Sharp PG-F320W User Manual
DATA PROJECTOR
MODEL
PG-F320W
OPERATION MANUAL
Introduction Quick Start
Setup
Connections
Operation
Basic
Features
Useful
Appendix
IMPORTANT
• For your assistance in reporting the loss
or theft of your Projector, please record
the Model and Serial Number located on
the bottom of the projector and retain this
information.
• Before recycling the packaging, please
ensure that you have checked the contents of the carton thoroughly against the
list of “Supplied accessories” on page 11.
Model No.:
Serial No.:
ii
SPECIAL NOTE FOR USERS IN THE U.K.
The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 10A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362
fuse marked
face of the plug, must be used.
Always refit the fuse cover after replacing the fuse. Never use the plug without the fuse
cover fitted.
In the unlikely event of the socket outlet in your home not being compatible with the plug
supplied, cut off the mains plug and fit an appropriate type.
DANGER:
The fuse from the cut-off plug should be removed and the cut-off plug destroyed immediately and disposed of in a safe manner.
Under no circumstances should the cut-off plug be inserted elsewhere into a 13A socket
outlet, as a serious electric shock may occur.
To fit an appropriate plug to the mains lead, follow the instructions below:
WARNING:
THIS APPARATUS MUST BE EARTHED.
IMPORTANT:
The wires in this mains lead are coloured in accordance with the following code:
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this apparatus may not correspond with the
coloured markings identifying the terminals in your plug proceed as follows:
or and of the same rating as above, which is also indicated on the pin
• The wire which is coloured green-and-yellow must be connected to the terminal in the
plug which is marked by the letter E or by the safety earth symbol
green-and-yellow.
or coloured green or
• The wire which is coloured blue must be connected to the terminal which is marked with
the letter N or coloured black.
• The wire which is coloured brown must be connected to the terminal which is marked with
the letter L or coloured red.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.
iii
The supplied CD-ROM contains operation instructions in English, German, French,
Spanish, Italian, Dutch, Swedish, Portuguese, Chinese and Korean. Carefully read
through the operation instructions before operating the projector.
Die mitgelieferte CD-ROM enthält Bedienungsanleitungen in Englisch, Deutsch, Französisch,
Spanisch, Italienisch, Niederländisch, Schwedisch, Portugiesisch, Chinesisch und Koreanisch.
Bitte lesen Sie die Bedienungsanleitung vor der Verwendung des Projektors sorgfältig durch.
Le CD-ROM fourni contient les instructions de fonctionnement en anglais, allemand,
français, espagnol, italien, néerlandais, suédois, portugais, chinois et coréen. Veuillez lire
attentivement ces instructions avant de faire fonctionner le projecteur.
Den medföljande CD-ROM-skivan innehåller bruksanvisningar på engelska, tyska,
franska, spanska, italienska, holländska, svenska, portugisiska, kinesiska och koreanska.
Läs noga igenom bruksanvisningen innan projektorn tas i bruk.
El CD-ROM suministrado contiene instrucciones de operación en inglés, alemán,
francés, español, italiano, holandés, sueco, portugués, chino y coreano. Lea
cuidadosamente las instrucciones de operación antes de utilizar el proyector.
Il CD-ROM in dotazione contiene istruzioni per l’uso in inglese, tedesco, francese,
spagnolo, italiano, olandese, svedese, portoghese, cinese e coreano. Leggere
attentamente le istruzioni per l’uso prima di usare il proiettore.
De meegeleverde CD-ROM bevat handleidingen in het Engels, Duits, Frans, Spaans,
Italiaans, Nederlands, Zweeds, Portugees, Chinees en Koreaans. Lees de handleiding
zorgvuldig door voor u de projector in gebruik neemt.
O CD-ROM fornecido contém instruções de operação em Inglês, Alemão, Francês,
Espanhol, Italiano, Holandês, Sueco, Português, Chinês e Coreano. Leia
cuidadosamente todas as instruções de operação antes de operar o projetor.
iv
Before using the projector, please read this operation manual carefully.
Introduction
Introduction
ENGLISH
There are two important reasons for prompt warranty registration of your new SHARP
Projector, using the REGISTRATION CARD packed with the projector.
1. WARRANTY
This is to assure that you immediately receive the full benefit of the parts, service
and labor warranty applicable to your purchase.
