Sharp R-85ST-AA User Manual

Important

R-85ST-AA

MICROWAVE OVEN WITH TOP & BOTTOM

GRILLS AND CONVECTION

OPERATION MANUAL WITH COOKBOOK

OPERATION MANUAL

This operation manual contains important information which you should read carefully before using

your microwave oven.

IMPORTANT: There may be a serious risk to health if this operation manual is not followed or if the

oven is modified so that it operates with the door open.

900 W (IEC 60705)

ENGLISH

OM_R_85ST_AA_EN.indd AOM_R_85ST_AA_EN.indd A 8/24/09 5:42:22 PM8/24/09 5:42:22 PM

Dear Customer,

Congratulations on acquiring your new combination microwave oven with top & bottom grill and convection, which from now on will make your kitchen chores considerably easier. You will be pleasantly surprised by the kinds of things you can do with your combined microwave oven. Not only can you use it for rapid defrosting or heating up of food, you can also prepare whole meals. The combination of microwave, convection and double grill means that food can cook and brown at the same time, and much faster, than by using the conventional method. In our test kitchen our microwave team has gathered together a selection of the most delicious international recipes which are quick and simple to prepare. Be inspired by the recipes we have included and prepare your own favourite dishes in your microwave oven. There are so many advantages to having a microwave oven which we are sure you will find exciting:

● Food can be prepared directly in the serving dishes, leaving less to wash up.

● Shorter cooking times and the use of little water and fat ensure that many vitamins, minerals and

characteristic flavours are preserved. We advise you to read the cookery book guide and operating instructions carefully. You will then easily understand how to use your oven.

Enjoy using your combined microwave oven and trying out the delicious recipes.

Your Microwave-Team

OM_R_85ST_AA_EN.indd Sec2:1OM_R_85ST_AA_EN.indd Sec2:1 8/24/09 5:42:22 PM8/24/09 5:42:22 PM

Attention:

Your product is

marked with this

symbol.

It means that used

electrical and

electronic products

should not be

mixed with general

household waste.

There is a separate

collection system for

these products.

A. Information on Disposal for Users

(private households)

1. In the European Union

Attention: If you want to dispose of this equipment, please do not use the ordinary dust bin!

Used electrical and electronic equipment must be treated separately and in accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment.

Following the implementation by member states private households within the EU states may return their used electrical and electronic equipment to designated collection facilities free of charge*.

In some countries* your local retailer may also take back your old product free of charge if you purchase a similar new one.

*) Please contact your local authority for further details. If your used electrical or electronic equipment has batteries or accumulators,

please dispose of these separately beforehand according to local requirements. By disposing of this product correctly you will help ensure that the waste

undergoes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health which could otherwise arise due to inappropriate waste handling.

2. In other Countries outside the EU

If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal.

For Switzerland: Used electrical or electronic equipment can be returned free of charge to the dealer, even if you don’t purchase a new product. Further collection facilities are listed on the homepage of www.swico.ch or www.sens. ch.

B. Information on Disposal for Business Users

1. In the European Union

If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of

the product. You might be charged for the costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities.

For Spain: Please contact the established collection system or your local authority for take-back of your used products.

2. In other Countries outside the EU

If you wish to discard of this product, please contact your local authorities and ask for the correct method of disposal.

OM_R_85ST_AA_EN.indd 2OM_R_85ST_AA_EN.indd 2 8/24/09 5:42:22 PM8/24/09 5:42:22 PM

CONTENTS

Operation manual

DEAR CUSTOMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

INFORMATION ON PROPER DISPOSAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-1-3

INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-3

BEFORE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-4

USING THE STOP KEY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-4

MICROWAVE POWER LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-5

MICROWAVE COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-6

HEATING WITHOUT FOOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-6

GRILL COOKING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-7

CONVECTION COOKING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-8-9

DUAL COOKING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-10-11

OTHER CONVENIENT FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-12-14

AUTOMATIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-15

AUTOMATIC COOKING CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-16-17

AUTOMATIC DEFROST CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-18

CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-19

SERVICE CALL CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-20

Cookbook

WHAT ARE MICROWAVES?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-21

THIS IS WHAT YOUR NEW COMBINATION MICROWAVE OVEN CAN DO . . . . . . . . . GB-21

SUITABLE OVENWARE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-22-23

TIPS AND ADVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-23-25

HEATING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-26

DEFROSTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-26

DEFROSTING AND COOKING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-27

COOKING MEAT, FISH AND POULTRY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-27

