Page 1
Camera Control Unit
CCU-TX7P
PAL
Page 2
T
he Sony CCU-TX7P is a compact camera
control unit designed for professional use
as the core of the Sony triax camera
control system for DXC-D30P/D30WSP and
DXC-637P Video Cameras. The CCU-TX7P
has numerous functions to assure operational
convenience and system versatility, as well as
the general benefits of the triax system which
include control over long distances, particularly
important in large systems, and high camera
mobility when using lightweight triax cables.
T
o suit varying applications, the CCU-TX7P runs on AC or DC (12 volts) power without the need for
an optional unit, and has a compact body (half 19-inch rack-mount size).The unit provides a
variety of video output signals: SDI, composite, Y/C, component and R/G/B, and supports
teleprompter systems and major intercom systems such as 2-wire, 4-wire, Clearcom and RTS. To meet
different needs, the CCU-TX7P also has two inputs for return video and a teleprompter monitor input.
I
t is easy to set up a triax camera control
system that suits varying applications by
combining the CCU-TX7P with the Sony
COU-TX7 Camera Operation Unit, RCP-TX7
Remote Control Panel and CA-TX7P Camera
Adaptor. This provides benefits such as quick
camera set-up and one-person camera
operation of multiple cameras without
requiring specialist skills.
F
eature-rich and cost-effective,
the CCU-TX7P broadens the range of
video camera applications, and opens
up a new world of opportunity to the video
professional.
2
Page 3
3
High Quality Triax
Transmission
The CCU-TX7P also employs analogue
component video transmission, with a
9MHz bandwidth for the luminance (Y)
signal and 4.5MHz for the colour
difference signals (R-Y/B-Y) .This
assures high quality and the provision of
various video outputs from the CCU.
Long Distance Transmission
Cable length can be extended up to a
maximum of 1500m via ø14.5mm triax
cable (with return video) (Fujikura),
1125m via ø13.2mm cable (Belden) or
750m via ø8.5mm cable (Fujikura,
Belden). Teleprompter video channel
can also be transmitted over a limited
length of cable.
High Speed High Quality Serial
Data Transmission
Data at up to a resolution of 10-bits can
be transmitted with high speed via serial
data transmission using a triax cable.
This provides the benefits of smooth,
real-time control with instant tactile
response from remote control devices.
AC/DC Operation
The CCU-TX7P is designed to operate
on not only AC but also DC power with
both an AC inlet and, for DC 12V (10.5V
to 17V), a DC inlet. DC operation
greatly expands system flexibility in
outside broadcast applications.
Digital Signal Outputs
The CCU-TX7P provides two SDI
outputs when the optional DXBK-701
SDI Output Board is installed. It can
MAIN FEATURES
MAIN FEATURES
transfer high quality digital signals with
just one cable to SDI ready units.Using
the SDI interface, a total digital DXC
system becomes a reality.
Note* The CCU-TX7P (Serial No. less than 41000)
needs some modification to accommodate the
SDI outputs. Please contact your nearest
Sony office.
Other Signal Outputs
The CCU-TX7P provides two composite
outputs, and two component output
selectable from Y/R-Y/B-Y, R/G/B and
Y/C. The CCU-TX7 also has a 4-pin
WF MODE (waveform monitor mode)
connector for flickerless parade
monitoring of signals, in addition to a
WF output and a PIX (picture monitor)
output.
Two Inputs for Return Video
The CCU-TX7P has two RETURN
VIDEO inputs (BNC type) and therefore
accept return video signals (VBS colour)
from two different systems. Two
channels of return video can be selected
from the Sony CA-TX7P Camera
Adaptor.
Colour Teleprompter Facility
The CCU-TX7P can be used with colour
teleprompter facilities. Since reverse
signal transmission (CA -> CCU) is
supported using a teleprompter video
channel in a triax cable, it is also
possible to transmit video signals other
than those for teleprompter from CA to
CCU, if necessary.
* For detailed information, please contact your
nearest Sony office.
Page 4
4
Flexible Intercom System
The CCU-TX7P is equipped with a
programme audio channel and a
bi-directional intercom channel.
Programme audio sound from an
external audio system can be fed to the
camera head. This can be mixed with
intercom sound; major intercom systems
(Four-wire/Two-wire/RTS/Clearcom) can
be interfaced via connectors on the rear
panel of the CCU-TX7P. The camera
control unit accepts two-channel input
from the external intercom system, and
communication can be initiated from the
CCU-TX7P, or the camera adaptor
(CA-TX7P) or the external intercom
system (CH-1 or CH-2).
