OWNER’S MANUAL
GUIDE D’UTILISATION
50” CLASS WIDE LCD HDTV
HDTV ACL GRAND ÉCRAN CATÉGORIE 50 PO
HDLCD5050
HDLCD5050A
ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the
required programming code.
Si vous utilisez avec cet appareil une télécommande universelle (autre que celle vendue avec ce téléviseur),
consultez la documentation accompagnant la télécommande universelle afin de connaître le code numérique correspondant au téléviseur.
ATTENTION
FRANÇAIS ENGLISH
AIR/CABLE MODE SELECTION
When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode.
If not using Cable TV, set this menu option to the “Air” position.
Lorsque l’appareil sort de l’usine, l’option Signal Type est en mode « Cable » (câblodistribution). Si vous
n’utilisez pas la câblodistribution, sélectionnez l’option « Air ».
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL.
SI VOUS DEVEZ COMMUNIQUER AVEC LE SERVICE CLIENTÈLE, PRENEZ NOTE
FOR INFORMATION ON OUR OTHER PRODUCTS, TO ORDER ACCESSORIES ONLINE,
POUR OBTENIR DES INFORMATIONS SUR NOS AUTRES PRODUITS, POUR COMMANDER DES ACCESSOIRES,
Avant de faire fonctionner l’appareil, veuillez lire le présent guide attentivement.
OR FOR RECYCLING INFORMATION, PLEASE VISIT OUR WEBSITE AT
Before operating the unit, please read this manual thoroughly.
SÉLECTION DU MODE AIR/CABLE
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
DU NUMÉRO DE MODÈLE AVANT D’APPELER.
CUSTOMER SERVICE – 1-800-289-0980
SERVICE/SERVICE CLIENTÈLE: 1-800-289-0980
ORION WEBSITE
SITE WEB ORION
OU LE RECYCLAGE, VEUILLEZ VISITER NOTRE SITE WEB:
www.sansuiproducts.com
ENGLISH
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY
FROM THIS PRODUCT AT TIMES.
CAUTION: TO PREVENT ELECTRIC SHOCK. DO NOT USE THIS POLARIZED PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
However, there is no guarantee that interference will not occur in a particular installation. If
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with the
The lamp(s) within this product contain mercury.
Disposal should be in compliance with local, state
or federal laws.
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Rules could void the user's authority to operate this equipment.
Location of the required marking
The rating sheet and the safety caution are
on the rear of the unit.
FCC Declaration of Conformity Compliance Statement
(Part 15):
The Sansui HDLCD5050 and HDLCD5050A, LCD HDTV
combination complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
The party responsible for compliance to these rules is:
ORION AMERICA,INC.
1105 SOUTH MAIN STREET PRINCETON, INDIANA
47670,U.S.A
Ph: 1-800-289-0980
Record the model number and serial number.
Model number _______________ Serial number _______________
EN 2
IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as
vases, should not be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from touching such power lines or
circuits, as contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points
or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid into
the unit.
19) If an outside antenna or cable system
EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE
is connected to the unit, be sure the
antenna or cable system is grounded
to provide some protection against
voltage surges and built-up static
charges, Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides
information with respect to proper
grounding of the mast and supporting
structure, grounding of the lead-in
wire to an antenna discharge unit, size
of grounding conductors, location of
GROUND
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
CLAMP
ANTENNA LEAD IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.
3 EN
IMPORTANT SAFETY INSTRUCTIONS
20) When replacement parts are required, be sure the service technician uses replacement parts
specified by the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety
checks to determine that the unit is in proper operating condition.
22) When you connect the product to other equipment, turn off the power and unplug all of the
equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal
injury. Read the owner's manual of the other equipment carefully and follow the instructions when
making any connections.
23) Sudden high volume sound may cause hearing or speaker damage. When you use headphones,
(if the unit is equipped with a headphone jack) keep the volume at a moderate level. If you use
headphones continuously with high volume sound, it may cause hearing damage.
24) Do not allow the product to output distorted sound for an extended period of time. It may cause
speaker overheating and fire.
25) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the
NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close to the point of cable entry as
practical.
26) The socket-outlet must be installed near the unit and easily accessible.
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and larger flat panel displays are popular
purchases. However, flat panel displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers,
chests or carts may fall over and cause injury.
THIS MANUFACTURER CARES!
The consumer electronics industry is committed to making home entertainment enjoyable and safe.
TUNE INTO SAFETY
One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of
your flat panel display.
Carefully read and understand all enclosed instructions for proper use of this product.
Don’t allow children to climb on or play with furniture and television sets.
Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.
Remember that children can become excited while watching a program, especially on a “larger than life” flat
panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or
knocked down.
Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
Use a mount that has been recommended by the display manufacturer and/or listed by an independent
laboratory (such as UL, CSA, ETL).
Follow all instructions supplied by the display and wall mount manufacturers.
If you have any doubts about your ability to safely install your flat panel display, contact your retailer about
professional installation.
Make sure that the wall where you are mounting the display is appropriate to support the weight of the unit/
product and wall mount. If you are unsure, contact a professional installer.
A minimum of two people are required for installation. Flat panel displays can be heavy.
EN 4
IMPORTANT SAFETY INSTRUCTIONS
CONDENSATION
Moisture will form in the operating section of the unit if the unit is brought from cool surroundings into a warm
room or if the temperature of the room rises suddenly. When this happens, unit's performance will be impaired.
To prevent this, let the unit stand in its new surroundings for about an hour before switching it on, or make sure
that the room temperature rises gradually.
Condensation may also form during the summer if the unit is exposed to the breeze from an air conditioner. In
such cases, change the location of the unit.
HOW TO HANDLE THE LCD PANEL
•
Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.
•
If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause
skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your
eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.
Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for
long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but
permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your
LCD Panel on for long periods of time while it is displaying the following formats or images:
•
Fixed images, such as stock tickers, video game patterns, TV station logos, and websites.
•
Special formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a
widescreen (16:9) display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any
responsibility for these symptoms.
LCD Panels are manufactured using an extremely high level of precision technology, however sometimes
•
parts of the screen may be missing picture elements or have luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that produces electromagnetic waves. Some
•
equipment placed too near this unit may cause interference.
Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless
•
headphones.
SAFETY PRECAUTIONS
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating.
Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 4 inches
(10 cm) free space around the entire unit.
4 inches
4 inches
Notes when mounting the LCD TV on a wall
If the unit is to be mounted on the wall, contact the retailer where
•
you purchased the LCD TV for advice, and have the equipment
professionally installed. Incomplete or improper installation may
cause injury to you, and/or damage to the LCD TV.
Bracket holes: To attach a wall mounting bracket (not supplied) attach
•
where indicated in the drawing right.
This manufacturer recommends professional installation.
•
Utilize an appropriate bracket and fasteners, sufficient to
•
accommodate the size and weight of the unit.
Assure the wall to which the unit is to be mounted will safely support
•
the size and weight of the unit, using the bracket and fasteners you
have selected.
Keep cords and cables connected to this flat panel display out of
•
reach of children.
To hang the television on a wall, remove these screws and then
•
remove a stand. Before performing work spread cushioning over the
base area to lay the TV on.
Bracket holes
Screws
5 EN
How to attach the stand
NOTE:
• Unplug the AC cord from the AC INPUT terminal.
• Before beginning this process, assure that the TV is laid on a clean, safe, and cushioned surface to avoid any
damage to the unit.
• Do not touch or press the TV-screen, glass might break under pressure.
Place the TV on its front onto a table.
Align the stand’s bottom-plate (supplied) as seen here.
It will fit in only one direction.
Hold the unit and attach the stand frame (a) slowly and secure the stand frame (a) with the 4 screws (supplied),
4x35mm (5/32 x 1-23/64 inches) as shown in figure 1.
