To aid in reporting this microwave oven in case of loss or theft, please record below the model number and
serial number located on the unit. We also suggest you record all the information listed and retain for future
reference.
CONTENTS
MODEL NUMBER _____________________ SERIAL NUMBER _______________
DATE OF PURCHASE____________________
DEALER__________________________ TELEPHONE __________________
SERVICER_________________________ TELEPHONE __________________
TO PHONE :
DIAL 1-800-BE-SHARP (237-4277) for :
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your authorized parts distributor)
ADDITIONAL CUSTOMER INFORMATION
DIAL 1-800-642-2122 for :
ACCESSORIES and COOKBOOK
TO WRITE :
Sharp Electronics Corporation
Customer Assistance Center
1300 Naperville Drive
Romeoville, IL 60446-1091
Please provide the following information when you write or call: model number, serial number , date of purchase,
your complete mailing address (including zip code), your daytime telephone number (including area code) and
description of the problem.
TO ACCESS INTERNET :
www.sharp-usa.com
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can result
in harmful exposure to microwave energy. It is important not to defeat or tamper with the
safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken
or loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
2
CONTENTS
2
For Customer Assistance
2
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy
3 Contents
4
Consumer Limited Warranty
4
Product Information Card
5
Important Safety Instructions
6
Unpacking Instructions
6 Optional Accessories
6
Grounding Instructions
7-9
Information You Need to Know
7 About Your Oven
7 About Food
8 About Utensils and Coverings
8 About Children and the Microwave
9 About Microwave Cooking
9 About Safety
9-10
Part Names
11-12
Introduction to Touch Screen
12-14
Before Operating
13 To Set The Clock
14 Stop/Clear
14-16
Manual Operation
14 High Power Cooking
15 Variable Power Cooking
15 Multiple Sequence Cooking
16 Manual Defrost
32 Minute Plus
33 Minute Plus+
33 Kitchen Timer
34 More or Less Time Adjustment
35
Cleaning and Care
36 Replacing Parts
36 Oven Light
36 Work Light and Night Light
36 Charcoal Filter
37
Specifications
37
THE ULTIMATE ACCESSORY
38
COOKBOOK ORDER FORM
38
Service Call Check
39-40
Quick Reference
39 One Touch Sensor
39 6x6 No Guess Cooking
39 More From Your Microwave 6x6
39 Beverage Center
39 Defrost 3+6
39 Set Up
40 Auto-Touch Guide
3
CONSUMER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand
product (the “Product”), when shipped in its original container, will be free from defective workmanship and
materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part
thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s)
set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set
forth below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to
misuse, abnormal service or handling, or which has been altered or modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below
and provide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET
FORTH BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above
limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than
those described herein, or to extend the duration of any warranties beyond the time period described above on
behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the
sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of
time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the
purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on
contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible,
for any damages or defects in the Product which were caused by repairs or attempted repairs performed by
anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental
or consequential economic or property damage. Some states do not allow the exclusion of incidental or
consequential damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE.
Your Product Model Number
& Description:
Warranty Period for
this Product:
Additional Item(s) Excluded from
Warranty Coverage (if any):
Where to Obtain Service:
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION,
CALL 1-800-BE-SHARP OR VISIT www.sharp-usa.com.
SAVE THE PROOF OF PURCHASE AS IT IS NEEDED SHOULD YOUR OVEN EVER REQUIRE WARRANTY SERVICE.
R-1750, R-1751, R-1752 and R-1754 Home Use Carousel™ Microwave
Oven. (Be sure to have this information available when you need service
for your Product.)
One (1) year parts and labor in-home service. The warranty period
continues for an additional six (6) years, for a total of seven (7) years,
with respect to the magnetron tube in the Product for parts only. Labor
and the servicer trip charge are not provided free of charge for this
additional period.
Non-functional accessories, turntable and light bulbs.
From a Sharp Authorized Servicer located In the United States. Be sure
to have Proof of Purchase available. For in-home service, the servicer
will come to the unit’s location. If it is necessary to remove the unit for
repair, the servicer will reinstall the unit at no extra charge, provided it
was installed according to Sharp’s Installation Instructions. To find the
location of the nearest Sharp Authorized Servicer, call Sharp toll free at
1-800-BE-SHARP (1-800-237-4277).
PRODUCT INFORMATION CARD
The product information card should be completed within ten days of purchase and returned. We will keep it on
file and help you access the information in case of loss, damage or theft. This will also enable us to contact you in
the unlikely event that any adjustments or modifications are ever required for your oven.
4
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
WARNING
1. Read all instructions before using the
appliance.
2. Read and follow the specific
- To reduce the risk of burns, electric shock, fire, injury to persons or exposure
to excessive microwave energy:
“PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” on page 2.
3. This appliance must be grounded. Connect
only to properly grounded outlet. See
“GROUNDING INSTRUCTIONS”
on page 6 and INSTALLATION
INSTRUCTIONS.
4. Install or locate this appliance only in
accordance with the provided installation
instructions.
5. Some products such as whole eggs and
sealed containers — for example, closed
glass jars — may explode and should not
be heated in this oven.
6. Use this appliance only for its intended
use as described in this manual. Do not
use corrosive chemicals or vapors in this
appliance. This type of oven is specifically
designed to heat, cook or dry food. It is not
designed for industrial or laboratory use.
7. As with any appliance, close supervision
is necessary when used by children.
8. Do not operate this appliance if it has a
damaged cord or plug, if it is not working
properly or if it has been damaged or
dropped.
9. This appliance should be serviced only by
qualified service personnel. Contact nearest Sharp Authorized Servicer for examination, repair or adjustment.
10. Do not cover or block any openings on the
appliance.
11.Do not store or use this appliance outdoors.
Do not use this product near water—for
example, near a kitchen sink, in a wet basement or near a swimming pool, and the like.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or
counter.
15. See door surface cleaning instructions on
page 35.
16. To reduce the risk of fire in the oven
cavity:
a. Do not overcook food. Carefully attend
appliance if paper, plastic or other combustible materials are placed inside the
oven to facilitate cooking.
b. Remove wire twist-ties from paper or
plastic bags before placing bag in oven.
c. If materials inside the oven should
ignite, keep oven door closed, turn
oven off, and disconnect the power
cord or shut off power at the fuse or
circuit breaker panel.
d. Do not use the cavity for storage pur-
poses. Do not leave paper products,
cooking utensils or food in the cavity
when not in use.
17. Clean ventilation openings and grease
filters frequently—Grease should not be
allowed to accumulate on ventilation
openings, hood (louver) or grease filters.
18. Use care when cleaning the louver and the
grease filters. Corrosive cleaning agents,
such as lye-based oven cleaners, may
damage the louver and the grease filters.
19. When flaming foods under the hood, turn
the fan on.
20. This appliance is suitable for use above
both gas and electric cooking equipment
36" wide or less.
SAVE THESE INSTRUCTIONS
5
UNPACKING INSTRUCTIONS
Unpacking and Examining Your Oven
Open the bottom of the carton, bend the carton flaps back and tilt the oven over to rest on plasticfoam pad.
Lift carton off oven and remove all packing materials, Installation Instructions, Wall Template, Top Template,
Charcoal Filter, Turntable and Turntable Support. SAVE THE CARTON AS IT
MAY MAKE INSTALLATION EASIER.
1.Remove the feature sticker from the outside of the door, if there is one.
