Some of the contents in this manual may differ from your phone depending on the software of the phone or your service provider.
World Wide Web |
English . 07/2008. Rev. 1.0 |
http://www.samsungmobile.com |
SCH-i910
user manual
Draft
Using this manual
This user manual has been specially designed to guide you through the functions and features of your device.
For any topics not covered in this manual, please refer to the Help embedded in the Windows Mobile® 6 Professional operating system.
Instructional icons
Before you start, familiarise yourself with the icons you will see in this manual:
Warning—situations that could cause injury to yourself or others
Caution—situations that could cause damage to your device or other equipment
X
→
[ ]
Note—notes, usage tips, or additional information
Refer to—pages with related information; for example:
X p. 12 (represents "see page 12")
Followed by—the order of options or menus you must select to perform a step; for example: Tap Start → Programs → Camera
(represents Start, followed by Programs, followed by
Camera)
Square brackets—device keys; for example: [ ] (represents the Power key)
Copyrights and trademarks
Rights to all technologies and products that comprise this device are the property of their respective owners:
•This product includes software licensed from MS, an affiliate of the
Microsoft Corporation. Microsoft and software bearing the Microsoft name are registered trademarks of the Microsoft Corporation. Before using this product, refer to the MICROSOFT SOFTWARE LICENSE TERMS FOR WINDOWS MOBILE 6 SOFTWARE Agreement at the back of this guide for information about rights and restrictions.
•Java™ is a trademark of Sun Microsystems, Inc.
•Bluetooth® is a registered trademark of the Bluetooth SIG, Inc. worldwide—Bluetooth QD ID: B014133
•DivX® is a registered trademark of DivX, Inc., and is used under license.
Safety and usage information |
.......... 5 |
Enter text with |
|
|
|
|
Samsung Phonepad ...................... |
16 |
|
1. Enter text |
13 |
Enter text with Transcriber ............ |
17 |
|
Change the text input |
|
Create a sketch ............................ |
18 |
|
method ....................................... |
13 |
|
|
|
Change the default text |
|
2. Communication |
19 |
|
input method ............................... |
13 |
Calls ........................................... |
19 |
|
Enter text with Block |
14 |
Messaging ................................... |
20 |
|
Recognizer ................................... |
|
|
||
Enter text with the |
15 |
3. Media |
24 |
|
keyboard ..................................... |
Camera |
24 |
||
Enter text with Letter |
|
|||
|
Media Album |
26 |
||
Recognizer |
15 |
|||
Photo Slides |
28 |
|||
Enter text with |
|
|||
|
Touch Player |
29 |
||
Samsung Keyboard ....................... |
15 |
|||
Enter text with |
|
Media Controller ........................... |
31 |
|
Samsung Keypad .......................... |
16 |
ShoZu ........................................ |
31 |
2
Contents
Video Editor ................................ |
33 |
Streaming Player ......................... |
36 |
FM Radio .................................... |
36 |
4. Personal productivity |
38 |
Contacts ..................................... |
38 |
Calendar ..................................... |
40 |
Office Mobile ............................... |
41 |
Notes ......................................... |
43 |
Tasks ......................................... |
43 |
Clock .......................................... |
44 |
5. Web |
46 |
Windows Live .............................. |
46 |
Messenger .................................. |
46 |
RSS Reader ................................. |
48 |
Podcasts ...................................... |
48 |
Google Launcher .......................... |
49 |
Google Maps ................................ |
50 |
6. Connectivity |
52 |
Bluetooth .................................... |
52 |
ActiveSync ................................... |
54 |
7. Additional programs |
57 |
Games ........................................ |
57 |
Java ........................................... |
57 |
Calculator .................................... |
57 |
Smart Converter ........................... |
58 |
Task Manager .............................. |
58 |
3
Contents |
|
Task Switcher .............................. |
59 |
Search your device ....................... |
59 |
Main Menu ................................... |
60 |
File Explorer ................................ |
60 |
TV Out Viewer .............................. |
60 |
Digital Frame ............................... |
61 |
Smart Reader .............................. |
61 |
8. Troubleshooting |
63 |
9.MICROSOFT SOFTWARE LICENSE TERMS FOR WINDOWS MOBILE 6 SOFTWARE
Agreement |
68 |
Health and Safty Information |
78 |
4
Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your device.
