ANDROID TABLET

User Manual

Please read this manual before operating your

device and keep it for future reference.

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Galaxy Tab, including but not limited to, accessories, parts, or software relating there to (the “Galaxy Tab System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.

Open Source Software

Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered under the open source licenses, please visit:

http://opensource.samsung.com

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING

GEN_SM-P600_UM_Eng_MIE_TN_100813_F4

THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.

Modification of Software

SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS, OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.

USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR CARRIER MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS.

Samsung Electronics America (SEA), Inc

Address:

85 Challenger Road Ridgefield Park,

New Jersey 07660

Toll Free Telephone:

Internet Address:

1-800-SAMSUNG

http://www.samsung.com

2013 Samsung Electronics America, Inc. All rights reserved. Do you have questions about your Samsung Mobile Device? For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:

www.samsung.com/us/support

Nuance®, VSuite™, T9® Text Input, XT9® Smart Input, and the Nuance logo are trademarks or registered trademarks of Nuance Communications, Inc., or its affiliates in the United States and/or other countries.

The Bluetooth

word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are

registered trademarks and are wholly owned by the Bluetooth SIG.

microSD

, microSDHCTM, and the microSD logo are Trademarks of the SD Card Association.

Google, the Google logo, Android, the Android logo, Gmail, Google Hangouts, Google Maps, Google Play, Google Play Books, Google Play Magazines, Google Play Movies & TV, Google Play Music, Picasa, and YouTube and other marks are trademarks of Google Inc.

Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc. Peel and the Peel logo are marks owned by Peel Technologies, Inc. and may be registered. Polaris Office and the Polaris Office logo are marks owned by Infraware and may be trademarks or registered trademarks.

Table of Contents

Section 1: Getting Started .......................... 7

Understanding This User Manual . . . . . . . . . . . 7

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Turning Your Device On and Off . . . . . . . . . . . 10

Setting Up Your Device . . . . . . . . . . . . . . . . . . 10

Task Manager . . . . . . . . . . . . . . . . . . . . . . . . 12

Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . 13

Galaxy Tab Accessories . . . . . . . . . . . . . . . . . 14

Securing Your Device . . . . . . . . . . . . . . . . . . . 14

Holding the Device . . . . . . . . . . . . . . . . . . . . . 16

Adjusting the Volume . . . . . . . . . . . . . . . . . . . 16

Switching to Silent Mode . . . . . . . . . . . . . . . . 17

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 17

Section 2: Understanding Your Device .... 18

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Front and Sides . . . . . . . . . . . . . . . . . . . . . . . 19

Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . 21

Navigating Your Device . . . . . . . . . . . . . . . . . 24

Using the Touch Screen . . . . . . . . . . . . . . . . . 25

S Pen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Samsung Smart Pause . . . . . . . . . . . . . . . . . . 36

Samsung Smart Scroll . . . . . . . . . . . . . . . . . . 36

Activating Multi Window . . . . . . . . . . . . . . . . . 37

Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Notifications Panel . . . . . . . . . . . . . . . . . . . . . 39

Indicator Icons . . . . . . . . . . . . . . . . . . . . . . . . 41

Primary Shortcuts . . . . . . . . . . . . . . . . . . . . . 42

Other App Shortcuts . . . . . . . . . . . . . . . . . . . . 42

Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

App Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . 43

Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Wallpapers . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Apps Screen . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . 47

Connecting to a Wi-Fi Network . . . . . . . . . . . . 50

Setting Up Accounts . . . . . . . . . . . . . . . . . . . . 51

Transferring Files . . . . . . . . . . . . . . . . . . . . . . 51

Upgrading the Device . . . . . . . . . . . . . . . . . . .52

Section 3: Accounts and Contacts ...........54

Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Your Google Account . . . . . . . . . . . . . . . . . . . . 55

Your Samsung Account . . . . . . . . . . . . . . . . . .55

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Section 4: Messaging ................................62

Types of Messages . . . . . . . . . . . . . . . . . . . . .62

Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Hangouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

Google+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Messenger . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