2. CONSUMER PRODUCT SAFETY ACT
To ensure that you will promptly receive any safety notification of inspection,
modification, or recall that SHARP may be required to give under the 1972
Consumer Product Safety Act, PLEASE READ CAREFULLY THE IMPORTANT
“LIMITED WARRANTY” CLAUSE.
U.S.A. ONLY
WARNING: High brightness light source. Do not stare into the beam of light, or view
directly. Be especially careful that children do not stare directly into the
beam of light.
WARNING: To reduce the risk of fire or electric shock, do not expose
this product to rain or moisture.
See bottom of projector.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT REMOVE SCREWS
EXCEPT SPECIFIED USER
SERVICE SCREW.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
NO USER-SERVICEABLE PARTS EXCEPT LAMP UNIT.
DO NOT REMOVE COVER.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence
of uninsulated “dangerous voltage”
within the product’s enclosure that may
be of sufficient magnitude to constitute
a risk or electric shock to persons.
The exclamation point within a triangle
is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the product.
WARNING: FCC Regulations state that any unauthorized changes or modifications to
this equipment not expressly approved by the manufacturer could void
the user’s authority to operate this equipment.
U.S.A. ONLY
1
INFORMATION
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the operation manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct the
interference at his own expense.
U.S.A. ONLY
The enclosed computer cable must be used with the device. The cable is
provided to ensure that the device complies with FCC Class A verification.
U.S.A. ONLY
WARNING:
This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
PRODUCT DISPOSAL
This product utilizes tin-lead solder, and lamp containing a small amount
of mercury. Disposal of these materials may be regulated due to
environmental considerations. For disposal or recycling information,
please contact your local authorities, the Electronics Industries Alliance:
www.eiae.org, the lamp recycling organization www.lamprecycle.org,
or Sharp at 1-800-BE-SHARP.
U.S.A. ONLY
Caution Concerning Lamp Replacement
See “Replacing the Lamp” on page 57.
This SHARP projector uses a DLP® chip. This very sophisticated panel contains 1,024,000 pixels
(micromirrors). As with any high technology electronic equipment such as large screen TVs,
video systems and video cameras, there are certain acceptable tolerances that the equipment
must conform to.
This unit has some inactive pixels within acceptable tolerances which may result in inactive dots
on the picture screen. This will not affect the picture quality or the life expectancy of the unit.
Authorized representative responsible for the European Union Community Market
SHARP ELECTRONICS (Europe) GmbH
Sonninstraße 3, D-20097 Hamburg
E.U. ONLY
2
How to Read this Operation Manual
■ The specifications are slightly different, depending on the model. However, you can connect and
operate all models in the same manner.
••
• In this operation manual, the illustration and the screen display are simplified for explanation, and
••
may differ slightly from the actual display.
Using the Menu Screen
ENTER button
Adjustment buttons (P/R/O/Q)
MENU/HELP button
ENTER button
Adjustment buttons
Menu Selections (Adjustments)
Example: Adjusting “Bright”.
• This operation can also be performed by using the buttons on the projector.
Press MENU/HELP.
1
• The “Picture” menu screen for the selected input mode is displayed.
Press Q or O and select “Picture”
2
to adjust.
Example: “Picture” screen menu for
COMPUTER (RGB) input
Menu item
Picture SCR PRJ Net. Help
Picture Mode
Contrast 0
Bright
Red
Blue
CLR Temp
TM
BrilliantColor
C.M.S. Setting
C.M.S.
Lamp Setting
Reset
SEL./ADJ. ENTER END
(P/R/O/Q)
RETURN button
•Press RETURN to return
to the previous screen
when the menu is
displayed.
MENU/HELP button
Standard
0
0
0
0
0
1
On
Bright
Features
Useful
Buttons used in
this operation
Button used in
this step
On-screen
display
Introduction
Info
........Indicates safeguards for using the projector.
.........Indicates additional information for setting up and operating the
Note
projector.