COOKING FRESH VEGETABLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-27

SYMBOL EXPLANATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .GB-28

COOKING CHARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-29-31

RECIPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GB-32-53

SERVICE ADDRESSES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12

SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

OM_R_85ST_AA_EN.indd 3OM_R_85ST_AA_EN.indd 3 8/24/09 5:42:22 PM8/24/09 5:42:22 PM

OVEN AND ACCESSORIES

1 Grill heating element (top grill) 2 Convection Fan 3 Oven lamp 4 Control panel 5 Door open button 6 Waveguide cover 7 Oven cavity 8 Turntable motor shaft 9 Grill heating element (bottom grill) 10 Ventilation openings 11 Door seals and sealing surfaces 12 Power cord 13 Outer cabinet

5 46 7

1 2

ACCESSORIES:

Check to make sure the following accessories are provided:

14 Turntable 15 Low rack (height: 2,5 cm) 16 High rack (height: 10,5 cm)

Place the turntable over the turntable shaft in the floor of the cavity. Before first using the turntable and racks, clean with mild soapy water. Do not cut or scratch the turntable.

Warning:

The accessories (e.g. turntable) will become very hot during GRILL, DUAL, CONVECTION and AUTOMATIC (except Defrost) modes. Always use thick oven gloves when removing the food or turntable from the oven to prevent burns.

NOTE: When you order accessories, please mention the following two items: Part name and model name to your dealer or SHARP authorised service agent.

OM_R_85ST_AA_EN.indd 4OM_R_85ST_AA_EN.indd 4 8/24/09 5:42:23 PM8/24/09 5:42:23 PM

CONTROL PANEL

1 2 3 4

Digital display and indicators:

1. TOP GRILL indicator

2. BOTTOM GRILL indicator

3. CONVECTION indicator

4. MICROWAVE indicator

5. COOKING IN PROGRESS indicator

6. LESS/MORE indicators

Operating keys:

7. AUTOMATIC keys

8. LESS/MORE keys

9. TIME keys

10. CONVECTION key

Press to change the convection setting

11. DUAL MODE key: 1 PRESS = MICROWAVE & CONVECTION

2 PRESSES = MICROWAVE & TOP GRILL 3 PRESSES = MICROWAVE & BOTTOM GRILL

12. START/+1min key

13. DOOR OPEN button

14. STOP key

15. GRILL MODE key:

1 PRESS = TOP GRILL 2 PRESSES = BOTTOM GRILL

3 PRESSES = TOP & BOTTOM GRILL

16. MICROWAVE POWER LEVEL key Press to change the microwave power setting

17. KITCHEN TIMER key

OM_R_85ST_AA_EN.indd 5OM_R_85ST_AA_EN.indd 5 8/24/09 5:42:23 PM8/24/09 5:42:23 PM

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS: READ CAREFULLY AND KEEP FOR FUTURE REFERENCE To avoid the danger of fire.

The microwave oven should not be left unattended during operation. Power levels that are too high, or cooking times that are too long, may overheat foods resulting in a fire.

This oven is designed for counter top or built-in use. Do not place the oven in a cabinet. When the oven is to be built-in, the installation frame EBR-47ST licensed by SHARP must be used. This is available from your dealer. Refer to the frame installation instructions or ask your dealer for the proper instruction procedure. Only the use of this frame will guarantee the safety and quality of the product. The electrical outlet must be readily accessible so that the unit can be unplugged easily in an emergency. The AC power supply must be 230V, 50Hz, with a minimum 16A distribution line fuse, or a minimum 16A distribution circuit breaker. A separate circuit serving only this appliance should be provided. Do not place the oven in areas where heat is generated. For example, close to a conventional oven. Do not install the oven in an area of high humidity or where moisture may collect. Do not store or use the oven outdoors.

If smoke is observed, switch off or unplug the oven and keep the door closed in order to stifle any flames.

