Samsung SM-P350 User Manual

User Manual

SM-P350

English (SEA). 04/2015. Rev.1.1

www.samsung.com

Table of Contents

Read me first

Getting started

6 Package contents

7 Device layout

9 S Pen

12 Charging the battery

14 Using a memory card

15 Turning the device on and off

16 Locking and unlocking the screen

Basics

Network connectivity

32 Wi-Fi

S Pen features

33 Air command

34 Action memo

36 Smart select

37 Image clip

38 Screen write

39 S Note

43 Scrapbook

44 Using the S Pen

17 Using the touch screen

20 Home screen layout

24 Notifications panel

26 Opening apps

26 Installing or uninstalling apps

28 Entering text

30 Screen capture

30 My Files

31 Power saving feature

Motions & usability features

47 Motions and gestures

49 Multi window

Personalising

53 Managing the Home and Apps screens

54 Setting wallpaper and ringtones

55 Changing the screen lock method

56 Private mode

2

Table of Contents

58 Multiple users

59 Setting up accounts

Contacts

60 Adding contacts

60 Importing and exporting contacts

61 Searching for contacts

Camera

62 Basic shooting

63 Shooting modes

65 Camera settings

Connecting with other
devices

79 Bluetooth

81 Wi-Fi Direct

83 Quick Connect

84 SideSync 3.0

91 Screen Mirroring

93 Mobile printing

Device & data manager

94 Transferring data from your previous

device

95 Using the device as a removable disk

for data transfer

Gallery

66 Viewing content on the device

Useful apps and features

67 S Finder

67 S Planner

69 Email

71 Internet

72 Music

73 Video

74 Clock

75 Calculator

96 Updating the device

97 Backing up and restoring data

97 Performing a data reset

Settings

98 About Settings

98 Connections

100 Device

103 Personal

106 System

Troubleshooting

75 Smart Manager

77 Google apps

3

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider, or
device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.

•

Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.

•

Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.

4

Read me first

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Note: notes, usage tips, or additional information

5

Getting started

Package contents

Check the product box for the following items:

•

Device

•

Quick start guide

•

The items supplied with the device and any available accessories may vary
depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible
with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.

6

Getting started

Light sensor

Device layout

Front camera

Microphone

Power button

Touch screen

Home button

Recent apps button

Headset jack

S Pen

GPS antenna

Rear camera

Volume button

Memory card slot

Back button

Multipurpose jack

Push clip

Push clip

Speaker

7

Getting started

•

Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.

•

Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.

•

Do not allow water to contact the touch screen. The touch screen may malfunction
in humid conditions or when exposed to water.

Buttons

Button Function

•

Press and hold to turn the device on or off.

Power

•

Press to turn on or lock the screen.

Recent apps

Home

Back

Volume

•

Tap to open the list of recent apps.

•

Tap and hold to launch the split screen view.

•

Press to turn on the screen while the screen is locked.

•

Press to return to the Home screen.

•

Press and hold to launch

•

Tap to return to the previous screen.

•

Press to adjust the device volume.

Google

.

8

Getting started

S Pen

S Pen button

S Pen nib

Name Functions

•

Use the S Pen to write, draw, or perform touch actions on the
screen.

S Pen nib

•

Hover the S Pen over items on the screen to access additional

Tweezers

S Pen button

Tweezers

S Pen features, such as Air Button and the air view feature.

•

Hover the S Pen over the screen and press the S Pen button to
display the air command features.

•

While pressing and holding the S Pen button, drag the S Pen over
items to select them.

•

Remove the S Pen nib with the tweezers when replacing the nib.

9

Getting started

Removing the S Pen

When you remove the S Pen from the slot, the device launches
air command features depending on the S Pen detachment option setting.

To change the setting, open the Apps screen and tap

options

.

Settings

Air command

→

S Pen

→

Replacing the S Pen nib

If the nib is dull, replace it with a new one.

Firmly hold the nib with the tweezers and remove it.

1

or displays the

Detachment

10

Getting started

Insert a new nib into the S Pen.

2

Be careful not to pinch your fingers with the tweezers.

•

Do not reuse old nibs. Doing so may cause the S Pen to malfunction.

•

Do not press the nib excessively when inserting the nib into the S Pen.

•

Do not insert the round end of the nib into the S Pen. Doing so may cause damage
to the S Pen or your device.

•

If the S Pen is not working properly, take it to a Samsung Service Centre. For more
information about the S Pen, visit the Samsung website.

•

If you use the S Pen at sharp angles on the screen, the device may not recognise
the S Pen actions. Do not bend or apply excessive pressure with the S Pen while
using it.

•

The Recent apps button and the Back button can be used with the S Pen.

11

Getting started

Charging the battery

Use the charger to charge the battery before using it for the first time. A computer can be also
used to charge the battery by connecting them via the USB cable.

Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.

•

When the battery power is low, the battery icon appears empty.

•

If the battery is completely discharged, the device cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for
a few minutes before turning on the device.

•

If you use multiple apps at once, network apps, or apps that need a connection
to another device, the battery will drain quickly. To avoid disconnecting from the
network or losing power during a data transfer, always use these apps after fully
charging the battery.

Connect the USB cable to the USB power adaptor and then plug the end of the USB cable

1

into the multipurpose jack.

Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.

12

Getting started

Plug the USB power adaptor into an electric socket.

2

•

The device can be used while it is charging, but it may take longer to fully charge
the battery.

•

If the device receives an unstable power supply while charging, the touch screen
may not function. If this happens, unplug the charger from the device.

•

While charging, the device may heat up. This is normal and should not affect the
device’s lifespan or performance. If the battery gets hotter than usual, the charger
may stop charging.

•

If the device is not charging properly, take the device and the charger to a
Samsung Service Centre.

After fully charging, disconnect the device from the charger. First unplug the charger

3

from the device, and then unplug it from the electric socket.

To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.

Reducing the battery consumption

Your device provides options that help you save the battery power. By customising these
options and deactivating features in the background, you can use the device longer between
charges:

•

Optimise the device using the Smart manager.

•

When you are not using the device, switch to sleep mode by pressing the Power button.

•

Close unnecessary apps using the task manager.

•

Deactivate the Bluetooth feature.

•

Deactivate the Wi-Fi feature.

•

Deactivate auto-syncing of apps.

•

Decrease the backlight time.

•

Decrease the screen brightness.

13

Getting started

Using a memory card

Installing a memory card

Your device accepts memory cards with maximum capacities of 128 GB. Depending on the
memory card manufacturer and type, some memory cards may not be compatible with your
device.

•

Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.

•

Use caution to insert the memory card right-side up.

•

The device supports the FAT and the exFAT file systems for memory cards. When
inserting a card formatted in a different file system, the device asks to reformat the
memory card.

•

Frequent writing and erasing of data shortens the lifespan of memory cards.

•

When inserting a memory card into the device, the memory card’s file directory
appears in the

Open the cover of the memory card slot.

1

Insert a memory card with the gold-coloured contacts facing downwards.

2

My Files

→

SD card

folder.

Push the memory card into the slot until it locks in place.

3

Close the cover of the memory card slot.

4

14

Getting started

Removing the memory card

Before removing the memory card, first unmount it for safe removal. On the Home screen, tap

Apps

→

Settings

Open the cover of the memory card slot.

1

Push the memory card until it disengages from the device, and then pull it out.

2

Close the cover of the memory card slot.

3

Do not remove the memory card while the device is transferring or accessing
information. Doing so can cause data to be lost or corrupted or can damage the
memory card or device. Samsung is not responsible for losses that result from the
misuse of damaged memory cards, including the loss of data.

→

Storage

→

Unmount SD card

.

Formatting the memory card

A memory card formatted on a computer may not be compatible with the device. Format the
memory card on the device.

On the Home screen, tap

→

CARD

ERASE EVERYTHING

Before formatting the memory card, remember to make backup copies of all
important data stored in the device. The manufacturer’s warranty does not cover loss
of data resulting from user actions.

Apps

→

.

Settings

→

Storage

→

Format SD card

→

FORMAT SD

Turning the device on and off

Press and hold the Power button for a few seconds to turn on the device.

When you turn on your device for the first time or after performing a data reset, follow the on­screen instructions to set up your device.

To turn off the device, press and hold the Power button, and then tap

Follow all posted warnings and directions from authorised personnel in areas where
the use of wireless devices is restricted, such as aeroplanes and hospitals.

15

Power off

.

Getting started

Locking and unlocking the screen

Pressing the Power button turns off the screen and locks it. Also, the screen turns off and
automatically locks if the device is not used for a specified period.

