1500W Router

264895

⁄

Défonceuse 1500 W Oberfräse, 1500 W Fresadora 1500 W Fresatrice 1500W Bovenfrees, 1500 W

www.silverlinetools.com

1 2 4 53 6

7 8 9

23 2422

2526

DIY

⁄

1500W Router

English .................. 4

Français ................ 10

Deutsch ................. 16

Español ................. 22

Italiano .................. 28

Nederlands ............ 34

www.silverlinetools.com

Description of Symbols

The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use

Wear hearing protection Wear eye protection Wear breathing protection Wear head protection

Wear hand protection

Read instruction manual

Caution!

Double insulated for additional protection

Conforms to relevant legislation and safety standards

Environmental Protection

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice

Speciﬁcation

Voltage: ........................................230-240V~50Hz

Power: ..........................................1500W

No load speed: .............................6000-26000min

Plunge Stroke: ..............................0-50mm

Collet size: ....................................¼", ½", 8 & 12mm

Base Diameter:.............................170mm

Base Shape: .................................Combined Circular & Flat

Dimensions (H x L x W): ................320x300x140mm

Protection Class: ..........................

Ingress Protection: .......................IP20

Weight: .........................................5.5kg

As part of our ongoing product development, speciﬁcations of Silverline

Sound and Vibration Information:

Sound pressure (LPA): ....................87dB(A)

Sound power (LWA): .......................98dB(A)

Uncertainty: ..................................3dB(A)

Weighted vibration: ......................3.86m/s

Uncertainty: ..................................1.5m/s

The sound intensity level for the operator may exceed 85dB(A) and sound

products may alter without notice

protection measures are necessary.

-1

WARNING: Always wear ear protection where the sound level exceeds 85dB(A) and limit the time of exposure if necessary. If sound levels are uncomfortable, even with ear protection, stop using the tool immediately and check the ear protection is correctly ﬁtted and provides the correct level of sound attenuation for the level of sound produced by your tool.

WARNING: User exposure to tool vibration can result in loss of sense of touch, numbness, tingling and reduced ability to grip. Long term exposure can lead to a chronic condition. If necessary, limit the length of time exposed to vibration and use anti-vibration gloves. Do not operate the tool with hands below a normal comfortable temperature, as vibration will have a greater effect. Use the ﬁgures provided in the speciﬁcation relating to vibration to calculate the duration and frequency of operating the tool.

Sound and vibration levels in the speciﬁcation are determined according to EN60745 or similar international standards. The ﬁgures represent normal use for the tool in normal working conditions. A poorly maintained, incorrectly assembled, or misused tool may produce increased levels of noise and vibration. www.osha.europa.eu provides information on sound and vibration levels in the workplace that may be useful to domestic users who use tools for long periods of time.

General Safety

WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, ﬁre and/ or serious injury.

WARNING: This appliance is not intended for use by persons (including children) with reduced, physical or mental capabilities or lack of experience or knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children must be supervised to ensure that they do not

play with the appliance. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated

(corded) power tool or battery-operated (cordless) power tool.

Work Area Safety

a) Keep work area clean and well lit. Cluttered or dark areas invite

accidents.

b) Do not operate power tools in explosive atmospheres, such as

in the presence of ﬂammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes.

c) Keep children and bystanders away while operating a power tool.

Distractions can cause you to lose control.

Electrical Safety

a) Power tool plugs must match the outlet. Never modify the plug in

any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodiﬁed plugs and matching outlets will reduce risk

of electric shock.

b) Avoid body contact with earthed or grounded surfaces, such as

pipes, radiators, ranges and refrigerators. There is an increased

risk of electric shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet conditions. Water

entering a power tool will increase the risk of electric shock.

d) Do not abuse the cord. Never use the cord for carrying, pulling or

unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the

risk of electric shock.

e) When operating a power tool outdoors, use an extension cord

suitable for outdoor use. Use of a cord suitable for outdoor use

reduces the risk of electric shock.

f) If operating a power tool in a damp location is unavoidable, use

a residual current device (RCD) protected supply. Use of an RCD

reduces the risk of electric shock.

WARNING: When used in Australia or New Zealand, it is recommended that this tool is ALWAYS supplied via Residual Current Device (RCD) with a rated residual current of 30mA or less.

1500W Router 264895

Personal Safety

a) Stay alert, watch what you are doing and use common sense

when operating a power tool. Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol or medication.

A moment of inattention while operating power tools may result in serious personal injury.

b) Use personal protective equipment. Always wear eye protection.

Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure the switch is in the

off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your

ﬁnger on the switch or energising power tools that have the switch on invites accidents.

d) Remove any adjusting key or wrench before turning the power

tool on. A wrench or a key left attached to a rotating part of the power

tool may result in personal injury.

e) Do not overreach. Keep proper footing and balance at all times.

This enables better control of the power tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or jewellery. Keep your

hair, clothing and gloves away from moving parts. Loose clothes,

jewellery or long hair can be caught in moving parts.

g) If devices are provided for the connection of dust extraction and

collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.

Power Tool Use and Care

a) Do not force the power tool. Use the correct power tool for your

application. The correct power tool will do the job better and safer at

the rate for which it was designed.

b) Do not use the power tool if the switch does not turn it on and off.

Any power tool that cannot be controlled with the switch is dangerous and must be repaired.

c) Disconnect the plug from the power source and/or the battery

pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive

safety measures reduce the risk of starting the power tool accidentally.

d) Store idle power tools out of the reach of children and do

not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous

in the hands of untrained users.

e) Maintain power tools. Check for misalignment or binding of

moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly

maintained power tools.

f) Keep cutting tools sharp and clean. Properly maintained cutting

tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance

with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for

operations different from those intended could result in a hazardous situation.

Service

a) Have your power tool serviced by a qualiﬁed repair person using

only identical replacement parts. This will ensure that the safety of

the power tool is maintained.

Router Safety

WARNING Before connecting a tool to a power source (mains switch power point receptacle, outlet, etc.) be sure that the voltage supply is the same as that speciﬁed on the nameplate of the tool. A power source with a voltage greater than that speciﬁed for the tool can result in serious injury to the user, and damage to the tool. If in doubt, do not plug in the tool. Using a power source with a voltage less than the nameplate rating is harmful to the motor.

• Use safety equipment including safety goggles or shield, ear protection, dust mask and protective clothing including safety gloves

• Cloths, cord, string etc should never be left around the work area

• Ensure the mains supply voltage is the same as the tool rating plate voltage

• Ensure any cable extensions used with this tool are in a safe electrical condition, and have the correct ampere rating for the tool

• Completely unwind cable drum extensions to avoid potential overheating

• Always check walls, ﬂoors and ceilings to avoid hidden power cables and pipes

• Ensure that you have removed embedded objects such as nails and screws from the workpiece before commencing operation

• Handle router bits with care, they can be extremely sharp

• Before use, check the bit carefully for signs of damage or cracks. Replace damaged or cracked bits immediately

• Always use both handles and ensure that you have a ﬁrm grip on the router before proceeding with any work

• Before using the tool to make a cut, switch on and let it run for a while. Vibration could indicate an improperly installed bit

• Take notice of the direction of rotation of the bit and the direction of feed

• Keep hands away from the rotating bit

• Never start the router while the cutter is touching the workpiece

• Ensure the plunge spring is always ﬁtted when using hand-held

• Ensure the cutter has completely stopped before plunging to the collet lock position

• Only use router cutters designed for woodwork, suitable for use between 8,000 and 20,000rpm

• Do not handle cutters immediately after use - they become very hot

• Only use cutters with a shank diameter exactly matched to the collet(s) supplied with this router

• Extreme care must be taken when using cutters with a diameter greater than 2" (50mm). Use very slow feed rates and/or multiple shallow cuts to avoid overloading the motor

• Always switch off and wait until the bit has come to a complete standstill before removing the machine from the workpiece

• Disconnect from power before carrying out any adjustment, servicing or maintenance

www.silverlinetools.com

Product Familiarisation

1 Left Handle 2 Depth Stop Wheel 3 Depth Scale 4 Brush Access Cover 5 Variable Speed Dial 6 Right Handle 7 Guide Rod Locking Knob 8 Spindle Lock Button

9 Collet Nut 10 Turret Stop 11 Guide Rod 12 Depth Stop Lock 13 Parallel Guide 14 Fine Adjustment Knob 15 Plunge Lock Lever 16 Dust Extraction Port 17 Base Plate 18 Safety Button 19 On/Off Switch 20 Brush Access Cover 21 Measurement Bar 22 Collets 23 Guide Bush 24 Spanner 25 Circle Guide 26 Roller Guide

Intended Use

Power tool designed mainly for woodworking. Cuts and creates proﬁles in wood using a wide range of cutters/router bits.

Unpacking Your Tool

• Carefully unpack and inspect your tool. Familiarise yourself with all its features and functions.

• Ensure that all parts of the tool are present and in good condition. If any parts are missing or damaged, have such parts replaced before attempting to use this tool.

