Model:SCR-3232
CONTENTS
CD-ROM
service
manual
n Specifications
n Cautions at Service
n External Part Name
n Disassembly Method
n Exploded Views
n Device Part List
n Packing Options
n Operational Position Diagram
n CD-ROM Block Diagram
n Troubleshooting
n Circuit Diagram
n
Main Components Block Diagram & Pin
Descriptions
n Electrical Parts List
32X
v The design and part of this product is subject to change without prior notice for performance improvement.
Electronics
Code No: BG68-20312A
©
Samsung Electronics Co., Ltd.
JULY, 1998
Printed in Korea
1
n Specifications
1. General Specifications
- Drive type : Computer built-in
- Power consumption : DC + 5V, 1A
DC + 12V, 1.5A
- Dimensions : 149mm(W)X41.5mm(L)X202.6mm(H)
- Net Weight : 950g
2. Electrical Features
- Interface : ATAPI BUS(IDE)
-
Data transfer rate 4800KByte/Sec MAX
(2400KByte/Sec AVG.)
- ACCESS TIME: 1/3 stroke : Below 120msec
full stroke : Below 190msec
- Buffer Capacity : 512Kbyte
- Error ratio : Mode 1: Below 10
-12
Mode 2: Below 10
-9
- Frequency response : 20Hz~20KHz
- Signal to noise ratio : 75dB(1KHz, Lineout)
- Distortion factor : 0.15% Less than(1KHz)
- Channel separation : 65dB(1KHz, Lineout)
- Signal output level :
LINEOUT : 0.7 Vrms(±20%)
H/PHONE:0.6 Vrms(±20%)
- Used laser : Semiconductor laser
2.
Earthing cautions at handling Pick-up
- Because the laser diode in optical Pick-up is subject to get
out of order due to the potential difference occurring by
electricity load charged in clothes or bodies, observe the
following earthing items at handling.
1) Body earthing(hand) : Be sure to wear a wrist strip with
one side earthed.(Impedance : Below 104).
It removes the electricity formed in body.
2) Work table earthing : Put the earthed conductive
plate(Impedance : Below 104) such as copper plate on
work table.
3) Cautions for clothes : Do not have any clothes touch with
Pick-up because the electricity formed in clothes is
destroyed easily.
n Cautions at Service
1. General Items
1) Be careful not to have your eyes or a part of body touch
with laser diode at repair because this product uses laser
diode.
2) Do not disassemble Pick-up at repair. If the laser diode is
bad, replace the entire Pick-up.
3) Keep away from TV or other electrical units at repair to
prevent influence from surrounding units.
4) If you replace the parts during repair, be sure to unplug
the power cable before replacement.
5) If you insert a disc into the drive, be sure to load it
correctly.
6) Because this unit can't be used by itself, surely mount it
on PC (486 DMA support) and check the operations in
use of private device driver floppy diskette. Refer to
Instruction manual.
7) This unit has many parts with features related to safety
and especially, for essential parts, the importance is
indicated on circuit diagram and part list.
Be certain to use the parts with same specifications at
replacing these parts.
1
n Specifications
1. General Specifications
- Drive type : Computer built-in
- Power consumption : DC + 5V, 1A
DC + 12V, 1.5A
- Dimensions : 149mm(W)X41.5mm(L)X202.6mm(H)
- Net Weight : 950g
2. Electrical Features
- Interface : ATAPI BUS(IDE)
-
Data transfer rate 4800KByte/Sec MAX
(2400KByte/Sec AVG.)
- ACCESS TIME: 1/3 stroke : Below 120msec
full stroke : Below 190msec
- Buffer Capacity : 512Kbyte
- Error ratio : Mode 1: Below 10
-12
Mode 2: Below 10
-9
- Frequency response : 20Hz~20KHz
- Signal to noise ratio : 75dB(1KHz, Lineout)
- Distortion factor : 0.15% Less than(1KHz)
- Channel separation : 65dB(1KHz, Lineout)
- Signal output level :
LINEOUT : 0.7 Vrms(±20%)
H/PHONE:0.6 Vrms(±20%)
- Used laser : Semiconductor laser
2.
Earthing cautions at handling Pick-up
- Because the laser diode in optical Pick-up is subject to get
out of order due to the potential difference occurring by
electricity load charged in clothes or bodies, observe the
following earthing items at handling.
1) Body earthing(hand) : Be sure to wear a wrist strip with
one side earthed.(Impedance : Below 104).
It removes the electricity formed in body.
2) Work table earthing : Put the earthed conductive
plate(Impedance : Below 104) such as copper plate on
work table.
3) Cautions for clothes : Do not have any clothes touch with
Pick-up because the electricity formed in clothes is
destroyed easily.
n Cautions at Service
1. General Items
1) Be careful not to have your eyes or a part of body touch
with laser diode at repair because this product uses laser
diode.
2) Do not disassemble Pick-up at repair. If the laser diode is
bad, replace the entire Pick-up.
3) Keep away from TV or other electrical units at repair to
prevent influence from surrounding units.
4) If you replace the parts during repair, be sure to unplug
the power cable before replacement.
5) If you insert a disc into the drive, be sure to load it
correctly.
6) Because this unit can't be used by itself, surely mount it
on PC (486 DMA support) and check the operations in
use of private device driver floppy diskette. Refer to
Instruction manual.
7) This unit has many parts with features related to safety
and especially, for essential parts, the importance is
indicated on circuit diagram and part list.
Be certain to use the parts with same specifications at
replacing these parts.
n External Part Name
1.Front
2.Rear
32X
Earphone jack
Digital output terminal
(Optional)
Sound output terminal Interface terminal
Master/Slave select pin Power terminal
Up/Down Volume
LED Stop/Open button
Play/Search button
Disc tray
2
EmergencyHOLE
nDisassembly Method
1. COVER BOTTOM ASSY disassembly
Remove 4 screws(23) on the bottom of COVER BOTTOM ASSY, lift the back up and disassemble COVER BOTTOM ASSY as
Figure Page 4.
2. COVER-TOP disassembly
After disassembling 4 hooks of FRONT ASSY(2) from COVER TOP(1), pull COVER TOP(1) forward and disassemble it.
3. ASSY DECK+PCB MAIN disassembly
Disassemble FPC PICK-UP(24)and FPC MOTOR(25) connected between assy deck and PCB main, then disassemble between deck
and PCB main.
3
n Operational Position Diagram
789
n Operational Position Diagram
10
7
n Troubleshooting
+5V, +12V of CN700 is normally inputted after
connection of power cable?
X201, X301, X401 oscillate?
Check power short and power supply cable
connection state
After checking IC201 75pin, IC301 11pin,
IC401 88pin for power input, if normal, replace
X201, X301, X401.
IC308 2pin changes from 0V to 5V?
IC302 6pin changes from 0V to 5V?
IC308 3pin : 0V→5V check
Y
Y
N
N
N
N
N
Y
N
N
N
N
N
N
Disc insert
Replace IC308
Check R314, R330, R305 soldering
Check power input of corresponding
IC and replace it
N
Tray in/out? Refer to ‘Tray open/close’
Y
Y
Y
Laser diode on? Refer to ‘No laser diode on’
Y
Focus up/down? Refer to ‘No focus lock’
Y
Focus lock?
Y
Disc rotates? Refer to ‘No disc rotation’
Y
Pause state
v Pause state : LED off as disc rotation state and continue 1 track jump
Y
Spindle lock?
