Sangean DDR-62 User Manual

DDR-62

中文

Revision 1

The iSangean App enables remote control of the DDR-62 running on your iPhone, iPod touch, iPad or Android smartphone.

iSangean is the remote control app for Sangean Internet radios and media streamers for your iPhone, iPod touch, iPad or Android smartphone. The

app allows selection of Internet radio stations, selection and control of media for UPnP/DLNA music streaming from a local computer, server or NAS

device, as well as control of FM radio and other functions (where these functions are present on the radio). The Now Playing screen provides radio

station or media information with direct control of the radio volume.

Download iSangean from Apple iTunes (Apple Store) and Google Play now!

Contents

Introduction .................................................................... 3-9

DDR-62 Internet radio features ........................................ 3

Before you can use this product ...................................... 3

Controls and connections .............................................. 4-5

Remote control operation .............................................. 6-7

Network remote control options ....................................... 8

Navigation controls .......................................................... 9

Network conguration ............................................... 10-18

Connecting your radio to your computer network ..... 10-18

Internet Radio mode .................................................. 19-32

Internet Radio-the basics ............................................... 19

Selecting a radio station by location and genre ........ 20-22

Searching for a radio station by name ........................... 23

Selecting a new or popular station ................................. 24

Selecting a podcast/BBC Listen Again ........................... 25

Presetting stations .......................................................... 26

Display modes ........................................................... 27-28

Customizing your radio ............................................. 29-30

Selecting favorite stations ......................................... 31-32

Music Player mode ..................................................... 33-43

Use with Windows, Apple Mac and Linux ...................... 33

Accessing your les via UPnP ................................... 34-35

Locating and playing media les using UPnP ................ 36

Media selection .............................................................. 37

Controlling playback .................................................. 38-39

Display modes ................................................................ 40

Playlists ..................................................................... 41-43

DAB mode ................................................................... 44-52

Selecting a DAB radio station ........................................ 45

Display modes ........................................................... 46-47

Finding new DAB radio stations ................................ 48-50

Station order setup .................................................... 51-52

FM mode ..................................................................... 53-58

Manual tuning ............................................................ 54-55

Scan tuning .................................................................... 56

Stereo/Mono switching ................................................... 57

Presetting stations in DAB and FM modes .................... 58

CD/MP3/WMA .............................................................. 59-68

Compact discs ............................................................... 59

Playing a CD ............................................................. 60-62

CD track programming ................................................... 63

CD/MP3/WMA mode ................................................. 64-67

SD/USB playback and recording .............................. 68-76

SD/USB le and folder selection ............................... 68-71

Recording to SD/USB ............................................... 72-74

Deleting les ............................................................. 75-76

USB charging .................................................................. 77

Charging with USB socket ............................................. 77

Standby USB charger .................................................... 77

Clock and Alarms ....................................................... 78-86

Automatically updating the clock ............................... 78-79

Manually setting the clock ......................................... 80-81

Setting the alarm clock .............................................. 82-85

Sleep timer ..................................................................... 86

Display and Auto ........................................................ 87-94

Equalizer ................................................................... 87-88

Brightness control ..................................................... 89-90

Touch sensitivity control panel ....................................... 91

Headphone socket and Line out socket ......................... 92

Auxiliary input socket ................................................. 93-94

Information ............................................................... 95-103

Factory reset .................................................................. 95

Software update ............................................................. 96

Network proles ........................................................... 97

Audio FAQ .................................................................... 98

Accessing your audio les via a UPnP server using Windows

Vista and XP ............................................................ 99-101

Codecs ......................................................................... 101

Cautions and Specications .................................. 102-103

Before you can use this product

Before you can use your internet radio, you must have the following:

A broadband Internet connection (not required for DAB, FM or Music

●

Player functions).

A wireless access point (WiFi) or a wired Ethernet connection connected

●

to your broadband Internet Service Provider, preferably via a router.

In many cases the broadband modem, router and wireless access

point will be a single combined unit supplied by your Internet Service

Provider or bought from a computer store.

If your wireless network is congured to use Wired Equivalent Privacy

●

(WEP) or WiFi Protected Access (WPA/WPA2) data encryption then you

either need to know the WEP, WPA or WPA2 key used for encryption so

you can get the internet radio to communicate with the network, or your

router needs to offer WiFi Protected Setup (WPS).

If connecting using WiFi, the internet radio will typically work within a 10-20

metre radio from your wireless access point. The actual range achieved will

depend upon the building type, other nearby wireless network, and possible

interference sources. DAB and FM radio functions can operate wherever

the internet radio is able to receive a suitable broadcast signal.

IMPORTANT:

Before you continue, make sure that your wireless access point or router

is powered up and working with your broadband Internet service (use your

computer to verify this). To get this part of the system working you must

read the instructions supplied with the wireless access point or router.

Controls and connections

(Front view)

1. Standby button

2. Remote control sensor

3. Radio button

4. Info / Menu button

5. Record button

6. Volume Up / Down button

7. Back button

8. Repeat button

9. Play / pause button

10. Select / stop button

11. Tuning Down / Rewind button

12. SD card / USB memory socket (behind panel)

13. Tuning Up / Fast-forward button

14. Sleep / Clock set button

15. Alarm button

16. Media button

17. CD Eject button

18. Loudspeakers x 2

19. CD slot

20. LCD display

Controls and connections

(Rear View)

21. Telescopic aerial

22. Wi-Fi antenna

23. Headphone socket

24. Line output socket

25. Auxiliary input socket

26. Optical output socket (Toslink)

27. Ethernet socket (RJ-45)

28. Mains input socket

Remote control handset

On / Standby button

Mute button

Key pad button 1-10 / 0

Select / Stop button

Tuning Down / Rewind button

Info / Menu button

Repeat button

Media button

Sleep / Clock set button

Record button

Equalizer button

Alarm button

Radio button

Auto-tune / Program tracks button

Random button

Play / Pause button

Folder Down button

Tuning Up / Fast-forward button

Back button

Folder Up button

Volume Up / Down buttons

CD eject button

Remote control battery replacement

1. Remove the battery cover on the rear of your remote control by applying pressure to the catch

in the direction shown by the arrow in the diagram, and then lifting the cover.

2. Insert 2 x AAA size batteries into the compartment. Make sure the (+) and the (-) ends of the

batteries are positioned as shown inside the compartment.

3. Close the battery cover by inserting the retaining lugs rst, then apply pressure to the free end

such that the catch latches the cover securely.

4. If the remote is not to be used for an extended period of time it is recommended that the batteries

are removed.

IMPORTANT:

The batteries should not be exposed to excessive heat such as sunshine, re or the like. After

use, disposable batteries should if possible be taken to a suitable recycling centre. On no account

should batteries be disposed of by incineration.

Do not leave batteries within reach of young children. They can be a chocking hazard.

1. Battery compartment

2. Latch

3. Retaining lugs (inside)

Using the touch panel

Network remote control options

The DDR-62 has a stylish touch panel instead of conventional buttons.

To operate the buttons simply touch the button area with the tip of a

nger for about half a second. The clock set and system menu functions marked with a dot (●) are accessed by means of a long touch (2-3

seconds) on the appropriate button until the display on the radio shows that the command has been accepted.

You may nd at rst that the radio does not always detect that you have

touched a button. If so, try touching with a little more pressure, or for

slightly longer. You will soon nd the optimum touch needed to control

your radio. The panel may be cleaned using a dry cloth. Do not use

abrasives, cleaning uids or solvents.

Remote control functions

Most of the functions of the DDR-62 radio can be controlled using either the touch panel or the remote control. However, there are a few functions which are only accessible using the remote control. These are: Radio station presets CD track access by numbers Audio mute DAB/FM auto-tune CD/iPod random function

As with the front panel, some operations require a longer operation of the button (explained in the relevant sections). In this case simply keep

your nger held on the remote controlbutton for 2-3 seconds until the

display on the radio shows that the command has been accepted.

Network Pin setup (Pin number)

Your radio has the option of being controlled by an application installed on an Apple iPhone/ iPod touch/ iPod or Android smartphones/tablet. The Pin number facility allows you to ensure that your radio can only be controlled by your own device rather than someone else’s.

Details of how this feature can be used with your Apple and Android device are explained in the separate sheet available from the Sangean website. The remote control application is called iSangean ( ) and is available on the Apple App Store and Google Play.

Keep network connected

By default, your radio will shut down its WiFi connection when it is in standby. This minimizes power consumption but it does mean that you will need to switch that radio on manually in order to use the remote control software.

If you need to be able to remotely control the radio even when it has been put into standby, make sure you choose to keep the network connected by setting "YES" in the ‘Keep network connected’ option in the network setting menu. In the standby mode display either the WiFi signal indicator is shown with or without a cross through it according to the chosen network settings.

Navigation controls

This page describes the basic means of controlling your DDR-62 internet radio. Instructions for

each operating mode are given in the later section of this book.

Pressing the Standby button brings your radio out of Standby mode. Pressing Standby while

the radio is in use will cause it to return to the Standby mode with the clock display.

Pressing the Radio button gives you access to each of the operating modes in turn: Internet

Radio, DAB+ radio, FM radio and Auxiliary Input.

Pressing the Media button gives you access to each of the operating modes in turn: CD, USB

memory device, SD cards, iPod and Music player.

Pressing and holding the Info/Menu button will access the menu system. The info button also

allows the display of information relating to the radio station or music le being played.

Many operations require the user to make a selection from the menu. Highlight the menu item

using the Tuning Up or Tuning Down buttons on the touch panel (alternatively, the Folder Up

or Folder Down buttons on the remote control handset). Press the Select button to select that

item. If there are more than ve items in a menu, then the display will automatically scroll up or

down so that the additional items become visible. A sliding bar on the right will give an indication

showing the current portion of the menu that is displayed. If there are many items in a menu,

then the radio allows the menu to “wrap around” in either direction. This can make it easier to

reach items at the end of a long menu, such as a list of countries or Internet radio stations.

If an error is made when navigating the menus, it is generally possible to go back to a higher

level menu by pressing the Back button.

Although controls on the Internet radio are shown, all functions are also available using the

remote control.

Conguration

Connecting your radio to your computer network

Place your radio on a at surface and plug the mains lead into the mains socket located on the

back of your radio ensuring that the plug is pushed fully into the socket.

If you wish to use a wired network connection, plug the Ethernet cable into the socket at the

back of the radio.

Plug the other end of the mains lead into the wall socket and switch on the wall socket.

IMPORTANT:

The mains plug is used as the means of connecting the radio to the mains supply. The mains

socket used for the radio must remain accessible during normal use. In order to disconnect

the radio from the mains completely, the mains plug should be removed from the mains socket

outlet completely.

When you apply power, the display on the radio will light up and say: ‘WELCOME’ and

‘STARTING’ with a progress indicator. The rst time that you use your radio (or after Factory

Reset) the display will show “Setup wizard” and “YES” will be highlighted on the screen. Press

the Select button to start the setup wizard. The screen will ask if you wish to run the setup

wizard again at the next start up. This will lead to the main menu.

Press the Tuning Up or Down buttons on the touch panel (Alternatively, the Folder Up or Down

buttons on the remote control handset) to highlight the desired clock format (either 12 Or 24

hour) then press the Select button to enter your selection. A menu allowing you to specify

the auto update option for the clock will appear on the display. The default of ‘Update from

Network’ will be the best option for most users.

Press the Tuning Up or Down buttons on the touch panel (Alternatively, the Folder Up or

Down buttons on the remote control handset) to choose an auto-update option for the clock.

This can be updated from DAB or FM radio, from the Network, or not updated. The default is

to auto update from the network. If you choose any other option, go to step 9. Otherwise you

will rst need to select the correct time zone and daylight savings setting, see steps 7 and 8.

If you choose “No update” you will need to set the clock manually later (see the section of

‘Manually setting the clock’). Press the Select button to conrm your choice.

Press the Tuning Up or Down buttons on the touch panel (Folder Up or Down buttons on the

remote control handset) to highlight the time zone which is applicable to your location. Press

the Select button to enter the setting.

You will then need to set the Daylight Savings option according to your location (Daylight

Savings is also known as Summer/Winter time). Press the Folder Up or Down buttons on the

remote control handset to highlight “YES” to turn on daylight savings if required or ‘NO’ if you

do not wish to use daylight savings then press the Select button to conrm the setting.

The display will then show a list of WiFi regional options for the network set up. Press the

TuningUp or Down buttons on the touch panel (Alternatively, the Folder Up or Down buttons

on the remote control handset) to highlight the required region and then press the Select

button to select it. Do this even if planning to use the wired Ethernet connection. Your radio

will then scan for available WiFi networks. If using WiFi we recommend that the WiFi antenna

is positioned vertically.

The radio will enter the Network Settings Wizard and will display ‘Scanning…’. After a short

10.

while the display will show a list of the available WiFi networks. If you are intending to use the

WiFi connection, go to step 11.

To use the Ethernet connection to your router (with automatic conguration). Press the Folder

Up or Down buttons on the remote control handset to point to the “[Wired]’ menu item. Press

the Select button and the radio will attempt to connect.

If your network allows automatic conguration (which is normal) the radio will acquire a network

address. The screen should say ‘Connecting…’, and then ‘Setup wizard completed’. Press the

Select button to exit the setup wizard and show the main menu.

There are two indicator lights incorporated into the connector. If you have problems with your

wired connection, they may help you to identify the possible cause of the problem.

Yellow ON = Link established; OFF = no connection

Yellow Flashing = Data transfer

Green ON = 100 Mbits/sec link; OFF = 10 Mbits/sec ilnk

If your network does not support automatic conguration or if you wish to set it up manually then

you should select ‘[Manual cong]’ instead of selecting ‘[Wired]’ in the Network Wizard.

If you plan to use a WiFi connection, you will rst need to identify your network in the list of

11.

network names presented by the Network Wizard. If no networks are found then you may

have to get your wireless router working (please see the instructions supplied with it) or

you may be too far from the router. When the radio nds your wireless network, it displays

the Network Name (SSID) for the wireless access point on the screen. This is a name that

is allocated to the access point in your router by the person who set up the network – for

example: ‘Jones family’ or ‘Paul’s network’. If the router supports WiFi Proteced Setup, then

‘[WPS]’ will be shown in front of the SSID. It is possible, and in some locations highly likely,

that your radio will nd more than one wireless network, in which case you should choose

which one you need to connect to.

