MODEL

LC-32AW5X
LC-37AW5X

LCD COLOUR TELEVISION

OPERATION MANUAL

LC-AW5X_FCover 9/12/06, 10:35 AM1

LC-32AW5X
LC-37AW5X

LCD COLOUR TELEVISION

ENGLISH

OPERATION MANUAL

Dear SHARP customer

Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of trouble­free operation of your product, please read the Important Safety Precautions carefully before using this product.

Contents

Dear SHARP customer …………………………………… 1
Contents …………………………………………………… 1
Trademarks ………………………………………………… 2
Important Safety Precautions ………………………… 3
Supplied accessories …………………………………… 4
Preparation ………………………………………………… 5

Inserting the batteries ………………………………… 5
Using the remote control unit ………………………… 5

Cautions regarding remote control unit ……… 5
Setting the TV ………………………………………… 6
Protection against overturning ……………………… 7
Basic connection ……………………………………… 8

Connecting to an antenna ……………………… 8

Connecting to the AC outlet …………………… 8
Setting the TV on the wall …………………………… 9
Removing the stand …………………………………… 9

Part names ………………………………………………… 10

TV (Front) ……………………………………………… 10
TV (Rear) ……………………………………………… 11
Remote control unit …………………………………… 12

Watching TV ……………………………………………… 13

Turning on the power ………………………………… 13
Turning off the power ………………………………… 13
Simple button operations for changing channels … 13
Using Flashback (A) on the remote control unit … 14
Using MPX on the remote control unit ……………… 14
Simple button operation for changing

volume/sound …………………………………… 15
Sleep timer …………………………………………… 15
Still image ……………………………………………… 15

Basic adjustment settings ………………………………16

Menu operation buttons ……………………………… 16
On-Screen Display …………………………………… 16
Menu items …………………………………………… 17
Auto installation ……………………………………… 18
Programme setup……………………………………… 18

Auto search ……………………………………… 18
Manual setting for each channel ……………… 19

Search tuning…………………………………19
Fine tuning …………………………………… 19
Colour system ……………………………… 19
Sound system (Broadcasting system) ……20

Skipping channels ………………………… 20
Sort ………………………………………………… 20
Label ……………………………………………… 21
Erase Programme ………………………………… 21

AV mode selection …………………………………… 22
OPC (Optical Picture Control) setting ……………… 22
Picture adjustments …………………………………… 23
Advanced ……………………………………………… 24

C.M.S. (Colour Management System) …………24
Colour temperature ……………………………… 24
3D-Y/C …………………………………………… 24
Film mode ………………………………………… 25
I/P setting ………………………………………… 25

AV mode selection …………………………………… 26
Audio adjustment ……………………………………… 26

LC-AW5X_01-05 9/12/06, 10:33 AM1

1

Contents

Useful adjustment settings ……………………………… 27

Password setting for child lock

(for TV input mode) ……………………………… 27
Input Label …………………………………………… 28
Image position ………………………………………… 28
Wide Screen Signalling (WSS) ……………………… 29
Picture aspect ratio …………………………………… 29
WIDE mode (for TV/AV input mode) ………………… 30
Language setting for on-screen display …………… 31
Audio Only ……………………………………………… 31
DNR (Digital Noise Reduction) ……………………… 31
Input Select …………………………………………… 32
Blue Screen …………………………………………… 33
Colour system setting ………………………………… 33
Power Control ………………………………………… 33
HDMI Setup …………………………………………… 34

Useful features …………………………………………… 35

Teletext function ……………………………………… 35
Teletext language setting …………………………… 36

Using external equipment ……………………………… 37

Displaying an external equipment image ………… 37
Displaying a DVD image (Example) ………………… 37
Connecting a VCR …………………………………… 37
Connecting a DVD player …………………………… 38
Connecting a game console or camcorder ………… 38
Connecting an HDTV tuner ………………………… 39

Appendix ………………………………………………… 40

Troubleshooting ……………………………………… 40
RS-232C port specifications ………………………… 41
Specifications ………………………………………… 43
Optional accessory …………………………………… 43

Dimensional drawings …………………………………… 44

Trademarks

• “HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”

2

LC-AW5X_01-05 9/12/06, 10:33 AM2

Important Safety Precautions

• Cleaning—Unplug the AC cord
from the AC outlet before cleaning
the product. Use a damp cloth to
clean the product. Do not use
liquid cleaners or aerosol
cleaners.

• Water and moisture—Do not use
the product near water, such as
bathtub, washbasin, kitchen sink,
laundry tub, swimming pool and in
a wet basement.

• Do not place vases or any other
water-filled containers on this
product.
The water may spill onto the
product causing fire or electric
shock.

• Stand—Do not place the product
on an unstable cart, stand, tripod
or table. Doing so can cause the
product to fall, resulting in serious
personal injuries as well as
damage to the product. Use only
a cart, stand, tripod, bracket or
table recommended by the
manufacturer or sold with the
product. When mounting the
product on a wall, be sure to
follow the manufacturer’s
instructions. Use only the
mounting hardware recommended
by the manufacturer.

• The LCD panel used in this
product is made of glass.
Therefore, it can break when the
product is struck forcefully or with
a sharp object. If the LCD panel is
broken, be careful not to be
injured by broken glass.

• Heat sources—Keep the product
away from heat sources such as
radiators, heaters, stoves and
other heat-generating products
(including amplifiers).

• To prevent fire, never place any
type of candle or naked flames on
the top or near the TV set.

• To prevent fire or shock hazard,
do not place the AC power cord
under the TV set or other heavy
items.

• Do not place heavy objects on this
product or stand on it. Doing so could
cause injury if the product overturns.
Take special care near children and
pets.

• When relocating the product
placed on a cart, it must be
moved with utmost care. Sudden
stops, excessive force and
uneven floor surface can cause
the product to fall from the cart.

• Ventilation—The vents and other
openings in the cabinet are
designed for ventilation. Do not
cover or block these vents and
openings since insufficient
ventilation can cause overheating
and/or shorten the life of the
product. Do not place the product
on a bed, sofa, rug or other similar
surface, since they can block
ventilation openings. This product
is not designed for built-in
installation; do not place the
product in an enclosed place
such as a bookcase or rack,
unless proper ventilation is
provided or the manufacturer’s
instructions are followed.

The LCD panel is a very high technology product
with 3,147,264 thin film transistors, giving you fine
picture details.
Due to the very large number of pixels,
occasionally a few non-active pixels may appear
on the screen as a fixed point of blue, green or
red.
This is within product specifications and does not
constitute a fault.

Precautions when
transporting the TV

Be sure to always carry the TV
by two people holding it with two
hands—one hand on each side
of the TV.

• Do not display a still picture for a long time, as this
could cause an afterimage to remain.

• Install the product in a place where the AC cord can
be easily unplugged from an AC outlet and the AC
INPUT terminal on the rear of the product.

LC-AW5X_01-05 9/12/06, 10:33 AM3

3

Supplied accessories

Make sure the following accessories are provided with the product.

AC cordRemote control unit “AAA” size battery (g2)

Page 12 Page 5

Cable clamp

Page 6

Safety restraints

Page 6

Page 6

Operation manualCable clamp

Restraining
band

NOTE

• Always use the AC cord supplied with the TV.

• The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly
from the actual operations.

• The illustrations used throughout this manual are based on LC-32AW5X.

4

LC-AW5X_01-05 9/12/06, 10:33 AM4

Screw
for band

Clamps Screws for

clamps

Page 7

Preparation

Inserting the batteries

Before using the TV for the first time, insert two “AAA” size batteries (supplied). When the batteries become
depleted and the remote control fails to operate, replace the batteries with new “AAA” size batteries.

1 Open the battery cover. 2 Insert two supplied “AAA” size

batteries.

• Place batteries with their terminals

corresponding to the (e) and (f)
indications in the battery compartment.

CAUTION

Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.

• Do not mix batteries of different types. Different types of batteries have different characteristics.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause
chemical leakage in old batteries.

• Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause a rash. If you
find any chemical leakage, wipe thoroughly with a cloth.

• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.

• If you will not be using the remote control unit for an extended period of time, remove the batteries from it.

3 Close the battery cover.

Using the remote control unit

Use the remote control unit by pointing it towards the
remote sensor window.
Objects between the remote control unit and sensor
window may prevent proper operation.

Cautions regarding remote control unit

• Do not subject the remote control unit to shock.
In addition, do not soak the remote control unit with liquids, or place it in an
area with high humidity.

• Do not install or place the remote control unit under direct sunlight.
The heat may cause deformation of the unit.

• The remote control unit may not work properly if the remote sensor window of
the TV is under direct sunlight or strong lighting. In such case, change the
angle of the lighting or TV, or operate the remote control unit closer to the
remote sensor window.

30˚

5 m

Remote control

30˚

sensor

LC-AW5X_01-05 9/12/06, 10:33 AM5

5

Preparation

Setting the TV

Notes on installing the TV

• Avoid direct sunlight and place the TV in a well-ventilated location.

