The model and serial numbers are located at the rear of the unit.
Record the serial number in the space provided below. Refer to
these numbers whenever you call upon your dealer regarding this
product.
Model No.Serial No.
WARNING
To prevent fire or shock hazard, do not expose
the unit to rain or moisture.
Dangerously high voltages are present inside
the unit. Do not open the cabinet. Refer servicing
to qualified personnel only.
FCC Notice
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly
approved in this manual could void your authority to operate this
equipment.
INFORMATION
This product complies with Swedish National Council for
Metrology (MPR) standards issued in December 1990 (MPR II) for
very low frequency (VLF) and extremely low frequency (ELF).
INFORMATION
Ce produit est conforme aux normes du Swedish National Council
for Metrology de décembre 1990 (MPR II) en ce qui concerne les
fréquences très basses (VLF) et extrêmement basses (ELF).
Hinweis
Dieses Gerät erfüllt bezüglich tieffrequenter (very low frequency)
und tiefstfrequenter (extremely low frequency) Strahlung die
Vorschriften des „Swedish National Council for Metrology (MPR)“
vom Dezember 1990 (MPR II).
INFORMACIÓN
Este producto cumple las normas del Consejo Nacional Sueco para
Metrología (MPR) emitidas en diciembre de 1990 (MPR II) para
frecuencias muy bajas (VLF) y frecuencias extremadamente bajas
(ELF).
Dieses Garät entspricht den folgenden europäischen EMVVorschriften für Betrieb in Wohngebieten, gewerblicher Gebleten
und Leichtindustriegebieten.
EN55022/1994 Klasse B
EN50082-1/1992
EN60555-2/1987
Hinweise
• Aus ergonomischen Gründen wird empfohlen, die
Grundfarbe Blau nicht auf dunklem Untergrund zu
verwenden (schlechte Erkennbarkeit, Augenbelastung bei zu
geringem Zeichenkontrast).
• Aus ergonomischen Gründen (flimmern) sollten nur
Darstellungen bei Vertikalfrequenzen ab 70 Hz (ohne
Zeilensprung) verwendet werden.
• Die Konvergenz des Bildes kann sich auf Grund des
Magnetfeldes am Ort der Aufstellung aus der korrekten
Grundeinstellung verändern. Zur Korrektur empfiehlt es sich
deshalb, die Regler an der Frontseite für Konvergenz so
einzustellen, daß die getrennt sichtbaren Farblinien für Rot,
Grün und Blau bei z.B. der Darstellung eines Buchstabens zur
Deckung (Konvergenz) gelangen.
Siehe hierzu auch die Erklärungen zu Konvergenz.
NOTICE
This notice is applicable for USA/Canada only.
If shipped to USA/Canada, install only a UL LISTED/CSA
LABELLED power supply cord meeting the following
specifications:
SPECIFICATIONS
Plug TypeNema-Plug 5-15p
CordType SVT or SJT, minimum 3 × 18 AWG
LengthMaximum 15 feet
RatingMinimum 7 A, 125 V
NOTICE
Cette notice s’applique aux Etats-Unis et au Canada
uniquement.
Si cet appareil est exporté aux Etats-Unis ou au Canada,
utiliser le cordon d’alimentation portant la mention UL
LISTED/CSA LABELLED et remplissant les conditions
suivantes:
SPECIFICATIONS
Type de ficheFiche Nema 5-15 broches
CordonType SVT ou SJT, minimum 3 × 18 AWG
LongueurMaximum 15 pieds
TensionMinimum 7 A, 125 V
• Macintosh is a trademark licensed to Apple Computer, Inc., registered in
the U.S.A. and other countries.
• Windows® and MS-DOS are registered trademarks of Microsoft
Corporation in the United States and other countries.
• IBM PC/AT and VGA are registered trademarks of IBM Corporation of
the U.S.A.
• VESA is a trademark of Video Electronics Standard Association.
• ENERGY STAR is a U. S. registered mark.
• All other product names mentioned herein may be the trademarks or
registered trademarks of their respective companies.
• Furthermore, “™” and “®" are not mentioned in each case in this
manual.
I
3
Getting Started
Getting Started
Precautions
Installation
• Prevent internal heat build-up by allowing adequate air
circulation. Do not place the monitor on surfaces (rugs,
blankets, etc.) or near materials (curtains, draperies) that
may block the ventilation holes.
• Do not install the monitor near heat sources such as
radiators or air ducts, or in a place subject to direct
sunlight, excessive dust, mechanical vibration or shock.
• Do not place the monitor near equipment which generates
magnetism, such as a transformer or high voltage power
lines.
