Sharp HT-X1H Operating Manual

Download

DEUTSCH

Siehe Seiten i bis vi und D-1 bis D-68.

HEIMKINO MIT DVD

HOME CINEMA AVEC DVD

HOME CINEMA CON DVD

HEMBIOGRAF MED DVD

MODELL MODÈLE MODELO MODELL

HT-X1H

BEDIENUNGSANLEITUNG

MODE D’EMPLOI

MANUAL DE MANEJO

BRUKSANVISNING

HOME CINEMA CON DVD THUIS-BIOSCOOP MET DVD CINEMA DOMÉSTICO COM DVD HOME CINEMA WITH DVD

MODELLO MODEL MODELO MODEL

MANUALE DI ISTRUZIONI GEBRUIKSAANWIJZING MANUAL DE OPERAÇÃO OPERATION MANUAL

FRANÇAIS

Se reporter aux pages i à vi et F-1 à F-68.

ESPAÑOL

Consulte las páginas i a vi y S-1 a S-68.

SVENSKA

Hänvisa till sidorna i till vi och V-1 till V-68.

ITALIANO

Leggere le pagine i a vi e I-1 a I-68.

NEDERLANDS

Raadpleeg de bladzijden i t/m vi en N-1 t/m N-68.

PORTUGUÊS

Favor consultar as páginas i a vi e P-1 a P-68.

ENGLISH

Please refer to pages i to vi and E-1 to E-68.

04/10/12

HT-X1H(H)_FR.fm

TINSZA030SJZZ

HT-X1H

BESONDERE ANMERKUNGEN REMARQUES SPÉCIALES NOTAS ESPECIALES SÄRSKILDA ANMÄRKNINGAR NOTE PARTICOLARI BIJZONDERE OPMERKINGEN NOTAS ESPECIAIS SPECIAL NOTES

● Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG.

● Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/ 68/CEE.

● Este aparato satisface las exigencias de las Directivas 89/336/CEE y 73/23/CEE, modificadas por medio de la 93/ 68/CEE.

● Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/ EEC och 73/23/EEC så som kompletteras av 93/68/EEC.

● Quest’apparecchio è conforme ai requisiti delle direttive 89/ 336/EEC e 73/23/EEC, come emendata dalla direttiva 93/68/ EEC.

● Dichiarazione di conformità

La società SHARP ELECTRONICS EUROPE GmbH dichiara che il prodotto SHARP MINI SISTEMI CD-XP300H è costruito in conformità alle prescrizioni del D.M.n˚548 del 28/8/95, pubblicato sulla G.U.n˚301 del 28/12/95 ed in particolare è conforme a quanto indicato nell’art. 2, comma 1 dello stesso decreto.

● Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/ EEG en 73/23/EEG, gewijzigd door 93/68/EEG.

● Este equipamento obedece às exigências das directivas 89/ 336/CEE e 73/23/CEE, na sua versão corrigida pela directiva 93/68/CEE.

● This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/ EEC.

HOME CINEMA CON DVD HT-X1H

● Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC med tillaeg nr. 93/68/EEC.

● Dette produktet oppfyller betingelsene i direktivene 89/336/ EEC og 73/23/EEC i endringen 93/68/EEC.

● Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset, joita on muutettu direktiivillä 93/68/EEC.

●

● Bei Einstellung der ON/STAND-BY-Taste auf STAND-BY ist

die Netzspannung immer noch im Gerät vorhanden. Wenn die ON/STAND-BY-Taste auf STAND-BY eingestellt wird, kann das Gerät unter Verwendung der Fernbedienung in Betrieb gesetzt werden.

Warnung:

In diesem Gerät sind keine vom Benutzer wartbaren Teile vorhanden. Niemals Abdeckungen entfernen, außer wenn Sie dafür qualifiziert sind. In diesem Gerät sind gefährliche Spannungen vorhanden. Vor Ausführung von irgendwelchen Kundendienstarbeiten oder bei längerer Nichtverwendung des Gerätes stets den Netzstecker aus der Netzsteckdose ziehen.

● Lorsque la touche ON/STAND-BY est mise en STAND-BY, l’appareil est toujours sous tension. Lorsque la touche ON/STAND-BY se trouve sur la position STAND-BY, l’appareil est prêt à fonctionner par la télécommande.

Avertissement:

Cet appareil contient des pièces non réparables par l’utilisateur. Personne non qualifiée n’enlèvera jamais les couvercles. L’appareil contenant des organes portés à haute tension, débrancher l’appareil avant toute réparation ou en période de non-utilisation.

0408_A5

04/10/12 HT-X1H(H)_com.fm

TINSZA030SJZZ

SHARP TINSZA030SJZZ (H)

● Cuando el botón ON/STAND-BY está puesto en la posición STAND-BY, todavía hay tensión dentro del aparato. Cuando el botón ON/STAND-BY está puesto en la posición STAND-BY, el aparato puede ponerse en funcionamiento utilizando el controlador remoto.

Advertencia:

Tenga en cuenta que dentro de este aparato no hay piezas que pueda reparar. No quite nunca las tapas a menos que se esté cualificado para hacerlo. Este aparato tiene en su interior tensiones peligrosas. Desenchufe siempre la clavija de la red del tomacorriente antes de realizar cualquier servicio de mantenimiento y cuando no se use el aparato durante un largo período de tiempo.

● När ON/STAND-BY knappen är i läge STAND-BY, finns

nätspänning i apparaten. Med ON/STAND-BY knappen i läge ST AND-BY kan apparaten startas med fjärrkontrollen.

Varning:

Apparaten innehåller inga delar som kan åtgärdas av kunden. Höljet får endast öppnas av kvalificerad personal. Apparaten innehåller farliga spänningar. Stickkontakten ska därför dras ut från nätuttaget före reparationsarbeten och bör dras ut om apparaten inte ska användas på mycket länge.

● Quando il tasto ON/STAND-BY si trova in posizione STAND-

BY, all’interno dell’apparecchio c’è ancora la corrente. Se il tasto ON/STAND-BY si trova nella posizione STANDBY, l’unità può essere accesa con il telecomando.

Avvertenza:

L’apparecchio non contiene parti riparabili dall’utente. Non togliere mai i coperchi, a meno di non essere qualificati per farlo. All’interno dell’apparecchio ci sono tensioni pericolose, per cui si deve sempre staccare la spina del cavo d’alimentazione dalla presa di corrente prima di qualsiasi intervento di manutenzione e quando non si usa l’apparecchio per un lungo periodo di tempo.

● Wanneer de ON/STAND-BY toets in de STAND-BY stand staat, loopt er nog steeds stroom (netspanning) in het toestel. Wanneer de ON/STAND-BY toets in de STAND-BY stand staat, kan het toestel ingeschakeld worden via de afstandsbediening.

Waarschuwing:

Dit toestel bevat geen door de gebruiker te repareren onderdelen. Verwijder de behuizing nooit tenzij u deskundig bent op dit gebied. In het toestel loopt een gevaarlijke spanning; haal de stekker altijd uit het stopcontact alvorens onderhoud uit te voeren of wanneer het toestel voor langere tijd niet gebruikt wordt.

● Quando o botão ON/STAND-BY estiver ajustado na posição STAND-BY, a voltagem de alimentação ainda se encontra presente dentro do aparelho. Quando o botão ON/STAND-BY estiver ajustado na posição STAND-BY, o aparelho pode ser colocado em operação através do controle remoto.

Advertência:

Neste aparelho não há partes que podem ser consertadas pelo usuário. Nunca retire a tampa, a menos que você tenha qualificação para tal. Este aparelho contém voltagens perigosas. Remova sempre o cabo de alimentação da tomada antes de efetuar qualquer conserto ou quando deixar o aparelho muito tempo fora de uso.

● When the ON/STAND-BY button is set at STAND-BY position, mains voltage is still present inside the unit. When the ON/STAND-BY button is set at STAND-BY position, the unit may be brought into operation by the remote control.

Warning:

This unit contains no user serviceable parts. Never remove

covers unless qualified to do so. This unit contains dangerous voltages, always remove mains plug from the socket before any service operation and when not in use for a long period.

0408_A5

HT-X1H

04/10/12 HT-X1H(H)_com.fm

TINSZA030SJZZ

HT-X1H

● Når ON/STAND-BY-knappen er sat i STAND-BY positionen, er der stadig netspaending til stede i apparatet. Når ON/STAND-BY-knappen er sat i STAND-BY position, kan apparatet startes v.hj.a. fjernbetjeningen.