ChatON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

Section 5: Multimedia ...............................67

Listening to Music . . . . . . . . . . . . . . . . . . . . . . 67

Play Music . . . . . . . . . . . . . . . . . . . . . . . . . . .67

Music Player . . . . . . . . . . . . . . . . . . . . . . . . . .70

Story Album . . . . . . . . . . . . . . . . . . . . . . . . . . .75

Flipboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

SketchBook for Galaxy . . . . . . . . . . . . . . . . . . .78

WatchON . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79

Section 6: Internet and Social

Networking .............................................80

Google Search . . . . . . . . . . . . . . . . . . . . . . . . .80

Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

Section 7: Camera and Video ...................83

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83

Zooming In and Out . . . . . . . . . . . . . . . . . . . . .87

Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96

Section 8: Connections .............................97

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

Wi-Fi Direct . . . . . . . . . . . . . . . . . . . . . . . . . .100

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . .101

Managing Downloads . . . . . . . . . . . . . . . . . .103

Kies Via Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . .105

Memory Card . . . . . . . . . . . . . . . . . . . . . . . . 105

Synchronizing with Windows Media Player . . 106

Connecting as a Mass Storage Device . . . . . 106

Section 9: Applications ..........................107

Updating Applications . . . . . . . . . . . . . . . . . 107

GPS Applications . . . . . . . . . . . . . . . . . . . . . 107

Accessing Applications . . . . . . . . . . . . . . . . 108

Action Memo . . . . . . . . . . . . . . . . . . . . . . . . 109

Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Bloomberg Businessweek+ . . . . . . . . . . . . . 110

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

ChatON . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Chrome . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Dropbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Evernote . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Flipboard . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Google . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Google Settings . . . . . . . . . . . . . . . . . . . . . . 115

Google+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Group Play . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Hangouts . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

KNOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Messenger . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

My Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

NYTimes . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Play Books . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Play Games . . . . . . . . . . . . . . . . . . . . . . . . . 120

Play Magazines . . . . . . . . . . . . . . . . . . . . . . 120

Play Movies & TV . . . . . . . . . . . . . . . . . . . . . 120

Play Music . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Play Store . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Polaris Office 5 . . . . . . . . . . . . . . . . . . . . . . . 122

S Finder . . . . . . . . . . . . . . . . . . . . . . . . . . . .123

S Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

S Translator . . . . . . . . . . . . . . . . . . . . . . . . .127

S Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Samsung Apps . . . . . . . . . . . . . . . . . . . . . . . 129

Samsung Hub . . . . . . . . . . . . . . . . . . . . . . . .129

Samsung Link . . . . . . . . . . . . . . . . . . . . . . . .129

Scrapbook . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . . 130

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131

SketchBook for Galaxy . . . . . . . . . . . . . . . . .131

Story Album . . . . . . . . . . . . . . . . . . . . . . . . .131

TripAdvisor . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Twitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Video Editor . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Voice Search . . . . . . . . . . . . . . . . . . . . . . . . . 132

WatchON . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

World Clock . . . . . . . . . . . . . . . . . . . . . . . . . .132

YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . .132

Section 10: Settings ................................ 133

About Settings . . . . . . . . . . . . . . . . . . . . . . . .133

Settings Tabs . . . . . . . . . . . . . . . . . . . . . . . .133

Connections . . . . . . . . . . . . . . . . . . . . . . . . .134

Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134

Wi-Fi Direct Settings . . . . . . . . . . . . . . . . . . .134

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . .134

Airplane Mode . . . . . . . . . . . . . . . . . . . . . . . .134

Data Usage . . . . . . . . . . . . . . . . . . . . . . . . . .135

Location Services . . . . . . . . . . . . . . . . . . . . .135

More Networks . . . . . . . . . . . . . . . . . . . . . . .136

Nearby Devices . . . . . . . . . . . . . . . . . . . . . . .137

Screen Mirroring . . . . . . . . . . . . . . . . . . . . . .138

Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138

Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . .140

Multi Window . . . . . . . . . . . . . . . . . . . . . . . .141

Lock Screen . . . . . . . . . . . . . . . . . . . . . . . . . 141

Wallpaper . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Font . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Notification Panel . . . . . . . . . . . . . . . . . . . . . 143

Accessibility . . . . . . . . . . . . . . . . . . . . . . . . . 144

Blocking Mode . . . . . . . . . . . . . . . . . . . . . . . 146

Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

Language and Input . . . . . . . . . . . . . . . . . . . 147

Voice Control . . . . . . . . . . . . . . . . . . . . . . . . 150

S Pen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

Motions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Palm Motion . . . . . . . . . . . . . . . . . . . . . . . . 152

