Gigaset A49H

The handset at a glance

1 Charge status of the batteries
2 Display keys
3Message key

Flashes: new messages received

4Speaker key
5 Control key (u)
6Talk key
7Directory key

(press down on the control key)

8End call key and

On/Off button

9Ringer tone on/off

(press and hold in idle status)
10 Keypad lock on/off (press and hold)
11 Flash key

- Consultation call (flash)

- Dialing pause (press and hold)
12 Microphone
13 Mute key

Please note

Charge the handset for
18 hours before first use.

1

1

U

12/11 11:56am
INT MENU

2

3
4
5
6

7
8

9
10
11
12
13

d

Display keys on handset:

Pressing a key launches the function that appears above that key in the display.

Display Function when pressed

INT
MENU

“

U

T
˜

OK

Call other registered handsets ¢ page 10.
Open main/submenu (see Menu tree ¢ page 19).
Go back one menu level.
Scroll up/down or adjust volume with u.
Move cursor to left/right with u.

Backspace deletes one character at a time.
Confirm menu function or save entry.

A49H/NAM/A31008

M2250

R301

3S19/O

i

f/16022010

2

ECO DECT

You are helping to protect the environment with your Gigaset A490.

Reduced energy consumption

Your telephone has an energy-saving adapter plug and uses less energy.

Reduced transmission power

The transmission power of your telephone is reduced automatically:

◆ The handset's transmission power is reduced depending on the distance to the base

station.

◆ The base station’s transmission power is reduced to almost zero when only one hand-

set is registered and the handset is in the base station.

You can reduce the transmission power of the handset and base station even further by
using Eco Mode. For further information, please see your phone's user guide.

A49H/NAM/A31008

M2250

R301

3S19/O

i

f/16022010

Safety precautions

Read this user guide and the safety precautions
carefully before use. Explain their contents and
the potential hazards associated with using the
telephone to your children.

Use only the power adapter sup-
plied.

$

Only insert approved rechargeable
batteries of the same type. Never use

ordinary (non-rechargeable) batteries
as they may pose a health hazard or
cause injury.

Using your telephone may affect
nearby medical equipment. Be aware
of the technical conditions in your par­ticular environment, e.g. doctor's sur­gery.

Notice to Hearing Aid Wearers:
This phone system is compatible with
inductively coupled hearing aids.

Do not install the phone in a bathroom
or shower room. The handset is not
splashproof.

Do not use your phone in environ­ments with a potential explosion haz­ard, e.g. paint shops.

If you give your phone to a third part y,
make sure you also give them the user

ƒ

guide.

Remove faulty base stations from use
as they could interfere with other wire­less services.

3

Disposal

Batteries should not be disposed of in
general household waste. Observe the
local waste disposal regulations,
details of which can be obtained from
your local authority or the dealer you
purchased the product from.
All electrical and electronic equip ment
must be disposed of separately from
general household waste using the
sites designated by local authorities.
The appropriate disposal and separate
collection of used equipment serve to
prevent potential harm to the environ­ment and to health. They are a prereq­uisite for the re-use and recycling of
used electrical and electronic equip­ment.
For further information on disposing of
your used equipment, please contact
your local authority, your refuse collec­tion service or the dealer you pur­chased the product from.

Emergency numbers cannot be dialed if the key-

¢ page 1) is activated!

pad lock (

Not all of the functions described in this user
guide are available in all countries.

Caring for your phone

Wipe down the handset with a damp cloth
(no solvents) or an antistatic cloth. Never
use a dry cloth. This can cause static.

Contact with liquid

If the handset comes into contact with liq­uid:

◆ Switch the handset off and remove the

batteries immediately.

◆ Allow the liquid to drain from the hand-

set.

◆ Pat all parts dry, then with the battery

compartment open and the keypad fac­ing down place the handset in a dry,
warm place for at least 72 hours (not in
a microwave, oven, etc.).

◆ Do not switch on the handset again

until it is completely dry.

When it has fully dried out, you will nor­mally be able to use it again.

!

A49H/NAM/A31008

M2250

R301

3S19

/

i

f/16022010

4

First steps

Checking the package contents

◆ One Gigaset A49H handset,

◆ One charging cradle with power adapter,

◆ Two batteries,

◆ One battery cover,

◆ One user guide.

Setting up the charging cradle

The charging cradle is designed for use in dry rooms in a temperature range of
+41°F to +113°F.

¤ Set up the charging cradle at a central location in your building on a flat, non-

slip surface.

Please note

Pay attention to the range of the base station.
This is up to 984 feet in unobstructed outdoor areas and up to 165 feet inside
buildings.

The feet do not usually leave any marks on surfaces. However, due to the multitude
of different varnishes and polishes used on today's furnishings, the occurrence of
marks on the surfaces cannot be completely ruled out.

Please note:

◆ Never expose the telephone to the influence of heat sources, direct sunlight or

other electrical devices.

◆ Protect your Gigaset from moisture, dust, corrosive liquids and fumes.

Connecting the base station

¤ Connect the plug from the charging cradle.

A49H/NAM/A31008

M2250

R301

3S19

/

i

f/16022010

5

Setting up the handset for use

The display is protected by a plastic film.

Please remove the protective film!

Inserting the batteries and closing the battery cover

Warn ing

Use only rechargeable nickel-metal hydride (NiMH) UL-approved AAA batter­ies recommended by Gigaset Communications GmbH (
use a conventional (non-rechargeable) battery or other battery types as this
could result in significant health risks and personal injury. For example, the
batteries could explode. The phone could also malfunction or be damaged as
a result of using batteries that are not of the recommended type.