Advarsel:

Apparatet indeholder ingen dele, der kan repareres af brugeren selv. Fjern aldrig kabinettet med mindre De er kvalificeret hertil. Apparatet indeholder farlig strømspaending. Traek altid stikket ud af stikkontakten før der foretages reparationer, eller hvis apparatet ikke er i brug i laengere tid.

DENNA APPARAT ÄR ANSLUTEN TILL 230 V VÄXELSTRÖM NÄR STICKPROPPEN ÄR INSKJUTEN I VÄGGUTTAGET. FÖR ATT FULLSTÄNDIGT KOPPLA IFRÅN APPARATEN, V.G. DRAG UT STICKPROPPEN.

● Vorsicht:

Das Gerät weder Tropf- noch Spritzwasser aussetzen. Ansonsten besteht die Gefahr eines Brandes oder elektrischen Schlages. Es dürfen keine mit Flüssigkeiten gefüllten Gegenstände wie Vasen auf dem Gerät abgestellt werden.

● Attention:

Pour éviter un incendie ou une secousse électrique, mettre l’appareil à l’abri de l’eau (éclaboussure, goutte). Ne pas poser sur l’appareil un récipient contenant du liquide.

● Advertencia:

Para evitar incendios y descargas eléctricas, no exponga el aparato a goteo o salpicadura de líquidos. No deberán ponerse encima del aparato objetos que estén llenos de líquido, como por ejemplo un florero.

● Varning:

Utsätt inte enheten för dropp eller stänk för att förhindra brand eller elektriska stötar. Inga vätskefyllda föremål såsom vaser får placeras på enheten.

● Attenzione:

Per prevenire incendi o scosse elettriche, non fare gocciolare nessun liquido sull’apparecchio e non bagnarlo. Non collocarvi sopra nessun oggetto riempito d’acqua, come per esempio vasi.

● Waarschuwing:

Stel het toestel niet bloot aan druipend of spattend water om brand en elektrische schokken te voorkomen. Met vloeistoffen gevulde voorwerpen, zoals vazen, mogen niet op het toestel geplaatst worden.

● Cuidado:

Para evitar incêndio ou choque elétrico, não exponha este aparelho a gotejamento ou salpicamento de água. Não coloque objetos com água como, por exemplo, um vaso de flores, em cima do aparelho.

● Warning:

To prevent fire or shock hazard, do not expose this appliance to dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the apparatus.

iii

04/10/12 HT-X1H(H)_com.fm

TINSZA030SJZZ

● Advarsel:

Til at forbygge ild og stød risiko, lad vaere med at undsaette denne indretning for drypning eller overstaenkning. Der må ikke anbringes nogen genstande fyldt med vand, som for eksempel vaser, på dette apparat.

● Advarsel:

For å unngå brann eller kortslutning, utsett ikke produktet for vann eller fuktighet. Gjenstander som inneholder vaeske, feks. en blomstervase, må ikke plasseres oppå apparatet.

● Varoitus:

Älä vie laitetta sateeseen tai kosteisiin tiloihin. Jos laite on kostunut, anna sen kuivua ennen kuin käytät sitä verkkovirralla. Nestettä sisältäviä astioita kuten esim. kukkamaljakoita ei saa asettaa laitteen päälle.

Dieses Produkt ist ein Laserprodukt der Klasse 1. Ce produit est classifié comme étant un LASER DE CLASSE 1. Este producto está clasificado como un PRODUCTO LÁSER DE

CLASE 1. Denna produkt klassificeras som KLASS 1 LASERPRODUKT. Questo prodotto è classificato come CLASS 1 LASER PRODUCT. Dit product is geclassificeerd als een KLASSE 1 LASER PRODUCT. Este produto é classificado como PRODUTO LASER DE CLASSE 1. This product is classified as a CLASS 1 LASER PRODUCT.

Dette produktet er klassifisert som et KLASSE 1 LASERPRODUKT. Dette produkt er klassificeret som et KLASSE 1 LASERPRODUKT. Tämä laite on luokiteltu LUOKAN 1 LASERLAITTEEKSI. Denna produkt klassificeras som KLASS 1 LASERAPPARAT.

0402_A5_2

HT-X1H

04/10/12 HT-X1H(H)_com.fm

TINSZA030SJZZ

HT-X1H

● VORSICHT

Verwendung von Regelungen oder Einstellungen bzw. Durchführung von anderen Verfahren als die hierin angegebenen kann zum Aussetzen gefährlicher Strahlung führen.

Da der in diesem Gerät verwendete Laserstrahl für die Augen schädlich ist, ist das Gehäuse unter keinen Umständen zu zerlegen. Wenden Sie sich für Wartungsarbeiten nur an berechtigten Fachhändler.

● ATTENTION

Respecter les indications données relatives à la manipulation, au réglage et au fonctionnement. En cas de non-respect, on s’exposera à une radiation dangereuse.

Éviter absolument de démonter l’appareil, qui utilise un rayon laser nuisible aux yeux. Pour toute réparation, s’adresser à une personne qualifiée.

● PRECAUCIÓN

El uso de los controles, ajustes o ejecución de procedimientos distintos de los especificados podría causar la exposición a radiación peligrosa.

No intente desmontar la caja ya que el haz de láser usado en este aparato es perjudicial para los ojos. Para el servicio de reparación, consulte a una persona cualificada.

● OBSERVERA

Användning av reglage eller justeringar eller handhavande på annat sätt än som anges kan leda till farlig bestrålning.

Försök inte ta isär höljet eftersom enhetens laserstråle är skadlig för ögonen. Överlåt service endast till kvalificerad personal.

● ATTENZIONE

L’uso dei comandi e l’effettuazione di regolazioni e procedimenti diversi da quelli specificati nel manuale possono provocare una pericolosa esposizione alle radiazioni.

Poiché il raggio laser usato in questo apparecchio può danneggiare gli occhi, non smontare l’apparecchio. Per le riparazioni rivolgersi a personale specializzato.

● LET OP

Gebruik van regelaars, het maken van instellingen, gebruik of handelingen anders dan in deze gebruiksaanwijzing vermeld, kan gevaarlijke straling blootleggen.

De laserstraal in dit toestel kan de ogen beschadigen, Probeer derhalve de ombouw niet te verwijderen. Laat reparaties alleen over aan erkend onderhoudspersoneel.

● CUIDADO

O uso de controles, ajustes ou a execução de procedimentos além daqueles especificados aqui pode resultar em perigosa exposição à radiação.

Como os raios laser usados nesta unidade são perigosos para os olhos, não tente desmontar o aparelho. Solicite o conserto somente para pessoas especializadas.

● CAUTION

Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

As the laser beam used in this unit is harmful to the eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only.

0403

04/10/12 HT-X1H(H)_com.fm

TINSZA030SJZZ

Eigenschaften der Laserdiode

Material: AIGaAs/AIGaInP Wellenlänge: 785 nm/650 nm Emissionsdauer: kontinuierlich Laser-Ausgang: max. 0,6 mW

Caractéristiques de la diode laser

Matière: AIGaAs/AIGaInP Longueur d’onde: 785 nm/650 nm Durée d’émission: ininterrompue Puissance de sortie

laser maximale: 0,6 mW

Características del diodo láser

Material: AIGaAs/AIGaInP Longitud de onda: 785 nm/650 nm Duración de emisión : continua Salida de láser: máx. 0,6 mW

Laserdiodens egenskaper

Material: AIGaAs/AIGaInP Våglängd: 785 nm/650 nm Utstrålningsvaraktighet: kontinuerlig Lasereffekt: max. 0,6 mW

Proprietà del diodo laser

Materiale: AIGaAs/AIGaInP Lunghezza d’onda: 785 nm/650 nm Durata di emissione: continua Uscita massima del laser: 0,6 mW

Laser diode specificaties

Materiaal: AIGaAs/AIGaInP Golflengte: 785 nm/650 nm Stralingsduur: doorlopend Laseruitgang: max. 0,6 mW

Propriedades do diodo de laser

Material: AlGaAs/AlGaInP Comprimento de onda: 785 nm/650 nm Duração da emissão: contínua Saída de laser: máx. 0,6 mW

Laser Diode Properties

Material: AIGaAs/AIGaInP Wavelength: 785 nm/650 nm Emission Duration: continuous Laser Output: max. 0.6 mW

0403

ADVERSEL-SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING. SE IKKE IND I STRÅLEN-HELLER IKKE MED OPTISKE INSTRUMENTER.

VARO! AVATTAESSA OLET ALTTIINA NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE ÄLÄ TUIJOTA SÄTEESEEN ÄLÄKÄ KATSO SITÄ OPTISEN LAITTEEN LÄPI.

VARNING-SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD. STIRRA EJ IN I STRÅLEN OCH BETRAKTA EJ STRÅLEN GENOM OPTISKT INSTRUMENT.

VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1 YLITTÄVÄLLE NÄKYVÄLLE JANÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.

VARNING - OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA BRUKSANVISNING SPECIFICERAS. KAN ANVÄNDAREN UTSÄTTAS FÖR SYNLIG OCH OSYNLIG LASERSTRÅLNING, SOM ÖVERSKRIDER GRÄNSEN FÖR LASERKLASS 1.

0408_A5 (3A_DVD+CD)

HT-X1H

04/10/12 HT-X1H(H)_com.fm

TINSZA030SJZZ

HT-X1H

ENGLISH

Introduction

Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product.

Special notes

"DTS" and "DTS Digital Surround" are registered trademarks of Digital Theater Systems, Inc.

Manufactured under license from Dolby Laboratories. "Dolby", "Pro Logic" and the double-D symbol are trademarks of Dolby Laboratories.

Unauthorised copying, broadcast, public display, transmission,

public performance and rental (regardless of whether or not

General Information

such activities are for profit) of disc contents are prohibited by law.

This system is equipped with copy protection technology that

causes substantial degradation of images when the contents of a disc are copied to a videotape.

HT-X1H Home Cinema with DVD consisting of HT-X1H (main unit and subwoofer/amplifier unit), CP-X1HF (front speakers), CP-X1HC (centre speaker) and CP-X1HS (surround speakers).

Copy Protection:

This unit supports Macrovision copy protection. On DVD discs that include a copy protection code, if the contents of the DVD disc are copied using a VCR, the copy protection code prevents the videotape copy from playing normally.

Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216, 4,819,098 and 4,907,093 licensed for limited viewing uses only.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

0403E

E-1

04/10/16 HT-X1H(H)E1.fm

TINSZA030SJZZ

Accessories

Please confirm that the following accessories are included.

HT-X1H

ENGLISH

Remote control 1 "AAA" size battery (UM-4,

R03, HP-16 or similar) 2

FM aerial 1 SCART cable 1 AC power lead 1

System connection cable 1Pattern paper for main

unit 1

Caution:

Do not use the supplied AC power lead for other equipment. Fire or electric shock may result.

Note:

Only the above accessories are included.

AM loop aerial 1

Button name label 1 Speaker connection lead 5

White

(for left front

speaker)

approx. 5 m

Blue

(for left surround

speaker)

approx. 15 m

(for centre speaker)

Red

(for right front

speaker)

approx. 5 m

Grey

(for right surround

speaker)

approx. 15 m

General Information

Green

approx. 5 m

E-2

04/10/16 HT-X1H(H)E1.fm

TINSZA030SJZZ

HT-X1H

ENGLISH

Contents

Page

General Information

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9

Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 12

Page

Audio CD Operation

Playing an audio CD

To play in random order (random play) . . . . . . . . . . . . . . . . . . 37

To start playback from the desired point (direct play) . . . . . . 38

E-3

Preparation for Use

System installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Main unit prepa r a t ion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 - 20

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 2

DVD Operation

Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 - 25

Basic operation

To locate the beginning of a chapter/track (skip) . . . . . . . . . . 26

Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . 26

To start playback from the desired point (direct play) . . . . . . 27

Useful operation

To change the subtitle la n gua ge . . . . . . . . . . . . . . . . . . . . . . . 28

To change the audio language (audio output) . . . . . . . . . . . . 29

To brighten an ima ge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

General Information

To improve the ima ge q ua li t y . . . . . . . . . . . . . . . . . . . . . . . . . . 30

To select a title from the top menu of the disc . . . . . . . . . . . . 31

To select a subtitle or audio language from the disc menu . . 31

Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

To zoom in on an image (zoom) . . . . . . . . . . . . . . . . . . . . . . . . 32

To play in the desired order (programmed playback) . . . . . . 33

To play repeatedl y (r e pe a t pla y ) . . . . . . . . . . . . . . . . . . . . . . . . 34

To play the contents between the specified points repeatedly

(A-B repeat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

To change the display on the main unit . . . . . . . . . . . . . . . . . . 35

To change the disp la y on TV screen . . . . . . . . . . . . . . . . . . . . 3 6

Super Video CD/Video CD Operation

Playing a super video CD or video CD Playing a super video CD or video CD with P. B. C.

(playback control) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

MP3, WMA and JPEG Disc Operation

Playing an MP3, W MA or JP EG di s c . . . . . . . . . . . . . . . . . 40, 41

Radio

Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42, 43

Using the Radio Da t a Sy s t e m (RDS) . . . . . . . . . . . . . . . . 44 - 48

Advanced Features

Enjoying surround sound (sound mode) . . . . . . . . . . . . . 49 - 52

Changing the default setting of the amplifier . . . . . . . . . 53 - 55

Changing th e init ial setting of DVD . . . . . . . . . . . . . . . . . 56 - 59

Language code list for disc language . . . . . . . . . . . . . . . . . . . 60

Sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Audio connec tion to other equipment . . . . . . . . . . . . . . . . . . . 62

To install the main unit on the wall . . . . . . . . . . . . . . . . . . . . . 63

References

Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64, 65

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . 66

Optional accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67, 68

04/10/16 HT-X1H(H)E1.fm

TINSZA030SJZZ

Precautions

General

Please ensure that the equipment is posi tioned in a well venti-

lated area and that there is at least 10 cm of free space along the sides and back. There must also be a minimum of 15 cm of free space on the top of the unit.

Main unit

10 cm 10 cm

15 cm

10 cm

In case of an electrical storm, unplug the

subwoofer/amplifier unit for safety.

Hold the AC power plug by the head when

removing it from the wall socket, as pulling the lead can damage internal wires.

Do not remove the outer cover, as this may result in electric shock. Refer internal service to your local SHARP service facility.

HT-X1H

ENGLISH

10 cm 10 cm

Subwoofer/amplifier unit

10 cm 10 cm

Use the system on a firm, level surface free from vibration.

Keep the system away from direct sunlight, strong magnetic

fields, excessive dust, humidity and electronic/electrical equipment (home computers, facsimiles, etc.) which generate elect rical noise. Do not place anything on top of the components.

Do not expose the system to moist ure, to temperatures higher

than 60°C or to extremely low temperatures.

! If your system does not work properly, disconnect the AC pow er

lead from the wall socket. Plug the AC power lead back in, and then turn on your system.

15 cm

10 cm

15 cm

10 cm

The ventilation should not be impeded by covering the ventilation

openings with items, such as newspapers, t ablecloths, curtains, etc. No naked flame sources, such as lighted candles, should be

placed on the components of the system. Attention should be drawn to the environmental aspects of bat-

tery disposal. The system is designed for use in moderate climate.

This system should only be used within the range of 5°C - 35°C.

Warning:

The voltage used must be the same as that specified by this system. Using this product with a higher vol tage other than that s pecified is dangerous and may result in a fire or other types of accident, causing damage. SHARP will not be held responsible for any damage resulting from the use of this system wi th a voltage other than that specified.

" Volume control

The sound level at a given volume setting depends on speaker ef ficiency, location, and various other factors. It is advisable to avoid exposure to high volume levels. Do not turn the volume on to full at switch on and listen to music at moderate levels.

04/10/16 HT-X1H(H)E1.fm

TINSZA030SJZZ

General Information

E-4

HT-X1H

ENGLISH

Controls and indicators

1 2 3 4 5 6 7 8

General Information

21 34 5 76 8 9

Display

12 13

Top and front panel

1.Disc Eject Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

2.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23, 24

3.Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.Chapter (Track) Skip Down or Fast Reverse Button . . . . . 26

5.Chapter (Track) Skip Up or Fast Forward Button . . . . . . . 26

6.Function Selector Button . . . . . . . . . . . . . . . . . . . . . . . . . . 50

7.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 2

8.On/Stand-by But ton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

9.Disc Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

10.Main Unit Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

11.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

12.Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 2

13.Headphone Socke t . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Rear panel

1.FM 75 Ohm Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . 15, 16

2.Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 16

3.AM Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 16

4.Auxiliary (Audio Signal) Input Sockets. . . . . . . . . . . . . . . . 62

5.SCART Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

6.S-video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

7.Video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

8.System Connection Sockets

(to subwoofer/amplifier unit) . . . . . . . . . . . . . . . . . . . . . 15, 16

9.Optical Digital Audio Input Socket . . . . . . . . . . . . . . . . . . . 62

Removing the back cover of the main unit:

For system connections, remove the back cover first.

