be accessed and
edited immediately after continuous
shooting while data writing is in prog­ress*, as can the menus and parame­ters. It is also possible to immediately
access the playback display, with the
number of still images remaining to
be written shown during playback.

* Not all me nu parameters can b e edited whil e data is

being w rit ten to th e memo ry card.

NEW

Display continuous shooting
group

Images shot in continuous mode
can be reviewed as groups, and the
play index display has been signifi­cantly improved. Continuous groups
can be deleted or protected in one
quick operation to save time on
location.

Switch Vertical and Horizontal AF Area

It is possible to use separate or
identical focus areas and points
for horizontal and vertical camera
orientations, reducing the need to

AF tracking sensitivity

NEW NEW NEW

The sensitivity with which autofocus
will follow subjects that move outside
the focus area can be adjusted in 5
steps when shooting stills. Higher
sensitivity is best for subjects at vary­ing distances, while lower sensitivi­ties can keep focus on a subject that
is briefly obscured by other objects.

NEW

readjust focus when shooting sub­jects that requires frequent camera
orientation changes.

AF Area Registration Recall Custom Setting During Hold

Frequently used focus point settings
can be memorized and instantly
recalled via custom button assign­ments. Focus area mode settings
can also be memorized and recalled
as required for fast, convenient
operation.

Memorized settings (exposure,
focus settings, drive mode, etc.) can
be assigned to custom buttons for
temporary recall while the button
is held, providing a convenient way
to quickly make temporary setting
changes.

Professional staminaCustomizable Functions for Smooth Focus Operation

Battery capacity increased by
approximately 2.2 times

A new NP-FZ100 battery provides
approximately 2.2 times the capac­ity of the NP-FW50. The optional
VG-C3EM Vertical Grip holds two
batteries, or an optional Multi Bat­tery Adaptor (NPA-MQZ1K) can hold
up to four Z batteries for even fur­ther extended recording time.

NEW NEW

USB power

USB Type-C™ and Multi/Micro USB
connectors allow external mobile bat­teries to power the camera for extend­ed recording time. The Multi/Micro USB

connector can be used with a remote
control unit or other accessory while
the USB Type-C™ connector is used
for power supply or PC tethering.

1918

New portraiture potential

Innovations in Eye AF technology make the delicate task of
photographing people smoother and easier, while 5-axis
image stabilization boosts mobility and flexibility for sig-
nificantly enhanced portraiture potential.

New portraiture potential

Innovations in Eye AF technology make the delicate task of
photographing people smoother and easier, while 5-axis
image stabilization boosts mobility and flexibility for sig­nificantly enhanced portraiture potential.

Automatic, instant eye focus

Doubled Eye AF performance*

Eye AF automatically detects and
focuses on the subject’s eye. Notable
improvements in detection preci­sion and speed in the

7R III result
in approximately doubled* tracking
performance when shooting moving

* Compared to the 7R II, app rox.
** Wit h SSM or S AM lenses on ly. With the L A-E A3 m ount ad apter. Eye AF not su ppor ted for movie record ing. AF-C ca n

only be used wh en the “ Phase d etec tion” AF sy stem is s elec ted, but focu s is fi xed at the fir st frame dur ing continuo us
shooting in any mode ot her than “Cont inuou s: Lo” (Hi+, Hi, M id).

NEW

portrait subjects. Eye focus is fast
and accurate even if the subject
is distant, looking away from the
camera, backlit, or in other situa­tions that would challenge previous
systems. Eye AF is also supported

for A-mount lenses mounted via an
adaptor.**

Eye AF can lock
on even w hile the
subject is tu rning
around

Subject looking down

* Eye AF ma y not fu nct ion as e xpec ted in some sit uatio ns.

Indoo r shot s when t he face is dimly l it Obst acles o bscure par t of the f ace (glasses, hands, etc.)

In-body image stabilization enhances shooting freedom

5-axis optical in-body image stabilization for a 5.5-step* exposure advantage

A new precision stabilization unit and
gyro sensors work with optimized
image stabilization algorithms to
achieve a 5.5-step* shutter speed
advantage. Camera shake is effec­tively compensated for in 5 axes, and
stabilization is effective for movies as

* CIPA standard s. Pitc h/yaw shake onl y. Planar T* F E 50mm F1.4 Z A lens. Long ex posure NR of f.

well as stills. The viewfinder image
is stabilized too, making it easier to
frame and focus. Effective stabiliza­tion is achieved with a wide range
of lenses, including non-stabilized
E-mount lenses, and A-mount
lenses mounted via an adaptor.

