SEAV LRX 2035 Reader User Manual

ELECTRONIC PANEL

GB

LRX 2035 READER

Mono-phase electronic control unit, for the automation of sliding
doors and rolling shutters with incorporated radio receiver and
the possibility of connecting to 1 or 2 BeSAFE Proximity
Readers to carry out proximity controls by means of BeSAFE
CARD and BeSAFE KEY transponders.

- Mod. LG 2035 READER : Without Radio Receiver

- Mod. LRS 2035 READ : 433.92 MHz

- Mod. LRS 2035 READER SET : 433.92 MHz “narrow band”

- Mod. LRH 2035 READER : 868.35 MHz “narrow band”

TECHNICAL DATA:

- Power supply : 230 Vac 50Hz 4.5W max.

- Flashing light output : 230 Vac 50Hz
100W Resistive Load max.
50W Inductive Load max.

- Motor output : 230 Vac 50Hz 750 W max.

- Aux. power supply output : 24 Vac 3 W max.

- Button and safety device input :24 Vdc

- Working temperature : -10 ÷ 55 °C

- Radio receiver :see model

- Transmitter type : 12-18 Bit, or Rolling Code

- Transponder type : BeSAFE CARD / KEY

- N. of devices that can be stored :63 Max.

- Dimension of panel :110x121x47 mm.

- Container : ABS V-0 (IP54).

C

ONNECTIONS OF THE

1 : 230 Vac input (phase).
2 :230 Vac input (Neutral)
3 :230 Vac flash input (Neutral)
4 : 230 Vac flash input (phase).
5 : Opening motor output
6 : Common motor output.
7 : Closing motor output.

C

ONNECTIONS OF THE

1 :24 Vac 3 W service power supply output.
2 :24 Vac 3 W service power supply output.
3 : Open-close push button input (NA).
4 : Common GND input.
5 : Safety device input (NC).
6 : Antenna earth input.
7 : Antenna hot pole input.

C

ONNECTIONS OF THE

1: Reader power supply + VDC
2: Reader reception 1
3: Reader transmission 1
4: GND power supply

C

ONNECTIONS OF THE

1: Reader power supply + VDC
2: Reader reception 2
3: Reader transmission 2
4: GND power supply

I

NSTALLATION OF PROXIMITY READER

1 or 2 "BeSAFE Reader" proximity readers can be connected to
the control unit.
The BeSAFE proximity reader is supplied inside of a container
highly resistance to water and atmospheric agents. Use a
shielded cable no longer than 15 meters for good operation
between the BeSAFE Reader and the LRX 2035 Reader
control unit.
The bottom part of the Reader where the antenna is placed
must be free from obstacles and placed in easily visible points
to facilitate use.

CN1 T

CN2 T

CN3 T

CN4 T

ERMINAL BOARD

ERMINAL BOARD

ERMINAL BOARD

ERMINAL BOARD

O

PERATING FEATURES

:

Step by step operation:

By using the low tension button panel to operate the frame
and/or proximity controls by means of BeSAFE CARD and
BeSAFE KEY transponders, commands will have the following
effect: The first command impulse activates the opening
mechanism until time expiry of the timing motor or the end run
is reached. The second command impulse closes the frame. If
a command impulse is received before end run is reached, the
control unit will halt both opening and closing motions. A
further input implements the re-starting of the motion in the
opposite direction.

Operation with different radio control models:

It is possible to program different radio control models:
memorising one code (1 button) Step by Step cyclical
functioning is obtained (Open - Stop - Close); memorising two
different codes (2 button) obtains distinct commands. The first
to Open and the second to Close. Memorising three different
codes (3 “BeFree” buttons) obtains distinct commands: the first
to Open, the second to Stop and the third to Close.

Operation with 1 button radio control:

Using the radio control with only one button, the following
operation is obtained: the first impulse commands Opening

until time expiry of the timing motor. The second impulse
commands Closing of the frame. If an impulse is given before
the motor time expires, the control unit stops the frame. A
further input implements the re-starting of the motion in the
opposite direction.

Operation with 2 button radio control:

Using the radio control with two buttons, the following operation
is obtained: the first button (“Up” associated to Opening)
commands Opening until time expiry of the timing motor and
the second button (“Down” associated to Closing) commands
the Closing of the frame. If the an Up command is given again
during Opening, the control unit continues the Opening motion,
while if a Down command is given, the control unit stops
motion.
The same procedure is valid during the Closing phase.

Operation with 3 button radio control (BeFree series):

Using the BeFree radio controls, the following operation is
obtained: the Up button commands opening until time expiry of
the timing motor, the Stop button commands stopping and the
Down button commands the closing of the frame. If during
opening or closing a Stop command is given, the control unit
commands the frame to stop. If during opening or closing the
command opposite the present motion is given, the control unit
commands to run in the opposite direction.

