Sharp LC-13S1E, LC-15S1E Schematic
LC-13S1E
LC-15S1E
SERVICE MANUAL
S93I1LC-13S1E
LCD COLOUR TELEVISION
LC-13S1E
MODELS
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
CONTENTS
» IMPORTANT SERVICE SAFETY PRECAUTION .........................................................................................2
» SPECIFICATIONS ........................................................................................................................................4
» OPERATION MANUAL .................................................................................................................................5
» DIMENSIONS ...............................................................................................................................................7
» REMOVING OF MAJOR PARTS ..................................................................................................................9
» ADJUSTING PROCEDURE OF EACH SECTION .....................................................................................13
» TROUBLE SHOOTING TABLE...................................................................................................................17
» CHASSIS LAYOUT .....................................................................................................................................23
» BLOCK DIAGRAM......................................................................................................................................24
» OVERALL WIRING DIAGRAM ...................................................................................................................26
» DESCRIPTION OF SCHEMATIC DIAGRAM .............................................................................................28
» SCHEMATIC DIAGRAM .............................................................................................................................29
» PRINTED WIRING BOARD ASSEMBLIES................................................................................................56
» REPLACEMENT PARTS LIST....................................................................................................................65
» PACKING OF THE SET ..............................................................................................................................79
LC-15S1E
Page
SHARP CORPORATION
LC-13S1E
2
1
1
LC-15S1E
IMPORTANT SERVICE SAFETY PRECAUTION
Ë
Service work should be performed only by qualified ser vice technicians who are
thoroughly familiar with all safety checks and the servicing guidelines which follow:
WARNING
1. For continued safety, no modification of any circuit
should be attempted.
2. Disconnect AC power before servicing.
CAUTION: FOR CONTINUED PROTECTION
AGAINST A RISK OF FIRE REPLACE ONLY WITH
SAME TYPE F3301(2A, 250V), F3302(1.25A, 250V),
F6501 (1.25A, 250V) AND F6502 (1.25A, 250V)
FUSE.
BEFORE RETURNING THE RECEIVER
(Fire & Shock Hazard)
Before returning the receiver to the user, perform
the following safety checks:
1. Inspect all lead dress to make certain that leads are
not pinched, and check that hardware is not lodged
between the chassis and other metal parts in the
receiver.
2. Inspect all protective devices such as non-metallic
control knobs, insulation materials, cabinet backs,
adjustment and compartment covers or shields,
isolation resistor-capacitor networks, mechanical
insulators, etc.
3. To be sure that no shock hazard exists, check for
leakage current in the following manner.
• Plug the AC cord directly into a 110~240 volt A C outlet,
and connect the DC power cable into the receiver's
DC jack. (Do not use an isolation transformer for this
test).
• Using two clip leads, connect a 50k ohm, 10 watt resistor
paralleled by a 0.15µF capacitor in series with all
exposed metal cabinet parts and a known earth ground,
such as electrical conduit or electrical ground connected
to an earth ground.
• Use an AC voltmeter ha ving with 5000 ohm per volt, or
higher, sensitivity or measure the AC voltage drop
across the resistor.
• Connect the resistor connection to all exposed metal
parts having a return to the chassis (antenna, metal
cabinet, screw heads, knobs and control shafts,
escutcheon, etc.) and measure the AC voltage drop
across the resistor.
All checks must be repeated with the AC cord plug
connection reversed. (If necessary, a nonpolarized
adaptor plug must be used only for the purpose of
completing these checks.)
Any reading of 0.75V peak (this corresponds to 0.5
mA. peak AC.) or more is excessive and indicates a
potential shock hazard which must be corrected before
returning the monitor to the owner.
DVM
AC SCALE
50k ohm
10W
0.15 F
TEST PROBE
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
SAFETY NOTICE
Many electrical and mechanical parts in LCD television
have special safety-related characteristics.
These characteristics are often not evident from visual
inspection, nor can protection afforded by them be
necessarily increased by using replacement components
rated for higher voltage , wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this manual; electrical
and shaded areas in the
Schematic Diagrams.
For continued protection, replacement parts must be
identical to those used in the original circuit.
