SHARP AR-122E, AR-152E, AR-153E, AR-157E Diagram

q

DIGITAL LASER COPIER /
DIGITAL MULTIFUNCTIONAL SYSTEM

PARTS GUIDE

CODE:00ZAR157E//P1

AR-122E
AR-152E
AR-153E

(AR-157E)

1

Exteriors

2

Original cover unit (AR-122E/152E/153E)

3

RSPF exteriors (AR-157E)

4

RSPF transport unit (AR-157E)

5

RSPF SPF pick up unit (AR-157E)

6

Operation panel

7

Side door unit

8

Optical frame

9

LSU unit

F

Delivery paper guide unit

G

Middle frame

H

Base plate unit 1

I

Base plate unit 2

J

Fusing unit

K

Drive unit

L

Single manual paper feeding cover unit
(AR-122E/152E)

M

Multi manual paper feeding cover unit
(AR-153E/157E)

CONTENTS

N

(AR-122E/152E)

O

P
Q
R
S
T
U
V
W
X
Y
Z
[

■

MODEL

Single manual paper feeding unit

Multi manual paper feeding unit
(AR-153E/157E)

Socket holder unit

TC case unit

250 sheets tray

Harness

2ND frame unit (AR-157E)

2ND paper feeding unit (AR-157E)

Packing material & accessories

Operation PWB

MCU PWB

DC power supply PWB (120V Series)

DC power supply PWB (127V Series)

DC power supply PWB (200V Series)

Index

AR-157E

Because parts marked with "!" is indispensable for the machine safety maintenance and poeration, it must
Be replaced with the parts specific to the product specification.

This document has been published to be used for

SHARP CORPORATION

after sales service only.
The contents are subject to change without notice.

DEFINITION

The definition of each Rank is as follows and also noted in the list

A: Parts necessary to be stocked as High usage parts.
B: Parts necessary to be stocked as Standard usage parts.
C: Low usage parts.
D: Parts necessary for refurbish.
E: Unit parts recommended to be stocked for efficient after sales service.

Please note that the lead time for the said parts may be longer than normal parts.
S: Consumable parts.
Please note that the following parts used in Copier under the same description are classified into A or B Rank depending upon

the place used.
Example: Gear made of Metal, Sprocket, Bearing, Belt made of Rubber, Spring clutch mechanism.
ARank : The parts which may be with the revolution or loading.
BRank : Parts similar to A Rank parts, but are not included in Rank A.

Because parts marked with "!" is indispensable for the machine safety maintenance and operation, it must be replaced with
the parts specific to the product specification.

F Other than this Parts Guide, please refer to documents Service Manual(including Circuit Diagram)of this model.
F Please use the 13 digit code described in the right hand corner of front cover of the document, when you place an order.
F For U.S. only-Use order codes provided in advertising literature. Do not order from parts department.

Exteriors

1

PRICE

NEW

NO. PARTS CODE

1 CCAB-0003QS23 AS N D Front cover
2 LSOU-0001QSJZ AY N D Delivery tray
3 XEBSE30P08000 AA CScrew(3×8)
4 LSOU-0008QSJZ AH N D Extension tray
5 XEBSE40P12000 AA CScrew(4×12)
6 PTPE-0041QSZZ AB N C Glass fixing tape B
7 DHAI-0285QSZZ AK N C OP-MCU harness
8 PSHEZ0369QSZZ AE N C Shading sheet

9 XBBSE30P08000 AA CScrew(3×8)
10 GCAB-0061QSZZ AK N D Left exterior
11 TLABH0403QSZZ AF N C Operation instruction label

GCOV-0045QSZZ AG D Rear cover SPF (AR-157E)

12

GCOV-0045QSZ1 AG N D Rear cover OC (AR-122E/152E/153E)
13 CFIX-0021QS01 AG N D Glass fixing plate
14 PGLSP0007QSZZ AV N B Table glass
15 PTPE-0040QSZZ AC N C Glass fixing tape A

PCOVP0035QSJZ AL N D Rear exterior cover JAG (AR-122E/152E)
16

PCOVP0040QSJZ AL D Rear exterior cover SPF (AR-153E/157E)

GCAB-0062QSZ1 AL N D Right exterior OC (AR-122E/152E)

17

GCAB-0062QSZZ AL D Right exterior (AR-153E/157E)

GCAB-0021QSJ1 AY N D Rear exterior (AR-122E/152E)

18

GCAB-0026QSJ2 AZ D Rear exterior SPF (AR-153E/157E)
19 TCAUA0770FCZZ AB D Service caution label
20 PMLT-0024QSZZ AC C Fan cushion
21 PFILZ0002QSZZ AL DOzone filter
22 PTPE-0044QSZZ AC C Slit glass tape (AR-153E/157E)
23 PGLSP0008QSZZ AH B SPF glass (AR-153E/157E)
24 PSHEZ0181QSJZ AC C Rear cabinet maylar (AR-153E/157E)
25 PTPE-0010QSZZ AC C Slit glass tape (AR-153E/157E)
26 TLABZ0058QSZZ AD D Class 1 label (AR-122E/152E)
27 PMLT-0069QSZZ AA N C Ground malt (AR-153E/157E)
28 PSHEZ0404QSZZ AF N C Right cabinet ground sheet (AR-153E/157E)
29 PTPE-0047QSZZ AC N C Ground tape F (AR-153E/157E)
30 PTPE-0048QSZZ AA N C Ground tape R (AR-153E/157E)

501 CFIX-0021RS51 BB N E Table unit

RANK

MARK

PART
RANK

DESCRIPTION

Original cover unit (AR-122E/152E/153E)

2

PRICE

NEW

NO. PARTS CODE

1 GCOVH0003QSJZ AL N D OC cover S
2 GCOVH0004QSJ1 AX N D OC cover M
3 PCUSS0024QSZZ AV NDOC mat

(Unit)

901 CCOVH0004RS54 BF N E OC cover unit

RANK

MARK

PART
RANK

DESCRIPTION

– 1 –

1

Exteriors

9

AR-122E
AR-152E

18

26

9

12

24

20

21

16

9

20

11

21

7

9

19

9

AR-153E
AR-157E

13

10

15

8

6

14

9

16

9

19

18

501

4

3

Original cover unit (AR-122E/152E/153E)

2

RSPF exteriors (AR-157E)

3

NO. PARTS CODE

1 LSOU-0035QSZZ AR D Original tray
2 LPLTP0011QSJZ AH C Control plate F
3 LPLTP0012QSJZ AH C Control plate R
4 NGERR0377FCZZ AD C Manual feeding rack gear
5 XEPSD30P08X00 AA CScrew(3×8X)
6 NGERH0193FCZZ AB C Manual feeding gear
7 MSPRP0059QSZZ AD C Control plate spring

9 LSOU-0006QSZZ AL D Middle tray
10 PCOVP0022QSJZ AT C Upper cover
11 CFRM-0011RS59 BG E RSPF pick up unit
12 LBNDJ0013FCZ1 AA C Wire band
13 XEBSE40P12000 AA CScrew(4×12)
14 XEBSE40P14000 AA CScrew(4×14)

5

PRICE

RANK

9

5

2

NEW

MARK

PART
RANK

1

27

29

AR-153E
AR-157E

1

2

3

22

23

PRP00952

DESCRIPTION

28

25

30

27

17

17

9

AR-122E
AR-152E

PRP00951

– 2 –

RSPF exteriors (AR-157E)

3

PRICE

NEW

NO. PARTS CODE

15 XHBSE30P10000 AA CScrew(3×10)
16 XBPSD30P06KS0 AA CScrew(3×6KS)
17 RPLU-0005QSZZ AQ B Gate solenoid
18 MLEVP0036QSZZ AD C Delivery gate lever
19 MSPRD0126QSZ1 AC C Delivery gate spring
20 PSPO-0004QSZZ AB C Delivery gate sponge
21 PSHEZ0384QSZZ AD C Base tray sheet
22 XEBSE30P14000 AA CScrew(3×14)
23 PSHEZ0151QSZZ AD C Motor sheet DSPF
24 XBPSD30P08KS0 AA CScrew(3×8KS)
25 MLEVF0041QSZZ AD CLever
26 NBRGM0501FCZZ AB CMetal D
27 PRNGP0090FCZZ AA C Ring(E5)
28 LPLTP0014QSZZ AK C Delivery gate
29 PSHEZ0068QSZZ AC C PS sheet
30 MHNG-0019QSZZ AS C RSPF hinge JAG
31 PCUSS0016QSZZ AB C Middle tray cushion
32 PSHEZ0380QSZZ AD C OC mat sheet DFJAG
33 LX-BZ0016QSZZ AC CScrew(3×8)
34 PSPO-0003QSZZ AC C Sponge
35 XRESP20-04000 AA CE-ring
36 NROLP0011QSZZ AD C Delivery roller
37 PSPO-0001QSZZ AB C Sponge
38 NSFTZ0013QSZZ AF C Delivery shaft
39 LPLTP0041QSZZ AE C Pressure plate
40 XBPSD30P10KS0 AB CScrew(3×10KS)
41 MSPRD0070QSZZ AC C Delivery spring B
42 MSPRD0069QSZZ AC C Delivery spring A
43 NSFTZ0014QSZZ AP CShaft
44 PSHEZ0381QSZZ AD C OC mat sheet DRJAG
46 NROLP0010QSZZ AD C Transport roller
47 MSPRP0052QSZZ AD C Delivery spring
48 MSPRD0154QSZZ AD C Delivery earth spring
49 NSFTZ0009QSZZ AE C Transport shaft
50 MSPRP0060QSZZ AD C Transport spring
51 MSPRC0149QSZZ AC C PS earth spring SPF
52 LPLTM0122QSZZ AD C Support plate earth
53 LPLTM0096QSZZ AF C Base tray reinforce plate
54 LSOU-0007QSJZ BB D Base tray R
55 XEBSD30P08000 AA CScrew(3×8)
56 PCUSS0025QSZZ AQ DOC mat
57 PSHEZ0386QSZZ AB D Rear side mylar A
58 PSHEZ0387QSZZ AB D Rear side mylar B
60 PSHEZ0383QSZZ AC C Book detect sheet

RANK

MARK

PART
RANK

DESCRIPTION

RSPF exteriors (AR-157E)

3

2

PRP00953

11

1

5

7

9

32

56

6

5

33

3

12

13

14

13

10

4

5

44

33

60

54

30

14

37

35

36

14

38

34

27

26

39

13

13

21

22

26

27

57

58

31

28

22
37

42

41

40

27

36

35

43

46

47
48

55

26

49

47

49

46

50

55

15

16

17

18

20

24

19

58

23

25

29

30

14

46

50

51

52

22

53

33

– 3 –

RSPF transport unit (AR-157E)

4

PRICE

NEW

NO. PARTS CODE

RANK

MARK

PART
RANK

1 PSHEZ2174FCZZ AB C Paper feeding sheet

2 PSHEZ0039QSZZ AG C Sheet

3 LPLTP0013QSZZ AD CPlate

4 MSPRC0062QSZZ AC C Pressure spring

5 PGIDM0022QSZZ AN C Paper feeding paper guide upper

6 NROLM0027QSZ1 AL C Delivery roller R

7 PBRSR0003QSZ2 AG B Discharge brush

8 PGIDH0028QSZZ AK C Paper feeding paper guide lower

9 XEBSD30P08000 AA CScrew(3×8)
10 PGIDM0057QSZZ AL C U-turn R paper guide
11 DHAI-0304QSZ1 AQ N C R-SPF interface harness
12 XHBSE30P06000 AA CScrew(3×6)
13 RMOTP0013QSZZ BB B SPF motor
14 PSPO-0004QSZZ AB C Delivery gate sponge
15 RPLU-0015QSZZ AS B Solenoid
16 LBNDJ0013FCZ1 AA C Wire band
17 LFRM-0015QSZZ AK C Drive frame R
18 XBBSD30P04000 AA CScrew(3×4)
19 XBPSD30P05K00 AA CScrew(3×5K)
20 XRESP50-06000 AA CE-ring
21 PSHEP3029FCZZ AA C Flange sheet DUP2
22 NBLTT0011QSZZ AG B Belt(85MXL4.8)
23 NGERH0047QSZZ AF C Gear(48T/15T)
24 XPSSP20-09000 AA C Spring pin(φ2-9)
25 NBRGM0501FCZZ AB CMetal D
26 NGERH0079QSZZ AD C Gear(30T)
27 NBRGC0017QSZZ AC C Bearing(F6-10)
28 PCLC-0010QSZZ AT B Transport clutch
29 XRESP40-06000 AA CE-ring
30 LFRM-0014QSZZ AE C Frame RD
31 MSPRP0065QSZZ AD C Open and shut lock spring
32 XEBSD30P12000 AA CScrew(3×12)
33 NPLYZ0146FCZZ AB C 22MXL pulley(22MXL)
34 NBLTT0032QSZZ AE B Belt(B75MXL4.8)
35 JKNBZ0004QSZZ AD C JAM release knob
36 MSPRC0063QSZZ AB C Delivery paper guide spring
37 RDTCT0004QSZZ AL B Inlet detect sensor
38 PGIDM0021QSZZ AQ C Transport R paper guide
39 LPLTP0015QSZZ AH C Turnover gate
40 NROLM0026QSZ1 AL C Transport roller
41 PGIDH0027QSZZ AK C Delivery R paper guide
42 PSHEZ0164QSZZ AF C White sheet
43 NROLM0022QSZ1 AL C PS roller
44 PSHEZ0162QSZZ AB C Harness protection sheet R
45 MSPRD0163QSZZ AC CEarth spring
46 LPINS0019QSZZ AB C Spring pin(φ2.5-9)
47 CPLTM0299QS01 AF C RSPF tension plate
48 MSPRT0294QSZZ AC C SPF tension spring
49 XEBSE30P10000 AA CScrew(3×10)

DESCRIPTION

RSPF transport unit (AR-157E)

4

1

6

25

20

48

33

20

49

20

34

20

9

33

46

47

35

2

3

5

4

7

8

9

31

37

25

25

46

38

36

40

42

10

32

24

25

26

45

31

39

36

41

43

32

11

16

9

21

22

23

12

30

20

29

27

28

9

20

25

12

19

18

13

14

16

16

17

15

44
9

PRP00954

– 4 –

RSPF SPF pick up unit (AR-157E)

5

PRICE

NEW

NO. PARTS CODE

1 GCAB-0008QSJZ AM D Open and shut exterior
2 PSPO-0002QSZZ AC C Stopper sponge
4 MARMP0003QSZ1 AD C Stopper arm
5 LSTPP0007QSZZ AC C Paper stopper R
6 XEBSD30P08000 AA CScrew(3×8)
7 CPWBF0009RS51 AG E SPF sensor PWB
8 DHAI-0293QSZZ AE C Sensor harness

9 MLEVP0009QSZZ AD C Set detect lever ACT
10 MLEVP0010QSZZ AE C Open and shut detect lever ACT
11 RPLU-0004QSZ1 AQ B PU solenoid
12 XBPSD30P06KS0 AA CScrew(3×6KS)
13 MARMP0002QSZZ AD C Solenoid arm
14 MSPRT0067QSZ1 AB C Solenoid arm spring
15 XRESP40-06000 AA CE-ring
16 NGERH0073QSZZ AE C Clutch gear(20T)
17 PPIPP0010QSZZ AD C Clutch sleeve
18 MSPRC1316FCZ1 AE C MF clutch spring B
19 LBOSZ1851FCZZ AC C STK clutch boss
20 LBSHZ0303FCZZ AC C M bushing C
21 NSFTZ0012QSZZ AG C Clutch shaft
22 LBSHZ0006QSZZ AC C M Bushing 2
23 NPLYZ0010QSZZ AE C 20MXL pulley
24 XRESP30-06000 AA CE-ring
25 MSPRT0066QSZ1 AC C Clutch pawl spring
26 PTME-0019QSZZ AD C Clutch pawl
27 NROLP0024QSZ1 AH C Pick up roller
28 NGERH0990FCZZ AB C Gear(16T)
29 XPSSP20-07000 AA C Spring pin(φ2-7)
30 NGERH0992FCZZ AB C Gear(20T)
31 NROLR0922FCZZ AR C Manual feeding roller
32 NSFTZ0011QSZ2 AF C PF shaft
33 MSPRC0115QSZZ AB C Paper feeding spring
34 MARMP0004QSZZ AF C Pick up arm
35 LFRM-0011QSJ2 AL D Paper feedind frame
36 MSPRD0114QSZ1 AD C PF frame spring

(Unit)

901 CFRM-0011RS59 BG E RSPF pick up unit

RANK

MARK

PART

RANK

DESCRIPTION

RSPF SPF pick up unit (AR-157E)

5

1

4

5

6

9

6

7

8

36

6

13

10

35

14

11

2

15

19

18

16

17

21

15

20

12

23

24

20

33

15

32

PRP00955

20

12

27

30

25

26

28

30

29

6

29

34

22

29

30

31

– 5 –

Operation panel

6

PRICE

NEW

NO. PARTS CODE

CPNLH0023QS12 AR N D Panel (AR-122E)
CPNLH0023QS13 AR N D Panel (AR-152E)

1

CPNLH0023QS21 AS N D Panel (AR-153E)
CPNLH0023QS22 AS N D Panel (AR-157E)

2 CBTN-0019QS02 AF E Copy key
3 JBTN-0020QSZZ AC C Copy key light
4 JBTN-0005QSZZ AC C% Key
5 CBTN-0050QS01 AE N E Operation key R
6 JBTN-0049QSZZ AF N C Operation key L

CPWBF0113QSE8 BB N E Operation PWB (AR-122E/152E)

8

CPWBF0113QSE9 BB N E Operation PWB (AR-153E)
CPWBF0113QSF0 BB N E Operation PWB (AR-157E)

9 XEBSD30P08000 AA CScrew(3×8)
10 GCAB-0063QSZZ AT N D Operation cabinet
11 XEBSE30P10000 AA CScrew(3×10)
12 GCAB-0064QSZZ AN N D Operation panel

Operation panel

6

RANK

MARK

PART
RANK

DESCRIPTION

1

12

2

6

4

5

3

9

9

11

8

9

10

9

9

PRP00956

– 6 –

Side door unit

7

PRICE

NEW

NO. PARTS CODE

1 GCAB-0007QSJ2 AU N D Side door
2 PTME-0004QSZZ AG C Lock pawl
3 MSPRT0029QSZZ AC C Lock pawl spring
4 PGIDM0008QSZZ AD C Hinge guide

LPLTM0043QSZZ AD C Earth plate (AR-122E/152E/153E)

5

LPLTM0132QSZZ AH C Earth plate (AR-157E)
6 MSPRD0076QSZ1 AD CEarth spring
7 XHBSE30P06000 AA CScrew(3×6)
8 XEBSE30P06000 AA CScrew(3×6)
9 LFRM-0003QSJ2 AN D Side door inner frame

10 XEBSD30P10000 AA CScrew(3×10)
11 MSPRC0032QSZZ AB C Transcription pressure spring
12 DHAI-0291QSZZ AC N C TCFB harness
13 MSPRC0031QSZZ AB C PS earth spring
14 MSPRC0030QSZZ AC C PS pressure spring
15 NSFTZ0006QSZ1 AG C PS shaft
16 XRESP30-06000 AA CE-ring
17 NROLP1122FCZZ AF C PS upper roller
18 CHLDZ0010RS52 AU E Transcription holder unit
21 XEPSD30P08X00 AA CScrew(3×8) (AR-157E)
22 NGERH0048QSZZ AE C DUP drive gear (AR-157E)
23 NGERH0051QSZZ AE C DUP drive gear A (AR-157E)
24 NROLP0025QSZZ AM C DUP drive roller (AR-157E)
25 MSPRC0050QSZZ AB C DUP pressupe spring (AR-157E)
26 NROLP1122FCZZ AF C PS upper roller (AR-157E)

Side door unit

7

RANK

MARK

PART

RANK

DESCRIPTION

Except
AR-157E

6

7

8

7

8

21

22

23

11

16

10

13

5

23

10

6

4

7

8

5

1

7

8

8

12

9

26

24

25

26

25

14

15

11

2

14

18

17

10

10

3

PRP00957

– 7 –

Optical frame

8

PRICE

NEW

NO. PARTS CODE

RANK

MARK

PART
RANK

DESCRIPTION

1 CGERH0162QS01 AN N E Pulley gear
2 CPLTM0288QS01 BC N E Scanner plate
3 CPLTM0291QS01 AG N E Tension plate
4 CPLTM0294QS01 AK N E Motor fixing plate
5 CPLYZ0028QS01 AM E Idle pulley

DUNT-0276QSZZ BT N E Carriage unit (Other Countries)

6

DUNT-0276QS11 BT N E Carriage unit (Europe)
7 LHLDZ0093QSZZ AC N C Rod holder
8 LSTPF0013QSZZ AC N C Rod stopper
9 LX-BZ0033QSZZ AB CScrew(3×6)

10 MLOKZ0004QSZZ AD N C Carriage lock
11 MSPRT0283QSZZ AC N C Tension spring
12 MSPRT0284QSZZ AC N C Motor spring
13 NBLTT0030QSZZ AH NBBelt
14 NBLTT0031QSZZ AF NBBelt
15 NGERH0161QSZZ AL N C Idle gear
16 NSFTZ0063QSZZ AK N C Slide shaft

PBRSR0002QSZ1 AH B Discharger brush (Other Countries)

17

PBRSR0002QSZ2 AG B Discharger brush (U.S.A,Soudi arabia)

18 PGIDM0099QSZZ AH N C Paper guide
19 PGUMS0004QSZZ AA C Table glass cushion
21 PSHEZ0367QSZZ AD N C Cable fixing sheet
22 PDUC-0005QSZZ AD N C Fan duct JAG
24 PSHEZ0377QSZZ AC N C Edge protect sheet
25 RMOTS0038QSZZ BL N B Scanner motor
26 XHBSE30P06000 AA CScrew(3×6)
27 XRESP50-06000 AA CE-ring
28 XRESP70-08000 AA CE-ring

PGIDM0059QSJZ AG N C OC hinge guide L (AR-153E)

29

PGIDM0019QSJZ AH C SPF hinge guide L (AR-157E)

PGIDM0060QSJZ AF N C OC hinge guide R (AR-153E)

30

PGIDM0020QSJZ AH C SPF hinge guide R (AR-157E)

