Samsung SMT807T Users Manual
112
Scrapbook
Use this application to create your own digital scrapbook
with content from webpages, videos and more.
Touc h Scrapbook.
Creating Categories
Touc h
Categories
➔ Create category, select a
layout from the list, enter a name, and then touch OK.
Collecting Items
While viewing webpages, or videos, with the S Pen
button pressed, draw a line around an area to select it.
Touch Scrapbook from the list of applications that
appears at the bottom of the screen, and then select a
category to add the selected area.
Alternatively, press the S Pen button while hovering
over the screen, touch Scrap booker on the general air
commands, draw a line around an area, and then
touch .
Viewing Items
Select a category, and then select an item. While
viewing an item, touch Link to go to the source it was
collected from.
Screen Saver
When your tablet screen automatically times out, instead of a
blank screen, enable the Galaxy Note Screen Saver, which is
actually an action-packed video tour of all the fantastic
features that you will find on your Galaxy Tab.
1. Tou ch
Screen Saver
.
The Galaxy Note 10.1 Screen Saver Settings screen
displays.
2. Follow the on-screen instructions to set up
Screen Saver.
Tip:
Tou ch
Back
to stop the Screen Saver video even if
Enable Touch To Stop is enabled.
DRAFT For Internal Use Only
Applications 113
Settings
Configure your device to your preferences.
Tou ch
Settings
.
For more information, refer to “Settings” on page 116.
SketchBook for Galaxy
Use this application to create a quick concept or sketch out
your idea for a project.
Note:
The SketchBook app must be installed before you can
use it. Touch OK on the pop-up and follow the on-screen
instructions.
1. From a Home screen, touch
Apps
➔
Galaxy Plus
folder ➔
SketchBook for Galaxy
.
2. Use artistic tools to draw and paint your digital art. The
image is saved in Gallery.
1. Create and save a sketchbook.
2. Display SketchBook information and settings.
3. Undo the last action.
4. Redo the last action.
5. Use SketchBook tools.
6. Change the brush types and settings.
7. Change a brush color.
8. Add or delete layers.
9. Register the frequently-used tools.
1
2
3
4
5
6
7
9
8
DRAFT For Internal Use Only
114
Story Album
Use Story Album to create a digital album of your story in
media.
Touc h
Samsung
folder ➔
Story Album
.
For more information, refer to “Story Album” on page 82.
TripAdvisor
Use this application to get travel information such as
destination or hotel. You can also book for a room and share
your reviews with others.
Touc h
Galaxy Plus
folder ➔ TripAdvisor.
Twitter
Get real-time stories, pictures, videos, conversations, ideas,
and inspiration all in your timeline. Follow people and your
interests to get unfiltered access and unique behind-the-
scenes perspectives. Express yourself with photos, videos
and comments.
Touc h
Twi tt er
.
Video
Use this application to play video files.
Touc h
Video
.
For more information, refer to “Video” on page 80.
Video Editor
Use this application to edit your videos.
Touch
Samsung
folder ➔ Video Editor.
Voice Search
Use this application to search webpages by speaking.
1. Tou ch
Google
folder ➔ Voice Search.
2. Speak a keyword or phrase when Speak now appears
on the screen.
WatchON
Enjoy all of your favorite movies and TV shows with
WatchON.
•
Before beginning your initial WatchON application setup, make
sure that your TV is turned off.
•
Sign into your Samsung account before using WatchON. For more
information, refer to
“Your Samsung Account”
on page 47.
DRAFT For Internal Use Only
Applications 115
Initial Configuration
1. From a Home screen, touch
Apps
➔
WatchON
.
The Privacy policy displays.
2. Read the Privacy policy, check the
I have read and
accept the terms of the above privacy policy
box, and
touch
Confirm
.
The Set up WatchON screen displays.
3. Touch
Set up WatchON
.
4. Follow the on-screen instructions.
WatchON Menu
1. From a Home screen, touch
Apps
➔
WatchON
.
2. Touch
Menu
for the following options.
• Sign in
: Sign in to your Samsung account to improve your
WatchON experience.
•Settings
: Configure Samsung WatchON settings. Follow the
on-screen instructions.
•Help
: Displays Samsung WatchON help information and a
Contact us telephone number.
World Clock
Use this application to check the time of many major cities in
the world.
Tou ch
Samsung
folder ➔
World Clock
.
Creating Clocks
Tou ch ,
Add city
and then enter a city name or
select a city from the cities list or globe, and then touch
Save
.
To apply summer time, touch and hold a clock, and
then touch
DST settings
.
Deleting Clocks
Touch and hold the clock, and then touch
Delete
.
YouTube
Use this application to watch videos from the YouTube
website.
Tou ch
YouTube
.
For more information, refer to “YouTube” on page 82.
