LC-13E1U
LC-15E1U

LIQUID CRYSTAL TELEVISION

ENGLISH

OPERATION MANUAL

IMPORTANT:
To aid reporting in case of loss or theft, please
record the TV’s model and serial numbers in the
space provided. The numbers are located at the
rear of the TV.

IMPORTANT INFORMATION

ENGLISH

Model No.:

Serial No.:

U.S.A. ONLY

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO

NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

The lightning flash with arrow­head symbol, within an equilat-

CAUTION

RISK OF ELECTRIC SHOCK.
DO NOT OPEN.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

eral triangle, is intended to alert
the user to the presence of
uninsulated “dangerous voltage”
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.

The exclamation point within a
triangle is intended to alert the
user to the presence of impor­tant operating and maintenance
(servicing) instructions in the
literature accompanying the
product.

IMPORTANT INFORMATION

WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment

not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

U.S.A. ONLY

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF

PLUG TO WIDE SLOT, FULLY INSERT.

“Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40
of the National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”

This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury.
Disposal of these materials may be regulated due to environmental considerations. For disposal or
recycling information, please contact your local authorities or the Electronic Industries Alliance:
www.eia.org

2

DEAR SHARP CUSTOMER

Thank you for your purchase of the Sharp LCD Color TV product. To ensure safety and
many years of trouble-free operation of your product, please read the Safety Precau­tions carefully before using this product.

IMPORTANT SAFETY PRECAUTIONS

Electricity is used to perform many useful functions, but it can also cause personal injuries and property
damage if improperly handled. This product has been engineered and manufactured with the highest
priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent
potential danger, please observe the following instructions when installing, operating and cleaning the
product. To ensure your safety and prolong the service life of your LCD color TV product, please read
the following precautions carefully before using the product.

■ Read instructions—All operating instructions must be read and understood before the product is
operated.

■ Keep this manual in a safe place—These safety and operating instructions must be kept in a
safe place for future reference.

■ Observe warnings—All warnings on the product and in the instructions must be observed
closely.

■ Follow instructions—All operating instructions must be followed.

■ Attachments—Do not use attachments not recommended by the manufacturer. Use of inad-

equate attachments can result in accidents.

■ Power source—This product must operate on a power source specified on the specification
label. If you are not sure of the type of power supply used in your home, consult your dealer or
local power company. For units designed to operate on batteries or another power source, refer
to the operating instructions.

■ Power cord protection—The power cords must be routed properly to prevent people from
stepping on them or objects from resting on them. Check the cords at the plugs and product.

■ If the AC adapter is misplaced or needs to be replaced, obtain the same type of adapter from a
SHARP service center or your dealer.

■ Overloading—Do not overload AC outlets or extension cords.
Overloading can cause fire or electric shock.

■ Entering of objects and liquids—Never insert an object into the product through vents or open­ings. High voltage flows in the product, and inserting an object can cause electric shock and/or
short internal parts. For the same reason, do not spill water or liquid on the product.

■ Servicing—Do not attempt to service the product yourself. Removing covers can expose you to
high voltage and other dangerous conditions. Request a qualified service person to perform
servicing.

■ Repair—If any of the following conditions occurs, unplug the power cord from the AC outlet, and
request a qualified service person to perform repairs.
a.When the power cord or plug is damaged.
b.When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d.When the product does not operate properly as described in the operating instructions.

Do not touch the controls other than those described in the operating instructions. Improper

adjustment of controls not described in the instructions can cause damage, which often

requires extensive adjustment work by a qualified technician.
e.When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product

indicates that the product needs servicing.

■ Replacement parts—In case the product needs replacement parts, make sure that the service
person uses replacement parts specified by the manufacturer, or those with the same character­istics and performance as the original parts. Use of unauthorized parts can result in fire, electric
shock and/or other danger.

■ Safety checks—Upon completion of service or repair work, request the service technician to
perform safety checks to ensure that the product is in proper operating condition.

■ Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the
product according to the method recommended by the manufacturer.

■ Polarization—This AC adapter may be equipped with a polarized alternating current line plug (a
plug having one blade wider than the other). This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.

3

IMPORTANT SAFETY PRECAUTIONS (Continued)

■ Cleaning—Unplug the power cord from the AC outlet before
cleaning the product. Use a damp cloth to clean the product.
Do not use liquid cleaners or aerosol cleaners.

■ Water and moisture—Do not use the product near water,
such as bathtub, washbasin, kitchen sink and laundry tub,
swimming pool and in a wet basement.

■ Stand—Do not place the product on an unstable cart, stand,
tripod or table. Placing the product on an unstable base can
cause the product to fall, resulting in serious personal
injuries as well as damage to the product. Use only a cart,
stand, tripod, bracket or table recommended by the manu­facturer or sold with the product. When mounting the product
on a wall, be sure to follow the manufacturer’s instructions.
Use only the mounting hardware recommended by the
manufacturer.

■ When relocating the product placed on a cart, it must be
moved with utmost care. Sudden stops, excessive force and
uneven floor surface can cause the product to fall from the
cart.

■ Ventilation—The vents and other openings in the cabinet are
designed for ventilation. Do not cover or block these vents
and openings since insufficient ventilation can cause over­heating and/or shorten the life of the product. Do not place
the product on a bed, sofa, rug or other similar surface,
since they can block ventilation openings. This product is not
designed for built-in installation; do not place the product in
an enclosed place such as a bookcase or rack, unless
proper ventilation is provided or the manufacturer’s instruc­tions are followed.

■ The LCD panel used in this product is made of glass.
Therefore, it can break when the product is dropped or
applied with impact. Be careful not to be injured by broken
glass pieces in case the LCD panel breaks.

■ Heat sources—Keep the product away from heat sources
such as radiators, heaters, stoves and other heat-generating
products (including amplifiers).

■ The LCD panel is a very high technology product with 921,600 thin film transistors, giving you fine
picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red.
Please note that this does not affect the performance of your product.

4

IMPORTANT SAFETY PRECAUTIONS (Continued)

(

)

■ If an outside antenna is connected to the television equipment, be sure the antenna system is
grounded so as to provide some protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code provides information with respect to proper grounding
of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit,
size of grounding conductors, Iocation of antenna-discharge unit, connection to grounding elec­trodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

ANTENNA
LEAD IN
WIRE

GROUND
CLAMP

ANTENNA

ELECTRIC
SERVICE
EQUIPMENT

NEC—NATIONAL ELECTRICAL CODE

GROUND CLAMPS
POWER SERVICE GROUNDING

ELECTRODE SYSTEM

NEC ART 250, PART H

DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

■ For added protection for this television equipment during a
lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet and
disconnect the antenna. This will prevent damage to the
equipment due to lightning and power-line surges.

■ An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power
lines or circuits as contact with them might be fatal.

5

CONTENTS

DEAR SHARP CUSTOMER .............................................................................................................3

IMPORTANT SAFETY PRECAUTIONS ....................................................................................... 3-5

SUPPLIED ACCESSORIES ............................................................................................................. 7

PREPARATION ............................................................................................................................ 8-10

Using the Remote Control ......................................................................................................... 8

Batteries for the Remote Control .............................................................................................. 8

Power Connection ...................................................................................................................... 9

Antenna Connection .............................................................................................................9, 10

FRONT AND REAR CONTROL OPTIONS ............................................................................. 11-13

Removing the Back Cover ....................................................................................................... 13

Listening with Headphones ..................................................................................................... 13

EZ SETUP ....................................................................................................................................... 14

EZ SETUP during the First Power On .................................................................................... 14

REMOTE CONTROL ...................................................................................................................... 15

BASIC OPERATION ................................................................................................................. 15-18

Turning on POWER................................................................................................................... 16

Switching TV/VIDEO [AV1/AV2/COMPONENT/TV] Modes ................................................... 16

Sound Volume ........................................................................................................................... 17

ON/OFF Standby ....................................................................................................................... 17

Changing the Channels ............................................................................................................ 18

SELECTING MENU ITEMS ............................................................................................................19

Selecting Menu Items ............................................................................................................... 19

ADJUSTMENT .......................................................................................................................... 20-37

Adjusting the SLEEP TIMER Settings ....................................................................................20

Adjusting the BRIGHTNESS Settings ..................................................................................... 21

Adjusting the PICTURE FLIP Settings ................................................................................... 22

Adjusting the LANGUAGE Settings ........................................................................................ 23

Adjusting the VIDEO ADJUST Settings ........................................................................... 24, 25

Adjusting the PRESET Settings .............................................................................................. 26

SET UP .................................................................................................................................27, 28

Adjusting the BLUE SCREEN Settings .................................................................................. 29

Adjusting the CLOSED CAPTION Settings ...................................................................... 30, 31

Adjusting the V-CHIP Settings .......................................................................................... 32-37

CONNECTING WITH EXTERNAL DEVICES .......................................................................... 38-40

How to Fix the Cables .............................................................................................................. 40

TROUBLESHOOTING ..............................................................................................................41, 42

SPECIFICATIONS........................................................................................................................... 43

DIMENSIONAL DRAWINGS ....................................................................................................44, 45

Page

6

SUPPLIED ACCESSORIES

Make sure the following accessories are provided with the product.