Programme Microphone System
The CCU-TX7P and CA-TX7P are
equipped with a two-channel microphone
system. Two XLR connectors on the
CA-TX7P provide balanced audio CH-1
and CH-2 inputs with microphone
phantom power available for an external
microphone. The MIC input gain of each
channel can be controlled within a range
of ±12dB in 16 steps by control volumes
on the internal board of the CCU-TX7P.
RS-232C Port
The CCU-TX7P is equipped with an
RS-232C port to link several CCU-TX7P
units for a multiple camera control
system, or to connect an external
personal computer.
Coaxial Control Capability
The CCU-TX7P is equipped with a
coaxial input. This enables each camera
to operate over conventional coaxial
cable instead of a triax cable, with power
supplied locally to the camera.
Compact Size
The CCU-TX7P is half a 19-inch rack
size wide and 4 units (4U) high. With the
Sony RMM-TXC7 Rack Mount Kit, two
CCU-TX7P units or one unit with a
waveform monitor can be mounted into a
standard 19-inch rack.
MAIN FEATURES
MAIN FEATURES
* For detailed information, please contact your
nearest Sony office.
DXBK-701 SDI Output Board
Page 5
5
Rotary Triax Connector
The Sony CA-TX7P Triax Camera
Adaptor is equipped with a rotary (70˚)
triax connector for easy cabling.
76-pin/50-pin Interface
The CA-TX7P is equipped with both
Pro 76-pin and Pro 50-pin interfaces,
which facilitate connections to DXC-D30P/
D30WSP and DXC-637P Video Cameras.
Viewfinder Box Cursor
Indication
The CA-TX7P can indicate a box cursor
on the screen of any DXC-D30P/
D30WSP viewfinder such as the
DXF-701WSCE and DXF-51. Cursor
position (H, V) and size (width, height)
can all be adjusted using control volumes
on the rear panel of the
CA-TX7P. Two kinds of cursors can be
stored and retrieved.
CA-TX7P
PERIPHERALS
PERIPHERALS
* This function is not available with the DXC-637P.
Pro 76-pin DigitalPro 50-pin
Page 6
6
As Remote Control Panel
●Full Camera Control
The Sony RCP-TX7 provides full control
functions as a remote camera control
panel for the CCU-TX7P. It covers the
complete range of control functions, from
basic camera control to more
sophisticated operation. It provides
camera set-up control using convenient
scene files, as well as basic control and
paint operation control. For engineering
and service personnel, the RCP-TX7also
provides comprehensive camera set-up
functions. The RCP-TX7 is a quarter the
width of a 19-inch rack so that four
RCP-TX7 units can be installed into a
standard 19-inch rack using the Sony
RMM-TXR7 Rack Mount Kit.
●Scene File System
The RCP-TX7 can store up to 16 scene
files. All parameters, both for camera
operation and set-up, can be adjusted
and stored in each scene file. The stored
scene file most suitable for each shooting
situation can be instantly recalled.
●Links in Control of Iris and Master
Black
In a multi-camera system, the control of
Iris and Master Black can be linked over
multiple RCP-TX7 panels. Simply press
the “IRIS/M.BLACK LINK”button on each
required RCP-TX7. When controlling Iris
and Master Black, the values of all the
linked RCP-TX7 units can be overridden
by one RCP-TX7. Any one of the units
can be set up as the master device.
●Colour Matching Capability
The RCP-TX7 has a useful colour
matching function. When using multiple
cameras and RCP-TX7 units, once one
RCP-TX7 has been set up, the master
data can be copied to the other RCPTX7 units. To do this, the user must first
set one RCP-TX7 as the master and the
others as subsidiary units.
RCP-TX7
Page 7
7
PERIPHERALS
PERIPHERALS
As Standalone Camera
Controller
Directly connected to the Sony
DXC-D30P/ D30WSP Video Camera
through a 10-pin remote connector, the
RCP-TX7 can be used as a standalone
remote control unit offering the same
functionality as the RM-M7G.
(This is only possible
with the
DXC-D30P/
D30WSP.)
Basic Camera Control with
COU-TX7
The Sony COU-TX7 Camera Operation
Unit can be attached to form a part of the
front panel of the CCU-TX7P to provide
basic control of camera operation and
painting. This is useful when using the
CCU-TX7P in limited space, such as in
field production vehicles.
●Convenient Liquid Crystal Display
The RCP-TX7 has an LCD (Liquid
Crystal Display) on the control panel.