DRAFT For Internal Use Only
116
Section 9: Settings
About Settings
Use this application to configure the device, set application
options, and add accounts.
To accessing Settings:
From a Home screen, touch
Apps
➔
Settings
.
– or –
From any screen, touch the top of the screen and
swipe downward, to display the Quick Settings, and
then touch
Settings
. For more information, refer to
“Notifications Panel” on page 36.
Settings Tabs
The Settings are divided into four main groups. When the
Settings screen displays, the tabs are located at the top of
the screen.
Connections
Control your device’s wireless connections.
Wi-Fi
Wi-Fi is a wireless networking technology that provides
access to local area networks. Your device supports Wi-Fi
802.11 a/b/g/n/ac.
For more information about using your device’s Wi-Fi
features, see “Wi-Fi” on page 83.
Wi-Fi Direct Settings
Wi-Fi Direct allows device-to-device connections so you
can transfer large amounts of data over a Wi-Fi connection.
for more information about using Wi-Fi Direct, see “Wi-Fi
Direct” on page 86.
Bluetooth
Bluetooth is a short-range wireless communications
technology for exchanging information over a distance of
about 30 feet. You do not need to line up the devices to send
information with Bluetooth. If the devices are in range, you
can exchange information between them—even if they are
in different rooms.
For more information about using Bluetooth, see “Bluetooth”
on page 87.
DRAFT For Internal Use Only
Settings 117
Airplane Mode
Airplane mode allows you to use many of your tablet’s
features, such as Camera, Games, and more, when you are
in an airplane or in any other area where accessing data is
prohibited.
Important!
When your tablet is in Airplane Mode, it cannot
access online information or applications.
Press and hold the
Power/Lock
Key
then touch
Airplane mode
.
– or –
Touch the top of the screen and swipe downward,
to display the Quick Settings, and then touch
Airplane mode
.
For more information, refer to “Notifications” on
page 35.
– or –
Tou ch
Settings
➔
Connections
tab ➔
Airplane mode
, touch the check box, and then touch
OK
to turn on Airplane mode.
Data Usage
View your Wi-Fi data usage.
1. From the
Settings
screen, touch
Connections
tab ➔
Data usage
.
2. Touc h th e
Data usage cycle
drop-down menu and
select a date.
The data usage displays as a visual (chart) and also
displays a list of each application with a breakdown of
data usage by application.
Note:
Data is measured by your device. Your service provider
may account for data usage differently.
3. Touc h
Menu
for options:
• Auto sync data
: Automatically sync data. Disabling auto sync
will reduce data usage and conserve battery power, but
notifications and updates will need to be manually
synchronized.
• Mobile hotspots
: Display all mobile hotspots near you.
DRAFT For Internal Use Only
118
Location Services
You value your privacy. So, by default, your device only
acquires your location when you allow it. To use
Location-Based Services, you must first enable location
services on your device.
Before you use applications such as Google Maps and find
your location or search for places of interest, you must
enable the Use wireless networks option or enable the GPS
satellites.
1. From the
Settings
screen, touch
Connections
tab ➔
Location services
.
2. Touch
Access to my location
to allow apps that have
asked your permission to use your location
information.
3. Touch
Use GPS satellites
to enable the GPS satellite.
4. Touch
Use wireless networks
to enable location
information using the wireless network.
5. Touch
My places
to save your favorite locations for use
with services that require location information.
More Networks
This tab displays additional wireless and network
information.
From the
Settings
screen, touch
Connections
tab ➔
More networks
.
Options display for VPN.
VPN
The VPN settings menu allows you to set up and manage
Virtual Private Networks (VPNs).
Important!
Before you can use a VPN you must establish and
configure one.
DRAFT For Internal Use Only
Settings 119
Adding a VPN
Before you add a VPN you must determine which VPN
protocol to use: PPTP, L2TP/IPSec PSK, L2TP/IPSec RSA,
IPSec Xauth PSK, IPSec Xauth RSA, or IPSec Hybrid RSA.
Note:
You must also set a screen unlock PIN or password
before you can use credential storage. For more
information, refer to “Screen Security” on page 124.
1. From the
Settings
screen, touch
Connections
tab ➔
More networks
➔
VPN
.
2. Touch
Add
.
3. In the form that appears, fill in the information provided
by your network administrator.
4. Touch
Save
to save your VPN settings.
Connecting To a VPN
1. From the
Settings
screen, touch
Connections
tab ➔
More networks
➔
VPN
.
2. Touch the VPN to which you want to connect.
3. In the pop-up that opens, enter any requested
credentials.
4. To uc h
Connect
.
Edit or Delete a VPN
1. From the
Settings
screen, touch
Connections
tab ➔
More networks
➔
VPN
.
