Package Contents
1
Package Contents
Package Contents
Handset (AQUOS R)
・Battery is built into handset.
・Handset back cover is not removable.
TV Antenna Cable (Complimentary sample)
クイックスタート (Japanese)
お願いとご注意 (Japanese)
Warranty
1/13
『aquos-r_01_Getting Started.docx』
Parts & Functions
Name
Description
Front Camera
Use to shoot photos or
videos of yourself.
Proximity/Light
Sensor
Proximity Sensor
prevents Touchscreen
misoperation during
calls. Light Sensor
adjusts Display
brightness according
to ambient light.
Display
Touchscreen-type
display; operate with
your fingers on
Display.
Mobile Light
Use as a light when
shooting
photos/videos with
Front Camera.
Earpiece
Hear the other party's
voice here.
Charging/Notificatio
n Lamp
Illuminates while
charging or for
incoming
calls/messages and
notifications.
2
Handset (Front)
Handset (Back and Sides)
Handset Keys
Handset (Front)
2/13
『aquos-r_01_Getting Started.docx』
Handset (Back and Sides)
Name
Description
Mic (Recorder
Mic)
Use while recording
videos or when talking
through
Speakerphone.
Camera
Shoot photos or
videos.
Mobile Light
Use as a camera
flash, flashlight, etc.
FeliCa mark
Hold up to
reader/writer to use
NFC/Osaifu-Keitai®.
External
Connection Jack
Connect AC Adaptor
or Micro USB Cable
here.
Mic/Recorder Mic
Talk to the other party
here. Also use while
recording videos or
when talking to
emopa.
Strap Eyelet
Attach straps here.
Earphones-
Microphone Jack
Connect TV Antenna
Cable or Earphones
with Mic (optional
accessory) here.
Card Slot
Insert/remove SD
Card and USIM Card.
Speaker
Listen to music, video
sound, TV, etc.
3
3/13
『aquos-r_01_Getting Started.docx』
Handset Keys
Name
Description
Volume Up Key
Increase volume.
Volume Down
Key
Decrease volume.
Long Press in lock
screen to
activate/cancel
Manner mode.
Shutter Key
Shoot photos. Long
Press to activate
(SHCamera). Press
twice with Display on
to activate Front
Camera, specified
shooting mode, etc.
(Power Key)
Turn Display off/on.
Long Press for power
on/off or reboot.
4
4/13
『aquos-r_01_Getting Started.docx』
USIM Card
① IC (gold) chip
5
USIM Card is an IC card containing phone number and other customer information.
Handling USIM Card
Inserting USIM Card
Removing USIM Card
SIM-Unlocking Handset
Handling USIM Card
See instructions included with USIM Card for handling.
Avoid applying labels. May damage USIM Card.
USIM is replaceable (at cost) in case of loss/damage.
Wipe clean with a dry, soft cloth.
Always keep the IC (gold) chip clean.
USIM Card Cautions
Observe the following when using USIM Card.
Always follow emergency procedures to suspend service if your USIM Card or
handset (USIM Card inserted) is lost/stolen. For details, contact Customer Service.
Customer is responsible for any damage caused by inserting USIM Card in an other-
brand IC card reader, etc. SoftBank Corp. is not responsible in such case.
It is recommended that you back up information that is saved on USIM Card.
SoftBank Corp. is not responsible for damages from saved information that is lost.
Always power off handset before inserting/removing USIM Card.
Note that USIM Card specifications and performance may change without notice.
Return USIM Card to SoftBank Corp. when canceling subscription.
USIM Card is the property of SoftBank Corp.
Returned USIM Cards are recycled for environmental purposes.
5/13
『aquos-r_01_Getting Started.docx』
Inserting USIM Card
6
Always power off beforehand.
Set USIM Card in USIM Tray beforehand. Do not insert USIM Card without setting it in USIM
Tray.
Open Card Slot Cap by hooking a finger on notch (○)
Pull out USIM Tray
Do not pull USIM Tray forcefully or at an angle; damage may result. Gently pull it out horizontally
by hooking a finger on it.
6/13
『aquos-r_01_Getting Started.docx』
7
Set USIM Card in USIM Tray
Place gently, noting orientation of USIM Card (notch/IC (gold) chip facing up).
Make sure USIM Card is in USIM Tray. Inserting USIM Tray with USIM Card on its edge may
cause damage.
Close Card Slot Cap
Push Card Clot Cap as shown ( and ) to close, then push it firmly all the way from circled
area (○) to hinge as shown ( ) so that there is no gap between handset and Card Slot Cap.
Removing USIM Card
Always power off beforehand.
7/13
『aquos-r_01_Getting Started.docx』
8
Open Card Slot Cap by hooking a finger on notch (○)
Pull out USIM Tray
Do not pull USIM Tray forcefully or at an angle; damage may result. Gently pull it out horizontally
by hooking a finger on it.