Remote Control

RRMCGA077WJSA (LC-13/15E1U)
RRMCGA077WJSB (LC-13/15E1UB)
RRMCGA077WJSC (LC-13/15E1UW)

Antenna Cable

“AAA” size (UM/SUM-4) Dry Battery (×2)

UBATU0038CEZZ

AC Cord

QCNWG0003CEPA

AC Adapter

UADP-0212CEZZ

UADP-A009WJPZ

QACCD3097CEPA

Operation Manual

UBATU0026GEZZ

TINS-A156WJN1

Cable Clamp

LHLDW0109CESA

(LC-13/15E1U, LC-13/15E1UW)

LHLDW0109CESB

(LC-13/15E1UB)

7

PREPARATION

Using the Remote Control

■ Use the remote control by pointing it towards the remote sensor window
on the main unit. Objects between the remote control and sensor
window may prevent proper operation.

Cautions regarding use of remote control

■ Do not expose the remote control to shock.
In addition, do not expose the remote control to liquid, and do not place
in an area with high humidity.

■ Do not install or place the remote control under direct sunlight. The heat
may cause deformation of the unit.

■ The remote control may not work properly if the remote sensor window
of the main unit is under direct sunlight or strong lighting. In such case,
change the angle of the lighting or LCD TV set, or operate the remote
control closer to the remote sensor window.

Batteries for the Remote Control

Before using the LCD TV set for the first time, install two (“AAA” size, UM/SUM-4) batteries (supplied).
When the batteries become depleted and the remote control fails to operate, replace the batteries with
new (“AAA” size, UM/SUM-4) batteries.

SLEEP indicator

POWER indicator
Remote Sensor

Window

1 Open the battery

cover.

■ Slide the cover while

pressing the (b) part.

Caution!

2 Insert two (“AAA” size, UM/

SUM-4) batteries.

–

+

+

–

■ Position the positive and
negative ends of the batteries
as indicated in the compart­ment.

3 Close the battery

cover.

■ Engage the claw on the
cover into the battery
housing and slide shut.

Cautions regarding batteries

Improper use of batteries can result in chemical leakage and/or explosion. Be sure to follow the instruc­tions below.

• Place batteries with their terminals corresponding to the (+) and (–) indications.

• Different types of batteries have different characteristics. Do not mix batteries of different types.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new

battery and/or cause the old battery to leak chemicals.

• Remove batteries when they become weak.
Chemicals that leak from batteries can cause a rash. If chemical leakage is found, wipe with a
cloth.

• The batteries supplied with the product may have a shorter life expectancy due to storage conditions.

• If the remote control will not be used for an extended period of time, remove the batteries from the

remote control.

8

PREPARATION (Continued)

Power Connection

ANT.

POWER

INPUT
DC12V

EO

ID

V

-IN 1

V

A
L

IO
D
U

A

R

EO

ID

-V

S

AD

HE

E

ON

O

E

ID

V

AV-IN 2/OUT

L

IO

D

U

A

R

T

N
E
N

O

P

M

O

C

Y

B

P

R

P

L

O
I

D

U

A

R

PH

T.

AN

R

E

W

PO

T
U
P

IN

V
12

C

D

Household power outlet

AC adapter

DC input terminal

(DC 12V)

AC cord

A

• Use a commercially available AC plug adapter, if necessary, depending on the design of the wall outlet.

• Always turn the MAIN POWER switch of the LCD TV set to off when connecting the AC adapter.

• Always unplug the AC adapter from the product and power outlet when not using for a long period of time.

Antenna Connection

CABLE TV (CATV) CONNECTION

• A 75-ohm coaxial cable connector is built into the set for easy hookup. When connecting the 75­ohm coaxial cable to the set, screw the 75-ohm cable to the ANT. terminal.

• Some cable TV companies offer “premium pay channels”. Since the signals of these premium pay
channels are scrambled, a cable TV converter/descrambler is generally provided to the subscriber
by the cable TV company. This converter/descrambler is necessary for normal viewing of the
scrambled channels. (Set your TV to channel 3 or 4, typically one of these channels is used. If this
is unknown, consult your cable TV company.) For more specific instructions on installing cable TV,
consult your cable TV company. One possible method of utilizing the converter/descrambler
provided by your cable TV company is explained below.

Please note: An RF switch provided with two inputs (A and B) is required (not supplied).

“A” position on the RF switch (not supplied) : You can view all unscrambled channels by using the

TV’s channel keys.

“B” position on the RF switch (not supplied) : You can view the scrambled channels via the converter/

descrambler by using the converter’s channel keys.

RF switch (not supplied)

OUT

IN

Cable TV converter/

descrambler

(not supplied)

A

• Consult your SHARP Dealer or Service Center for the type of splitter, RF switch or combiner that might be

required.

Two-set
signal
splitter
(not
supplied)

Cable TV Line

9

PREPARATION (Continued)

Antenna Connection (Continued)

ANTENNAS

• The antenna requirements for good color television reception are more important than those for black & white
television reception. For this reason, a good quality outdoor antenna is strongly recommended.
The following is a brief explanation of the type of connections that are provided with the various antenna
systems.

1. A 75-ohm system is generally a round cable with F-type
connector that can easily be attached to a terminal without
tools (not supplied).

75-ohm coaxial cable (round)

2. A 300-ohm system is a flat “twin-lead” cable that can be
attached to a 75-ohm terminal through a 300-75-ohm
adapter (not supplied).

300-ohm twin-lead cable (flat)

OUTDOOR ANTENNA CONNECTION

• Use one of the following two diagrams if you connect an outdoor antenna.
A: Using a VHF/UHF combination outdoor antenna.
B: Using separate VHF and/or UHF outdoor antennas.

• Connect the outdoor antenna cable lead-in to the ANT. terminal on the rear of the TV set.

A. Combination VHF/UHF Antenna

VHF/UHF

antenna

300-ohm
twin-lead

VIDEO

AV-IN 1

L

AUDIO

R

S-VIDEO

HEAD

O
E

ID

V

T
U

/O

2

IN

­V

A

L

IO
D
U

A

R

T
N
E

N
O
P

M
O
C

Y

B

P

R

P

L
IO

D
U
A

R

PHONE

ANT.

POWER

INPUT

DC12V

ANT.

POWER

INPUT
DC12V

Antenna cable (supplied)

Antenna input

terminal

300/75-ohm

(not supplied)

Combiner

(not supplied)

OUT IN

F-type connector

adapter

VHF/UHF

antenna

or

75-ohm

coaxial cable

B. Separate VHF and/or

UHF Antennas

UHF

antenna

300-ohm
twin-lead

300-ohm
twin-lead

75-ohm
coaxial cable

VHF

antenna

or

10

FRONT AND REAR CONTROL OPTIONS

Main unit (front view)

Upper control panel

VOL (–)/(+)
CH ( )/( )

MENU
TV/VIDEO

MAIN POWER

CHVOL

MENU

MAIN POWERTV/VIDEO

The screen can be
adjusted backwards to an
angle between 12
degrees and 35 degrees.
The screen cannot be set
up straight. When
changing the angle, make
sure to hold the stand and
adjust the screen to the
best viewable angle.

Adjustable
range

Speaker

Remote sensor window

SLEEP indicator

The SLEEP indicator lights up red when
the SLEEP TIMER is set to on.

POWER indicator

A green indicator lights when the power is on and a red indicator lights when in the
standby mode (the indicator will not light when the main power is off).

A

• TV/VIDEO, CH ( )/( ), VOL (–)/(+) and MENU on the main unit have the same functions as the same buttons on
the remote control. Basically, this operation manual provides a description based on operation with the remote
control.

• The outer dimensions and placement of buttons, etc. may slightly differ between the LC-13E1U and LC-15E1U.
However, the basic operations are the same.

11

FRONT AND REAR CONTROL OPTIONS (Continued)

Main unit (rear view)

VIDEO

AV-IN2/OUT

AUDIO

COMPONENT

AUDIO

VIDEO

L

R

Y

B

P

R

P

L

R

AUDIO (L)
AUDIO (R)
Y

PB

R

P
AUDIO (L)
AUDIO (R)

AV-IN2/OUT

COMPONENT

Carrying handle

O

E

ID

V

1

-IN
V

A
L
IO

D

U

A

R

O

E

ID

-V

S

D
A

E

H

E

N

O

H

O
E

D
I
V

AV-IN 2/OUT

L

IO
D
U

A

R

T
N
E

N
O
P

M

O

C

Y

B

P

R

P

L

O

I
D

U

A

R

P

.
T

N

A

R

E

W

O

P

T

U

P

IN

V

2

1

C

D

12

AV-IN1

AUDIO (L)

AUDIO (R)

S-VIDEO

HEADPHONE

Antenna terminal

POWER INPUT

(DC 12V)

VIDEO

VIDEO

L

AUDIO

R

S-VIDEO

HEAD

PHONE

ANT.

POWER

INPUT
DC12V

AV-IN1

FRONT AND REAR CONTROL OPTIONS (Continued)

Removing the Back Cover

■ Before connecting a connection cord into the rear terminal, remove the
back cover. Push in the tab and pull out the back cover carefully.

