Sony BDP-BX120, BDP-BX320, BDP-BX520, BDP-S1200 Operating Instruction

4-476-203-11(1)

Blu-ray Disc™ /
DVD Player

Operating Instructions

Thank you for your purchase. Before using this
player, please read these instruction carefully.

Getting Started

Playback

Internet

Settings and Adjustments

Additional Information

BDP-S1200/BDP-BX120/BDP-S3200/BDP-BX320/BDP-S5200/BDP-BX520

WARNING

To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.

To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.

Do not expose batteries or appliances with
battery-installed to excessive heat, such as
sunshine and fire.

CAUTION

The use of optical instruments with this product
will increase eye hazard. As the laser beam used
in this Blu-ray Disc/DVD player is harmful to
eyes, do not attempt to disassemble the cabinet.
Refer servicing to qualified personnel only.

This label is located on the laser protective
housing inside the enclosure.

This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.

This symbol is intended to alert the
user to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.

Precautions

• To prevent fire or shock hazard, do not place
objects filled with liquids, such as vases, on the
apparatus.

• Install this unit so that the AC adaptor can be
unplugged from the wall socket immediately in
the event of trouble.

This device complies with Industry Canada
licence-exempt RSS standard(s).
Operation is subject to the following two
conditions;
(1) this device may not cause interference, and
(2) this device must accept any interference

received,
including interference that may cause undesired
operation of the device.

For United States customers. Not
applicable in Canada, including in the
province Of Quebec.
Pour les consommateurs Aux États­Unis. Non applicable au Canada, y
compris la province de Québec.

FCC WARNING

You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
This transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
The shielded Interface cable (LAN cable)
must be used with the equipment in order to
comply with the limits for a digital device
pursuant to Subpart B of Part 15 of FCC
Rules.

2

b

This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the

equipment and receiver.

– Connect the equipment into an outlet on a

circuit different from that to which the
receiver is connected.

– Consult the dealer or an experienced radio/

TV technician for help.

For United States customers. Not
applicable in Canada, including in the
province Of Quebec.
Pour les consommateurs Aux États­Unis. Non applicable au Canada, y
compris la province de Québec.

FCC Radiation Exposure Statement
(BDP-S3200/BX320/S5200/BX520 only):

This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment and meets the FCC radio
frequency (RF) Exposure Guidelines in
Supplement C to OET65. This equipment
should be installed and operated keeping the
radiator at least 20cm or more away from
person’s body (excluding extremities: hands,
wrists, feet and ankles).

IC Radiation Exposure Statement
(BDP-S3200/BX320/S5200/BX520 only):

This equipment complies with IC radiation
exposure limits set forth for an uncontrolled
environment and meets RSS-102 of the IC
radio frequency (RF) Exposure rules. This
equipment should be installed and operated
keeping the radiator at least 20cm or more
away from person’s body (excluding
extremities: hands, wrists, feet and ankles).

Contains FCC ID : MCLJ20H078
Contains IC : 2878D-J20H078

For United States customers. Not
applicable in Canada, including in the
province Of Quebec.
Pour les consommateurs Aux États­Unis. Non applicable au Canada, y
compris la province de Québec.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.

8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.

9) Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet.

10)Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.

11)On ly use attachments/accessories specified by
the manufacturer.

3

12)Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13)Unp lug this apparatus during lightning storms
or when unused for long periods of time.

14)Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.

Owner’s Record

The model and serial numbers are located at the
rear of the unit. Record the serial number in the
space provided below. Refer to them whenever
you call upon your Sony dealer regarding this
product.

Model No.______________
Serial No.______________

For customers in the USA

If this product is not working properly, please call
1-866-909-7669.

For Customers in Canada

If this product is not working properly, please
contact our Customer Information Service
Center at 1-877-899-7669 or write to us at:
Customer Information Service 115 Gordon Baker
Road, Toronto, Ontario, M2H 3R6

4

Precautions

This equipment has been tested and found to
comply with the limits set out in the EMC
Directive using a connection cable shorter
than 3 metres.

On placement

• Place the player in a location with adequate
ventilation to prevent heat build-up in the
player.

• To reduce the risk of fire, do not cover the
ventilation opening of the appliance with
newspapers, tablecloths, curtains, etc.

• Do not expose the appliance to naked flame
sources (for example, lighted candles).

• Do not install this player in a confined space,
such as a bookshelf or similar unit.

• Do not place the player outdoors, in
vehicles, on ships, or on other vessels.

