Specifications and Main Features
- Picture Tube
- 0.25 mm aperture is applied to the tenår: distribution grid
- The size of the screen is 17 in” W
- Deflection Frequency
- Horizontal: 30-80 KHz
- Vertical: 50-120 Hz
- Viewable Picture Size
- 327 x 241 mm approx. (127/8 x 91/2 inches)
- 15.9” viewing image 16 x 16 7/8 – 17 7/8
- Logical Resolution
- Maximum: 1280 Horizontal dots
- Maximum 1024 lines Vertical
- Physical Resolution
- Maximum: 1280 Horizontal dots
- Maximum 1024 lines Vertical
- Standardized Image Area
- 312 x 234 mm approx (12 3/8” x 9 1/4’ench)
- Electrical Specs
- Input AC Voltage/ Current: 100 to 240 V , 50-60 Hz , 2-1A
- Mass: Approx 19 kg(41 lb-14nz)
- Size
- 406 x 426.5 x 451 mm (w/h/d) (16”x16’7/8”x17’7/8”)
- Power Saving Feature
- Follows International ENERGY STAR Program and TCO92 regulations.
Frequently Asked Questions
- How much logical resolution does the CPD-200SF/200SFT have to Its maximum standard?
- The logical maximum is 1280 x 1024.
- What are the electrical standards conformity requirements for this monitor?
- The electrical inputs of this monitor must not operate below 100 volts nor above 240 volts, must be rated at 50-60 Hz and must have the current of 2-1A at its peak usage.
- Could you tell us the weight of the CPD-200SF/200SFT?
- This monitor is approximately 19 kg heavy which is the equivalent of 41 lb-14 oz to such monitors.
- How large is the, Viewable display size of the said monitor?
- The viewable display size of this monitor is recorded at approximately 327 x 241 mm (127/8 x 9 1/2 inches).
- I wanted to ask if this monitor has a power save mode?
- Yes, likewise this monitor is compliant with the guidelines set forth by the international energy star program and can operate with lower power during compatible computer use.