Press the Folder Up or Down buttons on the remote control handset (alternatively, Tuning Up

12.

or Down buttons on the touch panel) to see the SSID for each wireless network that has been

found. If your network is shown proceed to step 14 on the next page. If it is not shown then

proceed to step 13. If you make a mistake at any point, use the Back button to go back to the

previous screen.

If your network is not found, it may be because the router is congured not to broadcast the

13. SSID. You should then use the Folder Up or Down buttons on the remote control handset and

Select buttons to highlight and select the ‘[Manual cong]’ option in order to enter the network details manually. This is described in ‘Manual Network Conguration”. If your network name

is being broad cast, and it was not found, then try re-scanning press the Back button), and if necessary try moving your radio to a location closer to your access point / router.

When the SSID for the wireless network you wish to connect to is highlighted on the

14. screen, press the Select button. If WiFi Pretected Setup (WPS) was indicated, you will see an additional menu at this point, otherwise proceed to step 15. Choose one of the WPS menu options as required for your router (WPS may be via push button, or using an

identicationnumber). ‘Push Button’ – the display prompts you to press the WPS button on

your routerand then the Select button on the radio. The two devices should then connect with

the encryption key sent automatically to the radio. ‘PIN’ – the display shows an identication

number which you must enter into your router using a web browser (refer to your router’s user documentation). You should then press the Select button on the radio. ‘Skip WPS’ – if you wish to enter the encryptionkey yourself (or if it was previously Entered). If you choose Push Button or PIN the screen will then show ‘Connecting…’ and then ‘Setup wizard completed’. Press the Select button to exit setup wizard.

If your network is congured without an encryption key, the screen should say ‘Connecting…’,

15. and then ‘Setup wizard completed’. Press the Select button to exit the setup wizard and show the main menu. If this is the case then you have successfully connected your radio to your network.

If the screen displays ‘Key’, it is because the network is using one of the encryption systems:

16. Wired Equivalent Privacy (WEP) or WiFi Protected Access (WPA). You will need to enter the correct WEP or WPA key into the radio to allow it to communicate with your wireless network. If you do not have the WEP or WPA key, then you should obtain it from the person who set up your network. Some wireless routers may come with an encryption key already set up by the supplier, in which case you should refer to the documentation provided with it. WPA is used here to also include WPA2.

WEP keys are 10 or 26 characters long (using 0 – 9, and A – F). Some wireless Routers can

17.

also use pass-phrases for WEP but these are not supported. WPA keys are usually set up using

a pass-phrase of between 8 and 63 characters. Your radio accepts pass-phrases for WPA keys.

To enter the WEP or WPA key, characters are selected and entered using the Menu Up or

Down, Left or Right (on the remote control) and Select buttons. The highlight scrolls through

the available characters as well as the three controls on the right. The character currently

highlighted will be entered when you press the Select button. Do this as needed until the

complete key has been entered. Remember, WEP keys only use the numbers 0-9 and letters

A-F. WPA keys are sensitive to upper and lower case characters. You must enter the key

exactly or the radio will not connect to the network. The three controls on the right-hand

side of the screen have special functions. You can quickly access these by pressing the Info

button and then use the Up or Down and Select buttons as needed:

select ‘ ’ to erase a character just entered (long press to clear)

select ‘ ’ when the complete key has been entered

select ‘ ’ to cancel an re-run the Network Wizard

If a WEP or WPA key has previously been entered for the selected SSID then the display

will show ‘Key: [Set]’. If you have previously entered a different key, you must clear this by

selecting the ‘ ’ symbol. This will remove the ‘[Set]’ indication. After the nal character

of the WEP or WPA key has been entered, highlight the ‘ ’ symbol and press the Select

button. Then screen will show ‘Connecting…’ and then ‘Setup wizard completed’. Press the

18.

Select button to the exit setup wizard. The radio should now be able to connect to the network.

Once you have connected your radio to the network (and therefore also to the Internet) it will

display the main menu. Press the Standby button to put the radio in Standby mode. It should

then display the time as obtained from the Internet. If the time display is not correct for any

reason, it can easily be adjusted later, see ‘Manually setting the clock’. If you have followed

the steps on the preceding pages successfully, your radio will have connected to your router,

and then made a connection to the Internet and set its clock. If this is the case, then you can

try listening to radio stations via the Internet.

Changing the network connection

In the sections above, you chose how your radio would be connected to your network, either

using a WiFi connection or using a wired Ethernet cable. From time to time, you may nd that you

need to connect to different computer networks. The Internet setup menu allows you to change

your radio’s network settings, scan for an alternative wireless network, or to manually congure

the network parameters. The steps outlined below describe how you can do this – see also the

section ‘Network Proles’.

Conguring the radio to use an alternative WiFi connection

1. From the Network settings menu select ‘Network wizard’. This will present you with details of

any WiFi networks that are found. Scroll down the list using the Folder Up or Down buttons on

the remote control panel to the desired network name. Press the Select button to select this

network. The radio will then use its WiFi system to communicate with the network. Depending

on the settings for the new network you may need to enter an encryption key. By default the

radio will then acquire an IP address and other network settings from your router using DHCP.

Conguring the radio to use the wired Ethernet connection

2. Connect your radio to your router using an Ethernet cable plugged into the socket (marked

LAN) at the back of the unit. From the Network settings menu select ‘Network Wizard’. This will

preset you the details of any WiFi networks that are found. Scroll down the list to the ‘[Wired]’

option using the Folder Up or Down buttons on the remote control handset. Press the Select

button to select this. The radio will then use its Ethernet connection to communicate with the

network. By default the unit will then acquire an IP address and other network settings from

your router using DHCP.

Manual network conguration

If you do not wish to use DHCP for automatic conguration, or if your network is congured with a

hidden SSID, then you will need to enter some network settings manually. (Note – a hidden SSID

may prevent casual observers from detecting your network, but is not recommended as a means

of network security.)

From the radio Network settings menu, select ‘Manual settings’. You must then choose whether to connect using ‘Wired’ or ‘Wireless’ connections. If you choose ‘Wireless’ there are as many as nine settings screens, shown by the ‘1 of 9’ progress marker in the top right

corner of the display. If you choose ‘Wired’ there are ve screens and the progress marker will reect this, although the steps to set up the network parameters are basically the same.

The next menu asks whether you wish to use DHCP to congure your network parameters (IP

address, subnet mask, gateway address, etc). Unless you are familiar with networking and related terminology, we recommend that you allow the use of DHCP. Choose ‘DHCP enable’ unless you need to specify the network details manually. If you have chosen ‘Wired’ and then ‘DHCP enable’, your radio should now establish a connection to the router using the Ethernet cable. Please skip to setp11. If you chose ‘Wireless’ and ‘DHCP enable’, please skip to step 6 in order to set up the wireless connection details. If you chose ‘DHCP disable’ for either connection method, the next step is to set up the IP address.

The manually specied IP address should be chosen to be compatible with the settings in your

router and must be a unique address on your network. If you are using DHCP for some devices

and static (manually congured) IP addresses for others, the IP address used should fall outside

the range that the router may allocate using DHCP. Typically, the first three groups of digits will be the same for all devices on your network. To enter the IP address, press the Folder Up or Down buttons to set the value for each group of digits and then press the Select button or the Left or Right buttons on the remote control to enter the value and to move on to the next group. When the IP address has been entered, the subnet mask should be entered. The subnet

mask denes which parts of the IP address are common across your network. For most small

networks the subnet mask will be 255.255.255.0 and this is entered in the same way.

The Gateway address is normally the IP address of the router through which the radio

connects to the internet and is entered in the same way as the previous addresses.

In most installations the DNS settings (DNS = Domain Name Server) will be set to the same

IP address as your router. In this case the secondary DNS may be left at zero. To enter the DNS address, press the Folder Up or Down buttons on the remote control to set the value for each group of digits and then press the Select button or the Left or Right buttons (on the remote control) to enter the value and to move on to the next group. Repeat this until all

eight groups of digits have been entered. If you previously specied ‘Wired’ and then ‘DHCP

disable’, your radio should now connect to the router using the Ethernet cable (in which case skip to step 11).

If you specied ‘Wireless’, the next step is to set up the WiFi connection, starting with the

name of the wireless network (SSID) followed by the encryption options and password. To enterthe SSID, characters are selected and entered using the Folder Up or Down, Left or Right on the remote control and Select buttons. The radio scrolls through the available characters as well as the three controls on the right. The character currently highlighted will be entered when you press theSelect button. Do this as needed until the complete network name has been entered. The SSID setting is sensitive to upper and lower case characters and symbols. You must enter it exactly as set up in your router. The three controls on the right-hand side of the screen have special functions. You can quickly access these by pressing the Info button and then use the Folder Up or Down and Select buttons on the remote control as needed: select ‘ ’ to erase a character just entered (long press to clear); Info again to continue select ‘ ’ when the complete SSID has been entered select ‘ ’ to cancel and go back to the DNS settings screen

Having entered the SSID, you must enter details of the encryption system used on your

wireless network. This should be the same as specied in your router settings. If your network

does not use encryption, then select the ‘Open’ option. Your radio should then connect to the network, so skip to step 11. If your network uses WEP (Wired Equivalent Privacy) select the ‘Pre-Shared Key’ option then go to step 8. The remaining options are for WPA or WPA2 (WiFi Protected Access) – see step 9.

If you chose ‘Pre-Shared Key’ in step 7, you should then choose the WEP option. The

key should be entered using only the numbers 0-9 and the letters A-F. The key will be 10 characters long for 64-bit encryption and 26 characters long for 128-bit encryption. The radio willaccept lower-case letters a-f as equivalent to upper-case A-F. Spaces or special symbols are not permitted in WEP keys.

The three controls on the right-hand side of the screen have special functions. You can

quickly access these by pressing the Info button and then use the MenuUp or Down and

Select buttons as needed:

select ‘ ’ to erase a character just entered (long press to clear); Info again to continue

select ‘ ’ when the complete encryption key has been entered

select ‘ ’ to cancel and go back to the SSID settings screen

Once the key is entered the radio should connect to your network. Please skip to step 11.

WPA and WPA2 are similar, although WPA2 offers a higher level of security. Whichever

you selected in step 7, you then have to specify the variant used. They are TKIP (Temporal Key Integrity Protocol) and AES (Advanced Encryption Standard). As previously, the setting should match that used by your router. Some routers allow both to be specified, and the router will use whichever variant is supported by the connected device. AES is regarded as the more secure option if it is available.

The radio will then require you to enter the encryption key. This must be a string of between 8

10.

and 63 characters and must be identical to the key which has been entered into your router. Note – the encryption key is sensitive to the use of upper and lower case letters and symbols. Take care to enter the key exactly, or the radio will not be able to connect to your router. The three controls on the right-hand side of the screen have special functions. You can quickly access these by pressing the Info button and then use the Folder Up or Down and Select buttons as needed: select ‘ ’ to erase a character just entered (long press to clear); Info again to continue select ‘ ’ when the complete encryption key has been entered select ‘ ’ to cancel and go back to the TKIP / AES options screen Once the key is entered the radio should connect to the network.

While the radio is trying to connect to the network, it will display ‘Processing…’ when

11.

checking the encryption key (if using the WiFi connection) and then ‘Connecting…’. If the connection is made successfully, the radio will return to the Network settings menu. If the unit cannot connect, then it will display a ‘Failed to connect’ message and will return to the SSID entry screen (step 6).Once connected, the network settings are stored in the radio. The settings are retained whenthe radio is disconnected from the mains. You may now use the Back and Radio or Media buttons to access the functions of your radio.

Internet Radio

Internet Radio – the basics

Before you can use your radio to listen to broadcasts via the Internet, it is necessary to have connected it to your computer network using either the wireless (WiFi) connection or the wired Ethernet connection located on the back of the unit.

There are literally many thousands of radio broadcasts available via the internet as well ‘Podcasts’. Your radio provides several ways of

searching for broadcasts in order to make nding and choosing them

easier. Once you have found radio stations which you like, you may either store them as presets within the radio, or add them to a list of your favorite stations which your radio can access. The number of presets is limited (there are ten presets on the radio), but you can store as many favorites as you like.

You may search for an internet radio station by Location. If you know the name of the station and the country from which a station is broadcast

this may be the easiest method to nd a station. It is also a great way to

experience radio from other parts of the world. You may also search for an internet radio station by Genre. If you prefer a particular type of music, Blues for example, you may search for a radio station that broadcasts that type of music, and you can choose from a list of Blues radio stations regardless of location, or taking location into account.

If you know part of the name of an internet radio station, you can enter it into the radio and it will search for stations that match that name. This can be helpful if you are unsure of the location or genre of a particular station.

The DDR-62 radio connects to a radio station database which serves many users in many countries. This means that there is a very wide range of program content available. You can also search for stations which have been recently added to those available (new stations) or you can search for the most popular.

Selecting a radio station by location

Press the Standby button to switch the radio on. Then press the Radio button to select the

internet radio mode display.

Press the Tuning Up or Down buttons on the touch panel (Alternatively, Folder Up or Down

buttons on the remote control handset) to enter the main Internet radio menu. Press the Tuning Up or Down buttons on the touch panel (Alternatively, Folder Up or Down buttons on the remote control handset) until ‘Station list’ is highlighted on the display and then press the Select button to select the option.

Press the Tuning Up or Down buttons on the touch panel until ‘Stations’ is highlighted on the

display and then press the Select button. Note that the menu may offer one or more local selections based upon the country in which the unit is being used, according to your internet IP address (‘United Kingdom’and ‘BBC’ stations, for example).

Press the Tuning Up or Down buttons on the touch panel until ‘Location’ is highlighted on the display and then press the Select button to select.

Pre ss the Tuning Up or Down buttons on the touch panel to s croll through th e list of continents. When the desired continent is highlighted press the Select button to enter your selection.