Utensils should be checked to ensure that they are suitable for use in the oven. See Page GB-27-28. Use only microwave safe containers and utensils on microwave modes.

When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.

Clean the waveguide cover, the oven cavity and the turntable after use. These must be dry and free from grease. Built-up grease may overheat and begin to smoke or catch fire.

Do not place flammable materials near the oven or ventilation openings. Do not block the ventilation openings. Remove all metallic seals, wire twists, etc., from food and food packages. Arcing on metallic surfaces may cause a fire. Do not use the microwave oven to heat oil for deep frying. The temperature cannot be controlled and the oil may catch fire. To make popcorn, use only special microwave popcorn makers. Do not store food or any other items inside the oven. Check the settings after you start the oven to ensure the oven is operating as desired.

To avoid overheating and fire, special care must be taken when cooking or reheating foods with a high sugar or fat content, for example, Sausage rolls, Pies or Christmas pudding. See the corresponding hints in operation manual and the cookery book section.

To avoid the possibility of injury

WARNING: Do not operate the oven if it is damaged or

malfunctioning. Check the following before use:

a) The door; make sure the door closes properly and

ensure it is not misaligned or warped.

b) The hinges and safety door latches; check to make sure

they are not broken or loose.

c) The door seals and sealing surfaces; ensure that they

have not been damaged.

d) Inside the oven cavity or on the door; make sure there

are no dents.

e) The power supply cord and plug; ensure that they are

not damaged. If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

Never adjust, repair or modify the oven yourself. It is hazardous for anyone other than a competent person to carry out any service or repair operation which involves the removal of a cover which gives protection against exposure to microwave energy.

Do not operate the oven with the door open or alter the door safety latches in any way. Do not operate the oven if there is an object between the door seals and sealing surfaces.

Do not allow grease or dirt to build up on the door seals and adjacent parts. Clean the oven at regular intervals and remove any food deposits. Follow the instructions for “Care and Cleaning” on page GB-18. Failure to maintain the oven in a clean condition could lead to a deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

Individuals with PACEMAKERS should check with their doctor or the manufacturer of the pacemaker for precautions regarding microwave ovens.

To avoid the possibility of electric shock

Under no circumstances should you remove the outer cabinet. Never spill or insert any objects into the door lock openings or ventilation openings. In the event of a spill, turn off and unplug the oven immediately, and call an authorised SHARP service agent. Do not immerse the power supply cord or plug in water or any other liquid. Do not let the power supply cord hang over the edge of a table or work surface.

ENGLISH

GB-1

OM_R_85ST_AA_EN.indd Sec3:1OM_R_85ST_AA_EN.indd Sec3:1 8/24/09 5:42:24 PM8/24/09 5:42:24 PM

IMPORTANT SAFETY INSTRUCTIONS

Keep the power supply cord away from heated surfaces, including the rear of the oven. Do not attempt to replace the oven lamp yourself or allow anyone who is not an electrician authorised by SHARP to do so. If the oven lamp fails, please consult your dealer or an authorised SHARP service agent. If the power supply cord of this appliance is damaged, it must be replaced with a special cord. The exchange must be made by an authorised SHARP service agent.

To avoid the possibility of explosion and sudden boiling:

WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.

Never use sealed containers. Remove seals and lids before use. Sealed containers can explode due to a build up of pressure even after the oven has been turned off. Take care when microwaving liquids. Use a widemouthed container to allow bubbles to escape.

Never heat liquids in narrow necked containers such as baby bottles, as this may result in the contents erupting from the container when heated and cause burns.

To prevent sudden eruption of boiling liquid and possible scalding:

1. Do not use excessive amount of time (See page

GB-30).

2. Stir liquid prior to heating/reheating.

3. It is advisable to insert a glass rod or similar

utensil (not metal) into the liquid whilst reheating.

4. Let liquid stand for at least 20 seconds in the oven

at the end of cooking time to prevent delayed eruptive boiling.

Do not cook eggs in their shells, and whole hard boiled eggs should not be heated in microwave ovens since they may explode even after microwave cooking has ended. To cook or reheat eggs which have not been scrambled or mixed, pierce the yolks and the whites, or the eggs may explode. Shell and slice hard boiled eggs before reheating them in the microwave oven.