Y
Pick up moves in at power on after moving
out?
Refer to ‘No sled operation’
IC302 3pin changes
from 5V to 0V when
power supplied?
Y
Check and
replace IC302
power
Y
Y
N
Is 3.3V supplied at IC202 4PIN?
IC202 surround circuits
R515, R514 check.
Is 3.3V sanctioned at IC201
DSPVCC terminal?
0V→5V changes at checking IC302 6pin
waveform while opening IC301 64pin and
IC401 9pin in turn
13
Equipments required at repair
1. Oscilloscope(100MHz and more) 2. PROBE for Oscilloscope(10:1)
3. PC(486 and more)
Verify the circuit of power unit and the first status(Plug-in the power cable without I/F cable and verify.)
TE signal at 1 track jump
N
8
No tray open/close
FPC is normally inserted in CN502? Retest after inserting FPC in CN502 properly
Start
N
Check SW301 pattern and soldering
v FPC : Flexible Printed Circuit
Replace SW301
After FPC short check, no error, check SW soldering of deck
FPC of CN502 is normally inserted?
Retest after inserting FPC in CN502 normally
After FPC short check, no error, check SW soldering of deck
FPC of CN502 is normally inserted?
Retest after inserting FPC in CN502 normally
N
N
N
IC301 49pin is 0V at pressing SW301?
Y
IC301 35pin is 0V with tray in?
CN502 16pin
becomes 0V?
CN502 14pin
becomes 0V?
Check R528,R511,R512 soldering
N
N
N
N
IC301 36pin is 0V with tray open?
Check R528,R511,R512 soldering.
Replace IC501Replace IC501
Y
Y
Y
Y
IC501 11pin change from 2.1V to +2V at pressing SW301?
N
N N
N
N
IC501 12pin changes from 2.1V to 2.5V at pressing SW301?
IC501 13pin changes from +6V to +4V, and 14pin
from +6V to +8V, at pressing SW301?
IC501 13pin and 14pin chage each from
6V, 6V, to 8V, 4V at pressing SW301?
Output Voltage of IC501 13Pin is impressed into
SLED
Motor
(-) and IC501 14Pin(+)?
Check pattern and soldering
between CN501 and IC301
Replace loading Motor.
Y
Y Y
YY
Y
14
OPEN tary repair
CLOSE operation repair
9
No laser on
Refer to ‘No tray open/close’
IC101 10pin changes from 0V to +3.3V? Refer to ‘Check power source and initial state’
N
N
IC101 9pin changes from 4.2V to 3.8V?
Check IC101 power input and replace.
Y
Open and close tray(Disc insettion)
Y
CN501 3pin changes from 2V to 2.5V?
Check D101, L101, Q102, R102, C103 soldering
Y
CN501 2pin changes from 0V to 0.7V? Check Pick-up FPC connection state
N
N
N
Y
Replace pick-up
Y
15
10
No SLED operation
Move pick-up out.
Insert 2 FPC and power cord.
SLED runs normally.
Y
Pick-up moves in?
The below waveform is outputted in
IC201 47Pin?
N
Refer to 'Check power source and initial state'
N
Voltage of IC501 21pin in 12V?
Check R511, R512
soldering.
After checking IC501
soldering, no error, replace IC
N
Y
N
N
16
The below signal is inputted
in SLED MOTOR - terminal?
Y
The below signal is inputted
in SLED Motor + terminal?
Y
Replace SLED Motor.
Y
No focus lock
Laser diode is on?
VNOTE : NEVER CHECK 'LASER DIODE
ON' STATE DIRECTLY WITH YOUR EYES
AND RECOGNIZE IT BY SIGNAL
INDICATED IN 'NO LASER DIODE ON' OF
THIS MANUAL.
Y
Insert disc
N
Refer to 'No laser diode on'
Focus up/down?
Y
The below waveform is outputted in IC201
42Pin?
Y
NN
Refer to 'Check power source
and initial state'
FE signals is outputted in IC101 16Pin?
Y
The below waveform is outputted in IC101
Check IC201 power input and soldering.
15Pin?
Y
N
N
Check IC101 power input, soldering and
R116 soldering.
Check IC101 power input and soldering.
Replace IC101
Y
The below waveform is inputted in CN501
The below waveform is inputted in CN501
17Pin?
Y
Y
14Pin?
Y
N
N
Check IC501 power input, soldering and
R506, R507, R505, R201, C216 soldering.
Y
X201 oscillates?
Y
Check power source and initial state.
Y
N
Pick-up connecting FPC is connected?
Y
Replace Pick-up.
17 18
Replace FPC.
11
No spindle motor rotation
Focus lock? Refer to 'No focus lock'
N
N
N
N
N
N
The side waveform is inputted in
IC502 2Pin?
Check IC201 power input and 49Pin soldering.
Check R207, C221 soldering and pattern
Replace IC201
Check R518 soldering
The below waveform is
inputted in IC502 21Pin?
CN502 8Pin is 3V?
Insert disc.
Y
Y
Y
Y
Y
Y
Y
Spindle motor kick signal
Check R519 soldering
CN502 1Pin is 2V?
Replace spindle Motor
Spindle Motor FPC is connected?
Replace IC502
Y
19
1220
No audio output
Focus lock? Refer to 'No focus lock'
N
Insert audio disc.
Y
Y
Spindle Motor rotates? Refer to 'No Spindle Motor rotation'
N
Y
IC301 50Pin is 0V at pressing SW302?
Solder SW302
N
Y
Audio signal is outputted in
IC201 77, 80Pin?
Check IC201 power and soldering.
N
Replace IC201
N
Y
Audio signal is outputted in
IC701 1, 7Pin?
Check IC701 power input and
peripheral integer VR soldering.
N
Replace IC701
N
Y
Audio signal is outputted in JK 701 Check L702, L701 soldering
N
21
When installing is impossible
Does INSTALL message appear? Normal
N
Connect power and I/F cable between
PC and CD-ROM
Y
Do the digital signal of IC301 and IC306
communication pattern change from 0V to
5V?
Check the soldering of IC402, IC301
and pattern open/short
N
N
Y
Do the digital signals of IC301 and IC401
communication pattern change from 0V to
5V?
Check the soldering of IC401, IC301
and pattern open/short
N
Y
Y
Is there soldering between the pattern of
IC401 and CN701
Check the soldering of Damping
Resister and IC, I/F Wafer
N
Resoldering
Y
Is IC301 64PIN 5V when main power
turns on?
Check main power-end and initial state
N
Does X301 oscillate?
Check soldering of C303, C304
Y
Y
Is IC201 95PIN 5V?
N
Y
6
n Packing Options
NO
1
2
3
4
5
6
7
8
9
CODE NO.