31 XHBSE30P08000 AA CScrew(3×8)
32 RCORF0018QSZZ AR N C FFC core
33 LPLTP0131QSZZ AD C Book sensor attachment plate (AR-157E)
34 MLEVP0047QSE1 AD C Book sensor ACT (AR-157E)
35 MSPRC0153QSZZ AB C Book sensor spring (AR-157E)
36 VHPGP1A71A1-1 AG B Photo transistor(GP1A71A1) (AR-157E)
37 DHAI-0303QSZZ AD C Harness (AR-157E)

PSHEZ0389QSZZ AH N C Scanner sheet (Other Countries)

39

PSHEZ0389QSZ1 AK N C Scanner sheet (Europe)

DHAI-0268QSZZ AZ C CCD-MCU harness (Other Countries)

40

DHAI-0268QSZ1 AH N C CCD-MCU harness (Europe)

41 RCORF0020QSZZ AL N C FFC core
42 PCUSU0026QSZZ AC N D Core cushion
43 PTPE-0045QSZZ AA N C CCD harness double-sided tape
44 PSHEZ0403QSZZ AG N C Noise sheet (Europe)
45 PSHEZ0401QSZZ AG N C Scanner core sheet (Europe)
46 PTPE-0046QSZZ AB N C Core double-sided tape (Europe)
47 PMLT-0068QSZZ AC N C Core holder malt (Europe)
48 PSHEZ0400QSZZ AG C PWB core miler (Europe)

Optical frame

8

29

6

21

21

47

41

46

32

40

39

44

48

42

43

45

32

19

10

19

19

17

31

16

11

5

3

33

31

19

31

31

30

31

9

1

34

35

27

36

24

28

37

19

19

2

12

4

15

14

5

13

PRP00958

26

25

9

8

26

9

22

7

18

– 8 –

LSU unit

9

PRICE

NEW

NO. PARTS CODE

1 XEBSD30P12000 AA CScrew(3×12)
2 DHAI-0282QSZZ AG N C LSU harness
3 LBNDJ0013FCZ1 AA C Wire band
4 DUNTK0013QS13 BS N E LSU unit(A4600D)
5 MSPRT0019QSZ1 AB C Delivery paper guide spring
6 PSHEZ0350QSZZ AB C LSU protect sheet A
7 PSHEZ0351QSZZ AB C LSU protect sheet B
8 RCORF0021QSZZ AK NCCore

LSU unit

9

RANK

MARK

PART

RANK

6

7

5

1

1

DESCRIPTION

2

8

3

5

1

1

4

1

PRP00959

Delivery paper guide unit

F

PRICE

NEW

NO. PARTS CODE

1 NROLP0046QSZZ AC C Delivery roller upper
2 MSPRT0020QSZ1 AB C Delivery roller spring
4 CPWBF0116RS53 AP E POD sensor PWB
5 MLEVP0005QSZZ AD C Delivery actuator
6 PGIDM0006QSZ2 AM C Delivery paper guide
7 MSPRC0021QSZZ AB C Delivery transport roller spring
8 NROLP1122FCZZ AF C PS upper roller

9 MSPRD0281QSZZ AD N C Delivery earth spring
10 DHAI-0285QSZZ AK N C OP-MCU harness
13 PTUBP0005QSZZ AC CTube (AR-157E)
14 DHAI-0282QSZZ AG N C LSU harness
15 RCORF0018QSZZ AR N C FFC core (Europe)
16 PSHEZ0402QSZZ AG C Panel core sheet (Europe)

Delivery paper guide unit

F

RANK

1

2

1

2

MARK

PART

RANK

4

DESCRIPTION

13

14

5

6

7

8

9

7

16

15

8

10

PRP00960

– 9 –

Middle frame

G

PRICE

NEW

NO. PARTS CODE

1 NROLP0007QSZ1 AQ C Delivery roller lower
2 NBRGC0579FCZZ AE C Roller bearing
3 NROLP0012QSZ2 AL N C Delivery trasport roller lower
4 NPLYZ0001QSZZ AE C Pulley(22T)
5 NBLT-0005QSZZ AH B Delivery roller drive belt (AR-122E/152E/153E)
6 LBNDJ0043FCZZ AA C Snap band(SG-130)
7 NCPL-0006QSZZ AC C Hopper cupring S
8 MSPRC0024QSZ1 AC C Hopper spring

9 RMOTD0009QSZZ AU B Toner motor
10 XEBSD30P10000 AA CScrew(3×10)
11 XEBSD30P30000 AA CScrew(3×30)
12 NFANP0005QSZ1 BR NBFan
13 LHLDZ0018QSZZ AE C TC high voltage holder
14 QSLP-0006QSZZ AE C BC HV electrode plate
15 XEBSD30P06000 AA C Screw(M3×6)
16 QSLP-0005QSZZ AE C TC HV electrode plate
17 XBPSC30P06K00 AA CScrew(3×6K)
18 DHAI-0267QSZZ AG C BC harness
19 DHAI-0292QSZZ AF N C TC harness
20 NBLTT0001QSZZ AH B Belt 308
21 LFRM-0035QSZZ AZ D Middle frame
22 JKNBZ0001QSZZ AE C Roller rotation knob
23 DHAI-0287QSZZ AF N C PPD2 interface harness

DHAI-0274QSZZ AG C HL harness 1 (100V Series)

24

DHAI-0276QSZ2 AL C HL harness 1 (200V Series)

25 PGIDM0009QSZZ AG C Harness guide

LPINS0008QSZZ AD C DV guide pin (Other Countries)

26

LPINS0009QSZZ AD C DV guide pin (Europe,Australia,New zealand)
27 DHAI-0271QSZZ AP C DSV harness
28 LX-BZ3006SC0S AA CScrew(3×6)
29 XBBSD30P08000 AA CScrew(3×8)
30 XEBSE40P12000 AA CScrew(4×12)
31 LPLTM0133QSZ1 AE C DUP motor sink (AR-157E)
32 PSPAZ0017QSZZ AK C DUP spacer (AR-157E)
33 XEBSD30P10000 AA CScrew(3×10) (AR-157E)
34 XHBSE30P06000 AA CScrew(3×6) (AR-157E)
35 RMOTP0012QSZZ AW B DUP transport motor (AR-157E)
36 PSHEZ0156QSZZ AE C Harness protection sheet (AR-157E)
37 NBLTT0004QSZZ AH BBelt (AR-157E)
38 PSHEZ0155QSZZ AD C Sheet (AR-157E)
39 PMLT-0067QSZZ AC N C Cushion

RANK

MARK

PART
RANK

DESCRIPTION

Middle frame

G

AR-157E

29

10

4

20

28

10

10

29

10

1

2

22

30

4

25

23

10

24

39

3

30

30

17

18

15

19

17

37

4

15
6

27

30

8

7

26

21

14

15

16

13

10

38

34

36

33

34

34

35

10

9

11

12

11

30

PRP00961

32

31

5

– 10 –

Base plate unit 1

H

PRICE

NEW

NO. PARTS CODE

1 CPWBF0116RS51 AP E PPD1sensor PWB
2 MLEVP0006QSZZ AD C PS front actuator
3 MSPRC0026QSZ1 AB C PS front actuator spring
4 XEBSE30P10000 AA CScrew(3×10)
5 PGIDM0010QSZ1 AG C TC front guide upper
6 XRESP50-06000 AA CE-ring
7 NROLR0013QSZZ AQ C PS lower roller
8 NBRGC0100FCZ1 AC C Bearing 6

9 NGERH0020QSZZ AG C Cluth gear(26T)
10 PPIPP0109FCZ1 AC CPipe A
11 MSPRC1316FCZ1 AE C MF clutch spring B
12 XPSSJ20-07000 AA C Spring pin(φ2-7)
13 LBOSZ1851FCZZ AC C STK clutch boss
14 XRESP40-06000 AA CE-ring
15 LBOSZ1031FCZZ AC C Clutch boss
16 MSPRC0161QSZZ AF C Clutch spring
17 PPIPP0003QSZZ AD C Clutch sleeve
18 NGERH1132FCZZ AH C Clutch gear(29T)
19 NBRGP0562FCZZ AD C Bearing
20 CROLP0015QS01 AU C Paper feeding roller
21 NGERH0022QSZZ AC C Gear(33T)
22 NGERH0026QSZZ AD C Gear(21/29T)
23 NGERH0025QSZZ AD C W gear(30T)
24 CPLTM0024QS01 AG C PF plate 2
25 LPLTM0046QSZZ AE C PS earth plate
27 DHAI-0269QSZZ AD C CED1 harness
28 GDAI-0001QSJ1 BF N D Base plate
29 PSHEZ2026FCZ1 AB C Sheet M1 (AR-153E/157E)
30 LHLDZ0017QSZZ AD C Pressure plate holder (AR-153E/157E)
31 MSPRC0047QSZZ AA C Pressure plate spring (AR-153E/157E)
32 PCOVP0013QSZZ AD D Malti cover (AR-153E/157E)
34 LRALP0001QSJ1 AL N C Base plate rail R
35 XEBSE40P12000 AA CScrew(4×12)
36 PSHEZ2174FCZZ AB C Paper feeding sheet (AR-153E/157E)
37 XBPSD30P08KS0 AA CScrew(3×8KS)
38 PCOVP0007QSJZ AE N D Sensor cover
40 XEBSE30P12000 AA CScrew(3×12)
41 MSPRC0077QSZ1 AB C Front exterior lever spring
42 LPLTM0016QSZZ AE C Front exterior lever plate
43 LX-WZ0023FCZZ AA CWasher
44 XEBSE30P10000 AA CScrew(3×10)
45 XEBSE40P12000 AA CScrew(4×12)
46 CPLTM0038QS02 AG C 2nd joint gear fixing plate (AR-153E/157E)
47 NGERH1169FCZZ AF C 2nd joint gear (AR-153E/157E)
48 XRESP70-08000 AA CE-ring
49 LHLDZ0080QSZZ AC C DV fixation holder
50 LPLTM5422FCZZ AC C M4 plate
51 XEBSD30P08000 AA CScrew(3×8)
60 PCOVP0008QSZZ AE C 2nd gear cover (AR-122E/152E)
61 PCOVP0009QSZZ AE C 2nd connector cover (AR-122E/152E)
62 MSPRC0037QSZZ AB C Transport lower roller spring (AR-122E/152E)

RANK

MARK

PART

RANK

DESCRIPTION

– 11 –

Base plate unit 1

H

4

4

14

16

16

4

4

13

13

21

21

14

15

15

22

22

23

23

14

14

4

4

12

25

25

11

11

17

17

12

14

14

10

9

9

14

14

10

18

18

24

24

4

4

6

6

8

8

5

5

19

47

47

19

48

48

7

7

45

45

4

4

2

2

1

1

3

3

46

46

50

37

37

51

49

28

28

14

14

62

20

20

36

36

62

26

26

32

32

31

31

61

27

27

29

29

30

30

60

PRP00962

35

35

34

34

– 12 –

35

35

42

42

43

43

41

41

44

44

38

38

40

40

Base plate unit 2

I

PRICE

NEW

NO. PARTS CODE

1 LHLDZ0092QSZZ AP N C PWB holder JAG

3 XHBSE30P06000 AA CScrew(3×6)

CPWBX0112QS3A BW N E MCU PWB (AR-122E)

4

CPWBX0112QS3G BW N E MCU PWB (AR-152E)

! 6 RDENC0007QSZZ BG N E High voltage PWB

!
! RDENC0006QS11 BQ N E DC power supply PWB (127V Series)
! RDENC0006QS13 BN N E DC power supply PWB (200V Series)

! 26 QACCD761AQCZZ BE BAC cord (100V Series)

CPWBX0112QS3D BY E MCU PWB (AR-153E/157E)

11 XEBSE30P10000 AA CScrew(3×10)

RDENC0006QS12 BN E DC power supply PWB (120V Series)

13

14 XBBSE30P06000 AA CScrew(3×6)
15 XEBSE40P12000 AA CScrew(4×12)
17 GDAI-0001QSJ1 BF N D Base plate
18 GLEGG0064FCZZ AC C Rubber foot
21 LPLTM0020QSZZ AL C Base plate reinforce plate F
22 PSHEZ0390QSZZ AL N C PWB holder sheet
23 RCORF0018QSZZ AR N C FFC core
24 LHLDZ0096QSZZ AN C AC in let holder (100V Series)
25 XBPSN40P06K00 AA CScrew(4×6K)

27 RCORF0021QSZZ AK NCCore
28 RCORF0034FCZZ AR CCore (100V Series)
30 LFRM-0062QSZZ AG N C Connector frame
31 DHAI-0294QSZZ AK N C Center frame harness
32 DHAI-0305QSZ1 AP N C Inlet interface harness (200V Series)
33 CPWBF0122QS31 AZ E Noise filter PWB (200V Series)
34 LHLDC0097QSZZ AG N C Noise filter holder (200V Series)
35 XEBSD30P10000 AA CScrew(3×10) (200V Series)
36 DHAI-0276QSZ2 AL C HL harness 1 (200V Series)
37 DHAI-0265QSZZ AM N C 2NDCS interface harness (AR-153E)
38 PSHEZ0405QSZZ AE C Connector ground sheet (Europe)

RANK

MARK

PART

RANK

DESCRIPTION

Base plate unit 2

I

14

11

200V Series 100V Series

11

35

36

25

28

3

13

14

33

25

15

32

34

A

27

14

38

15

6

3

3

3

3

4

3

27

3

22

26

24

3

23

31

A

15

17

30

1

3

37

15

18

21

18

PRP00963

15

– 13 –

Fusing unit

J

PRICE

NEW

NO. PARTS CODE

1 PGIDM0023QSZZ AP C U-turn guide lower
2 VRH-ST2HB157K AD C Resistor(1/2W 150MΩ)
3 MSPRD0282QSZZ AH N C FU earth wire
4 PBRSR0004QSZ1 AD N B Discharge brush FU
5 PCOVP0010QSZZ AG D Fusing cover F
6 MSPRP0033QSZZ AD C Copy lamp spring F
7 LFRM-0004QSZZ AV D Fusing upper frame
8 LX-BZ0010QSZZ AB CScrew(3×6)

9 RDTCT0128FCZZ AR BThermistor
10 XBPSD30P10KS0 AB CScrew(3×10KS)
11 CTME-0229FC04 AG C Separator pawl
12 CTHM-0019DS52 AT E FU thermostat unit
13 CPWBF0116RS52 AP E PPD2 sensor PWB
14 MSPRP0034QSZZ AE C Copy lamp spring R
15 PCOVP0011QSZZ AK D Fusing cover R

DHAI-0278QSZ1 AK C HL harness 2 (100V Series)

16

DHAI-0280QSZ1 AH N C HL harness 2 (200V Series)
17 LBNDJ0013FCZ1 AA C Wire band
18 LSTPP0116FCZZ AA C Roller stopper
19 NGERH0540FCZ3 AD C Fushing gear(45T)
20 NBRGP0567FCZZ AG C Fusing bearing
21 NROLI0014QSZ3 BA N C Heart roller

!
! RLMPU0011QSZZ BA B Heater lamp (200V Series)

RLMPU0010QSZZ BA B Heater lamp (100V Series)
22

23 MLEVP0015QSZZ AF C Pressure lever R
24 NBRGP0260FCZ1 AD C Pressure bearing N
25 MSPRC0055QSZZ AC C Pressure spring
26 LX-WZ0313FCZZ AA CWasher
27 NROLR0028QSZZ AZ C Pressure roller
28 MLEVP0014QSZZ AF C Pressure lever F
29 LPLTM0022QSZ4 AG C Scraper
30 LFRM-0005QSZZ AQ D Fusing lower frame
31 XEBSE30P12000 AA CScrew(3×12)
32 TCAUH0017QSZZ AC D High temperature caushion label
33 PSHEZ0045QSZ2 AC C PG earth sheet N2
34 PGIDH0026QSZZ AE C Fusing front paper guide
35 PSHEP0023QSZZ AF C Fusing front PG sheet
36 LX-BZ0735FCZZ AA CScrew
37 MSPRT0054QSZ1 AB C Gate spring
38 LPLTP0009QSZZ AS C Turn over gate
39 XRESP30-04000 AA CE-ring
40 PSHEP0047QSZZ AC C Handle label
41 XEBSE30P08000 AA CScrew(3×8)
42 LX-BZ0011QSZZ AB CScrew

(Unit)

DUNTW0285RS13 BS N E Fusing unit (100V Series)

901

DUNTW0285RS12 BS N E Fusing unit (200V Series)

RANK

MARK

PART
RANK

DESCRIPTION

– 14 –

Fusing unit

J

41

41

4

41

15

41

13

41

1

14

12

2

8

3

11

21

8

6

7

20

11

10

9

8

22

24

17

20

16

18

19

23

5

28

18

24

26

25

42

39

27

29

33

31

36

38

40

26

32

34

35

36

25

31

30

37

42

– 15 –

PRP00964

Drive unit

K

PRICE

NEW

NO. PARTS CODE

1 XBBSD40P06000 AA CScrew(4×6)
2 RMOTP0036QSZZ BD N B Main motor
3 MSPRC0053QSZ1 AC C Pulley spring (AR-122E/152E/153E)
4 NGERH0050QSZZ AD C Ratchet gear(33T) (AR-122E/152E/153E)
5 NPLYZ0002QSZZ AC C Pulley(17T) (AR-122E/152E/153E)
6 NGERH0010QSZZ AD C Gear(28T)
7 NGERH0009QSZZ AD C Gear(46/16T)
8 NGERH0014QSZZ AD C Gear(30/15T)

9 CGERH0011RS51 AE E MG gear unit
10 NGERH0015QSZZ AD C Gear(37/15T)
11 NGERH0007QSZZ AH C Gear(68/26T)
12 NGERH0016QSZZ AD C Cupring gear(34T)
13 NGERH0019QSZZ AD C Ratchet gear(21T)
14 NGERH0018QSZZ AC C Ratchet gear(28T)
15 MSPRC0023QSZ1 AC C Ratchet spring
16 NGERH0008QSZ3 AL C Gear(55/19T)
17 NGERH0017QSZZ AD C Gear(33/20/15T)
18 NGERH0012QSZZ AE C Gear(20T)
19 NGERH0013QSZZ AG C Gear(31/17T)
20 CPLTM0042QS02 AY C Main drive plate
21 XBBSD30P04000 AA CScrew(3×4)
22 RPLU-0035QSZZ AL N B Solenoid
23 MSPRC1318FCZ1 AA C Spring B
24 PTME-0002QSZZ AD C PS roller pawl
25 RPLU-0002QSZZ AN B Solenoide
26 PTME-0003QSZ1 AD C Roller pawl
27 DHAI-0296QSZZ AK N C Main motor harness

(Unit)

CPLTM0042RS55 BM N E Drive unit[Except No.27] (AR-122E/152E/153E)

901

CPLTM0042RS56 BM E Drive unit[Except No.27] (AR-157E)

RANK

MARK

PART
RANK

DESCRIPTION

K

Drive unit

27

1

2

3

4

5

6

7

26

23

25

8

24

9

21

22

23

10

21

20

11

12

13

16

14

15

17

19

PRP00965

18

– 16 –

Single manual paper feeding cover unit (AR-122E/152E)

L

PRICE

NEW

NO. PARTS CODE

1 CCLEZ0005RS51 AQ E Charger cleaner unit
2 XEBSE30P08000 AA CScrew(3×8)
3 PCOVP0012QSJ1 AH C Single upper cover
4 CSW-M0016RS51 AG E Side door detect switch unit
5 XEPSD20P10000 AA CScrew(2×10)
6 MSPRP0110QSZ1 AD C Door switch spring

Single manual paper feeding cover unit (AR-122E/152E)

L

RANK

MARK

PART

RANK

1

2

4

DESCRIPTION

3

5

Multi manual paper feeding cover unit (AR-153E/157E)

M

NO. PARTS CODE

1 CCLEZ0005RS51 AQ E Charger cleaner unit
2 XEBSE30P08000 AA CScrew(3×8)
3 PCOVP0023QSJ1 AH D Multi upper cover
4 CSW-M0016RS51 AG E Side door detect switch unit
5 XEPSD20P10000 AA CScrew(2×10)
6 MSPRP0110QSZ1 AD C Door switch spring
7 PSHEZ0075QSZZ AC C MB upper guide sheet

Multi manual paper feeding cover unit (AR-153E/157E)

M

PRICE

RANK

6

NEW

MARK

PART

RANK

1

PRP00966

DESCRIPTION

7

2

3

4

6

5

– 17 –

PRP00967

Single manual paper feeding unit (AR-122E/152E)

N

PRICE

NEW

NO. PARTS CODE

1 CPWBF0116RS54 AP E MFD sensor PWB

2 DHAI-0295QSZZ AC N C Manual feeding earth harness

3 LBNDJ0013FCZ1 AA C Wire band

4 XHBSE30P06000 AA CScrew(3×6)

5 CPLTM0023QS02 AF C SB plate 1

6 NGERH0972FCZZ AB C Gear(27T)

7 XRESP40-06000 AA CE-ring

8 XEBSE30P08000 AA CScrew(3×8)

9 NGERH0990FCZZ AB C Gear(16T)
10 XPSSJ20-07000 AA C Spring pin(φ2-7)
11 NBRGP0562FCZZ AD C Bearing
12 NROLR0016QSZZ AT C MF transport roller
13 LFRM-0006QSJZ AN N D Single manual feed frame
14 MSPRC0039QSZ1 AC CEarth spring
15 XEBSD30P06KS0 AA CScrew(3×6KS)
16 MSPRC0038QSZ1 AC C Actuator spring
17 MLEVP0007QSZZ AD C Actuator
18 MSPRC0080QSZZ AB C SB transport earth spring
20 PGIDM0014QSJZ AF C DUP upper guide
21 PGIDM0013QSJZ AF N C SB side guide R
22 PGIDM0012QSJZ AF N C SB side guide F

NSFTZ0007QSZ1 AG C Roller shaft (Other Countries)

23

NSFTZ0007QSZZ AG N C Roller shaft (AR-122E Europe)
24 NROLP1122FCZZ AF C PS upper roller
25 LFRM-0007QSJ2 AL N D Single manual feed lower frame
26 MSPRC0036QSZ1 AB CMF spring
27 NGERH0021QSZZ AD C Manual feeding gear
28 XEPSD30P06X00 AA CScrew(3×6X)
29 MSPRP0079QSZZ AD C SB earth plate spring
30 XEBSE30P06000 AA CScrew(3×6)
31 MSPRD0108QSZZ AC C SB lower earth spring
32 XEBSE40P12000 AA CScrew(4×12)
33 MSPRC0109QSZZ AC CSpring