NEW

FE 70-200mm F2.8 GM OSS (SEL70200GM), 1/1000 sec., F5.6, ISO 800

Pitch and yaw compensation Horizontal and vertical shift compensation Roll compensation

Compensation for co mmon ly experienced pitch and
yaw shake a t long focal length s.

Compensation for X a nd Y-axis s hif t shake at high mag­nification (during macrophotography, etc.).

Compensation for roll shake on the Z-axis duri ng long
exposures. Most in-lens systems for interchangeable­lens cameras c annot compensate for roll shake.

2120

22

23

Smooth studio workflow

Features and operation related to PC remote shooting and
flash lighting have been updated in many important ways,
complementing improved response and higher efficiency
for professional studio applications.

Speed and flexibility for tethered shooting Professional lighting capability

USB 3.1 Gen 1 compatible USB Type-CTM connector for fast transfer Improved flash compatibility

A USB Type-

C™

connector that sup­ports fast USB 3.1 Gen 1 data trans­fer makes high-speed PC Remote
data transfer available for smooth

handling of large RAW image files.
Quickly review images on a PC, and
continue shooting without having to
wait for slow file transfers.

NEW

A standard sync terminal is provided
for convenient synchronization with
studio flash units and other external
lighting equipment. Release time
lag has been minimized for smooth,
responsive flash photography. Con-

* Maximum continuous shootin g spee d will de pend o n the f lash and shoot ing settings used.
** Rea r cur tain s ync is n ot available w ith optical wirel ess f lash units.

Image storage selection for PC remote

When the camera is tethered to a
computer, still images can be stored
in the camera as well as on the com­puter so they can be reviewed without
having to leave the camera position.

NEW

And when shooting RAW & JPEG it
is possible to transfer only the JPEG
files to the computer to reduce data
volume and allow transferred im­ages to be reviewed immediately.

Powerful software support

New Sony imaging software suite*

NEW

NEW

tinuous flash shooting at up to 10 fps*
offers advanced capture capability.
Slow sync and rear curtain sync** can
be selected when shooting with wire­less off-camera flash for even further
enhanced versatility.

A new suite of imaging apps from
Sony provides top-quality RAW
development, convenient PC tether­ing, and efficient viewing/manage­ment. Live viewing on the computer
screen with semi-transparent refer­ence overlay capability is available

* Refer to the downloa d page for details: ht tp://www.sony.ne t/disoft /d/

during tethered shooting. Focus
points can also be set from the
computer. The new Pixel Shif t Multi
Shooting feature can also be used
while tethered, and the pixel-shifted
images can be immediately com­posited and viewed.

Capture One (for Sony)*

Capture One Express (for Sony)
is free software for precise, high­quality finishing of RAW data.

* Please con tac t Phase O ne regarding a ll inqu irie s as to usage and suppor t including f unctional compatibility o f Capture

One Ex pres s (for So ny) and Capture One Pro (for Sony).

Capture One Pro (for Sony) can be
purchased for local adjustment and
PC Remote compatibility.

FE 85mm F1.4 GM (SEL85F14GM), 1/250 sec., F8, ISO 100, Profoto Pro-10 flash units

A new dimension of
subjective resolution

Still images of art and architecture take on a new dimension of
reality with unprecedented subjective resolution.

Lifelike detail, texture, color, and atmosphere

Pixel Shift Multi Shooting : Superior resolution from 42.4 megapixel RGB information

This new feature takes advantage
of the advanced in-body image
stabilization system control capabil­ity available in the

7R III, precisely
shifting the sensor in 1-pixel incre­ments to capture four pixel-shif ted
images containing a total of approx-

* Image size after comp ositing is app rox. 42.4 million (7952 x 530 4) pixels.

Notes A de dicated sof tware appl ication is required for compositing. Image com positing

may not be success ful if camer a or subject m oveme nt caus es blur. The use of a t ri­pod is re commended, a s is the use of PC tethere d contr ol or a rem ote comm ander
(when PC tethered cont rol is no t being u sed) where pos sible. U ncomp resse d RAW
and sile nt mod e are automati cally selected f or Pixel Shif t Multi shoo ting. Some
restr ictions apply to flash and oth er dev ices. R efer to the Sony supp ort s ite for
details.

http://www.sony.net/psms/

imately 169.6 million pixels* that are
later composited using a computer
to achieve overwhelming subjec­tive resolution in a single image. Still
images are captured with true-to­life details, texture, and color, with
minimal moiré and color artifacts.

Even the atmosphere of the subject
and surroundings are reproduced
with breathtaking fidelity, making
Pixel Shift Multi Shooting an ideal
technology for archival images of
art, architecture, and more.