Smart Screen . . . . . . . . . . . . . . . . . . . . . . . . 152

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Cloud . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Backup and Reset . . . . . . . . . . . . . . . . . . . . 156

Date and Time . . . . . . . . . . . . . . . . . . . . . . . 157

Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . 158

Application Manager . . . . . . . . . . . . . . . . . . 158

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

Power Saving Mode . . . . . . . . . . . . . . . . . . . 161

Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

About Device . . . . . . . . . . . . . . . . . . . . . . . . 166

Section 11: Health and Safety

Information ............................................168

Exposure to Radio Frequency (RF) Signals . . 168 Specific Absorption Rate (SAR)

Certification Information . . . . . . . . . . . . . . 173

FCC Part 15 Information to User . . . . . . . . . . 175

Smart Practices While Driving . . . . . . . . . . . 175

Battery Use and Safety . . . . . . . . . . . . . . . . . 176

Samsung Mobile Products and Recycling . . . 178

UL Certified Travel Charger . . . . . . . . . . . . . . 178

Display / Touch-Screen . . . . . . . . . . . . . . . . 179

GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

Care and Maintenance . . . . . . . . . . . . . . . . . 180

Responsible Listening . . . . . . . . . . . . . . . . . 181

Operating Environment . . . . . . . . . . . . . . . . . 183

Restricting Children's Access to Your

Mobile Device . . . . . . . . . . . . . . . . . . . . . . 185

FCC Notice and Cautions . . . . . . . . . . . . . . . . 185

Other Important Safety Information . . . . . . . .185

Section 12: Warranty Information ..........187

Standard Limited Warranty . . . . . . . . . . . . . . 187

End User License Agreement for Software . . . 192

Social Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

LIMITATION OF LIABILITY . . . . . . . . . . . . . . . . 205

Social Hub Privacy Policy . . . . . . . . . . . . . . . . 207

INFORMATION THAT WE COLLECT . . . . . . . . . 208

USE OF INFORMATION WE COLLECT . . . . . . . 208

DISCLOSURE OF INFORMATION TO

THIRD PARTIES . . . . . . . . . . . . . . . . . . . . . .209

CHILDREN . . . . . . . . . . . . . . . . . . . . . . . . . . .210

SECURITY OF THE INFORMATION

WE COLLECT . . . . . . . . . . . . . . . . . . . . . . .210

CHAT ROOMS AND OTHER PUBLIC AREAS . . .211

CONTESTS AND SWEEPSTAKES . . . . . . . . . . .211

ACCURACY OF THE INFORMATION

WE COLLECT . . . . . . . . . . . . . . . . . . . . . . .211

CHANGES TO PRIVACY POLICY . . . . . . . . . . . .212

Social Hub End User License Agreement . . . .212

Index .........................................................218

Section 1: Getting Started

This section helps you to quickly start using your device.

Understanding This User Manual

The sections of this manual generally follow the features of your device. A robust index for features begins on page 218.

Also included is important safety information, beginning on page 168, that you should know before using your device.

This manual gives navigation instructions according to the default display settings. If you select other settings, navigation steps may be different.

Unless otherwise specified, all instructions in this manual assume that you are starting from a Home screen. To get to a Home screen, you may need to unlock the device. For more information, refer to “Securing Your Device” on page 14.

Note:

Instructions in this manual are based on default settings and may vary from your device depending on the software version on your device and any changes to the device’s settings.

Note:

Unless stated otherwise, instructions in this user manual start with the device unlocked, at the Home screen.

All screen images in this manual are simulated. Actual displays may vary depending on the software version of your device and any changes to the device’s settings.

Special Text

In this manual, some text is set apart from the rest. This special text is intended to point out important information, share quick methods for activating features, define terms, and more. The definitions for these methods are as follows:

•

Notes

: Presents alternative options for the current feature, menu,

or sub-menu.

•

Tips

: Provides quick or innovative methods or useful shortcuts.

•

Important

: Points out important information about the current

feature that could affect performance.

•

Warning

: Brings important information to your attention that can help to prevent loss of data or functionality or damage to your device.