2. Touch and hold the VPN that you want to edit or delete.
3. In the pop-up that opens, touch:
• Edit network
, make the desired VPN setting changes, and
touch
Save
.
– or –
• Delete network
to delete the VPN.
DRAFT For Internal Use Only
120
Nearby Devices
This option allows you to share your media files with nearby
DLNA (Digital Living Network Alliance) enabled devices.
Warning!
If file sharing is enabled, other devices can access
your data. Use the Wi-Fi network and this option
with care.
To configure this option:
1. From the
Settings
screen, touch
Connections
tab ➔
Nearby devices
.
2. Touch the
OFF/ON
button to turn Nearby devices
ON .
The device name displays under Device name. The
default is the model number: SM-P600.
3. In the Advanced section, set the following options:
• Shared contents
: Select the content to share. Choices are:
Videos, Photos, and Music.
• Allowed devices list
: Indicate the devices accessible to your
device.
• Not-allowed devices list
: Indicate the devices not accessible
to your device.
•Download to
: Set whether to download data to Device or
SD card.
• Upload from other devices
: If a nearby device attempts to
upload data, this setting indicates the response. Options are:
Always accept, Always ask, and Always reject.
Screen Mirroring
To share your device’s screen with another device, enable
Screen Mirroring.
1. From the
Settings
screen, touch
Connections
tab ➔
Screen Mirroring
.
The Screen Mirroring screen displays.
The
OFF/ON
button is set to ON . Available
devices are listed.
2. Tou ch
Scan
to find more devices.
3. Tou ch
Menu
➔
Help
to for more information.
DRAFT For Internal Use Only
Settings 121
Device
This section of the Settings screen contains settings for your
device.
Sound
Volume
Set the volume level for all types of sounds.
1. From the
Settings
screen, touch
Device
tab ➔
Sound
➔
Volume
.
2. Touch and drag the sliders to set the volume for:
•Music
,
video
,
games
,
and other media
: Sounds made by
music apps, video apps, and more.
• Notifications
: Sounds for alerts to new messages and other
events.
• System
: Application sounds and other sounds made by your
device.
Tip:
You can also set System volume from a Home screen by
pressing the Volume Key.
3. Touch
OK
to save your settings.
Vibration Intensity
Select how intense the vibration is for different options.
1. From the
Settings
screen, touch
Device
tab ➔
Sound
➔
Vibration intensity
.
2. Touch and drag the sliders to adjust the vibration
intensity for Notification and Haptic feedback.
3. To uc h
OK
to save the setting.
Notifications
Select a default ringtone for message, alarm, and other
notifications.
1. From the
Settings
screen, touch
Device
tab ➔
Sound
➔
Default notification sound
.
2. Touch a ringtone to hear a sample and select it.
3. To uc h
OK
to save the setting.
System
You can activate or deactivate both touch and screen lock
sounds.
1. From the
Settings
screen, touch
Device
tab ➔
Sound
.
DRAFT For Internal Use Only
122
2. Touch the check box next to any of the following
options to activate the feature:
• Touch sounds
: Makes a sound when you touch the screen.
• Screen lock sound
: Makes a sound when your screen is
locked or unlocked.
• Haptic feedback
: Vibrate when soft keys are tapped and for
certain software actions.
• Pen attach/detach sound
: Set the sound that is made when
the pen is attached or detached from your tablet.
Samsung Keyboard
Set the keyboard sounds.
1. From the
Settings
screen, touch
Device
tab ➔
Sound
.
2. Touch the check box next to either of the following
options to activate the feature:
•Key-tap sound
: Enables auditory feedback when you touch an
on-screen key.
• Key-tap vibration
: Enables the device to vibrate when you touch
an on-screen key.
HDMI
To set the HDMI (High-Definition Multimedia Interface) audio
setting:
1. From the
Settings
screen, touch
Device
tab ➔
Sound
.
2. Tou ch
Audio output
.
3. Tou ch
Stereo
or
Surround
to set the audio output
setting.
More Settings
To find the best sound for you and use this while you play
music:
1. From the
Settings
screen, touch
Device
tab ➔
Sound
.
2. Tou ch
Adapt Sound
.
3. Read the on-screen instructions.
4. Tou ch
Start
when you are ready to begin.
DRAFT For Internal Use Only
Settings 123
Display
Use the Display settings to configure the way your device’s
screen operates.
From the
Settings
screen, touch
Device
tab ➔
Display
.
The following options are available:
• Brightness
: Touch and drag the slider to set the brightness or
touch
Automatic brightness
. Touch
OK
to save the setting.
• Screen timeout
: Set the length of delay between the last key
press or screen touch and the automatic screen timeout (dim
and lock).
• Touch key light duration
: Set the duration for the touch button
backlight.
• Screen mode
: Select a screen mode from the following:
–
Adapt display
: Use this mode for optimizing the display
according to the display settings.
