Sanyo DWM-2500 User Manual

INSTRUCTION MANUAL

DVD Home Theater System

DWM-2500

SANYO'S HELP-LINE

Call the toll-free number below if you have any difficulties operating this product. 1-800-813-3435 (Weekdays: 7:30 AM - 4:00 PM Central Time)

1AD6P1P1839-- DWM-2500, Issue Number 1

English

CONTENTS

Accessories........................................................................... E2

Safety Certification ................................................................ E3

For Safe and Efficient Operation........................................... E3

Controls................................................................................. E4

Multi-Brand TV Remote Control............................................ E5

Basic Connections ................................................................ E7

Speaker Connections ...................................................... E7

Speaker Placement ......................................................... E8

TV Connections............................................................... E9

Antenna Connections .....................................................E1 1

Additional Connection Examples....................................E11

Power Supply ................................................................. E11

Before Operation................................................................. E12

Common Operation ....................................................... E12

Selecting Surround Mode.............................................. E13

Adjusting the Speaker Volume Balance ........................ E14

Adjusting the Subwoofer Level...................................... E14

Playable Discs..................................................................... E15

Disc Playback...................................................................... E16

Preparations .................................................................. E16

Basic Playback .............................................................. E16

Stopping Playback......................................................... E17

Continuing Playback from Where You Stopped

Watching (LAST MEMO PLAY), for DVD only............... E17

Selecting a DVD Menu .................................................. E18

Selecting a Top Menu [DVD] ......................................... E18

Chapter (Track) Skip ..................................................... E18

Title Search [DVD]......................................................... E19

Chapter Search [DVD]................................................... E19

Time Search [DVD]........................................................ E19

Time Search [CD].......................................................... E19

Track Search [CD]......................................................... E19

Fast Playback................................................................ E20

Slow Motion Playback [DVD]......................................... E20

Still Picture (Pause)....................................................... E20

Frame by Frame Advance Playback [DVD]..................... E20

Picture Zoom (Pin Point Zoom) [DVD] .......................... E21

Viewing from a Desired Camera Angle

(Multi-Angle) [DVD] ....................................................... E21

Angle Replay ................................................................. E21

Repeat Playback ........................................................... E22

Designated Range Repeat Playback (A-B Repeat) ...... E22

Random Playback [CD] ................................................. E23

Programmed Playback [CD].......................................... E23

Selecting Subtitle Language [DVD] ............................... E24

Selecting Audio Soundtrack Language

(Multi-Language) [DVD]................................................. E24

Selecting On-Screen Information .................................. E25

Selecting Picture Mode ................................................. E25

TVGuardian Operation........................................................ E26

Before Setting................................................................ E26

Setting TVGuardian....................................................... E26

How It Works After Setting TVGuardian ........................ E27

MP3/WMA CD Operation .................................................... E28

Before Starting .............................................................. E28

MP3/WMA CD Playback................................................ E28

Stopping Playback......................................................... E29

Pause ............................................................................ E29

File Skip......................................................................... E29

Repeat Playback ........................................................... E29

Picture Disc Operation ........................................................ E30

Kodak Picture CD Playback .......................................... E30

JPEG CD Playback ....................................................... E31

Picture Zoom ................................................................. E31

Initial Settings...................................................................... E32

Setting Language .......................................................... E32

Setting Display .............................................................. E32

Setting Audio ................................................................. E33

Setting Parental............................................................. E34

Language Code List ...................................................... E35

Enjoying Video Sources...................................................... E36

Listening to the Radio ......................................................... E36

Automatic/Manual Tuning.............................................. E36

To Preset Stations ......................................................... E36

Listening to Preset Stations........................................... E37

Sleep Timer Operation ........................................................ E38

Maintenance ....................................................................... E38

Troubleshooting Guide........................................................ E39

Specifications ...................................................................... E40

Warranty.............................................................................. E41

Please Read This Manual.

Because DVD is a new technology, we recommend that you read this manual carefully before connecting your DVD Home Theater System and operating it for the first time. Keep the manual in a safe place for future reference.

IMPORTANT INFORMATION:

To connect this DVD Home Theater System to a TV, TV must have a Video input jack (RCA-type) at least. You cannot connect it to an antenna terminal of TV.