NEW

The Pixel Shift Multi Shooting principle

In a “normal” digital capture each pixel represents just
one color: red, green, or blue. The surrounding pixels
are used to supply the necessary extra information
required to interpolate and reproduce the remaining
two primary colors. Pixel Shift Multi Shooting, however,
composites four pixel-shifted images so that each of the
sensor’s 42.4 million effective pixels can represent red,
green, and blue values simultaneously. Extra interpola­tion becomes unnecessary so the data from the sensor
can be directly synthesized to recreate the final colors.
The result is unprecedented reproduction accuracy and
detail for true-to-life textures. Images shot using this
feature can be processed using the dedicated PC soft­ware from Sony running on a personal computer.

Pixel Shift Multi Shooting

Normal single shot

1) RGB color information
acquired at a 1:2:1 ratio.

R : 10.5M
G : 21M
B : 10.5M

2) Demosaicing provides the
remaining color information.

Normal singl e shot

Pixel Shif t Mult i Shoo ting after compositing

1) The image sensor is moved in 1-pixel increments while shooting four sequential frames.

R : 10.5M X 4
G : 21M X 4
B : 10.5M X 4

2) Each pixel represents
R, G, and B information.

Tripod provided by Man frot to

2524

Breathtaking movie reality

5K (15-megapixel) oversampling results in 4K movies with an
overwhelming sense of depth and detail, while a new HLG picture
profile supports high-quality HDR content creation. High resolution
and wide dynamic range come together with stunning realism.

High-resolution, wide-dynamic-range 4K

4K movies** from 5K (15-megapixel) data

Full pixel readout in the Super 35
mode, without the need for pixel bin­ning, makes it possible to condense
5K (15-megapixel) data into high­resolution, extraordinarily beautiful
4K movies with minimal moiré and
jaggies. Advanced image process­ing also allows full-frame 4K movie
recording with dramatically improved
image quality at mid to high sensitivi­ties. Super 35mm or full-frame re­cording can be selected as required.

Broad support for HDR content creation

Sony’s S-Log gamma curve provides
extra flexibility to achieve a “look”
that best serves your artistic vision
during post-production color grad-

NEW

* Connect to an HDR (HLG) compatib le Son y TV v ia a USB cable wh en displayin g HDR (HLG) mo vies .
** A Class 10 or higher SD HC/SDXC card i s requi red for XAVC S f ormat movie record ing. UHS spee d class 3 or higher is

required for 1 00 Mbps recor ding.

NEW

ing, while a newly added HLG (Hy­brid Log-Gamma)* picture profile
supports instant HDR production
without the need for color grading.

Extra care has been taken to ensure
that a wide range of HDR content
creation requirements are fully sup­ported.

*

HLG (Hybrid Log-Gamma) support for instant HDR workflow

Movies recorded using the HLG
profile will appear true-to-life with
no blocked shadows or blown high­lights when played back on an HDR

(HLG) compatible TV, without the
need for color grading. The BT.2020
color space is supported, providing
a wider color gamut.

NEW NEW

S-Log3 for wide 14-stop dynamic range

In addition to S-Log2, S-Log3 is
available for better gradation from
shadows to mid-tones (18% gray)
and a wide dynamic range of up to
14 stops for movies. A new color S­Gamut3 color space that is a refined
version of S-Gamut is also provided.

SDR HDR (HLG)

S-Gamut3.Cine/S-Log3 Color Grading

Comprehensive moviemaking controlWide dynamic range

Improved Fast Hybrid AF for movies

NEW NEW NEW

Fast Hybrid AF performance during
movie recording has been refined,
providing a wide AF area that is
similar to that provided for still im­ages. AF now accurately locks onto
movie subjects over a wider area.

Frame rates from 1 fps to 120 fps
can be selected in eight steps for
up to 60x quick motion and 5x slow
motion while recording with full-HD
quality.

* Sound n ot recorded. C lass 10 o r higher SDHC /SDXC

card required.

S&Q Record Setting

NTSC 24p 30p 60p

PAL 25p 50p

S&Q Frame Rate

NTSC 1fps 2fps 4fps 8fps 15fps 30fps 60fps 120fps

PAL 1fps 2fps 3fps 6fps 12fps 25fps 50fps 100fps

Enhanced Zebra function Slow and quick motion

This function simplifies exposure
monitoring, especially when shoot­ing with Log gamma. A new mini­mum brightness level setting helps
to avoid blown out highlights.

Proxy recording

NEW

4K movies and lower-resolution
proxy movies can be recorded
simultaneously. The smaller proxy
files are ideal for quick previewing
or pre-editing that can reduce the
time required for final 4K editing.

Auto Power Off Temperature* Other movie features

This function sets the temperature
at which the camera will automati­cally shut of f. “High” allows longer
movie recording times when the
camera is mounted on a tripod.