• If the player is brought directly from a cold
to a warm location, or is placed in a very
damp room, moisture may condense on the
lenses inside the player. Should this occur,
the player may not operate properly. In this
case, remove the disc and leave the player
turned on for about half an hour until the
moisture evaporates.

• Do not install the player in an inclined
position. It is designed to be operated in a
horizontal position only.

• Do not place metal objects in front of the
front panel. It may limit reception of radio
waves.

• Do not place the player in a place where
medical equipment is in use. It may cause a
malfunction of medical instruments.

• If you use a pacemaker or other medical
device, consult your physician or the
manufacturer of your medical device before
using the wireless LAN function.

• Do not place heavy or unstable objects on
the player.

• Do not place any objects other than discs on
the disc tray. Doing so may cause damage to
the player or the object.

• Take out any discs from the tray when you
move the player. If you don’t, the disc may
be damaged.

• Disconnect the AC adaptor and all other
cables from the player when you move the
player.

On power sources

• The player is not disconnected from the AC
power source as long as it is con nected to the
wall outlet, even if the player itself has been
turned off.

• Disconnect the player from the wall outlet if
you are not going to use the player for a long
time. To disconnect the AC adaptor, grasp
the plug itself; never pull the cord.

• Observe following points to prevent the AC
adaptor being damaged. Do not use the AC
adaptor if it is damaged, as doing so may
result in an electric shock or fire.
– Do not pinch the AC adaptor between the

player and wall, shelf, etc.

– Do not put anything heavy on the AC

adaptor or pull on the AC adaptor itself.

On AC adaptor

• Use the supplied AC adaptor for this player,
as other adaptors may cause a malfunction.

• Do not disassemble or reverse-engineer.

• Do not confine the AC adaptor in a closed
place such as a bookshelf or an AV cabinet.

• Do not connect the AC adaptor to a
traveler’s electric transformer, which may
generate heat and cause a malfunction.

• Do not drop or apply shock.

On adjusting volume

Do not turn up the volume while listening to a
section with very low level inputs or no audio
signals. Your ears and the speakers may be
damaged when the sound level reaches the
peak.

On cleaning

Clean the cabinet, panel, and controls with a
soft cloth. Do not use any type of abras ive pad,
scouring powder or solvent such as alcohol or
benzine.

On cleaning discs, disc/lens cleaners

Do not use cleaning discs or disc/lens cleaners
(including wet or spray types). These may
cause the apparatus to malfunction.

On replacement of parts

In the events that this player is repaired,
repaired parts may be collected for reuse or
recycling purposes.

On connecting to the HDMI OUT jack

Observe the following as improper handling
may damage the HDMI OUT jack and the
connector.

• Carefully align the HDMI OUT jack on the
rear of the player and the HDMI connector
by checking their shapes. Make sure the
connector is not upside down or tilted.

• Be sure to disconnect the HDMI cable when
moving the player.

• Hold the HDMI connector straight when
connecting or disconnecting the HDMI
cable. Do not twist or force the HDMI
connector into the HDMI OUT jack.

5

On watching 3D video images
(BDP-S5200/BX520 only)

Some people may experience discomfort
(such as eye strain, fatigue, or nausea) while
watching 3D video images. Sony recommends
that all viewers take regular breaks while
watching 3D video images. The length and
frequency of necessary breaks will vary from
person to person. You must decide what works
best. If you experience any discomfort, you
should stop watching the 3D video images
until the discomfort ends; consult a doctor if
you believe necessary. You should also
review (i) the instruction manual and/or the
caution message of any other device used
with, or Blu-ray Disc contents played with this
product and (ii) our website
(http://esupport.sony.com/) for the latest
information. The vision of young children
(especially those under six years old) is still
under development. Consult your docto r (such
as a pediatrician or eye doctor) before
allowing young children to watch 3D video
images. Adults should supervise young
children to ensure they follow the
recommendations listed above.

IMPORTANT NOTICE

Caution: This player is capable of holding
a still video image or on-screen display
image on your television screen
indefinitely. If you leave the still video
image or on-screen display image
displayed on your TV for an extended
period of time you risk permanent damage
to your television screen. Plasma display
panel televisions and projection
televisions are susceptible to this.

If you have any questions or problems
concerning your player, please consult your
nearest Sony dealer.

Copy Protection

Please be advised of the advanced content
protection systems used in both Blu-ray
Disc™ and DVD media. These systems,
called AACS (Advanced Access Content
System) and CSS (Content Scramble System),
may contain some restrictions on playback,
analog output, and other similar features. The
operation of this product and the restrictions
placed may vary depending on the date of
purchase, as the governing board of the AACS
may adopt or change its restriction rules after
the time of purchase.

