Sony BDP-SX1000 User Manual
4-264-055-13(1)
Portable Blu-ray
Disc™ / DVD Player
Operating Instructions
Preparations
Playback
Settings and Adjustments
Additional Information
BDP-SX1000
WARNING
To reduce the risk of fire or electric
shock, do not expose this apparatus
to rain or moisture.
To avoid electrical shock, do not
open the cabinet. Refer serv icing to
qualified personnel only.
The AC power cord must be
changed only at a qualified service
shop.
Batteries or batteries installed
apparatus shall not be exposed to
excessive heat such as sunshine,
fire or the like.
CAUTION
The use of optical instruments with
this product will increase eye
hazard. As the laser beam used in
this Blu-ray Disc/DVD player is
harmful to eyes, do not attempt to
disassemble the cabinet.
Refer servicing to qualified
personnel only.
This label is located on the bottom
of the unit.
This symbol is
intended to alert the
user to the presence
of uninsulated
within the product’s enclosure that
may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
maintenance (servicing)
instructions in the literature
accompanying the appliance.
“dangerous voltage”
This symbol is
intended to alert the
user to the presence
of important
operating and
Precautions
• To prevent fire or shock hazard,
do not place objects filled with
liquids, such as vases, on the
apparatus.
• Install this unit so that the AC
power cord can be unplugged
from the wall socket
immediately in the event of
trouble.
• The player is not disconnected
from the AC power source as
long as it is connected to the wall
outlet, even if the player itself
has been turned off.
FCC WARNING
You are cautioned that any
changes or modifications not
expressly approved in this
manual could void your
authority to operate this
equipment.
The shielded Interface cable
(LAN cable) must be used with
the equipment in order to
comply with the limits for a
digital device pursuant to
Subpart B of Part 15 of FCC
Rules.
b
This equipment has been tested
and found to comply with the
limits for a Class B digital
device, pursuant to Part 15 of t he
FCC Rules. These limits are
designed to provide reasonable
protection against harmful
interference in a residential
installation. This equipment
generates, uses, and can radiate
radio frequency energy and, if
not installed and used in
accordance with the instructions,
may cause harmful interference
to radio communications.
However, there is no guarantee
that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or
television reception, which can
be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of
the following measures:
– Reorient or relocate the
receiving antenna.
– Increase the separation
between the equipment and
receiver.
– Connect the equipment into an
outlet on a circuit different
from that to which the receiver
is connected.
– Consult the dealer or an
experienced radio/TV
technician for help.
Owner’s Record
The model and serial numbers are
located at the bottom of the unit.
Record the serial number in the
space provided below. Refer to
them whenever you call upon your
Sony dealer regarding this product.
Model No.______________
Serial No.______________
If this product is not working
properly, please call 1-866-909-
7669.
2
Important Safety
Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near
water.
6) Clean only with dry cloth.
7) Do not block any ventilation
openings. Install in accordance
with the manufacturer’s
instructions.
8) Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety
purpose of the polarized or
grounding-type plug. A
polarized plug has two blades
with one wider than the other.
A grounding type plug has two
blades and a third grounding
prong. The wide blade or the
third prong are provided for
your safety. If the provided
plug does not fit into your
outlet, consult an electrician for
replacement of the obsolete
outlet.
10)Protect the power cord from
being walked on or pinched
particularly at plugs,
convenience receptacles, and
the point where they exit from
the apparatus.
11)Only use attachments/
accessories specified by the
manufacturer.
12)Use only with the cart, stand,
tripod, bracket, or table
specified by the manufacturer,
or sold with the apparatus.
When a cart is used, use caution
when moving the cart/
apparatus combination to avoid
injury from tip-over.
14)Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus
has been damaged in any way,
such as power-supply cord or
plug is damaged, liquid has
been spilled or objects have
fallen into the apparatus, the
apparatus has been exposed to
rain or moisture, does not
operate normally, or has been
dropped.
Do not take apart or remodel the
player. Doing so can result in
electric shock. Consult your
nearest Sony dealer or Sony
Service Center for exchange of
rechargeable batteries, internal
checks or repair.
