INTRODUCTION/OVERVIEW

The S5000 Signal Management System provides an economical yet extremely versatile
platform for signal distribution and processing tasks.

Separate left and right passive rear backplanes permit differing tasks to reside within
the same frame.

PRODUCT SCOPE

The S5000 is shipped with (1) power supply and (2) backplane adapters. Three styles of
rear backplane are available From SIGMA ELECTRONICS as well as a wide variety of
distribution and processing modules. Modules and the appropriate mating backplane
options are summarized below. A redundant power supply is available as an option.

Table 1. S5000 Series Modules and Supported Backplanes

14797 • November 2004 • Introduction/Overview

Module Function

DA5305
DA5310
DA5315
DA5320
DA5325
DV5505
DV5515
SG5605
SG5610
HD5805

CI5705

Quad AES A-D Converter
Quad AES D-A Converter
OctaStream AES Delay
OctaStream AES Router/Mixer
OctaStream AES Sample Rate Converter
SDI Monitor DA
HD-SD Synchronizer
OctaStream Reference Generator
HD/SD Reference Generator
HD-SDI DA 1x 8
5000 Controller Interface

Supported Backplanes

RP302 NVision

Twisted Pair

AES

RP303

BNC AES

Analog Video

RP305

HD-SDI

SD-SDI

X X

XX
X
X
X

X
X
X

X
X

X

X

X
X

None Needed

IO594

Optical

C
O
N
T
A
C
T

N
V
I
S
I
O
N

Page 1

14797 • November 2004 • Receiving Inspection and Unpacking

RECEIVING INSPECTION AND UNPACKING

By the time you have found and opened this manual, you have already begun to unpack
the shipping container. Since damage may have occurred in shipping it is important to
perform the following checks immediately:

• Inspect the shipping container(s) for damage.

• If you find any damage to the containers, carefully inspect the product for damage.

• If any damage is discovered, notify the shipping carrier immediately.

Compare what you received against the packing slip. If anything is missing or has
suffered damage unrelated to shipping, contact SIGMA ELECTRONICS Technical
Support immediately. Contact information is located at the front of this manual.

Page 2

BACKPLANE CONFIGURATION

The S5000 can be easily reconfigured in the field if requirements change. Typically the
rear backplanes need to be replaced to accommodate a different module loading. If you
obtained the S5000 with no rear backplanes installed, or simply need to replace one
refer to the steps and figure below.

1. Remove AC power connection(s) to the frame by disconnecting the line cord(s).

2. Disconnect all cables from the frame and remove the frame from the rack. DO
NOT attempt to change backplanes with the frame installed!

3. Remove all modules from the affected side of the frame.

4. Remove the screws holding the backplane in place.

5. Gently pull the backplane assembly rearward and out of the frame.

14797 • November 2004 • Backplane Configuration

6. Install the replacement backplane being careful not to damage the copper EMI
gasket or motherboard I/O pins. It helps to line up the I/O pin side of the backplane
first.

7. Install modules, reconnect cabling and apply AC power.

Figure 1. Removing the I/O Backplane

Page 3

14797 • November 2004 • Backplane Configuration

S5000 backplane options

RP305 SWB I/O

RP303 BNC I/O

EM0305-00SD/HD-SDI

RP302 Twisted Pair I/O

Figure 2. S5000 backplanes

AES EM0303-00

EM0302-00

AES

Page 4

S5000 FRAME DESCRIPTION

The S5000 Signal Management System (part number S5000) consists of a 2 rack unit
(RU) high metal frame assembly that installs in a standard 19” wide equipment rack.
The frame includes a built-in motherboard (EM0328) that provides module
interconnections and a power distribution board (EM0326) for distributing power from
the AC inputs to the power supplies.

A removable front door with built-in cooling fan provides cooling and EMI
suppression. Modules slide into the frame from the front and plug into the backplane
and motherboard. Information about the modules is presented in the individual module
User Guides.