Cinavia Notice

This product uses Cinavia technology to limit
the use of unauthorized copies of some
commercially-produced film and videos and
their soundtracks. When a prohibited use of an
unauthorized copy is detected, a message will
be displayed and playback or copying will be
interrupted.

More information about Cinavia technology is
provided at the Cinavia Online Consumer
Information Center at http://www.cinavia.com.
To request additional information about
Cinavia by mail, send a postcard with your
mailing address to: Cinavia Consumer
Information Center, P.O. Box 86851, San
Diego, CA, 92138, USA.

About this manual

The cover page photo is BDP-S5200.

Copyrights and Trademarks

• “AVCHD” and the “AVCHD 3D/

Progressive” logo are trademarks of
Panasonic Corporation and Sony
Corporation.

• Java is a trademark of Oracle and/or its

affiliates.

• , “XMB,” and “xross media bar” are

trademarks of Sony Corporation and Sony
Computer Entertainment Inc.

• Manufactured under license from Dolby

Laboratories. Dolby, Pro Logic, and the
double-D symbol are trademarks of Dolby
Laboratories.

6

• For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS
Licensing Limited. DTS, the Symbol, &
DTS and the Symbol together are registered
trademarks, and DTS 2.0+Digital Out is a
trademark of DTS, Inc. © DTS, Inc. All
Rights Reserved.

• The terms HDMI® and HDMI High­Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC in the
United States and other countries.

• Blu-ray Disc™, Blu-ray™, Blu-ray 3D™,
BD-Live™, BONUSVIEW™, and the
logos are trademarks of the Blu-ray Disc
Association.

• “DVD Logo” is a trademark of
DVD Format/Logo Licensing Corporation.

• “DVD+RW,” “DVD-RW,” “DVD+R,”
“DVD-R,” “DVD VIDEO,” and “CD” logos
are trademarks.

• “BRAVIA” is a trademark of Sony
Corporation.

• MPEG Layer-3 audio coding technology
and patents licensed from Fraunhofer IIS
and Thomson.

• This product incorporates proprietary
technology under license from Verance
Corporation and is protected by U.S. Patent
7,369,677 and other U.S. and worldwide
patents issued and pending as well as
copyright and trade secret protection for
certain aspects of such technology. Cinavia
is a trademark of Verance Corporation.
Copyright 2004-2010 Verance Corporation.
All rights reserved by Verance. Reverse
engineering or disassembly is prohibited.

• Windows Media is either a registered
trademark or trademark of Microsoft
Corporation in the United States and/or
other countries.
This product contains technology subject to
certain intellectual property rights of
Microsoft. Use or distribution of this
technology outside of this product is
prohibited without the appro priate license(s)
from Microsoft.

Content owners use Microsoft PlayReady™
content access technology to protect their
intellectual property, including copyrighted
content. This device uses PlayReady
technology to access PlayReady-protected
content and/or WMDRM-protected conten t.
If the device fails to properly enforce
restrictions on content usage, content
owners may require Microsoft to revoke the
device’s ability to consume PlayReady­protected content. Revocation should not
affect unprotected content or content
protected by other content access
technologies. Content owners may require
you to upgrade PlayReady to access their
content. If you decline an upgrade, you will
not be able to access content that requires
the upgrade.

• This product meets ENERGY STAR®
guidelines for energy efficiency.
ENERGY STAR and the ENERGY STAR
mark are registered U.S. marks. ENERGY
STAR is a registered mark owned by the
U.S. government.

• Music and video recognition t echnology and
related data are provided by Gracenote®.
Gracenote is the industry standard in music
recognition technology and related content
delivery. For more information, please visit
www.gracenote.com.
CD, DVD, Blu-ray Disc, and music and
video-related data from Gracenote, Inc.,
copyright © 2000-present Gracenote.
Gracenote Software, copyright © 2000­present Gracenote. One or more patents
owned by Gracenote apply to this product
and service. See the Gracenote website for a
nonexhaustive list of applicable Gracenote
patents. Gracenote, CDDB, MusicID,
MediaVOCS, the Gracenote logo and
logotype, and the “Powered by Gracenote”
logo are either registered trademarks or
trademarks of Gracenote in the United
States and/or other countries.

7

•Wi-Fi®, Wi-Fi Protected Access® and
Wi-Fi Alliance® are registered marks of the
Wi-Fi Alliance.