Pierce the skin of such foods as potatoes, sausages and fruit before cooking, or they may explode.

To avoid the possibility of burns

WARNING: The contents of feeding bottles and baby food jars must be stirred or shaken and the temperature checked before consumption, in order to avoid burns.

Use pot holders or oven gloves when removing food from the oven to prevent burns. Always open containers, popcorn makers, oven cooking bags, etc., away from the face and hands to avoid steam burns and eruption of boiling.

To avoid burns, always test food temperature and stir before serving and pay special attention to the temperature of food and drink given to babies, children or the elderly. during use. Young children should be kept away.

Temperature of the container is not a true indication of the temperature of the food or drink; always check the food temperature. Always stand back from the oven door when opening it to avoid burns from escaping steam and heat. Slice stuffed baked foods after heating to release steam and avoid burns.

To avoid misuse by children

WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

When the appliance is operated in the GRILL, CONVECTION, DUAL, and AUTOMATIC modes (except AUTOMATIC DEFROST), children should only use the oven under adult supervision due to the temperature generated.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

Do not lean or swing on the oven door. Do not play with the oven or use it as a toy. Children should be taught all important safety instructions: use of pot holders, careful removal of food coverings; paying special attention to packaging (e.g. self-heating materials) designed to make food crisp, as they may be extra hot.

Accessible parts may become hot

GB-2

OM_R_85ST_AA_EN.indd Sec3:2OM_R_85ST_AA_EN.indd Sec3:2 8/24/09 5:42:24 PM8/24/09 5:42:24 PM

IMPORTANT SAFETY INSTRUCTIONS

Other warnings

Never modify the oven in any way. Do not move the oven while it is in operation. This oven is for home food preparation only and may only be used for cooking food. It is not suitable for commercial or laboratory use.

To promote trouble-free use of your oven and avoid damage.

Never operate the oven when it is empty except where recommended in the operation manual, see Page GB-6. Doing so may damage the oven. When using a browning dish or self-heating material, always place a heat-resistant insulator such as a porcelain plate under it to prevent damage to the turntable due to heat stress. The preheating time specified in the dish’s instructions must not be exceeded. Do not use metal utensils, which reflect microwaves and may cause electrical arcing. Do not put cans in the oven. Use only the turntable designed for this oven. Do not use the oven without the turntable.

Do not place anything on the outer cabinet during operation. Do not use plastic containers for microwaving if the oven is still hot from using the GRILL, CONVECTION, DUAL and AUTOMATIC modes (except AUTOMATIC DEFROST) because they may melt. Plastic containers must not be used during above modes unless the container manufacturer says they are suitable.

NOTE:

If you are unsure how to connect your oven, please consult an authorised, qualified electrician. Neither the manufacturer nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the correct electrical connection procedure. Water vapour or drops may occasionally form on the oven walls or around the door seals and sealing surfaces. This is a normal occurrence and is not an indication of microwave leakage or a malfunction.

INSTALLATION

1. Remove all packing materials from the inside of the

oven cavity. Discard the loose polythene sheet from between the door and cavity. Remove the feature sticker, if attached, from the outside of the door.

Remove this film

4. The oven door may become hot during cooking. Place or mount the oven so that the bottom of the oven is 85 cm or more above the floor. Keep children away from the door to prevent them burning themselves.

5. Do not allow the power supply cord to run over any hot or sharp surfaces, such as the hot air vent area at the top rear of the oven.

6. Ensure there is a minium of free space above the

oven of 19 cm.

2. Check the oven carefully for any signs of damage.

3. Place the oven on a flat, level surface strong enough

to support the oven’s weight plus the heaviest item likely to be cooked.

This oven is designed to be used on a countertop or

built into a kitchen cabinet. When building the oven into a kitchen cabinet, see “To avoid damage of the fire” on page GB-1.

7. Securely connect the plug of the oven to a standard earthed (grounded) household electrical outlet.

19cm

ENGLISH

GB-3

OM_R_85ST_AA_EN.indd Sec1:3OM_R_85ST_AA_EN.indd Sec1:3 8/24/09 5:42:24 PM8/24/09 5:42:24 PM

BEFORE OPERATION

Your oven comes pre-set for Energy Save Mode.This facility saves electricity when the oven is not in use. When you first plug it in nothing will appear in the digital display.