The display will show a list of countries within the chosen continent. If there are many

countries shown you can scroll through the list continually in either direction. For example, if

the chosen continent was Europe, then to nd the United Kingdom scroll up from the top of

the list to the bottom by pressing the Tuning Up button. Press the Select button to choose the desired country.

You will typically find that you then have the option to select either ‘All Stations’ or one of

a number of categories. The lists are always sorted alphabetically, and long lists will wrap around from top to bottom or bottom to top.

Selecting a radio station by location - cont.

8. Press the Tuning Up or Down buttons on the touch panel to highlight your chosen radio station

and then press the Select button to enter your selection. The display will show ‘Connecting…’

while the radio connects to the new station. The station should then start playing. Adjust the

volume as needed.

If the station has on-demand content, that is, it gives the option of listening to programs which

have already been broadcast or to Podcasts, there will be an additional screen showing the

radio station name as well as a ‘Podcasts’ option. These are selected using additional menus,

determined by the radio station and the content. There may simply be a list of programs, or

there may also be options to choose from broadcasts on particular dates or days of the week.

The examples shown here are typical. Podcasts and Listen Again content can also be accessed

separately from the main Internet Radio menu.

If your radio cannot connect to a radio station

Note:

If your radio is unable to connect to an internet radio station it will generally either display ‘Network

Error’ or ‘Stopped’. This can be for many reasons, but typically Will be due to one of the following:

The radio station may not be broadcasting at the preset time.

The radio station may not be able to accommodate any more connections from internet listeners.

The broadcaster may limit listening to specic countries or regions.

There may be network congestion (either locally or at a distance) which is affecting the reliability

of the connection.

If your radio can connect, but the audio is not continuous and the radio keeps having to

reconnect, this may be due to the radio station only having limited connection capacity.

Selecting a radio station by genre

Press and hold the Menu button to enter the main Internet radio menu. Press the Tuning Up or

Down buttons on the touch panel (Alternatively, the Folder Up or Down buttons on the remote control handset) until ‘Station list’ is highlighted on the display and then press the Select button.

Press the Tuning Up or Down buttons on the touch panel (Alternatively, the Folder Up or Down

buttons on the remote control handset) until ‘Stations’ is highlighted on the display and then press the Select button.

Press the Tuning Up or Down buttons on the touch panel (Alternatively, Folder Up or Down

buttons on the remote control panel) until ‘Genre’ is highlighted on the display and then press the Select button.

Press the Tuning Up or Down buttons on the touch panel (Alternatively, the Folder Up or Down

buttons on the remote control handset) to scroll through the list of content types. This menu is normally cyclic – you can scroll the list continually in either direction. When the chosen genre is highlighted, press the Select button.

You then have the choice of ‘All Stations’ of the chosen genre, or a list of countries. Note if a

country is not shown then the station may still appear in the ‘All Stations’ list. Press the Tuning Up or Down buttons on the touch panel (Or Folder Up or Down buttons on the remote control) and the Select button to choose as needed.

A list of radio stations is then shown. Press the Tuning Up or Down buttons on the touch panel

(Or Folder Up or Down buttons on the remote control) until the desired station name is highlighted on the display.

Press the Select button to select the station. The display will show ‘Connecting…’ while it nds

the new station. If the radio is unable to connect this may be for one of the reasons explained.

Adjust the Volume as needed to set the listening level.

Searching for a radio station by name

There may be occasions when you know the name of a radio station but you do not know the

location or genre. This facility allows you to search for the station using a part (or parts) of the

radio station name.

Press and hold the Menu button to enter the main Internet radio menu. Press the Tuning Up or

Down buttons on the touch panel until ‘Station list’ is highlighted on the display and then press

the Select button.

Press the Tuning Up or Down buttons on the touch panel until ‘Stations’ is highlighted on the

display and then press the Select button.

Press the Tuning Up or Down buttons on the touch panel until ‘Search stations’ is highlighted

on the display and then press the Select button.

To enter the search word(s) press the Folder Up or Down, Left or Right buttons on the remote

control to highlight each character for the search in turn, and press the select button to enter. If

you make an error press the Info button to access the delete character ‘ ’ on the screen

and the character selection. After the nal character of the search has been entered, use the

Info button and then the Folder Up or Down buttons on the remote control handset to highlight

the ‘ ’ symbol on the screen and then press the Select button to nish.

The radio will search for radio stations that match your search data. If you include a space

between two search items the radio will look for station names which include both items. Thus

a search for ‘ROCK 100’ could nd a station called ‘100 Classic Rock Hits’ as well as a station

called ‘100.FM Rocks’

Press the Folder Up or Down buttons on the remote control handset to highlight the station that

you wish to listen to and press the Select button to conrm your choice. The display will show

‘Connecting…’ while it nds a new station.

Selecting a new or popular station

As described in the section ‘Internet Radio – the basics’, your radio connects via the the Internet

to a database of radio stations. This option is provided to highlight stations which are newly

added to the list of those available, or stations which are particularly popular with listeners around

the world. Your radio allows you to easily choose stations from these two categories, using

menus very similar to those used when nding stations by location and genre.

Press and hold the Menu button to enter the main Internet radio menu. Press the Tuning Up or

Down buttons on the touch panel (Or Folder Up or Down buttons on the remote control) until

‘Station list’ is highlighted on the display and then press the Select button.

Press the Tuning Up or Down buttons on the touch panel (or Folder Up or Down buttons on the

remote control) until ‘Stations’ is highlighted on the display and then press the Select button.

Press the Tuning Up or Down buttons on the touch panel (or Folder Up or Down on the remote

control) until ‘Popular stations’ or ‘New stations’ is highlighted on the display. Press the Select

button to enter your choice.

Press the Tuning Up or Down buttons on the touch panel (or Folder Up or Down buttons on

the remote control) to highlight the station that you wish to listen to and then press the Select

button to enter your choice. The display will show ‘Connecting…’ while the new station is

found.

Selecting a podcast / BBC Listen Again

Some radio stations allow you to listen to programs that have already been broadcast. The BBC’s

Listen Again service is an example of this. In addition, radio broadcasters and individuals may

make programs which are intended normally to be downloaded into a computer or copied onto

a portable media player. These are commonly known as Podcasts. On your radio, both Listen

Again programs and Podcasts are grouped together as Podcasts, and the same menu is used

to access and listen to both types of programming. Listen Again programs are also accessible

viathe Stations menu.

Press and hold the Menu button to enter the main Internet radio menu. Press the Tuning Up

or Down buttons on the touch panel (or the Folder Up or Down buttons on the remote control)

until ‘Station list’ is highlighted on the display and then press the Select button.

Press the Tuning Up or Down buttons on the touch panel (or Folder Up or Down buttons on the

remote control) until ‘Podcasts’ is highlighted on the display and press the Select button.

You may then search by location, genre, or using part of the name of the podcast. The

searches operate in exactly the same way as when searching for a conventional radio station.

Searching by location is done rst by continent, then by country. You may then list ‘All shows’

or search within a country by genre. Searching by genre is more direct, since once the genre is

chosen the next menu display shows a list of available podcasts. Searching by name operates

in the same way as when searching for a named radio station, selecting the ‘ ’ symbol when

you have entered the text. You may enter one or more pieces of text which will be used for the

search.

Press the Tuning Up or Down buttons on the touch panel (or the Folder Up or Down buttons on

remote control) and then press the Select button to conrm your chosen podcast. The display

will show ‘Connecting…’ while it nds the new program.

Presetting stations

With so many Internet radio stations available, it is desirable to have a means of rapidly selecting

the stations that you listen to most frequently. Your radio has ten memory presets which can

easily be set to store the details of any Internet radio station. The radio station presets are

retained in memory even when the radio is switched off. Please see also the section ‘Last

Listened’ and ‘Conguring My Favorite Stations’.

Storing a preset

1. Press the Standby button to switch on your radio. Tune to the required station using one of the

methods described on the preceding pages.

2. To store the currently playing radio station as a preset, press and hold the required Preset button

(1 – 10) on the remote control until the display shows ‘Preset stored’. The station will be stored

using the chosen preset button. Repeat this procedure as needed for the remaining presets.

3. Stations which are already stored in the presets may be over-written by following the above

procedure.

Recalling a preset

1. Press the Standby button to switch on your radio. Select the Internet radio mode using the

Radio button.

2. Momentarily press the required Preset button on the remote control. Your radio will then connect

to the station stored in preset memory. The preset used will be shown at the bottom of the

display screen.

Last Listened

It is often helpful to be able to go back to a station that you have already listened to. Your radio has

a ‘Last Listened’ feature which provides you with quick access to the ten most recently listened to

radio stations or podcasts. As each new radio station is listened to the oldest item is deleted from

the list. The Last Listened list is stored when the radio is disconnected from the mains.

1. With the radio switched on and in Internet radio mode, press and hold the Menu button. The

rst item on the menu is ‘Last listened’. With this item highlighted press the Select button.

2. The display will then show a list of the last ten Internet radio stations or podcasts. Press the

Tuning Up or Down buttons on the touch panel to highlight whichever you wish to listen to and

then press the Select button to cause your radio to reconnect to that radio station or podcast.

Display modes

Your radio has a range of display options when in Internet Radio mode. Note that not all

information may be available for all Internet radio stations

1. Press and release the Info button to cycle through the different options.

a. Description Displays information about the radio station or scrolling text messages

such as artist/track name, phone number etc.

b. Genre Displays program type information e.g. Pop, Classic, News, etc. and

the location of the current radio station

c. Reliability Displays the reliability of the data stream from the station currently

being received. d. Format Displays the bit rate and format of the station being received. e. Playback buffer Displays status when connecting to and playing a radio station. This

indicates the reliability of the data stream to your radio. If there are

no bars shown to the right of the dividing line then the data stream

reliability may be poor and you may nd that there are many breaks

in the audio (this is not always the case for REAL audio streams). f . Format Displays the current date.

Additional or alternative information may be displayed when listening to Podcasts, Categories

displayable can include…

Episode name Show description

Show genre Show language

Episode URL Bit rate

Codec Sampling rate

Whenever the radio is displaying an information screen (as opposed to a menu screen), the

time is displayed in the top-right corner of the display, and a WiFi strength or Ethernetconnection

indicator is shown in the bottom-right corner.

Customizing your radio

In addition to storing your favourite radio stations in the radio presets, your radio allows you to create customised lists of stations which can appear in two special menus on the radio called 'My Favourites' and 'My Added Stations'. Your radio uses a database which is accessed via the

Internet in order to nd out which radio stations are available and how it should connect to them.

You are able to add your personal selections to this database. These will only be accessible by you using your PC or your radio. You can choose the stations which will appear in the 'My

Favourites' menu from the large selection already listed. Additionally, if you nd a radio station

that is not listed then you may also add the Internet address (URL) of the station's audio stream to your selection. It will then appear on your radio via the 'My Added Stations' menu item.

Registering an account

Open the web site http://www.wifi radio-frontier.com using the Internet browser on your

1. computer. Click on the ‘Register here’ link and follow the on-screen instructions to register an account. During the registration process the web site asks for an access code. This allows it to uniquely identify your internet radio from the many others that it also provides data for. To obtain the access code, please follow these steps.

With your radio switched on and in Internet radio mode, press and hold the Menu button, then

2. select 'Station list' using the Folder Up or Down buttons on the remote control and Select buttons. Scroll down the Station list menu to the item called 'Help'. Press the Select button to enter the Help menu.

In the Help menu, select the menu item ‘Get access code.’ Provided that the radio is connected

3. to the Internet, a code will be displayed of typically seven characters (Upper case letters and numbers). Make a note of this code for the next step. If you need to re-register late you must repeat this process to get a fresh access code.

You should then use the code displayed by the radio to ll in the Access Code eld on the web

4. page when you set up your account. Once you have your account set up, if you have other radios which use the same data base, you may also add them to your account. You will need to get an access code from each radio in order to add it to the account. They may then share your favorite and added radio station details.

Customizing your radio - cont.

Conguring My Favorite Stations

Usin g the w ebsit e at http:// ww w.wi fi radi o- front ier.com it is

1. possible to search among the many radio stations that are available by location, genre, or language. You may also choose from new or popular stations.

When the radio stations that you have found are shown on your

2. computer screen, they are shown with a 'Play' icon and an 'Add to favourites' icon (the plus symbol and heart). Clicking on the 'Play' icon will allow you to hear the radio station via your computer. Clicking on the 'Add to favourites' icon will cause the radio station to be added to the list accessible via your radio.

To help you organise your favourites, and since you may have a

3. many after a while, the website will allow you to specify the name for a category or group under which the radio station will be listed on your radio. Suitable names might be 'Rock', 'Smooth', 'Mum's stations', and so on. Whenever you add another radio station to your favourites you can either add it to an existing category or create a new one.

Once you have Internet radio stations available in your ‘My Favorite

4. Stations’ list, you may play these stations from your radio. These stations will be available on your radio from the Internet radio menu item 'My Favourites'.

To look at , modify or delete your favou rite stations lists on t he

5. website, use the link 'My favourites' in the 'My account' area. To delete a favourite radio station, click on the icon with a heart and minus symbol.

Conguring My Added Stations

If you wish to listen to a radio which is not a currently held in the

1. database at http://www.wiradio-frontier.com, it is possible to add the details yourself. You will need to obtain the internet address (URL) for the audio system for the station that you wish to add. This may be information provided by the radio station itself, via its website, or perhaps passed to you from another listener.

Us the ‘My added stations’ li nk in the ‘My account’ area on the

2. website. This allows you to add details of new stations or to modify those already added. You can provide a name for the radio station which will be shown on your radio. You must also provide the web address, location and format details.

Once you have Internet radio stations available in your ‘My Added

3. Stations’ list, you may play these stations from your radio. These will be available on your radio from the Internet radio menu item called ‘My added Stations.’

It is possible to add the web addresses for audio streams which may

4. not be playable by your radio. If you attempt to play such a stream, your radio will normally display an error message of some kind. The Sangean DDR-62 can only play MP3, WMA, AAC and Real Audio internet radio streams.

To look at, modify or delete your added stations list on the website,

5. use the link ‘My added stations’ in the ‘My account’ area. To delete an added radio station, click on the icon with a heart and minus symbol.

Selecting your favorite stations

Press and hold the Menu button to enter the main Internet radio menu.