Figure 3 illustrates the S5000 Frame front view (door open), showing the slots for the

slide-in printed circuit modules. The following list of printed circuit modules is keyed
to the numbers on the illustration:

14797 • November 2004 • S5000 Frame Description

Frame Front View

Œ

•

Ž

•

PS5000 Power Supplies: Two power supply modules slide into the center of the frame from
the front. One is standard, the other redundant (optional). The power supplies accept 90-130/
180-250 VAC (auto-ranging) and produce DC power for all modules.

Left Bay of 5 Modules: Any of the available modules may be inserted into these slots, depend­ing on the backplane. Note that different backplanes are required for
SDI/HD-SDI video, balanced AES and unbalanced AES.

Right Bay of 5 Modules: Any of the available modules may be inserted into these slots,
depending on the backplane. Note that different backplanes are required for
SDI/HD-SDI video, balanced AES and unbalanced AES.

CI5705 Communication Interface: The module that provides communication between mod­ules in the frame and other frames is located above the power supply modules.

•

Card 1
Card 2
Card 3
Card 4

Card 5

Comm Intrfc

PS 1

PS 2

Card 6
Card 7
Card 8

Card 9
Card 10

• Ž

Œ

Figure 3. S5000 Front View with the Door Removed

Page 5

14797 • November 2004 • S5000 Frame Description

Frame Rear View

Figure 4 illustrates the S5000 Frame rear view. The following list, which is keyed to the

figure, explains the purpose of the connectors on the rear panel.

Œ

•

Ž

•

•

A B C D

A B

C

A B C D

Video Reference Inputs: Analog NTSC or PAL looping 75 ohm reference video input. Not
used with DA modules.

IEC Standard AC power connectors: Connect to AC power.

Alarms Connector: Open collector type power supply alarm outputs. May be connected to a

customer-supplied alarm indicator.
Network Connector: RS-485 9-pin D connector. Commands and queries to the CI5705 Com-

munication Interface are made through this connector.
Input/Output Connectors: Connect inputs and outputs to the modules using these connectors.

Connectors are mounted in rows directly behind the modules they serve. For example, the top
row of connectors corresponds to the top module.

•

DCBA

DCBA

D

E F H I

GE F H IJJ

G

GE F H I J

Œ •

CAUTION

JIHFE G

IHFE G J

VIDEO REF

EM0305-00SD/HD-SDI

NTWK EIA-485

ALARMS

SIGMA ELECTRONICS, INC.

5000 SERIES

90-130/180-250V~

1.2A/0.6A
50/60Hz

105 WATTS MAX

T 1.25A 250V FUSES LOCATED

ON POWER SUPPLIES

R

CONTROL NO. 9K50

PROFESSIONAL
VIDEO/AUDIO

P/S 1

P/S 2

A B C D

A B

C

A B C D

•

DCBA

DCBA

D

E F H I

IHFE G J

GE F H IJJ

G

GE F H I J

JIHFE G

SD/HD-SDI EM0305-00

Frame I/O Backplane Descriptions

Three I/O backplanes are currently available for the S5000 frame. All three backplanes
are completely passive and contain no active circuitry:

• SDI/HD-SDI Digital Video I/O (RP305)—Accepts SDI or HD-SDI modules.
Contains high quality, high data rate BNC connectors.

• AES Unbalanced I/O (RP303)—Accepts AES digital audio and analog video
modules. Uses standard BNC connectors for single-ended connections.

• AES Balanced I/O (RP302)—Accepts AES digital audio modules. Uses Phoenix
terminal block connectors for balanced connections.

The backplanes install independently on the back of the frame. The same backplane can
be used on both sides, or you can mix backplanes on the same frame.

Page 6

Ž

•

Figure 4. S5000 Rear Panel

14797 • November 2004 • S5000 Frame Specifications

S5000 FRAME SPECIFICATIONS

Table 2 lists specifications for the S5000 Signal Management System.