Safety warnings
Keep your device away from small children and pets
Keep your device and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed.
Protect your hearing
Listening to a headset at high volumes can damage your hearing. Use only the minimum volume setting necessary to hear your conversation or music.
Install mobile devices and equipment with caution
Ensure that any mobile devices or related equipment installed in your vehicle are securely mounted. Avoid placing your device and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly.
Handle and dispose of batteries and chargers with care
•Use only Samsung-approved batteries and chargers specifically designed for your device. Incompatible batteries and chargers can cause serious injuries or damage to your device.
•Never dispose of batteries or devices in a fire. Follow all local regulations when disposing of used batteries or devices.
5
•Never place batteries or devices on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.
•Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating.
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches) between mobile devices and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your device is interfering with a pacemaker or other medical device, turn off the device immediately and contact the manufacturer of the pacemaker or medical device for guidance.
Turn off the device in potentially explosive environments
Do not use your device at refuelling points (service stations) or near fuels or chemicals. Turn off your device whenever directed by warning signs or instructions. Your device could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the device, its parts, or accessories.
Reduce the risk of repetitive motion injuries
When sending text messages or playing games on your device, hold the device with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks.
6
Safety precautions
Drive safely at all times
Avoid using your device while driving and obey all regulations that restrict the use of mobile devices while driving. Use hands-free accessories to increase your safety when possible.
Follow all safety warnings and regulations
Comply with any regulations that restrict the use of a mobile device in a certain area.
Use only Samsung-approved accessories
Using incompatible accessories may damage your device or cause injury.
Turn off the device near medical equipment
Your device can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel.
Turn off the device or disable the wireless functions when in an aircraft
Your device can cause interference with aircraft equipment. Follow all airline regulations and turn off your device or switch to a mode that disables the wireless functions when directed by airline personnel.
7
Protect batteries and chargers from damage
•Avoid exposing batteries to very cold or very hot temperatures (below 0° C/ 32° F or above 45° C/113° F). Extreme temperatures can reduce the charging capacity and life of your batteries.
•Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or permanent battery damage.
•Never use a damaged charger or battery.
•Risk of explosion if a battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.
Handle your device carefully and sensibly
•Do not allow your device to get wet— liquids can cause serious damage. Do not handle your device with wet hands. Water damage to your device can void your manufacturer’s warranty.
•Avoid using or storing your device in dusty, dirty areas to prevent damage to moving parts.
•Your device is a complex electronic device—protect it from impacts and rough handling to avoid serious damage.
•Do not paint your device, as paint can clog moving parts and prevent proper operation.
•Avoid using the device’s camera flash or light close to the eyes of children or animals.
8
•Your device and memory cards may be damaged by exposure to magnetic fields. Do not use carrying cases or accessories with magnetic closures or allow your device to come in contact with magnetic fields for extended periods of time.
Avoid interference with other electronic devices
Your device emits radio frequency (RF) signals that may interfere with unshielded or improperly shielded electronic equipment, such as pacemakers, hearing aids, medical devices, and other electronic devices in homes or vehicles. Consult the manufacturers of your electronic devices to solve any interference problems you experience.
Important usage information
Use your device in the normal position
Avoid contact with your device’s internal antenna.
Allow only qualified personnel to service your device
Allowing unqualified personnel to service your device may result in damage to your device and will void your warranty.
Ensure maximum battery and charger life
•Avoid charging batteries for more than a week, as overcharging may shorten battery life.
9
•Over time, unused batteries will discharge and must be recharged before use.
•Disconnect chargers from power sources when not in use.
•Use batteries only for their intended purpose.
