Samsung SL600 User Manual
User Manual
SL600
Thank you for buying a Samsung Camera.
This manual will help you learn to capture
images, share or print your photos, and edit
photos with the accompanying software.
Please read this manual thoroughly.
Getting to Know your cameraInstructions
Use this camera in the following order.
Setting up the application software
Take a picture
Insert the USB cable
Check the camera's
power
Check [Removable Disk]
To use this camera with a PC,
install the application software
rst. After this has been done, the
stored images in the camera can be
moved to the PC and can be edited
by an image editing program. (p.89)
Take a picture. (p.21)
Insert the supplied USB cable
into the PC’s USB port and the
camera’s USB connection
terminal. (p.89)
Check the camera’s power. If the
power is turned off, preset the
camera button to turn it on.
Open Windows’s EXPLORER
and search for [Removable Disk].
(p.90)
Thank you for buying a Samsung Digital Camera.
å
Prior to using this camera, please read the user manual
thoroughly.
å
If you require After Sales service, please bring the camera and the
cause of the camera malfunction (such as battery, Memory card
etc.) to the A/S center.
å
Please check that the camera is operating properly prior to when
you intend to use it (e.g. for a trip or an important event) to avoid
disappointment. Samsung takes no responsibility for any loss or
damage that may result from camera malfunction.
å
Keep this manual in a safe place.
å
If you use a card reader to copy the images on the memory card to
your PC, the images could be damaged. When transferring the
images taken with the camera to your PC, be sure to use the
supplied USB cable to connect the camera to your PC. Please note
that the manufacturer holds no responsibility for loss or damage of
images on the memory card due to the use of a card reader.
å
The contents and illustrations of this manual are subject to change
without prior notice for upgrading the camera functions.
Ä
Microsoft, Windows and Windows logo are registered trademarks
of Microsoft Corporation incorporated in the United States and/or
other countries.
Ä
Adobe and Reader are either trademarks or registered
trademarks in the United States and/or other countries.
Ä
All brand and product names appearing in this manual are
registered trademarks of their respective companies.
Ä
For Open Source License information, refer to the
"OpenSourceInfo.pdf" in the provided CD-ROM.
001
Danger
Warning
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
å
Do not attempt to modify this camera in any way. To do so may
result in re, injury, electric shock or severe damage to you or your
camera. internal inspection, maintenance and repairs should only
be carried out by your dealer or Samsung Camera Service center.
å
Please do not use this product in close proximity to ammable or
explosive gases, as this could increase the risk of explosion.
å
Should any form of liquid or a foreign object enter the camera, do
not use it. Switch off the camera, and then disconnect the power
source. You must contact your dealer or Samsung Camera Service
center. Do not continue to use the camera as this may cause a re
or electric shock.
å
Do not insert or drop metallic or inammable foreign objects into
the camera through access points e.g. the memory card slot and
battery chamber. This may cause a re or electric shock.
å
Do not operate this camera with wet hands. This could pose a risk
of electric shock.
002
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
å
Do not use the ash in close proximity to people or animals.
Positioning the ash too close to your subject’s eyes may cause
eyesight damage.
å
For safety reasons keep this product and accessories out of reach
of children or animals to prevent accidents e.g.:
- Swallowing battery or small camera accessories. If an accident
should occur, please consult a doctor immediately.
- There is the possibility of injury from the camera’s moving parts.
å
Battery and camera may become hot during prolonged use and it
may result in camera malfunction. Should this be the case, allow
the camera to sit idle for a few minutes to allow it time to cool.
å
Do not leave this camera in places subject to extremely high tem-
peratures, such as a sealed vehicle, direct sunlight or other places
of extremes in temperature. Exposure to extreme
temperatures may adversely affect the camera’s internal
components and could cause a re.
å
When in use, do not cover the camera or Charger. This may cause
heat to build up and distort the camera body or cause a re. Always
use the camera and its accessories in a well-ventilated area.
Caution
Contents
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in a minor or moderate injury.
å
Leaking, overheating, or damaged battery could result in re or injury.
- Use battery with the correct specication for the camera.
- Do not short circuit, heat or dispose of battery in re.
- Do not insert the battery with the polarities reversed.
å
Remove the battery when not planning to use the camera for a
long period of time. Otherwise the battery may leak corrosive
electrolyte and permanently damage the camera’s components.
å
Do not re the ash while it is in contact with hands or objects. Do
not touch the ash after using it continuously. It may cause burns.
å
Do not move the camera while it is switched on, if you are using
the AC adapter. After use, always switch off the camera before
unplugging the cable from the wall socket. Then make sure that
any connector cords or cables to other devices are disconnected
before moving the camera. Failure to do so may damage the cords
or cables and cause a re or electric shock.