501 CFRM-0007RS54 AX N E SB manual feeding lower frame unit
502 CFRM-0006RS53 BB N E Single manual paper feeding unit

RANK

MARK

PART
RANK

DESCRIPTION

Single manual paper feeding unit (AR-122E/152E)

N

502

1

12

32

33

23

17

24

22

20

16

14

15

32

5

6

2

3

8

4

8

7

7

11

9

10

7

13

32

18

8

21

25

24

PRP00968

– 18 –

27

26

28

31

30

29

501

Multi manual paper feeding unit (AR-153E/157E)

O

PRICE

NEW

NO. PARTS CODE

1 NROLR0922FCZZ AR C Manual feeding roller
2 XRESP40-06000 AA CE-ring
3 NGERH0992FCZZ AB C Gear(20T)
4 MARMP0173FCZZ AC CArm C
5 NROLP1008FCZZ AK C Roller R
6 XPSSJ20-07000 AA C Spring pin(φ2-7)
7 NGERH0990FCZZ AB C Gear(16T)
8 NSFTZ2311FCZZ AU C Cam boss A shaft

9 LBSHZ0303FCZZ AC C M bushing C
10 LBRC-0055FCZZ AK C Multi F bracket
11 XEBSE30P08000 AA CScrew(3×8)
12 PGIDM0014QSJZ AF C DUP upper guide
13 XEBSD30P06000 AA C Screw(M3×6)
14 MSPRC0049QSZZ AC C Manual feeding earth spring
15 LBOSZ1851FCZZ AC C STK clutch boss
16 MSPRC1315FCZ1 AD C Clutch spring A
17 PPIPP0109FCZ1 AC CPipe A
18 LBOSZ0118QSZZ AE C Cam boss A1R
19 NGERH0972FCZZ AB C Gear(27T)
20 NGERH0991FCZZ AC C Gear(20.20MXL)
21 LBNDJ0013FCZ1 AA C Wire band
22 DHAI-0295QSZZ AC N C Manual feeding earth harness
23 XHBSE30P06000 AA CScrew(3×6)
24 XBPSD30P06KS0 AA CScrew(3×6K)
25 CPLTM0023QS03 AG C Paper plate 1
26 PPIPP0175FCZZ AC CPipe B
27 MSPRC1316FCZ1 AE C MF clutch spring B
28 LBOSZ1509FCZ1 AD C Cam boss B
29 RPLU-0003QSZZ AN B Multi feeding solenoid
30 MSPRC1318FCZ1 AA C Spring B
31 PTME-0179FCZZ AC C Manual paper feeding pawl B
32 PTME-0178FCZ1 AC C Manual paper feeding pawl A
33 MSPRC2175FCZZ AA C Pawl A spring
34 XBBSD30P08000 AA CScrew(3×8)
35 LFRM-0010QSJZ AN D Multi frame
36 XEBSE40P12000 AA CScrew(4×12)
37 LSTPP0300FCZZ AB C Stopper plate
38 MARMP0205FCZZ AF CArm B
39 MARMP0204FCZ1 AF CArm A
40 MHNG-0002QSZZ AC C Arm hinge
41 MSPRC0048QSZZ AB CArm C spring
42 PGIDM0018QSJZ AF C MB side guide R
43 PGIDM0017QSJZ AF C MB side guide L
44 PCOVP0019QSJZ AL D Multi tray front cover
46 NGERH0021QSZZ AD C Manual feeding gear
48 LSOU-0002QSJZ AL D Multi tray 1
49 LSOU-0003QSJZ AH D Multi tray 2
50 MSPRC0109QSZZ AC CSpring

501 CSOU-0002RS56 AX E Multi manual paper feeding tray unit
502 CFRM-0010RS54 BG E Multi manual paper feeding unit

RANK

MARK

PART

RANK

DESCRIPTION

– 19 –

Multi manual paper feeding unit (AR-153E/157E)

O

502

12

3

1

2

2

2

7

7

6

4

6

2

34

2

18

13

15

14

11

10

9

32

33

17

16

6

19

2

2

29

30

28

31

21

20

27

26

11

22

23

24

25

2

18

50

43

44

35

5

8

37

38

42

48

36

39

11

11

40

41

46

– 20 –

49

501

PRP00969

Socket holder unit

P

PRICE

NEW

NO. PARTS CODE

1 LHLDZ0009QSDZ AG C HV interface holder

2 CHAI-0298RS51 AL N C MC harness unit

3 CHAI-0273RS51 AN N C GB-MCFB harness unit

4 XBPSC30P06ES0 AA CScrew(3×6ES)

5 MSPRC0017QSZ1 AC CHV terminal spring

6 MSPRC0018QSZ1 AC CHV terminal spring

7 MSPRC0016QSZ1 AC CHV terminal spring

8 XEBSD30P08000 AA CScrew(3×8)

9 LBNDJ0013FCZ1 AA C Wire band

Socket holder unit

P

TC case unit

Q

NO. PARTS CODE

1 PSHEZ0018QSZZ AF C Discharge plate sheet

2 PGIDM0011QSZZ AE C Separator guige

3 PSHEP0019QSZ1 AC C TC sheet

4 PGIDH0025QSZ1 AG C TC front guide

5 XEBSD30P06000 AA C Screw(M3×6)

6 PSHEP0021QSZZ AA C TC cover sheet R

7 MSPRT0513FCZ1 AA C MC tension spring

8 DWIR-0466CSZZ BG B Charger wire

9 QSLP-0007QSZZ AC C TC electrode plate
10 MSPRC0027QSZZ AC C TC electrode spring
11 MSPRC0028QSZZ AC C BC electrode spring
12 MSPRC0051QSZ1 AA C Front guide earth spring
13 PSHEP0020QSZZ AB C TC cover sheet F
14 LHLDZ0010QSZ1 AL C TC holder
15 LFIX-0004QSZZ AC C Holer fixing plate
16 PCASZ0002QSZZ AL DTC case

(Unit)

901 CHLDZ0010RS52 AU E Transcription holder unit

RANK

PRICE

RANK

MARK

NEW

MARK

4

PART

RANK

3

PART

RANK

2

9

5

DESCRIPTION

1

8

8

7

6

PRP00970

DESCRIPTION

TC case unit

Q

5

9

12

PRP00971

1

7

11

5

10

6

4

5

2

3

13

8

5

14

5

16

15

5

– 21 –

250 sheets tray

R

PRICE

NEW

NO. PARTS CODE

1 LPLTM5106FCZZ AR C Turning plate 250
2 PSHEZ4142FCZZ AC C Rotation plate sheet
3 LHLDW1226FCZZ AB C Turn fasner
4 LPLTM2642FCGZ AD C Tray rear plate
5 LPLTP5107FCZZ AH C 250 tray side plate F
6 PTME-0255FCZZ AG C 250 Tray pawl F
7 XRESP40-06000 AA CE-ring
8 PSHEP0061QSZZ AA C Tray guide sheet

9 XEBSE30P08000 AA CScrew(3×8)
10 LX-WZ2028SCZZ AA CWasher(φ12)
11 NGERH0193FCZZ AB C Manual feeding gear
12 TLABZ3568FCZZ AB D Indication label
13 LPLTP5108FCZZ AH C 250 tray side plate R
14 PTME-0256FCZZ AG C 250 Tray pawl R
15 MSPRC0108QSZZ AC C 250 Tray spring
16 MSPRC1873FCZ1 AB C Tray spring
17 MSPRC1145FCZZ AA C Stopper spring
18 LSTPP0161FCZZ AB C Rotation plate stopper
19 GCASP0001QSJ2 AZ N D 250 Tray case
20 TLABZ4047FCZZ AC C Enagy star label (U.S.A,Australia,New zealand)

(Unit)

901 CCASP0001RS55 BF N E 250 Tray unit(Except No.20)

250 sheets tray

R

RANK

MARK

PART
RANK

DESCRIPTION

3

2

1

12

8

9

10

7

11

4

5

8

7

6

15

13

14

16

17

18

19

20

PRP00972

– 22 –

Harness

S

PRICE

NEW

NO. PARTS CODE

DHAI-0268QSZZ AZ C CCD-MCU harness (Other Countries)

2

DHAI-0268QSZ1 AH N C CCD-MCU harness (Europe)
3 DHAI-0294QSZZ AK N C Center frame harness
4 DHAI-0285QSZZ AK N C OP-MCU harness
5 DHAI-0296QSZZ AK N C Main motor harness
6 PSHEZ0390QSZZ AL N C PWB holder sheet
7 DHAI-0287QSZZ AF N C PPD2 interface harness

DHAI-0274QSZZ AG C HL harness 1 (100V Series)
8

DHAI-0276QSZ2 AL C HL harness 1 (200V Series)
9 DHAI-0271QSZZ AP C DSV harness

DHAI-0278QSZ1 AK C HL harness 2 (100V Series)

10

DHAI-0280QSZ1 AH N C HL harness 2 (200V Series)

RANK

MARK

PART

RANK

DESCRIPTION

Harness

S

2ND frame unit (AR-157E)

T

PRICE

NO. PARTS CODE

1 GCOVA0005QSJZ AL D Front cover
2 XEBSE40P12000 AA CScrew(4×12)
3 GCOVA0006QSJZ AN D Rear cover
4 PGIDM0016QSJZ AY C Guide L
5 XEBSD40P12000 AA CScrew(4×12)
6 LPLTM0036QSZZ AF C 2ND joint plate R
7 GLEGG0064FCZZ AC C Rubber foot
8 PGIDM0015QSJZ AY C Guide R
9 MSPRC2544FCZZ AC C 2ND transport cover spring

10 GCOVA0007QSZZ AK D Transport cover
11 NROLP1060FCZZ AF C U-turn roller
12 MSPRT0112QSZ1 AC C Transport collar spring
13 MARMP0012QSZZ AD C 2ND door arm
14 GCOVA0008QSJZ AK D Right cover
15 XHBSD40P08000 AA CScrew(4×8)
16 XEBSE40P16000 AA CScrew(3×16)
17 CFRM-0009RS54 BF E 2ND paper feeding unit
18 DHAI-0306QSZZ AG C 2CS harness

RANK

NEW

MARK

PART

RANK

2

6

3

4

9

5

7

10

8

PRP00973

DESCRIPTION

2ND frame unit (AR-157E)

T

16

2

– 23 –

2

1

2

2

5

4

7

9

16

3

5

6

9

16

18

15

5

17

8

11

11

12

PRP00974

13

14

7

10

12

13

16

2ND paper feeding unit (AR-157E)

U

PRICE

NEW

NO. PARTS CODE

1 NROLP0019QSZ1 AP C Transport roller
2 NBRGC0016QSZZ AD C Bearing(B-F5-13)
3 XRESP40-06000 AA CE-ring
4 LBNDJ0013FCZ1 AA C Wire band
5 NGERH0992FCZZ AB C Gear(20T)
6 XPSSP20-07000 AA C Spring pin(φ2-7)
7 LBOSZ1031FCZZ AC C Clutch boss
8 MSPRC0161QSZZ AF C Clutch spring

9 PPIPP0007QSZZ AD C Clutch sleeve
10 NGERH1132FCZZ AH C Clutch gear(29T)
11 NGERH1207FCZZ AF C 2ND joint gear(40T)
12 MARMP0229FCZZ AE C 2ND joint arm
13 MSPRC2545FCZZ AB C 2ND joint arm spring
14 DHAI-0306QSZZ AG C 2CS harness
15 VHPGP1A71A1-1 AG B Photo transistor(GP1A71A1)
16 MLEVP0033QSZZ AF C PPDI actuator
17 MSPRD0058QSZZ AG CEarth spring
18 RPLU-0010QSZZ AN B PF solenoid
19 XHBSD30P06000 AA CScrew(3×6)
20 PTME-0008QSZZ AD C PF clutch pawl
21 MSPRC2546FCZZ AB C 2ND clutch pawl spring
22 NGERH0041QSZZ AF C Gear(18/26T)
23 NGERH0990FCZZ AB C Gear(16T)
24 QSW-B0003QSZZ AF B Tray detect switch
25 CROLP0015QS01 AU C Paper feeding roller
26 LFRM-0009QSZ2 AQ D Paper feedind frame

(Unit)

901 CFRM-0009RS54 BF E 2ND paper feeding unit

RANK

MARK

PART
RANK

DESCRIPTION

2ND paper feeding unit (AR-157E)

U

14

15

16

2

6

5

3

14

4

1

11

3

7

18

17

13

12

8

9

2

10

3

20

22

21

3

23

23

19

24

26

3

25

PRP00975

– 24 –

Packing material & accessories

V

PRICE

NEW

NO. PARTS CODE

SPAKA0408QSZZ AN D Top packing OC (AR-122E/152E)

1

SPAKA0429QSZZ AM N D Top packing OC (AR-153E)

!
! QACCV6621JHPZ * N B AC cord (AR-122E/152E Other Countries)
! QACCB7521QCZZ AS B AC cord (AR-153E Special Country,South africa,India)
! QACCB7622QCN1 AZ B AC cord (AR-153E Hong kong)
! QACCBR623QCPZ AY N B AC cord (AR-153E Other Countries)
! QACCF7620QCZZ AX B AC cord (AR-153E Syngapore,Malaysia,Indonesia)
! QACCLR622QCPZ AR B AC cord (AR-153E Australia,New zealand)
! QACCD761AQCZZ BE BAC cord (100V Series)

SPAKA0410QSZZ AQ D Top packing DSPF (AR-157E)
QACCER622QCPZ AQ B AC cord (AR-122E/152E U.Kingdom,Switzrland)

3

4 UBNDA0001FCZZ AA C AC cable band
5 SSAKA5003CCZZ AA D Vinyl bag(140×260mm)
6 SSAKZ0002QSZZ AF D Body vinyl bag

TINSA0810QSZZ AS N D Operation manual (Arabic)
TINSE0778QSZZ AX N D Operation manual (English)
TINSE0800QSZZ AR N D Operation manual (English(U.S.A))
TINSE0817TSZZ * N D Operation manual (English)
TINSZ0770TSZZ * N D Operation manual (German,French,Italian,Dutch,Spanish,Switzrland)

7

TINSZ0771TSZZ * N D Operation manual (English,French,Hungarian,Polish,Russian)
TINSZ0818TSZZ * N D Operation manual (Swedish,Finnish,Norwegian,Danish)

GCOVZ0149FCZZ AU D

TCADZ0049QSZZ AH D Installation card (Europe)

8 SSAKA2347QCZZ AB D Vinyl bag(240×300mm)

SPAKA0405QSZZ AN D Bottom packing (AR-122E/152E)

9

SPAKA0406QSZZ AS D Bottom packing (AR-153E)
SPAKA0407QSZZ AS D Bottom packing (AR-157E)
SPAKC0402TS13 * N D Packing case (AR-122E Europe)
SPAKC0402RS21 AU N D Packing case (AR-122E Other Countries)
SPAKC0402RS22 AU N D Packing case (AR-122E Thailand,Syngapore,Malaysia,Indonesia,India)

10

SPAKC0402TS14 * N D Packing case (AR-152E)
SPAKC0404RS15 AX N D Packing case (AR-157E)
SPAKC0428RSZZ AW N D Packing case (AR-153E)

12 LHLDW1226FCZZ AB C Turn fasner
13 TTAG-0002QSZZ AB D Tray rotation tag

SPAKA0051RSZZ AC D OC packing (AR-122E/152E/153E)

14

SPAKA0163RSZZ AC D OC packing(DSPF) (AR-157E)
15 TTAG-0006QSZZ AE N D Scanner fixing tag JAG
17 CLEVP0016QS01 AL C Pressure block lever
19 SPAKA0421QSZZ AC D Middle tray packing (AR-157E)
20 SPAKA0411QSZZ AE D Accessories Add A
21 SPAKA5116FCZZ AB D SPF protect sheet (AR-157E)
22 TCAUH0007QSZZ AD D Laser caution label
23 SPAKA0432QSZZ AC N D SPF protect sheet JAG (AR-157E)

RANK

MARK

PART

RANK

Dust cover A3A (AR-122E Except Australia,New zealand,Syngapore,Malaysia,Indonesia,

DESCRIPTION

Hong kong,India,South africa)

Packing material & accessories

V

14

21

14

23

17

22

200V Series

15

1

7

5

6

8

1

13

3

19

5

4

3

9

20

12

10

PRP00976

– 25 –

Operation PWB

W

PRICE

NEW

NO. PARTS CODE

1 QCNCM0861FCZZ AB C Connector(3pin) [CN302]
2 QCNCW1132LC1H AD C Connector(18pin) [CN301]

QSW-P0001ESZZ AC B Tact swtch(SKQNAB010) [MAGK,ZDWK,CLK,ZUPK,OLK]
QSW-P0001ESZZ AC B Tact swtch(SKQNAB010) [10UPK,1UPK,EXUPK,EXDWK]

3

QSW-P0001ESZZ AC B Tact swtch(SKQNAB010) [EXMODK,CRSK,PSW,SCNK]
QSW-P0001ESZZ AC B Tact swtch(SKQNAB010) (AR-157E)[DUPK]
QSW-P0001ESZZ AC B Tact swtch(SKQNAB010) (Except AR122E/152E)[BPK]

4 VCCCCY1HH201J AA C Capacitor(50WV 200pF) [C317,C319,C326,C327]
5 VCEAJU1CW476M AB C Capacitor(16WV 47µF) [C301]
6 VCKYCY1CB104K AB C Capacitor(16WV 0.1µF) [C311,C323]
7 VCKYCY1HB102K AA C Capacitor(50WV 1000pF) [C302∼310,312∼316]
8 VCKYCY1HB223K AC C Capacitor(50WV 0.022µF) [C318,325]

9 VHDDSS133//-1 AA B Diode(1SS133) [D301∼310]
10 VHILC7935//-1 AN B IC(LC7935) [IC303]
11 VHI74HC151M-1 AD B IC(74HC151M) [IC301,IC302]

VHP1LHEE-002A AC B LED(Red)(1LHEE-002A) [TPL,DPL,JPL,MPL]

12

VHP1LHEE-002A AC B LED(Red)(1LHEE-002A) (Except AR122E/152E)[SJAL]
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) [PE,ME,RPL,AE,ZPL]
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) [EXD,EXN,EXL,CS1L]
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) [BPL,3RE,2RE,1RE]

13

VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) [NOR,1ENR,2ENR,PML]
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) [ONLL,SCNL]
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) (AR-157E)[DAA1,DAA2,DU21,DU22]
VHP1LHLE-002A AC B LED(Green)(LTL-1LHLE-002A) (Except AR122E/152E)[SPFL,CS2L]

14 VHP3650AG2J-1 AL B LED(7SEGMENT)(LTC-3650AG-02J) [LEDM]

VRS-CY1JD101J AA C Resistor(1/16W 100Ω ±5%) [R302,308,309,310,312]

15

VRS-CY1JD101J AA C Resistor(1/16W 100Ω ±5%) [R313,314,318,319,321]
VRS-CY1JD101J AA C Resistor(1/16W 100Ω ±5%) [R322,324,327,336]
VRS-CY1JD102J AA C Resistor(1/16W 1.0KΩ ±5%) [R317,335,338,339]

16

VRS-CY1JD102J AA C Resistor(1/16W 1.0KΩ ±5%) [R340,352,357,360]
17 VRS-CY1JD121J AA C Resistor(1/16W 120Ω ±5%) [R328∼334,341∼349,361]
18 VRS-CY1JD151J AA C Resistor(1/16W 150Ω ±5%) [R350,351,358]
19 VRS-CY1JD152J AA C Resistor(1/16W 1.5KΩ ±5%) [R304,359]
20 VRS-CY1JD471J AA C Resistor(1/16W 470Ω ±5%) [R353,354]

VRS-CY1JD472J AA C Resistor(1/16W 4.7KΩ ±5%) [R301,303,305,306,307]
21

VRS-CY1JD472J AA C Resistor(1/16W 4.7KΩ ±5%) [R311,315,316,320,323]

VRS-CY1JD472J AA C Resistor(1/16W 4.7KΩ ±5%) [R325,326,337,355]

22 VRS-CY1JD511J AA C Resistor(1/16W 510Ω ±5%) [R356,362]
23 RH-TX0003ESZZ AC B Digital trnsistor(KRA225S) [Q301,302,303]

(Unit)

CPWBF0113QSE8 BB N E Operation PWB (AR-122E/152E)

901

CPWBF0113QSE9 BB N E Operation PWB (AR-153E)

CPWBF0113QSF0 BB N E Operation PWB (AR-157E)

RANK

MARK

PART
RANK

DESCRIPTION

MCU PWB

X

PRICE

NEW

NO. PARTS CODE

1 QCNCM0079QSZZ AC C Connector(2pin) [CN116]
2 QCNCM0923FC14 AE C Connector(14pin) (AR-153E/157E)[CN115]
3 QCNCM0923FC18 AF C Connector(18pin) [CN119]

QCNCM0923FC24 AF C Connector(24pin) [CN101]

4

QCNCM0923FC24 AF C Connector(24pin) (AR-153E/157E)[CN122]

5 QCNCW0948FCZ5 AC C Connector(5pin) (AR-153E/157E)[CN114]
6 QCNCM1005MCZZ AB C Connector(2pin) [CN124]
7 QCNCM2401SC0C AB C Connector(3pin) [CN111]
8 QCNCM2401SC0D AC C Connector(4pin) [CN106A,CN103]
9 QCNCM2401SC0E AC C Connector(5pin) [CN123]

QCNCM7014SC0C AA C Connector(3pin) [CN113,CN110]
10

QCNCM7014SC0C AA C Connector(3pin) (AR-153E/157E)[CN109]
11 QCNCM7014SC0D AB C Connector(4pin) [CN112]
12 QCNCM7014SC0E AB C Connector(5pin) [CN120]
13 QCNCM7014SC0F AB C Connector(6pin) [CN125]
14 QCNCP0340QCZZ AC C Connector(3pin) [CN108]
15 QCNCP0341QCZZ AC C Connector(3pin) [CN117]
16 QCNCW0024QSZZ AF C Connector(32pin) [CN105]
17 QCNCW0078QSZZ AF C Connector(35pin) [CN104]
19 QCNCW1124LC0H AC C Connector(8pin) [CN107]
20 QCNCW1124LC1H AD C Connector(18pin) [CN102]
21 QSOCZ0002QSZZ AD C IC socket(8pin) [For IC102]
22 RCILZ0015QSZZ AD CCoil [L129]
23 RCRSP0016QSZZ AD B Cristal(19.6608MHz) [X101]
24 RCRUB0013QSZZ AN B Cristal(24MHz) [X102]
25 RCRUB0016QSZZ AN B Cristal(13.9867MHz) [X103]