For Future Reference
PP. 62 and 63
39
IndexMaintenance Troubleshooting
P. 67P. 52
3
Contents
Preparing
Introduction
How to Read this Operation Manual .... 3
Contents ............................................... 4
IMPORTANT SAFEGUARDS ............... 6
How to Access the PDF Operation
Manuals ............................................ 10
Accessories ........................................ 11
Part Names and Functions ................. 12
Projector ............................................... 12
Rear View ............................................. 13
Inserting the Batteries .......................... 15
Usable Range ...................................... 15
Quick Start
Quick Start .......................................... 16
Setup and Projection ............................ 16
Setup
Setting up the Projector ...................... 18
Setting up the Projector ....................... 18
Standard Setup (Front Projection) ....... 18
Ceiling-mount Setup ............................ 18
Projection (PRJ) Mode ......................... 19
Screen Size and Projection Distance .. 20
Connections
Connecting the Projector to
Other Equipment .............................. 21
Controlling the Projector by
a Computer ....................................... 24
Connecting the Power Cord ............... 25
Using
Basic Operation
Tu r ning the Projector On/Off .............. 26
Turning the Projector on ....................... 26
Turning the Power off (Putting the
Projector into Standby Mode) ........... 26
Image Projection ................................. 27
About the Setup Guide ........................ 27
Adjusting the Projected Image ............ 27
Correcting Trapezoidal Distortion ........ 29
Switching the Input Mode .................... 30
Adjusting the Volume ........................... 30
Displaying the Black Screen and
Tur ning off the Sound Temporarily .... 30
Resize Mode ......................................... 31
Useful Features
Operating with the Remote Control .... 33
Displaying and Setting the
Break Timer........................................ 33
Displaying the Pointer .......................... 33
Using the Spot Function ...................... 33
Switching the Eco+Quiet Mode ........... 33
Auto Sync (Auto Sync Adjustment) ..... 34
Freezing a Moving Image .................... 34
Selecting the Picture Mode .................. 34
Displaying an Enlarged Portion of
an Image ............................................ 34
Using the Remote Control as the
Wireless Computer Mouse ................ 35
Menu Items ......................................... 36
Using the Menu Screen ...................... 39
Menu Selections (Adjustments) ........... 39
Picture Adjustment (“Picture” Menu) ... 41
Selecting the Picture Mode .................. 41
Adjusting the Image ............................. 42
Adjusting the Color Temperature ......... 42
Adjusting the Colors ............................. 42
Progressive ........................................... 43
Lamp Setting ........................................ 43
Adjusting the Projector Image
(“SCR - ADJ” Menu) ......................... 44
Setting the Resize Mode ...................... 44
Adjusting the Image Position ............... 44
Keystone Correction ............................ 44
Setting the On-screen Display ............. 45
Selecting the Background Image ........ 45
Selecting the Setup Guide ................... 45
Reversing/Inverting Projected
Images ............................................... 45
Selecting the On-screen Display
Language ........................................... 45
Adjusting the Projector Function
(“PRJ - ADJ” Menu) .......................... 46
Auto Sync (Auto Sync Adjustment) ..... 46
Auto Power Off Function ...................... 46
Auto Restart Function .......................... 46
STANDBY Mode ................................... 46
Setting the Confirmation Sound
(System Sound) ................................. 46
Speaker Setting .................................... 46
Audio Input ........................................... 47
Selecting the Transmission Speed
(RS-232C) .......................................... 47
Fan Mode Setting ................................. 47
System Lock Function .......................... 47
Checking the Lamp Life Status ........... 48
Keylock Function .................................. 48
4
Setting up the Projector Network
Environment (“Network” menu) ........ 49
Setting a Password .............................. 49
DHCP Client Setting ............................. 50
TCP/IP Setting ...................................... 50
Confirming the Projector Information ... 50
Troubleshooting with the
“Help” Menu ...................................... 51
Utilizing the “Help” Menu Functions .... 51
Reference
Appendix
Maintenance ....................................... 52
Cleaning and Replacing the
Dust Filters ....................................... 53
Cleaning the Dust Filters ...................... 53
Replacing the Dust Filters .................... 54
Maintenance Indicators ...................... 55
Regarding the Lamp ........................... 57
Lamp ..................................................... 57
Caution Concerning the Lamp ............ 57
Replacing the Lamp ............................. 57
Removing and Installing the
Lamp Unit .......................................... 58
Resetting the Lamp Timer .................... 59
Storing the Projector ........................... 60
How to Use the Storage Case ............. 60
Computer Compatibility Chart ............ 61
Troubleshooting .................................. 62
For SHARP Assistance ...................... 64
Specifications ..................................... 65
Dimensions ......................................... 66
Index ................................................... 67
Introduction
5
IMPORTANT SAFEGUARDS
CAUTION: Please read all of these instructions before you operate this product
and save these instructions for later use.