å
Take care not to touch the lens or lens cover to avoid taking an
unclear image and possibly causing camera malfunction.
å
Avoid obstructing the lens or the ash when you capture an image.
å
When using this camera in low temperatures, you may experience
the following. These are not camera malfunctions and usually
recover at normal temperature.
- It takes longer to turn on the LCD monitor and the color may differ
from the subject.
- When changing the composition, there may be an after image on
the LCD monitor.
å
Credit cards may be demagnetized if left near case. Avoid leaving
magnetic strip cards near the case.
å
Never connect the 20 pin connector to the USB port of a PC. This
carries a high risk of computer malfunction.
READY
RECORDING
007 System chart
007 Package Contents
007 Sold Separately
008 Identification of features
008 Front & Top
009 Back
010 Bottom
010 5 Function button
011 Self-timer lamp
011 Camera Status Lamp
011 Mode icon
012 Connecting to a Power Source
015 Inserting the memory car
015 Using the
016 Instructions on how to use the memory
018 When using the camera for the first tim
019 LCD monitor indicato
020 How to use the men
021 Starting the recording mod
021 Selecting modes
021 How to use the Smart Auto mod
023 How to use the Program mode
023 How to use the DIS mode
024 Using the Photo Help Guide mode
025 How to use the Scene modes
026 How to use the Movie mod
Anti-scratch Mask
card
d
r
u
e
e
e
e
003
Contents
004
027 Recording the movie clip without sound
027 Pausing while recording a movie clip
(Successive Recording)
028 Things to Watch Out for When Taking
Pictures
029 Using the camera buttons to set the camer
029 POWER butto
029 SHUTTER butto
029 ZOOM butto
031 Info (DISP) / Up butto
031 Macro
033 Focus loc
033 Flash / Left butto
035 Self-timer / Right butto
037 MENU butto
037 OK butto
037 Shootin
038 How to Enable Functions Using
the MENU Button
038 Photo Size / Movie Siz
039 Quality / Frame rat
039 Exposure compensatio
040 IS
040 White balance
041 Face Detectio
043 Face Ton
043 Face Retouc
044 Auto Focus typ
044 Meterin
n
n
n
n
/ Down button
k
n
n
n
n
g
e
e
n
O
n
e
h
e
g
045 Photo Style Selector
046 Image Adjust
047 ACB
047 Drive mode
048 Voice Memo
a
SETUP
048 Voice Recording
049 Recording the movie clip without voice
050 Sound
050 Volume
050 Start up sound
050 Shutter sound
050 Beep sound
051 AF sound
051 Display
051 Language
051 Function Description
052 Start up image
052 Display Brightness
052 Quick View
052 Display Save
053 Settings
053 Formatting a memory
053 Initialization
054 Setting up the Date / Time / Date type
Contents
054 Time Zone
054 File name
055 Imprinting the recording date
055 Auto power off
056 Auto Focus lamp
056 Selecting Video out type
057 Setting the USB
058 Starting play mode
PLAY
058 Playing back a still image
058 Playing back a movie clip
059 Movie clip capture function
059 Playing back a recorded voic
059 Playing back a voice memo
060 LCD monitor Indicator
061 Using the camera buttons to set the
camera
061 Thumbnail / Enlargement
061 Smart Album
063 Info (DISP) / Up button
063 Play & Pause / OK butto
064 Left / Right / Down / MENU butto
064 Delete butto
n
065 Setting up the play back function using
the LCD monitor
button
n
067 Edit
067 Resize
068 Rotating an image
068 Photo Style Selector
069 Image Adjust
071 Starting the Multi Slide Show
071 Start the Multi Slide Show
071 Selecting Images
072 Congure Multi Slide show effects
072 Setting play interval
072 Setting Background Music
073 File Options
073 Deleting images
073 Protecting images
074 Voice memo
075 DPOF
e
077 Copy to Card
078 PictBridge
079 PictBridge : Picture Selectio
079 PictBridge : Print Settin
080 PictBridge : Rese
080 Important note
s
082 Warning indicato
083 Before contacting a service cente
n
085 Specification
s
n
g
t
r
r
005
Contents
SOFTWARE
006
088 Transferring files to your computer
(for Windows)
088 For Windows users
092 Transferring files to your computer (for Mac)
092 For Mac users
094 FAQ
System chart
Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the
optional equipment, contact your nearest Samsung dealer or Samsung service center. Parts and accessories illustrated below may differ from
exact appearance.
