SilentKnight Communicator Configuration User Manual
IPDACT-CONFIGURATOR Application
Setup Instructions
1. Installation Requirements
1.1. PC
• Pentium III processor or higher.
• Minimum RAM memory: 128 Mbytes.
• Operating system: Windows XP
• Free hard disk space: 30 Mbytes.
• Minimum screen resolution: 800x600, 256 colors.
• Ethernet 10/100BT network card.
1.2. IPDACT, IPDACT-2 or IPDACT-2UD
The IPDACT-Configurator application is compatible with:
IPDACT versions 4 and 5 or above.
IPDACT-2 version 5 or above.
IPDACT-2UD version 5 or above.
The IPDACT versions 4.1 and 5.0 and above can be identified via the sticker
as shown in the following figure.
IPDACT Dm 379-Iv2
TM
, Windows 2000TM.
Fig. 1
Dm379-Iv2
1
2. Installing the application
It is strongly recommended you close all programs before starting the installation
process. This is to prevent conflicts with files that are in execution when copying
files from the installation CD to the hard disk.
Place the installation CD into the PC’s CD reader. This disk starts up
automatically. Subsequently, once you have inserted the CD, the following
window will appear on your PC screen.
Fig. 2
Click on ‘Next’ to continue installation. The next screen permits you to select the
hard disk file to install the IPDACT-Configurator application. The installation
program shows a default file. Should you not want to use this, you can select a
different file to install the application using the ‘Change’ button.
Dm379-Iv2
2
Fig. 3
Press ‘Next’ to continue installation. The subsequent window shows the
application shortcut default name: ‘IPDACT Configurator’.
Dm379-Iv2
3
Fig. 4
Access the application through the Windows
TM
Start up menu: “All
programs\IPDACT Configurator\IPDACT Configurator”.
The next window displays a summary on the previously selected options before
carrying out the actual installation.
Dm379-Iv2
4