Notes About the Discs
• To keep the disc clean, handle
the disc by its edge. Do not
touch the surface.
Dust, fingerprints, or scratches
on the disc may cause it to
malfunction.
• Do not expose the disc to
direct sunlight or heat sources
such as hot air ducts, or leave it
in a car parked in direct
sunlight as the temperature
may rise considerably inside
the car.
• After playing, store the disc in
its case.
• Clean the disc with a cleaning
cloth. Wipe the disc from the
center out.
• Do not use solvents such as
benzine, thinner,
commercially available disc/
lens cleaners, or anti-static
spray intended for vinyl LPs.
• If you have printed the disc’s
label, dry the label before
playing.
• Do not use the following discs.
– A lens cleaning disc.
– A disc that has a non-
standard shape (e.g., card,
heart).
– A disc with a label or sticker
on it.
– A disc that has cellophane
tape or sticker adhesive on it.
• Do not resurface the playing
side of a disc to remove
surface scratches.
13)Unplug this apparatus during
lightning storms or when
unused for long periods of
time.
3
Precautions
Road safety
Do not use the monitor unit and
headphones while driving,
cycling, or operating any
motorized vehicle. Doing so
may create a traffic hazard and is
illegal in some areas. It can also
be potentially dangerous to play
your headsets at high volume
while walking, especially at
pedestrian crossings. You
should exercise extreme caution
or discontinue use in potentially
hazardous situations.
On safety
Should any solid object or liquid
fall into the cabinet, unplug the
player and have it checked by
qualified personnel before
operating it any further.
On power sources
• If you are not going to use the
player for a long time, be sure
to disconnect the player from
the wall outlet. To disconnect
the AC power cord, grasp the
plug itself; never pull the cord.
• Do not touch the AC power
cord or the AC adaptor with
wet hands. Doing so may
cause shock hazard.
• Use a commercially available
AC plug adaptor, if necessary,
depending on the design of the
wall outlet.
Wall
outlet
AC power cord
(supplied)
On temperature increases
Heat may build up inside the
player during charging or if it is
being used for a long time. This
is not a malfunction.
On placement
• Do not place the player in a
confined space such as a
bookshelf or similar unit.
• Do not cover the ventilation of
the player with newspapers,
tablecloths, curtains, etc. And
do not place the player on a
soft surface, such as a rug.
• Do not place the player and
adaptors in a location near heat
sources, or in a place subject to
direct sunlight, excess ive dust,
sand, moisture, rain, or
mechanical shock, or in a car
with its windows closed.
• Do not place the player in an
inclined position. It is
designed to be operated in a
horizontal position only.
• Keep the player and discs
away from equipment with
strong magnet, such as
microwave ovens, or large
loudspeakers.
• Do not drop or apply strong
shock.
Do not place heavy objects on
the player and accessories.
On operation
• If the player is brought directly
from a cold to a warm location,
or is placed in a very damp
room, moisture may condense
on the lenses inside the player.
Should this occur, the player
may not operate properly. In
this case, remove the disc and
leave the player for about half
an hour until the moisture
evaporates. Wipe off moisture
attached to the LCD surface
with tissue etc. Turn on the
power again later.
• Keep the lens on the player
clean and do not touch it.
Touching the lens may
damage the lens and cause the
player to malfunction. Leave
the disc lid closed except when
you insert or remove discs.
• Do not use the player in an
area subject to excessive dust
or cigarette smoke. Dust buildup or cigarette smoke residue
on internal components such
as the lens may cause the
player to malfunction.
On Liquid Crystal Display
• Although manufactured with
high precision technology, the
LCD may occasionally display
dots of various colors. That is
not a malfunction.
• Do not place or drop any
object onto the LCD surface.
Also, do not apply pressure
from hands or elbows.
• Do not damage the LCD
surface with a sharp edged
tool.
AC plug adaptor
(not supplied)
• Do not connect the AC power
cord to a traveler’s electric
transformer, which may
generate heat and cause a
malfunction.