Table 2. S5000 Frame Specifications

Type Parameter

Electrical

AC Power 90-130/180-250 VAC, 50/60Hz, Auto-ranging
AC Fuses 1.25T - 1.25A, 250V SloBlo, 5 x 20 mm
AC Connectors 2, IEC Filtered AC
Power Consumption 105 Watts (maximum)
Regulatory Compliance UL Listed and CE Compliant

Mechanical

Module Slots 10
Power Supply Slots 2 (1 Main, 1 Optional Redundant)
Dimensions EIA Standard

2 RU (3.5 inches, 89 mm) High

19.0 inches (482.6 mm) Wide

15.0 inches (381 mm) Deep

Weight (fully loaded) 25 lbs (11.35 kg) maximum.

Video Ref Input

Type Analog PAL and/or NTSC Color Black (not required for DAs)
Connectors BNC with loop-thru
Return Loss >30dB to 5MHz

External Communications Port

Type EIA-485 (reserved for future use)
Connectors 1 9-pin D

External Alarm Port 1 3-pin Phoenix
Environmental

Operating Temperature 0 to 40 degrees Centigrade, ambient
Relative Humidity 0 to 90%, non-condensing

Page 7

14797 • November 2004 • Installing the Frame in a Rack

INSTALLING THE FRAME IN A RACK

To install the S5000 frame in an equipment rack, see Figure 5 and follow these steps:

Warning: The power cords supplied with the S5000 provide the only means of AC
mains disconnection. The equipment must be located near the AC source power outlet
and the outlet must be easily accessible to allow power to the equipment to be
disconnected quickly in an emergency.

1. Determine the placement of the 2 RU frame in the rack.

Note: Be sure to allow unrestricted cooling air flow through the front
and sides of the frame. Frames may be stacked with no space in between.

2. Attach the rack support brackets to the rear rack rails.

3. Attach the rear rack supports to the sides of the frame.

4. Lift the frame into position, inserting the rear rack supports into the slots in the
rack support brackets.

5. Secure the rack ears at the front frame to the rack with rack screws.

Rear Rack Supports

Do not block air

vents at sides

Rack Ears

Cooling Airflow

Rack Support Bracket

Page 8

Figure 5. Frame Installation

Frame Door Installation and Removal

Push latch

toward fan

to open

The frame door includes latches on both sides that must be pressed inward in order to
remove the door.

Caution: Be careful not to drop and damage the door when you release the latches. The
latches are the only mechanism holding the door in place.

When installing the door, just push the door onto the frame and the latches will latch
themselves automatically.

14797 • November 2004 • Installing the Frame in a Rack

Push latch
toward fan
to open

Figure 5-1. Removing the Frame Door

Page 9

14797 • November 2004 • Installing the Frame in a Rack

Power Supply and Communication Interface Installation and Removal

The Power Supply modules and Communication Interface install in the slots in the
center of the frame. If you have only one power supply module, install it in the bottom
center slot. The redundant supply installs directly above the main module.

The Power Supply module has a latch similar to the latches on the frame front cover
to ensure the Power Supply remains in place.

• To insert the module, simply slide it into the cell until the connector seats and the
latch snaps into position.

• To remove the Power Supply module, grasp the card pull tab while pushing the
latch to the left and pull the card straight out of its slot. (See Figure 6.)

Caution: (1) To prevent damage to the Power Supply module latch, be sure to press the
latch open (to the left) when removing the module.
Caution: (2) Heat sinks and other components may be hot. To prevent burns, avoid
touching components.

The Communication Interface installs in the slot above the redundant Power Supply.

• To insert the module, simply slide it into the cell until the connector seats.

• To remove the Communication Interface module, grasp the extractor, pivot toward
the front and pull the card straight out of its slot. (See Figure 6.)

CI5705 - Pivot
extractor toward
front, then pull card .

CARD PULL - Pull
toward you while
releasing latch.

LATCH - Push left
to release module.

Figure 6. Removing the Power Supply Module

Page 10

INSTALLING MODULES

Before you insert the printed circuit modules into the frame, make sure you are using
the correct I/O backplane.

