Sharp R-3731 User Manual

Important
R-3731
MICROWAVE OVEN
OPERATION MANUAL
900 W (IEC 60705)
%
%
%
1
CONTENTS
OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 6
TO REPLACE THE MAINS PLUG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
MAFF HEATING CATEGORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
BEFORE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
COOKING WITH PRE-PROGRAMMED MEMORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
PRE-SET MEMORY CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
TIME REDUCE COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
MANUAL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
MICROWAVE POWER LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
MICROWAVE COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
DEFROSTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
OTHER CONVENIENT FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 - 17
CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
SERVICE CALL CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
COOKBOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 - 27
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
OPERATION MANUAL
This operation manual contains important information which you should read carefully before
using your microwave oven.
IMPORTANT: There may be a serious risk to health if this operation manual is not followed or if
the oven is modified so that it operates with the door open.
2
OVEN AND ACCESSORIES
1
2
9
7
8
5
4
3
10
11
6
1 Door 2 Door hinges 3 Oven lamp 4 Waveguide cover 5 Control panel 6 Door opening button 7 Door lock openings 8 Coupling 9 Oven cavity 10 Door seals and sealing surfaces 11 Door safety latches 12 Ventilation openings 13 Outer cabinet 14 Power supply cord
15
16
12
13
14
ACCESSORIES:
Check to make sure the following accessories are provided:
(15) Turntable (16) Roller stay
Place the turntable support in the centre of the oven floor so that it can freely rotate around the coupling. Place the turntable onto the turntable support so that it locates firmly into the coupling. To avoid turntable damage, ensure dishes or containers are lifted clear of the turntable rim when removing them from the oven.
NOTE: When you order accessories, please mention two items: part name and model name to your dealer or SHARP authorised service agent.
Coupling
CONTROL PANEL
3
1. DIGITAL DISPLAY
2. INDICATORS:
These indicators will light corresponding with below symbols
:Time reduce : Memory :Manual : Percentage (for microwave
power level) : Lock (showing oven lock is set) : Cook (showing oven in operation)
OPERATION KEYS:
3. NUMBER keys for time and memory
programming
4. START key
5. DOOR OPENING button
6. STOP key
7. TIME REDUCE key
8. MEMORY key
9. SOUND key
10. TIMER key
11. DEFROST key
12. AUTO MINUTE key
13. MICROWAVE POWER key
To change the microwave power setting
14. MANUAL key
1
14
13
12
11
10
9
8
7
6
2
3
4
5
%
4
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTION: READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
To avoid the danger of fire.
The microwave oven should not be left unattended during operation. Power levels that are too high, or cooking times that are too long, may overheat foods resulting in a fire.
This oven is not designed to built into a kitchen unit. The electrical outlet must be readily accessible so that the unit can be unplugged easily in an emergency. The AC power supply must be 230-240V, 50Hz. It is recommended that a separate circuit serving only this appliance be provided. Do not place the oven in areas where heat is generated. For example, close to a conventional oven. Do not install the oven in an area of high humidity or where moisture may collect. Do not store or use the oven outdoors.
If food being heated begins to smoke, DO NOT OPEN THE DOOR. Turn off and unplug the oven and wait until the food has stopped smoking. Opening the door while food is smoking may cause a fire
Use only microwave-safe containers and utensils. See pages 19 - 20.
Do not leave the oven unattended when using disposable plastic, paper or other combustible food containers
Clean the waveguide cover, the oven cavity, the turntable and roller stay after use. These must be dry and free from grease. Built-up grease may overheat and begin to smoke or catch fire.
Do not place flammable materials near the oven or ventilation openings. Do not block the ventilation openings. Remove all metallic seals, wire twists, etc., from food and food packages. Arcing on metallic surfaces may cause a fire. Do not use the microwave oven to heat oil for deep frying. The temperature cannot be controlled and the oil may catch fire.
To make popcorn, use only special microwave popcorn makers. Do not store food or any other items inside the oven. Check the settings after you start the oven to ensure the oven is operating as desired. See the corresponding hints in this operation manual and the cookery book section.
To avoid the possibility of injury
WARNING:
Do not operate the oven if it is damaged or malfunctioning. Check the following before use: a)The door; make sure the door closes properly
and ensure it is not misaligned or warped.
b)The hinges and safety door latches; check to
make sure they are not broken or loose.
c)The door seals and sealing surfaces; ensure
that they have not been damaged.
d)Inside the oven cavity or on the door; make
sure there are no dents.
e)The power supply cord and plug; ensure that
they are not damaged.
Never adjust , repair or modify the oven yourself. It is hazardous for anyone other than a competent person to carry out any service or repair operation which involves the removal of a cover which gives protection against exposure to microwave energy.
Do not operate the oven with the door open or alter the door safety latches in any way. Do not operate the oven if there is an object between the door seals and sealing surfaces.