To operate the built-in TVGuardian

This unit has the built-in TVGuardian® Foul Language Filter (TVG®). When a disc supporting closed caption is played, it will mute the audio during the entire phrase containing offensive language. For more details, see page E26.

-E1-

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit.

CAUTION: TO PREVENT THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

ACCESSORIES

RB-TS760MT wireless remote control

REMOTE CONTROL RB-TS760MT

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit.

WARNING: UNAUTHORIZED RECORDING OF COPY-

RIGHTED MATERIAL MAY VIOLATE APPLICABLE COPYRIGHT LAWS. THE MANUFACTURER ASSUMES NO RESPONSIBILITY FOR UNAUTHORIZED DUPLICATION, USE OR OTHER ACTS WHICH INFRINGE UPON THE RIGHTS OF COPYRIGHT OWNERS.

FRONT R

Front right speaker cable Length: Approx. 16.4 feet (5 meters)

Front left speaker cable Length: Approx. 16.4 feet (5 meters)

AM loop antenna

FM indoor antenna lead wire

Video cable

Front center speaker cable Length: Approx. 16.4 feet (5 meters)

Surround right speaker cable Length: Approx. 23 feet (7 meters)

E A

R A E

Surround left speaker cable Length: Approx. 23 feet (7 meters)

SUBW

OOFER

SUBW

Subwoofer speaker cable Length: Approx. 16.4 feet (5 meters)

Note: The speaker cables are packed in the speaker package.

-E2-

SAFETY CERTIFICATION

This unit is made and tested to meet exacting safety standards. It meets UL and FCC requirements and complies with safety performance standards of the U.S. Depart-

ment of Health and Human Services.

CAUTION - USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

THIS UNIT SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.

FCC INFORMATION

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

CAUTION: Changes or modifications not expressly approved by Sanyo may void the user's authority to operate this equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FOR SAFE AND EFFICIENT OPERATION

• Do not damage the power cord.

• When not in use, disconnect the power cord from the outlet.

Grasp the plug, not the cord, when disconnecting the unit.

• If water should enter the unit, electrical shock or a malfunction may result. Use in an area where there is low humidity and little dust.

• Do not disassemble or alter the unit in any way.

• Do not use the unit in areas where extremes in temperature

occur (below 40°F (5°C) or exceeding 95°F (35°C)), or where it may be exposed to direct sunlight.

• Because of the DVD video player extremely low noise and wide dynamic range, there is a tendency to set the volume on the amplifier higher than necessary. Doing so may produce an excessively high output from the amplifier which can cause damage to your speakers. Please be careful in this regard.

• Sudden changes in the surrounding temperature can cause dew to form on the optical pickup lens inside the unit. Under this condition the unit may be unable to operate properly. If this should occur, remove the disc and allow the unit to adjust to the surrounding temperature.

• When carrying the unit, be sure to remove a disc which may be inside and turn the power off. Then unplug the power cord from the AC outlet after 10 seconds. Carrying the unit with a disc inside may damage the disc and/or the unit.

• The unit is automatically set to the Screen Saver mode after approximately 15 minutes have elapsed under the stop or pause mode.

CAUTION:

The unit must be placed in a well ventilated area. Do not place any object on the top of the unit. Do not block ventilation holes. The cabinet of the unit warms up when it is used for a long time, but it is not a malfunction.

Press [q] on the unit (or [OPEN/CLOSE] on the remote control) when closing the disc tray. Do not push the disc tray.

-E3-

2 3 6 7 84 51

11 10 9

CONTROLS

1. Disc tray

2. Open/Close button (q)

3. Function button (FUNCTION)

4. Preset tuning, Skip/Next/Previous buttons (f - PRESET + e)

5. FL display

FL display

3 75

1 102 8 94 6

17 16

PGM ALL REP.1A-

L.M. MP3

1. Dolby Digital indicator (s D)

2. *DTS indicator (DTS)

3. Play indicator (a)

4. Last memory indicator (L.M.)

5. Pause indicator (k)

6. PM3 indicator (MP3)

7. WMA indicator (WMA)

8. Title and Track indicator (T)

9. Message or number indicators (Title, chapter, track, playing time or other information)

WMA

RND

T C

6. Stop button (n)

7. Play button (a)

8. Power button (z/ON)

9. Headphone jack (PHONES)

10. Volume control (VOLUME)

11. Remote sensor (IR)

SLEEP

MONO

111213

10. Sleep timer indicator (SLEEP)

11. FM mono indicator (MONO)

12. FM stereo indicator (ST)

13. Chapter indicator (C)

14. Random play indicator (RND)

15. Repeat mode indicators (ALL, REP., 1, A-B)

16. Program indicator (PGM)

17. Dolby Pro Logic indicator (s PL)

* DVD video disc with DTS may not work correctly. You

can see the picture on the TV screen, but there is no sound. For more details, please refer to “Selecting Audio Soundtrack Language” on page E24.