RFILZ0004QSZZ AM C Filter(ZJSR5101-223) [L101,L113,L123,L124]
26

RFILZ0004QSZZ AM C Filter(ZJSR5101-223) [L125,L126,L127]
27 RH-DX0001ESZZ AC B Diode(11EQS06-TA1B2) [D139]

RANK

MARK

PART
RANK

DESCRIPTION

– 26 –

MCU PWB

X

PRICE

NEW

NO. PARTS CODE

28 RH-DZ0016FCZZ AB B Diode(MA700) [D101]
29 RH-IX0001QSZZ BD B IC(MT48LC8M16ATG-8E) (AR-153E/157E)[IC110]
30 RH-IX0002QSZZ AZ B IC(MT48LC4M16ATG-8E) (AR-122E/152E)[IC110]
31 RH-IX0020QSZZ AS B IC(UT61L1024JC-15) [IC112]
32 RMPTW4100QCJJ AA B Block resistor(10Ω×4) [BR156,BR157,BR158]
33 RMPTW4102QCJJ AB B Block resistor(1.0KΩ×4) [BR160,BR161,BR162,BR163]

RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR101,BR102,BR103,BR104,BR105]
RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR106,BR107,BR108,BR109,BR110]
RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR111,BR112,BR114,BR115,BR117]

34

RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR133,BR135,BR137,BR139,BR145]
RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR146,BR148,BR150,BR152,BR153]
RMPTW4103QCJJ AB B Block resistor(10KΩ×4) [BR154,BR155,BR159]
RMPTW4330QCJJ AB B Resistor arrey(33Ω×4 1/32W ±5%) [BR116,BR118,BR119,BR120,BR121]
RMPTW4330QCJJ AB B Resistor arrey(33Ω×4 1/32W ±5%) [BR122,BR123,BR124,BR125,BR126]
RMPTW4330QCJJ AB B Resistor arrey(33Ω×4 1/32W ±5%) [BR127,BR128,BR129,BR130,BR134]

35

RMPTW4330QCJJ AB B Resistor arrey(33Ω×4 1/32W ±5%) [BR136,BR138,BR140,BR141,BR131]
RMPTW4330QCJJ AB B Resistor arrey(33Ω×4 1/32W ±5%) [BR132,BR142,BR143,BR144,BR147]
RMPTW4330QCJJ AB B Resistor arrey(33Ω×4 1/32W ±5%) [BR149,BR151]

36 TLABZ4201FCZZ AC D Version label
37 VCCCCZ1HH101J AA C Capacitor(50WV 100pF) [C104,C105,C190,C191,C192]
38 VCCCCZ1HH120J AA C Capacitor(50WV 12pF) [C106,C165,C167]
39 VCCCCZ1HH220J AA C Capacitor(50WV 22pF) [C102,C103]
40 VCCCCZ1HH330J AA C Capacitor(50WV 33pF) [C186,C188,C194,C302]

VCCCCZ1HH470J AA C Capacitor(50WV 47pF) [C126,C315,C316,C317,C318]

41

VCCCCZ1HH470J AA C Capacitor(50WV 47pF) [C319,C320,C321,C166]
42 VCEAGA1CW105M AA C Capacitor(16WV 1.0µF) [C206]
43 VCEAGA1CW106M AA C Capacitor(16WV 10µF) [C109]
44 VCEAGA1CW226M AB C Capacitor(16WV 22µF) [C174,C286,C287,C322]

VCEAGA1CW476M AB C Capacitor(16WV 47µF) [C139]
45

VCEAGA1CW476M AB C Capacitor(16WV 47µF) (AR-153E/157E)[C217,C219]
46 VCEAGA1EW476M AA C Capacitor(25WV 47uF) [C284]
47 VCEAGA1VW106M AA C Capacitor(35WV 10µF) [C212]
48 VCEAGA1VW476M AB C Capacitor(35WV 47uF) [C208,C276,C282,C299,C300]

VCKYCY1HB104K AA C Capacitor(50WV 0.10µF) [C277,C313,C314,C209,C210]
49

VCKYCY1HB104K AA C Capacitor(50WV 0.10µF) [C213,C334,C335,C301]
50 VCKYCZ1CB223K AB C Capacitor(16WV 0.022µF) [C125,C163,C169,C197,C200]

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C101,C107,C108,C110,C111]

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C112,C113,C114,C115,C124]

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C127,C128,C129,C130,C131]

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C132,C133,C134,C135,C136]

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C137,C138,C140,C141,C142]

51

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C143,C144,C145,C146,C147]

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C148,C149,C150,C151,C152]

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C153,C154,C155,C156,C157]

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C158,C159,C160,C161,C162]

VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C164,C168,C170,C171]

VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C261,C262,C263,C264,C265]

VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C266,C278,C279,C280,C281]

VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C290,C291,C292,C293,C294]

52

VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C295,C296,C297,C298,C303]

VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C304,C305,C306,C307,C309]

VCKYCZ1HB102K AA C Capacitor(50WV 1000pF) [C310,C311,C312]

53 VCKYCZ1HB222K AA C Capacitor(50WV 2200pF) [C211,C214,C218,C222]
54 VCKYCZ1HB821K AC C Capacitor(50WV 820pF) [C201,C202,C203,C204]
55 VHDDSS133//-1 AA B Diode(1SS133) [D104,D120,D124,D127]

VHDKDS121++-1 AC B Diode(KDS121) [D116,D117,D118,D121,D122]

VHDKDS121++-1 AC B Diode(KDS121) [D123,D125,D126,D128,D129]

56

VHDKDS121++-1 AC B Diode(KDS121) [D130,D131,D132,D133]

VHDKDS121++-1 AC B Diode(KDS121) [D134,D135,D136,D137]

57 VHDKDS226++-1 AC B Diode(KDS226) [D102,D103,D119,D138,D140,D143]
58 VHEMTZJ22B/-1 AA B Zener diode(MTZJ22B) (AR-153E/157E)[D109]
59 VHI28F4BVEB85 AX B IC(28F4BVEB85) [IC111]

VHI74HC151M-1 AD B IC(74HC151M) [IC114,IC115]
60

VHI74HC151M-1 AD B IC(74HC151M) (AR-153E/157E)[IC117]
61 VHIBA6920FP-1 AL B IC(BA6920FP) [IC129]
62 VHID65001AF-1 AG B IC(D65001AF) [IC119,IC121]
63 VHID65503F+-1 AG B IC(D65503F) [IC124,IC125]
64 VHIEES02L400P AG B IC(EES02L400P) [IC102]
65 VHIH8S2320+-1 AY B IC(H8S/2320) [IC103]
66 VHIHG73C1191C BH B IC(HG73C1191C) [IC106]
67 VHIKA7805AP-1 AE B IC(KIA7805API) [IC130]
68 VHIKIA358F+-1 AE B IC(KIA358F) [IC122]
69 VHIKIA393F+-1 AE B IC(KIA393F) [IC120]
70 VHIL6219DS+-1 AN B IC(L6219DS) [IC127]
71 VHILCX244WM-1 AG B IC(74LCX244WM) [IC118,IC113]
72 VHIM51957BFP1 AH B IC(M51957BFP1) [IC104]
73 VHIMTD1361F-1 AR B IC(MTD1361F) (AR-153E/157E)[IC128]
74 RH-IX0005ESZZ AE B IC(IX0005ES) [IC131]
75 VHINC7ST08M-1 AD B IC(NC7ST08M) [IC107]
76 VHIP2010ASR-1 AN B IC(P2010ASR) [IC101]

RANK

MARK

PART
RANK

DESCRIPTION

– 27 –

MCU PWB

X

PRICE

NEW

NO. PARTS CODE

77 VHITD62064AF/ AM B IC(TD62064AF) (AR-153E/157E)[IC123,IC126]
78 VHIVHCT244M-1 AG B IC(VHCT244M) [IC116]
79 VHVICPN38//-1 AF B IC protector(ICPN38) [CP101,CP102,CP103]
80 VRD-HT2EY151J AA C Resistor(1/4W 150Ω ±5%) (AR-153E/157E)[R251]
81 VRD-HT2EY391J AA C Resistor(1/4W 390Ω ±5%) [R245,R246,R247,R253]
82 VRD-HT2EY472J AA C Resistor(1/4W 4.7KΩ ±5%) [R166]
83 VRN-VT3ATR68J AC C Resistor(1W 0.68Ω ±5%) [R178,R177]
84 VRS-CZ1JD000J AA C Resistor(1/16W 0Ω ±5%) [R102,R105,R106,R287]
85 VRS-CZ1JD100J AA C Resistor(1/16W 10Ω ±5%) [R144,R145,R149,R267]
86 VRS-CZ1JD101J AA C Resistor(1/16W 100Ω ±5%) [R120,R170,R202,R278]
87 VRS-CZ1JD102F AA C Resistor(1/16W 1KΩ ±1%) [R154]

VRS-CZ1JD102J AA C Resistor(1/16W 1.0KΩ ±5%) [R157,R181,R185,R195,R207]

88

VRS-CZ1JD102J AA C Resistor(1/16W 1.0KΩ ±5%) [R214,R216,R235,R236,R237]
VRS-CZ1JD102J AA C Resistor(1/16W 1.0KΩ ±5%) [R244,R187,R188,R282,R291]

89 VRS-CZ1JD103F AA C Resistor(1/16W 10KΩ ±1%) [R117,R158,R173]

VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R108,R110,R111,R112,R113]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R115,R118,R122,R123,R124]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R125,R126,R127,R128,R134]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R136,R137,R140,R141,R146]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R147,R148,R172,R187,R188]

90

VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R189,R190,R192,R193,R208]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R209,R210,R211,R212,R213]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R221,R222,R223,R224,R226]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R227,R228,R231,R233,R234]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ ±5%) [R238,R242,R248,R249]

91 VRS-CZ1JD105F AA C Resistor(1/16W 1.0MΩ ±1%) [R155]
92 VRS-CZ1JD113F AA C Resistor(1/16W 11KΩ ±1%) [R114]
93 VRS-CZ1JD122F AA C Resistor(1/16W 1.2KΩ ±1%) [R171]
94 VRS-CZ1JD122J AA C Resistor(1/16W 1.2KΩ ±5%) [R201]

VRS-CZ1JD152J AA C Resistor(1/16W 1.5KΩ ±5%) [R150,R151,R152,R153,R160]

95

VRS-CZ1JD152J AA C Resistor(1/16W 1.5KΩ ±5%) [R162,R163,R164,R165,R167]
VRS-CZ1JD152J AA C Resistor(1/16W 1.5KΩ ±5%) [R168,R179,R180]

96 VRS-CZ1JD153J AA C Resistor(1/16W 15KΩ ±5%) [R240,R275]
97 VRS-CZ1JD202J AA C Resistor(1/16W 2.0KΩ ±5%) [R184]
98 VRS-CZ1JD203J AA C Resistor(1/16W 20KΩ ±5%) [R215,R217]

99 VRS-CZ1JD220J AA C Resistor(1/16W 22Ω ±5%) [R107]
100 VRS-CZ1JD241J AA C Resistor(1/16W 240KΩ ±5%) [R174,R175,R176]
101 VRS-CZ1JD242J AA C Resistor(1/16W 2.4KΩ ±5%) [R198,R203]
102 VRS-CZ1JD272J AA C Resistor(1/16W 2.7KΩ ±5%) [R218]
103 VRS-CZ1JD301J AA C Resistor(1/16W 300Ω ±5%) [R169,R199]
104 VRS-CZ1JD303J AA C Resistor(1/16W 30KΩ ±5%) [R182,R183]

VRS-CZ1JD330J AA C Resistor(1/16W 33Ω ±5%) [R119,R254,R255,R256,R257]

105

VRS-CZ1JD330J AA C Resistor(1/16W 33Ω ±5%) [R258,R259,R260,R261,R262]
VRS-CZ1JD330J AA C Resistor(1/16W 33Ω ±5%) [R276,R277,R285,R121]

106 VRS-CZ1JD332J AA C Resistor(1/16W 3.3KΩ ±5%) [R232]
107 VRS-CZ1JD393J AA C Resistor(1/16W 39KΩ ±5%) [R211,R223,R226,R227]
108 VRS-CZ1JD432F AA C Resistor(1/16W 4.3KΩ ±1%) [R159]
109 VRS-CZ1JD471J AA C Resistor(1/16W 470Ω ±5%) [R239]
110 VRS-CZ1JD472J AA C Resistor(1/16W 4.7KΩ ±5%) [R281]
111 VRS-CZ1JD473J AA C Resistor(1/16W 47KΩ ±5%) [R161,R204,R205]
112 VRS-CZ1JD511J AA C Resistor(1/16W 510Ω ±5%) [R186]
113 VRS-CZ1JD563J AA C Resistor(1/16W 56KΩ ±5%) [R241]
114 VRS-CZ1JD621J AA C Resistor(1/16W 620Ω ±5%) [R200]
115 VRS-CZ1JD751J AA C Resistor(1/16W 750Ω ±5%) [R196]
116 VRS-CZ1JD752F AA C Resistor(1/16W 7.5KΩ ±1%) [R156]
117 VRS-CZ1JD752J AA C Resistor(1/16W 7.5KΩ ±5%) [R191,R194,R229,R230,R231]
118 VRS-HT3DA102J AA C Resistor(2W 1.0KΩ ±5%) [R220]
119 VRS-HT3DA1R0J AB C Resistor(2W 1.0Ω ±5%) (AR-153E/157E)[R206,R197]
120 VRS-HT3DA101J AA C Resistor(2W 100Ω ±5%) [R225]
121 VRS-HT3DAR22J AA C Resistor(2W 0.22Ω ±5%) [R219]
122 VSKRA119S++-1 AB B Transistor(KRA119S) [Q102]
123 VSKRC106S++-1 AB B Transistor(KRC106S) [Q103,Q106,Q107,Q110]
124 VSKTA1281++-1 AD B Transistor(KTA1281) [Q108]
125 VSKTA1505S+-1 AC B Transistor(KTA1505S) [Q101]
126 VSKTC3198++-1 AB B Transistor(KTC3198+) [Q109]
127 RFILN0043FCZZ AC C Filter(ZJSR5101-102) [L103,L110]

(Unit)

CPWBX0112QS3A BW N E MCU PWB (AR-122E)

901

CPWBX0112QS3G BW N E MCU PWB (AR-152E)
CPWBX0112QS3D BY E MCU PWB (AR-153E/157E)

RANK

MARK

PART
RANK

DESCRIPTION

– 28 –

DC power supply PWB (120V Series)

Y

PRICE

NEW

NO. PARTS CODE

1 0AV1690000106 AD C Ceramic capacitor(DE1007-486E222M-KH 2200PF KH) [C1,C003,C020,C021]
2 0AV1560000003 AH C Film capacitor(RE224-C 0.22µF 250V) [C2,C006]
3 0AV1690000088 AC C Ceramic capacitor(TRPE132R104K50 0.22µF 250V) [C4,C019,C114]
4 0AV1560000002 AD C Film capacitor(RE104-C 0.1µF 250V) [C5]
5 0AV1690000094 AD C Ceramic capacitor(DE1207-486E332M-KH 3300PF KH) [C7]
6 0AV1480000083 AC C Film capacitor(ECQB1H102JF4 1000pF 50V) [C8,C023]
7 0AV1480000079 AC C Film capacitor(ECQB1H103JF4 0.01µF 50V) [C9,0014]
8 0AV1390000176 AQ C Al-electrolytic capacitor(LLS2D471MHLZ 470µF 200V) [C10]
9 0AV1610000091 AC C Ceramic capacitor(DE0905-979R102K1K 1000PF 1KV) [C11.C101]

10 0AV1690000110 AD C Ceramic capacitor(TRPE132R683K50 0.068µF 50V) [C12]
11 0AV1390000107 AC C Al-electrolytic capacitor(UPJ1HR47MDH 0.47µF 50V) [C13,C106]
12 0AV1610000108 AD C Ceramic capacitor(DE1307-486R222K1K 2200PF 1KV) [C15]

0AV1390000108 AC C Al-electrolytic capacitor(UPJ1V220MDH 22µF 35V) [C17,C018,C111,C107]

13

0AV1390000108 AC C Al-electrolytic capacitor(UPJ1V220MDH 22µF 35V) [C108,C109]
14 0AV1390000177 AC C Al-electrolytic capacitor(UPJ1E221MPH 220µF 25V) [C102]
15 0AV1390000181 AE C Al-electrolytic capacitor(UHD1A102MPR 1000µF 10V) [C103,C104]
16 0AV1390000178 AG C Al-electrolytic capacitor(UPJ1H821MHH 820µF 50V) [C105]
17 0AV1390000182 AG C Al-electrolytic capacitor(UHD1V102MHR 1000µF 35V) [C110]
18 0AV1390000179 AC C Al-electrolytic capacitor(UPJ1H100MDH 10µF 50V) [C112]
19 0AV1610000109 AC C Ceramic capacitor(DE0705-979R471K1K 470PF 1KV) [C113,C116]
20 0AV1390000180 AC C Al-electrolytic capacitor(UPJ1H3R3MDH 3.3µF 50V) [C115]

0AV3050086000 AB B Diode(1SS270A 0.15A 70V) [D1,D014,D106,D108]
21

0AV3050086000 AB B Diode(1SS270A 0.15A 70V) [D111,D113,D115,D118]
22 0AV3060027000 AH B Diode(D3SB60 4A 600V) [D2]
23 0AV3060043000 AC B Rectifier(RLIN4005-E 1A 600V) [D3,D004,D012,D015]
24 0AV3070058000 AC B Zenner diode(RD5.6ES 0.4W) [D5,D110,D116]
25 0AV3050036000 AF B Diode(RG1C 0.7A 1000V) [D6]
26 0AV3050019000 AF B Diode(ERA9102 0.5A 200V) [D7,D008,D010]
27 0AV3070085000 AC B Zenner diode(RD33ES 0.4W) [D9]
28 0AV3070056000 AD B Zenner diode(RD20ES 0.4W) [D11,D013]
29 0AV3050097000 AG B Diode(SF10LC20U 10A 200V) [D101]
30 0AV3050099000 AD B Diode(D1NL20U 1A 200V) [D102]
31 0AV3050098000 AG B Diode(SF5SC4 5A 40V) [D103]
32 0AV3070061000 AC B Zenner diode(RD4.7ES 0.4W) [D104]
33 0AV3070057000 AC B Zenner diode(RD30ES 0.4W) [D107]
34 0AV3070074000 AC B Zenner diode(RD13ES 0.4W) [D109]
35 0AV3070081000 AC B Zenner diode(RD3.9ES 0.4W) [D112,D117]
36 0AV3190008000 AN B FET(F12F50VX3 12A 500V) [Q1]
37 0AV3001015090 AD B Transistor(2SA1015 -0.15A -50V) [Q2]
38 0AV3020143999 AD B Transistor(DTC143ESA 0.1A 50V) [Q101,Q108,Q110]
39 0AV3040494000 AP B FET(2SJ494 20A 60V) [Q102]

0AV3021815090 AC B Transistor(2SC1815 0.15A 50V) [Q104,Q106,Q107]
40

0AV3021815090 AC B Transistor(2SC1815 0.15A 50V) [Q109,Q113]
41 0AV3001020000 AE B Transistor(2SA1020 -2A -50V) [Q105]
42 0AV3000143999 AD B Transistor(DTA143ESA -0.1A -50V) [Q112]
43 0AV2014743030 AA C Fixed carbon film resistor(RDF50S470KΩJ 470KΩ 1/2W) [R1]
44 0AV2041013020 AC B Fusing resistor(RF25S100ΩJ 100Ω 1/4W) [R2]
45 0AV2011213030 AB C Fixed carbon film resistor(RDF50S120ΩJ 120Ω 1/2W) [R3]
46 0AV2041213030 AC B Fusing resistor(RF50S120ΩJ 120Ω 1/2W) [R4]
47 0AV2013933030 AC C Fixed carbon film resistor(RDF50S39KΩJ 39KΩ 1/2W) [R5,R006]
48 0AV2011043010 AA C Fixed carbon film resistor(RDF16S100KΩJ 100KΩ 1/6W) [R7,R008]
49 0AV2012233010 AA C Fixed carbon film resistor(RDF16S22KΩJ 22KΩ 1/6W) [R9,R121,R133,R135]
50 0AV2013333010 AA C Fixed carbon film resistor(RDF16S33KΩJ 33KΩ 1/6W) [R10,R014,R026]
51 0AV2011003020 AA C Fixed carbon film resistor(RDF25S10ΩJ 10Ω 1/4W) [R11]
52 0AV2091083042 AC C Special power resistor(SPR1B0.1ΩJ 0.1Ω 1W) [R12]
53 0AV2041013010 AC B Fusing resistor(RF16S100ΩJ 100Ω 1/6W) [R13]

0AV2011033010 AA C Fixed carbon film resistor(RDF16S10KΩJ 10KΩ 1/6W) [R15,R019,R023]
54

0AV2011033010 AA C Fixed carbon film resistor(RDF16S10KΩJ 10KΩ 1/6W) [R104,R122,R134]
55 0AV2016833010 AA C Fixed carbon film resistor(RDF16S68KΩJ 68KΩ 1/6W) [R16]
56 0AV2015603010 AA C Fixed carbon film resistor(RDF16S56ΩJ 56Ω 1/6W) [R17]
57 0AV2026833062 AD C Metal oxide film resistor(RSS3FB68KΩJ 68KΩ 3W) [R18]
58 0AV2016803030 AA C Fixed carbon film resistor(RDF50S68ΩJ 68Ω 1/2W) [R20]
59 0AV2015633010 AA C Fixed carbon film resistor(RDF16S56KΩJ 56KΩ 1/6W) [R21]
60 0AV2011023010 AA C Fixed carbon film resistor(RDF16S1KΩJ 1KΩ 1/6W) [R22,R113]
61 0AV2018233020 AB C Fixed carbon film resistor(RDF25S82KΩJ 82KΩ 1/4W) [R24,R025]
62 0AV2011033030 AB C Fixed carbon film resistor(RDF50S10KΩJ 10KΩ 1/2W) [R101]
63 0AV2012213010 AA C Fixed carbon film resistor(RDF16S220ΩJ 220Ω 1/6W) [R103]
64 0AV2016823010 AA C Fixed carbon film resistor(RDF16S6.8KΩJ 6.8KΩ 1/6W) [R105]