Package Contents
Camera
Quick Start Manual
(AD68-04539A)
Sold Separately
SD/SDHC memory card
(see p.17)
Rechargeable battery
(AD43-00194A)
Anti-scratch Mask
(AD63-04939A)
Camera case
AC adapter (AD44-00143A) /
USB cable (AD39-00165A)
AV cable
(AD39-00146A)
Camera strap
(Black : AD63-02604A/
Silver : AD63-02596A)
Battery charger
(AD44-00164A)
Software CD
(User manual included)
(AD46-00296A)
007
Identication of features
Front & Top
008
Shutter button
POWER button
Flash
AF sensor /
Self-timer lamp
Microphone
Speaker
Lens / Lens cover
Identification of features
Back
LCD monitor
Zoom Tele(T) button / Digital zoom
Zoom Wide(W) button / Thumbnail
Camera status lamp
MENU button
5 function button
Play mode button
Fn / Delete button
USB / AV / DC terminal
Strap eyelet
MODE button
009
Identification of features
Bottom
Tripod socket
010
Memory card slot
Battery chamber
5 Function button
Information / Up button
Flash /
Left button
OK / Play & Pause button
Battery holderBattery chamber cover
Macro / Down button
Self-timer /
Right button
Identification of features
Self-timer lamp
Icon Status Description
- For the rst 8 seconds, the lamp blinks at 1 second
Blinking
Blinking
Blinking
Blinking
intervals.
- For the nal 2 seconds, the lamp blinks quickly at
0.25-second intervals.
For the 2 seconds, the lamp blinks quickly at
0.25-second intervals.
A picture will be taken after about 10 seconds and 2
seconds later a second picture will be taken.
After pressing the Shutter button, the image is taken
in accordance with the subject’s movement.
Camera Status Lamp
Status Description
Power on
After taking a picture
When ash battery is charging
When the USB cable is
inserted to a PC
Transmitting Data with a PC
When the USB cable is
inserted into a printer
When the printer is printing
When the AF activates
The lamp turns on and off when the camera
is ready to take a picture
The lamp blinks while saving the image data and
turns off when the camera is ready to take a picture
The lamp blinks
The lamp lights up
(LCD monitor turns off after initializing the device)
The lamp blinks (LCD monitor turns off)
The lamp is off
The lamp blinks
The lamp turns on
(The camera focus on the subject)
The lamp blinks
(The camera doesn’t focus on the subject)
Mode icon
Refer to p.21 for more information about the camera mode setting.
MODE
ICON
MODE Scene Movie
ICON
MODE
ICON
MODE Children Landscape Close up Text
ICON
MODE Sunset Dawn Backlight Fireworks
ICON
MODE
ICON
Smart Auto
Beauty Shot
Beach&Snow
Program DIS
SCENE
Frame Guide
Night Portrait
Photo Help
Guide
011
Connecting to a Power Source
You should use the rechargeable battery BP70A supplied with the
camera. Be sure to charge the battery before using the camera.
Ê
BP70A rechargeable battery Specication
Model BP70A
Type Lithium lon
Capacity 740mAh
Voltage 3.7V
C
harging time
Ê
Number of images and battery life: Using the BP70A
Battery life /
Number of images
Still image
Ä
These gures are measured under Samsung’s standard conditions
Approx. 125 MIN /
Approx. 250 shots
Movie Approx. 110 MIN
Approximately 150 Minutes
Conditions
Using the fully charged battery, Default
settings, Program mode, Shot to shot
interval: 30Sec.
Changing the zoom position between
the Wide and the Tele after every shot.
Using the ash on every second shot.
Using the camera for 5 minutes and
then powering it off for 1 minute.
Using the fully charged battery
640x480 image size
30fps frame rate
and shooting conditions and may vary depending on the user’s
methods.
012
Important information about battery usage.
å
When camera is not in use, turn off the power.
å
Please remove the battery if the camera will not be used
for long periods. Batteries can lose power over time and are
prone to leaking if kept inside the camera.
å
Low temperatures (below 0°C) can affect the performance of
the battery and you may experience reduced battery life.
å
Batteries will usually recover at normal temperatures.
å
During extended use of the camera, the camera body may
become warm. This is perfectly normal.
Ê
Connecting the AC adapter with the USB cable can be used as an
AC cable, and you can charge the rechargeable battery with the
AC cable.
- Using an AC cable
: Connect the AC adapter to the USB
cable. It can be used as a power
cable.
- Using a USB cable
: Remove the AC adapter.
You can download stored images
to your PC (p.89) or supply the
power to your camera through the
USB cable.
Connecting to a Power Source
Important information about USB cable usage.
å
Use a USB cable with the correct specication.
å
If the camera is connected to the PC through a USB hub :
connect the camera directly to the PC.
å
If the camera and other devices are connected to the PC at
the same time : remove other device.
å
Camera can not be detected using the front side USB port
of computer. In this case, use the back side USB port of
computer.