• Wi-Fi CERTIFIED™, WPA™, WPA2™,
Wi-Fi Protected Setup™, Miracast™ and
Wi-Fi CERTIFIED Miracast™ are marks of
the Wi-Fi Alliance.

• The Wi-Fi CERTIFIED Logo is a
certification mark of the Wi-Fi Alliance.

• The Wi-Fi Protected Setup Mark is a mark
of the Wi-Fi Alliance.

•DLNA®, the DLNA Logo and DLNA
CERTIFIED™ are trademarks, service
marks, or certification marks of the Digital
Living Network Alliance.

•Opera® Devices SDK from Opera Software
ASA. Copyright 2002-2012 Opera Software
ASA. All rights reserved.

• All other trademarks are trademarks of their
respective owners.

• Other system and product names are
generally trademarks or registered
trademarks of the manufacturers. ™ and ®
marks are not indicated in this document.

Gracenote® End User License
Agreement

This application or device contains software
from Gracenote, Inc. of Emeryville, California
(“Gracenote”). The software from Gracenote
(the “Gracenote Software”) enables this
application to perform disc and/or file
identification and obtain music-related
information, including name, artist, track, and
title information (“Gracenote Data”) from
online servers or embedded databases
(collectively, “Gracenote Servers”) and to
perform other functions. You may use
Gracenote Data only by means of the intended
End-User functions of this application or
device.

You agree that you will use Gracenote Data,
the Gracenote Software, and Gracenote
Servers for your own personal non­commercial use only. You agree not to assign,
copy, transfer or transmit the Gracenote
Software or any Gracenote Data to any third
party. YOU AGREE NOT TO USE OR
EXPLOIT GRACENOTE DATA, THE
GRACENOTE SOFTWARE, OR
GRACENOTE SERVERS, EXCEPT AS
EXPRESSLY PERMITTED HEREIN.

You agree that your non-exclusive license to
use the Gracenote Data, the Gracenote
Software, and Gracenote Servers will
terminate if you violate these restrictions. If
your license terminates, you agree to cease
any and all use of the Gracenote Data, the
Gracenote Software, and Gracenote Servers.
Gracenote reserves all rights in Gracenote
Data, the Gracenote Software, and the
Gracenote Servers, including all ownership
rights. Under no circumstances wi ll Gracenote
become liable for any payment to you for any
information that you provide. You agree that
Gracenote, Inc. may enforce its rights under
this Agreement against you directly in its own
name.

,continued to page 10

8

Contents

2WARNING
4 Precautions

Getting Started

11 Guide to Parts and Controls
15 Step 1: Connecting the Player
17 Step 2: Preparing for Network Connection
17 Step 3: Easy Setup

Playback

19 Playing a Disc
21 Playing from a USB Device
21 Playing via a Network
24 Available Options

Internet (BDP-S3200/BX320/S5200/BX520 only)

26 Browsing Websites

Settings and Adjustments

28 Using the Settings Displays
28 [Software Update]
28 [Screen Settings]
30 [Audio Settings]
30 [BD/DVD Viewing Settings]
31 [Parental Control Settings]
31 [System Settings]
32 [Network Settings]
33 [Easy Network Settings]
33 [Resetting]

Additional Information

34 Troubleshooting
38 Specifications

9

The Gracenote service uses a unique identifier
to track queries for statistical purposes. The
purpose of a randomly assigned numeric
identifier is to allow the Gracenote service to
count queries without knowi ng anything about
who you are. For more information, see the
web page for the Gracenote Privacy Policy for
the Gracenote service.

The Gracenote Software and each item of
Gracenote Data are licensed to you “AS IS.”
Gracenote makes no representations or
warranties, express or implied, regarding the
accuracy of any Gracenote Data from in the
Gracenote Servers. Gracenote reserves the
right to delete data from th e Gracenote Servers
or to change data categories for any cause that
Gracenote deems sufficient. No warranty is
made that the Gracenote Software or
Gracenote Servers are error-free or that
functioning of Gracenote Software or
Gracenote Servers will be uninterrupted.
Gracenote is not obligated to provide you with
new enhanced or additional data types or
categories that Gracenote may provide in the
future and is free to discontinue its services at
any time.