To unlock the screen, press the Power button or the Home button and flick your finger in any
direction within the unlock screen area.

You can change the unlock code to unlock the screen. Refer to Changing the screen lock

method for more information.

16

Basics

Using the touch screen

•

Do not allow the touch screen to come into contact with other electrical devices.
Electrostatic discharges can cause the touch screen to malfunction.

•

To avoid damaging the touch screen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.

•

The device may not recognise touch inputs close to the edges of the screen, which
are outside of the touch input area.

•

Leaving the touch screen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touch screen when you do not use the
device.

Tapping

To open an app, to select a menu item, to press an on-screen button, or to enter a character
using the keyboard on the screen, tap it with a finger or the S Pen.

17

Basics

Tapping and holding

Tap and hold an item or the screen for more than 2 seconds to access available options.

Dragging

To move an item, tap and hold it and drag it to the target position.

18

Basics

Double-tapping

Double-tap on a webpage or image to zoom in. Double-tap again to return.

Flicking

Flick left or right on the Home screen or the Apps screen to see another panel. Flick up or
down to scroll through a webpage or a list of items, such as contacts.

Spreading and pinching

Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.

19

Basics

Home screen layout

Home screen

The Home screen is the starting point for accessing all of the device’s features. It displays
widgets, shortcuts to apps, and more. Widgets are small apps that launch specific app
functions to provide information and convenient access on your Home screen.

To view other panels, scroll left or right, or tap one of the screen indicators at the bottom of
the screen. To customise the Home screen, refer to Managing the Home screen.

A widget

An app

A folder

Screen indicators

Favourite apps

20

Basics

Home screen options

On the Home screen, tap and hold an empty area, or pinch your fingers together to access
the available options.

21

Basics

Apps screen

The Apps screen displays icons for all apps, including newly installed apps.

On the Home screen, tap

Apps

to open the Apps screen. To view other panels, scroll left or
right, or select a screen indicator at the bottom of the screen. To customise the Apps screen,
refer to Managing the Apps screen.

Edit the Apps
screen.

An app

A screen indicator

22

Basics

Indicator icons

Indicator icons appear on the status bar at the top of the screen. The icons listed in the table
below are most common.

The status bar may not appear at the top of the screen in some apps. To display the
status bar, drag down from the top of the screen.

Icon Meaning

Wi-Fi connected

Bluetooth feature activated

GPS activated

Synced with the web

Alarm activated

S Pen detached

Mute mode activated

Flight mode activated

Error occurred or caution required

Battery power level

23

Basics

Activate or deactivate options.

Rearrange quick setting

Notifications panel

Using the notifications panel

When you receive new notifications, such as messages, indicator icons appear on the status
bar. To see more information about the icons, open the notifications panel and view the
details.

To open the notifications panel, drag the status bar downwards. To close the notifications
panel, drag the bar from the bottom of the screen upwards.

You can use the following functions on the notifications panel.

Tap and hold a button to view

more detailed settings.

Tap a notification and perform

Launch S Finder.

various actions.

Adjust the brightness.

buttons.

Launch Settings.

Select a user or add users.

Launch Quick Connect.

Clear all notifications.

24

Basics

Rearranging quick setting buttons

To rearrange quick setting buttons on the notifications panel, tap
drag the item to another location, and then tap

DONE

.

EDIT

, tap and hold an item,

Using the quick setting buttons

You can activate or deactivate some features on the notifications panel. Tap the following
options to activate or deactivate them. You can view more detailed settings if you tap and
hold a button.

•

Wi-Fi

: Refer to Wi-Fi for more information.

•

Location

•

Sound

•

Screen rotation

•

Bluetooth

: Activate or deactivate the GPS feature.

/

Mute

: Select a sound mode.

: Allow or prevent the interface from rotating when you rotate the device.

Some apps do not allow screen rotation.

: Refer to Bluetooth for more information.

•

Power saving

•

Flight mode

•

Do not disturb

block notifications. To select which notifications will be blocked, tap

and notifications

•

Reading mode

protect your eyes when reading at night.

•

U. power saving

•

Smart stay

•

Private mode

•

Screen Mirroring

•

Sync

: When you activate this feature, the device automatically syncs apps, such as

calendar or email.

: Refer to Power saving feature for more information.

: Refer to Flight mode for more information.

: Activate or deactivate blocking mode. In blocking mode, the device will

→

Do not disturb

: Activate or deactivate reading mode. In reading mode, the device helps

: Refer to Ultra power saving mode for more information.

: When you activate this feature, the screen stays on as long as you look at it.

: Refer to Private mode for more information.

: Refer to Screen Mirroring for more information.

.

Settings

→

Sounds

25

Basics

Opening apps

On the Home screen or the Apps screen, select an app icon to open it.

To open the list of recently-used apps, tap

and select an app icon to open.

Closing an app

Tap and drag an app icon to the left or right to close it. To close all running apps, tap

CLOSE ALL

.

Installing or uninstalling apps

Samsung Galaxy Apps

Use this app to purchase and download apps.

Tap

Galaxy Apps

This app may not be available depending on the region or service provider.

on the Apps screen.

Installing apps

Browse apps by category or tap

Select an app to view information about it. To download free apps, tap
and download apps where charges apply, tap the button that shows the app’s price.

To change the auto update settings, tap →
then select an option.

SEARCH

to search for a keyword.

Settings

Install

→

Auto update apps

. To purchase

, and

26

Basics

Play Store

Use this app to purchase and download apps.

Tap

Play Store

Installing apps

Browse apps by category or tap to search for a keyword.

on the Apps screen.

Select an app to view information about it. To download free apps, tap
and download apps where charges apply, tap the price and follow the on-screen instructions.

To change the auto update settings, tap →
then select an option.

Settings

→

INSTALL

Auto-update apps

. To purchase

, and

Managing apps

Uninstalling or disabling apps

To disable default apps, open the Apps screen and tap
can disable. Select an app and tap

To uninstall downloaded apps, open the Apps screen and tap

→

DONE

manager

. Alternatively, on the Apps screen, tap
, select an app, and then tap

DISABLE

→

DONE

Settings

UNINSTALL

EDIT

. appears on the apps that you

.

EDIT

→ →

→

Applications

.

UNINSTALL

→

Application

Enabling apps

On the Apps screen, tap

DISABLED

, select an app, and then tap

•

Disabling apps: Disable selected default apps that cannot be uninstalled from the
device. You cannot use disabled apps.

•

Uninstalling apps: Uninstall downloaded apps.

Settings

→

Applications

ENABLE

→

Application manager

.

, scroll to

27

Basics

Delete a preceding character.

Change the language.

Entering text

Keyboard layout

A keyboard appears automatically when you enter text to send messages, create memos, and
more.

Text entry is not supported in some languages. To enter text, you must change the
input language to one of the supported languages.

Enter uppercase. For all caps,

tap it twice.

Enter punctuation marks.

Switch to handwriting mode.

Break to the next line.

Move the cursor.

Enter a space.

Changing the input language

Tap and hold , tap →
you select two or more languages, you can switch between the input languages by sliding
the space key left or right.

Select input languages

, and then select the languages to use. If

Using additional keyboard functions

Tap and hold to use various functions. Other icons may appear instead of depending
on the last function that was used.

•

: Enter text by voice.

Open the keyboard.

Start or pause entering text by
voice.

28

Basics

•

•

•

: Switch to handwriting mode.

Switch between number

mode and character mode.

Switch to the standard

keyboard.

This feature may not be available depending on the region or service provider.

: Add an item from the clipboard.

: Enter emoticons.

•

•

: Switch to the floating or split keyboard.

: Change the keyboard settings.

Copying and pasting

Tap and hold over text.

1

Drag or to select the desired text, or tap

2

Tap

Copy

or

Cut

3

Place the cursor where the text is to be inserted and tap →

4

you have previously copied, tap

. The selected text is copied to the clipboard.

→

Clipboard

Select all

and select the text.

to select all text.

Paste

. To paste text that

29

Basics

Search for files or folders.

Screen capture

Capture a screenshot while using the device.

Press and hold the Home button and the Power button simultaneously. You can view
captured images in
with others.

You can also capture screenshots using other methods. Refer to Palm swipe to capture for
more information.

It is not possible to capture a screenshot while using some apps.

Gallery

. After capturing a screenshot, you can edit the image and share it

My Files

Use this app to access various files stored in the device or in other locations, such as cloud
storage services.

Tap

My Files

on the Apps screen.

View recent files.

View files by categories.

View files stored in the device.

View files saved in cloud

storage services.

View storage information.

Access additional options.

30

Basics

Power saving feature

Power saving mode

Save the battery power by limiting the device’s functions.