å
If the USB port of the PC doesn’t meet the Power output
standard (5V, 500mA), the battery may not be charged.
Ê
How to charge the rechargeable battery
å
Before inserting any cables or AC adapter, check the directions
and do not insert by force. It may cause breakage of cable or
camera.
å
If the charging LED of the AC Charger does not turn on or blink
after inserting the rechargeable battery, please check whether
the battery is inserted correctly.
å
If you charge the battery with the camera power on, the battery
won’t be fully charged. Turn the camera off while charging the
battery.
Ê
Charging LED of the AC charger
Charging LED
Being Charged Red LED is on
Charging is complete Green LED is on
Charging error Orange LED is off or blinking
å
If you insert the fully discharged battery to charge it, do not turn on
the camera at the same time. The camera may not be turned on
because of the low battery capacity. Charge the battery for more
than 10 minutes before using the camera.
å
Do not use the ash frequently or take a movie clip with the fully
discharged battery charged for a short time. Even if the charger
is inserted, the camera power may be turned off because the
rechargeable battery is discharged again.
013
Connecting to a Power Source
When using the battery, please keep the following
guidelines. Failure to do so may cause the generation of
heat, re, or explosion
If you nd the battery shape distorted in size, try to contact a
å
service center. It may present physical dangers.
Use only the recommended battery charger.
å
Do not place the product close to the re device.
å
Do not insert the product into the microwave oven.
å
Do not place the product inside a car during the summer.
å
Do not place the product in a space with hot temperature and
å
high humidity range.
Do not use the product for long time in the carpet, comforter, or
å
electronic mattress.
Do not leave the product turned on where the air cannot be
å
circulated.
Be careful about the battery slot not to be connected with
å
accessories like necklace, coin, key, watch, and so on.
Use only authentic, manufacturer-recommended, Lithiumion
å
replacement batteries.
Do not try to disassemble or perforate the product by using the
å
sharp pin.
Do not give a hard pressure on the product.
å
Do not let the product fall down from the height, or do not give a
å
shock to the product.
Do not exposure the product to the high temperature over 60
å
(140℉) degree.
Do not exposure the product to the water or humidity.
å
014
Guidelines of disposal
Do not throw away the over used battery.
å
Destruction by re is not allowed for disposal of battery.
å
The disposal instruction may differ depending on the nation or
å
the specic region. Please follow the given method of disposal.
Guideline of recharging the battery
Do not recharge the battery by using the different method other
å
than the user manual indicates. Failure to following the right
instruction may cause the re or the explosion.
℃
Connecting to a Power Source
Ê
Insert the battery as shown
- If the camera does not turn on
after you have inserted battery,
please check whether the
battery (+ / -) direction is right.
- When the battery chamber
cover is opened, do not force
the battery chamber cover,
this may damage it.
Ê
There are 4 indicators for battery condition that are displayed on
the LCD monitor.
Battery
indicator
The battery is
Battery
When using the camera and the battery in a place that is excessively cold or hot,
Ä
fully charged
status
the battery status on the LCD may be different from the actual battery status.
Low battery
capacity
(Prepare to
recharge or use
spare battery)
Low battery
capacity
(Prepare to
recharge or use
spare battery)
Battery empty
(Recharge
or use spare
battery)
Inserting the memory card
Ê
Insert the memory card as shown.
- Turn off the camera’s power
before inserting the memory card.
- Have the front label of the
memory card facing toward the
front of the camera (Lens) and
the card pins toward the back of
the camera (LCD monitor).
- Do not insert the memory card
the wrong way round.
Doing so may damage the
memory card slot.
Using the Anti-scratch Mask
Ê
Insert the anti-scratch mask as shown.
-
Using the anti-scratch mask
can protect the camera from
accidental scratches.
Make sure two points of
holes in the camera body are
connected to the anti-scratch
mask.
015
Instructions on how to use the memory card
å
Be sure to format the memory card (see p.53) if you are using a
newly purchased memory card for the rst time, if it contains data
that the camera cannot recognize, or if it contains images captured
with a different camera.
å
Turn off the camera power whenever the memory card is being
inserted or removed.
å
Repeated use of the memory card will eventually reduce the
memory card’s performance. Should this be the case, you will
need to purchase a new memory card. Wear and tear on the
memory card is not covered by the Samsung warranty.
å
The memory card is an electronic precision device.
Do not bend, drop or subject the memory card to any heavy
impact.
å
Do not store the memory card in an environment with strong
electronic or magnetic elds, e.g. near loud speakers or TV
receivers.
å
Please do not use or store in an environment where there are
extremes in temperature.
å
Do not allow the memory card to become dirty or to come into
contact with any liquid. Should this happen, clean the memory
card with a soft cloth.
