Sony DSC-TF1 User Manual [en, es]

4-452-084-22(1)

Digital Still Camera / Instruction Manual GB

Cámara fotografía digital / Manual de instrucciones ES

DSC-TF1

English

Learning more about the camera (“Cyber-shot User Guide”)

“Cyber-shot User Guide” is an on-line manual. Refer to it for in-depth instructions on the many functions of the camera. 1 Access the Sony support page.

http://www.sony.net/SonyInfo/Support/

2 Select your country or region. 3 Search for the model name of your camera within the

support page.

• Check the model name on the bottom of your camera.

Checking the supplied items

The number in parentheses indicates the number of pieces.

• Camera (1)

• Rechargeable battery pack NP-BN (1) (This rechargeable battery pack cannot be used with Cyber-shot that are supplied with the NP-BN1 battery pack.)

• Dedicated USB cable (1) (Pan-International Industrial GP00621A-11)

• AC Adaptor AC-UB10/UB10B/UB10C/UB10D (1)

• Power cord (mains lead) (not supplied in the USA and Canada) (1)

• Wrist strap (1)

• Instruction Manual (this manual) (1)

• Notes on the water-proofing (1)

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call your Sony dealer regarding this product.

Model No. DSC-TF1 Serial No. _____________________________ Model No. AC-UB10/AC-UB10B/AC-UB10C/AC-UB10D Serial No. _____________________________

WARNING

To reduce fire or shock hazard, do not expose the unit to rain or moisture.

IMPORTANT SAFETY INSTRUCTIONS

-SAVE THESE INSTRUCTIONS DANGER TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS

If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the proper configuration for the power outlet.

CAUTION

[ Battery pack

If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical burns. Observe the following cautions.

• Do not disassemble.

• Do not crush and do not expose the battery pack to any shock or force such as

hammering, dropping or stepping on it.

• Do not short circuit and do not allow metal objects to come into contact with the battery

terminals.

• Do not expose to high temperature above 60°C (140°F) such as in direct sunlight or in a

car parked in the sun.

• Do not incinerate or dispose of in fire.

• Do not handle damaged or leaking lithium ion batteries.

• Be sure to charge the battery pack using a genuine Sony battery charger or a device that can charge the battery pack.

• Keep the battery pack out of the reach of small children.

• Keep the battery pack dry.

• Replace only with the same or equivalent type recommended by Sony.

• Dispose of used battery packs promptly as described in the instructions.

[ AC Adaptor

Use the nearby wall outlet (wall socket) when using the AC Adaptor. Disconnect the AC Adaptor from the wall outlet (wall socket) immediately if any malfunction occurs while using the apparatus.

For Customers in the U.S.A. and Canada

[ RECYCLING LITHIUM-ION BATTERIES

Lithium-Ion batteries are recyclable. You can help preserve our environment by returning your used rechargeable batteries to the collection and recycling location nearest you.

For more information regarding recycling of rechargeable batteries, call toll free 1-800-822-8837, or visit http://www.rbrc.org/

Caution: Do not handle damaged or leaking Lithium-Ion batteries.

[ Battery pack

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This Class B digital apparatus complies with Canadian ICES-003.

For Customers in the U.S.A.

UL is an internationally recognized safety organization. The UL Mark on the product means it has been UL Listed.

If you have any questions about this product, you may call:

Sony Customer Information Center 1-800-222-SONY (7669)

The number below is for the FCC related matters only.

[ Regulatory Information

Declaration of Conformity

Trade Name: SONY Model No.: DSC-TF1 Responsible Party: Sony Electronics Inc. Address: 16530 Via Esprillo,

Telephone No.: 858-942-2230

This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

[ CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

[ Note:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

San Diego, CA 92127 U.S.A.

The supplied interface cable must be used with the equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.

For Customers in Europe

[ Notice for the customers in the countries applying EU Directives

This product has been manufactured by or on behalf of Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan. Inquiries related to product compliance based on European Union legislation shall be addressed to the authorized representative, Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or guarantee matters, please refer to the addresses provided in the separate service or guarantee documents.

