Sony FWD-32LX1R-B User Manual

ATTRACT. ENTERTAIN. INFORM.
SONY DISPLAYS
Why Sony?
Elevate your environment.
Sony® displays are an elegant choice for information and entertainment environments. Bring refinement and sophistication to guest rooms, conference rooms, reception areas, restaurants, lounges or anywhere video performance and simple style are essential.
A history of excellence.
Derived from a heritage of award-winning television and professional broadcast excellence, Sony displays provide unparalleled picture quality, networking flexibility and intuitive setup. No matter which technology you choose, count on Sony to bring you an uncompromising combination of superior performance and industry-leading reliability.
Powerful solutions.
From advanced networking options that let you centrally control, deliver and troubleshoot digital content to tuner options that integrate data, video and televisions, Sony displays offer powerful solutions that help you attract, entertain, and inform your audience.
1
2
3
4
5
6
7
8
9
10
11
12
Multiple Connections
PC and video inputs give you the flexibility to connect to cable boxes, satellite, HD video sources and other peripherals such as DVD players and VCRs.
Easy Video Wall Setup
Intuitive, on-screen setup makes it easy to create (up to) a 16-panel video wall. Ideal for large scale, high definition visual display applications for entertainment, retail and conference room applications.
Expansion Slots
Additional slots let you customize your display to fit your application. Choose from a range of interface boards to accommodate Sony input/output boards.
• Networking Solutions - Centrally manage one or hundreds of networked displays across a standard IP network
• Input/Output Boards - Additional video inputs or output boards will help you meet your needs, such as augmenting the RGB/component input with BNC connectors or RGB/component active loop-through
• TV Tuners - Optional TV tuner card integrates data, video, television and hotel networking services
®
TV tuners, networking cards or
Flat panel technology offers new and exciting ways to broadcast information, television programs, and
1
HDTV
. Both the plasma and LCD technologies offer sharp, detailed pictures and bright, lifelike colors.
When deciding which system to go with, it’s helpful to assess your needs and pick the display technology
that will best suit your application.
Flat Panel LCDs with WEGA Engine™ system
State-of-the-art LCD technology for businesses that
need digital still or motion signage and video solution
with premium features and upscale style.
Choose LCD technology if:
You display still images or are concerned about
1
2
3
4
5
6
7
8
9
10
11
12
32" / 40" LCD Display FWD32LX1R / FWD40LX1
• WEGA Engine™ system – Sony’s unique solution optimizes the display’s potential to achieve better resolution and sharpness, higher contrast, less digital noise, and greater picture dimension
• Phenomenal picture performance- Utilizing the latest S-LCD panel technology, Sony's LCDs provide a wide viewing angle, high brightness, superior
wider screen viewing angles
The environment is often filled with natural light
Energy efficiency is a priority
• You display still or video images that require high
resolution for crisp text
contrast and fast response time to deliver crisp, clear text and smooth motion images.
• Low power consumption and long-life panel delivers hours of use to keep total cost of ownership low
• New crystal-coated design with pearl white bezel option gives a new, elegant look
• Clean back panel with cable management prevents tampering with wires in hotel guest rooms and other public areas
• Internal option network/tuner cards (sold separately) allow easy use in hotel guest rooms and digital signage areas
PlasmaPro™ Displays
Leading edge plasma technology for businesses that
need digital motion signage and video solution at an
affordable price.