* Set to “St andard” for h andhe ld shooting. Use a tripod or other suppor t when “High” is s elec ted. Shootin g time may

var y according to env ironmenta l condi tions and cam era tem pera ture when set to “High.”

Photo Capture

High-quality stills can be extracted
from movies and stored separately:
8 megapixel stills from 4K movies,
and 2 megapixel stills from full-HD
movies.

NEW

Picture profiles, Clean HDMI, Time
Code/User Bit, REC control, Gamma
Display Assist, and other details
provide comprehensive support for
advanced video workflows.

Tripod provided by Man frot to

2726

Other features that enhance

1/100sec.(100Hz), 1/120sec.(120Hz)

the 7R III experience

A well thought out selection of customizable functions, detailed AE
and AWB settings, plus image management and sharing features
provide handy solutions to a wide range of professional needs.

Customizable functions

My Menu & new menu interface

A n e w My M en u f ea t ur e a ll o ws u p to 3 0
items to be registered for instant recall.
Registered items can be arranged in
any convenient order, and unused items
can be erased as required. The primary
menus have also been reorganized for
smoother search and operation.

NEW

Fast parameter editing via Fn menu

The Fn button can be used to quick­ly display and select from up to 12
freely assignable functions while
shooting. Assign functions you use
frequently for fast, ef ficient selec­tion and operation.

Custom button assignments Anti-flicker shooting

Custom button assignments allow the
camera interface to be customized
for individual shooting preferences.
Eleven buttons can be reassigned to
select functions you choose, and sep­arate functions can be assigned for
the still, movie, and playback modes.

Customizable front/rear dials
and release button

The control direction of the front
and rear dials can be set via the
menus. It is also possible to assign
the large, accessible shutter button
to start and stop movie recording,
rather than using the MOVIE button.

NEW NEW

Instant mode dial recall of memorized camera setups

Camera setups, including modes and cam­era settings, can be registered in memory
for instant recall via the mode dial: up to
three in the camera, and four on a mem­ory card. Memory card setups can also be
loaded into a separate

7R III body.

Flexible Auto Exposure and Auto White Balance

1200-segment live view exposure
analysis enhances stability

NEW NEW NEW

The live view image is divided into
1,200 segments for detailed analysis
of subject color and lighting. The
use of focus information to ensure
consistent AE control is another
innovation that can reduce varia­tions in image brightness in varying
situations.

Additional modes expand
metering versatility Versatile spot metering

A new Highlight mode detects the
brightest area in the frame to avoid
blown highlights, and an Entire
Screen Average mode can provide
stable auto exposure through com­position changes.

When the Focus Area parameter is
set to Flexible Spot or Expand Flexible
Spot the metering spot location can
be linked to the focus area so that the
optimum metering point is maintained
automatically. Two spot sizes are avail­able to match a wide range of subjects.

NEW

NEW

Flicker from fluorescent lights and
other artificial lighting can ruin still
images if it and the shutter timing
are out of sync. The

7R III auto-

matically detects flicker and adjusts

Flickering
light source

Norma l
Shooting

shutter timing to eliminate its effects.

* Only 10 0 Hz and 120 Hz flicker is detec ted. Co ntinu ous

shooting spe ed may decrea se. Ant i-flicker sh ooting is
not available durin g silen t shoot ing, BULB exposure, or
movie recording.

Priority Set in AWB

NEW

When incandescent lamps or simi­lar are the primary light source and
white balance is set to Auto, the color
tone priority can be set to Standard,

Anti-flicker
Shooting

Ambience, or White. Ambience pri­ority produces a warm tone, while
white priority is designed to provide
accurate white reproduction.

Data management and sharing

Location Information Link via Bluetooth

After the camera has been paired
to the PlayMemories Mobile™ app
installed on a compatible mobile
phone or tablet device, it can ac­quire location data from the mobile
device and record that data with still
images or movies. The PlayMemo­ries Home™ application can then
be used on a personal computer to
organize images imported into the
computer on a map.

* Blueto oth con nec tiv ity availa ble wi th the f ollowing

terminal dev ices (at th e date of re lease):

- Android (An droid 5 .0 or later, Bluetooth 4. 0 or later)

- iPhone/iPad (iPhone 4S or later, 3rd generation iPad
or later)

Please refer to http://www.sony.net /pmm/btg/ for

more information.

* Use the latest v ersion of PlayMemories Mobil e.

NEW NEW NEW

Wi-Fi / NFCTM / QR code FTP file transfer via Wi-Fi

With one-touch remote, a smart­phone or tablet functions as a view­finder/remote control. One-touch
sharing transfers photos/videos to the
device. Install the PlayMemories Mo­bile app on an NFC-enabled Android
device via Wi-Fi, then touch the device
to the camera to connect. The camera
now features QR code compatibility

* PlayMemories Mob ile mus t be installe d on the smartphon e or tab let de vice.