2. DO NOT REMOVE THE WAVEGUIDE COVER, which is located on the
ceiling in the oven cavity. Check to see that there are Installation Instructions,
Wall Template, Top Template and RK-230 Charcoal Filter , which is used when
recirculating is chosen. Read enclosures and SAVE the Operation Manual.
Check the oven for any damage, such as misaligned or bent door, damaged door
seals and sealing surfaces, broken or loose door hinges and latches and dents
inside the cavity or on the door. If there is any damage, do not operate the oven
and contact your dealer or SHARP AUTHORIZED SERVICER. See Installation Instructions for more details.
OPTIONAL ACCESSORIES
Two optional accessories are available for this oven.
1. Charcoal Filter (RK-230). The filter packed in the oven is required when hood exhaust is recirculated.
See Charcoal Filter on page 36. To purchase a replacement Charcoal Filter, check with the dealer or call
1-800-642-2122. Have credit card ready.
2.Filler Panel Kit. For use when the oven is installed in a 36-inch or 42-inch wide opening. The metal filler
panels come in 3-inch wide pairs. One set is needed for a 36-inch opening and 2 sets for a 42-inch opening.
White and black are available.
To purchase contact:Modern-Aire Ventilating Corporation
7319 Lankershim Blvd.
North Hollywood, CA 91605
Phone: (818) 765-9870 Fax: (818) 765-4916
GROUNDING INSTRUCTIONS
This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a grounding
plug. It must be plugged into a wall receptacle that is properly installed and grounded in accordance with the
National Electrical Code and local codes and ordinances. In the event of an electrical short circuit, grounding
reduces risk of electric shock by providing an escape wire for the electric current.
WARNING – Improper use of the grounding plug can result in a risk of electric shock.
Electrical Requirements
Check Installation Instructions for proper location for the power supply.
The electrical requirements are a 120 volt 60 Hz, AC only, 15 amp. or more protected
electrical supply. It is recommended that a separate circuit serving only the oven be
provided.
The oven is equipped with a 3-prong grounding plug. It must be plugged into a wall
receptacle that is properly installed and grounded. DO NOT UNDER ANY
CIRCUMSTANCES CUT OR REMOVE THE GROUNDING PIN FROM THE PLUG.
Notes: 1. If you have any questions about the grounding or electrical instructions, consult a qualified electri-
cian or service person.
2. Neither Sharp nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the correct electrical connection procedures.
Radio or TV Interference
Should there be any interference caused by the microwave oven to your radio or TV, check that the microwave
oven is on a different electrical circuit, relocate the radio or TV as far away from the oven as feasible or check
position and signal of receiving antenna.
6
INFORMATION YOU NEED TO KNOW
ABOUT YOUR OVEN
This Operation Manual is valuable: read it carefully
and always save it for reference.
A good microwave cookbook is a valuable asset.
Check it for microwave cooking principles,
techniques, hints and recipes. See pages 37 and 38
for ordering the Ultimate Accessory, the SHARP
CAROUSEL MICROWAVE COOKBOOK.
NEVER use the oven without the turntable and
support nor turn the turntable over so that a large dish
could be placed in the oven. The turntable will turn
both clockwise and counterclockwise. See page 30
for complete instructions.
ALWAYS have food in the oven when it is on to
absorb the microwave energy.
ABOUT FOOD
FOOD
Eggs, sausages,
nuts, seeds,
fruits &
vegetables
Popcorn
• Puncture egg yolks before cooking to
prevent “explosion”.
•Pierce skins of potatoes, apples, squash,
hot dogs and sausages so that steam escapes.
•Use specially bagged popcorn for the
microwave oven.
•Listen while popping corn for the popping to slow to 1 or 2 seconds or use
special Popcorn pad.
DO
When using the oven at power levels below 100%,
you may hear the magnetron cycling on and off.
Condensation is a normal part of microwave cooking.
Room humidity and the moisture in food will
influence the amount of moisture that condenses in
the oven. Generally, covered foods will not cause as
much condensation as uncovered ones. Vents on the
oven back must not be blocked.
The oven is for food preparation only. It should not
be used to dry clothes or newspapers.
Your oven is rated 1100 watts by using the IEC Test
Procedure. In using recipes or package directions,
check food a minute or two before the minimum time
and add time accordingly.
DON'T
•Cook eggs in shells.
•Reheat whole eggs.
•Dry nuts or seeds in shells.
• Pop popcorn in regular brown bags or
glass bowls.
• Exceed maximum time on popcorn
package.
Baby food
General
•Transfer baby food to small dish and
heat carefully, stirring often. Check
temperature before serving.
• Put nipples on bottles after heating and
shake thoroughly. “Wrist” test before
feeding.
• Cut baked goods with filling after heating to release steam and avoid burns.
•Stir liquids briskly before and after
heating to avoid “eruption”.
•Use deep bowl, when cooking liquids
or cereals, to prevent boilovers.
7
•Heat baby food in original jars.
•Heat disposable bottles.
•Heat bottles with nipples on.
•Heat or cook in closed glass jars or air
tight containers.
•Can in the microwave as harmful bacteria may not be destroyed.
•Deep fat fry.
•Dry wood, gourds, herbs or wet papers.
• Operate the oven empty.
INFORMATION YOU NEED TO KNOW
ABOUT UTENSILS AND COVERINGS
It is not necessary to buy all new cookware. Many
pieces already in your kitchen can be used successfully in your new microwave oven.
Use these utensils for safe microwave cooking and
reheating:
•glass ceramic (Pyroceram®), such as
Corningware
•heat-resistant glass (Pyrex
• microwave-safe plastics (some microwavesafe plastics are not suitable for cooking foods
with high fat and sugar content.)
•paper plates
• microwave-safe pottery, stoneware and
porcelain
•browning dish (Do not exceed recommended
preheating time. Follow manufacturer's
directions.)
®
.
®
)
These items can be used for short time reheating
of foods that have little fat or sugar in them:
•wood, straw, wicker
DO NOT USE
•metal pans and bakeware
•dishes with metallic trim
• non-heat-resistant glass
• non-microwave-safe plastics (margarine tubs)
• recycled paper products
•brown paper bags
•food storage bags
•metal twist-ties
Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and
microwave on 100% power for 30 seconds. A dish
which becomes very hot should not be used.
The following coverings are ideal:
• Paper towels are good for covering foods for
reheating and absorbing fat while cooking bacon.
•Wax paper can be used for cooking and reheating.
•Plastic wrap that is specially marked for microwave
use can be used for cooking and reheating. DO NOT
allow plastic wrap to touch food. Vent so steam
can escape.
• Lids that are microwave-safe are a good choice
because heat is kept near the food to hasten cooking.
• Oven cooking bags are good for large meats or foods
that need tenderizing. DO NOT use metal twist ties.
Remember to slit bag so steam can escape.
How to use aluminum foil in your microwave oven:
• Small flat pieces of aluminum foil placed smoothly
on the food can be used to shield areas that are
either defrosting or cooking too quickly.
• Foil should not come closer than one inch to any
surface of the oven.
Should you have questions about utensils or
coverings, check a good microwave cookbook or
follow recipe suggestions.
ACCESSORIES There are many microwave
accessories available for purchase. Evaluate carefully
before you purchase so that they meet your needs. A
microwave-safe thermometer will assist you in
determining correct doneness and assure you that
foods have been cooked to safe temperatures. Sharp
is not responsible for any damage to the oven when
accessories are used.