(b)
LCD PANEL SIDE
(a)
(b)
Figure 1
Finally secure the bottom-plate (b) with 5 screws (supplied), 4x12mm (5/32 x 15/32 inches) as indicated by the
arrows in figure 2.
Be sure to follow the instructions. Insufficient tightening or incorrect installation of the stand will not support
•
your unit correctly, and could result in damage or injury from tip-over.
Figure 2
How to remove the stand
When you transport this product, remove the stand and pack flat against the back of the unit in the carton. To
remove the stand, perform these steps in reverse order.
For wall mounting, the base must be removed. To disconnect the base/stand remove the 4 screws from the back
(see page 5).
EN 6
Features
Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box.
•
Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for
•
hearing impaired viewers.
•
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control
adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Programmable TV Sleep Timer - Operable from the remote control, the LCD TV can be programmed for up
•
to 120 minutes to turn off automatically.
V-Chip - The V-Chip function can read the rating of a broadcast program or movie content if the program is
•
encoded with this information. V-Chip will allow you to set a restriction level.
Digital Audio Jack (Coaxial) - When a component with a built-in Dolby Digital decoder is connected, Dolby
•
Digital sound can produce the effect of being in a movie theater or a concert hall.
HDMI/Component Video Jacks - A VCR, DVD player, satellite receiver or other audio/video component can
•
be connected to this unit.
On-Screen 3 Languages Display - You can select one of 3 languages, English, French or Spanish for on-
•
screen programming.
* Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
* HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
Power source
TO USE AC POWER
Connect the AC cord plug into this unit’s AC INPUT jack.
1.
Connect the AC cord into an AC outlet.
2.
Wider Hole
and Blade
AC 120V, 60Hz
AC cord (supplied)
NOTE:
•
Please make sure to insert the cord securely at both the LCD TV and the wall outlet.
•
The AC cord has a polarized type AC line plug. If the supplied AC cord does not match your AC outlet, contact
a qualified electrician.
WARNING:
•
DO NOT CONNECT THIS UNIT TO THE POWER USING ANY DEVICE OTHER THAN THE SUPPLIED AC
CORD. THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE.
•
DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE SPECIFIED. THIS COULD CAUSE
FIRE, ELECTRICAL SHOCK, OR DAMAGE.
CAUTION:
•
WHEN THIS UNIT IS NOT USED FOR A LONG TIME, (E.G., AWAY ON A TRIP) IN THE INTEREST OF
SAFETY, BE SURE TO UNPLUG IT FROM THE AC OUTLET.
•
DO NOT PLUG/UNPLUG THE AC CORD WHEN YOUR HANDS ARE WET. THIS MAY CAUSE ELECTRICAL
SHOCK.
IF YOU NEED TO REPLACE THE SUPPLIED AC ADAPTER OR AC CORD, THE SPECIFIED ONE IS
•
RECOMMENDED. CONTACT CUSTOMER SERVICE AT 1-800-289-0980.
AC outlet
7 EN
Contents
Before using your unit
IMPORTANT SAFETY INSTRUCTIONS ...........3
SAFETY PRECAUTIONS .................................5
How to attach the stand ....................................6
How to remove the stand ..................................6
Features ............................................................7
Power source ....................................................7
Contents ...........................................................8
Parts and functions ...........................................9
Remote control ...............................................10
Antenna connections ......................................11
Cable TV connections ..................................... 11
Connections to other equipment .....................12
TV operation
Starting setup .................................................15
TV operation ...................................................15
Quick guide for menu operation ......................16
Convenience functions ...................................17
Memorizing channels ......................................18
Checking the digital signal strength ................19
Labeling channels ...........................................19
Labeling video inputs ......................................19
Setting the V-Chip ...........................................20
Closed Caption ...............................................21
CC advanced .................................................. 21
Setting the picture size ....................................22
Time Shift ........................................................23
Additional information
Reception disturbances ..................................24
Troubleshooting ..............................................25
Specifications ................................................26
limited WARRANTY ........................................27
EN 8
Parts and functions
Remote sensor
Power Indicator
Red : Standby
Green : On
Rear
To display the menu screen.
Press MENU button to display the menu screen.
CH (CHANNEL)
+/–
to select the desired setting during the menu screen
operations.
DIGITAL AUDIO
COAXIAL OUT jack
PC/DVI AUDIO IN jack
HDMI3 IN jack
PC MONITOR IN jack
Left sideFront
POWER button
CH (CHANNEL)
/ buttons
VOL (VOLUME) +/– buttons
MENU button
INPUT/ENTER button
buttons and INPUT/ENTER button can be used
/ buttons,
VOL (VOLUME)
AC INPUT jack
USB input
HDMI1/DVI IN jack
HDMI2 IN jack
ANT. (RF) IN jack
COMPONENT IN jacks
VIDEO2 IN jacks
(VIDEO/AUDIO (L(MONO)/R))
VIDEO1 IN jacks (VIDEO/AUDIO (R/L(MONO)))
VAR .(VARIABLE) AUDIO (R/L) OUT jacks
9 EN
Remote control
1
2
3
4
5
6
7
8
9
10
11
1.POWER Button - Use to turn the power on/off to
the LCD TV.
2.DISPLAY Button - When you press this button,
the current information will be displayed on a
screen. To remove the display from the screen,
press this button again.
3.Direct Channel Selection Buttons (0-9) - Allows
direct access to any channel of the LCD TV.
4.– Button -This button is used when selecting
digital channels.
5.MENU Button - Use to display the On-Screen
menu function.
6.
12
13
14
15
16
17
18
CURSOR ▲/▼/◀/▶
menu functions of the LCD TV.
7.ENTER Button - Use to enter or select
information for On-Screen operations.
8.MUTE Button - To turn off the sound, press this
button once. The LCD TV will be silenced and
the symbol “Mute” will appear on the screen. The
muting feature can be released by pressing the
MUTE button again or one of the VOL (VOLUME)
+ or – buttons.
9.VOL (VOLUME) + / – Buttons - Press the +
button to increase, or the – button to decrease the
sound level.
10.INPUT SELECT Button - Use to change the
external input.
11.CCD Button - Use to display the Closed Caption
menu screen.
12.SLEEP Button - To set the LCD TV to turn off
after a preset amount of time, use the SLEEP
button on the remote control.
13.PICTURE SIZE Button - Use to change the
picture size.
14.RECALL Button - This button allows you to go
back to the previous channel selected by just
pressing the RECALL button. Press this button
again to return to the channel you were watching.
15.EXIT Button - Press to remove setup menu.
16.AUDIO Button - Change soundtrack language.
17.CH (CHANNEL)
channels of the LCD TV.
18.Time Shift control Buttons - See page 23.
Buttons
- Use to operate the
/ Buttons - To change the
Before using the remote control, batteries must first be installed.
HOW TO INSTALL BATTERIES
1. Open the battery compartment cover.
2. Install two “AAA” batteries (supplied).
3. Replace the battery compartment cover.
EN 10
Use two “AAA” size batteries. The batteries may last
approximately one year depending on how much the
remote control is used. For best performance, it is
recommended that batteries should be replaced on a
yearly basis, or when the remote operation becomes
erratic. Do not mix old and new batteries or different
types.
BATTERY PRECAUTIONS
These precautions should be followed when using
batteries in this device:
•
Use only the size and type of batteries specified.
•
Be sure to follow the correct polarity when
installing the batteries as indicated in the battery
compartment. Reversed batteries may cause
damage to the device.
•
Do not mix different types of batteries together
(e.g. Alkaline, Carbon-zinc or Rechargeable) or old
batteries with fresh ones.
•
If the device is not to be used for a long period of
time, remove the batteries to prevent damage or
injury from possible battery leakage.
•
Do not try to recharge batteries not intended to be
recharged; they can overheat and rupture. (Follow
battery manufacturer’s directions.)
Antenna connections
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your
antenna system. If you are using a Cable TV service, see “Cable TV connections”.