–
Dynamic
: Use this mode to make the display tone more vivid.
–
Standard
: Use this mode for normal surroundings.
–
Movie
: Use this mode for dim surroundings, such as in a
dark room.
• Reading mode
: Use Reading mode to optimize the screen for
reading from selected applications. Touch the
OFF/ON
button
to turn Reading mode ON .
•Daydream
: Set the device to launch a screensaver when your
device is connected to a desktop dock or charging. Touch the
OFF/ON
button to turn Daydream ON .
• Show battery percentage
: Set the device to display the
remaining battery life.
• Edit after screen capture
: Set the device to edit a screenshot
after capturing it.
Multi Window
Set the device to use Multi Window.
1. From the
Settings
screen, touch
Device
tab ➔
Multi
window
.
2. Touc h th e
OFF/ON
button to turn Multi window
ON .
3. To uc h
Open in multi window view
to automatically view
contend in a multi window when you open files from
My Files or Video, or attachments from email and
messages.
DRAFT For Internal Use Only
124
For more information, refer to “Activating Multi Window” on
page 33.
Lock Screen
Screen Security
Choose settings for unlocking your screen. For more
information about using the lock and unlock features, see
“Securing Your Device” on page 14.
1. From the
Settings
screen, touch
Device
tab ➔
Lock screen
.
2. Touch
Screen lock
for these settings:
•Swipe
: Swipe the screen to unlock it.
• Pattern
: A screen unlock pattern is a touch gesture you create
and use to unlock your device. Follow the prompts to create or
change your screen unlock pattern.
•PIN
: Select a PIN to use for unlocking the screen.
• Password
: Create a password for unlocking the screen.
•None
: No pattern, PIN, or password is required.
Note:
Additional options are available based on the
Screen lock
setting.
Swipe Options
The options available when Screen lock is set to Swipe are:
•
Multiple widgets
: Display multiple widgets on your lock screen.
Appears as an options after a lock mode is enabled.
•
Clock widget options
: Set the size of the Clock widget that is
displayed on your home screens, and whether to show the date.
•
Shortcuts
: Set shortcuts to appear at the bottom of the Lock
screen. Touch the
OFF/ON
button
to turn it ON .
•
Personal message
: Edit the personal message and touch the
OFF/ON
button
to turn it ON
.
•
Owner Information
: Enable or disable whether to show owner
information on the lock screen.
–
Tou ch
Owner information
and then touch
Show owner info on
lock screen
to enable or disable the option.
–
Touch the text field and use the keyboard to enter the text to
display on the lock screen.
•
Unlock effect
: Set the effect you receive when unlocking the phone.
You can select None, Watercolor, or Ripple.
DRAFT For Internal Use Only
Settings 125
•
Ink effect
: This setting defaults to Blue.
•
Wake up in lock screen
: Unlock the screen using wake-up
command when swipe or motion lock is enabled.
•
Action Memo on lock screen
: Set the device to launch action
memo when you double-tap the locked screen with the S Pen
button pressed.
•
Help text:
Show help information on the Lock screen.
Additional Pattern, PIN, and Password Options
These additional options are available when Screen lock is
set to Pattern, PIN, or Password:
•
Make pattern visible
: See the pattern as you draw it.
•
Lock automatically
: Set how quickly to lock the screen after the
screen automatically turns off.
•
Lock instantly with power key
: Use this option to enable the
lock screen when the power key is pressed. If this option is not
enabled, the screen dims or brightens when the power key is
pressed.
Wallpaper
You can choose a picture to display on the Home Screen,
Lock screen, or to both the Home and lock screens. Choose
from preloaded wallpaper images or select a photo you have
downloaded or taken with the Camera.
1. From the
Settings
screen, touch
Device
tab ➔
Wallpaper
.
2. To uc h
Home screen
,
Lock screen
, or
Home and lock
screens
.
The Select wallpaper from screen displays the
following options:
Gallery
,
Live wallpapers
, and
Wallpapers
.
For more information, refer to “Wallpapers” on page 41.
DRAFT For Internal Use Only
126
Font
Set the font for screen displays and the size you want it to
display.
1. From the
Settings
screen, touch
Device
tab ➔
Font
.
2. Touch
Font style
then touch a font or touch
Get fonts
online
to browse and download a new font.
3. Touch
Font size
and select a font size.
Notification Panel
Customize the Notification panel.
1. Tou ch
Settings
➔
Device
tab ➔
Notification panel
.
2. Touch
Brightness adjustment
to adjust the screen
brightness from the Notification panel.
3. To customize which quick setting buttons appear at the
top of the notifications panel, touch and drag buttons to
reorder them.
Accessibility
Accessibility services are special features to make using the
device easier for those with certain physical disabilities. Use
the Accessibility settings to activate these services.
