Sega WAVERUNNERGP STD User Manual
1ST PRINTING JUNE ‘03
www.seuservice.com
STD Version
Owner’s Manual
SEGA ENTERPRISES, INC. USA
MANUAL NO. 999-1869
Game Code: WRG
VISIT OUR WEBSITE!
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain the safety:
To ensure the safe usage of the product, be sure to read the following before using the product. The
following instructions are intended for the users, operators and the personnel in charge of the operation of the product. After carefully reading and sufciently understanding the warning displays and
cautions, handle the product appropriately. Be sure to keep this manual nearby the product or elsewhere convenient for referring to it when necessary.
Herein, explanations which require special attention are enclosed with dual lines. Depending on the
potentially hazardous degrees, the terms of WARNING, CAUTION, etc. are used. Be sure to understand the contents of the displays before reading the text.
Indicates that mishandling the product by disregarding this warning
will cause a potentially hazardous
WARNING!
situation which can result in death
or serious injury.
CAUTION!
Indicates that mishandling the product
by disregarding this caution will cause
a slight hazardous situation which can
result in personal injury and or material
damage.
For the safe usage of the product, the following pictographs are used:
Indicates “HANDLE WITH CARE.” In order to protect the human body an equipment,
this display is attached to places where the Owner’s Manual and or Service Manual should
be referred to.
Perform work in accordance with the instructions herein stated.
Instructions for work are explained by paying attention to the aspect of accident prevention. Failing to
perform work as per the instructions can cause accidents. In the case where only those who have technical expertise should perform the work to avoid hazardous situation, the instructions herein state that the
serviceman should perform such work.
Be sure to turn off power before working on the machine.
To prevent electric shock, be sure to turn off power before starting the work in which the worker touches
the interior of the product. If the work is to be performed in the power-on status, the Instruction Manual
herein always states to that effect.
Be sure to ground the Earth Terminal (this, however, is not required in the case where a power cord
with earth is used).
This product is equipped with the Earth Terminal. When installing the product, Connect the Earth Terminal to the “accurately grounded indoor earth terminal” by using an earth wire. Unless the product is
grounded appropriately, the user can be subject to electric shock. After performing repair, etc. for the
Control equipment, ensure that the Earth Wire is rmly connected to the Control equipment.
Ensure that the Power Supply used is equipped with an Earth Leakage Breaker.
This product does not incorporate the Earth Leakage Breaker. Using a power supply which is not
equipped with the Earth Leakage Breaker can cause a re when earth leakage occurs.
Be sure to use fuses which meet the specied rating. (only for the machines which use fuses).
Using fuses exceeding the specied rating can cause a re and electric shock.
Specication changes (removal of equipment, conversion and addition) not designated by SEGA
are not allowed.
The parts of the product include warning labels for safety, covers for personal protection, etc. It is
very hazardous to operate the product by removing parts and or modifying the circuits. Should doors,
lids and protective parts be damaged or lost, refrain from operating the product, and contact where the
product was purchased from or the ofce herein stated. SEGA shall not be held responsible for any
accidents, compensation for damage to a third party, resulting from the specications not designated by
SEGA.
Ensure that the product meets the requirements of appropriate Electrical Specications.
Before installing the product, check for Electrical Specications. SEGA products have a nameplate
on which Electrical Specications are described. Ensure that the product is compatible with the power
supply voltage and frequency requirements of the location. Using any Electrical Specications different
from the designated Specications can cause a re and electric shock.
Install and operate the product in places where appropriate lighting is available, allowing warning
labels to be clearly read.
To ensure safety for the customers, labels and printed instructions describing potentially hazardous situation are applied to places where accidents can be caused. Ensure that where the product is operated
has sufcient lighting allowing the warnings to be read. If any label is peeled off, apply it again immediately. Please place an order with where the product was purchased from or the ofce herein stated.
When handling the Monitor, be very careful. (Applies only to the product w/monitor.)
