Silverline Air Micro Grinder Kit User Manual [en, de, es, fr, it]

3 Year Guarantee

*Register online within 30 days. Terms & Conditions apply

Garantie de 3 ans *Enregistrez votre produit en ligne dans les 30 jours. Sous réserve des Conditions Générales d’utilisation

3 Jahre Garantie *Registrieren Sie sich innerhalb von 30 Tagen online. Es gelten die allgemeinen Geschäftsbedingungen

3 años de garantía

*Regístrese online dentro de 30 días. Se aplican los términos y condiciones

3 anni di garanzia *Registrarsi on-line entro 30 giorni. Termini e Condizioni si applicano

3 Jaar Garantie *Registreer online binnen 30 dagen. Algemene voorwaarden van toepassing

www.silverlinetools.com

AIR

Air Micro Grinder Kit

633630

90psi

Air Micro Grinder Kit Coffret de meuleuse

pneumatique de précision Druckluft-Stabschleifer-Satz

www.silverlinetools.com

Juego de esmerilar micro Mini smerigliatrice

ad aria compressa Stift freesmachine

Fig. 1

Fig. 2

Fig. 3

AIR

90psi

Air Micro Grinder Kit

English .................. 4

Français ................ 8

Deutsch ................. 12

Español ................. 16

Italiano .................. 20

Nederlands ............ 24

www.silverlinetools.com

Description of Symbols

The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use.

Wear hearing protection Wear eye protection. Wear breathing protection Wear head protection

Wear hand protection

Read instruction Manual

Speciﬁcation

Working pressure: ..............................90psi

Air consumption: ..................................4CFM

Air inlet: ................................................1⁄4" BSP

No load speed: ......................................56000rpm

As part of our ongoing product development,

speciﬁcations of Silverline products may alter without

notice.

Carefully read and understand this manual and any label attached to the tool before use. Keep these instructions with the product for future reference. Ensure all persons who use this product are fully acquainted with this manual.

Even when used as prescribed it is not possible to eliminate all residual risk factors. Use with caution. If you are at all unsure of the correct and safe manner in which to use this tool, do not attempt to use it.

General Power Tool Safety Warnings

WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, ﬁre and/ or serious injury.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work Area Safety

a) Keep work area clean and well lit. Cluttered or dark areas invite

accidents

b) Do not operate power tools in explosive atmospheres, such as

in the presence of ﬂammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes

c) Keep children and bystanders away while operating a power tool.

Distractions can cause you to lose control

Personal Safety

a) Stay alert, watch what you are doing and use common sense

when operating a power tool. Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol or medication.

A moment of inattention while operating power tools may result in serious personal injury

b) Use personal protective equipment. Always wear eye protection.

Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries

c) Prevent unintentional starting. Ensure the switch is in the

off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your

ﬁnger on the switch or energising power tools that have the switch on invites accidents

d) Remove any adjusting key or wrench before turning the power

tool on. A wrench or a key left attached to a rotating part of the power

tool may result in personal injury

e) Do not overreach. Keep proper footing and balance at all times.

This enables better control of the power tool in unexpected situations

f) Dress properly. Do not wear loose clothing or jewellery. Keep your

hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts

g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards

Power Tool Use & Care

a) Do not force the power tool. Use the correct power tool for your

application. The correct power tool will do the job better and safer at

the rate for which it was designed

b) Do not use the power tool if the switch does not turn it on and off.

Any power tool that cannot be controlled with the switch is dangerous and must be repaired

c) Disconnect the plug from the power source and/or the battery

pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive

safety measures reduce the risk of starting the power tool accidentally

d) Store idle power tools out of the reach of children and do

not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous

in the hands of untrained users

Air Micro Grinder Kit633630

e) Maintain power tools. Check for misalignment or binding of

moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly

maintained power tools

f) Keep cutting tools sharp and clean. Properly maintained cutting

tools with sharp cutting edges are less likely to bind and are easier to control

g) Use the power tool, accessories and tool bits etc. in accordance

with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for

operations different from those intended could result in a hazardous situation

Service

a) Have your power tool serviced by a qualiﬁed repair person using

only identical replacement parts. This will ensure that the safety of

the power tool is maintained

Air Tool Safety

Dangerous environment

• Always ensure there is adequate clear space around the work area. Only use spraying tools in a well ventilated area or a specialist spray booth. Be aware that air hoses can present a trip hazard; always lay hoses in a way that minimises hazards

Protect your eyes

• Always wear safety goggles or safety glasses

Protect your hearing

• Always wear ear protection

Protection from vibration

• Hand-held air tools may produce vibration and should not be used for long periods without a break. Vibration can cause disease. Gloves may help to maintain good blood circulation in the ﬁngers.