O

E
D
I

V

1

N

-I
V
A

L

IO

D
U

A

R

O

E
D
I
V

-

■ To mount the cover, insert the 2 hooks on the bottom of the cover
into the cabinet and press on the upper part of the back cover until
the tab locks in place with a click.

O
E
D

I
V

T

U
/O
2

N

-I
V
A

L

O
I

D
U
A

R

T

N
E
N

O

P
M
O
C

Y

B

P

R

P

L

IO
D
U

A

R

Listening with Headphones

■ Plug the headphone mini-plug into the HEADPHONE jack located on the rear of the TV set.

S

D

A
E
H

E
N
O

H

P

.
T

N
A

R
E

W
O
P

T
U
P

IN

V
2
1

C
D

▼ On-screen display

1

c Rear terminal

VOLUME

60

O

E

ID

V

IN

­V
A

L
IO

D
U

A

R

O

E

ID

V

-

S

D

A

E

H

E

N

O
H
P

.
T

N
A

R
E

W

O

P

T
U
P

IN

V
2
1

C

D

Headphones

A

• Headphones are not included in the supplied accessories.

• No sound will be heard from the main unit speakers when a headphone mini-plug is connected into the

HEADPHONE jack.

13

EZ SETUP

EZ SETUP during the First Power On

Control section of main unit

MAIN POWER

MENU

MAIN POWER

TV/VIDEO

CHVOL

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

MENU/

FLASHBACK

CHVOL

a/b/c/d

■ When you turn on the TV for the first time, it will automatically
memorize the broadcasting channels.
Please perform the following instructions before you press MAIN
POWER.
(1) Insert the batteries into the remote control. (See page 8.)
(2) Connect the antenna cable to the TV set. (See page 10.)
(3) Connect the AC adapter to the DC input terminal of the product

and plug in the AC cord to the wall outlet. (See page 9.)

1 Press MAIN POWER, located on

the upper side of the main unit, to
turn on the TV. The SELECT
LANGUAGE mode will be dis-

SELECT LANGUAGE
ENGLI SH
ESPAÑOL
FRANCAI S

played.

2 Press a/b to select “ENGLISH”,

“ESPAÑOL (SPANISH)” or
“FRANCAIS (FRENCH)”.

SELECT : ENTER: EXIT:

3 Press c/d to access EZ SETUP

mode.

4 Press d.

The tuner will automatically search
for the broadcasting and cable TV
channels. (The CH No. will
automatically increase when it
appears.)

If you want to stop the EZ SETUP
process once it has started, press
c and it will be canceled. If you
want to SET UP again, please refer
to pages 27 and 28 on SET UP.

CONNECT ANTENNA OR CA BL E.

START EZ SETUP?

YES : NO : EXIT:

MENU

MENU

To cancel EZ SETUP

Press c.

PLEASE WAIT

AUTO PROGRA

STOP:

MM

ING

5 Once EZ SETUP is completed, the

lowest channel number memorized
will be displayed.

A

• Do not let the EZ SETUP screen display unattended for a long time.

• If EZ SETUP does not memorize all the channels in your region, please refer to pages 27 and 28 for more

information on manually memorizing the channels using CHANNEL SETTING.

• It may be difficult to PRESET when the broadcasting signals are weak, the channel cycle frequency is incorrect or
the frequency jamming is occurring around the area. Please refer to pages 27 and 28 for more information on
manually memorizing channels using CHANNEL SETTING.

14

2

REMOTE CONTROL

POWER (p. 17)

DISPLAY*

SLEEP (p. 20)

BRIGHT (p. 21)

MUTE (p. 17)

VOL(+)/(–) (p. 17)

CH ( )/( )

(p. 18)

MTS*3 (p. 17)

POWER

1

SLEEP PIC. FLIP

DISPLAY

PIC. FLIP (p. 22)

MENU/
a/b/c/d (Cursor control)

MENU

(p. 19)

CC (CLOSED CAPTION)

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

(pp. 30, 31)

TV/VIDEO (p. 16)

FLASHBACK*

2

Channel Select (p. 18)

*1Displays the receiving chan-

nel for 10 seconds.

*2Returns to the previous

channel.

*3Selects audio settings.

BASIC OPERATION

This product is factory set to comply with the TV broadcasting system in the United States. For Brazil,
Argentina and Uruguay, set the color system according to the country before using this product by
following the table below.
The VIDEO INPUT mode is compatible with color systems worldwide and is automatically set.

The World Multi Auto System

Country

U.S.A.

Canada, Mexico, Color: NTSC NTSC (N358) World Multi
Latin America TV ch: US ch US ch Auto System

Brazil

Argentina, Color: PAL-N NTSC (N358) World Multi Set color system to
Uruguay TV ch: US ch US ch Auto System PAL-N (see page 25)

TV broadcasting
system

Color: NTSC NTSC (N358) World Multi Not required

TV ch: US ch US ch Auto System or N/A

Color: PAL-M NTSC (N358) World Multi Set color system to
TV ch: US ch US ch Auto System PAL-M (see page 25)

Factory setting of color system User setting

TV Video TV

Not required or N/A

is compatible with all color
systems indicated below.

1 N358
2 N443
3 PAL
4 PAL-M
5 PAL-N
6 SECAM
7 PAL-60

15

BASIC OPERATION (Continued)

Turning on POWER

Control section of main unit

MAIN POWER

1 Press MAIN POWER, located on

the upper side of the main unit, to

▼ On-screen display

on.

MENU

MAIN POWER

TV/VIDEO

CHVOL

2 The POWER indicator instantane-

ously changes from red to green
and the main unit is turned on.

A

• The input mode indication disappears after
several seconds.

Notes:

POWER indicator

Switching TV/VIDEO [AV1/AV2/COMPONENT/TV] Modes

POWER

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

TV/VIDEO

1 Turn on the power of the con-

nected video equipment.

2 Press TV/VIDEO and select the

applicable input source. The
screen displays AV1, AV2, COM­PONENT or TV mode each time
TV/VIDEO is pressed.

A

• The AV input mode indication remains

for 3 seconds.

• AV1: Video equipment connected to the

AV1 input terminals.
An S-Video input terminal is
additionally provided for the AV1
input. If both the S-Video terminal
and normal video terminals are
connected with cables, the S­Video input terminal takes priority.

• AV2: AV2 mode is used to adjust the

preset settings and IN or OUT
can be selected. AV2 indication is
not displayed when OUT is
selected. (For details on setting
AV2-IN/OUT, see page 26.)

• COMPONENT:

Video equipment connected to the
COMPONENT input terminals.

AV1 mode

AV2 mode

COMPONENT mode

TV mode

STEREO<ON A I R
SAP

M

ONO

2

AV1

AV2

COMPONE NT

12

16

BASIC OPERATION (Continued)

Sound Volume

POWER

R

E

W

PO

SLEEP PIC. FLIP

MUTE

DISPLAY

MENU

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MUTE

VOL
(+)/(–)

MTS

1 Press VOL (+) to increase the sound

volume. The segment of the indicator
increases.

2 Press VOL (–) to decrease the sound

volume. The segment of the indicator
decreases.

To mute the sound

1 Press MUTE to temporarily turn off

the sound.
The MUTE mark
4 seconds.

is displayed for

2 Press MUTE or VOL (+)/(–) to turn

the sound back to the previous level.
The mute function is automatically
turned off when any of the following
buttons are pressed: POWER,

VOL (+)/(–) or MTS.

To select MTS (Multi ch TV Sound)

1 Press MTS to display the MTS

screen.

2 Press MTS to select the MTS

settings.
STEREO: stereo audio
SAP: second audio program
MONO: monophonic audio

A

•<ON AIR appears when a STEREO or SAP

broadcast is being aired.

VOLUME

50

VOLUME

10

VOLUME

30

STEREO<ON A I R
SAP
M

ONO

2

ON/OFF Standby

ER

W

PO

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

POWER

To turn off the LCD TV

Press POWER on the remote control.
The POWER indicator will turn red.

To turn the LCD TV back on

Press POWER again.
The POWER indicator will turn green.

17

BASIC OPERATION (Continued)

Changing the Channels

Changing channels by using Channel Select on the remote control

• This LCD TV set allows you to select up to 125 channels (1 to 125). To select a channel, enter a 2­or 3-digit number.

R

E

W

PO

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

CH

)/( )

(

Channel
Select

To select a 1- or 2-digit channel
number (e.g., Channel 5):

Complete the following procedure
within 4 seconds.

1 Press the button.
2 Press the

A

• When selecting a 1-digit channel number,

do not fail to press the button first.

To select a 3-digit channel number
(e.g., Channel 115):

Complete the following procedure
within 4 seconds.

5

button.

1 Press the button.
2 Press the button.
3 Press the

A

• The 3-digit channel number can be
selected only when the receiving mode is
set to CABLE in CH-SETTING. (For details
on setting the receiving mode, see page

27.)

5

button.

0 –

5

1 ––

11–

115

Changing channels with CH ( )/( ) on the remote control

Air Press CH ( ) and the channels change in the order shown below:

2 → 3 → . . . → 68 → 69 → 2 → 3 → . . .
Press CH (

) and the channels change in the order shown below:

3 → 2 → 69 → 68 → . . . → 3 → 2 → . . .