Some of the monitor (TV) parts are subject to high tension voltage. Even after running off power, some
portions are still subject to high tension voltage sometimes. Monitor repair and replacement should be
performed only be those technical personnel who have knowledge of electricity and technical expertise.
Be sure to adjust the monitor (projector) properly. (Applies only to the product w/monitor.)
Do not operate the product leaving on-screen ickering or blurring as it is. Using the product with the
monitor not properly adjusted may cause dizziness or a headache to an operator, a player, or the customers.
When transporting or reselling this product, be sure to attach this manual to the product.
In the case where commercially available monitors and printers are used in this product, only the contents relating to this product are explained herein. Some commercially available equipment has functions and reactions not stated in this manual. Read this manual together with the specic Instruction
Manual of such equipment.
•
Descriptions herein contained may be subject to improvement changes without notice.
•
The contents described herein are fully prepared with due care. However, should any question arise or
errors be found, please contact SEGA.
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION.
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately after
transporting to the location. Nevertheless, an irregular situation may occur during transportation. Before
turning on power, check the following points to ensure that the product has been transported in a satisfactory status.
Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
Are Casters and Adjusters, damaged?
Do the power supply voltage and frequency requirements meet with those of the location?
Are all wiring connectors correctly and securely connected? Unless connected in the correct direction,
connector connections can not be made accurately. Do not insert connectors forcibly.
Do power cords have cuts and dents?
Do the fuses used meet specied rating? Is the Circuit Protector in an energized status?
Are all accessories available?
Can all Doors and Lids be opened with the Accessory keys? Can Doors and Lids be rmly closed?
TABLE OF CONTENTS
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
TABLE OF CONTENTS
INTRODUCTION OF THE OWNER’S MANUAL
1. HANDLING PRECAUTIONS ..........................................................................................
2. PRECAUTIONS CONCERNING INSTALLATION LOCATION ...................................
3. OPERATION .....................................................................................................................
4. NAME OF PARTS .............................................................................................................
5. ACCESSORIES .................................................................................................................
6. ASSEMBLING AND INSTALLATION ............................................................................
7. PRECAUTIONS TO BE HEEDED WHEN MOVING THE MACHINE ........................
8. CONTENTS OF GAME ....................................................................................................
9. EXPLANATION OF TEST AND DATA DISPLAY .........................................................
10. COIN SELECTOR ............................................................................................................
11. MONITOR ........................................................................................................................
12. PERIODIC INSPECTION TABLE ..................................................................................
13. TROUBLESHOOTING ....................................................................................................
14. GAME BOARD ................................................................................................................
15. DESIGN RELATED PARTS ...........................................................................................
16. COMMUNICATION PLAY .............................................................................................
17. PARTS ...............................................................................................................................
17. WIRE COLOR CODE TABLE ........................................................................................
18. WIRING DIAGRAM .......................................................................................................
1 - 2
3 - 4
5 - 7
8
9 - 10
11 - 18
19 - 20
21 - 25
26 - 43
44 - 45
46 - 47
48
49 - 52
53 - 54
55
56 - 60
61 - 64
65
XXX
SPECIFICATIONS
Installation Space : 38.25 inches wide X 84.5 inches deep
Height : 77.5 inches
Width : 30.25 inches
Length : 76.5 inches
Weight : 550 lbs
Power, maximum current : 420 W 3.5 A (AC 120V 60 Hz AREA)
MONITOR : 29 inch supplied by Wells Gardner
model #wgm-2972XX
INTRODUCTION OF THE OWNERS MANUAL
This Owner's Manual is intended to provide detailed descriptions together with all the
necessary information covering the general operation of electronic assemblies, electromechanicals, servicing control, spare parts, etc. as regards the product,
WAVERUNNER GP STANDARD VERSION.
This manual is intended for the owners, personnel and managers in charge of operation
of the product. Operate the product after carefully reading and sufciently understanding the instructions. If the product fails to function satisfactorily, non-technical personnel
should under no circumstances touch the internal system. Please contact where the product was purchased from.