Press the Tuning Up or Down buttons on the touch panel until 'Station list' is highlighted on the

display. Press the Select button to enter the menu.

Press the Tuning Up or Down buttons on the touch panel until 'My Favourites' is highlighted on

the display. Press the Select button and your favorite stations list will appear on the display

(set up as described on the preceding page).

Press the Tuning Up or Down buttons on the touch panel to highlight the required station and

then press the Select button to conrm your selection. The display will show 'Connecting...'

while it nds the new station. If the station has on-demand content (that is, it gives the option of

listening to programs which have already been broadcast), 'Selecting a podcast / BBC Listen

again'. Should you be unable to connect to a particular station, please note that some radio

stations do not broadcast 24 hours per day, and some stations are not always on-line.

Selecting your added stations

1. Press and hold the Menu button to enter the main Internet radio menu. Press the Tuning Up or

Down buttons on the touch panel until 'Station list' is highlighted on the display and then press

the Select button.

2. Press the Tuning Up or Down buttons on the touch panel until 'My Added Stations' is highlighted

on the display and then press the Select button.

3. Press the Tuning Up or Down buttons on the touch panel to highlight the required station and

then press the Select button to conrm your selection. The display will show 'Connecting...'

while it nds the new station.

Should you be unable to connect to a particular station, please note that some radio stations do

not broadcast 24 hours per day, and some stations are not always on-line.

In addition, as mentioned in the previous section, it is possible to specify audio streams for 'My

added stations' which are not compatible with your radio. In this event the station will not be

playable.

The Sangean DDR-62 can only play MP3, WMA, AAC and Real Audio internet radio streams.

Note that the audio coding formats listed are generic terms. There are many variations of each

format, as well a variety of streaming protocols in use by different radio broadcasters. Your radio

has been designed to play the vast majority of coding and streaming formats in current use by

broadcasters.

Music player

Use with Windows, Apple Mac and Linux

The Music Player allows you to play audio fi les which are stored on computer in your network.

In order to play les from a computer on your network, your radio must connect to a le server application which uses the Universal Plug and

Play (UPnP) protocol. If your computer uses Windows 7, Vista or XP, then it is likely that your computer already has a UPnP server application available. Windows Media Player (versions 11 and 12) has this capability, and it is able to

make your les available to your radio. It also allows you to select les

by Album, Artist, and so on.

Windows Media Player 12 can serve MP3, WMA, AAC and WAV les

to your radio. Windows Media Player 11 is only able to serve MP3 and

WMA les to your radio. If you have your radio les stored in the FLAC

format, or if you are an Apple Mac or Linux user, there are other UPnP server applications which you may use with your radio.

The Music Play er on the r ad io can playback a udio files in M P3 ,

WMA, AAC, FLAC and WAV formats. WMA Lossless les can also be

played when using Windows Media Player as it will convert these to a compatible format before streaming them to the radio. Note that the

playback of les encoded using WMA Voice, WMA 10 Professional, and for les which have DRM protection are not supported.

Whe n using a UPnP server, the search and selectio n criteri a are determined by the server software, but typically include Artist, Album

and Genre. Many server applications also allow you to access your les

according to the folders within which they are stored as well as other criteria.

Windows Media Player is less exible than some other UPnP servers,

but is generally easier to set up. It is supplied as a standard component

of windows 7, Vista or XP.

Many UPnP server applications are also capable of sharing pictures

and video les to other network connected devices. if this is the case (as

it is with Windows Media Player 11 and 12) you may see the option of

choosing between ‘Music’, ‘Video’ and ‘Pictures’ on the Music Player’s

Menu. You should only select the ‘Music’ option. Content offered via the

alternative options will not be playable on your radio.

Some third part server application allow customization of the search

criteria and indexing methods. This can useful of you have a very large

collection of store music les.

Here is a short selection of alternative UPnP server applications,

although many other are available.

Twonky Media Server (Windows, Apple Mac, Linux)

TVersity (Windows)

Elgato EyeConnect (for Apple Mac OS X)

Media Tomb (Linux, MAC OS X)

Please refer to the documentation for your chosen server application for

full details of its conguration and usage.

Accessing your audio ﬁles via a UPnP server

If your computer is running Windows 7, then Windows Media Player version 12 includes a UPnP

server which will make your ﬁles available to your radio.

If you have Windows Vista or XP (Please refer to the section of ‘Accessing your audio ﬁles via a UPnP server using Windows Vista and XP’). There are other UPnP server solutions available for non-Windows users and for Windows users who may wish to use an alternative (see the

preceding section).

It is beyond the scope of this instruction book to cover all possible options for UPnP. We explain the use of Microsoft's Windows Media Player here since that will be the first choice for the

majority of users.

Set up UPnP access with Windows Media Player 12

Windows Media Player 12 (referred to here as WMP 12) can create a library from all the media

ﬁles available on your PC. To add new media ﬁles to the library, select 'Library', then 'Music',

then 'All music' or 'Artist', 'Album' etc. This will show you the current library contents.You may

then simply drag and drop ﬁles from other locations into the library. Alternatively, with media

ﬁles or folders on the screen, you may right-click on the ﬁle or folder and select 'Include in

library' and then select 'Music'. In this way you can quickly add additional content to your music

library.

In WMP 12 , click on 'Stream' (see picture at right) and then select 'Automatically allow devices

to play my media'. Then accept the 'Automatically allow all computer and media devices'

option. There are other options (see overleaf) but this is the simplest if you just wish to quickly

enable media streaming to your radio.

Press the Standby button to switch the unit on. Then press the Media button as needed until

the Music Player mode display is shown. The main 'Music Player' menu will then be displayed.

Set up UPnP access on a Windows PC - cont.

Press the Tuning Up or Down buttons on the touch panel until 'Shared media' is highlighted

and press the Select button to select. The radio will scan for all available UPnP servers. It may

take a few seconds for the radio to complete its scan. The radio will display '<Empty>' if no

UPnP servers are found.

After scanning, select your UPnP server using the Tuning Up or Down and Select buttons

on the touch panel. If you allowed automatic connection previously, your radio should now

connect and you may skip to the next page. If you did not permit automatic connections, your

radio will then normally display 'Unauthorized' at this stage.

Your PC may prompt you that there has been a connection to your UPnP server. Whether

prompted or not, in order that the radio may access the music ﬁles, you will need to click the

'Library' tab in WMP 12 and select the 'Stream...' item to open the 'Media Streaming' window.

elect 'Automatically allow devices to play my media' then select 'Automatically allow all

computer and media devices'.

Alternatively select 'More Streaming options' to enable sharing on a 'per device' basis.

In the 'More streaming options' window, the radio will be listed as a blocked device. Click on

the button shown to select 'Allowed'.

Note:

If you are using Microsoft Windows' ﬁrewall software, this should be correctly conﬁgured by

WMP 12. If you are using third party ﬁrewall software you may need to manually conﬁgure it to

allow your unit and WMP 12 to communicate.

On the radio, select the named server again using the Tuning Up or Down and Select buttons.

If WMP 12 is now able to communicate with your radio you will be presented with some media

selection options on the display.

Locating and playing media les using UPnP

Once the UPnP server has been congured to share media les with your radio, you may select

the les that you wish to play as follows:-

Press the Standby button to switch on the unit. Press the Media button as needed until the

Music Player mode display is shown. The main Music Player menu will then be displayed.

Press the Tuning Up or Down buttons on the touch panel until 'Shared media' is highlighted on

the display and then press the Select button to cause the radio to scan for UPnP servers. Note

that it may take a few seconds for the radio to complete its scan. The display will return to the

Music Player menu if no UPnP servers are found.

After a successful scan, press the Tuning Up or Down buttons on the touch panel to highlight

your UPnP server and then press the Select button. If the display shows multiple media types,

select 'Music'. (Some UPnP servers can serve pictures and video content to suitable devices.)

The radio will now list the media categories which are made available by the UPnP server -

for example, 'Album', 'Artist' and 'Genre'. Press the Tuning Up or Down buttons on the touch

panel to highlight which category you wish to browse, then press the Select button to conrm

your choice. If you wish to use the search function press the Tuning Up or Down buttons (on

the touch panel) until 'Search' is selected on the display. You may select characters to build a

keyword for searching for content to play. When you rst set up sharing with a UPnP server,

not all of your les will be available immediately. The UPnP server must look inside each le

to identify the artist and album information from 'tags' embedded in them. The server may also

need time to access the Internet to obtain additional information such as 'album art' which it

can display when you examine your music library on your PC. For a library of many les this

can take some time.

Media selection

When searching via UPnP you will have a selection of search criteria as determined by the UPnP

server software on your computer. This allows you to search by a given information type (Album,

Artist, Genre, etc.) and then to narrow the search to an album or to a particular track within an

album.

Some UPnP server applications allow the search options to be customized. The searches

described here are just examples of the possibilities.

Listening to a complete album

Use the Tuning Up or Down buttons to choose content by Artist, Album, Genre, etc. according

to your needs then press the Select button to enter your choice.

When you reach the album or folder the menu will then switch to showing the tracks in that

album or folder. When searching by UPnP they will normally be listed in track number order (but

as with the search criteria, this can vary according to the server application used).

With the first track in the album indicated, press the Select button. The album will then

begin playing. While the radio is playing from your media library, you may use the menus as

described above to choose a different selection. When you select the track from which to play,

the radio will then immediately begin playing the new selection.

Listening to a particular track

1. If you wish to play only a particular track from an album or folder, rst choose the album or folder

as described on the preceding pages.

2. Press the Tuning Up or Down buttons until the required track is highlighted.

3. Press and release the Select button. The track will begin playing. The radio will then play

subsequent tracks from the same album or folder.

Controlling playback

1. Press the Play/Pause button to pause playback of the current track.

2. If you press the Play/Pause button, playback will resume from the point where it was paused.

3. Press the Rewind/Tuning Down button to start playback of the previous track in the list.

4. Press the Fast-forward/Tuning Up button to start playback of the next track in the list.

5. Press and hold the Fast-forward/Tuning Up or Rewind/Tuning Down button to move through

the current track. The longer the button is pressed, the greater the speed at which the player

will move through the track. Release the button when the desired point is reached. (Note that

this feature is not supported when playing les encoded using the FLAC format.)

Controlling playback cont.

Repeat tracks

1. When playing a track activate the repeat option by pressing the Repeat button. Your selected

tracks will be played repeatedly and the repeat indicator will show on the display.

2. To turn off the repeat option press the Repeat button again.

Shufe tracks

1. When playing a track activate the shufe option by pressing the Random button. Your selected

tracks will be shufed and the shufe indicator will show on the display.

2. To turn off shufe press the Random button again.

If both Repeat and Shufe playback options are activated then both Repeat and Shufe icons will

be shown in the display.

Note:

The shufe play function may only be used if the current selection comprises fewer than 512

tracks.

Display modes

Your radio has a range of display options when in Music Player mode. Note that the availability of

information depends on the specic media les, their format and upon the server capability. (Not

all UPnP servers make information from the media  les available in the same way.)

1. Press the Info button to cycle through the different options.

a. Progress bar Displays the playback progress for the track currently playing. b. Artist Displays the artist information for the track currently playing. c. Album Displays the album information for the track currently playing. d. Format Displays the bit rate and format of the track currently playing. e. Buffer Di spl ays th e r adi os int ern al buffe r stat us dur ing media

playback.

Whenever the Music Player is displaying an information screen (as opposed to a menu screen),

the time is displayed in the top-right corner of the display, and a WiFi strength or Ethernet

connection indicator is shown in the bottom-right corner together with an indicator showing the

radio is obtaining the media from a UPnP server.

Playlists

Sometimes you may wish to set up a list of music tracks or albums which can then be played

without further ac tion - as background m usic for a party, for example. Your radio can be

congured to hold a queue of up to 500 tracks in a playlist menu. The tracks or albums for the

playlist can be selected from your UPnP server. The playlist is held in memory in your radio until

external power is removed, or until the playlist is cleared from the menu.

Adding a single track to your playlist

1. When selecting (or when playing) a track using a UPnP server press and hold the Select button

and the display will show 'Added to My playlist'.

2. The track will be added to the playlist for playback later.

Adding an entire album or folder

3. When using a UPnP server highlight the chosen album, artist or folder and press and hold the

Select button. The display will show 'Added to My playlist'.

4. Each of the tracks within the album, artist or folder selection will be added to the playlist

individually. This allows any unwanted tracks to be removed from the playlist if needed (see

the following sections).

Viewing your playlist

1. Press the Standby button to switch on the unit. Press the Media button as needed until the

Music Player mode display is shown. The Music Player menu will then be shown on the display.

2. Press the Folder Up or Down buttons (on the remote control) until 'My Playlist' is highlighted on

the display. Press the Select button to enter the playlist.

3. Press the Folder Up or Down buttons to scroll through the playlist. Tracks which are served via

UPnP will show their track name.

Erasing a track from the playlist

1. Press and hold the Menu button to enter the main Music Player menu.

2. Press the Folder Up or Down buttons (on the remote control) until 'My Playlist' is highlighted on

the display. Press the Select button to enter the playlist.

3. Press the Folder Up or Down buttons until the track you wish to erase is highlighted. Press and

hold the Select button (on the remote control).

4. You will be asked to confirm the deletion. To delete the track press the Folder Up or Down

buttons until 'YES' is highlighted on the display. Press the Select button to cause the track to

be deleted.

5. If you do not wish to delete the track highlight 'NO' and press the Select button to cancel the

operation.

Clearing the playlist

1. Press and hold the Menu button to enter the main Music Player menu.

2. To clear the whole playlist press the Folder Up or Down buttons (on the remote control) until

'Clear My playlist' is highlighted on the display. Press the Select button.

3. To clear the whole playlist press the Folder Up or Down buttons until 'YES' is highlighted on the

display. Press the Select button to cause the playlist to be cleared.

4. If you do not wish to clear the playlist highlight 'NO' and press the Select button to conrm.

Playing your playlists

1. Press and hold the Menu button to enter the main Music Player menu.

2. Press the Folder Up or Down buttons (on the remote control) until 'My playlist' is highlighted on

the display. Press the Select button.