Getting Started 7

Text Conventions

This manual provides condensed information about how to use your device. To make this possible, the following text conventions are used to represent often-used steps:

➔

Arrows are used to represent the sequence of selecting successive options in longer, or repetitive, procedures. For example:

From a Home screen, touch

➔

Connections

tab ➔

Wi-Fi

Apps

➔ Settings

Battery

Your device is powered by a rechargeable, standard Li-Ion battery. A Wall/USB Charger (Charging Head and USB cable) are included with the device for charging the battery.

Warning!

Use only approved charging devices. Approved accessories are designed to maximize battery life. Using other accessories may invalidate your warranty and may cause damage.

Battery Indicator

The Battery icon in the Status Bar shows the battery power level. When battery power is 15% or less, your device prompts you to charge the battery. If you continue to operate the device without charging, the device powers off. For battery use information, see “About Device” on page 166.

Charging the Battery

Your device comes with a Wall/USB Charger (Charging Head, and USB cable) to charge your device from any standard AC power outlet.

Note:

The battery comes partially charged. You must fully charge the battery before using your device for the first time. After the first charge, you can use the device while charging.

1. Insert the USB cable into the Charging Head.

2. Insert the USB cable into the device’s Charger/

Accessory Port.

Warning!

While the device is charging, if the touch screen does not function due to an unstable power supply, unplug the USB power adapter from the power outlet or unplug the USB cable from the device.

3. Plug the Charging Head into a standard AC power

outlet.

4. When charging is complete, unplug the Charging Head

from the power outlet and remove the USB cable from the device.

Note:

You cannot charge the battery using the USB cable and

your PC.

Note:

If the battery is completely discharged, you cannot turn on the device, even with the USB power adapter connected. Allow a depleted battery to charge for a few minutes before you try to turn on the device.

Getting Started 9

Turning Your Device On and Off

Turning Your Device On



Press and hold the

For more information, refer to “Unlocking the Device” on page 15.

Note

: Your device’s internal antenna is located along the top back of the device. Do not block the antenna; doing so may affect signal quality and may cause the device to operate at a higher power level than is necessary.

Power/Lock Key

Turning Your Device Off

1. Press and hold the

2. On the Device options menu, touch

Power/Lock Key

Power off

Setting Up Your Device

When you turn on your device for the first time, it displays a Welcome screen. Follow the prompts to set up features and preferences on your device.

Some screens can be skipped (touch (touch

Back

1. From the Welcome screen, select a language and

touch

to get started.

Note:

If you are visually impaired or hard of hearing, touch

Accessibility

Settings. For more information, refer to “Accessibility” on page 144.

. For more information, see Accessibility

) or re-displayed

2. Follow the prompts to complete each section. For each

topic, you will have the option to skip it and continue to

the next screen.

•Wi-Fi

: Sign in to an available Wi-Fi network. For secured Wi-Fi

networks, you will need to enter a password. For more

“Wi-Fi”

information, refer to

• Date and time

• End User License Agreement

Agreement and touch

and conditions above

error reports during device failures, touch

• Samsung Account

Samsung Account, or touch the instructions to set up a new Samsung Account.

–

Touch Account.

• Got Google?

Account, or touch new Google Account.

: Set the date, time, and select a time zone.

variety of services

: Touch

on page 97.

: Read the End User License

I understand and agree to the terms

. If you would like to send Samsung

Yes

: Touch

to sign in to your current

Create new account

to learn more using your Samsung

Yes

to sign in to your current Google

and follow the instructions to set up a

and follow

• Make it Google

instructions to create a new Google Account, or touch

Not now

–

Touch to learn more about Google Accounts.

–

This screen only displays if you did not previously sign in to your Google Account.

• Google and your Location

location services. Touch each location service to enable.

•Entertainment

instructions to enter credit card information for your Google Play account, or touch

–

This screen only displays if you previously signed in to your Google Account.

• This tablet belongs to…

information is used by the tablet to personalize certain apps.

•Dropbox Account

instructions to set up a new Dropbox Account, or touch to sign in to your existing Drop Box Account.

: Touch

Get an account

: Read the information about

: Touch

Set up credit card

Not now

: Enter your first and last name. This

: Touch

Create account

and follow the

Getting Started 11

• Thank you

: This screen displays the Device name and an

option to learn more.

–

Device name

to identify the tablet when using Bluetooth, Wi-Fi Direct, and so on. The default is the model name, SM-P600.

–

Learn more

see more details.

–

Finish

the Home screen.