The use of a substitute replacement parts which do not
have the same safety characteristics as the factory
recommended replacement parts shown in this service
manual, may create shock, fire or other hazards.
components having such features are identified by “ å”
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012
23456789012345678901234567890121234567890123456789012345678901212345678901234567890123456789012
2
Replacement Parts Lists and
LC-13S1E
LC-15S1E
Precautions for using lead-free solder
1 Employing lead-free solder
"MAIN PWB" of this model employs lead-free solder . The LF symbol indicates lead-free solder , and is attached on
the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.
Example:
L Fa
Indicates lead-free solder of tin, silver and copper.
2 Using lead-free wire solder
When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional
lead wire solder may cause damage or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40°C, we recommend
you to use a dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit,
contact our service station or service branch in your area.
3 Soldering
As the melting point of lead-free solder (Sn-Ag-Cu) is about 220°C which is higher than the conventional lead
solder by 40°C, and as it has poor solder wettability, you may be apt to keep the soldering bit in contact with the
PWB for extended period of time. However, Since the land may be peeled off or the maximum heat-resistance
temperature of parts may be exceeded, remov e the bit from the PWB as soon as you confirm the steady soldering
condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on
and off the power of the bit as required.
If a different type of solder stays on the tip of the soldering bit, it is allo y ed with lead-free solder. Clean the bit after
every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
Part No, ★ Description Code
ZHNDAi123250E J φ0.3mm 250g(1roll) BL
ZHNDAi126500E J φ0.6mm 500g(1roll) BK
ZHNDAi12801KE J φ1.0mm 1kg(1roll) BM
3
LC-13S1E
LC-15S1E
SPECIFICATIONS
Item 13" LCD
LCD panel
Number of dots 921,600 dots
Video colour system PAL/SECAM/NTSC
TV TV-Standard (CCIR) B/G, I, D/K, L
TV-Tuning System Auto preset 200 ch.
STEREO/BILINGUAL NICAM, A2 stereo
AUTO
PRESET YES
CATV ~Hyper Band
Brightness 430 cd/m
Lamp life 60,000 hours
Viewing angles H: 170° V: 170°
Audio amplifier
Speakers 3 cm 7.5 cm 2 pcs.
Terminals AV-IN 1 21 pin Euro-SCART
AV-IN 2 S-VIDEO, VIDEO, AUDIO
OUT AUDIO
Antenna DIN
Headphones 3.5 mm ø jack (Front)
OSD
language English/German/French/Spanish/Italian/Swedish/Dutch/Russian
Power requirement DC 12 V, AC 110 V – 240 V, 50/60 Hz
Weight 3.6 kg w/o accessories 4.2 kg w/o accessories
Accessories Operation Manual, Remote Control, Batteries ( 2), AC adapter, AC cord,
■ As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improve-
ment without prior notice. The performance specification figures indicated are nominal values of production units. There may be some
13" Advanced Super View & BLACK TFT LCD 15" Advanced Super View & BLACK TFT LCD
2.1 W
Cable clamp
COLOUR TV, Model: LC-13S1E 15" LCD COLOUR TV, Model: LC-15S1E
2
2
4
OPERATION MANUAL
12°
35°
Part Names of Main Unit
Controls
• TV/VIDEO, CH (
)/(
)
(–)/(+) (Volume) and MENU on the main unit have the same functions as the same buttons on the remote
control.
Fundamentally, this operation manual provides a description based on operation using the remote control.
Headphone jack
Plug the headphone mini-plug into the Headphone jack located on
the front of the TV set.
OPC sensor
Remote sensor
OPC sensor indicator (Optical Picture Control)
The Optical Picture Control indicator lights up green when the
Brightness
is set to Auto.
POWER/STANDBY/Remote sensor indicator
A green indicator lights when the power is on and a red indicator
lights when in the standby mode (the indicator will not light when the
main power is off). A red indicator blinks when the TV set receives
the remote control signal.
* The examples used throughout this manual are based
on the LC-15S1E model.
(–)/(+) (Volume)
Upper control panel
CH (
)/( )
MENU
TV/VIDEO
(MAIN POWER)
The screen can be adjusted
backwards to an angle between
12 degrees and 35 degrees.
The screen cannot be set up
straight. When changing the
angle, make sure to hold the
stand and adjust the screen to
the best viewable angle.