3. To play the playlist from a particular track, press the Folder Up or Down buttons until the desired

track is highlighted then press the Select button to start play.

4. While playing from the playlist, you can use this function to jump to a particular track within the

playlist. While playing from the playlist, you may add additional tracks or albums or remove

specic tracks (please see the preceding sections).

DAB Radio

Using DAB mode for the rst time

Carefully extend the telescopic aerial.

Press the Standby button to switch on the radio. If the radio has been used before the last

used mode will be selected.

Press the Radio button as needed so that DAB radio mode is selected on the display.

If this is the rst time that DAB mode is used a quick scan of the Band III DAB channels will be

carried out. The display will show 'Scanning'. (If the radio has been used before the last used

station will be selected instead.)

During the scanning process, as new stations are detected the station counter will increase

and the stations will be added to the list which is stored in the radio. The bar graph indicates

the progress of the scan.

When scanning is completed the radio will list the stations found (in numeric-alpha order

0....9...A...Z), unless it has previously been tuned to a DAB station. Press the Folder Up or

Down buttons to scroll through the list of available DAB radio stations. Press the Select button

to select the highlighted station. The display may show 'Connecting...' while the radio re-tunes.

Use the Volume buttons to set the sound level as needed.

If the station list is still empty after the scan the display will show 'Service not available'. If

no stations are found it may be necessary to relocate your radio to a position giving better

reception.

Selecting a DAB radio station

1. When playing a DAB radio station, the display normally shows the name of the current station

with other related information.

2. Press the Folder Up or Down buttons to access the radio station list and to scroll through the

available stations.

3. Press the Select button to select the highlighted station. The display may show 'Connecting...'

while the radio re-tunes.

4. Use the Volume buttons to set the sound level as needed.

Note:

If the display shows 'Station Not Available' it may be necessary to relocate your radio to a position

giving better reception. A question-mark in front of the station name merely indicates that the

station has not recently been detected by the radio. It may still be available.

Secondary services

Some DAB radio stations can have one or more secondary stations associated with them.

Typically these are not broadcast continually. If a station has a secondary station available then

the secondary will appear in the list of station names beneath the main (or primary) station.

Examples are the programs 'Daily Service' and 'Parliament' on BBC Radio 4.

1. To listen to a secondary service, press the Folder Up or Down buttons to scroll to the chosen

station, and press the Select button to tune to the station. If the secondary service is not available

(off-air) then the primary service will be selected.

Display modes

Your radio has a range of display options when in DAB mode:-

1. Press the Info button to cycle through the different options.

a. Text Displays text messages such as the artist or track name,

phone in number, trafc alerts, etc.

b. Program Type Displays the type of station being listened to such as Pop,

Classic, News etc.

c. Multiplex Name / Frequency Displays t he nam e of the DAB multiplex to w hich the

current station belongs as well as its broadcast frequency.

d. Signal error / strength Displays the signal error and strength for the station being

listened to. A lower error number indicates a better quality

of radio signal. The signal strength graph can be used when

positioning the radio or its antenna. For good reception the

graph should occupy three or more blocks.

e. Bit rate and audio type Displays the digital bit rate and audio coding information for the

station being listened to.

f . Date Displays the current date.

A signal strength indicator is always shown in the lower area of the display on the right hand side.

If the broadcast being received is in stereo, then the stereo speaker symbol will be shown.

If the currently tuned station has been stored as a preset, then the preset number will also be

shown.

Finding new DAB radio stations

Should you wish to use your radio for DAB reception in a new location, or if no stations were

detected during the initial scan, you can follow this procedure to allow your radio to nd out which

DAB radio stations are available.

1. Ensure that the telescopic antenna is extended, and then press the Radio button as needed to

select DAB radio mode.

2. Once in DAB mode press and hold the Menu button.

3. Press the Folder Up or Down buttons until 'Full scan' is highlighted on the display.

4. Press the Select button to initiate the scan. The display will show 'Scanning' and your radio will

perform a scan of the DAB Band III frequencies. As new stations are found the station counter

will increase and stations will be added to the list. The bar graph indicates the progress of the

scan.

5. Alternatively press the Auto button on the remote control to initiate a scan of the DAB Band III

frequencies. The Auto button may not operate in all display modes. In this case use the menu

option above.

Manual Tuning

Manual tuning allows you to tune directly to the various Band III DAB channels (5A to 13F).

1. When in DAB mode press and hold the Menu button so that the display shows the DAB menu.

2. Press the Folder Up or Down buttons until 'Manual tune' is highlighted.

3. Press the Select button to enter manual tune mode.

4. Press the Folder Up or Down buttons to choose the required DAB channel.

5. Press the Select button to cause the radio to tune to the chosen channel.When the radio has

tuned, the display shows the channel number and frequency, and the name of the DAB multiplex

found (if any). A bar graph shows the signal strength and is useful if you need to reposition the

radio or its aerial. The minimum signal marker 'I' which separates the left and right parts of the

signal graph shows the minimum signal level required for satisfactory reception. Any new radio

stations found on the tuned DAB multiplex will be added to the list stored in the radio.

6. Press and hold the Menu button or press the Back button to choose a different frequency.

7. Press the Menu or Back button a second time to access the main DAB menu th en select

'Station list' to return to normal tuning.

Dynamic Range Control setting

Dynamic Range Control (also known as DRC) can make quieter sounds easier to hear when your

radio is used in a noisy environment by reducing the dynamic range of the audio signal.

1. Press the Standby button to switch on your radio.

2. Press the Radio button as needed to select DAB radio mode.

3. Press and hold the Menu button to enter the DAB menu.

4. Press the Folder Up or Down buttons until 'DRC' is highlighted on the display.

5. Press the Select button to enter the DRC adjustment mode. The current DRC setting will be

indicated with an asterisk.

6. Use the Folder Up or Down buttons to highlight the required DRC setting (the default is Off).

'DRC Off' - DRC is switched off, Broadcast DRC will be ignored.

'DRC high' - DRC is set as sent by broadcaster.

'DRC low' - DRC level is set to 1/2 that sent by broadcaster.

7. Press and release the Select button to conrm the setting.

Note:

Not all DAB broadcasts use the DRC function. If the broadcast does not provide DRC information,

then the DRC setting in the radio will have no effect.

Station order setup

Your radio has 3 station order settings from which you can choose. The station order settings are,

alphanumeric, ensemble and valid.

Note: The default station order on your radio is alphanumeric.

Press the Standby button to switch on your radio.

Press the Radio button as needed to select DAB radio mode.

Press and hold the Menu button to enter the DAB menu list.

Press the Folder Up or Down buttons until 'Station order' is highlighted. Press the Select button

to enter the station order adjustment mode.

Use the Folder Up or Down buttons to choose between 'Alphanumeric',

'Ensemble' and 'Valid'.

'Alphanumeric' - sorts the station list alpha-numerically 0...9 A...Z.

'Ensemble' - organizes the station list by DAB multiplex.

'Valid' - shows only those stations for which a signal can be found.

The current setting is indicated by an asterisk.

Press the Select button to select the required station order.

Press the Back button as needed to return to the DAB menu or to the stations list.

Prune stations

If you move to a different part of the country, some of the stations which were listed may no

longer be available. Also, from time to time, some DAB services may stop broadcasting, or may

change location or frequency. Stations which cannot be found, or which have not been received

for a very long time are shown in the station list with a question mark. The Prune stations function

will delete the marked DAB stations from your station list.

1. Press the Standby button to switch on your radio.

2. Press the Radio button as needed to select DAB radio mode.

3. Press and hold the Menu button to enter the DAB menu.

4. Press the Folder Up or Down buttons until 'Prune invalid' is highlighted. Press the Select button.

5. To cause the stations list to be pruned, eliminating unavailable stations press the Folder Up or

Down buttons until 'YES' is highlighted on the display.

6. Press the Select button to cause the invalid station names to be removed from the station list.

If you do not wish to prune stations, highlight 'NO' and then press the select button. The display

will revert to the previous menu.

Note:

If you have moved your radio to a different part of the country you should also carry out a search

for new stations (please see the section 'Finding new stations')

FM Radio

Operating your radio in FM mode

Carefully extend the telescopic aerial and press the Standby button to switch on your radio.

Press the Radio button as needed to select FM radio mode.

Press the Tuning Up button (on the radio) or the Tunning Up button (on the remote control) and

then the Auto button on the remote control. The displayed frequency will increase. Your radio

will scan up the FM band from the currently displayed frequency and will stop scanning when it

nds a station of sufcient strength.

The display will show the frequency of the signal which has been found. If RDS information

is available, after a few seconds the display will show the radio station name. If you only hear

hiss or interference, simply press the Auto button to scan further. Your radio may have found a

spurious interference signal.

To find more FM stations press the Auto button (on the remote control) to repeat the scan

operation. To scan down in frequency, press the Tunning Down button (on the radio) or the

Tunning Down button (on the remote control) and then the Auto button. Your radio will scan

down the FM band from the currently displayed frequency and will stop scanning when it nds

a signal of sufcient strength.

Alternatively press and hold the Tunning Up on the radio to scan up in frequency or the

Tunning Down button to scan down the FM band.

When the end of the waveband is reached your radio will recommence tuning from the

opposite end of the waveband. Use the Volume buttons to adjust the sound level as needed.

Manual tuning

Carefully extend the telescopic aerial and press the Standby button to switch on your radio.

Press the Radio button as needed to select FM radio mode.

Press the Tuning Up or Down buttons (on the radio) or Tuning Up or Tuning Down buttons

(on the remote control) to control the frequency that the radio will tune to. The frequency

will change in steps of 50kHz. When the end of the waveband is reached the radio will

recommence tuning from the opposite end of the waveband.

Use the Volume buttons to adjust the sound level as needed.

Display modes

Your radio has a range of display options when in FM mode:-

1. Press the Info button to cycle through the different options.

a. Text Displays text messages such as the artist or track name, phone in

number, trafc alerts, etc.

b. Program Type Displays the type of station being listened to such as Pop, Classic,

News etc. c. Frequency Displays the frequency of the FM signal. d. Date

Note:

If no RDS information is available, then the radio will only be able to display the frequency. There

will be no text or program type information available under these conditions. The radio only

provides displays when there is information available. So if there is no text, for example, that

display is not available. The RDS indicator at the bottom of the display shows that there is some

RDS data present in the broadcast being received. The stereo speaker display shows that the

radio is receiving a stereo broadcast (please see also 'Stereo/Mono switching').

Displays the current date.

Scan setting

When using the FM mode your radio can be set to either scan local stations or to scan all stations

including distant radio stations.

Press the Radio button as needed to select FM radio mode.

Press and hold the Menu button to enter the FM menu.

Press the Folder Up or Down buttons on the remote control(or Tuning Up or Down buttons on

the touch panel) until 'Scan setting' is highlighted and then press the Select button to enter the

scan adjustment mode. The current scan setting is indicated with an asterisk.

To set your radio so that only the stations with the strongest signals are found during scanning

press the Folder Up or Down buttons until 'YES' is highlighted. Press the Select button to

conrm the setting. (Normally this will restrict scanning to local transmissions.)

Alternatively, to set your radio so that all available stations are found during scanning (local

and distant transmissions) press the Folder Up or Down buttons until 'NO' is highlighted. Press

the Select button to conrm the setting.

Press and hold the Menu button to return to the normal FM mode display.

Stereo / Mono switching

If the FM radio station being listened to has a weak signal, some hiss may be audible. It is

possible to reduce this hiss by forcing the radio to play the station in mono rather than stereo.

Press the Radio button as needed to select the FM radio mode display and tune to the required

FM station as previously described.

Press and hold the Menu button to enter the FM menu.

Press the Folder Up or Down buttons until 'Audio setting' is highlighted on the display. Press

the Select button to enter the audio setting mode. The current setting is indicated with an

asterisk.

To switch to mono in order to reduce the hiss from a weak FM signal press the Folder Up or

Down buttons until 'YES' is highlighted. Press the Select button to conrm the setting.

Alternatively, to return to the normal automatic 'stereo or mono' mode press the Folder Up or

Down buttons until 'NO' is highlighted. Press the Select button to conrm the setting.

Press and hold the Menu button to return to the normal FM mode display.

Presetting stations in DAB and FM modes

There are 10 memory presets each for DAB and FM radio. They are used in the same way for each operating mode.

1. Press the Standby button to switch on your radio.

2. Tune to the required radio station as previously described.

3. To store the station as a preset, press and hold the required Preset button (1 - 10) until the display shows 'Preset stored'. The station will be stored under the chosen preset button. Repeat this procedure as needed for the remaining presets.

4. Stations which are already stored in the presets may be over written by following the above procedure.

Note:

The radio station presets are retained in memory when the radio is switched off and disconnected from the mains supply.

Recalling a preset in DAB and FM modes

1. Press the Standby button to switch on your radio.

2. Select the required operating mode using the Radio button.

3. Momentarily press the required Preset button. Your radio will then tune to the station stored in the selected preset memory. The chosen preset number is also shown in the lower area of the radio display, e.g. 'P2'.

4. Alternatively in FM radio mode only, use the Folder Up or Down buttons (on the remote control) to access FM presets already stored.

Compact discs

CD-R/CD-RW discs

Use only Digital Audio CDs which have the symbol.

DO NOT USE THESE TYPES OF DISC:

Mini (8cm) CDs. Use only full-size 12cm discs. Mini CDs will jam

the feed mechanism.

Discs which do not have a complete metallic reection layer. Discs

with a large transparent section will not be detected and may fail

to play or eject.

Discs which are extra thin or exible. Such discs may fail to feed

in or out correctly and may jam the CD mechanism.

Never write on a CD or attach any sticker to the CD. Always hold the

CD at the edge and store it in its box after use with the label facing up.

To remove dust and dirt, breathe on the CD and wipe it with a soft, lint

free cloth in a straight line from the centre towards the edge. Cleaning

agents may damage the CD.

Do not expose the CD to rain, moisture, sand or to excessive heat. (e.g.

from heating equipment or in motor cars parked in the sun). CD-R/CD-

RW discs

Your DDR-62 can playback CD-DA format audio CD-R/CD-RW discs

that have been nalized upon completion of recording.