0AV2014723010 AA C Fixed carbon film resistor(RDF16S4.7KΩJ 4.7KΩ 1/6W) [R106,R114,R115,R116]
65

0AV2014723010 AA C Fixed carbon film resistor(RDF16S4.7KΩJ 4.7KΩ 1/6W) [R123,R124,R136,R137]
66 0AV2011533010 AA C Fixed carbon film resistor(RDF16S15KΩJ 15KΩ 1/6W) [R107]
67 0AV2990007000 AC C Metal film resistor(SN14K2C2.2KΩD 2.2KΩ 1/6W) [R109,R111]
68 0AV2014713010 AA C Fixed carbon film resistor(RDF16S470ΩJ 470Ω 1/6W) [R110,R112]
69 0AV2990082000 AC C Metal film resistor(SN14K2C12KΩD 12KΩ 1/6W) [R119]
70 0AV2990083000 AC C Metal film resistor(SN14K2C3.44KΩD 3.44KΩ 1/6W) [R120]
71 0AV2021023052 AC C Metal oxide film resistor(RSS2FB1KΩJ 1KΩ 2W) [R130]
72 0AV2014733010 AA C Flame proof fixed carbon film resistor(RDF16S47KΩJ 47KΩ 1/6W) [R131]
73 0AV2012203010 AA C Flame proof fixed carbon film resistor(RDF16S22ΩJ 22Ω 1/6W) [R132]
74 0AV4070061000 AF C Inductor(LF-4Z-E182) [L1,L002]
75 0AV4120002000 AC C Inductor(B-01-A) [L3,L004,L101]

RANK

MARK

PART

RANK

DESCRIPTION

– 29 –

DC power supply PWB (120V Series)

Y

PRICE

NEW

NO. PARTS CODE

75 0AV4120002000 AC C Inductor(B-01-A) [L102,L103]
76 0AV4080007000 AH C Inductor(SK-12M-4Y) [L5]
77 0AV4120013000 AC C Inductor(T3140P3206536HW) [L104]
78 0AV4000134711 AS B Transformer(N-T01-347-F11) [T1]
79 0AV3160034000 AQ B Triac(TM1641PLF113) [TR1]
80 0AV5140021000 AF B Power thermistor(M5R114T3C) [TH1]
81 0AV5190002000 AF B Varistor(ENC271D-10A) [X1]
82 0AV3180000004 AL B Phototriac coupler(S21ME3Y) [PC1]
83 0AV3082561300 AF B Photo coupler(PS2561) [PC2,PC003]
84 0AV3090076000 AF B IC(MM1431ATT) [IC1,IC102]
85 0AV3090077000 AN B IC(FA3647P) [IC2]
86 0AV3090078000 AN BIC(PQ20RX11) [IC101]
87 0AV3090071000 AN B IC(PQ3RD23) [IC103]
88 0AV5030123000 AD B Connector(B02B-VT) [CN1]
89 0AV5030124000 AF B Connector(B04P-XL) [CN2]
90 0AV5030125000 AG B Connector(B16B-PHDSS-B) [CN101]
91 0AV5080010000 AQ B Relay(FTR-H1AA024V) [RL1]
92 0AV5190022000 AK B Arrestor(RA-351M-V6-Y-2) [Z1,Z002]
93 0AV5040012000 AM B Switch(SDDJE30501 10A 250V) [S1]

! 94 0AV5060058000 AK A Fuse(CES6-15A-N1 15A/125V) [F1]
! 95 0AV5060020000 AG A Fuse(TSCSA5AT-JUC 5A/125V) [F2]

96 0AV5050005000 AA C Fuse holder(PFC5000-0203)
97 0AV5130006000 AB C Terminal(TP00335-31)
98 0AV5130008000 AC C Terminal(TP00370-41)

99 0AV7100003000 AE C Insulation sheet(M-30AD-D-3)
100 0AV6114125811 AF C Heatsink(LM41258)
101 0AV8117730414 AB C Screw(NACPEW-B3×8ZF B3×8)
102 0AV8117730514 AB C Screw(NACPEW-B3×10ZF B3×10)
103 0AV7414135811 AD C Label(LV41358)
104 0AV5110012000 AB C Jumper wire(RJ-SKA-06 6mm) [RJ701,RJ717,RJ724]

0AV5110001000 AA C Jumper wire(RJ-SCA-06 10mm) [RJ712,RJ713,RJ715]

105

0AV5110001000 AA C Jumper wire(RJ-SCA-06 10mm) [RJ721,RJ725,RJ727]
0AV5110006000 AA C Jumper wire(RJ-SDA-06 12.5mm) [RJ711,RJ723,RJ726,RJ731]

106

0AV5110006000 AA C Jumper wire(RJ-SDA-06 12.5mm) [RJ740,RJ742,RJ744]
0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ702,RJ704,RJ705,RJ714]
0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ719,RJ720,RJ729,RJ730]

107

0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ732,RJ733,RJ734,RJ735]
0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ737,RJ739,RJ741,RJ743]
0AV5110004000 AA C Jumper wire(RJ-SGA-06 20mm) [RJ703,RJ706,RJ708,RJ709,RJ710]

108

0AV5110004000 AA C Jumper wire(RJ-SGA-06 20mm) [RJ722,RJ728,RJ736,RJ738]

! 901 RDENC0006QS12 BN E DC power supply PWB (120V Series)

(Unit)

RANK

MARK

PART
RANK

DESCRIPTION

DC power supply PWB (127V Series)

Z

PRICE

NEW

NO. PARTS CODE

1 0AV1690000106 AD C Ceramic capacitor(DE1007-486E222M-KH 0.22µF 250V) [C1,C003,C020,C021]
2 0AV1560000003 AH C Film capacitor(RE224-C 0.22µF 250V) [C2,C006]
3 0AV1690000088 AC C Ceramic capacitor(TRPE132R104K50 0.1µF 50V) [C4,C019,C114]
4 0AV1560000002 AD C Film capacitor(RE104-C 0.1µF 250V) [C5]
5 0AV1690000094 AD C Ceramic capacitor(DE1207-486E332M-KH 3300PF KH) [C7]
6 0AV1480000083 AC C Film capacitor(ECQB1H102JF4 1000pF 50V) [C8,C023]
7 0AV1480000079 AC C Film capacitor(ECQB1H103JF4 0.01µF 50V) [C9,0014]
8 0AV1390000197 AR N C Al-electrolytic capacitor(LLS2E471MHLZ 470µF 250V) [C10]

9 0AV1610000091 AC C Ceramic capacitor(DE0905-979R102K1K 1000PF 1KV) [C11,C101]
10 0AV1690000110 AD C Ceramic capacitor(TRPE132R683K50 0.068µF 50V) [C12]
11 0AV1390000107 AC C Al-electrolytic capacitor(UPJ1HR47MDH 0.47µF 50V) [C13,C106]
12 0AV1610000108 AD C Ceramic capacitor(DE1307-486R222K1K 2200PF 1KV) [C15]

0AV1390000108 AC C Al-electrolytic capacitor(UPJ1V220MDH 22µF 35V) [C17,C018,C111,C107]

13

0AV1390000108 AC C Al-electrolytic capacitor(UPJ1V220MDH 22µF 35V) [C108,C109]
14 0AV1390000177 AC C Al-electrolytic capacitor(UPJ1E221MPH 220µF 25V) [C102]
15 0AV1390000181 AE C Al-electrolytic capacitor(UHD1A102MPR 1000µF 10V) [C103,C104]
16 0AV1390000178 AG C Al-electrolytic capacitor(UPJ1H821MHH 820µF 50V) [C105]
17 0AV1390000182 AG C Al-electrolytic capacitor(UHD1V102MHR 1000µF 35V) [C110]
18 0AV1390000179 AC C Al-electrolytic capacitor(UPJ1H100MDH 10µF 50V) [C112]
19 0AV1610000109 AC C Ceramic capacitor(DE0705-979R471K1K 470PF 1KV) [C113,C016]
20 0AV1390000180 AC C Al-electrolytic capacitor(UPJ1H3R3MDH 3.3µF 50V) [C115]

0AV3050086000 AB B Diode(1SS270) [D1,D014,D106]
21

0AV3050086000 AB B Diode(1SS270) [D108,D111]

0AV3050086000 AB B Diode(1SS270) [D113,D115,D118]

22 0AV3060027000 AH B Diode(D3SB60 4A 600V) [D2]
23 0AV3060043000 AC B Rectifier(RLIN4005-E 1A 600V) [D3,D004,D012,D015]
24 0AV3070058000 AC B Zenner diode(RD5.6ES 0.4W) [D5,D110,D116]
25 0AV3050036000 AF B Diode(RG1C 0.7A 1000V) [D6]

RANK

MARK

PART
RANK

DESCRIPTION

– 30 –

DC power supply PWB (127V Series)

Z

PRICE

NEW

NO. PARTS CODE

26 0AV3050019000 AF B Diode(ERA9102 0.5A 200V) [D7,D008,D010]
27 0AV3070085000 AC B Zenner diode(RD33ES 0.4W) [D9]
28 0AV3070056000 AD B Zenner diode(RD20ES 0.4W) [D11,D013]
29 0AV3050097000 AG B Diode(SF10LC20U 10A 200V) [D101]
30 0AV3050099000 AD B Diode(D1NL20U 1A 200V) [D102]
31 0AV3050098000 AG B Diode(SF5SC4 5A 40V) [D103]
32 0AV3070061000 AC B Zenner diode(RD4.7ES 0.4W) [D104]
33 0AV3070057000 AC B Zenner diode(RD30ES 0.4W) [D107]
34 0AV3070074000 AC B Zenner diode(RD13ES 0.4W) [D109]
35 0AV3070081000 AC B Zenner diode(RD3.9ES 0.4W) [D112,D117]
36 0AV3190008000 AN B FET(F12F50VX3 12A 500V) [Q1]
37 0AV3001015090 AD B Transistor(2SA1015 -0.15A -50V) [Q2]
38 0AV3020143999 AD B Transistor(DTC143ESA 0.1A 50V) [Q101,Q108,Q110]
39 0AV3040494000 AP B FET(2SJ494 20A 60V) [Q102]

0AV3021815090 AC B Transistor(2SC1815 0.15A 50V) [Q104,Q106,Q107]

40

0AV3021815090 AC B Transistor(2SC1815 0.15A 50V) [Q109,Q113]
41 0AV3001020000 AE B Transistor(2SA1020 -2A -50V) [Q105]
42 0AV3000143999 AD B Transistor(DTA143ESA -0.1A -50V) [Q112]
43 0AV2014743030 AA C Fixed carbon film resistor(RDF50S470KΩJ 470KΩ 1/2W) [R1]
44 0AV2041013020 AC B Fusing resistor(RF25S100ΩJ 100Ω 1/4W) [R2]
45 0AV2011213030 AB C Fixed carbon film resistor(RDF50S120ΩJ 120Ω 1/2W) [R3]
46 0AV2041213030 AC B Fusing resistor(RF50S120ΩJ 120Ω 1/2W) [R4]
47 0AV2013933030 AC C Fixed carbon film resistor(RDF50S39KΩJ 39KΩ 1/2W) [R5,R006]
48 0AV2011043010 AA C Fixed carbon film resistor(RDF16S100KΩJ 100KΩ 1/6W) [R7,R008]
49 0AV2012233010 AA C Fixed carbon film resistor(RDF16S22KΩJ 22KΩ 1/6W) [R9,R121,R133,R135]
50 0AV2013333010 AA C Fixed carbon film resistor(RDF16S33KΩJ 33KΩ 1/6W) [R10,R014,R026]
51 0AV2011003020 AA C Fixed carbon film resistor(RDF25S10ΩJ 10Ω 1/4W) [R11]
52 0AV2091083042 AC C Special power resistor(SPR1B0.1ΩJ 0.1Ω 1W) [R12]
53 0AV2041013010 AC B Fusing resistor(RF16S100ΩJ 100Ω 1/6W) [R13]

0AV2011033010 AA C Fixed carbon film resistor(RDF16S10KΩJ 10KΩ 1/6W) [R15,R019,R023]
54

0AV2011033010 AA C Fixed carbon film resistor(RDF16S10KΩJ 10KΩ 1/6W) [R104,R122,R134]
55 0AV2016833010 AA C Fixed carbon film resistor(RDF16S68KΩJ 68KΩ 1/6W) [R16]
56 0AV2015603010 AA C Fixed carbon film resistor(RDF16S56ΩJ 56Ω 1/6W) [R17]
57 0AV2026833062 AD C Metal oxide film resistor(RSS3FB68KΩJ 68KΩ 3W) [R18]
58 0AV2016803030 AA C Fixed carbon film resistor(RDF50S68ΩJ 68Ω 1/2W) [R20]
59 0AV2015633010 AA C Fixed carbon film resistor(RDF16S56KΩJ 56KΩ 1/6W) [R21]
60 0AV2011023010 AA C Fixed carbon film resistor(RDF16S1KΩJ 1KΩ 1/6W) [R22,R113]
61 0AV2018233020 AB C Fixed carbon film resistor(RDF25S82KΩJ 82KΩ 1/4W) [R24,R025]
62 0AV2011033030 AB C Fixed carbon film resistor(RDF50S10KΩJ 10KΩ 1/2W) [R101]
63 0AV2012213010 AA C Fixed carbon film resistor(RDF16S220ΩJ 220Ω 1/6W) [R103]
64 0AV2016823010 AA C Fixed carbon film resistor(RDF16S6.8KΩJ 6.8KΩ 1/6W) [R105]

0AV2014723010 AA C Fixed carbon film resistor(RDF16S4.7KΩJ 4.7KΩ 1/6W) [R106,R114,R115,R116]
65

0AV2014723010 AA C Fixed carbon film resistor(RDF16S4.7KΩJ 4.7KΩ 1/6W) [R123,R124,R136,R137]
66 0AV2011533010 AA C Fixed carbon film resistor(RDF16S15KΩJ 15KΩ 1/6W) [R107]
67 0AV2990007000 AC C Metal film resistor(SN14K2C2.2KΩD 2.2KΩ 1/6W) [R109,R111]
68 0AV2014713010 AA C Fixed carbon film resistor(RDF16S470ΩJ 470Ω 1/6W) [R110,R112]
69 0AV2990082000 AC C Metal film resistor(SN14K2C12KΩD 12KΩ 1/6W) [R119]
70 0AV2990083000 AC C Metal film resistor(SN14K2C3.44KΩD 3.44KΩ 1/6W) [R120]
71 0AV2021023052 AC C Metal oxide film resistor(RSS2FB1KΩJ 1KΩ 2W) [R130]
72 0AV2014733010 AA C Flame proof fixed carbon film resistor(RDF16S47KΩJ 47KΩ 1/6W) [R131]
73 0AV2012203010 AA C Flame proof fixed carbon film resistor(RDF16S22ΩJ 22Ω 1/6W) [R132]
74 0AV4120002000 AC C Inductor(B-01-A) [L1,L002]

0AV4120002000 AC C Inductor(B-01-A) [L3,L004,L101]
75

0AV4120002000 AC C Inductor(B-01-A) [L102,L103]
76 0AV4080007000 AH C Inductor(SK-12M-4Y) [L5]
77 0AV4120013000 AC C Inductor(T3140P3206536HW) [L104]
78 0AV4000134711 AS B Transformer(N-T01-347-F11) [T1]
79 0AV3160034000 AQ B Triac(TM1641PLF113) [TR1]
80 0AV5140021000 AF B Power thermistor(M5R114T3C) [TH1]
81 0AV5190002000 AF B Varistor(ENC271D-10A) [X1]
82 0AV3180000004 AL B Phototriac coupler(S21ME3Y) [PC1]
83 0AV3082561300 AF B Photo coupler(PS2561) [PC2,PC003]
84 0AV3090076000 AF B IC(MM1431ATT) [IC1,IC102]
85 0AV3090077000 AN B IC(FA3647P) [IC2]
86 0AV3090078000 AN BIC(PQ20RX11) [IC101]
87 0AV3090071000 AN B IC(PQ3RD23) [IC103]
88 0AV5030123000 AD B Connector(B02B-VT) [CN1]
89 0AV5030124000 AF B Connector(B04P-XL) [CN2]
90 0AV5030125000 AG B Connector(B16B-PHDSS-B) [CN101]
91 0AV5080010000 AQ B Relay(FTR-H1AA024V) [RL1]
92 0AV5190022000 AK B Arrestor(RA-351M-V6-Y-2) [Z1,Z002]
93 0AV5040012000 AM B Switch(SDDJE30501 10A/250V) [S1]

! 94 0AV5060090000 AE N A Fuse(314SB15AT-JUC 15A/250V) [F1]
! 95 0AV5060091000 AF N A Fuse(215SB-5AA-SB 5A/250V) [F2]

96 0AV5050005000 AA C Fuse holder(PFC5000-0203)
97 0AV5130006000 AB C Terminal(M1866-A)
98 0AV5130008000 AC C Terminal(TP00370-41)
99 0AV7100003000 AE C Insulation sheet(M-30AD-D-3)

100 0AV6114125811 AF C Heatsink(LM41258)
101 0AV8117730414 AB C Screw(NACPEW-B3×8ZF B3×8)

RANK

MARK

PART

RANK

DESCRIPTION

– 31 –

DC power supply PWB (127V Series)

Z

PRICE

NEW

NO. PARTS CODE

102 0AV8117730514 AB C Screw(NACPEW-B3×10ZF B3×10)
103 0AV7414135811 AD C Label(LV41358)
104 0AV5110012000 AB C Jumper wire(RJ-SKA-06 6mm) [RJ701,RJ718,RJ724]

0AV5110001000 AA C Jumper wire(RJ-SCA-06 10mm) [RJ712,RJ713,RJ715]

105

0AV5110001000 AA C Jumper wire(RJ-SCA-06 10mm) [RJ721,RJ725,RJ727]
0AV5110006000 AA C Jumper wire(RJ-SDA-06 12.5mm) [RJ711,RJ723,RJ726,RJ731]

106

0AV5110006000 AA C Jumper wire(RJ-SDA-06 12.5mm) [RJ740,RJ742,RJ744]
0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ702,RJ704,RJ705,RJ714]
0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ719,RJ720,RJ729,RJ730]

107

0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ732,RJ733,RJ734,RJ735]
0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ737,RJ739,RJ741,RJ743]
0AV5110004000 AA C Jumper wire(RJ-SGA-06 20mm) [RJ703,RJ706,RJ708,RJ709]

108

0AV5110004000 AA C Jumper wire(RJ-SGA-06 20mm) [RJ710,RJ722,RJ728]
0AV5110004000 AA C Jumper wire(RJ-SGA-06 20mm) [RJ736,RJ738]

! 901 RDENC0006QS11 BQ N E DC power supply PWB (127V Series)

(Unit)

DC power supply PWB (200V Series)

[

NO. PARTS CODE

1 0AV1690000106 AD C Ceramic capacitor(DE1007-486E222M-KH 2200PF KH) [C20,C021]
2 0AV1690000088 AC C Ceramic capacitor(TRPE132R104K50 0.1µF 50V) [C4,C019,C114,C012]
3 0AV1560000002 AD C Film capacitor(RE104-C 0.1µF 250V) [C2,C005,C006]
4 0AV1690000111 AD C Ceramic capacitor(DE1210-2E222M-KX 2200PF KX) [C1,C003,C007]
5 0AV1480000083 AC C Film capacitor(ECQB1H102JF4 1000pF 50V) [C8,C023]
6 0AV1480000079 AC C Film capacitor(ECQB1H103JF4 0.01µF 50V) [C9,0014]
7 0AV1390000183 AQ C Al-electrolytic capacitor(LLS2G101MHLY 100µF 400V) [C10]
8 0AV1610000091 AC C Ceramic capacitor(DE0905-979R102K1K 1000PF 1KV) [C11,C101]

9 0AV1390000184 AC C Al-electrolytic capacitor(UPJ1H2R2MDH 2.2µF 50V) [C106]
10 0AV1390000107 AC C Al-electrolytic capacitor(UPJ1HR47MDH 0.47µF 50V) [C13]
11 0AV1610000108 AD C Ceramic capacitor(DE1307-486R222K1K 2200PF 1KV) [C15]

0AV1390000108 AC C Al-electrolytic capacitor(UPJ1V220MDH 22µF 35V) [C17,C018,C111]

12

0AV1390000108 AC C Al-electrolytic capacitor(UPJ1V220MDH 22µF 35V) [C107,C108,C109]
13 0AV1390000177 AC C Al-electrolytic capacitor(UPJ1E221MPH 220µF 25V) [C102]
14 0AV1390000181 AE C Al-electrolytic capacitor(UHD1A102MPR 1000µF 10V) [C103,C104]
15 0AV1390000178 AG C Al-electrolytic capacitor(UPJ1H821MHH 820µF 50V) [C105]
16 0AV1390000182 AG C Al-electrolytic capacitor(UHD1V102MHR 1000µF 35V) [C110]
17 0AV1390000179 AC C Al-electrolytic capacitor(UPJ1H100MDH 10µF 50V) [C112]
18 0AV1610000109 AC C Ceramic capacitor(DE0705-979R471K1K 470PF 1KV) [C113]
19 0AV1390000180 AC C Al-electrolytic capacitor(UPJ1H3R3MDH 3.3µF 50V) [C115]
20 0AV1610000114 AD C Ceramic capacitor(DE0605-979SL680J2K 68PF 2KV) [C16]

0AV3050086000 AB B Diode(1SS270 0.15A 70V) [D1,D014,D106,D108]
21

0AV3050086000 AB B Diode(1SS270 0.15A 70V) [D111,D113,D115,D118]
22 0AV3060027000 AH B Diode(D3SB60 4A 600V) [D2]
23 0AV3060043000 AC B Rectifier(RLIN4005-E 1A 600V) [D3,D004,D012,D015]
24 0AV3070058000 AC B Zenner diode(RD5.6ES 0.4W) [D5,D110,D116]
25 0AV3050036000 AF B Diode(RG1C 0.7A 1000V) [D6]
26 0AV3050019000 AF B Diode(ERA9102 0.5A 200V) [D7,D008,D010]
27 0AV3070085000 AC B Zenner diode(RD33ES 0.4W) [D9]
28 0AV3070056000 AD B Zenner diode(RD20ES 0.4W) [D11]
29 0AV3050097000 AG B Diode(SF10LC20U 10A 200V) [D101]
30 0AV3050099000 AD B Diode(D1NL20U 1A 200V) [D102]
31 0AV3050098000 AG B Diode(SF5SC4 5A 40V) [D103]
32 0AV3070061000 AC B Zenner diode(RD4.7ES 0.4W) [D104]
33 0AV3070057000 AC B Zenner diode(RD30ES 0.4W) [D107,D013]
34 0AV3070074000 AC B Zenner diode(RD13ES 0.4W) [D109]
35 0AV3070081000 AC B Zenner diode(RD3.9ES 0.4W) [D112,D117]
36 0AV3042605000 AN B FET(SK2605 5A 800V) [Q1]
37 0AV3001015090 AD B Transistor(2SA1015 -0.15A -50V) [Q2]
38 0AV3020143999 AD B Transistor(DTC143ESA 0.1A 50V) [Q101,Q108,Q110]
39 0AV3040494000 AP B FET(2SJ494 20A 60V) [Q102]