å
Please keep the memory card in its case when not in use.
å
During and after periods of extended use, you may notice that the
memory card is warm. This is perfectly normal.
å
Do not use a memory card that is used in another digital camera.
To use the memory card in this camera, format the memory card
using this camera.
å
Do not use a memory card formatted by another digital camera or
memory card reader.
016
å
If the memory card is subjected to any of the following, the
recorded data may become corrupted :
- When the memory card is used incorrectly.
- If the power is switched off or the memory card is removed while
recording, deleting (formatting) or reading.
å
Samsung cannot be held responsible for lost data.
å
It is advisable to copy important data onto other media as back-up
e.g. hard disks, CD etc.
å
If there is insufcient memory available :
A [Memory Full] message will appear and the camera will not
operate. To optimize the amount of memory in the camera, replace
the memory card or delete unnecessary images stored on the
memory card.
Don't remove the memory card when the camera status lamp is
å
blinking as this may cause damage to data on the memory card.
Instructions on how to use the memory card
The camera can use SD/SDHC Memory Cards.
Card pins
Write protect switch
Label
[SD (Secure Digital) memory card]
å
The SD/SDHC memory card has a write protect switch that
prevents image les from being deleted or formatted. By sliding
the switch to the bottom of the SD/SDHC memory card, the data
will be protected. By sliding the switch to the top of the SD/SDHC
memory card, the data protection will be cancelled.
å
Slide the switch to the top of the SD/SDHC memory card before
taking a picture.
When using a 1GB SD memory, the specied shooting capacity will be
as follows. These gures are approximate as image capacities can be
affected by variables such as subject matter and memory card type.
Recorded image
size
Still
*Movie
clip
å
å
å
Super Fine
About 147 About 284 About 403 - -
About 167 About 309 About 441 - -
About 202 About 367 About 528 - -
About 211 About 374 About 537 - -
About 339 About 566 About 792 - -
About 532 About 802 About 1065 - -
About 870 About 1144 About 1437 - -
About 1471 About 1670 About 1872
The zoom button doesn’t function during the movie recording.
The recording times can be changed by the zoom operation.
You can record videos of up to 4GB or 2hours each.
Fine
Normal
- - -
- - -
30 FPS 15 FPS
About 9'54"
About 26'24" About 49'23"
About 18'58"
017
When using the camera for the rst time
Ê
Charge the rechargeable battery fully before using the camera for
the rst time.
Ê
When the camera is turned on for the rst time, a menu will be
displayed on the LCD monitor to set date, time, time zone and
language. This menu will not be displayed again after setting up
the date, time, time zone and language. Set up the date, time,
time zone and language before using this camera.
Ê
Setting up the language
1. Select the [Language] menu by
pressing the Up/Down button and press
the Right button.
2. Select the desired sub menu by
pressing the Up/Down button and press
the OK button.
Language :English
Date & Time :London
Time Zone :08/12/01
Back Set
English
한국어
Français
Deutsch
Español
Italiano
018
Ê
Setting up the date, time and date type
1. Select the [Date&Time] menu by
pressing the Up/Down button and press
the Right button.
2. Select the desired sub menu by
Language :English
Date & Time :10/01/01
Time Zone :London
yyyy mm dd
2010 / 01 / 01 12:00 Off
pressing the Up/Down/Left/Right
button and press the OK button.
Back Set
Left/Right button : Selects world time/year/month/day/hour/
minute/date type.
Up/Down button : Changes the value of each item.
Ê
Setting up the Time Zone
1. Select the [Time Zone] menu by
Time Zone
pressing the Up/Down button and press
the Right button.
2. Press the Left/Right button to select the
desired mode.
Ä
For more information about the World Time, refer to the p.54.
London
[GMT +00:00] 2010/01/01 12:00 PM
Back DST
LCD monitor indicator
Ê
The LCD monitor displays information about the shooting
functions and selections.
[Image & Full Status]
No. Description Icons Page
1 Recording mode
2 Voice Memo
Number of available shots
3
4
remaining
Remaining time 00:00:00 p.17
Memory card icon /
Internal memory icon
00001 p.17
p.21
p.48
No. Description Icons Page
5 Battery
Optical / Digital Zoom bar /
6
Digital Zoom rate
7 Photo Size / Movie Size
Image Quality /
8
9 Metering
10 Flash
11
12
13
14 Date / Time 2010/01/01 12:00 PM p.54
15 Camera shake Warning
16
17 Image adjust
18 Photo Style Selector
19
20
21
-
22
Frame Rate
Self-timer /
Drive mode
Macro
Face Detection · Self-Portrait
· Smile Shot · Blink Detection
Auto Focus Frame
ISO / Face Retouch /
Without voice
White Balance
Face Tone
Exposure compensation
Aperture Value /
Shutter Speed
/
p.15
p.29
p.38
p.39
p.44
p.33
p.36/
47
p.31
p.41
p.28
p.44
p.46
p.45
p.40/
43/49
p.40/
43
p.39
-
019
How to use the menu
1.