: Enter a name for the tablet. This name is used

: Touch this option and then touch each feature to

: Your setup is now complete. Touch this option to display

Task Manager

Your device can run applications simultaneously and some applications run in the background.

Use Task Manager to see which applications are running on your device and to end running applications to extend battery life. You can also uninstall applications from your device and see how much memory is used by applications.

Task Manager Application

The Task Manager application provides information about applications, including

RAM manager

To access the Task Manager:

1. Add the Active Apps Manager widget to a Home screen

and then touch the Active Apps Manager widget. For more information, refer to “Widgets” on page 42.

2. Tou ch

3. Tou ch

4. Tou ch

5. Tou ch

For more information, refer to “Apps Screen” on page 45.

Active applications

on your device. Touch

End all

to end all running applications.

Downloaded

Google Play. Touch from your device.

RAM manager

Access Memory (RAM) currently in use. Touch

memory

Storage

external (SD card) storage memory statistics.

Active applications, Downloaded

, and

Storage

to view applications running

End

to end an application or

to view applications installed from

Uninstall

to remove an application

to display the amount of Random

Clear

to clear inactive and background processes.

to view internal (Device memory) and

Memory Card

Your device supports removable microSD or microSDHC memory cards with maximum capacities of 64 GB (depending on the memory card manufacturer and type). Memory cards are used to store music, photos, videos, and other files.

Note:

You can only store music files that you own (from a CD

or purchased with the device) on a memory card.

Installing a Memory Card

1. Open the Memory Card Slot cover and turn to expose

the slot.

2. With the gold contacts facing down, carefully slide the

memory card into the slot, pushing gently until it clicks into place.

3. Replace the Memory Card Slot cover.

Getting Started 13

Removing a Memory Card

Important!

For more information, refer to “Memory Card” on page 105.

To prevent damage to information stored on the memory card, unmount the card before removing it from the device.

Apps

1. From a Home screen, touch

➔

General

tab ➔

Storage

SD card

2. Under

touch

3. Open the Memory Card Slot cover and turn to expose

the slot.

4. Gently press down on the memory card, so that it pops

out from the slot, and carefully pull the card out.

5. Replace the Memory Card Slot cover.

, touch Unmount SD card

➔ Settings

and then

Galaxy Tab Accessories

To find accessories for your Galaxy Tab:

1. Go to

samsung.com/us/mobile/galaxy-tab-accessories

Galaxy Tab accessories display.

2. Use your model number to find compatible

accessories.

Securing Your Device

By default, the device locks automatically when the screen times out or you can lock it manually. You can unlock the device using one of the default Unlock screens or, for increased security, use a personal screen unlock pattern.

For more information about creating and enabling a Screen unlock pattern, see “More Networks” on page 136.

For other settings related to securing your device, see “Location Services” on page 135.

Note:

Unless stated otherwise, instructions in this User Manual start with the device unlocked, at the Home screen.

Locking the device manually



Press the

Power/Lock Key

Unlocking the Device

1. Press the

2. Swipe across the screen as shown.

Power/Lock Key

The Lock screen displays.

The last screen you accessed displays.

Prevent others from using or accessing personal data and information stored in the device by using the security features. The device requires an unlock code whenever unlocking it.

Setting a Pattern

1. From a Home screen, touch Device

tab ➔

➔

2. Draw a pattern by connecting four dots or more, and

then draw the pattern again to verify it. Set a backup unlock PIN to unlock the screen when you forget the pattern.

Lock screen

Apps

➔ Settings

➔

Screen lock

Getting Started 15

➔

Pattern

Setting a PIN

1. From a Home screen, touch Device

tab ➔

➔

2. Enter at least four numbers, and then enter the

password again to verify it.

Lock screen

Apps

➔

Screen lock

➔ Settings

Setting a Password

1. From a Home screen, touch

➔

Device

tab ➔

Lock screen

Password

2. Enter at least four characters including numbers

and symbols, and then enter the password again to verify it.

Apps

➔

Screen lock

➔ Settings

➔

Unlocking the Device

Turn on the screen by pressing the Power button or the Home

button, and enter the unlock code.

Note:

If the unlock code is forgotten, take the device to a

Samsung Service Centre to reset it.

Holding the Device

Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery.

Adjusting the Volume

Press the Volume button up or down to adjust the ringtone volume, or to adjust the sound volume when playing music or video.