0AV3021815090 AC B Transistor(2SC1815 0.15A 50V) [Q104,Q106,Q107]
40

0AV3021815090 AC B Transistor(2SC1815 0.15A 50V) [Q109,Q113]
41 0AV3001020000 AE B Transistor(2SA1020 -2A -50V) [Q105]
42 0AV3000143999 AD B Transistor(DTA143ESA -0.1A -50V) [Q112]
43 0AV2011053030 AB C Fixed carbon film resistor(RDF50S1MΩJ 1MΩ 1/2W) [R1]
44 0AV2041013020 AC B Fusing resistor(RF25S100ΩJ 100Ω 1/4W) [R2]
45 0AV2011213030 AB C Fixed carbon film resistor(RDF50S120ΩJ 120Ω 1/2W) [R3]
46 0AV2041213030 AC B Fusing resistor(RF50S120ΩJ 120Ω 1/2W) [R4]
47 0AV2011043030 AA C Fixed carbon film resistor(RDF50S100KΩJ 100KΩ 1/2W) [R5,R006]
48 0AV2012243010 AA C Fixed carbon film resistor(RDF16S220KΩJ 220KΩ 1/6W) [R7,R008]
49 0AV2012233010 AA C Fixed carbon film resistor(RDF16S22KΩJ 22KΩ 1/6W) [R121,R133,R135]
50 0AV2013333010 AA C Fixed carbon film resistor(RDF16S33KΩJ 33KΩ 1/6W) [R10,R014]
51 0AV2011003020 AA C Fixed carbon film resistor(RDF25S10ΩJ 10Ω 1/4W) [R11]
52 0AV2091083042 AC C Special power resistor(SPR1B0.1ΩJ 0.1Ω 1W) [R12]
53 0AV2044703010 AB B Fusing resistor(RF16S47ΩJ 47Ω 1/6W) [R13]

RANK

PRICE

RANK

MARK

NEW

MARK

PART
RANK

PART
RANK

DESCRIPTION

DESCRIPTION

– 32 –

DC power supply PWB (200V Series)

[

PRICE

NEW

NO. PARTS CODE

0AV2011033010 AA C Fixed carbon film resistor(RDF16S10KΩJ 10KΩ 1/6W) [R15,R019,R023]

54

0AV2011033010 AA C Fixed carbon film resistor(RDF16S10KΩJ 10KΩ 1/6W) [R104,R122,R134]
55 0AV2016833010 AA C Fixed carbon film resistor(RDF16S68KΩJ 68KΩ 1/6W) [R16]
56 0AV2011013010 AA C Fixed carbon film resistor(RDF16S100ΩJ 100Ω 1/6W) [R17]
57 0AV2021043062 AD C Metal oxide film resistor(RSS3FB100KΩJ 100KΩ 3W) [R18]
58 0AV2016803030 AA C Fixed carbon film resistor(RDF50S68ΩJ 68Ω 1/2W) [R20]
59 0AV2015633010 AA C Fixed carbon film resistor(RDF16S56KΩJ 56KΩ 1/6W) [R21]
60 0AV2011023010 AA C Fixed carbon film resistor(RDF16S1KΩJ 1KΩ 1/6W) [R22,R113]
61 0AV2012243020 AA C Fixed carbon film resistor(RDF25S220KΩJ 220KΩ 1/4W) [R24,R025]
62 0AV2011033030 AB C Fixed carbon film resistor(RDF50S10KΩJ 10KΩ 1/2W) [R101]
63 0AV2012733010 AA C Fixed carbon film resistor(RDF16S27KΩJ 27KΩ 1/6W) [R9]

0AV2014723010 AA C Fixed carbon film resistor(RDF16S4.7KΩJ 4.7KΩ 1/6W) [R106,R114,R115,R116]
64

0AV2014723010 AA C Fixed carbon film resistor(RDF16S4.7KΩJ 4.7KΩ 1/6W) [R123,R124,R136,R137]
65 0AV2011533010 AA C Fixed carbon film resistor(RDF16S15KΩJ 15KΩ 1/6W) [R107]
66 0AV2990007000 AC C Metal film resistor(SN14K2C2.2KΩD 2.2KΩ 1/6W) [R109,R111]
67 0AV2014713010 AA C Fixed carbon film resistor(RDF16S470ΩJ 470Ω 1/6W) [R103,R105,R110,R112]
68 0AV2990082000 AC C Metal film resistor(SN14K2C12KΩD 12KΩ 1/6W) [R119]
69 0AV2990083000 AC C Metal film resistor(SN14K2C3.44KΩD 3.44KΩ 1/6W) [R120]
70 0AV2021023052 AC C Metal oxide film resistor(RSS2FB1KΩJ 1KΩ 2W) [R130]
71 0AV2014733010 AA C Flame proof fixed carbon film resistor(RDF16S47KΩJ 47KΩ 1/6W) [R131,R026]
72 0AV2012203010 AA C Flame proof fixed carbon film resistor(RDF16S22ΩJ 22Ω 1/6W) [R132]
73 0AV4070062000 AF C Inductor(LF-4Z-E822) [L1,L002]
74 0AV4120002000 AC C Inductor(B-01-A) [L3,L101,L102,L103]
75 0AV4080010000 AP C Inductor(DR-18728A) [L5]
76 0AV4120013000 AC C Inductor(T3140P3206536HW) [L104]
77 0AV4000135411 BD B Transformer(N-T01-354-D11) [T1]
78 0AV3160034000 AQ B Triac(TM1661PLF113) [TR1]
79 0AV5140022000 AF B Power thermistor(M10010T3C) [TH1]
80 0AV5190009000 AL B Varistor(ENC471D-14A) [X1]
81 0AV3180000004 AL B Phototriac coupler(S21ME3Y) [PC1]
82 0AV3082561300 AF B Photo coupler(PS2561) [PC2,PC003]
83 0AV3090076000 AF B IC(MM1431ATT) [IC1,IC102]
84 0AV3090077000 AN B IC(FA3647P) [IC2]
85 0AV3090078000 AN BIC(PQ20RX11) [IC101]
86 0AV3090071000 AN B IC(PQ3RD23) [IC103]
87 0AV5030123000 AD B Connector(B02B-VT) [CN1]
88 0AV5030130000 AF B Connector(B04P-XL-R) [CN2]
89 0AV5030125000 AG B Connector(B16B-PHDSS-B) [CN101]
90 0AV5080010000 AQ B Relay(FTR-H1AA024V) [RL1]
91 0AV5190024000 AK B Arrestor(RA-102M-C6-Y) [Z1,Z002]
92 0AV5040012000 AM B Switch(SDDJE30501 10A 250V) [S1]

! 93 0AV5060085000 AF A Fuse(215RB-10AA-SB 10A/250V) [F1,F003]
! 94 0AV5060083000 AF A Fuse(215SB-3R15AA-SB 3.15A/250V) [F2]

95 0AV5050005000 AA C Fuse holder(PFC5000-0203)
96 0AV5130008000 AC C Terminal(TP00370-41)
97 0AV7100003000 AE C Insulation sheet(M-30AD-D-3)
98 0AV6114125811 AF C Heatsink(LM41258)
99 0AV8117730414 AB C Screw(NACPEW-B3×8ZF B3×8)

100 0AV8117730514 AB C Screw(NACPEW-B3×10ZF B3×10)
101 0AV7414136011 AD C Label(LV41360)
102 0AV5110012000 AB C Jumper wire(RJ-SKA-06 6mm) [RJ701,RJ718,RJ724]

0AV5110001000 AA C Jumper wire(RJ-SCA-06 10mm) [RJ712,RJ713,RJ715]

103

0AV5110001000 AA C Jumper wire(RJ-SCA-06 10mm) [RJ721,RJ725,RJ727]

0AV5110006000 AA C Jumper wire(RJ-SDA-06 12.5mm) [RJ711,RJ723,RJ726,RJ731]

104

0AV5110006000 AA C Jumper wire(RJ-SDA-06 12.5mm) [RJ740,RJ742,RJ744]

0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ702,RJ704,RJ705,RJ714]

0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ719,RJ720,RJ729,RJ730]

105

0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ732,RJ733,RJ734,RJ735]

0AV5110002000 AA C Jumper wire(RJ-SEA-06 15mm) [RJ737,RJ739,RJ741,RJ743]

0AV5110004000 AA C Jumper wire(RJ-SGA-06 20mm) [RJ703,RJ706,RJ710,RJ722]

106

0AV5110004000 AA C Jumper wire(RJ-SGA-06 20mm) [RJ728,RJ736,RJ738]

! 901 RDENC0006QS13 BN N E DC power supply PWB (200V Series)

(Unit)

RANK

MARK

PART

RANK

DESCRIPTION

– 33 –

■

Index

PARTS CODE NO.

[C]
CBTN-0019QS02
CBTN-0050QS01
CCAB-0003QS23
CCASP0001RS55
CCLEZ0005RS51

CCOVH0004RS54
CFIX-0021QS01
CFIX-0021RS51
CFRM-0006RS53
CFRM-0007RS54
CFRM-0009RS54

CFRM-0010RS54
CFRM-0011RS59

CGERH0011RS51
CGERH0162QS01
CHAI-0273RS51
CHAI-0298RS51
CHLDZ0010RS52

CLEVP0016QS01
CPLTM0023QS02
CPLTM0023QS03
CPLTM0024QS01
CPLTM0038QS02
CPLTM0042QS02
CPLTM0042RS55
CPLTM0042RS56
CPLTM0288QS01
CPLTM0291QS01
CPLTM0294QS01
CPLTM0299QS01
CPLYZ0028QS01
CPNLH0023QS12
CPNLH0023QS13
CPNLH0023QS21
CPNLH0023QS22
CPWBF0009RS51
CPWBF0113QSE8

CPWBF0113QSE9

CPWBF0113QSF0

CPWBF0116RS51
CPWBF0116RS52
CPWBF0116RS53
CPWBF0116RS54
CPWBF0122QS31
CPWBX0112QS3A

CPWBX0112QS3D

CPWBX0112QS3G

CROLP0015QS01

CSOU-0002RS56
CSW-M0016RS51

CTHM-0019DS52
CTME-0229FC04

DHAI-0265QSZZ
DHAI-0267QSZZ
DHAI-0268QSZ1

DHAI-0268QSZZ

DHAI-0269QSZZ
DHAI-0271QSZZ

DHAI-0274QSZZ

DHAI-0276QSZ2

"

"

"

"

"

"

"

"

"

"

"

"

[D]

"

"

"

"

"

PRICE

NEW

MARK

PART
RANK

RANK

6- 2 AF E
6- 5 AE N E

1- 1 AS N D
22- 901 BF N E
16- 1 AQ E
17- 1 AQ E

2- 901 BF N E

1- 13 AG N D

1- 501 BB N E
18- 502 BB N E
18- 501 AX N E
24- 17 BF E
25- 901 BF E
19- 502 BG E

3- 11 BG E

5- 901 BG E
15- 9 AE E

8- 1 AN N E
20- 3 AN N C
20- 2 AL N C
21- 901 AU E

7- 18 AU E
26- 17 AL C
18- 5 AF C
19- 25 AG C
12- 24 AG C
12- 46 AG C
15- 20 AY C
15- 901 BM N E
15- 901 BM E

8- 2 BC N E

8- 3 AG N E

8- 4 AK N E

4- 47 AF C

8- 5 AM E

6- 1 AR N D

6- 1 AR N D

6- 1 AS N D

6- 1 AS N D

5- 7 AG E
27- 901 BB N E

6- 8 BB N E
27- 901 BB N E

6- 8 BB N E
27- 901 BB N E

6- 8 BB N E
12- 1 AP E
14- 13 AP E
10- 4 AP E
18- 1 AP E
13- 33 AZ E
13- 4 BW N E
28- 901 BW N E
13- 4 BY E
28- 901 BY E
13- 4 BW N E
28- 901 BW N E
12- 20 AU C
25- 25 AU C
19- 501 AX E
16- 4 AG E
17- 4 AG E
14- 12 AT E
14- 11 AG C

13- 37 AM N C
11- 18 AG C
23- 2 AH N C

8- 40 AH N C
23- 2 AZ C

8- 40 AZ C
12- 27 AD C
11- 27 AP C
23- 9 AP C
11- 24 AG C
23- 8 AG C
11- 24 AL C
13- 36 AL C

PARTS CODE NO.

DHAI-0276QSZ2
DHAI-0278QSZ1

"

DHAI-0280QSZ1

"

DHAI-0282QSZZ

"

DHAI-0285QSZZ

"
"

DHAI-0287QSZZ

"
DHAI-0291QSZZ
DHAI-0292QSZZ
DHAI-0293QSZZ
DHAI-0294QSZZ

"
DHAI-0295QSZZ

"
DHAI-0296QSZZ

"
DHAI-0303QSZZ
DHAI-0304QSZ1
DHAI-0305QSZ1
DHAI-0306QSZZ

"
DUNT-0276QS11
DUNT-0276QSZZ
DUNTK0013QS13
DUNTW0285RS12
DUNTW0285RS13
DWIR-0466CSZZ

[G]
GCAB-0007QSJ2
GCAB-0008QSJZ
GCAB-0021QSJ1
GCAB-0026QSJ2
GCAB-0061QSZZ
GCAB-0062QSZ1
GCAB-0062QSZZ
GCAB-0063QSZZ
GCAB-0064QSZZ
GCASP0001QSJ2
GCOV-0045QSZ1
GCOV-0045QSZZ
GCOVA0005QSJZ
GCOVA0006QSJZ
GCOVA0007QSZZ
GCOVA0008QSJZ
GCOVH0003QSJZ
GCOVH0004QSJ1
GCOVZ0149FCZZ
GDAI-0001QSJ1

"

GLEGG0064FCZZ

"

[J]
JBTN-0005QSZZ
JBTN-0020QSZZ
JBTN-0049QSZZ
JKNBZ0001QSZZ
JKNBZ0004QSZZ

[L]
LBNDJ0013FCZ1

"
"
"
"
"
"

"
LBNDJ0043FCZZ
LBOSZ0118QSZZ
LBOSZ1031FCZZ

"
LBOSZ1509FCZ1
LBOSZ1851FCZZ

"

"
LBRC-0055FCZZ
LBSHZ0006QSZZ

PRICE

NEW

MARK

PART
RANK

RANK

23- 8 AL C
14- 16 AK C
23- 10 AK C
14- 16 AH N C
23- 10 AH N C
10- 14 AG N C

9- 2 AG N C

10- 10 AK N C

1- 7 AK N C
23- 4 AK N C
11- 23 AF N C
23- 7 AF N C

7- 12 AC N C
11- 19 AF N C

5- 8 AE C
13- 31 AK N C
23- 3 AK N C
18- 2 AC N C
19- 22 AC N C
15- 27 AK N C
23- 5 AK N C

8- 37 AD C

4- 11 AQ N C
13- 32 AP N C
24- 18 AG C
25- 14 AG C

8- 6 BT N E

8- 6 BT N E

9- 4 BS N E
14- 901 BS N E
14- 901 BS N E
21- 8 BG B

7- 1 AU N D

5- 1 AM D

1- 18 AY N D

1- 18 AZ D

1- 10 AK N D

1- 17 AL N D

1- 17 AL D

6- 10 AT N D

6- 12 AN N D
22- 19 AZ N D

1- 12 AG N D

1- 12 AG D
24- 1 AL D
24- 3 AN D
24- 10 AK D
24- 14 AK D

2- 1 AL N D

2- 2 AX N D
26- 7 AU D
12- 28 BF N D
13- 17 BF N D
13- 18 AC C
24- 7 AC C

6- 4 AC C

6- 3 AC C

6- 6 AF N C
11- 22 AE C

4- 35 AD C

14- 17 AA C
18- 3 AA C
19- 21 AA C
20- 9 AA C
25- 4 AA C

3- 12 AA C

4- 16 AA C

9- 3 AA C
11- 6 AA C
19- 18 AE C
12- 15 AC C
25- 7 AC C
19- 28 AD C
12- 13 AC C
19- 15 AC C

5- 19 AC C
19- 10 AK C

5- 22 AC C

– 34 –

PARTS CODE NO.

LBSHZ0303FCZZ

"
LFIX-0004QSZZ
LFRM-0003QSJ2
LFRM-0004QSZZ
LFRM-0005QSZZ
LFRM-0006QSJZ
LFRM-0007QSJ2
LFRM-0009QSZ2
LFRM-0010QSJZ
LFRM-0011QSJ2
LFRM-0014QSZZ
LFRM-0015QSZZ
LFRM-0035QSZZ
LFRM-0062QSZZ
LHLDC0097QSZZ
LHLDW1226FCZZ

"
LHLDZ0009QSDZ
LHLDZ0010QSZ1
LHLDZ0017QSZZ
LHLDZ0018QSZZ
LHLDZ0080QSZZ
LHLDZ0092QSZZ
LHLDZ0093QSZZ
LHLDZ0096QSZZ
LPINS0008QSZZ
LPINS0009QSZZ
LPINS0019QSZZ
LPLTM0016QSZZ
LPLTM0020QSZZ
LPLTM0022QSZ4
LPLTM0036QSZZ
LPLTM0043QSZZ
LPLTM0046QSZZ
LPLTM0096QSZZ
LPLTM0122QSZZ
LPLTM0132QSZZ
LPLTM0133QSZ1
LPLTM2642FCGZ
LPLTM5106FCZZ
LPLTM5422FCZZ
LPLTP0009QSZZ
LPLTP0011QSJZ
LPLTP0012QSJZ
LPLTP0013QSZZ
LPLTP0014QSZZ
LPLTP0015QSZZ
LPLTP0041QSZZ
LPLTP0131QSZZ
LPLTP5107FCZZ
LPLTP5108FCZZ
LRALP0001QSJ1
LSOU-0001QSJZ
LSOU-0002QSJZ
LSOU-0003QSJZ
LSOU-0006QSZZ
LSOU-0007QSJZ
LSOU-0008QSJZ
LSOU-0035QSZZ
LSTPF0013QSZZ
LSTPP0007QSZZ
LSTPP0116FCZZ
LSTPP0161FCZZ
LSTPP0300FCZZ
LX-BZ0010QSZZ
LX-BZ0011QSZZ
LX-BZ0016QSZZ
LX-BZ0033QSZZ
LX-BZ0735FCZZ
LX-BZ3006SC0S
LX-WZ0023FCZZ
LX-WZ0313FCZZ
LX-WZ2028SCZZ

[M]
MARMP0002QSZZ
MARMP0003QSZ1
MARMP0004QSZZ
MARMP0012QSZZ
MARMP0173FCZZ
MARMP0204FCZ1

PRICE

NEW

MARK

PART

RANK

RANK

19- 9 AC C

5- 20 AC C

21- 15 AC C

7- 9 AN D
14- 7 AV D
14- 30 AQ D
18- 13 AN N D
18- 25 AL N D
25- 26 AQ D
19- 35 AN D

5- 35 AL D

4- 30 AE C

4- 17 AK C
11- 21 AZ D
13- 30 AG N C
13- 34 AG N C
22- 3 AB C
26- 12 AB C
20- 1 AG C
21- 14 AL C
12- 30 AD C
11- 13 AE C
12- 49 AC C
13- 1 AP N C

8- 7 AC N C
13- 24 AN C
11- 26 AD C
11- 26 AD C

4- 46 AB C
12- 42 AE C
13- 21 AL C
14- 29 AG C
24- 6 AF C

7- 5 AD C
12- 25 AE C

3- 53 AF C

3- 52 AD C

7- 5 AH C
11- 31 AE C
22- 4 AD C
22- 1 AR C
12- 50 AC C
14- 38 AS C

3- 2 AH C

3- 3 AH C

4- 3 AD C

3- 28 AK C

4- 39 AH C

3- 39 AE C

8- 33 AD C
22- 5 AH C
22- 13 AH C
12- 34 AL N C

1- 2 AY N D
19- 48 AL D
19- 49 AH D

3- 9 AL D

3- 54 BB D

1- 4 AH N D

3- 1 AR D

8- 8 AC N C

5- 5 AC C
14- 18 AA C
22- 18 AB C
19- 37 AB C
14- 8 AB C
14- 42 AB C

3- 33 AC C

8- 9 AB C
14- 36 AA C
11- 28 AA C
12- 43 AA C
14- 26 AA C
22- 10 AA C

5- 13 AD C

5- 4 AD C

5- 34 AF C
24- 13 AD C
19- 4 AC C
19- 39 AF C

PARTS CODE NO.