Module Type Model Number Required I/O Backplane

Quad AES A-D Converter DA5305 AES backplane
Quad AES D-A Converter DA5310 AES backplane
OctaStream AES Delay DA5315 AES backplane
OctaStream Router/Mixer DA5320 AES backplane
OctaStream Sample Rate Converter DA5325 AES backplane
OctaStream Ref Generator SG5605 AES backplane
SDI Monitor DA DV5505 SWB backplane
HD-SDI Synchronizer DV5515 SWB backplane
HD-SDI Ref Generator SG5610 SWB backplane
HD-SDI DA 1x8 HD5805 SWB backplane

14797 • November 2004 • Installing Modules

Table 3. S5000 Backplanes

You can now insert the circuit boards into the frame. Note that boards can be inserted
and removed with power on. Referring to Figure 7, insert modules into any available
card slots, making sure the correct I/O backplane is in place for the type of modules
being inserted.

To install a module, simply insert it into the rails in the slot and push it toward the rear
of the frame until it seats into place. Be sure to push firmly on the card when it contacts
the I/O module to ensure it seats. Then make connections to it at the back of the frame.

Caution: For proper cooling, the frame door must remain closed. The door may be
opened for a short time, but irregular performance may occur. The temperature and
performance will stabilize again within 5 minutes after the door is closed.

Card 1
Card 2
Card 3
Card 4

Card 5

Comm Intrfc

PS 1

PS 2

Card 6
Card 7
Card 8

Card 9
Card 10

Figure 7. Card Locations in the Frame

Page 11

14797 • November 2004 • Making Connections to the Frame

MAKING CONNECTIONS TO THE FRAME

Make connections to the frame as described on the following pages. For the specific
inputs and outputs of a particular module, please refer to the individual user guide for
that module. The frame backplane (BNC) is shown in Figure 8 below.

A B C D

A B C D

A B C D

ON POWER SUPPLIES

CONTROL NO. 9K50

PROFESSIONAL

R

VIDEO/AUDIO

P/S 1

P/S 2

A B C D

A B C D

A B C D

DCBA

DCBA

IHFE G J

GE F H IJJ

GE F H I

GE F H I J

CAUTION

JIHFE G

VIDEO REF

EM0305-00SD/HD-SDI

NTWK EIA-485

ALARMS

SIGMA ELECTRONICS, INC.

5000 SERIES

90-130/180-250V~

1.2A/0.6A
50/60Hz

105 WATTS MAX

T 1.25A 250V FUSES LOCATED

Figure 8. S5000 Frame I/O Backplane (RP305 SWB I/O)

DCBA

DCBA

GE F H IJJ

GE F H I

GE F H I J

JIHFE G

IHFE G J

SD/HD-SDI EM0305-00

Page 12

Signal Input and Output Connections

Make connections to the AES audio, SDI video, or HD-SDI video signal input
connectors as shown in Figure 9. Use 75 ohm cable for BNC connectors or 110 ohm

shielded twisted pair cable for Phoenix connectors.

14797 • November 2004 • Making Connections to the Frame

AES or SDI/HD-SDI
BNC connection

BNC - Use 75 ohm
coaxial cable

Figure 9. Typical Input and Output Connections

External Input and Output Terminations

Unused inputs of SDI modules and both the unused inputs and unused outputs of Super
Wideband HD-SDI modules should be terminated using a customer-supplied 75-ohm
external termination.

AES Balanced Audio Connection
Using Shielded Twisted Pair Cable

+ - S

Phoenix - Use
110 ohm shielded
twisted pair cable

SDI outputs and AES inputs and outputs do not need to be terminated.

Page 13

14797 • November 2004 • Making Connections to the Frame

Alarm Connections

The ALARMS connector includes normally closed connections from pin 1 and pin 2 to
COM, which is connected to chassis ground. If both Power Supply modules fail (or AC
is disconnected from both), the pin 1 to COM circuit opens. The alarm associated with
pin 2 is reserved for future use.

Figure 10 shows one circuit that can be used with the Alarms connector. It contains

LEDs that are normally OFF and turn ON to indicate a failure.

Caution: The power supply for the alarm circuit must not exceed 30 VDC or 150 mA.
Load resistor value varies depending on voltage.