Automatic closing:

The control unit closes the frame automatically without sending
other commands.
Choice of this operating mode is described under the
instruction for setting the delay period.

Safety device:

The control unit allows for the connection and control of
Photocells, Tyre sensors (NC).
Command from these devices is ignored during opening whilst
when the frame is closing they will reverse the direction of
movement.
If not used the terminals must be jumped.

PROGRAMMING:

SEL button: selects the type of function to be memorised. The

selection is indicated by a flashing LED.
By repeatedly pressing the button it is possible to choose the
desired function. The selection will remain active for 10
seconds indicated by a flashing LED. If no other operations are
executed during this period, the control board will return to its
previous state.
SET button: programs the information relative the type of
function previously selected with the SEL button.

LED Reference LED Off LED On

1) CODE No code Device activated

2) LAMP/CORT. Flashing Courtesy Light

3) T. MOT. Unlimited timing Programmed delay

4) T. PAUSE. No automatic close With automatic close

1) CODE: (Programming of the Radio controls and/or
Transponder)

The control unit can memorise up to 63 different radio
commands or Transponders.

Programming BeSafeCard/Key transponders:

The transponders are programmed as follows: press the SEL
button. The CODE LED will start to flash and at the same time
bring the transponder closer to the “BeSAFE Reader” proximity
reader. The CODE LED will remain on for an instant signalling
the memorisation. Afterwards the CODE LED will continue to

flash for 10 seconds waiting for another transponder to be
memorised, after which it will exit programming mode.

Programming of 1 or 2 button radio commands.

The transmission code is programmed in the following manner:
press the SEL button until the LED CODE flashes. At the same
time transmit the first code of the remote control (“Up”
associated to opening). As soon as the LED CODE begins to
flash rapidly, send the second code to be memorised (“Down”
associated to closing). The CODE LED will remain lit and the
programming is complete. If the second code is not sent within
10 seconds, the control unit will exit the programming phase
and select the function with only one button of the remote
control.

Programming the 3 button “BeFree Series” remote control.

The control unit can memorise the whole “BeFree” radio control
by programming only the UP button.
Code programming of the “BeFree” radio controls is carried out
in the following manner: press the SEL button until the LED
CODE flashes. At the same time press the UP button of the
desired radio control. The CODE LED will remain on and the
programming is complete.
Cancellation: Cancellation of all memorised devices is
carried out in the following manner: press the SEL button and
the LED CODE will start to flash. Then press the SET button.
The procedure is now complete and the LED CODE will stop
flashing.

Device already in memory or not compatible warning:

The control unit can memorise up to 63 devices with different
codes. If the user attempts to perform the programming
procedure for a device which is already stored in the memory or
which is not compatible, the CODE LED will begin to flash
rapidly for a few moments, to indicate that this procedure
cannot be performed. The unit then returns to the programming
stage once again.

Maximum number of devices which can be stored:

The control unit can memorise up to 63 devices with different
codes. If the maximum number of devices has been reached
and a programming process started, the control unit will
indicate that it has failed by flashing all the LEDs except the
CODE LED which will remain lit in a constant manner. After 10
seconds the control unit exits programming mode.

2) LAMP/CORT: (Selection of the flashing light or the courtesy
light)

The control unit has a 230 Vac output, for connection to a
flashing light or a courtesy light.
The control unit is supplied by the manufacturer with the
flashing function even with delay enabled. If you wish to set up
the flashing light function, proceed as follows: use the SEL
button to navigate to the LAMP/CORT LED when flashing and
then press the SET button. The LAMP/CORT button will light up
permanently.
Repeat the operation if you wish to put the previous
configuration back into operation.
If you wish to set up the courtesy light, repeat the operation
described above, pressing the SEL button twice instead of
once (the LAMP/CORT LED will flash rapidly). Repeat the
operation if you wish to put the previous configuration back into
operation.

Flashing Light function even in delay: The 230 Vac
output will be activated each time that the automation is
moving, for the duration of the motor time. If the delay period is
memorised, the 230Vac output will be active even during the
delay.
Flashing function: The 230 Vac output will be activated
each time that the automation is moving, for the duration of the
motor time.
Functioning of the Courtesy light: The 230 Vac output will be
activated for 3 minutes, each time that an opening command is
given

C) T. MOT. Flashing light ON/OFF alternated

lashing light ON/OFF alternated

Operator present CH = OFF Operator present CH = ON

3) T. MOT. (Programming the motor operating time max. 4
minutes)

The control unit is factory supplied with a predefined working
time motor equal to 30 sec.
If a reprogramming of the motor operating time is needed, it
must be carried out through the closed frame in the following
manner: use the SEL button to navigate to the T. MOT LED
when flashing, then continuously press the SET button. The
rolling shutter will start the opening. When you have reached
the required height, release the SET button and at the same
time the motor time storage will be completed and the T. MOT.
LED will remain lit and fixed. If you want an infinite motor time,
use the SEL button to navigate to the T.MOT LED when
flashing and press the SET button for less than 1 second. At
the same time the LED will shut off and the operation will be
completed. It is advisable to memorise a time that is a few
seconds longer after the frame has reached the end.