MARMP0205FCZZ
MARMP0229FCZZ
MHNG-0002QSZZ
MHNG-0019QSZZ
MLEVF0041QSZZ
MLEVP0005QSZZ
MLEVP0006QSZZ
MLEVP0007QSZZ
MLEVP0009QSZZ
MLEVP0010QSZZ
MLEVP0014QSZZ
MLEVP0015QSZZ
MLEVP0033QSZZ
MLEVP0036QSZZ
MLEVP0047QSE1
MLOKZ0004QSZZ
MSPRC0016QSZ1
MSPRC0017QSZ1
MSPRC0018QSZ1
MSPRC0021QSZZ
MSPRC0023QSZ1
MSPRC0024QSZ1
MSPRC0026QSZ1
MSPRC0027QSZZ
MSPRC0028QSZZ
MSPRC0030QSZZ
MSPRC0031QSZZ
MSPRC0032QSZZ
MSPRC0036QSZ1
MSPRC0037QSZZ
MSPRC0038QSZ1
MSPRC0039QSZ1
MSPRC0047QSZZ
MSPRC0048QSZZ
MSPRC0049QSZZ
MSPRC0050QSZZ
MSPRC0051QSZ1
MSPRC0053QSZ1
MSPRC0055QSZZ
MSPRC0062QSZZ
MSPRC0063QSZZ
MSPRC0077QSZ1
MSPRC0080QSZZ
MSPRC0108QSZZ
MSPRC0109QSZZ

"
MSPRC0115QSZZ
MSPRC0149QSZZ
MSPRC0153QSZZ
MSPRC0161QSZZ

"
MSPRC1145FCZZ
MSPRC1315FCZ1
MSPRC1316FCZ1

"

"
MSPRC1318FCZ1

"
MSPRC1873FCZ1
MSPRC2175FCZZ
MSPRC2544FCZZ
MSPRC2545FCZZ
MSPRC2546FCZZ
MSPRD0058QSZZ
MSPRD0069QSZZ
MSPRD0070QSZZ
MSPRD0076QSZ1
MSPRD0108QSZZ
MSPRD0114QSZ1
MSPRD0126QSZ1
MSPRD0154QSZZ
MSPRD0163QSZZ
MSPRD0281QSZZ
MSPRD0282QSZZ
MSPRP0033QSZZ
MSPRP0034QSZZ
MSPRP0052QSZZ
MSPRP0059QSZZ
MSPRP0060QSZZ
MSPRP0065QSZZ
MSPRP0079QSZZ

PRICE

NEW

MARK

PART

RANK

RANK

19- 38 AF C
25- 12 AE C
19- 40 AC C

3- 30 AS C

3- 25 AD C
10- 5 AD C
12- 2 AD C
18- 17 AD C

5- 9 AD C

5- 10 AE C
14- 28 AF C
14- 23 AF C
25- 16 AF C

3- 18 AD C

8- 34 AD C

8- 10 AD N C
20- 7 AC C
20- 5 AC C
20- 6 AC C
10- 7 AB C
15- 15 AC C
11- 8 AC C
12- 3 AB C
21- 10 AC C
21- 11 AC C

7- 14 AC C

7- 13 AB C

7- 11 AB C
18- 26 AB C
12- 62 AB C
18- 16 AC C
18- 14 AC C
12- 31 AA C
19- 41 AB C
19- 14 AC C

7- 25 AB C
21- 12 AA C
15- 3 AC C
14- 25 AC C

4- 4 AC C

4- 36 AB C
12- 41 AB C
18- 18 AB C
22- 15 AC C
18- 33 AC C
19- 50 AC C

5- 33 AB C

3- 51 AC C

8- 35 AB C
12- 16 AF C
25- 8 AF C
22- 17 AA C
19- 16 AD C
12- 11 AE C
19- 27 AE C

5- 18 AE C
15- 23 AA C
19- 30 AA C
22- 16 AB C
19- 33 AA C
24- 9 AC C
25- 13 AB C
25- 21 AB C
25- 17 AG C

3- 42 AC C

3- 41 AC C

7- 6 AD C
18- 31 AC C

5- 36 AD C

3- 19 AC C

3- 48 AD C

4- 45 AC C
10- 9 AD N C
14- 3 AH N C
14- 6 AD C
14- 14 AE C

3- 47 AD C

3- 7 AD C

3- 50 AD C

4- 31 AD C
18- 29 AD C

– 35 –

PARTS CODE NO.

MSPRP0110QSZ1

"
MSPRT0019QSZ1
MSPRT0020QSZ1
MSPRT0029QSZZ
MSPRT0054QSZ1
MSPRT0066QSZ1
MSPRT0067QSZ1
MSPRT0112QSZ1
MSPRT0283QSZZ
MSPRT0284QSZZ
MSPRT0294QSZZ
MSPRT0513FCZ1

[N]
NBLT-0005QSZZ
NBLTT0001QSZZ
NBLTT0004QSZZ
NBLTT0011QSZZ
NBLTT0030QSZZ
NBLTT0031QSZZ
NBLTT0032QSZZ
NBRGC0016QSZZ
NBRGC0017QSZZ
NBRGC0100FCZ1
NBRGC0579FCZZ
NBRGM0501FCZZ

"
NBRGP0260FCZ1
NBRGP0562FCZZ

"
NBRGP0567FCZZ
NCPL-0006QSZZ
NFANP0005QSZ1
NGERH0007QSZZ
NGERH0008QSZ3
NGERH0009QSZZ
NGERH0010QSZZ
NGERH0012QSZZ
NGERH0013QSZZ
NGERH0014QSZZ
NGERH0015QSZZ
NGERH0016QSZZ
NGERH0017QSZZ
NGERH0018QSZZ
NGERH0019QSZZ
NGERH0020QSZZ
NGERH0021QSZZ

"
NGERH0022QSZZ
NGERH0025QSZZ
NGERH0026QSZZ
NGERH0041QSZZ
NGERH0047QSZZ
NGERH0048QSZZ
NGERH0050QSZZ
NGERH0051QSZZ
NGERH0073QSZZ
NGERH0079QSZZ
NGERH0161QSZZ
NGERH0193FCZZ

"
NGERH0540FCZ3
NGERH0972FCZZ

"
NGERH0990FCZZ

"

"

"
NGERH0991FCZZ
NGERH0992FCZZ

"

"
NGERH1132FCZZ

"
NGERH1169FCZZ
NGERH1207FCZZ
NGERR0377FCZZ
NPLYZ0001QSZZ
NPLYZ0002QSZZ
NPLYZ0010QSZZ
NPLYZ0146FCZZ

PRICE

NEW

MARK

PART
RANK

RANK

16- 6 AD C
17- 6 AD C

9- 5 AB C

10- 2 AB C

7- 3 AC C

14- 37 AB C

5- 25 AC C
5- 14 AB C

24- 12 AC C

8- 11 AC N C
8- 12 AC N C
4- 48 AC C

21- 7 AA C

11- 5 AH B
11- 20 AH B
11- 37 AH B

4- 22 AG B
8- 13 AH N B
8- 14 AF N B
4- 34 AE B

25- 2 AD C

4- 27 AC C
12- 8 AC C
11- 2 AE C

3- 26 AB C

4- 25 AB C
14- 24 AD C
12- 19 AD C
18- 11 AD C
14- 20 AG C
11- 7 AC C
11- 12 BR N B
15- 11 AH C
15- 16 AL C
15- 7 AD C
15- 6 AD C
15- 18 AE C
15- 19 AG C
15- 8 AD C
15- 10 AD C
15- 12 AD C
15- 17 AD C
15- 14 AC C
15- 13 AD C
12- 9 AG C
18- 27 AD C
19- 46 AD C
12- 21 AC C
12- 23 AD C
12- 22 AD C
25- 22 AF C

4- 23 AF C

7- 22 AE C
15- 4 AD C

7- 23 AE C

5- 16 AE C

4- 26 AD C

8- 15 AL N C
22- 11 AB C

3- 6 AB C
14- 19 AD C
18- 6 AB C
19- 19 AB C
18- 9 AB C
19- 7 AB C
25- 23 AB C

5- 28 AB C
19- 20 AC C
19- 3 AB C
25- 5 AB C

5- 30 AB C
12- 18 AH C
25- 10 AH C
12- 47 AF C
25- 11 AF C

3- 4 AD C
11- 4 AE C
15- 5 AC C

5- 23 AE C

4- 33 AB C

PARTS CODE NO.

NROLI0014QSZ3
NROLM0022QSZ1
NROLM0026QSZ1
NROLM0027QSZ1
NROLP0007QSZ1
NROLP0010QSZZ
NROLP0011QSZZ
NROLP0012QSZ2
NROLP0019QSZ1
NROLP0024QSZ1
NROLP0025QSZZ
NROLP0046QSZZ
NROLP1008FCZZ
NROLP1060FCZZ
NROLP1122FCZZ

"
"

"
NROLR0013QSZZ
NROLR0016QSZZ
NROLR0028QSZZ
NROLR0922FCZZ

"
NSFTZ0006QSZ1
NSFTZ0007QSZ1
NSFTZ0007QSZZ
NSFTZ0009QSZZ
NSFTZ0011QSZ2
NSFTZ0012QSZZ
NSFTZ0013QSZZ
NSFTZ0014QSZZ
NSFTZ0063QSZZ
NSFTZ2311FCZZ

[P]
PBRSR0002QSZ1
PBRSR0002QSZ2
PBRSR0003QSZ2
PBRSR0004QSZ1
PCASZ0002QSZZ
PCLC-0010QSZZ
PCOVP0007QSJZ
PCOVP0008QSZZ
PCOVP0009QSZZ
PCOVP0010QSZZ
PCOVP0011QSZZ
PCOVP0012QSJ1
PCOVP0013QSZZ
PCOVP0019QSJZ
PCOVP0022QSJZ
PCOVP0023QSJ1
PCOVP0035QSJZ
PCOVP0040QSJZ
PCUSS0016QSZZ
PCUSS0024QSZZ
PCUSS0025QSZZ
PCUSU0026QSZZ
PDUC-0005QSZZ
PFILZ0002QSZZ
PGIDH0025QSZ1
PGIDH0026QSZZ
PGIDH0027QSZZ
PGIDH0028QSZZ
PGIDM0006QSZ2
PGIDM0008QSZZ
PGIDM0009QSZZ
PGIDM0010QSZ1
PGIDM0011QSZZ
PGIDM0012QSJZ
PGIDM0013QSJZ
PGIDM0014QSJZ

"
PGIDM0015QSJZ
PGIDM0016QSJZ
PGIDM0017QSJZ
PGIDM0018QSJZ
PGIDM0019QSJZ
PGIDM0020QSJZ
PGIDM0021QSZZ
PGIDM0022QSZZ
PGIDM0023QSZZ
PGIDM0057QSZZ

PRICE

NEW

MARK

PART
RANK

RANK

14- 21 BA N C

4- 43 AL C
4- 40 AL C
4- 6 AL C

11- 1 AQ C

3- 46 AD C

3- 36 AD C
11- 3 AL N C
25- 1 AP C

5- 27 AH C

7- 24 AM C
10- 1 AC C
19- 5 AK C
24- 11 AF C
10- 8 AF C
18- 24 AF C

7- 17 AF C

7- 26 AF C
12- 7 AQ C
18- 12 AT C
14- 27 AZ C
19- 1 AR C

5- 31 AR C

7- 15 AG C
18- 23 AG C
18- 23 AG N C

3- 49 AE C

5- 32 AF C

5- 21 AG C

3- 38 AF C

3- 43 AP C

8- 16 AK N C
19- 8 AU C

8- 17 AH B

8- 17 AG B

4- 7 AG B
14- 4 AD N B
21- 16 AL D

4- 28 AT B
12- 38 AE N D
12- 60 AE C
12- 61 AE C
14- 5 AG D
14- 15 AK D
16- 3 AH C
12- 32 AD D
19- 44 AL D

3- 10 AT C
17- 3 AH D

1- 16 AL N D

1- 16 AL D

3- 31 AB C

2- 3 AV N D

3- 56 AQ D

8- 42 AC N D

8- 22 AD N C

1- 21 AL D
21- 4 AG C
14- 34 AE C

4- 41 AK C

4- 8 AK C
10- 6 AM C

7- 4 AD C
11- 25 AG C
12- 5 AG C
21- 2 AE C
18- 22 AF N C
18- 21 AF N C
18- 20 AF C
19- 12 AF C
24- 8 AY C
24- 4 AY C
19- 43 AF C
19- 42 AF C

8- 29 AH C

8- 30 AH C

4- 38 AQ C

4- 5 AN C
14- 1 AP C

4- 10 AL C

– 36 –

PARTS CODE NO.

PGIDM0059QSJZ
PGIDM0060QSJZ
PGIDM0099QSZZ
PGLSP0007QSZZ
PGLSP0008QSZZ
PGUMS0004QSZZ
PMLT-0024QSZZ
PMLT-0067QSZZ
PMLT-0068QSZZ
PMLT-0069QSZZ
PPIPP0003QSZZ
PPIPP0007QSZZ
PPIPP0010QSZZ
PPIPP0109FCZ1

"
PPIPP0175FCZZ
PRNGP0090FCZZ
PSHEP0019QSZ1
PSHEP0020QSZZ
PSHEP0021QSZZ
PSHEP0023QSZZ
PSHEP0047QSZZ
PSHEP0061QSZZ
PSHEP3029FCZZ
PSHEZ0018QSZZ
PSHEZ0039QSZZ
PSHEZ0045QSZ2
PSHEZ0068QSZZ
PSHEZ0075QSZZ
PSHEZ0151QSZZ
PSHEZ0155QSZZ
PSHEZ0156QSZZ
PSHEZ0162QSZZ
PSHEZ0164QSZZ
PSHEZ0181QSJZ
PSHEZ0350QSZZ
PSHEZ0351QSZZ
PSHEZ0367QSZZ
PSHEZ0369QSZZ
PSHEZ0377QSZZ
PSHEZ0380QSZZ
PSHEZ0381QSZZ
PSHEZ0383QSZZ
PSHEZ0384QSZZ
PSHEZ0386QSZZ
PSHEZ0387QSZZ
PSHEZ0389QSZ1
PSHEZ0389QSZZ
PSHEZ0390QSZZ

"
PSHEZ0400QSZZ
PSHEZ0401QSZZ
PSHEZ0402QSZZ
PSHEZ0403QSZZ
PSHEZ0404QSZZ
PSHEZ0405QSZZ
PSHEZ2026FCZ1
PSHEZ2174FCZZ

"
PSHEZ4142FCZZ
PSPAZ0017QSZZ
PSPO-0001QSZZ
PSPO-0002QSZZ
PSPO-0003QSZZ
PSPO-0004QSZZ

"
PTME-0002QSZZ
PTME-0003QSZ1
PTME-0004QSZZ
PTME-0008QSZZ
PTME-0019QSZZ
PTME-0178FCZ1
PTME-0179FCZZ
PTME-0255FCZZ
PTME-0256FCZZ
PTPE-0010QSZZ
PTPE-0040QSZZ
PTPE-0041QSZZ
PTPE-0044QSZZ
PTPE-0045QSZZ
PTPE-0046QSZZ

PRICE

NEW

MARK

PART

RANK

RANK

8- 29 AG N C
8- 30 AF N C
8- 18 AH N C
1- 14 AV N B
1- 23 AH B
8- 19 AA C
1- 20 AC C

11- 39 AC N C

8- 47 AC N C

1- 27 AA N C
12- 17 AD C
25- 9 AD C

5- 17 AD C
12- 10 AC C
19- 17 AC C
19- 26 AC C

3- 27 AA C
21- 3 AC C
21- 13 AB C
21- 6 AA C
14- 35 AF C
14- 40 AC C
22- 8 AA C

4- 21 AA C
21- 1 AF C

4- 2 AG C
14- 33 AC C

3- 29 AC C
17- 7 AC C

3- 23 AD C
11- 38 AD C
11- 36 AE C

4- 44 AB C

4- 42 AF C

1- 24 AC C

9- 6 AB C

9- 7 AB C

8- 21 AD N C

1- 8 AE N C

8- 24 AC N C

3- 32 AD C

3- 44 AD C

3- 60 AC C

3- 21 AD C

3- 57 AB D

3- 58 AB D

8- 39 AK N C

8- 39 AH N C
13- 22 AL N C
23- 6 AL N C

8- 48 AG C

8- 45 AG N C
10- 16 AG C

8- 44 AG N C

1- 28 AF N C
13- 38 AE C
12- 29 AB C
12- 36 AB C

4- 1 AB C
22- 2 AC C
11- 32 AK C

3- 37 AB C

5- 2 AC C

3- 34 AC C

3- 20 AB C

4- 14 AB C
15- 24 AD C
15- 26 AD C

7- 2 AG C
25- 20 AD C

5- 26 AD C
19- 32 AC C
19- 31 AC C
22- 6 AG C
22- 14 AG C

1- 25 AC C

1- 15 AC N C

1- 6 AB N C

1- 22 AC C

8- 43 AA N C

8- 46 AB N C

PARTS CODE NO.

PTPE-0047QSZZ
PTPE-0048QSZZ
PTUBP0005QSZZ

[Q]
QACCB7521QCZZ
QACCB7622QCN1
QACCBR623QCPZ
QACCD761AQCZZ

"
QACCER622QCPZ
QACCF7620QCZZ
QACCLR622QCPZ
QACCV6621JHPZ
QCNCM0079QSZZ
QCNCM0861FCZZ
QCNCM0923FC14
QCNCM0923FC18
QCNCM0923FC24
QCNCM1005MCZZ
QCNCM2401SC0C
QCNCM2401SC0D
QCNCM2401SC0E
QCNCM7014SC0C
QCNCM7014SC0D
QCNCM7014SC0E
QCNCM7014SC0F
QCNCP0340QCZZ
QCNCP0341QCZZ
QCNCW0024QSZZ
QCNCW0078QSZZ
QCNCW0948FCZ5
QCNCW1124LC0H
QCNCW1124LC1H
QCNCW1132LC1H
QSLP-0005QSZZ
QSLP-0006QSZZ
QSLP-0007QSZZ
QSOCZ0002QSZZ
QSW-B0003QSZZ
QSW-P0001ESZZ

[R]
RCILZ0015QSZZ
RCORF0018QSZZ

"

"
RCORF0020QSZZ
RCORF0021QSZZ

"
RCORF0034FCZZ
RCRSP0016QSZZ
RCRUB0013QSZZ
RCRUB0016QSZZ
RDENC0006QS11

"
RDENC0006QS12

"
RDENC0006QS13

"
RDENC0007QSZZ
RDTCT0004QSZZ
RDTCT0128FCZZ
RFILN0043FCZZ
RFILZ0004QSZZ
RH-DX0001ESZZ
RH-DZ0016FCZZ
RH-IX0001QSZZ
RH-IX0002QSZZ
RH-IX0005ESZZ
RH-IX0020QSZZ
RH-TX0003ESZZ
RLMPU0010QSZZ
RLMPU0011QSZZ
RMOTD0009QSZZ
RMOTP0012QSZZ
RMOTP0013QSZZ
RMOTP0036QSZZ
RMOTS0038QSZZ
RMPTW4100QCJJ
RMPTW4102QCJJ
RMPTW4103QCJJ
RMPTW4330QCJJ

PRICE

NEW

MARK

PART

RANK

RANK

1- 29 AC N C
1- 30 AA N C

10- 13 AC C

26- 3 AS B
26- 3 AZ B
26- 3 AY N B
13- 26 BE B
26- 3 BE B
26- 3 AQ B
26- 3 AX B
26- 3 AR B
26- 3 } N B
28- 1 AC C
27- 1 AB C
28- 2 AE C
28- 3 AF C
28- 4 AF C
28- 6 AB C
28- 7 AB C
28- 8 AC C
28- 9 AC C
28- 10 AA C
28- 11 AB C
28- 12 AB C
28- 13 AB C
28- 14 AC C
28- 15 AC C
28- 16 AF C
28- 17 AF C
28- 5 AC C
28- 19 AC C
28- 20 AD C
27- 2 AD C
11- 16 AE C
11- 14 AE C
21- 9 AC C
28- 21 AD C
25- 24 AF B
27- 3 AC B

28- 22 AD C
10- 15 AR N C
13- 23 AR N C

8- 32 AR N C
8- 41 AL N C

13- 27 AK N C

9- 8 AK N C
13- 28 AR C
28- 23 AD B
28- 24 AN B
28- 25 AN B
13- 13 BQ N E
30- 901 BQ N E
13- 13 BN E
29- 901 BN E
13- 13 BN N E
31- 901 BN N E
13- 6 BG N E

4- 37 AL B
14- 9 AR B
28- 127 AC C
28- 26 AM C
28- 27 AC B
28- 28 AB B
28- 29 BD B
28- 30 AZ B
28- 74 AE B
28- 31 AS B
27- 23 AC B
14- 22 BA B
14- 22 BA B
11- 9 AU B
11- 35 AW B

4- 13 BB B
15- 2 BD N B

8- 25 BL N B
28- 32 AA B
28- 33 AB B
28- 34 AB B
28- 35 AB B

– 37 –

PARTS CODE NO.

RPLU-0002QSZZ
RPLU-0003QSZZ
RPLU-0004QSZ1
RPLU-0005QSZZ
RPLU-0010QSZZ
RPLU-0015QSZZ
RPLU-0035QSZZ

[S]
SPAKA0051RSZZ
SPAKA0163RSZZ
SPAKA0405QSZZ
SPAKA0406QSZZ
SPAKA0407QSZZ
SPAKA0408QSZZ
SPAKA0410QSZZ
SPAKA0411QSZZ
SPAKA0421QSZZ
SPAKA0429QSZZ
SPAKA0432QSZZ
SPAKA5116FCZZ
SPAKC0402RS21
SPAKC0402RS22
SPAKC0402TS13
SPAKC0402TS14
SPAKC0404RS15
SPAKC0428RSZZ
SSAKA2347QCZZ
SSAKA5003CCZZ
SSAKZ0002QSZZ

[T]
TCADZ0049QSZZ
TCAUA0770FCZZ
TCAUH0007QSZZ
TCAUH0017QSZZ
TINSA0810QSZZ
TINSE0778QSZZ
TINSE0800QSZZ
TINSE0817TSZZ
TINSZ0770TSZZ
TINSZ0771TSZZ
TINSZ0818TSZZ
TLABH0403QSZZ
TLABZ0058QSZZ
TLABZ3568FCZZ
TLABZ4047FCZZ
TLABZ4201FCZZ
TTAG-0002QSZZ
TTAG-0006QSZZ

[U]
UBNDA0001FCZZ

[V]
VCCCCY1HH201J
VCCCCZ1HH101J
VCCCCZ1HH120J
VCCCCZ1HH220J
VCCCCZ1HH330J
VCCCCZ1HH470J
VCEAGA1CW105M
VCEAGA1CW106M
VCEAGA1CW226M
VCEAGA1CW476M
VCEAGA1EW476M
VCEAGA1VW106M
VCEAGA1VW476M
VCEAJU1CW476M
VCKYCY1CB104K
VCKYCY1HB102K
VCKYCY1HB104K
VCKYCY1HB223K
VCKYCZ1CB223K
VCKYCZ1CF104Z
VCKYCZ1HB102K
VCKYCZ1HB222K
VCKYCZ1HB821K
VHDDSS133//-1

"
VHDKDS121++-1
VHDKDS226++-1
VHEMTZJ22B/-1
VHI28F4BVEB85
VHI74HC151M-1

PRICE

NEW

MARK

PART
RANK

RANK

15- 25 AN B
19- 29 AN B

5- 11 AQ B
3- 17 AQ B

25- 18 AN B

4- 15 AS B

15- 22 AL N B

26- 14 AC D
26- 14 AC D
26- 9 AN D
26- 9 AS D
26- 9 AS D
26- 1 AN D
26- 1 AQ D
26- 20 AE D
26- 19 AC D
26- 1 AM N D
26- 23 AC N D
26- 21 AB D
26- 10 AU N D
26- 10 AU N D
26- 10 } N D
26- 10 } N D
26- 10 AX N D
26- 10 AW N D
26- 8 AB D
26- 5 AA D
26- 6 AF D

26- 7 AH D

1- 19 AB D
26- 22 AD D
14- 32 AC D
26- 7 AS N D
26- 7 AX N D
26- 7 AR N D
26- 7 } N D
26- 7 } N D
26- 7 } N D
26- 7 } N D

1- 11 AF N C

1- 26 AD D
22- 12 AB D
22- 20 AC C
28- 36 AC D
26- 13 AB D
26- 15 AE N D

26- 4 AA C

27- 4 AA C
28- 37 AA C
28- 38 AA C
28- 39 AA C
28- 40 AA C
28- 41 AA C
28- 42 AA C
28- 43 AA C
28- 44 AB C
28- 45 AB C
28- 46 AA C
28- 47 AA C
28- 48 AB C
27- 5 AB C
27- 6 AB C
27- 7 AA C
28- 49 AA C
27- 8 AC C
28- 50 AB C
28- 51 AB C
28- 52 AA C
28- 53 AA C
28- 54 AC C
27- 9 AA B
28- 55 AA B
28- 56 AC B
28- 57 AC B
28- 58 AA B
28- 59 AX B
27- 11 AD B

PARTS CODE NO.