Note:
You can download accessibility applications from
Google Play and manage their use here.
From the
Settings
screen, touch
Device
tab ➔
Accessibility
.
Configure the following settings:
• Auto-rotate screen
: When this option is checked, the screen
orientation changes when you rotate the device. When this
option is not checked, the screen orientation locks in the
current orientation (landscape or portrait) and the orientation
does not change when you rotate the device.
Tip:
From any screen, touch the top of the screen and swipe
downward, to display the Quick Settings screen. Touch
Screen rotation
to enable or disable the auto-rotate
feature. For more information, refer to “Notifications
Panel” on page 36.
DRAFT For Internal Use Only
Settings 127
• Screen timeout
: Select the screen delay time the screen delays
shutting off after inactivity for the selected period of time.
• Lock Automatically
:
This option only appears depending on
the Screen lock setting. For more information, refer to
“Screen Security”
on page 124.
• Speak passwords
: Speaks passwords to enter them.
• Easy touch mode
: Enable this option to stop or snooze alarms,
calendar events, and timer alerts, and to accept or reject
incoming calls.
•Show shortcut
: Set this option to display an Accessibility
shortcut on the Device options pop-up when you press and
hold the power key.
• Manage accessibility
: Save and update your accessibility
settings or share them with another device. You can export your
settings, import a previously saved file, or share your file with
another device.
Services
• TalkBack
: Activate the TalkBack feature.
Note:
TalkBack, when installed and enabled, speaks feedback
to help blind and low-vision users.
Important!
TalkBack can collect all of the text you enter,
except passwords, including personal data and
credit card numbers. It may also log your user
interface interactions with the device.
Vision
•Font size
: Set the font size.
• Magnification gestures
: Use exaggerated gestures such as
triple-tapping, double pinching, and dragging two fingers
across the screen.
• Negative colors
: Reverse the display of on-screen colors
from White text on a Black background to Black text on a White
background.
DRAFT For Internal Use Only
128
• Color adjustment
: Adjust the display colors, if you are color
blind and have difficulty reading the display because of the
colors. Touch
OFF/ON
button to turn it ON . Follow the
on-screen instructions.
• Notification reminder
: Play a beep when a notification for a
call, message, and so on, has been missed. Touch
OFF/ON
button to turn it ON
• Accessibility shortcut
: Quickly enable accessibility features
in two quick steps. Touch
OFF/ON
button to turn it
ON . Follow the on-screen instructions.
• Text-to-speech options
: To set voice output settings, touch
Text-to-speech options
and select the preferred TTS engine.
For more information, refer to
“Speech”
on page 132.
Touch
Speech rate
to set the speed at which the text is spoken.
Touch
Listen to an example
to play a short speech
demonstration.
Hearing
• Sound balance
: Use the slider to set the Left and Right
balance when using a stereo device.
•Mono Audio
: When Mono audio is enabled, you can listen
through one earphone to mono audio sound.
• Turn off all sounds
: Turn off all sounds including receiver
voice.
• Flash notification
: Set your camera light to blink whenever
you receive a notification.
Mobility
• Assistant menu
: Improve the device accessibility for users
with reduced dexterity. Touch
OFF/ON
button to turn it
ON . Follow the on-screen instructions.
• Press and hold delay
: Select a time interval for this action.
Recognition
• Interaction control
: Enable or disable motions and screen
timeout. You can also block areas of the screen from touch
interaction. Touch
OFF/ON
button to turn it ON . Follow
the on-screen instructions.
DRAFT For Internal Use Only
Settings 129
Blocking Mode
When enabled, notifications for selected features are
disabled.
1. From the
Settings
screen, touch
Device
tab ➔
Blocking mode
.
2. Touch the
OFF/ON
button to turn Blocking mode
ON .
3. Touch
Turn off notifications
to enable this feature.
4. The
Set time
option allows you to set Blocking mode for
a specific time range or
Always
.
Touch the
Always
field to disable it and configure the
From
and
To
time fields.
Note:
When this option is enabled, displays in the
Status Bar.
Controls
Use these settings to configure Language and input, Voice
control, S Pen, Motions, Palm motion, and Smart screen.
Language and Input
Language
Set the language used by your device.
1. From the
Settings
screen, touch
Controls
tab ➔
Language and input
➔
Language
.
2. Touch a language / locale from the list.
Keyboards and Input Methods
Set the keyboard used by your device.
1. From the
Settings
screen, touch
Controls
tab ➔
Language and input
.
2. To uc h
Default
and select a keyboard.
Samsung keyboard is the only selection available for
this device.
3. To uc h
Set up input methods
.