Before Use

• Attach the Dust Extraction Port (16) to the Base Plate (17) using the nuts and bolts supplied

WARNING: Always attach a workshop vacuum or dust extraction system to the Dust Extraction Port before using the router if possible. Dust from materials can be toxic especially man-made composite

materials

Operation

WARNING: Always ensure that the machine is disconnected from the power supply before ﬁtting and removing cutters, attaching/removing

attachments, or altering any machine settings.

Installing a router bit

• Press in the Spindle Lock Button (8) and rotate the spindle so that the lock engages

• The Collet Nut (9) can then be slackened (it may be necessary to use the supplied spanner)

• Ensure that the correct size of collet is installed. If it is necessary to change the collet, unscrew the Collet Nut completely, change the collet and replace the nut

• Insert the router cutter into the collet, ensuring that at least 20mm, or half of the shaft (whichever is greater) is inserted into the collet

• The Collet Nut can then be tightened using the Spanner (24) supplied. Do not over-tighten the Collet Nut, as this could cause damage to the collet or the spindle lock

CAUTION: The supplied 12mm and ½” Collets and the 8mm and ¼” Collets are very similar in size. Ensure that the correct Collet is used to match the shank of the cutter (router bit) that will be ﬁtted.

Removing a router bit

• Press in the Spindle Lock Button (8) and loosen the Collet Nut (9). The router bit should now be loose and can be removed

• If the router bit does not release from the collet, gently tap the collet nut to release

• Always keep the collet, Collet Nut, spindle threads, and cutter shanks clean to ensure reliable service

Adjusting the plunge depth

• To release the plunge mechanism, rotate the Plunge Lock Lever (15) to its upper position

• The depth stop can be adjusted by slackening the Depth Stop Lock (12), and rotating the Depth Stop Wheel (2)

• Always tighten the Depth Stop Lock before making a cut

• The Depth Scale (3) can be used to judge changes in depth setting, but actual cutting depth is best measured by making a trial cut on scrap material

Fine adjustment

• Fine adjustment of the plunge depth can be made using the Fine Adjustment Knob (14). One full rotation clockwise will result in a 1mm reduction in plunge depth

Base Plate

The router features a combined ﬂat-sided and round Base Plate (17). This allows the round edge to follow contours easily but also gives an easy straight edge which may be useful for some straight cuts (when the Parallel Guide cannot be used), using with guide bushes and also where the edge of the base plate needs to be closer to the cutter, for use with Dovetail Jigs, for example. In use, always remember which edge of the base plate you are working with as the distance is different to the cutter. If the cutter impacts hard material such as metal the cutter will be destroyed and the router itself may be damaged.

Setting the depth of cut

• To lock the router at a particular depth of cut, hold the router head down and rotate the Plunge Lock Lever (15) to its lower position. This will hold the router head in this position

Switching On/Off

• Ensure that the cutter is held securely in the collet, and that the cutter is not in contact with the workpiece or any other object

• To start the motor, hold the Safety Button (18) down, and squeeze the On/ Off Switch (19). The router is equipped with a soft-start feature so the motor will take a few moments to reach its full operating speed

• To stop the motor, release the On/Off Switch

1500W Router 264895

Speed control

• The speed of the router is set using the Variable Speed Dial (5); a higher number on the dial corresponds to a higher motor speed

• Choosing the correct speed for the cutter and material will produce a higher quality of ﬁnish, and prolong the service life of your router cutters

Making a cut

• Always hold the router using both hands. Use clamps as appropriate to ensure that the workpiece will not move

• Turn on and allow the motor to reach its full operating speed as set by the Variable Speed Control (5)

• Lower the cutter into the workpiece whilst moving the router slowly, keeping the base held ﬂat against the work

• If edge cutting, keep the workpiece on the left-hand side of the router, relative to the cutting direction. Keep the pressure constant and allow the cutter to work steadily through the material. Be aware that knots, and other variations, will slow the rate of progress

• To avoid 'bit chatter', direct the cut anti-clockwise for external cuts, and clockwise for internal cuts

• Moving the router too fast can result in a poor quality ﬁnish, and overloading of the motor. Moving the router too slowly can result in overheating the workpiece

Making multiple pass cuts

• The Turret Stop (10) allows the maximum depth of cut to be achieved in up to 7 steps. Each step of the turret is equal to approximately 3mm depth of cut. Set the desired total depth of cut using the depth stop, to the lowest turret step

• Rotate the Turret Stop so that the depth stop will contact the highest step when the router is plunged. The ﬁrst pass of the cut can now be made