Speaker
Adjustable range
Terminals
POWER INPUT DC 12V
Antenna
AV-IN 1
(21-pin Euro-SCART)
AUDIO OUT (R)
AUDIO OUT (L)
Rear View
Carrying
handle
AUDIO (R)
AUDIO
(L)
VIDEO
S-VIDEO
AV-IN2
●The screen can be adjusted back-
wards
to an angle between 12 and 35
degrees.
When changing the angle, make sure
to hold the stand and adjust to the
best
viewable angle.
* Be careful to prevent the product from
falling over when adjusting the angle.
Also
place the product on a stable
base.
Stand
Round lock for Kensington
Security Standard Slot.
1
LC-13S1E
LC-15S1E
5
LC-13S1E
Part Names of Remote Control
CH
MENU
E
REVEAL
HOLD
END
M
MENUSOUND
SUBTITLE
SUBPAGE
TEXT
ROTATE
W
ID
E
T
CH
OK
E
TV/VIDEO
REVEAL
HOLD
END
MENUSOUND
SUBTITLE
SUBPAGE
TEXT
ROTATE
B
R
IG
H
T
T
M
T
BRIGHT
Selects the brightness
and OPC of the display.
HOLD
Temporarily holds the
current
Teletext page.
(Power)
OK, Programme Table
SUBTITLE
Displays the Teletext
Subtitle directly.
SOUND
Switches the sound
mode.
Right / Left Selection
Red, Picture Menu
Green, Sound Menu
(+)/(-) (Volume)
Channel Select
(Flashback)
Returns to the previous
channel.
SUBPAGE
Displays the Teletext
Subpage directly.
TEXT
Displays the Teletext mode
screen.
REVEAL
Displays hidden information
such as solutions to riddles
and puzzles.
ROTATE
Rotates the display in every
direction.
END
Returns to normal screen.
Upwards/Downwards
Selection, zoom display
function (Teletext mode)
MENU
Displays the TV menu.
Cyan, Status Display
Turns on the status display
when the menu is not
displayed.
Yellow,
Timer function Menu
(Mute)
Switches
the sound on and off.
CH (
)/(
)
Displays previous/next page.
(Teletext mode)
TV/VIDEO
Switches the input source
between AV1, AV2 and
TV
mode.
Installing Batteries in the Remote Control
Before using the LCD TV set for the first time, install the two R-03 ( AAA size, UM/SUM-4) batteries supplied in the remote
control. When the batteries become depleted and the remote control fails to operate, replace the batteries with new R-03
( AAA size, UM/SUM-4) batteries.
1
Open the battery cover.
2
Insert two R-03 ( AAA size,
UM/SUM-4) batteries.
3
Replace the battery cover.
■ Position the positive and
negative ends of the
batteries as indicated in
the compartment.
Caution!
Precautions regarding batteries
■ Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the instructions below.
¥ Place batteries with their terminals corresponding to the (+) and (—) indications.
¥ Different types of batteries have different characteristics. Do not mix batteries of different types.
¥ Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries and/or cause old
batteries to leak chemicals.
¥ Remove batteries as soon as they are depleted. Chemicals that leak from batteries can cause a rash. If chemical
leakage is found, wipe it off with a cloth.
¥ The batteries supplied with the product may have a shorter life expectancy due to storage conditions.
¥ If the remote control is not to be used for an extended period of time, remove the batteries from the remote control.
Preparation
■ Engaging the lower
claw with the remote
control, close the
cover.
■ Slide the cover while
pressing the ( ) part.
+
—
+
—
LC-15S1E
6
REMOVING OF MAJOR PARTS
Cabinet A
Cabinet B
Terminal Cover
(LC-13S1E)
Stand
4
3
3
1
5
2
1. Remove the stand fixing screws (4 pcs.).
2. Remove the terminal cover.
3. Remove the terminal section fixing screws (2 pcs.) (LC-13S1E).
3. Remove the terminal section fixing screw (1 pc.) (LC-15S1E).
4. Remove the cabinet B fixing screws (7 pcs.).
5. Remove the cabinet B after opening from the direction of an arrow.
6. Detach the connector from each PWB.
LC-13S1E
LC-15S1E
P3600
6
Tuner PWB
P3305
SC3901
P4003
R/C, LED
6
SC2001
6
P2001
PWB
P701
P4001
66
SC1202
6
6
P1900
SC1203
6
SC1203
Main PWB
9
LC-13S1E
LC-15S1E
7. Remove the 3 lock screws from the main PWB and undo the hooks a and b. Lifting the other PWBs close to the
hooks, draw out the main PWB.