¤ Insert the batteries with the polar-

ity in the correct direction.
The polarity is indicated in/on the
battery compartment.

¢ page 11). Never

¤ Slide the battery cover from the

bottom up onto the casing until it
clicks into place.

¤ To open the battery cover, for

instance to replace the bat­teries, press the ribbing at
the top of the battery cover
and slide it downward.

A49H/NAM/A31008

M2250

R301

3S19

/

i

f/16022010

6

Registering the handset to the base station

Before you can use the phone, you must first register the handset to the base sta­tion. The actual registration procedure will depend on the type of base station. You
must activate manual registration of the handset on both the handset and the
base station.

1. On the base station:

press and hold the registration/paging key for min. 3 sec.

2. On the handset:

within 60 sec. of pressing the registration/paging key

MENU ¢ Settings ¢ OK ¢ Handset ¢ OK ¢ Register HS ¢ OK ¢
¢ Enter the system PIN of the base station (default is 0000) ¢ OK.

Registering flashes in the display.

Registration takes approx. 1 minute.

The following is displayed after successful
registration:

If more than one handset is registered to the base
station, the internal handset number appears in the
top left of the display, e.g. 2.

INT MENU

U

Initial charging and discharging of the batteries

The correct charge level can only display if the batteries are first fully charged and
discharged.

¤ Place the handset in the base station or charging cradle for 18

18 h

hours.

¤ Then remove the handset from the base station or charging cra-

dle and do not replace it until the batteries are completely dis­charged.

◆ After the first battery charge and discharge you may replace your handset

in the base station or charging cradle after every call.

◆ Always repeat the charging and discharging procedure if you remove the

batteries from the handset and reinsert them.

◆ The batteries may warm up during charging. This is not dangerous.

◆ After a while, the charge capacity of the batteries will decrease for techni-

cal reasons.

Please ensure that the handset is in the charging cradle if you are absent for a
long time (e.g. during holidays) or remove the batteries from the handset. Oth­erwise the batteries could be damaged.

Please note

Warn ing

A49H/NAM/A31008

M2250

R301

3S19

/

i

f/16022010

7

Charge status of the batteries

The charge status is indicated by the top right display icon. After the initial charg­ing procedure a complete charging to full capacity takes at least 18 hours.

◆ e U (empty to full)

◆ e flashes: batteries almost empty

◆ U flashes: charging

Setting the date and time

Set the date and time so that the correct date and time can be assigned to incom­ing calls, and so that the alarm can be used.

MENU ¢ Settings ¢ OK ¢ Date/Time ¢ OK
¢ Date: ¢ ~ (enter the month, day and year in 6-digit format) ¢ OK
¢ Time: ¢ ~ (enter hours and minutes in 4-digit format, change am/pm by press­ing P or #) ¢ OK ¢ a (press to return to idle state)

Please note

When entering the time and date, you can move the position of an entry to the
left or right by pressing the control button up or down.

Display in idle state

Once the phone is registered and the time set, the idle
display shows as in this example. If more than one
handset is registered to the base station, the internal
handset number appears in the top left of the display,
e.g. 2.

12/11 11:56am

INT MENU

Activating/deactivating the handset

Press and hold the a key to activate or deactivate
the handset.

If you place a deactivated handset in the base station or charging cradle, it will
automatically activate.

Your phone is now ready for use.

If you have any questions about using your phone, please read the tips on trouble­shooting ("Troubleshooting"
page 16.

¢ page 12) or contact our Customer Care team

U

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

Making calls

Making external calls and ending calls

External calls are calls using the public tele­phone network.

~

(Enter the phone number) ¢c.

The phone number is dialed. (Or you can
first press and hold
and then enter the number.) During the call
you can adjust the earpiece volume using

t and set the volume with u.

End the call/cancel dialing:

Press the end call key

Accepting a call

The handset indicates an incoming call by
ringing and by a display on the screen.
Press the talk key

Auto Answer is activated (see Menu

When

¢ page 19), simply remove the hand-

tree
set from the base station/charging cradle.

In id le state, use
setting the call volume and use
volume.

Caller ID

Caller ID (CID) and Caller Name ID (CNID) are
optional subscription services provided by
your telephone service provider. These fea­tures supply incoming caller identification
information that displays on your handset.

When you get a call, the caller's number dis­plays on your handset; the caller's name
displays if it is stored in the directory or if
CNID has been requested.

®

appears in the display if you have
not requested Caller ID,
if the caller has withheld CID, and

able appears if the caller h as not requested

CID.

c to hear the dial tone

a.

c to accept the call.

t to activate the menu for

u to set the

Withheld appears

Unavail-

8

Muting

You can mute your handset when making
external calls. Your caller can no longer hear
you but you can still hear them.

Press the Mute key
activate/deactivate the function.

m during the call to

Speakerphone

Activating while dialing:

Enter the number

d. The speaker key is illuminated red

key
now.

Switching between earpiece and speaker
mode:

During a call and press the speaker key
to activate or deactivate the speakerphone.
During a call, use
for setting the speaker volume and use
to set the volume.

~ and press the speaker

t to activate the menu

Using the directory and lists

Directory

To open the directory: press v.
You can s ave up to 80 entries in the direc-

tory. Each entry can contain a maximum of
32 characters for the phone number and an
additional 14 characters for the name. For
information on entering letters and charac-

¢ page 11.

ters

Saving the first number in the directory

v

¢ New Entry? ¢ OK
¢ ~ (enter number) ¢ OK
¢ ~ (enter name) ¢ OK

Storing additional entries in the directory

v

¢ MENU ¢ New Entry ¢ OK
¢ ~ (enter number) ¢ OK
¢ ~ (enter name) ¢ OK

d

u

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

Selecting a directory entry

Open the directory with v. You hav e the
following options:

◆ Use u to scroll through the entries until

the required name is selected.