Handle SIM cards and memory cards with care
•Do not remove a card while the device is transferring or accessing information, as this could result in loss of data and/or damage to the card or device.
•Protect cards from strong shocks, static electricity, and electrical noise from other devices.
•Frequent writing and erasing will shorten the life span of memory cards.
•Do not touch gold-coloured contacts or terminals with your fingers or metal objects. If dirty, wipe the card with a soft cloth.
Ensure access to emergency services
Emergency calls from your device may not be possible in some areas or circumstances. Before travelling in remote or undeveloped areas, plan an alternate method of contacting emergency services personnel.
10
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
11
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.
ABOUT DIVX VIDEO
DivX® is a digital video format created by DivX, Inc. This is an official DivX Certified device that plays DivX video. Plays DivX® video up to 320x240. May play DivX® video up to 400x240.
ABOUT DIVX VIDEO-ON-DEMAND
This DivX® Certified device must be registered with DivX in order to play DivX Video-on-Demand (VOD) content. First generate the DivX VOD registration code for your device and submit it during the registration process. [Important: DivX VOD content is protected by a DivX DRM (Digital Rights Management) system that restricts playback to registered DivX Certified devices. If you try to play DivX VOD content not authorized for your device, the message "Authorization Error" will be displayed and your content will not play.] Learn more at www.divx.com/vod.
12
With your device’s touch screen, you can type or write text and create drawings in notes, documents, and messages.
When you need to enter text, tap an input panel icon at the bottom of the screen. Tap the arrow next to the input panel icon and choose one of the following input methods for entering text:
•Block Recognizer
•Keyboard
•Letter Recognizer
•Samsung Keyboard
•Samsung Keypad
•Samsung Phonepad
•Transcriber
You can tap the input panel icon at any time to show or hide the input panel.
Some of the input methods may not be supported according to the language.
1.From any text field, tap the arrow next to the input panel icon.
2.Tap Options...
13
Enter text
3.From the Input Method tab, choose an input method.
4.Tap .
You can also set options for some input methods.
Write individual letters and numbers in text in the Palm Graffiti style.
1.Tap the input panel icon.
2.Tap the arrow next to the input panel icon and select Block Recognizer.
3.Write each character in the writing area at the bottom of the screen:
•Write letters on the left side of the writing area.
•Write numbers on the right of the writing area.
Drag your finger upward to change case (ABC, Abc, or abc). Tap once on the screen to enter symbols (123 or abc will change to ).
To view demonstrations of how to write characters, tap .
14
1.Tap the input panel icon.
2.Tap the arrow next to the input panel icon and select Keyboard.
3.Tap characters to enter your text.
To switch to numbers and symbols, tap 123. To access special characters, tap
áü.
Write individual letters and numbers on the touch screen.
1.Tap the input panel icon.
2.Tap the arrow next to the input panel icon and select Letter Recognizer.
Enter text
3.Write each character in the writing area at the bottom of the screen:
•Write upper-case letters in the ABC column on the left side of the writing area.
•Write lower-case letters in the abc column in the middle of the writing area.
•Write numbers and symbols in the 123 column on the right side of the writing area.
To view demonstrations of how to write characters, tap .
1.Tap the input panel icon.
2.Tap the arrow next to the input panel icon and select Samsung Keyboard.
15
Enter text
3.Tap characters to enter your text.
To enter upper-case letters, tap . To enter numbers and symbols, tap
.
Enter text with
Samsung Keypad
1.Tap the input panel icon.
2.Tap the arrow next to the input panel icon and select Samsung Keypad.
3.Tap characters to enter your text.
In T9 mode, tap the appropriate keys to enter an entire word.
In ABC mode, tap the appropriate key until the character you want appears.
In Number mode, tap the appropriate key to enter a number.
In Symbol mode, tap the appropriate key to enter a symbol.
1.Tap the input panel icon.
2.Tap the arrow next to the input panel icon and select Samsung Phonepad.
3.Tap characters to enter your text.