8. Remove the 5 lock screws from the tuner PWB and undo the hooks c and d. Detach the chassis frame (right),
together with its terminals, from the tuner PWB. Undo the hooks e and f in the same way. Detach the chassis
frame (left), together with its terminals, from the tuner PWB.
9. Remove the 2 lock screws from the R/C, LED PWB and take out the R/C, LED PWB.
10. Remove the 3 lock screws each from the right and left speakers and take out both the speakers.
8
7
Chassis Frame (R)
c
d
Tuner PWB
e
f
a
LCD panel unit
Main PWB
Chassis Frame (L)
b
10
Speaker (L)Speaker (R)
R/C, LED
9
PWB
10
10
» Precautions in handling the LCD panels
1. Work in a clean room (with humidities below 50%).
2. Be sure to wear an anti-static armband.
3. Handle the panels on an electro-conductive mat.
4. Be careful not to fall, shake and shock the panels.
11. Remove the LCD panel unit.
12. Detach the prism sheet, diffusion sheet and reflection/deflection sheet.
13. Detach the four reflection mirrors.
14. Remove the lamp unit.
15. Detach the Light guide plate.
16. Detach the two lamp reflection sheets.
13
Reflection Mirror
Reflection Sheet-1
(PSHEP0279CEZZ:LC-13S1E)
(PSHEP0284CEZZ:LC-15S1E)
LC-13S1E
LC-15S1E
Back Shield
(PSHEP0306CEZZ:LC-13S1E)
(PSHEP0307CEZZ:LC-15S1E)
11
LCD Panel Unit
Reflection Sheet (Cover)
12
(PSHEP0278CEZZ:LC-13S1E)
(PSHEP0283CEZZ:LC-15S1E)
Prism Sheet
(PSHEP0277CEZZ:LC-13S1E)
(PSHEP0282CEZZ:LC-15S1E)
Reflection/deflection Sheet
(PSHEP0276CEZZ:LC-13S1E)
(PSHEP0281CEZZ:LC-15S1E)
Diffusion Sheet
15
14
(KLMP-0120CEZZ:LC-13S1E)
(KLMP-0122CEZZ:LC-15S1E)
Lamp Unit
Light Guide Plate
(PGIDMA010WJZZ:LC-13S1E)
(PGIDMA011WJZZ:LC-15S1E)
13
Reflection Mirror
16
Reflection Sheet-2
(PSHEP0280CEZZ:LC-13S1E)
(PSHEP0285CEZZ:LC-15S1E)
11
LC-13S1E
LC-15S1E
» Precautions at the time of the side B(back) service of main unit.
1. Remove only SC2001 of the FFC for connection between Main unit(SC2001) and Tuner unit(SC3901), and connect the extended cable (QCNW-A369WJZZ) for service.
2. Remove only P701 of the FFC for connection between Main unit(P701) and Tuner unit(P1900), and connect the
extended cable (QCNW-B594WJZZ) for service.
3. Remove the main unit fixing screws(3 pcs.), a substrate is reversed.
Tuner PWB
P1900
SC3901
SC2001
R/C, LED PWB
P701
1
2
Main PWB
3
Main PWB
(Side B)
Step Part No. Description
1 QCNW-A369WJZZ Extension Cable 50-pin Main (SC2001)-Tuner (SC3901)
2 QCNW-B594WJZZ Extension Cable 13-pin Main (P701)-Tuner (P1900)
12
LC-13S1E
LC-15S1E
ADJUSTING PROCEDURE OF EACH SECTION
The best adjustment is made before shipping. If any position deviation is found or after part replace is performed,
adjust as follows.
Preparation for adjustments
Use the dedicated AC adaptor or stable DC power supply.