Electrical energy can perform many useful functions. This product has been engineered
and manufactured to assure your personal safety. BUT IMPROPER USE CAN RESULT IN
POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the
safeguards incorporated in this product, observe the following basic rules for its installation,
use and servicing.
1. Read Instructions
All the safety and operating instructions should
be read before the product is operated.
2. Retain Instructions
The safety and operating instructions should be
retained for future reference.
3. Heed Warnings
All warnings on the product and in the operating
instructions should be adhered to.
4. Follow Instructions
All operating and use instructions should be
followed.
5. Cleaning
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
6. Attachments
Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7. Water and Moisture
Do not use this product near water–for example,
near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a
swimming pool; and the like.
8. Accessories
Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may
fall, causing serious injury to a child or adult, and
serious damage to the product. Use only with a
cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the product. Any mounting of the product should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
9. Transportation
A product and cart
combination should be
moved with care. Quick
stops, excessive force,
and uneven surfaces may
cause the product and cart
combination to overturn.
10. Ventilation
Slots and openings in the cabinet are provided
for ventilation to ensure reliable operation of the
product and to protect it from overheating, and
these openings must not be blocked or covered.
The openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar
surface. This product should not be placed in a
built-in installation such as a bookcase or rack
unless proper ventilation is provided or the
manufacturer’s instructions have been adhered
to.
11. Power Sources
This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply to your home, consult your product dealer
or local power company. For products intended
to operate from battery power, or other sources,
refer to the operating instructions.
12. Grounding or Polarization
This product is provided with one of the following
types of plugs. If the plug should fail to fit into the
power outlet, please contact your electrician.
Do not defeat the safety purpose of the plug.
a. Two-wire type (mains) plug.
b. Three-wire grounding type (mains) plug with
a grounding terminal.
This plug will only fit into a grounding type
power outlet.
13. Power-Cord Protection
Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at plugs, convenience
receptacles, and the point where they exit from
the product.
14. Lightning
For added protection for this product during a
lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from
the wall outlet and disconnect the cable system.
This will prevent damage to the product due to
lightning and power-line surges.
6
Introduction
15. Overloading
Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can
result in a risk of fire or electric shock.
16. Object and Liquid Entry
Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short-out parts that could result
in a fire or electric shock. Never spill liquid of any
kind on the product.
17. Servicing
Do not attempt to service this product yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
18. Damage Requiring Service
Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
a. When the power-supply cord or plug is
damaged.
b. If liquid has been spilled, or objects have fallen
into the product.
c. If the product has been exposed to rain or
water.
d. If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the
operating instructions, as an improper
adjustment of other controls may result in
damage and will often require extensive work
by a qualified technician to restore the product
to normal operation.
e. If the product has been dropped or damaged
in any way.
f. When the product exhibits a distinct change
in performance, this indicates a need for
service.
19. Replacement Parts
When replacement parts are required, be sure
the service technician has used replacement
parts specified by the manufacturer or have the
same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock, or other hazards.
20. Safety Check
Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operating condition.
21. Wall or Ceiling Mounting
This product should be mounted to a wall or
ceiling only as recommended by the
manufacturer.
22. Heat
This product should be situated away from heat
sources such as radiators, heat registers, stoves,
or other products (including amplifiers) that
produce heat.
• DLP® and the DLP logo are registered trademarks of Texas Instruments and BrilliantColor
is a trademark of Texas Instruments.
• Microsoft
®
and Windows® are registered trademarks of Microsoft Corporation in the United
States and/or other countries.
• PC/AT is a registered trademark of International Business Machines Corporation in the
United States.
®
• Adobe
• Macintosh
Reader® is a trademark of Adobe Systems Incorporated.
®
is a registered trademark of Apple Computer, Inc. in the United States and/or
other countries.
• All other company or product names are trademarks or registered trademarks of their
respective companies.
• Some IC chips in this product include confidential and/or trade secret property belonging
to Texas Instruments. Therefore you may not copy, modify, adapt, translate, distribute,
reverse engineer, reverse assemble or discompile the contents thereof.
TM
7
Observe the following safeguards when setting up your
projector.
Caution concerning the lamp unit
■ Potential hazard of glass particles if lamp ruptures. In case
of lamp rupture, contact your
nearest Sharp Authorized
Projector Dealer or Service
Center for replacement.