◆ Enter the first character of the name and

scroll to the entry with

u, if required.

Dialing with the directory

v ¢ u (select entry) ¢ c

Using other functions

v ¢ u (select entry) ¢ MENU

The following functions can be selected

u:

with

New Entry

Show Number

Use Number

Delete Entry

Send List

Delete List

Send List

Create and save a new
entry for the directory.

Display the phone
number.

Edit or add to the number.
Then dial or use other
functions with

Edit selected entry.

Delete selected entry.

Delete all directory
entries.

Send the complete list to
another handset

¢ page 9).

(

MENU.

Sending the directory to another handset

Prerequisites:

◆ The sending and receiving handsets

must both be registered to the same
base station.

◆ The other handset and the base station

can send and receive directory entries.

v ¢ u (select entry) ¢ MENU

¢ Send List ¢ OK ¢ u (select number of

the receiving handset) ¢ OK

While the list is being transferred the hand­set displays
set numbers affected. When the transfer is
complete, both handsets beep.

Copy #/#, identifying the hand-

9

Last number redial list

This list contains the 10 last dialed numbers.

Dialing from the last number redial list

c

(press briefly) ¢ u (select entry) ¢ c

Managing entries in the last number redial list

c (press briefly) ¢ u (select entry)

¢ MENU

You can select the following settings:

Use Number

Copy to Dir.

Delete Entry
Delete List

Calls list/network mailbox list

The message key flashes as soon as a new
entry appears in the calls list/answering

machine list. A message appears in the dis­play.
When you press the
play. If only one list contains new messages,
this opens automatically.

If calls are saved in the network mail­box, you will receive a message if the
appropriate settings have been made
(depending on your network provider).

Calls list

Prerequisite: CID (¢ page 8)

Depending on the type of list set

¢ page 19), the calls list contains:

(

◆ answered calls

◆ missed calls

Edit or add to the number.
Then dial or use other
functions with

Copy an entry to the direc­tory.

Delete selected entry.
Delete all entries.

f key, all the lists dis-

Please note

MENU.

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

Depending on the type of list set, all num­bers of the last 25 incoming calls are saved
or just the missed calls are saved.

The calls list displays as follows:

CallsList 01+02

Number of new entries + number of old, read
entries

Open the calls list

f

¢ CallsList 01+02 ¢ OK

The last incoming call displays.
If necessary, use

Using other functions

u to select another entry.

u (select entry) ¢ MENU

The following functions can be selected

u:

with

Delete Entry

Copy to Dir.

Date/Time

Status

Show Name

Delete List

Delete current entry.

Copy an entry to the direc­tory.

Call date and time (if set).

New Call: new missed call.
Old Call: entry already

read.

If you requested CNID,
you can view the name
registered for this phone
number with your net­work provider.

War ning ! All old and new
entries are deleted.

Returning a call from the calls list

f

¢ CallsList 01+02 ¢ OK

¢ u (select entry) ¢ c

Using key 1 for fast access to the network mailbox

Simply press and hold key 1 on the hand­set and you are connected directly to the
network mailbox.

See Menu tree

¢ page 19.

10

Using mutliple handsets

Making internal calls

Internal calls are free calls to other handsets
registered to the same base station.

To make a call to other handsets, press

◆ INT ¢ ~ (1...4, enter internal number

of the handset), the handset is called or

◆ INT ¢ star key P, all handsets are

called.

When a participant answers you can speak
to them. To end the call, press

a.

Internal consultation call/ connecting a call

When you are using one handset for an
external call, press the
all handsets.

◆ Before the internal participant answers,

press the end call key
diverted to the participant who answers
the call.

◆ After the internal participant answers,

you can talk to him. Press the end call

a to divert the call, or press the “

key
display key to reconnect to the external
participant.

INT key to call one or

a; the call is

Setting the alarm clock

Activating/deactivating the alarm clock

MENU ¢ Alarm Clock ¢ OK ¢ Activa­tion ¢ OK ¢ Off or On ¢ OK

When activated:

¢ Set the wake-up time ¢ OK

When the alarm clock rings, press any key to
switch it off for 24 hours. If the alarm clock
is set, the wake-up icon
screen and the wake-up time displays
instead of the date.

l appears on the

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

Setting the wake-up time

MENU ¢ Alarm Clock ¢ OK ¢ Wake-up
time ¢ OK

Enter the wake-up time in hours and min-

, change am/pm by pressing P or #,

utes
then press

OK.

Phone settings

For details on audio settings, see Menu tree

¢ page 19.

Changing the display language

MENU ¢ Settings ¢ OK ¢ Handset

¢ OK ¢ Language ¢ OK ¢ select the

language
If you accidentally choose a language you

do not understand, press

MENU ¢ v ¢ v ¢ v ¢ OK ¢ v

¢ OK

¢ OK

Select another language with u and

OK.

press

Resetting the handset

You can reset individual settings and
changes that you have made. Entries in the
directory and the handset's registration to
the base station are retained.

MENU ¢ Settings ¢ OK ¢ Handset

¢ OK ¢ Reset Handset ¢ OK ¢ Reset?
¢ OK

Cancel the reset with a.

11

Appendix

Entering letters/characters

Press the relevant key the number of times
indicated.
Briefly press the pound key
from "Abc" to "123" mode, from "123" to
"abc"mode and from "abc" to "Abc" mode.