BG69-50015A
BG69-20003A
BE69-30304A
BG46-30001J
BG39-40010A
BE69-30304A
BG68-10010A
BG68-10011A
BG39-30002A
PARTS
BOX SYSTEM
CUSHION-SET
PE-BAG
INSTALL-DISK
CBF-HARNESS
PE-BAG
MANUAL-USERS
MANUAL-USERS
CABLE-IF
SET
SPECIFICATION
SW-E MANILA 400g
EPE WHITE
T0.1X270X260 ANTI
SHARED W/ SCR-3230
4P, 500mm
T0.1X270X260 ANTI
CD-ROM(Korean)
CD-ROM(Eng/Ger)
40 Pin I/F Cable
SCR-3232
COUNT
1
2
1
1
1
1
1
1
1
1
REMARK
32X
2636
NO CODE NO PARTS SPEC LOCATION NO Q’TY
1 0903-000006 IC-MICRO CONTROLLER KS88C4400 IC301 1
2 1102-001024 PROM AT27C512R IC306 1
3 1201-001231 RF-AMP TA2119FN IC101 1
4 BG14-10001H IC SIGNAL PROCESSOR TC9450F IC201 1
5 0904-001237 IC-CONTROLLER TC9466FA IC401 1
6 1003-001068 IC MOTOR DRIVER BA6849FP IC502 1
7 1003-001130 IC 4-CH DRIVER KA3012D IC501 1
8 1203-001005 IC-VOLTAGE DETECTOR XC61AC3502M IC308 1
9 1203-001473 IC-VOLTAGE REGULATOR PQ20WZ51 IC202 1
10 0801-002353 IC-CMOS LOGIC 74VHCT00 IC302 1
11 0803-000605 IC-TTL LOGIC 74LS374 IC305 1
12 1201-000003 IC-AMPLIFIER 3414A IC701 1
IC
R-CHIP-1
NO CODE NO PARTS SPEC LOCATION NO Q’TY
1 2007-000070 R-CHIP 0 ohm R108,109,124,208,275,307,314,327,501,817,C 12
206,L101
2 2007-000036 R-CHIP 2 ohm R520,521,522,523 4
3 2007-000882 R-CHIP 4.7 ohm R211 1
4 2007-001442 R-CHIP 10 ohm R102 1
5 2007-000071 R-CHIP 22 ohm R402,403,406,408,409,416,417,418,419, 21
420,421,422,423,424,425,426,427,428,
429,430,431
2007-000115 R-CHIP 82 ohm R404,405,407,410,411,412,413,414 8
6 2007-000074 R-CHIP 100 ohm R309,310 2
7 2007-000116 R-CHIP 120 ohm R308 1
8 2007-000075 R-CHIP 220 ohm R101,103,518,519 4
9 2007-000763 R-CHIP 330 ohm R135, 303 2
10 2007-000077 R-CHIP 470 ohm R330 1
11 2007-000119 R-CHIP 560 ohm R614 1
12 2007-000078 R-CHIP 1 Kohm R117,119,123,201,202,326,703,705,706,708, 12
715,720
13 2007-000122 R-CHIP 1.2 Kohm R436 1
14 2007-000080 R-CHIP 2 Kohm R615 1
15 2007-000124 R-CHIP 2.2 Kohm R532,533,733,734 4
16 2007-000662 R-CHIP 2.2 Kohm NR100 1
272737
R-CHIP-2
NO CODE NO PARTS SPEC LOCATION NO Q’TY
17 R-CHIP 2.4 Kohm R118 1
18 2007-000082 R-CHIP 3.3 Kohm R203,204,207 3
19 2007-000084 R-CHIP 4.7 Kohm R305,312,313,317,319,320,321,323,324,325 10
20 2007-000962 R-CHIP 5.1 Kohm R528 1
21 2007-000090 R-CHIP 10 Kohm R121,272,280,304,315,316,331,332,432,433, 17
438,439,440,442,443,717,718
22 2007-000091 R-CHIP 12 Kohm R121,272 2
23 2007-000458 R-CHIP 18 Kohm R276 1
24 2007-000094 R-CHIP 22 Kohm R277,278,704,709 4
25 2007-000616 R-CHIP 24 Kohm R271 1
26 2007-000655 R-CHIP 27 Kohm R112,113 2
27 2007-000134 R-CHIP 33 Kohm R110,111,273,274,529 5
28 2007-000939 R-CHIP 47 Kohm R114,116,435,441 4
29 2007-000100 R-CHIP 68 Kohm R506,507,515,517,701,714 6
30 2007-000131 R-CHIP 91 Kohm R702,707 2
31 2007-000102 R-CHIP 100 Kohm R333 1
32 2007-000060 R-CHIP 100 Kohm-F R505,508,509,510,512,514,516 8
33 2007-000106 R-CHIP 220 Kohm R530,531 2
34 2007-000107 R-CHIP 470 Kohm R334 1
35 2007-000065 R-CHIP 2.2 Kohm R210 1
C-CHIP
NO CODE NO PARTS SPEC LOCATION NO Q’TY
1 C-CERAMIC 3 pf C124 1
2 2203-001567 C-CERAMIC 10 pf C207,208 2
3 2203-001103 C-CERAMIC 6.8 nf C509 1
4 2203-000477 C-CERAMIC 1 nf C312 1
5 2203-000715 C-CERAMIC 3.3 nf C216,219 2
6 2203-000888 C-CERAMIC 4.7 nf C209 1
7 2203-000257 C-CERAMIC 10 nf C111,202,211,274,521,609 6
8 2203-000372 C-CERAMIC 15 nf C273 1
9 2203-001634 C-CERAMIC 33 nf C203,215 2
10 2203-000062 C-CERAMIC 47 nf C217,218 2
11 2203-001556 C-CERAMIC 100 nf C100,104,113,213,221,222,275,301,306,311,307 36
308,313,403,404,405,406,407,515,507,508,513
514,515,516,517,519,520,601,602,603,608
702,703,704,705
28282838
C-CHIP (continued)
NO CODE NO PARTS SPEC LOCATION NO Q’TY
12 2203-001402 C-CERAMIC 220 nf C112 1
13 2203-000919 C-CERAMIC 470 nf C510,511,512 3
14 2203-001083 C-CERAMIC 5 pf C303,304 2
15 2203-001618 C-CERAMIC 27 pf C401,402 2
16 2203-001636 C-CERAMIC 33 pf C110 1
17 2203-001697 C-CERAMIC 82 pf C701,706 2
18 2203-001656 C-CERAMIC 470 pf C262 1
19 2203-000477 C-CERAMIC 1 uf C106,114,115,116 4
20 2402-001009 C-CERAMIC 100uf/6.3V C276,607,610,713,714 5
21 2402-000112 C-CERAMIC 10uf/16V C709,710,712,715 4
22 2402-000136 C-CERAMIC 22uf/16V C278,518 2
23 2402-000008 C-CERAMIC 47uf/16V C103,105,107,109,212,214,302,604,711 9