Use of this product is unlikely to cause physical injuries or damages to property. However,
where special attention is required this is indicated by a thick line, the word "IMPORTANT"
and its sign in this manual.
Indicates that mishandling the product by disregarding this display can cause the
STOP
product's intrinsic performance not to be obtained, resulting in malfunctioning.
IMPORTANT!
SEGA AMUSEMENTS USA, INC./CUSTOMER SERVICE
45133 Industrial Drive, Fremont, California 94538, U.S.A.
Phone : (415) 701-6580
Fax : (415) 701-6594
DEFINITION OF LOCATION MAINTENANCE MAN AND SERVICEMAN
LISTED
U
L
®
5K92
AMUSEMENT MACHINE
Non-technical personnel who do not have technical knowledge and expertise should
refrain from performing such work that this manual requires the location's main-
WARNING!
Ensure that parts replacement, servicing & inspections, and troubleshooting are performed by the
location's maintenance man or the serviceman. It is instructed herein that particularly hazardous work
should be performed by the serviceman who has technical expertise and knowledge.
The location's maintenance man and serviceman are herein dened as follows:
"Location's Maintenance Man" :
Those who have experience in the maintenance of amusement equipment and vending machines, etc.,
and also participate in the servicing and control of the equipment through such routine work as equipment assembly and installation, servicing and inspections, replacement of units and consumables, etc.
within the Amusement Facilities and or locations under the management of the Owner and Owner's
Operators of the product.
tenance man or a serviceman to carry out, or work which is not explained in this
manual. Failing to comply with this instruction can cause a severe accident such
as electric shock.
Activities of Location's Maintenance Man :
Assembly & installation, servicing & inspections, and replacement of units & consumables as regards
amusement equipment, vending machines, etc.
Serviceman :
Those who participate in the designing, manufacturing, inspections and maintenance service of the
equipment at an amusement equipment manufacturer.
Those who have technical expertise equivalent to that of technical high school graduates as regards
electricity, electronics and or mechanical engineering, and daily take part in the servicing & control
and repair of amusement equipment.
Serviceman's Activities :
Assembly & installation and repair & adjustments of electrical, electronic and mechanical parts of
amusement equipment and vending machines.
NOTES:
1. HANDLING PRECAUTIONS
When installing or inspecting the machine, be very careful of the following points and pay attention to
ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the cautionary
matters herein stated can cause personal injury or damage to the machine.
• Before performing work, be sure to turn power off. Performing the work without turning power off can cause an electric shock or short circuit. In the case
WARNING!
work should be performed in the status of power on, this manual always states
to that effect.
• To avoid electric shock or short circuit, do not plug in or unplug quickly.
• To avoid electric shock, do not plug in or unplug with a wet hand.
• Do not expose Power Cords and Earth Wires on the surface, (oor, passage,
etc.). If exposed, the Power Cords and Earth Wires are susceptible to damage.
• Damaged cords and wires can cause electric shock or short circuit.
To avoid causing a re or electric shock, do not put things on or damage Power
Cords.
• When or after installing the product, do not unnecessarily pull the power cord.
If damaged, the power cord can cause a re or electric shock.
In case the power cord is damaged, ask for replacement through where the prod-
uct was purchased from or the ofce herein stated. Using the cord as is damaged can cause re, electric shock or leakage.
• Be sure to perform grounding appropriately. Inappropriate grounding can cause
an electric shock.
• Be sure to use fuses meeting specied rating. Using fuses exceeding the specied rating can cause a re or electric shock.
• Completely make connector connections for IC BD and others. Insufcient
insertion can cause an electric shock.
• Specication changes, removal of equipment, conversion and/or addition, not
designated by SEGA are not permitted.
• Failure to observe this may cause a re or an electric shock. Non-compliance
with this instruction can have a bad inuence upon physical conditions of the
players or the lookers-on, or result in injury during play.
• SEGA shall not be held responsible for damage, compensation for damage to a
third party, caused by specication changes not designated by SEGA.