This product has been tested and found compliant with the limits set out in the EMC regulation for using connection cables shorter than 3 meters (9.8 feet).

[ Attention

The electromagnetic fields at the specific frequencies may influence the picture and sound of this unit.

[ Notice

If static electricity or electromagnetism causes data transfer to discontinue midway (fail), restart the application or disconnect and connect the communication cable (USB, etc.) again.

[ Disposal of Old Electrical & Electronic Equipment (Applicable in

the European Union and other European countries with separate collection systems)

please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product,

[ Disposal of waste batteries (applicable in the European Union

and other European countries with separate collection systems)

This symbol on the battery or on the packaging indicates that the battery provided with this product shall not be treated as household waste. On certain batteries this symbol might be used in combination with a chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb) are added if the battery contains more than 0.0005% mercury or 0.004% lead.

potentially negative consequences for the environment and human health which could otherwise be caused by inappropriate waste handling of the battery. The recycling of the materials will help to conserve natural resources. In case of products that for safety, performance or data integrity reasons require a permanent connection with an incorporated battery, this battery should be replaced by qualified service staff only. To ensure that the battery will be treated properly, hand over the product at end-of-life to the applicable collection point for the recycling of electrical and electronic equipment. For all other batteries, please view the section on how to remove the battery from the product safely. Hand the battery over to the applicable collection point for the recycling of waste batteries. For more detailed information about recycling of this product or battery, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

By ensuring these batteries are disposed of correctly, you will help prevent

Notice for customers in the United Kingdom

A moulded plug complying with BS 1363 is fitted to this equipment for your safety and convenience. Should the fuse in the plug supplied need to be replaced, a fuse of the same rating as the supplied one and approved by ASTA or BSI to BS 1362, (i.e., marked with an or mark) must be used. If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.

About water-proof, dust-proof, and shock-proof performance of the camera

This camera is equipped to be water-proof, dust-proof and shock-proof. Damage caused from misuse, abuse or failure to properly maintain the camera is not covered by the limited warranty.

• This camera is water-proof/dust-proof equivalent to IEC60529 IP68. The camera is operable up to a water depth of 10 m (33 ft) for 60 minutes.

• Do not subject the camera to pressurized water, such as from a tap.

• Do not use in hot springs.

• Use the camera in the recommended operating water temperature range of 0°C to 40°C (32°F to 104°F).

• The shock resistance of this camera has passed the in-house drop test from a height of 1.5 m (5 ft) onto a 5-cm (2 inches) thick plywood board, which conforms to the MIL-STD 810F Method 516.5-Shock standards (test method standard of the U.S. Defense Department).

* Depending on use conditions and circumstances, no guarantee is made regarding

damage to, malfunction of, or the water-proof performance of this camera.

• As for dust-proof/shock-proof performance, there is no guarantee that the camera will not become scratched or dented.

• Sometimes water-proof performance is lost if the camera is subjected to a strong shock such as from being dropped. We recommend the camera be inspected at an authorized repair shop for a fee.

• Accessories supplied do not meet water-proof, dust-proof, and shock-proof specifications.

Notes before using the camera under/near water

• Make sure that no foreign matter such as sand, hair, or dirt gets inside the battery/memory card cover. Even a small amount of foreign matter may lead to water entering the camera.

• Confirm that the sealing gasket and its mating surfaces have not become scratched. Even a small scratch may lead to water entering the camera. If the sealing gasket or its mating surfaces become scratched, take the camera to an authorized repair shop to have the sealing gasket replaced for a fee.

1 Sealing gasket 2 Surface contacting the

sealing gasket

• If dirt or sand gets on the sealing gasket or its mating surfaces, wipe the area

clean with a soft cloth that will not leave behind any fibers. Prevent the sealing gasket from becoming scratched by touching it while charging a battery or using a cable.