Your DDR-62 may fail to play some CD-R/CD-RW discs due to poor

recording and wide variation in quality of the CD-R/CD-RW disc.

Finalizing enables a CD-R/CD-RW disc to playback on audio players

such as your DDR-62. A disc which has not been nalized may have

information added to it using a computer but may always be playable.

Inserting a CD

Ensure the CD player is empty before inserting a disc. If there is a disc in the player then the

CD indicator will be lit. If you cannot insert a disc, press the CD Eject button to remove the CD

currently in the player.

1. Press the Standby button to switch on your radio.

2. To select the CD mode press the Media button until 'CD' shows on the display.

3. To eject a CD press and release the CD Eject button. To reload a CD that has just been ejected,

press the Eject button a second time.

4. Insert a disc with printed side facing up into the CD slot. The disc will be loaded automatically.

The unit will check the CD type and load its track list. The display will show 'Loading' and then

'Reading' as the information is read.

5. If you load a disc containing MP3 or WMA les your radio will enter the MP3 / WMA mode.

Playing a CD

1. Press the Play / Pause button to start playing the disc. The display will show the first track

number.

2. Adjust the Volume to the required setting.

3. To pause playing press the Play / Pause button. To resume press the Play / Pause button again.

4. To stop play, press the Stop button. The total number of CD tracks and the stop symbol (■) will

be displayed. If you put the unit into standby mode without pressing the Stop button, then the

next time the unit is switched on it will return to the previously played track.

5. To take out the CD, press the CD Eject button. The display will show 'Eject'. In order to protect

the disc if it is not removed, the unit will reload the CD after 10 seconds and then enter standby

mode.

Selecting a track

1. While the CD is playing, press either the Fast-forward or Rewind buttons to change to the

desired track. The updated track number is shown in the display.

2. You can also skip tracks when the player is paused or stopped. Skip to the desired track using

the Fast-forward or Rewind button, release the button when the desired track is displayed.

3. Press the Play / Pause button to play the selected track.

Selecting a desired track

1. For track numbers 1-9 simply press the corresponding digit button. For track numbers ten and

above press the required digits using the 10/0 button to enter the digit zero.

2. If the track number entered exceeds the number of tracks on the CD, then the last track on the

CD will be played.

Search function

1. While the CD is playing, press and hold the Fast-forward or Rewind button. Release the button

when the desired part of the track is reached.

Repeat a single track

2. While the CD is playing, press the Repeat button until the repeat single track symbol ( )

appears in the display. The current track will be repeated.

Repeat all tracks

3. While the CD is playing, press the Repeat butto n until the repea t all tracks symbol ( )

appears in the display. All of the tracks on the CD will be played repeatedly.

Play tracks introduction

4. While the CD is playing, press the Repeat button until the track introduction symbol (INTR)

appears in the display. The first 10 seconds of each track will be played. When the desired

track is reached, press the Repeat button once more to revert to normal play mode.

Shufe tracks

5. While the CD is playing, press the Random button (on the remote control) until the shuffle

symbol ( ) appears in the display. The tracks will be shufed. To cancel the shufe function,

press the Random button a second time.

CD track programming

In addition to playing of complete CDs, selected tracks, or a random selection, the CD player

allows you to program a sequence of up to 20 tracks to be played in whatever order you choose.

1. With the unit in CD mode and with a CD inserted, make sure that the CD is stopped (press the

Stop button).

2. To enter programming mode, press the Auto button (on the remote control).

3. Choose the rst track using the Fast-forward or Rewind buttons.

4. Press the Auto button to enter the selected track into the program.

5. Choose another track using the Fast-forward or Rewind buttons, and enter it into the program

using the Auto button (track 10 in example shown).

6. Repeat step 5 to store as many as 20 tracks in the program.

7. When the program is complete, press the Play / Pause button to start playing. The tracks will

then be played in the order that you have just programmed.

8. Pressing the Stop button, or switching to another operating mode will erase the program.

Note:

If you are programming the tracks using a CD with MP3 or WMA les in folders (see the following

sections), you can also use the Up or Down Folder buttons to specify the folder in steps 3 and 5

above.

MP3 / WMA CD Mode

The DDR-62 is able to play CD-R and CD-RW discs containing MP3 and WMA files. It is

assumed in this section that a le is equivalent to a CD track.

An MP3 / WMA CD may not contain more than 512 les and not more than 99 folders. MP3 and

WMA les should be created with an audio sample rate of 44.1kHz (this is normal for les created

from CD audio content). MP3 and WMA data rates up to 320 kilobits per second are supported.

WMA Lossless files are not supported. The unit will not play files which include digital rights

management (DRM) protection.

When burning CD-R and CD-RW discs with audio les, various problems may arise which could

lead to problems with playback. Typically such problems are caused by poor CD writing or audio

encoding software, or by the hardware settings of the PC's CD writer, or by the CD being used.

Should such problems arise, contact the customer services of your CD writer or software

manufacturer or look in their product documentation for relevant information. When you are

making audio CDs, take care to observe all legal guidelines and ensure that the copyright of third

parties is not infringed.

1. To select the CD mode press the Media button until 'CD' shows on the display, or insert a suitably

prepared CD-R or CD-RW disc.

2. Insert a CD with printed side facing up into the CD slot. The disc will be loaded automatically.

The unit will check the CD type and load its track list. The display will show "loading" and then

"reading" as the information is read. If there are many les or folders on the CD then it may

take some tens of seconds to read all of the le and folder names and to identify those which

are playable (with .mp3 or .wma lename extension).

Playing an MP3 / WMA CD

1. Press the Play / Pause button to start playing from the CD. The display will show the rst folder

and le numbers - " 01" and " 001".

2. To pause playing press the Play / Pause button. To resume playing press the Play / Pause

button again.

3. To stop play, press the Stop button. The total number of les on the disc and 'Stop' will be displayed.

If you put the unit into standby mode without pressing the Stop button, then the next time the

unit is switched on it will return to the previously played le.

4. To take out the CD, press the CD Eject button. The display will show 'Eject'. In order to protect

the disc if it is not removed, the unit will reload the disc after 10 seconds and then enter standby

mode. To reload a CD that has just been ejected, press the Eject button a second time.

Selecting a le

1. While the CD is playing, press either the Fast-forward or Rewind buttons to change to the

desired le. The le number is updated in the display. If there is more than one folder, when all

les in the current folder have been played the next folder will be played.

2. You can also skip files when the player is in stop mode. Skip to the desired file using the

Fast-forward or Rewind buttons and release the button when the desired le number is displayed.

3. Press the Play / Pause button to play the selected le.

Select a specic le

1. For file numbers 1-9 simply press the corresponding digit button. For file numbers ten and

above press the required digits using the 10/0 button to enter the digit zero.

2. If the le number entered exceeds the number of playable les on the CD, then the last le will

be played. File numbers up to 512 may be entered. The numbers of les in folders are added

together. So, for example, if the rst two folders each contain 10 les, then entering 15 will play

the fth le in the second folder.

Search function

1. While the MP3 / WMA CD is playing, press and hold the Fast-forward or Rewind buttons. Release

the button when the desired part of the current le is reached.

To skip to another folder

1. With the MP3 / WMA CD in stop or play mode, press and release either the Up or Down Folder

buttons (on the remote control). The rst le of the next or previous folder will be played.

Repeat, Intro, shufe and Programmed play

The DDR-62 allows you to u se the s ame playback option s for file s as can be used for

conventional audio CDs. In addition to Repeat Once and Repeat All options, there is also a

Repeat Folder facility.

Display modes

Your radio has a range of display options when in MP3 / WMA CD mode. Note that not all

information may be available for all les.

1. Press the Info button to cycle through the different options.

a. Progress Displays the playback progress for the track currently playing. b. File name Displays the le name and audio format of the track currently playing. c. Album Displays the name of the album from which the current track is taken. d. Artist Displays the name of the artist for the currently playing track. e. Title Displays the title of the currently playing track.

Using SD cards or USB memory devices

This section describes how to use your radio to access and playback your audio les via USB

memory devices and Secure Digital (SD, SDHC) cards. The DDR-62 can also record to SD, SDHC or USB media in MP3 format.

Important:

Your radio is only designed to work with USB memory ash memory devices. It is not intended to

be connected to hard disk drives or any other type of USB device.

The DDR-62 has been tested with a range of USB memory devices of up to 64GB capacity and SD cards up to 2GB and SDHC cards up to 16GB are supported. However, there are many different card variants available and not all cards can be guaranteed to work in the DDR-62.

Memory must use the FAT 32 ling system in order to operate in the DDR-62.

Audio formats supported for playback are MP3 and WMA. Playback doesnot support files

encoded using WMA lossless, WMA Voice, WMA 10 professional, nor les of any format which

have DRM protection.

SD card and USB slots are located behind the front panel beneath the touch panel. This is opened by pushing and releasing the right hand corner of the panel. To close the panel, press the right-hand side of the panel door until it clicks back into place.

Do not attempt to open or close the panel door using the left hand edge as this may distort or damage the panel.

Cautions:

In order to minimize the risk of damage to your radio, your SD card or your USB Memory, please place the unit such that the device cannot easily be knocked while it is inserted in the socket. Remove the USB or SD card before carrying the unit or if not using the USB or SD feature for a prolonged period. Place the unit in Standby mode removing your SD card or USB memory device.

Inserting and removing memory devices

1. To insert an SD card into your radio push the card label side upward and gold contacts rst

into the card slot on the front of your radio until it clicks. To remove the card, push the card in

so that it clicks once more. It will then be pushed out slightly allowing removal.

USB memory devices plug into the rectangular slot on the right hand side, behind the front panel.

Note: that the USB socket is upside down compared to those commonly found on PCs.

2. To select either SD card or USB mode press the Media button until the desired mode is shown

on the display.

Playing MP3 / WMA les - SD / USB

1. Press the Play / Pause button to start playing from the SD card / USB memory device. The display

will show the rst folder and le numbers - " 01" and " 001".

2. To pause playing press the Play / Pause button. To resume playing press the Play / Pause button

again.

3. To stop play, press the Stop button. The total number of les and folders on the media and the

stop symbol (■) will be displayed.

If you put the unit into standby mode without pressing the Stop button, then the next time the unit

is switched on it will return to the previously played le.

Selecting a le

1. While the SD card / USB memory device is playing, press either the Fast-forward or Rewind

buttons to change to the desired le. The le number is updated in the display. If there is more

than one folder, when all les in the current folder have been played the next folder will be played.

2. You can also skip files when the player is in stop mode. Skip to the desired file using the

Fast-forward or Rewind buttons and release the button when the desired le number is displayed.

3. Press the Play / Pause button to play the selected le.

Select a specic le

1. For le numbers 1-9 simply press the corresponding digit button. For le numbers ten and above

press the required digits using the 10/0 button to enter the digit zero.

2. If the le number entered exceeds the number of playable les on the SD card / USB memory

device, then the last le will be played.

File numbers up to 512 may be entered. The numbers of les in folders are added together. So,

for example, if the rst two folders each contain 10 les, then entering 15 will play the fth le in

the second folder.

Search function

1. While the SD card / USB memory device is playing, press and hold the Fast-forward or Rewind

buttons. Release the button when the desired part of the current le is reached.

To skip to another folder

1. With the SD card / USB memory device in stop or play mode, press and release either the Up

or Down Folder button (on the remote control). The rst le of the next or previous folder will

be played.

Repeat, Intro, shufe and Programmed play

The DDR-62 allows you to u se the s ame playback option s for file s as can be used for

conventional audio CDs. In addition to Repeat Once and Repeat All options, there is also a

Repeat Folder facility.

Recording to SD / USB

Your DDR-62 radio has been designed to allow you to make recordings to SD / SDHC cards or to

USB connected memory devices. Recordings are made in MP3 format at 128k bits per second.

SD / SDHC or USB memory media must use the FAT32 le system in order to operate with the

DDR-62. Such media is usually supplied already formatted or can be formatted using a PC with a

suitable card reader (for SD / SDHC cards) or USB connection (for USB memory).

It is possible to record onto media which already contains les written by the radio or using your

computer. The recorded les will be added to those already present on the media.

Making a recording

1. Select the desired source for the recording (Internet Radio, DAB, FM, CD, etc.). Internet Radio

is shown in the illustration. Set the volume to the required listening level (the volume of the

recording will not be affected by this).

2. Insert the media on to which the recording is to be made.

3. Press the Record button. The display will show "Record initial...". Recording will then start with

the recording source shown on the display. If only one media type is present, then after a short

while recording will start. If both SD and USB media are detected, then the radio will default to

the option previously set. The default media option is accessed through the 'System settings'

menu then by selecting 'Rec default dest.'. Select 'SD card' or 'USB' memory as needed.

Making a recording cont.

If recording from a CD, recording will be started from the beginning of the currently playing track.

Each track on the CD will be recorded as a separate ﬁle on the media.

4. In order to stop the recording press the Record button once more.Recording will stop and a ﬁle

will have been written to the storage media.

Files that have been written to the media are held in a folder called "RECORD". Recordings are

held in sub-folders according to the source used for the recording.

The illustration shows the folders as they may appear on a PC running Windows with ﬁles in the

CD folder being shown on the right.

Note:

The SD card / USB me mory device shoul d only be removed when recording is stopped.

Removing media while recording is in progress may corrupt data on the card leading to the loss

of ﬁles previously written.

The USB connection is primarily intended to be used to allow the DDR-62 to play MP3 and WMA

files from solid-state fl ash memory devices. You may be able to play files which have been

stored on a USB hard disc drive (but the drive must have its own power supply). If you wish to

play ﬁles from another music player, then we recommend that this is connected to the Auxiliary

input socket.

Recording MP3 / WMA les from CD / SD / USB

In addition to recording from conventional sources, the DDR-62 radio can also record from MP3

or WMA les that have previously been written to CD, SD or USB media. In this case the les are

copied rather than re-encoded to MP3 in order to avoid a reduction in quality. You may copy les

from CD or SD to USB and from CD or USB to SD.

Select the desired source for the recording (SD, USB or CD).

Press the Play button to start playing the source media (if it does not automatically start). Set

the volume to the required listening level (the volume of the recording will not be affected by

this).