Be sure to perform periodic maintenance inspections herein stated.
1
www.seuservice.com
www.seuservice.com
3
STOP
IMPORTANT!
For the IC board circuit inspections, only the logic tester is allowed. The use of a
multiple-purpose tester is not permitted, so be careful in this regard.
The Projector is employed for this machine. The Projector's screen is susceptible
to damage, therefore, be very careful when cleaning the screen. For details, refer to
PROJECTOR.
Some parts are the ones designed and manufactured not specically for this game
machine. The manufacturers may discontinue, or change the specications of, such
general-purpose parts. If this is the case, Sega cannot repair or replace a failed
game machine whether or not a warranty period has expired.
www.seuservice.com
2
2. PRECAUTIONS CONCERNING INSTALLATION LOCATION
This product is an indoor game machine. Do not install it outside. Even indoors, avoid
installing in places mentioned below so as not to cause a re, electric shock, injury
WARNING!
LIMITATIONS OF USAGE REQUIREMENTS
and or malfunctioning.
Places subject to rain or water leakage, or places subject to high humidity in the
proximity of an indoor swimming pool and or shower, etc.
Places subject to direct sunlight, or places subject to high temperatures in the prox-
imity of heating units, etc.
Places lled with inammable gas or vicinity of highly inammable/volatile chemi-
cals or hazardous matter.
Dusty places.
Sloped surfaces.
Places subject to any type of violent impact.
Vicinity of anti-disaster facilities such as re exits and re extinguishers.
The operating (ambient) temperature range is from 5˚ to 30˚.
Be sure to check the Electrical Specications.
Ensure that this product is compatible with the location's power supply, voltage and
WARNING!
A plate describing Electrical Specications is attached to the product.
Non-compliance with the Electrical Specications can cause a re and electric
This product requires the Breaker and Earth Mechanisms as part of the location
Ensure that the indoor wiring for the power supply is rated at 15A or higher (AC
Be sure to independently use the power supply equipped with the Earth Leakage
Putting many loads on one electrical outlet can cause generation of heat and a re
When using an extension cord, ensure that the cord is rated at 15A or higher (AC
frequency requirements.
shock.
facilities. Using them in a manner not independent can cause a re and electric
shock.
single phase 100 ~ 120V area), and 8A or higher (AC 220 ~ 240V area). Non-compliance with the Electrical Specications can cause a re and electric shock.
Breaker. Using a power supply without the Earth Leakage Breaker can cause an
outbreak of re when earth leakage occurs.
resulting from overload.
100 ~ 120V area) and 8A or higher (AC 220 ~ 240V area). Using a cord rated
lower than the specied rating can cause a re and electric shock.
3
www.seuservice.com
www.seuservice.com
5
76.5 in.
Vent approx. 8 in.
30.14 in.
8 in.
OPERATION AREA
For the operation of this machine, secure a minimum area of 40in (W) X 85in (D).
WARNING!
Be sure to provide sufcient space so as to allow this product's ventilation fan to
SEGA shall not be held responsible for damage, compensation for damage to a third
In order to prevent injury resulting from the falling down accident during game
play, be sure to secure the minimum area for operation.
function efciently. To avoid machine malfunctioning and a re, do not place any
obstacles near the ventilation opening.
party, resulting from the failure to observe this instruction.
STOP
For transporting the machine into the location's building, the minimum necessary dimensions of the opening (of doors, etc.) are 31in (W) and 78in (H).
IMPORTANT!
Electric current consumption
MAX. 5 A (AC 120V 60 Hz)
www.seuservice.com
FIG. 2
4
3. OPERATION
PRECAUTIONS TO BE HEEDED BEFORE STARTING THE OPERATION
To avoid injury and trouble, be sure to constantly give careful attention to the behavior and manner of
the visitors and players.
In order to avoid accidents, check the following before starting the operation:
To ensure maximum safety for the players and the customers, ensure that where
WARNING!
the product is operated has sufcient lighting to allow any warnings to be read.