Protective clothing

• Always wear appropriate protective equipment including but not limited to overalls, gloves, facemask etc

• It is the user’s responsibility to ensure that other persons in the vicinity of the work area are also equipped with the appropriate protective equipment

Use the correct air hose

• Use lightweight hose to connect the tool to the air compressor

• Most air tools should be ﬁtted with a coil hose; only use a straight hose

with spray guns

• When spraying, ensure that the gun is connected to a clean, ﬁltered air supply

Always disconnect

• Always ensure that your air tool has fully stopped functioning before putting it down

• Disconnect an air tool from the air supply before performing any servicing, or changing any blades, discs, or other attachments

• Ensure blades, discs or attachments are correctly ﬁtted before reconnecting to air supply

• Ensure the air tool is switched OFF before connecting to air supply. Be aware that air tools may hold residual pressure after use. Always bleed air pressure from the tool after shutting off air supply

Do not abuse the machine

• Do not overload the machine. Allowing the machine to work at its optimum speed is more efﬁcient and prolongs its service life

• Do not increase air pressure above the recommended level; excessive pressure leads to wear of moving parts, possible failure and may cause the machine casing to split

• Do not attempt to modify air tools. Any attempt to modify this air tool could result in serious injury to you or others, and will invalidate its warranty

Product Familiarisation

1 Grinder

2 Collet 3 Collet Spanners 4 ¼” BSP Quick Connector 5 Inline Oiler 6 1.5m Air Hose With Air Inlet 7 Grinding Stones 8 Machine Oil Bottle

www.silverlinetools.com

Unpacking Your Tool

• Carefully unpack and inspect your tool. Fully familiarise yourself with all features and functions of it.

• Ensure that all parts of the tool are present and in good condition. If any parts are missing or damaged, have such parts replaced before attempting to use this tool.

Operating Instructions

Silverline air tools generally operate within a maximum operating air pressure of 90psi (see speciﬁcation details). The air pressure should be controlled with a combined regulator oil/water ﬁlter ensuring a constant supply of dry air and oil to the machine. Always check the machine's operating pressure and set the regulator accordingly. Water collects in the compressor tank and this water will cause serious corrosion to your machines. The tank must be drained on a daily basis to prevent any water build up in the air supply. Dirty wet air will rapidly corrode the internal working parts of your machine and shorten its working life signiﬁcantly.

NOTE: Some air tools, including this grinder, have built in regulators, which are used to control speed/torque performance. Where a machine does not have a built in regulator the speed/torque can still be adjusted by varying the pressure on your air supply regulator.

Preparing the tool

1. Connect the Inline Oiler (5) to the air inlet, and the ¼" BSP Quick

Connector (4). Ensure tight connections

2. On the Inline Oiler (5), unscrew the screw ﬁxing to access the oil

reservoir. Fill the reservoir with air tool oil

NOTE: DO NOT UNDER ANY CIRCUMSTANCES USE NORMAL ENGINE OIL

3. Reﬁt screw to re-seal the reservoir

Fitting/removing a grinding stone

1. Ensure grinder is not connected to the air supply

2. Use one Collet Spanner (3) to clamp the drive shaft. See Fig. 2. You

may need to rotate the drive shaft until the ﬂat faces are aligned with the collar ﬁxing positions