Choose plasma technology if:
• You display constant-motion video or
dynamic multimedia
• You need real color reproduction such as
broadcast applications
• Larger screen sizes or low cost per inch is a priority
50" PlasmaPro™ Display FWD50PX2
• Large, high resolution screen (1366 x 768) with a 10,000 :1 ultra-high contrast ratio for stunning digital video signage and conference rooms
• 60,000 hour panel life for high ROI(return on investment)
• Clean back panel with cable management prevents tampering with wires in hotel guest rooms and other public areas
42" PlasmaPro™ Display PFM-42X1
• 1024 x 768 (XGA) resolution with exceptional crisp image for high definition video content
• 60,000 hour panel life for high ROI (return on investment)
• Multiple inputs RBG/YUV(component), DVI-HDCP, Composite, Y/C(S-Video)
42" PlasmaPro™ Display FWD-42PV1
• 10,000:1 ultra-high contrast and 500 cd/m2 high brightness are excellent for signage and entertainment
• Low cost, high value solution with 60,000 hour panel life
• Internal option network/tuner cards allow easy use in hotel guest rooms and digital signage areas
Specifications
LCD Displays PLASMA Displays
Model Number
Screen Size (viewable area
measured diagonally)
Resolution
Pixel Pitch
FWD-32LX1R / FWD-40LX1
32" / 40"
1366 x 768 WXGA
0.51 x 0.51 mm/
0.648 x 0.648 mm
Colors
Panel Type
Contrast Ratio
Brightness
Dimensions (W x H x D)/
Weight
Screen Protector
Color Systems
a-Si-TFT active matrix LCD panel
32LX1R = 31.6" x 19.4" x 4.4” / 38.5lbs.
40LX1 = 39.2" x 23.9" x 4.9" / 60.5lbs.
NTSC, PAL, SECAM, NTSC4.43, PAL60, PAL-M,
16.7 Million
1000:1
450 cd/m2
Anti-Glare/Anti-Reflective
PAL-N
Audio
Video Inputs
14W Stereo AMP (7W x 2 Digital AMP)
RGB/Component (HD-15), DVI-HDCP, Composite
(BNC), Y/C (S-video)
Video Output
Composite (BNC), Y/C (S-Video)
Composite Out Loop Through
Remote Control
Color Temperature Control
1
2
3
4
5
6
7
8
9
10
11
12
Closed Caption Decoder
Viewing Angle
High Altitude Capable
Mount Design
Power
Design Color
Picture in Picture
Picture and Picture
Safety Regulations
Fully Discrete RS232C and Multi-Function Remote
Discrete Control RGB
FWD-40LX1 = 178 degrees (H/V) FWD-32LX1R = 170 degrees (H/V)
Ye s
Ye s
Landscape or Portrait
32LX1R=170W, 40LX1=240W
Frosted Black,
Crystal Silver, Pearl White
Ye s
UL1950, CSA No.950 (c-UL), CE LVD (EN60950), FCC Class B, VCCI Class B, CE EMC (EN55022
Class-B, EN61000-3-2, EN61000-3-3), C-Tick (AS/
NZS 3548/ 95, AS/NZS 4252.1), CCIP, JEIDA, CB,
KTL, MIC
Supplied Accessories
Optional Accessories
(Sold separately)
Limited Warranty
Optional Card Slots
(Sold separately)
AC Power Cord, Operating Instructions, AC Plug
Holder (2), AA/R6 size Battery (2), Cable Holder (4),
Remote Control, Component Cable
Universal Table Stands & Wall Brackets, Multiple
Networking options that include
Status/Control/Streaming Content/Storing
Content,Tuners with Hospitality Connections,
Alternate Inputs, and Component/RGB Loop
Through
2 years parts and labor, 1 year panel onsite service
Limited Warranty²
(Extended service available-Sold separately)
32LX1R=1 / 40LX1=2 Networking, Input,
and Loop Through
Model Number
Screen Size (viewable area
measured diagonally)
Resolution
Pixel Pitch
FWD-42PV1
42"
852 x 480
1.08 x 1.08 mm
PFM-42X1
42"
1024 x 768
0.90 x 0.676 mm (non-square)
FWD-50PX2
50"
1366 x 768
0.86 x 0.81 mm
Colors
Panel Type
Contrast Ratio
Brightness
Dimensions (W x H x D)/
Weight
Screen Protector
Color Systems
Audio
Video Inputs
Video Output
Remote Control
Color Temperature Control
Image Retention Protection
Closed Caption Decoder
High Altitude Model
Mount Design
Power
Design Color
1.06 Billion
AC-Type Plasma Display Panel
10,000:1
500 cd/m2
40.8" x 24.9" x 4.8” / 63.8lbs.