See “Replacing the Lamp” on
page 57.
Caution concerning the setup of the
projector
■ For minimal servicing and to maintain high
image quality, SHARP recommends that this
projector be installed in an area free from
humidity, dust and cigarette smoke. When the
projector is subjected to these environments,
the vents and lens must be cleaned more often. As long as the projector is regularly
cleaned, use in these environments will not
reduce the overall operation life of the unit.
Internal cleaning should only be performed
by a Sharp Authorized Projector Dealer or
Service Center.
Do not set up the projector in places
exposed to direct sunlight or bright light.
■ Position the screen so that it is not in direct
sunlight or room light. Light falling directly on
the screen washes out the colors, making
viewing difficult. Close the curtains and dim
the lights when setting up the screen in a
sunny or bright room.
Caution regarding placing of the projector
■ Place the projector on a level site within the
adjustment range (8 degrees) of the adjustment foot.
■ After the projector is purchased, a faint smell
from the vent may appear when the power is
first turned on. This is normal and is not a
malfunction. It will disappear after the projector is used for a while.
When using the projector in high-altitude
areas such as mountains (at altitudes of
approximately 1,500 meters (4,900 feet)
or more)
■ When you use the projector in high-altitude
areas with thin air, set “Fan Mode” to “High”.
Neglecting this can affect the longevity of the
optical system.
Warning about placing the projector in
a high position
■ When placing the projector in a high position,
make certain it is carefully secure to avoid
personal injury caused by the projector falling down.
Do not subject the projector to hard
impact and/or vibration.
■ Protect the lens so as not to hit or damage
the surface of the lens.
Rest your eyes occasionally.
■ Continuously watching the screen for long
hours will cause eye strain. Take regular
breaks to rest your eyes.
Avoid locations with extremes of
temperature.
■ The operating temperature of the projector is
from 41°F to 95°F (+5°C to +35°C).
■ The storage temperature of the projector is
from –4°F to 140°F (–20°C to +60°C).
Do not block the exhaust and intake
vents.
■ Allow at least 11 13/16 inches (30 cm) of space
between the exhaust vent and the nearest
wall or obstruction.
■ Ensure that the intake vent and the exhaust
vent are not obstructed.
■ If the cooling fan becomes obstructed, a protection circuit will automatically put the projector into standby mode to prevent overheat
damage. This does not indicate a malfunction. (See pages 55 and 56.) Remove the pro-
jector power cord from the wall outlet and wait
at least 10 minutes. Place the projector where
the intake and exhaust vents are not blocked,
plug the power cord back in and turn on the
projector. This will return the projector to the
normal operating condition.
8
Caution regarding usage of the projector
■ If you are not to use the projector for a long
time or before moving the projector, make
certain you unplug the power cord from the
wall outlet, and disconnect any other cables
connected to it.
■ If the power cord is unplugged while the
cooling fan is running, some parts of the
projector may still be hot. Use caution when
handling the projector.
■ Do not carry the projector by holding the lens.
■ When storing the projector, ensure you at-
tach the lens cap to the projector. (See page
12.)
■ Do not expose the projector to direct sunlight
or place next to heat sources. Doing so may
affect the cabinet color or cause deformation
of the plastic cover.
Other connected equipment
■ When connecting a computer or other audiovisual equipment to the projector, make the
connections AFTER unplugging the power
cord of the projector from the AC outlet and
turning off the equipment to be connected.
■ Please read the operation manuals of the projector and the equipment to be connected for
instructions on how to make the connections.
Using the projector in other countries
■ The power supply voltage and the shape of
the plug may vary depending on the region
or country you are using the projector in.
When using the projector overseas, make
sure you use an appropriate power cord for
the country you are in.
Temperature monitor function
■
If the projector starts to overheat due to setup
problems or blockage of the air vents, “ ” and
“ ” will illuminate in the lower left corner
of the picture. If the temperature continues to
rise, the lamp will turn off, the temperature warning indicator on the projector will blink, and after
a 60-second cooling-off period the projector will
enter standby mode. Refer to “Maintenance Indicators” on page 55 for details.
Info
• The cooling fan regulates the internal temperature, and its performance is automatically
controlled. The sound of the fan may change
during projector operation due to changes in
the fan speed. This does not indicate
malfunction.
• Even if you unplug the power cord after
projector operation, the cooling fan continues
to run for a while.