Combination VHF/UHF Antenna (Single 75 ohm cable)
Antenna
Jack
75 ohm
Coaxial
Cable
Connect the 75 ohm cable from the combination
VHF/UHF antenna to the Antenna Jack.
Cable TV connections
This TV has an extended tuning range and can tune most cable channels without using a Cable TV
Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled.
Descrambling these signals for normal viewing requires the use of a descrambler device which is
generally provided by the Cable TV company.
For subscribers to basic Cable TV service
75 ohm
Antenna
Jack
Coaxial
Cable
For subscribers to scrambled Cable TV service
If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect
the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial
Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the
connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel
3 or 4) and use the Converter/Descrambler box to select channels.
For basic Cable TV service not requiring a Converter/
Descrambler box, connect the 75 ohm Coaxial Cable directly
to the Antenna Jack on the back of the TV.
Incoming
75 ohm
Cable TV
Cable
Converter/
Descrambler
75 ohm Cable to TV
Antenna
Jack
For subscribers to unscrambled Cable TV service with scrambled premium channels
If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require
the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available
from the Cable TV company or an electronics supply store). Follow the connections shown below. With the
switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the
“A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the
Converter/Descrambler box to tune scrambled channels.
Incoming
75 ohm
Cable TV
Cable
Splitter
Converter/
Descrambler
A/B Switch
75 ohm Cable to TV
A
B
Antenna
Jack
11 EN
Connections to other equipment
The exact arrangement you use to interconnect various video and audio components to this unit is dependent
on the model and features of each component. Check the Owner’s Manual provided with each component for
the location of video and audio inputs and outputs.
To connect the TV to a VCR
Rear of the unit
Video/Audio cord (not supplied)
To VIDEO/AUDIO IN
To Video/Audio OUT
To connect the TV to a DVD player with Component Video Input
You can enjoy a high quality picture by connecting the unit’s COMPONENT VIDEO OUT jacks of your DVD
player with the component video cables (not supplied).
Left of the unit
To AUDIO IN
To COMPONENT IN
Y
Pb
Pr
Component video cord
(not supplied)
To Component OUT
Y
Pb
Pr
VCR
DVD
Audio cord (not supplied)
NOTE:
Component Video input of the unit are for use with a device which output 480i/1080i interlaced signals and
•
480p/720p progressive signals.
To connect the TV to a camcorder, or a game console
To playback from a camcorder, connect the camcorder to the unit as shown.
This unit can also be used as a display device for many video games. However, due to the wide variety of
signals generated by these devices and subsequent hook-up variations required, they have not all been
included in the suggested connection diagrams. You’ll need to consult each component’s Owner’s Manual for
additional information.
Rear of the unit
Video/Audio cord (not supplied)
To VIDEO/AUDIO IN
To Video/Audio OUT
To Audio OUT
or
GAME CONSOLE
EN 12
Connections to other equipment
To connect an audio system
This connection allows you to use an audio amplifier and external speakers, and adjust the audio level using the
TV’s remote control.
To control the audio, turn on the TV and the stereo amplifier, and turn off the TV’s built-in speakers (see page 17).
Rear of the unit
Amplifier
To VAR. (VARIABLE)
AUDIO (R/L) OUT
Audio cord (not supplied)
To Audio (L) Input
To Audio (R) Input
NOTE:
To hear sound when using an external audio amplifier, the volume of both the TV and the amplifier must be set
•
above 0 (zero).
For example, if the volume of the TV is set to 0, you will not be able to hear any sound, even if the volume of the
•
amplifier is at its highest level.
Using an AV Amplifier with built-in digital surround
If you are using an AV Amplifier with built-in digital surround sound, you can enjoy various audio systems including
Dolby Digital Surround audio that sounds just like the movie.
Connect an AV amplifier with built-in Dolby Digital decoder, etc. as shown below.
Front
Speaker
(Right)
To DIGITAL AUDIO
COAXIAL OUT
Coaxial digital cable
Digital Audio Input
Rear of the unit
(not supplied)
To Coaxial
Front
Speaker
(Left)
Subwoofer
TV
Center Speaker
Surround
Speaker
(Right)
AV Amplifier with built-in digital surround
decoder as listed above
Surround
Speaker (Left)
NOTE:
When you are viewing digital broadcast, this unit will not work in conjunction with DTS audio or MPEG audio.
•
There will be no sound output if connected to an AV amplifier with a built-in DTS decoder or MPEG decoder.
13 EN
Connections to other equipment
To connect a HDMI or a DVI device to the unit
The HDMI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital
video from a DVI device.
When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate
analog audio cords required.
Rear and Left of the unit
To PC/DVI AUDIO IN
NOTE:
When using HDMI1/DVI IN to connect your HDMI or DVI devices, you must select the corresponding
•
audio input source (HDMI or DVI) on the menu screen (see page 17). Otherwise you will only see the
image with no sound.
To connect the TV to a PC (Personal Computer)
BEFORE YOU CONNECT THIS TV TO YOUR PC, CHANGE THE ADJUSTMENT OF YOUR PC’S
RESOLUTION AND REFRESH RATE (60 HZ).
Connect one end of a (male to male) VGA cable to the video cord of the computer and the other end to the
connector PC MONITOR IN on the rear of the
case of a Multimedia computer, connect the audio cord to the audio output of your Multimedia computer and to
the AUDIO IN connector of the PC/DVI AUDIO IN jack of the TV. You can also connect the PC with HDMI cable.
If you use HDMI cable, you don’t have to connect the audio cord. If you use DVI-to-HDMI cable, please connect
audio cord as same way as VGA cable.
Press INPUT SELECT on the remote control to select PC mode.
Switch on the computer. The TV can operate as the computer monitor.
Audio cord (not supplied)
HDMI - to - DVI adapter cable
(HDMI type A connector)
To HDMI IN
HDMI cable (type A connector)
(not supplied)
(not supplied)
TV
. Attach the connectors firmly with the screws on the plug.
To DVI output
or
To HDMI output
DVI device
HDMI device
In
VGA
Rear and Left of the unit
To HDMI IN
To
PC/DVI
AUDIO
IN
NOTE:
The on-screen displays will have a different appearance in PC mode than in TV mode.
•
If there is no video signal from the PC when the unit is in PC mode, “No signal” will appear on the TV-screen.
•
When the PC connected to the HDMI terminal and 1920x1080 resolution (FHD) is selected, the top and
•
bottom, right and left edges of the picture may be hidden on all picture sizes. In this case, use the PC
MONITOR IN jack (VGA cable) is recommended to connect.
When the PC’s resolution is set to 1920 x 1080/60 Hz (FHD mode), a signal that differs from the FHD signal,
•
which has been confirmed operational on this TV, may appear depending on the PC used. In this case, “Auto
Adjust” or other Position Adjustment functions may fail to correct the image position.
To solve this problem, change the PC settings to select another resolution.
To PC
MONITOR
IN
HDMI cable (not supplied)
VGA cable (not supplied)
Audio cord (not supplied)
Monitor Display modes
Mode Resolution Refresh rate
VGA 640x480 60/ 72/ 75 Hz
VGA 720x400 70Hz
SVGA 800x600 56/ 60/ 72/ 75 Hz
XGA 1024x768 60/ 70/ 75 Hz
WXGA 1280x768 60Hz
WXGA 1280x720 60Hz
WXGA 1360x768 60Hz
SXGA 1280x1024 60Hz
WXGA+ 1440x900 60Hz
FHD 1920x1080 60Hz
To return to normal mode
Press INPUT SELECT again.
EN 14
Starting setup
The Auto Setup menu appears the first time you
turn on the TV, and assists you to specify the
Air/Cable setting, and program your channels
automatically.
IMPORTANT: Make sure that the antenna or cable
TV system connection is made!
To turn on the TV, press POWER. (POWER
1
indicator on the front of the unit changes green.
It may take approx. 10 seconds for a picture to
appear on screen.) The Auto Setup function
begins.