File Names and Copyright

The first three characters of still im­age file names can now be edited for
easier identification, and copyright
information can be automatically em-

Flicker

detected and

timing adjusted

NEW

Exposure standard adjustment

NEW

The standard exposure value can
be adjusted from -1 to +1 stop in 1/6
stop increments. This setting can be
made separately for each metering
mode.

ISO AUTO Min. shutter speed

This function sets the shutter speed
above which ISO sensitivity will begin
to change when the camera mode
is set to “P” or “A” and “ISO AUTO” is
selected. It can be used to minimize
subject blur when shooting moving
subjects.

This function allows convenient Wi-Fi
transfer of still image files selected
via the menu display to a specified
remote FTP server. FTPS (File Transfer
Protocol over SSL/TLS) is supported,
allowing SSL or TLS encr ypted data
transfer for maximum security.

bedded in still image files. Record­ing the photographer’s name and
author’s name along with images
provides basic copyright protection.

2928

Essential apps

PlayMemories Home™

It’s easy to install this image man­agement software onto a Windows
or Mac computer, then use it for

PlayMemories Mobile™

The PlayMemories Mobile app can
be installed on a compatible smart­phone or tablet to provide remote
camera control and easy image
transfer. The new PlayMemories

easy viewing, editing and printing.
You can also upload and share con­tent via network services.

Mobile version provides updated
remote camera control, with the
same operability as available on the
camera itself.

Number of recordable frames for single media

(Image size L 42M, aspect ratio 3:2)

8GB 32GB 64GB 256GB

Standard 770 3,100 6,200 24,500

Fine 520 2,100 4,200 16,500

Extra fine 270 1,050 2,150 8,700

RAW & JPEG

(Compressed RAW)

RAW

(Compressed RAW)

RAW & JPEG

(Uncompressed RAW)

RAW

(Uncompressed RAW)

• Recom mended memor y cards for mo vie recording i n AVCHD/MP4 f ormats:

Memor y Stick PRO Duo (Ma rk2), Memor y Stick PRO-H G Duo, SD memor y
card/S DHC mem ory card/SDX C memor y card(Class 4 o r more)

• Recom mende d memory car d for mov ie recording in X AVC S format: SD HC/

SDXC memo ry ca rd of Class 10 or hig her

• The num bers in the tab le show ap proximate max imum recordabl e time

obtain ed by totaling al l movi e file s.

• AVCHD mo vies are autom atica lly di vided i nto separate f iles up to a maxi-

mum of 2GB each.

130 520 1,050 4,200

170 700 1,400 5,600

75 300 600 2,400

88 355 710 2,850

Movie recording time for single media

(Hours:Minutes:Seconds)

8GB 32GB 64GB 256GB

XAVC S 4K

XAVC S HD

AVCHD

30p 100M/ 25p 100M 0:08:00 0:35:00 1:1 5:00 5:15:00

30p 60M/ 25p 60M 0:1 0:00 1:00:00 2: 05:00 8:35:00

24p 100M 0:08:00 0: 35:00 1:1 5:00 5:15:00

24p 60M 0:1 0:00 1:00:00 2:0 5:00 8:35:00

120p 100M/ 100p 100M 0:08:00 0: 35:00 1:1 5:00 5:15:00

120p 60M/ 100p 60M 0:1 0:00 1:00:00 2:0 5:00 8:35:00

60p 50M/ 50p 50M 0:1 5:00 1:1 5:00 2:3 0:00 10:25:00

60p 25M/ 50p 25M 0:30:00 2: 2 5:00 5:00:00 20:15:00

30p 50M/ 25p 50M 0: 1 5:00 1: 1 5:00 2: 30:00 10:25:00

30p 16M/ 25p 16M 0:50:00 3: 50:00 7: 45:00 31:25:00

24p 50M 0:1 5:00 1: 1 5:00 2: 30:00 10:25:00

60i 24M (FX)/ 50i 24M (FX) 0:40:00 2:55:00 6:00:00 24: 15:00

60i 17M (FH)/ 50i 17M (FH) 0: 55:00 4:0 5:00 8: 1 5:00 33: 15:00

Controls

1 Hook for sh oulder str ap
2 Microphone jack
3 Flas h sync termi nal
4 Headphones jack
5 HDMI micro jack jack
6 U SB Type-C
7 Cha rge lamp
8 M ulti/Mic ro USB termina l