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.

-E4-

MULTI-BRAND TV REMOTE CONTROL

2 3

6 5

1.Power button (z/ON)

2.Number and other function buttons These buttons are used as number buttons and as function buttons of each name.

• When using as a number button, press the appropriate

button directly.

• When using as a function button of each name, press the

appropriate button while holding the SHIFT button down. Number buttons (1 – 9, 0) Angle button (ANGLE) Angle replay button (A.REPLAY) Zoom button (ZOOM) Audio button (AUDIO) Sleep button (SLEEP)

3.TV control buttons Power button (TV POWER) TV/VIDEO select button (TV/VIDEO) Channel scanning buttons (-TV CH +)

4.Tuner controls FM mode button (FM MODE) Tuner function/Band select button (TUNE/BAND) Tuning buttons (- TUNE +) Preset tuning buttons (- PRESET +)

5.Amplifier controls Surround button (SURROUND) Muting button (MUTE) Bass button (BASS) Sound preset button (SOUND) Function button (FUNCTION) Volume buttons (- VOLUME +)

6.Shift button (SHIFT)

7.Open/Close button (OPEN/CLOSE)

8.Return button (RETURN) (See page E29.)

9.Clear/Trim button (CLEAR, TRIM) Note: At Trimming mode, press the button while holding the SHIFT button down. (See page E14.)

10.Test tone button (TEST) (See page E14.)

11.Menu button (MENU)

12.Directional arrow buttons (o, a, p, b)

13.On-screen display button (ON SCREEN)

14.Play button (a)

15.Stop button (n)

16.Skip/Next/Previous buttons (f, e)

17.Subtitle On/Off button (S.T.ON/OFF)

18.Subtitle change button (S.T.CH)

19. Repeat button (REPEAT)

20.A-B repeat button (A-B REP)

21.Last memory button (L.MEMO)

22.Picture mode/Search mode button (PICTURE MODE/SEARCH MODE) Note: At Search mode, press the button while holding the SHIFT button down.

23.Forward slow button (F.SLOW I a)

24.Reverse slow button (R.SLOW b I)

25.Fast forward/Fast reverse buttons (d, c)

26.Pause/Step button (k)

27.Top menu button (TOP MENU)

28.Enter button (ENTER)

29.Setup button (SETUP)

30.Program/Random play button (PROGRAM/RANDOM)

16 18

17 19

-E5-

Inserting batteries

Two "AA" batteries

(not supplied)

Note: Remove the batteries if the remote control is not to be used for a month or more. Batteries left in the unit may leak and cause damage.

To set the remote control code for TV

This remote control can operate the basic functions of TVs made by the manufacturers listed below. To enter the remote control code for your brand of TV, follow the steps below.

1. In the chart below, find the code corresponding to your brand

2. While holding down [TV POWER], enter the 2-digit code

IMPORTANT NOTE:

SPENT OR DISCHARGED BATTERIES MUST BE RECYCLED OR DISPOSED OF PROPERLY IN COMPLIANCE WITH ALL APPLICABLE LAWS. FOR DETAILED INFORMATION, CONTACT YOUR LOCAL COUNTY SOLID WASTE AUTHORITY.

Remote control range

Remote sensor

Within approx. 20 feet

(6 meters)

30°30°

Notes:

• Only remote-controlled TVs can be operated using this remote

• There may be some TV models that cannot be operated with

of TV . using the number buttons [0 - 9], then release [TV POWER].

• The remote control is now set to operate your TV.