Introduction
9
How to Access the PDF Operation Manuals
PDF operation manuals in several languages are included in the CD-ROM. To utilize these manuals, you need to install Adobe
®
dows
or Macintosh®).
Please download Adobe
®
Reader® from the Internet (http://www.adobe.com).
®
Reader® on your computer (Win-
Accessing the PDF Manuals
For Windows®:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click the “My Computer” icon.
3 Double click the “CD-ROM” drive.
4 When you want to view the operation
manual
1) Double click the “MANUALS” folder.
2) Double click the language (name of the
folder) that you want to view.
3) Double click the pdf file to access the
projector manuals.
When you want to view the SETUP
MANUAL
1) Double click the “SETUP” folder.
2) Double click the language (name of the
folder) that you want to view.
3) Double click the pdf file to access the
SETUP MANUAL.
Note
• If the desired pdf file cannot be opened by double clicking the mouse, start Adobe® Reader® first,
then specify the desired file using the “File”, “Open” menu.
For Macintosh®:
1 Insert the CD-ROM in the CD-ROM drive.
2 Double click the “CD-ROM” icon.
3 When you want to view the operation
manual
1) Double click the “MANUALS” folder.
2) Double click the language (name of the
folder) that you want to view.
3) Double click the pdf file to access the
projector manuals.
When you want to view the SETUP
MANUAL
1) Double click the “SETUP” folder.
2) Double click the language (name of the
folder) that you want to view.
3) Double click the pdf file to access the
SETUP MANUAL.
SETUP MANUAL
Refer to the “SETUP MANUAL” contained on the supplied CD-ROM for details.
Connecting Pin Assignments ............................................... 2
RS-232C Specifications and Commands ............................. 4
Setting up the Projector Network Environment .................... 9
Controlling the Projector via LAN ....................................... 15
Setting up the Projector Using RS-232C or Telnet ............ 20
Resetting the Lamp Timer of the Projector via LAN .......... 30
Troubleshooting .................................................................. 32
10
Accessories
Supplied accessories
Introduction
Two R-6 batteries
(“AA” size, UM/SUM-3,
HP-7 or similar)
Remote control
<RRMCGA592WJSA>
DIN-D-sub RS-232C adaptor
(5 57/64" (15 cm))
Power cord*
(1) (2) (3) (4)
For U.S. and
Canada, etc.
(6' (1.8 m))
<QACCDA007WJPZ>
* Use the power cord that corresponds to the wall outlet in your country.
• Operation manual (this manual <TINS-D356WJZZ> and CD-ROM <UDSKAA095WJZZ>)
Note
• Codes in “< >” are Replacement parts codes.
<QACCVA011WJPZ>
<QCNWGA091WJPZ>
For Europe,
except U.K.
(6' (1.8 m))
RGB cable
(10' (3.0 m))
<QCNWGA045WJPZ>
Storage case
<GCASNA014WJSA>
For U.K. and
Singapore
(6' (1.8 m))
<QACCBA036WJPZ>
Lens cap (attached)
<CCAPHA024WJSA>
For Australia, New
Zealand and Oceania
(6' (1.8 m))
<QACCLA018WJPZ>
Optional accessories
■ 3 RCA to mini D-sub 15 pin cable (10n (3.0 m))
■ Remote receiver
■ Lamp unit
■ Ceiling-mount adaptor
■ Ceiling-mount unit
AN-C3CP2
AN-MR2
AN-F310LP
AN-60KT
AN-XRCM30 (for U.S.A. only)
AN-TK201 <for AN-60KT>
AN-TK202 <for AN-60KT>
AN-EP101B <for AN-XRCM30>
(for U.S.A. only)
Note
• Some of the optional accessories may not be available depending on the region. Please check with
your nearest Sharp Authorized Projector Dealer or Service Center.
11
Part Names and Functions
Numbers in Z refer to the main pages in this operation manual where the topic
is explained.
Projector
Top View
Powe r
indicator
STANDBY/ON
button
For turning the
power on and
putting the
projector into
standby mode.
ENTER button
For setting
items selected
or adjusted on
the menu.
KEYSTONE
button
For entering the Keystone
Correction mode.
Front View
26
55
26
39
29
26
Lamp indicator
55
Temperature warning
55
indicator
VOL (Volume) buttons
30
(–O/Q+)
For adjusting the
speaker sound level.
INPUT buttons (P/R)
30
For switching input
mode.