• Place the TV in a level location.

1

2

Removing the terminal cover

TV (rear view)

Press down the hooks
to remove the cover
toward you.

Connecting the AC cord, antenna, and external equipment to the TV

AC cord

See pages 8 and 37–39 for
connecting antennas and
external equipment, such
as VCR and DVD player.

3

AC outlet

• Place the TV close to the AC outlet, and keep the power plug within reach.

Bundling the cables and closing the terminal cover

Insert the cable clamp in
the hole on the TV as
shown.

Cable clamp

Cable clamp

CAUTION

• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE
AC CORD CONNECTED.

6

LC-AW5X_06-12 9/12/06, 10:33 AM6

Preparation

Protection against overturning

There is a danger of the product overturning in the case of a disaster or sudden collision. Carry out the following
tip-resistant measurement for your safety.

Anchoring the TV to the wall or a pillar

View from the top

Cup hook (commercially available)

1

Fix the product with the 2 clamps
(supplied), using the screws
(supplied).

2

Fix the TV to the wall using extra strong
ties (commercially available).

Fixing the TV to the table

1

Lay the TV down on cushioning (such
as a blanket) over a table.

2

Attach the band (supplied) to the bottom
of the stand using the screw (supplied).

3

Transfer the product to the table where
you intend to fix the TV.

4

Fix the TV to the table by the band with a
screw (commercially available).

• Use a screw (commercially available)
whose shape is compatible with the
band.

Restraining

band

(supplied)

Wall

Tie
(commercially
available)

Clamps
(supplied)

Screws for attaching clamps
(supplied)

Thick soft cloth
(e.g. Blanket)

Table

Stand

Screw
(supplied)

Screw
(commercially
available)

Restraining

band

(supplied)

CAUTION

• As this product is heavy, use a table that is wide enough to support the product and capable of withstanding the

product’s weight. The table should be set where it will not be overturned.

Table

7

LC-AW5X_06-12 9/12/06, 10:33 AM7

Preparation

Simple operations for watching a TV programme

Basic connection

Connecting to an antenna

To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections
that are used for coaxial cable.

Standard DIN45325 plug (IEC169-2)
75-ohm coaxial cable (round cable)

(commercially available)

Room antenna terminal
(75-ohm type)

Connecting to the AC outlet

Antenna cable

To antenna

terminal

Rear view

AC outlet

NOTE

• Always turn off the power of the TV when connecting the AC cord.

• Disconnect the AC cord from the AC outlet if the TV will not be used for a long period of time.

8

LC-AW5X_06-12 9/12/06, 10:33 AM8

Preparation

Setting the TV on the wall

• You can mount the TV on the wall, using the optional AN-37AG2 bracket.

• For details, refer to the instructions supplied with the optional bracket.

CAUTION

• This TV should be mounted on the wall only with the AN-37AG2 (SHARP) wall mount bracket. The use of other

wall mount brackets may result in an unstable installation and may cause serious injuries.

• Installing the Liquid Crystal Television requires special skill that should only be performed by qualified service

personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper
mounting or mounting that results in accident or injury.

<Example>

Hanging on the wall

AN-37AG2 wall mount bracket. (See the bracket instructions for details.)

Regarding the angle when mounting the TV
on the wall

• The maximum angle to which you can tilt the
wall-mounted TV is as follows. Do not tilt it
more than the maximum angle.

LC-32AW5X 0˚, 5˚ or 10˚
LC-37AW5X 0˚ or 5˚

• Tilt the wall-mounted TV slowly when adjusting

Vertical Mounting Angular Mounting

its angle.

Removing the stand

For wall mounting with the optional bracket, remove the stand.

Before attaching/detaching stand

• Before detaching (or attaching) stand, unplug the AC cord from the AC outlet.

• Remove all terminal covers and connected cables.

• Lay the TV down on cushioning (such as a blanket) over a table.

• Make sure two or more people perform the operation.

CAUTION

• Do not remove the stand from the TV unless using an optional bracket to mount it.

1

2

3

Unfasten the screw used to
secure the cover in place.

NOTE

• To attach the stand, perform the above steps in reverse order.

LC-AW5X_06-12 9/12/06, 10:33 AM9

Unfasten the four screws used
to secure the stand in place.

Detach the stand from the TV.
(Hold the stand so it will not
drop from the edge of the base
area.)

9

Part names

30

TV (Front)

Channel up (r)/down (s) buttons

Volume up (+)/down (–) buttons

TV/VIDEO button

POWER (On/Off) button

Remote control sensor

Regarding the headphone jack

• Use headphones with a stereo mini plug (Ø 3.5 mm).

• Be sure to unplug headphones from the jack when they are
not in use.

• The speakers do not output volume when headphones are
plugged in.

• Audio adjustments (page 26) do not affect the audio of
connected headphones.

• You can set the volume to different levels for each input
source.

10

LC-AW5X_06-12 9/12/06, 10:33 AM10

OPC sensor

POWER indicator

Headphone jack

OPC indicator*

SLEEP timer indicator

*OPC: Optical Picture Control

(See page 22.)

Volume display when headphones are plugged in

Part names

TV (Rear)

RS-232C terminal

INPUT 4 (HDMI)

INPUT 3 (HDMI)

terminals

terminal

INPUT 1 terminals

INPUT 2 terminals

MONITOR OUTPUT

terminals

AC INPUT terminal

Antenna input terminal

LC-AW5X_06-12 9/12/06, 10:33 AM11

11

Part names

Remote control unit

Select the TELETEXT mode. (all TV

m (TELETEXT)

image, all TEXT image, TV/TEXT
image) (See pages 35 and 36.)

POWER (STANDBY/ON)

To switch the power on and off.
(See page 13.)

(Hold)

TELETEXT mode: Stop updating
Teletext pages automatically. Press

again to release the hold mode.

(See page 35.)

0 – 9

Set the channel. (See page 13.)
TELETEXT mode: Set the page.
(See page 35.)

A (Flashback)

Press to return to the previous image
in normal viewing mode. (See page

14.)

INPUT1

Directly select and output the signal
from the INPUT1 terminal. (See
page 32.)

INPUT2

Directly select and output the signal
from the INPUT2 terminal. (See
page 32.)

MPX

Select the sound multiplex mode.
(See page 14.)

k (Reveal hidden for
TELETEXT)

TELETEXT mode: Display hidden
characters. (See page 35.)

(SUBTITLE for TELETEXT)

To turn the subtitles on and off.
(See page 36.)

v (Top/Bottom/Full)
TELETEXT mode: Set the area of

magnification. (See page 35.)

(Subpage)

Display the Teletext subpage
directly. (See page 36.)

WIDE

Change the wide image mode.
(See page 30.)

INPUT4

Directly select and output the
signal from the INPUT4 terminal.
(See page 32.)

INPUT3

Directly select and output the
signal from the INPUT3 terminal.
(See page 32.)

DISPLAY

Display the programme
information.

Set the volume. (See page 15.)

VOLk/VOLl

e (MUTE)

Mute the sound. (See page 15.)

FREEZE

Freeze a motion picture on the
screen. (See page 15.)

AV MODE

Select a video setting: AV MODE
(STANDARD, MOVIE, GAME, USER,
DYNAMIC) (See page 22.)

a/b/c/d (Cursor)

Select a desired item on the setting
screen. (See page 16.)

EXIT

Return to the default screen.

CHr/CHs
TV input mode: Select the channel.
(See page 13.)
TELETEXT mode: Select the page.
(See page 35.)

SLEEP

Set the Sleep timer. (See page 15.)

OPC

To switch Optical Picture Control
on and off. (See pages 22.)

MENU

Display the menu screen. (See
page 16.)

ENTER

Execute a command.

RETURN

MENU mode: Return to the
previous menu screen. (See page

16.)

Colour (RED/GREEN/YELLOW/
BLUE)

TELETEXT mode: Select a page.
(See page 35.)

NOTE

• When using the remote control unit, point it at the TV.

12

LC-AW5X_06-12 9/12/06, 10:33 AM12

Watching TV

Turning on the power

Press POWER on the TV.

• POWER indicator (Green): The TV is on. (After a few seconds,
an image appears with sound.)

• After turning the power “ON” by pressing POWER on the TV,
you can turn the power ON/OFF by pressing POWER on the
remote control.

POWER button

POWER indicator

Turning off the power

Press POWER on the remote control.

• The TV enters standby mode and the image on the screen
disappears.

• The POWER indicator on the TV changes from green to red.

Press POWER on the TV.

• The POWER indicator on the TV turns off.

• When the TV is turned off by POWER on the TV, you cannot
turn on the power by pressing POWER on the remote control.

Simple button operations for
changing channels

You can change channels in several ways.

Using CHr/son the remote control unit

• Press CHr to increase the channel number.

• Press CHs

NOTE

• CHr/s on the TV operates the same as CHr/son

the remote control unit.

Using 0 – 9 on the remote control unit

Select the channels directly by pressing buttons 0 to

9.

to decrease the channel number.