LC-13/15S1E AC adaptor: UADP-A043WJPZ
DC power supply: 12V 5.0A
1.Adjusting procedure
• Checker adjustment
Power ON (Adjustment processing mode) → +B adjustment → Counter bias adjustment → TAMP (Contrast)
adjustment → White balance adjustment
2.Entering the adjustment processing mode
There are the following two methods.
• Setting the pin (81)(KEY4) or pin (82)(KEY5) of IC2001 (microprocessor) to GND, turn on the power.
• A "POWER" ke y is made on with pushing an "TV/VIDEO" and "MENU" k e ys at the same time .(K of the inspection
process mode is displayed b y the upper left of the image plane.) → Ne xt, "CH (Ù)" and "VOL (–)" ke ys are pushed
at the same time.(It becomes the image plane of the adjustment process mode.).....When it is canceled, it is made
to turn it off.(Even off in the "MAIN POWER" key, off with R/C are good.)
3.Key operation in the adjustment process mode
• The receiving channel UP/DOWN is performed with the "CH (ù)/(Ù)" keys.
One push ... The UP/DOWN tuning is performed per channel.
Continuous push ... The UP/DOWN search is performed until a next receivable station is found.
• V arious adjustments
The adjustment is performed for each item by the "MENU", "Menu cursor", "CH (ù)/(Ù)" or "VOL (+)/(–)" keys
(LCD TV set and remote control).
• Adjustment item is chosen with the Menu cursor upward/downward keys.
• The adjustment item makes a toggle operation with the "MENU" key input. (Next item)
If the "MENU" key is input while the bottom item is selected, it moves to the top item on the next page.
• Press the auto preset button on the remote controller in the adjustment process mode, and the top item of the
next page will show up regardless of which item appears now.
Page 1 → Page 2 → ... → Page 66 → Page 1
• Press the manual memory button on the remote controller in the adjustment process mode, and the top item of
the same page will show up.
• UP/DOWN of each adjustment vale selected is performed with the VOL (+)/(–) keys input.
13
LC-13S1E
LC-15S1E
4.Initialization
When the microprocessor (IC2001) or the EEPROM (IC2007, IC2009) has been replaced or when the EEPROM
has been initialized, readjust the each adjustments.
4-1. Connect the pins (81) and (82) of IC2001 (microprocessor) to GND, and turn on the power.
4-2. Check that the model name is (A661).
4-3. Select the inch size (13) : (LC-13S1E) and (15) : (LC-15S1E).
4-4. LED changes green from red after setting finish and about 15 seconds, initialization is completed, and it
becomes adjustment mode.
4-5. Writing the model-by-model data
For the Ver.1.00A microprocessor, get it initialized first and then make the settings, listed below, on it. (The
microprocessor version is indicated at the bottom of Adjustment Process Page 1.)
Ver.1.00A data reprogramming (INCH SIZE [13]) (LC-13S1E / E(K) / E(R))
Adjustment process page
12
47
47
–
Ver.1.00A data reprogramming (INCH SIZE [13]) (Only for LC-13S1E(K))
Adjustment process page
12
11
11
11
11
11
PAL TV PKCFSOFT7C
PAL TV LDL Y
PAL AV LDLY
DPS 2DH
PAL TV PKCFSOFT7C
PAL TV COLOR
PAL AV COLOR
PAL TV TINT
PAL AV TINT
PAL BRIGHTNESS
Item
Item
OSD settings
6 → 4
0 → +1
0 → +1
–
OSD settings
4 → 6
41 → 37
41 → 37
–2→ +1
–2→ +1
–15→ –3
Ver.1.00A data reprogramming (INCH SIZE [15]) (LC-13S1E / E(K) / E(R))
Adjustment process page
11
11
11
11
12
47
47
Ver.1.00A data reprogramming (INCH SIZE [15]) (Only for LC-15S1E(K))
Adjustment process page
11
11
11
11
12
PAL BRIGHTNESS
PAL-M BRIGHTNESS
PAL-N BRIGHTNESS
PAL60 BRIGHTNESS
PAL TV PKCFSOFT7C
PAL TV LDL Y
PAL AV LDLY
PAL TV COLOR
PAL AV COLOR
PAL TV TINT
PAL AV TINT
PAL TV PKCFSOFT7C
Item
Item
OSD settings
0 → –8
0 → –8
0 → –8
0 → –8
6 → 4
0 → +1
0 → +1
OSD settings
38→ 37
38→ 37
–2→ +1
–2→ +1
4 → 6
14
5.Adjustment
5-1. +B adjustment...Page 1 +B-ADJ
Adjust the voltage of the pin (4) of P1900 to 5.00 ±0.02V with R3714.
