LOGO! App V1.0.0
LOGO!
Edition
Manual
Answers for industry.
03/2013
© Siemens AG 2013
LOGO! App from Siemens
The free of charge LOGO! App enables you to monitor actual process values of your LOGO! 0BA7 application with a
smart phone or a tablet PC via WLAN or Internet. It allows to switch digital signal and adjust analogue values or timer
settings. Supported will be the WLAN connection to a LOGO! 0BA7 basic module via IP address typically or DynDNSnames which are used in the Internet.
With your LOGO! App you can ...
... define customised names.
For fixed connections and preconfigured values you can define customised names. This
helps if you want to connect to several LOGO! devices and monitor different values.
Device list with names
Diagnostic information
... display diagnostic information in tabular form.
The diagnostic information of the LOGO! modules are shown as a table. Any entry in the
diagnostic buffer can be deleted via the LOGO! App only if the problem was solved.
... read and change date and time settings.
Furthermore you can read, manually change or synchronise date and time settings with
the actual date/time of your mobile device.
Date and time settings
LOGO! App from Siemens - Overview2
Security information:
The functions and solutions described in this entry are mainly limited to the realization
of the automation task. In addition, please note that suitable security measures in
compliance with the applicable Industrial Security standards must be taken, if your system is interconnected with other parts of the plant, the company's network or the Internet. More information can be found under entry ID 50203404
.
http://support.automation.siemens.com/WW/view/en/50203404
© Siemens AG 2013
LOGO! App from Siemens
With LOGO! App you can ...
... display and modify configured values in tabular form.
Preconfigured values of the LOGO! program like parameters of function blocks or network inputs and outputs can be shown as table and the value can be changed.
Table of preconfigured
values including names
Trend view o f the
configured values
... display configured values as a diagram.
Up to five of the configured values can be marked in the table shown graphically in a
trend view. No further adjustments are necessary, the scaling will be done automatically. The name and the real address of the value will be also shown in the diagram.
The monitoring and control of the system with an LOGO! Text Display or an HMI panel
is possible at the same time and won't be influenced by the LOGO! App.
Further information see under:
www.siemens.com/logo
LOGO! App from Siemens - Overview 3