Turn on the camera and press the MENU button. A menu for each camera mode appears.
Shooting
Sound
Display
Settings
Exit Change
2. Use the up or down button to navigate through the menus.
Photo Size
Quality
EV
ISO
White Balance
Face Detection
Focus Area
Shooting
Sound
Display
Settings
Exit Change
Photo Size
Quality
EV
ISO
White Balance
Face Detection
Focus Area
Press the
Up or Down
button.
Volume
Start Sound
Shooting
Shutter Sound
Sound
Beep Sound
Display
AF Sound
Settings
Exit Change
Press the
Up or Down
button.
3. Use the left or right button to select a sub menu.
Volume
Start Sound
Shooting
Shutter Sound
Sound
Beep Sound
Display
AF Sound
Settings
Exit Change
Press the
Left or Right
button.
Volume :Medium
Start Sound :Off
Shutter Sound :1
Beep Sound :1
AF Sound :On
Exit Back
Press the
Left or Right
button.
4. Select a submenu and click the OK button to save settings and return to the previous window.
020
Language
Function Description
Shooting
Start Image
Sound
Display Brightness
Display
Quick View
Settings
Power Save
Exit Change
Volume :Medium
Start Sound :Off
Shutter Sound :1
Beep Sound :1
AF Sound :On
Back Set
Off
Low
Medium
High
Starting the recording mode
Selecting modes
You can select the shooting modes by using the MODE button on the
back of your camera.
Ê
How to use the MODE button
1. Press the MODE button and a menu will
be displayed.
2. Select a desired mode by pressing the
Up / Down button and then press the OK
button.
Smart Auto
Program
DIS
Photo Help Guide
Scene
This mode allows you to directly set various features
for shooting.
How to use the Smart Auto mode( )
The camera automatically chooses the appropriate camera settings
based on a detected type of scene. It will be helpful if you are not
familiar with the camera settings for various scenes.
1. Insert the battery (p.15). Insert the
battery taking note of the polarity
(+ / -).
2. Insert the memory card (p.15). As this
camera has a 9.9MB internal memory,
you do not need to insert the memory
card. If the memory card is not inserted,
an image will be stored on the internal memory.
If the memory card is inserted, an image will be stored on the
memory card.
3. Close the battery chamber cover.
4. Press the POWER button to turn on the camera.
5. Select Smart Auto mode by using the MODE button.
6. Point the camera towards the subject and compose the image by
using the LCD monitor.
7. Press the Shutter button to capture an image.
021
Starting the recording mode
If the camera does not recognize a proper scene mode, the
å
default settings will be used.
Even if there is a face detected, the camera may not select a
å
portrait mode depending on the subject’s position or lighting.
The camera may not select the correct scene depending on
å
shooting environments, such as camera shake, lighting, and
distance to the subject.
The [Night] mode recognizes scenes only when the ash is set
å
to off. The camera operates the [Tripod] mode after checking the
shooting condition on the tripod for a certain time.
Despite using a tripod, the camera may not select a tripod mode
å
depending on the subject’s movement.
022
Ê
Each scene is recognized in the following conditions;
[Landscape] ( ) : When shooting outdoor scenes
[White] (
[Night] (
[Night Portrait] (
[Backlight] ( ) :
[Backlight Portrait]
[Portrait] (
[Macro] (
[Macro Text] (
[Tripod] (
[Action] (
[Macro Portrait]
[Blue Sky] ( ) : When shooting blue sky
[Sunset Sky] ( ) :
[Macro Color] ( ) :
[Natural Green]
) : When shooting a white background
) : When shooting the nighttime scenes
) :
When shooting people in a dark outdoor place
When shooting a backlit scenery without a portrait
( ) : When shooting a backlit portrait
) : When shooting a portrait
) : When shooting close-ups
) : When shooting texts in a close focus
) : When shooting a subject that doesn’t move
for a certain time after the camera is mounted
on the tripod (available only when the camera
recognizes it as nighttime)
) : When shooting a subject making frequent
movements
( ) :
( ) :
When shooting close-up portrait shot
When shooting sunset
When shooting close-up shot for the subject
with various colors
When shooting nature such as forest and leaves
Starting the recording mode
How to use the Program mode ( )
Selecting the automatic mode will congure the camera with
optimal settings. You can still manually congure all functions
except the aperture value and shutter speed.