Standard characters

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x 11x 12x13 x14x

1)

1 £ $ ¥ ¤

1

a b c 2 ä á à â ã ç

2

d e f 3 ë é è ê

I

g h i 4 ï í ì î

4

j k l 5

5

m n o 6 ö ñ ó ò ô õ

L

p q r s 7 ß

M

t u v 8 ü ú ù û

N

w x y z 9 ÿ ý æ ø å

O

. , ? ! 0 + - : ¿ ¡ " ’ ; _

Q

P
#

1) Space

* /

Abc

123

-->

-->
abc

123

( ) < = > %

# @ \ & §

Specifications

Recommended batteries

Technology: Nickel-metal-hydride
(NiMH)
Size: AAA (Micro, HR03)
Voltage: 1.2 V
Capacity: 650 mAh

We recommend the following types of bat­tery:

◆ GP 550/700 mAh

◆ Yuasa Phone 700/800 mAh

◆ Peacebay 550/650 mAh

◆ Corun Ni-MH AAAJ650 (650 mAh)

◆ Highpower HFR-44AAAJ650 (650 mAh)

(Valid at the time of going to press)
The handset is supplied with nickel-metal

hydride UL-approved AAA batteries.

# to switch

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

General specifications

DECT standard is supported*
WDCT standard is supported*
Range up to 984 feet outdoors

Operation time
(DECT version)
– Talk time
– Standby time

Operation time
(WDCT version)
– Talk time
– Standby time

Base station power
supply

Environmental con­ditions in operation

*) countr y-specific

up to 165 feet indoors

up to 12 hours
up to 177hours

up to 6 hours
up to 144 hours

100/240 V~, 50 Hz

+41°F to +113°F, 20% to
75% relative humidity

Troubl esh ooting

If you have any questions about using your
telephone, visit our website at
www.gigaset.com/customercare
for 24-hour support. The table below con­tains a list of common problems and possi­ble solutions.

Problem Cause Solution

Nothing
appears in
the display.

No wireless
connection
to the base
station,

Base flashe

s in the dis­play.

The hand­set is not
switched
on.

The batter­ies are
empty.

The hand­set is out­side the
range of
the base
station.
The hand­set is not
registered.
The base
station is
not turned
on.

Press the end call

a for approx.

key
5 seconds or place the
handset in the base
station.
Charge or replace the
batteries.

Move the handset
closer to the base
station.

Register the handset

¢ page 6.

Check the power con­nector on the base sta-

¢ page 4.

tion

12

Industry Canada Certification

Operation is subject to the following two condi­tions (1) this device may not cause interference,
and (2) this device must accept any interference,
including interference that may cause undesired
operation of the device.
NOTICE: The Industry Canada label identifies cer­tified equipment. This certification means that the
equipment meets certain telecommunications
network, protective, operational and safety
requirements as prescribed in the appropriate
Terminal Equipment Technical Requirements doc­ument(s). The Department does not guarantee
the equipment will operate to the user’s satisfac­tion.
Before installing this equipment, users should
ensure that it is permissible to be connected to
the facilities of the local telecommunications
company. The equipment must also be installed
using an acceptable method of connection. The
customer should be aware that compliance with
the above conditions may not prevent
degradation of service in some situations.
Repairs to certified equipment should be coordi­nated by a representative designated by the sup­plier. Any repairs or alterations made by the user
to this equipment, or equipment malfunctions,
may give the telecommunications company
cause to request the user to disconnect the equip­ment.
Users should ensure for their own protection that
the electrical ground connections of the power
utility, telephone lines and internal metallic water
pipe system, if present, are connected together.
This precaution may be particularly important in
rural areas
NOTE: Users should not attempt to make such
connections themselves, but should contact the
appropriate electric inspection authority,
or electrician, as appropriate.
This product meets the applicable Industry
Canada technical specifications.

The Ringer Equivalence Number is an indication
of the maximum number of devices allowed to be
connected to a telephone interface. The termina­tion of an interface may consist of any combina­tion of devices subject only to the requirement
that the sum of the RENs of all devices does not
exceed five.
This Class B digital apparatus complies with Cana­dian ICES-003.
Cet appareil numérique de la classe B est con­forme à la norme NMB-003 du Canada.

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

FCC / ACTA Information

Warning: Changes or modifications to this unit

not expressly approved by Gigaset Communica­tions USA LLC could void the FCC authority to
operate the equipment. This includes the addi­tion of any external antenna device.
This equipment complies with Part 68 of the FCC
rules and the requirements adopted by the ACTA.
On the bottom of the base station is a label that
contains, among other information, a product
identifier in the format US:AAAEQ##TXXXX. If
requested, this number must be provided to the
telephone company.
A plug and jack used to connect this equipment
to the premises wiring and telephone network
must comply with the applicable FCC Part 68 rules
and requirements adopted by the ACTA.
A compliant telephone cord and modular plug is
provided with this product. It is designed to be
connected to a compatible modular jack that is
also compliant. See installation instructions for
details.
The REN is used to determine the number of
devices that may be connected to a telephone
line. Excessive RENs on a telephone line may result
in the devices not ringing in response to an
incoming call. In most but not all areas, the sum of
RENs should no t exceed fi ve (5.0). To be certain of
the number of devices that may be connected to
a line, as determined by the total RENs, contact
the local telephone company. For products
approved after July 23, 2001, the REN for this
product is part of the product identifier that has
the format US:AAAEQ##TXXXX. The digits repre­sented by ## are the REN without a decimal po int
(e.g., 03 is a REN of 0.3). For earlier products, the
REN is separately shown on the label.
If this equipment causes harm to the telephone
network, the telephone company will notify you
advance, that temporary discontinuance of serv­ice may be required. But if advance notice isn’t
practical, the telephone company will notify the
customer as soon as possible. Also, you will be
advised of your right to file a complaint with the
FCC if you believe it is necessary.
The telephone company may make changes in its
facilities, equipment, operations or procedures
that could affect the operation of the equipment.
If this happens the telephone company will pro­vide advance notice in order for you to make nec­essary modifications to maintain uninterrupted
service. If you experience trouble with this tele­phone system, disconnect it from the network
until the problem has been corrected or until you
are sure that the equipment is not malfunction­ing.
If trouble is experienced with this equipment, for
repair or warranty information, please contact
Support at 1-866-247-8758. If the equipment is
causing harm to the telephone network, the tele­phone company may request that you disconnect
the equipment until the problem is resolved. This