DRAFT For Internal Use Only
130
Configuring the Samsung Keyboard
To configure the Samsung keyboard:
Touch next to Samsung keyboard to display the
following options:
• Select input languages
: Used to set a default text entry
language. Touch this field, scroll through the options, and touch
the desired input language. When activated, a check appears
in the box.
•Predictive text
: Enable or disable XT9 predictive text. When
enabled the system suggests words matching your text entries,
and, optionally, completes common words automatically.
When XT9 is enabled, touch the
Predictive text
field to set the
following options:
–
Live word update
: Automatically update with popular new
words every day.
–
Personalized data
: Enter personalized data to improve
prediction results.
–
Learn from Facebook
: Log in to let your device learn your
Facebook style.
–
Learn from Gmail
: Log in to let your device learn your Gmail
style.
–
Learn from Twitter
: Log in to let your device learn your Twitter
style.
–
Learn from Contacts
: Allow your device to learn your Contacts
style.
–
Clear remote data
: Delete your anonymous data stored on the
personalization server.
–
Clear personal data
: Remove all personalized data entered.
• Auto replacement
: Complete or replace the word you are
typing with the most probable word when you touch the space
bar or a punctuation mark.
• Auto capitalization
automatically capitalizes the first letter of
the first word in each sentence (standard English style).
• Auto spacing:
automatically inserts spaces between words.
• Auto punctuate
automatically inserts a full stop in a sentence
by touching the space bar twice when using the on-screen
QWERTY keyboard.
DRAFT For Internal Use Only
Settings 131
• Keyboard swipe
: Select one of the following:
–
None
: Enable or disable the keyboard swipe feature.
–
SwiftKey Flow
: Enable or disable the SwiftKey Flow feature.
When enabled, you can enter text by sliding your finger across
the keyboard.
–
Cursor control
: Enable or disable the smart keyboard
navigation feature to move the cursor by scrolling the keyboard.
• Key-tap feedback
: Select one or more of the following:
–
Sound
: Enable or disable auditory feedback when you touch an
on-screen key.
–
Vibration
: Enable or disable vibration when you touch an
on-screen key.
–
Character preview
: Provide an automatic preview of the
current character selection within the text string. This is helpful
when multiple characters are available within one key.
• Pen detection
: Set the device to open the handwriting panel
when the field is tapped with the S Pen.
•Help
: Access help information for using the Samsung
keyboard.
• Reset settings
: Reset Samsung keyboard settings.
Google Voice Typing
1. To uc h
Google voice typing
to automatically use Google
voice typing.
2. Touch next to Google voice typing.
The following options are available:
• Choose input languages
: Touch
Automatic
to use the local
language or select a language from the list.
• Block offensive words
: Enable or disable blocking of
recognized offensive words from the results of your voice-input
Google searches.
When enabled, a check mark appears in the check box.
• Download offline speech recognition
: Enable voice input
while offline. Touch the
All
tab to download speech recognition
for other languages.
Handwriting Recognition
Tou ch
Language
to select a language for handwriting
search.
DRAFT For Internal Use Only
132
Speech
Set the speech settings for Voice search.
1. From the
Settings
screen, touch
Controls
tab ➔
Language and input
.
2. Touch
Voice search
to configure:
• Language
: Choose a language for your voice input.
• Speech output
: Always provides audible readout of text, or
only when using Hands-free functions.
• Block offensive words
: Enable or disable blocking of
recognized offensive words from the results of your voice-input
Google searches.
• Hotword detection
: When enabled, saying the word Google
launches voice search.
• Download offline speech recognition
: Enable voice input
while offline. Touch the
All
tab to download speech recognition
for other languages.
• Bluetooth headset
: Record audio through a Bluetooth
headset, if available.
Voice output provides audible readout of text, for example,
the contents of email messages.
1. From the
Settings
screen, touch
Controls
tab ➔
Language and input
.
2. Tou ch
Text-to-speech options
and select the preferred
TTS engine.
3. Touch next to the preferred TTS engine and
configure.
4. Under General, configure the following:
• Speech rate
: Set the speed at which the text is spoken.
• Listen to an example
: Play a sample of speech synthesis
(available if voice data is installed).
Mouse/trackpad
This option sets your Pointer speed.
1. From the
Settings
screen, touch
Controls
tab ➔
Language and input
.
2. Tou ch
Pointer speed
then drag the slider to the right to
go faster or to the left to go slower.
3. Tou ch
OK
to save your setting.
DRAFT For Internal Use Only
Settings 133
Voice Control
Set the device to recognize voice commands for controlling
your device. You can select the features to control with voice
commands.
1. From the
Settings
screen, touch
Controls
tab ➔
Voice
Control
.
2. Touch the
OFF/ON
button to turn Voice Control
ON .
3. Touch the items you want to control. Choose from
Alarm, Camera, and Music.
S Pen
Change the settings for using the S Pen.