S5000

S5000 Internal

Rear Alarm

Connector

Example Circuit

LEDs switch ON to indicate fault

NC

NC

1 P/S fail

COM

2

see text

Figure 10. Alarm Connections

22k

1k

Q1

22k

1k

Q2

Alarms

1 COM 2

470

470

LED1

LED2

+

9 - 18 VDC

_

Page 14

POWER SUPPLY MODULE (PS5000)

The Power Supply module accepts and adjusts automatically to a wide range of AC
input voltages (90-130/180-250 VAC, 50/60 Hz). Regulators on the module rectify the
AC to produce +/- 7 and +/- 15 VDC which is distributed to the other modules in the
frame.

Figure 11 shows a block diagram of the Power Supply module. The input stage of the

supply includes an AC power line fuse to protect the equipment and a Power Factor
Correction (PFC) stage, which minimizes harmonics and peak currents on the line.
Following this stage a Switching Regulator produces the required DC voltages. Sharing
diodes on the DC rails allow redundant supplies to connect in parallel with isolation
between the supplies. Power for the cooling fan and the green “power on” indicator
LED comes from the +15 volt rail.

Key features of the power supply are the following:

• Power factor correction

• Auto-ranging; no input voltage selection required

• Fused input

14797 • November 2004 • Power Supply Module (PS5000)

• LED DC power present indicator

• Current, voltage, and power limiting

• Charge dump circuit drains hazardous voltages when the power supply is removed
from the frame.

Control
Circuits

Voltage, current, and

power sensing and

limiting

Switching
Regulator

AC

Fuse and

Filter

Power Factor

Correction

+7

-7

+15

-15

Figure 11. Power Supply Block Diagram

Page 15

14797 • November 2004 • Power Supply Module (PS5000)

Power Supply Test Points

There are four test points on the front edge of the power supply modules. When
checking the test points, test both the main and redundant supplies. The approximate
range of voltages that may be expected at these points is listed below. Voltages outside
of listed ranges may indicate a bad power supply module; replace with a known good
module.

Table 4. Power Supply Test Points

PS TEST POINT DC VOLTAGE RANGE

+7 +6.0 to +8.0

-7 -6.0 to -8.0
+15 +13.0 to +16.0

-15 -13.0 to -16.0

Warning: Power supply components may be hot when the power supply has been
operating. To prevent burns, do not touch components when removing power supplies.

Page 16

COMMUNICATIONS INTERFACE SETUP

The CI5705 can be used to control operation of modules within the S5000 frame. This
is accomplished via communications through a 9-pin D-subminiature connector located
on the back of the unit labeled NTWK EIA-485. Communications to the S5000 must
adhere to the RS-485 or RS-422 communications protocol.

The NTWK EIA-485 connector on the rear of the S5000 utilizes the pinout detailed in
the table which follows.

Table 5. NTWK EIA-485 Pin Assignment

PIN # FUNCTION DIRECTION

1 Ground --­2 Receive A Output- Rx Data (A)­3 Transmit B Input- TxData (B)+

14797 • November 2004 • Communications Interface Setup

4 Receive Common --­5 N/C --­6 Ground --­7 Receive B Output- Rx Data (B)+
8 Transmit A Input- Tx Data (A)­9 Ground ---

Computers equipped with only RS-232 communications ports will require an RS-232­to-RS-422/485 converter like the B&B Electronics model #4WSD9R (http://www.bb­elec.com/bb-elec/literature/4WSD9R-3903ds.pdf for more information), or others, to
successfully communicate with the S5000 frame. Carefully check the pinout of the
device you select. If it does not match the above information, an adapter cable may need
to be made.

The CI5705 communications interface needs to have a number of parameters
configured for proper operation when connected to a master controlling device via the
NTWK EIA-485 connector on the rear of the S5000.

Each frame in the system must have its own identity. The identification code is assigned
to the frame using the first three DIP switches (SW1,SW2 and SW3) of S2 located at
the front of the CI5705 card. The following table indicates the settings required for each
Frame ID.