Auto Setup
TV Location Store
E-POP Demo Off
Signal Type Cable
Automatic Search Start
Press ▲ or ▼ to select “TV Location”, then press
2
◀ or ▶ to select “Store” or “Home”. This product
qualifies for ENERGY STAR in Home mode
default setting.
NOTE:
This unit has been preset to STORE brightness.
•
This setting does not qualify under ENERGY
STAR. To reduce brightness and energy
consumption, change setting to ‘HOME’. This
setting does qualify under ENERGY STAR.
The device may not conform to the ENERGY
•
STAR standard after Reset is performed or the
Backlight is adjusted.
Press ▲ or ▼ to select “E-POP Demo”, then press
3
◀ or ▶ to select “On” or “Off”.
On: A TV feature introduction will pop up at the
bottom of the screen.
Off: Turn off the E-POP Demo feature.
Press ▲ or ▼ to select “Signal Type”, then press
4
◀ or ▶ to select “Cable” or “Air”.
Press ▲ or ▼ to select “Automatic Search”, then
5
press ▶ or ENTER.
“Auto Setup” will begin. After the Auto Setup
6
is completed, the TV channel appears on the
screen.
Depending on the reception condition, it may
•
take up to 30 minutes to complete memorizing
digital cable channels. Please allow the
process to complete without interruption.
NOTE:
If you press EXIT in the process of “Auto Setup”, the Auto
•
Setup stops and changes to the normal screen.
When you make a menu selection, your changes occur
•
immediately. You do not have to press EXIT to see your
changes.
TV operation
To turn on the TV, press POWER.
1
(POWER indicator on the front of the unit
changes green. It may take approx. 10 seconds
for a picture to appear on screen.)
Adjust the volume level by pressing VOL + or – .
2
The volume level will be indicated on the screen
by green bars. As the volume level increases, so
do the number of bars. If the volume decreases,
the number of green bars also decreases.
Set the Signal Type option to the appropriate
3
position (see “Air/Cable selection” on page 18).
Press the Direct Channel Selection (0-9, –)
4
buttons to select the channel.
(If you press only channel number, channel
selection will be delayed for a few seconds.)
TO SELECT ANALOG CHANNELS
1-9: Press 1-9 as needed. Example, to
10-99: Press the 2 digits in order. Example,
100-135: Press the 3 digits in order. Example, to
TO SELECT DIGITAL CHANNELS
Press the first 1-3 digits, then press the – button,
followed by the remaining number.
Example, to select channel 15-1, press 1, 5, –, 1,
then press ENTER.
•
•
The same program may be available on either
•
VHF/UHF/CABLE CHANNELS
VHF
2-13
UHF
14-69
NOTE:
If a channel with no broadcast is selected, the sound will
•
automatically be muted.
It may take a few seconds for a digital channel picture to
•
appear on screen after being selected.
To select the video input source
To view a signal from another device connected to
your LCD TV, such as a VCR player, press INPUT
SELECT, then press ▲ or ▼ or corresponding
Number buttons (0-7), then press ENTER.
0.TV
1.Video1
2.Video2
3.Component
4.HDMI1
5.HDMI2
6.HDMI3
7.PC
[0-7]:Select
select channel 2, press 2, then press
ENTER.
to select channel 12, press 1, 2, then
press ENTER.
select channel 120, press 1, 2, 0, then
press ENTER.
If a channel is selected with only audio content,
“Audio only” will be displayed on the screen.
If a channel is selected with a weak digital
signal, “Digital channel signal strength is low”
will be displayed on the screen.
an analog channel or a digital channel. You may
choose to watch either format.
If a channel is selected to which you have not
subscribed,
be displayed on the screen.
Air Cable
Input Select
“Digital channel is encrypted” will
VHF
2-13
STD/HRC/IRC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-135 (100) (135)
01 (4A)
15 EN
CH /
Press and release CH / . The channel
automatically stops at the next channel set into
memory.
For proper operation, before selecting channels, they
should be set into the memory. See “Memorizing
channels” on page 18.
DISPLAY
Press DISPLAY to display the current information on
the screen.
When the TV receives a digital signal, the digital
information will appear.
62-1 HDTV_Moving_Picture...
CH-1 TV-MA
Digital Air
No Program Information is available
USB Memory Information
Play Time
Message : Now Live View
: --:--:--
USB Memory is unplugged
Full
1080i
Sleep Timer
Off
English
Channel number• Station name•
Broadcast program name
Channel label (if preset)•
•
V-Chip rating• Signal type•
Sleep timer• Audio language•
Program guide• Picture size•
Resolution• Time Shift display•
When the TV receives an analog signal, the analog
information will appear.
14
Analog Cable
G
Mono
Full
480i
Sleep Timer
Off
Quick guide for menu
operation
Call menu and for example: Select Language.
Press INPUT SELECT to select TV mode.
1
Press MENU. The TV menu screen will appear.
2
3
4
5
NOTE:
•
Main Menu
Audio
CH
Channel
Lock
Setup
>>
ENTER :Set:Select
Press ▲ or ▼ to select “Setup”, then press ▶ or
ENTER.
Press ▲ or ▼ to select “Language”, then press ◀
or ▶ to select the desired language.
…on the following pages the menu can be called
in the same way as here.
Press EXIT to return to the normal screen.
If no buttons are pressed for more than about 60
seconds, the menu screen will return to normal
operation automatically.
Channel number• Channel label (if preset)•
V-Chip rating• Signal type•
Sleep timer• Picture size•
Audio information
• Resolution•
(Stereo, SAP or Mono)
Press DISPLAY again to clear the call display.
NOTE:
After a few seconds, DISPLAY screen will return to
•
normal TV operation automatically.
SLEEP
To set the TV to turn off after a preset amount of time,
press SLEEP on the remote control. The clock will
count up 10 minutes for each press of the SLEEP
button (Off, 0h 10m, 0h 20m, ..., 2h 0m). After the sleep
time is programmed, the display will appear briefly
every ten minutes to remind you that the sleep timer
is operating. To confirm the sleep timer setting, press
SLEEP and the remaining time will be displayed for a
few seconds. To cancel the sleep timer, press SLEEP
repeatedly until the display turns to Off.
EN 16
Convenience functions
You can change the default settings by pressing the MENU button on your remote, then select the one of the icons at the left
of the menu - follow the On-Screen prompts to set your preferences.
Icon Selected Items Setup hint
Picture Picture
Preference
Picture Setting Brightness /Contrast /
DBC On/Eco/Off
Backlight*
Picture Size See page 22.
Film Mode On/Off
PC Setting Hor Position /
DNR On/Off DNR (Digital Noise Reduction) can reduce the roughness of the picture.
Audio
Channel Add / Delete See page 18.
Lock See page 20.
Setup Closed Caption See page 21.
NOTE:
*1 If there is no input signal in the PC mode, after 1 minute Auto Shut Off will be activated. In PC mode the “PC Standby”
*2
Equalizer Mode
Audio Setting Bass/Treble You can adjust the sound quality to your preference. (Flat mode only)
MTS Stereo / SAP / Mono The multi-channel TV sound (MTS) feature provides high-fidelity
Surround On/Off The dynamic presence and sound created offers a thoroughly
Auto Volume On/Off Volume level can be adjusted automatically by the sound level.
Audio Language
HDMI1 Audio HDMI When you connect the HDMI device to the TV, select this setting.
Speakers On/Off
DTV Signal See page 19.
Auto Ch Memory See page 18.
Ch Label See page 19.
Language
Video Label See page 19.
On Timer Off / 0h30m / 1h00m
Auto Shut
1
Off*
Auto Setup See page 15.
PC Standby On/Off
Reset*
setting takes precedence.
The device may not conform to the Energy Star standard after Reset is performed or the Backlight is adjusted.