Operation under insufcient lighting can cause bodily contact with each other,
hitting accident, and or trouble between customers.
Be sure to perform appropriate adjustment of the monitor (projector). For operation
of this machine, do not leave monitor's ickering or deviation as is. Failure to
observe this can have a bad inuence upon the players' or the customers' physical
conditions.
It is suggested to ensure a space allowing the players who feel sick while playing
the game to take a rest.
Check if all of the adjusters are in contact with the
surface. If they are not, the Cabinet can move and
cause an accident.
Ensure that all of the Adjusters are in contact with the oor.
5
www.seuservice.com
www.seuservice.com
7
Do not put any heavy item on this product. Placing any heavy item on the product
WARNING!
CAUTION!
Do not climb on the product. Climbing on the product can cause falling down ac-
To avoid electric shock, check to see if door & cover parts are damaged or omitted.
To avoid electric shock, short circuit and or parts damage, do not put the following
Flower vases, owerpots, cups, water tanks, cosmetics, and receptacles/containers/
To avoid injury, be sure to provide sufcient space by considering the potentially
crowded situation at the installation location. Insufcient installation space can cause
making bodily contact with each other, hitting accidents, and or trouble between customers.
can cause a falling down accident or parts damage.
cidents. To check the top portion of the product, use a step.
items on or in the periphery of the product.
vessels containing chemicals and water.
www.seuservice.com
6
PRECAUTIONS TO BE HEEDED DURING OPERATION (PAYING ATTENTION TO CUSTOMERS)
To avoid injury and trouble, be sure to constantly give careful attention to the behavior and manner of
the visitors and players.
To avoid injury and accidents, those who fall under the following categories are not
allowed to play the game.
• Those who need assistance such as the use of an apparatus when walking.
WARNING!
• Those who have high blood pressure or a heart problem.
• Those who have experienced muscle convulsion or loss of consciousness when playing
video game, etc.
• Those who have a trouble in the neck and or spinal cord.
• Intoxicated persons.
• Pregnant women or those who are in the likelihood of pregnancy.
• Persons susceptible to motion sickness.
• Persons whose act runs counter to the product's warning displays.
A player who has never been adversely affected by light stimulus might experience
dizziness or headache depending on his physical condition when playing the game.
Especially, small children can be subject to those conditions. Caution guardians of
small children to keep watch on their children during play.
Instruct those who feel sick during play to have a medical examination.
To avoid electric shock and short circuit, do not allow customers to put hands and
ngers or extraneous matter in the openings of the product or small openings in or
around the doors.
To avoid falling down and injury resulting from falling down, immediately stop the
customer's leaning against or climbing on the product, etc.
To avoid electric shock and short circuit, do not allow the customers to unplug the
power plug without a justiable reason.
Instruct the player to take a rm
WARNING!
Immediately stop such violent acts as hitting and kicking the product. Such violent
CAUTION!
grip of the handle Bars during
play. This machine reacts as per
the contents of the game. To
avoid injury, instruct the players
to refrain from single-handed
taking grip of the handle Bar
(which is very likely to cause
potentially hazardous situation,
should he attempt to do so).
acts can cause parts damage or falling down, resulting in injury due to fragments
and falling down.
7
www.seuservice.com
www.seuservice.com
9
4. NAME OF PARTS
Marquee
Monitor
Control Panel
Seat
TABLE 4 Dimensions and Weights
Items Width X Depth X Height Weight
Cabinet 30.25in (W) X 35.75in (D) X 77.5in (H) 450 lbs
Seat Section 30.25in (W) X40.75in (D) X 25.25in (H) 100 lbs
When assembled 30.25in (W) X 76.5in (D) X 77.5in (H) 550 lbs
www.seuservice.com
8
5. ACCESSORIES
When transporting the machine, make sure that the following parts are supplied.
TABLE 5 a ACCESSORIES
DESCRIPTION OWNERS MANUAL
Part No. (Qty.)