TV brands Code

ADMIRAL 05, 10, 13 EMERSON 17 FISHER 03 GE 07 GOLD STAR 01 HITACHI 02 JVC 15 MAGNAVOX 08 MATSUSHITA 12, 18 MITSUBISHI 14 PANASONIC 12, 18 QUASAR 12, 18 RCA 06 SAMSUNG 16 SANYO 03 SHARP 00, 13 SONY 11 TECHNOL ACE 05 TOSHIBA 04 ZENITH 09, 10

control. (Refer to your TV instruction manual for more details.) this remote control. If this is the case, use the original remote

control supplied with the TV.

IMPORTANT NOTE: If the batteries in the remote control are changed, the code settings for the TV must be re-entered.

Write your code number below for future reference. TV:

-E6-

BASIC CONNECTIONS

Note:

Do not connect the power cord to a 120V AC 60Hz outlet until all connections have been made.

Speaker Connections

To achieve proper stereo reproduction, connect the speaker wires without shorting to adjacent wires as shown below.

Front right speaker Front left speaker Center speaker

Twist and pull it off.

RedBlack RedBlack RedBlack

FRONT R

Red

Label of Speaker Wire Color Tube Use

(Positive Polarity)

FRONT R Red Front right speaker FRONT L White Front left speaker CENTER Green Center speaker REAR R Gray Surround right speaker REAR L Blue Surround left speaker SUBWOOFER Violet Subwoofer

White

Green

FRONT L

CENTER

Green

Violet

FRONT R

Surround right speaker

RedBlack

Gray

FRONT L

Surround left speaker

REAR R

RedBlack

SUBWOOFER

CENTER

SUBWOOFER

INPUT

RedBlack

Blue

REAR L

Gray

REAR R

Blue

REAR L

Subwoofer

-E7-

Speaker Placement

Front left speaker

Subwoofer

Place it near the Front speaker.

Front right speaker

Center speaker

Surround left speaker

Need help? Call

1-800-813-3435

Surround right speaker

The supplied speakers have built-in magnetic stray field compensation. They may be placed close to a TV without affecting the color purity. The five speakers are all the same and can be used for Front left and right, Center, Surround left and right speakers.

The front, center, and surround speakers should be placed at approximately the same distance from the listening position. Place the front left and right speakers either side of the TV. Place the center speaker directly above the TV. Place the surround speakers either sides of the listening position, or slightly to the rear, approximately 2 feet ~ 3 feet 3 inches (60 cm ~ 1 meter) higher than ear level. The subwoofer can be placed near the front speaker and not too far from the TV.

Example: To hang the speaker on a wall

Approximately 3/32 inch

(2.5 mm)

Front left speaker Front right speaker

Subwoofer

Surround left

speaker

Notes:

• The angles in the diagram are approximate.

• Please refer to “Setting Audio” on page E33.

• Set the TV’s built-in speaker volume to minimum.

Example: To mount the speaker with a stand

Stand (not supplied)

Center speaker

30°30°

120°

Surround right speaker

Round head screw (not supplied)

Note: Be careful of dropping the speaker system, it might cause damage or serious injuries.

Machine screw (not supplied)

-E8-

Built-in nut for 3/16 machine screw

COMPONENT VIDEO INPUT

YPBP

TV Connections

Using MONITOR OUT VIDEO jack

Connect the Video cable with yellow connectors (supplied) between the MONITOR OUT VIDEO jack of the unit and the VIDEO INPUT jack on the TV.

Important Information:

To connect the unit to a TV, TV must have a Video input jack (RCA-type) at least. You cannot connect it to an antenna terminal of TV.

Partial back panel

To MONITOR OUT VIDEO jack (Yellow)

Video cable (supplied)

Notes:

• Please refer to your TV instruction manual.

• When you connect the unit to your TV, be sure to turn off the

power and disconnect both units from the wall outlet until all the connections have been made.

• Do not connect the MONITOR OUT (S-VIDEO/VIDEO) and COMPONENT VIDEO OUT jacks of the unit to a VCR directly. The playback picture will be distorted because DVD video discs are copy protected.

Using MONITOR OUT S-VIDEO jack Note: Please follow the steps before turn on the power.

1. If your TV has the S-VIDEO INPUT jack, connect the *Svideo cable (not supplied) between the MONITOR OUT SVIDEO jack of the unit and the S-VIDEO INPUT jack of the TV. (The MONITOR OUT VIDEO jack connection is not necessary.) You can enjoy clearer picture playback.