POWER indicator

Off

Red

Green

NOTE

• If you are not going to use this TV for a long period of time, be
sure to remove the AC cord from the AC outlet.

• Minor power is consumed when the unit is in standby mode.

Power off.

The TV is in standby mode.

The TV is on.

POWER button

a

To select a 1-digit channel (e.g. channel 2):

• Press 0, followed by 2.
To select a 2-digit channel (e.g. channel 12):

• Press 1, followed by 2.

When viewing Teletext information

View a page directly which is 3-digit page number from
100 to 899 by pressing buttons 0 to 9.

Channel display

Channel display changes approximately after 3
seconds as shown below.

(Example)

SAT.1

12

SAT.1

12

PAL

B/G

MONO

LC-AW5X_13-15 9/12/06, 10:33 AM13

13

Watching TV

Using Flashback (A) on the remote
control unit

Press A to switch the currently tuned channel to the
previously tuned channel.
Press A again to switch back to the currently tuned
channel.

Press A to toggle between the currently selected input
source and the previously selected one.

Press A to return to the previous page in TELETEXT
mode.

Using MPX on the remote control
unit

When receiving a monaural signal

Each time you press MPX, the mode switches between
NICAM MONO and MONO.

Monaural mode

BBC2

99

NICAM

MONO

BBC2

99

MONO

In the TV mode of A2 TV broadcasts

When receiving a stereo signal

Each time you press MPX, the mode switches between
STEREO and MONO.

Stereo mode

BBC2

99

STEREO

BBC2

99

MONO

When receiving a bilingual signal

Each time you press MPX, the mode switches among
CH A, CH B and CH AB.

Bilingual mode

BBC2

99

BBC2

99

In the NICAM TV broadcasts

When receiving a stereo signal

Each time you press MPX, the mode switches between
NICAM STEREO and MONO.

Stereo mode

BBC2

99

NICAM

STEREO

BBC2

99

MONO

When receiving a bilingual signal

Each time you press MPX, the mode switches among
NICAM CH A, NICAM CH B, NICAM CH AB and
MONO.

Bilingual mode

BBC2

99

NICAM

CH A

BBC2

99

NICAM

CH B

CH A

BBC2

99

CH AB

CH B

When receiving a monaural signal
When you press MPX, “MONO” displays.

Monaural mode

BBC2

99

MONO

NOTE

• “BBC2” and “99” are tentative network name and channel.

BBC2

MONO

14

LC-AW5X_13-15 9/12/06, 10:33 AM14

BBC2

99

99

NICAM

CH AB

Watching TV

0 hr. 30 min. 1 hr. 00 min. 1 hr. 30 min.

2 hr. 30 min. 2 hr. 00 min.

Off

Simple button operation for changing
volume/sound

NOTE

• Within 30 minutes after pressing e, press one of the

buttons below to cancel the mute.

ll

—VOL
—e

• Mute will be cancelled after 30 minutes. However, the

TV will not suddenly output loud sound as the volume
level will be set to 0 automatically. Increase the volume
level by pressing VOLk.

2

kk

l/VOL

k

ll

kk

Press e again within 30 minutes to cancel
the mute.

• Before 30 minutes, the volume level returns to
the previous setting.

Sleep timer

Allows you to set a time when the TV automatically
switches to standby.

1

Press SLEEP.

• Remaining time displays when sleep timer has
been set.

Sleep Timer: Remain 2 hr. 00 min.

Changing the volume

You can change the volume on the TV or on the remote
control unit.

• To increase the volume, press VOL

• To decrease the volume, press VOL

kk

k.

kk

ll

l.

ll

20

NOTE

• “TV”, “INPUT1”, “INPUT2” and “INPUT3” modes can store
volume adjustment values separately.

Using e (Mute) on the remote control unit

e mutes the current sound output.

1

Press e.

• The sound is silenced.

•“M” has been displayed on the screen for 30

minutes.

Mute

2

• When the time has been set, countdown automatically
starts.

• Five minutes before the preset of time expires, the
remaining time displays each minute.

• Select “Off” by pressing SLEEP to cancel the sleep timer.

Each time you press SLEEP, the remaining
time switches as shown below.

NOTE

Still image

You can freeze a motion picture on the screen.

1

2

• When this function is not available, “No still image
available.” will display.

Press FREEZE.

Press RETURN again to exit still image.

NOTE

LC-AW5X_13-15 9/12/06, 10:33 AM15

15

Basic adjustment settings

Menu operation buttons

Use the following buttons on the remote control to
operate the menu.

On-Screen Display

Example

...

[

Option

MENU

Option

Audio Only

DNR

Input Select

Blue Screen

Colour System

Power Control

HDMI Setup

Colour System

1 Item displayed in yellow

• This indicates the item currently selected.

• Press ENTER to go to the adjustment screen
for this item.

2 Item displayed in white

• This indicates an item can be selected.

3 Item displayed in grey

• This indicates that the item cannot be
selected.
*There are various reasons why items cannot

be selected, but the main reasons are as
follows:

1. Nothing is connected to the selected
input terminal.

2. The function is not compatible with the
current input signal.

]

1

2

3

MENU: Press to open or close the menu

screen.

a/b/c/d: Press to select a desired item on the

screen or adjust a selected item.

ENTER: Press to go to the next step or

complete the setting.

RETURN: Press to return to the previous step.

ENTER

: Select : Enter

RETURN

: Back

MENU

: End

The bar above is an operational guide for
the remote control. The bar will change in
accordance with each menu setting
screen.

16

NOTE

• The screens in the operation manual are for explanation
purposes (some are enlarged, others cropped) and may
vary slightly from the actual screens.

LC-AW5X_16-21 9/12/06, 10:34 AM16

Basic adjustment settings

Menu items

List of menu items to help you with operations


AV Mode ......................................... Page 22

OPC ................................................ Page 22

Backlight ........................................ Page 23

Contrast ......................................... Page 23

Brightness ..................................... Page 23

Colour ............................................ Page 23

Tint ................................................. Page 23

Sharpness ...................................... Page 23

Advanced

C. M. S. ................................. Page 24

Colour Temp. ....................... Page 24

3D-Y/C .................................. Page 24

Film Mode ............................ Page 25

I/P Setting ............................ Page 25

Audio

AV Mode ......................................... Page 26

Treble.............................................. Page 26

Bass ............................................... Page 26

Balance .......................................... Page 26

Setup

Auto Installation ............................ Page 18

Programme Setup ..................Pages 18-21

Child Lock ...................................... Page 27

Input Label ..................................... Page 28

Position .......................................... Page 28

WSS ................................................ Page 29

4:3 Mode ........................................ Page 29

Language ....................................... Page 31

Text Language ............................... Page 36

Option

Audio Only ..................................... Page 31

DNR ................................................ Page 31

Input Select

Input1 ................................... Page 32

Blue Screen ................................... Page 33

Colour System............................... Page 33

Power Control

No Signal Off ....................... Page 33

No Operation Off ................. Page 33

HDMI Setup

Signal Type .......................... Page 34

Colour Matrix....................... Page 34

Auto View ............................. Page 34

Audio Select ........................ Page 34

NOTE

• Some menu items may not be displayed depending on the selected input source.

17

LC-AW5X_16-21 9/12/06, 10:34 AM17

Basic adjustment settings

MENU

[

Setup

...

Programme Setup

]

Setup Option

Child Lock

Input Label

Auto Installation

Programme Setup

Position

Language

Text Language

4:3 Mode

WSS

Auto installation

You can run auto installation again, even after setting
up the preset channels.

1

2

3

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Auto Installation”, and
then press ENTER.

...

[

Setup

MENU

Setup Option

Auto Installation

Programme Setup

Child Lock

Input Label

Position

WSS

4:3 Mode

Language

Text Language

Auto Installation

]

Programme setup

You can run the auto search procedure again at any
time by accessing the Setup menu and Programme
Setup. Channels can be tuned automatically or
manually.

Auto search

You can also automatically search by performing the
procedure below. This is the same function as
programme auto search in auto installation.

1

2

3

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Programme Setup”,
and then press ENTER.
If you have already set the password, enter
it here.

• See page 27 for setting a password.

18

LC-AW5X_16-21 9/12/06, 10:34 AM18

4

5

6

If you have already set the password, enter
it here.

• See page 27 for setting a password.

––––

Press a/b to select “Yes”, and then press
ENTER.

Press a/b to select the desired language
listed on the screen, and then press ENTER.
Press a/b to select the desired sound
system, and then press ENTER.
You do not need to do anything during the
auto search.
“Search is completed.” is displayed. Press

MENU to exit.

4

5

Press a/b to select “Auto Search”, and then
press ENTER.

Press a/b to select “Yes”, and then press
ENTER.
Press a/b to select the desired sound
system, and then press ENTER.
“Search is completed.” is displayed. Press

MENU to exit.