Cable Press CH (

) and the channels change in the order shown below:
1 → 2 → 3 → . . . → 125 →1 → 2 → 3 → . . .
Press CH (

) and the channels change in the order shown below:
3 → 2 → 1 → 125 → . . . → 3 → 2 → 1 → . . .

18

SELECTING MENU ITEMS

Selecting Menu Items

• This LCD TV set allows you to adjust the various settings using the menu screen. Select the desired
menu item by following the steps below and then refer to the indicated page for details.

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

MENU/

FLASHBACK

CHVOL

a/b/c/d

* The screen indications shown above are larger than actual for easy reading.

screen.

2 Press a/b to select the desired

menu item.

3 Press c/d to enter.
4 Press MENU to exit.

M

ENU

SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

A

• The TINT display only appears when
the color system is set to N358 or
N443.

• The displayed items differ depending
on the setting conditions.

• The selected item changes to yellow.

• Items in magenta cannot be se-

lected.

• TV mode
This product is factory set to comply
with the color system in the United
States (NTSC-N358). For Brazil
(PAL-M), Argentina (PAL-N) and
Uruguay (PAL-N), set the color
system before using this product.

• COLOR SYSTEM
When you set COLOR SYSTEM to
AUTO, the AUTO mode automati­cally detects the receiving signal
system and adjusts the reception
system of the TV set.
When the picture or sound is not
stable, set a specific COLOR
SYSTEM (not AUTO). The picture
and sound may be improved.

• To return to the previous screen,
select RETURN.

• You can adjust some settings with
the special buttons: CC, PIC. FLIP,
SLEEP and BRIGHT (see pages 20,
21, 22 and 30).

MENU

1 Press MENU to display the MENU

(Page 20)

SLEEP TIMER

RETURN

M

ER [––– REMAIN]

SLEEP TI

SELECT : ADJU ST : EXIT:

(Pages 24, 25)

V IDEO ADJUST ( TV )
RETURN
PICTURE [ 30]

TINT

COLOR

BLACK LEVEL

SHARPNESS

COLOR SYSTEM

RESET

SELECT : ENTER: EXIT:

[ 0]
[ 0]
[ 0]
[ 0]
[ N358]

(Pages 21, 22 and 26)

PRESET
RETURN
BRI GHTNESS [ BRI GHT ]

W

ER OFF

ADJ UST :

[OFF ]

M

AL ]

[NOR
[IN ]

AUTO PO

PICTURE FLIP

AV2 IN/OUT

SELECT : EXIT:

(Page 31)

CLOSED CAPT ION
RETURN

[OFF]

CC/ TEXT

SELECT : EXIT:

ADJ UST :

(Pages 34–37)

INPUT SECRE T NO.

– – – –

EXIT:

(Pages 23, 27–29)

SET UP
RETURN

BLUE SCREEN [OFF]
LANGUAGE
CH–SE TT ING

SELECT : EXIT:

ADJ UST :

MENU

MENU

MENU

MENU

MENU

MENU

19

ADJUSTMENT

Adjusting the SLEEP TIMER Settings

You can set the SLEEP TIMER to automatically turn off the TV.

Directly setting the SLEEP TIMER

R

E

W

PO

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

ER

W

PO

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

SLEEP

MENU/
a/b/c/d

1 Press SLEEP to display the SLEEP

TIMER screen.

2 Press SLEEP to set the sleep timer

(in minutes).

The time can be set in increments
of 30 minutes and in the range
between 30 and 120 minutes.

The SLEEP TIMER is turned off
when --- is displayed.

A

• The SLEEP TIMER screen automatically
disappears in 3 seconds.

Setting the SLEEP TIMER on the
MENU screen

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

SLEEP TIMER.

3 Press c/d to display the SLEEP

TIMER screen.

–– – REMA I N

60 REMAIN

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

MENU

4 Press c/d to set the sleep timer

(in minutes).

SLEEP T IMER
RETURN

M

ER [––– REMAIN]

SLEEP T I

The time can be set in increments
of 30 minutes and in the range
between 30 and 120 minutes.

The SLEEP TIMER is turned off
when --- is displayed.

SELECT : ADJ UST : EXIT:

5 Press MENU to return to the main

screen.

A

• When you set the SLEEP TIMER, the SLEEP indicator lights.

• After you set the SLEEP TIMER, if you turn off the MAIN POWER on the TV set or press the POWER button on
the remote control, the SLEEP TIMER setting is cancelled and the SLEEP indicator goes out.

• 5 minutes before the SLEEP TIMER turns off the TV, 5 REMAIN is displayed on the screen for 4 seconds. The
SLEEP TIMER counts down and shows a similar 4-second display for each remaining minute until the timer turns
off the TV.

20

MENU

ADJUSTMENT (Continued)

Adjusting the BRIGHTNESS Settings

You can set the brightness of the screen.

Directly setting the BRIGHTNESS

ER

W

O

P

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

BRIGHT

MENU/
a/b/c/d

1 Press BRIGHT to display the

BRIGHTNESS screen.

2 Press BRIGHT to change the

setting.

BRIGHT NORMAL

DARK

A

• The BRIGHTNESS screen automatically
disappears in 3 seconds.

• [BRIGHT]: maximum brightness
[NORMAL]: 60% brightness (suitable for
viewing in a well-lit area and saves
energy)
[DARK]: 10% brightness (sufficiently bright
when viewing in a dimly lit area)

Setting the BRIGHTNESS on the
MENU screen

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

PRESET.

3 Press c/d to enter.

BRI GHTNESS [ BR I GHT]

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

MENU

4 Press a/b to move the cursor to

BRIGHTNESS.

5 Press c/d to set the brightness.
6 Press MENU to return to the main

screen.

PRESET
RETURN
BR I GHTNE SS [ BRI GHT]
AUTO PO

W

ER OFF

ADJ UST :

[OFF ]
[NOR

M

AL ]

[IN ]

PICTURE FLIP
AV2 IN/OUT

SELECT : EXIT :

MENU

21

ADJUSTMENT (Continued)

Adjusting the PICTURE FLIP Settings

You can set the orientation of the picture.

Directly setting the PICTURE FLIP

R

E

W

O

P

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

PIC. FLIP

1 Press PIC. FLIP to display the

PICTURE FLIP screen.

2 Press PIC. FLIP to change the

setting.

MIRROR ROTATENORMAL

UPSIDE DOWN

A

• The PICTURE FLIP screen automatically
disappears in 3 seconds.

• [NORMAL]: normal image
[MIRROR]: mirror image
[ROTATE]: rotated image
[UPSIDE DOWN]: upside down image

ABC

P I CTURE F LI P [ NORMAL]

ABC

P I CTUR E FL I P [M I RROR]

P I CTURE F LI P [ ROTA TE ]

ABC

P IC TURE F LI P [ UPSI DE DOWN]

ABC

22

POWER

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

Setting the PICTURE FLIP on the
MENU screen

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

PRESET.

3 Press c/d to enter.

4 Press a/b to move the cursor to

PICTURE FLIP.

5 Press c/d to set the PICTURE

FLIP.

6 Press MENU to return to the main

screen.

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

PRESET
RE TURN
BR I GHTNE SS [ BRI GHT]
AUTO PO

W

ER OFF

ADJ UST :

[OFF ]

[NOR

M

AL ]

[IN ]

PICTURE FLIP
AV2 IN/ OUT

SELECT : EXIT :

MENU

MENU

ADJUSTMENT (Continued)

Adjusting the LANGUAGE Settings

The language for the On-Screen Display can be ENGLISH, SPANISH or FRENCH.

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

SET UP.

3 Press c/d to enter.

4 Press a/b to move the cursor to

LANGUAGE.

5 Press c/d to enter.

6 Press a/b to select the lan-

guage.

7 Press MENU to return to the main

screen.

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

SET UP
RETURN
BLUE SCREEN [OFF]

LANGUAGE

CH–SETT ING

SELECT : EXIT:

LANGUAGE
ENGLI SH
ESPAÑOL
FRANCAIS

ENTER:

MENU

MENU

MENU

SELECT : EXIT:

MENU

23

ADJUSTMENT (Continued)

Adjusting the VIDEO ADJUST Settings

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

VIDEO ADJUST.

3 Press c/d to enter.

4 Press a/b to move the cursor to

the desired item.

5 Press c/d to enter.

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

V IDEO ADJUST(TV)
RETURN
PICTURE [ 30]
TINT
COLOR
BLACK LEVEL
SHARPNESS
COLOR SYSTEM
RESET

SELECT : ENTER: EXIT:

[ 0]
[ 0]
[ 0]
[ 0]
[ N358]

MENU

MENU

MENU

6 Press c/d to change the setting.

A

• See page 25 for the settings.

7 Press MENU to return to the main

screen.

RETURN

P ICTURE

30

– +

SELECT : ADJ UST : EXIT:

MENU

24

ADJUSTMENT (Continued)

Adjusting the VIDEO ADJUST Settings (Continued)

TV mode

Selected item Press c Press d

PICTURE Decrease contrast Increase contrast

TINT Toward purple Toward green

COLOR Lower color intensity Higher color intensity

BLACK LEVEL Less brightness More brightness

SHARPNESS Soft picture Sharp picture

COLOR SYSTEM

AV mode

Selected item Press c Press d

PICTURE Decrease contrast Increase contrast

TINT Toward purple Toward green

COLOR Lower color intensity Higher color intensity

BLACK LEVEL Less brightness More brightness

SHARPNESS Soft picture Sharp picture

RED-BLUE Stronger red Stronger blue

GREEN Weaker green Stronger green

COLOR SYSTEM Press c/d to select the COLOR SYSTEM.