ABOUT CHILDREN AND THE MICROWAVE
Children below the age of 7 should use the microwave oven with a supervising person very near to
them. Between the ages of 7 and 12, the supervising
person should be in the same room.
The child must be able to reach the oven comfortably; if not, he/she should stand on a sturdy stool.
At no time should anyone be allowed to lean or swing
on the oven door.
Children should be taught all safety precautions: use
potholders, remove coverings carefully, pay special
attention to packages that crisp food because they may
be extra hot.
Don’t assume that because a child has mastered one
cooking skill he/she can cook everything.
Children need to learn that the microwave oven is
not a toy. See page 32 for Child Lock feature.
8
INFORMATION YOU NEED TO KNOW
ABOUT MICROWAVE COOKING
•Arrange food carefully. Place thickest areas toward
outside of dish.
•Watch cooking time. Cook for the shortest amount
of time indicated and add more as needed. Foods
severely overcooked can smoke or ignite.
• Cover foods while cooking. Check recipe or cookbook for suggestions: paper towels, wax paper,
microwave plastic wrap or a lid. Covers prevent
spattering and help foods to cook evenly.
• Shield with small flat pieces of aluminum foil any
thin areas of meats or poultry to prevent overcooking before dense, thick areas are cooked thoroughly.
•Stir foods from outside to center of dish once or
twice during cooking, if possible.
•Turn foods over once during microwaving to speed
cooking of such foods as chicken and hamburgers.
Large items like roasts must be turned over at
least once.
ABOUT SAFETY
• Check foods to see that they are cooked to the
United States Department of Agriculture’s recommended temperatures:
TEMP
160°F
165°F
170°F
180°F
To test for doneness, insert a meat thermometer in a
thick or dense area away from fat or bone. NEVER
leave the thermometer in food during cooking,
unless it is approved for microwave oven use.
... for fresh pork, ground meat,
boneless white poultry, fish,
seafood, egg dishes and
frozen prepared food.
... for leftover, ready-to-reheat
refrigerated, and deli and
carry-out “fresh” food.
... white meat of poultry.
... dark meat of poultry.
FOOD
• Rearrange foods like meatballs halfway through
cooking both from top to bottom and from the center
of the dish to the outside.
•Add standing time. Remove food from oven and
stir, if possible. Cover for standing time which
allows the food to finish cooking without
overcooking.
•Check for doneness. Look for signs indicating that
cooking temperatures have been reached.
Doneness signs include:
-Food steams throughout, not just at edge.
-Center bottom of dish is very hot to the touch.
-Poultry thigh joints move easily.
-Meats and poultry show no pinkness.
-Fish is opaque and flakes easily with a fork.
•Always use potholders to prevent burns when
handling utensils that are in contact with hot food.
Enough heat from the food can transfer through
utensils to cause skin burns.
•Avoid steam burns by directing steam away from
the face and hands. Slowly lift the farthest edge of
a dish’s covering and carefully open popcorn and
oven cooking bags away from the face.
• Stay near the oven while it’s in use and check cook-
ing progress frequently so that there is no chance
of overcooking food.
• NEVER use the cavity for storing cookbooks or
other items.
•Select, store and handle food carefully to preserve
its high quality and minimize the spread of
foodborne bacteria.
• Keep waveguide cover clean. Food residue can
cause arcing and/or fires.
•Use care when removing items from the oven so
that the utensil, your clothes or accessories do not
touch the safety door latches.
9
PART NAMES
FRONT VIEW
14
15
13
16
12
17
BOTTOM VIEW
(Front of Microwave)
1 Oven door with see-through window
2 Door hinges
3 Waveguide cover:
DO NOT REMOVE.
4 Turntable motor shaft
5 Oven light
It will light when oven is operating or
door is open.
6 Rack holders
7 Safety door latches
The oven will not operate unless the
door is securely closed.
The turntable will rotate clockwise or
counterclockwise. Only remove for cleaning.
16 Removable turntable support
First, carefully place the turntable support in
the motor shaft in the center of the oven floor.
Then, place the turntable on the turntable
support securely.
The Home Page is for entering time for cooking or kitchen timer. The TOUCH
SCREEN shows cooking information and recipes and lets the user enter chosen
options by simply touching directly on the screen.
Minute Plus+ : 33
Touch to access
screen where 12
common cooking
times are shown that
simply require one
touch to start.
STOP/CLEAR : 14
During programming,
press once to return to
the Home Page.
During cooking, press
once to stop cooking
or twice to cancel the
cooking program.
MINUTE PLUS : 32
Press once to cook for
one minute at 100%
or press repeatedly to
extend cooking time
in multiples of one
minute.
START
Press to start oven
after programming.
6x6 NO GUESS
COOKING : 18-19
Press each pad to
show six selections
on the TOUCH
SCREEN.
FAN OPTIONS :
29
Press pad to show
3 selections.
LIGHT OPTIONS : 29
Press pad to show
3 selections.
TURNTABLE ON/OFF : 30
Press to turn turntable off.
The icon will appear on the
display.
SET UP : 31-32
Press to show
Clock, Child Lock,
Sound Adjustment,
Auto Start, Video
Demo or Screen
ONE TOUCH SENSOR
: 16-17
Select pad to
bake potatoes,
pop popcorn or
reheat previously
prepared foods.
Kitchen Timer : 33
Touch Kitchen
Timer, enter desired
time and press
START.
BEVERAGE CENTER :
28
Press to prepare or
reheat coffee or tea.
KEEP WARM: 28
Press to warm food
up to 30 minutes.
DEFROST 3+6 :
26-27
Press to select
one of three
SuperDefrost or one
of six CompuDefrost
options.
MORE FROM YOUR
MICROWAVE 6x6 :
20-25
Press pad to show
six categories, each
with six foods.
Breakfast Bar,
Lunch on the Run,
One Dish Dinners,
Low Calorie
Entrees, Supper
Soups and Sauces
and Delicious
Desserts are the
options.
Contrast.
Number next to the control panel illustration
indicates page on which there are feature descriptions and usage information.
11
INTRODUCTION TO TOUCH SCREEN
Your new Sharp Smart & Easy Touch Screen Microwave Oven features a large screen on the Control Panel
which, not only provides much information to make using the oven easy, but also, is used to input information
directly about the food being cooked, quantity or desired doneness.
Example 1: Home Page
The Home Page is the beginning. It shows the time of day, if
the clock has been set. It also shows Minute Plus+, where by
touching the screen the next screen appears, making it easy to
select one of twelve commonly used times. T ouching Kitchen
Timer tells the oven that the time set is only for timing, not
for cooking.
Note that if cooking time is touched on the screen, that Minute
Plus+ and Kitchen Timer disappear and Power Level appears.
Touching Power Level leads to the next screen for selecting
the desired Power Level.
Example 2: Suppose you want to cook meat loaf in 6x6 NO GUESS COOKING:
1 Press Meats on the
Control Panel in 6x6 NO
GUESS COOKING.
Example 3: Suppose you want to cook Spicy Couscous in More From Your Microwave 6x6:
1 Press MORE FROM
YOUR MICROWAVE
6x6 on the Control Panel.
2 Note that six meat
selections appear on the
TOUCH SCREEN.
Touch Meat Loaf.
On all recipe screens and some preparation screens, there will be forward and back arrows, located in the
upper corners of the TOUCH SCREEN. Touch to read the entire recipe before beginning any cooking.
