remotely controlled,
clearly focused
Sony PTZ Camera Series
If you thought exceptional picture quality and camera control wasn’t
remotely possible, Sony’s Pan/Tilt/Zoom cameras will change your
mind. From video conferencing to distance learning, from worship
to sporting events, from telemedicine to patient consulting, there’s a
Sony remotely controlled PTZ camera that puts you clearly right in the
middle of the action, with legendary reliability, picture quality and
autofocus accuracy that set the Sony PTZ cameras apart.
Our expanded line of SD and HD models meets your needs with 10x to
28x optical zoom options and mounting flexibility. The dynamic 1080p
and 1080i models offer unprecedented clarity and resolution, ideal
for small to large spaces in a variety of government, corporate, studio,
educational, medical and house of worship applications. Every model
offers the VISCA™ protocol created by Sony, with a host of convenient
features in a sleek design.
Test out these amazing cameras that you
control remotely for close-up access.
SD Cameras
BRC-300
3-CCD Pan/Tilt/Zoom
Color Video Camera
Optional RM-BR300 Controller
1/4.7-type CCD x 3 image sensor
Superb picture quality
Horizontal resolution - 600 TV lines
Minimum illumination – 7 lx
Supports SD output as standard
Optional interface card slot for SDI, i.Link™
DV interface, fiber and RGB capability
NTSC image format
12x optical, 4x digital zoom lens
Fully remote controllable via
RS-232C/RS-422 (VISCA protocol)
Optional VISCA RM-BR300 Controller
Wide-range, quiet and
quick pan/tilt mechanism:
• Pan: -170° to +170°
(max. speed 60°/second)
• Tilt: -30° to +90°
(max. speed 60°/second)
4:3/16:9 aspect selectable
(16:9 precision technology)
Desktop or ceiling mountable with
E:Flip function
EVI-D90
EVI-D90/W
28x SD Pan/Tilt/Zoom
Color Video Cameras
1/4-type ExView HAD CCD® sensor
Progressive or interlace scan option
Video output: VBS (RCA jack) and
Y/C (4 pin MiniDIN)
Excellent low light sensitivity:
Minimum illumination 0.65 lux
(F1.35, 50IRE)
High zoom ratio AF lens: 28x optical,
12x digital
Wide D function (Auto Wide-D)
Image stabilizer function
Auto ICR function
Auto focus
Alarm function
Wide-range, quiet and quick
pan/tilt/zoom mechanism:
•
Pan: -170º to +170º
(max. speed 100º/second)
•
Tilt: -20º to +90º
(max. speed 90º/second)
Backward compatible D70 mode
Desktop or ceiling mountable with
E:Flip function
Available in white or black housing
Optional VISCA RM-BR300 Controller
EVI-D80
EVI-D80/W
18x SD Pan/Tilt/Zoom Color Video
Cameras
1/4-type CCD sensor
Video output: VBS (RCA jack) and
Y/C (4 pin MiniDIN)
High zoom ratio AF lens: 18x optical,
12x digital
Excellent low light sensitivity:
Minimum illumination 0.4 lux (F1.4, 50IRE)
Auto focus
Alarm function
Wide-range, quiet and quick
pan/tilt/zoom mechanism:
•
Pan: -170º to +170º
(max. speed 100º/second)
•
Tilt: -20º to +90º
(max. speed 90º/second)
Backward compatible D70 mode
Desktop or ceiling mountable with
E:Flip function
Available in white or black housing
Optional VISCA RM-BR300 Controller
HD Cameras
BRC-H900
1080i 3 CMOS HD
Pan/Tilt/Zoom Color Video Camera
Optional RM-IP10 Controller
1/2-type Exmor® CMOS x 3 image sensor
Superb broadcast picture quality
Full HD 1080i/60 resolution
High sensitivity – 4 lx minimum illumination
Advanced color adjustment
HD-SDI, component, RGB and composite,
Y/C video interfaces
Selectable image formats:
1080i/720p/NTSC/PAL at 59.94Hz and 50Hz
14x optical zoom lens
Fully remote controllable via RS-232C/RS-422
(VISCA™ protocol)
Optional VISCA RM-BR300 Controller
Optional IP control with RM-IP10 controller &
BRBK-IP10 card
Tally lamp
Wide-range, quiet and quick pan/tilt mechanism:
• Pan: -170° to +170° (max. speed 60°/second)
• Tilt: -30° to +90° (max. speed 60°/second)
Horizontal viewing angle: 59.6° (wide-end)
Desktop or ceiling mountable with E:Flip function
a camera for every occasion
BRC-H700
1080i 3 CCD HD
Pan/Tilt/Zoom Color Video Camera
Optional RM-BR300 Controller
1/3-type IT CCD x 3 image sensor
Superb picture quality
HD 1080i/60 resolution
Minimum illumination – 6 lx
Supports analog RGB, Y/Pb/PR output as standard
Optional interface card slot for HD-SDI,
computer XGA and HDV™ formats
Selectable image formats:
1080i at 59.94Hz and 50Hz
12x optical, 4x digital zoom lens
Fully remote controllable via RS-232C/RS-422
(VISCA protocol)
Optional VISCA RM-BR300 Controller
Wide-range, quiet and quick pan/tilt mechanism:
• Pan: -170° to +170° (max. speed 60°/second)
• Tilt: -30° to +90° (max. speed 60°/second)
Horizontal viewing angle: 60.3° (wide-end)
Desktop or ceiling mountable with E:Flip function
BRC-Z700
BRC-Z330
1080i 3 CMOS HD
Pan/Tilt/Zoom Color Video Camera