MENU/HELP
39
button
51
For displaying
adjustment and
setting screens,
and help screen.
Adjustment buttons
39
(P/R/O/Q)
For selecting menu
items.
Focus ring
For adjusting
the focus.
HEIGHT
ADJUST lever
12
27
28
Intake vent
52
Zoom ring
27
For enlarging/
reducing the picture.
Remote control
15
sensor
Push both sides of the lens cap to
attach or remove.
Numbers in Z refer to the main pages in this operation manual where the topic
is explained.
Rear View
Terminals
Introduction
MONITOR OUT terminal
(Output terminal for computer RGB,
component and DVI analog signals. Shared
for COMPUTER/COMPONENT and DVI-I)
Te rminal for connecting a monitor.
DVI-I input terminal
Te rminal for DVI
digital, computer
RGB, and component signals.
COMPUTER/
COMPONENT
input terminal
Te rminal for computer
RGB and component
signals.
AUDIO 1
input terminal
AUDIO OUT
terminal
Audio output terminal of
equipment connected to the audio
input terminal.
RS-232C
terminal
Te rminal for controlling the
projector using a computer.
21
22
21
22
23
23
24
23
S-VIDEO input terminal
22
Te rminal for connecting
video equipment with an
S-video terminal.
USB terminal
35
Te rminal connecting
with the USB terminal
on the computer for
using the supplied
remote control as the
computer mouse.
LAN terminal
25
Te rminal for
controlling the
projector using a
computer via
network.
AUDIO 2 input
23
terminal
VIDEO input
22
terminal
Te rminal for
connecting video
equipment.
Exhaust vent
52
Speaker
AC socket
Connect the
supplied
power cord.
Rear
adjustment
foot
Using the Kensington Lock
• This projector has a Kensington Security Standard connector for use with a Kensington
MicroSaver Security System. Refer to the information that came with the system for
instructions on how to use it to secure the projector.
25
28
46
Kensington Security
Standard connector
13
Part Names and Functions (Continued)
STANDBY button
For putting the projector
into the standby mode.
COMPUTER, DVI,
S-VIDEO, VIDEO buttons
For switching to the
respective input modes.
BREAK TIMER button
For displaying the
break time.
MAGNIFY buttons
For enlarging/reducing
part of the image.
PAGE UP/PAGE
DOWN buttons
Same as the [Page Down] and
[Page Up] keys on a computer
keyboard, when with the USB
connection (using a USB cable
or the optional remote
receiver).
POINTER button
For displaying the
pointer.
MOUSE/Adjustment
buttons (P/R/O/Q)
• For moving the
computer cursor when with the USB
connection (using a USB cable or the
optional remote receiver).
• For selecting and adjusting menu
items.
L-CLICK button
For the Left click
when with the USB connection
(using a USB cable or the
optional remote receiver).
KEYSTONE button
For entering the
Keystone Correction mode.
AUTO SYNC button
For automatically
adjusting images when
connected to a computer.
ECO+QUIET button
For lowering the noise
of the cooling fan and
extending the lamp life.
26
30
33
34
35
33
35
39
35
29
34
33
ON button
26
For turning the power
on.
FREEZE button
34
For freezing images.
AV MUTE button
30
For temporarily
displaying a black
screen and turning
off the sound.
VOL +/– (Volume)
30
buttons
For adjusting the
speaker sound level.
SPOT button
33
For displaying the
spotlight.
ENTER button
39
For setting items
selected or adjusted
on the menu.
R-CLICK/RETURN
35
button
39
• For the Right click
when with the USB
connection (using a
USB cable or the
optional remote
receiver).
• For returning to the
previous menu screen
during menu
operations.
MENU/HELP button
39
For displaying
51
adjustment and
setting screens, and
help screen.
RESIZE button
31
For switching the
picture size
(NORMAL,
STRETCH, etc.).
PICTURE MODE
34
button
For selecting the
appropriate picture.
14
Inserting the Batteries
Pull down the tab on the cover and remove the cover
1
towards the direction of the arrow.
Insert the batteries.
2
• Insert the batteries making sure the polarities correctly match
the m and n marks inside the battery compartment.
Insert the lower tab of the cover into the opening,
3
and lower the cover until it clicks in place.
Incorrect use of the batteries may cause them to leak or explode. Please
follow the precautions below.