Anti-Glare/Anti-Reflective
NTSC, PAL, SECAM, NTSC4.43,PAL60,
RGB/Component (HD-15), DVI-HDCP,
RS232C and Multi-Function Remote
PAL-M, PAL-N
7W x 2 Digital AMP
Composite (BNC), Y/C (S-video)
Composite (BNC), Y/C (S-Video)
Composite Out Loop Through
Discrete Control RGB
Multi-Mode Picture Orbit/Picture Inversion/White Screen/Timers/Power Save/
Auto WideMode/Background/Smart Fan Technology/Auto Dimming Function
Yes
FWD-42PV1A/S
Portrait Model FWD-42PV1P/B
260W, Stand-by 1W
Silver or Black
AC-Type Plasma Display Panel
NTSC, PAL, SECAM, NTSC4.43,PAL60,
RGB/Component (HD-15), DVI-HDCP,
Composite (BNC), Y/C (S-video)
Composite (BNC), Y/C (S-Video)
RS232C and Multi-Function Remote
1.06 Billion
5,000:1
360 cd/m2
40.7" x 24.9" x 4.1” / 65.4lbs.
Anti-Glare/Anti-Reflective
PAL-M, PAL-N
7W x 2 Digital AMP
Composite Out Loop Through
Discrete Control RGB
Ye s
N/A
Landscape or Portrait
400W
Silver or Black
1.06 Billion
AC-Type Plasma Display Panel
10,000:1
450 cd/m2
49.4” x 29.6” x 4.4” / 94.6lbs.
Anti-Glare/Anti-Reflective
NTSC, PAL, SECAM, NTSC4.43,PAL60, PAL-M,
PAL-N
7W x 2 Digital AMP
RGB/Component (HD-15), DVI-HDCP,
Composite (BNC), Y/C (S-video)
Composite (BNC), Y/C (S-Video)
Composite Out Loop Through
Fully Discrete RS232C and Multi-Function Remote
Discrete Control RGB
Ye s
N/A
Landscape or Portrait
380W (approx.)
Silver or Black
Picture in Picture
Picture and Picture
Safety Regulations
Supplied Accessories
Optional Accessories
(Sold separately)
Limited Warranty
Optional Card Slots
(Sold separately)
Ye s
DVI-D Cable, AC Power Cord, Operating Instructions, AC Plug Holder (2), AA/R6 size Battery (2),
Tuners with Hospitality Connections, Alternate Inputs, and Component/RGB Loop Through
2 available: 1 for Networking or Tuners; 1 for Networking, Tuners, Input, or Loop Through
Picture and Picture
UL1950, CSA No.950 (c-UL), CE LVD (EN60950), FCC Class B, IC Class B,
VCCI Class B, CE EMC (EN55022 Class-B,EN55024, EN61000-3-2, EN61000-3-3),
C-Tick (AS/ NZS 3548/ 95, AS/NZS 4252.1), JEIDA, CB
Cable Holder (4), Component Cable, Remote Control
Universal Table Stands & Wall Brackets, Multiple Networking options
which include Status Control/Streaming Content, Storing Content Tuners,
2-year parts and labor, 1-year panel onsite service Limited Warranty²
(Extended Service available - Sold separately)
1 available for Input or Loop Through
2 available, 1 for Networking, Tuners, Inputs or Loop
Through; 1 for Input, or Loop Through
Ye s
Bringing It All Together.
TV Tuners
TV tuners with hotel networking capability integrate data,
cable, TV channels and hotel networking services for
hotel guest rooms, conference rooms and lounges.
Sony offers networking devices, television tuners
and software solutions that let you centrally manage,
control and deliver digital content and information.
From promoting a special offer in a shopping
environment, to broadcasting presentations in a
conference room setting or providing guest room
entertainment, Sony’s solutions provide you an
easy-to-use, cost-effective way to deliver your
message when you want it, where you want it.