OTHER
NO CODE NO PARTS SPEC LOCATION NO Q’TY
1 3708-001107 CONNECTOR-FPC CNN-16PIN CN502 1
2 3708-001254 CONNECTOR-FPC CNN-17PIN CN501 1
3 3711-003262 CONNECTOR-HEADER:56P CN701 CN701 1
4 3710-000001 CONNECTOR-SOCKET:2P 1R,2.54mm 1
5 3301-001082 CORE-FERRITE BEAD CIB32P600NEM B601,602,L701,702 4
6 0407-000116 DIODE-ARRAY DAP202K D101 1
7 3722-000107 EARPHONE JACK HSJ1A15 JK701 1
8 0601-000005 LED-CHIP SML-010MTT86 D301 1
9 BG99-90001B PCB MAIN 1
10 2802-001068 RESONATOR 20MHz X301 1
11 2802-001047 RESONATOR 33.86MHz X201 1
12 2802-001047 RESONATOR 25.4MHz X401 1
13 3704-000249 SOCKET-IC:32P PLCC, 1.27mm 1
14 3404-001030 SWITCH-TACT JPT1236HA SW301,302 2
15 0501-000338 TR-SMALL Q101 1
16 0501-000251 TR-SMALL BC807:PNP Q102 1
17 2101-001004 VR-ROTARY 20K-VR VR701 1
18 2802-001047 THERMISTER NTH5G1M42B104 T301 1
n CD-ROM Block diagram
SPINDLE CONTTROL
TRACKING CONTROL
FOUSING CONTROL
B.L SPINDLE MOTOR
BRUSH SLED MOTOR
OPTICAL PICKUP
DRIVING MECHANISM
SLED CONTROL
LASER CONTROL
RF SIGNAL
EJECT MECHANISM
COMPACT DISC
DISC TURN TABLE
CLAMPING PULLEY
DISC ACCESS INDICATOR
EJECT BUTTON
HEADPHONE OUTPUT
PLAY BUTTON
SLED SERVO ERROR
SPINDLE SERVO ERROR
TRACKING SERVO ERROR
FOCUSING SERVO ERROR
RF
SIGNAL
OSC
33.86MHz
CERAMIC OSC
25.4MHz
CERAMIC OSC
EFM DEMODULATOR
CIRC DECODER
TC9450F
RF AMP. & APC
TA2119FN
SPINDLE DRIVER
BA6849FP
ACTURATOR
DRIVER
SERVO SWITCHER
SUB CODE QCH
20MHz
CERAMIC
OSC
SPINDLE KICK/BRAKE
SLED DRIVER
LOAD/EJECT
DRIVER
KA3012D
CPU
KS88C4400
SUB CODE
DATA
DATA
CONTROL
CD-ROM DECODER
LAYERED ERROR
CORRECTION
SUB CODE DECODER
DATA CONTROL
TC9466FA
PROM
AT27C512R
CONTROLLER SECTION
MAIN PCB
DRIVE SECTION
AUDIO SECTION
DIGITAL
OUT
(OPTION)
AUDIO
OUTPUT
MASTER/
SLAVE
HOST
CONTROLLER
5/12V POWER
4PIN CNPIN CONNECTOR4PIN CN
HEADPHONE
AMPLIFIER
3414A
11 12
1424
n Main Components Block Diagram and Pin Descriptions
• KS88C4400 MICROCONTROLLER
P0.2/A1080P0.3/A1179P0.4/A1278P0.5/A1377P0.6/A1476P0.7/A15
75
VDD1(int.)
74
P1.0/AD073P1.1/AD172P1.2/AD271P1.3/AD370P1.4/AD469P1.5/AD568P1.6/AD667P1.7/AD7
66EA65
1
P0.1/A9
2
P0.0/A8
3
P5.7
4
P5.6
5
P5.5
6
P5.4
7
P5.3
8
P5.2
9
P5.1
10
P5.0
11
V
DD2(ext.)
12
P2.7/TB
13
P2.6/TA
14
PM
15
DR
16
P2.3/DM
17
P2.2/DW
18
P2.1/DS
19
P2.0/AS
20
PxD
21
TxD
22
PWM1
23
PWM0
24
P3.0/TCCK/INT0
252627282930313233343536373839
40
P3.1/TDCK/INT1
P3.2/TCG/INT2
P3.3/TDG/INT3
P3.4
P3.5
P3.6/CAP
P3.7/WAIT
VSS2(ext.)
P4.0/INT4
P4.1/INT5
P4.2/INT6
P4.3/INT7
P4.4/INT8
P4.5/INT9
P4.6/INT10
P4.7/INT11
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
RESET
NC
NC
V
SS1(int.)
X
OUT
XIN
P6.0
P6.1
P6.2
P6.3
P6.4
P6.5
P6.6
P6.7
P7.7/ADC7
P7.6/ADC6
P7.5/ADC5
P7.4/ADC4
P7.3/ADC3
AV
SS
P7.2/ADC2
P7.1/ADC1
AV
REF
P7.0/ADC0
KS88C4400
80-QFP
(TOP VIEW)
EXTERNAL ADDRESS/DATA BUS
P0.0-P0.7
(A8-A15)
P1.0-P1.7
(AD0-AD7) P2.0-P2.7
PORT A PORT AD PORT C
(AS, DS, DW, DM, DR, PM)
SAM8 BUS
RESET
EA
P2.6
P2.7
X
IN
XOUT
PORT2
MAIN
OSC
TA
TB
TCCK
TDCK
TCG
TDG
TIMERS
A and B
TIMERS
C and D
SERIAL
PORT
RxD
TxD
AV
SS
AVREF
A/D
CONVERTER
ADC0/P7.0-
ADC7/P7.7
SAM8 BUS
V
DD1(INTERNAL)
VSS1(INTERNAL)
VDD2(EXTERNAL)
VSS2(EXTERNAL)
PWM/
CAPTURE
MODULE
PWM0 PWM1
CAPTURE
(P3.6)
P6.0-P6.7
1040-BYTE
REGISTER FILE
16-KB ROM
SAM8 CPU
PORT I/O & INTERRUPT
CONTROL
PORT 3
PORT 4
PORT 5
PORT 6
P5.4-P5.7
P5.0-P5.3
P4.0-P4.7
P3.0-P3.7
4 4 4 4
4
4
25
MICOM PIN DESCRIPTIONS
PIN NAME FUNCTION PIN NAME FUNCTION
1 A9 ADDRESS LINE 41 TEST_P1 PRODUCTION TEST PIN 0
2 A8 ADDRESS LINE 42 AVref CVCC
3 /XCE MICOM INTERFACE CHIP ENABLE 43 TEST_P2 PRODUCTION TEST PIN 1
4 /XCM MICOM INTERFACE FIRST WORD ENABLE 44 TEST_P3 PRODUCTION TEST PIN2
5 /XRD MICOM INTERFACE READ SIGNAL 45 Avss GROUND
6 /XWR MICOM INTERFACE WRITE SIGNAL 46 NC NO CONNECTION
7 BUS3 MICOM INTERFACE DATA INPUT/OUTPUT SIGNAL 47 FVO NOT USE
8 BUS2 MICOM INTERFACE DATA INPUT/OUTPUT SIGNAL 48 UBL UNBALLACE DISC CHECK
9 BUS1 MICOM INTERFACE DATA INPUT/OUTPUT SIGNAL 49 /EJECT EJECT KEY INPUT
10 BUS0 MICOM INTERFACE DATA INPUT/OUTPUT SIGNAL 50 /PLAY PLAY KEY INPUT
11 VDD2 VCC 51 NC NO CONNECTION
12 NC NO CONNECTION 52 NC NO CONNECTION
13 NC NO CONNECTION CVCC 53 NC NO CONNECTION
14 /CE FLASH CHIP ENABLE 54 NC NO CONNECTION