Basic adjustment settings

Fine

Colour System

Sound System

Skip

Search

179.25 MHz

Fine

Colour System

Sound System

Skip

Search

AUTO

PAL

SECAM

NTSC 3.58

PAL-60

NTSC 4.43

Manual setting for each channel

You can set some channel items manually. They are
Search, Fine (TV frequency), Colour System, Sound
System, and Skip.

1

2

3

4

5

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Programme Setup”,
and then press ENTER.
If you have already set the password, enter
it here.

• See page 27 for setting a password.

Press a/b to select “Manual Adjust”, and
then press ENTER.

Press a/b to select “Yes”, and then press

ENTER.

Programme Setup “Manual Adjust” menu

01 SAT.1 02 PR07 03 KABEL

Fine tuning

1

Press a/b/c/d to select the channel you
want to edit, and then press ENTER.

• The selected channel information displays.

2

Press a/b to select “Fine”, and then press

ENTER.

3

Press c/d to adjust the frequency, and then
press RETURN or MENU.

• Adjust while checking the background picture

• Instead of the method above, you can also set

• When setting a frequency on the “Fine” screen,

a

• 179.25 MHz: Press 1 s 7 s 9 s 2 s 5.

• 49.25 MHz: Press 0 s 4 s 9 s 2 s 5.

as a reference.

by directly entering the frequency number of
the channel with 0 – 9.

the last figure of the frequency needs to be “0”
or “5”.

You can select one of the following settings.

1 Search (See page 19.)
2 Fine (See page 19.)
3 Colour system (See page 19.)
4 Sound system (See page 20.)
5 Skip (See page 20.)

Search tuning

1

Press a/b/c/d to select the channel you
want to edit, and then press ENTER.

• The selected channel information displays.

2

Press a/b to select “Search”, and then
press ENTER.

...

[

MENU

Search

Fine

Colour System

Sound System

Skip

Setup

Programme Setup

]

179.25 MHz

NEXT

Colour system

1

Press a/b/c/d to select the channel you
want to edit, and then press ENTER.

• The selected channel information displays.

2

Press a/b to select “Colour System”, and
then press ENTER.

• Receivable colour systems are listed.

3

Press a/b to select the optimum colour
system, and then press ENTER.

Colour system menu

3

LC-AW5X_16-21 9/12/06, 10:34 AM19

As ENTER is pressed, the next channels will
be searched in order.

19

Basic adjustment settings

Manual setting for each channel (continued)

Sound system (Broadcasting system)

1

2

3

• Check the sound system if the sound output were not
correct.

Skipping channels

Channels with “Skip” set to “On” are passed over when
using CHr/s even if selected while watching the
image from the TV.

Press a/b/c/d to select the channel you
want to edit, and then press ENTER.

• The selected channel information displays.

Press a/b to select “Sound System”, and
then press ENTER.

• Receivable sound systems (Broadcasting
systems) are listed.

Sound system menu

...

[

MENU

Search

Fine

Colour System

Sound System

Skip

Setup

Programme Setup

]

B/G

D/K

I

M

Press a/b to select the optimum sound
system, and then press ENTER.

NOTE

Sort

Channel positions can be sorted freely.

1

2

3

4

5

6

7

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Programme Setup”,
and then press ENTER.
If you already set the password, enter it here.

• See page 27 for setting a password.

Press a/b to select “Sort”, and then press
ENTER.

Press a/b to select “Yes”, and then press
ENTER.

Press a/b/c/d to select the channel you
want to move, and then press ENTER.

Move it to the desired position by pressing
a/b/c/d, and then press ENTER.

• Please be aware that the neighbouring
channels are switched during this procedure.

(Example)
When moving channel 10 to channel 4’s
position.

04 05

1

2

3

Press a/b/c/d to select the channel you
want to edit, and then press ENTER.

• The selected channel information will be
displayed.

Press a/b to select “Skip”, and then press
ENTER.

• Skip menu displays.

Skip menu

Search

Fine

Colour System

Sound System

Skip

Off

On

Press a/b to set “Skip” to “On”, and then
press ENTER.

8

09 10

a button

04 10

09 05

04 05

10 09

c button

c button a button

10 04

09 05

10 05

04 09

Repeat the steps 6 and 7 until all desired
channels are sorted.

20

LC-AW5X_16-21 9/12/06, 10:34 AM20

Basic adjustment settings

Label

Channels can be labelled freely.

1

2

3

4

5

6

7

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Programme Setup”,
and then press ENTER.
If you already set the password, enter it here.

• See page 27 for setting a password.

Press a/b to select “Label”, and then press
ENTER.

Press a/b to select “Yes”, and then press
ENTER.

Press a/b/c/d to select the channel you
want to label, and then press ENTER.

Press a/b to select characters and c/d to
move to the desired digit, and then press

ENTER to complete the label setting.

Erase Programme

The individual programme can be erased.

1

2

3

4

5

6

7

8

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Programme Setup”,
and then press ENTER.
If you already set the password, enter it here.

• See page 27 for setting a password.

Press a/b to select “Erase Programme”,
and then press ENTER.

Press a/b to select “Yes”, and then press
ENTER.

Press a/b/c/d to select the channel you
want to erase, and then press ENTER.

Press ENTER to erase the channel.
All the subsequent programmes move up.

Repeat the steps 6 and 7 until all desired
channels are erased.

Erase programme menus

SAT.1 Pro702 KABEL03 04 05

01

06 07 08 09 10

11 12 13 14 15

16 17 18 19 20

01 SAT.1 03 KABELPro702

06 07 08 09 10

11 12 13 14 15

16 17 18 19 20

01 SAT.1 02 KABEL

06 07 08 09 10

11 12 13 14 15

16 17 18 19 20

04 05

03 04 05

LC-AW5X_16-21 9/12/06, 10:34 AM21

21

Basic adjustment settings

AV mode selection

AV mode gives you five viewing options to choose from
to best match the system environment, which can vary
due to factors like room-brightness, type of programme
watched or the type of image input from external
equipment.

Using AV MODE on the remote control unit

1

2

AV Mode: STANDARD

AV Mode: DYNAMIC

Press AV MODE.

• Present AV mode displays.

Press AV MODE again before the mode
displayed on the screen disappears.

• The mode changes as shown below.

AV input mode

AV Mode: MOVIE

AV Mode: GAME

AV Mode: USER (TV)

OPC (Optical Picture Control) setting

You can set the TV to automatically adjust the screen
to suitable backlight brightness according to the
lighting conditions.

Using OPC on the remote control unit

Press OPC to switch the OPC function on and off.

Using OPC on the menu screen

1

2

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Using AV Mode on the menu screen

1

2

3

4

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Press a/b to select “AV Mode”, and then
press ENTER.

Press a/b to select the desired item, and
then press ENTER.

Selected item

STANDARD

MOVIE

GAME

USER

DYNAMIC

For a highly defined image in a normally
bright room.

For a movie.

Lowers image brightness for easier viewing.

Allows the user to customise settings as
desired. You can set the mode for each
input source.

For a clear-cut image emphasising high
contrast for sports viewing.

Description

3

Press a/b to select “OPC”, and then press

ENTER.

4

Press a/b to select the desired item, and
then press ENTER.

Selected item

Off

On

On (Display)

NOTE

• Make sure no object obstructs the OPC sensor, which
could affect its ability to sense surrounding light.

The brightness is fixed at the value set in
“Backlight“ (See page 23).

Automatically adjusts.

Displays the OPC effect on the screen while
adjusting the brightness of the screen.

Description

NOTE

• You can select a different AV MODE item for each input
mode. (For example, select STANDARD for TV input and
DYNAMIC for VIDEO input.)

22

LC-AW5X_22-26 9/12/06, 10:34 AM22

Basic adjustment settings

Picture adjustments

You can adjust the picture to your preference.

Follow the steps to adjust the picture.

1

2

3

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Press a/b to select a specific adjustment
item.

4

Press c/d to adjust the item to your desired
position.

NOTE

• For resetting all adjustment items to factory preset values,

press a/b to select “Reset”, press ENTER, press a/b
to select “Yes”, and then press ENTER.

• “Backlight” cannnot be adjusted when “OPC” is set to
“On” or “On (Display)”.

Adjustments items

[

]

MENU

AV Mode [STANDARD]

OPC

Backlight [+ 6]

Contrast

Brightness

Colour

Tint

Sharpness

Advanced

Reset

Selected item cbutton

Backlight

Contrast

Brightness

Colour

Tint


Picture Audio

[Off]

–

[ 30]

[ 0]

[ 0]

[ 0]

[ 0]

–

–

–

The screen dims

For less contrast

For less brightness

For less colour
intensity

Skin tones become
purplish

+

+

+

+

dbutton

The screen brightens

For more contrast

For more brightness

For more colour
intensity

Skin tones become
greenish

Sharpness

For less sharpness

For more sharpness

NOTE

• Select “Advanced” and then press ENTER to set “C.M.S”,
“Colour Temp.”, “3D-Y/C”, “Film Mode” or “I/P Setting”. See
pages 24 and 25.

LC-AW5X_22-26 9/12/06, 10:34 AM23

23

Basic adjustment settings

Colour Temp.