Switching to Silent Mode

Use one of the following methods:

•

Press and hold the Volume button down until it switches to

silent mode.

•

Press and hold the Power button, and then touch

Vibrate

•

Open the notifications panel at the top of the screen, and then

touch

Sound

Vibrate

Mute

Troubleshooting

If your device has fatal errors, hangs up, or freezes, you may need to reset the device to regain functionality.

•

If your device is frozen and unresponsive, press and hold the

Power/Lock Key

for 8 to 10 seconds.

Getting Started 17

Section 2: Understanding Your Device

This section outlines key features of your device and describes the screen and the icons that appear when the device is in use. It also shows how to navigate through the device.

Features

•

10.1-inch WQXGA (2560x1600) TFT (PLS) LCD touch screen

•

Android Version: Jelly Bean 4.3

•

Wi-Fi, 1.9 GHz dual-core processor

•

Full HTML Web Browser

•

Bluetooth 4.0 Wireless technology. For more information, refer to

“Bluetooth”

•

Built-in Wi-Fi technology (802.11 a/b/g/n/ac)

•

8 megapixel camera and camcorder, plus 2 megapixel full HD forward-facing camera for video chat

•

Full integration of Google applications (Gmail, YouTube, Google Maps, and Voice Search)

•

Photo gallery that supports GIF, AGIF, JPEG, PNG, BMP, WBMP, and WEBP formats

on page 101.

•

Messaging Features:

–

Gmail

–

Email (corporate and personal)

–

Google Hangouts (Instant Messaging and Video Chat)

•

HD Video Player (1080p)

–

Codec: MPEG4, H.264, H.263, VC-1, VP8, WMV7/8, Sorenson Spark, MP43

–

Format: AVI, MP4, 3GP, MKV, WMV, ASF, FLV

•

Music player that supports MP3, AAC/AAC+/EAAC+, WMA, Vorbis,

FLAC, AC-3, AMR-NB/WB, WAV

•

Support for microSD and microSDHC memory cards

•

Preloaded applications such as AllShare Play, Google Play Books, Google Play information, refer to page 46.

Warning!

Store, Music Hub, and Polaris Office. For more

“More Application Information”

This device does not support some USB storage media devices. For more information, refer to “Galaxy Tab Accessories” on page 14.

Front and Sides

7 8

The following items can be found on the front and sides of your device as illustrated.

Light Sensor

automatically when taking photos with the front-facing Camera.

Front-facing Camera Lens

recording videos.

3.5mm Headset Jack

3. External Speakers

notification tones, and for other sounds.

Display Screen

rotates with the tablet as you turn it. You can turn this feature on and off. For more information, refer to “Rotating the Screen” on page 28.

: Used to control screen brightness

: Used when taking photos or

: Plug in for headphones.

: Used in music or video playback,

: The orientation of the display screen

Memory Card Slot

: Install a memory card for storage

of files.

: Display a list of options.

7. Home

: Display the central Home screen. Touch and

hold to display recent apps that have been accessed.

Back

: Return to the previous screen or option.

Understanding Your Device 19

Back, Top, and Bottom

The following items can be found on the back, top, and bottom of your device as illustrated.

Flash

: Provides adequate light when taking pictures in

dark places.

Camera Lens

videos.

Infrared Blaster

controlling external devices.

Volume Key

Master Volume. During music playback, press volume.

Power/Lock Key

off. Press to lock the device or to wake the screen for unlocking.

S Pen

various functions. For more information, refer to “S Pen” on page 31.

Charger/Accessory Port

charging or to sync music and files.

Microphone

: Used when taking photos or recording

: Emits infrared signals used for

: From a Home screen, press to adjust

to adjust

: Press and hold to turn the device on or

: A built-in stylus that allows you to perform

: Plug in a USB cable for

: Used for video chat.

1 2

Home Screen

The Home screen is the starting point for using your device.

Note:

Unless stated otherwise, instructions in this user manual start with the device unlocked, at the Home screen.

System Bar

screen where you can find navigation buttons and icons that show notifications, battery power, and connection details.

Status Icons

the Time / Status Icons area to display the Status Details panel. For more information, refer to “Indicator Icons” on page 41.

Time

“Date and Time” on page 157.

Widgets

Some widgets are found on the Home screen by default. For more information, refer to “Widgets” on page 42.