This LCD shows menu status information
on the current adjustment. Function
status such as Detail Level, Gamma,
Knee, White Balance and Black (Flare)
Balance can also be displayed on the
LCD by using an INDICATION button.
The LCD also displays troubleshooting
hints when an operational difficulty arises
from use of the RCP-TX7 controls.
COU-TX7
DXF-51(5-inch)
Monochrome Viewfinder
DXC-D30P/
D30WSP or
DXC-637P
Camera Head
DXF-701WSCE
(*)
or
DXF-601CE
Viewfinder
(*)
DXF-701WSCE can be
used only with DXC-D30P/D30WSP.
WRR-810A + DC-WL800(DC Pack Unit)
Wireless Microphone Receiver
Zoom Lens
CA-TX7P
Camera Adaptor
Triax Cable
Intercom
(Headset)
CCU-TX7P
Camera Control Unit
Waveform
Monitor
Vectorscope
Picture Monitor
SDI Output
(w/DXBK-701)
AC
DC 12V
COU-TX7
Camera Operation
Unit
RCP-TX7
Remote Control Panel
CCA-7
(10-pin/10-pin)
(Max.50m)
Either the COU-TX7 or the
RCP-TX7 is used as a
control panel of the CCU-TX7P.
Intercom
(System & Headset)
SYSTEM CONFIGURATION
SYSTEM CONFIGURATION
Page 8
Distributed by
MK4126V2OHB99APR
Printed in Japan
©1999 Sony Corporation
163 (6 1/2)
370 (14
5
/8)
280 (11
1
/8)
230 (9
1
/8)70
15
370 (14
5
/8)
45
55
122 (4
7
/8)
26
164 (6
1
/2)5
9.5 (3/8)200 (7 7/8)
140 (5
5
/8)830
354 (14)
404 (16)
29
60
70
10
424 (16 3/4)
29
482 (19)
177 (7) 380 (15)
482 (19)
23.3
436 (17
1
/4)
49.5
155 (6
1
/8)
146 (5
3
/4)
80 (3 1/4)
105 (4
1
/4)
42.7
22.7
10
300 (11
7
/8)
15
330 (13)
100
261.2 (10
3
/8)
14
316 (12
1
/2)
27.5
70
50
221 (8
3
/4)
220 (8 3/4)
CCU-TX7P CA-TX7P
©1999 Sony Corporation. All rights reserved. Reproduction in whole or in part without Sony’s written
permission is prohibited.
Features and specifications are subject to change without notice.
Sony is a trademark of Sony Corporation.
The Quality Management systems in design of the CCU-TX7P, CA-TX7P, RCP-TX7, COU-TX7, RMM-TXC7
and RMM-TXR7 have been assessed and registered as meeting the requirements of ISO 9001.
SPECIFICATIONS
SPECIFICATIONS
3. RCP-TX7
Power requirements 10 to 17V (supplied from
camera or CCU)
Power consumption 4.0W
Operating temperature -10˚C to 45˚C (14˚F to 113˚F)
Storage temperature -20˚C to 55˚C (-4˚F to 131˚F)
Weight Approx. 1.5kg (3 lb 5 oz)
Dimensions (W x H x D) 100 x 330 x 70mm
(4 x 13 x 2 7/8 inches)
Cable length 50m max. (with CCA-7 cable)
Supplied accessory CCA-7-5 Connecting Cable (5m)
Number plate (1set)
Screws and washers x 2
Operation manual x 1
4. COU-TX7
Weight Approx. 330g (12.6 oz)
Dimensions (W x H x D) 105 x 155 x 43mm
(4 1/4 x 6 1/8 x 1 3/4 inches)
Supplied accessory Operation manual x 1
5. RMM-TXC7
Weight Approx. 3.7 kg (8 lb 3 oz)
Dimensions (W x H x D) 482 x 177 x 380mm
(19 1/8 x 7 x 15 inches)
Supplied accessories Installation manual x 1
Blank panel x 1
6. RMM-TXR7
Weight Approx. 2.7 kg (5 lb 12 oz)
Dimensions (W x H x D) 482 x 75 x 354mm
(19 x 3 x 14 inches)
Supplied accessories Installation manual x 1
Blank panel x 2
7. DXBK-701
Power Consumption 4.5 W
Weight 330 g (11.6 oz)