■ When the COMPONENT mode is selected:

A

• TINT is displayed only when N358 or N443 is selected.

• In BLUE SCREEN, VIDEO ADJUST settings displayed in magenta cannot be selected.

• Selecting RESET will return all settings to the factory settings. (See page 24.)

• TV mode

This product is factory set to comply with the color system in the United States (NTSC-N358). For Brazil (PAL­M), Argentina (PAL-N) or Uruguay (PAL-N), adjust the color system before using this product.

• COLOR SYSTEM
When you set COLOR SYSTEM to AUTO, the AUTO mode automatically detects the receiving signal system
and adjusts the reception system of the TV set.
When the picture or sound is not stable, set a specific COLOR SYSTEM (not AUTO). The picture and sound
may be improved.

25

ADJUSTMENT (Continued)

Adjusting the PRESET Settings

1 Press MENU to display the MENU

screen.

POWER

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

2 Press a/b to move the cursor to

PRESET.

3 Press c/d to enter.

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

MENU

MENU

4 Press a/b to move the cursor to

the desired item.

5 Press c/d to change the setting.

SELECT : ENTER: EXIT:

PRESET
RETURN
BR I GHTNE SS [ BRI GHT]
AUTO PO

W

ER OFF
PICTURE FLIP
AV2 IN/OUT

[OFF ]
[NOR

M

AL ]

[IN ]

6 Press MENU to return to the main

screen.

SELECT : EXIT :

ADJ UST :

Selected item Factory setting Setting options

BRIGHTNESS [BRIGHT] Maximum brightness [NORMAL] Brightness 60% → Suitable for viewing in a well-lit area.

[DARK] Brightness 10%

AUTO POWER OFF [OFF] [ON] The power of the LCD TV set is turned off when there is
(only TV mode) no signal for 5 minutes.

[OFF] This feature is inactive.

PICTURE FLIP [NORMAL] Normal image [MIRROR] Mirror image → To display mirror images for special uses.

orientation

Saves energy.

→ Sufficiently bright when

viewing in a dimly lit area.

ABC

ABC

[ROTATE] Rotated image

uses.

→ To display rotated images for special

ABC

MENU

[UPSIDE DOWN] Upside down image

down for special uses.

→ To display images upside

ABC

AV2 IN/OUT [IN] [OUT ] Line Output is selected, Output volume is fixed, Speaker

[OUT

output is available.

] Line Output is selected, Output volume is variable,

Speaker output is Mute.

26

ADJUSTMENT (Continued)

SET UP

■ CHANNEL SETTING

It is necessary to set the receiving mode to AIR or CABLE channels to receive locally broadcast TV
programs.

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

SET UP
RETURN
BLUE SCREEN [OFF]

LANGUAGE

CH–SETT ING

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

SET UP.

3 Press c/d to enter.

4 Press a/b to move the cursor to

CH-SETTING.

5 Press c/d to enter.

MENU

6 Press a/b to move the cursor to

AIR/CABLE.

7 Press c/d to enter.

8 Press a/b to move the cursor to

the desired mode.

9 Press MENU to return to the main

screen.

SELECT : EXIT:

CH–SETT ING
RETURN
AIR/ CABLE
CH SEARCH
CH

SELECT : ENTER: EXIT:

AIR/CABLE
AIR
CABLE

SELECT :

MEM

ENTER:

ORY

EXIT:

MENU

MENU

MENU

A

• Receivable channels of your TV set are:
AIR channels: CABLE channels:
VHF: 2 through 13. 1 (HRC and IRC mode only)
UHF: 14 through 69. 2 through 125 (STD, HRC and IRC)

27

ADJUSTMENT (Continued)

SET UP (Continued)

■ Saving broadcast TV channels in the memory

1 Press MENU to display the MENU

screen, press a/b to move the

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

cursor to SET UP, and press c/d
to enter.

2 Press a/b to move the cursor to

CH-SETTING, and press c/d to
enter.

3 Press a/b to move the cursor to

CH SEARCH, and press c/d to
enter.

CH–SETT ING

RETURN

AIR/ CABLE
CH SEARCH
CH

MEM

ORY

4 Press d. The tuner will search

through all available channels in
your area and add them to the
TV’s memory.

A

• To interrupt CH SEARCH, press c.
CH SEARCH will stop at the current
channel and will not add any higher
channels.

CH SEARCH

A IR 2

START: EXIT:

5 Press MENU to exit.

■ Adding weak or additional channels or erasing unwanted channels from TV memory

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

Channel
Select

1 Press MENU to display the MENU

screen, press a/b to move the
cursor to SET UP, and press c/d
to enter.

2 Press a/b to move the cursor to

CH-SETTING, and press c/d to
enter.

3 Press a/b to move the cursor to

CH MEMORY, and press c/d to
enter.

4 Use a/b or Channel Select to

select each desired channel to add
or erase.

5 Press d to add the channel to the

TV’s memory or press c to erase
the channel from the TV’s memory.

CH–SETT ING

RETURN

AIR/ CABLE
CH SEARCH
CH

MEM

ORY

CH MEMORY

A IR 2

TO ADD: EXIT:

d

to add channel 2
to the TV memory

c

to erase channel 2
from the TV memory

6 Press MENU to exit.

CH MEMORY

A IR 2

MENU

MENU

A

• If CH SEARCH is performed again, the previously memorized channels will be lost.

28

TO ERASE: EXIT:

MENU

ADJUSTMENT (Continued)

Adjusting the BLUE SCREEN Settings

■ BLUE SCREEN

Automatically turns the screen blue if a broadcast signal is not received.

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

SET UP.

3 Press c/d to enter.

4 Press a/b to move the cursor

to BLUE SCREEN.

5 Press c/d to select ON or OFF.
6 Press MENU to return to the main

screen.

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

SET UP
RETURN
BLUE SCREEN [OFF]

LANGUAGE

CH–SETT ING

SELECT : EXIT:

SET UP
RETURN
BLUE SCREEN [ON ]

LANGUAGE

CH–SETT ING

ADJ UST :

MENU

MENU

SELECT : EXIT:

ADJ UST :

A

• When received signals are weak or interfered with by some other signals, the BLUE SCREEN function may be
activated. To watch the TV under such conditions, set BLUE SCREEN to OFF.

• When the AV-1, AV-2 or COMPONENT input mode is selected, if no signal is being input, the BLUE SCREEN
function is activated.

MENU

29

ADJUSTMENT (Continued)

Adjusting the CLOSED CAPTION Settings

■ SETTING CLOSED CAPTION

• This TV set is equipped with an internal Closed Caption decoder. “Closed Caption” is

a system which allows conversations, narration, and sound effects in TV programs
and home videos to be viewed as captions on the TV screen (see the illustration).

• Not all programs and videos will offer closed captioning. Please look for the “ ”
symbol to ensure that captions will be shown.

• The Closed Caption broadcasts can be viewed in two modes: CAPTION and TEXT.
For each mode, two channels are available: CH1 and CH2.
The CAPTION mode shows subscripts of dialogs and commentaries of TV dramas
and news programs while allowing a clear view of the picture.
The TEXT mode displays various information over the picture (such as TV program
schedules and weather forecasts, etc.) that is independent of the TV programs.

Directly setting the CLOSED CAPTION

R

E

W

O

P

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

CC

MUTE

1 Press CC to display the CC/TEXT

screen.

2 Press CC to change the setting.

CC 1 CC 2OFF T1 T2

A

• CC1: CAPTION mode for CH1 data
CC2: CAPTION mode for CH2 data
T1: TEXT mode for CH1 data
T2: TEXT mode for CH2 data

CC/ TEXT [CC1]

A

• If a broadcast has CLOSED CAPTION and MUTE is pressed, the set enters CAPTION mode automatically.
Pressing MUTE again will return the set to its previous condition.

• Closed Caption may malfunction (white blocks, strange characters, etc.) if signal conditions are poor or if there are
problems at the broadcast source. This does not necessarily indicate a problem with your set.

• If any button is pressed to call up the On-Screen Display while viewing a Closed Caption broadcast, the closed
captions will disappear momentarily.

• If no TEXT broadcast is being received while viewing in the TEXT mode, the screen may become dark and blank
for some programs. Should this occur, switch the Closed Caption mode to OFF.

30

ADJUSTMENT (Continued)

Adjusting the CLOSED CAPTION Settings (Continued)

■ SETTING CLOSED CAPTION

Setting the CLOSED CAPTION on
the MENU screen

ER

W

PO

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

CLOSED CAPTION.

3 Press c/d to enter.
4 Press a/b to move the cursor to

CC/TEXT.

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

SELECT : ENTER: EXIT:

CLOSED CAPTION

RETURN

[OFF]

CC/TEXT

MENU

5 Press c/d to change the CLOSED

CAPTION setting.

CC 1 CC 2OFF T1 T2

6 Press MENU to return to the main

screen.

