Screw Fastening System
SM
DS50-14v
DS50DW-14v
Senco Products, Inc.
8485 Broadwell Rd.
Cincinnati, Ohio 45244
NFE080 Revised August 8, 2001 (Replaces 4/19/01) ©2000, 2001 by SENCO Products, Inc. Cincinnati, Ohio 45244ÑU.S.A.
Questions? Comments? e-mail: toolprof@senco.com
Visit our website: www.senco.com or www.duraspin.com
Bits
Phillips Driver
Square
DS50DW-14V / DS50-14v
KB3435
EA0122 DS50DW-14V / DS50-14V
EA0123 DS50-14V
HA0120
KB3382
GC0647
FA0195
KB3437
KB0017
AB0113
KB4252
HA0119
YA0061
Nosepiece
US
Metric
Japanese
Australia
DS50DW-14V DS50-14V
FA0215
FA0216
FA0217
FA0217
US
Metric
Japanese
Australia
FA0198
FA0205
FA0206
FA0206
WA0006
WA0005
VB0006
AB0112
VB0014
GC0713
Charger
US
Japan
Europe / S.America
Australia
United Kingdom
VB0004
VB0008
VB0009
VB0010
VB0012
AC0192
Motor & Gear Assy.
DS50DW-14V
DS50-14V
VC0023
VA0017
VA0010
DuraSpin DS50DW-14v / DS50-14v
™
REPLACEMENT PARTS LIST•LISTA DE PARTES DE REPUESTO•ERSATSTEILE-LISTE•LISTE DE PIÈCES DE RECHANGE
PART NO. DESCRIPTION DESCRIPCIÓN BESCHREIBUNG DÉSIGNATION
AB0112 .................. SUPPORT (LEFT)...............................SOPORTE (IZQUIERDO)................................ TRÄGER (LINKS) .............................................. SUPPORT (GAUCHE)
AB0113 .................. COVER (RIGHT) ................................CUBIERTA (DERECHO) ................................. ABDECKUNG (RECHTS) ....................................COUVERCLE (DROITE)
AC0192 .................. BELT HOOK .......................................GANCHO DE CINTúRON.................................GURTHAKEN ...................................................... CROCHET DE CEINTURE
EA0122 .................. SCREW BIT (Phillips No.2) ...............BROCA DE TORNILLO...................................SCHRAUBENDREHERBIT .................................. BROCHE À VIS
EA0123 .................. SCREW BIT (Square No.2) ...............BROCA DE TORNILLO...................................SCHRAUBENDREHERBIT.................................. BROCHE À VIS
FA0195................... SLIDE BODY ASSEMBLY .................. CONJUNTO DE CUERPO DESLIZANTE .........BAUGRUPPE GLEITGEHÄUSE ..........................ASSEMBLAGE BLOC GLISSIERE
FA0198................... NOSE PIECE (US) .............................PIEZA DE LA BOCA (AMERICANA) ................ NASENSTÜCK (US)............................................ EMBOUT (US)
FA0205................... NOSE PIECE (METRIC) .....................PIEZA DE LA BOCA (METRICA) ..................... NASENSTÜCK (METRISCH)...............................EMBOUT (SYSTÉME MÉRTIQUE)
FA0206................... NOSE PIECE (JAPAN/AUSTRALIA) ..PIEZA DE LA BOCA (JAPON/AUSTRALIA).....NASENSTÜCK (JAPAN/AUSTRALIA) ................. EMBOUT (JAPON/AUSTRALIA)
FA0215................... NOSE PIECE (US) .............................PIEZA DE LA BOCA (AMERICANA) ................ NASENSTÜCK (US)............................................ EMBOUT (US)
FA0216................... NOSE PIECE (METRIC) .....................PIEZA DE LA BOCA (METRICA) ..................... NASENSTÜCK (METRISCH)...............................EMBOUT (SYSTÉME MÉRTIQUE)
FA0217................... NOSE PIECE (JAPAN/AUSTRALIA) ..PIEZA DE LA BOCA (JAPON/AUSTRALIA).....NASENSTÜCK (JAPAN/AUSTRALIA) ................. EMBOUT (JAPON/AUSTRALIA)
GC0647 .................. ROLLER ............................................RODILLO .......................................................ROLLE ............................................................... GALET
GC0713 .................. STRIP GUIDE COVER .......................CUBIERTA ..................................................... ABDECKUNG .....................................................COUVERCLE
HA0119 .................. TRIGGER ASSEMBLY .......................ASAMBLE DE GATILLO.................................. AUSLöSER-ZUSAMMENBAU ............................. GACHETTED’ ASSEMBLÉE