From the
Settings
screen, touch
Controls
tab ➔
S Pen
.
The following options display:
• Turn off pen detection
: Set the screen not to respond when
inserting or removing the S Pen.
•Pointer
: Show the pointer when you hover the S Pen over the
screen. Touch the
OFF/ON
button to turn this option
ON .
• Direct pen input
: Launch handwriting pad when hovering the
S Pen over a text input field. Touch the
OFF/ON
button to turn
this option ON .
• Air view
: Show the S Pen pointer when the S Pen is hovering
over the screen. Touch the
OFF/ON
button to turn this option
ON . Touch Air view to select what will be shown when
you hover your pen over an item on the screen: Information
preview, Progress preview, Icon labels, and List scrolling.
• Air command
: While hovering over an item with the S Pen,
press the pen button to display a list of options for the item or
general air commands. Touch the
OFF/ON
button to turn this
option ON .
• Sound and haptic feedback
: Set the device to make a sound
and vibrate when pointing at items with the S Pen.
• Pen detachment options
: Launch action memo or air
command when the S Pen is pulled out of the slot.
• Pen attach/detach sound
: Emit a sound when the S Pen is
inserted into, or pulled out of, the slot.
DRAFT For Internal Use Only
134
Motions
Activate the motion recognition feature and change the
settings that control motion recognition on your device.
From the
Settings
screen, touch
Controls
tab ➔
Motions
.
Touch the
OFF/ON
button to turn each of the following
options ON .
•Zoom
: Zoom in or out while viewing images in Gallery or
browsing webpages, when you tap and hold two points with
your fingers and then tilt the device back and forth.
•Move an icon
: Set the device to make a sound and vibrate
when pointing at items with your finger.
•Browse an image
: Set the device to scroll through an image
by moving the device in any direction when the image is
zoomed in.
Palm Motion
Activate the palm motion feature to control the device by
touching the screen.
From the
Settings
screen, touch
Controls
tab ➔
Palm motion
.
Tou ch the
OFF/ON
button to turn each of the following
options ON .
• Capture screen
: Set the device to capture an image of the
screen when you sweep your hand to the left or right across the
screen.
•Mute/Pause
: Set the device to pause media playback when
you touch the screen with your palm.
DRAFT For Internal Use Only
Settings 135
Smart Screen
To set Smart screen options:
From the
Settings
screen, touch
Controls
tab ➔
Smart screen
.
The following options display:
•Smart stay
: Prevent the display backlight from turning off while
you are looking at the display.
• Smart rotation
: Set the interface not to rotate according to the
orientation of your face.
•Smart pause
: Pause video playback when you look away from
the screen.
• Smart scroll
: Touch the
OFF/ON
button to turn this option
ON . The following options are available:
–
Scroll by
: Select a method to scroll the screen up or down.
–
Speed
: Adjust the speed for scrolling the screen.
–
Visual Feedback display
: Display a signal icon when the
device recognizes your action.
Note:
This feature may not work properly in bright light, in
dark conditions, or when the device is being moved or
shaken.
DRAFT For Internal Use Only
136
General
This tab provides the ability to create and modify your
accounts. It also provides access to settings for Cloud
accounts, the backup and reset features, date and time,
Accessory, Application manager, Battery,
Power saving mode, Storage, Security, Developer options,
and About device.
Accounts
Set up and manage accounts, including your Google
accounts, Samsung accounts, and email accounts.
Your device provides the ability to synchronize information
from a variety of accounts, including Email, Facebook,
Google, and your Samsung account. Depending on the
account, you can choose to synchronize your calendar,
contacts, and other types of content.
With synchronization, you can ensure that the information on
your device is updated with any information that changes in
your accounts.
Managing Accounts
To view the accounts you have added:
1. From the
Settings
screen, touch
General
tab ➔
(account).
The (account) is either Google, Samsung account, or
some other account you have added, such as Email.
Each of your accounts (Google, Samsung, and so on)
are listed under Accounts.
2. Tou ch
Sync all
to synchronize all accounts listed. Touch
Cancel sync
to stop the synchronization.
3. Touch an account to view the sync settings for that
account.
•
Touch
Sync now
to synchronize all data for the selected
account.
– or –
Touch the account data to synchronize, such as, Calendar,
Contacts, and so on.
•
To remove the account, touch
Remove account
and then
touch
Remove account
at the prompt to remove the account
and delete all its messages, contacts, and other data.
DRAFT For Internal Use Only
Settings 137
4. For Google accounts, touch one of the items listed
under Privacy to view various settings for that item.
– or –
For Samsung accounts, touch
Account settings
to
manage Samsung account settings or
Backup
to set
Samsung account back up and restore options.
– or –
For Email accounts, touch
Settings
to manage various
settings for that account.