Reference page

E-5

04/10/16 HT-X1H(H)E1.fm

TINSZA030SJZZ

10 11 12

Display

1 2

3 4

6 7 8

14 15

16 17

1.Programme Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 33, 43

2.Random Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

3.Repeat/One Track Repeat/A - B Repeat Indicators . . . 34, 35

4.2 channel Stereo Sound Mode Indicator . . . . . . . . . . . . . . 51

5.Multi Channel Sound Mode Indicato r . . . . . . . . . . . . . . . . . 52

6.PCM Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

7.DTS Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

8.Dolby Digital Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . 49

9.Dolby Pro Logic Indicator . . . . . . . . . . . . . . . . . . . . . . . . 49

10.Audio Signal/Speaker Indicators . . . . . . . . . . . . . . . . . . . . 50

11.Track Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

12.Chapter Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

13.Title Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

14.Pause Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

15.Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

16.Total Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

17.Angle Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

18.RDS Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

19.Traffic Programme Indicator . . . . . . . . . . . . . . . . . . . . . . . . 44

20.Traffic Announcement Indicator . . . . . . . . . . . . . . . . . . . . . 44

21.Dynamic PTY Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

22.FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 42

23.FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . 42

24.Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Reference page

HT-X1H

ENGLISH

General Information

18 19 20 21 22 23 24

04/10/16 HT-X1H(H)E1.fm

E-6

TINSZA030SJZZ

HT-X1H

ENGLISH

Controls and indicators (continued)

1 2

3 4 5 6 7 8

10 11

17 18 19

20 21

13 14 15 16

General Information

30 31

Remote control

1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . 21

2.Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

23 24

25 26

2827

3.On/Stand-by But ton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

5.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

6.Random or Programme Button . . . . . . . . . . . . . . . . . . . 33, 37

7.A - B Repeat or Repeat Button . . . . . . . . . . . . . . . . . . . 34, 35

8.Unit Display Select or Dimmer B u t t on . . . . . . . . . . . . . 22, 35

9.On Screen Display On/Off Bu t t on . . . . . . . . . . . . . . . . . . . . 36

10.Top Menu or Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . 31

11.Chapter (Track) Skip Down or Fast Reverse Button . . . . . 26

12.Disc Eject Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

13.Multi Channel Se le c t Button . . . . . . . . . . . . . . . . . . . . . . . . 52

14.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53, 56

15.Stereo (2 channel) Select Button . . . . . . . . . . . . . . . . . . . . 51

16.Chapter (Track) Skip Up or Fast Forward Button . . . . . . . 26

17.Angle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

18.DVD Audio Language Select or

CD Audio Output Select Button . . . . . . . . . . . . . . . . . . . . . 29

19.Gamma Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

20.RDS Programme Type/Traffic Information

Search Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

21.RDS Display Mode Select Button . . . . . . . . . . . . . . . . . . . . 44

22.Direct Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

23.Subtitle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

24.Super Picture Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

25.Zoom Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

26.RDS ASPM (Auto Station Programme Memory) Button . . 46

27.Tuner Preset Down or Cursor Button . . . . . . . . . . . . . . 32, 43

28.Tuning Up or Cursor Button . . . . . . . . . . . . . . . . . . . . . 32, 42

29.Tuner Preset Up or Cursor Button . . . . . . . . . . . . . . . . 32, 43

30.Tuning Down or Cursor Button . . . . . . . . . . . . . . . . . . . 32, 42

31.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Reference page

E-7

04/10/16 HT-X1H(H)E1.fm

TINSZA030SJZZ

Remote control

1.Mute Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

3.Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

4.Frame Advance or Pause Button . . . . . . . . . . . . . . . . . 24, 31

5.DVD Initial Setting Button . . . . . . . . . . . . . . . . . . . . . . . . . . 56

6.Amplifier Initial Setting Button . . . . . . . . . . . . . . . . . . . . . . 54

7.Shift Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

8.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . 22

9.Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

10.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23, 24

TV Operation Buttons

You can operate some functions of SHARP' TVs with the remote control of this system.

However, some models cannot be operated.

Reference page

HT-X1H

ENGLISH

1 2

8 9

3 4

5 6

TV Channel Up Button TV Channel Down Bu tto n

Switches the TV channel up.

TV On/Stand-by Button TV Volume Up Button

Sets the TV power to "ON" or "STAND-BY".

TV/VCR Input Sele ct B u t ton

Switches the input to TV or VCR.

1 2

4 5

Switches the TV channel down.

Turns up the TV volume.

TV Volume Down Bu tton

Turns down the TV volume.

General Information

E-8

04/10/16 HT-X1H(H)E1.fm

TINSZA030SJZZ

HT-X1H

ENGLISH

Controls and indicators (continued)

General Information

Front/surround speakers

1.Speaker

2.Speaker Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3 4

3.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 17

4.Colour Label

White ... Left Front Speaker Red ... Right Front Speaker Blue ... Left Surround Speaker Grey ... Right Surround Speaker

Centre speaker

1.Speaker

2.Speaker Stand

3.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 17

4.Colour Label: Green

Subwoofer/amplifier unit

1.Bass Reflex Duct

2.Woofer

3.Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4.AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

5.System Connection Sockets (to main unit) . . . . . . . . . 15, 16

6.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 17

Reference page

E-9

04/10/16 HT-X1H(H)E1.fm

TINSZA030SJZZ

Description of discs

Types of playable discs

The unit can play back discs bearing any of the following marks:

DVD

DVD-Video Disc DVD-R DVD-RW DVD+R DVD+RW

HT-X1H

ENGLISH

Audio CD Audio CD-R Audio CD-RW

4.7

Recorded in the video mode (*1) (*2)

(*1) Some discs may not play properly due to the status of the

equipment used for recording, characteristics of the discs, scratches, dirt, or dirty optical pickup lens.

(*2) DVD-RW discs recorded in VR mode (Video Recording format)

cannot be played back.

Some DVD discs may not function as described in the manual. See the disc jacket for restrictions.

Video CD

Super video CD Video CD

Recorded in the video mode (*1)

Or CDV (*1) CD-R/RW recorded in MP3/WMA/JPEG

(*1) Only the audio on the CDV can be played. (*2) Some discs may not play properly due to the status of the

equipment used for recording, characteristics of the discs, scratches, dirt, or dirty optical pickup lens.

For unplayable discs, see page 12.

Icons used in this operation manual

Some functions may not be available depending on discs. The following icons indicate the discs that can be used in the section.

... Indicates DVDs. ... Indicates super video CDs. ... Indicates video CDs. ... Indicates audio CDs. ... Indicates CD-R/RW with MP3 recording. ... Indicates CD-R/RW with WMA recording. ... Indicates CD-R/RW with JPEG recording.

Some operations may not be performed depending on discs

even if they are described in this manual. During operation, " " may be displayed on the screen. This

means that the operations described in this manual are prohibited by the disc.

format (*2)

General Information

E-10

04/10/16 HT-X1H(H)E1.fm

TINSZA030SJZZ

HT-X1H

ENGLISH

Description of discs (continued)

! DVD-Video

A popular type of DVD disc of the same size as a CD, mainly containing video images.

Region num ber

DVD discs are programmed with region numbers indicating countries in which they can be played. This system can play discs with region number "2" or "ALL".

Title and chapter

DVD-Video discs are divided into "ti tles" and "chapters". If the di sc has more than one movie on it, each movie is a separate "title". "Chapters" are subdivisions of titles.

Region number (playable area number)

ALL

! Super video CD/video CD/audio CD

Track

Super video CD, video CD and audio CD are composed of "tracks". Tracks are equivalent to songs on a CD.

Track 1 Track 2 Track 3 Track 4

! MP3/WMA/JPEG format on CD-R/CD-RW

An MP3 file is an audio data compressed in the MPEG 1 audio layer 3 format. MP3 files have the extension ".mp3". (Files with the extension ".mp3" may not play, or noise may occur during playback i f not recorded in the MP3 format.)

E-11

Title 1 Title 2

Chapter 1

General Information

! DVD-R/DVD-RW/DVD+R/DVD+RW

You can play DVD-R/DVD-RW/DVD+R/DVD+RW discs recorded

in the video mode.

Before playing DVD-R/DVD-RW/DVD+R/DVD+RW discs with

this unit, finalize them with the equipment used for recording.

Chapter 2 Chapter 3 Chapter 1 Chapter 2

WMA is an audio file format developed by Microsoft with the ".wma" extension. This type of audio file is recorded through Microsoft Windows operating system.

A JPEG file is still image data compressed in the JPEG (Joint Photographic Experts Group) format. JPEG files have the extension ".jpg".

Folder and file

MP3/WMA/JPEG discs consist of "folders" and "files".

JPEG

WMA

MP3

disc

04/10/16 HT-X1H(H)E2.fm

disc

Folder 1

File 1

Folder 2

File 2 File 1

File 2

TINSZA030SJZZ

! Icons used on DVD discs

Check the icons of the DVD jacket before playing your discs.