To VIDEO INPUT jack

AUDIO

R-AUDIO-L VIDEO

VIDEO INPUT

Need help? Call

1-800-813-3435

Using COMPONENT VIDEO OUT jacks

Note: Please follow the steps before turn on the power.

1. If your TV has the COMPONENT VIDEO INPUT jacks, connect the *Component video cable (not supplied) between the COMPONENT VIDEO OUT jacks of the unit and the COMPONENT VIDEO INPUT jacks of the TV. (The MONITOR OUT VIDEO or S-VIDEO OUT jack connection is not necessary.) You can enjoy high quality picture playback.

2. Set the VIDEO OUT SELECT switch to the COMPONENT position.

2. Set the VIDEO OUT SELECT switch to the S position.

TV with S-VIDEO INPUT jack

S-VIDEO IN 1

Partial back panel

*S-video cable (not supplied)

*Please consult your local audio/video dealer.

TV with COMPONENT VIDEO INPUT jacks

Blue

Red

Green

Partial back panel

*Component Video cable (not supplied)

*Please consult your local audio/video dealer.

-E9-

Green

RedBlue

Using RF Modulator

If your TV does not have a Video input jack and has an antenna terminal only, please purchase the *RF Modulator (not supplied). (*Please consult your audio/video dealer.)

Example: Unit, TV and RF Modulator connections

Partial back panel

To MONITOR OUT VIDEO jack (Yellow)

1. Connect the antenna cable (not supplied) to the ANT. IN terminal of the RF Modulator.

2. Connect the 75-ohm coaxial cable (not supplied) between the TO TV terminal of the RF Modulator and the VHF/UHF ANTENNA IN terminal of the TV.

3. Connect the Video cable with yellow connectors (supplied) between the MONITOR OUT VIDEO jack of the unit and the VIDEO input jack of the RF Modulator.

Example: Unit, VCR, TV and RF Modulator connections

To MONITOR OUT VIDEO jack (Yellow)

RF Modulator

A/V INPUT JACKS

R-AUDIO-LVIDEO

TO TV ANT. IN

CHANNEL

VHF/UHF

ANTENNA

4. Turn on the TV, and set the channel number (CHANNEL3 or CHANNEL4) on both TV and RF Modulator, whichever is not used for regular broadcasts in your area.

Note: For more details, please refer to the instruction manual of the RF Modulator.

VHF/UHF

ANTENNA

VHF/UHF

CHANNEL

FROM ANT.

TO TV

OUT

VIDEO

LINE1(AUX1)

IN OUT

AUDIO

HiFi Stereo VCR

1. Connect the antenna cable (not supplied) to the VHF/UHF FROM ANT IN terminal of the VCR.

2. Connect the 75-ohm coaxial cable (not supplied) between the TO TV OUT terminal of the VCR and the ANT. IN terminal of the RF Modulator.

3. Connect the 75-ohm coaxial cable (not supplied) between the TO TV terminal of the RF Modulator and the VHF/UHF ANTENNA IN terminal of the TV.

4. Connect the audio cables (not supplied) between the VIDEO (AUDIO) IN 1 or 2 jacks of the unit and the AUDIO OUT jacks of the VCR. Use the red connectors for the right-R jacks and the white connectors for the left-L jacks.

A/V INPUT JACKS

R-AUDIO-LVIDEO

TO TV ANT. IN

CHANNEL

Partial back panel

5. Connect the Video cable with yellow connectors (supplied) between the MONITOR OUT VIDEO jack of the unit and the VIDEO input jack of the RF Modulator.

6. Turn on the TV, and set the channel number (CHANNEL3 or CHANNEL4) on all TV, VCR and RF Modulator, whichever is not used for regular broadcasts in your area.

Note: For more details, please refer to the instruction manual of the RF Modulator.

RF Modulator

-E10-

Antenna Connections

FM antenna

The FM indoor antenna lead wire is sufficient to receive most local FM broadcasts and should be connected to the rear FM 75Ω terminal. Extend the antenna lead wire as straight as possible and, while listening to the sound from the system, secure it in a position where the best FM reception is found. In fringe areas, or where reception is distorted or noisy, an FM outdoor antenna (not supplied) should be connected instead of the FM indoor antenna lead wire. The terminals will accept 75ohm coaxial cable.

AM antenna

The AM loop antenna is sufficient to receive most local AM broadcasts. Assemble the loop antenna.