BEFORE OPERATING
Before operating your new SMART & EASY
TOUCH SCREEN microwave oven, be sure to read
and understand this operation manual.
Before the oven can be used, follow the steps:
1. Plug in the oven. Close the door. You can select
either: Video Demo or Set Clock.
2. T ouch Set Clock and follow the instructions below .
NOTE:
If no choice is made for 30 seconds, the V ideo Demo
will begin automatically. To cancel the Video Demo,
press the STOP/CLEAR pad and the display will
return to the Home Page. To set the clock, press the
Set Up pad, touch Clock and follow the directions
on the Touch Screen.
TO SET THE CLOCK
•Suppose you want to enter the correct time of day: 12:30 PM.
1 After touching Set Clock, enter the time
of day (hour) by touching Hour 11 times.
2 Enter the time of day (minutes)
by touching 10 Min. 3 times.
3 Select AM or PM and then press the
START pad.
4 The clock will start. The display
will return to the Home Page.
13
BEFORE OPERATING
NOTE :
1.If you make a mistake while setting the clock,
touch STOP/CLEAR pad. The Home Page will
appear. To set clock again, press Set Up pad on
the control panel and Clock. Keep touching the
screen until the desired time of day appears.
2. If you want to change the setting of the time of
day, press Set Up pad and follow the directions.
3. If the electrical power supply to your microwave
oven should be interrupted, the screen will intermittently show V ideo Demo or Set Clock after the
power is reinstated. If this occurs during cooking,
the program will be erased. Simply touch Set Clock
and follow the directions.
4.If you touch continously the Hour, 10 Min or 1 Min
on the Touch Screen, the time will count up
automatically.
STOP/CLEAR
Touch the STOP/CLEAR pad to:
1.Return the Home Page to the display , if you make
a mistake during programming.
2.Stop the oven temporarily during cooking.
3.Cancel Kitchen Timer/Auto Start.
4.Cancel a program during cooking, touch twice.
MANUAL OPERATION
TIME COOKING
Your oven can be programmed for 99 minutes and 99 seconds (99.99). Always enter the seconds after the
minutes, even if they are both zeros.
HIGH POWER COOKING
•Suppose you want to cook for five minutes at 100% power:
1 Enter cooking time, 5, 0, 0 by touching
numbers. Note the top line of the display.
Press the START pad.
NOTE:
If the door is opened or STOP/CLEAR pad is pressed
once during cooking process, the cooking time in the
display automatically stops. The cooking time starts
2 The display will begin counting down the
to count down again when the door is closed and the
START pad is pressed.
cooking time. During the cooking, the power
level will appear in the display.
14
MANUAL OPERATION
VARIABLE POWER COOKING
There are eleven preset power levels. T o change the power level, touch Power Level after entering the cooking
time. Using lower power levels increases the cooking time which is recommended for foods such as cheese,
milk and long slow cooking of meats. Consult cookbook or recipes for specific recommendations.
• Suppose you want to cook for 5 minutes at 30% power:
1 Enter cooking time, 5, 0, 0
by touching numbers.
Touch Power Level.
2 Touch 30%. The top line of
the display will show time
and chosen power level.
Press START pad.
3 The display will begin counting
down the cooking time. During
the cooking, the power level
will appear in the display.
MUL TIPLE SEQUENCE COOKING
The oven can be programmed for up to four automatic cooking sequences, switching from one power level
setting to another automatically. Sometimes cooking directions tell you to start on one power level and then
change to a different power level. Your oven can do this automatically.
•Suppose you want to cook roast beef for 5 minutes at 70% power and then continue to cook for 30 minutes at
50% power:
1 Enter cooking time, 5, 0, 0
by touching numbers.
Touch Power Level.
2 Touch 70%. You can omit
this step when you set 100%
power.
3 Touch Multiple Sequence.
4 Touch second cooking
time 3, 0, 0, 0. Touch
Power Level.
5 Touch 50%. Then press the
START pad.
15
6 The display will begin counting
down the total cooking time.
During the cooking, the power
level will appear in the display.
MANUAL OPERATION
MANUAL DEFROST
If the food that you wish to defrost is not listed
on the COMPU DEFROST or SUPER DEFROST
CHARTS or is above or below the limits in the
AMOUNT column on the COMPU DEFROST or
SUPER DEFROST CHARTS, you need to defrost
manually.
You can defrost any frozen food, either raw or
previously cooked, by using 30% power. Follow
the exact procedure found on page 15. Estimate
defrosting time, enter it. Then touch Power Level on
the Touch Screen and select 30%.
For either raw or previously cooked frozen food the
ONE TOUCH SENSOR
rule of thumb is approximately four minutes per
pound. For example, defrost four minutes for one
pound of frozen spaghetti sauce.
Always stop the oven periodically to remove or
separate the portions that are defrosted. If food is
not defrosted at the end of the estimated defrosting
time, program the oven in one minute increments on
30% power until totally defrosted.
When using plastic containers from the freezer,
defrost only long enough to remove from the plastic
in order to place in a microwave-safe dish.
Sharp's Sensor is a semi-conductor device that detects
the vapor (moisture and humidity) emitted from the
food as it heats. The sensor adjusts the cooking times
and power level for various foods and quantities.
Using Sensor Settings
1.After oven is plugged in, wait two minutes before
using any Sensor setting.
2.Be sure the exterior of the cooking container and
the interior of the oven are dry. Wipe off any
moisture with a dry cloth or paper towel.
3.The oven works with foods at normal storage
temperature. For example, popcorn would be at
room temperature.
4. Any Sensor Cooking or Reheating selection can
be programmed with More or Less Time
Adjustment. See page 34.
5. More or less food than the quantity listed in the
chart should be cooked following the guidelines
in any microwave cookbook.
6.During the first part of Sensor Cooking or
Reheating, SENSING will appear on the display.
Do not open the oven door or press STOP/CLEAR
pad during this part of the cooking cycle. The
measurement of vapor will be interrupted. If this
occurs, an error message will appear. To continue
cooking, touch the STOP/CLEAR pad and cook
manually.
When the sensor detects the vapor emitted from
the food, remainder of cooking or reheating time
will appear. The door may be opened when
remaining cooking time appears on the display. At
this time, you may stir or season food, as desired.
7.If the sensor does not detect vapor properly when
cooking or reheating foods, error messages will be
displayed, and the oven will turn off.
8. Check food for correct temperature after cooking.
If additional time is needed, continue to cook
manually.
Covering Foods
Some foods work best when covered. Use the cover
recommended in the procedure for these foods.
1.Casserole lid.
2.Plastic wrap: Use plastic wrap recommended for
microwave cooking. Cover dish loosely; allow
approximately 1/2 inch to remain uncovered to
allow steam to escape. Plastic wrap should not
touch food.
3. Wax paper: Cover dish completely; fold excess
wrap under dish to secure. If dish is wider than
paper, overlap two pieces at least one inch to cover .
Be careful when removing any covering to allow
steam to escape away from you.
16
ONE TOUCH SENSOR
REHEAT / POPCORN / BAKED POTATOES
You can cook many foods by touching just one pad. You don’t need to calculate cooking time or power level.
•Suppose you want to reheat canned chili.
1 Press Reheat pad and then
touch the Regular Turntable
On to reheat canned chili.