15 /URO TC 9466 IC READ 55 XRST DSP RESET
16 /UCS TC 9466 IC CHIP SELECT 56 LED_BUSY BUSY LED
17 /UWR TC 9466 IC WRITE 57 EMPHA EMPHASIS CONTROL
18 NC NO CONNECTION 58 NC NO CONNECTION
19 CLK TC 9466 IC INTERRUPT 59 XIN RESONATOR CLOCK IN
20 NC NO CONNECTION 60 XOUT RESONATOR CLOCK OUT
21 NC NO CONNECTION 61 Vss1 GROUND
22 NC NO CONNECTION 62 NC NO CONNECTION
23 NC NO CONNECTION 63 NC NO CONNECTION
24 FLAGA TRACK ZERO CROSS CHECK 64 RESET MICOM RESET
25 FLAGC FOCUS OK CHECK 65 VCC VCC
26 GFS NOT USE 66 A7 ADDRESS LINE AND DATA PORT
27 SPM_DIR SPINDLE KICK/BRAKE 67 A6 ADDRESS LINE AND DATA PORT
28 NC NO CONNECTION 68 A5 ADDRESS LINE AND DATA PORT
29 DRV_MUTE KA3012 MUTE 69 A4 ADDRESS LINE AND DATA PORT
30 FG SPINDLE FG INPUT 70 A3 ADDRESS LINE AND DATA PORT
31 SPM_DIR SPM-DIR 71 A2 ADDRESS LINE AND DATA PORT
32 VSS GROUND 72 A1 ADDRESS LINE AND DATA PORT
33 NC NO CONNECTION 73 A0 ADDRESS LINE AND DATA PORT
34 D_INT ROM DECODER INTERRUPT 74 VDD VCC
35 CLOSE TRAY CLOSE SIGNAL 75 A15 ADDRESS LINE
36 OPEN TRAY OPEN SIGNAL 76 A14 ADDRESS LINE
37 NC NO CONNECTION 77 A13 ADDRESS LINE
38 MON SPINDLE MOTOR ON/OFF 78 A12 ADDRESS LINE
39 NC NO CONNECTION 79 A11 ADDRESS LINE
40 SCOR SUB CODE SYNC INTERRUPT 80 A10 ADDRESS LINE
1626
• TC9466F QFP PIN DIAGRAM
TOP VIEW
SBSY
SFSY
SBDI
CLCK
SBOK
C2PI
LRCK
DAI
BCKI
VSS
XI
XO
VDD
MD0
MD1
MD2
MD3
MD4
MD5
MD6
MD7
VSS
MA0
MA1
MA2
ASCK
ADA
DASP
VSS
HCS3
HCS1
HA2
HA0
PDIAG
HA1
VSS
IOCS16
INTRQ
HDAK
CSEL
VSS
IORDY
HRD
HWR
HDRQ
VSS
HD15
HD0
HD14
HD1
ACK
ALRCK
VSS
VDD
TEST3
TEST2
TB14
TB13
TB12
TB11
TB10
TB9
VPB
TB8
TB7
TB6
TB5
TB4
TB3
TB2
TBST1
TBST0
VSS
VDD
VDD
MA3
MA4
MA5
MRD
MWR
MCE
MINT
CKSTP
RST
VDD
HD7
HD8
HD6
HD9
VSS
HD5
HD10
HD4
HD11
VSS
HD3
HD12
HD2
HD13
VSS
75 74 73 72 71 70 696867 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51
123 45678910111213141516171819202122232425
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
4
4
32
16
8
16
16
16
8
16
32
8
8
8
6
3
8
13417
3
32
2
16
2
5
8
16 3 2 9
Buffer
DRAM 1Mbit
CD-Mecha
BCKI,LRCK
DAI,C2PI
SBDI,SBOK
SBSY,SFSY
CLCK
ACK
ABCK,ALRCK
ADA
Audio
ASYC
CD-IF
EDC
Da
C2P
HEDda
HSYC
BSYC
SUB-IF
SBDa
SBQDa
BD[15:0]
BWU,BWL
BOE
RAS,CAS
BA[8:0]
Buffer Address
ECC
M-FIFO
(8B)
H-FIFO
(32B)
DRIVER
H Interrupt
M Interrupt
(H-IF)
(M-IF)
Address
Clock
MICOM
CSEL
PDIAG,
DASP
IORDY
HDRQ
HDAK
IOCS16
HD[15:0]
HRD,HWR
HC33,HCS1
HA[2:0]
INTRQ
CKSTP
RST
GND
VDD
TEST[3:0]
TB[14:2]
MD[7:0]
MA[5:0]
MINT
MWR,MRD
MCE
DAC
XI XO
• TC9466F FUNCTIONAL BLOCK DIAGRAM
27
NO SYMBOL DESCRIPTIONS NO SYMBOL DESCRIPTIONS
1 MA3 MICOM ADDRESS INPUT 51 VDD POWER SOURCE TERMINAL
2 MA4 MICOM ADDRESS INPUT 52 VDD POWER SOURCE TERMINAL
3 MA5 MICOM ADDRESS INPUT 53 VSS GROUND TERMINAL
4 MRD MICOM READ SIGNAL INPUT 54 TEST0 TEST TERMINAL
5 MWR MICOM WRITE SIGNAL INPUT 55 TEST1 TEST TERMINAL
6 MCE CHIP ENABLE SIGNAL INPUT 56 TB2 TEST TERMINAL
7 KINT INTERRUPT REQUEST OUTPUT 57 TB3 TEST TERMINAL
8 CKSTP CLOCK PARTIAL STOP INPUT 58 TB4 TEST TERMINAL
9 RST RESET TERMINAL 59 TB5 TEST TERMINAL
10 VDD POWER SOURCE TERMINAL 60 TB6 TEST TERMINAL
11 HD7 HOST DATA INPUT 61 TB7 TEST TERMINAL
12 HD8 HOST DATA INPUT 62 TB8 TEST TERMINAL
13 HD6 HOST DATA INPUT 63 VPB GROUND TERMINAL (DRAM AREA)
14 HD9 HOST DATA INPUT 64 TB9 TEST TERMINAL
15 VSS GROUND TERMINAL 65 TB10 TEST TERMINAL
16 HD5 HOST DATA INPUT 66 TB11 TEST TERMINAL
17 HD10 HOST DATA INPUT 67 TB12 TEST TERMINAL
18 HD4 HOST DATA INPUT 68 TB13 TEST TERMINAL
19 HD11 HOST DATA INPUT 69 TB14 TEST TERMINAL
20 VSS GROUND TERMINAL 70 TEST2 TEST TERMINAL
21 HD3 HOST DATA INPUT 71 TEST3 TEST TERMINAL
22 HD12 HOST DATA INPUT 72 VDD POWER SOURCE TERMINAL
23 HD2 HOST DATA INPUT 73 VSS GROUND TERMINAL
24 HD13 HOST DATA INPUT 74 ALRCK LRCK OUTPUT FOR DAC ON FAST PLAY
25 VSS GROUND TERMINAL 75 ACK BASE CLOCK INPUT ON FAST PLAY
26 HD1 HOST DATA INPUT 76 SBSY SUBCODE BLOCK SYNC OUTPUT
27 HD14 HOST DATA INPUT 77 SFSY SUBCODE DATA SYNC FRAME INPUT
28 HD0 HOST DATA INPUT 78 SBDI SUBCODE DATA INPUT
29 HD15 HOST DATA INPUT 79 CLCK SUBCODE DATA CLOCK OUTPUT
30 VSS GROUND TERMINAL 80 SBOK SUBCODE Q DATA FLAG INPUT
31 HDRQ DATA REQUEST TERMINAL 81 C2PI DATA CORRECTION FLAG INPUT