13

equipment is of a type that is not intended to be
repaired by the Customer (user).
This telephone system may not be used on coin
service provided by the telephone company. Con­nection to party line ser vice is subject to state tar­iffs. Contact the state public utility commission,
public service commission or corporation com­mission for information. Privacy of communica­tions may not be ensured when using this phone.
If your home has specially wired alarm eq uipment
connected to the telephone line, ensure the
installation of this equipment does not disable
your alarm equipment. If you have questions
about what will disable alarm equipment, consult
your telephone company or a qualified installer.
This telephone system equipment has been
tested and found to comply with the limits for
Class B digital device, pursuant to Part 15 of the
FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) This device must
accept any interference received, including inter­ference that may cause undesired operation.
These limits are designed to provide reasonable
protection against harmful interference in a resi­dential installation. Some cordless telephones
operate at frequencies that may cause interfer­ence to nearby TV’s and VCR’s; to minimize or pre­vent such interference, the system base should
not be pl aced near or on t op of a TV or VC R; and , if
interference is experienced, moving the base far­ther away from the TV or VCR will often reduce or
eliminate the interference.
However, there is no guarantee that interference
will not occur in a particular installation. If this tel­ephone system does cause harmful interference
to radio or television reception, which can be
determined by turning the system off and on, the
user is encouraged to try to correct the interfer­ence by one or more of the following measures:

in

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the base sta­tion and receiver.

3. Connect the base station into an outlet on a cir­cuit different from that to which the receiver is
connected.

4. Consult the dealer or an experienced radio TV
technician for help.

Notice for Direct Inward Dialing ("DID")

ALLOWING THIS EQUIPMENT TO BE OPERATED IN
SUCH A MANNER AS TO NOT PROVIDE FOR
PROPER ANSWER SUPERVISION IS A VIOLATION
OF PART 68 OF THE FCC‘S RULES.

Notice to Hearing Aid Wearers:

This phone system is compatible with inductively
coupled hearing aids.

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

Power Outage:

In the event of a power outage, your cordless
telephone will not operate. The cordless tele­phone requires electricity for operation. You
should have a telephone that does not require
electricity available for use during power outages.

Notice:

The installation of the base unit should allow
at least 8 inches between the base and persons to
be in compliance with FCC RF exposure guide­lines.

For body worn operation, the portable part
(handset) has been tested and meets FCC RF
exposure guidelines. Use with an accessory that
contains metal parts may not ensure compliance
with FCC RF exposure guidelines.

Notice to telephone company service:
If you n eed serv ice from you r telepho ne company,
please provide them with the information
Facilit y interface Code (FIC )
Service Order Code (SOC)
Universal Service Order Code (USOC)
as indicated on the label on the bottom side of the
base station.

Safety precautions

Before using your telephone equipment, basic
safety instructions should always be followed to
reduce the risk of fire, electric shock and injury to
persons.

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on
the product.

3. Unplug this product from the wall telephone
jack and power outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use damp
cloth for cleaning.

4. Do not use this product near water, for example,
near a bathtub, wash bowl, kitchen sink, or laun­dry tub, in a wet basement or near a swimming
pool.

5. Place this product securely on a stable surface.
Serious damage and/or injury may result if the
unit falls.

6. Slots or openings in the cabinet and the back
and bottom are provided for ventilation, to pro­tect it from overheating. These openings must not
be blocked or covered. This product should never
be placed near or over a radiator or heat register,
or in a place where proper ventilation is not pro­vided.

7. This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of AC line
power to your home, consult your dealer or local
power company.

8. Do not place objects on the power cord. Install
the unit where no one can step or trip on t he cord.

14

9. Do not overload wall outlets and extension
cords as this ca n result i n the ris k of fire o r electri c
shock.

10. Never push objects of any kind into this prod­uct through cabinet slots as they may touch dan­gerous voltage points or short out parts that
could result in the risk of fire or electric shock.
Never spill liquid of any kind on this product.
11 . To r edu ce t he ris k o f el ect ri c sh ock or bur ns, do
not disassemble this produc t. Take it to a qualified
service center when service is required. Opening
or removing covers may expose you to dangerous
voltages, dangerous electrical current or other
risks. Incorrect reassembly can cause electric
shock when the appliance is subsequently used.

12. Unplug the product from the wall outlet and
refer servicing to qualified service personnel
under the following conditions:
a.) When the power cord is damaged or frayed.
b.) If liquid has been spilled into the product.
c.) If the product has been exposed to rain or
water.
d.) If the product does not operate normally by

ing the operating instructions. Adjust only

follow
those controls
instructions because improper adjustment of
other controls may result in damage and may
require extensive work by a qualified technician
to restore the product to normal operation.
e.) If the product has been dropped or physically
has been damaged.
f.) If the product exhibits a distinct change in per­formance.