Sports Bright and dynamic picture (factory-set)
Standard Standard picture quality (factory-set)
Movie Movie-like picture setting (factory-set)
Memory Your personal preferences (set by you; see “Picture Setting”)
Sharpness / Color / Tint
Color Temperature Cool (Bluish) / Standard (Neutral) / Warm (Reddish)
2
Ver Position
Clock
Phase
Auto Adjust To adjust the all PC settings automatically.
Standard/Music/Movie/
News/Memory/Flat
Equalizer Setting 100Hz/250Hz/500Hz/1kHz/2kHz/4kHz/10kHz (Not available in Flat mode)
Balance You can adjust the sound quality to your preference.
DVI When you connect the DVI device to the TV with analog audio cords,
/ 1h30m / 2h00m /
3h00m⋅⋅⋅12h00m
On/Off If the Auto Shut Off feature is On, a station being viewed stops
2
You can adjust the picture quality to your preference.
Use this feature to change the Black level automatically according to the
brightness of an image. The Black level will become dark in a dark scene. If “Eco”
is selected, the power consumption is reduced and “Backlight” will be skipped.
The Backlight feature adjusts the screen brightness for improved
picture clarity.
A smoother motion may be obtained by setting the Film Mode to “On” (480i only).
To adjust the horizontal / vertical position of the image on the PC monitor
screen. Each video standard will require a different value for this setting.
To minimize any vertical bars or stripes visible on the screen background.
This must be adjusted after the frequency has been set optimize picture quality.
You can adjust the Equalizer Mode to your preference.
stereo sound. MTS also can transmit a second audio program (SAP)
containing a second language or other audio information.
When the TV receives a stereo or SAP broadcast, the word “Stereo” or
“SAP” displays on-screen every time you press DISPLAY.
enjoyable listening experience.
When two or more audio languages are included in a digital signal, you can select
one of the audio languages. (This function is available only for digital broadcast.)
select this setting.
Use this feature to turn the TV speakers off when you connect an audio system.
You can choose from three different languages (English, Français (French) and
Español (Spanish)) for the on-screen displays.
Select the language you prefer first, then proceed with the other menu options.
You can set the On Timer to automatically turn on the TV. To cancel the
On Timer select “Off ”.
broadcasting and the TV is not operated, the TV will automatically shut
itself off after 15 minutes.
In PC mode, if no signal is received or no operation performed for 1
minute, the TV will turn to standby mode automatically (LED light will
flash red). When an input signal is received or an operation performed
on the PC, the TV will return to the On mode.
The Reset function returns your Picture/Audio settings to the factory settings.
“Picture Size”, “MTS” , “Audio Language”, “HDMI1 Audio” and “Speakers”
cannot be reset by this function.
17 EN
Memorizing channels
This TV is equipped with a channel memory
feature which allows channels to skip up or down
to the next channel set into memory, skipping
over unwanted channels. Before selecting
channels, they must be programmed into the
TV’s memory. To use this TV with an antenna, set
the Signal Type option to the Air mode. When
shipped from the factory, this menu option is in
the Cable mode.
Air/Cable selection
Select “Channel ⇒ Auto Ch Memory ⇒ Signal
1
Type”.
Press ◀ or ▶ to select “Air” or “Cable”.
2
Air - VHF/UHF channels
Cable - CABLE TV channels
CH
Auto Ch Memory
Signal Type Cable
Automatic Search Start
NOTE:
•
It may take a few seconds for a digital channel
picture to appear on screen after being selected.
Automatic Search
Select “Channel ⇒
1
Search”, then press ▶ or ENTER.
CH
Auto Ch Memory
Signal Type Cable
Automatic Search Stop
The TV will begin memorizing all the channels
2
available in your area.
It may take from 15 minutes to 30 minutes to
•
complete memorizing digital cable channels.
Depending on the reception condition, a bar
display may not advance for several minutes,
please be patient.
NOTE:
•
Memorizing channels is best accomplished during
evening “PRIMETIME” hours, as more stations are
broadcasting digital signals. Memorizing channels can
only be accomplished while a station is broadcasting
a digital signal to set that channel into memory.
If you are unsure of the digital channels available
•
in your area, you may visit www.antennaweb.org to
receive a list based on your address or zip code.
Should you require further assistance you may call
our toll-free customer service line at 1-800-289-0980.
New digital channels may be added to your area
•
periodically, it is recommended to perform the
“Automatic Search” procedure regularly.
Auto Ch Memory
⇒ Automatic
Adding Channel
If you find a new digital channel unregistered, you can
add the new channel into the channel memory.
Tune in the new channel.
1
Select “Channel ⇒ Add/Delete ⇒ Adding
2
Channel”, then press ▶ or ENTER.
CH
Add/Delete
Adding Channel >>
Add/Delete >>
Clear All >>
The new channel will be added into the channel
3
memory.
Add/Delete channel
You can select the channel that you want to skip.
Select “Channel ⇒ Add/Delete ⇒ Add/Delete”,
1
then press ▶ or ENTER.
Press ▲ or ▼ to select the channel that you want
2
to skip.
CH
Add/Delete
CH
Signal
2 Analog
3
Analog Add
3-1
Digital Delete
3-2
Digital Add
4 Analog Delete
Press ◀ or ▶ to select “Add” or “Delete”,
3
whichever function you want to perform.
Repeat steps 2 - 3 for other channels you want to
4
add or delete.
Add
Clear All
All channels are deleted from the channel memory.
Select “Channel ⇒ Add/Delete ⇒ Clear All”, then
press ▶ or ENTER.
CH
Add/Delete
Adding Channel >>
Add/Delete >>
Clear All >>
EN 18
Checking the digital
signal strength
This TV will allow you to view the digital signal
meter for digital channels.
Select “Channel ⇒ DTV Signal”, then press ▶ or
1
ENTER.
The digital signal strength screen will appear.
2
If necessary, adjust the direction of the antenna to
obtain the maximum signal strength.
CH
DTV Signal
Signal Level
NOTE:
Signal meter feature is not available for analog
•
channels.
After 240 seconds, DTV Signal screen will return to
•
normal TV operation automatically.
0 50 100
Labeling channels
Channel label appear with the channel number
display each time you turn on the TV, select a
channel, or press DISPLAY.
You can choose any four characters to identify a
channel.
To create channel labels
Select “Channel ⇒ Ch Label”, then press ▶ or
1
ENTER.
Press ◀ or ▶ to select a channel you want to
2
label, then press ▼.
CH
Ch Label
Channel Number
Ch Label
Label Clear
15-1
CH-1
>>
Repeat steps 2-3 for other channel. You can
4
assign a label to each channel.
When you finish inputting the label name, press
5
EXIT to return to the normal screen.
To clear a Ch Label
After step 2 above, press ▲ or ▼ to select “Label
Clear”, then press ▶ or ENTER.
NOTE:
•
The channel labels will be reset after “Automatic
Search” on page 18.
Labeling video inputs
The Video Label feature allows you to label each
input source for your TV.
Select “Setup ⇒ Video Label”, then press ▶ or
1
ENTER.
Press ▲ or ▼ to select an input which you want to
2
label.
Press ◀ or ▶ to select the desired label for that
3
input source.
Video Label
Video 1 -
Video 2 -
Component HDMI 1 -
HDMI 2 HDMI 3 PC -
– / VCR / DVD / STB / Cable / Satellite / Receiver /
Game / Camcorder / PC / DVI PC / Blu-ray
Press ◀ or ▶ repeatedly until the character you
3
want appears in the first space.
CH
Ch Label
Channel Number 15-1
Ch Label
Label Clear >>
The characters rotation as follows:
If the character which you desire appears, press
ENTER.
Repeat this step to enter the rest of the characters.
If you would like a blank space in the label name,
you must choose the empty space from the list of
characters.
SPACE
CH-1
, () @ / + =
-
-
19 EN
Setting the V-Chip
An age limitation can be set to restrict children from
viewing or hearing violent scenes or pictures that you
may choose to exclude. The restriction applies to “TV
Rating” and “Movie Rating” if this data is transmitted.