9 Mode di al
10 M ode dial loc k release but ton
11 Microphone
12 Ima ge sensor pos ition mark
13 Speake r
14 Multi I nterface S hoe

TM

terminal

1

2

3

15 Fron t dial
16 Power sw itch
17 Sh utter but ton
18 C1 (Cust om 1) button
19 C2 (Cust om 2) button
20 Exposure compensation dial
21 AF illuminator/Self-timer lamp
22 Remote sensor
23 Lens release button
24 M ount index
25 Mount
26 Image sensor
27 L ens contac ts

9

10

11

12

13

14

21

4

5

6

7

8

22

23

15

16
17

18

19

20

24

25

26

27

28

29

30

31
32

33

34

35

36

37

38

39

40
41

42

43

44

45

28 B attery in sertion s lot
29 Tri pod socket ho le
30 Eye s ensor
31 View fin der
32 Eye piece cup
33 C 3 button (Cus tom butto n 3)
34 M ENU button
35 Monitor
36 P layback but ton
37 M OVIE butto n
38 R ear dial
39 F or shooting: A EL button
For v iewing: Imag e index but ton

46

47

40 For sh ooting: AF- ON button
For v iewing: Enla rge button
41 Multi-selector
42 For shooting: Fn (Function) button
For v iewing: Sen d to Smartph one butto n
43 Co ntrol whee l
44 Acce ss lamp
45 Fo r shooting: C4 b utton (Custo m button 4)
For v iewing: Del ete button
46 Diopter-adjustment dial
47 Med ia slot cover sw itch
48 H ook for shou lder strap
49 N mar k

48

49

3130

7R II / 7R III comparison

Fast, expressive lenses

Image quality Standard ISO

Low noise Up to 1 stop improvement for mid sensitivity.

Gradation Up to 15 stops low-sensitivity dynamic range. 14-bit

Sharpness, color Large improvement.

Pixel Shift Multi Shooting New

Speed Continuous shooting

Continuous shooting (Silent)

No. of recordable frames

Basic AF performance

Lower AF detection brightness limit

Eye AF Large improvement in detection precision, speed.

Operability &

5-axis image stabilization

Reliability

EVF

Improvement

up to ISO 25600 up to ISO 32000

RAW* support for continuous and silent shooting.

5 fps (approx.) 10 fps (approx.)

Single only 10 fps (approx.)

23 compressed

RAW images

76 compressed

RAW images

Up to 2x** faster in low light, approx. 2x** faster tracking

EV-2 EV-3

Approx. 2x** faster tracking. A-mount lens support.

4.5 steps 5.5 steps

XGA OLED
Tru-Finder

Quad-VGA OLED

Tru-Finder

+ 1/3 stop

Speed doubled (approx.)

Continuous supported

3.3x improvement

1 stop increase.

+ 1 stop

1.5x resolution, 2x luminance
(approx.). 120 fps*** finder
frame rate support, 30% faster
startup. High quality mode.

E-mount G Master

FE 85mm F1.4 GM

(SEL85F14GM)

FE 16-35mm F2.8 GM

(SEL1635GM)

E-mount G Lens

FE 12- 24mm F4 G

(SEL1224G)

E-mount ZEISS

TM

®

TM

FE 100mm F2.8 STF OSS GM

(SEL100F28GM)

FE 70-200mm F2.8 GM OSS

(SEL70200GM)

NEW

FE 24-105mm F4 G OSS

(SEL24105G)

FE 24-70mm F2.8 GM

(SEL2470GM)

FE 100-400mm F4.5-5.6 GM OSS

(SEL100400GM)

FE PZ 28-135mm F4 G OSS

(SELP28135G)

1.4x Teleconverter Lens

(SEL14TC)

for SEL70200GM and SEL100400GM

FE 70-200mm F4 G OSS

(SEL70200G)

FE 70-300 F4.5-5.6 G OSS

(SEL70300G)

2x Teleconverter Lens

(SEL20TC)

for SEL70200GM and SEL100400GM

FE 90mm F2.8 Macro G OSS

(SEL90M28G)

Battery

Media

USB connector for PC
tethering

NP-FW50 NP-FZ100

Single slot

(UHS-I)

USB 2.0

(Multi/ Micro USB)

(UHS-II support)

USB 3.1 Gen 1

(USB Type-C

Dual slot

Controls AF-on, Multi Selector, Touch Panel.

Movies Improved quality in full-frame 4K high-sensitivity

movies, improved movie AF, Hybrid Log-Gamma,
S-Log3, Slow&Quick motion, Photo Capture, Proxy
Recording.

Others Sync terminal, Anti-flicker shooting, improved

peaking, Focus magnification with AF support, My
Menu, Rating, Display continuous shooting group,
FTP over Wi-Fi, and more.