Note: Since 5.0V is a reference voltage of all power voltage, adjust it precisely.
5-2. Counter-bias adjustment
Vary the "COM BIAS" setting on Page 2 of the adjustment process mode so that the contrast be sharpest
(black looks most sinking).
5-3. TAMP adjustment
1) Receive the upper left of 75% white half colour bar signal.
2) See if the "Y" reading on page 2 of the adjustment process mode is somewhere following. If not, make the
"PAL TAMP" adjustment to get the "Y" reading in the range of AE thru BD.
3) If the adjustment of "PAL TAMP" is executed, write its adjustment value to the "SECAM TAMP" manually.
(Screen of the page 2 of the adjustment processing menu OSD)
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
0
1
2
3
4
5
6
7
8
9
10
11
12
13
2
COM B I AS 9 0
PAL TAMP 27
SECAM TAMP 27
RCUTOF F
GCU TOF F
BCU TOF F
RGA I
GG
BGA I
TAMP
TAMP
AI
Y
N 0
N
N
H
L
LC-13S1E
LC-15S1E
0
0
0
0
0
B
6
D
B
E
A
Y Data
(White 75%)
5-4. White balance adjustment
Adjust "RCUTOFF", "BCUTOFF", "RGAIN" and "BGAIN" on the page 2 of the adjustment processing so as
to obtain the colour of the same level as the standard set.
15
LC-13S1E
LC-15S1E
6. Factory Setting
6-1. Perform a factory setting after completing all adjustments.
6-2. A "POWER" keys is made on with pushing an "TV/VIDEO" and "MENU" keys at the same time.
6-3. "K" of the inspection process mode is displayed on the screen upper left.
6-4. CH (ù) and VOL (+) keys are pushed about 2 seconds at the same time.
6-5. Release keys, if "E" is displayed on the screen upper left and "COMPLETE" is displa yed on the bottom of it.
6-6. After a while, a power will be in a standby mode and a setup will be finished.
Note: "First installation" serves on "Deutsch".
7. Lamp error detection
7-1. Functional description
This LCD colour television has a function (lamp error detection) to be turned OFF automatically for safety
when the lamp or lamp circuit is abnormal.
If the lamp or lamp circuit is abnormal, or some other errors happen, and the lamp error detection is executed,
the followings occur.
1 The main unit of television is turned OFF 5 seconds after it is turned ON. (The power LED on the front
side of TV turns from green to red.)
2 If the situation 1 happens 5 times sequentially, television can not be turned ON. (The power LED remains
red.)
7-2. Countermeasures
7-2-1.Check when turning OFF the lamp error detection
When television is turned OFF by the lamp error detection mentioned above, it enters the adjustment
process with the power LED red. Entering the adjustment process turns OFF the error detection and turns
ON TV.
This enables the operation check to detect errors in the lamp or lamp circuit.
Check whether "ERROR NO RESET" on line 3, page 1 of the adjustment process is 1 or more. If it is 1 or
more, it indicates the lamp error detection was executed.
7-2-2.Resetting of the lamp error count
After confirming that the lamp or lamp circuit is normal, reset the lamp error count. Select "ERROR NO
RESET" on line 3, page 1 of the adjustment process and set the number to 0 using the volume button.
Page 1 of the adjustment process
1
M O D E L A661
INCH SIZE ~
ERROR NO RESET 5
PUBLIC MODE OFF
EXT CONTROL OFF
EXT MODE UART
UPDATE MODE NORMAL
TEXT RESET OFF
Reset 0
V E R R O M 1 . 0 0 A
Note~:13=LC-13S1E, 15=LC-15S1E
Afterwards, perform the operation check to confirm that the lamp error detection does not function.
16
TROUBLE SHOOTING TABLE
No picture and No sound
Check all the settings microprocessor's adjust process menu.
Do F3301 and F3302
function?