Display Description

Format recorded on the DVD To adopt the video format to

Type of subtitles recorded Recorded subtitle languages.

Example: You can select a subtitle lan-

1. English

2. German

Number of camera angles Number of angles recorded on

Number of audio tracks and audio recording systems

Example: 1: Original <English> (Dolby Digital 5.1 Surround)

2. German (Dolby Digital 2 ch)

the connected TVs ("widescreen TV" or "4:3 size TV").

guage.

the DVD. You can view scenes from dif-

ferent angles.

The number of audio tracks and audio recording systems are indicated.

You can change the audio

language. Audio and recording sys-

tem vary depending on the DVD. Check them in the DVD's manual.

! Discs that cannot be played

DVDs without the region num-

ber "2" or "ALL". DVDs with SECAM system

DVDs with MPEG sound

DVD-ROM

DVD-RAM

Notes:

The discs above cannot be played at all, or no sound is heard

although images appear on the screen or vice versa. Faulty playback may damage the speakers and can have an

adverse effect on your hearing when played at high volume settings. You cannot play illegally produced discs.

A disc with scratches or fingerprints may not play properly. Refer

to "Care of discs (page 66)" and clean the disc.

DVD-Audio

CDG

Photo CD

CD-ROM

SACD

Discs recorded in special for-

mats, etc.

HT-X1H

ENGLISH

General Information

04/10/16 HT-X1H(H)E2.fm

E-12

TINSZA030SJZZ

HT-X1H

ENGLISH

System installation

Installation image (with optional accessories):

Front

Subwoofer/ amplifier unit

speaker (left)

Surround speaker (left)

! Magnetically shielded speaker s

The front and centre speakers may be placed beside or near the TV as they are magnetically shielded. How ever, colour variation may occur, depending on the type of the TV.

If colour variation occurs...

Preparation for Use

Turn off the TV (from the power switch). After 15 - 30 minutes, turn the TV on again.

If the colour variation is still present...

Move the speakers further away from the TV. Refer to the user's manual of the TV for details.

Centre speaker

Main unit

Surround speaker (right)

Front speaker (right)

! Placing the speaker system

The best surround effect will be achieved by placing each speaker at the same distance from the listening position. It is recommended to arrange the speakers as shown below.

Centre

Front speaker (left)

Subwoofer/

amplifier unit

Surround speaker (left)

Notes:

The default distance i s set t o 2 m . If spe ak ers cannot be placed at

equal distances, refer to "Speaker delay setting" (see page 54). Place the TV halfway between the front speakers.

It is recommended that the centre speaker be placed near the

television. Place the surround speakers at a position just above the height of

your ears. You can place the subwoofer/amplifier unit anywhere you like. As

it vibrates whilst reproduc ing bass, place it on a stable, sturd y surface.

speaker

Same distance

Front speaker (right)

Default setting:

2 m

Surround speaker (right)

E-13

Note:

The surround speakers and subwoofer/ampl ifier unit are not magnetically shielded.

Front speaker

(left)

Centre speaker

04/10/16 HT-X1H(H)E2.fm

Front speaker

(right)

TINSZA030SJZZ

Main unit preparation

Installation methods

HT-X1H

ENGLISH

Make sure to unplug the AC power lead before installing the main unit or change the position.

The stand is attached to the main unit at the factory.

Stand

You can also place the main unit horizontally or mount it on the wall without the stand. (See page 63 for mounting it on the wall.)

Notes:

When attaching or removing the stand, place the main unit on a cushion or soft cloth to avoid damage. Remove the only specified screws. Malfunction may occur. Be careful not to lose the removed screws.

Caution:

Do not change the installation direction when the main unit is turned on. Disc may not be read or may be damaged.

Placing horizontally

1 Remove the 2 screws

and the stand.

Stand

2 Fix the removed screws.

3 Attach the included

button name label.

Button name label

Note:

Attach the button name label carefully. It is difficult to peel off.

Preparation for Use

04/10/16 HT-X1H(H)E2.fm

E-14

TINSZA030SJZZ

HT-X1H

ENGLISH

System connections

Make sure to unplug the AC power lead before making any connections.

Preparation for Use

Aerial connection

(see page 16)

AM loop aerial

FM aerial

Connecting the AC power lead

(see page 20)

Subwoofer/ amplifier unit

Main unit

White Red Green

Blue Grey

TV connection

(see page 18)

Connecting the system connection cable

Front speaker

(left)

White

Surround speaker

(left)

Centre

speaker

Green

(see page 16)

Front speaker

Surround speaker

(right)

Speaker connection (see page 17)

(right)

Red

SHARP TINSZA030SJZZ (H)

GreyBlue

E-15

04/10/16 HT-X1H(H)E2.fm

TINSZA030SJZZ

SHARP TINSZA030SJZZ (H)

Connect the main unit and subwoofer/amplifier unit as follows.

Subwoofer/ amplifier unit

Black

Blue

Main unit

Aerial terminals

Blue Black

! Connecting the system connection cable

! Aerial connection

Supplied FM aerial:

Connect the FM aerial wire to the FM 75 OHMS socket and position the FM aerial wire in the direction where the strongest signal can be received.

Supplied AM loop aerial:

Connect the AM loop aerial wire to the AM and GND terminals. Position the AM loop aerial for optimum reception. Place the AM loop aerial on a shelf, etc., or attach it to a stand or a wall with screws (not supplied).

Note:

Placing the aerial on the system or near the AC power lead may cause noise pickup. Place the aerial away from the system for better reception.

Installing the AM loop aerial:

< Assembling > < Attaching to the wall >

Wall Screws (not supplied)

External FM or AM aerial:

Use an external FM or AM aeri al if you require better reception. Consult your dealer. When using an external AM aerial, be sure t o keep the wire of the AM loop aerial connected.

AM loop

aerial

External FM aerial

FM aerial

AM loop aerial

External AM aerial

15 m

HT-X1H

ENGLISH

Preparation for Use

Earth wire

04/10/16 HT-X1H(H)E2.fm

Earth rod

7.5 m

E-16

TINSZA030SJZZ

HT-X1H

ENGLISH

System connections (continued)

! Speaker connection

Make sure to leave the AC power lead disconnected when connecting the speakers.

To prevent accidental short circuits between and terminals, connect the speaker wires to the speakers first and then to the subwoofer/amplifier unit.

When connecting speakers, match the colours of the back label, tube for the speaker wire, and speaker terminal of the subwoofer/amplifier unit.

1 Connect the wires to the speakers.

Example :To connect the left front speaker.

Label (white)

Red

Tube (white)

Black

2 Connect the other end to the

Preparation for Use

subwoofer/amplifier unit.

Subwoofer/ amplifier unit

Black

Tube (white)

Red

Speaker terminal (white)

Caution:

The supplied speakers are exclusively for the HT-X1H. Do

not connect them to other equipment, and do not connect other speakers to the HT-X1H. It may cause malfunction.

Do not mistake the and , and right and l eft terminals of the

speaker wires. (The right speaker is placed on the right when you face the subwoofer/amplifier unit.) Do not stand or sit on the speakers. You may be injured.

Do not allow any objects to fall into or to be placed in the bass

reflex ducts. The speaker grilles are not removable.

Do not short-circuit the speaker wire. If it

happens with the power on, the protection circuit is activated and the system enters the stand-by mode. In this case, check that the speaker wire is connected correctly before turning on the power again.

Incorrect

! Attaching the optional floor speaker stand

The front speakers and surround speakers support the optional floor speaker stand (see page 66). Remove the ori ginal stand for each speaker using a screwdriver first. For details, refer to the manual for the floor speaker stand.

E-17

Note:

Keep the removed speaker stands or screw in a safe place.

04/10/16 HT-X1H(H)E2.fm

TINSZA030SJZZ

! TV connection

Three types of sockets [AV (TV), S-VIDEO and VIDEO] are available for connection of a TV and the main unit. Connect according to your TV.

Connecting to a TV with SCART socket:

You can enjoy DVD images by connecting your TV and the main unit with the supplied SCART cable.

Set the video output mode to "SCART" (default setting). For the procedure, refer to "Changing the initial setting of DVD" on pages 56, 58.

Main unit

Connecting to a TV with an S-video input socket:

If your TV is equipped with an S-video input socket, you can enjoy higher quality images by connecting it with an S-video cable (not supplied).

Set the video output mode to "S-Video". For the procedure, refer to "Changing the initial setting of DVD" on pages 56, 58.