Handling the LCD screen
• Bright points of light (red, blue or green) may appear
on the LCD screen. This is not a malfunction. The LCD
screen is made with high-precision technology and
more than 99.99 % of the picture element is intact.
However, some of the picture element may not
appear or some of the picture element may appear
constantly.
• Do not leave the LCD screen facing the sun as it can
damage the LCD screen. Take care when you place the
monitor by a window.
• Do not push or scratch the LCD screen. Do not place a
heavy object on the LCD screen. This may cause the
screen to lose uniformity.
• If the monitor is used in a cold place, a residual image
may appear on the screen. This is not a malfunction.
When the monitor becomes warm, the screen returns to
normal.
• If a still picture is displayed for a long time, a residual
image may appear. The residual image will eventually
disappear.
• The screen and the cabinet become warm during
operation. This is not a malfunction.
Maintenance
• Clean the cabinet, panel and controls with a soft cloth
lightly moistened with a mild detergent solution. Do not
use any type of abrasive pad, scouring powder or solvent,
such as alcohol or benzine.
• Do not rub, touch, or tap the surface of the screen with
sharp or abrasive items such as a ballpoint pen or
screwdriver. This type of contact may result in a scratched
picture tube.
• Clean the screen with a soft cloth. If you use a glass
cleaning liquid, do not use any type of cleaner
containing an antistatic solution or similar additive as this
may scratch the screen’s coating.
Transportation
• When you transport this monitor, grip the bottom of the
screen firmly with both hands. If you drop the monitor,
you may be injured or the monitor may be damaged.
• When you transport this monitor for repair or shipment,
use the original carton and packing materials.
Warning on power connection
• Use an appropriate power cord for your local power
supply.
For the customers in the UK
If you use the monitor in the UK, please use the supplied
UK cable with the UK plug.
Examples of plug types
for 100 to 120 V AC for 200 to 240 V AC
The outlet should be installed near the equipment
and be easily accessible.
for 240 V AC only
Replacement of the fluorescent tube
A specially designed fluorescent tube is installed as the
lighting apparatus for this monitor. If the LCD screen
becomes dark, unstable or does not turn on, replace the
fluorescent tube with an new one. Consult your Sony dealer
when replacing the fluorescent tube.
4
Mounting on a wall or an arm
Ask a specialist to mount the monitor on a wall or an arm.
Do not mount the monitor yourself.
Disposal of the monitor
• Do not dispose of the monitor with general waste.
Do not include the monitor with household waste.
• The fluorescent tube includes mercury. Dispose of the
monitor in accordance with the regulations of your
local sanitation authority.
Identifying Parts and Controls
See the pages in parentheses for further details.
CPD-L150 is used for illustration purposes throughout this
manual.
Getting Started
Getting Started
Front
1
2
3
4
5
6
1u (power) switch and indicator (pages 8,
17)
Turns the monitor on or off.
The indicator lights up in green when the monitor is
turned on, and either flashes in green and orange or
lights up in orange when the monitor is in power
saving mode.
Rear
7External control connector
Inputs the external control signal of RS-232 format.
Consult your dealer for further information.
8DC IN connector (page 6)
Provides DC power to the monitor from the AC
adaptor.
7
8
EN
9
FDESI
2MENU (menu) button (pages 8, 11 – 15, 17)
Displays the MENU OSD (On-Screen Display).
3‹ (brightness) (ø ) button (pages 8 – 9, 11
– 15)
Adjusts the picture brightness.
Functions as the ø button when selecting menu items.
4> (contrast) (‡ ) button (pages 8 – 9, 11 –
15)
Adjusts the contrast.
Functions as the ‡ button when selecting menu items.
5+/– (adjust) buttons (pages 9, 11 – 15)
Adjusts the selected menu item.
6AUTO button (pages 8, 11)
After you have connected this monitor, press the AUTO
button to automatically adjust the picture to the
computer.
You also should press this button if the picture is not
centered or if it is fuzzy.
9RGB input connector (HD15) (page 6)
Inputs analog RGB video signals (0.714 Vp-p, positive)
and SYNC signals.
Use of the Tilt
Use the tilt feature to adjust the monitor to the desired angle
within 30° vertically.
To turn the monitor vertically, hold it at the bottom with
both hands as illustrated below.
30°
5
Getting Started
Setup
Before using this monitor, check that the following items are
included in your carton:
• LCD monitor (1)
• AC adaptor (1)
• Rear cover (1)
• Power cord (1)
• HD15 video signal cable (1)
• Macintosh adapter (1)
• Windows
• Macintosh Utility Disk (1)
• TCO’95 Eco-document (1)
• Warranty card (1)
• These operating instructions (1)
Monitor Information Disk/Utility Disk (1)
If your PC system is not compatible with DDC1 and
DDC2B
This monitor uses the No. 9 pin in the video signal connector for
DDC1 and DDC2B compatibility.