* Limited to 12 bi ts dur ing compressed R AW continuous shooti ng, BU LB ex posur e, or when Long E xposure NR is O N.
** Sony test conditions.
*** i n NTS C mode. 1 00fps in PAL mode.

2.2x capacity

Higher write speed,
simultaneous write, sequential
write (Auto Switch Media).

Faster transfer speed

TM

)

Vario-Tessar T*
FE 16-35mm F4 ZA OSS

(SEL1635Z)

A-mou nt Explore higher perspectives

Vario-Tessar T*
FE 24-70mm F4 ZA OSS

(SEL2470Z)

Distagon T*
FE 35mm F1.4 ZA

(SEL35F14Z)

Sonnar T*
FE 35mm F2.8 ZA

(SEL35F28Z)

See the world from more creative perspectives with the full range of
premium Sony A-mount lenses. Fisheye, wide-angle, super telepho­to, macro, and legendary ZEISS® lenses offer the ultimate in imaging
expression. An optional LA-EA3 or LA-EA4 Mount Adaptor is required
to mount A-mount lenses on the

7R III.

Plana r T*
FE 50m m F1. 4 ZA

(SEL50F14Z)

Library

Sonnar T*
FE 55mm F1.8 ZA

(SEL55F18Z)

Enter the exciting world of Sony α products through α Library,
the new photography-themed application for tablets.

“sony α librar y“

Go to Google Play for Android Tablet. For iPad, go to App Store.Then search for “sony α library“.

3332

Options for expanded photographic capability

System chart

Flash Light

Microphone / Monitor

Vertical Grip

VG-C3EM

• Optimum hold*1 and control comfort when shooting in

vertical orientation
Houses two NP-FZ100 batteries for longer operation, and sup-

•

ports USB charging via the camera

The VG-C3EM Vertical Grip makes shooting in vertical
orientation just as efficient and comfortable as horizontal
orientation with a full complement of essential controls, in­cluding a duplicate Multi-Selector. The grip shape is identi­cal to the grip on the camera body, so no hold adjustment is
required. The VG-C3EM features a magnesium alloy exterior
for high rigidity and durability, and the design is dust and
moisture resistant

The VG-C3EM not only provides space for two NP-FZ100
rechargeable battery packs, significantly extending operat­ing time, but it also allows the batteries to be charged via
the camera USB connector so the batteries don’t have to be
removed from the grip.

*1 Si multaneous u se with LE-E A2 or LA-E A4 mount adap tor not

suppor ted due to narro w clearance bet ween mount ada pter and
vertical grip.

*2 Not gua ranteed to be 10 0% dust and mois ture proof.

*2

for maximum reliability.

• Twice the capacity

of the NP-FW50 for
long life

• I nfoLITHIUM® support

enables remaining
battery charge display
on the camera LCD
screen

Rechargeable Battery Pack

NP-FZ100

Multi Battery Adaptor Kit

NPA-MQZ1K

• Allows sequential use of up to four NP-FZ100 batteries

• Also functions as a four-battery rapid charger

This Multi Battery Adaptor Kit houses up to four NP-FZ100
rechargeable battery packs and connects to the camera via
a plug-in plate, providing dramatically extended operat­ing time for sessions that can’t be interrupted by battery
changes. The NPA-MQZ1K also supports power supply from

*2

. It includes two USB ports so that power can be

NP-FW50
delivered to the camera and a USB device simultaneously.
LED indicators show the remaining power for each battery.
Three tripod mount sockets on the upper surface and three
on the lower surface provide flexible mounting options.

In addition to supplying power, the NPA-MQZ1K also
functions as rapid charger, Four NP-FZ100 batteries can be
charged to 90% level in approximately 480 minutes.

*1 With t he supplied AC ada ptor. NP-FW50 c harging not supp orted.
*2 NP- FW50 compat ible cameras: 7/7 II/7R/7R II/7S/7S II/6500/

6300/6 000/5100/5 000/350 0/3000/DSC-R X10/RX10 II /RX10 III/
RX 10 IV.

• Fully charges one

• LED indicator shows

• Slim, 33-millimeter

Battery Charger

*1

NP-FZ100 battery in
approx. 150 min.

charge status

portable design

BC-QZ1

Radio Wireless Flash

HVL-F45RM

• Compact and lightweight clip-on flash with high GN45*1

output

• Functions as a wireless radio commander or receiver in

multi-flash setups

The HVL-F45RM is compact and convenient for use in the
field or studio, delivering up to Guide Number 45
with less than a 2.5-second
a wireless radio commander or receiver, and when used as
a commander can control up to 15 compatible off-camera
flash units or receivers in up to 5 groups
works at distances up to 30 meters
operation without pairing errors.