2 Press the START pad.
ONE TOUCH SENSOR COOKING CHART
FOOD
Reheat
Regular
Turntable On
Stirrable
Turntable Off
Non Stirrable
Turntable Off
Popcorn1 pkg
Baked Potatoes
AMOUNT
4 - 36 oz
13x9x2
glass utility
casserole
13x9x2
glass utility
casserole
3.0 - 3.5 oz (Regular)
1.5 - 1.75 oz (Snack)
1 - 6
Place in dish or casserole slightly larger than amount to be
reheated. Flatten, if possible. Cover with lid, plastic wrap or wax
paper. Use covers such as plastic wrap or lids with lar ger quantities of more dense foods such as stews. After reheating, stir well,
if possible. Re-cover and allow to stand 2 to 3 minutes. Foods
should be very hot. If not, continue to heat with variable power
and time.
Ideal for reheating stirrable casseroles, such as macaroni and
cheese or stew. Cover with vented plastic wrap or wax paper.
Follow directions. At end, stir and allow to stand, covered, for 5
to 10 minutes.
Ideal for reheating non-stirrable casseroles, such as lasagna.
Cover with vented plastic wrap or wax paper. Follow directions.
At end, stir and allow to stand, covered, for 5 to 10 minutes.
Use only popcorn packaged for microwave oven use. Try
several brands to decide which you like the best. Do not try to
pop unpopped kernels.
Pierce. Place on paper-towel-lined turntable. After cooking,
remove from oven, wrap in aluminum foil and let stand 5 to
10 minutes.
PROCEDURE
3 After cooking, follow
instructions.
17
6x6 NO GUESS COOKING
Your oven has six food pads and each pad has six
selections. Many sensor cooked foods are included
in 6x6 NO GUESS COOKING. See the sensor
cooking information on page 16. For foods not using
the sensor, follow the directions on the Touch Screen
to enter quantity. When cooking foods with the sensor,
it is not neccessary to enter quantity or weight. The
foods using the sensor are indicated with “ * ” in the
chart on page 19.
VEGETABLES
The desired doneness can be selected for any vegetables choice.
• Suppose you want to cook broccoli (normal):
1 Press the Vegetables pad
and then touch the desired
vegetable: Broccoli.
2 Touch the desired doneness, and
the oven will start automatically.
When the sensor detects the vapor
emitted from the food, remaining
cooking time will appear. The
oven door can be opened
whenever the count down time is
displayed on the Touch Screen.
3 After cooking, follow
instructions.
NOTE:
You can also start the cooking by pressing the ST AR T pad at step 2. At that time “normal” is selected automatically.
The doneness can be changed after pressing the START pad by touching the desired doneness on the display
within seven seconds.
MEATS - POULTRY - FISH/SEAFOOD
FROZEN FOODS - PASTA GRAINS
•Suppose you want to cook 2.0 lb boneless pork loin:
.25 - 1.25 lb
6 - 17 oz
24 - 40 oz
3 - 8 oz
Pint, Quart,
Half Gallon
6, 12, 16 oz
1
/2
- 2 cups
1
/2
- 2 cups
8 - 9 oz
2 - 8 oz
.3 - 2.0 cups
.5 - 2.0 cups
NOTE:
1.You can enter the amount only within the range of
the 6x6 NO GUESS COOKING CHART.
* It is not necessary to enter quantity with these foods
because they are cooked by the sensor.
2.6x6 NO GUESS COOKING can be programmed
with More or Less Time Adjustment. See page 34.
19
MORE FROM YOUR MICROWAVE 6x6
More From Your Microwave 6x6 has six cooking
categories to assist with meal preparation. There are
some foods in the Breakfast Bar and Lunch on the
BREAKFAST BAR / LUNCH ON THE RUN
• Suppose you want to use Breakfast Bar to cook two servings of hot cereal.
Run that use the sensor. See sensor cooking information
on page 16. For foods not using the sensor, follow the
directions on the screen to enter quantity.
1 Press MORE FROM
YOUR MICROWAVE 6x6
pad and then touch the
desired category: Breakfast
Bar.
2 Select the desired food:
Hot Cereal.
3 Enter desired quantity by
touching the screen. Then
press START pad. When
the oven stops, follow
instructions.
BREAKFAST BAR CHAR TLUNCH ON THE RUN CHART
FOOD
Scrambled Eggs
Bacon*
Hot Cereal
Fresh Rolls or Muffins
Frozen Rolls or Muffins
Frozen Breakfast Food*
* It is not necessary to enter quantity with these foods
because they are cooked by the sensor.
NOTE:
1.You can program with More or Less Time
Adjustment. See page 34.
2.More or less than the quantity listed in the chart
should be cooked following the guidelines in any
microwave book.
Meal in a Cup*
Hot Dogs in Buns*
Soup*
Microwave Pizza*
Pizza Reheat**
Frozen Sandwich*
**Must enter number of slices on Touch Screen.
Other foods in chart do not require quantity input.
See Touch Screen for directions.
3.The final cooking result will vary according to the
food condition (e.g. initial temperature, shape,
quality, covering). Check food for correct
temperature after cooking. If additional time is
needed, continue to cook manually.
ONE DISH DINNERS - LOW CALORIE ENTREES SUPPER SOUPS AND SAUCES DELICIOUS DESSERTS
• Suppose you want to use One Dish Dinners to cook Spicy Couscous.
1 Press MORE FROM YOUR
MICROWAVE 6x6 pad and
then touch the desired
category: One Dish Dinners.
4 When ready to cook, press
START pad. The oven has
the cooking instructions in it
so it is not necessary for you
to make any decisions!
2 Select the desired food:
Spicy Couscous.
5 When the oven stops, read
the instructions on the
Touch Screen, open the
door, complete the steps
and close door. Press
START pad.
3 All ingredients for the recipe
and step-by step procedures are
shown. Touch the arrow marks
on the screen to read the recipe
through before cooking. The
forward
arrows allow one to check all
steps BEFORE beginning any
cooking.
1 tsp cumin
2c red, green and yellow pepper strips
1 large onion, chopped
1c black beans, rinsed and drained
6 10-inch warm flour tortillas
1 large tomato, chopped
8 oz boneless white fish, cut into 6 pieces
8 oz scallops
8 oz shrimp, peeled and deveined
Curried Vegetable
2 tbsp oil
1
2c
/2-inch sweet potato cubes
2c 1/2-inch white potato cubes
1 medium zucchini, cut into 1-inch cubes
1 medium red pepper, cut into 1/2-inch cubes
1 medium green pepper, cut into 1/2-inch
cubes
1 medium onion, cut into 1/2-inch cubes
2 tbsp curry powder
1 tsp ground cumin
15 oz can garbanzo beans, rinsed and drained
141/2 oz can diced tomatoes
15 oz can crushed tomatoes
1 tsp salt
4c vegetable or chicken broth
3c water
3c vegetable bouillon
1c dried split peas
Defrost 3+6 pad has two special defrosting methods.
SUPER DEFROST
SuperDefrost rapidly defrosts specific foods and weights found in the SUPER DEFROST chart.
• Suppose you want to defrost 1.0 pound boneless chicken.
1 Press Defrost 3+6 pad and
then touch desired food:
1 pound boneless chicken.
The oven will start
automatically.
NOTE:
1. To defrost foods above or below the weights
allowed on the SUPER DEFROST Chart,
use CompuDefrost or Manual Defrost. See
CompuDefrost on page 27 and Manual Defrost on
page 16.
2 When the oven stops, read
instructions on the screen,
open the door, complete the
instructions and close the
door. Press START pad.