4) T. PAUSE:

(Maximum programmed automatic closing 4 minutes.)

The manufacturer furnishes the control unit with an automatic
closure (pause time equal to 15 sec.). If a reprogramming of
the automatic closing time is needed, it must be carried out
through the closed frame in the following manner: use the SEL
button to navigate to the T. PAUSE LED when flashing. Then
press and hold down the SET button for a period equal to the
desired pause interval between closing and opening
operations. At expiration of the desired time release the SET
button. At the same time the memorisation of automatic closing
time will be determined and the T. PAUSE LED will remain lit.
If you do not want automatic closing, take position on the T.
PAUSE LED when flashing. Then press the SET button for less
than a second. At the same time the LED will shut off and the
operation will be concluded.

EXTENDED MENU 1

The control unit is supplied by the manufacturer with the option
of selecting only the functions listed in the main menu.
To enable the functions of extended menu 1, proceed as
follows: press and hold the SET button for 5 seconds; the T.
MOT. and T. PAUSE LEDs will start flashing alternately. The
user then has 30 seconds in which to select the extended
menu 1 functions using the SEL and SET buttons. After 30
seconds the control unit returns to the main menu.

---------------------- EXTENDED MENU 1 -----------------

LED Reference LED Off LED On

A) CODE remote PGM = OFF remote PGM = ON
B) LAMP/CORT Step by step Automatic

D) T. PAUSE. F

A) CODE
(Remote programming of radio control):

The control unit allows the transmission code to be
programmed remotely, without using the SEL button on the unit
itself.
To program a transmission code remotely, proceed as follows:
send the previously memorised radio control code continuously
for more than 10 seconds; the control unit will enter the
programming mode as described above for the CODE LED in
the main menu.
The control unit is supplied by the manufacturer with remote
programming of a transmission code not enabled; to enable the
function proceed as follows: check that the extended menu 1 is
enabled (T. MOT. and T. PAUSE LEDs start flashing
alternately), use the SEL button to navigate to the CODE LED
when flashing and press the SET button: the CODE LED

remains lit in a constant manner and programming is complete.
Repeat the procedure to restore the previous configuration.

B) LAMP/CORT. (

The control unit is supplied by the manufacturer with the
Automatic mode disabled. If you wish to enable the function,
proceed as follows: check that the extended menu 1 is enabled
(T. MOT. and T. PAUSE LEDs start flashing alternately), use
the SEL button to navigate to the LAMP/CORT LED when
flashing and press the SET button: press the SET button: the
LAMP/CORT LED remains lit in a constant manner and
programming is complete.
In this way, by using the low tension button panel to operate the
frames and/or proximity controls by means of BeSAFE CARD
and BeSAFE KEY transponders, commands will have the
following effect: the first command impulse activates the
opening mechanism until time expiry of the timing motor. The
second command impulse closes the frame. If an impulse is
sent before time has expired, the control unit will reverse
motion direction both for opening and closing. Repeat the
procedure to restore the previous configuration.

Step by Step / Automatic operation

):

EXTENDED MENU 2

The control unit is supplied by the manufacturer with the option
of selecting only the functions listed in the main menu.
To enable the functions of extended menu 2, proceed as
follows: access extended menu 1 (as described in the
corresponding paragraph), then press the SET button again
and hold for 5 seconds; the T. MOT. and T. PAUSE LEDs will
flash simultaneously: the user has 30 seconds within which to
select the functions of extended menu 2 using the SEL and
SET buttons. Then after a further 30 seconds the control unit
returns to the main menu.

---------------------- EXTENDED MENU 2 -----------------

LED Reference LED Off LED On

A) CODE Anti-Pass-Back = OFF Anti-Pass-Back = ON
B) LAMP/CORT
C) T. MOT. Flashing light ON/OFF simultaneous
D) T. PAUSE. Flashing light ON/OFF simultaneous

A) CODE (Anti-Pass-Back):

The control unit is supplied by the manufacturer with the Anti­pass-back function disabled. If you wish to enable the function,
proceed as follows: check that the extended menu 2 is enabled
(T. MOT. and T. PAUSE LEDs start flashing simultaneously),
use the SEL button to navigate to the CODE LED when
flashing and press the SET button: the CODE– LED remains lit
in a constant manner and programming is complete. In this
manner the control unit will operate in Antipassback mode,
which means alternated functioning of Readers 1 and 2
(passage to reader 1 will be allowed only after having passed
by reader 2 and vice versa).
Repeat the operation if wanting to restore the previous
configuration.