• Continue to make passes, rotating the Turret Stop anti-clockwise by one step for each pass until the full depth of cut has been achieved. (NOTE: For total cuts of less than 21mm the number of steps will be reduced)

Using the parallel guide

• When grooving, or chamfering, use of the Parallel Guide (13) will help to ensure that accurate cuts are made

• Position the two Guide Rods (11) into the grooves in the top of the Base Plate (17)

• Locate the Parallel Guide onto the Guide Rods, so that it extends to the correct side of the router for the cut that you intend to make

• Slide the Parallel Guide to the required position relative to the cutter

• The Measurement Bar (21) can be clipped to one of the Guide Rods to help ensure accurate alignment. Ensure that the plastic pads on the parallel guide are not in contact with the cutter

• Make the cut as described above, but keep the vertical edge of the Parallel Guide held against the edge of the workpiece

• If it is necessary to follow a curved edge, remove the protective plastic pads from the Parallel Guide and ﬁt the Roller Guide (26) using the screws provided. Use the same cutting technique as described above, allowing the roller to follow the edge of the workpiece

Using the circle guide

• Use the Circle Guide (25) to cut circles and arcs

• Position a Guide Rod (11) into one of the grooves in the top of the Base Plate (17)

• Locate the Circle Guide onto the end of the Guide Rod so that it extends to the correct side of the router for the intended cut with the point facing downwards. Rotate the pointed screw clockwise so that it makes contact with the workpiece. Lock the Circle Guide to the Guide Rod by tightening the wing nut

• Slide the Circle Guide to the correct distance from the cutter for the radius of the circle or arc and tighten the Guide Rod Locking Knob (7) to secure in position. For a more secure attachment, a second Guide Rod Locking Knob can be used

• Make the cut, keeping the circle guide point pressed into the workpiece

Using a guide bush

• The Guide Bush (23) should be used when template cutting

• To ﬁt the Guide Bush, ﬁrst remove the protective plastic pad from underneath the Base Plate (17). The Guide Bush can then be attached using the same nuts and bolts that secure the Dust Extraction Port (16)

• The circular ﬂange should face downwards

• Replace the protective plastic pad before use

NOTE: Only use cutters with an diameter smaller than 16mm with the supplied Guide Bush

Accessories

A wide range of suitable accessories for this tool are available from your Silverline stockist, including a large selection of cutter/router bits. Spares including carbon brushes, guide bushes and collets are available from your Silverline stockist or www.toolsparesonline.com.

Maintenance

WARNING: Always remove the plug from the mains power supply before carrying out any maintenance/cleaning.

Cleaning

• Keep your tool clean at all times. Dirt and dust will cause internal parts to wear quickly, and shorten the machine’s service life. Clean the body of your machine with a soft brush, or dry cloth. If available, use clean, dry, compressed air to blow through the ventilation holes

Brushes

• Over time the carbon brushes inside the motor may become worn

• Excessively worn brushes may cause loss of power, intermittent failure, or visible sparking

• To replace the brushes, remove the two Brush Access Covers (4) & (20). Remove the worn brushes and ensure the sockets are clean. Carefully replace with new brushes and then replace the Brush Access Covers

• After ﬁtting run the router without load for 2-3 minutes to help the brushes bed in. The process of the brushes fully bedding in may take repeated uses. Motor sparking may continue until new carbon brushes have bedded in

• Alternatively, have the machine serviced at an authorised service centre

Disposal

Always adhere to national regulations when disposing of power tools that are no longer functional and are not viable for repair.

• Do not dispose of power tools, or other waste electrical and electronic equipment (WEEE), with household waste

• Contact your local waste disposal authority for information on the correct way to dispose of power tools

www.silverlinetools.com

Troubleshooting

The following chart contains information designed to assist in diagnosing and resolving router problems.

Problem Possible cause Solution

No supply of power Check that power is available at source

Router will not operate

Router runs or cuts slowly

Makes an unusual sound

Excessive vibration Bent or damaged cutter Replace cutter

Heavy sparking occurs inside

motor housing

Brushes worn or sticking

Switch is faulty Contact an authorised repair agent

Motor components faulty or short circuited Contact an authorised repair agent

Blunt or damaged cutter Resharpen or replace cutter

Variable Speed Dial (5) set low Increase variable speed setting

Motor is overloaded Reduce pushing force on router

Mechanical obstruction Contact an authorised repair agent

Armature has shorted sections Contact an authorised repair agent

Brushes not moving freely Disconnect power, remove brushes, clean or replace

Armature short circuited or open circuited Contact an authorised repair agent

Commutator dirty Contact an authorised repair agent

Disconnect power, open Brush Access Covers (4) & (20). and ensure

brushes are not damaged or heavily worn

Fine Adjustment Knob (14)