Are T3701's secondary
outputs, +34V, +9V, +5V
and -110V normal?
Replace F3301 and F3302.
Check S4001 and
connection cable.
Is T3701's primary oscillator
waveform normal?
Check T3701's secondary
load.
Yes Yes
No
No
No No
No
Yes
Check J3300 periphery and
connection cable.
Replace F6501 and F6502.
Yes
Yes
No
No
No
Yes
Yes
Back light lamp failure to light up
Is the primary side of
T6500, T6502 periphery
short-circuiting?
Replace the back light lamp
with new one and check
again.
Remove F3301 and F3302
and check the load side.
Is there short-circuiting?
Is there short-circuiting of
T3701 primary side periphery,
Q3701, Q3703 and S4001.
Is the pin(121) of IC1201 in
the "H" state?
Is the output of Q3601 in the
"
L
"
state?
Check the OFL2 line, IC1201
and their peripheral parts.
Check the OFL2 line, Q3601
and their peripheral parts.
Check T6500, T6502, Q6500
~ Q6704 and connection
cable.
LC-13S1E
LC-15S1E
17
LC-13S1E
No picture (1/3)
Check all the settings microprocessor's adjust process menu.
Is in/output of
IC801 normal?
Is in/output of
IC1201 normal?
Check IC801
and its
peripheral parts.
Check IC1201
and its
peripheral parts.
Check LCD
panel voltages
and waveform.
Yes
Yes
No
No
No picture
at all
Is voltages at
pins (6), (7) and
(18) of tuner
normal?
Is output at pin
(13) of tuner
normal?
Check the
power line.
Check tuner
and its
peripheral parts.
Is input at pin
(16) of IC802
normal?
Is the pin (3)
of IC802 at "H"
state?
Yes
Yes
No
No
No
No
No
Yes
No TV output
Is the pin (48)
of IC2001 at
"H" state?
Yes
Check the its
line.
Check the its
line.
Check IC802
and its
peripheral parts.
Is input at pin
(7) of IC802
normal?
Check V1_V
line and its
peripheral parts.
No
No VIDEO 2
output
LC-15S1E
TROUBLE SHOOTING TABLE (Continued)
18
TROUBLE SHOOTING TABLE (Continued)
No picture (2/3)
Check all the settings microprocessor
’s adjust process menu.
Is input at pin
(14) of IC802
normal?
Check the V2_V
line and its
peripheral parts.
No
No VIDEO 1
output
Check the SY-line,
SC-line and their
peripheral parts.
Is input at pin (9)
of IC802 and pin
(1) of IC805
normal?
No
No S-VIDEO
output
Check IC1201
and its
peripheral parts.
No
Yes
Yes
No TELETEXT
output
Is input at pins (136),
(137), (138), and
(142) of IC1201
normal?
No
Check the R, G
and B line.
Is output at pins
(57)~(59) of IC1601
normal?
No
Yes
Check Vout line and
its peripheral parts.
Is input at pin (21) of
IC1601 normal?
Check IC1601 and its
peripheral parts.
LC-13S1E
LC-15S1E
19
LC-13S1E
No picture (3/3)
Check all the settings microprocessor's adjust process menu.
Is output of
R0~R7
normal?
Is output of
G0~G7
normal?
Is output of
B0~B7
normal?
Yes
Yes
No
No
No
Colour is
unusual
Is in/output of
SPIO and
SPOI normal?
No
No picture
inversion
No
Gradation
defect
Is output of U/D
normal?
Yes
No
Check R1224, R1227
and their peripheral
parts.
Check R1234 and
its peripheral parts.
Check IC1202, Q1206
and their peripheral
parts.
Check R1231, R1267
and their peripheral
parts.
Check R1268, R1269
and their peripheral
parts.
Is output V0, V7, V21,
V64, V112, V176,
V235 and V255
normal?
Check IC1101 and its
peripheral parts.
LC-15S1E
TROUBLE SHOOTING TABLE (Continued)
20
TROUBLE SHOOTING TABLE (Continued)
No sound (1/2)
Check all the settings microprocessor's adjust process menu.
Is the pin (53) of
IC2001 in the
"L" state?
Is output at pins
(27) and (28) of
IC1900 normal?