32 HWR HOST WRITE SIGNAL INPUT 82 LRCK CHANNEL CLOCK INPUT
33 HRD HOST READ SIGNAL INPUT 83 DAI DATA SIGNAL INPUT
34 IORDY IO TRANSFER READY OUTPUT 84 BCKI BIT CLOCK INPUT
35 VSS GROUND TERMINAL 85 VSS GROUND TERMINAL
36 CSEL CABLE SELECT INPUT 86 XI MASTER CLOCK I/O
37 HDAK DATA ACKNOWLEDGE INPUT 87 XO MASTER CLOCK I/O
38 INTRQ INTERRUPT SIGNAL OUTPUT 88 VDD POWER SOURCE TERMINAL
39 IOCS16 DATA BIT WIDE SELECT OUTPUT 89 MD0 MICOM DATA I/O
40 VSS GROUND TERMINAL 90 MD1 MICOM DATA I/O
41 HA1 HOST ADDRESS 1 INPUT 91 MD2 MICOM DATA I/O
42 PDIAG POST DIAGNOSTIC I/O 92 MD3 MICOM DATA I/O
43 HA0 HOST ADDRESS 0 INPUT 93 MD4 MICOM DATA I/O
44 HA2 HOST ADDRESS 2 INPUT 94 MD5 MICOM DATA I/O
45 HCS1 CHIP SELECT 1 INPUT 95 MD6 MICOM DATA I/O
46 HCS3 CHIP SELECT 3 INPUT 96 MD7 MICOM DATA I/O
47 VSS GROUND TERMINAL 97 VSS GROUND TERMINAL
48 DASP DRIVE ACTIVE OUTPUT 98 MA0 MICOM ADDRESS INPUT
49 ADA DATA OUTPUT FOR DAC ON FAST PLAY 99 MA1 MICOM ADDRESS INPUT
50 ABCK BCK OUTPUT FOR DAC ON FAST PLAY 100 MA2 MICOM ADDRESS INPUT
PIN DESCRIPTIONS
18
• TC9450F (DSP CHIP)
+
–
+
–
+
–
+
–
+
–
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
1
2
AUDIO
OUT
VSS3
BCK
AOUT
DOUT
MBOV
IPF
SBOK
CLOCK
VDD3
VSS5
DATA
SFSY
SBSY
SPCK
SPDA
COFS
MONIT
VDD5
TESTIO0
AWRC
PVDD3
PDOS
PDO
TMAX
TMAXS
XVDD3
XO
XI
XVSS3
TEST2
TEST1
TEST0
TESIN
TESTIO1
FGIN
DACT
CKSE
DMOUT
IO3
IO2
IO1
IO0
VSS3
VDD3
FLGD
FLGC
FLGB
FLGA
SEL
VDD3
DIGITAL
OUT
SUBCODE
OUT
16K RAM
ROM RAM
DIGITAL
EQUALIZER
SERVO
CONTROL
DECODER
ERROR
CORECTION
MICOM
INTERFACE
CLOCK
GENERATOR
CAV
ADRESS
STATUS
LPF
DA COUNTER
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
9998979695949392919089888786858483828180797877
76
100
30292827263132333435363738394041424344454647484950
+
–
DA PWMCONVERTOR
DATA
SLICER
CLV
ACTIVE
WIDERANGE
PLL
TMAX
VCO
DVSS3
RO
DVDD3
DVR
LO
DVSS3
TEST3
TEST4
BUS0
BUS1
BUS2
BUS3
VDD5
VSS5
XRD
XWR
XCM
XCE
TEST5
RST
HSO
UHSO
SHSO
EMPH
LRCK
VSS3
DMO
FVO
FMO
TEBC
RFGC
VREF
TRO
FOO
TEZI
TEI
SBAD
FEI
RFRP
RFZI
RFCT
AVDD3
RFI
SLCO
AVSS3
VCOF
VCOREF
PVREF
LPFO
LPFN
28
29
PIN PIN DESCRIPTIONS PIN PIN DESCRIPTIONS
NO NAME NO NAME
1 VSS3 DIGITAL GND TERMINAL 51 VDD3 DIGITAL +3.3V POWER SOURCE TERMINAL
2 BCK BIT CLOCK OUTPUT TERMINAL (1.411MHz) 52 SEL AUTO POWER CONTROL ON/OFF SIGNAL OUTPUT TERMINAL
3 AOUT AUDIO DATA OUTPUT TERMINAL 53 FLGA INTERNAL SIGNAL CHECKING FLAG TERMINAL
4 DOUT DIGITAL DATA OUTPUT TERMINAL 54 FLGB INTERNAL SIGNAL CHECKING FLAG TERMINAL
5 MBOV BUFFER MEMORY OVER SIGNAL OUTPUT TERMINAL 55 FLGC INTERNAL SIGNAL CHECKING FLAG TERMINAL
6 IPF COMPLEMENTARY BLOCK OUTPUT TERMINAL 56 FLGD INTERNAL SIGNAL CHECKING FLAG TERMINAL
7 SBOK CRCC RESULT OUTPUT TERMINAL FOR SUBCODE Q DATA 57 VDD3 DIGITAL +3.3V POWER TERMINAL
8 CLCK SUBCODE P-W DATA READ CLOCK TERMINAL 58 VSS3 DIGITAL GND
9 VDD3 DIGITAL +3.3V POWER TERMINAL 59 I00 GENERAL I/O TERMINAL
10 VSS5 DIGITAL GND TERMINAL 60 I01 GENERAL I/O TERMINAL
11 DATA SUBCODE P-W OUTPUT TERMINAL 61 I02 GENERAL I/O TERMINAL
12 SFSY PLAY DEVICE FRAME SYNC SIGNAL OUTPUT TERMINAL 62 I03 GENERAL I/O TERMINAL
13 SBSY SUBCODE BLOCKING OUTPUT TERMINAL 63 /DMOUT 100~1 OUTPUT MODE SELECT TERMINAL
14 SPCK DSP INTERNAL STATUS CHECKING CLOCK TERMINAL 64 /CKSE OSCILLATING DEVICE SELECT TERMINAL
15 SPDA DSP STATUS OUTPUT TERMINAL 65 /DACT DIGITAL/ANALOG CONVERT TEST TERMINAL
16 COFS ERROR CORRECTION CLOCK (7.35 MHz)OUTPUT TERMINAL 66 FGIN DIGITAL/ANALOG CONVERT TEST TERMINAL
17 MONIT DSP INTERNAL STATUS OUTPUT TERMINAL 67 TESI01 TEST INPUT TERMINAL
18 VDD5 DIGITAL +5V TERMINAL 68 TESIN TEST INPUT TERMINAL
19 TESTOO TEST TERMINAL 69 TEST0 TEST TERMINAL
20 AWRC VCO OUTPUT TERMINAL FOR ACTIVE-WIDE RANGE PLL 70 TEST1 TEST TERMINAL
21 PVDD3 +3.3V POWER TERMINAL FOR PLL-EXCLUSIVELY 71 TEST2 TEST TERMINAL
22 PDOS POSITION GAP SIGNAL OUTPUT TERMINAL OF EFM & PLCK SIGNALS 72 XVSS3 MICOM CLOCK DRIVING CIRCUIT GND TERMINAL
23 PDO POSITION GAP SIGNAL OUTPUT TERMINAL OF EFM & PLCK SIGNALS 73 XI MICOM CLOCK DRIVING CIRCUIT INPUT TERMINAL
24 TMAXS TMAX DETECTION RESULT OUTPUT TERMINAL 74 XO MICOM CLOCK DRIVING CIRCUIT OUTPUT TERMINAL