On the Apps screen, tap
to activate it.

To automatically activate power saving mode when the remaining battery power reaches the
preset level, tap

Start power saving

Settings

→

Battery

and select an option.

→

Power saving mode

, and then tap the switch

Ultra power saving mode

Use this mode to extend the device’s battery power. In ultra power saving mode, the device
performs the following:

•

Restricts the available apps to essential and selected apps only.

•

Deactivates the Bluetooth feature.

On the Apps screen, tap
activate it.

To add an app to the Home screen, tap

To remove an app from the Home screen, tap

Settings

→

Battery

→

Ultra power saving mode

and select an app.

MORE

→

Remove

, and tap switch to

, select an app with , and

then tap

To change the settings for ultra power saving mode, such as network connectivity or sound,
tap

To deactivate ultra power saving mode, tap

DONE

MORE

The usage time left shows the time remaining before the battery power runs
out. Usage time left may vary depending on your device settings and operating
conditions.

→

Settings

.

.

MORE

→

Disable ultra power saving mode

.

31

Network connectivity

Wi-Fi

Connect the device to a Wi-Fi network to use the Internet or share media files with other
devices. Refer to Wi-Fi for additional options.

•

Your device uses a non-harmonised frequency and is intended for use in all
European countries. The WLAN can be operated in the EU without restriction
indoors, but cannot be operated outdoors.

•

Turn off Wi-Fi to save the battery when not in use.

On the Apps screen, tap

1

Select a network from the Wi-Fi networks list. Networks that require a password appear

2

with a lock icon.

Tap

3

CONNECT

Once the device connects to a Wi-Fi network, the device will reconnect to that
network each time it is available without requiring a password. To prevent the device
connecting to the network automatically, select it from the list of networks and tap

FORGET

.

.

Settings

→

Wi-Fi

, and then tap the switch to activate it.

32

S Pen features

Air command

Remove the S Pen from the slot, or hover the S Pen over any part of the screen and press the
S Pen button to access four useful features.

If this feature is not activated, open the Apps screen, tap

command

With the air command features, you can perform various actions.

, and then tap the

Smart select

Action memo

Air command

switch to activate it.

Settings

Image clip

Screen write

→

S Pen

→

Air

•

Action memo

search the web, and more. Refer to Action memo for more information.

•

Smart select

•

Image clip

Image clip for more information.

•

Screen write

Refer to Screen write for more information.

: Write memos quickly and link actions to them. You can send emails,

: Collect content quickly. Refer to Smart select for more information.

: Draw around an area of the screen you want to save or share. Refer to

: Capture, edit, and write memos on screenshots, and then share them.

33

S Pen features

Erase the memo.

Save the memo.

Action memo

Open the Action memo pad and create memos to perform various actions using the written
or drawn information.

On the air command panel, tap

1

Write or draw a memo.

2

Tap .

3

The entire memo will be selected. If you want to use specific information from the
memo, tap the outside of the selected area to deselect the memo and draw around the
information to use it.

Write a memo or change the

pen colour.

Select an input.

Action memo

.

Access additional options.

Discard the memo.

Add the memo as a widget to
the Home screen.

Available functions for the

selected memo information

Adjust the size of the memo

pad.

Edit the memo as S Note file.

34

S Pen features

Select an app to use with the selected memo information.

4

The selected app will launch from

Send an email.

Action memo

.

Create a task.Create a contact.

Search for a location.

Search the web.

Viewing memos

On the Action memo screen, tap →
it.

View action memo list

. Select a memo to view and edit

Adding Action memo widgets on the Home screen

After composing a memo, tap and hold , and then drag the memo to an empty area on the
Home screen. An Action memo widget is added to the Home screen and you can view and
edit the memo.

Editing a memo as S Note file

While composing a memo, tap to open
colour that you were using in

Action memo

S Note

and edit the memo in it. The same pen

will be applied in

S Note

.

35

S Pen features

Smart select

Collect the desired area of content appearing on the screen with the S Pen. You can collect
content from webpages or music and videos during playback.

When there is content you want to collect, such as a part of a webpage, open the air

1

command panel and tap

Drag the S Pen across the content you want to collect.

2

Smart select

.

Select an option to use with the collected item.

3

•

SAVE

: Save the item in

•

SHARE

•

insert it into messages, notes, and more.

•

: Share the item with others.

: Extract text from the item. You can copy the extracted text to the clipboard or

: Save the item in the collected items list to collect more content.

Scrapbook

.

Extract text.

36

S Pen features

Collecting multiple items

Tap to add content to your collected items list to use it later. To collect additional content,
tap

To view collected items, tap the collected items pop-up window. You can share, delete, or
save multiple items at once. To individually select an item in the collected items list, tap and
hold an item.

To delete the collected items, tap and hold the collected items list pop-up window, and then
drag it to

on the collected items pop-up window.

Delete

at the top of the screen.

Image clip

Use the S Pen to draw a closed shape around the area you want to save or share. You can crop
part of an image.

When there is content you want to capture, such as a part of an image, open the air

1

command panel and tap

Image clip

.

Draw around an area to select it with the S Pen.

2

Reshape the selected area by selecting a shape icon on the toolbar, or tap
automatically reshape the selected area.

to

37

S Pen features

Select an option to use with the selected area.

3

•

SAVE

•

SHARE

: Save the selected area in

: Share the selected area with others.

Scrapbook

.

Screen write

Capture screenshots to write or draw on them.

When there is content you want to capture, such as a part of a webpage, open the air

1

command panel and tap

The current screen is automatically captured and the editing toolbar appears on the
screen.

Screen write

.

Write a memo on the screenshot.

2

Select an option to use with the screenshot.

3

•

SHARE

•

SAVE

It is not possible to capture a screenshot while using some apps.

: Share the screenshot with others.

: Save the screenshot. You can view captured images in

38

Gallery

.

S Pen features

S Note

Create custom notes by recording your thoughts and ideas. You can insert multimedia files
and create Photo notes.

Starting S Note

Tap

1

S Note

on the Apps screen.

Alternatively, on the Home screen, tap

Select cover styles and tap

2

Select a default note template and tap

3

Select an account to sync your notes with and tap

4

If you are not signed in to the selected account, follow the on-screen instructions to sign
in to the account.

If you sync your notes with an account, you can view them on other devices by
registering the account on other devices.

NEXT

.

in the

NEXT

.

S Note

START

widget.

.

39

S Pen features

Using the S Note widget

You can launch some S Note features directly from the

On the Home screen, tap an icon in the

Launch S Note.

Create a note in handwriting

mode.

S Note

widget.

Creating notes

Tap

1
2

S Note

Alternatively, on the Home screen, tap

Tap .

on the Apps screen.

in the

S Note

S Note

widget.

widget.

Create a note in text mode.

Compose a note.

3

Tap

to write or draw on the screen, or tap to enter text using the keyboard.

Insert a multimedia file.

Write a note.

Erase the note.

Enter a note.

Select the note.

Access additional options.

Save the note.

Change the input mode to
draw with both the S Pen and
a finger, or to draw only with
the S Pen.

Undo and redo the last action.

Append another page to the
current note.

40

S Pen features

Changing the pen settings

When writing or drawing on the screen, tap once more to change the pen type, line
thickness, or pen colour.

Save the current setting as a

pen profile.

Open the preset pen profiles
list.

Change the pen type.

Change the line thickness.

Change the pen colour.

Fountain pen

Select a new colour using the
colour picker.

Calligraphy pen

Using the line eraser

Tap .

1

Tap an area to erase.

2

The whole line on the area will be erased. The line eraser can erase your S Note line by
line.

•

To only erase the area you touch with the S Pen, tap once more and deselect

line by line

. You can adjust the size of the eraser by dragging the size adjustment bar.

Erase

•

To clear the note, tap

Even with a smaller eraser, you may still not be able to precisely erase the intended
part.

ERASE ALL

.

41

S Pen features

Editing handwritten notes

Edit handwritten notes using various editing options, such as cutting, moving, resizing, or
transforming.

When there is handwriting or a drawing on the note, tap .

1

Tap or draw a line around the input to select and edit it.

2

To move the input to another location, select the input, and then drag it to a new
location.

To resize the input, select the input and drag the frame handle.

Use one of the following options:

3

•

Properties

•

Transform into

•

Cut

: Cut out the input. To paste it to another location, tap and hold the location, and

then tap

•

Copy

then tap

•

Delete

: Change the input properties, such as layout, size, colour, or thickness.

: Refine or convert handwriting or drawings.

Paste

: Copy the input. To paste it to another location, tap and hold the location, and

Paste

: Delete the input.