Main unit

To S-video output socket

Video signal

HT-X1H

ENGLISH

To SCART [AV (TV)] output socket

Video/audio signal

SCART cable (supplied)

To SCART input socket

S-video cable

To S-video input socket

Note:

When the video and S-video cables are both connected, the images from the S-video input socket appears on your TV.

04/10/16 HT-X1H(H)E2.fm

(commercially available)

TINSZA030SJZZ

Preparation for Use

E-18

HT-X1H

ENGLISH

System connections (continued)

Connecting to a TV with a video input socket:

If your TV is equipped only with a video input socket (without SCART), connect a video cable (not supplied) to enjoy images.

Set the video output mode to "S-Video". For the procedure, refer to "Changing the initial setting of DVD" on pages 56, 58.

Main unit

! Attaching the back cover

After making all the connecti ons, attach t he back cover to t he main unit. Fit the claws into the holes.

E-19

Preparation for Use

To video output socket

To video input socket

Notes:

Change the TV input in accordance with the connected socket.

Do not connect other equipment (VCR, etc.) between the TV and

the main unit. Images may be distorted. Refer to the operation manual of the equipment to be connected.

Insert the plugs fully to avoid fuzzy pictures or noise.

Video signal

Video cable (commercially available)

! Headphones

Before plugging in or unplugging the headphones, reduce the

volume. Be sure your headphones have a 3.5 mm diameter plug and are

between 16 ohms and 50 ohms impedance. The recommended impedance is 32 ohms. Plugging in the headphones disconnec ts the speakers automati-

cally. Adjust the volume using the VOLUME control.

04/10/16 HT-X1H(H)E2.fm

TINSZA030SJZZ

! Connecting the AC power lead

After checking all the connections have been made correctly, plug the AC power lead to the AC power input socket of the subwoofer/ amplifier unit, and then to the wall socket.

HT-X1H

ENGLISH

! To turn the power on

Press the ON/STAND-BY button.

If the power does not turn on, check if the AC power lead and sy stem connection cable are plugged in properly.

Subwoofer/

amplifier unit

Cooling fan

Wall socket (AC 230 V, 50 Hz)

Notes:

Never use a power lead other tha n the one supplied . Otherwise,

a malfunction or an accident may occur. Unplug the AC power lead from the wall soc ket i f the subwoofer/

amplifier unit will not be in use for a prolonged period of time.

Cooling fan:

A cooling fan is built into this subwoofer/amplifier unit for better heat radiation. Do not cover the opening in this section with any obstacles to avoid damage to the subwoofer/amplifier unit.

To set the system to stand- by mode:

Press the ON/STAND-BY button again.

Note:

After the system enters the powe r stand- by mode, wait a few seconds to turn on again.

Subwoofer/

amplifier unit

Main unit

Preparation for Use

04/10/16 HT-X1H(H)E2.fm

E-20

TINSZA030SJZZ

HT-X1H

ENGLISH

Remote control

! Battery installation

1 Remove the battery cover. 2 Insert the supplied batteries according to the direction indi-

cated in the battery compartment.

When inserting or removing the batteries, push them toward the

battery terminals.

3 Replace the cover.

Precautions for battery use:

Replace all old batteries with new ones at the same time.

Do not mix old and new batteries.

Remove the batteries if the system will not be used for long peri-

ods of time. This will prevent potential damage due to battery

Preparation for Use

leakage.

Caution:

Do not use rechargeable batteries (nickel-cadmium battery, etc.).

Installing the batteries incorrectly may cause the system to mal-

function.

Battery removal:

Remove the battery cover. Push each battery toward the battery terminal and take them out.

Notes concerning use:

Replace the batteries if the operating distance is reduced or if the

operation becomes erratic. Purchase 2 "AAA" size batteries (UM4, R03, HP-16 or similar). Periodically clean the transmitte r on the remote control and the

sensor on the main unit with a soft cloth. Exposing the sensor on the main unit to strong light may interfere

with operation. Change the lighting or the direction of the main unit if this occurs. Keep the remote control away from moisture, heat, shoc k, and

vibrations.

! Test of the remote control

Check the remote control after checking all the connections (see pages 15 - 20). Point the remote control directly at the r emote sensor on the main unit.

The remote control can be used within the range shown below:

Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy music.

The main unit is equipped with 2 remote sensors. Use them

according to the installation method as shown below.

Main unit

Remote sensor

0.2 m - 6 m

E-21

04/10/16 HT-X1H(H)E3.fm

TINSZA030SJZZ

General control

! Volume control

Main unit operation:

When the VOLUME control is turned clockwise, the volume will increase. When it is turned anti-clockwise, the volume will decrease.

Remote control operation:

Press the VOL (+ or -) button to increase or decrease the volume.

0 1 10

......

39 40

! Muting

The volume is muted temporarily when pressing the MUTE button.

Press again to restore the vol-

ume. The mute status is cancelled

when you adjust the volume.

! To change the display brightness (2 levels)

Hold the DISPLAY/(-DIMMER) button down for 3 seconds or more. Each time you press, brightness changes.

Dimmed

(*)

Brightened

HT-X1H

ENGLISH

Preparation for Use

(*) After approx. 5 seconds of DVD playback, the display dims and

the original brightness returns when you stop playback. The brightness remains unchanged during playback of other media.

04/10/16 HT-X1H(H)E3.fm

TINSZA030SJZZ

E-22

HT-X1H

ENGLISH

Playing a dis c

Turn on the TV, and switch the input to the "VIDEO 1" or "VIDEO 2", etc. accordingly.

Press the ON/STAND-BY button to turn the power on.

Press the button to set the input to "DVD".

Insert a disc into the disc insertion slot with t he la bel si de toward you.

The disc enters automatically.

Notes:

Do not push in the disc. Damage may result.

Load an 8 cm disc gently in the middle of the insertion slot

(do not use an adaptor.)

No Disc

DVD VideoCD CD

Audio Visual Entertainment

E-23

Disc insertion slot

Label side

DVD Operation

Label side

Disc insertion slot

Some discs play automatically.

04/10/16 HT-X1H(H)E3.fm

TINSZA030SJZZ

If playback does not start, press the (DVD/CD ) button.

The sound mode in use appears during DVD playback.

Play indicator

Chapter or track number

When the menu appears on the TV screen:

On DVD, select an item by using the cursor ( , , or ) button and press the ENTER button.

On super video CD or video CD, select an item by using the direct number buttons.

To interrupt playback:

Press the STILL button on the remote control.

To resume playback from the same point, press the DVD/CD button.

To stop playback: DVD:

Press the button twice.

SVCD/VCD/CD/MP3/WMA/JPEG:

Press the button.

Playing time

Caution w he n inserting disc:

Do not touch the playback side.

Do not insert two or more discs in the disc insertion slot.

Discs with labels, stickers or glue attached

may cause damage to the main unit.

Do not use discs of special shapes (heart, oc-

tagon, etc.) or 8 cm discs with an adaptor. Malfunction may result.

A disc with scratches or fingerprints may not play properly. Re-

fer to "Care of discs (page 66)" and clean the disc. Insert or remove the disc straight. Otherwise,

damage may result.

To remove the disc:

1. In the stop mode, press the button.

2. Remove the disc.

HT-X1H

ENGLISH

Disc

DVD Operation

04/10/16 HT-X1H(H)E3.fm

E-24

TINSZA030SJZZ

HT-X1H

ENGLISH

Playing a disc (continued)

Notes:

When you turn on the power or switch t he input to "DVD" i nitiali-

sation starts and operation is not possible for a few seconds. Stop positions may be recorded on some discs. When you play

such a disc, playback stops there. During an operation, " " may appear indicating that the opera-

tion is disabled by the disc. Some DVD discs may not f unction as described in the manual.

See the disc jacket for restrictions. Some CD-R/CD-RW may not play properly due to the stat us of

the disc or equipment used for record ing. Change the recording speed or disc. For more details, see the manual for the equipment. Sound may skip at high volume depending on the disc. In this

case, turn down the volume.

Caution:

Be careful not to damage the disc when inserting or removing it.

A disc does not play if damaged, dirty or loaded upside down.

Make sure to remove the disc before transporting the main unit.

Otherwise the disc inside may cause malfunction. Do not let coins, clips, etc. get into the disc inser tion slot. Mal-

function may occur. When attempting to play discs with scr atches or of a different

DVD Operation

region number, or unplayable or restricted (*1) discs, an error message will appear on the TV display and the disc will not play.

(*1)Viewing is prohibited on some DVDs according to the audi-

ence age.

! To resume playback after stopping (resume

play)

You can resume playback from the point playback is stopped.

Whilst the disc is playing, press the button.

The system stores the point you stopped.

To restart play, press the (DVD/CD ) button.

Playback resumes from the point you left off.