Dimensions (W x H x D) 17 x 148 x 277 mm
(11/16 x 5 7/8 x 11 inches)
1. CCU-TX7P
Input connectors GEN LOCK: BNC type, loopthrough,
VBS/BS, 1.0Vp-p, 75ohms
RETURN (1,2): BNC type, loopthrough,
VBS, 1.0 Vp-p, 75ohms
PROMPT (prompter): BNC type, loopthrough,
VBS, 1.0 Vp-p, 75ohms
PGM IN: XLR 3-pin x 1
Output connectors VBS (1,2): BNC type, VBS, 1.0 Vp-p, 75ohms
(*1)Y/R-Y/B-Y (1,2): BNC type,
Y:1.0Vp-p, 75ohms
R-Y/B-Y:525mVp-p, 75ohms
(*1)R/G/B (1,2): BNC type,
700mVp-p, 75ohms
(*1)Y/C (1,2): BNC type,
Y:1.0Vp-p, 75ohms
C: 300mVp-p, 75ohms
(*2)SDI (1,2): Conform to serial digital interfase
(270Mbs), 0.8 Vp-p, 75Ω
SYNC: BNC type,
VBS, 0.3 Vp-p, 75ohms, negative
PIX (picture monitor): BNC type,
1.0 Vp-p, 75ohms
WF (waveform monitor): BNC type,
700 mVp-p, 75ohms
(Encoded output: 1.0 Vp-p, 75ohms)
WF MODE: 4-pin x 1
MIC OUT (CH-1/2): XLR 3-pin x 2,
0dBu/-20dBu balanced, 2 channels
Camera control CAMERA: Triax (Fischer type) x 1
input/output COAX: BNC type x 1
connectors REMOTE: 10-pin
INTERCOM/TALLY: D-sub 25-pin x 1
4W/2W
TALLY: 24V DC, TTL level or
contact selectable
INTERCOM (Front): XLR 5-pin x 1
RTS: XLR 3-pin x 1
RS232C: D-sub 25-pin x 2
Power requirements AC 220 to 240V or DC 10.5 to 17.0V
Power consumption 95W max.
Cable length 1500m max. (ø14.5mm)
Operating temperature 5˚C to 40˚C (41˚F to 104˚F)
Storage temperature -20˚C to 55˚C (-4˚F to 131˚F)
Weight Approx. 8.45 kg (18 lb 10oz)
Dimensions (W x H x D) 218 x 169 x 415mm (8 5/8 x 6 3/4 x 16 3/8 inches)
Supplied accessories AC power cord x 1
Plug holder for AC power cord x 1
Number plate (1 set)
Operation manual x 1
(*)Note: 1) These CCU output signals can be selected to be R/G/B or Y/R-Y/B-Y or Y/C.
2) Using optional DXBK-701 (SDI output board)
2. CA-TX7P
Input/output connectors CCU: Triax (Fischer type) x 1
Pro 76P Digital or
Pro 50P switchable
CAMERA INTERFACE: XLR 3-pin x 2, 600ohms, balanced
MIC IN (CH-1/2)
Input level : Mic in: -60dB
: Line in: -20dB
DC IN: XLR 4-pin x 1,10.5V to 17V
DC OUT: 4-pin x 1, 10.5V to 17V, Max 12W
PROMPTER OUT: BNC type x 1, 1.0Vp-p, 75ohms
RETURN OUT: BNC type x 1, 1.0Vp-p, 75ohms
INTERCOM/PROGRAMME: XLR 5-pin x 1 (for Headset)
Input level:-60dBs (dynamic)
Output level:∞ to 12dBs
DATA OUT: 10-pin x 1
DC 0 to 5V (analogue) x 4
DC 0 or 5V (digital) x 2
Power requirements DC 120V (from Triax connector) or
DC 12V (10.5 to 17.0V) (from DC IN connector)
Power consumption
Operating temperature -10˚C to 45˚C (14˚F to 113˚F)
Storage temperature -20˚C to 55˚C (-4˚F to 131˚F)
Operating humidity 20% to 90%
Weight Approx. 2.7 kg (5 lb 15oz)
Dimensions (W x H x D) 226 x 221 x 131mm (9 x 8 3/4 x 5 1/4 inches)
Supplied accessory Operation manual x 1
DC 120V DC 12V
(Supplied from triax connector) (Supplied from DC IN connector)
CA-TX7P Total CA-TX7P Total
internal only internal only
CA-TX7P only 10.5W 10.5W 7.5W 7.5W
w/DXC-D30P,
DXF-701CE
11.2W 26W 7.5W 22.3W
w/DXC-D30P,
DXF-51
12.3W 35W 7.5W 30.2W
unit: mm (inch)
Loading...