To operate the oven in Energy Save Mode:

1. Plug in the oven. Nothing will appear in the

display at this time.

2. Open and close the door. The oven display will

show “. 0”.

3. Heat the oven without food (See page GB-6).

USING THE STOP KEY

In Energy Save Mode, if you do not operate the oven for 3 minutes or more (i.e. closing the door, pressing the STOP key, or at the end of cooking), you will not be able to operate the oven until you open and close the oven door.

Use the STOP key to:

1. Erase a mistake during programming.

2. Stop the oven temporarily during cooking.

3. Cancel a programme during cooking,

press the STOP key twice.

GB-4

OM_R_85ST_AA_EN.indd Sec1:4OM_R_85ST_AA_EN.indd Sec1:4 8/24/09 5:42:24 PM8/24/09 5:42:24 PM

MICROWAVE POWER LEVELS

Your oven has 6 power levels. To choose the power level, follow the advice given in the cookbook.

900 WATT = 100 % output 630 WATT = 70 % output 450 WATT = 50 % output

• To set the power, touch the MICROWAVE POWER LEVEL key until the desired level is displayed.

• If the MICROWAVE POWER LEVEL key is touched once, "900W" (100%) will be displayed. If you miss your desired level, continue touching the MICROWAVE POWER LEVEL key until you reach the level again.

• If the level is not selected, the level 900 W (100 %) is automatically set.

270 WATT = 30 % output 90 WATT = 10 % output 0 WATT = 0 % output

ENGLISH

GB-5

OM_R_85ST_AA_EN.indd Sec1:5OM_R_85ST_AA_EN.indd Sec1:5 8/24/09 5:42:25 PM8/24/09 5:42:25 PM

MICROWAVE COOKING

Your oven can be programmed for up to 99.90 minutes. (99.90).

Example: Suppose you want to heat soup for 2 minutes and 30 seconds on 630 W microwave power.

1. Set the time:

Press 1 MIN key

twice and the 10 SEC key three times.

2. Choose desired power

630 W by pressing

MICROWAVE POWER LEVEL key twice.

3. Start cooking.

Check the display

NOTES:

1. When the door is opened during the cooking

process, the cooking time on the digital display stops automatically. The cooking time starts to count down again when the door is closed and the START/+1min key is pressed.

2. If you wish to know the power level during cooking, press the MICROWAVE POWER

LEVEL key.

3. When the operation of the oven has finished, “.

NOTE FOR REHEATING READY MEALS:

Place the ready meal in a heat-resistant flan dish on the low rack.

HEATING WITHOUT FOOD

You may detect smoke or a burning smell when using the grill(s), dual grill or convection for the first time. This is normal and not a sign that the oven is out of order. To avoid this problem, when first using the oven, operate both top and bottom grills without food for 20 minutes.

1. Enter the required

heating time (20 min) by pressing the

10 MIN key twice.

2. Press the GRILL MODE key

three times.

IMPORTANT: During grill operation, to allow smoke or smells to disperse open a window or switch the kitchen ventilation on. Make sure there is no food in the oven.

As long as your finger is pressing the MICROWAVE POWER LEVEL key, the power level will be displayed.

0“ will reappear on the display.

3. Start heating.

Check the display

The oven will count down. When the oven has finished cooking, open the door to cool the oven cavity.

WARNING: The oven door, outer cabinet and oven cavity will become hot. Take care to avoid burns when cooling the oven down after operation.

GB-6

OM_R_85ST_AA_EN.indd Sec1:6OM_R_85ST_AA_EN.indd Sec1:6 8/24/09 5:42:25 PM8/24/09 5:42:25 PM

GRILL COOKING

Your oven has 2 grill heating elements, and a combination of 3 grill cooking modes. Input the time first then select the desired grill mode by pressing the GRILL MODE key as indicated below.

Press GRILL MODE key

Example:

Suppose you want to cook for 5 minutes using the TOP GRILL only.

1. Enter the desired

cooking time by pressing the 1 MIN key five times.

NOTES:

1. The high or low racks are recommended when grilling.

2. You may detect smoke or a burning smell when using the grill for the first time, this is normal and not a

sign that the oven is out of order. Please see heating without food on the previous page.