SELECT : EXIT :

CLOSED CAPTION

RETURN

CC/TEXT

ADJ UST :

[OFF]

MENU

31

ADJUSTMENT (Continued)

Adjusting the V-CHIP Settings

■ V-CHIP

• This function allows TV programs to be restricted and TV usage to be controlled based on FCC data. It prevents
children from watching violent or sexual scenes that may be harmful.

• Restriction of TV programs includes two ratings that contain information about the program: the MPAA rating and
the TV Parental Guidelines. The MPAA rating is restricted by age. TV Parental Guidelines are restricted by age
and content.

• Since a TV program may use either the MPAA rating or the TV Guidelines, both should be adjusted for complete
control.

[1] MPAA RATING

RATING

G GENERAL AUDIENCES. All ages admitted.
PG PARENTAL GUIDANCE SUGGESTED. Some material may not be suitable for children.

age

base

MPAA RATING (examples)

Example 1:

PG-13 in the age-based rating is
blocked, this will also automatically
block the higher ratings R, NC-17
and X.

PG-13 PARENTS STRONGLY CAUTIONED. Some material may be inappropriate for children under 13.
R RESTRICTED. Under 17 requires accompanying parent or adult guardian.
NC-17 NO ONE 17 AND UNDER ADMITTED.
X X is an older rating that is unified with NC-17 but may be encoded in the data of older movies.:

Example 2:

R in the age-based rating is
blocked, this will also automatically
block the higher ratings NC-17 and
X.

ote:

A

• The MPAA rating is only age-based.

32

ADJUSTMENT (Continued)

Adjusting the V-CHIP Settings (Continued)

[2] TV PARENTAL GUIDELINES

content base

⇐

RATING

TV-Y (All children)

TV-Y7 (Direct to Older Children) ✕

⇑

TV-G (General Audience) X

age

TV-PG (Parental Guidance

base

Suggested) xxx

⇓

TV-14 (Parents Strongly
Cautioned) X

TV-MA (Mature Audience Only) X ✕✕ ✕

: The content rating can be set, but this rating is not normally broadcast by TV stations.

✕ : The content rating can be set.

TV PARENTAL GUIDELINES (examples)

Example 1:

When TV-Y7 in the age-based rating is set to BLOCK, this will automatically block the higher ratings: TV-G, TV-PG, TV-14
and TV-MA. In addition, D, L, S, V and FV in CONTENT are automatically blocked unless you manually set BLOCK
CONTENT.

FV V S L D

(Fantasy (Violence) (Sexual (Adult (Sexually

Violence) Situation) Language) Suggestive

✕✕ ✕ ✕

✕✕ ✕ ✕

⇒

Dialog)

Example 2:

When no item in the age-based rating is blocked, D in the content-based rating will be automatically blocked.

A

• Age-based ratings can be modified by the content-based ratings, but only in the combinations indicated by an X in
the table above.

• Choosing a lower age-based rating blocks the higher age-based ratings regardless of content rating settings.

• If you set TV-Y and TV-Y7 to BLOCK, CONTENT will display all items.

33

ADJUSTMENT (Continued)

Adjusting the V-CHIP Settings (Continued)

■ SETTING V-CHIP

[1] MPAA RATING

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

Channel
Select

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor

to V-CHIP BLOCK, and press
c/d to enter.

3 INPUT SECRET NO. will display.

Input the 4-digit secret number by
using Channel Select.

A

• When you input the secret number
for the first time, press MENU to
register. Otherwise, continue to step

4.

4 Press c/d to move the cursor

to MPAA, and press c/d to
enter.

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

M

ENU
SLEEP T IMER
V IDEO ADJUST
PRESET
CLOSED CAPT I ON
V–CHIP BLOCK
SET UP

INPUT SECRET NO.

– – – –

V–CHIP BLOCK
RETURN
M

PAA

TV GUIDEL INES

STATUS

[OFF]

EXIT:

MENU

5 Press a/b to move the cursor

to PG, and then press c/d to
select BLOCK. If you set PG to
BLOCK, PG-13, R, NC-17 and X
are automatically blocked.

6 Press MENU to return to the

main screen.

A

• If you set G to BLOCK, all ratings are automatically blocked.

• If you set X to BLOCK, G, PG, PG-13, R and NC-17 are not blocked.

34

SELECT : ENTER: EXIT:

M

PAA
RETURN
G [ –––––]
PG [ BLOCK ]
PG– 13 [BLOCK]
R [BLOCK ]
NC–17 [BLOCK ]
X [ BLOCK ]

SELECT : ADJUST : EXIT:

MENU

MENU

ADJUSTMENT (Continued)

Parent Control (V-CHIP Operation Continued)

Adjusting the V-CHIP Settings (Continued)

[2] TV GUIDELINES

● Setting TV GUIDELINES

1 Repeat steps 1 to 3 of [1] MPAA

RATING. (See page 34.)

ER

POW

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

MENU/

FLASHBACK

CHVOL

a/b/c/d

● Setting BLOCK CONTENT

POWER

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

MENU/

FLASHBACK

CHVOL

a/b/c/d

2 Press a/b to move the cursor to

TV GUIDELINES.

3 Press c/d to enter.

4 Press a/b to move the cursor to

TV-Y7, and press c/d to select
BLOCK. If you set TV-Y7 to
BLOCK, TV-G, TV-PG, TV-14 and
TV-MA are automatically blocked.
In addition, D, L, S, V and FV in
CONTENT are automatically
blocked.

5 Press MENU to return to the main

screen.

1 Press a/b to move the cursor to

BLOCK CONTENT, and press
c/d to enter.

2 Press a/b to move the cursor to

the desired item, and press c/d
to select BLOCK or ----- (un­block).

V–CHIP BLOCK
RETURN
M

PAA

TV GUIDEL INES

STATUS

[OFF]

SELECT : ENTER: EXIT:

TV GUI DEL INES

RETURN

TV–Y [ –––––]
TV–Y7 [BLOCK]
TV–G [BLOCK ]
TV–PG [BLOCK]
TV– 14 [BLOCK]
TV–

M

A [BLOCK]

BLOCK CONT ENT

[D L S V FV ]

SELECT : ADJUST : EXIT:

TV GUI DEL INES

RETURN

TV–Y [ –––––]
TV–Y7 [–––––]
TV–G [ –––––]
TV–PG [ ––––– ]
TV– 14 [––––– ]
TV–

M

A [ –––––]

BLOCK CONT ENT

[ ]

SELECT : EXIT:

BLOCK CONTENT
RETURN
D [ –––––]

L [BLOCK]

S [ –––––]
V [ –––––]
FV [–––––]

ENTER:

MENU

MENU

MENU

SELECT : ADJUST : EXIT:

3 Press MENU to return to the main

screen.

A

• If you set TV-14 to BLOCK, TV-MA is automatically blocked. Contents D, L, S and V are automatically blocked by
X in the table on page 33.

MENU

35

ADJUSTMENT (Continued)

Adjusting the V-CHIP Settings (Continued)

[3] ACTIVATING V-CHIP BLOCK

● Setting STATUS

You can activate V-CHIP BLOCK after setting [1] MPAA RATING and/
or [2] TV GUIDELINES.

POWER

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU/
a/b/c/d

Channel
Select

1 Repeat steps 1 to 3 of [1] MPAA

RATING.

2 Press a/b to move the cursor to

STATUS.

3 Press c/d to set STATUS to ON.

A

• If STATUS is set to OFF, V-CHIP

V–CHIP BLOCK
RETURN
M

PAA

TV GUIDEL INES

STATUS

[ON]

SELECT : ENTER: EXIT:

BLOCK will not be activated.

4 Press MENU to return to the main

screen.

[4] CANCELING THE V-CHIP BLOCK SCREEN WHILE V-CHIP BLOCK IS ACTIVATED

1 V-CHIP HAS BEEN ACTIVATED

ER

W

O

P

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

MENU

appears if you watch a program
with the same Program Rating
data you configured.

A

• V-CHIP HAS BEEN ACTIVATED will
not be displayed if STATUS is not
configured to ON.

V–CHI P HAS BEEN ACT I VATED

TV–Y

2 Press MENU to display INPUT

SECRET NO.

Channel
Select

3 Input the 4-digit secret number by

using Channel Select; V-CHIP
BLOCK is temporarily canceled. If
you input an incorrect secret
number, SECRET NO. IS
INCORRECT is displayed. In this
case, input the correct secret
number.

INPUT SECRET NO.

– – – –

EXIT:

MENU

MENU

A

• If you turn the power on from off, V-CHIP BLOCK will be activated again.

• If you select V-CHIP BLOCK again by using MENU, V-CHIP BLOCK will be turned on again.

36

ADJUSTMENT (Continued)

VOL

CH MENU

Adjusting the V-CHIP Settings (Continued)

[5] CHANGING THE V-CHIP BLOCK SETTINGS

1 Repeat steps 1 to 2 of [1] MPAA

R

E

W

PO

DISPLAY

SLEEP PIC. FLIP

MENU

MUTE

BRIGHT CC TV/VIDEO

FLASHBACK

CHVOL

Channel
Select

RATING, then INPUT SECRET

NO. will be displayed.