1. Select the Program mode by using the
MODE button. (p.21)
2. Press the MENU button to congure
advanced functions.
How to use the DIS mode ( )
Digital Image Stabilization (DIS) mode.
This mode will reduce the effect of camera shake and help you get
a well-exposed image in dim conditions.
1. Select the DIS mode by using the
MODE button. (p.21)
2. Point the camera towards the subject
and compose the image by using the
LCD monitor.
3. Press the Shutter button to capture an
image.
Ê
Things to watch out for using the DIS mode
1. The digital zoom will not operate in the DIS mode.
2. If the lighting condition is brighter than uorescent lighting
conditions, the DIS will not activate.
3. If the lighting condition is darker than uorescent lighting
conditions, camera shake warning indicator ( \ ) will display.
For best results only take pictures in situations where the
camera shake warning indicator ( \ ) is not displayed.
4. If the subject is moving, the captured image may be blurred.
5. As the DIS uses the camera's digital signal processor, it may
take a little longer for the camera to process and save the
images.
023
Starting the recording mode
Using the Photo Help Guide mode ( )
Helps the user learn the correct picture taking method and includes
solutions for potential problems that may occur. This also enables
the user to practice the best way to take the pictures.
Photo Help Guide
Features to use when the image is out of focus
Half-press the shutter button to focus
To focus on a subject 80 cm away or more
To focus on a subject less than 80 cm away
To focus on people’s faces
Back Change
Pressing the
Up button
Press the shutter button
to practice using this
feature.
Guide list
024
Photo Help Guide
Photo Help Guide
Features to use when the image is out of focus
Features to reduce camera shake
Features to use in low light conditions
Features to use when adjusting brightness
Features to use when adjusting colors
Change
Guide list
Pressing the
Left/Right button
Pressing the OK button
[Function that can be used when focusing is difcult]
Available functions of the photo help guide
Functions that can be used when focusing is difcult
å
Functions that can be used when the image is blurred
å
Functions that can be used when lming in the dark
å
Functions that can be used when adjusting the picture brightness
å
Functions that can be used when adjusting the picture color
å
Pressing the
Left/Right button
Photo Help Guide
To focus on your subject, halfpress the shutter button:
- Green frame: subject is in focus
- Red frame: subject is out of focus
1/2
Pressing the OK button
Back Practice
Pressing the
Up/Down button
Photo Help Guide
When the subject is in focus,
press the shutter button
completely to capture the image
Pressing the OK buttonPressing the shutter button
or video. If the subject is out of
focus, try half-pressing the shutter
button again.
Back Practice
2/2
Starting the recording mode
How to use the Scene modes ( )
Use the menu to easily congure optimal settings for a variety of
shooting situations.
1. Select the Scene mode by using the
MODE button. (p.21)
2. Press the Right button, then press the
Up/Down button to select the desired
mode.
3. Point the camera towards the subject
and compose the image by using the
LCD monitor.
4. Press the shutter button to capture an
image.
Smart Auto
Program
DIS
Photo Help Guide
Scene
This mode allows you to choose an appropriate scene
for a variety of situations.
Beauty Shot
Frame Guide
Night
Portrait
Children
Landscape
Close Up
The scene modes are listed below.
[Beauty Shot] (
) : Take a photo of portraits by setting
options to clear facial imperfections.
[Frame Guide] (
) : Use this mode when you want someone
else to take a picture for you from the
angle you choose.
[Night] (
) : Use this for shooting still images at night
or in other dark conditions.
[Portrait] (
[Children] (
) : To take a picture of a person.
) : To take a picture of fast moving
objects, for example, children.
[Landscape] (
[Close Up] (
) : To take pictures of distant scenery.
) : Close-up shooting for small objects such
as plants and insects.
[Text] ( ) : Use this mode to shoot a document.
[Sunset] ( ) : For taking pictures of sunsets.
[Dawn] ( ) : Daybreak scenes.
[Backlight] ( ) :
Portrait without shadows caused by backlight.
[Fireworks] ( ) : Firework scenes.
[Beach&Snow] ( ) : For ocean, lake, beach and snowscape
scenes.
025
Starting the recording mode
Ê
How to use the [Frame Guide] mode
Set [Frame Guide] mode when you want someone else to take a
picture for you from the angle you choose.
1. Take a picture from the angle you
choose.
- A guide appears around the sides
of the picture.
2. Then another person can take the
picture by aligning the edge of the
picture to be taken with the guide
framing the sides of the window.
Guide
Frame Guide: Shutter
Cancel Frame: OK
Cancel Frame: OK
How to use the Movie mode ( )
A movie clip can be recorded for as long as the available recording
time of the memory capacity allows. (Max.2 hours)
1. Select the Movie mode by using the
MODE button. (p.21)
2. Point the camera towards the subject
and compose the image by using the
LCD monitor.