.

.

Magnified handwriting mode

Tap

MORE

the magnifier frame appears in the magnified window at the bottom of the screen. You can
precisely enter or correct the handwriting.

→

Show Magnified note

and drag the magnifier frame to an area. The area in

42

S Pen features

Sketch recording

You can record your actions while composing a note.

Tap

1
2

3

MORE

Tap and write or draw a note.

Your actions are recorded in real time.

To stop recording, tap again.

→

Record sketching

.

Tap

to view the recording.

Scrapbook

Collect content from various sources to create your own digital scrapbook. While viewing
webpages or videos, you can select and add a desired area to scrapbooks.

This app may not be available depending on the region or service provider.

When you launch this app for the first time or restart it after performing a data reset, read and
agree to the terms and conditions, and then set a sync option.

Tap

1
2

Scrapbook

Tap to select a category and select a scrapbook.

If there is a link below the scrapbook content, tap the link to go to the source.

on the Apps screen.

Tap

EDIT

3

You can add a title, text, memos, or tags to the scrapbook.

Tap

4

to edit it.

SAVE

to save the changes.

43

S Pen features

Using the S Pen

Write, draw, or perform touch actions with the S Pen. You can easily access additional features
by pressing the S Pen button.

Air view

Hover over an item on the screen with the S Pen to perform various functions.

If this feature is not activated, open the Apps screen, tap

, and then tap the

view

Air view

switch to activate it.

Settings

→

S Pen

Previewing information

Point at the screen to preview content or view information in a pop-up window.

→

Air

44

S Pen features

Using Air Button

Hovering the S Pen over items in some apps, such as
Button on the preview window. You can perform various actions directly from the preview
window using Air Button.

Air Button

Gallery

and

Video

, will display Air

Pen Select

While pressing and holding the S Pen button, drag the S Pen over text or item lists to select
multiple items or text. You can also copy and paste the selected items or text into another
app or share them with others.

45

S Pen features

Direct pen input

Fill in forms and write messages using your handwriting with the S Pen.

If this feature is not activated, open the Apps screen, tap

pen input

, and then tap the switch to activate it.

Writing in text fields

Hover the S Pen over a text field.

1

Tap to open the handwriting field.

2

Settings

→

S Pen

→

Direct

Write with the S Pen.

3

When you are finished, tap .

4

Writing in apps

You can write directly on the screen with the S Pen when using some features and apps.

46

Motions & usability features

Motions and gestures

Excessive shaking or impact on the device may result in unintended inputs. Control
motions properly.

Mute

On the Apps screen, tap
activate it.

Cover the screen with your palm to mute alarms.

Settings

→

Motions and gestures

, and then tap the

Mute

switch to

47

Motions & usability features

Palm swipe to capture

On the Apps screen, tap

capture

Place the side of your hand on the screen and sweep it across the screen from the right to
the left or vice versa to capture a screenshot. You can view captured images in
capturing a screenshot, you can edit the image and share it with others.

switch to activate it.

It is not possible to capture a screenshot while using some apps.

Settings

→

Motions and gestures

, and then tap the

Palm swipe to

Gallery

. After

48

Motions & usability features

Multi window

About Multi window

Multi window lets you run two apps at the same time in the split screen view. You can also run
multiple apps at the same time in the pop-up view.

Some apps may not support this feature.

Split screen view

Tap to open the list of recently used apps.

1

Swipe upwards or downwards and tap on a recent app window.

2

The selected app will launch in the upper window.

Select another app to launch.

3

You can also launch the split screen view by tapping and holding .

49

Motions & usability features

Using additional options

When using apps in the split screen view, select an app window and tap the circle between
the app windows to access the following options:

•

•

: Switch locations between app windows.

: Drag and drop text or copied images from one window to another. Tap and hold an

item in the selected window and drag it to a location in another window.

Some apps may not support this feature.

50

Motions & usability features

•

: Minimise the window.

•

: Maximise the window.

•

: Close the app.

Adjusting the window size

Drag the circle between the app windows up or down to adjust the size of the windows.

Pop-up view

On the Apps screen, launch an app to use in the pop-up view.

1

Drag down diagonally from either end of the top edge.

2

The app screen will appear in the pop-up view.

Drag and drop content.

Minimise the window.

Close the app.

Maximise the window.

51

Motions & usability features

Moving pop-up windows

To move a pop-up window, tap and hold the circle on a window and drag it to a new location.

Launching the pop-up view from the split screen view

On the split screen view, tap an app window to launch it in the pop-up view.

1

Tap and hold the circle between the app windows.

2

The selected app will launch in a pop-up window.

52

Personalising

Managing the Home and Apps screens

Managing the Home screen

Adding items

Tap and hold an app or a folder from the Apps screen, and then drag it to the Home screen.

To add widgets, open the Home screen, tap and hold an empty area, tap
hold a widget, and then drag it to the Home screen.

Widgets

, tap and

Moving and removing an item

Tap and hold an item on the Home screen, and then drag it to a new location.

To move the item to another panel, drag it to the side of the screen.

You can also move frequently-used apps to the shortcuts area at the bottom of the Home
screen.

To remove an item, tap and hold the item. Then, drag it to
the screen.

Remove

that appears at the top of

Creating a folder

On the Home screen, tap and hold an app, and then drag it over another app.

1

Enter a folder name.

2

To add more apps to the folder, tap and hold another app, and then drag it to the folder.

53

Personalising

Managing panels

On the Home screen, tap and hold an empty area to add, move, or remove a panel.

To add a panel, scroll left to the last panel, and then tap

To move a panel, tap and hold a panel preview, and then drag it to a new location.

To remove a panel, tap and hold a panel preview, and then drag it to
the screen.

To set a panel as the main Home screen, tap

.

.

Remove

at the top of

Managing the Apps screen

Moving items

On the Apps screen, tap

To move the item to another panel, drag it to the side of the screen.

EDIT

. Tap and hold an item and drag it to a new location.

Setting wallpaper and ringtones

Setting wallpaper

Set an image or photo stored in the device as wallpaper for the Home screen or the locked
screen.

On the Home screen, tap and hold an empty area, and then tap

1

on the Apps screen, tap

Select a screen to change or apply wallpaper to.

2

Scroll left or right and select from images displayed at the bottom of the screen.

3

To select photos taken by the device’s camera or other images, tap

Tap

4

SET AS WALLPAPER

Settings

or

DONE

→

Wallpaper

.

.

Wallpapers

From Gallery

. Alternatively,

.

54

Personalising

Changing ringtones

Change ringtones for notifications.

On the Apps screen, tap

Default notification sound

Settings

→

Sounds and notifications

, select a ringtone, and then tap OK.

→

Ringtones and sounds

→

Changing the screen lock method

You can change the way that you lock the screen to prevent others from accessing your
personal information.

On the Apps screen, tap
select a screen lock method. The device requires an unlock code whenever unlocking it.

If the unlock code is forgotten, take the device to a Samsung Service Centre to reset it.

Pattern

Draw a pattern by connecting four dots or more, and then draw the pattern again to verify it.

Settings

→

Lock screen and security

→

Screen lock type

, and then

Set a backup PIN to unlock the screen when you forget the pattern.

PIN

A PIN consists of numbers only. Enter at least four numbers, and then enter the password
again to verify it.

Password

A password consists of characters and numbers. Enter at least four characters including
numbers and symbols, and then enter the password again to verify it.

55

Personalising

Private mode

Hide personal content in your device to prevent others from accessing it.

In private mode, you can hide items in

Gallery, Video, Music, My Files, S Note

, and

Activating private mode

On the Apps screen, tap

1

activate it.

If you are activating private mode for the first time, follow the on-screen instructions to
set up a private mode access code.

Follow the on-screen instructions to enter the preset private mode access code.

2

Private mode is activated and

You can view and access the hidden items only when private mode is activated. To
hide items stored in the private folder, deactivate private mode.

Settings

→

Privacy

appears on the status bar.

→

Private mode

, and then tap the switch to

Internet

.

Hiding content

On the Apps screen, launch an app to hide items.

1

Select an item and tap

2

If private mode is not activated, follow the on-screen instructions to enter the preset
private mode access code.

The selected items will be moved to the private folder.

MORE

→

Move to Private

.

56

Personalising

Viewing hidden content

You can view hidden items only when private mode is activated.

On the Apps screen, tap

1

activate it.

Follow the on-screen instructions to enter the preset private mode access code.

2

On the Apps screen, tap

3

Items moved to the private folder will appear on the screen. For bookmarks, you can view
them with the

Internet

Settings

My Files

app.

