Page 2
200
Securitron PSM Power Supply Monitor
Power
Dimensions Specifications
4"
[10 2m m]
12"
[30 5mm]
Electrical
• Voltage: VDC power from
corresponding power supply
• Current Draw
— 250 mA at 12 VDC
— 200 mA at 24 VDC
Environmental
• Operating Temperature: 32˚ to 105˚F [0 to 40˚C]
Shipping Weight
• 5 lbs [2.27kg]
9"
[22 9m m]
US assaabloyesh.com | 800.626.7590 | customerservice.esh@assaabloy.com
Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com
Copyr ight © 2019, Hanche tt Entr y Systems , Inc., an A SSA ABLOY Group c ompany. All r ights re served . Reproduc tion
in whol e or in part w ithout the e xpress w ritten p ermissio n of Hanchet t Entry Sy stems, Inc . is prohibi ted.
Updated 5/31/19 Patent pending and/or patent www.assaabloydss.com/patents
Page 3
Securitron® FAR
Fire Alarm Reset
Manual door lock power reset
for code compliance
201
Power
Provides functionality
beyond a standard fire
trigger relay when local
code requires manual
reset after a fire alarm.
This self-contained unit interfaces to a fire alarm
unit to cut power to devices downstream of the
power supply in an alarm situation. The power
stays off until the Securitron FAR’s Keyswitch
is manually reset. This feature is required by
some jurisdictions to prevent the unintentional
re-arming of doors until the fire alarm is reset
and power is restored to the access control
system during an ongoing emergency.
Securitron FAR shown with BPS and Fire Alarm
FAR-12,24
F1
F2
R#
BPS Power
Supply
F1
F2
FA
FA
-
Terminal
Strip
Fire alarm
interface
(latching
auxiliary
relay)
Features
Standard Features
• Key switch for manual reset
capability where required by code
• Enables manual cut-off of
power for testing and other
emergency situations
• Simple bi-color, LED status indicator
for easy-to-read power status
• Easy-to-mount metal enclosure
equipped with securit y cam lock
• CFAR version available to meet
Canadian fire release requirements
• Select 12 VDC unit or 24 VDC unit to
match power supply output voltage
• 5A-rated SPDT plunger switches
• MagnaCare
no-fault, no questions asked warranty
®
lifetime replacement,
Dimensions
2.5"
[63m m]
5.25"
[133 m m]
5.25"
[133 m m]
Specifications
Dimensions
• Contact: 3/4"H x 4-1/4"L x 3/4"D
[19mm H x 101mm L x 19mm D]
• Switch: 1-1/2"H x 4-1/4"L x 3/4"D
[38mm H x 108mm L x 19mm D]
Electrical
• Main Output: SPDT at max of
125 mA at 24 VDC; 250 mA at 12 VDC
• Tamper Output: Closed when secure;
open to alarm—1A max current
Environmental
• Operating Temperature:
-40˚ to 150˚F [-40˚ to 65˚C]
Shipping Weight
• 1.5 lbs [0.68 kg]
Part Number | Description
FAR-12
FAR-24
Fire Alarm Reset Control—12 VDC
Fire Alarm Reset Control—24 VDC
