SKIL 7314 User Manual

ORBITAL SANDER
7314 (F0157314..)

SKIL Europe BV - Konijnenberg 60 07/08 2610398483
4825 BD Breda - The Netherlands

www.skileurope.com

www.skileurope.com

ORIGINAL INSTRUCTIONS . . . . . . . . . . . . . 5

NOTICE ORIGINALE . . . . . . . . . . . . . . . . . . 7

ORIGINALBETRIEBSANLEITUNG . . . . . .

10

ORIGINELE GEBRUIKSAANWIJZING. . . . 13

BRUKSANVISNING I ORIGINAL . . . . . . . . 17

ORIGINAL BRUGSANVISNING . . . . . . . . . 19

ORIGINAL DRIFTSINSTRUKS. . . . . . . . . .

22

ALKUPERÄISET OHJEET . . . . . . . . . . . . . 25

MANUAL ORIGINAL. . . . . . . . . . . . . . . . . . 27

MANUAL ORIGINAL. . . . . . . . . . . . . . . . . . 31

ISTRUZIONI ORIGINALI . . . . . . . . . . . . . . 34

EREDETI HASZNÁLATI UTASÍTÁS. . . . . . 37

PÒVODNÍM NÁVODEM K POUÎÍVÁNÍ . . . 40

OR‹J‹NAL ‹fiLETME TAL‹MATI . . . . . . . . . 43

INSTRUKCJÑ ORYGINALNÑ. . . . . . . . . . . 45

ОДЛИННИК РУКОВОДСТВА

ПО ЭКСПЛУАТАЦИИ . . . . . . . . . . . . . . . .

49

ОРИГІНАЛЬНА ІНСТРУКЦІЯ

З ЕКСПЛУАТАЦІЇ . . . . . . . . . . . . . . . . . . .

52

ΠΡΩΤΟΤΥΠΟ Ο∆ΗΓΙΩΝ ΧΡΗΣΗΣ . . . . . . 56

INSTRUCØIUNI DE FOLOSIRE

ORIGINALE . . . . . . . . . . . . . . . . . . . . . . . .

59

ОРИГИНАЛНО РЪКОВОДСТВО

ЗА ЕКСПЛОАТАЦИЯ . . . . . . . . . . . . . . . .

62

PÔVODN¯ NÁVOD NA POUÎITIE. . . . . . . 66

ORIGINALNE UPUTE ZA RAD . . . . . . . . . 69

ORIGINALNO UPUTSTVO ZA RAD. . . . . . 71

IZVIRNA NAVODILA. . . . . . . . . . . . . . . . . . 74

ALGUPÄRANE KASUTUSJUHEND. . . . . . 77

ORI˛INÅLÅ LIETO·ANAS PAMÅC±BA . . . 80

ORIGINALI INSTRUKCIJA . . . . . . . . . . . . . 83

GB

F

D

NL

S

DK

N

FIN

E

P

I

H

CZ

TR

PL

RU

UA

GR

RO

BG

SK

HR

SRB

SLO

EST

LV

LT

ME77

2

1

2

7314

3

250

Watt

EPTA 01/2003

1,3 kg

ø

29000

1,5

p/

mm

min

F

115x140mm

115x107mm

G

A

B

RUBBER

D

C

E

3

4

A

B

4

6

5

8

7

D

C

E

! before the sanding surface reaches the

workpiece, you should switch on the tool

! before switching off the tool, you should lift it

from the workpiece

• Holding and guiding the tool 7

! while working, always hold the tool at the grey-

coloured grip area(s)

- guide the tool parallel to the working surface

! do not apply too much pressure on the tool; let

the sanding surface do the work for you

- do not tilt the tool in order to avoid unwanted
sanding marks

- keep ventilation slots G 2 uncovered

APPLICATION ADVICE

• Move the tool in straight movements in line with the
grain

- for sanding bare wood surfaces

- for extra fi ne fi nishing

• Never use the same sanding sheet for wood and metal

• Recommended sanding sheet grits:
coarse - for removing paint;

for sanding of extremely rough wood
medium - for sanding of rough or plain wood
fi ne - for smoothing of wood;

for fi nishing of bare wood;

for smoothing surfaces with old paint

• Use different grit sizes when the working surface is
rough:

- start sanding with coarse or medium grit

- fi nish with fi ne grit

• Vibration level

The vibration emission level stated at the back of this

instruction manual has been measured in accordance
with a standardised test given in EN 60745; it may be
used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned

- using the tool for different applications, or with

different or poorly maintainted accessories, may
signifi cantly increase the exposure level

- the times when the tool is switched off or when it is

running but not actually doing the job, may
signifi cantly reduce the exposure level

! protect yourself against the effects of vibration by

maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns

MAINTENANCE / SERVICE

• Always keep tool and cord clean (especially the
ventilation slots G 2)

- remove adhering sanding dust with a brush

! disconnect the plug before cleaning

• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools

- send the tool undismantled together with proof of

purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skileurope.com)

ENVIRONMENT

• Do not dispose of electric tools, accessories and
packaging together with household waste material

(only for EU countries)

- in observance of European Directive 2002/96/EC on

waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility

- symbol 8 will remind you of this when the need for

disposing occurs

F

Ponceuse vibrante 7314
INTRODUCTION

• Cet outil sert au ponçage et au polissage à sec du bois,
des surfaces peintes, du plastique et du mastic

• Lisez et conservez ce manuel d’instructions 3

SPECIFICATIONS TECHNIQUES 1
ELEMENTS DE L’OUTIL 2

A Levier pour changer la feuille de ponçage
B Perforatrice de feuilles
C Sac à poussière
D Micro-fi ltre
E Adaptateur de l’aspirateur
F Interrupteur marche/arrêt
G Fentes de ventilation

SECURITE

INSTRUCTIONS GENERALES DE SECURITE

ATTENTION! Lisez tous les avertissements de

sécurité et toutes les instructions. Ne pas suivre les

avertissements et instructions peut entraîner un choc
électrique, un incendie et/ou de graves blessures sur les
personnes. Conservez tous les avertissements et

toutes les instructions pour pouvoir s’y reporter
ultérieurement. La notion d’”outil électroportatif” dans les

avertissements se rapporte à des outils électriques
raccordés au secteur (avec câble de raccordement).

1) SECURITE DE LA ZONE DE TRAVAIL

a) Maintenez l’endroit de travail propre et bien éclairé.

Un lieu de travail en désordre ou mal éclairé augmente
le risque d’accidents.

7