Yes
Yes
No
No
No
No sound
from front
speakers
Yes
Muting effect is
on. Check the
FSMUTE line.
Check IC1900
and its
peripheral parts.
Is the pin (52) of
IC2001 in the
"L" state?
Is output at pins
(24) and (25) of
IC1900 normal?
Is output at pins
(1) and (7) of
IC350 normal?
Yes
Yes
No
No
No
Yes
Muting effect is
on. Check the
HP_MUTE line.
Check IC1900
and its
peripheral parts.
Check IC350
and its
peripheral parts.
No sound
from
headphone
TV sound
failure
Is output at pins
(33) and (34) of
IC1900 normal?
Is output at pins
(1) and (7) of
IC3500 normal?
Check IC1900
and its
peripheral parts.
Check IC3500
and its
peripheral parts.
Yes
No
No
No
No sound
from output
line
Check the tuner
and its
peripheral parts.
Yes
No
Is output at pin
(11) of Tuner
normal?
Is input at pin
(67) of IC1900.
Check IC1900
and its
peripheral
parts.
Check
Headphone Jack
and connection
cable.
No
Is output at pins
(8) and (12) of
IC3301 normal?
Check IC3301
and its
peripheral parts.
Check front
speaker and
connection
cable.
Yes
Is output at pins (1)
and (7) of IC1902,
IC1903 and IC1904
normal?
Check IC1902,
IC1903, IC1904 and
their peripheral parts.
LC-13S1E
LC-15S1E
21
LC-13S1E
No sound (2/2)
Check all the settings microprocessor
’s adjust process menu.
Yes
No
No
No sound from SCART
No
SCART sound failure
Yes
No
Check IC1900 and its
peripheral parts.
Is output at pins (36) and (37) of
IC1900 normal?
Check IC1901 and its
peripheral parts.
Is output at pins (1) and (7) of
IC1901 normal?
Check their lines and their
peripheral parts.
Is input at pins (53) and (54) of
IC1900 normal?
Check IC1900 and its
peripheral parts.
Is output at pins (27) and (28) of
IC1900 normal?
LC-15S1E
TROUBLE SHOOTING TABLE (Continued)
22
LC-13S1E
D
N
R
S
R
—
—
V
LC-15S1E
BLOCK DIAGRAM
ANTENNA
H
SC3902 SCART
(AV1)
AUDIO IN
G
F
J5000
E
AUDIO OUT
VIDEO OUT
SDA/RXD
SCL/TXD
VIDEO IN
SC_R/G/B
S
(AV2) INPUT
VIDEOJ5001
(AV2) INPUT
AUDIO
(AV2) INPUT
2
I
C/UART
SY
V1_V
V1.L/R
TV_V
TUNER
SY
2
I
C
SC_L/RO
TV/AV
SELECTOR
IC802
CHROMA
SELECTOR
SC
IC805
SIF1
AI_L/R
AUDIO AMP
IC1901
AMP
IC803(1/2)
ANA_IN1+
SC2_IN_L/R
SC1_OUT_L/R
SC1_IN_L/R
CVBS/SY_IN
AMP
IC803(1/2)
R/G/B_IN
SC_IN
MSP
IC1900
VPC
IC801
VOUT
SYNC SEP
IC804
I
UART
CSYNC
2
C
DACM_L/R
DACA_L/R
SC2_OUT_L/R
2
PROM
E
IC2009
2
I
C
2
C
I
MICON
IC2001
AU
I
VPC_
SY
CONT
RE
L_E
Q3707
IC3702
Q3708
+3.3V
+9V
+8V
+5V
+1.8V
+3.3V
+3.3V
+32V
—11V
Q3705
+23V
+17V
VOLTAGE
CONVERTER
IC705
REG IC704
REG IC710
+5
+3.
+2.
REG IC2004
J3300
D
DC12V
REG IC2003
INPUT
VCC
REG IC706
C
DC/DC
SIGVCC
VCC
CONVERTER
T3701
B
PWM IC3701
INV+B
A
KEY
Q3703 REG IC702 REG IC709
+5V
+3.4V
+34V
Q3709
REG IC708
REG IC806
REG IC707
B12V1A
24
87109654321
Loading...
