Sony DPP-F700 - Digital Photo Printer/frame Specifications

DPP-

F700

Digital Photo Frame 7” LCD

Sony’s DPP

-F700 Digital Photo Frame/Printer makes it simple to beautifully display

up to 2,000 2 MP photos on a 7”LCD screen and print 4x6" photos

1

Large 7”wide (16:10) LCD
display

Large 7” wide (16:10) LCD
display displays your photos
with vibrant color and crisp
detail in WVGA (800 x 480)
resolution.

1

1

Quick Prints

Print photos as fast as 45
seconds

Get creative

Creat calendars, photo
layouts, photo ID

Plug-and-Play, PC-less image
transfer

Plug-and-Play, PC-less image
transfer is a snap with direct

USB input from most digital
cameras, as well as support

for most memory cards .

5

6

Photo Display

Display your photos as a
single image, in thumbnail
view for quick searching, or
as a slideshow.

1 GB

internal storage

capacity

1 GB internal storage
capacity with Auto Sizing
feature lets you store up to
2,000 2 MP photos.

2

2

Auto Orientation sensor

An Auto Orientation sensor
automatically selects portrait
or landscape view depending
on the horizontal or vertical
placement of the frame.

Clock and calendar modes

Clock and calendar modes
provide added convenience
for your home or office.

Remote control

Supplied remote control lets
you navigate the Digital
Photo Frame without leaving
the comfort of your couch or
office chair.

Rosalinda Morrison ●

16530 Via Esprillo ●

San Diego, CA 92127-1898

Last Updated: 10/19/2009

DPP-

F700

Digital Photo Frame 7” LCD

Please visit the Dealer Network for more

information at www.sony.com/dn

Specifications

General

Action Buttons: Buttons: "Power"; "Standby",

"View Mode"
Touch pad: up, down, left, right arrows;
"Enter"; "Menu", "Back", "Print" Backlit
SONY® logo can be switched on/off.

Function: Delete, Zoom (-), Zoom (+),

Rotate image, Auto Touch Up, Image
display setting(Fit to screen/Full Image),
and Placement supported(Landscape,
Portrait, Auto orientation)

Convenience Features

Remote Control:

"Power"; Up, Down, Left and
Right arrows; "Enter", "Menu", "Cancel",
and "View Select"

Inputs and Outputs

USB Port(s): TypeA- B for computer

Display

Screen Size:

7" measured diagonally

Resolution: LCD Panel Resolution: Wide VGA

800 x 480

Hardware

LCD Panel Type: Clear Photo LCD; Panel

Size: 198 x 112 mm

Media & Modes Supported: Memory Stick;

Memory Stick Duo; Memory Stick PRO;
Memory Stick PRO Duo; HighSpeed
Memory Stick; HighSpeed Memory Stick
Duo; Memory Stick Micro (M2)(with
optional adaptor); MagicGate Memory
Stick; MagicGate Memory Stick Duo;
Memory Stick PRO-HG Duo(8-bit parallel
transfer of Memory Stick PRO-HG Duo is
not supported); SD card; mini SD card
(with optional adaptor); micro SD card
(with optional adaptor); SDHC card; mini
SDHC card(with optional adaptor); micro
SDHC card(with optional adaptor); MMC;
RS-MMC; MMC Plus; Compact Flash Type I;
Compact Flash Type II; xD-picture card;
xD-picture card Type M; xD-picture card
Type H

Optics/Lens

Pixels:

Max pixels available to decode and

print: 48 mega pixels

Power

AC Power:

100V-240V(50/60Hz)

Power Type: DC24V
Power Consumption (in Operation):

Approx. 100W(Max), Less than 1W(stand
by)

Video

Format(s) Supported:

JPEG, TIFF, and BMP

Playback: Still Image Playback; Slideshow

Playback(10 patterns); Index Playback;
Calender Playback; Placement supported

-

Landscape, Portrait, Auto orientation

Aspect Ratio: 16:10

Operating Conditions

Operating Temperature: Temperature

range 5 degrees C - 35 degrees C

Dimensions

Weight: Approx. 1.8kg (without AC adaptor,

paper tray, and ink)

Measurements: Landscape position:

Approx. W:276 x H:150 x D:186mm;
Portrait postion:Approx. W:149 x H:275 x
D: 185mm; Print position: Approx. W:276 x
H:85 x D: 149mm

Supplied Accessories

remote control

Optional Accessories

Color print pack SVM-F series

Color:

black

UPC Code:

027242776197

1. Viewable area, measured diagonally.

2. Actual usable memory capacity is 940MB because a portion of
memory is used for data management purposes.

3. USB input requires optional USB cable, sold separately.

4. Some cards required an adaptor, sold separately.