To cancel resume play:

Press the button again.

Notes:

The resume play feature is disabled on some discs.

Depending on the disc, playback may resume slight ly before the

position where it was stopped.

Pre-Stop

Play

Stop

E-25

04/10/16 HT-X1H(H)E3.fm

TINSZA030SJZZ

Basic operation

! Fast forw ard/Fast reverse (search)

You can search the desired point as you play the disc.

Whilst a disc is playing, hold down the or button for 2

seconds or more.

The scanning speed will change as follows at each press of the button.

The speed changes as follows on DVD/super video CD/video CD/audio CD:

Fast Forward 2x

HT-X1H

ENGLISH

! To locate the beginning of a chapter/track

(skip)

You can skip the current chapter (track) to the next or previous.

Whilst a disc is playing, press the

or button.

Press the button to skip to the next chapter (track).

On DVD/Super Video CD/Video CD/Audi o C D:

Press the button to skip to the beginning of the current chapter (track). Press the button again to skip to the beginning of the previous chapter (track).

On MP3/WMA/JPEG discs:

Press the button to skip to the beginning of the previous track (not the current one).

Notes:

Some discs do not display the chapter (track) and the skip f ea-

ture is disabled. On a DVD, you cannot skip across titles.

When operating super video CD or video CD with the P.B.C.

function, set the P.B.C. to off (see page 39).

Fast Reverse 2x Fast Reverse 8x Fast Reverse 30x Play

The disc is forwarded by the button and reversed by the

button.

The speed cannot be changed on MP3 and WMA discs.

Press the (DVD/CD ) button to return to the normal playback.

Notes:

On some discs, the search function is disabled.

On a DVD, search does not operate across titles.

On an MP3 and WMA, search does not operate across files.

Whilst searching on a DVD, super video CD or video CD, the

sound is not heard and the subtitles will not appear. Audio CD or MP3/WMA disc sounds will break up during search.

This is not a malfunction. When search is performed during the playback, pictures may not

be forwarded or reversed in the search speed specif ied in this manual, depending on the disc or the scene being played.

04/10/16 HT-X1H(H)E3.fm

Fast Forward 2x

Fast Forward 8x

Fast Forward 30x

Play

TINSZA030SJZZ

DVD Operation

E-26

HT-X1H

ENGLISH

Basic operation (continued)

! To start playback from the desired point (direct

play)

To select and play the desired title:

Playback starts from chapter 1 of the selected title.

Whilst in the stop or playback mode, press the DIRECT button.

Within 10 seconds, select the title by pressing the cursor ( or ) button.

Enter the desired title number by using the direct number buttons.

Within 10 seconds, press the ENTER button.

To select and play the desired chapter:

Perform steps 1 - 3 of "To select and play the desired title"

DVD Operation

above.

Within 10 seconds, select the chapter by pressing the cursor ( or ) button.

Enter the desired chapter number by using the direct number buttons.

Title number

Chapter number

Entering title or chapter numbers using the direct number buttons: If the number is 2 digits or more, press "+10" and enter the number.

Example:

To select chapter 1, press "1". To select chapter 12, press "+10" and "2". To select chapter 22, press "+10", "+10" and "2". To select chapter 112, press "+10" eleven times and press "2".

To play by specifying time (time search):

/ 0801

--:--:--001 / 010

Whilst a disc is playing, press the DIRECT button.

Within 10 seconds, select the time by pressing the cursor ( or ) button.

Specify the time by using the direct number buttons.

To specify 1 hour 23 minutes and 40 seconds, enter

"012340". If you enter the wrong number, start over from step 1.

Within 10 seconds, press the ENTER button.

Notes:

Some discs cannot play from the specified point.

Time search feature is disabled on some discs.

Time

001 / 010 --:--:--

E-27

Within 10 seconds, press the ENTER button.

Notes:

Direct play feature is disabled on some discs.

Some discs may not display the chapter number.

04/10/16 HT-X1H(H)E3.fm

TINSZA030SJZZ

Useful operat ion

The subtitle language and the audio language you select during playback are reset each time y ou set this system to the stand-by mode or change the disc. To keep your preferred languages, set them in the initial setting screen (see page 56).

! To change the subtitle language

You can change the subtitle language or hide subtitles during playback.

Whilst a disc is playing, press the SHIFT button and then the SUBTITLE button.

Repeat step 1 to select the desired subtitle language.

English French Spanish Subtitle Off

You can select one from the subtitle languages that are re-

corded on a DVD. To hide subtitles on the screen, select "Subtitle Off".

Notes:

Some DVDs prohibit changing the subtitle language.

If no subtitles are recorded on the disc, " " is displayed.

It may take a little time to switch the subtitle language to the

selected one. When you set the unit to the stand-by mode or replace t he disc,

settings return to the default.

Subtitle 01/09: English

Subtitle 02/09: Spanish

HT-X1H

ENGLISH

DVD Operation

04/10/16 HT-X1H(H)E3.fm

E-28

TINSZA030SJZZ

HT-X1H

ENGLISH

Useful operation (continued)

! To change the audio language (audio output)

During playback, you can change t he audio language (audio output).

Whilst a disc is playing, press the SHIFT button and then the

AUDIO button.

Repeat step 1 to select the desired audio number.

Audio language information

Audio 1/3: AC-3 5.1 English

! To brighten an image

During playback, press the SHIFT button and then the GAMMA button to select "ON".

"ON" and "OFF" will be switched by each press of these buttons.

Within 10 seconds, press the cursor ( or ) button to set the

level.

OFF

E-29

When playing DVD, the language changes as follows:

Audio 1/3: AC-3 5.1 English

Audio 2/3: AC-3 2 English

When playing super video CD, video CD, audio CD and MP3, the sound changes as follows:

DVD Operation

Mono Left Mono Right Stereo

Notes:

The audio language on some DVDs may not be changed.

For audio language and audio system, refer to the manual of th e

disc. When you set the unit to the stand-by mode or replace the disc,

settings return to the default.

1: Original <English> (Dolby Digital 5.1

2: English (Dolby Digital 2 ch Surround)

Surround)

Level Setting Level Setting

OFF Normal image ON Brighter ON Slightly brighter ON A lot brighter

To restore the original brightness:

In step 1, select "OFF".

04/10/16 HT-X1H(H)E3.fm

TINSZA030SJZZ

HT-X1H

ENGLISH

! To improve the image quality

During playback, press the SHIFT button and then the S.PICTURE button to select "ON".

"ON" and "OFF" will be switched by each press of these buttons.

Within 10 seconds, press the cursor ( or ) button to set the

level.

Level Setting Level Setting

OFF Normal ON Clearer ON Slightly clearer ON A lot clearer

To restore the original image quality:

In step 1, select "OFF".

OFF

DVD Operation

04/10/16 HT-X1H(H)E3.fm

E-30

TINSZA030SJZZ

HT-X1H

ENGLISH

Useful operation (continued)

! To select a title from the top menu of the disc

On a DVD with multiple titles, you can select a title from the top menu.

In the stop mode or during playback, press the SHIFT button and then the TOP MENU/MENU button.

Press the cursor ( , , or ) button to change the setting and press the ENTER button.

The selected title is played.

You can also use the direct number buttons for some discs.

Note:

The procedure shown here provides only general steps. The actual procedure for using the disc menu depends on the disc you are using. See the disc jacket for details.

! To select a subtitle or audio language from the

disc menu

You can select the desired subtitle/audio language and sound system (5.1 ch Dolby Digital or DTS sound) on your DVD if it has a disc menu.

DVD Operation

In the stop mode or during playback, press the TOP MENU/ MENU button.

Press the cursor ( , , or ) button to change the setting and press the ENTER button.

You can also use the direct number buttons for some discs.

Note:

The procedure shown here provides only general steps. The actual procedure for using the disc menu depends on the disc you are using. See the disc jacket for details.

Example

1. Highlights

2. Start Movie

21 Drama Action

Comedy

43SF

! Still picture/Frame advance

You can freeze the image and advance frame by frame.

Whilst a disc is playing, press the STILL button.

Each press of the STILL button advances the frame in the still mode.

Press the (DVD/CD ) button to return to the normal playback.

Note:

Still picture and frame advance features are disabled on some discs.

Pause

! Slow-motion play

You can slow down the playback speed.

Whilst a disc is playing, press the STILL button.

Hold down the or butt on for 2 seconds or more.

Press the (DVD/CD ) button to return to the normal playback.

Note:

On some discs, slow-motion play functions are disabled.

Pause

Slow Forward

Slow ForwardSlow Backward /

SHARP TINSZA030SJZZ (H)

E-31

04/10/21 HT-X1H(H)E4.fm

TINSZA030SJZZ

! To change the angle

You can change the angle of view when playing a DVD video disc that contains scenes recorded from multiple angles.