3. After cooking and opening the door, the display may show “NOW COOLING”.

2. Choose TOP GRILL

function by pressing GRILL MODE key once.

GRILL HEATING ELEMENT IN USE

Top Grill

Bottom Grill

Top & Bottom Grill together

3. Start cooking.

SYMBOL

Check the display

WARNING:

The oven cavity, door, outer cabinet, turntable, racks, dishes and especially the bottom grill will become very hot, always use thick oven gloves when removing the food or turntable from the oven to prevent burns.

ENGLISH

GB-7

OM_R_85ST_AA_EN.indd Sec1:7OM_R_85ST_AA_EN.indd Sec1:7 8/24/09 5:42:25 PM8/24/09 5:42:25 PM

CONVECTION COOKING

This microwave oven has 10 pre-set oven temperatures which use a combination of the top and bottom grills.

Press CONVECTION key

Oven Temperature (° C)

Note:

Temperature measurements taken whilst the oven is in convection mode will differ from the displayed level. This is due to the grill elements turning on and off in order to regulate the oven temperature. This will not affect the cooking results as long as the operation manual and cookbook are followed correctly.

Example 1: To cook with preheating

Suppose you want to pre-heat to 180o C and cook for 20 minutes at 180o C.

1. Enter the desired convection

temperature by pressing the CONVECTION key five times. The display will show 180° C.

3. Enter the cooking time.

Press the 10 MIN key

twice.

1 2 3 4 5 6 7 8 9 10

250 230 220 200 180 160 130 100 70 40

2. Press the START/+1min

key to start pre-heating. The display shows “PREHEAT”

4. Press the START/+1min key.

When the pre-heated temperature has been reached the audible signal sounds. The display will show “180C”. Open the door and place the food inside the oven. Close the door.

Check the display

NOTES:

1. After preheating, if you want to cook at a different temperature press the CONVECTION key until the

desired setting appears on the display. In the example above, to change the temperature you would press the CONVECTION key after entering the cooking time.

2. When the oven reaches the programmed preheating temperature, it will automatically hold at the

pre-heated temperature for 30 minutes. After 30 minutes the display will change to “. 0“. The selected convection programme will be cancelled.

3. After cooking and opening the door, the display may show “NOW COOLING”.

WARNING:

GB-8

OM_R_85ST_AA_EN.indd Sec1:8OM_R_85ST_AA_EN.indd Sec1:8 8/24/09 5:42:26 PM8/24/09 5:42:26 PM

CONVECTION COOKING

Example 2: To cook without preheating

Suppose you want to cook at 250o C for 20 minutes.

1. Enter the desired

cooking time (20 min.) by pressing the 10 MIN key twice.

NOTES:

1. After cooking and opening the door, the display may show “NOW COOLING”.

2. To change the convection temperature, press the CONVECTION key until the desired temperature appears on

the display.

WARNING: The oven cavity, door, outer cabinet, turntable, racks, dishes and especially

the bottom grill will become very hot, always use thick oven gloves when removing the food or turntable from the oven to prevent burns.

2. Select the desired

cooking temperature. (250o C).

3. Press the START/+1min key.

Check the display

ENGLISH

GB-9

OM_R_85ST_AA_EN.indd Sec1:9OM_R_85ST_AA_EN.indd Sec1:9 8/24/09 5:42:26 PM8/24/09 5:42:26 PM

DUAL COOKING

Your oven has 3 DUAL cooking modes combining the heat of the grill(s) with the power of the microwave. To select the DUAL cooking mode, press the DUAL MODE key until the desired setting appears in the display. Generally, dual cooking time shortens the total cooking time.

Press DUAL MODE key

DUAL 1

DUAL 2

DUAL 3

NOTES:

• To adjust the microwave power, press the MICROWAVE POWER LEVEL key.

• To adjust the convection temperature, press the CONVECTION key until the desired temperature appears

on the display.

• For DUAL 1 the oven temperature can be changed from 40° C to 250° C in ten levels.

Example 1:

Suppose you want to cook for 20 minutes using DUAL 1 (90 W microwave power and 200o C CONVECTION).

1. Enter the desired

cooking time (20 min.) by pressing the 10 MIN key twice.