Insert the media that the les will be recorded on to (SD or USB).

Press the Record button. The display will show "Record initial...".

If only one media type is present, the audio will stop while the source media is taken back to

the beginning of the current le. Recording will then start.

If both SD and USB media are detected, then the radio will default to the option previously set.

The default media option is accessed through the 'System settings' menu then by selecting

'Rec default dest.'. Select 'SD card' or 'USB' memory as needed. The source media will be

taken back to the beginning of the current le and recording will then start.

In order to stop the recording press the Record button once more. Recording and playback will

stop and all les that have been played will have been copied to the storage media.

Deleting les

After having recorded les to SD or USB media, you may later wish to delete them in order to

reclaim the space used. The DDR-62 can be used to delete individual les, or to delete all of the

media les on the media.

Deleting a single le

1. With the radio in USB or SD mode, and with the media inserted and the le you wish to delete

is currently playing, press and hold the Menu button.

2. Press the Folder Up or Down buttons on the remote control (or Tuning Up or Down on the touch

panel) until 'Delete this le' is highlighted on the display.

3. Press the Select button. The display will ask you if you wish to 'Delete this le?'

4. If you do not wish to delete the le, use the Folder Up or Down button to highlight 'NO' and

press the Select button to conrm.

Alternatively, to delete the le use the Folder Up or Down button to highlight 'YES' and press the

Select button to conrm deletion.

The le will be deleted and the details of the next le will be displayed. If there are no more les

left on the media, then the display will show 'No Music File'.

Note: Once a le has been deleted, it is not possible to recover the le.

Deleting les cont.

Deleting all les

1. With the radio in USB or SD mode, and with the media inserted press and hold the Menu button.

2. Press the Folder Up or Down buttons until 'Delete all' is highlighted on the display.

3. Press the Select button. The display will ask you if you wish to 'Delete all les?'

4. If you do not wish to delete all the les, use the Folder Up or Down button to highlight 'NO' and

press the Select button to conrm.

Alternatively, to delete all the les on the media use the Folder Up or Down button to highlight

'YES' and press the Select button to conrm deletion.

All the les will be deleted. If there are no more les left on the media, then the display will show

'No Music File'. The operation will generally only take a few seconds. When completed, the

display will show 'No Music File'.

Note: Once the les have been deleted, it is not possible to recover the previous contents.

USB charging

Charging with USB socket

● The USB jack can also provide power for the USB memory stick with 1A 5V maximum and most

of iPhone models or smartphones. However, it does not support external Hard disk drive and

all of mobile phones and electronic device.

● The maximum volume of the output power speaker will decrease when your USB is charging.

Important:

Do not connect this USB socket with your PC USB port, as it highly possible may cause

breakdown of the units.

Standby USB charger

By default, your radio cannot charge your handheld device with USB socket when it is in standby.

This minimizes power consumption but it does mean that you will need to switch that radio on

manually in order to charge your device with the USB socket.

If you need to be able to charge your device even when it has been put into standby, make sure

you choose "YES" in the "Standby USB charger" option in the system setting menu.

Clock and Alarms

Automatically updating the clock

Your radio will normally update the clock automatically when connected to the internet. If you

enter a time setting manually, the radio will calculate a local time offset which is then stored in

memory. Whenever it synchronizes the clock using the internet, including after a power failure,

your radio will then set the clock automatically using this information. You may wish to use the

radio away from the internet, in which case you may specify that the unit sets its clock from

DAB or FM radio broadcasts. After a power failure the radio will then set its clock the next time

that you turn on the radio in DAB or FM mode. Alternatively you may specify that the time is

not automatically updated. In this case the clock must always be set manually after a power

interruption.

With your radio switched on, press and hold the Menu button to access the menu for the

current mode.

Press the Folder Up or Down buttons until 'System settings' is highlighted on the display. Press

the Select button to enter the system settings menu.

Press the Folder Up or Down buttons until 'Time/Date' is highlighted on the display. Press the

Select button to enter the time setup.

Press the Folder Up or Down buttons until 'Auto update' is highlighted on the display. Press the

Select button to enter the auto-update menu.

Press the Folder Up or Down buttons to choose an update option from 'Update from DAB',

'Update from FM', 'Update from Network' or 'No update' as required. Press the Select button to

conrm your choice. The radio will then exit to the previous menu display.

Setting the clock format

The clock display used in standby mode and on the playing mode screens can be set to 12 or 24

hour format. The selected format is then also used when setting the alarms.

1. With your radio switched on, press and hold the Menu button to access the menu for the current

mode.

2. Press the Folder Up or Down buttons on the remote control (or the Tuning Up or Down buttons

on the touch panel) until 'System settings' is highlighted on the display. Press the Select button

to enter the system settings menu.

3. Press the Folder Up or Down buttons until 'Time/Date' is highlighted on the display. Press the

Select button to enter the time setup.

4. Press the Folder Up or Down buttons until 'Set format' is highlighted on the display. Press the

Select button to enter the clock format menu. The current clock display format is marked with

an asterisk.

5. Press the Folder Up or Down buttons to select either 12 or 24 hour format. Press the Select

button to conrm your choice of clock format. The display will then revert to the previous menu.

If the 12 hour clock format is chosen, the radio will then use the 12 hour clock for the setting of

alarms, and will display a 12 hour clock with an AM or PM indicator when in standby mode.

Manually setting the clock

The DDR-62 radio will normally set its clock automatically to UK time after a connection to the

Internet has been established. Should you need to set the time manually, change the time zone,

or manually switch from winter to summer time (GMT to BST - also known outside the UK as

daylight savings time), then please follow this procedure.

Press the Standby button to switch on your radio. To set the time and date press and hold the

Clock/Set button then follow steps 6 to 10.

To set all time settings press and hold the Menu button to access the menu for the current

mode.

Press the Folder Up or Down buttons until 'System settings' is highlighted on the display.

Press the Select button to enter the system settings menu.

To change the time zone setting go to step 11. To change from winter to summer time go to

step 13. To change the current time or date setting press the Folder Up or Down buttons until

'Time/Date' is highlighted on the display, then press the Select button to enter the time and

date setting screen.

Press the Folder Up or Down buttons until 'Set Time/Date' is highlighted on the display. Press

the Select button to enter the clock setup. The day digits will  ash.

Press the Folder Up or Down buttons until the correct day is shown on the display. Press the

Select button to enter the selection. The month digits will then  ash.

Press the Folder Up or Down buttons to select the correct month. Press the Select button. The

year digits will then  ash.

Manually setting the clock - cont.

Press the Folder Up or Down buttons to select the correct year. Press the Select button to

enter the selection. The hour digits will then ash.

Press the Folder Up or Down buttons to select the correct hour. Press the Select button to

enter the selection. The minute digits will then ash.

Press the Folder Up or Down buttons to select the correct minutes. Press the Select button to

10.

enter the selection. The display will then return to the previous menu.

Press the Folder Up or Down buttons until 'Set time zone' is highlighted on the display then

11.

press the Select button.

Press the Folder Up or Down buttons to highlight the time zone which is applicable to your

12.

location, then press the Select button to conrm the setting. Press and hold the Menu button

to exit or go to step 13 to set the summer/winter time option.

Press the Folder Up or Down buttons until 'Daylight savings' is highlighted on the display then

13.

press the Select button. The asterisk shows the current setting. In the UK, ON is equivalent to

British Summer Time, OFF is equivalent to Greenwich Mean Time.

14.

Press the Folder Up or Down buttons to highlight 'ON' or 'OFF' as required then press the

Select button to conrm the setting.

Press and hold the Menu button to exit.

15.

Setting the alarm clock

Your radio has two separate alarms which can be set to wake you to either the radio, CD, USB,

SD, iPod or a buzzer alarm. In the event of a power interruption your radio has built in memory

that will retain your alarm settings. Ensure that the time is set correctly before setting the alarms.

Press the Alarm button to see the current alarm settings. If no change is required, press and

hold the Menu button or press the Back button to exit. The Alarm menu can also be accessed

using the 'System settings' menu.

Press the Folder Up or Down buttons until the desired alarm (1 or 2) is highlighted on the

display. Press the Select button to enter alarm setup.

Press the Folder Up or Down buttons until 'Time' is highlighted on the display. Press the Select

button to adjust the alarm time.

Press the Folder Up or Down buttons to choose the alarm hour. Press the Select button to

conrm the setting.

Press the Folder Up or Down buttons to choose the alarm minute. Press the Select button to

conrm the setting. The display will then return to the alarm setting menu. If the radio has been

set to use a 12 hour clock format, there will also be an option here for setting AM or PM for the

alarm time.

Setting the alarm clock - cont.

Press the Folder Up or Down buttons to highlight 'Enable' and press the Select button. The

display will show the Frequency options for the alarm. The alarm frequency options are as

follows:

'Off' - the alarm will be disabled

'Daily' - the alarm will sound everyday

'Once' - the alarm will sound once

'Weekends' - the alarm will sound only at weekends

'Weekdays' - the alarm will sound on weekdays only

Press the Folder Up or Down buttons to choose the required alarm frequency option. Choosing

Off will disable the alarm. Press the Select button to conrm the selection. If you choose to set

the alarm to Once you will also need to set the date using the Folder Up or Down and Select

buttons.

The alarm can be set to buzzer, Internet radio, DAB radio, FM radio, CD, USB, SD and iPod.

For whichever radio mode is selected, the radio alarm may be set to any of the stations which

have been stored as presets or to the station most recently listened to. Press the Folder Up or

Down buttons to highlight the current 'Mode' option for the alarm, then press the Select button

if you wish to change it. Press the Folder Up or Down buttons to highlight either 'Buzzer' or the

required mode. Press the Select button to conrm the selection.

If setting the alarm to a radio option, Press the Folder Up or Down buttons to highlight the

'Preset:' option then press the Select button if you wish to change it. Choose from either the

radio station 'Last listened' to, or from the presets 1 - 10. Scroll to the chosen option and press

the Select button to conrm the selection. Note that you can only set the alarm to use a preset

which has already been stored.

Setting the alarm clock - cont.

9. Press the Folder Up or Down buttons until the 'Volume:' option is highlighted on the display and

press the Select button if you wish to change it. The radio uses the saved volume setting for

each alarm when it sounds. Set the required volume using the Folder Up or Down buttons and

the Select button to conrm the setting.

10. In order to store the alarm settings press the Folder Up or Down buttons until 'Save' is highlighted.

Press the Select button to store the alarm settings. Your radio will show 'Alarm saved' and will

then go back to the list of alarms with the new alarm setting shown in the display. If you decide

not to save the settings, press the Back button. The display will show 'Save changes' with a

'YES' or 'NO' option. Press the Folder Up or Down buttons to choose 'NO' and then press the

Select button. 'Alarm not saved' will show on the display. Active alarms are shown using small

alarm indicators at the bottom of the playing displays and on the clock display when in standby.

Note:

If you make a mistake at any point while setting the alarms, use the Back button to go back to the

previous screen.

When the alarm sounds

The buzzer or radio alarm will sound at the selected times for up to 60 minutes unless cancelled.

The volume used for the alarm will be as specied during the alarm setting procedure. If the radio

cannot connect to the specied radio station, the buzzer alarm will be used instead. To cancel

an alarm, press the Standby button to return to standby mode. The alarm icon will  ash at the

bottom of the playing mode displays, and the radio will automatically switch back to standby

mode when the 60 minutes have elapsed.

Disabling alarms

1. To disable a single alarm enter the alarm setup menu and press the Folder Up or Down buttons

until the desired alarm is highlighted on the display. Press the Select button.

2. Press the Folder Up or Down buttons until the 'Enable:' option is highlighted on the display.

Press the Select button.

3. Press the Folder Up or Down buttons to highlight 'Off' and press the Select button.

4. Press the Folder Up or Down buttons until the 'Save' option is highlighted on the display then

press the Select button to save the new setting. The chosen alarm will now be disabled.

Controlling alarms in standby

When your radio is in standby the alarms can be controlled using the Alarm button. This avoids

the risk of disturbance to someone who is asleep.

1. To change the states of the alarms when in standby press the Alarm button. The display will

cycle through none, either and both alarms enabled.

Snooze timer

1. The buzzer or radio alarm can be silenced for 5 minutes by pressing the Alarm button. Should you wish for a longer snooze duration this can be extended. Pressing the Alarm button again while the radio is snoozed will set the available snooze time to 5, 10, 15 or 30 minutes.

2. While the snooze timer is active the remaining snooze time is shown next to the ashing alarm

icon on the clock display.

3. In order to cancel the Snooze timer while the alarm is suspended, press the Standby button.

The display will briey show an 'Alarm Off ' message.

Sleep timer

Your radio can be set to turn off after a preset time has elapsed. The sleep timer setting can be adjusted between 15 and 120 minutes in 15 minute increments.

1. Press the Standby button to switch on your radio.

2. To use the sleep timer, press and release the Sleep / Clock set button to enter the sleep setup. 'Sleep off' will appear on the display.

3. Repeatedly press the Sleep / Clock set button to select the desired sleep time. The options are 15, 30, 45, 60, 75, 90, 105 or 120 minutes. Use the OFF option to cancel the sleep function.

4. Your radio will switch off after the preset sleep time has elapsed.

5. Your radio will switch into standby mode after the preset time has elapsed. An active sleep timer is shown using a small timer indicator at the bottom of the playing displays. This indicator also shows the sleep time remaining before the radio switches itself into standby mode.

6. To cancel the sleep time before the preset time has elapsed and to turn off the radio, press the Standby button to turn the unit off manually. To cancel the sleep timer and leave the radio playing, go back into the sleep timer settings (steps 1 to 3 above) and select the Off option in step 3. Alternatively, simply press the Standby button twice in succession to cancel the timer and switch the radio back on again.

The sleep time can also be accessed from the main menu. Use the Folder Up or Down and Select buttons to set the sleep time.

Display and Audio

Equalizer function

The sound on your radio can be adjusted to suit your personal taste for the material that you are

listening to. The DDR-62 has a range of equalizer modes. Alternatively you may set the treble

and bass levels to your own preferences which can be accessed from the My EQ menu item.