→

→

Privacy

Private

→

Private mode

.

, and then tap the switch to

Unhiding content

In the private folder, tap and hold an item, and then tick items to unhide.

1

Tap

2
3

MORE

Select a folder to move the items to, and then tap

→

Remove from Private

.

MOVE HERE

.

The items will be moved to the selected folder.

Automatically deactivating private mode

You can set the device to automatically deactivate private mode each time the screen turns
off.

On the Apps screen, tap

1

activate it.

Follow the on-screen instructions to enter the preset private mode access code.

2
3

Tap the

Auto disable

When the
private folder if the screen turns off during transfer.

Auto disable

Settings

switch to activate it.

option is enabled, the device will fail to transfer files to the

→

Privacy

→

Private mode

, and then tap the switch to

57

Personalising

Multiple users

Set up additional user accounts for other users to use the device with personalised settings,
such as email accounts, wallpaper preferences, and more. Following types of user accounts
are available.

•

Owner

time, and cannot be created more than one. This account has full control of the device
including user account management.

•

User

device settings that affect all accounts.

•

Restricted profile

the owner account, and cannot use the services that require logging in.

: The owner account is created only when setting up the device for the first

: This account allows users to access their own apps and content, and customise the

: A restricted account can only access the apps and content allowed by

Adding users

On the Apps screen, tap

1

Tap

2
3

Add user or profile

Follow the on-screen instructions to complete the account setup.

Settings

→

User

→

Users

→ OK →

.

SET UP NOW

.

Adding restricted profile

On the Apps screen, tap

1

Tap

2
3

Add user or profile

Set an unlock code, and then select the content that restricted users are allowed to
access.

Settings

→

Restricted profile

→

Users

.

→

SET UP SCREEN LOCK

.

Switching users

On the Apps screen, tap

1

Select the account to switch to, and then unlock the device.

2

Settings

→

Users

.

58

Personalising

Managing users

When using the owner account, you can delete accounts or change the settings for restricted
accounts.

To change the settings, on the Apps screen, tap
account. Then, select or deselect apps and content to allow or restrict the account’s access to
them.

To delete the account, tap

. To delete the restricted account, tap → .

Settings

→

Users

and tap next to an

Setting up accounts

Adding accounts

Some apps used on your device require a registered account. Create accounts to have the
best experience with your device.

On the Apps screen, tap
Then, follow the on-screen instructions to complete the account setup.

To sync content with your accounts, select an account and select items to sync.

Settings

→

Accounts

→

Add account

and select an account service.

Removing accounts

On the Apps screen, tap

Remove account

.

Settings

→

Accounts

, select an account, and then tap

MORE

→

59

Contacts

Adding contacts

Moving contacts from other devices

You can move contacts from other devices to your device. Refer to Transferring data from

your previous device for more information.

Creating contacts manually

On the Apps screen, tap

1

Tap and enter contact information.

2

•

: Add an image.

3

•

Tap

/ : Add or delete a contact field.

SAVE

.

Contacts

.

Importing and exporting contacts

Import contacts from storage services to your device or export contacts from the device to
storage services.

On the Apps screen, tap

Tap

MORE

option.

→

Settings

Contacts

→

Import/Export contacts

.

, and then select an import or export

60

Contacts

Searching for contacts

On the Apps screen, tap

Use one of the following search methods:

•

Scroll up or down the contacts list.

•

Drag a finger along the index at the left side of the contacts list to scroll through it
quickly.

•

Tap the search field at the top of the contacts list and enter search criteria.

Once a contact is selected, take one of the following actions:

•

: Add to favourite contacts.

•

: Compose an email.

Contacts

.

Adding shortcuts for contacts to the Home screen

Add shortcuts to contacts that you frequently communicate with on the Home screen.

On the Apps screen, tap

1

Contacts

.

Select a contact.

2

Tap

3

MORE

→

Add shortcut on home screen

.

61

Camera

Basic shooting

Taking photos or recording videos

Tap

1
2
3

Camera

Tap the image on the preview screen where the camera should focus.

Tap to take a photo or tap to record a video.

•

Spread two fingers apart on the screen to zoom in, and pinch to zoom out.

•

To capture an image from the video while recording, tap

on the Apps screen.

Capture

.

•

To change the focus while recording a video, tap where you want to focus. To focus on
the centre of the screen, tap

Display current

mode.

Select among

various effects that

are available.

Use this for

delayed-time shots.

Change camera

settings.

.

View photos and
videos you have
captured.

Start recording a
video.

Take a photo.

Switch between the
front and rear
cameras.

Change the shooting
mode.

•

The camera automatically shuts off when unused.

•

Make sure that the lens is clean. Otherwise, the device may not work properly in
some modes that require high resolutions.

62

Camera

Launching Camera on the locked screen

To quickly take photos of special moments, launch

On the locked screen, drag

This feature may not be available depending on the region or service provider.

Camera etiquette

•

Do not take photos or record videos of other people without their permission.

•

Do not take photos or record videos where legally prohibited.

•

Do not take photos or record videos in places where you may violate other people’s
privacy.

outside the large circle.

Camera

on the locked screen.

Shooting modes

Auto

Use this mode to allow the camera to evaluate the surroundings and determine the ideal
mode for the photo.

On the Apps screen, tap

Camera

→

MODE

→

Auto

.

Panorama

Use this mode to take a photo composed of many photos strung together. The device

in

identifies the photo with

On the Apps screen, tap

To get the best shot, follow these tips:

•

Move the camera slowly in one direction.

•

Keep the image within the frame on the camera’s viewfinder.

•

Avoid taking photos of indistinct backgrounds, such as an empty sky or a plain
wall.

Gallery

Camera

→

.

MODE

→

Panorama

.

63

Camera

Continuous shot

Use this mode to take a series of photos of moving subjects.

On the Apps screen, tap

Tap and hold

to take several photos continuously.

Camera

→

MODE

→

Continuous shot

.

Beauty face

Use this mode to take a photo with lightened faces for gentler images.

On the Apps screen, tap

Camera

→

MODE

→

Beauty face

.

Interval shot

Use this mode to take series of self-portraits at an interval and save photos you want.

On the Apps screen, tap

1

Tap to use the front camera.

2

Tap

3

MODE

→

Interval shot

Camera

.

.

When the device detects your face, tap to take a photo of yourself. You can also tap the

4

screen to take a photo.

The device will take photos at the two-second intervals.

Tick photos you want to save and tap

5

SAVE

.

Sound & shot

Use this mode to take a photo with sound. The device identifies the photos with in

On the Apps screen, tap

Camera

→

MODE

→

Sound & shot

.

Sports

Use this mode to take a photo of fast-moving subjects.

On the Apps screen, tap

Camera

→

MODE

→

Sports

.

Gallery

.

64

Camera

Camera settings

On the Apps screen, tap
in both still camera and video camera modes.

•

Picture size (rear)

higher quality photos, however they will take up more memory.

•

Video size (rear)

however they will take up more memory.

•

Gesture control

portraits.

•

Save as horizontally flipped

scene, when taking photos with the front camera.

•

View mode

•

Grid lines

•

Location tags

•

: Change the aspect ratio of the preview screen.

: Display viewfinder guides to help composition when selecting subjects.

: Set the device to attach the location tag to the photo.

To improve GPS signals, avoid shooting in locations where the signal may be
obstructed, such as between buildings or in low-lying areas, or in poor weather

Camera

/

Picture size (front)

: Select a resolution. Higher resolutions result in higher quality videos,

: Set the device to detect your palm, so you can use it to take self-

→

SETTINGS

: Invert the image to create a mirror-image of the original

. Not all of the following options are available

: Select a resolution. Higher resolutions result in

conditions.

•

When you share a photo with the location tag attached, the location information
may be exposed to others. To avoid this, when viewing the photo, tap

→

Details

information.

•

Review pictures

•

Storage location

•

Volume keys function

zoom function.

•

Reset settings

The available options vary depending on the mode used.

: Reset the camera settings.

→

EDIT

, and then tap under

: Set the device to show photos after capturing them.

: Select the memory location for storage.

: Set the device to use the Volume button to control the shutter or

Location

to delete your location

MORE

65

Gallery

Access additional options.

Move to the previous screen.

Viewing content on the device

On the Apps screen, tap

Video files show the

To hide or show the menus, tap the screen.

Add to the favourites list.

Gallery

icon on the preview thumbnail.

and select an image or a video.

Delete the image.

Share the image to others.

Modify the image.

66

Useful apps and features

S Finder

Use this app to search for content on the device. You can apply various filters and view the
search history.

Open the notifications panel and tap

Searching for content

Tap the search field and enter a keyword, or tap and say a keyword.