Remove USIM Card
8/13
『aquos-r_01_Getting Started.docx』
9
Close Card Slot Cap
Push Card Clot Cap as shown ( and ) to close, then push it firmly all the way from circled
area (○) to hinge as shown ( ) so that there is no gap between handset and Card Slot Cap.
SIM-Unlocking Handset
Handset can be SIM-unlocked. SIM-unlocking handset allows other-carrier SIM cards to be used
with it.
Some services, functions, etc. may have restrictions when an other-carrier SIM card is used.
SoftBank Corp. does not guarantee operation whatsoever.
For details on SIM unlocking, see SoftBank Website.
9/13
『aquos-r_01_Getting Started.docx』
Charging Handset
10
Battery is built into handset.
Internal Battery
About Charging
Charging with AC Adaptor
Internal Battery
A lithium-ion battery is built into handset; it is not removable.
Recycling
This product requires a lithium-ion battery. Lithium-ion batteries are recyclable. To
recycle a used lithium-ion battery, take it to any shop displaying the recycling symbol.
Battery Cautions
Storage
To help maintain performance and life of Internal Battery, do not store in the following
conditions (battery level should be at approximately 40% for optimal storage).
Full (immediately after charging is complete)
Exhausted (too low to power on handset)
Bulges of Internal Battery
10/13
『aquos-r_01_Getting Started.docx』
Depending on use, bulges may appear near end of battery life; this does not affect
Charging Option
Description
AC Adaptor
Connect handset and AC Adaptor (sold
separately) directly.
USB charging
Connect handset and a PC with Micro USB
Cable (optional accessory).
11
safety.
Internal Battery Replacement
Internal Battery is a consumable item; may need to be replaced if operating time
shortens noticeably. Internal Battery is not user replaceable; its replacement incurs fees
and requires handset submission to a SoftBank Shop or other appropriate servicer. For
details, contact a SoftBank Shop or SoftBank Customer Support, General Information.
About Charging
The following charging options are available.
Charging/Notification Lamp
Charging/Notification Lamp illuminates red while charging; illuminates green when
charge is almost full.
Charging/Notification Lamp goes out when charge is full.
If Charging/Notification Lamp is blinking, charging is not working properly. Make sure
that you are using Charger and products specified by SoftBank Corp. If you are using
specified products only, contact a SoftBank Shop or SoftBank Customer Support,
General Information.
Charging Cautions
Water Resistance
AC Adaptor (sold separately) and Micro USB Cable (optional accessory) are not
waterproof. Never connect Micro USB plug while handset or Charger is wet.
Handset is water resistant; however, if Micro USB plug is inserted while it is wet, liquid
(tap water, beverage, sea water, pet urine, etc.) or a foreign object adhered to handset
or Micro USB plug may cause overheating, burnout, fire, malfunction, burns, etc. due to
electric shock, short-circuiting, etc.
Handling Cords
Do not pull, bend, or twist cord; may damage the cord.
About Charging Abroad
11/13
『aquos-r_01_Getting Started.docx』
SoftBank Corp. is not liable for problems resulting from charging handset abroad.
12
Charging with AC Adaptor
Purchase and use ZSCAZX (USB Type-C Quick ChargeTM 3.0 AC Adaptor)
For information on other peripheral devices, see SoftBank Website.
The following explains how to charge handset using ZSCAZX (USB Type-C Quick ChargeTM 3.0
AC Adaptor).
1 SB-AC17-TCQC (SoftBank SELECTION Qualcomm
smartphones)
®
Quick ChargeTM 3.0 AC Adaptor for
1
.
Insert Micro USB plug of AC Adaptor into External Connection Jack
Insert Micro USB plug in correct orientation; otherwise, External Connection Jack may be
damaged. Check contours and orientation of Micro USB plug, then insert it with tabs (○) facing
down.
12/13
『aquos-r_01_Getting Started.docx』
13
Raise plug on AC Adaptor and plug into household AC outlet
Charging/Notification Lamp illuminates once charging starts.
Charging/Notification Lamp goes out when charge is full.
After charging, remove Micro USB plug from External Connection Jack, then unplug
AC Adaptor and lower plug
13/13
『aquos-r_01_Getting Started.docx』
Specifications
Item
Description
Dimensions (W x H x D)
Approx. ●● mm x ●●● mm x ●.● mm
(without protruding parts)
Weight
Approx. ●●● g
Maximum Output
3G: ●.●● W
GSM (850 MHz, 900 MHz): ● W
GSM (1800 MHz, 1900 MHz): ● W
4G: ●.● W
Internal Battery Capacity
●,●●● mAh
Continuous Talk Time
1
3G: Approx. ●●● minutes
GSM: Approx. ●●● minutes
VoLTE: Approx. ●●● minutes
Continuous Standby Time
2
3G: Approx. ●●● hours
GSM: Approx. ●●● hours
4G (AXGP Network): Approx. ●●● hours
4G (FDD-LTE Network): Approx. ●●● hours
TV Continuous Viewing Time
3
Approx. ● hours
Charging Time
4
ZSDBA4 (Micro USB Quick ChargeTM 2.0 AC
Adaptor)
5
: Approx. ●●● minutes
ZSDBA6 (Micro USB 1.0 A AC Adaptor)6: Approx.