The HVL-F45RM also provides high-visibility tabbed menus
and a Quick Navi interface for easy, intuitive operation.
Customizable keys give you direct access to the functions
you use the most. The flash bounce head rotates and tilts for
flexible lighting in a wide range of situations, and the overall
design is dust and moisture resistant

*1 105 mm at ISO 100 in met ers.
*2 1/1 man ual flash emis sion, alkaline b atteries.
*3

Up to 5 group s in GROUP mo de, and up to 3 grou ps in TTL or M ANUAL m ode.
*4 Interna l Sony tests.
*5 Not gua ranteed to be 10 0% dust and mois ture proof.

*2

recycle time. It can be used as

*4

, providing reliable

*5

for high reliability.

• Provides an ideal rest­ing spot for a finger,
improving hold comfort
and stability

*1

power

*3

. Radio wireless

Grip Extension

GP-X1EM

Flash

HVL-F60M

Wireless Radio
Comander

FA-WRC1M

Power / Other

Rechargeable
battery Pack

NP-FZ100

LCD Protec t
Semi Hard Sheet

PCK-LG1

Body Cap

ALC-B1EM

Multi Terminal
Connecting Cable

VMC-MM1

Flash

HVL-F45RM

Wireless Radio
Receiver

FA-WRR1

Battery Charger

BC-QZ1

Eyepiece Cup

FDA-EP18

Circular PL Filters

VF-49CPAM
55CPAM
62CPAM
67CPAM
72CPAM
77CPAM
82CPAM

HDMI Cable
(Micro)

DLC-HEU15/30

Multipod

VCT-MP1

Flash

HVL-F43M

/
/
/
/
/
/

Flash

HVL-F32M

Flash

HVL-F20M

Multi Battery
Adaptor Kit

NPA-MQZ1K

Grip Extension

GP-X1EM

MC Protectors

VF-49MPAM
55MPAM

/

62MPAM

/

67MPAM

/

72MPAM/
77MPAM

/

82MPA

/

M405MP

Tripod

VCT-P300

Stereo
Microphone

ECM-XYST1M

Battery Video Light

HVL-LE1

Battery Video IR Light

HVL-LEIR1

Vertical Grip

VG-C3EM

Tripod / Commander

/

Remote Control Tripod

VCT-VPR10

Remote Commander

RM-VPR1

Battery Video Light

HVL-LBPC

Ring Light

HVL-RL1

Remote
Control
Tripod

VCT-VPR1

Remote Commander
and IR Receiver Kit

RMT-VP1K

Remote
Commander

RM-SPR1

XLR Adaptor Kit

XLR-K2M

Electret Condenser
Microphone

ECM-MS2

UWP-D Package

UWP-D11/D12

Clip-on LCD Monitor

CLM-FHD5

Cace

Soft Carrying Case

LCS-SC21

Shotgun
Microphone

ECM-CG60

Soft
Carrying
Case

LCS-SL20

Soft
Carrying
Case

LCS-PSC7

Back Pack

LCS-BP2

Wireless
Microphone

ECM-AW4

XLR Adaptor Kit

XLR-K1M

Electret Condenser
Microphone

ECM-680S

Clip-on LCD Monitor

CLM-V55

Wireless
Microphone

ECM-W1M

Multi Interface
Shoe Adaptor

SMAD-P3

Back Pack

LCS-BP3

Sling Bag

LCS-SB1

Soft
Carrying
Case

LCS-SC8

Strap/Grip Belt

Screen Protect Glass Sheet

PCK-LG1

• Hard (hardness rating

9H), shatterproof
glass provides reliable
screen protection

• Compatible with

touch-sensitive and
tilting LCDs

• AS coating resists

staining and finger­prints

Eyepiece Cup

FDA-EP18

• Slides easily into place

with a secure locking
mechanism

• Soft material for

optimum eye fit and
comfort

SD Cards (UHS-II)

SF-G Series (32/64/128 GB)

• Ultra-fast write speed

up to 299MB/s, read
speed up to 300MB/s

• Ideal for high-speed

continuous shooting
and 4K video recording

• Supplied Sony File Res­cue software recovers
accidentally deleted
photos and video

Bracket

VCT-55LH

Shoe Cap

FA-SHC1M

Remote
Commander

RMT-DSLR2

Shoulder
Strap

STP-SB2AM

Sony Photo Galley:

http://www.sony.net/Products/di_photo_gallery/

Shoulder
Strap

STP-SS5

Shoulder
Strap

STP-XH70

Shoulder
Strap

STP-XH1

Sony Camera Channel:

https://www.youtube.com/c/ImagingbySony

3534