2 Input the 4-digit secret number by

using Channel Select; the V-
CHIP select mode will be dis­played. Set V-CHIP BLOCK again.

INPUT SECRET NO.

– – – –

INPUT SECRET NO.

* * * *

EXIT:

EXIT:

MENU

MENU

[6] CHANGING OR CLEARING THE SECRET NUMBER

If you forget the secret number, clear the secret number as follows.

Upper control panel
of the main unit

1 Repeat steps 1 to 2 of [1] MPAA

RATING, or 1 to 2 of [4]
CANCELING THE V-CHIP
BLOCK SCREEN WHILE V-CHIP
BLOCK IS ACTIVATED, then

INPUT SECRET NO. will be
displayed.

CH ( )

VOL (+)

MENU

2 Press and hold both CH ( ) and

VOL (+) on the TV set simultane-

ously until the message INPUT
SECRET NO. blinks.

3 Press MENU to exit.

37

CONNECTING WITH EXTERNAL DEVICES

You can enjoy picture and sound by connecting a VCR or a home video game system to the terminals
located on the rear of the TV set.
When connecting an external device, turn off the power of the main unit first to prevent any possible
damage.

Example of external devices that can be connected

External devices that can be connected
to AV-IN2 terminal

<Example>

• VCR

• Laser disc player

External devices that can be connected
to COMPONENT terminal

<Example>

• DVD, etc.

AUX 1

AUX 1
TUNER/BAND

TUNER/BAND

AUX 2

AUX 2

AUX 3

AUX 3

DVD

DVD

SURROUND

SURROUND
ON/OFF

ON/OFF

* If your external device has a component

terminal, COMPONENT connection is
recommended (you can view high-quality
pictures).

External devices that can be connected
to AV-IN1 terminal

<Example>

• Video camera

• Home video game system

* If your external device has an S-Video terminal,

S-VIDEO connection is recommended.

O

E

VID

1

-IN

V

A

L

IO

D

U

A

R

EO

S-VID

EAD

H

E

N

O

PH

AV-IN 2/OUT

O

C

AUDIO

VIDEO

L

AUDIO

R

T

N

E

N

O

P

M

Y

B

P

R

P

L

R

T.

N

A

R

E

W

O

P

T

PU

IN

12V

C

D

A

• PC connection is not possible.

• For the cable, use a commercially available audio/video cable.

• Only connect audio/video signals to AV-IN1 and 2 terminals. Connecting other signals may result in a malfunction.

• AV-IN1 has 2 video input terminals: VIDEO and S-VIDEO. When you connect external devices to both terminals

(and if you select AV-IN1), you can only view pictures from the S-VIDEO terminal. To view the picture from the
VIDEO terminal, do not connect any external device to the S-VIDEO terminal.

• For more information about external device connections, see the manuals of your external devices.

38

CONNECTING WITH EXTERNAL DEVICES (Continued)

Connecting a VCR, DVD player or a video camera (AV-IN1/2/COMPONENT)

AV-IN2/O

COM

VIDEO

UDIO

A

PO

AUDIO

To AV-IN2 terminal

T

U

L

R

T

NEN

Y

B

P

R

P

L

R

To audio/video output
terminal

To component input

Video

Audio (L)

Audio (R)

VCR

(Video) terminal

Y

EO

ID

V

-IN 1

AV

L

DIO

AU

R

O

S-VIDE

EAD

H

NE

VIDEO

-IN 2/OUT

AV

L

AUDIO

R

NENT

PO

COM

Y

B

P

R

P

L

DIO

AU

R

PHO

T.

AN

ER
OW
P

UT
INP
C12V
D

To component input
(Audio) terminal

To AV-IN1 terminal

VIDEO

AV-IN1

L

AUDIO

R

S-VIDEO

To audio/video output

PB

PR
Audio (L)

Audio (R)

Video

Audio (L)

Audio (R)

AUX 1

AUX 1
TUNER/BAND

TUNER/BAND

AUX 2

AUX 2

AUX 3

AUX 3

DVD

DVD

SURROUND

SURROUND

ON/OFF

ON/OFF

DVD Player

terminal

HEAD

PHONE

Video camera

To S-Video input terminal

ANT.

POWER

INPUT

DC12V

S-Video

VCR

To S-Video output terminal

A

• If your VCR (or other external devices) has an S-Video terminal, S-VIDEO connection is recommended. (Use an
S-Video cable.)

• When you connect external devices to both S-VIDEO and VIDEO terminals (and if you select AV-IN1), you can
only view pictures from the S-VIDEO terminal.

• You cannot view multiple or synthesized pictures by connecting two or more external devices. When connecting
an external device, use care to connect the video and audio cables to the corresponding terminals.

• Do not connect antennas or headphones to AV-IN1.

39

CONNECTING WITH EXTERNAL DEVICES (Continued)

Outputting video and audio (video output)

You can output video and audio data from the TV set through the AV output terminals (AV-OUT).

• When using as an OUTPUT terminal, select PRESET in the MENU and set AV2 IN/OUT to OUT.
(See page 26.)

• The factory setting for AV2 IN/OUT is IN.

VIDEO

AV-IN2/OUT

L

AUDIO

R

COMPONENT

Y

O

E

ID

V

T

U
O
/

2

IN

­V

A

L

IO
D

AU

R

T

N
E

N
O

P

M
O
C

Y

B

P

R

P

L

IO
D
U

A

R

O

E
D
I

V

1

-IN
V
A

L

IO

D

U

A

R

O

E
D
I

V

-

S

D
A

E

H

E
N

O

H

P

.
T

N

A

R

E

W
O

P

T

U

P
N

I

V

2

1
C

D

Connect to a VCR,
audio amplifier, etc.

A

• AV2 has 2 OUT modes (see page 26).

• When using the S-Video input for AV-IN1, no video output will be made to the AV output terminal, but audio output

will be made for connection to external audio systems.

How to Fix the Cables

• Fix cables and cords with the attached cable
clamp so that they do not get caught when
mounting the cover.

• Connect the cables and cords after fixing the
cable clamp.

VIDEO

T
U

O
/
2

N

I

-
V
A

L

AUDIO

R

T
N
E

N

O

P
M
O

C

Y

B

P

R

P

L

AUDIO

R

O
E

ID

V

1

-IN
V
A

L

IO

D
U

A

R

O

E

ID

-V

S

D
A

E

H

E

N

O
H
P

.
T

N
A

R
E

W

O

P

T
U
P

IN

2V
1

C

D

Cable clamp

40

TROUBLESHOOTING

■ Before calling for repair service, check the following items for possible remedies to
the encountered symptoms.

TV set

Sound

Problem Check item

• Make sure the AC adapter is properly inserted in the



There is no
picture or
sound.

There is no
picture.
There is no
picture from
AV-IN1.

There is no
sound.

There is no
picture or
sound, just
noise.

power outlet.

• Reception other than those of broadcasting stations
can be considered.

• Make sure the input mode is set to TV.

• Make sure the main power switch of the main unit is

on.

• Make sure the BLACK LEVEL is properly adjusted.

• Fluorescent lamp may have reached the end of

service life.

• Make sure the S-Video terminal is free of connections.

• Make sure the volume is not set to minimum.

• Make sure the sound is not set to mute.

• Make sure that headphones are not connected.

• Make sure the antenna cable is properly connected.

• Consider whether TV signals are being properly

received.

Reference

Pages

9

–

16
16

24, 25

43

39

17
17
13

9

–

Picture is not
clear.

Picture is light
or improperly
tinted.

The picture is
too dark.

Remote control does not work.

• Make sure the antenna cable is properly connected.

• Consider whether TV signals are being properly

received.

• Check color adjustment.

• Check color system setting.

• Press the BRIGHT button.

• Check PICTURE and BLACK LEVEL adjustment.

• Fluorescent lamp may have reached the end of

service life.

• Check the batteries of the remote control.

• Make sure the remote sensor window is not under

strong lighting.

9

–

24, 25
24, 25

15

24, 25

43

8
8

41

TROUBLESHOOTING (Continued)

Antenna

Problem Check item

• The reception may be weak.

• The state of the broadcast may also be bad.

The picture is
not sharp.

The picture
moves.

The picture is
doubled or
tripled.

The picture is
spotted.

• Make sure the antenna is facing the right direction.

• Make sure the outside antenna is not disconnected.

• Make sure the antenna is facing the right direction.

• There may be reflected electric waves from mountains or

buildings.

• There may be interference from automobiles, trains, high
voltage lines, neon lights, etc.

• There may be interference between the antenna cable and AC
cord. Try positioning them further apart.

• Is the unit receiving interference from other devices?

There are
stripes on the
screen or
colors fade.

Transmission antennas of radio broadcasting stations, transmis­sion antennas of amateur radios and cellular phones may also
cause interference.

• Use the unit as far apart as possible from devices that may
cause possible interference.

■ Cautions regarding use in high and low temperature environments

• When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear
slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns normal.

• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight
or near a heater, as this may cause the cabinet to deform and the LCD panel to malfunction.
Storage temperature: –4°F to +140°F (–20°C to +60°C)

42

SPECIFICATIONS

Items

LCD panel
Number of dots 921,600 dots VGA
Video color systems N358, N443, PAL, PAL-M, PAL-N, SECAM, PAL-60

Destination USA/Latin A/Twn
TV Standard (CCIR) NTSC/PAL-M/PAL-N

TV function TV Tuning System PLL 181 ch.