●●● minutes
Maximum Transmission Speed
7
SoftBank 4G LTE: ●●●.● Mbps8 in downlink,
●●.● Mbps in uplink
SoftBank 4G: ●●● Mbps9 in downlink, ●●
Mbps in uplink
14
Handset
TV Antenna Cable
Materials
Handset
Handset specifications are as follows.
Times in the table vary with location, status, settings, etc.
Display employs precision technology; however, some pixels may remain on/off.
1/6
『aquos-r_11_For Assistance.docx』
SoftBank 3G: ●● Mbps in downlink, ●.● Mbps
in uplink
1 Average measured with handset fully charged, in strong signal conditions at rest.
Item
Description
Cable Length
Approx. 136 mm (including plug and jack)
Weight
Approx. 5 g
4-Pole Mini-Plug
Round type, diameter 3.5 mm, 4-pole
Materials Used/Surface Finish
Elastomer resin + Nickel base + brass + PP resin
+ POM resin/gold plating
Parts
Materials Used/Surface Finish
Display Surface
Tempered glass/AF coating
Back Surface
Acrylic resin + PC resin/hard coating
Side Surface
PC resin + ABS resin/coating, hard coating, printing
Exterior
PA resin (containing glass)/coating, hard coating
15
2 Average measured with handset fully charged, without calls or operations, in strong signal
conditions at rest, and with data communication and Urgent News disabled. May vary with battery
strength, ambient temperature, settings, etc.
3 Calculated in full-screen landscape mode, with Automatic brightness in Brightness level disabled
(and with the default Brightness settings), with Earphones with Mic (sold separately), and volume
at maximum, starting from handset fully-charged and continuing until 10% remaining battery
charge.
Usable time may vary with radio signal conditions and the content played.
4 Measured with power off using AC Adaptor.
5 SB-AC12-HDQC (SoftBank SELECTION Qualcomm
smartphones)
6 SB-AC13-HDMU (SoftBank SELECTION Micro USB 1.0 A AC Adaptor for smartphones)
7 Provided on a best-effort basis; transmission speed may decrease or transmission may become
unavailable due to traffic conditions, network environment, etc.
8 Available in certain areas. Depending on area, maximum downlink speed is set to ●●● Mbps,
●●●.● Mbps, ●● Mbps, or ●●.● Mbps or less.
®
Quick ChargeTM 2.0 AC Adaptor for
9 Depending on area, maximum downlink speed is set to ●●● Mbps or less.
TV Antenna Cable
Materials
2/6
『aquos-r_11_For Assistance.docx』
3/6
Shutter Key
Aluminum/anodizing
Power Key
Aluminum/anodizing
Volume Up/Down Key
Aluminum/anodizing
Camera Panel
Tempered glass/AR coating
Camera Ornament
Aluminum/anodizing
Earpiece Screen
Polyester resin/water-repellent treatment
External Connection Jack (metal part)
Copper alloy + SUS/gold plating, tin plating
External Connection Jack (resin part)
PA resin
Card Slot Cap
PC resin/coating, hard coating
Card Slot Cap Hinge
Elastomer resin
Card Slot Cap Gasket
EPDM
USIM Card Slot
SUS
SD Card Slot
SUS/nickel plating
USIM Tray
POM resin
IMEI Plate
PET resin
16
『aquos-r_11_For Assistance.docx』
Warranty & After-Sales Service
17
Warranty
After-Sales Service
Warranty
Handset purchase includes warranty.
Check shop name and purchase date.
Read warranty and keep in a safe place.
Warranty period is given in warranty.
Cautions
Damages
SoftBank Corp. is not responsible for any damages for user or third party resulting from
lost opportunities to make a call, etc. due to breakage, malfunction, or trouble of
product.
Malfunction/Repairs
Information/settings on handset may be lost/changed due to malfunction or repairs. It is
recommended that you keep a copy of Address Book contacts and other important
information. SoftBank Corp. is not responsible for loss/change of data (contacts,
images, sound, etc.) or settings due to malfunction, repairs, change of model, or any
other handling.
Disassembly/Modification
Disassembly/modification of handset is prohibited under the Radio Law. Note that
handset cannot be accepted for repairs if modified.
Adhering stickers, etc. on Display or Keys or adhering decorations with glue, etc. may
be deemed to be modifications, and prevent acceptance of handset for repairs.
After-Sales Service
To request repairs, contact Customer Service or a nearby SoftBank Shop. Have details of
symptoms ready.
During the warranty period, repairs are made under the terms and conditions of the warranty.
4/6
『aquos-r_11_For Assistance.docx』
After the warranty period, if handset can be repaired, repairs will be made at cost.
18
Further inquiries
For more information on after-sales service, contact a nearby SoftBank Shop or
Customer Service.
5/6
『aquos-r_11_For Assistance.docx』
Loading...