Page 17

14797 • November 2004 • Communications Interface Setup

FRAME ID SW1 SW2 SW3

0 RESERVED
1 OFF ON ON
2 ON OFF ON
3 OFF OFF ON
4 ON ON OFF
5 OFF ON OFF
6 ON OFF OFF
7 OFF OFF OFF

Depending upon the controlling device’s operating parameters, the CI5705 may need to
have its communication speed changed. DIP switches SW4 and SW5 of S2 located at
the front of the CI5705 card are used to set the communication speed as detailed in
Table 6 below-

Table 6. Frame ID Setting

Table 7. Communication Speed

SPEED SW4 SW5

9600 ON ON

19.2K OFF ON

38.4K ON OFF

57.6K OFF OFF

Page 18

14797 • November 2004 • Communications Interface Setup

Page 19

14797 • November 2004 • S5000 System Theory of Operation

S5000 SYSTEM THEORY OF OPERATION

See Figure 12. The S5000 frame is a relatively simple system consisting of a metal rack
frame, replaceable I/O backplanes on each side of the back of the frame, a power
distribution board, and a motherboard. A variety of modules may be inserted into the
frame as desired to create a complete signal distribution and processing system.

The I/O backplanes hold the BNC or Phoenix I/O connectors to which the external
input/output cables are connected. The plug-in DA modules are fitted with connectors
that plug into the backplane BNC or Phoenix connectors to carry I/O signals onto and
off of the modules.

A rear motherboard (EM0328) inside the center rear of the frame connects to the I/O
modules and, in the case of video cards, connects directly to processing modules via
connectors at the corner of each module cell. Reference signals, DC power, and other
signals are carried between modules via the motherboard.

A Power Distribution board (EM0326) inside the center rear of the frame connects the
external AC power connectors to the Power Supply modules.

Page 20

Card Corner Connectors

Connect Here

14797 • November 2004 • S5000 System Theory of Operation

Motherboard Assembly

Power Distribution Board

AC Connectors

Figure 12. S5000 Frame Exploded View

Page 21

14797 • November 2004 • Maintenance

MAINTENANCE

The S5000 does not require any periodic electrical or physical maintenance. You may
want to check the system’s indicators occasionally to ensure that the system is operating
normally and to make sure cooling air flow through the fan in the front of the frame is
unobstructed.

Fuse Replacement

Fuses are located on Power Supply modules. If a problem occurs on a module, the first
thing to do is check the fuses. The following table lists the fuses:

LOCATION FUSE VALUE

Power Supply AC Line Fuse 5 x 20 MM Time-Delay 1.25A

Warning: Dangerous voltages and high temperatures are present on the Power Supply
Card. Take precautions to prevent burns and electric shock: Do not touch exposed
wires, connecting pins, heat sinks, or components. Handle the board by its edges.

Table 8. Power Supply Fuses

Page 22

14797 • November 2004 • Troubleshooting

TROUBLESHOOTING

Many system troubles are caused by easily-corrected errors, such as poor quality or
missing input or reference signals. Table 9 lists common problems and their solutions in
approximately the most likely order of occurrence. Try troubleshooting the system
yourself, and if you are not successful, call Sigma Electronics Technical Support, as
explained near the front of this manual.

In the event that a problem is caused by a bad circuit board, swapping the bad board
with a replacement circuit board is the quickest solution. If you need to order
replacement boards or other assemblies, call Sigma Electronics Technical Support.

Table 9. System Troubleshooting

SYMPTOM POSSIBLE CAUSES AND SOLUTIONS

System not powering up. Verify that the power cord(s) are plugged into the frame and the AC power

source. Use a voltmeter to verify the presence of power at the AC mains.

One or a few modules not powering
up or not operating properly.

Intermittent or missing signal on
outputs.

Check the DC test points on the front of the Power Supply modules (see Power

Supply Test Points on page 16.)

Check the AC line fuse on the Power Supply module. See Fuse Replacement on

page 22.

Check that the modules are fully seated in the frame.

Check input sources to make sure the signal is in good condition at the point
where it originates.

Check input and output cable continuity while wiggling the cables.

Possible low voltage on Power Supply module. Check Power supply test point
voltages. See Power Supply Test Points on page 16.

Possible bad DA/Processing module. Swap the module with a known good
module.

Page 23

14797 • November 2004 • Notes

NOTES

Page 24