To get more refined results, tap filters under the search field.

To select search categories, tap

MORE

S Finder

→

.

Select search locations

.

S Planner

Creating events

Tap

1
2

S Planner

Tap . Alternatively, select a date with no events in it and tap the date again.

on the Apps screen.

If the date already has saved events in it, tap the date and tap

67

.

Useful apps and features

Enter event details.

3

Enter a title.

Set a start and end date for the

Enter the location of the event.

Add more details.

Select a calendar to use or
sync with.

event.

Set a reminder for the event.

Attach a map showing the
location of the event.

Tap

SAVE

4

to save the event.

Creating tasks

Tap

1
2

3

S Planner

Tap

TASKS

To add more details, tap

Tap

SAVE

on the Apps screen.

, enter details, and then tap

.

to save the task.

TODAY

or

TOMORROW

Syncing events and tasks with your accounts

Tap

S Planner

To add accounts to sync with, tap
an account to sync with and sign in.

on the Apps screen.

MORE

→

Manage calendars

→

to set a due date.

Add account

. Then, select

To change an account’s syncing option, open the Apps screen, tap
then select an account service.

68

Settings

→

Accounts

, and

Useful apps and features

Attach images, videos and

Email

Setting up email accounts

Tap

Email

on the Apps screen.

Set up an email account when opening

Enter the email address and password. Tap

SETUP

the setup.

To set up another email account, tap

If you have more than one email account, you can set one as the default account. Tap

→

for a company email account. After that, follow the on-screen instructions to complete

Settings

→

MORE

→

Set default account

Email

MORE

for the first time.

NEXT

for a private email account or tap

→

Settings

, select an account, and then tap

→

Add account

MANUAL

.

DONE

Sending emails

Tap

Email

Tap

on the Apps screen.

at the bottom of the screen to compose an email.

others.

Send the email.

MORE

.

Add recipients.

Enter a subject.

Enter the email text.

Access additional options.

Add a CC or BCC.

Add recipients from the
contacts list.

69

Useful apps and features

Go to the previous or next

Reading emails

Tap

Email

Select an email account to use, and new emails are retrieved.

Tap an email to read.

Add this email address to the

on the Apps screen.

email.

contacts list or view other

options.

Access additional options.

Open attachments.

Reply to the email.

Mark the email as a reminder.

Delete the email.

Forward the email.Reply to all recipients.

70

Useful apps and features

Refresh the current webpage.

Internet

Tap

1
2
3

To view the toolbars, drag your finger downwards slightly on the screen.

Internet

Tap the address field.

Enter the web address or a keyword, and then tap Go.

on the Apps screen.

Move to the previously-visited

page.

Read an article in reading

mode.

Close the tab.

Open a new tab.

Access additional options.

View your bookmarks, saved
pages, and recent Internet
history.

Open the homepage.

71

Useful apps and features

Music

Playing music

Tap

Music

Select a music category, and then select a song to play.

on the Apps screen.

Access additional options.

Open the playlist.

Set the file as your favourite

song.

Turn on shuffle.

Skip to the previous song. Tap

and hold to move backwards

quickly.

Pause and resume playback.

To listen to songs at equal volume levels, tap

volume

switch to activate it.

When

Smart volume

is activated, the volume may end up louder than the device
volume level. Use caution to avoid long-term exposure to loud sounds to prevent
damage to your hearing.

MORE

→

Settings

Adjust the volume.

Change the repeat mode.

Skip to the next song. Tap and
hold to move forwards
quickly.

, and then tap the

Smart

Smart volume

may not be activated for some files.

72

Useful apps and features

Open the playlist.

Video

Playing videos

Tap

Video

Select a video to play.

backwards by dragging

on the Apps screen.

Move forwards or

the bar.

Access additional
options.

Pause and resume
playback.

Adjust the volume.

Move the control panel

to the left.

Change screen ratio.

Skip to the previous

video. Tap and hold to

move backwards

quickly.

Move the control panel
to the right.

Switch to the pop-up
video player.

Skip to the next video.
Tap and hold to move
forwards quickly.

73

Useful apps and features

Clock

ALARM

On the Apps screen, tap

Clock

→

ALARM

.

Setting alarms

Set an alarm time and tap

To open the keypad to enter an alarm time, tap

To activate or deactivate alarms, tap

OPTIONS

to set other various alarm options, and then tap

next to the alarm in the alarms list.

Stopping alarms

Tap

DISMISS

SNOOZE

to stop an alarm. If you have previously enabled the snooze option, tap

to repeat the alarm after a specified length of time.

Deleting alarms

Tap on an alarm in the list of alarms.

KEYPAD

SAVE

.

.

WORLD CLOCK

On the Apps screen, tap

Creating clocks

Enter a city name or select a city from the cities list or globe, and then tap .

Deleting clocks

Tap on a clock.

Clock

→

WORLD CLOCK

.

STOPWATCH

On the Apps screen, tap

Tap

Tap

START

STOP

to time an event. Tap

to stop timing. To clear lap times, tap

Clock

→

STOPWATCH

LAP

to record lap times.

.

RESET

.

74

Useful apps and features

TIMER

On the Apps screen, tap

Set the duration, and then tap

To open the keypad to enter the duration, tap

Tap

DISMISS

when the timer goes off.

Clock

→

TIMER

START

.

.

KEYPAD

.

Calculator

Use this app for simple or complex calculations.

Tap

Calculator

To clear the history, tap

on the Apps screen.

CLEAR HISTORY

.

Smart Manager

The Smart manager provides an overview of the status of your device’s battery, storage, RAM,
and system security. You can also automatically optimise the device with one tap of your
finger.

Using the quick optimisation feature

On the Apps screen, tap

The quick optimisation feature improves device performance through the following actions.

•

Identifying apps that use excessive battery power and clearing some memory.

•

Deleting unnecessary files and closing apps running in the background.

•

Scanning for malware and phishing attacks.

Smart Manager

→

CLEAN ALL

.

75

Useful apps and features

Using the Smart manager

On the Apps screen, tap

Smart Manager

and select a feature.

Battery

Check the remaining battery power and time to use the device. For devices with low battery
levels, conserve battery power by activating power saving features and closing apps that are
consuming an excessive amount of battery power.

The usage time left shows the time remaining before the battery power runs
out. Usage time left may vary depending on your device settings and operating
conditions.

Storage

Check the status of used and available memory capacity. You can delete unused and residual
files or uninstall apps that you do not use any more.

RAM

Check the amount of available RAM. You can close background apps and reduce the amount
of RAM you are using to speed up your device.

Device security

Check the device’s security status. This feature scans your device for malware and blocks
phishing attacks and malicious websites.

76

Useful apps and features

Google apps

Google provides entertainment, social network, and business apps. You may require a Google
account to access some apps. Refer to Setting up accounts for more information.

To view more app information, access each app’s help menu.

Some apps may not be available or may be labelled differently depending on the
region or service provider.

Chrome

Search for information and browse webpages.

Gmail

Send or receive emails via the Google Mail service.

Google+

Share your news and follow updates that your family, friends, and others share. You can also
back up your photos and videos, and more.

Maps

Find your location on the map, search for locations, and view location information for various
places.

Play Music

Discover, listen to, and share music on your device.

Play Movies & TV

Watch videos stored on your device and download various content to watch from

Play Store

.

Play Books

Download various books from

Play Store

and read them.

Play Newsstand

Read news and magazines that interest you in one convenient location.

77

Useful apps and features

Play Games

Download games from

Play Store

and play them with others.

Drive

Store your content on the cloud, access it from anywhere, and share it with others.

YouTube

Watch or create videos and share them with others.

Photos

Manage photos, albums, and videos that you have saved on the device and uploaded to

Google+

.

Hangouts

Chat with your friends individually or in groups and use images, emoticons, and video calls
while you are chatting.

Google

Search quickly for items on the Internet or your device.

Voice Search

Search quickly for items by saying a keyword or phrase.

Google Settings

Configure settings for some features provided by Google.

78

Connecting with other devices

Bluetooth

About Bluetooth

Bluetooth creates a direct wireless connection between two devices over short distances. Use
Bluetooth to exchange data or media files with other devices.

•

Samsung is not responsible for the loss, interception, or misuse of data sent or
received via Bluetooth.

•

Always ensure that you share and receive data with devices that are trusted
and properly secured. If there are obstacles between the devices, the operating
distance may be reduced.

•

Some devices, especially those that are not tested or approved by the Bluetooth
SIG, may be incompatible with your device.

•

Do not use the Bluetooth feature for illegal purposes (for example, pirating copies
of files or illegally tapping communications for commercial purposes).