B) LAMP/CORT (

The control unit is supplied by the manufacturer with the user
present while closing function disabled. If you wish to enable
the function, proceed as follows: check that the extended menu
2 is enabled (T. MOT. and T. PAUSE LEDs start flashing
simultaneously), use the SEL button to navigate to the
LAMP/CORT LED when flashing and press the SET button: the
LAMP/CORT LED remains lit in a constant manner and
programming is complete. In this manner the control unit while
operate in User present while closing mode. The input controls
for Ascent (PUL = Step by step) and Descent (D.S. = User
present) will be modified with the Normally Open operation.
Repeat the operation if wanting to restore the previous
configuration.

User present while closing function)

:

RESET:

To reset the default configuration of the control unit, press the
SEL and SET buttons simultaneously; all RED indicator LEDs
will switch on and then off again immediately.

DIAGNOSTIC:

In correspondence to each low voltage PUL e DS input
command, the control unit uses LED signals allowing rapid
status control. Functioning logic: a lit LED means input closed,
an unlit LED means input open.

I

MPORTANT FOR THE INSTALLER

The control unit was designed to be assembled together with
other components (motor, shutter or gate, safety devices) to
constitute a finished product (machine) in compliance with
Machinery Directives.
The safety of the final installation and the compliance with all
prescribed Standards is the responsibility of the person who
assembles the various parts to construct a total closing.

It is also advised to comply with the following

recommendations:

− Before automating the frame, check that it is in good
conditions, in compliance with the Machinery Directive
and with EN 12604.

− Wiring of the various electrical components outside of the
control unit must be carried out in compliance with that
prescribed in Standard EN 60204-1 and its amendments
at point 5.2.7 of EN 12453. Power supply and connection
cables must be fixed using the cable glands provided.

− The gearmotor used to move the frame must comply with
that prescribed at point 5.2.7 of EN 12453.

− Mounting of a push button panel for manual control must
be done positioning the push button panel where the
user is not in a dangerous position, in compliance with
point 5.2.8 of EN 12453.

− The control unit does not have any type of isolating
device for the 230 Vac line. It will therefore be the
responsibility of the installer to arrange an isolating
device inside the plant. It is necessary to install a mono­phase switch with over-voltage category III. It must be
positioned where it can be protected from accidental
closing, according to that prescribed in point 5.2.9 of EN

12453.

− In compliance with 5.4.2 of EN 12453, it is recommended
to use gearmotors equipped with an electric-mechanical
release device, so that the door can be moved manually
in case of necessity.

− In compliance with 5.4.3. of EN 12453, use electric-
mechanical release systems or similar devices which
stop the door safely in the end run position.

− Cables for power and connection to the motor suitable for
insertion in the pg9 cable glands provided must have an
outside diameter between 4.5 and 7 mm. The internal
conductor wires must have a nominal section of

0.75mm

− Fix a warning sign near the place of installation, conform
with ISO 3864, with minimum height of 60 mm.

− When installation is complete, carry out all the controls
prescribed by EN 12453 - EN 12445 to be sure that the
closing complies with the provisions.

− For a correct functioning of the radio receiver, if using one
or more control units, the installation at a minimum
distance of at least 3 metres one from the other is
recommended.

2.

If a raceway is not used, use H05RR-F cables.

I

MPORTANT FOR THE INSTALLER

- The device must never be used by children or persons with
reduced physical-psychological abilities, unless supervised or
trained on the functioning and the use modalities.

- Do not allow children to play with the device and keep the
radio-controls away from their reach.

- Ensure there is no one immediately near-by as the door is not
fully open or closed.

- ATTENTION: keep this instruction manual and respect the
important safety prescriptions contained herein. The non
compliance with the prescriptions may cause damages and
serious accidents.

- Frequently examine the plant to detect any signs of
damaging. Do not use the device if a repair intervention is
necessary.

Attention

All operations which require the opening of the casing (cables
connection, programming, etc.) must be carried out by expert
personnel during installation. For any further operation which
requires the casing to be re-opened (re-programming, repair or
installation amendments) contact the after-sales assistance.

The products:

Electronic control unit:

LG 2035 READER - LRS 2035 READER

LRS2035 READER SET - LRH 2035 READER

comply with the specifications of the Directives

R&TTE 99/5/EC, EMC 2004/108/EC, LVD 2006/95.

Rev. 1.2 of 15-05-12