“clicks” or not adjusting

Plunge Lock Lever (15) engaged Release Plunge Lock Lever

Reached end of adjustment range Reset Fine Adjustment Knob and set depth with Depth Stop Wheel (2)

Silverline Tools Guarantee

This Silverline product comes with a 3 year guarantee

Register this product at www.silverlinetools.com within 30 days of purchase in order to qualify for the 3 year guarantee. Guarantee period begins according to the date of purchase on your sales receipt.

Terms & Conditions

Guarantee period becomes effective from the date of retail purchase as detailed on your sales receipt.

PLEASE KEEP YOUR SALES RECEIPT

If this product develops a fault within 30 days of purchase, return it to the stockist where it was purchased, with your receipt, stating details of the fault. You will receive a replacement or refund.

If this product develops a fault after the 30 day period, return it to:

Silverline Tools Service Centre PO Box 2988 Yeovil BA21 1WU, UK

The guarantee claim must be submitted during the guarantee period. You must provide the original sales receipt indicating the purchase date, your

name, address and place of purchase before any work can be carried out.

You must provide precise details of the fault requiring correction. Claims made within the guarantee period will be veriﬁed by Silverline Tools

to establish if the deﬁciencies are related to material or manufacturing of the product.

Carriage will not be refunded. Items for return must be in a suitably clean and safe state for repair, and should be packaged carefully to prevent damage or injury during transportation. We may reject unsuitable or unsafe deliveries.

All work will be carried out by Silverline Tools or its authorized repair agents.

The repair or replacement of the product will not extend the period of guarantee

Defects recognised by us as being covered by the guarantee shall be corrected by means of repair of the tool, free of charge (excluding carriage charges) or by replacement with a tool in perfect working order.

Retained tools, or parts, for which a replacement has been issued, will become the property of Silverline Tools.

1500W Router 264895

Registering your purchase

Registration is made at silverlinetools.com by selecting the Guarantee Registration button. You will need to enter:-

• Your personal details

• Details of the product and purchase information Once this information is entered your guarantee certiﬁcate will be created in

PDF format for you to print out and keep with your purchase.

The repair or replacement of your product under guarantee provides beneﬁts which are additional to and do not affect your statutory rights as a consumer.

What is covered:

The repair of the product, if it can be veriﬁed to the satisfaction of Silverline Tools that the deﬁciencies were due to faulty materials or workmanship within the guarantee period.

If any part is no longer available or out of manufacture, Silverline Tools will replace it with a functional replacement part.

Use of this product in the EU.

What is not covered:

Silverline Tools does not guarantee repairs required as a result of: Normal wear and tear caused by use in accordance with the operating

instructions eg blades, brushes, belts, bulbs, batteries etc. The replacement of any provided accessories drill bits, blades, sanding

sheets, cutting discs and other related items. Accidental damage, faults caused by negligent use or care, misuse, neglect,

careless operation or handling of the product. Use of the product for anything other than normal domestic purposes. Change or modiﬁcation of the product in any way. Use of parts and accessories which are not genuine Silverline Tools

components. Faulty installation (except installed by Silverline Tools). Repairs or alterations carried out by parties other than Silverline Tools or its

authorized repair agents. Claims other than the right to correction of faults on the tool named in these

guarantee conditions are not covered by the guarantee.

CE Declaration of Conformity

The undersigned: Mr Darrell Morris as authorised by: Silverline Tools

Declares that the

Identiﬁcation code: 264895 Description: 1500W Router

Conforms to the following Directives:

• Machinery Directive 2006/42/EC

• Low Voltage Directive 2006/95/EC

• EMC Directive 2004/108/EC

• RoHS Directive 2011/65/EU

• EN60745-1:2009

• EN60745-2-17:2010

• EN55014-1:2006+A1:2009

• EN55014-2:1997+A1:2001+A2:2008

• EN61000-3-2:2006+A1:2009+A2:2009

• EN61000-3-3:2008

Notiﬁed body: Intertek Testing Services, Hangzhou, China

The technical documentation is kept by: Silverline Tools

Date: 17/10/13

Signed by:

Director

Name and address of the manufacturer:

Powerbox Ltd., Boundary Way, Lufton Trading Estate, Yeovil, Somerset,

BA22 8HZ, United Kingdom

www.silverlinetools.com

Description des symboles

La plaque signalétique ﬁgurant sur votre outil peut présenter des symboles. Ces symboles constituent des informations importantes relatives au produit

ou des instructions concernant son utilisation.