Samsung is not responsible for the repercussion of illegal use of the Bluetooth
feature.

79

Connecting with other devices

Pairing with other Bluetooth devices

On the Apps screen, tap

1

The detected devices are listed.

Select a device to pair with.

2

If your device has paired with the device before, tap the device name without confirming
the auto-generated passkey.

If the device you want to pair with is not in the list, request that the device turns on its
visibility option.

Accept the Bluetooth authorisation request on both devices to confirm.

3

Settings

→

Bluetooth

, and then tap the switch to activate it.

Sending and receiving data

Many apps support data transfer via Bluetooth. You can share data, such as contacts or media
files, with other Bluetooth devices. The following actions are an example of sending an image
to another device.

Sending an image

On the Apps screen, tap

1

Select an image.

2

Tap

3

4

Share

If the device you want to pair with is not in the list, request that the device turns on its
visibility option.

Accept the Bluetooth authorisation request on the other device.

→

Bluetooth

Gallery

, and then select a device to transfer the image to.

.

80

Connecting with other devices

Receiving an image

When another device sends you an image, accept the Bluetooth authorisation request. You
can view received images in

Gallery

.

Unpairing Bluetooth devices

On the Apps screen, tap

1

The device displays the paired devices in the list.

Tap next to the device’s name to unpair.

2

Tap

3

Unpair

.

Settings

→

Bluetooth

Wi-Fi Direct

About Wi-Fi Direct

.

Wi-Fi Direct connects devices directly via a Wi-Fi network without requiring an access point.

Connecting to other devices

On the Apps screen, tap

1

Tap

2

3
4

Wi-Fi Direct

The detected devices are listed.

If the device you want to connect to is not in the list, request that the device turns on its
Wi-Fi Direct feature.

Select a device to connect to.

Accept the Wi-Fi Direct authorisation request on the other device to confirm.

.

Settings

→

Wi-Fi

, and then tap the switch to activate it.

81

Connecting with other devices

Sending and receiving data

You can share data, such as contacts or media files, with other devices. The following actions
are an example of sending an image to another device.

Sending an image

On the Apps screen, tap

1

Select an image.

2

Tap

3
4

Share

Accept the Wi-Fi Direct authorisation request on the other device.

If the devices are already connected, the image will be sent to the other device without
the connection request procedure.

→

Wi-Fi Direct

Gallery

, and then select a device to transfer the image to.

.

Receiving an image

When another device sends you an image, accept the Wi-Fi Direct authorisation request. You
can view received images in

Gallery

.

Ending the device connection

On the Apps screen, tap

1

Tap

2
3

Wi-Fi Direct

The device displays the connected devices in the list.

Tap the device name to disconnect the devices.

.

Settings

→

Wi-Fi

.

82

Connecting with other devices

Quick Connect

About Quick connect

Use this feature to easily search and connect to nearby devices.

•

Connection methods may vary depending on the type of connected devices or the
shared content.

•

Device name may vary depending on the Bluetooth devices to pair with. For
example, the device name can be shown as BT MAC.

Connecting to other devices

Open the notifications panel and tap

1

If you are using this feature for the first time, select a visibility option and tap

QUICK CONNECT

When the panel opens, the Wi-Fi and Bluetooth features are activated automatically and
the device searches for nearby devices.

If you have installed Samsung Link on your device, the list of devices registered with
Samsung Link will appear at the top of the screen.

Select a device to connect to.

2

The next steps may vary depending on the connected device. Follow the on-screen
instructions to complete the connection between the devices.

To allow nearby devices to search for your device and connect to it, tap

Device visibility

.

, and then select an option.

Quick Connect

.

ENABLE

SETTINGS

Re-searching for devices

→

If the desired device does not appear in the list, search for the device.

Tap

REFRESH

and select the device from the list of detected devices.

Deactivating the Quick connect feature

Tap .

83

Connecting with other devices

Sharing content

Share content with the connected devices.

Open the notifications panel and tap

1

Select a device from the list of detected devices.

2

Tap

3
4

Share content

Select the content to share and tap

Your device sends the content to the connected device.

and select a media category.

Quick Connect

DONE

.

.

SideSync 3.0

About SideSync 3.0

Use this app to control a smartphone’s screen with a virtual smartphone screen on your
tablet.

You can also control your tablet’s screen with a virtual screen on a computer via
Wi-Fi or a USB cable. Download and install SideSync 3.0 from the Samsung website
(www.samsung.com/sidesync) on the computer. For more information, refer to the
help menu on the virtual screen.

•

On your tablet, view messages or use the smartphone’s chat room.

•

On your tablet, watch a video playing on the smartphone on a larger display.

•

Easily transfer files between your tablet and smartphone by dragging and dropping the
files.

Before using this app

•

Your tablet and smartphone must support Wi-Fi Direct.

•

SideSync 3.0 must be installed on both your tablet and smartphone.

If it is not installed on any device, download and install it from

•

SideSync 3.0 operates only on devices with Android version 4.4 or higher.

Galaxy Apps

or

Play Store

.

84

Connecting with other devices

Connecting your tablet and a smartphone

On your tablet, tap

1

Launch

2

The tablet searches for available smartphones automatically.

3

Select one of the detected smartphones.

SideSync 3.0

SideSync 3.0

on a smartphone.

on the Apps screen.

Tap OK on the smartphone screen.

4

85

Connecting with other devices

The smartphone’s virtual screen is displayed on your tablet and the smartphone’s screen

5

is turned off.

86

Connecting with other devices

Minimise the screen.

Using the virtual smartphone screen

Browse the screen and use apps in the virtual smartphone screen. You can send or receive
messages, or chat with others.

•

Some features, such as
screen.

•

The smartphone’s virtual screen may differ depending on the smartphone.

Screen Mirroring

, may not work in the virtual smartphone

Access additional options.

Screen rotation

Screen capture

Open the same webpage in

the web browser of your

tablet.

Maximise the screen to fit your
tablet's screen.

Close SideSync 3.0.

Virtual smartphone screen

Recent apps button

Back button

Home button

87

Connecting with other devices

Moving the virtual smartphone screen

Tap and drag the top edge of the virtual smartphone screen to move it to another location.

Adjusting the size of the virtual smartphone screen

Tap and hold at the bottom right of the virtual smartphone screen.

1

When the frame appears, drag the frame to adjust the size.

2

Entering text

When you enter text in the virtual smartphone screen, the tablet’s keyboard appears. Enter
text using the keyboard.

88

Connecting with other devices

Switching between the smartphone screen and the virtual smartphone
screen

It is not possible to use the smartphone screen and the virtual smartphone screen at the
same time. When you are using the virtual smartphone screen on the tablet, the smartphone
screen turns off.

Using the smartphone screen

Press the Home button on the smartphone to turn on the smartphone screen and turn off the
virtual smartphone screen on the tablet.

Using the virtual smartphone screen

Tap

SWITCH TO TABLET

turn off the smartphone screen.

on the tablet’s screen to turn on the virtual smartphone screen and

Playing music or videos on the tablet

Play music or videos stored in the smartphone via the screen and speaker of the tablet.

Open a music or video file in the virtual smartphone screen on the tablet.

1

The selected file is played using the tablet’s screen and speaker.

2

Adjust the volume on the virtual smartphone screen or the tablet during playback.

89

Connecting with other devices

Copying files between devices

Copying files from the smartphone to the tablet

Tap and hold a file on the virtual smartphone screen.

1

Select the files to copy, tap and hold any selected file, and then drag it to the tablet’s

2

screen.

3

My Files
DONE

is launched on the tablet’s screen. Select a folder to save the file in and tap

.

Copying files from the tablet to the smartphone

Tap and hold a file on the tablet’s screen.

1

Select the files to copy, tap and hold any selected file, and then drag it to the virtual

2

smartphone screen.

3

My Files

and tap

is launched on the virtual smartphone screen. Select a folder to save the file in

DONE

.

Using call functions with the tablet

You can use your smartphone’s call functions with the speaker and the microphone of the
tablet. Receive an incoming call or make a call using virtual smartphone screen.

For more information about the call functions, refer to the smartphone’s user manual.

90

Connecting with other devices

Screen Mirroring

About Screen Mirroring

Use this feature to connect your device to a large screen with an AllShare Cast dongle or
HomeSync and then share your contents.

Screen Mirroring

-enabled devices
(AllShare Cast dongle,
HomeSync)

•

This feature may not be available depending on the region or service provider.

•

Some files may be buffered during playback, depending on the network
connection.

•

To save energy, deactivate this feature when not in use.