Some PC systems which are not compatible with either DDC1 or
DDC2B may not accept the No. 9 pin. If you are not sure whether
your PC system accepts the No. 9 pin or not, use the HD15 (Female)
- HD15 (Male without the No. 9 pin) adapter (not supplied). Make
sure the male side (without the No. 9 pin) is connected to the
computer.
Connecting to a Macintosh or compatible
computer
This monitor works with any IBM or compatible system
equipped with VGA or greater graphics capability.
Although this monitor works with other platforms running
at horizontal frequencies between 30 and 70 kHz, including
Macintosh and Power Macintosh systems, a cable adapter is
required. Please consult your dealer for advice on which
adapter is suitable for your needs. This monitor also can
receive the RGB signals of the PAL and NTSC systems.
Step 1: Connect the monitor to the
computer
With the computer switched off, connect the video signal
cable to the monitor using the supplied HD15 video signal
cable.
• If you are using an IBM PC/AT or compatible computer,
refer to the section below.
• If you are using a Macintosh or compatible computer,
refer to the following section, “Connecting to a Macintosh
or compatible computer.”
Connecting to an IBM PC/AT or compatible
computer
to HD15
Macintosh or
compatible
computer
to monitor output
Macintosh adapter
(supplied)
HD15 video
signal cable
(supplied)
About the supplied Macintosh adapter
The supplied Macintosh adapter is compatible with Macintosh LC,
Performa, Quadra and Power Macintosh series computers.
Macintosh II series and some older versions of Power Book models
may need an adapter with micro switches (not supplied).
Step 2: Connect the power cord
With the monitor switched off, connect one end of the DC
power cord to the monitor and the other end to a power
outlet.
IBM PC/AT or
compatible
computer
6
to HD15
to monitor output
HD15 video
signal cable
(supplied)
to a power outlet
Power cord
(supplied)
AC adaptor
(supplied)
to DC IN
Getting Started
Getting Started
Step 3: Attaching the rear cover
After connecting the computer and power cord, attach the
supplied rear cover.
Make sure that you keep the screen upright when attaching
the rear cover.
1 Hook the computer cable and power cord.
2 Insert the tabs on the back of the rear cover into the
catches, and then push down.
Step 4: Turning on the monitor and
computer
First turn on the monitor, then turn on the computer.
The installation of your monitor is complete.
Note
If “OUT OF SCAN RANGE” or “NO INPUT SIGNAL” appears on
the screen, see “Warning Messages” on page 18.
For customers using Windows 95/98
To maximize the potential of your monitor, install the new model
information file from the supplied Windows Monitor Information
Disk/Utility Disk onto your PC.
This monitor complies with the “VESA DDC” Plug & Play standard.
If your PC/graphics board complies with DDC, select “Plug & Play
Monitor (VESA DDC)” or this monitor’s model name as the
monitor type in the “Control Panel” of Windows 95/98. If your
PC/graphics board has difficulty communicating with this monitor,
load the Windows Monitor Information Disk/Utility Disk and
select this monitor’s model name as the monitor type.
For customers using Windows NT4.0
Monitor setup in Windows NT4.0 is different from Windows 95/98
and does not involve the selection of monitor type. Refer to the
Windows NT4.0 instruction manual for further details on adjusting
the resolution, refresh rate, and number of colors.
EN
FD
3 Turn the screw to fasten the rear cover.
ESI
Unlocked
Locked
7
Getting Started
MENU
Automatically Adjusting the
If the picture is flickering or fuzzy, press the AUTO button.
The monitor is automatically adjusted to match the signal
from the connected computer.
Further fine adjustments may be needed with some
computers. In this case, manually adjust the monitor by
referring to “Customizing Your Monitor” on page 9.
1 Turn on the monitor.
2 Turn on the computer.
3 Press the AUTO button.
The picture is adjusted to fit the center of the screen.
AUTO
Notes
• This function is intended for use with a computer running
Windows or similar graphic user interface software that
provides a full-screen picture. It may not work properly if the
background color is dark or if the input picture does not fill the
screen to the edges (such as an MS-DOS prompt).
• The screen may go blank for a few seconds while performing the
auto-sizing function. This is not a malfunction.
If the picture is flickering or fuzzy even after you
press the AUTO button
Adjust the Pitch and Phase manually (page 11).
Selecting the On-Screen Display
Language
You can select the OSD language from English, French,
German, Spanish, Italian, and Japanese.
1 Press the MENU button.
The MENU OSD appears.
