Page 1
GT4e
Series
INDUSTRY VERTICALS
• Manufacturing
• Logistics
• Transportation
• Automobile
• Retail
• Government
APPLICATIONS
• Asset Tracking
• Warehouse Management System
• Logistic Tracking
• Retail Labelling
• Laboratory High-Resolution
Labelling at 609dpi
RFID-ready
No PC required
Tri-interface port for various connectivity
Large LCD display with graphical icons for
user-friendly operation
Easy-to-navigate menu options
609dpi high resolution printing
Engineered to Redefi ne
High Performance
Industrial Printing
Engineered to Redefi ne
High Performance
Industrial Printing
Page 2
General Specifi cations
PRINTER MODEL GT408e GT412e GT424e
GT4e
SI/GT4e/0808/1.1
Specifi cations might vary from region to region and are subject to change without notice. The acronyms used to identify the programming languages of non-SATO products may be the property of the respective
companies and are used here to identify their various programming languages. It is used only for explanation without intent to infringe and SATO makes no claims to the authenticity of their command language or functionality.
INTERNATIONAL HEADQUARTERS
SATO INTERNATIONAL PTE. LTD.
438A Alexandra Road #05-01/04,
Alexandra Technopark, Singapore 119967
P: +65 6271 2122 F: +65 6271 2151
E: [email protected]
W: www.satoworldwide.com
AMERICAS
SATO INTERNATIONAL AMERICA, INC.
(Regional HQ)
P: +1 704 644 1650
E: [email protected]
W: www.satoamerica.com
SATO AMERICA, INC.
P: +1 704 644 1650
E: [email protected]
W: www.satoamerica.com
SATO LABELING SOLUTIONS AMERICA, INC.
P: +1 630 771 4200
E: [email protected]
W: www.satolabeling.com
SATO FRANCE S.A.S.
P: +33 (0)3 20 62 96 40
E: [email protected]
W: www.satoeurope.com/fr
SATO IBERIA S.A.
P: +34 902 333 341
E: [email protected]
W: www.satoeurope.com/es
ASIA PACIFIC AND OCEANIA
SATO INTERNATIONAL ASIA
PACIFIC PTE. LTD. (Regional HQ)
P: +65 6271 5300
E: [email protected]
W: www.satoworldwide.com
SATO ASIA PACIFIC PTE. LTD.
P: +65 6271 5300
E: sales@satoasiapacifi c.com
W: www.satoasiapacifi c.com
SATO AUTO-ID MALAYSIA SDN. BHD.
P: +60 3 7620 8901
E: [email protected]
W: www.satoasiapacifi c.com
SATO AUTO-ID (THAILAND)
CO., LTD.
P: +662 736 4460
E: [email protected]
W: www.satoasiapacifi c.com
SATO SHANGHAI CO., LTD.
P: +86 (021) 6306 8899
E: [email protected]
W: www.satochina.com
SATO AUSTRALIA PTY LTD.
P: +61 3 8814 5330
E: [email protected]
W: www.satoaustralia.com
SATO NEW ZEALAND LTD.
P: +64 9 477 2222
E: [email protected]
W: www.satonewzealand.com
For a full list of all SATO offi ces, refer to www.satoworldwide.com
Contact
EUROPE
SATO INTERNATIONAL EUROPE N.V.
(Regional HQ)
P: +32 (0)2 788 80 00
E: [email protected]
W: www.satoeurope.com
SATO UK LTD.
P: +44 (0) 1255 2400 00
E: [email protected]
W: www.satouk.com
SATO LABELLING SOLUTIONS EUROPE GmbH
P: +49 6272 9201 324
E: [email protected]
W: www.satoeurope.com/de
SATO POLSKA SP. Z O.O.
P: +48 71 381 03 60
E: [email protected]
W: www.satoeurope.com/pl
PRINTING SPECIFICATIONS
Print Method Direct Thermal/Thermal Transfer
Print Resolution 8 dots/mm (203dpi) 12 dots/mm (305dpi) 24 dots/mm (609dpi)
Max Print Speed 300mm/sec (12ips) 300mm/sec (12ips) 150mm/sec (6ips)
Max Print Area Max (W x P): Max (W x P): Max (W x P):
104 x 2500mm (4.1” x 98.4”) 104 x 1500mm (4.1” x 59.1”) 104 x 400mm (4.1” x 15.7”)
MEDIA SPECIFICATIONS
Sensor Type Refl ective Sensor (for use with pre-printed marks), Adjustable See-Through Sensor (for die-cut labels with gaps)
Media Thickness Label thickness (With backing liner): 0.06 to 0.268 mm (0.002” to 0.01”)
Media Size Width: 22 ~ 128mm (0.87” ~ 5.04”). With paper backing, 25 ~ 131mm (1” ~ 5.16”)
Pitch: 5 ~ 397mm (0.2” ~ 15.63”). With paper backing, 9 ~ 400mm (0.35” ~ 15.74”)
Media Roll Outer Diameter Max external diameter 265mm (Paper core size: 1.5”, 3”, 4”)
Wind Direction For Face-in and Face-out (Face-out is for linerless labels only)
CONSUMABLES SPECIFICATIONS
Ribbon Size Width Max: 128mm (5.04”)
Length Max: 450m
Winding Direction Face-in and Face-out
MEMORY/PROCESSING
Main Memory Flash-ROM: 6MB
CPU 32 bit RISC
COMMUNICATION INTERFACES
Standard Interface Plug In Interface Cards: RS-232C, High-speed RS-232C, USB, IEEE 1284, LAN,
Centronics, RS-422/485 or Wireless LAN
Optional Mini LAN
External Port 14-pin connector, 25-pin connector
FONTS/BARCODE SYMBOLOGIES
Standard Fonts U, S, M, WB, WL, XU, XS, XM, XB, XL, OUTLINE, OCR-A, OCR-B
TrueType Fonts CG Times, CG Triumvirate
Barcodes 1D Barcode UPC-A/E, JAN/EAN, CODE 39, CODE 93, CODE 128, UCC/EAN 128, NW-7, Customer Barcode, MSI,
Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, BookLand, POSTNET, RSS-14
2D Barcode QRCode (Chinese QR and Korean QR are individually operated), PDF 417 (Including Micro PDF417),
MAXI Code, Data Matrix, Composite Symbology (Compatible with CC-A/B/C by UPC-A/E, JAN/EAN,
CODE 39, CODE 128, RSS-14)
Character Rotation 0º, 90º, 180º, 270º rotation
OPERATING & ENVIRONMENTAL
Power Consumption Max: 200VA / 200W (Standby: 62VA / 89W)
Power Supply Current AC 100 - 240 V
Dimensions (W x D x H): 271 x 455 x 305mm (10.67” x 17.9” x 12”)
Weight Approx. 15kg
Temperature / Humidity Usage Environment: 0 ~ 40ºC / 30 ~ 80%RH (Non condensing)
Storage Environment: -5 ~ 60ºC / 30 ~ 90%RH (Non condensing)
ACCESSORIES & OPTIONS
Special Options Cutter, Dispense Unit (with Backing Paper Rewinder), Dispenser, Internal Rewinder, Linerless Kit,
RFID Kit, Real Time Clock
Memory Cartridge Extended Flash Memory Board (24MB)