C. M. S. – Value

C. M. S. – Saturation

C. M. S. – Hue

3D – Y/C

Film Mode

I/P Setting

Standard

Off

Fast

Slow

Advanced

Advanced setting enables you to set the picture
adjustment in more detail. There are five options you
can choose from.

C.M.S. (Colour Management System)

Colour tone is managed using the six-colour
adjustment setting.

1

2

3

4

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Press a/b to select “Advanced”, and then
press ENTER.

Press a/b to select a specific adjustment
item among “C.M.S.-Hue”, “C.M.S.­Saturation” and “C.M.S.-Value”, and then
press ENTER.

C. M. S. – Hue

C. M. S. – Saturation

C. M. S. – Value

Colour Temp.

3D - Y/C

Film Mode

I/P Setting

Reset

R

Y

G

C

B

M

[ 0]

[ 0]

[ 0]

[ 0]

[ 0] –

[ 0] –

–

–

–

–

+

+

+

+

+

+

Colour temperature

Adjusts the colour temperature to give the best white
image.

1

Repeat steps 1 to 3 in C.M.S. (Colour
Management System).

2

Press a/b to select “Colour Temp.”, and
then press ENTER.

3

Press a/b to select the desired level, and
then press ENTER.

Selected item

High
Mid-High
Middle
Mid-Low
Low

Description

White with bluish tone

White with reddish tone

3D-Y/C

Provides high quality images with minimal dot crawl
and cross colour noise.

1

2

Repeat steps 1 to 3 in C.M.S. (Colour
Management System).

Press a/b to select “3D-Y/C”, and then
press ENTER.

5

Press c/d to adjust the item to your desired
position.

NOTE

• For resetting all adjustment items to factory preset values,

press a/b to select “Reset”, and then press ENTER.

Selected item

C.M.S-Hue

C.M.S­Saturation

C.M.S-Value

This is a standard to adjust the colour
either more reddish or more bluish in tone.

Increases or decreases the saturation of a
selected colour.

A higher value makes the image brighter.
A lower value makes the image darker.

Description

3

Press a/b to select the desired level, and
then press ENTER.

Selected item

Off
Standard
Fast
Slow

3D-Y/C off
Normal adjustment

For movie image

For still image

NOTE

• “3D-Y/C” is not selectable depending on the input signal
type.

• 3D-Y/C may not operate depending on the input signal
type or noisy input signal.

Description

LC-AW5X_22-26 9/12/06, 10:34 AM24

24

Basic adjustment settings

Film mode

Automatically detects a film-based source (originally
encoded at 24/25 frames/second, depending on the
vertical frequency), analyses it then recreates each
still film frame for high-definition picture quality.

1

2

3

4

5

I/P setting

Adjusting the image and input signal can give you a
more beautiful picture.

1

Press MENU and the MENU screen displays.

Press c/d to select “Picture”.

Press a/b to select “Advanced”, and then
press ENTER.

Press a/b to select “Film Mode”, and then
press ENTER.

Press a/b to select “On”, and then press
ENTER.

Repeat steps 1 to 3 in Film mode.

2

3

• The picture is progressive scan when Film Mode is “On”.

Press a/b to select “I/P Setting”, and then
press ENTER.

Press a/b to select “Interlace” or
“Progressive”, and then press ENTER.

NOTE

LC-AW5X_22-26 9/12/06, 10:34 AM25

25

Basic adjustment settings

AV mode selection

This option links to “AV Mode” in the Picture menu.
(See page 22.)

Audio adjustment

For each selected AV mode, you can adjust the
following three items: Treble, Bass, and Balance; to
your preferred setting. After choosing the AV mode
you want to adjust, next carry out audio adjustment.

1

2

3

Press MENU and the MENU screen displays.

Press c/d to select “Audio”.

STANDARD

Treble

Bass

Balance

Reset

Press a/b to select a specific adjustment
item.

4

Press c/d to adjust the item to your desired
position.

Selected item

Treble

Audio

[0] –

[0]

[0]–L

cbutton

For weaker treble

Setup

+

+

R

dbutton

For stronger treble

Bass

Balance

NOTE

• For resetting all adjustment items to factory preset values,

press a/b to select “Reset”, press ENTER, press a/b
to select “Yes”, and then press ENTER.

For weaker bass

Decrease audio from
the right speaker

For stronger bass

Decrease audio from
the left speaker

26

LC-AW5X_22-26 9/12/06, 10:34 AM26

Useful adjustment settings

Yes

No

Change Password

Channel Setting

Reset

Yes

No

Change Password

Channel Setting

Reset

Password setting for child lock
(for TV input mode)

Allows you to use a password to protect certain settings
from being accidentally changed.

Setting a password

Register a 4-digit password number to use the Child
Lock function.

1

2

3

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Child Lock”, and then
press ENTER.

Setting a channel

1

2

3

4

Repeat steps 1 to 4 in Setting a password.

Press a/b to select “Channel Setting”, and
then press ENTER.

Press a/b to select “Yes”, and then press
ENTER.

Press a/b/c/d to select the channel that
you wish to apply the Child Lock, and then
press ENTER.

• The Child Lock setting becomes effective only
when the TV is turned off after the Child Lock is
applied.

4

5

6

7

If you already set the password, enter it here.

––––

Press a/b to select “Change Password”,
and then press ENTER.

Change Password

Channel Setting

Reset

New Password

Reconfirm

–––

–

––––

Enter the 4-digit number as a password using
0 – 9.

Change Password

Channel Setting

Reset

New Password

Reconfirm

–––

–

––––

Enter the same 4-digit number as in step 6
to confirm.

Resetting the password

Allows you to reset your password.

1

2

3

• As a precautionary measure, make a note of your

password on the back of this operation manual, cut it
out and keep it in a safe place that children cannot
reach.

• This function is only available for TV input mode.

• To relock a channel which has been temporarily unlocked
by inputting the correct password, turn power off and then
on again.

Repeat steps 1 to 4 in Setting a password.

Press a/b to select “Reset”, and then press
ENTER.

Press a/b to select “Yes”, and then press

ENTER.

NOTE

NOTE

• To view a locked channel you must enter a password.
When you select a locked channel, a password prompt
message pops up.

• When no password is input for 20 seconds after the prompt
message is displayed, the TV goes into standby mode.

LC-AW5X_27-32 9/12/06, 10:34 AM27

27

Useful adjustment settings

Reset

H-Pos. [0] – +

V-Pos. [0] –

+

Input Label

You can assign each input source a label you like.

1

2

3

4

5

6

Press INPUT1, INPUT2, INPUT3, or INPUT4
to select the desired input source.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Input Label”, and then
press ENTER.

Press a/b to select characters and c/d to
move to the desired digit to label the input
source.

• When you want to change the input label that
you have already assigned to the default name,
press c/d to move to “CLEAR” on the “Input
Label” screen, and then press ENTER.

Repeat the above until the name is fully spelt
out, and then press MENU.

• The name can be 6 characters or less.

• When you want to set an input source name of
less than 6 characters, press MENU to exit from
the labelling menu.

Image position

For adjusting a picture’s horizontal and vertical position.

1

2

3

4

5

Selected item

H-Pos.

V-Pos.

• For resetting all adjustment items to the factory preset values,

press a/b to select “Reset”, and then press ENTER.

• Adjustments are stored separately according to input

source.

• Images may not be displayed properly depending on the
settings and/or input signals.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Position”, and then
press ENTER.

Press a/b to select “H-Pos.” or “V-Pos.”.

Press c/d to adjust the item to your desired
position.

Description

Centres the image by moving it to the left or right.

Centres the image by moving it up or down.

NOTE

TV

INPUT1

INPUT2

DVD

(Example)

NOTE

• You cannot change labels if the input source is TV.

28

LC-AW5X_27-32 9/12/06, 10:34 AM28

Useful adjustment settings

Wide Screen Signalling (WSS)

WSS allows a television to switch automatically among
the different screen formats.

1

2

3

4

• Try to set WIDE mode if an image does not switch to the
correct screen format. When the broadcast signal contains
no WSS information, the function will not work even if
enabled.

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “WSS”, and then press
ENTER.

Press a/b to select “On” or “Off”, and then
press ENTER.

NOTE

Picture aspect ratio

The WSS signal has 4:3 auto-switching that allows you
to select between Normal and Panorama.

1

2

3

4

4:3 mode “Panorama”

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “4:3 Mode”, and then
press ENTER.

Press a/ b to select “Panorama” or
“Normal”, and then press ENTER.

WSS signal 4:3 screen

4:3 mode “Normal”

Selected item

Panorama

Normal

Description

Wide image without side bars

Normal range keeping 4:3 or 16:9 aspect
ratio

LC-AW5X_27-32 9/12/06, 10:34 AM29

29

Useful adjustment settings

WIDE mode (for TV/AV input mode)

Manual Selection

1

Press WIDE.

• The WIDE MODE menu displays.

• The menu lists the wide mode options selectable
for the type of video signal currently received.