Port de protection auditive Port de lunettes de sécurité Port du masque respiratoire Port du casque

Port de gants

Lire le manuel d’instructions

Caution!

Double isolation pour une protection supplémentaire

Conforme à la règlementation et aux normes européennes de sécurité pertinentes

Protection de l’environnement

Les produits électriques usagés ne doivent pas être jetés avec les ordures ménagères. Veuillez les recycler dans les centres prévus à cet effet. Pour de plus amples informations, veuillez contacter votre municipalité ou point de vente.

Caractéristiques techniques

Tension: ........................................230 à 240 V~ 50 Hz

Puissance: ....................................1500 W

Vitesse à vide: ..............................6000 à 26000 min

Profondeur de plongée: ................0-50 mm

Pinces de serrage:........................¼", ½", 8 et 12 mm

Diamètre de la semelle:................170 mm

Forme de la semelle: ....................Combinée : circulaire et plate

Dimensions (H x L x l): ..................320 x 300 x 140 mm

Classe de protection: ....................

Indice de protection: .....................IP20

Poids: ...........................................5,5 kg

Du fait de l’évolution constante de notre développement produits, les

caractéristiques techniques des produits Silverline peuvent changer sans

Informations concernant le bruit et les vibrations:

Pression sonore (LPA): ...................87 dB(A)

Puissance acoustique (LWA): ..........98 dB(A)

Incertitude: ...................................3 dB(A)

Vibration pondérée: ......................3,86 m/s

Incertitude: ...................................1,5 m/s

Le niveau d’intensité sonore subi par l’opérateur peut dépasser 85 dB(A) et il est

par conséquent nécessaire de prendre des mesures de protection sonore.

notiﬁcation préalable.

-1

Attention : Toujours porter des protections sonores lorsque le niveau d’intensité est supérieur à 85 dB(A) et limiter le temps d’exposition si nécessaire. Si l’intensité sonore devient inconfortable, même avec les protections, arrêter immédiatement d’utiliser l’appareil, vériﬁer que les protections soient bien mises et qu’elles soient adéquates avec le niveau sonore produit par l’appareil.

Attention : L’exposition de l’utilisateur aux vibrations peut engendrer une perte du toucher, des engourdissements, des picotements et ainsi réduire la capacité de préhension. De longues expositions peuvent également provoquer ces symptômes de façon chronique. Si nécessaire, limiter le temps d’exposition aux vibrations, et porter des gants anti-vibrations. Ne pas utilisez cet appareil avec vos mains sous des conditions en dessous de températures normales, car l’effet vibratoire en est accentué. Se référer au cas de ﬁgures des caractéristiques relatives aux vibrations pour calculer le temps et fréquence d’utilisation de l’appareil.

Les niveaux sonores et vibratoires des caractéristiques techniques sont déterminés en fonction de la norme EN60745 ou autres normes internationales. Ces données correspondent à un usage normale de l’appareil, et ce dans des conditions de travail normales. Un appareil mal entretenu, mal assemblé ou mal utilisé peut augmenter les niveaux sonores et vibratoires. Pour plus d’informations sur la directive des émissions sonores et vibratoires, visitez le site http://osha.europa.eu/fr.

Consignes générales de sécurité (pour appareils éléctriques)

AVERTISSEMENT : Veuillez lire l’intégralité des consignes de sécurité et des instructions. Le non-respect de ces consignes et instructions peut

entraîner un risque de choc électrique, d’incendie et/ou se traduire par des blessures graves.

Attention : Cet appareil n’est pas conçu pour être utilisé par des personnes (enfants compris) ayant des capacités physiques ou mentales réduites, ou n’ayant pas la connaissance ou l’expérience requise, à moins d’être sous la supervision d’une personne responsable de leur sécurité ou d’avoir reçu les instructions nécessaires. Les enfants ne doivent pas s’approcher et jouer avec cet

appareil. Veuillez conserver ces instructions et consignes de sécurité pour référence

ultérieure. L’expression « appareil électrique » employée dans les présentes consignes

recouvre aussi bien les appareils ﬁlaires à brancher sur le secteur que les appareils sans ﬁls fonctionnant sous batterie.