• Do not open/close the battery/memory card cover with wet or sandy hands or

near water. There is a risk this will lead to sand or water getting inside. Before opening the cover, perform the procedure described in “Cleaning after using the camera under/near water”.

• Open the battery/memory card cover with the camera completely dry.

• Always confirm that the battery/memory card cover has been securely

locked.

Notes on using the camera under/near water

• Do not subject the camera to shock such as from jumping into water.

• Do not open and close the battery/memory card cover while under/near

water.

• This camera sinks in water. Place your hand through the wrist strap to

prevent the camera from sinking.

• Faint, white, circular spots may appear in under-water flash photos due to

reflections off of floating objects. This is not a malfunction.

• If water drops or other foreign matter is present on the lens, you will be

unable to record clear images.

Cleaning after using the camera under/near water

• Always clean the camera with water after use

within 60 minutes, and do not open the battery/memory card cover before cleaning is finished. Sand or water may get inside places where it cannot be seen. If not rinsed, waterproof performance will be degraded.

• Allow the camera to sit in pure water poured

into a cleaning bowl for about 5 minutes. Then, gently shake the camera, press each button, slide the zoom lever inside the water, to clean away any salt, sand or other matter lodged around the buttons.

• After rinsing, wipe away water drops with a soft cloth. Allow the camera to

dry completely in a shady location with good ventilation. Do not blow dry with a hair dryer as there is a risk of deformation and/or degraded waterproof performance.

• Wipe away water drops or dust on the memory card/battery cover with a soft

dry cloth.

• This camera is constructed to drain water. Water will drain from openings around the ON/OFF (Power) button, zoom lever, and other controls. After removing from water, place the camera on a dry cloth for a while to allow water to drain.

• Bubbles may appear when the camera is placed under water. This is not a malfunction.

• The camera body may become discolored if it comes in contact with sunscreen or suntan oil. If the camera does come in contact with sunscreen or suntan oil, quickly wipe it clean.

• Do not allow the camera to sit with salt water inside or on the surface. This may lead to corrosion or discoloration, and degradation of water-proof performance.

• To maintain the water-proof performance, we recommend that once a year you take the camera to your dealer, or to an authorized repair shop, to have the sealing gasket of the battery/memory card cover replaced for a fee.

Identifying parts

A ON/OFF (Power) button B Shutter button C For shooting: W/T (zoom) lever

For viewing: (Index) lever/

(Playback zoom) lever

D Flash E Self-timer lamp/Smile Shutter

lamp/AF illuminator

F Charge lamp/Light sensor

• The brightness of the LCD monitor is automatically adjusted to the ambient lighting conditions using the light sensor. Do not cover the light sensor with your hand and so on.

G Microphone H Lens I Speaker J LCD screen K (Playback) button L Mode lamp M Mode button N Hook for wrist strap O / (In-Camera Guide/Delete)

button

P MENU button Q Control button

MENU on: v/V/b/B MENU off: (Self-Timer)/

(Flash)

R Memory card slot S Access lamp T Battery/Memory card cover U Battery eject lever V Battery insertion slot W USB / A/V OUT terminal X Tripod socket hole

• Use a tripod with a screw less than 5.5 mm (7/32 inches) long. Otherwise, you cannot firmly secure the camera, and damage to the camera may occur.

Inserting the battery pack

Battery eject lever

Open the cover.

Insert the battery pack.

• While pressing the battery eject lever, insert the battery pack as illustrated. Make sure that the battery eject lever locks after insertion.

• Securely close the battery cover until you hear the slide lock on the cover catch in place and so that the yellow mark under the slide lock can no longer be seen.

• Closing the cover with the battery inserted incorrectly may damage the camera.

• Push the end of the cover to close it.

Charging the battery pack

For customers in the USA and Canada

Power cord (Mains lead)

For customers in countries/regions other than the USA and Canada

Connect the camera to the AC Adaptor (supplied),

using the dedicated USB cable (supplied).

Connect the AC Adaptor to the wall outlet (wall socket).

The Charge lamp lights orange, and charging starts.