CAUTION:

When installing an outdoor antenna, follow the installation instructions in the attached “IMPORTANT SAFETY INSTRUCTIONS”.

FM outdoor antenna (not supplied)

Ground

Antenna discharge unit (not supplied)

Unwind the antenna wires, then

connect the plug to the AM LOOP terminal. If you have difficulty inserting the plug, turn it over and reinsert it. Place the loop antenna in a position

which yields the best AM reception, or attach it to a wall or other surface as shown.

Screws (not supplied)

NOTE: To minimize noise...

• Keep the speaker wires, power cord and all other system connection cables away from the loop antenna.

• Do not place the antenna close to a TV or speaker.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Section 820-40 of the NEC which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

Additional Connection Examples

1st video equipment input jack (VIDEO (AUDIO) IN 1)

Connect an audio cable (not supplied) from the audio output jacks of the TV to the VIDEO (AUDIO) IN 1 jacks.

AM loop antenna

FM indoor antenna lead wire

Plug

75-ohm coaxial cable (not supplied)

Headphones jack (PHONES)

Connect a pair of stereo headphones with miniplug (8 ohms - 32 ohms, not available from SANYO) to the PHONES jack for monitoring or for private listening. The speakers are automatically disconnected when headphones are connected.

PHONES

AUDIO

OUTPUT

Audio cable (not supplied)

2nd video equipment input jack (VIDEO (AUDIO) IN 2)

Connect an audio cable (not supplied) from the audio output jacks of the video equipment to the VIDEO (AUDIO) IN 2 jacks.

Power Supply

Connect the power cord to a 120VAC 60Hz outlet. This unit is equipped with a polarized plug. If you have difficulty inserting the plug, turn it over and reinsert it. If the unit will not be used for a long time, disconnect the AC plug from the AC outlet.

Notes:

• Before plugging the power cord into an AC outlet, make sure that all the connections have been made.

• The unit is not disconnected from the AC power unless the power cord is unplugged from the AC outlet.

-E11-

z/ONq

(Open/Close)

(Play)

FUNCTION VOLUME

BEFORE OPERATION

Common Operation

Turning the power on and off

Press [z/ON] to turn the power on.

•“HELLO” appears briefly on the FL display. (After connecting the power cord, when you press [z/ON] for the first time, the volume-reset feature automatically sets the initial volume level.) When the power cord is connected to the AC outlet, the unit will respond to commands from the remote control.

z/ON

OPEN/CLOSE

To turn the power off, press [z/ON] again.

•“GOOD-BYE” appears briefly on the FL display.

Smart start function

If the following buttons are pressed when the power is turned off, the unit turns on automatically and the selected source is activated.

[q], [a] (Front panel of the unit) [OPEN/CLOSE], [a], [TUNE/BAND] (Remote control)

Selecting the source

Press [FUNCTION] to select the desired source. Each time the button is pressed, the display changes as follows:

DVD/CD VIDEO 1 VIDEO 2 FM TUNER AM TUNER

• When the source selection is changed, disc playback automatically stops.

Adjusting the volume

Rotate [VOLUME] (or press [VOLUME] + or - on the remote control). The volume level appears on the FL display (VOL 0 ~ VOL MAX).

To reduce the volume temporarily (muting)

Press [MUTE] on the remote control. “MUTE” blinks on the FL display. To restore the previous volume setting, press [MUTE] again.

TUNE/BAND

MUTE

FUNCTION

BASS

SOUND

– VOLUME +

(Play)

Selecting the sound mode

1. Press [SOUND] repeatedly to select the desired sound mode (“BASS”, “TREBLE”, “CINE (Cinema)” or “QS (Q-Surround”).

2. Press the button as desired.

Sound mode Press Display change BASS o or p “+5” ~ “-5” TREBLE o or p “+5” ~ “-5” CINE ENTER “ON” or “OFF” QS ENTER “LOW” or “HI”

Note for “CINE”: When enjoying a DVD disc with the volume set low at night, select this mode. It enhances spoken lines making speech clearer.

3. Repeat steps 1 to 2 for another sound mode.

4. Press [SOUND] repeatedly to close the display.

Bass boost system

Press [BASS] repeatedly to select the desired bass boost effect.

BOOST v BASS OFF v NORMAL v BOOST . . .

-E12-

+ 29 hidden pages