2. Press the DUAL

Cooking method

MICRO 270 W

CONV 250° C

MICRO 270 W

TOP GRILL

MICRO 270 W

BOTTOM GRILL

MODE key once.

Microwave Power Range

90 W - 450 W

90 W - 900 W

3. Press the MICROWAVE POWER LEVEL key

once (90 W).

Symbol

4. Press CONVECTION

key three times (200o C).

5. Start cooking.

NOTE: After cooking and opening the door, the display may show “NOW COOLING”.

Check the display

GB-10

OM_R_85ST_AA_EN.indd Sec1:10OM_R_85ST_AA_EN.indd Sec1:10 8/24/09 5:42:26 PM8/24/09 5:42:26 PM

DUAL COOKING

Example 2: Suppose you want to cook for 20 minutes on DUAL 2, using 90 W microwave power and TOP GRILL.

1. Enter the desired

cooking time by pressing the 10

MIN key twice.

4. Start cooking.

NOTE: After cooking and opening the door, the display may show “NOW COOLING”.

WARNING: The oven cavity, door, outer cabinet, turntable, racks, dishes and especially

the bottom grill will become very hot, always use thick oven gloves when removing the food or turntable from the oven to prevent burns.

2. Press DUAL MODE key

twice.

Check the display

3. Press the MICROWAVE POWER LEVEL

key once (90 W).

ENGLISH

GB-11

OM_R_85ST_AA_EN.indd Sec1:11OM_R_85ST_AA_EN.indd Sec1:11 8/24/09 5:42:27 PM8/24/09 5:42:27 PM

OTHER CONVENIENT FUNCTIONS

1. MULTIPLE SEQUENCE COOKING. A sequence of 4 stages (maximum) can be programmed which may combine the MICROWAVE, GRILL, DUAL or CONVECTION modes.

EXAMPLES OF SEQUENCE COOKING:

1. Micro or Preheat + Micro + Micro + Dual or Convection or Grill or Micro

2. Micro or Preheat + Dual or Convection or Grill or Micro + Dual or Convection or Grill or Micro

3. Dual or Convection or Grill or Micro + Micro + Dual or Convection or Grill or Micro

Example: Stage 1: 10 minutes at 450 W power Stage 2: 5 minutes Dual 2 at 90 W Stage 3: 20 minutes using the TOP GRILL.

STAGE 1

1. Enter the desired cooking

time (10 minutes) by pressing the 10 MIN key once.

2. Select 450 W microwave

power by pressing the

MICROWAVE POWER LEVEL key three times.

STAGE 2

3. Enter the desired cooking

time (5 minutes) by pressing the 1 MIN key five times.

STAGE 3

6. Enter the desired

cooking time (20 minutes) by pressing the 10 MIN key twice.

4. Select DUAL MODE 2

only, by pressing the

DUAL MODE key twice.

7. Select TOP GRILL by pressing the GRILL MODE key once.

x1 x1

5. Select 90 W low power by pressing the MICROWAVE POWER LEVEL key once.

x2 x1

8. Start to cook

by pressing the START/+1min key.

Check the display

GB-12

OM_R_85ST_AA_EN.indd Sec1:12OM_R_85ST_AA_EN.indd Sec1:12 8/24/09 5:42:27 PM8/24/09 5:42:27 PM

OTHER CONVENIENT FUNCTIONS

2. LESS / MORE keys.

The LESS ( ▼ ) and MORE ( ▲ ) keys allow you to easily decrease or increase programmed setting times, (for

a less well or more well cooked result), used for AUTOMATIC operations or when cooking is underway.

a) Changing the pre-programmed time setting. Example: Suppose you want to cook 0,9 kg Roast chicken using the AUTOMATIC and MORE ( ▲ ) keys.

1. Choose the AUTOMATIC

menu for Roast chicken by pressing the

AUTOMATIC key once.

NOTES:

To cancel LESS or MORE press the same key again. To change MORE to LESS simply press the LESS ( ▼ ) key. To change LESS to MORE simply press the MORE ( ▲ ) key.

b) Changing the heating time while the oven is operating: The cooking time can be decreased or increased in 1 minute steps each time the LESS ( ▼ ) and MORE ( ▲ ) keys are pressed.