Sécurité sur la zone de travail

a) Maintenir une zone de travail propre et bien éclairée. Des zones

encombrées et mal éclairées sont sources d’accidents.

b) Ne pas utiliser d’outils électriques dans des environnements

explosifs, tels qu’à proximité de liquides, de gaz ou de poussières inﬂammables. Les appareils électriques produisent des étincelles

susceptibles d’enﬂammer la poussière ou les vapeurs présentes.

c) Eloigner les enfants et les passants pendant l’utilisation d’un

appareil électrique. Ceux-ci peuvent provoquer une perte d’attention

et faire perdre la maîtrise de l’appareil.

Sécurité électrique

a) La prise d’un appareil électrique doit être adaptée à la prise du

secteur. Ne jamais modiﬁer la prise en aucune façon. Ne jamais utiliser d’adaptateur sur la prise électrique d’appareil mis à la terre. Des prises non modiﬁées, adaptées aux boîtiers de prise de

courant, réduiront le risque de décharge électrique.

b) Eviter le contact corporel avec les surfaces mises à la terre telles

que tuyaux, radiateurs, cuisinières et réfrigérateurs. Le risque de

décharge électrique est plus important si le corps est mis à la terre.

c) Ne pas exposer l’appareil électrique à la pluie ou à l’humidité.

L’inﬁltration d’eau dans un appareil électrique accroît le risque de décharge électrique.

d) Ne pas maltraiter le cordon électrique. Ne jamais utiliser le

cordon électrique pour porter, tirer ou débrancher l’appareil. Protéger le cordon électrique de la chaleur, du contact avec

Défonceuse 1500 W 264895

l’essence, des bords tranchants et pièces rotatives. Un cordon électrique endommagé ou entortillé accroît le risque de décharge électrique.

e) Lors d’une utilisation de l’appareil électrique en extérieur, se

servir d’une rallonge appropriée à une utilisation en extérieur.

Cela réduit le risque de décharge électrique.

f) Si une utilisation de l’appareil électrique dans un environnement

humide ne peut être évitée, utiliser une alimentation protégée par un disjoncteur différentiel. L’utilisation d’un disjoncteur différentiel

réduit le risque de décharge électrique.

ATTENTION : Lorsque utilisé en Australie ou en Nouvelle Zélande, il est recommandé que cet appareil soit toujours alimenté via un disjoncteur différentiel ayant un courant résiduel de 30 mA ou moins.

Sécurité des personnes

a) Rester vigilent et faire preuve de bon sens lors de la manipulation de

l’appareil. Ne pas utiliser un appareil électrique lorsque l’on se trouve dans un état de fatigue, ou sous l’inﬂuence de drogues, d’alcool ou de médicaments. Un moment d’inattention pendant l’utilisation d’un outil

électrique peut se traduire par des blessures graves.

b) Porter un équipement de protection approprié. Toujours porter

une protection oculaire. Le port de masque à poussières, chaussures

de sécurité antidérapantes, casque de sécurité et protections antibruit adaptés aux différentes conditions de travail réduit le risque de blessures corporelles.

c) Eviter tout démarrage accidentel ou intempestif. S’assurer que

l’interrupteur marche-arrêt soit en position d’arrêt avant de brancher l’appareil sur l’alimentation secteur ou d’installer la batterie, de prendre l’appareil ou de le transporter. Porter un

appareil électrique tout en maintenant le doigt posé sur l’interrupteur ou brancher un appareil électrique dont l’interrupteur est sur la position de marche est source d’accidents.

d) Enlever toute clé et tout instrument de réglage avant de mettre

l’appareil électrique en marche. Une clé ou un instrument de

réglage laissé ﬁxé à un élément en rotation de l’appareil électrique peut entraîner des blessures physiques.

e) Ne pas essayer d’atteindre une zone hors de portée. Se tenir

toujours en position stable permettant de conserver l’équilibre.

Cela permet de mieux contrôler l’appareil électrique dans des situations inattendues.

f) Porter des vêtements appropriés. Ne pas porter de vêtements

amples ou des bijoux pendants. Eloigner cheveux, vêtements et gants des pièces en mouvement. Les vêtements amples, les bijoux

pendants et cheveux longs peuvent être happés par les pièces en rotation.

g) Si l’appareil est pourvu de dispositifs destinés au raccord

d’équipements d’extraction et de récupération de la poussière/ sciure, s’assurer qu’ils soient bien ﬁxés et utilisés correctement.

L’utilisation de ces dispositifs peut réduire les risques dus à la poussière.