GRACENOTE DISCLAIMS ALL
WARRANTIES EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, TITLE, AND
NON-INFRINGEMENT. GRACENOTE
DOES NOT WARRANT THE RESULTS
THAT WILL BE OBTAINED BY YOUR
USE OF THE GRACENOTE SOFTWARE
OR ANY GRACENOTE SERVER. IN NO
CASE WILL GRACENOTE BE LIABLE
FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES OR FOR ANY
LOST PROFITS OR LOST REVENUES.
© 2000 to present. Gracenote, Inc.

10

Getting Started

6 5

Guide to Parts and Controls

Front panel

1

Getting Started

2 34

A Disc tray
B Z (open/close)
C [/1 (on/standby)

Turns on the player, or sets to
standby mode.

D (USB) jack

Connect a USB device to this jack.

E Power indicator

Lights up when the player is turned
on.

F Remote sensor

To lock the disc tray (Child Lock)

You can lock the disc tray to avoid
accidental opening of the tray.
While the player is turned on, press
x STOP, HOME, and then TOP MENU
button on the remote to lock or unlock
the tray.

11

Rear panel

A DC IN 12 V (AC adaptor input) jack
B LAN (100) terminal
C HDMI OUT jack
D DIGITAL OUT (COAXIAL) jack

12

Remote

The available functions of the remote are
different depending on the disc or the
situation.

z

N PLAY, VOL +, and AUDIO buttons have
a tactile dot. Use the tactile dot as a reference
when operating the player.

The player automatically returns to
standby mode

If any button on the player or remote is
not pressed for more than 20 minutes,
the player automatically returns to
standby mode.

A Z OPEN/CLOSE

Opens or closes the disc tray.

-TV- INPUT

Switches between TV and other
input sources.

-TV- [/1 (on/standby)

Turns on the TV, or sets to standby
mode.

[/1 (on/standby)

Turns on the player, or sets to
standby mode.

B Color buttons (YELLOW/

BLUE/RED/GREEN)

Shortcut keys for interactive
functions.

C TOP MENU

Opens or closes the BD’s or DVD’s
Top Menu.

POP UP/MENU

Opens or closes the BD-ROM’s
Pop-up Menu, or the DVD’s menu.

OPTIONS (page 24)

Displays the available options on the
screen.

RETURN

Returns to the previous display.

</M/m/,

Moves the highlight to select a
displayed item.

b

M/m as a shortcut key for track search

during music CD playback.

Center button (ENTER)

Enters the selected item.

Getting Started

13

HOME

C

Enters the player’s home menu.
Displays the wall paper when
pressed on the category icon of the
home menu.

SEN (page 21)

Accesses the “Sony Entertainment
Network™” online service.

NETFLIX

Accesses the “NETFLIX” online
service. For further NETFLIX
online service details, visit the
following website and check the
FAQ:
http://www.sony.com/
bluraysupport/

D m/M (fast reverse/fast

forward)

• Fast reverse/fast forward the disc
when you press the button during
playback. The search speed
changes each time you press the
button during video playback.

• Plays in slow motion, when
pressed for more than one second
in pause mode.

• Plays one frame at a time, when
you press for a short time in pause
mode.

N PLAY

Starts or re-starts playback.

. PREV/NEXT >

Skips to the previous/next chapter,
track, or file.

X PAUSE

Pauses or re-starts playback.

x STOP

Stops playback and remembers the
stop point (resume point).
The resume point for a title/track is
the last point you played or the last
photo for a photo folder.

14

SUBTITLE (page 30)

Selects the subtitle language when
multi-lingual subtitles are recorded
on BD-ROMs/DVD VIDEOs.

VOL +/–

Adjusts the TV volume.

AUDIO (page 30)

Selects the language track when
multi-lingual tracks are recorded on
BD-ROMs/DVD VIDEOs.
Selects the sound track on CDs.

MUTING

Turns off the sound temporarily.

DISPLAY (page 20)

Displays the playback and web
browsing (BDP-S3200/BX320/
S5200/BX520 only) information on
the screen.

Home menu display

The home menu appears when you press
HOME. Select a category using </,.
Select an item using M/m, and press
ENTER.

Item

[Setup]: Adjusts the player settings.
[Photo]: Displays photos.
[Music]: Plays music.
[Video]: Plays videos.
[Input]: Perform Screen mirroring

with compatible source device
(BDP-S3200/BX320/S5200/BX520
only).

[Network]: Displays network items.

ategory

Step 1: Connecting the Player

Do not connect the AC adaptor until you have made all the connections.

Connecting to your TV

Connect the player to your TV with a High Speed HDMI Cable.

High Speed HDMI Cable

* See “Supplied accessories” (page 38).

*

Getting Started

High quality

15