: The area along the bottom of the Home

: Indicate the status of your tablet. Touch

: The current time. For more information, refer to

: Applications that run on the Home screen.

Home screen

: The starting point for using your device. Place shortcuts, widgets, and other items to customize your device to your needs.

Primary Shortcuts

: Shortcuts to common features. These shortcuts are found on all Home screens by default. For more information, refer to “Primary Shortcuts” on page 42.

Understanding Your Device 21

Google Search

For more information, refer to “Google Search” on page 80.

Apps

: Search the web by typing or speaking.

: Display the Apps screen.

Extended Home Screen

The Home screen consists of the Home panel plus additional panels that extend beyond the display width to provide more space for adding shortcuts and widgets. For more information, refer to “Adding and Removing Home Screen Panels” on page 23.

Slide your finger horizontally across the screen to scroll to the left or right side panels.

Note:

The center panel displays when you touch

Home

Customizing the Home Screens

To customize the Home screens to suit your preferences:

1. Navigate to one of the Home screen panels.

2. Touch and hold on the screen until the

pop-up displays.

3. Tou ch

4. Under

Set wallpaper

wallpaper. For more information, refer to “Wallpapers” on page 45.

Add to Home screen

• Apps and widgets

Home screen.

•Folder

to add a folder on a Home screen. For more

information, refer to

•Page

to add a Home screen.

to change the Home screen

touch:

to add app or widget shortcuts on the

“Folders”

on page 44.

Display Settings

You can customize display screen settings to your preferences. For more information, refer to “Display” on page 140.

Home screen

Adding and Removing Home Screen Panels

Your device comes with seven Home screen panels. You can customize the Home screen by removing or adding panels.

Note:

The panel in the center position displays when you touch

Home



From a Home screen, pinch the screen from the left and right side to the center to display the editing screen.

Tip: Tip:

Touch and hold on the screen until the

pop-up displays. Under

Add to Home screen

Home screen

, touch

Page

add a Home screen.

Use these controls to configure panels:

Remove

: Touch and drag a panel to the Trash Can to

remove the panel from the Home screen.

Default Home Page

: Touch the Home icon on a panel to

set it as the default home screen.

Add

: Touch to add a new panel, up to a total of seven.

This option is available when less than seven panels have been added.

To rearrange the order of panels:



Touch and drag a panel to a new location.

To return to the Home screen:



Tou ch Back

Understanding Your Device 23

Navigating Your Device

Use command buttons and the touch screen to navigate.

Command Buttons

Back

Touch Back or step.

Home

Touch Home Touch and hold to open a list of thumbnail images of apps

you have worked with recently. Touch an App to open it. Touch to display the Task Manager. To launch Google Search, touch . Touch to clear all thumbnail images.

Context-Sensitive Menus

Context-sensitive menus offer options for features or screens. To access context-sensitive menus:

• Touch

• Touch an option in the list.

to return to the previous screen, option,

to display the center Home screen.

to display a list of options.

Screen Capture



Touch and hold the capture and save an image of the current screen.

Note:

A copy of the screenshot is automatically saved to the

clipboard.

To view the screen shots:

1. From a Home screen, touch Samsung

2. Tou ch

3. Touch a screen capture file to display it.

storage

Screenshots

Power/Lock Key

folder ➔

➔

Device storage

and Home

Apps

My Files

➔

Pictures

➔

Application Bar

The Application Bar is the area along the top of various application screens. It usually contains the Search and Menu icons, as well as other icons that are used to display options and settings.

Using the Touch Screen

Use only fingers or the S Pen to use the touch screen.

Caution!

Do not allow the touch screen to come into contact with other electrical devices. Electrostatic discharges can cause the touch screen to malfunction.

To avoid damaging the touch screen, do not tap it with anything sharp or apply excessive pressure to it with your fingertips.

Note:

The device may not recognise touch inputs close to the edges of the screen, which are outside of the touch input area.

Leaving the touch screen idle for extended periods may result in afterimages (screen burn-in) or ghosting. Turn off the touch screen when you do not use the device.

Finger Gestures

Touching

To open an application, to select a menu item, to press an on-screen button, or to enter a character using the on-screen keyboard, touch it with a finger.

Understanding Your Device 25

Touching and Holding

Touch and hold an item for more than 2 seconds to access available options.

