Sony DPP-FP97 Operating Instruction

4-129-103-11 (4)
Before you begin
Digital Photo Printer
DPP-FP97
Operating Instructions
Before operating this unit, please read “Read This First” and “About the Print Packs” supplied and this manual, “Operating Instructions,” thoroughly and retain them for future reference.
Owner's Record
The model and serial numbers are located on the bottom of the printer. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No.: DPP-FP97 Serial No. ________________________
Preparations
Direct printing
digital camera
Printing from a Bluetooth-
compliant device
Printing from a PC
Error messages
Troubleshooting
Additional information
© 2009 Sony Corporation
Please read the supplied “Read This First” and “About the Print Packs.”