1
2
3
4
5
6
7
8
9
10
11
12
ICS-SP20 Internal TV Tuner with Hospitality Support
• Supports major view-on-demand systems including
LodgeNet, OnCommand, Hospitality Network, and NXTV
• 181 channel access, closed captioning, V-chip program
controls, and channel lock capability
• Input mapping to TV channels-DVI and other inputs can be
assigned to unused TV channels for hospitality applications
BKM-FW32 Internal Network Management Card
Allows for status and control via IP address to manage multiple monitors from a single remote location using a standard IP network.
• Internal single card slot solution
• For Ethernet status and control
• Compatible with SNMP protocol for advanced software control and automation
Networking Solutions
Optional networking devices (sold separately) let you centrally
control, deliver and troubleshoot digital content across a
standard IP network to one or hundreds of networked displays.
Reduce labor and production costs associated with managing
individual content.
• Integrated Software Support - Use Display Commander or use
PJNet!™ Software to manage and control your display and
projector assets.
EBS-N200D Network Media Player The network streaming device provides status, control and streaming video/audio over IP, enabling affordable and flexible asset management and streaming content solutions for classrooms, conference rooms and digital signage applications.
• Transmit, receive, and control video and audio over an IP network with your Sony® display
• Real Time Streaming Content - Deliver powerful content with real time streaming and decoding of MPEG/4/2/1 files, jpgs and even Internet websites
• 2GB³ storage capacity - now you can stream live or store
• Now with Macromedia® Flash® and Microsoft® PowerPoint® viewer included
• Local playback available with user accessible 2.0GB³ Hard Drive
• Asset Management - Centralize your AV/IT support resources while saving your company time and money by remotely troubleshooting and diagnosing up to 255 Sony displays or projectors
• Remote PC Desktop View - Access your conference room display or projector through your company's network utilizing remote view capability to control your presentation, either wireless or wired
• Integrated Software Support - Utilize Display Commander to create playlists as well as distribute playlists and content. Scheduling playback times and locations is easy with Display Commander. With PJNet!™ you can be notified by email or pager if your displays are not functioning or missing
• 5.1 digital audio capability for full surround sound
• USB ports can be used for touch screen kiosk applications
NSP-1 Digital Signage Player
The powerful NSP-1 is the engine that drives revenue-generating digital signage solutions.
• Handle layers of high-quality graphics, text, and video, for delivering dynamic programming directly to customers
• Dedicated audio track and an option to feed live video to the unit
• Use grouping function of BZNPD1 software by combining several groups of NSP1s and programming different content to each of these groups
BKM-FW50 Network Media Card
• Streaming or local playback with Compact Flash card (card not included)
• Perfect for small to medium sized businesses
• Simple automatic operation, presentation automatically starts
• No need for network, no need for software
• Special software,use web browser for control
• Drag and drop MPGs, JPGs, and GIFs
• Place on Compact Flash
Accessories
Networking and Tuners
EBS-N200D (all PFM and FWD models): Network Media Player
includes an integrated web browser for easy digital signage
BKM-FW32 (All FWD models) Network Management Card
BKM-FW50(FWD42PV1, FWD50PX2, FWD32LX1R & FWD40LX1):
Network Media Card for easy digital signage with Compact Flash
NSP-1 (all PFM and FWD models): Digital Signage Player
ICS-SP20 (all FWD models): Internal TV tuner with hospitality support
EBS-SP10 (PFM42X1): External TV tuner with hospitality support
EBS-SP15 (all PFM and FWD models): Hospitality clone device,
for duplicating settings from one display to many others
1
2
3
4
5
6
7
8
9
10
11
12
Wall Brackets and Stands
PLP-91/D (all models):
Automatic Tilt Wall Mount allows for a flat installation with angled viewing of up to 15 degrees. Ideal for high installations or installations requiring portrait mounting. This sturdy mount provides tilted viewing of a plasma monitor, without adjusting screws. Includes additional security flange to lock monitor to bracket
SPM-TRI/C (all models):