3. Holding the drive shaft static, ﬁt the other spanner to the collet and

rotate counter-clockwise to open the collet

4. If a grinder head is in the machine, you can remove it now

To ﬁt a grinding stone

1. Insert the shank of the grinding stone into the collet as far as it will go

2. Clamp the drive shaft with one spanner. See Fig. 2

3. Fit the other spanner to the collet and rotate clockwise to tighten

Operating

1. Connect tool to air supply and turn on air supply

2. Hold the body of the machine with one hand, ensuring the grinder

head is not in contact with any object. See Fig.3

3. With the other hand, rotate barrel switch at the base of the Grinder (1)

clockwise to the ON position to start the grinder

4. Rotate barrel switch counter-clockwise to the OFF position to turn off

the grinder

IMPORTANT: Never run the grinder without oil in the inline oiler

Storage

NOTE: There is very little that can go wrong with your air tool and it should be noted that where an air tool fails to work it is generally because the internal workings have corroded due to dirty wet air and failure to follow the instructions given below

• When you store the machine after use, always ensure there is oil in the inline oiler. If necessary, top up the oil before packing the machine away neatly in its case

• Failure to comply with the operating and maintenance instructions may invalidate the guarantee

• Always store the machine neatly in the case provided

633630 Air Micro Grinder Kit

Silverline Tools Guarantee

This Silverline product comes with a 3 year guarantee

Register this product at www.silverlinetools.com within 30 days of purchase in order to qualify for the 3 year guarantee. Guarantee period begins according to the date of purchase on your sales receipt.

Registering your purchase

Registration is made at silverlinetools.com by selecting the Guarantee Registration button. You will need to enter:-

• Your personal details

• Details of the product and purchase information

Once this information is entered your guarantee certiﬁcate will be created in PDF format for you to print out and keep with your purchase.

Terms & Conditions

Guarantee period becomes effective from the date of retail purchase as detailed on your sales receipt.

PLEASE KEEP YOUR SALES RECEIPT

If this product develops a fault within 30 days of purchase, return it to the stockist where it was purchased, with your receipt, stating details of the fault. You will receive a replacement or refund.

If this product develops a fault after the 30 day period, return it to:

Silverline Tools Service Centre PO Box 2988 Yeovil BA21 1WU, UK

The guarantee claim must be submitted during the guarantee period. You must provide the original sales receipt indicating the purchase date,

your name, address and place of purchase before any work can be carried out.

You must provide precise details of the fault requiring correction. Claims made within the guarantee period will be veriﬁed by Silverline Tools

to establish if the deﬁciencies are related to material or manufacturing of the product.

Carriage will not be refunded. Items for return must be in a suitably clean and safe state for repair, and should be packaged carefully to prevent damage or injury during transportation. We may reject unsuitable or unsafe deliveries.

All work will be carried out by Silverline Tools or its authorized repair agents.

The repair or replacement of the product will not extend the period of guarantee

Defects recognised by us as being covered by the guarantee shall be corrected by means of repair of the tool, free of charge (excluding carriage charges) or by replacement with a tool in perfect working order.

Retained tools, or parts, for which a replacement has been issued, will become the property of Silverline Tools.

The repair or replacement of your product under guarantee provides beneﬁts which are additional to and do not affect your statutory rights as a consumer.

What is covered:

The repair of the product, if it can be veriﬁed to the satisfaction of Silverline Tools that the deﬁciencies were due to faulty materials or workmanship within the guarantee period.

If any part is no longer available or out of manufacture, Silverline Tools will replace it with a functional replacement part.

Use of this product in the EU.

What is not covered:

Silverline Tools does not guarantee repairs required as a result of: Normal wear and tear caused by use in accordance with the operating

instructions eg blades, brushes, belts, bulbs, batteries etc. The replacement of any provided accessories drill bits, blades, sanding

sheets, cutting discs and other related items. Accidental damage, faults caused by negligent use or care, misuse,

neglect, careless operation or handling of the product. Use of the product for anything other than normal domestic purposes. Change or modiﬁcation of the product in any way. Use of parts and accessories which are not genuine Silverline Tools

components. Faulty installation (except installed by Silverline Tools). Repairs or alterations carried out by parties other than Silverline Tools or its

authorized repair agents. Claims other than the right to correction of faults on the tool named in

these guarantee conditions are not covered by the guarantee.

www.silverlinetools.com

Description des symboles

La plaque signalétique ﬁgurant sur votre outil peut présenter des symboles. Ces symboles constituent des informations importantes relatives au produit ou des instructions concernant son utilisation.

