R
GB
ADIO CONTROL
BEH
APPY SERIES
Radio control with 12 bit code transmission.
- Mod. BeHappy S 1 New : one channel
- Mod. BeHappy S 2 New : two channels
- Mod. BeHappy S 3 New : three channels
T
ECHNICAL CHARACTERISTICS
- Powered by a lithium battery: 3Vdc (CR 2032)
- Working frequency: 433,92MHz
- Combinations: 12 bit
- Maximum consumption: <20mA
- Working temperature: -10÷55°C
- Dimensions: 33x69x13mm
D
ESCRIPTION OF FUNCTIONING
The transmitter, according to the model, is complete with
either 1, 2 or 3 buttons for the management of either 1, 2 or 3
different uses.
“S“ NEW
PROGRAMMING
By pressing the 10 micro-switches of the Dip-Switch SW1,
moving them to the “ON” or “OFF” position, the desired code
may be selected. Such a code must correspond to the code
which has been memorised on the receiver. (The standard
factory configuration: uneven “ON”).
WARNING
−−−− The lithium battery 3 Vdc (CR2032) must be changed
every two years in order to guarantee the correct
functioning of the transmitter.
−−−− In order to substitute the dead batteries, follow the
illustration.
−−−−
The used battery must be disposed of correctly in an
appropriate recycling bin.
SEAV s.r.l. declares that the products:
Radio control
BeHappy S1 New, S2 New, S3 New
Comply with the fundamental requirements of the Directive
R&TTE 99/5/EC.
-1- Rev. 1.1 09/03/11