In T9 mode, tap the appropriate keys to enter an entire word.
In ABC mode, tap the appropriate key until the character you want appears.
In Number mode, tap the appropriate key to enter a number.
In Symbol mode, tap the appropriate key to enter a symbol.
16
With Transcriber, you can write anywhere on the screen. Unlike Letter Recognizer or Block Recognizer, you can use cursive (joined-up) handwriting to write complete words.
1.Tap the input panel icon.
2.Tap the arrow next to the input panel icon and select Transcriber.
3.Write legibly anywhere on the screen.
4.Pause and allow Transcriber to convert your writing to text.
You can access the following tools from the Transcriber toolbar:
Tap To
Change Transcriber options
Enter text
Tap To
View demonstrations of how to write characters
Open the list of punctuation marks, symbols, and numbers
Change the input mode to
A, a, or 123
Insert a space
Start a new line
Move the cursor to the left
Move the cursor to the right
Clear your input
Open the Help application
17
Enter text
With Notes, you can create and capture sketches.
1.From the Today screen, tap Start → Programs → Notes.
2.Tap New.
3.Make a stroke that crosses at least three ruled lines to start a drawing frame.
Sketches that do not cross three ruled lines will be treated as writing.
4.Continue your sketch with strokes. To edit the sketch, tap Menu → Draw.
Tap and hold the sketch until the selection handles appear. You can then tap and hold the handles to drag or resize the sketch or tap Menu to access other options.
18
Your device allows you to send and receive many types of calls and messages over cellular networks and the wireless web.
Learn to use your device’s call functions. For basic call functions, see the Quick Start Guide.
Call an international number
1.Press [].
2.Tap Keypad if necessary.
3. Press and hold to insert the + character (this replaces the international access code).
4. Press the number keys to enter the complete number you want to dial (country code, area code, and phone number), and then tap or press [] to dial.
5. To end the call, press [].
Make a call from the contact list
1.From the Today screen, tap Start → Phonebook to open your contact list.
2.Scroll to a contact and tap the contact’s name.
To search for a contact, tap and enter a few letters of the contact’s name.
3.Tap the number you want to dial.
4.To end the call, press [].
19
Communication
Make a call from Call History
1.From the Today screen, tap Start → Programs → Call Log.
2.Select a call log by using the dropdown menu at the top left of the screen.
3.Scroll to a contact and tap the contact’s name.
4.Tap the number you want to dial.
5.To end the call, press [].
Forward calls
1.From the Today screen, tap Start → Settings → Phone.
2.From the Services tab, tap Call Forwarding → Get Settings...
3.Tap a forwarding option and enter a phone number.
4. Tap .
Bar (block) calls
1.From the Today screen, tap Start → Settings → Phone.
2.From the Services tab, tap Call Barring → Get Settings...
3.Tap the type of calls you want to bar.
4.Tap .
Learn to use messaging functions. For instructions on entering text, see "Enter text." X p. 13
Send a text message
1.From the Today screen, tap Start → Messaging → Messaging.
20
2.Tap Menu → New.
3.Enter a destination number or tap
Menu → Add Recipients to select a contact.
4.Tap the message body.
5.Enter your message text.
6.Tap Send to send the message.
Send a multimedia message
1.From the Today screen, tap Start → Messaging → Messaging.
2.Tap Menu → New.
3.Enter a destination number or tap
Menu → Add Recipients to select a contact.
4.Tap the subject field and enter a message subject.
Tap Yes to change the message to a multimedia message.
Communication
5.Tap the message body.
6.Enter your message text.
7.Tap Menu → Toolbar.
8.Tap an attachment icon to add a file to the message:
•: attach a picture
• : attach a music file
• : attach a video
• : capture and attach a photo
•: record and attach a voice memo
• : record and attach a video
9.Tap Send to send the message.
Send an email message
1.From the Today screen, tap Start → Messaging.
2.Tap the name of an email account.
21
Communication
3.Tap Menu → New.