WIDE MODE

Normal

Zoom 14:9

Panorama

Full

Cinema 16:9

Cinema 14:9

4:3 Mode set to “Panorama”

Selected item

Normal

Zoom 14:9

Panorama

Full

Cinema 16:9

Cinema 14:9

For 4:3 “standard” pictures. A side bar appears on each side.

For 14:9 letterbox pictures. A thin side bar appears on each side, and you may also see bars on
the top and bottom with some programmes.

In this mode the picture is progressively stretched toward each side of the screen.

For 16:9 squeeze pictures.

For 16:9 letterbox pictures. Bars may appear on the top and bottom with some programmes.

For 14:9 letterbox pictures. Bars may appear on the top and bottom with some programmes.

4:3 Mode set to “Normal”

2

Press WIDE or a/b while the WIDE MODE
menu displays on the screen.

• As you toggle down the options, each is
immediately reflected on the TV.

Auto Selection

If you set “WSS” and “4:3 Mode” in the Setup menu on
page 29, the optimum WIDE mode is automatically
chosen for every broadcast containing the WSS
information.

“WSS” menu

To enable Auto Selection, set “WSS” in the Setup menu
to “On”. (See page 29.)

“4:3 Mode” menu

To set the type of the wide screen, select “Panorama”
or “Normal” in the 4:3 Mode menu. (See page 29.)

NOTE

• If the broadcast signal contains no WSS information, Auto
Selection will not function even when the WSS option is
enabled.

Description

Normal Zoom 14:9 Panorama

30

LC-AW5X_27-32 9/12/06, 10:34 AM30

FullCinema 16:9Cinema 14:9

Useful adjustment settings

Off

High

Low

Language setting for on-screen
display

You can also select a language from setup menu.
Select from among 3 languages: English, Chinese and
Arabic.

1

2

3

4

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Language”, and then
press ENTER.

Press a/b to select the desired language
listed on the screen, and then press ENTER.

Audio Only

When listening to music from a music programme, you
can set the display off and enjoy audio only.

DNR (Digital Noise Reduction)

Produces a clearer video image.

1

2

3

4

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “DNR”, and then press
ENTER.

Press a/b to select the desired level, and
then press ENTER.

1

2

3

4

Selected item

On

Off

• When you make operations that change the picture on the
TV such as by changing the input source, the Audio Only
function is set to “Off”.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Audio Only”, and then
press ENTER.

Press a/b to select “On”, and then press

ENTER.

Description

Audio is output without screen image.

Both screen images and audio are output.

NOTE

LC-AW5X_27-32 9/12/06, 10:34 AM31

31

Useful adjustment settings

Input Select

Selecting input source

Can use for selecting the input source.

Using TV/VIDEO on the TV

TV/VIDEO allows you to choose from the available

input sources.

1

2

Using INPUT1, INPUT2, INPUT3 or INPUT4 on the
remote control unit

INPUT1, INPUT2, INPUT3 or INPUT4 allows you to

directly select the desired input source.

Press TV/VIDEO on the TV.

Press TV/VIDEO on the TV to select the input
source.

• The image and sound from the selected input
source are output on the TV.

• You can also select the input source by
pressing a/b.

Selecting input signal type

For setting the signal type of external equipment.

1

2

3

4

5

• If no (colour) image displays, try to change the other

signal type.

• Check the operation manual of the external equipment
for the signal type.

• When the signal type is set to “Auto”, the input terminal
where cable is connected is automatically selected.

• When the signal type is set to “Auto” and multiple video
signal cables are connected, the signal type is selected
in the following prioritised order:
Input 1: Components Video

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Input Select”, and then
press ENTER.

Press a/b to select “Input1”, and then press
ENTER.

Press a/b to select a signal type you want
to set, and then press ENTER.

Input source

Input 1

NOTE

Selectable item

Auto, Component, Video

Press the desired input source button among
INPUT1, INPUT2, INPUT3 or INPUT4 on the remote
control.

• The image and sound from the selected input source are
output on the TV.

32

LC-AW5X_27-32 9/12/06, 10:35 AM32

Useful adjustment settings

Blue Screen

Automatically turns the screen blue if no broadcast
signal is received.

1

2

3

4

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “Blue Screen”, and then
press ENTER.

Press a/b to select “On”, and then press

ENTER.

Colour system setting

You can change the colour system to one that is

compatible with the image on the screen.

1

Press MENU and the MENU screen displays.

Power Control

Power Control setting allows you to save energy.

No Signal Off

When set to “Enable”, the power will automatically shut
down if no signal inputs for 15 minutes.

1

2

3

4

5

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

• Power control menu displays.

Press a/b to select “Power Control”, and
then press ENTER.

Press a/b to select “No Signal Off”, and
then press ENTER.

Press a/b to select “Enable”, and then
press ENTER

• Five minutes before the power shuts down,
remaining time displays every minute.

2

3

4

• Factory preset value is “AUTO”.

• If “AUTO” is selected, colour system for each channel is
automatically set. If an image does not display clearly,
select another colour system (e.g. PAL, NTSC 4.43).

Press c/d to select “Option”.

Press a/b to select “Colour System”, and
then press ENTER.

Press a/b to select a compatible video
signal system of your equipment, and then
press ENTER.

AUTO

PAL

SECAM

NTSC 3.58

NTSC 4.43

PAL-60

NOTE

NOTE

• “Disable” is factory preset value.

• When a TV programme finishes, and the TV receives signal
input, this function may not operate.

No Operation Off

When set to “Enable”, the power will automatically shut
down if there is no operation for 3 hours.

1

2

3

4

5

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

• Power control menu displays.

Press a/b to select “Power Control”, and
then press ENTER.

Press a/b to select “No Operation Off”, and
then press ENTER.

Press a/b to select “Enable”, and then
press ENTER.

• Five minutes before the power shuts down,
remaining time displays every minute.

LC-AW5X_33-34 9/12/06, 10:35 AM33

NOTE

• “Disable” is factory preset value.

33

Useful adjustment settings

HDMI Setup

HDMI (High-Definition Multimedia Interface) terminal
selection.

To watch an HDMI equipment image, select

1

2

3

4

“INPUT3” or “INPUT4” using INPUT3 or
INPUT4 on the remote control unit or
TV/VIDEO on the TV.

Press MENU and the MENU screen displays.

Press c/d to select “Option”.

Press a/b to select “HDMI Setup”, and then
press ENTER.

• The HDMI Setup can be selected only when
“INPUT3” or “INPUT4” is selected.

...

[

MENU

Option

Option

Audio Only

DNR

Input Select

Blue Screen

Colour System

Power Control

HDMI Setup

HDMI Setup

]

NOTE

• Refer to your external equipment operation manual for
the signal type.

• When connecting a DVI-HDMI conversion adaptor/cable
to the HDMI terminals, the image may not come in clearly.

5

HDMI Setup
items

Signal
Type

Colour
Matrix

Auto
View

Audio
Select

Press a/b to select the desired item or
setting, and then press ENTER.

Selectable

items

RGB/
YCbCr4:4:4/
YCbCr4:2:2

Auto/
ITU601/
ITU709

Enable/
Disable

Digital/
Analogue

Select the video signal type from
the HDMI terminal. User settings
for this item are normally in effect
only when the TV is connected with
a DVI-HDMI conversion cable.
When connected to an HDMI
device, the TV automatically
detects the “Signal Type” and
ignores user settings before
operating.

Select the video colour matrix type
when a YCbCr signal is input.
Select the YCbCr colour system
when a YCbCr signal is input.
When an RGB signal is input, the
settings for this item are ignored.
“Auto” should normally be
selected.

Set whether or not to use WIDE
MODE based on signal recognition,
including an HDMI signal.

Select “Digital” for audio signal via
the HDMI terminal. Select
“Analogue” for audio signal via the
AUDIO jack. (selectable only when
using INPUT3 [HDMI] terminals.)

Description

34

LC-AW5X_33-34 9/12/06, 10:35 AM34

Useful features

Teletext function

What is Teletext?

Teletext broadcasts pages of information and
entertainment to specially equipped television sets.
Your TV receives Teletext signals broadcast by a TV
network, and decodes them into graphical format for
viewing. News, weather reports, sports information,
stock exchange prices and programme previews are
among the many services available.

Teletext mode

Teletext is turned on/off with m on the remote control
unit. You can operate your TV in Teletext mode directly
by inputting commands with the remote control unit.

TELETEXT

TELETEXT

When viewing the Teletext information

• Press CHr to increase the page number.

• Press CHs to decrease the page number.

NOTE

• When you turn TELETEXT on and change a Teletext page
right after changing channels, the relevant page may not
be displayed until TV finishes reading all the Teletext
information.

Button functions

Turning on and off Teletext

1

2

Select a TV channel or external input source
providing the Teletext programme.

Press m to display the Teletext.

Colour (RED/GREEN/YELLOW/BLUE):

You can select a group or block of pages displayed in
the coloured brackets at the bottom of the screen by
pressing the corresponding Colour (RED/GREEN/

YELLOW/BLUE) on the remote control unit.