You may set this restriction separately. To use the
V-Chip function, you must register a password.
To register a password
Select “Lock”, then press ▶ or ENTER.
1
Select and enter your password (4 digits) using
2
Number buttons (0-9), then press ENTER.
Lock
New Password
“ ” appears instead of the number.
Enter the same password again to confirm, then
3
press ENTER.
The password is now registered.
NOTE:
If you forget the password, contact Customer
•
Service at 1-800-289-0980 for assistance.
Your original remote control will be required.
To avoid forgetting the password, write it down and
•
keep in a safe place.
How to enter the V-Chip menu
Select “Lock” menu, then press ▶ or ENTER.
1
Use Number buttons (0-9) to enter your
2
password, then press ENTER. The V-Chip menu
will appear.
To set the V-Chip
In the V-Chip menu, press ◀ or ▶ to set “V-Chip”
1
to “On”.
Press ▲ or ▼ to select “V-Chip Set”, then press ▶
2
or ENTER.
The V-Chip Set menu will appear.
Press ▲ or ▼ to select which rating will be used,
3
then press ▶ or ENTER. Each rating below will
appear.
TV Rating
TV Rating
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
You can set the rating using age level and genre.
Age:
TV-Y : All children
TV-Y7 : 7 years old and above
TV-G : General audience
TV-PG : Parental guidance
TV-14 : 14 years old and above
TV-MA : 17 years old and above
EN 20
* * *
_
When you select TV-Y7, TV-PG, TV-14 or TV-MA,
press DISPLAY to explain the rating.
Genre:
D : Dialogue
L : Language
S : Sex
V : Violence
FV : Fantasy Violence
Movie Rating
Movie Rating
G
PG
PG-13
R
NC-17
X
G : All ages
PG : Parental guidance
PG-13 : Parental guidance
R : Under 17 years old parental guidance
suggested
NC-17 : 17 years old and above
X : Adult only
Press ▲/▼ to select the desired rating, then press
4
ENTER.
Press EXIT to return to the normal screen.
5
V-Chip function is activated now.
NOTE:
•
The V-Chip function is activated only on programs
and input sources that include a rating signal.
less than 13 years old
To change the password
In the V-Chip menu, press ▲ or ▼ to select
1
“Change Password”, then press ▶ or ENTER.
The Change Password screen will appear.
Enter a new password using Number buttons
2
(0-9), then press ENTER.
Enter the same password again to confirm, then
3
press ENTER.
The password is now registered.
Downloading the additional V-Chip rating system
As a supplement to the standard V-Chip rating
system, your television will be able to download an
additional rating system, if such a system becomes
available in the future.
To download the additional V-Chip rating system
(when available)
In the V-Chip menu, press ◀ or ▶ to set “V-Chip”
1
to “On”.
Press ▲ or ▼ to select “V-Chip Set (DTV)”, then
2
press ▶ or ENTER.
If the TV is not storing the additional rating
3
system, the TV will begin downloading it, which
may take some time to be completed.
Set your preferred content rating limits for the
4
additional rating system.
You also need “Update” procedure to update
5
rating information.
NOTE:
You can only download the additional V-Chip rating
•
system when your TV is receiving a digital signal.
When you download the additional rating system, it
•
may take some time for the download to occur.
The V-Chip rating information and system are not
•
determined or controlled by the TV.
The standard V-Chip rating system is available
•
whether your TV is receiving a digital signal or not,
and will block both analog and digital programs. To
set the restriction level using the standard V-Chip
rating system, select “V-Chip Set” in step 2.
The downloadable V-Chip rating system is an
•
evolving technology, and availability, content, and
format may vary.
You cannot select this feature if the TV is not
•
receiving a digital signal for the current station.
To clear the all V-Chip settings
In the V-Chip menu, press ▲ or ▼ to select
1
“V-Chip Clear”, then press ▶ or ENTER.
The V-Chip Clear screen will appear.
Use Number buttons (0-9) to enter your
2
password, then press ENTER. All of your settings
return to the factory settings.
Closed Caption
NOTE:
•
If the program or video you selected is not closedcaptioned, no captions will display on-screen.
•
If text is not available in your viewing area, a black
rectangle may appear on-screen. If this happens,
set the CC Setting to “Off”.
•
When selecting Closed Captions, the captioning will
be delayed approx. 10 seconds.
•
If no caption signal is received, no captions will appear,
but the television will remain in the Caption mode.
•
Misspellings or unusual characters may
occasionally appear during Closed Captioning.
This is normal with Closed Captioning, especially
with live programs. This is because during live
programs, captions are also entered live. These
transmissions do not allow time for editing.
When Captions are being displayed, on-screen
•
displays, such as volume and mute may be seen
but may interfere with Closed Captions.
Some cable systems and copy protection systems
•
may interfere with the Closed Captioned signal.
If using an indoor antenna or if TV reception is very
•
poor, the closed caption decoder may not appear or
may appear with strange characters or misspelled
words. In this case, adjust the antenna for better
reception or use an outdoor antenna.
Closed Caption menu also can be displayed by
•
pressing CCD on the remote control.
WHAT IS CLOSED CAPTIONING?
This television has the capability to decode and
display Closed Captioned television programs.
Closed Captioning will display text on the screen
for hearing impaired viewers or it will translate and
display text in another language.
Captions: This Closed Caption mode will display
text on the screen in English or another language.
Generally, Closed Captions in English are transmitted
on C1 and Closed Captions in other languages are
transmitted on C2.
Text: The Text Closed Caption mode will usually fill
1/2 of the screen with a programming schedule or
other information.
Select “Setup ⇒ Closed Caption”, then press ▶ or
1
ENTER.
Press ◀ or ▶ to set “CC Setting” to “On”.
2
On: Captions will be displayed on the screen.
Off: Captions will not be displayed on the screen.
Press ▲ or ▼ to select “Analog Caption” or “Digital
3
Caption”.
When you select “Analog Caption”, you can
choose from C1, C2, C3, C4, T1, T2, T3 and T4.
When you select “Digital Caption”, you can
choose from CS1, CS2, CS3, CS4, CS5 and CS6.
Press ◀ or ▶ to select the desired Closed
4
Caption mode for both Digital and Analog Caption.
Press ▲ or ▼ to select “CC Priority”, then press
5
◀ or ▶ to select “Digital CC” or “Analog CC”.
NOTE:
Depending on the broadcast signal, some
•
Analog Captions will function with a Digital
broadcast signal. This step prevent that two
kind of captions are overlapping.
CC advanced
When you have selected “Custom” as the display
method, you can adjust the various setting listed
below as follows:
This feature is designed to customize Digital Caption
only.
Select “Setup ⇒ Closed Caption”, then press ▶ or
1
ENTER.
Press ◀ or ▶ to set “CC Setting” to “On”.
2
Press ▲ or ▼ to select “Digital CC Preset”, then
3
press ◀ or ▶ to select “Custom”.
Press ▲ or ▼ to select “CC Advanced”, then
4
press ▶ or ENTER.
The CC Advanced menu will appear.
Press ▲ or ▼ to select the desired item, then
5
press ◀ or ▶ to change the setting.
CC Advanced
Tex t S iz e Au to
Text Type Auto
Text Edge Auto
Text Color Auto
Text Opacity Auto
Background Color Auto
Background Opacity Auto
21 EN
You can select from among the following items
and parameters.
Text Size: Auto, Small, Standard, Large
Text Type: Auto, Style1, Style2, Style3, Style4,
Text Edge: Auto, None, Raised, Depressed,
Text Color: Auto, Black, White, Red, Green,
Text Opacity: Auto, Solid, Transparent,
Background
Color:
Background
Opacity:
NOTE:
•
You cannot set both “Text Color” and “Background
Color” as a same color.
•
You cannot set both “Text Opacity” and “Background
Opacity” to “Transparent”.