Adding an Account
To add a new account:
1. From the
Settings
screen, touch
General
tab ➔
Add account
.
2. Touch one of the account types.
3. Follow the prompts to enter your credentials and set up
the account.
Tip:
For more information about the types of accounts that you
can add, see “Accounts” on page 46.
Sign in to Your Samsung Account
Several applications and options require that you create and
sign in to a Samsung Account.
To sign in to your Samsung account:
1. From the
Settings
screen, touch
General
tab ➔
Add account
.
2. To uc h
Samsung account
.
The Samsung account sign in screen displays.
3. To uc h
variety of services
to display information about
Samsung services that are available.
4. If you have no Samsung account, touch
Create new
account
.
– or –
If you do have a Samsung account, touch
Sign in
.
The Samsung account screen displays.
DRAFT For Internal Use Only
138
5. Use the keyboard to enter the required information and
touch
Sign up
or
Sign in
.
Tip:
The password is for your Samsung account, not the
password you use for the email address you are entering.
Plus, you can use only letters, numbers, !, @, $, %, &, ^,
and * for your Samsung account password.
6. If you are creating a new account, the Terms and
Conditions screen displays. Read the Terms and
conditions, Special terms, and Privacy policy and touch
I accept all the terms above
.
The Settings screen displays with Samsung account
listed under Accounts.
Cloud
Back up your personal data using your Samsung Account or
use Dropbox to sync your device content.
1. From the
Settings
screen, touch
General
tab ➔
Cloud
.
2. Under
Personal data management
:
If you have not signed in to your Samsung Account,
touch
Add account
. For more information about
Samsung accounts, see “Sign in to Your Samsung
Account” on page 137.
If you have signed in to your Samsung Account:
•
Touch your Samsung Account to manage your sync settings or
remove your Samsung Account.
•
Touch
Storage usage
to show the storage used and the
remaining storage available.
•
Touch
Sync settings
to sync your calendar, contacts, Internet,
S Note, and Scrapbook settings with your Samsung Account.
•
Touch
Backup
to manage your back up and restore options.
•
Touch
Restore
to retrieve data from your Samsung account.
DRAFT For Internal Use Only
Settings 139
3. Under
Content sync (with Dropbox)
:
If you have not signed in to you Dropbox account, touch
Link Dropbox account
. For more information, refer to
“Dropbox” on page 96.
Backup and Reset
You can also back up your data to the Google server and
reset your device to its factory defaults.
Backup and Restore
To enable or disable backup of your information to the
Google server.
1. From the
Settings
screen, touch
General
tab ➔
Backup and reset
.
2. Touch
Back up my data
to enable or disable back up of
application data, Wi-Fi passwords, and other settings
to the Google server.
Once the
Back up my data
option is enabled, then the
Backup account
and the
Automatic restore
options are
available.
3. To uc h
Backup account
and touch your Google Gmail
account or touch
Add account
to set your Google Gmail
account to be backed up to the Google server.
4. To uc h
Automatic restore
to enable automatic
restoration of settings from the Google server. When
enabled, backed-up settings are restored when you
reinstall an application.
Factory Data Reset
Use Factory data reset to return your device to its factory
defaults. This setting erases all data from the device,
including Google or other email account settings, system and
application data and settings, and downloaded applications,
as well as your music, photos, videos, and other files. If you
reset the tablet in this way, the next time you turn on your
tablet you are prompted to reenter the same kind of
information as when you first started Android.
1. From the
Settings
screen, touch
General
tab ➔
Backup and reset
.
2. To uc h
Factory data reset
.
The Factory data reset screen displays reset
information.
DRAFT For Internal Use Only
140
3. Touch
Reset device
, then follow the prompts to perform
the reset.
Date and Time
By default, your device receives date and time information
from the wireless network. When you are outside network
coverage, you may want to set date and time information
manually using the Date & time settings.
1. From the
Settings
screen, touch
General
tab ➔
Date and time
.
2. Configure the following settings:
•Set date
: Enter the current date (only available when the
Automatic setting is disabled).
•Set time
: Enter the current time (only available when the
Automatic setting is disabled).
• Select time zone
: Choose your local time zone (only available
when the Automatic setting is disabled).
• Use 24-hour format
: Set the format for time displays.
• Select date format
: Set the format for date displays.
Accessory
To change accessory settings:
From the
Settings
screen, touch
General
tab ➔
Accessory
.
• Dock sound
: play a sound when your device is connected to
or removed from a desktop dock.
• Audio output mode
: use the dock speaker when your device
is connected to a desktop dock.
• Audio output
: Select a sound output format to use when
connecting your device to HDMI devices. Some devices may
not support the surround sound setting.
•Daynote
: show the quick note pad when the cover is
flipped open.
•Unit
: Set unit options.
DRAFT For Internal Use Only
Loading...