4
On rechargeable battery
• Because of the battery’s
limited life, its capacity
gradually deteriorates over
time and repeated use.
Exchange a new one for the
old one when the battery holds
about only half the normal
period.
• To prevent battery
deterioration, charge the
battery at least once every half
a year or every year.
• Certain co untries may r egulate
disposal of the battery used to
power this product. Please
consult with your local
authority.
On AC adaptor and car
battery adaptor
• Use the supplied adaptors for
the player, as other adaptors
may cause a malfunction.
• Do not disassemble or reverseengineer.
• Do not touch the metal parts,
as it may cause a short and
damage the adaptors,
especially if touched by other
metal objects.
On adjusting volume
Do not turn up the volume while
listening to a section with very
low level inputs or no audio
signals. If you do, the speakers
may be damaged when a peak
level section is played.
On headphones
• Preventing hearing damage:
Avoid using headphones at
high volumes. Hearing e xperts
advise against continuous,
loud, and extended play. If you
experience a ringing in your
ears, reduce the volume or
discontinue use.
• Showing consideration for
others: Keep the volume at a
moderate level . This will allow
you to hear external sounds
and still be considerate to the
people around you.
On cleaning
• Clean the cabinet, panel, and
controls with a soft cloth
slightly moistened with a mild
detergent solution. Do not use
any type of abrasive pad,
scouring powder or solvent
such as alcohol or benzine.
• Wipe the LCD surface with the
soft dry cloth lightly. To
prevent dirt buildup, wipe it
frequently.
Do not wipe the LCD surface
with a wet cloth. If water
enters, a malfunction may
result.
• If picture/sound is distorted,
the lens may be covered with
dust. In this case, use a
commercially-available
blower brush for camera
lenses to clean the lens.
Avoid touching the lens
directly during cleaning.
On cleaning discs, disc/
lens cleaners
Do not use cleaning discs or
disc/lens cleaners (including wet
or spray types). These may cause
the apparatus to malfunction.
On replacement of parts
In the events that this player is
repaired, repaired parts may be
collected for reuse or recycling
purposes.
On connecting to the HDMI
OUT jack
Observe the following as
improper handling may damage
the HDMI OUT jack and the
connector.
• Carefully align the HDMI
OUT jack on the right of the
player and the HDMI
connector by checking their
shapes. Make sure the
connector is not upside down
or tilted.
• Be sure to disconnect the
HDMI cable when moving the
player.
• Hold the HDMI connector
straight when connecting or
disconnecting the HDMI
cable. Do not twist or force the
HDMI connector into the
HDMI OUT jack.
,continued
5
IMPORTANT NOTICE
Caution: This player is
capable of holding a still
video image or on-screen
display image on your
television screen
indefinitely. If you leave the
still video image or onscreen display image
displayed on your TV for an
extended period of time you
risk permanent damage to
your television screen.
Plasma display panel
televisions and projection
televisions are susceptible to
this.
If you have any questions or
problems concerning your
player, please consult your
nearest Sony dealer.
6
Table of Contents
WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Guide to Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Rotating and Folding Down the LCD Panel . . . . . . . . . . . . . . . . . . . . . . . . . .10
Preparations
Checking the Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Charging the Rechargeable Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Using the Car Battery Adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Connecting to the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connecting to Other Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Playback
Playing a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Playing from a USB Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Available Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Settings and Adjustments
Using the Settings Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Network Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Screen Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Audio Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
BD/DVD Viewing Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Parental Control Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Resetting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Additional Information
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
7
Guide to Parts and Controls
Player
The available functions of the player and
remote differ depending on the disc or the
situation.
z
The VOLUME + and N (play) buttons have a
tactile dot. Use the tactile dot as a reference when
operating the player.
A LCD panel
B VOLUME (sound volume) +/–
Adjusts the volume.
C Remote sensor
The main remote sensor is located next to
the HOLD indicator. The sub remote
sensor is located at the lower left side of
the LCD panel.
D N (play)
Starts or re-starts playback.