Style5, Style6, Style7
Uniform, Left Shadow, Right
Shadow
Blue, Yellow, Magenta, Cyan
Translucent, Flashing
Auto, Black, White, Red, Green,
Blue, Yellow, Magenta, Cyan
Auto, Solid, Transparent,
Translucent, Flashing
Setting the picture size
You can change to a variety of picture sizes—
Natural, Cinema Wide1, Cinema Wide2, Cinema
Wide3, Full and Native.
Selecting the picture size
Select “Picture ⇒
1
ENTER
Press
2
▲ or ▼
(0-4) to select the desired picture size, as described
below.
Picture Size
0.Natural
1.Cinema Wide1
2.Cinema Wide2
3.Cinema Wide3
4.Full
Picture Size
to display “Picture Size” menu
or corresponding Number buttons
”, then press ▶ or
.
Cinema Wide1 (for 4:3 format programs)
To fill the screen, the right and left edges are
extended, however; the center of the picture remains
near its former ratio.
The top and bottom edges of the picture may be hidden.
Cinema Wide2 (for letter box programs)
The entire picture is uniformly enlarged—it is
stretched the same amount both wider and taller
(retains its original proportion).
The top and bottom edges of the picture may be hidden.
Cinema Wide3 (for letter box programs with
subtitles)
To fill the width of the screen, it is extended
horizontally. However; it is only slightly extended at the
top and the bottom.
The top and bottom edges of the picture may be hidden.
A B C D E F G - - - - - - - - - - - - - - - -
Full (for 16:9 source programs)
Full will display the picture at the maximum size.
A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -
Native (for PC mode only)
Detects the resolution of the signal of the image and it
will be shown on the screen with same amount of pixels.
NOTE:
Selectable picture sizes may vary depending on the
•
input source or broadcast signal.
Picture Size menu also can be displayed by
•
pressing PICTURE SIZE on the remote control.
Natural
In some cases, this image will display the size of
standard 4:3 with a black side bar.
EN 22
NOTE:
Some High Definition and/or Digital broadcasts may
•
not allow you to change the picture size.
In HDMI or COMPONENT mode with a scanning
•
rate of 720p, 1080i or 1080p (HDMI only) only the
Cinema Wide2 and Full picture size feature are
available.
In PC mode, only the Natural, Full and Native
•
picture size features are available. In PC mode
(WXGA, WXGA+, FHD), only the Full and Native
picture size features are available.
When the PC connected to the HDMI terminal and
•
1920x1080 resolution (FHD) is selected, the top
and bottom, right and left edges of the picture may
be hidden on all picture sizes.
Time Shift
You can record a digital program by using the
USB memory drive. This function is for your
convenience, and allows you to pause/record a
live program for a period of time based on the
size of the USB drive inserted.
Note: The connected USB device must;
Have a minimum approx. 100 MB of memory (32 GB
•
max.).
Formatted as FAT16/32.
•
Have a write speed higher than 40Mb/sec.
•
Contain no other files.
•
Do not use USB extension cable.
•
Preparation:
Plug-in an external storage device into USB port.
To start recording, press
•
will start and the picture will be paused.
To view a live program, press ■ (STOP).
•
The paused picture goes back to a live program
and recording continues.
To stop recording, press ■ (STOP) again during
•
viewing a live program with recording.
To start playback, press
•
program starts playback.
If you want to watch the program while recording,
press
(PLAY).
You can watch the recorded program while
recording the current program.
•
To pause the playback picture, press
•
To stop the playback, press
•
To fast forward or fast reverse, press (SKIP–) or
(SKIP+).
USB status display
Press DISPLAY while watching a DTV channel, or
press the Time Shift operation buttons. The status
display will appear.
(PAUSE). The recording
(PLAY). The recorded
(PAUSE).
(STOP).
Playback status :
(PLAY), (STOP), (PAUSE),
(SKIP+),
Recording
(SKIP-)
Delayed time from the current program
or Playing time in the play mode.
If there are no recorded program in
•
the USB memory, --:--:-- will appear
USB Memory Information
●
▶
Delay Time : 00:02:09
Message: Now Play View
Message display
•
Now Live View... Viewing live program
•
Now Play View... Viewing recorded program
•
Now Pause View... Pausing the program
•
Not Available... Inhibited function
•
USB Memory is full...Caution of available USB memory
less than 100MB (Insufficient USB free space...will show
(PAUSE) is pressed.)
when
No Data... When you press (PLAY) and there are no
•
data recorded in the USB memory
USB Memory is unplugged... USB memory is not connected
•
To delete the recorded program
Disconnect the USB memory, record another
program, or turn off the TV.
Note:
Time shift does not work for ATV or external inputs. If you
•
change the signal while recording a program (Live View),
recording will stop.
During Play view mode, ATV channel select or input select
•
will not work.
Time shift recordable time is approximately 10 minutes
•
per 1 GB for HD or 30 minutes for SD (depending on the
program).
You cannot watch the recorded program on a PC or other
•
device.
All of the USB memory may not able to be used.
•
We will accept no responsibility whatsoever for loss of files
•
on USB devices caused by connection to this unit.
23 EN
Reception disturbances
Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF
antenna. Outdoor antennas are recommended for best results. The most common types of television
interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV
system, the disturbance may be caused by the local Cable TV company broadcast.
IGNITION
Black spots or horizontal streaks may appear, the picture may flutter or
drift. Usually caused by interference from automobile ignition systems,
neon lamps or AC powered tools and appliances such as drills or hair
dryers.
GHOSTS
Ghosts are caused by the television signal following two paths. One is the
direct path and the other is reflected by tall buildings, hills or other large
objects. Changing the direction or position of the antenna may improve
the reception.
SNOW
If the TV is located far from the TV station, in a fringe reception area where
the signal is weak, small dots may appear in the picture.
If the signal is extremely weak, the installation of a larger external antenna
may be necessary.
RADIO FREQUENCY INTERFERENCE (RFI)
Caused by two-way radios, this type of interference produces moving
ripples or diagonal streaks in the picture. Some cases may cause a loss of
contrast in the picture. Changing the direction and position of the antenna
or installing an RFI filter may improve the picture.
PICTURE SIZE VARIATION
A slight picture size variation is normal when you adjust the CONTRAST or
BRIGHTNESS settings.
CARE AND MAINTENANCE
To prevent fire or shock hazard, disconnect the TV from the power source before cleaning.
The finish on the cabinet may be cleaned with mild soap and a soft, damp cloth and cared for as other furniture.
Use caution when cleaning or wiping the plastic parts.
EN 24
Troubleshooting
Use the following checklist for troubleshooting if you have problems with your LCD TV. Consult your local dealer
or service outlet if problems persist. Be sure all connections are properly made when using with other units.
SYMPTOMS POSSIBLE SOLUTIONS
TV does not
operate.
Poor sound
or no sound.
Poor picture
or no picture.
Poor
reception on
some
channels.
Poor color or
no color.
wobbles or
drifts.
Make sure the power cord is plugged in.
•
Try another AC outlet.
•
Power is off, check fuse or circuit breaker.
•
Unplug unit for an hour, then plug it back
•
in.
Station or Cable TV experiencing
•
problems, tune to another station.
Check sound adjustments (VOL +/- or
•
MUTE).
Check for sources of possible
•
interference.
Station or Cable TV experiencing
•
problems, tune to another station.
Make sure channels are set into memory.
•
Check antenna or Cable TV
•
connections, adjust antenna.
Check for sources of possible
•
interference.
Check picture control adjustments.
•
Station or Cable TV experiencing
•
problems, tune to another station.
Make sure channels are set into memory.
•
Station is weak, adjust antenna to
•
receive desired station.
Check for sources of possible
•
interference.
Station or Cable TV experiencing
•
problems, tune to another station.
Make sure channels are set into memory.
•
Check picture control adjustments.
•
Check antenna or Cable TV
•
connections, adjust antenna.