2. SuperDefrost can be programmed with More or
Less Time Adjustment. See page 34.
3 After the defrost cycle ends,
read the screen. Remove the
food from oven, cover and
let stand for the suggested
time to allow defrosting to
be completed.
SUPER DEFROST CHART
FOOD
Ground meat
Boneless
Chicken
Bone-in
Chicken Pieces
NOTE:
SuperDefrost provides just enough defrosting that the foods can be used in recipes or for cooking. There will
be some ice crystals remaining.
AMOUNT
1.0 lb
1.0 lb
2.0 lb
At pause, turn over, remove any thawed pieces and break remainder
apart. At end, let stand, covered, for 3 to 5 minutes.
At pause, turn over and separate into pieces. At end, let stand, covered,
for 3 to 5 minutes.
At pause, turn over and separate into pieces. At end, let stand, covered,
for 3 to 5 minutes.
PROCEDURE
26
DEFROST 3+6
COMPU DEFROST
CompuDefrost automatically defrosts all the foods found in the COMPU DEFROST chart below.
•Suppose you want to defrost a 2.0 pound steak.
1 Press Defrost 3+6 pad and
then touch COMPU
DEFROST 6 Choices.
4 When the oven stops, read
instructions on the screen,
open the door, complete the
instructions and close the
door. Press START pad.
instructions on the screen,
open the door, complete the
instructions and close the
door. Press START pad.
.
5-3.0 lb
.5 - 4.0 lb
.5 - 3.0 lb
2.0 - 4.0 lb
2-6cups
1-6cups
3 Enter desired weight by
touching the screen. Then
press START pad.
6 After the defrost cycle ends,
read the screen. Remove the
food from oven, cover and
let stand for the suggested
time to allow defrosting to
be completed.
5-10 min.
10 - 20 min.
10 - 20 min.
30 - 45 min.
5-15 min.
5-15 min.
NOTE:
1. You can input the amount only within the range
of the COMPU DEFROST CHART.
2.CompuDefrost can be programmed with More or
Less Time Adjustment. See page 34.
3. To defrost other foods or foods above or below
the weights allowed on COMPU DEFROST
CHART, use time and 30% power. See Manual
Defrost on page 16.
27
BEVERAGE CENTER
Beverage Center enables you to restore coffee or tea to a more suitable drinking temperature or to prepare
instant coffee or tea.
•Suppose you want to make two cups of coffee.
1 Press Beverage Center pad
and then touch Prepare.
BEVERAGE CENTER CHART
FOOD
Prepare coffee/tea1 - 4 cups
Reheat
AMOUNT
1
/2 - 2 cups
2 Touch desired number on
the screen. The oven will
start automatically.
3 When oven stops, follow
instructions on the screen.
KEEP WARM
Keep Warm enables you to keep cooked food at the ideal serving temperature for up to 30 minutes.
•Suppose you want to keep on cooked casserole warm for 5 minutes.
1 Press Keep Warm pad and
then enter the desired time.
Press START.
Keep Warm can be programmed as the final stage in Multiple Sequence cooking. See page 15.
28
2 The display will begin counting
down. During the warming time,
Keep Warm will appear in the
display.
FAN OPTIONS
There are 3 choices in Fan Options.
• Suppose you want to turn the fan on at high speed.
Press Fan Options pad and then touch
the desired option: High Speed.
• Suppose you want to set the Auto Fan to stay on for a selected time.
1 Press Fan Options pad
and then touch the desired
option: Auto Fan.
2 Select the desired speed:
High Speed.
To turn the fan off, press the Fan Options
again and touch Off on the display.
LIGHT OPTIONS
There are 3 choices on Light Options.
• Suppose you want to turn the night light on.
3 Select the desired time.
Press the START pad.
Press Light Options pad and then
touch the desired option: Night Light.
To turn the light off, press the Light Options
again and touch Off on the display.
29
LIGHT OPTIONS
• Suppose you want to turn the Auto Night Light on.
1 Press Light Options pad
and then touch the desired
option: Auto Night Light.
TURNTABLE ON/OFF
For most cooking, the turntable should be on; however
the turntable can be turned off so that it does not rotate
when extra large dishes, such as the popular 13 x 9 x 2
glass utility casserole, are used. The casserole should
be placed on the turntable so that it is level.
The display indicates when the turntable is off.The
door can be opened for checking food and the
turntable will stay in the off position. After checking,
close door and touch START
All special features can only be used with the turntable
on. When the turntable is set in the off position, only
manual operation can be used except for the Reheat
function which can be used for both options.
When cooking large quantities of food which cannot
be stirred, it is best to use a lower power level such
as 40% or 50%. You may speed cooking for large
amounts by programming 5 to 10 minutes on 100%
power (HIGH) followed by the desired time on
lower power. See page 15 for how to program multiple
sequences. You may wish to reverse a large casserole
once during cooking; simply open door, reposition
casserole, close door and touch START.
• Suppose you want to turn the turntable off.
2 Select the desired time.
Press the START pad.
USING THE RACK
The Rack allows several foods to be cooked or
reheated at one time. However, for the best cooking
and reheating, use the turntable on and the automatic
features.
When using the Rack, set time and power level
manually. Allow plenty of space around and
between the dishes. Pay close attention to the cooking/
reheating progress. Reposition the foods and reverse
them from rack to turntable at least once during any
cooking or reheating time. Using a lower power level
will assist in better cooking/reheating uniformity.
AVOID:
•Storing the Rack in the oven when not in use.
•Popping popcorn on the turntable with the Rack in
the oven.
•Using any browning dish on the Rack.
•Using special features with the Rack. Special
features are designed to be used with foods only
on the revolving turntable.
• Cooking directly on the Rack—use microwave-safe
cookware.
Press Turntable On/Off. The turntable off icon
will appear on the top left of the display.
To turn the turntable on again, press Turntable
On/Off. The turntable off icon will disappear.
30
SET UP
Set Up has six functions.
1. Clock
2. Auto Start
3. Sound Adjustment
To use any function, press Set Up, touch desired function and follow directions on the screen.
1.CLOCK
Press the Set Up pad, touch Clock and follow the directions on the screen. See page 13.
2.AUTO START
The Auto Start function allows you to set your oven to start automatically at a later time.
•Suppose you want to start cooking a stew for 20 minutes on 50% power at 4:30 P.M. Before setting, check to
make sure the clock is showing the correct time of day.
4. Child Lock
5. Video Demo
6. Screen Contrast
1 Press Set Up pad and then
touch the desired function:
Auto Start.
4 Touch 50%. The top line of
the display will show time
and chosen power level.
Press START pad.
NOTE:
1. Auto Start can be used for manual cooking only, if
clock is set.
2 Enter start time (4:30) using
the screen choices and then
touch PM. Press START pad.
5 Auto Start time will appear.
3 Enter cooking time, 2, 0, 0,
0 by using numbers on the
screen. Touch Power Level.
2. Be sure to choose foods that can be left in the oven
safely until the Auto Start time. Acorn or butternut
squash are often a good choice.
31
SET UP
3.SOUND ADJUSTMENT
The oven offers a choice of Simple Beep, Melody
or No Sound. The oven comes set for Melody.
Touch your choice on the screen and then press
START. The selected sound does not change even if
the electrical power supply is interrupted. Note that
even when No Sound is chosen, there will be a sound
for the Kitchen Timer, if it was set.