13. Avoid using a telephone (other than a cordless
type) during a thunderstorm. There may be a
remote risk of electrical shock from lightning.
Therefore we suggest a surge arrestor.

14. Do not use the telephone to report a gas leak
in the vicinity of the leak.

15. Emergency/911 numbers may not be dialed if
the keypad is locked.

16. Minimum No. 26 AWG telecommunication line
cord must be used with this phone.

that are covered by the operating

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

BATTERY SAFETY PRECAUTIONS

To reduce the risk of fire, injury or electric shock,
and to properly dispose of batteries, please read
and understand the following instructions.
CONTAINS NICKEL METAL HYDRIDE BAT TERY. BAT­TERY MUST BE RECYCLED OR DISPOSED OF PROP­ERLY. DO NOT DISPOSE OF IN MUNICIPAL WASTE.

1. Only use the batteries specified for use with this
product.

2. DO NOT USE NICKEL CADMIUM OR LITHIUM
BATTERIES, or mix batteries of different sizes or
from different manufacturers in this product. DO
NOT USE NONRECHARGEABLE BATTERIES.

3. Do not dispose of the batteries in a fire; the cells
may explode. Do not expose batteries to water.
Check with local codes for special disposal
instructions.

4. Do not open or mutilate the batteries. Released
electrolyte is corrosive and may cause damage to
the eyes or skin. The electrolyte may be toxic if
swallowed.

5. Exercise care in handling the batteries in order
not to short the batteries with conducti ng materi­als such as rings, bracelets, and keys. The batteries
or conducting material may overheat and cause
burns or fire.

6. Charge the batteries provided with, or identi­fied for use with, this product only in accordance
with the instructions and limitations specified in
the user’s manual. Do not attempt to charge the
batteries with any means other than that speci­fied in the users manual.

7. Periodically clean the charge contacts on both
the charger and handset.

15

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

16

Service (Customer Care)

Customer Care Warranty for Cordless Products

product operation information, or for problem resolution, call:

To obtain Customer Care Warranty service,

Toll Free: 1-866-247-8758

End-user limited warranty

This product is covered by a one year limited war­ranty. Any repair replacement or warranty service,
and all questions about this product should be
directed to: 1-866-247-8758.

This limited, non-transferable warranty is pro­vided to the original buyer/end-consumer (" you")
for systems, handsets and accessories (collec­tively, "Product") provided by Gigaset Communi­cations USA LLC or Gigaset Communications Can­ada Inc. (collectively "Gigaset NAM"). Gigaset
NAM warrants to you that at the date o f purchase,
the Product is free of defects in workmanship and
materials and the software included in the Prod­uct will perform in substantial compliance to its
program specifications.

1. WARRANTY PERIOD

The Product warranty period is one (1) year from
the original date of purchase by you. Proof of pur­chase (e.g., sales slip or invoice) must be provided
with any Product returned during the warranty
period. Batteries supplied with the Products are
warranted to be free from defects at the time of
purchase only.

2. EXCLUSIVE REMEDY

Gigaset NAM's entire liability and your exclusive
remedy if the Product is defective in materials or
workmanship during the warranty period and is
returned shall be that the Product will be repaired
or replaced as set forth in Section 4 below. Recon­ditioned replacement components, parts or
materials may be used in the replacement or
repair. Data in the memory of the Product may be
lost during repair.

3. THIS LIMITED WARRANTY DOES NOT
COVER AND IS VOID WITH RESPECT TO
THE FOLLOWING:

– Cosmetic damage, physical damage to the

surface of the Product, including, without lim­itation, breakage, cracks, dents, scratches or
adhesive marks on the LCD screen or outside
casing of the Product.

– Products which have been repaired, main-

tained or modified (including the antenna) by
anyone other than Gigaset NAM or a Gigaset
NAM-approved repair facility, or that have
been improperly installed.

– Cost of installation, removal or reinstallation.
– Damage due to any telephone, electronic,

hardware or software program, network,
Internet or computer malfunctions, failures,
or difficulties of any kind, including without
limitation, server failure or incomplete, incor­rect, garbled or delayed computer transmis­sions.

– Equipment and components not manufac-

tured, supplied or authorized by Gigaset
NAM.

– M odification of the Product's components, or

operation of the Product in an unsuitable
environment or in a manner for which it is not
intended, including but not limited to failures
or defects caused by misuse, abuse, accidents,
physical damage, abnormal operation,
improper handling or storage, neglect, altera­tions, unauthorized installation, removal or
repairs, failure to follow instructions, prob­lems caused by the carrier's network cover­age, exposure to fire, water or excessive mois­ture or dampness, floods, or extreme changes
in climate or temperature, acts of God, riots,
acts of terrorism, spills of food or liquids,
viruses or other software flaws introduced
into the Product or other acts which are not
the fault of Gigaset NAM and which the Prod­uct is not specified to tolerate, includin g dam­age caused by mishandling or blown fuses.

– Products which have had warranty stickers,

electronic serial number and/or serial number
label removed, altered, rendered illegible or
fraudulently applied to other equipment.

– Signal reception problems (unless caused by

defect in material or workmanship in the
Product ).

– Products operated outside published maxi-

mum ratings.

– Performance of the Products when used in

combination with other products or equip­ment not manufactured, supplied or author-

ized by Gigaset NAM.
– Consumables (such as batteries and fuses).
– Payments for labor or service to representa-

tives or service centers not authorized to per-

form product maintenance by Gigaset NAM.
– Loss of data.
– Testing and examination discloses that the

alleged defect or malfunction in the Product

does not exist.