3. Press the shutter button once and
movie clips are recorded for as long as
the available recording time (Max.2 hours) allows. Movie clips
will still be recorded if the shutter button is released. If you wish
to stop recording, press the shutter button again.
Ä Movie clip size and type are listed below.
- Movie clip size : 640x480, 320x240 (Selectable)
- Movie clip le type : AVI (MJPEG)
- Frame Rate : 30 FPS, 15 FPS (Selectable)
026
Starting the recording mode
Recording the movie clip without sound
You can record the movie clip without sound.
Steps from 1-3 are the same as those for Movie mode.
4. Press the MENU button.
5. Press the Up / Down button to select
the [Movie] menu and press the Right
button.
6. Select the [Voice] menu by pressing
the Up / Down button and press the OK
button.
7. Select the [Off] menu by pressing the Left / Right button.
8. Press the OK button. You can record a movie without sound.
Ä
See p.49 for further details.
Pausing while recording a movie clip (Successive Recording)
This camera allows you to temporarily stop during unwanted
scenes, while recording a movie clip. Using this function, you can
record your favorite scenes into a movie clip without having to
create multiple movie clips.
Ê
Using Successive Recording
Steps from 1-2 are the same as those for Movie mode.
3. Press the shutter button and movie
clips are recorded for as long as the
available recording time. (Max.2 hours)
Movie clips will still be recorded if the
shutter button is released.
4. Press the OK button to pause
recording.
5. Press the OK button again to resume the recording.
6. If you wish to stop recording, press the shutter button again.
Stop Pause
027
Things to Watch Out for When Taking Pictures
å
Pressing the shutter button down half way.
Lightly press the shutter button to conrm focus and ash battery
charge. Press the shutter button all way down to take the picture.
[Lightly press the shutter button]
å
The available memory capacity may vary depending on shooting
conditions and camera settings.
å
When the Flash Off, Slow synchro mode or DIS mode is selected
in a low lighting condition, the camera shake warning indicator
( \ ) may appear on the LCD monitor. In this case, use a tripod,
support the camera on a solid surface or change to ash shot
mode.
å
Shooting against the light
å
Avoid obstructing the lens or the ash when you capture an image.
028
: It is best to take pictures with the sun in the
background. Taking pictures against the
sun may make the picture come out dark.
To take a picture against the light, please
use the [Backlight] in scene shooting mode
(p.25), ll-in ash (p.33), spot metering
(p.44), exposure compensation (p.39) or
ACB (p.47) function.
[Press the shutter button]
å
Compose the image by using the LCD monitor.
å
Under certain conditions the auto focus system may not perform
as expected.
- When photographing a subject that has little contrast.
- If the subject is highly reective or shiny.
- If the subject is moving at high speed.
- When there is strong reected light, or when the background is
very bright.
- When the subject matter has only horizontal lines or the subject
is very narrow (such as a stick or agpole).
- When the surroundings are dark.
Using the camera buttons to set the camera
ZOOM button
The recording mode function can be set up by using the camera buttons.
POWER button
Used for turning the camera’s power
on / off. If there is no operation during
the specied time, the camera's power
will be turned off automatically to save
battery life. Refer to p.55 for more
information about the auto power off
function.
SHUTTER button
Used for taking an image or recording a movie clip in the Recording
mode.
å
In Movie mode
Pressing the shutter button down
fully starts the process for recording
a movie clip. Press the shutter
button once and the movie clip is
recorded for as long as the available
recording time on the memory
allows. If you wish to stop recording,
press the shutter button again.
å
In Still image mode
Pressing the shutter button down halfway activates the autofocus
and checks the condition of the ash. Pressing the shutter button
down fully takes and stores the image. If you select voice memo
recording, the recording will start after the camera has nished
storing the image data.
If the menu is not displayed, this button
works as the OPTICAL ZOOM or
DIGITAL ZOOM button.
This camera has a 5X optical zoom and
a 3X digital zoom function. Using both
will offer a total zoom ratio of 15X.
Ê
TELE Zoom
Optical zoom TELE : Pressing the ZOOM T button. This will zoom
Digital zoom TELE : When the maximum (5X) optical zoom
[WIDE zoom]
into the subject i.e. the subject will appear
nearer.
is selected, pressing the ZOOM T button
activates the digital zoom software.
Releasing ZOOM T button stops the digital
zooming at the required setting. Once the
maximum digital zoom (3X) is achieved,
pressing the ZOOM T button will have no
effect.
Pressing
the ZOOM
T button
[TELE zoom] [Digital zoom 3.0X]
Pressing
the ZOOM
T button
029
Loading...