999-XXXX (1)
Note
Figures
If Part No. has no description, the Number has not been
registered or can not be registered. Such a part may not be
obtainable even if the customer desires to purchase it.
Therefore, ensure that the part is in safekeeping with you.
SERVICE MANUAL NAOMI ENG
420-6455-01 (1)
INSTRUCTION MANUAL FOR THE
GAME BOARD
KEY MASTER
220-5576 (2)
For opening/closing the doors
KEY (2)
For the CASHBOX DOOR
The Keys are inside the Coin Chute Door at the time of shipment
from the factory.
TAMPERPROOF
WRENCH
T-27 Torx 1/4-20 (1)
T-15 Torx 8/32 (1)
Tool
9
www.seuservice.com
www.seuservice.com
11
②
③
①
HOW TO USE THE CARTON BOX
When requesting for the replacement/repair of this product's Game Board (NAOMI
STOP
BOARD), follow the instructions below. Transporting the Game Board in an undesignated status is unacceptable. An erroneous handling can cause parts damage.
IMPORTANT!
• Put the Game Board in the Carton Box together with the Shield Case. Do not unnecessarily disassemble nor remove parts.
• By paying careful attention to the following Figure and the direction shown by onCarton-Box printing, put the Shield Case in the Carton Box.
• When putting the Shield Case in the Carton Box, do not remove Leg Brackets.
• The projected portions of the packing material is intended for cushioning. Therefore, do not bend the projected portions.
"CHECK SIDE" Display
FILTER BOARD
Bend the packing material in numerical order, and wrap the Shield Case with the packing material
and put it in the Carton Box as shown. Putting it upside down or packing otherwise in the manner not
shown can damage the Game Board and the parts.
Serial No. Display
Serial No. Display
Projected portions of
the packing material.
FIG. 5
www.seuservice.com
10
6. ASSEMBLING AND INSTALLATION
Perform assembly work by following the procedure herein stated. Failing to com-
ply with the instructions can cause electric shock hazard.
WARNING!
Perform assembling as per this manual. Since this is a complex machine, erroneous
assembling can cause an electric shock, machine damage and or not functioning as
per specied performance.
When assembling, be sure to use plural persons. Depending on the assembly work,
there are some cases in which working by one person alone can cause personal
injury or parts damage.
Ensure that connectors are accurately connected. Incomplete connections can cause
electric shock hazard.
Be careful so as not to damage wirings. Damaged wiring can cause electric shock
and short circuit hazards.
Do not carelessly push the PTV. Pushing the PTV carelessly can cause the PTV to
fall down.
This work should be performed by the Location's Maintenance Man or Serviceman.
Performing work by non-technical personnel can cause a severe accident such as
electric shock. Failing to comply with this instruction can cause a severe accident
such as electric shock to the player during operation.
Provide sufcient space so that assembling can be performed. Performing work in
places with narrow space or low ceiling may cause an accident and assembly work
to be difcult.
To perform work safely and avoid serious accident such as the cabinet's falling
down, do not perform work in places where step-like grade differences, a ditch, or
slope exist.
CAUTION!
To perform work safely and securely, be sure to prepare a step which is in a secure and
stable condition. Performing work without using the step can cause violent falling
down accidents.
When carrying out the assembling and installation, follow the following 7-item sequence.
1
SECURING IN PLACE (ADJUSTER ADJUSTMENT)
2
POWER SUPPLY, AND EARTH CONNECTION
3
TURNING POWER ON
4
ASSEMBLY CHECK
11
www.seuservice.com
www.seuservice.com
13
Tools required for the work
Phillips type screwdriver (for M4, M5 screw)
WRENCH (for M16 hexagon bolt)
KEY MASTER
Box nut screwdriver (for M4 hexagon nut) or WRENCH
www.seuservice.com
12
1
SECURING IN PLACE (ADJUSTER ADJUSTMENT)
Make sure that all of the adjusters are in contact with the oor. If they are not, the
cabinet can move and cause an accident.
