Sennheiser CABLE II-8 Datasheet
BROADCAST CABLES FOR HEADSETS
/ HEADPHONES
OVERVIEW CABLE COMPATIBILITY
P48
´* because P48 amp is integrated in the ear cap
´* P48 power supply needed because P48 amp is integrated in
´** P48 power supply is needed
MARCH 2019
Update on cable compatibility for Broadcast Headsets:
HMD 300 PROseries, HMD/ HME 26-II series, HMD/HMDC/ HME 27series
MODULAR CABLING SYSTEM
The HMD 300 PRO series, HMD/HME 26-II and HMD/HME/HMDC 27series utilizes the modular
cabling system from the cable-II-series. The headset cables can accommodate multipin
connectors or independent connectors for mic and headphone. Cable options include straight
cables with a coiled segment that eliminates structure born noise, and a fully coiled cable.
By stocking various cable types, you will be able to quickly configure tailor-made headsets for your
customers.
MODULAR HEADSET CABLES
MODEL ARTICLE DESCRIPTION COMPATIBILITY IMAGE
CABLE-II-X3K1-GOLD 508546
CABLE-II-X3K1-
505783
CABLE-II-X4F 505784
Straight copper cable with coiled
segment to eliminate structure born
noise. Reinforced with Aramid for
improved durability, and softer shield for
greater flexibility. XLR-3 connector and
6,3 mm (1/4”) jack plug with gold plated
contacts, 2 m
Straight copper cable reinforced with
Aramid for improved durability with short
coiled part for minimum structure born
noise with XLR-3 connector and 6,3 mm
(¼”) jack with P48 amp,
2 m
Straight copper cable with coiled
segment to eliminate structure born
noise. Reinforced with Aramid for
improved durability. XLR-4F
connector, 2 m
• HMD 300 PRO
• HMD 301 PRO
• HMD 300-XQ-2
• HMD 26-II
• HME 26-II-P48 *
(not HME 26-II)
• HMD 27/ HMDC 27
• HME 27 *
the earcup of the headset
• HME 26-II **
´* because P48 amp is integrated in the earcup of the headset
• HMD 300 PRO
• HMD 301 PRO
• HMD 26-II
• HME 26-II
• HMD 27
(Not HME 26-II-P48 *)
(Not HME 27 *)
(Not HME 26-II-P48 *)
(Not HME 27*, not
HMDC 27*)
1
BROADCAST CABLES FOR HEADSETS
/ HEADPHONES
OVERVIEW CABLE COMPATIBILITY
Coiled copper cable with XLR
connector and
3 m
Coiled copper cable with XLR
connector, 3 m
´* P48 Power supply necessary
´* P48 power supply needed
´* because P48 amp is integrated in the ear cap
´* because P48 amp is integrated in the ear cap
MODEL ARTICLE DESCRIPTION COMPATIBILITY IMAGE
CABLE-II-X5 505785
CABLE-II-6 508545
CABLE-II-8 505797
Straight copper cable with coiled
segment to eliminate structure born
noise. Reinforced with Aramid for
improved durability. XLR-5M
connector, 2 m
Straight copper cable with coiled
segment to eliminate structure born
noise. Unterminated end, 1.85 m
Straight copper cable with coiled
segment to eliminate structure born
noise. Reinforced with Aramid for
improved durability. Unterminated
ends, 2 m
• HMD 300 PRO
• HMD 301 PRO
• HMD 26-II
• HME 26-II
(Not HME 26-II-P48 *)
• HMD 27
(Not HME 27*, not
HMDC 27*)
• HMD 300 PRO
• HMD 301 PRO
• HMD 26-II
• HME 26-II
• HME 26-II-P48 *
• HMD 27/ HMDC 27 *
• HME 27 *
´* P48 Power supply necessary
• HMD 300 PRO
• HMD 301 PRO
• HMD 26-II
• HME 26-II
• HME 26-II-P48 *
• HMD 27/ HMDC 27 *
• HME 27 *
CABLE-H-X3K1 502456
CABLE-H-X4F 502457
-3
6,3mm (1/4”) jack,
-4F
2
• HMD 300 PRO
• HMD 301 PRO
• HMD 26-II
• HME 26-II-P48 *
(Not HME 26-II)
• HMD 27/ HMDC 27 *
• HME 27 *
• HMD 300 PRO
• HMD 301 PRO
• HMD 26-II
• HME 26-II
(Not HME 26-II-P48 *)
• HMD 27/ *
(Not HME 27
HMDC 27 *)
*, not
