BESMART RADIO CONTROL
Radio control with Random 18-bit transmission
codes and the ability to copy existing codes from
other radio controls in the same series. It may be
used in conjunction with other transmitters in the
same series and integrates perfectly with all
SEAV receivers and electronic control units.
- Mod. BeSmart S2: two channels 433.92MHz
- Mod. BeSmart S4: four channels 433.92 MHz
- Mod. BeSmart H2: two channels 868,30 MHz
- Mod. BeSmart H4: four channels 868,30 MHz
GB
TECHNICAL DATA
- Alkaline battery powered : 12V mod.23A
- Operating frequency : 433.92 MHz
- Combinations : 262144
- Max. consumption : 25 mA
- Operating temperature : -20 to +55 °C
- Dimensions : 75x38x15 mm.
OPERATING DESCRIPTION
Depending on the model, the radio control is
equipped with 2 or 4 buttons that are used to
control 2 or 4 different functions.
INITIAL OPERATING CONDITION
The radio control is supplied with default random
codes.
OPERATION
Creating a new random code (Reset):
The radio control is supplied with default random
codes. If you want to create a new set of random
codes, follow the RESET process: press the two
buttons (the top and bottom buttons on the 4channel model and the only two buttons on the 2channel model) simultaneously and hold them for
10 seconds. After the LED lights up, press the
same two buttons within 3 seconds. The LED will
flash 3 times to indicate that the process is
complete.
WARNING! The RESET process completely
deletes the default codes.
Copying all the information in the radio
control:
It is only possible to copy all the transmission
codes to the radio control from other devices if
they are the same model.
To copy all the information between radio
controls, proceed as follows: remove the cover on
the back of the transmitter to provide access to
the relevant connector. connect the two radio
controls with the cable supplied as “optional”
(programming cable CP2195), press any button
on the control supplying
for 4 seconds. The LED on the control receiving
the information will flash 3 times to indicate that
the operation is complete.
WARNING! The default configuration of the radio
control has no password protection, it is therefore
possible to copy all information. In cases where
the control is supplied with an active password it
will not be possible to carry out the copying
process.
Other functions using a PC:
The radio control can be connected to a Personal
Computer using the “SW 2188” software package
which is supplied as optional and enables you to
utilise further functions.
Other functions using a Programmer:
The radio control can be connected to a “PGM
2191” portable Programmer which is supplied as
optional and enables you to utilise further
functions.
information and hold it
WARNING
− The battery should be replaced every year to
guarantee the optimal transmitter range.
− To replace an exhausted battery, remove the
plastic cover on the back of the radio control, take
the battery out and replace it with a new one,
observing the correct battery polarities.
− Used batteries should be discarded in special
collection bins.
IMPORTANT REMARKS
Changes or modifications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate the equipment.
DECLARATION OF CONFORMITY
SEAV s.r.l. hereby declares that the product
below
BeSmart Radio control
complies with the provisions set forth in the
EC/99/5 directive based on the following
standards:
EN 301489-3; EN 300 220-3; EN 60950
The sample tested meets the essential
requirements specified above.
Rev. 1.0 05/04/05
FCC ID: QUS-BESMART
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Rev. 1.0 05/04/05