MENU
MENU
EXIT
PHASE
PITCH
CENTER
ZOOM
COLOR
LANGUAGE
OPTION
2 Press the ø /‡ buttons to select LANGUAGE, and
press the MENU button.
The LANGUAGE OSD appears.
LANGUAGE
ENGLISH
FRANÇAIS
DEUTSCH
ESPAÑOL
ITALIANO
œ{Œ
3 Press the ø /‡ buttons to select the desired language,
and press the MENU button.
The MENU OSD of the selected language appears.
MENU
MENU
EXIT
PHASE
PITCH
CENTER
ZOOM
COLOR
LANGUAGE
OPTION
OK
OK
MENU
MENU
8
The OSD automatically disappears after about 30 seconds.
To close the OSD, press the MENU button again.
Customizing Your Monitor
Getting Started
Customizing Your Monitor
Before adjusting
Connect the monitor and the computer, and turn them
on.
Wait for at least 30 minutes before making adjustments
for the best result.
Adjusting the Picture Brightness
Once the brightness is adjusted, it will be stored in memory
for all input signals received.
1 Press the ‹ (brightness) ø button.
The BRIGHTNESS OSD appears.
BRIGHTNESS
26
48. 4kHz / 60Hz
Horizontal
Frequency*
2 Press the +/– buttons.
+ . . . for more brightness
– . . . for less brightness
Vertical
Frequency*
Adjusting the Contrast
Once the contrast is adjusted, it will be stored in memory for
all input signals received.
1 Press the > (contrast) ‡ button.
The CONTRAST OSD appears.
CONTRAST
26
48. 4kHz / 60Hz
Horizontal
Frequency*
2 Press the +/– buttons.
+. . . for more contrast
–. . . for less contrast
The OSD automatically disappears after about 3 seconds.
* The horizontal and vertical frequencies for the received input
signal appear in the CONTRAST OSD.
Vertical
Frequency*
EN
FDESI
The OSD automatically disappears after about 3 seconds.
* The horizontal and vertical frequencies for the received input
signal appear in the BRIGHTNESS OSD.
If the screen is too bright when using the monitor in a
dark room
Decrease the BACKLIGHT (page 14).
9
Customizing Your Monitor
Introducing the On-Screen
Display System
Most adjustments are made using the MENU OSD.
To change the on-screen display language, see “Selecting
the On-screen Display Language” (page 8).
MENU
EXIT
PHASE
PITCH
CENTER
ZOOM
COLOR
LANGUAGE
OPTION
EXIT
Closes the MENU OSD.
PHASE
Displays the PHASE OSD. Adjust the phase when the
characters or pictures appear fuzzy throughout the entire
screen. Adjust the phase after adjusting the pitch.
PITCH
Displays the PITCH OSD. Adjust the pitch when the
characters or pictures are not clear at some parts of the
screen.
CENTER
Displays the CENTER OSD for adjusting the centering of
the picture.
ZOOM
Displays the ZOOM OSD for selecting the picture’s display
mode. Select FULL MODE to display the picture using the
entire screen, or select REAL MODE to display the picture at
its actual resolution.
OK
MENU
Using the Utility Disk
The supplied Utility Disk contains test patterns to be used
for Pitch, Phase, and Centering adjustments.
These test patterns will help you confirm that your
adjustments are correct.
Pitch adjustment
Adjust the Pitch if vertical stripes appear on the screen, or a
part of the screen flickers or blurs.
Adjust the screen so that the bold, vertical lines of the test
pattern disappear.
Phase adjustment
Adjust the Phase if the entire screen flickers or blurs, or if
horizontal stripes are observed on the screen.
Adjust the screen until the horizontal stripes are at a
minimum.
Centering adjustment
Adjust the Centering if the picture is not centered.
Move the picture up, down, left, or right until the red frame
at the perimeter of the test pattern disappears.
Using the test pattern
1 Set ZOOM to REAL MODE (page 12).
2 Load the supplied Utility Disk and display the test
pattern.
Use the appropriate disk for your computer.
For Windows 95/98
Windows Monitor Information Disk/Utility Disk
For Macintosh
Macintosh Utility Disk
3 Select the pitch, phase, or centering from the
monitor’s MENU OSD, and adjust the screen while
viewing the test pattern (pages 11, 12).
COLOR
Displays the COLOR OSD for adjusting the color
temperature.
LANGUAGE
Displays the LANGUAGE OSD for selecting the on-screen
display language.
OPTION
Displays the OPTION OSD. You can adjust settings such as
the backlight, OSD position, power saving delay time and
control lock.
10
4 When you have finished, click [END] on the screen to
turn off the test pattern.