25 TMAX TMAX DETECTION RESULT OUTPUT TERMINAL 75 XVDD3 MICOM CLOCK DRIVING CIRCUIT +3.3V POWER TERMINAL
26 LPFN AMP REVERSE INPUT TERMINAL FOR LOW-PASS FILTER 76 DVSS3 D/A CONVERT R CHANNEL ANALOG GND TERMINAL
27 LPFO AMP OUTPUT TERMINAL FOR LOW-PASS FILTER 77 RO R CHANNEL AUDIO OUTPUT TERMINAL
28 PVREF VREF(+1.65V) FOR PLL ONLY 78 DVDD3 DIGITAL/ANALOG CONVERT +3.3V POWER TERMINAL
29 VCOREF VCO CENTER FREQUENCY BASE LEVEL VOLTAGE TERMINAL 79 DVR DIGITAL/ANALOG CONVERT BASE VOLTAGE TERMINAL
30 VCOF VCO FILTER TERMINAL 80 LO L CHANNEL AUDIO OUTPUT TERMINAL
31 AVSS3 ANALOG GNDTERMINAL 81 DVSS3 D/A CONVERT L CHANNEL ANALOG GND TERMINAL
32 SLCO DATA SLICE GENERATING DIGITAL/ANALOG CONVERT OUTPUT TERMINAL 82 TEST3 TEST TERMINAL
33 RFI RF SIGNAL INPUT TERMINAL 83 TEST4 TEST TERMINAL
34 AVDD3 ANALOG +3.3V POWER TERMINAL 84 BUS0 DATA INPUT TERMINAL FOR MICOM INTERFACE
35 RFCT RERP SIGNAL INTERMEDIATE VOLAGE 85 BUS1 DATA INPUT TERMINAL FOR MICOM INTERFACE
36 RFZI INPUT TERMINAL FOR RERO ZERO CROSS 86 BUS2 DATA INPUT TERMINAL FOR MICOM INTERFACE
37 RFRP RF RIPPLE SIGNAL INPUT TERMINAL 87 BUS3 DATA INPUT TERMINAL FOR MICOM INTERFACE
38 FEI FOCUS ERRORSIGNAL INPUT TERMINAL 88 VDD5 DIGITAL 5V POWER SOURCE TERMINAL
39 SBAD SUBBEAM ADDITION SIGNAL INPUT 89 VSS5 DIGITAL GNDTERMINAL
40 TEI TRACKING ERROR SIGNAL INPUT 90 /XRD READ SIGNAL FOR MICOM INTERFACE
41 TEZI TRACKING ERROR ZERO CROSS INPUT 91 /XWR WRITE SIGNAL FOR MICOM INTERFACE
42 FDO FOCUS EQ. OUTPUT TERMINAL 92 /XCM FIRST WORD RECOGNIZE SIGNAL FOR MICOM INTERFACE
43 TRO TRACKING EQ. OUTPUT TERMINAL 93 /XCE MICOM INTERFACE CHIP ENABLE TERMINAL
44 VREF ANALOG-BASED POWER(+1.65V) 94 TEST5 TEST MODE SELECT TERMINAL
45 RFGC RF AMPLITUDE CONTROL SIGNAL OUTPUT TERMINAL 95 /RST RESET INPUT TERMINAL
46 TEBC TRACKING BALANCE CONTROL SIGNAL OUTPUT TERMINAL 96 /HSO PLAY SPEED MODE FLAG OUTPUT TERMINAL
47 FMO FEED EQ. OUTPUT TERMINAL 97 /UHSO PLAY SPEED MODE FLAG OUTPUT TERMINAL
48 FVO SPEED ERROR OR FEED EQ OUTPUT TERMINAL 98 /SHSO PLAY SPEED MODE FLAG OUTPUT TERMINAL
49 DMO DISK MOTOR EQ OUTPUT TERMINAL 99 EMPH EMPHASIS FLAG OUTPUT TERMINAL OF SUBCODE QDATA
50 VSS3 DIGITAL GND TERMINAL 100 LRCK CHANNEL CLOCK (44.1KHz) OUTPUT TERMINAL
PIN DESCRIPTIONS
2030
FEO
16
FEN
17
VDDIN
18
VREF
19
RFRP
20
BTC
21
RFCT
22
PKC
23
RERPIN
24
RFGO
25
GVSW
26
AGCIN
27
RFO
28
GND
29
RFN2
30
SBAD
15
TEO
14
TEN
13
VRO
12
TEB
11
SEL
10
LDO
9
MDI
8
TNI
7
TPI
6
FPI
5
FNI
4
GMAD
3
RFGC
2
VCC
1
BOTTOM
PEAK
AGC-AMP
20k
11k
11k
100k
100k
100k
20k
20k
50µA
20k 20k
36k
150k
60k 60k
20k100k
150k
15k
10k
20µA 36p
50k
15k
10k
30k
16.7k
20k
48k
2.9k
83k
SW1
LDC
SW2
SW3
1k
1.4k
2.26k
I(1/4)
I(3/4)
I(3/4)
I(1/4)
10k
238k
238k
15k
15p
24k
3 STATE
DET
10p
30k
10k
10p
60k
40p
40p
12k
12k
I - I
I - I
• TA2119FN
31
PIN NO PIN NAME FUNCTION
1 VCC POWER SOURCE/VOLTAGE TERMINAL
2 RFGC RF FREQUENCY CONTROL SIGNAL INPUT TERMINAL
3 GMAD OPEN-LOOP GAIN CONTROL TERMINAL OF AGC AMP
4 FNI MAIN BEAM AMP INPUT TERMINAL
5 FPI MAIN BEAM AMP INPUT TERMINAL
6 TPI SUB BEAM AMP INPUT TERMINAL
7 TNI SUB BEAM AMP INPUT TERMINAL
8 MDI MONITOR PHOTO-DIODE AMP INPUT TERMINAL
9 LDO LASER DIODE AMP OUTPUT TERMINAL
10 SEL INTERNAL GAIN AND SIGNAL SWITCH TERMINAL
11 TEB TRACKING BALANCE CONTROL SIGNAL INPUT TERMINAL
12 VRO STANDARD VOLTAGE RATING TERMINAL(VRO,2.1V)
13 TEN TRACKING ERROR SIGNAL GENERATING AMP REVERSE INPUT TERMINAL
14 TEO TRACKING ERROR SIGNAL GENERATING AMP OUTPUT TERMINAL
15 SBAD SUB BEAM ADDITIONAL OUTPUT TERMINAL
16 FEO FOCUS ERROR SIGNAL GENERATING AMP OUTPUT TERMINAL
17 FEN FOCUS ERROR SIGNAL GENERATING AMP REVERSE INPUT TERMINAL
18 VDD 3.3V POWER SOURCE VOLTAGE TERMINAL
19 VREF VOLTAGE RATING (VREF,1.6V) OUTPUT TERMINAL
20 RFRP SIGNAL GENERATING AMP OUTPUT TERMINAL FOR TRACK COUNTER
21 BTC RECT SIGNAL GENERATING BOTTOM DETECTOR CONTROL TERMINAL
22 RFCT RFRP SIGNAL CENTER LEVEL OUTPUT TERMINAL
23 PKC RFCT SIGNAL GENERATING PEAK DETECTOR CONTROL TERMINAL
24 RFRPIN SIGNAL GENERATING AMP INPUT TERMINAL FOR TRACK COUNTER
25 RFGO RF SIGNAL AMPLITUDE ADJUSTING AMP INPUT TERMINAL
26 GVSW AGC,TE, FE AMP GAIN SWITCH TERMINAL
27 AGCIN RF SIGNAL AMPLITUDE ADJUSTING AMP INPUT TERMINAL
28 RFO RF SIGNAL GENERATING AMP OUTPUT TERMINAL