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

This warranty does not cover customer education,
instruction, installation or removal, set up adjust­ments, problems related to service(s) provided by
a carrier or other service provider, and/or signal
reception problems. Gigaset NAM shall not be
responsible for software, firmware, information,
or memory data contained in, stored on, or inte­grated with any Products returned for repair,
whether under warranty or not. This warranty is
valid only in the country in which it is purchased
(i.e., the United States of America or Canada
respectively, but not both).

USE WITH ACCESSORIES NOT SUPPLIED BY
GIGASET NAM OR NOT OTHERWISE EXPRESSLY
AUTHORIZED BY GIGASET NAM MAY VOID WAR­RANTY.

4. WARRANTY CLAIM PROCEDURE

All warranty claims must be made by notifying
Gigaset NAM prior to the expiration of the war­ranty period. Gigaset NAM's obligation to provide
warranty support shall not extend past the end of
the warranty period, except that any product
repaired or replaced during the warranty period
shall continue to be warranted for the balance of
such warranty period or thirty (30) days, which­ever is greater.

Support service will be provided for you by
accessing the toll free customer service number:
1-866-247-8758

5. LIMITATION OF WARRANTY

Gigaset NAM makes no warranty or representa­tion that the software in the Products will meet
your requirements or will work in combination
with any hardware or applications software prod­ucts provided by third parties, that the operation
of the software will be uninterrupted or error free,
or that all defects in the software products will be
corrected.

6. LIMITATION ON REMEDIES; NO
CONSEQUENTIAL OR OTHER DAMAGES

Your exclusive remedy for any breach of this lim­ited warranty is as set forth above. Except for any
refund elected by Gigaset NAM, YO U ARE NOT

ENTITLED TO ANY DAMAGES, INCLUDING BUT
NOT LIMITED TO CONSEQUENTIAL DAMAGES,

if the Product does not meet the limited warranty
, and, to the maximum extent allowed by applica­ble law, even if any remedy fails of its essential
purpose. The terms below ("Exclusion of Inciden­tal, Consequential and Certain Other Damages")
are also incorporated into this limited warranty .
Some states/jurisdictions/provinces do not allow
the exclusion or limitation of incidental or conse­quential damages, so the above limitation or
exclusion may not apply to you. This limited war­ranty gives you specific legal rights. You may have
others which vary from state/jurisdiction/prov­ince to state/jurisdiction/province.

17

7. DISCLAIMER OF WARRANTIES

GIGASET NAM AND ITS SUPPLIERS PROVIDE THE
PRODUCT AND SUPPORT SERVICES (IF ANY ) AS IS
AND WITH ALL FAULTS. THE LIMITED WARRANTY
IS IN LIEU OF ANY OTHER EXPRESS WARRANTIES
(IF ANY) CREATED BY ANY DOCUMENTATION OR
PACKAGING EXCEPT FOR THE LIMITED WAR­RANTY, AND TO THE MAXIMUM EXTENT PERMIT­TED BY APPLICABLE LAW IS IN LIEU OF ANY
IMPLIED OR STATUTORY WARRANTIES, INCLUD­ING, BUT NOT LIMITED TO, THE IMPLIED WARRAN­TIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, OF ACCURACY OR COM­PLETENESS OR RESPONSES, OF RESULTS, OF
WORKMANLIKE EFFORT, OF LACK OF VIRUSES
AND OF LACK OF NEGLIGENCE, ALL WITH REGARD
TO THE PRODUCT, AND THE PROVISION OF OR
FAILURE TO PROVIDE SUPPORT SERVICES. ALSO,
THERE IS NO WARRANTY OR CONDITION OF TITLE,
QUIET ENJOYMENT, QUIET POSSESSION, OR COR­RESPONDENCE TO DESCRIPTION OR NONIN­FRINGEMENT WITH REGARD TO THE PRODUCT.
Some states/jurisdictions/provinces do not allow
limitations on how long an implied warranty lasts
or the exclusion or limitation of incidental or con­sequential damages, so the above exclusions or
limitations may not apply to you. If an implied
warranty or condition is created by your state/
province and federal or state/provincial law pro­hibits disclaimer of it, you also have an implied
warranty or condition, BUT ONLY AS TO DEFECTS
DISCOVERED DURING THE PERIOD OF THIS LIM­ITED WARRANTY (ONE YEAR). AS TO ANY DEFECTS
DISCOVERED AFTER THE ONE YEAR PERIOD,
THERE IS NO WARRANTY OR CONDITION OF ANY
KIND. This limited warranty gives you specific
legal rights, and you may also have other rights
which vary from state to state/province to prov­ince. In no event shall Gigaset NAM's liability
exceed the cost of repairing or replacing defective
Products as provided herein, and any such liabili­ties will terminate upon expiration of the war­ranty period.

Any supplements or updates to the Product or the
software in the Product, including without limita­tion, any (if any) software fixes or upgrades or bug
fixes provided to you after the expiration of the
one year limited warranty period are not covered
by any warranty or condition, express, implied or
statutory.