• Turn off the camera while charging the battery.

• You can charge the battery pack even when it is partially charged.

• When the Charge lamp flashes and charging is not finished, remove and

re-insert the battery pack.

Charge lamp Lit: Charging Off: Charging finished Flashing:

Charging error or charging paused temporarily because the camera is not within the proper temperature range

Notes

• If the Charge lamp on the camera flashes when the AC Adaptor is connected to the wall outlet (wall socket), this indicates that charging is temporarily stopped because the temperature is outside the recommended range. When the temperature gets back within the appropriate range, the charging resumes. We recommend charging the battery pack in an ambient temperature of between 10°C to 30°C (50°F to 86°F).

• The battery pack may not be effectively charged if the terminal section of the battery is dirty. In this case, wipe any dust off lightly using a soft cloth or a cotton swab to clean the terminal section of the battery.

• Connect the AC Adaptor (supplied) to the nearest wall outlet (wall socket). If malfunctions occur while using the AC Adaptor, disconnect the plug from the wall outlet (wall socket) immediately to disconnect from the power source.

• When charging is finished, disconnect the AC Adaptor from the wall outlet (wall socket).

• Be sure to use only genuine Sony brand battery packs, dedicated USB cable (supplied) and AC Adaptor (supplied).

Charging time (Full charge)

The charging time is approximately 115 min. using the AC Adaptor (supplied).

Notes

• The above charging time applies when charging a fully depleted battery pack at a temperature of 25°C (77°F). Charging may take longer depending on conditions of use and circumstances.

Charging by connecting to a computer

The battery pack can be charged by connecting the camera to a computer using the dedicated USB cable.

To a USB jack

Notes

• Note the following points when charging via a computer:

– If the camera is connected to a laptop computer that is not connected to a power

source, the laptop battery level decreases. Do not charge for an extended period of time.

– Do not turn on/off or restart the computer, or wake the computer to resume from

sleep mode when a USB connection has been established between the computer and the camera. The camera may cause a malfunction. Before turning on/off, or restarting the computer or waking the computer from sleep mode, disconnect the camera and the computer.

– No guarantees are made for charging using a custom-built computer or a

modified computer.

Battery life and number of images that can be recorded and played back

Battery life Number of images

Shooting (still images) Approx. 95 min. Approx. 200 images Actual shooting (movies) Approx. 40 min. — Continuous shooting (movies) Approx. 90 min. — Viewing (still images) Approx. 210 min. Approx. 4200 images

Notes

• The above number of images applies when the battery pack is fully charged. The

number of images may decrease depending on the conditions of use.

• The number of images that can be recorded is for shooting under the following

conditions: – Using Sony microSD memory card (Class 4 or faster) (sold separately) – The battery pack is used at an ambient temperature of 25°C (77°F).

• The number for “Shooting (still images)” is based on the CIPA standard, and is for

shooting under the following conditions: (CIPA: Camera & Imaging Products Association) – [Disp. Resolution] is set to [Standard]. – Shooting once every 30 seconds. – The zoom is switched alternately between the W and T ends. – The flash strobes once every two times. – The power turns on and off once every ten times.

• The battery life for movies is based on the CIPA standard, and is for shooting under the following conditions: – Recording mode: 1280×720 – “Actual shooting (movies)”: Indicates the approximate shooting time as a

guideline when you repeatedly perform shooting, zooming, standby for shooting, and turning on and off the camera.

– “Continuous shooting (movies)”: When continuous shooting ends because of set

limits (29 minutes), press the shutter button again to continue shooting. Shooting functions such as the zoom do not operate.

Supplying power

The camera can be supplied with power from the wall outlet (wall socket) by connecting to the AC Adaptor (supplied), using the dedicated USB cable (supplied). You can import images to a computer without worrying about draining the battery pack by connecting the camera to a computer using the dedicated USB cable. In addition, you can use the AC Adaptor AC-UD10 (sold separately) or ACUD11 (sold separately) to supply power when shooting.