Utilisation et entretien des appareils électriques

a) Ne pas forcer sur l’appareil électrique. Utiliser l’appareil

électrique approprié au travail à effectuer. Un appareil électrique

adapté et employé au rythme pour lequel il a été conçu permettra de réaliser un travail de meilleure qualité et dans de meilleures conditions de sécurité.

b) Ne pas utiliser un appareil électrique dont l’interrupteur marche-

arrêt est hors service. Tout appareil électrique dont la commande

ne s’effectue plus par l’interrupteur marche-arrêt est dangereux et doit être réparé.

c) Débrancher l’appareil électrique ou démonter sa batterie avant

d’effectuer tout réglage ou changement d’accessoire et avant de le ranger. De telles mesures préventives réduiront les risques de

démarrage accidentel.

d) Ranger les appareils électriques inutilisés hors de portée des

enfants et ne pas permettre l’utilisation de cet appareil aux personnes non habituées à son maniement ou n’ayant pas lu les présentes instructions. Les appareils électriques sont dangereux

dans les mains d’utilisateurs inexpérimentés.

e) Veiller à l’entretien des appareils électriques. Vériﬁer que les

éléments rotatifs soient bien alignés et non grippés. S’assurer de l’absence de pièces cassées ou endommagées susceptibles de nuire au bon fonctionnement de l'appareil. Si l’appareil électrique est endommagé, le faire réparer avant toute utilisation.

De nombreux accidents sont dus à l’utilisation d’appareils électriques mal entretenus.

f) Veiller à ce que les outils de coupe soient tenus affûtés et

propres. Des outils de coupe bien entretenus, aux tranchants bien

affûtés, sont moins susceptibles de se gripper et sont plus faciles à contrôler.

g) Utiliser l’appareil électrique, les accessoires et outils à monter

conformément à ces instructions, en tenant compte des conditions de travail et de la tâche à réaliser. Toute utilisation d’un

appareil électrique autre que celle pour laquelle il a été conçu peut entraîner des situations à risque.

Révision

a) Ne faire réparer votre appareil électrique que par un réparateur

qualiﬁé utilisant uniquement des pièces de rechange identiques.

Cela permet de maintenir la sécurité d’utilisation de l’appareil électrique.

Consignes de sécurité supplémentaires concernant les défonceuses électriques

• Ne mettez jamais la défonceuse en marche lorsque la fraise est en contact avec la pièce de travail.

• Assurez-vous que la fraise est complètement arrêtée avant de plonger l'appareil pour le mettre en position de blocage du collet.

• Ne touchez pas les fraises immédiatement après leur utilisation car elles deviennent très chaudes.

• Assurez-vous que le ressort de plongée est toujours installé pendant l’utilisation de la défonceuse à main.

• Utilisez toujours des fraises conçues pour le travail du bois et appropriées à une utilisation entre 8000 et 20000 tr/min.

• Utilisez uniquement des fraises dont le diamètre de la queue de ﬁxation correspond exactement à celui de la/des pince (s) livré(es) avec cette défonceuse.

• Il faut faire très attention de ne pas surcharger le moteur pendant l’utilisation de fraises d’un diamètre supérieur à 50 mm (2"). Déplacez très lentement l’appareil et/ou faites de multiples fraisages peu profonds pour éviter la surcharge du moteur.

• Débranchez toujours l’appareil de l’alimentation secteur avant de le régler, de le réparer ou de l’entretenir.

• Déroulez complètement le rouleau de câble de rallonge électrique aﬁn d’éviter le risque de surchauffe.

• Lorsqu’il est nécessaire d’utiliser une rallonge, il est nécessaire de s’assurer que son ampérage nominal correspond à celui de l’outil électrique et qu’elle est en bon état.

• Assurez-vous que la tension de l’alimentation secteur est la même que celle indiquée sur l’outil.

• Votre outil électrique dispose d’une double isolation pour une protection supplémentaire contre le risque de défaillance de l’isolation électrique interne de cet outil.

• Vériﬁez toujours les murs, les sols et les plafonds aﬁn d’éviter les câbles électriques et les tuyaux cachés.

• Après des longues périodes de fonctionnement, les pièces métalliques externes et les accessoires pourraient être chauds.

• Manipulez les fraises avec précaution ; elles peuvent être extrêmement coupantes.

• Vériﬁez si la fraise est endommagée ou fendue avant de l’utiliser. Si c’est le cas, remplacez-la immédiatement.

• Tenez toujours l’outil par les deux poignées et assurez-vous d’avoir une bonne prise sur la défonceuse avant d’entreprendre tout travail.

www.silverlinetools.com

+ 28 hidden pages

Silverline Plunge Router User Manual [en, de, es, fr, it]

Specifications and Main Features

Frequently Asked Questions

User Manual