Check for sources of possible
•
interference.
•
Station or Cable TV experiencing
problems, tune to another station.
•
Make sure channels are set into memory.
•
Cable TV company is scrambling signal.
•
Adjust antenna.
SYMPTOMS POSSIBLE SOLUTIONS
Digital
broadcasting
screen
problem.
No CATV
reception.
Horizontal or
diagonal bars
on screen.
No reception
above
channel 13.
No Remote
operation.
TV shuts off.
Closed
Caption is not
activated.
TV is not
shown in your
language.
Cannot delete
E-POP.
Check digital signal strength.•
Check all Cable TV connections.
•
Set Signal Type menu option to the
•
Cable mode.
Station or Cable TV system problems,
•
try another station.
Check antenna connections, adjust or
•
re-direct antenna.
Check for sources of possible
•
interference.
Make sure Signal Type option is in the
•
appropriate mode.
If using antenna, check UHF antenna
•
connections.
Batteries are weak, dead or inserted
•
incorrectly.
Remote is out of range, move closer to
•
TV (within 15 feet).
Make sure Remote is aimed at sensor.
•
Confirm there are no obstructions
•
between the Remote and the TV.
Make sure the power cord is plugged in.
•
Sleep Timer is set.
•
Power interrupted.
•
TV station experiencing problems or
•
program tuned is not closed captioned.
Try another channel.
Check Cable TV connection or VHF/UHF
•
antenna, reposition or rotate antenna.
Set closed caption decoder in the menu.
•
Select proper language in the menu
•
options.
•
Set the “E-POP Demo” in the Auto Setup
menu to “Off”.
BLOCK NOISE / PICTURE FREEZE
Block noise or picture freeze may appear on the screen caused by weak signals, interference from automobile
ignition systems, neon lamps or AC powered tools and appliances such as drills or hair dryers.
FOR CUSTOMER SERVICE, ADDITIONAL SET-UP AND OPERATING ASSISTANCE, OR TO ORDER ACCESSORIES PLEASE CALL:
1-800-289-0980
WHEN CALLING CUSTOMER SERVICE – PLEASE HAVE YOUR MODEL NUMBER READY
OR WRITE TO:
ORION SALES, INC.
3471 N. UNION DR.
OLNEY, ILLINOIS 62450
FOR INFORMATION ON OUR OTHER PRODUCTS, TO ORDER ACCESSORIES ONLINE,
OR FOR RECYCLING INFORMATION, PLEASE VISIT OUR WEBSITE AT
www.sansuiproducts.com
25 EN
Specifications
GENERAL
Power supply: AC 120V, 60Hz
Power consumption: Operation: 200W
Weight: 19.8 kg (43.7 lbs)
Dimensions: Width: 1177.0 mm (46-23/64 inches)
Operating temperature: 5˚C - 40˚C
Operating humidity: Less than 80% RH
Type: 1257.3mmV (50” class/49.50” diagonal)
Display method: Transmission TFT color LCD panel
Number of Pixels: 1920 (H) × 1080 (V)
Broadcasting system: US system M
Receiving channels: VHF 2-13
Tuner type: Frequency synthesized
Inputs: Video: (RCA) 1 V (p-p), 75 ohms
Outputs: Audio: 0-600mVrms/1k ohm
Speakers: 40.6 mm × 121.9 mm (1-5/8 inches × 4-13/16 inches), 8 ohms × 2
Audio output power: 10.0W + 10.0W
ACCESSORIES Remote control
Designs and specifications are subject to change without notice.
Stand by: 0.3W
Height: 775.9 mm (30-35/64 inches)
Depth: 281.6 mm (11-5/64 inches)
ATSC standard (8VSB), QAM
UHF 14-69
CATV 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)
95-99 (A-5)-(A-1)
100-135 (100)-(135)
01 (4A)
Audio: (RCA) –8 dBm/50k ohms
Component video: (Y) 1 V (p-p), 75 ohms
(Pb)/(Pr) 0.7 V (p-p), 75 ohms
HDMI: HDMI compliant (type A connector)
HDCP compliant
E-EDID compliant
Suggested scan rates: 480p, 480i, 720p,1080i,1080p
HDMI Audio: 2-channel PCM
32/44.1/48 kHz sampling frequency
16/20/24 bits per sample
PC Monitor: Mini-Dsub 15pin
Antenna: VHF/UHF In 75 ohms coaxial
Digital audio out: 0.5 V (p-p), 75 ohms terminated
Batteries (AAA) × 2
AC Cord
Stand
Screws × 9
for Stand (4×12mm (5/32 × 15/32 inches)) × 5
•
for Frame Stand (4×35mm (5/32 × 1-23/64 inches)) × 4
•
Frame Stand
EN 26
limited
WARRANTY
ORION warrants this product to be free from manufacturing defects in material and workmanship under
normal use and conditions for a period of 1 year from date of original purchase in the United States.
Should service be necessary under this warranty for any reason due to a manufacturing defect or
malfunction during the first 12 months from date of original purchase, ORION will provide in-home repair service by
an ORION authorized Independent Service Center at no charge. Also, if an original part fails due to manufacturing
defect in material and workmanship within one year from date of original purchase we will replace the defective
part, provided the defect or malfunction is verified along with dated proof of purchase.
There are ORION authorized Independent Service Centers located throughout the country. For the one
nearest you, DIAL TOLL FREE: 1-800-289-0980 or visit our website at www.sansuiproducts.com. ORION will not
be liable for damages incurred in shipment of the unit. If there are no ORION authorized Independent Service
Centers in your area please call - 1-888-296-7466 for assistance.
Note: This warranty is void if the product is:
(a) Damaged through negligence, misuse, abuse, or accident.
(b) Used in a commercial application or rentals.
(c) Modified or repaired by anyone other than an Independent Service Center authorized by ORION to effect
warranty repairs to the class of product or by the ORION Factory Service Center.
(d) Damaged because it is improperly connected to the equipment of other manufacturers.
This warranty does not cover:
(a) Damage to equipment not properly connected to the product.
(b) Costs incurred in the shipping of the product to an ORION authorized Independent Service Center or
ORION Factory Service Center.
(c) Damage or improper operation of unit caused by customer abuse, misuse, negligence, or failure to follow
operating instructions provided with the product.
(d) Ordinary adjustments to the product which can be performed by customer as outlined in the owner’s
manual.
(e) Signal reception problems caused by external antenna or cable systems.
50” CLASS WIDE LCD HDTV
THIS WARRANTY IS NON TRANSFERABLE AND APPLIES ONLY TO THE ORIGINAL PURCHASER
AND DOES NOT EXTEND TO SUBSEQUENT OWNERS OF THE PRODUCT. ANY APPLICABLE IMPLIED
WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED IN DURATION TO A
PERIOD OF THE EXPRESS WARRANTY AS PROVIDED HEREIN BEGINNING WITH THE DATE OF ORIGINAL
PURCHASE AT RETAIL AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED SHALL APPLY TO THIS
PRODUCT THEREAFTER. ORION MAKES NO WARRANTY AS TO THE FITNESS OF THE PRODUCT FOR
ANY PARTICULAR PURPOSE AND USE.
UNDER NO CIRCUMSTANCES SHALL ORION BE LIABLE FOR ANY LOSS, DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGE ARISING OUT OF OR IN CONNECTION WITH THE
USE OF THIS PRODUCT.
THIS WARRANTY IS VALID ONLY IN THE UNITED STATES OF AMERICA. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, HOWEVER, YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE
TO STATE. SOME STATES DO NOT ALLOW LIMITATION ON IMPLIED WARRANTIES OR EXCLUSION OF
CONSEQUENTIAL DAMAGE, THEREFORE THESE RESTRICTIONS MAY NOT APPLY TO YOU.
ORION SALES, INC.
3471 N. UNION DR.
OLNEY, ILLINOIS 62450
27 EN
Loading...