Do not allow grease or dirt to build up on the door seals and adjacent parts. Clean the oven at regular intervals and remove any food deposits. Follow the instructions for “Care and Cleaning” on page 18. Failure to maintain the oven in a clean condition could lead to a deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.
5
IMPORTANT SAFETY INSTRUCTIONS
Individuals with PACEMAKERS should check with their doctor or the manufacturer of the pacemaker for precautions regarding microwave ovens.
To avoid the possibility of electric shock
Under no circumstances should you remove the outer cabinet. Never spill or insert any objects into the door lock openings or ventilation openings. In the event of a spill, turn off and unplug the oven immediately, and call an authorised SHARP service agent. Do not let the power supply cord hang over the edge of a table or work surface. Keep the power supply cord away from heated surfaces, including the rear of the oven. Do not attempt to replace the oven lamp yourself or allow anyone who is not an electrician authorised by SHARP to do so. If the oven lamp fails, please consult your dealer or an authorised SHARP service agent.
To avoid the possibility of explosion and sudden boiling:
WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.
Never use sealed containers. Remove seals and lids before use. Sealed containers can explode due to a build up of pressure even after the oven has been turned off. Take care when microwaving liquids. Use a wide­mouthed container to allow bubbles to escape.
Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to be taken when handling the container.
To prevent sudden eruption of boiling liquid and possible scalding:
1. Stir liquid prior to heating/reheating.
2. It is advisable to insert a glass rod or similar
utensil into the liquid whilst reheating.
3. Let liquid stand for at least 20 seconds in the
oven at the end of cooking time to prevent delayed eruptive boiling.
Do not cook eggs in their shells, and whole hard boiled eggs should not be heated in microwave ovens since they may explode even after microwave cooking has ended. To cook or reheat eggs which have not been scrambled or mixed, pierce the yolks and the whites, or the eggs may explode. Shell and slice hard boiled eggs before reheating them in the microwave oven.
Pierce the skin of such foods as potatoes, sausages and fruit before cooking, or they may explode.
To avoid the possibility of burns
Use pot holders or oven gloves when removing food from the oven to prevent burns. Always open containers, popcorn makers, oven cooking bags, etc., away from the face and hands to avoid steam burns.
To avoid burns, always test food temperature and stir before serving and pay special attention to the temperature of food and drink given to babies, children or the elderly.
Temperature of the container is not a true indication of the temperature of the food or drink; always check the food temperature. Always stand back from the oven door when opening to avoid burns from escaping steam and heat. Slice stuffed baked foods after heating to release steam and avoid burns. Keep children away from the door to prevent them burning themselves.
To avoid misuse by children
WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.
Do not lean or swing on the oven door. Do not play with the oven or use it as a toy. Children should be taught all important safety instructions: use of pot holders, careful removal of food coverings; paying special attention to packaging (e.g. self-heating materials) designed to make food crisp, as they may be extra hot.
6
IMPORTANT SAFETY INSTRUCTIONS
Other warnings
Never modify the oven in any way. Do not move the oven while it is in operation. This oven is for home food preparation only and may only be used for cooking food. It is not suitable for commercial or laboratory use.
To promote trouble-free use of your oven and avoid damage.
Never operate the oven when it is empty. When using a browning dish or self-heating material, always place a heat-resistant insulator such as a porcelain plate under it to prevent damage to the turntable and roller stay due to heat stress. The preheating time specified in the dishes instructions must not be exceeded. Do not use metal utensils, which reflect microwaves and may cause electrical arcing. Do not put cans in the oven. Use only the turntable and the roller stay designed for this oven. To prevent the turntable from breaking: (a)Before cleaning the turntable with water, leave
the turntable to cool.
(b)Do not put hot foods or hot utensils on a cold
turntable.
(c) Do not put cold foods or cold utensils on a hot
turntable. Do not place anything on the outer cabinet during operation.
NOTE:
If you are unsure how to connect your oven, please consult an authorised, qualified electrician. Neither the manufacturer nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the correct electrical connection procedure. Water vapour or drops may occasionally form on the oven walls or around the door seals and sealing surfaces. This is a normal occurrence and is not an indication of microwave leakage or a malfunction.
IMPORTANT! ELECTRICAL CONNECTION.
•Do not allow water to come into contact with the power supply cord or plug.
• Insert the plug properly into the socket.
• Do not connect other appliances to the same socket using an adaptor plug.
• If the plug or socket is loose or the power supply cord is damaged, it must be replaced with a special cord. The exchange must be made by a SHARP approved service facility.
•When removing the plug from the socket always grip the plug, never the cord as this may damage the power supply cord and the connections inside the plug.
• If the fitted mains plug to your oven is a rewireable type and in the unlikely event of the socket outlet in your home not being compatible with the plug supplied, remove the plug and fit an appropriate type, observing the wiring code given in `To replace the mains plug’ on page 7. If you wish to remove or replace the plug supplied, ensure the plug is removed properly and not cut off.