TELETEXT

GREEN

RED

0 – 9:
Directly select any page from 100 to 899 by using 0 – 9.

YELLOW BLUE

v (Top/Bottom/Full):

Each time you press v, the TELETEXT image switches
as shown below.

Full

Top

3

LC-AW5X_35-39 9/12/06, 10:35 AM35

Press m again to display the Teletext on the
right screen and normal image on the left
screen.

• Each time you press m, the screen switches

as shown upper right.

• If you select a programme with no Teletext
signal, “No Teletext available.” is displayed.

Bottom

k (Reveal hidden for TELETEXT):

To reveal hidden information such as an answer to a
quiz, press k.

• Press k again to hide the information.

(Hold):

To stop updating Teletext pages automatically, press .

• Press again to release the hold mode.

35

— +

MENU

[

Setup

...

Text Language

]

Arabic/Hebrew

West Europe

East Europe

Turkish/Greek

Useful features

Displaying Subtitle

You can display several subtitles as they are
transmitted.

1

1

2

2

• Subtitle will not be displayed when the service does not
contain the subtitle information.

Press to display the subtitle.

• Subtitle is updated by information sent by the
broadcasting station.

• To stop updating subtitle automatically, press

.

Press to exit the subtitle screen.

NOTE

Teletext language setting

If Teletext information does not display correctly,
perform the setting procedure below.
Select from among 4 kinds of language tables: West
Europe, East Europe, Turkish/Greek, Arabic/Hebrew.
Each table is compatible with the Teletext languages
listed below.

1

2

3

4

Press MENU and the MENU screen displays.

Press c/d to select “Setup”.

Press a/b to select “Text Language”, and
then press ENTER.

Press a/b to select receivable teletext
broadcasting language in your country, and
then press ENTER.

Displaying Subpages

You can display several subpages as they are
transmitted.

1

2

Press m to display Teletext.

Press to display the subpage as shown
below.

Subpage screen

NOTE

• Teletext can display only when it is sent by a network. Not
used to convert between languages.

3

4

36

LC-AW5X_35-39 9/12/06, 10:35 AM36

0002 00 01 02 03

Select the desired subpage by using c/d.

• 0 – 9 directly selects the desired subpage.

Press to exit the subpage screen.

MENU

[

Option

...

Input Select

]

Auto

Component

Video

Using external equipment

You can connect many types of external equipment to your TV, like a VCR, DVD player, HDTV tuner, game
console and camcorder. To view external source images, select the input source from INPUT1, INPUT2, INPUT3
or INPUT4 on the remote control unit or TV/VIDEO on the TV.

Displaying an external equipment image

Explanation here is for the setting when connecting
DVD to INPUT1 terminal.

CAUTION

• To protect all equipment, always turn off the TV before
connecting to a VCR, DVD player, HDTV tuner, game
console, camcorder or other external equipment.

NOTE

• See pages 37 to 39 for external equipment connection.

• Please refer to the relevant operation manual (VCR, DVD
player, etc.) carefully before making connections.

• Each time TV/VIDEO is pressed, the input source toggles.

• If the image does not come in clearly, you may need to
change the input signal type setting on the “Input Select”
menu.

• Refer to your external equipment operation manual for
the signal type.

Displaying a DVD image (Example)

1

2

The setting is stored and can be selected.

To watch a DVD image, select “INPUT1”
using INPUT1 on the remote control unit or
TV/VIDEO on the TV.

TV

INPUT1

INPUT2

INPUT3

Select the desired signal type on “Input
Select” in the “Option” menu. (See page 32.)

For INPUT1 signal

Connecting a VCR

You can use the INPUT 2 terminal when connecting a VCR and other audiovisual equipment.

To watch an image from this input terminal, you
need to select the input source (see page 37)
and the input signal type (see page 32).

VIDEO

Composite cable (VIDEO/AUDIO)
(commercially available)

L

AUDIO

R

VCR

LC-AW5X_35-39 9/12/06, 10:35 AM37

37

Using external equipment

Connecting a DVD player

You can use the INPUT 1 or INPUT 3 (HDMI) terminal when connecting to a DVD player and other audiovisual
equipment.

NOTE

• When using a DVI-HDMI conversion adaptor, input the Audio Signal from the AUDIO terminal of INPUT 3.

DVD player

HDMI

or

Y

B

P

(CB)

P

R

(CR)

HDMI Cable (commercially available)

Component cable
(commercially available)

To watch an image from this input terminal, you
need to select the input source (see page 37)
and the input signal type (see page 32).

L

AUDIO

R

Audio cable
(commercially available)

When using component cable, select
“Component” for “Input Select” in the menu.

Connecting a game console or camcorder

A game console, camcorder and some other audiovisual equipment are conveniently connected using the
INPUT 2 terminals.

NOTE

• You can also connect the game console to INPUT 1 terminals to enjoy clearer picture.

To watch an image from this input terminal, you
need to select the input source (see page 37)
and the input signal type (see page 32).

VIDEO

Composite cable (VIDEO/AUDIO)
(commercially available)

L

AUDIO

R

Game console/Camcorder

38

LC-AW5X_35-39 9/12/06, 10:35 AM38

Using external equipment

Connecting an HDTV tuner

You can use the INPUT1 terminal when connecting to an HDTV tuner and other audiovisual equipment.

To watch an image from this input terminal, you
need to select the input source (see page 37)
and the input signal type (see page 32).

Y

P

B

(CB)

P

R

(CR)

L

AUDIO

R

HDTV tuner

Component cable
(commercially available)

Audio cable
(commercially available)

When using component cable, select
“Component” for “Input Select” in the menu.

LC-AW5X_35-39 9/12/06, 10:35 AM39

39

Appendix

Troubleshooting

Problem Possible Solution

• No power.

• Unit cannot be operated.

• Remote control unit does not
operate.

• Picture is cut off.

• Strange colour, light colour, or
dark, or colour misalignment.

• Power is suddenly turned off.

• Check if you pressed POWER on the remote control unit. (See page 13.)
If the indicator on the TV lights up red, press POWER.

• Is the AC cord disconnected? (See page 6.)

• Has the power been turned on? (See page 13.)

• External influences such as lightning, static electricity, etc., may cause improper
operation. In this case, operate the unit after first turning the power off the TV or
unplugging the AC cord and re-plugging it in after 1 or 2 minutes.

• Are batteries inserted with polarity (e, f) aligned? (See page 5.)

• Are batteries worn out? (Replace with new batteries.)

• Are you using it under strong or fluorescent lighting?

• Is a fluorescent light illuminated to remote control sensor?

• Is the image position correct? (See page 28.)

• Are screen mode adjustments such as picture size made correctly? (See pages
29 to 30.)

• Adjust the picture tone. (See pages 23 to 25 and 31.)

• Is the room too bright? The picture may look dark in a room that is too bright.

• Check the colour system setting. (See pages 19 and 33.)

• Check the input signal setting. (See page 32.)

• The unit’s internal temperature has increased.
Remove any objects blocking vent or clean.

• Check the power control setting. (See page 33.)

• Is sleep timer set? (See page 15.)

• No picture.

• No sound.

• Is connection to other equipment correct? (See pages 37 to 39)

• Has input signal setup been done correctly after connection? (See page 32.)

• Is the correct input selected? (See page 32.)

• Is picture adjustment correct? (See pages 23 to 25.)

• Is the antenna connected properly? (See page 8.)

• Is “On” selected in “Audio Only”? (See page 31.)

• Is the volume too low? (See page 15.)

• Make sure that headphones are not connected. (See page 10.)

Cautions regarding use in high and low temperature environments

• When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear
slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.

• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight
or near a heater, as this may cause the cabinet to deform and the LCD panel to malfunction.
Storage temperature: –20°C to +60°C.

40

LC-AW5X_40-44 9/12/06, 10:33 AM40

Appendix

RS-232C port specifications

PC Control of the TV

• When a program is set, the TV can be controlled from the PC using the RS-232C terminal.
The input signal (PC/video) can be selected, the volume can be adjusted and various other adjustments and
settings can be made, enabling automatic programmed playing.

• Attach an RS-232C cable cross-type (commercially available) to the supplied Din/D-sub RS-232C for the

connections.

NOTE

• This operation system should be used by a person who is accustomed to using PCs.

Communication conditions

Set the RS-232C communications settings on the PC to match the communications conditions of the TV. The
communications settings of the TV are as follows:

Baud rate:
Data length:
Parity bit:

Stop bit:

Flow control:

Communication procedure

Send the control commands from the PC via the RS-232C connector.
The TV operates according to the received command and sends a response message to the PC.
Do not send multiple commands at the same time. Wait until the PC receives the OK response before sending
the next command.

9,600 bps
8 bits
None

1 bit

None

Command format

Eight ASCII codes e CR

C1 C2 C3 C4 P1 P2 P3 P4

Parameter

Input the parameter values, aligning left, and fill with space(s) for the remainder. (Be sure that four values are input for
the parameter.)
When the input parameter is not correct, “ERR” returns. (Refer to “Response code format”.)