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

8. EXCLUSION OF INCIDENTAL,
CONSEQUENTIAL AND CERTAIN OTHER
DAMAGES

TO THE MAXIMUM EXTENT PERMITTED BY APPLI­CABLE LAW, IN NO EVENT SHALL GIGASET NAM,
SELLER OR THEIR SUPPLIERS BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSE­QUENTIAL DAMAGES WHATSOEVER (INCLUDING,
BUT NOT LIMITED TO, DAMAGES FOR LOSS OF
PROFITS OR CONFIDENTIAL OR OTHER INFORMA­TION, FOR BUSINESS INTERRUPTION, FOR PER­SONAL INJURY, FOR LOSS OF PRIVACY, FOR FAIL­URE TO MEET ANY DUTY INCLUDING OF GOOD
FAITH OR OF REASONABLE CARE, FOR NEGLI­GENCE, AND FOR ANY OTHER PECUNIARY OR
OTHER LOSS WHATSOEVER) ARISING OUT OF OR
IN ANY WAY RELATED TO THE USE OF OR INABIL­ITY TO USE THE PRODUCT, THE PROVISION OF OR
FAILURE TO PROVIDE SUPPORT SERVICES, OR
OTHERWISE UNDER OR IN CONNECTION WITH
ANY PROVISION OF THIS LIMITED WARRANTY,
EVEN IN THE EVENT OF THE FAULT, TORT (INCLUD­ING NEGLIGENCE), STRICT LIABILITY, BREACH OF
CONTRACT OR BREACH OF WARRANTY OF
GIGASET NAM OR SELLER OR ANY SUPPLIER, AND
EVEN IF GIGASET NAM OR SELLER OR ANY SUP­PLIER HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. REPAIR OR REPLACEMENT, AS
PROVIDED UNDER THE WARRANTY, IS YOU R SOLE
AND EXCLUSIVE REMEDY FOR BREACH OF THE
LIMITED WARRANTY.

9. LIMITATION OF LIABILITY AND
REMEDIES

NOTWITHSTANDING ANY DAMAGES THAT YOU
MIGHT INCUR FOR ANY REASON WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, ALL DAM­AGES REFERENCED ABOVE AND ALL DIRECT OR
GENERAL DAMAGES), THE ENTIRE LIABILITY OF
GIGASET NAM, SELLER AND ANY OF THEIR SUP­PLIERS UNDER ANY PROVISION OF THIS LIMITED
WARRANTY AND YOUR EXCLUSIVE REMEDY FOR
ALL OF THE FOREGOING (EXCEPT FOR ANY REM­EDY OF REPAIR OR REPLACEMENT ELECTED BY
GIGASET NAM OR SELLER OR SUPPLIER WITH
RESPECT TO ANY BREACH OF THE LIMITED WAR­RANTY) SHALL BE LIMITED TO THE GREATER OF
THE AMOUNT ACTUALLY PAID BY YOU FOR THE
PRODUCT OR FIVE DOLLARS ($5.00 USD/CAN).
THE FOREGOING LIMITATIONS, EXCLUSIONS AND
DISCLAIMERS SHALL APPLY TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, EVEN IF
ANY REMEDY FAILS ITS ESSENTIAL PURPOSE.

18

10. GOVERNING LAW

If this Product was purchased in the United States
of America this limited warranty will be governed
by the laws of Texas, and exclude the United
Nations Convention on Contracts for the Interna­tional Sale of Goods. If this Product was purchased
in Canada this limited warranty will be governed
by the laws of the Province of Ontario and the fed­eral laws of Canada applicable therein, and
exclude the United Nations Convention on Con­tracts for the
International Sale of Goods.

If you want to learn more about Gigaset Service or
for Support on your Gigaset phone, visit our web

http://www.gigaset.com or please call

site at
1-866-247-8758.

Issued by
Gigaset Communications GmbH
Frankenstr. 2a, D-46395 Bocholt
Manufactured by Gigaset Communications
GmbH under trademark license of Siemens AG.

© Gigaset Communications GmbH 2009
All rights reserved.
Subject to availability. Rights of modifications
reserved.
Product attributes subject to change.
We reserve the right, to make changes without
notice in equipment design and/or components.
Part Number: A31008-M2250-R301-2-3S19
© Copyright 2009

A49H/NAM/A31008

M2250

R301

3S19/if/1602

2010

19

Menu tree

Your phone has an extensive range of fea­tures. These are offered in the form of
menus.

To select a function while the phone is in

idle state, press

Alarm Clock

Activation Activating/deactivating the alarm clock
Wake -up time Input format: HHMM,

Audio Settings

Handset Volume Earpiece 3 levels available

Ringer Volume 5 levels + "crescendo" available
Ringer Melody External Calls

Advis. Tones Switch advisory tones (e.g. positive or negative confirma-

VoiceMail

Set Key 1 Netw. Mailbx Assign key 1 with network mailbox and enter

Settings

Date/Time Enter date (MMDDYY format), then time (HHMM format, change am/pm by

Handset Language (English,

Base (Menu dependent on base station)

MENU (open menu), use

change am/pm by pressing

Speaker

Internal Calls 10 melodies available
Alarm Clock 10 melodies available

tion, menu start, key tones, battery warning) on or off.

P or #) ¢ page 7

pressing

Spanish or French)
Auto Answer Automatically activate/deactivate auto answer

Register HS Manually register the handset
Call list type Missed Calls ¢ page 9

Reset Handset Reset the handset

t and v keys to scroll to the function

the
you require and press

To return to idle state: press the

OK to confirm.

a key.

P or #

5 levels available

10 melodies available

the network mailbox number (in idle state, press
and hold key
Netw. Mailbx: your network provider's answering
machine; must be requested separately. The net­work mailbox list can display if your network pro­vider supports this function and if key
been assigned with the network mailbox.

Set the display language

1 to dial).

1 has

¢ page 11

¢ page 8

¢ page 6

All Calls ¢ page 9

¢ page 11