Optional RM-IP10 Controller
1/4-type CMOS x 3 image sensor
Superb picture quality
HD 1080i/60 resolution
Minimum illumination – 6 lx
Supports HD and SD outputs as standard
Optional interface card slot for HD-SDI
and SD-SDI formats
Selectable image formats:
1080i/NTSC/PAL at 59.94Hz and 50Hz
20x optical, 4x digital zoom lens
Fully remote controllable via RS-232C/RS-422
(VISCA protocol)
Optional VISCA RM-BR300 Controller
Optional IP control with RM-IP10 controller &
BRBK-IP7Z card
Wide-range, quiet and quick pan/tilt mechanism:
• Pan: -170° to +170° (max. speed 60°/second)
• Tilt: -30° to +90° (max. speed 60°/second)
Horizontal viewing angle: 55.2° (wide-end)
Desktop or ceiling mountable with
E:Flip function
1080i CMOS HD
Pan/Tilt/Zoom Color Video Camera
Optional RM-IP10 Controller
1/3-type CMOS image sensor
Superb picture quality
HD 1080i/60 resolution
Minimum illumination – 6 lx
Supports HD and SD outputs as standard
Optional interface card slot for HD-SDI
and Analog SD formats
Selectable image formats:
1080i/720p/NTSC/PAL at 59.94Hz and 50Hz
18x optical, 4x digital zoom lens
Fully remote controllable via RS-232C/RS-422
(VISCA protocol)
Optional VISCA RM-BR300 Controller
Optional IP control with RM-IP10 controller &
BRBK-IP10 card
Wide-range, quiet and quick pan/tilt mechanism:
• Pan: -175° to +175° (max. speed 60°/second)
• Tilt: -30° to +90° (max. speed 60°/second)
Horizontal viewing angle: 55.1° (wide-end)
Desktop or ceiling mountable with
E:Flip function
EVI-H100S
EVI-H100S/W
EVI-H100V
EVI-H100V/W
1080p HD Pan/Tilt/Zoom
Color Video Cameras
1/2.8-type Exmor CMOS image sensor
Superb picture quality
Full HD 1080p/30 resolution
Auto ICR function
HD-SDI video interface
Selectable image formats:
1080p / 1080i / 720p /SD (letter box)
at 59.94Hz, 50Hz, 29.97Hz and 25Hz
20x optical, 12x digital zoom lens
Wide D function (auto wide-D)
Wide-range, quiet and quick pan/tilt/zoom mechanism:
• Pan: -170º to +170º (max. speed 100º/second)
• Tilt: -20º to +90º (max. speed 90º/second)
Horizontal viewing angle: 55.4º (wide) to 2.9º (tele)
Desktop or ceiling mountable with E:Flip function
Available in white or black housing
Optional VISCA RM-BR300 Controller
1080p HD Pan/Tilt/Zoom
Color Video Cameras
1/2.8-type Exmor CMOS image sensor
Superb picture quality
Full HD 1080p/30 resolution
DVI video interface
Auto ICR function
Selectable image formats:
1080p / 1080i / 720p at 59.95Hz,
50Hz, 29.97Hz and 25Hz
20x optical, 12x digital zoom lens
Wide D function (auto wide-D)
Wide-range, quiet and quick pan/tilt/zoom mechanism:
• Pan: -170º to +170º (max. speed 100º/second)
• Tilt: -20º to +90º (max. speed 90º/second)
Horizontal viewing angle: 55.4º (wide) to 2.9º (tele)
Desktop or ceiling mountable with E:Flip function
Available in white or black housing
Optional VISCA RM-BR300 Controller
EVI-HD7V
EVI-HD3V
EVI-HD1
1080p HD Pan/Tilt/Zoom
Color Video Camera
1/3-type CMOS image sensor
Superb picture quality
DVI video interface
Selectable image formats:
1080p / 1080i / 720p / 640x480
(letter box) at 59.94Hz and 50Hz
10x optical, 4x digital zoom lens
Wide-range, quiet and quick
pan/tilt/zoom mechanism:
• Pan: -100° to +100°
(max. speed 300°/second)
• Tilt: -25° to +25°
(max. speed 125°/second)
Wide horizontal viewing angle:
70° (wide) to 8° (tele)
Desktop mountable
Optional VISCA RM-BR300 Controller
720p HD Pan/Tilt/Zoom
Color Video Camera
1/3-type CMOS image sensor
Superb picture quality
DVI video interface
Selectable image formats:
720p / 640x480 (letter box)
10x optical, 4x digital zoom lens
Wide-range, quiet and quick
pan/tilt/zoom mechanism:
• Pan: -100° to +100°
(max. speed 300°/second)
• Tilt: -25° to +25°
(max. speed 125°/second)
Wide horizontal viewing angle:
70° (wide) to 8° (tele)
Desktop mountable
Optional VISCA RM-BR300 Controller
Multi-format HD Pan/Tilt/Zoom
Color Video Camera
1/3-type CMOS image sensor
Superb picture quality
Multi-format video outputs from
NTSC/PAL to Full HD: HD-SDI, HD Analog
component (Y/Pb/Pr), VBS, Y/C
Selectable image formats:
1080i / 1080p / 720p / NTSC / PAL
10x optical, 4x digital zoom lens
Wide-range, quiet and quick
pan/tilt/zoom mechanism:
• Pan: -100º to +100º
(max. speed 300º/second)
• Tilt: -25º to +25º
(max. speed 125º/second)
Wide horizontal viewing angle:
70º (wide) to 8º (tele)
Desktop mountable
Optional VISCA RM-BR300 Controller
sony.com/ptz
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/ptz
IS-1255
© 2013 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without
written permission is prohibited. Features and specifications are subject to change
without notice. Sony, Exmor, ExView HAD CCD, VISCA, and the Sony make.believe logo are
trademarks of Sony.
Printed in USA 5/13