STEREO MTS+SAP

CATV 125 ch.
4-LINE COMB FILTER Yes
Brightness 430 cd/m
Lamp life 60,000 hours
Viewing angles H: 170° V: 170°
Audio amplifier 2.1 W × 2
Speakers 1 3/16  2 15/16 in. (3  7.5 cm), 2 pcs.

AV1 AV-IN1, S-VIDEO-IN

AV2 AV-IN2/AV-OUT
Terminals COMPONENT COMPONENT-IN, AUDIO-IN

Antenna F-Type

Headphone Mini-jack for stereo (ø 3.5 mm)
OSD language English/French/Spanish
Power supply DC 12 V, AC 110–240 V, 50/60 Hz
Weight 8.2 lbs. (3.7 kg), 9.9 lbs. (4.5 kg),

Accessories Remote control, Batteries, Antenna cable, AC adapter,

Model

LC-13E1U LC-15E1U

13” ASV & BLACK-TFT LCD 15” ASV & BLACK-TFT LCD

2

w/o accessories w/o accessories

AC cord, Cable clamp, Operation manual

As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of
production units. There may be some deviations from these values in individual units.

43

DIMENSIONAL DRAWINGS

LC-13E1U

1

(313)

64

/

21

12

(276)

64

/

55

10

Unit: inch/(mm)

67/

32

(158)

2

°

(180)

64

/

5

7

(5)

16

/

3

0

(59)

64

/

21

2

(320)

32

/

19

12

529/

3

32

5

°

723/

(150)

107/

64

(187)

64

(257)

(290)

32

/

13

11

(220)

32

/

21

8

VOL CH MENU TV/VIDEO MAIN POWER

1317/

64

(337)

POWER SLEEP

44

313/

16

525/

(97)

25/

32

16

(147)

(59)

(129)

64

/

5

5

(157)

16

/

3

6

VIDEO

AV-IN 2/OUT

AUDIO

COMPONENT

AUDIO

3.9/100315/

16

(100)

VIDEO

AV-IN 1

L

AUDIO

R

L

R

Y

P

B

P

R

L

R

S-VIDEO

HEAD
PHONE

ANT.

POWER

INPUT
DC12V

(100)

16

/

15

3

(33)

64

/

19

1

DIMENSIONAL DRAWINGS (Continued)

LC-15E1U

1

2

/32(347)

21

13

637/64 (167)

°

61/4 (159)

1033/64 (267)

3

5

°

/32 (309)

5

12

VOL CH MENU TV/VIDEO MAIN POWER

1459/64 (379)

Unit: inch/(mm)

/64 (59)

21

2

/64 (352)

55

13

/8 (302)

7

11

811/32 (212)

313/16 (97)

/32 (131)

5

5

/16 (173)

13

6

/64 (237)

21

9

AV-IN 2/OUT

COMPONENT

/64 (198)

POWER SLEEP

51

7

/16(5)

3

0

3.9/100315/16 (100)

VIDEO

AV-IN 1

L

AUDIO

VIDEO

L

AUDIO

R

Y

P

B

PR

L

AUDIO

R

R

S-VIDEO

HEAD
PHONE

ANT.

POWER

INPUT
DC12V

/16 (100)

15

3

/8 (35.2)

3

1

215/16 (59)

69/64 (156)

45

CALLING FOR SERVICE

For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories, supplies, or customer
assistance, please call 1-800-BE-SHARP.

LIMITED WARRANTY

END-USER LIMITED WARRANTY

SHARP ELECTRONICS CORPORATION warrants to the first end user purchaser that this Sharp brand product (the
“Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it
will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured
equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.

This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below
nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or
other misuse, abnormal service or handling, or which has been altered or modified in design or construction.

In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide
proof of purchase to the servicer.

To the extent permitted by applicable state law, the warranties set forth herein are in lieu of, and exclusive of, all other
warranties, express or implied. Specifically, ALL OTHER WARRANTIES OTHER THAN THOSE SET FORTH ABOVE ARE
EXCLUDED. ALL EXPRESS AND IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY,
FITNESS FOR USE, AND FITNESS FOR A PARTICULAR PURPOSE ARE SPECIFICALLY EXCLUDED. If, under
applicable state law, implied warranties may not validly be disclaimed or excluded, the duration of such implied warranties is
limited to the period(s) from the date of purchase set forth below.

Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those
described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.

The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and
exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described
herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise.
In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused
by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any
way responsible for any incidental or consequential economic or property damage. Some states do not allow limits on
warranties or on remedies for breach in certain transactions; in such states, the limits herein may not apply.

Model Specific Section

Your Product Model Number & Description: LC-15E1U LCD Color Television

Warranty Period for this Product: One (1) year parts and labor from the date of purchase.

Additional Item(s) Excluded from
Warranty Coverage (if any): None

Where to Obtain Service: From a Sharp Authorized Servicer located in the United States.

What to do to Obtain Service: Ship prepaid or carry in your Product to a Sharp Authorized Servicer.

TO OBTAIN PRODUCT INFORMATION, CALL 1-888-LCD-SHARP OR VISIT www.sharpusa.com

LC-13E1U LCD Color Television

(Be sure to have this information available when you need service for
your Product.)

To find the location of the nearest Sharp Authorized Servicer, call
Sharp toll free at 1-800-BE-SHARP.

Be sure to have Proof of Purchase available. If you ship the Product,
be sure it is insured and packaged securely.

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07430-2135

SHARP CORPORATION

46

VALID IN CANADA ONLY

LIMITED WARRANTY

Consumer Electronics Products

Congratulations on your purchase!

Sharp Electronics of Canada Ltd. (hereinafter called “Sharp”) gives the following express warranty to the first consumer purchaser for this
Sharp brand product, when shipped in its original container and sold or distributed in Canada by Sharp or by an Authorized Sharp Dealer:

Sharp warrants that this product is free, under normal use and maintenance, from any defects in material and workmanship. If any such
defects should be found in this product within the applicable warranty period, Sharp shall, at its option, repair or replace the product as
specified herein.

This warranty shall not apply to:
(a) Any defects caused or repairs required as a result of abusive operation, negligence, accident, improper installation or inappropriate

use as outlined in the owner’s manual.

(b) Any Sharp product tampered with, modified, adjusted or repaired by any party other than Sharp, Sharp’s Authorized Service Centres

or Sharp’s Authorized Servicing Dealers.

(c) Damage caused or repairs required as a result of the use with items not specified or approved by Sharp, including but not limited to

head cleaning tapes and chemical cleaning agents.

(d) Any replacement of accessories, glassware, consumable or peripheral items required through normal use of the product including but

not limited to earphones, remote controls, AC adapters, batteries, temperature probe, stylus, trays, filters, belts, ribbons, cables and

paper.
(e) Any cosmetic damage to the surface or exterior that has been defaced or caused by normal wear and tear.
(f) Any damage caused by external or environmental conditions, including but not limited to transmission line/power line voltage or liquid

spillage.
(g) Any product received without appropriate model, serial number and CSA/cUL markings.
(h) Any products used for rental or commercial purposes.
(i) Any installation, setup and/or programming charges.

Should this Sharp product fail to operate during the warranty period, warranty service may be obtained upon delivery of the Sharp product
together with proof of purchase and a copy of this LIMITED WARRANTY statement to an Authorized Sharp Service Centre or an
Authorized Sharp Servicing Dealer. In home warranty service may be provided at Sharp’s discretion on any Sharp television with the
screen size of 27” or larger and on any Sharp Over-the-Range Microwave Oven.

This warranty constitutes the entire express warranty granted by Sharp and no other dealer, service centre or their agent or employee is
authorized to extend, enlarge or transfer this warranty on behalf of Sharp. To the extent the law permits, Sharp disclaims any and all
liability for direct or indirect damages or losses or for any incidental, special or consequential damages or loss of profits resulting from a
defect in material or workmanship relating to the product, including damages for the loss of time or use of this Sharp product or the loss
of information. The purchaser will be responsible for any removal, reinstallation, transportation and insurance costs incurred. Correction of
defects, in the manner and period of time described herein, constitute complete fulfillment of all obligations and responsibilities of Sharp
to the purchaser with respect to the product and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict
liability or otherwise.

WARRANTY PERIODS: Parts & Labour (exceptions noted)

Audio Products 1 year
Camcorder 1 year
DVD Products 1 year
LCD Projector 1 year (lamp 90 days)
LCD TV 1 year
Microwave Oven 2 years (magnetron component-3 additional years)
Television Products 1 year (picture tube component-1 additional year)
VCR Product 1 year
Vacuum Cleaner 1 year

To obtain the name and address of the nearest Authorized Sharp Service Centre or Dealer, please contact:

SHARP ELECTRONICS OF CANADA LTD. 335 Britannia Road East Mississauga, Ontario L4Z 1W9

For more information on this Warranty, Sharp Extended Warranty

Offers, Sharp Canada Products, Accessory Sales, Dealer or Service

Locations, please call [phone]

Visit our Web site: www.sharp.ca