HA0120 .................. BIT RELEASE ASSEMBLY .................CONJUNTO DE LIBERACION DE LA BROCA .......BAUGRUPPE BITLÖSEMECHANISMUS............ ASSEMBLAGE LIBÉRATION BROCHE
KB0017 .................. SCREW.............................................. TORNILLO .....................................................SCHRAUBE ........................................................VIS
KB0289 .................. SCREW.............................................. TORNILLO .....................................................SCHRAUBE ........................................................VIS
KB3382 .................. SCREW.............................................. TORNILLO .....................................................SCHRAUBE ........................................................VIS
KB3435 .................. SCREW.............................................. TORNILLO .....................................................SCHRAUBE ........................................................VIS
KB3437 .................. SCREW.............................................. TORNILLO .....................................................SCHRAUBE ........................................................VIS
KB4252 .................. RETURN SPRING ..............................MUELLE .........................................................FEDER................................................................RESSORT
VA0010 .................. MOTOR & GEAR ASSEMBLY............CONJUNTO DE MOTOR Y
VA0017 .................. MOTOR & GEAR ASSEMBLY............CONJUNTO DE MOTOR Y ENGRANAJE............... BAUGRUPPE MOTOR U. GETRIEBE ...................ASSEMBLAGE MOTEUR ET PIGNON
VB0004 .................. CHARGER (US) .................................CARAGADOR (AMERICA) ..............................LADEGERÄT (US) ..............................................CHARGEUR (US)
VB0006 .................. TRIGGER SWITCH ............................INTERRUPTOR DEL ACCIONADOR ................AUSLÖSEKNOPF ...............................................GACHETTE
VB0008 .................. CHARGER (JAPAN) ..........................CARAGADOR (JAPON) ..................................LADEGERÄT (JAPAN)........................................ CHARGEUR (JAPON)
VB0009 .................. CHARGER (EUROPE/S.AMERICA).... CARAGADOR (EUROPA/S.AMERICA)............LADEGERÄT (EUPOPA/S.AMERICA).................CHARGEUR (EUROPE/S.AMERICA)
VB0010 .................. CHARGER (AUSTRALIA) ..................CARAGADOR (AUSTRALIA) ........................... LADEGERÄT (AUSTRALIEN) .............................CHARGEUR (AUSTRALIE)
VB0012 .................. CHARGER (U.K.) ...............................CARAGADOR (INGLATERRA) ........................ LADEGERÄT (GB) .............................................. CHARGEUR (ROYAUME UNI)
VB0014 .................. BATTERY CONNECTOR-WIRING ........CABLEADO DE CONEXION DE LA BATERIA ...BATTERIEANSCHLUSSKABEL ........................... CÂBLAGE CONNECTEUR BATTERIE
VC0023 .................. BATTERY 14.4V ................................ BATERIA DE 14,4V........................................ BATTERIE 14,4V ...............................................BATTERIE 14,4V
WA0005 ................. CLUTCH ASSEMBLY......................... CUNJUNTO DEL EMBRAGUE .........................BAUGRUPPE KUPPLUNG .................................. ASSEMBLAGE EMBRAYAGE
WA0006 ................. DRIVE SHAFT ASSEMBLY ................CONJUNTO DEL EJE IMPULSOR ...................BAUGRUPPE ANTRIEBSWELLE .........................ASSEMBLAGE ARBRE DE COMMANDE
YA00061 ................ WRENCH KIT ....................................CONJUNTO .................................................... EINBAUSATZ .....................................................KIT
ENGRANAJE............... BAUGRUPPE MOTOR U. GETRIEBE ...................ASSEMBLAGE MOTEUR ET PIGNON