Port de protection auditive Port de lunettes de sécurité Port de masques respiratoires

Port du casque

Lire le manuel d’instructions

Port de gants

Caractéristiques techniques

Pression d’utilisation : ..........................6,2 bar

Consommation en air : .........................113 l/min

Entrée d’air : .........................................1⁄4" BSP

Vitesse à vide : ......................................56000 tr/min

Dans le cadre du développement continu de nos produits,

les caractéristiques techniques des produits Silverline sont

sujettes à modiﬁcations sans préavis.

Lisez attentivement ce manuel ainsi que toute étiquette apposée sur l’outil et assurez-vous d’en comprendre le sens avant utilisation. Rangez ces consignes avec l’outil, pour référence ultérieure. Assurez-vous que toute personne venant à utiliser cet outil ait attentivement pris connaissance de ce manuel.

Sachez qu’utiliser un outil conformément aux prescriptions ne garantit pas l’élimination de tous les facteurs de risque. Procédez avec prudence. N’utilisez pas cet outil si vous avez des doutes quant à la manière sûre et correcte de procéder.

Consignes générales de sécurité relatives aux appareils électriques

AVERTISSEMENT Veuillez lire l’intégralité des consignes de sécurité et des instructions. Le non-respect de ces consignes et instructions peut

entraîner un risque de choc électrique, d’incendie et/ou se traduire par des blessures graves

Veuillez conserver ces instructions et consignes de sécurité pour référence ultérieure.

L’expression « appareil électrique » employée dans les présentes consignes recouvre aussi bien les appareils ﬁlaires à brancher sur le secteur que les appareils sans ﬁls fonctionnant sous batterie.

Sécurité sur la zone de travail

a) Maintenir une zone de travail propre et bien éclairée. Des zones

encombrées et mal éclairées sont sources d’accidents.

b) Ne pas utiliser d’outils électriques dans des environnements

explosifs, tels qu’à proximité de liquides, de gaz ou de poussières inﬂammables. Les appareils électriques produisent des étincelles

susceptibles d’enﬂammer la poussière ou les vapeurs présentes.

c) Eloigner les enfants et les passants pendant l’utilisation d’un

appareil électrique. Ceux-ci peuvent provoquer une perte d’attention

et faire perdre la maîtrise de l’appareil.

Sécurité des personnes

a) Rester vigilent et faire preuve de bon sens lors de la manipulation

de l’appareil. Ne pas utiliser un appareil électrique lorsque l’on se trouve dans un état de fatigue, ou sous l’inﬂuence de drogues, d’alcool ou de médicaments. Un moment d’inattention pendant

l’utilisation d’un outil électrique peut se traduire par des blessures graves.

b) Porter un équipement de protection approprié. Toujours porter

une protection oculaire. Le port de masque à poussières, chaussures

de sécurité antidérapantes, casque de sécurité et protections antibruit adaptés aux différentes conditions de travail réduit le risque de blessures corporelles.

c) Eviter tout démarrage accidentel. S’assurer que l’interrupteur

marche-arrêt soit en position d’arrêt avant de brancher l’appareil sur l’alimentation secteur ou d’installer la batterie, de prendre l’appareil ou de le transporter. Porter un appareil électrique tout en

maintenant le doigt posé sur l’interrupteur ou brancher un appareil électrique dont l’interrupteur est sur la position de marche est source d’accidents.

d) Enlever toute clé et tout instrument de réglage avant de mettre

l’appareil électrique en marche. Une clé ou un instrument de

réglage laissé ﬁxé à un élément en rotation de l’appareil électrique peut entraîner des blessures physiques.

e) Ne pas essayer d’atteindre une zone hors de portée. Se tenir

toujours en position stable permettant de conserver l’équilibre.

Cela permet de mieux contrôler l’appareil électrique dans des situations inattendues.

f) Porter des vêtements appropriés. Ne pas porter de vêtements

amples ou des bijoux pendants. Eloigner cheveux, vêtements et gants des pièces en mouvement. Les vêtements amples, les bijoux

pendants et cheveux longs peuvent être happés par les pièces en rotation.

+ 19 hidden pages