4.Enter the recipient’s address in the to field or tap Menu → Add Recipient...
to select a contact.
The Cc and Bcc fields are located above the from field.
5.Tap the subject field and enter a message subject.
6.Tap the message body.
7.Enter your message text.
8.To add an attachment, tap Menu → Insert → an attachment type.
9.Tap Send to send the message.
Retrieve emails from a web server
Before you retrieve email messages from an internet service provider or VPN connection, you must create an email account.
To retrieve messages from your Outlook account, see "Synchronise your data." X p. 55
1.From the Today screen, tap Start → Messaging.
2.Tap the name of an email account.
3.Tap Menu → Send/Receive.
22
Communication
View messages
You can access message folders for all your messaging accounts (email, SMS, and MMS) in one location.
To view messages,
1.From the Today screen, tap Start → Messaging.
2.Tap Messaging or the name of an email account.
The Inbox for the account you selected will open.
While viewing message folders, you can switch message folders or accounts by using the dropdown menu at the top left of the screen.
23
Learn to use the Camera, Media Album, Photo Slides, Touch Player, Media Controller, ShoZu, Video Editor, Streaming Player, and FM Radio. To learn about your device’s other media functions, refer to the Windows Mobile Help.
Available programs may differ depending on your service provider or region.
Your device allows you to take digital photos (jpg format) or record videos (3gp format).
Capture a photo
1.Press and hold [Camera].
2.Rotate the device anti-clockwise to landscape orientation.
Camera is always activated in landscape orientation.
3.Aim the lens at the subject and make any adjustments (see "Adjust Camera settings").
4.Press the trackpad or [Camera] to capture the image.
5. Tap to save the photo and return to the viewfinder.
View a photo
1.From the viewfinder, tap .
2.Scroll to the photo you want.
24
Adjust Camera settings
From the viewfinder, tap an icon, and then tap a setting.
Icon Function
Mode (switch to camcorder)
Shot mode
Scene mode
Picture size
Camera settings
Flash
Focus
White balance
Quick view
Media
Record video
1.Press and hold [Camera].
2.Rotate the device anti-clockwise to landscape orientation.
Camera is always activated in landscape orientation.
3.Tap to launch the camcorder.
4.Aim the lens at the subject and make any adjustments (see "Adjust Camcorder settings").
5.Press the trackpad or [Camera] to begin recording.
6.When you have finished, tap , or press the trackpad or [Camera] to stop recording.
7. Tap to save the video and return to the viewfinder.
25
Media
Play a video
1.From the viewfinder, tap .
2.Scroll to the video you want.
3.Tap to play it.
Adjust Camcorder settings
From the viewfinder, tap an icon, and then tap a setting.
Icon Function
Mode (switch to camera)
Recording mode
Resolution
Video settings
Focus
White balance
Icon Function
Quick view
With Media Album, you can view and access all the files and folders on your device.
View a photo
1.From the Today screen, tap Start → Programs → Media Album.
2.If necessary, tap My Storage → DCIM → 100SSCAM.
3.Tap a thumbnail to open it.
26
While viewing photos, you can perform the following functions:
•To zoom in, drag your finger upward on the right side of the screen. To exit the zoom screen, tap the screen twice.
•To view your photos as a slideshow, tap Menu → Play Slide Show.
•To send a photo, tap Menu → Send → a sending option.
•To set a photo as a background or caller ID image, tap Menu → Set as → an option.
•To delete a photo, tap Menu → Delete.
•To crop a photo, tap Menu → Crop.
•To edit the picture, tap Menu → Edit Image.
Media
Play a video
1.From the Today screen, tap Start → Programs → Media Album.
2.If necessary, tap My Storage → DCIM → 100SSCAM.
3.Tap a thumbnail to open it.
Open documents
1.From the Today screen, tap Start → Programs → Media Album.
2.Locate and open the folder where the document is stored.
3.Tap the document name or thumbnail to open it.
Send a file
1.From the Today screen, tap Start → Programs → Media Album.
27