Press the Standby button to switch on your radio. Access the menu for the current mode by

pressing and holding the Menu button. Alternatively press the EQ button on the remote control

and proceed to step 4.

Press the Folder Up or Down buttons until 'System settings' is highlighted on the display. Press

the Select button to enter the system settings menu.

Press the Folder Up or Down buttons until 'Equalizer' is highlighted on the display. Press the

Select button.

Press the Folder Up or Down buttons to cycle through and highlight the various modes. Press

the Select button to conrm your selection.

a - 'Normal (Flat)'

b - 'Jazz'

c - 'Rock'

d - 'Movie'

e - 'Classic'

f - 'Pop'

g - 'News'

h - 'My EQ'

The currently selected mode is marked with an asterisk.

Setting up your My EQ prole

If you nd the preset equalizer functions not to your liking, you may set up a custom treble and

bass setting as follows:

1. Follow steps 1-3 on the preceding page in order to enter the Equalizer menu or alternatively

press the EQ button on the remote control.

2. Press the Folder Up or Down buttons until 'My EQ prole setup' is highlighted on the display.

Press the Select button to enter the adjustment mode.

3. To adjust the bass level press the Folder Up or Down buttons until 'Bass' is highlighted on the

display. Press the Select button to enter the adjustment mode and press the Folder Up or Down

buttons until the desired level (between -14 and +14) is displayed. The sound will change as

you adjust the level. Press the Select button when you are happy with the bass setting.

4. To adjust the treble level press the Folder Up or Down buttons until 'Treble' is highlighted on

the display. Press the Select button to enter the adjustment mode and press the Folder Up or

Down buttons until the desired level (between -14 and +14) is displayed. The sound will change

as you adjust the level. Press the Select button when you are happy with the treble setting.

5. Press the Back button and the display will prompt you to save the changes. If you wish to save

the changes highlight 'YES'. If you do not wish to save the changes highlight 'NO'. Press the

Select button to enter the selection.

6. To use the 'My EQ' prole press the Folder Up or Down buttons until 'My EQ' is highlighted, and

then press the Select button to make the selection.

To quickly cancel the effect of the 'My EQ' profi le press the Folder Up or Down buttons until

'Normal (Flat)' is highlighted on the display and press the Select button to select. The treble and

bass settings will be remembered for the next time that you wish to use the 'My EQ' setting.

Brightness control

The brightness of the display can be adjusted for when the radio is in Standby and for when it is

in use. If you use the unit in the bedroom, you may prefer a lower standby brightness level than

the standard setting. There are three brightness levels and an almost off 'night-time' setting.

1. Press the Standby button to switch on your radio. Access the menu for the current mode by

pressing and holding the Menu button.

2. Press the Folder Up or Down buttons until 'System settings' is highlighted on the display. Press

the Select button to enter the system settings menu. Press the Folder Up or Down buttons until

'Brightness' is highlighted on the display. Press the Select button.

3. To adjust the display brightness when the radio is switched on press the Folder Up or Down

buttons until 'Normal' is highlighted on the display. To adjust the display brightness when the

radio is in standby press the Folder Up or Down buttons until 'Standby' is highlighted.Press the

Select button to enter the selected brightness adjustment mode.

4. To adjust the brightness level press the Folder Up button on the radio to increase the brightness

level and the Folder Down button to decrease it. The backlight level will change so that you

can see the effect of each setting. Note that the backlight is almost completely off at the zero

setting. Press the Select button to set the level. Press and hold the Menu button to exit.

When the radio is in Standby mode, pressing a button will cause the radio to switch to the Normal

brightness level for a few seconds. This is so that even if the Standby brightness level is set to

zero (almost off), it is still possible to see the time by quickly pressing a button.

Contrast / viewing angle control

The contrast of the display can be adjusted. The adjustment also changes the angle from which

the display can best be seen.

1. Access the menu for the current mode by pressing and holding the Menu button. Press the

Folder Up or Down buttons until 'System settings' is highlighted on the display. Press the

Select button to enter the settings menu.

2. Press the Folder Up or Down buttons until 'Contrast' is highlighted on the display and press

the Select button.

3. Press the Folder Up or Down buttons to adjust the contrast and viewing angle. The contrast

level indication on the screen will change at the same time. When you find the setting that

gives the best legibility for the location in which the radio is used, press the Select button to

save the setting.

4. Press and hold the Menu button to exit.

Mute function

Pressing the Mute button will mute the output from the loudspeakers.

1. Press the Mute button to mute the sound output.

2. Press the Mute button again or one of the Volume buttons to un-mute the sound output.

Touch panel sensitivity control

The sensitivity of the touch panel may be adjusted. The default setting will normally be found

to provide satisfactory operation, however, the touch panel system may respond differently

depending upon the moisture of the skin. The touch panel sensitivity may be set to low, normal or

high.

1. Access the menu for the current mode by pressing and holding the Menu button.

2. Press the Folder Up or Down buttons until 'System settings' is highlighted on the display. Press

the Select button to enter the system settings menu.

3. Press the Folder Up or Down button until 'Touch pad set' is highlighted on the display. Press

the Select button to enter the adjustment mode.

4. Press the Folder Up or Down buttons to highlight the desired touch panel sensitivity level.

5. Press and release the Select button to save the new setting.

The default setting after a system reset is Normal.

Headphone socket

A 3.5mm Headp ho ne Socket locat ed on the rear of you r radi o is provided f or use with

headphones.

Inserting a plug automatically mutes the internal loudspeaker.

Please be aware that the sensitivity of headphones can vary widely. We therefore recommend

setting volume to a low level before connecting headphones to the radio. It is also recommended

to reduce the volume before unplugging your headphones.

Important:

Excessive sound pressure from earphones and headphones can cause hearing loss.

Line out socket (3.5mm Jack)

A 3.5mm Line Out socket located on the rear of your radio is provided for connecting the audio

signal to an external amplier. Inserting an audio cable into this socket will not mute the internal

loudspeaker. Set the volume control on the radio to minimum if desired.

Auxiliary input socket

A 3.5mm Auxiliary Input socket located on the rear of your radio is provided for connecting the

audio signal from an external audio source such as an MP3 or CD player.

1. Connect a stereo lead from the headphone output of your MP3 or CD player to the Aux In socket

located at the rear of the radio. Typically this lead will have a 3.5mm stereo plug at both ends.

2. Switch on your radio.

3. Press the Radio button until 'AUX in' mode is shown on the display.

4. Press the 'play' on the connected audio device. If you are using its headphone output for the

connection, set its volume control to a level of somewhere between two-thirds and maximum

(the objective is to get a strong audio signal but without too much distortion). Then adjust the

volume on the radio as required.

Note:

if using an iPod as the sound source, you may need to set its output to maximum to get an

adequate audio signal level.

5. After use, disconnect your player in order to listen to your radio conventionally.

Optical S/PDIF output socket

A digital output socket providing an S/PDIF signal is provided on the rear of your radio for

connection to an amplier, mini-disc or other equipment with a digital optical input. This feature is

not active for iPod or AUX in modes.

Aerial removal

The fitted telescopic aerial is suitable for most applications. The telescopic aerial may be

removed to allow connection to an external aerial using a coaxial cable.

First remove the two small screws holding the antenna connector cover in place (use a small

-head screw driver). Then using the spanner (not supplied), remove the telescopic aerial by

cross

rotating

in an anti-clockwise direction when viewed from the rear of the product.

This will expose an F-type connector to which an external aerial may be connected.

Information

Factory reset

If you wish to completely reset your radio to its initial state this may be performed by following this

procedure. By performing a factory reset, all user entered settings will be erased.

Access the menu for the current mode by pressing and holding the Menu button. Press the

Folder Up or Down buttons to highlight the 'Main menu' option, then press the Select button to

select.

Press the Folder Up or Down buttons until 'System settings' is highlighted and then press the

Select button.

Press the Folder Up or Down buttons until 'Factory Reset' is highlighted and then press the

Select button. Press the Folder Up or Down buttons and to highlight 'YES' to proceed. If you

do not wish to carry out a system reset, highlight 'NO' and then press the Select button. The

display will revert to the previous menu.

With 'YES' highlighted, press the Select button. A full reset will be performed and the radio

will restart as if rst plugged in. The DAB stations list together with any preset stations will be

erased and your wireless network connection details will be lost. All conguration settings will

be restored to their defaults, the clock and alarms will be reset.

In case of malfunction for any reason, reset the product as described above to resume normal

operation. It may be necessary in some cases to disconnect the mains power, then reconnect

power after 10 seconds. In case of malfunction due to electrical fast transient (burst), reset

the product as above (reconnection of the power source may be required) to resume normal

operation.

Software update

From time to time, new software features for your radio may be developed. Your radio has therefore been designed to allow its internal software to be updated using your Internet connection.You should not attempt to update your radio unless it is recommended to you by Sangean Customer Services. Updating the software may remove all network settings, radio station presets and alarm settings from your radio. It is important that you do not attempt this procedure unless you have a good Internet connection and a reliable mains power supply. If the radio connects to your router using a WiFi connection, make sure that this is also reliable before proceeding.

The 'Software update' option is accessed via the 'System settings' menu. When you select

1. 'Software update' the menu will display 'Auto check setting' and 'Check now'. If you want your radio to check periodically for new software versions press the Folder Up or Down buttons to highlight 'Auto check settings'. Then press the Select button and select 'YES'. If you do not want your radio to check for updates select the 'NO' option.

To check if there are any software updates available currently, press the Folder Up or Down

2. buttons to highlight 'Check now' and then press the Select button. The radio will check to see if an update is available. The display will show 'Checking for new versions'. If there are no updates then the display will show 'Software up to date'. If a software update is available your radio will then offer the choice of updating the software or not, displaying 'New version

available. Update software?'. Select the 'YES' option if you wish to go through the update

process.

If you choose to update your radio it will first download the new software and will then

3. reprogram its internal memory. This may take a few minutes depending on the speed of your internet connection.

Once the software update is completed, the radio will prompt you to press Select to restart.

4. Press the Select button and your radio will then restart. You may find that you will need to

recongure your network connection following an update. You may also need to re-enter all radio station presets, alarm settings, and conguration options.

VERY IMPORTANT:

Do not switch off the power to the radio until the update operation is complete and the radio has restarted, otherwise the unit may become permanently damaged.

Network proles

Each time that you connect your radio to a WiFi network, the radio will store the details of that

connection (SSID, security key, DHCP/IP address settings) as a prole. Up to four such proles

are stored in the radio so that if the unit is used in multiple locations there is no need to enter the

network settings when returning to a location previously visited. The radios stores the four most

recent proles in memory identied by their SSID. Normally the radio will attempt to connect to

one of the stored proles and only if it is unable to do so will you need to use the Network Wizard.

In the event that you visit a location only once you may wish to delete the prole for the network

in that location to avoid losing other proles.

1. Access the menu for the current mode by pressing and holding the Menu button. Press the

Folder Up or Down buttons until 'System settings' is highlighted on the display. Press the Select

button to enter the settings menu.

2. Press the Folder Up or Down buttons until 'Network' is highlighted on the display. Press the

Select button to enter the Network settings menu.

3. Press the Folder Up or Down buttons until 'Network prole' is highlighted on the display. Press

the Select button to see the stored proles. The prole which is currently in use (if any) is marked

with an asterisk.

4. To remove a prole from memory, press the Folder Up or Down buttons to highlight the prole

to be deleted and then press the Select button.

5. The radio will offer a 'YES' or 'NO' selection. Press the Folder Up or Down buttons to select 'YES'

and then press the Select button. The selected prole will be deleted.

Note: that it is not possible to delete a prole which is currently in use.

Software version display

The software version display is provided for reference and customer support purposes and

cannot be changed.

1. Access the menu for the current mode by pressing and holding the Menu button. Press the

Folder Up or Down buttons until 'System settings' is highlighted on the display. Press the Select

button to enter the System settings menu.

2. Press the Folder Up or Down buttons until 'Radio Info' is highlighted on the display. Press the

Select button to display the software version and radio ID. Follow steps 1 and 2 above to view

'System info' for your radio.

3. Press and hold the Menu button to exit.

Audio FAQ

Your radio can access some audio help for Internet Radio use.

1. With your radio switched on and in the Internet Radio mode, press and hold the Menu button.

Press the Folder Up or Down buttons until 'Station list' is highlighted on the display. Press the

Select button.

2. Press the Folder Up or Down buttons until 'Help' is highlighted on the display. Press the Select

button to enter the Help menu.

3. Press the Folder Up or Down buttons until 'FAQ' is highlighted. Press the Select button to display

some frequently asked questions.

4. Press the Folder Up or Down buttons to choose a question that suits your requirements and

press the Select button to listen to the answer. Adjust the volume as needed.

Accessing your audio ﬁles via a UPnP server using Windows Vista and XP

If your computer is running Windows Vista or XP, then Windows Media Player version 11 includes

a UPnP server which will make your ﬁles available to your radio. There are other UPnP server

solutions available for non-Windows users and for Windows users who may wish to use an

alternative (see the section of Use with Windows, Apple Mac and Linux). It is beyond the scope

of this instruction book to cover all possible options for UPnP. We explain the use of Microsoft's

Windows Media Player here since that will be the ﬁrst choice for the majority of users.

Set up UPnP access on a Windows PC

1. If your PC is running Microsoft Windows Vista or Windows XP then you can use Microsoft's

Windows Media Player version 11 to act as your UPnP (Universal Plug and Play) media server.

If not already installed on your PC, Windows Media Player 11 may be downloaded from Microsoft’s

web site and installed by following the instructions detailed in its installation wizard, or by using

Microsoft's Windows Update facility.

2. Once installed, Windows Media Player 11 can

to it on your PC. To add new media ﬁles to the library, select the 'Library' tab, then 'Add to Library… >

Advanced Options', click 'Add', choose the ﬁles you wish to add and click ‘OK’.

The next step is to connect your radio to Windows Media Player 11 and to conﬁgure the program

to allow the radio to access your media library.

3. Press the Standby button to switch the unit on. Then press the Media button as needed until

the Music Player mode display is shown. The main 'Music Player' menu will then be displayed.

create a library from all the media ﬁles available

Sangean DDR-62 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