X (pause)
Pauses or re-starts playback.
x (stop)
Stops playback and remembers the stop
point (resume point).
The resume point for a title/track is the
last point you played or the last photo for
a photo folder.
./> (previous/next)
Skips to the previous/next chapter, track,
or file.
Hold down
reverse/fast forward (1 level only).
./> on the player to
E HOME
Enters the player’s home menu.
Displays the wallpaper when pressed on
the category icon of the home menu.
TOP MENU
Opens or closes the BD’s or DVD’s Top
Menu.
POP UP/MENU
Opens or closes the BD-ROM’s Pop-up
Menu, or the DVD’s menu.
OPTIONS (page 17)
The options menu that can be selected
appears on the screen.
RETURN
Returns to the previous display.
</M/m/,
Moves the highlight to select a displayed
item.
ENTER (center button)
Enters the selected item.
F DISPLAY (page 16)
Displays the playback information on the
screen.
8
G SOUND
Switches among 4 different sound modes
each time pressed.
This function is available for the sound
output from the player’s speaker.
H Speaker
I Disc lid
J OPEN button
Opens the disc lid.
K PUSH CLOSE
Closes the disc lid.
L POWER indicator
Lights up when the player is turned on.
M CHARGE indicator
Lights up when charging the
rechargeable battery.
Flashes when the battery is empty.
N HOLD indicator
Lights up when the ?/1/HOLD switch is
set in the direction of HOLD.
O ?/1 (on/standby)/HOLD switch
• Turns on the player, or sets to standby
mode.
• To avoid accidental button operation of
the player, set the switch in the
direction of HOLD. All the buttons on
the player are locked, while the buttons
on the remote remain operable.
P PHONES (headphones) jack A, B
Q (USB) jack
Connect a USB device to this jack.
R AUDIO IN/OUT jack
S VIDEO IN/OUT jack
T HDMI OUT jack
U LAN (100) terminal
V DC IN 14.3V jack
Connect the AC adaptor or car battery
adaptor.
Remote
z
Number 5, AUDIO, VOL +, and N PLAY buttons
have a tactile dot. Use the tactile dot as a reference
when operating the player.
W Number buttons (0 - 9)
Enters the title/chapter numbers, etc.
AUDIO (page 22)
Selects the language track when multilingual tracks are recorded on BDROMs/DVD VIDEOs.
Selects the sound track on CDs.
SUBTITLE (page 22)
Selects the subtitle language when multilingual subtitles are recorded on BDROMs/DVD VIDEOs.
X Color buttons (YELLOW/BLUE/
RED/GREEN)
Shortcut keys for interactive functions.
,continued
9
Y m/M (fast reverse/fast
forward)
• Fast reverses/fast forwards the disc
when pressed during playback. Each
time you press the button during
playback of videos, the search speed
changes.
• Plays in slow motion, when pressed for
more than one second in pause mode.
This function is available when the
remote is pointed at the main remote
sensor.
• Plays one frame at a time, when pressed
briefly in pause mode.
Z / (replay/advance)
Briefly replays the current scenes for
10 seconds/briefly fast forwards the
current scenes for 15 seconds.
wj [/1 (on/standby)
Turns on the player, or sets to standby
mode.
Rotating and Folding Down the LCD Panel
Open the LCD panel to the vertical position,
then slowly rotate it 180 degrees.
After rotating the LCD panel 180 degrees
clockwise, push the LCD panel down onto
the main body of the player. In this position
the panel is facing up.
Home menu display
The home menu appears when you press
HOME. Select a category using </,.
Select an item using M/m, and press ENTER.
Item Category
(Setup): Adjusts the player settings.
(Photo): Displays photos.
(Music): Plays music.
(Video): Plays videos.
(Input): Plays videos/music/photos from
other equipment.
To return the LCD panel to its original
position
Open the LCD panel to the vertical position
and slowly rotate the LCD panel counterclockwise.
b
Return the LCD panel to its original position after
use, so the LCD panel will not be damaged by
sudden shocks or rough treatment.
10
Loading...