When " " appears on the TV during playback, press the SHIFT button and then the ANGLE button.

TV screen Unit display

Repeat step 1 to select the desired angle number.

Notes:

Some DVDs prohibit changing the angle.

The angle number is not displayed if there is no other angle

recorded. " " is displayed instead. Refer to the manual of the disc as the operation may vary

depending on the disc.

! To zoom in on an image (zoom)

You can magnify images during playback.

Whilst a disc is playing, press the SHIFT button and then the ZOOM button.

Repeat step 1 to select the desired zoom setting.

Zoom x 1.5 Zoom x 2 Zoom x 3 off (no indicator)

To shift the view and display the desired part of a zoomed image, press the cursor ( , , or ) button repeatedly.

Zoom x 1.5

1.5 x

HT-X1H

ENGLISH

DVD Operation

SHARP TINSZA030SJZZ (H)

To return to normal view:

Press the SHIFT button and then the ZOOM button. Repeat this to select "Zoom off". When you cancel the zoom function, you cannot shift the view.

Notes:

An image may become distorted when zoomed.

Subtitles cannot be zoomed.

The position of the current part is indicated in the lower left of the

screen.

E-32

04/10/21 HT-X1H(H)E4.fm

TINSZA030SJZZ

HT-X1H

ENGLISH

E-33

Useful operation (continued)

! To play in the desired order (programmed play-

back)

You can play back the desired chapters, tracks or files in the sequence you want. Maximum of 40 numbers can be programmed.

Whilst in the stop mode, press the RANDOM/PROGRAM button.

The programming screen appears.

Press the cursor ( or ) button to select "Add" and press the ENTER button.

When programming for discs other than DVD, go to step 4.

Press the cursor ( or ) button to select a title number and press the ENTER button.

The chapter selection screen appears.

Press the cursor ( or ) button

DVD Operation

to select a number and press the ENTER button.

Repeat steps 3 - 4 to programme more. Up to 40 chapters, tracks or files can be programmed.

Program List

No. Program Info.

Program List

No. Program Info. Select

1 T - ? --:--

Program List

No. Program Info. Select

1 T - 1 C - ? --:--

Program List

No. Program Info. Select

1 T - 1 C - 1 06:03 2 T - 3 C - 5 05:06

3 T - 5 C - ? --:--

Add

Insert Modify Delete Clear All

Exit

Title 1

Title 2 Title 3 Title 4 Title 5

Chapter 1

Chapter 2 Chapter 3 Chapter 4 Chapter 5

Chapter 1 Chapter 2

Chapter 3

Chapter 4 Chapter 5

Press the cursor ( ) button to finish programming.

To delete the wrong number, press the cursor ( or ) button to select it and press the CLEAR button.

Use the cursor ( or ) button to select a number to start with, and press the (DVD/CD )

button.

Playback starts from the select-

Program List

No. Program Info. Select

1 T - 1 C - 1 06:03 2 T - 3 C - 5 05:06

3 T - 5 C - 7

Program List

No. Program Info. Select

1 T - 1 C - 1 06:03

2 T - 3 C - 5 05:06 3 T - 5 C - 7

04:53

Chapter 1 Chapter 2 Chapter 3 Chapter 4 Chapter 5

ed number and ends after the last number in the programme.

"PROGRAM" lights up on the

main unit during programmed

play. Programmed numbers are

stored until a disc is removed or you turn the power off.

To change the programmed contents:

1 Whilst stopped, press the RANDOM/PROGRAM button to show

the programming screen. 2 Press the TOP MENU/MENU button to show the menu list. 3 Use the cursor ( or ) button to select the desired menu item and

then press the ENTER button.

"Add" Adds a chapter, track or file to the programme.

"Insert" Inserts a chapter, track or file above (before) the se-

lected number of a programme.

"Modify" Modifies the programme.

"Delete" Deletes the selected number.

"Clear All" Deletes the programme.

"Exit" Turn off the programming screen. Notes:

Titles cannot be programmed.

Programming cannot be performed whilst paused or in the pl ay-

back mode.

On some discs, programmed play does not work.

04/10/21 HT-X1H(H)E4.fm

TINSZA030SJZZ

! To play repeatedly (repeat play)

You can play a chapter (track) or a title repeatedly by s pecifying it during playback.

Whilst the disc is playing, press the A B REPEAT/ button.

Each time the button is pressed, the repeat play mode changes in the following order.

TV screen Unit display

For DVD, the mode changes as follows:

Chapter Repeat on

Title Repeat on

Repeat off

For super video CD/video CD/audio CD, the mode changes as follows:

Track Repeat on

Disc Repeat on

Repeat off

For MP3/WMA/JPEG discs, the mode changes as follows:

File Rep

Folder Rep

Disc Rep

Rep off

Disappear

Repeats the chapter currently playing.

Repeats the title currently playing.

The normal playback

Repeats the track currently playing.

Repeat play of all of the tracks.

The normal playback

Repeats the file currently playing.

Repeats the folder (directory) currently playing.

Repeat play of all of the files.

The normal playback

Select "Repeat off" by pressing the A B REPEAT/ button repeatedly to return to the normal playback.

Caution:

After performing repeat play, be sure to press the button. Otherwise, the disc will play continuously.

Notes:

Repeat play is not available on some discs.

Repeat play is not possible during random play.

When operating super video CD or video CD with the P.B.C.

function, set the P.B.C. to off (see page 39).

HT-X1H

ENGLISH

DVD Operation

04/10/21 HT-X1H(H)E4.fm

E-34

TINSZA030SJZZ

HT-X1H

ENGLISH

Useful operation (continued)

! To play the contents between the specified

points repeatedly (A-B repeat)

You can play the desired portion repeatedly by specifying it during playback.

Whilst a disc is playing, press the SHIFT button and then the A B REPEAT/ button.

TV screen Unit display

A-B Set A

! To change the display on the main unit

During playback, press the DISPLAY/(-DIMMER) button.

Each time you press the button, the display will change as follows:

DVD:

Title elapsed time Title/Chapter

number

Chapter elapsed time

E-35

This registers the start point (A).

Press the SHIFT button and then the A B REPEAT/ button again to enter the end point (B).

A-B Repeat on

A-B repeat plays from the start point (A) to the end point (B).

Press the SHIFT button and then the A B REPEAT/ but-

DVD Operation

ton to return to the normal playback.

Notes:

A-B repeat play is disabled on some discs.

Some scenes in DVD may not allow A-B repeat play.

A-B repeat play for DVD is possible only within a title.

A-B repeat play for super video CD, video CD and audio CD are

possible only within a track. When you press the button, the current A-B repeat play is can-

celled. (For DVD, press the button twice.)

SVCD/VCD/CD:

Track elapsed time Total elapsed time

Notes:

Title/chapter numbers or elapsed time may not appear depend-

ing on the disc.

The playing time of the disc specified on the jacket, etc. may not

include silence between tracks, and may differ from that dis-

played on the main unit.

Elapsed time on the display does not indicate the actual time.

When operating super video CD or video CD with the P.B.C.

function, set the P.B.C. to off (see page 39).

04/10/21 HT-X1H(H)E4.fm

TINSZA030SJZZ

! To change the display on TV screen

You can display or hide the operation indicators on the TV screen.

Whilst the disc is playing, press the ON SCREEN button. (The display is changed at each press of this button.)

When playing DVD, the display changes as follows:

When playing a super video CD, video CD or audio CD, the di splay changes as follows:

1 / 19 01:02

L R

Track playing time Repeat mode information PBC information (VCD) Audio information

HT-X1H

ENGLISH

1 / 8 2 / 10 00:38:58

1 / 8 2 / 10 -01:09:50

1 / 8 2 / 10 00:07:43

1 / 8 2 / 10 -00:02:38

DEF 1/9 DEF1/3 1 / 3

Title playing time Total number of chapters Current chapter number Total number of titles Current title number Disc type

Remaining playing time of the current title

Chapter playing time

Remaining playing time of the current chapter

Angle information Repeat mode information Audio language information Subtitle information

1 / 19 -03:14

1 / 19 20:00

1 / 19 -40:37

L R

Remaining track playing time

Elapsed total playing time

Remaining total playing time

Note:

On super video CD or video CD, elapsed total playing time or remaining total playing time appears when P.B.C is off (see page

39).

DVD Operation

E-36

04/10/21 HT-X1H(H)E4.fm

TINSZA030SJZZ

HT-X1H

ENGLISH

Playing an audio CD

The following playback functions are the same as DVD operations.