Reminder:
An audible signal reminds you that cooking,
defrosting or reheating has finished. The sound will
repeat every 60 seconds and continue for 30 minutes
unless you touch STOP/CLEAR or open the door . T o
set the Reminder, touch On on the End of Cooking
Reminder screen. The setting does not change even
if the electrical power supply is interrupted. The
Reminder cannot be set if “No Sound” was selected.
4.CHILD LOCK
The Child Lock prevents unwanted oven operation
such as by small children. The oven can be set so
that the control panel is deactivated or locked.
5.VIDEO DEMO
The Video Demo is an automated “tour” through
many of the features of the SMART & EASY
TOUCH SCREEN oven. You may wish to observe
it when the oven is new or when you are teaching
family members how to use the oven. There are five
short segments in the Video Demo.
6.SCREEN CONTRAST
Normally there is no need to change the display
contrast; however, should you wish to do so, touch
Lighter or Darker until the contrast is as desired.
And then press START pad. Be cautious when
touching Lighter so that the display is always readable. The selected contrast will not change even if
the electrical power supply is interrupted.
OTHER CONVENIENT FEATURES
MINUTE PLUS
Minute Plus allows you to cook for a minute at 100% power by simply touching the MINUTE PLUS pad. You
can also extend cooking time in multiples of one minute by repeatedly touching the MINUTE PLUS pad during
manual cooking.
• Suppose you want to heat a cup of soup for one minute using 100% power.
NOTE:
To use Minute Plus, touch pad within three minutes
after cooking, closing the door, touching the STOP/
CLEAR pad or during cooking.
Touch MINUTE PLUS
pad on control panel.
32
OTHER CONVENIENT FEATURES
MINUTE PLUS+
Touch Minute Plus+ on the screen to access a new screen with 12 common cooking times at 100% power.
Touch desired time and the oven starts automatically.
• Suppose you want to melt butter for 30 seconds.
2 Touch desired time: 30 seconds.1 Touch Minute Plus+.3 The oven will start
automatically.
KITCHEN TIMER
Use this feature as a general purpose timer. You can enter any time up to 99 minutes and 99 seconds. If you
want to cancel the timer during the count down phase, simply press STOP/CLEAR and the display will return
to the Home Page.
•Suppose you want to time a three minute long distance phone call:
1 Touch Kitchen Timer.3 The Kitchen Timer will
NOTE:
Even if all sound is off, the oven will beep when the Kitchen Timer ends.
2 Enter desired time by
touching numbers : 3, 0, 0.
Press START pad.
33
start counting down.
OTHER CONVENIENT FEATURES
MORE OR LESS TIME ADJUSTMENT
The programmed cooking times are tailored to the most popular tastes. To adjust the cooking time to your
individual preference use the “more” or “less” feature to either add or reduce cooking time.
•Suppose you want to cook Ground Beef for more time:
1 Press Meats pad in the 6x6
NO GUESS COOKING and
then touch Ground Beef.
NOTE:
1. Once you have selected either More Time or Less
Time, it cannot be changed.
2 Prepare the food following
the information on the screen.
And press START pad.
3 After pressing the START
pad, Less Time and More
Time will appear. Touch
desired choice, if any.
2. Choosing More Time or Less Time must be done
within seven seconds after touching START.
34
CLEANING AND CARE
DOOR
Wipe the window on both sides with a damp cloth to
remove any spills or spatters. Metal parts will be
easier to maintain if wiped frequently with a damp
cloth. Avoid the use of harsh abrasives.
EXTERIOR
The outside surface is painted. Clean the outside with
mild soap and water; rinse and dry with a soft cloth.
Do not use any type of household or abrasive
cleaner.
INTERIOR
Cleaning is easy because no heat is generated to the
interior surfaces; therefore, there is no baking and
setting of spills or spattering. To clean the interior
surfaces, wipe with a soft cloth and warm water. DO
NOT USE ABRASIVE OR HARSH CLEANERS
OR SCOURING P ADS. For heavier soil, use baking
soda or a mild soap; rinse thoroughly with hot water.
NEVER SPRAY OVEN CLEANERS DIRECTLY
ONTO ANY PART OF THE OVEN.
WA VEGUIDE COVER
Carefully wash any food particles from the waveguide
cover located on the right side in the oven cavity . Do
not remove the waveguide cover.
ODOR REMOV AL
Occasionally, a cooking odor may remain in the oven.
To remove, combine 1 cup water , grated peel and juice
of 1 lemon and several whole cloves in a 2 cup glass
measuring cup. Boil for several minutes using 100%
power. Allow to set in oven until cool. W ipe interior
with a soft cloth.
TURNTABLE / TURNTABLE
SUPPORT
The turntable and turntable support can be removed
for easy cleaning. Wash them in mild, sudsy water;
for stubborn stains use a mild cleanser and scouring
sponge as described above. They are also dishwasherproof. Use upper rack of dishwasher. The turntable
motor shaft is not sealed, so excess water or spills
should be wiped up immediately.
Turntable
Turntable Support
GREASE FIL TERS
Filters should be cleaned at least once a month. Never
operate the fan or oven without the filters in place.
1.Pull down slightly on the tab toward the front of
the oven and remove the filter. Repeat for the other
filter.
2. Soak the filters in a sink or dish pan filled with
hot water and detergent. DO NOT use ammonia or
other alkali; they will react with the filter material
and darken it.
3.Agitate and scrub with a brush to remove embedded
dirt.
4.Rinse thoroughly and shake dry.
5.Replace by fitting the filter back into the opening.
CONTROL PANEL
Care should be taken in cleaning the control panel. If
the control panel becomes soiled, open the oven door
before cleaning. Wipe the panel with a cloth
dampened slightly with water only. Dry with a soft
cloth. Do not scrub or use any sort of chemical
cleaners. Close door and touch STOP/CLEAR.
TOUCH SCREEN
Wipe the touch screen with a damp cloth and then
dry with a soft cloth. Do not allow soil to accumulate
on the touch screen.
Tab
Grease filter
35
REPLACING PARTS
CHARCOAL FIL TER
Charcoal Filter, Sharp Part number RK-230 which
was enclosed with your oven, is used for nonvented,
recirculated installation. The filter should be changed
every 6 to 12 months depending on use. See page 6
for ordering information.
1.Disconnect power to the oven at the circuit breaker
panel or by unplugging.
2. Remove center screw from the top center of the
louver and push down carefully on the tab at each
end of the louver to disengage.
3.Pull the louver away from the unit.
4.Change the charcoal filter.
5.To replace, insert the top tabs of hood louver into
the 3 openings on the cavity faceplate holding
louver at a slightly outward tilt. Rotate louver so
the top tabs are positoned in the cavity faceplate
openings. Push in the bottom of louver to ensure
that the three bottom clips snap into the cavity
faceplate. Check for proper engagement and replace
the screw removed in step 2.
Top tabs
Oven light
Screw
3.Remove old light bulb and replace only with
equivalent watt bulb available from a Sharp
Authorized Servicer or parts distributor. Bulbs are
also available at most hardware stores or lighting
centers. DO NOT USE BULB LARGER THAN
30 WATTS.
4.Replace the oven light cover by carefully pushing
into place. Replace the charcoal filter, if used. Push
the louver back into place and replace the louver
mounting screw.
WORK LIGHT AND
NIGHT LIGHT
1. To replace light bulbs, first disconnect power to
the oven at the circuit breaker panel or by
unplugging.
2. To release cover, remove the screw on the light
cover. (See illustration.)