Command 4-digits: Command. The text of four characters.
Parameter 4-digits: Parameter 0 – 9, space, ?

Return codeCommand 4-digits Parameter 4-digits

0

0009

– 30

100

0055

When “?” is input for some commands, the present setting value responds.

?

????

LC-AW5X_40-44 9/12/06, 10:33 AM41

41

Appendix

Response code format

Normal response

OK

Return code (0DH)

Problem response (communication error or incorrect command)

ERR

Return code (0DH)

Commands

• Commands not indicated here are not guaranteed to operate.

CONTROL ITEM COMMAND PARAMETER

0

R

W

O

POWER SETTING

INPUT SELECTION A

CHANNEL

INPUT SELECTION B

VOLUME

POSITION

P

_

D

G

T

I

D

V

A

I

D

C

C

I

I

I

V

H

V

*

H

C

C

*

P

U

H

_

W

D

H

_

1

P

N

0

1

P

N

1

1

P

N

3

M

L

O

*

S

O

P

*

S

O

P

*

POWER OFF (STANDBY)

_

_

_

INPUT SWITCHING (TOGGLE)

_

_

_

INPUT1 – 4 0: TV

_

_

_

TV DIRECT CHANNEL (1 – 99)

_

_

*

CHANNEL UP

_

_

_

CHANNEL DOWN

_

_

_

INPUT1 (AUTO)

_

_

_

INPUT1 (COMPONENT)

_

_

_

INPUT1 (VIDEO)

_

_

_

VOLUME (0 – 60)

_

_

*

H-POSITION (AV) (ⳮ10 – 10)

_

*

*

V-POSITION (AV) (ⳮ20 – 20)

_

*

*

CONTROL

CONTENTS

CONTROL ITEM COMMAND PARAMETER

WIDE MODE

MUTE

AUDIO CHANGE

SLEEP TIMER

W

W

W

W

W

W

W

M

M

M

A

O

O

O

O

O

O

0

E

D

I

1

E

D

I

2

E

D

I

3

E

D

I

4

E

D

I

5

E

D

I

6

E

D

I

0

E

T

U

1

E

T

U

2

E

T

U

_

A

H

C

0

M

T

F

1

M

T

F

2

M

T

F

3

M

T

F

4

M

T

F

5

M

T

F

_

_

_

TOGGLE

_

_

_

NORMAL

_

_

_

ZOOM 14:9

_

_

_

PANORAMA

_

_

_

FULL

_

_

_

CINEMA 16:9

_

_

_

CINEMA 14:9

_

_

_

TOGGLE

_

_

_

ON

_

_

_

OFF

_

_

_

TOGGLE

_

_

_

OFF

_

_

_

SLEEP TIMER 30 MIN

_

_

_

SLEEP TIMER 1 HOUR

_

_

_

SLEEP TIMER 1 HOUR 30 MIN

_

_

_

SLEEP TIMER 2 HOUR

_

_

_

SLEEP TIMER 2 HOUR 30 MIN

NOTE

• If an underbar (_) appears in the parameter column, enter a space.

• If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL CONTENTS.

CONTROL

CONTENTS

42

LC-AW5X_40-44 9/12/06, 10:33 AM42

Appendix

Specifications

Item

Model

LCD panel

Number of dots 3,147,264 dots (1366 g 768 g 3 dots)

Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60

TV
Function

Brightness 450 cd/m

Backlight life 60,000 hours (at Backlight Standard position)

Viewing angles H : 176° V : 176°
Audio amplifier 10W g 2

Speakers Ø 6.5 cm 4pcs

Terminals

OSD language English/Chinese/Arabic

Power Requirement AC 110–240 V, 50 Hz

Power Consumption

Weight

Operating Temperature 0°C - 40°C

Receiving
Channel

TV-Tuning System Auto Preset 99 ch

STEREO/BILINGUAL NICAM: B/G, I, D/K A2 stereo: B/G

Rear

Front

VHF/UHF 44.25-863.25 MHz

CATV S1–S41ch (including Hyperband)

ANTENNA IN

INPUT 1

INPUT 2

INPUT 3 HDMI (HDMI input) (480P, 580P, 1080I/50Hz, 1080I/60Hz, 720P/50Hz, 720P/60Hz),

INPUT 4 HDMI (HDMI input) (480P, 580P, 1080I/50Hz, 1080I/60Hz, 720P/50Hz, 720P/60Hz)
MONITOR OUTPUT
RS-232C 9 pin D-sub male connector
Headphones Ø 3.5mm jack (Audio output)

LC-32AW5X LC-37AW5X

32o (80 cm) Advanced Super View &
BLACK TFT LCD

PAL: B/G, D/K, I SECAM: B/G, D/K, K/K1 NTSC: MTV-Standard

2

UHF/VHF 75 q DIN type

VIDEO in, AUDIO in,
COMPONENT in (480I, 580I, 480P, 580P, 1080I/50Hz, 1080I/60Hz, 720P/60Hz)

VIDEO in, AUDIO in

AUDIO in

VIDEO out, AUDIO out

158 W (0.8 W Standby) (Method IEC60107)

17.4 kg (without stand) 20.7 kg (with stand)

37o (94 cm) Advanced Super View &
BLACK TFT LCD

171 W (0.8 W Standby) (Method IEC60107)

21.2 kg (without stand) 24.5 kg (with stand)

• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units. There may be some deviations from these values in individual units.

Optional accessory

The listed optional accessory is available for the LCD colour TV.
Please purchase it at your nearest shop.

Wall mount bracket
(for LC-32AW5X/LC-37AW5X)

Part name Part number

AN-37AG2

• Additional optional accessories may be available in the near
future. When purchasing, please read the newest catalogue for
compatibility and check the availability.

Password

LC-AW5X_40-44 9/12/06, 10:33 AM43

43

Dimensional drawings

LC-32AW5X, LC-37AW5X

700(823)

590(655)63

653(718.5)

671(671)

815(932)

394.5

(464)

• Figures within parentheses are for
LC-37AW5X

Unit: mm

100

(100)

120

(120)

(63.5)

100

(100)

200(200)

399(430)

306(306)

200(200)

44

LC-AW5X_40-44 9/12/06, 10:33 AM44

FOR LOCATION ENQUIRIES WITHIN

AUSTRALIA

REGARDING YOUR LOCAL

SHARP APPROVED SERVICE CENTRE

VISIT OUR WEBSITE AT

www.sharp.net.au

OR CALL SHARP CUSTOMER CARE

1300 135 022

(LOCAL CALL COST APPLY WITHIN AUSTRALIA)

SHARP CORPORATION OF AUSTRALIA PTY LTD

FOR LOCATION ENQUIRIES WITHIN

SHARP APPROVED SERVICE CENTRE

www.sharp.net.nz

CONTACT YOUR SELLING DEALER/RETAILER

SHARP CORPORATION OF NEW ZEALAND LIMITED

SPform019(JUNE 2004)

NEW ZEALAND

REGARDING YOUR LOCAL

VISIT OUR WEBSITE AT

OR CALL

SHARP CUSTOMER SERVICES

TELEPHONE: [phone]

FACSIMILE: 09 573 0113

LC-AW5X_45-46 9/12/06, 10:35 AM2

This Sharp product is warranted against faults in materials and manufacture for a period
of twelve (12) months from the date of original purchase.

If service is required during the warranty period, please contact your nearest Sharp
Approved Service Centre. These repairs would be carried out at no charge to the
owner, subject to the conditions specified herein.

The owner is responsible for any transportation and insurance costs if the product has
to be returned for repair.

This warranty does not extend to accessories or defects or injuries caused by or resulting
from causes not attributable to faulty parts or the manufacture of the product, including
but not limited to, defect or injury caused by or resulting from misuse, abuse, neglect,
accidental damage, improper voltage, liquid spillage, vermin infestation, software, or
any alterations made to the product which are not authorised by Sharp.

Please retain your sales documentation, as this should be produced to validate a
warranty claim.

This warranty is in addition to and in no way limits, varies or excludes any express and
implied rights and remedies under any relevant legislation in the country of sale.

IMPORTANT

DO NOT RETURN THIS DOCUMENT TO SHARP

For your reference, please enter the particulars of your purchase
below and retain, with your purchase documentation.

e

Model No.

Serial No.

Date of Purchase

Retailer

IMPORTANT NOTICE: This warranty applies only to products sold in Australia & New Zealand

Printed on post-consumer recycled paper.

SHARP CORPORATION OF

AUSTRALIA PTY. LIMITED

ood Drive

gwood NSW2148

ABN 40 003 039 405

1 Huntingw

Huntin

SHARP CORPORATION OF

NEW ZEALAND LIMITED

59 Hugo Johnston Driv

enrose, Auckland

P

SPform030 (JUNE 2004)

Printed in Malaysia
TINS-C789WJZZ
06P10-MA-NF

LC-AW5X_FCover 9/12/06, 10:35 AM2