Notes

• Power cannot be supplied when the battery pack is not inserted in the camera.

• When the camera is connected directly to a computer or to a power outlet using the supplied AC Adaptor, power supply is available only in playback mode. If the camera is in shooting mode or while you are changing the settings of the camera, power is not supplied even if you make a USB connection using the dedicated USB cable.

• If you connect the camera and a computer using the dedicated USB cable while the camera is in playback mode, the display on the camera will change from the playback screen to the USB connection screen. Press the (Playback) button to switch to the playback screen.

• The AC Adaptor AC-UD11 (sold separately) may not be available in some countries/regions.

Inserting a memory card (sold separately)

“Memory Stick Micro” media (M2)

Make sure that the correct side is facing up.

Open the cover.

Insert the memory card (sold separately).

• With the camera lens facing upward, as illustrated, insert the memory card straight in until it clicks into place.

• If you push forcefully on the microSD memory card (in the direction of the battery insertion slot) while inserting it, you may damage the camera.

• Be careful when removing the microSD memory card, as it may pop out quickly.

Close the cover.

• Securely close the battery cover until you hear the slide lock on the cover catch in place and so that the yellow mark under the slide lock can no longer be seen.

microSD memory card

TerminalPrinting surface

Memory cards that can be used

Memory card For still images For movies

A Memory Stick Micro (M2) (Mark2 only)

microSD memory card (Class 4 or faster)

microSDHC memory card (Class 4 or faster)

• In this manual, the products in the table are collectively referred to as follows:

A: “Memory Stick Micro” media B: microSD memory card

To remove the memory card/battery pack

Memory card: Push the memory card in once to eject the memory card. Battery pack: Slide the battery eject lever. Be sure not to drop the battery pack.

Notes

• Never remove the memory card/battery pack when the access lamp (page 11) is lit. This may cause damage to data in the memory card/internal memory.

Setting the clock

ON/OFF (Power)

Control button

Select items: v/V/b/B Set: z

Press the ON/OFF (Power) button.

Date & Time setting is displayed when you turn on the camera for the first time.

• It may take time for the power to turn on and allow operation.

Select a desired language.

Select a desired geographic location by following the

on-screen instructions, then press z on the control button.

Set [Date & Time Format], [Summer Time] and [Date &

Time], then select [OK] t [OK].

• Midnight is indicated as 12:00 AM, and noon as 12:00 PM.

Follow the instructions on the screen.

• If you set [Disp. Resolution] to [High], the battery charge may be depleted faster.

Shooting still images/movies

Shutter button

Mode button

: Still image : Sweep Panorama : Movie

Shooting still images

Press the shutter button halfway down to focus.

When the image is in focus, a beep sounds and the z indicator lights.

Press the shutter button fully down to shoot an image.

Shooting movies

Press the shutter button fully down to start recording.

• Use the W/T (zoom) lever to change the zoom scale.

Press the shutter button fully down again to stop

recording.

Notes

• The sound of the lever operating will be recorded when the zoom function operates while shooting a movie.

• The panoramic shooting range may be reduced, depending on the subject or the way it is shot. Therefore even when [360°] is set for panoramic shooting, the recorded image may be less than 360 degrees.

W/T (Zoom)

W: zoom out T: zoom in

• Continuous shooting is possible for approximately 29 minutes at one time at the

camera’s default settings and when the temperature is approximately 25°C (77°F). When movie recording is finished, you can restart recording by pressing the shutter button again. Recording may stop to protect the camera depending on the ambient temperature.

Viewing images

W: zoom out

(Playback)

T: zoom in

Control button

/ (Delete)

Press the (Playback) button.

• The last image shot is displayed.

Selecting next/previous image

Select an image by pressing B (next)/b (previous) on the control button. Press z in the center of the control button to view movies.

Deleting an image

1 Press / (Delete) button. 2 Select [This Image] with v on the control button, then press z.

Returning to shooting images

Press the shutter button halfway down.

Select images: B (next)/b (previous) Set: z

+ 47 hidden pages