3.Replace light bulbs with equivalent watt bulb
available from your Sharp Authorized Servicer or
parts distributor. Bulbs are also available at most
hardware stores or lighting centers. DO NOT USE
A BULB LARGER THAN 30 WATTS.
4.Close light cover and secure with screw removed
in step 2.
Cavity
faceplate
Charcoal
filter
OVEN LIGHT
Remove the louver per instructions 1-3 above and
charcoal filter, if used.
1.T o replace light bulb, first disconnect power to the
oven at the circuit breaker panel or by unplugging.
2.Open light cover located behind filter mounting by
carefully pulling up on the front edge.
Hood louver
Bottom clips
CAUTION: Light cover may become very hot. Do not
touch glass when light is on.
Light cover
Screw
Light bulbs
36
SPECIFICATIONS
R-1750, R-1751, R-1752, R-1754,
AC Line Voltage:
AC Power Required:
Output Power:
Frequency:
Outside Dimensions (not including handle):
Cavity Dimensions:
Oven Capacity:
Cooking Uniformity:
Weight:
Work/Night Light:
* The International Electrotechnical Commission’s standardized method for measuring output wattage.
This test method is widely recognized.
In compliance with standards set by:
FCC–Federal Communications Commission Authorized.
DHHS –Complies with Department of Health and Human Services (DHHS) rule, CFR, Title 21, Chapter I,
Subchapter J.
–This symbol on the nameplate means the product is listed by Underwriters Laboratories, Inc.
Single phase 120V, 60Hz, AC only
1600 watts, 14 amps.
1100 watts* (IEC Test Procedure)
2450 MHz
15
29
/16"(W) x 16 3/8"(H) x 16 15/16"(D)
7
21"(W) x 8
1.6 Cu. Ft.
Turntable system
Approx. (net) 55 lb, (gross) 60 lb
2 bulbs 30w max. each (incandescent light bulbs)
/8"(H) x 14 7/16"(D)
THE ULTIMATE ACCESSORY
✪
Great recipes
✪
Reliable microwave
reference guide
✪
Many color photos
✪
Step-by-step
instructions
✪
Nutritional
information for
each recipe
✪
Durable wipe-clean
soft cover with 128
8 1/
✪
Helpful tips and
x 11 pages
2
special techniques
TO ORDER
Simply call this toll-free number : 1-800-642-2122. Please
have your credit card ready.
If you prefer to order by mail, complete and return the
order form on page 38. Please include check or money
order (payable to Sharp Accessories & Supplies Center)
for $6.00 plus $4.25 shipping & handling and tax, if
applicable, per book.
SATISFACTION GUARANTEED
You must be completely satisfied with the Sharp
Carousel Microwave Cookbook. If, within 14 days, you
are dissatisfied for any reason, simply return the book and
we'll gladly refund your $6.00 plus tax.
CAROUSEL MICROWA VE
COOKBOOK
(SOLAMENTE ESCRITO EN INGLES!)
37
SERVICE CALL CHECK
Please check the following before calling for service:
Place one cup of water in a glass measuring cup in the oven and close the door securely.
Operate the oven for one minute at HIGH 100%.
A
Does the oven light come on?YES _______ NO _______
B
Does the cooling fan work?YES _______ NO _______
(Put your hand over the rear ventilating openings.)
C
Does the turntable rotate?YES _______ NO _______
It is normal for the turntable to turn in either direction.
D
Is the water in the oven warm?YES _______ NO _______
If “NO” is the answer to any of the above questions, please check electrical outlet, fuse and/or circuit breaker.
If they are functioning properly, CONTACT YOUR NEAREST SHARP AUTHORIZED SERVICER.
A microwave oven should never be serviced by a “do-it-yourself” repair person.
NOTE: If count-down time is appearing on the screen and counting down very rapidly, follow directions below
to cancel Hidden Demo.
Press STOP/CLEAR pad and hold for four seconds until an audible signal is heard.
Quickly press STOP/CLEAR key four times within the next two seconds.
Cut along this line.
COOKBOOK ORDER FORM
PERSONAL RECIPES AND NO TES
Please send me ______ cookbooks at $10.25 each$ ________
Illinois sales tax, (if applicable) per book $.44 no. of books _____________$ ________
Other tax, (if applicable) no. of books _____________$ ________
TOTAL ORDER AMOUNT$ ________
I have enclosed a check made payable to Sharp Accessories & Supplies Center.
Please bill myVISAMASTERCARD AMERICAN EXPRESS
Acct. No. _______________________________________ Expiration date _______ / ___________
Signature_________________________________________________________________________
(All credit card orders must be signed.)
Name _____________________________________________________________________________________
Address ___________________________________________________________________________________
City ____________________________________________ State ____________ Zip ______________________
Daytime Phone No. ( _______ ) _________________________________________________________________
For more complete information and safety precautions, refer to your Operation Manual.
SET CLOCK
If the oven has just been plugged in, touch Set
Clock on the screen and follow the directions. To
reset the clock, press Set Up pad on the control panel.
Then touch Clock on screen.
1
Enter the time of day (hour).
2
Enter the time of day (minutes).
3
Select AM or PM and then
press START pad.
START
MANUAL OPERATION
High Power Cooking
1
Enter cooking time by touching
numbers on the home page.
2
Press START pad.
START
Variable Power Cooking
1
After Step 1 above, touch Power
Level on the screen.
2
Touch desired Power Level
(Ex: 30%).
3
Press START pad.
START
ONE TOUCH SENSOR: REHEAT
Press Reheat pad and touch desired
function. Follow the directions on the
TOUCH SCREEN and press ST AR T.
When sensor detects the vapor
emitted from the food, remainder of
cooking time will appear.
MORE FROM YOUR
MICROWAVE 6X6
1
Press the MORE FROM
YOUR MICROWAVE 6x6
pad and then touch the desired
category.
2
Select the desired food from
the screen.
3
Follow directions on the screen.
4
When the oven stops, follow
instructions.
START
6x6 NO GUESS COOKING
For foods not using the sensor, follow the directions on the screen to enter quantity . When cooking
foods with the sensor, it is not neccessary to enter
quantity or weight.
1
Press the Vegetables pad and then
touch the desired vegetable.
2
Touch the desired doneness and
the oven will start automatically.
3
After cooking, follow instructions.
DEFROST 3+6: COMPU DEFROST
1
Press the Defrost 3+6 pad and then
touch COMPU DEFROST 6 Choices.
2
Select the desired food and weight
by touching the screen.
3
Press START pad.
4
Follow instructions.
5
After the defrost cycle ends, read the
START
screen. Remove the food from oven, cover
and let stand for the suggested time to
allow defrosting to be completed.
SET UP: AUTO START
The Auto Start function allows you to set the
oven to start automatically at a later time.
1
Press the Set Up pad and then touch
Auto Start on the screen.
2
Follow instuctions.
MINUTE PLUS
Minute Plus allows you to cook for
one minute at 100% power by
simply touching the MINUTEPLUS pad on the control panel.
MINUTE PLUS+
Touch Minute Plus+ on the screen to access a new
screen with 12 common cooking times at 100%
power. Touch desired time and the oven starts
automatically.
Carousel® and Auto-touch® are registered trademarks of Sharp Corporation.
SHARP ELECTRONICS CORPORATION
®
Sharp Plaza, Mahwah, New Jersey 07430-2135
TINSEB228MRK0 Printed in USA
40
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