Tabletop stand with clear acrylic base specifically designed for all PlasmaPro™ and LCD models
SPM-TRI/E (all models):
Affordable tabletop stand with silver base, specifically designed for all PlasmaPro and LCD displays
SFM1 (all 42" and 50" models), SFM2 (FWD-32LX1R)
Flat wall mount, single wallplate features multiple mounting slots
Speakers
SS-SP50FW/S (50"):
Silver speakers for FWD-50PX2/S and FWD-50PX2/B
SS-SP20B/S (42"):
Silver speakers for PFM-42X1/S
SS-SP20B/B (42"):
Black speakers PFM-42X1/B
SS-SP40FW/S (40"):
Silver speakers for FWD-40LX1/S and FWD-40LX1/B
SS-SP40FW/W (40"):
Pearl White speakers for FWD-40LX1/W
SS-SP42FW/S (42"):
Silver speakers for FWD-42PV1/S
SS-SP42FW/B (42"):
Black speakers for FWD-42PV1/B
SS-SP32FW/S (32"):
Silver speakers for FWD-32LX1R/S and FWD-32LX1R/B
SS-SP32FW/W (32"):
Pearl White speakers for FWD-32LX1R/W
Input Boards
BKM-V11 (PFM-42X1):
Additional component/RGB input board, using 5-BNC connectors for the PFM-42X1 PlasmaPro™ displays
BKM-V12 (PFM-42X1):
RGB/Component active loop-through for the PFM-42X1 PlasmaPro™ model
BKM-FW11 (all FWD models):
Additional component/RGB input board, using 5-BNC connectors
BKM-FW12 (all FWD models):
RGB/Component active loop-through
Applications & Solutions
Lobby & Reception Areas
Welcome your guests with dynamic messaging on Sony’s high brightness screens make a great first impression.
Guest Room Entertainment
Hotel networking options allow your guests to enjoy pay-per-view movies on the dynamically upscale design of a Sony® flat display.
Conference / Training Rooms
Sony’s easy-to-use networking products enable business clients to deliver their presentation with polish and impact.
Restaurants & Lounges
Attract and entertain customers with live sports and movie broadcasts at a low cost with Sony's power-saving, long-life panels.
Shopping Malls
Sony’s easy-to-use Digital signage solutions and bright panels can influence your sales with lively, effective digital signage.
Home Theater
Entertain your family with Sony's high definition, vivid picture, framed with elegantly-styled panels.
Sony stands behind its family of office technology products with value-added programs including its limited warranty, flexible extended service plan options, program support and outstanding customer care.
Display Evaluation Program: Receive access to samples for timely evaluation of new display products,
resulting in a smoother transition period and decision-making process.
Program participation may be subject to approval. Please see your Sony representative for more details.
Sony offers a 2-year parts and labor and 1-year panel onsite service limited warranty.
2
Onsite Service Program: Providing up to five years of onsite service from the day the product is purchased. If the product is within 50 miles of a Sony authorized service provider, service is performed on-site. Otherwise, coverage includes all shipping and depot costs. (Sold separately)
Priority Business Technical Support: Sony offers its clients 24-hour technical support by phone (877-350-3477), seven days a week, for troubleshooting advice and display-related assistance.
1. Requires an HDTV-compatible tuner/receiver sold separately.
2. When available, Sony will provide onsite service in fullfilment of its limited warranty obligations. Any such services are subject to the terms and conditions of the limited warranty. See actual Limited Warranty for details. Onsite Service will be provided via third-party technician to be dispatched as needed following phone-based troubleshooting. Some repairs may be accomplished with self-repair kits. Onsite Services may not be available in all locations.
3. GB means one billion bytes when referring to hard drive capacity. Accessible capacity may vary.
For more information or complete terms and conditions: www.sony.com/displays or www.sony.com/professional
©2005 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Features and specifications are subject to change without notice. Sony, PJNet!, WEGA Engine, WEGA, PlasmaPro, “like.no.other,” and its logo are trademarks of Sony. Microsoft and PowerPoint are registered trademarks of Microsoft Corporation. Macromedia and Flash are trademarks or registered trademarks of Macromedia, Inc. in the United States and/or other countries. All other trademarks are property of their respective owners. Screen images are simulated. Screen sizes represent viewable area measured diagonally. Non-metric measures and weights are approximate.
Printed 11/2005
Loading...