3. +1 min function The +1min function allows you to operate the following functions:

a) Direct Start

You can start to cook directly on full microwave power (900 W) and in 1 minute steps by pressing the

START/+1min key.

NOTE: To avoid children’s misuse, the START/+1min key can be used only within 2 minutes after a preceding operation, i.e., closing the door or pressing the STOP key.

2. Choose the desired result

(well cooked) by pressing the MORE key once within 2 seconds.

3. The oven will start to

cook automatically.

b) Extending the cooking time.

You can extend the cooking time in multiples of 1 minute, by pressing the START/+1min key, during the

cooking process.

ENGLISH

GB-13

OM_R_85ST_AA_EN.indd Sec1:13OM_R_85ST_AA_EN.indd Sec1:13 8/24/09 5:42:28 PM8/24/09 5:42:28 PM

OTHER CONVENIENT FUNCTIONS

4. TO CHECK SETTINGS WHILE THE OVEN IS OPERATING

You can check the power level, oven temperature, the programmed and actual oven temperatures ie:

when pre-heating.

TO CHECK THE POWER LEVEL:

To check the microwave power level during cooking press the MICROWAVE POWER LEVEL key. The oven continues to count down, although the display shows the power level.

TO CHECK THE CONVECTION TEMPERATURE:

To check the convection temperature during cooking press the CONVECTION key. When the oven is preheating, you can check the actual oven temperature.

5. KITCHEN TIMER FUNCTION

You can use the timer for timing where microwave cooking is not involved for example, to time boiled

eggs cooked on a conventional hob.

Example: To set the timer for 5 minutes.

2. Press the KITCHEN TIMER key once.

As long as your finger is pressing the key, the power level will be displayed.

As long as your finger is pressing the key, the convection temperature in ° C will be displayed.

3. Press the 1 MIN key five times.

1. Open and Close

the door to activate

KITCHEN TIMER key.

4. Press the xx (START)

key to start the timer.

GB-14

OM_R_85ST_AA_EN.indd Sec1:14OM_R_85ST_AA_EN.indd Sec1:14 8/24/09 5:42:28 PM8/24/09 5:42:28 PM

AUTOMATIC OPERATION

The AUTOMATIC keys automatically work out the correct cooking mode and cooking time of the foods illustrated below.

FROZEN PIZZA

FRENCH FRIED

POTATOES

ROAST CHICKEN

GRATIN

FISH FINGERS

What you need to know when using the AUTOMATIC keys:

1. Input the menu by pressing the desired key. The AUTOMATIC keys can only be input within 2 minutes after cooking completion, closing the door or pressing the STOP key.

2. To increase the weight press the selected key until the desired weight is displayed. Enter the weight of the

food only. Do not include the weight of the container. For food weighing more or less than the weights/quantities given in the cooking charts (see cookery book section) cook using manual operation.

3. The programmed cooking times are average times. If you want to alter the cooking times of AUTOMATIC programmes, use the LESS ( ▼ ) or MORE ( ▲ ) keys. For best results use the cooking chart instructions (see cookery book section).

4. The oven will start to cook instantly after the weight has been input.

CHILLED PIZZA

FROZEN BAGUETTES

GRILL SKEWERS CAKE AUTOMATIC DEFROST

WARNING: The oven cavity, door, outer cabinet, turntable, racks, dishes and especially

the bottom grill will become very hot, always use thick oven gloves when removing the food or turntable from the oven to prevent burns.

NOTE:

When manipulation is required (eg: to turn food over) the oven will stop and the audible signal will sound, the display will show the necessary action. To continue cooking, press the START/+1min key. The final temperature of the food will vary according to its initial temperature. Check food is piping hot after cooking. If necessary, you can extend the cooking time. Always refer to the cooking charts given in the cookery book section.

Example: Suppose you want to cook 200 g of French Fried Potatoes.

Choose the menu and quantity by pressing the FRENCH FRIED

POTATOES key once.

The oven will instantly begin to cook.

GB-15

ENGLISH

OM_R_85ST_AA_EN.indd Sec1:15OM_R_85ST_AA_EN.indd Sec1:15 8/24/09 5:42:28 PM8/24/09 5:42:28 PM

+ 47 hidden pages