•

If you specify a Wi-Fi frequency, AllShare Cast dongles or HomeSync may not be
detected or connected.

•

If you play videos or games on a TV, select an appropriate TV mode to get the best
experience.

91

Connecting with other devices

Viewing content on a TV

Before you connect your device to a TV, connect the screen mirroring-enabled device to the
TV. To set up the connection, refer to the device’s user manual. The following actions are an
example of viewing content on a TV connected via an AllShare Cast dongle.

Connect the AllShare Cast dongle to the TV using an HDMI cable.

1

On the TV, select a connection mode, such as HDMI mode, to connect an external device.

2

Open the notifications panel and tap

3

The detected devices are listed.

Select a device to connect to.

4

Your device’s screen appears on the TV screen.

If you connect the device for the first time, tap and hold the dongle’s name in the list and
enter the PIN shown on the TV screen.

Open or play a file, and then control the display with the keys on your device.

5

EDIT

→

Screen Mirroring

.

92

Connecting with other devices

Mobile printing

Connect the device to a printer via Wi-Fi or Wi-Fi Direct, and print images or documents.

Some printers may not be compatible with the device.

Adding printer plug-ins

Add printer plug-ins for printers you want to connect the device to.

On the Apps screen, tap

plug-in

, and search for a printer plug-in in

Settings

→

More connection settings

Play Store

. Select a printer plug-in and install it.

→

Printing

→

Download

Connecting to a printer

On the Apps screen, tap
plug-in, and then tap the switch to activate it. The device searches for printers that are
connected to the same Wi-Fi network as your device.

To add printers manually, select a printer plug-in, tap

PRINTER

To change print settings, select a printer plug-in and tap

, enter details, and then tap OK.

Settings

→

More connection settings

MORE

→

MORE

→

Printing

Add printer

→

Printing settings

, select a printer

→

ADD

.

Printing content

While viewing content, such as images or documents, tap

printers

, and then select a printer.

Share

→

Print

→ →

All

93

Device & data manager

Transferring data from your previous device

You can transfer data from a previous device to your new device via Samsung Smart Switch.
The following versions of Samsung Smart Switch are available.

•

Mobile version: Transfer data between mobile devices. You can download the app from

Galaxy Apps

•

Computer version: Transfer data between your device and a computer. You can download
the app from www.samsung.com/smartswitch.

•

Samsung Smart Switch is not supported on some devices or computers.

•

Limitations apply. Visit www.samsung.com/smartswitch for details. Samsung
takes copyright seriously. Only transfer content that you own or have the right to
transfer.

or

Play Store

.

Transferring data from a mobile device

Transfer data from your previous device to your new device.

Download and install Smart Switch from

Launch
previous device.

Smart Switch

and follow the on-screen instructions to transfer data from your

Galaxy Apps

or

Play Store

.

Transferring data from a computer

Back up data from your previous device to a computer and import the data to your new
device.

On the computer, visit www.samsung.com/smartswitch to download Smart Switch.

1

On the computer, launch Smart Switch.

2

If your previous device is not a Samsung device, back up data to a computer using a
program provided by the device’s manufacturer. Then, skip to the fifth step.

94

Device & data manager

Connect your previous device to the computer using the USB cable.

3

On the computer, follow the on-screen instructions to back up data from the device.

4

Then, disconnect your previous device from the computer.

Connect your new device to the computer using the USB cable.

5

On the computer, follow the on-screen instructions to transfer data to your new device.

6

Using the device as a removable disk for data transfer

Move audio, video, image, or other types of files from the device to the computer, or vice
versa.

Do not disconnect the USB cable from the device when you are transferring files.
Doing so may cause data loss or device damage.

The devices may not connect properly if they are connected via a USB hub. Directly
connect the device to the computer’s USB port.

Connect the device to the computer using the USB cable.

1

Open the notifications panel, and then tap

2

device (MTP)

Camera (PTP)

Tap
not have any appropriate driver installed.

Transfer files between your device and the computer.

3

.

if your computer does not support Media Transfer Protocol (MTP) or

Connected as a media device

→

Media

95

Device & data manager

Updating the device

The device can be updated to the latest software.

Updating over the air

The device can be directly updated to the latest software by the firmware over-the-air (FOTA)
service.

On the Apps screen, tap

To automatically check for available updates, tap the
it.

Settings

→

About device

→

Software update

Auto update

→

Update now

switch to activate

Updating with Smart Switch

Connect the device to a computer and update the device to the latest software.

On the computer, visit www.samsung.com/smartswitch to download and install Smart

1

Switch.

On the computer, launch Smart Switch.

2

Connect the device to the computer using a USB cable.

3

If a software update is available, follow the on-screen instructions to update the device.

4

.

•

Do not turn off the computer or disconnect the USB cable while the device is
updating.

•

While updating the device, do not connect other media devices to the computer.
Doing so may interfere with the update process. Before updating, disconnect all
other media devices from the computer.

96

Device & data manager

Backing up and restoring data

Keep your personal information, app data, and settings safe on your device. You can back up
your sensitive information to a backup account and access it later. You must sign in to your
Google or Samsung account to back up or restore data. Refer to Setting up accounts for more
information.

Using a Samsung account

On the Apps screen, tap
to back up, and then tap

To set the device to automatically back up data, tap the

To restore data using a Samsung account, tap
device to restore the selected items.

Settings

BACK UP NOW

→

Backup and reset

→

Back up my data

.

Restore

Auto back up

. Current data will be deleted from the

switch to activate it.

, select the items

Using a Google account

On the Apps screen, tap
switch to activate it. Tap

To restore data using a Google account, tap the
you reinstall apps, backed up settings and data will be restored.

Settings

Backup account

→

Backup and reset

, and then tap the

and select an account as the backup account.

Automatic restore

switch to activate it. When

Back up my data

Performing a data reset

Delete all settings and data on the device. Before performing a factory data reset, ensure you
back up all important data stored on the device. Refer to Backing up and restoring data for
more information.

On the Apps screen, tap

→

DEVICE

ERASE EVERYTHING

Settings

→

Backup and reset

. The device automatically restarts.

97

→

Factory data reset

→

RESET

Settings

About Settings

Use this app to configure the device, set app options, and add accounts.

Tap

Settings

on the Apps screen.

To search for settings by entering keywords, tap

SEARCH

.

Connections

Wi-Fi

Activate the Wi-Fi feature to connect to a Wi-Fi network and access the Internet or other
network devices.

On the Settings screen, tap

To use options, tap

MORE

Setting Wi-Fi sleep policy

Tap

MORE

→

Keep Wi-Fi on during sleep

Wi-Fi

.

, and then tap the switch to activate it.

.

Bluetooth

Activate the Bluetooth feature to exchange information over short distances.

On the Settings screen, tap

Bluetooth

, and then tap the switch to activate it.

Flight mode

This disables all wireless functions on your device. You can use only non-network services.

On the Settings screen, tap

Flight mode

, and then tap the switch to activate it.

98

Settings

Data usage

Keep track of your data usage amount.

On the Settings screen, tap

To use more options, tap

•

Restrict networks

network.

Data usage

MORE

: Set the device to disable sync in the background while using Wi-Fi

.

.

More connection settings

Customise settings to control networks.

On the Settings screen, tap

Printing

Configure settings for printer plug-ins installed on the device. You can search for available
printers or add one manually to print files.

VPN

More connection settings

.

Set up and connect to virtual private networks (VPNs).

Ethernet

The Ethernet option is available when an Ethernet adaptor is connected to the device. Use
this option to activate the Ethernet feature and configure network settings.

99

Settings

Device

Sounds and notifications

Change settings for various sounds on the device.

On the Settings screen, tap

•

Sound mode

•

Volume

•

Ringtones and sounds

•

Sound quality and effects

•

Do not disturb

•

Notifications on lock screen

the locked screen.

•

App notifications

: Set the device to use sound mode or silent mode.

: Adjust the volume level for music and videos, system sounds, and notifications.

: Change settings for managing interruptions.

: Change the notification settings for each app.

Display

Change the display settings.

On the Settings screen, tap

•

Brightness

: Set the brightness of the display.

Sounds and notifications

: Change the ringtone and system sound settings.

: Select a sound effect to apply when you adjust to music.

: Set whether or not to show the content of notifications on

Display

.

.

•

Font

: Change the font size and type.

•

Screen timeout

backlight.

•

Smart stay

looking at the display.

•

Screen mode

•

Daydream

: Set the device to prevent the display backlight from turning off while you are

: Change the screen mode.

: Set the device to launch a screensaver when the device is charging.

: Set the length of time the device waits before turning off the display’s

100