Caution
• Danger of explosion if battery is incorrectly replaced.
Replace only with alkaline or manganese batteries.
• Insert the batteries making sure the polarities correctly match the m and n marks inside the battery
compartment.
• Batteries of different types have different properties, therefore do not mix batteries of different types.
• Do not mix new and old batteries.
This may shorten the life of new batteries or may cause old batteries to leak.
• Remove the batteries from the remote control once they have run out, as leaving them in can cause them
to leak.
Battery fluid from leaked batteries is harmful to skin, therefore ensure you wipe them first and then remove
them using a cloth.
• The batteries included with this projector may run down in a short period, depending on how they are kept.
Be sure to replace them as soon as possible with new batteries.
• Remove the batteries from the remote control if you will not be using the remote control for a long time.
• Comply with the rules (ordinance) of each local government when disposing of worn-out batteries.
Usable Range
The remote control can be used to control the
projector within the ranges shown in the
illustration.
Remote control sensor
Introduction
Note
• The signal from the remote control can be reflected off a screen for easy operation. However, the effective distance of the signal may
differ depending on the screen material.
When using the remote control
• Ensure that you do not drop it or expose it to
moisture or high temperature.
• The remote control may malfunction under a
fluorescent lamp. In this case, move the projector away from the fluorescent lamp.
30°
30°
Remote control
23n (7 m)
Remote control
signal transmitters
15
Quick Start
This section shows the basic operation (projector connecting with the computer). For details, see
the page described below for each step.
Setup and Projection
In this section, connection of the projector and the computer is explained using one example.
3
STANDBY/ON
8
button
INPUT buttons
6
ENTER button
4
Adjustment buttons
5
(P/R/O/Q)
KEYSTONE
5
button
Zoom ring
4
Focus ring
4
HEIGHT
4
ADJUST lever
1. Place the projector facing a wall or a screen
STANDBY button
8
ON button
3
COMPUTER button
6
ENTER button
4
Adjustment buttons
5
(P/R/O/Q)
KEYSTONE button
5
_P. 18
2. Connect the projector to the computer and plug the power cord
into the AC socket of the projector
When connecting equipment other than a computer, see
pages 22 and 23.
3. Remove the lens cap and turn the projector on
On the projector On the remote control
16
_PP. 21, 24, 25
_P. 26
4. Adjust the projected image with the Setup Guide
RGB
1024 × 768
COMPUTER
1 After the projector turns on, the Setup Guide appears.
(When “Setup Guide” is set to “On”. See page 45.)
2 Follow the steps in the Setup Guide and adjust the focus, picture size, and height (angle).
3 After adjusting the focus, height (angle) and picture size, press ENTER to finish the Setup
Guide.
_PP. 27, 28
5. Correct trapezoidal distortion
Correcting trapezoidal distortion using Keystone Correction.
On the projector
On the remote control
Shrinks
upper side.
Shrinks
lower side.
_P. 29
6. Select the INPUT mode
Select the “COMPUTER” using INPUT on the projector or COMPUTER on the remote control.
On the
projector
• When you press INPUT on the projector, the INPUT list appears.
Press '/" to switch the INPUT mode.
On the remote
control
INPUT list
INPUT
COMPUTER
D
DVI-D Computer
D
DVI-D Video
On-screen display (RGB)
_P. 30
Quick Start
7. Turn the computer on
8. Turn the power off
Press STANDBY/ON on the projector or STANDBY on the remote control, and then press the
button again while the confirmation message is displayed to put the projector into standby mode.
On-screen display
_P. 26
On the
projector
On the remote
control
17
Setting up the Projector
Setting up the Projector
For optimal image quality, position the projector perpendicular to the screen with the projector’s feet
flat and level. Doing so will eliminate the need for Keystone correction and provide the best image
quality. (See page 29.)
Standard Setup (Front Projection)
■ Place the projector at the required distance from the screen according
to the desired picture size. (See page 20.)
Example of standard setup
Side View
Screen
H
Lens center
L
Note
• Refer to page 20 for additional information concerning “Screen Size and Projection Distance”.
Ceiling-mount Setup
■ It is recommended that you use the optional
Sharp ceiling-mount adaptor and unit for this
installation. Before mounting the projector,
contact your nearest Sharp Authorized Projector Dealer or Service Center to obtain the
recommended ceiling-mount adaptor and unit
(sold separately).
18
Loading...