29 GND GND TERMINAL
30 RFN2 RF SIGNAL GENERATING AMP INPUT TERMINAL
PIN DESCRIPTIONS
22
PIN DESCRIPTIONS
PIN DESCRIPTIONS
28 27 26 25 24 23 22 21 20 19 18 17 16
1 3 4 5 6 7 21 20 19 18 17 16 15
GND
LEVEL-SHIFT
LEVEL-SHIFT
10K
TSD
PV
CC1 PVCC2
PVCC1/2
PV
CC1/2
PV
CC1/2
PV
CC2/2 PVCC2/2
PV
CC2/2 PVCC2/2
SV
CC
GND
MUTE
PV
CC1/2
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
LEVEL-SHIFT
LEVEL-SHIFT
15
2
A3
A2
A1
GND
H1+
H1-
H2+
H2-
H3+
H3-
2
4
6
8
9
10
11
12
13
14
Hall 3
Hall 2
Hall 1
HALL AMP
+
+
+
+
+
FIN
Hall Bias
SHORT BRAKE
VH
CNF
SB
FR
ECR
EC
PS
FG
V
CC
VCC
VM2
VM1
V
M
RNF
RNF
28
27
26
25
24
23
22
21
20
18
17
15
V
CC
TORQUE
SENSE AMP
PS
V
CC
CURRENT
SENSE AMP
GAIN
CONTROL
TSD
DRIVER
TL
SERVO
SIGNAL
R
D
Q
Q
CK
+
+
PIN NO. PIN NAME
FUNCTION
1 N.C. N.C
2 A3 Output3 for motor
3 N.C. N.C
4 A2 Output3 for motor
5 N.C. N.C
6 N.C. N.C
7 A1 Output3 for motor
8 GND GND
9 H1+ Hall input Amp1.positive input
10 H1- Hall input Amp1.negative input
11 H2+ Hall input Amp2.positive input
12 H2- Hall input Amp2.negative input
13 H3+ Hall input Amp3.positive input
14 H3- Hall input Amp3.negative input
15 VH Hall Bias
16 N.C. N.C
17 CNF Capacitor connection pin for phase compensation
18 SB Short Brake terminal
19 N.C. N.C
20 FR Rotation detect terminal
21 ECR Torque control standsrd voltage input terminal
22 EC Torque control voltage input terminal
23 PS START/STOP switch
24 FG FG signal output terminal
25 VCC Power supply for signal division
26 VM2 Power supply2 for driver
27 VM1 Power supply1 for driver
28 RNF Power supply for driver division
FIN FIN GND
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Symbol
CH1-O
CH1-O
AMP1-O
AMP1-I(-)
AMP1-I(+)
BIAS
SVCC
GND
MUTE
AMP2-1(+)
AMP2-1(-)
AMP2-O
CH2-O
CH2-O
GND
CH3-O
CH3-O
AMP3-O
AMP3-I(-)
AMP3-I(+)
PVCC2
PVCC1
AMP4-I(+)
AMP4-I(-)
AMP4-O
CH4-O
CH4-O
GND
I/O
O
O
O
I
I
I
-
I
I
I
O
O
O
O
O
O
I
I
-
-
I
I
O
O
O
-
Description
Drive CH1 Output(-)
Drive CH1 Output(+)
OP-AMP CH1 Output
OP-AMP CH1 Input(-)
OP-AMP CH1 Input(+)
Bias Input
Supply Voltage(Signal)
Ground
Mute
OP-AMP CH2 Input(+)
OP-AMP CH2 Input(-)
OP-AMP CH2 Output
Drive CH2 Output(+)
Drive CH2 Output(-)
Ground
Drive CH3 Output(-)
Drive CH3 Output(+)
OP-AMP CH3 Output
OP-AMP CH3 Input(-)
OP-AMP CH3 Input(+)
Supply Voltage(CH2&CH3)
Supply Voltage(CH1&CH4)
OP-AMP CH4 Input(+)
OP-AMP CH4 Input(-)
OP-AMP CH4 Output
Drive CH4 Output(+)
Drive CH4 Output(-)
Ground
• KA3012D
• BA6849FP
32
2333
• DAP 202K
1 2
3
• 2SB 1132 (KTA 1664)
-TOP VIEW-
123
A12 NC A14
3 1 31
15 17 19
A7 A15 VCC A13
O2 NC O4
O1 GND O3 O5
4 2 32 30
14 16 18 20
5
6
7
8
9
10
11
12
13
29
A6
A5
A4
A3
A2
A1
A0
NC
O0
A8
A9
A11
NC
OE/VPP
A10
CE
O7
O6
28
27
26
25
24
23
22
21
PLCC Top View
Pin Name Function
A0-A15 Addresses
O0-O7 Outputs
CE Chip Enable
OE/Vpp Output Enable/Vpp
NC No Connect
• AT27PC512
• TC4S66F
OE, CE AND
PROGRAM LOGIC
OUTPUT
BUFFERS
DATA OUTPUTS
O0-O7
Y-GATING
CELL MATRIX
IDENTIFICATION
Y DECODER
X DECODER
A0-A15
ADDRESS
INPUTS
CE
OE/VPP
GND
Vcc
Mode/Pin CE OE/V
PP
Ai Outputs
Read V
IL
V
IL
Ai D
OUT
Output Disable V
IL
V
IH
X
(1)
High Z
Standby V
IH
X
(1)
X High Z
Pid Program
(2)
V
IL
V
PP
Ai D
IN
GM Inhibit V
IH
V
PP
X
(1)
High Z
Duct Identification
(4)
V
IL
V
IL
A9=V
H
(3)
IdentificationCode
A0=VIHor V
IL
A1-A15=V
IL
IN/OUT
1 5
4
OUT/IN
2
V
SS
V
CONT
DD
3
V
IN/OUT
DD
OUT/IN
V
CONTROL
SS
2434
• GD74VHCT00
• XC61AC3502MR
• MC74LS374DW
20
Vcc19O
7
18
D
7
17
D
6
16
O
6
15
D
5
14
O
5
13
D
4
12
O
4
11
CP
1 2 3 4 5 6 7 8 9 10
OE O
0 D0 D1 O1 D2 O2 D3 O3 GND
1A1B1
2
1Y 3
2A2B4
5
2Y 5
3A3B9
10
3Y 8
4A4B12
13
4Y 11
11A
21B
31Y
42A
52B
62Y
7GND
14
13
12
11
10
9
8
Vcc
4B
4A
4Y
3B
3A
3Y
08
INPUTS OUTPUT
nA
L
L
H
H
nB
L
H
L
H
nY
H
H
H
L
H=HIGH voltage level
L=Low voltage level
VOUT
VIN
VSS
Vref
1
V
OUT
3
V
IN
2
V
SS
-TOP VIEW-
• KSC 1623 (2SC 2412K)
B E
C
• NJM3414M
A+INPUT 3
A OUTPUT 1
A-INPUT 2
4
6
8
7
5
B+INPUT
B OUTPUT
B-INPUT
GND
B B
V1(5V)
25
35
• PQ20VZ51
20VZ51
1 2 334
5
1
2
3
4
5
Spesific IC
• Pin configuration
Pin No Pin Name
• DC input(VIN)
‚ ON/OFF control
terminal(VC)
ƒ DC output(VO)
„ Output voltage minute
adjustment
terminal(VADJ)
… GND
Circuit Diagram
Loading...