• If the plug fitted to your oven is a non-rewirable plug and in the unlikely event of the socket outlet in your home not being compatible with the plug supplied, cut-off the mains plug and fit an appropriate type, observing the wiring code given in `To replace the mains plug’ on page 7.
Danger:
The fuse from the cut-off plug should be removed and the plug disposed of in a safe manner. Under no circumstances should the cut-off plug be inserted into a socket outlet as a serious electric shock may occur. The plug must not be used without the fuse cover fitted. If you have any doubt about your microwave oven obtain the help of a qualified electrician.
When replacing the plug please ensure that you use a BSI or ASTA approved plug to BS1363, this should be fitted with a brown coloured 13 amp fuse approved by BSI or ASTA to BS1362. If you have any doubt about electrical connection seek the help of a qualified electrician.
WARNING: THIS APPLIANCE MUST BE EARTHED
To wire an appropriate plug, follow the wiring code given in `To replace the mains plug’ on page 7.
7
TO REPLACE THE MAINS PLUG
INSTALLATION
1. Remove all packing materials from the inside of
the oven cavity. Discard the loose polythene sheet from between the door and cavity. Remove the feature sticker, if attached, from the outside of the door.
2. Check the oven carefully for any signs of damage.
3. Place the oven on a flat, level surface strong
enough to support the oven’s weight plus the heaviest item likely to be cooked.
4. Ensure there is a minimum of free space above the oven of 19 cm.
5. Do not stack this oven.
6. Securely connect the plug of the oven to a
standard earthed (grounded) household electrical outlet.
19 cm
Remove this film.
The wires in the mains cable are colour coded as shown opposite:
As the colours of the cores in the mains lead of your oven may not correspond with the coloured marking identifying the terminals in your plug, connect the wires as described below: Make sure the terminal screws are tight and the cable is held securely by the cable grip where it enters the plug. Like most appliances in your home, your oven must be connected to a single phase 230-240 Volt, 50Hz alternating current supply. If you do not make the proper electrical connections you might damage the oven or injure yourself. Neither SHARP nor the supplier will be liable if this happens.
green and yellow stripes = EARTH blue = NEUTRAL brown = LIVE
• The green and yellow wire to the plug terminal
marked E or or coloured green or coloured green and yellow.
• The blue wire to the plug terminal marked N or coloured black or coloured blue.
• The brown wire to the plug terminal marked L or coloured red or coloured brown.
THIS APPLIANCE MUST BE EARTHED. IF YOU HAVE ANY DOUBTS ABOUT YOUR ELECTRICAL SUPPLY ASK A QUALIFIED ELECTRICIAN.
8
MAFF HEATING CATEGORY
BEFORE OPERATION
LOCK FUNCTION
•Your oven has a lock function and is locked when you first connect to an electrical socket. At that time the digital display will show:
• The lock will be set when the oven is plugged in, and you can use all functions except for the MEMORY key.
•To release the lock function, press the MANUAL key and hold for 2 seconds until the audible sound is heard. LOCK indicator will disappear and you can use the MEMORY key. To lock the oven press the MANUAL key and hold for 2 seconds.
•Your oven is already installed with 30 cooking programmes for apetito products in each number key. The first 20 programmes cannot be changed.
• The input is cancelled when any keys are not pressed for more than 3 minutes.
SOUND SETTING
• If you wish the oven to operate with no sound,
press the MANUAL key and then the SOUND key once. When you hear the signal your oven will operate without sound. To restore sound, press the MANUAL key and then the SOUND key again and the signal will sound twice.
STOPPING THE OVEN
• will appear on the display after the time reaches zero (e.g. at the end of the cooking time). If you press the STOP key twice during cooking, appears in the display.
• If you wish to stop the oven during cooking: Press the STOP key once or open the door. To start the oven again, close the door and
press the START key within 1 minute.
• If you wish to cancel a programme during cooking, press the STOP key twice.
• If you wish to erase a mistake during programming, press STOP key once.
The heating category of this microwave oven is E. The heating category (a letter A to E) developed by
MAFF (Ministry of Agriculture, Fisheries and Food) with microwave oven and food manufacturers indicates the ability of the oven to heat small quantities of food (up to 500g [1lb 2oz]). It does not represent the general performance of the oven.
Food packs carry cooking instructions for heating categories A to E. Follow instructions for the letter corresponding to the oven’s heating category. The higher the output power and heating category of the oven the less heating time is required as shown opposite.
Microwave output power in Watts (based on international (IEC 60705) standard).
600 700 800 900 1000 Watts
OVEN OUTPUT POWER
Less heating time required
More heating time required
OVEN OUTPUT CATEGORY
Less heating time required
More heating time required
Letter representing the oven heating category.
Microwave Symbol.
A B C D E