WARNING!
This product has 8 casters (4 for FRONT CABINET, 4 for REAR CABINET) and 8 Adjusters
(4 for FRONT CABINET, 4 for REAR CABINET). (FIG. 6. 3a) When the installation position is
determined, cause the adjusters to come into contact with the oor directly, make adjustments in a
manner so that the casters will be raised approximately 5mm from the oor and make sure that the
machine position is level.
Transport the product to the
1
installation position. Be sure to
provide adequate space allowing
the player to get on and off.
2
Have all of the Adjusters make
contact with the oor. Adjust
the Adjuster's height by using
a wrench so that the machine
position is kept level.
CASTER
3
After making adjustment, fasten
the Adjuster Nut upward and
secure the height of Adjuster
(FIG. 6. 3 b).
ADJUSTER
FASTEN UPWARD.
FIG. 6. 3 b ADJUSTER
Note: Actual unit will differ from image.
ADJUSTER
FIG. 6. 3 a BOTTOM VIEW
Note: Actual unit will differ from image.
CASTER
Approx.5mm
ADJUSTER
FIG. 6. 3 c
Refer to this Fig. (Scale:1/100) for
the layout of the place of installation.
10cm
FIG. 6. 3 d
Be sure to provide space as shown between the Air
Vent and the wall surface.
13
15cm
www.seuservice.com
www.seuservice.com
15
2
POWER SUPPLY, AND EARTH CONNECTION
Be sure to independently use the power supply socket outlet equipped with an Earth
WARNING!
Ensure that the "accurately grounded indoor earth terminal" and the earth wire cable
Ensure that the power cord and earth wire are not exposed on the surface (passage,
After wiring power cord on the oor, be sure to protect the power cord. Exposed
Leakage Breaker. Using a power supply without an Earth Leakage Breaker can
cause a re when electric leakage occurs.
are available (except in the case where a power cord plug with earth is used). This
product is equipped with the earth terminal. Connect the earth terminal and the indoor earth terminal with the prepared cable. If the grounding work is not performed
appropriately, customers can be subjected to an electric shock, and the product's
functioning may not be stable.
etc.). If exposed, they can be caught and are susceptible to damage. If damaged,
the cord and wire can cause electric shock and short circuit accidents. Ensure that
the wiring position is not in the customer's passage way or the wiring has protective
covering.
power cord is susceptible to damage and causes an electric shock accident.
The AC Unit is mounted on the right side of the machine. The AC Unit has Main SW, Circuit Protector, Earth Terminal and the Inlet which connects the Power Cord.
1
Ensure that the Main SW is OFF.
MAIN SW
CIRCUIT PROTECTOR
Main SW off
INLET
EARTH TERMINAL
Connect with the
indoor earth terminal.
AC Cable (Power Cord)
FIG. 6. 5 a AC UNIT
www.seuservice.com
14
Connect one end of the earth wire to the AC Unit earth
2
terminal, and the other end to the indoor earth terminal. The AC Unit earth terminal has a Bolt and Nut
combination. Take off the Nut, pass the end of earth
wire through the Bolt, and fasten the Nut.
3
Note that the Earth Wire is incorporated in the Power
Cord for the Areas of AC 120V (USA) and AC 220 ~
240V, and therefore, this procedure is not necessary.
4
Firmly insert the power plug into the
socket outlet.
Insert the opposite side of Power Cord
plug to the AC Unit's connector ("INLET").
5
Perform wiring for the Power Cord
and Earth Wire. Install protective
covering for the Power Cord and
Earth Wire.
Connect the Earth Wire
to the Earth Terminal.
FIG. 6. 5 b Earth Wire Connection
HOW TO USE THE CORD CLAMP
Wiring Cover
FIG. 6. 5 c Connecting Power Cord and Earth Wire
In case the Power Plug is apt to come out of place, secure the
Power Cord to the periphery of the AC Unit with the Cord Clamp
(an accessory).
15
www.seuservice.com
Loading...