VHI74HC151M-1
VHIBA6920FP-1
VHID65001AF-1
VHID65503F+-1
VHIEES02L400P
VHIH8S2320+-1
VHIHG73C1191C
VHIKA7805AP-1
VHIKIA358F+-1
VHIKIA393F+-1
VHIL6219DS+-1
VHILC7935//-1
VHILCX244WM-1
VHIM51957BFP1
VHIMTD1361F-1
VHINC7ST08M-1
VHIP2010ASR-1
VHITD62064AF/
VHIVHCT244M-1
VHP1LHEE-002A
VHP1LHLE-002A
VHP3650AG2J-1
VHPGP1A71A1-1

"
VHVICPN38//-1
VRD-HT2EY151J
VRD-HT2EY391J
VRD-HT2EY472J
VRH-ST2HB157K
VRN-VT3ATR68J
VRS-CY1JD101J
VRS-CY1JD102J
VRS-CY1JD121J
VRS-CY1JD151J
VRS-CY1JD152J
VRS-CY1JD471J
VRS-CY1JD472J
VRS-CY1JD511J
VRS-CZ1JD000J
VRS-CZ1JD100J
VRS-CZ1JD101J
VRS-CZ1JD102F
VRS-CZ1JD102J
VRS-CZ1JD103F
VRS-CZ1JD103J
VRS-CZ1JD105F
VRS-CZ1JD113F
VRS-CZ1JD122F
VRS-CZ1JD122J
VRS-CZ1JD152J
VRS-CZ1JD153J
VRS-CZ1JD202J
VRS-CZ1JD203J
VRS-CZ1JD220J
VRS-CZ1JD241J
VRS-CZ1JD242J
VRS-CZ1JD272J
VRS-CZ1JD301J
VRS-CZ1JD303J
VRS-CZ1JD330J
VRS-CZ1JD332J
VRS-CZ1JD393J
VRS-CZ1JD432F
VRS-CZ1JD471J
VRS-CZ1JD472J
VRS-CZ1JD473J
VRS-CZ1JD511J
VRS-CZ1JD563J
VRS-CZ1JD621J
VRS-CZ1JD751J
VRS-CZ1JD752F
VRS-CZ1JD752J
VRS-HT3DA101J
VRS-HT3DA102J
VRS-HT3DA1R0J
VRS-HT3DAR22J
VSKRA119S++-1
VSKRC106S++-1
VSKTA1281++-1
VSKTA1505S+-1
VSKTC3198++-1

PRICE

NEW

MARK

PART
RANK

RANK

28- 60 AD B
28- 61 AL B
28- 62 AG B
28- 63 AG B
28- 64 AG B
28- 65 AY B
28- 66 BH B
28- 67 AE B
28- 68 AE B
28- 69 AE B
28- 70 AN B
27- 10 AN B
28- 71 AG B
28- 72 AH B
28- 73 AR B
28- 75 AD B
28- 76 AN B
28- 77 AM B
28- 78 AG B
27- 12 AC B
27- 13 AC B
27- 14 AL B
25- 15 AG B

8- 36 AG B
28- 79 AF B
28- 80 AA C
28- 81 AA C
28- 82 AA C
14- 2 AD C
28- 83 AC C
27- 15 AA C
27- 16 AA C
27- 17 AA C
27- 18 AA C
27- 19 AA C
27- 20 AA C
27- 21 AA C
27- 22 AA C
28- 84 AA C
28- 85 AA C
28- 86 AA C
28- 87 AA C
28- 88 AA C
28- 89 AA C
28- 90 AA C
28- 91 AA C
28- 92 AA C
28- 93 AA C
28- 94 AA C
28- 95 AA C
28- 96 AA C
28- 97 AA C
28- 98 AA C
28- 99 AA C
28- 100 AA C
28- 101 AA C
28- 102 AA C
28- 103 AA C
28- 104 AA C
28- 105 AA C
28- 106 AA C
28- 107 AA C
28- 108 AA C
28- 109 AA C
28- 110 AA C
28- 111 AA C
28- 112 AA C
28- 113 AA C
28- 114 AA C
28- 115 AA C
28- 116 AA C
28- 117 AA C
28- 120 AA C
28- 118 AA C
28- 119 AB C
28- 121 AA C
28- 122 AB B
28- 123 AB B
28- 124 AD B
28- 125 AC B
28- 126 AB B

– 38 –

PARTS CODE NO.

[X]

XBBSD30P04000

"

XBBSD30P08000

"
XBBSD40P06000
XBBSE30P06000
XBBSE30P08000
XBPSC30P06ES0
XBPSC30P06K00
XBPSD30P05K00
XBPSD30P06KS0

"

"
XBPSD30P08KS0

"
XBPSD30P10KS0

"
XBPSN40P06K00
XEBSD30P06000

"

"
XEBSD30P06KS0
XEBSD30P08000

"

"

"

"

"
XEBSD30P10000

"

"

"
XEBSD30P12000

"
XEBSD30P30000
XEBSD40P12000
XEBSE30P06000

"
XEBSE30P08000

"

"

"

"

"

"
XEBSE30P10000

"

"

"

"
XEBSE30P12000

"
XEBSE30P14000
XEBSE40P12000

"

"

"

"

"

"

"

"
XEBSE40P14000
XEBSE40P16000
XEPSD20P10000

"
XEPSD30P06X00
XEPSD30P08X00

"
XHBSD30P06000
XHBSD40P08000
XHBSE30P06000

"

"

"

"

"

"
XHBSE30P08000
XHBSE30P10000

PRICE

NEW

MARK

PART

RANK

RANK

15- 21 AA C

4- 18 AA C
11- 29 AA C
19- 34 AA C
15- 1 AA C
13- 14 AA C

1- 9 AA C
20- 4 AA C
11- 17 AA C

4- 19 AA C
19- 24 AA C

3- 16 AA C

5- 12 AA C
12- 37 AA C

3- 24 AA C
14- 10 AB C

3- 40 AB C
13- 25 AA C
11- 15 AA C
19- 13 AA C
21- 5 AA C
18- 15 AA C
12- 51 AA C
20- 8 AA C

3- 55 AA C

4- 9 AA C

5- 6 AA C

6- 9 AA C
11- 10 AA C
11- 33 AA C
13- 35 AA C

7- 10 AA C

4- 32 AA C

9- 1 AA C
11- 11 AA C
24- 5 AA C
18- 30 AA C

7- 8 AA C

1- 3 AA C
14- 41 AA C
16- 2 AA C
17- 2 AA C
18- 8 AA C
19- 11 AA C
22- 9 AA C
12- 4 AA C
12- 44 AA C
13- 11 AA C

4- 49 AA C

6- 11 AA C
12- 40 AA C
14- 31 AA C

3- 22 AA C
11- 30 AA C
12- 35 AA C
12- 45 AA C
13- 15 AA C

1- 5 AA C
18- 32 AA C
19- 36 AA C
24- 2 AA C

3- 13 AA C

3- 14 AA C
24- 16 AA C
16- 5 AA C
17- 5 AA C
18- 28 AA C

3- 5 AA C

7- 21 AA C
25- 19 AA C
24- 15 AA C
11- 34 AA C
13- 3 AA C
18- 4 AA C
19- 23 AA C

4- 12 AA C

7- 7 AA C

8- 26 AA C

8- 31 AA C

3- 15 AA C

PARTS CODE NO.

XPSSJ20-07000

"
"

XPSSP20-07000

"
XPSSP20-09000
XRESP20-04000
XRESP30-04000
XRESP30-06000

"
XRESP40-06000

"

"

"

"

"

"
XRESP50-06000

"

"
XRESP70-08000

"

[0]

0AV1390000107

"

"
0AV1390000108

"

"
0AV1390000176
0AV1390000177

"

"
0AV1390000178

"

"
0AV1390000179

"

"
0AV1390000180

"

"
0AV1390000181

"

"
0AV1390000182

"

"
0AV1390000183
0AV1390000184
0AV1390000197
0AV1480000079

"

"
0AV1480000083

"

"
0AV1560000002

"

"
0AV1560000003

"
0AV1610000091

"

"
0AV1610000108

"

"
0AV1610000109

"

"
0AV1610000114
0AV1690000088

"

"
0AV1690000094

"
0AV1690000106

"

"
0AV1690000110

PRICE

NEW

MARK

PART

RANK

RANK

12- 12 AA C
18- 10 AA C
19- 6 AA C
25- 6 AA C

5- 29 AA C
4- 24 AA C
3- 35 AA C

14- 39 AA C

5- 24 AA C

7- 16 AA C
12- 14 AA C
18- 7 AA C
19- 2 AA C
22- 7 AA C
25- 3 AA C

4- 29 AA C

5- 15 AA C
12- 6 AA C

4- 20 AA C

8- 27 AA C
12- 48 AA C

8- 28 AA C

29- 11 AC C
30- 11 AC C
31- 10 AC C
29- 13 AC C
30- 13 AC C
31- 12 AC C
29- 8 AQ C
29- 14 AC C
30- 14 AC C
31- 13 AC C
29- 16 AG C
30- 16 AG C
31- 15 AG C
29- 18 AC C
30- 18 AC C
31- 17 AC C
29- 20 AC C
30- 20 AC C
31- 19 AC C
29- 15 AE C
30- 15 AE C
31- 14 AE C
29- 17 AG C
30- 17 AG C
31- 16 AG C
31- 7 AQ C
31- 9 AC C
30- 8 AR N C
29- 7 AC C
30- 7 AC C
31- 6 AC C
29- 6 AC C
30- 6 AC C
31- 5 AC C
29- 4 AD C
30- 4 AD C
31- 3 AD C
29- 2 AH C
30- 2 AH C
29- 9 AC C
30- 9 AC C
31- 8 AC C
29- 12 AD C
30- 12 AD C
31- 11 AD C
29- 19 AC C
30- 19 AC C
31- 18 AC C
31- 20 AD C
29- 3 AC C
30- 3 AC C
31- 2 AC C
29- 5 AD C
30- 5 AD C
29- 1 AD C
30- 1 AD C
31- 1 AD C
29- 10 AD C

– 39 –

PARTS CODE NO.

0AV1690000110
0AV1690000111
0AV2011003020

"

"
0AV2011013010
0AV2011023010

"

"
0AV2011033010

"

"
0AV2011033030

"

"
0AV2011043010

"
0AV2011043030
0AV2011053030
0AV2011213030

"

"
0AV2011533010

"

"
0AV2012203010

"

"
0AV2012213010

"
0AV2012233010

"

"
0AV2012243010
0AV2012243020
0AV2012733010
0AV2013333010

"

"
0AV2013933030

"
0AV2014713010

"

"
0AV2014723010

"

"
0AV2014733010

"

"
0AV2014743030

"
0AV2015603010

"
0AV2015633010

"

"
0AV2016803030

"

"
0AV2016823010

"
0AV2016833010

"

"
0AV2018233020

"
0AV2021023052

"

"
0AV2021043062
0AV2026833062

"
0AV2041013010

"
0AV2041013020

"

"
0AV2041213030

"

"

PRICE

NEW

MARK

PART
RANK

RANK

30- 10 AD C
31- 4 AD C
29- 51 AA C
30- 51 AA C
31- 51 AA C
31- 56 AA C
29- 60 AA C
30- 60 AA C
31- 60 AA C
29- 54 AA C
30- 54 AA C
31- 54 AA C
29- 62 AB C
30- 62 AB C
31- 62 AB C
29- 48 AA C
30- 48 AA C
31- 47 AA C
31- 43 AB C
29- 45 AB C
30- 45 AB C
31- 45 AB C
29- 66 AA C
30- 66 AA C
31- 65 AA C
29- 73 AA C
30- 73 AA C
31- 72 AA C
29- 63 AA C
30- 63 AA C
29- 49 AA C
30- 49 AA C
31- 49 AA C
31- 48 AA C
31- 61 AA C
31- 63 AA C
29- 50 AA C
30- 50 AA C
31- 50 AA C
29- 47 AC C
30- 47 AC C
29- 68 AA C
30- 68 AA C
31- 67 AA C
29- 65 AA C
30- 65 AA C
31- 64 AA C
29- 72 AA C
30- 72 AA C
31- 71 AA C
29- 43 AA C
30- 43 AA C
29- 56 AA C
30- 56 AA C
29- 59 AA C
30- 59 AA C
31- 59 AA C
29- 58 AA C
30- 58 AA C
31- 58 AA C
29- 64 AA C
30- 64 AA C
29- 55 AA C
30- 55 AA C
31- 55 AA C
29- 61 AB C
30- 61 AB C
29- 71 AC C
30- 71 AC C
31- 70 AC C
31- 57 AD C
29- 57 AD C
30- 57 AD C
29- 53 AC B
30- 53 AC B
29- 44 AC B
30- 44 AC B
31- 44 AC B
29- 46 AC B
30- 46 AC B
31- 46 AC B

PARTS CODE NO.

0AV2044703010
0AV2091083042

"
"

0AV2990007000

"
"

0AV2990082000

"
"

0AV2990083000

"
"

0AV3000143999

"
"

0AV3001015090

"
"

0AV3001020000

"
"

0AV3020143999

"
"

0AV3021815090

"
"

0AV3040494000

"

"
0AV3042605000
0AV3050019000

"

"
0AV3050036000

"

"
0AV3050086000

"

"
0AV3050097000

"

"
0AV3050098000

"

"
0AV3050099000

"

"
0AV3060027000

"

"
0AV3060043000

"

"
0AV3070056000

"

"
0AV3070057000

"

"
0AV3070058000

"

"
0AV3070061000

"

"
0AV3070074000

"

"
0AV3070081000

"

"
0AV3070085000

"

"
0AV3082561300

"

"
0AV3090071000

PRICE

NEW

MARK

PART
RANK

RANK

31- 53 AB B
29- 52 AC C
30- 52 AC C
31- 52 AC C
29- 67 AC C
30- 67 AC C
31- 66 AC C
29- 69 AC C
30- 69 AC C
31- 68 AC C
29- 70 AC C
30- 70 AC C
31- 69 AC C
29- 42 AD B
30- 42 AD B
31- 42 AD B
29- 37 AD B
30- 37 AD B
31- 37 AD B
29- 41 AE B
30- 41 AE B
31- 41 AE B
29- 38 AD B
30- 38 AD B
31- 38 AD B
29- 40 AC B
30- 40 AC B
31- 40 AC B
29- 39 AP B
30- 39 AP B
31- 39 AP B
31- 36 AN B
29- 26 AF B
30- 26 AF B
31- 26 AF B
29- 25 AF B
30- 25 AF B
31- 25 AF B
29- 21 AB B
30- 21 AB B
31- 21 AB B
29- 29 AG B
30- 29 AG B
31- 29 AG B
29- 31 AG B
30- 31 AG B
31- 31 AG B
29- 30 AD B
30- 30 AD B
31- 30 AD B
29- 22 AH B
30- 22 AH B
31- 22 AH B
29- 23 AC B
30- 23 AC B
31- 23 AC B
29- 28 AD B
30- 28 AD B
31- 28 AD B
29- 33 AC B
30- 33 AC B
31- 33 AC B
29- 24 AC B
30- 24 AC B
31- 24 AC B
29- 32 AC B
30- 32 AC B
31- 32 AC B
29- 34 AC B
30- 34 AC B
31- 34 AC B
29- 35 AC B
30- 35 AC B
31- 35 AC B
29- 27 AC B
30- 27 AC B
31- 27 AC B
29- 83 AF B
30- 83 AF B
31- 82 AF B
29- 87 AN B

– 40 –

PARTS CODE NO.

0AV3090071000

"

0AV3090076000

"
"

0AV3090077000

"
"

0AV3090078000

"
"

0AV3160034000

"
"

0AV3180000004

"
"

0AV3190008000

"

0AV4000134711

"
0AV4000135411
0AV4070061000
0AV4070062000
0AV4080007000

"
0AV4080010000
0AV4120002000

"

"

"
0AV4120013000

"

"
0AV5030123000

"

"
0AV5030124000

"
0AV5030125000

"

"
0AV5030130000
0AV5040012000

"

"
0AV5050005000

"

"
0AV5060020000
0AV5060058000
0AV5060083000
0AV5060085000
0AV5060090000
0AV5060091000
0AV5080010000

"

"
0AV5110001000

"

"
0AV5110002000

"

"
0AV5110004000

"

"
0AV5110006000

"

"
0AV5110012000

"

"
0AV5130006000

"
0AV5130008000

"

"
0AV5140021000

"
0AV5140022000

PRICE

NEW

MARK

PART

RANK

RANK

30- 87 AN B
31- 86 AN B
29- 84 AF B
30- 84 AF B
31- 83 AF B
29- 85 AN B
30- 85 AN B
31- 84 AN B
29- 86 AN B
30- 86 AN B
31- 85 AN B
29- 79 AQ B
30- 79 AQ B
31- 78 AQ B
29- 82 AL B
30- 82 AL B
31- 81 AL B
29- 36 AN B
30- 36 AN B
29- 78 AS B
30- 78 AS B
31- 77 BD B
29- 74 AF C
31- 73 AF C
29- 76 AH C
30- 76 AH C
31- 75 AP C
29- 75 AC C
30- 74 AC C
30- 75 AC C
31- 74 AC C
29- 77 AC C
30- 77 AC C
31- 76 AC C
29- 88 AD B
30- 88 AD B
31- 87 AD B
29- 89 AF B
30- 89 AF B
29- 90 AG B
30- 90 AG B
31- 89 AG B
31- 88 AF B
29- 93 AM B
30- 93 AM B
31- 92 AM B
29- 96 AA C
30- 96 AA C
31- 95 AA C
29- 95 AG A
29- 94 AK A
31- 94 AF A
31- 93 AF A
30- 94 AE N A
30- 95 AF N A
29- 91 AQ B
30- 91 AQ B
31- 90 AQ B
29- 105 AA C
30- 105 AA C
31- 103 AA C
29- 107 AA C
30- 107 AA C
31- 105 AA C
29- 108 AA C
30- 108 AA C
31- 106 AA C
29- 106 AA C
30- 106 AA C
31- 104 AA C
29- 104 AB C
30- 104 AB C
31- 102 AB C
29- 97 AB C
30- 97 AB C
29- 98 AC C
30- 98 AC C
31- 96 AC C
29- 80 AF B
30- 80 AF B
31- 79 AF B

PARTS CODE NO.

0AV5190002000

"
0AV5190009000
0AV5190022000

"
0AV5190024000
0AV6114125811

"

"
0AV7100003000

"

"
0AV7414135811

"
0AV7414136011
0AV8117730414

"

"
0AV8117730514

"

"

PRICE

NEW

MARK

PART

RANK

RANK

29- 81 AF B
30- 81 AF B
31- 80 AL B
29- 92 AK B
30- 92 AK B
31- 91 AK B
29- 100 AF C
30- 100 AF C
31- 98 AF C
29- 99 AE C
30- 99 AE C
31- 97 AE C
29- 103 AD C
30- 103 AD C
31- 101 AD C
29- 101 AB C
30- 101 AB C
31- 99 AB C
29- 102 AB C
30- 102 AB C
31- 100 AB C

– 41 –

CAUTION FOR BATTERY REPLACEMENT

(Danish) ADVARSEL !

Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering.

(English) Caution !

Dispose of used batteries according to manufacturer's instructions.

(Finnish) VAROITUS

Vaihda paristo ainoastaan laitevalmistajan suosittelemaan

(French) ATTENTION

ll y a danger d'explosion s'il y a remplacement incorrect

de la batterie. Remplacer uniquement avec une batterie du

Mettre au rébut les batteries usagées conformément aux

Udskiftning må kun ske med batteri

Levér det brugte batteri tilbage til leverandoren.

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type

Paristo voi räjähtää,jos se on virheellisesti asennettu.

tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden

même type on d'un type équivalent recommandé par

af samme fabrikat og type.

recommended by the manufacturer.

mukaisesti.

le constructeur.

instructions du fabricant.

(Swedish) VARNING

(German) Achtung

Als Ersatzbatterien dürfen nur Batterien vom gleichen Typ oder

(For USA,CANADA)

Contains lithium-ion battery. Must be disposed of properly.

Remove the battery from the product and contact

agencies for information on recycling and disposal options.

Explosionsfara vid felaktigt batteribyte.

Använd samma batterityp eller en ekvivalent

typ som rekornmenderas av apparattillverkaren.

Kassera använt batteri enligt fabrikantens

Explosionsgefahr bei Verwendung inkorrekter Batterien.

vom Hersteller empfohlene Batterien verwendet werden.

Entsorgung der gebrauchten Batterien nur nach den vom

Hersteller angegebenen Anwerisugen.

CAUTION FOR BATTERY DISPOSAL

Instruktion.

federal or state environmental

– 42 –

q

COPYRIGHT

No part of this publication may be reproduced,

electronic, mechanical, photocopying, recording, or otherwise,

without prior written permission of the publisher.



2002 BY SHARP CORPORATION

All rights reserved.

Printed in Japan.

stored in a retrieval system, or transmitted.

In any form or by any means,

SHARP CORPORATION
Digital Document Systems Group
Products Quality Assurance Department
Yamatokoriyama, Nara 639-1186, Japan

2002 July Printed in Japan t