Dragging

To move an icon, thumbnail, or preview to a new location, touch and hold it and drag it to the target position.

Double-Tapping

Double-tap on a webpage, map, or image to zoom in a part. Double-tap again to return.

Flicking

Flick left or right on the Home screen or the Applications screen to see another panel. Flick up or down to scroll through a webpage or a list, such as contacts.

Understanding Your Device 27

Pinching

Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.

Control Motions

Simple motions allow easy control of the device. Before using motions, make sure the motion feature is

activated.

1. From a Home screen, touch Controls

tab ➔

➔

2. Touch the

Note:

Excessive shaking or impact to the device may result in

unintended inputs. Control motions properly.

Motions

OFF/ON

button to turn Motions ON .

Apps

➔ Settings

Rotating the Screen

Many applications allow display in either portrait or landscape orientation. Rotating the device causes the display to automatically adjust to fit the new screen orientation.

To prevent the display from rotating automatically, open the notifications panel and deselect

Note:

Some applications do not allow screen rotation.

Some applications display a different screen depending on the orientation. The calculator turns into a scientific calculator when rotated to landscape.

Screen rotation

Tilting

Touch and hold two points on the screen, and then tilt the device back and forth to zoom in or out.

Note:

To move an icon to a new location, touch and hold it and drag it to the target position. For more information, refer to “Dragging” on page 26.

Panning to Browse

When an image is zoomed in, touch and hold a point on the screen, and then move the device in any direction to browse the image.

Understanding Your Device 29

Palm Motions

Use palm motions to control the device by touching the screen.

Before using motions, make sure the palm motion feature is activated.

Apps

➔

Screenshots

➔ Settings

. It is not

1. From a Home screen, touch

➔

Controls

tab ➔

Palm motion

OFF/ON

2. Touch the ON

Sweeping

Sweep your hand across the screen to capture a screenshot. The image is saved in possible to capture a screenshot while using some applications.

button to turn Palm motion

Gallery

Covering

Cover the screen with a palm to pause media playback.

SPen

S Pen Button

S Pen Tip

The S Pen is a stylus that assists you in performing different functions. By using the Pen button, you can minimize having to switch between touch and pen input.

Replacing the S Pen Nib

While using the S Pen, the S Pen nib may get dull. If the nib is dull, replace it with a new one.

1. Hold the nib with the tweezer firmly, and then pull

it out.

S Pen button S Pen tip

: Perform advanced S Pen actions.

: Perform basic S Pen actions.

2. Insert a new nib into the S Pen until you hear a click.

Understanding Your Device 31

Using the S Pen

The included S Pen can be used to easily select items or perform functions. Actions using the S Pen with the button pressed provide additional conveniences, such as screen capture.

Pull out the S Pen from the slot to use it.

When you pull out the S Pen from the slot, the device detects it and performs the following:

•

Turns on the touch screen (if it is off).

•

Launches action memo, or display general air commands.

Notes:

•

The pen nib of the S Pen is replaceable. If the pen nib gets dull, replace it with a new one.

•

If the S Pen is not working properly, take it to a Samsung Service Centre. Refer to the Samsung website for more information about the S Pen.

•

For best results, keep the S Pen mostly perpendicular to the touch screen and avoid using it at sharp angles.

•

The Menu button and the Back button cannot be activated by the S Pen.

Capturing Screenshots

With the S Pen button pressed, touch the screen until you hear a click. A screenshot is saved in the

Screenshots

It is possible to draw or write on or to crop a screenshot. The edited image is saved in the

It is not possible to capture a screenshot while using some applications.

folder.

Gallery

➔

Screenshots

Gallery

➔

folder.

Launching Action Memo

With the S Pen button pressed, double-tap the screen to launch action memo.

Jot down or draw a note, and then select the memo by tapping to perform various actions, such as adding contacts or sending a email. With the memo selected, draw a line around an area with the S Pen to perform actions with the selected area.

Understanding Your Device 33

Selecting and Capturing an Image

With the S Pen button pressed, draw a line around an area to select it.

If necessary, use one of the following options:

Restore the original selection.

Convert the selection to circular shape.

Convert the selection to rectangular shape.

Customize the selection.

Select an application to use with the selected area from the icons that appear at the bottom of the screen.

Using Air Command

Press the S Pen button while hovering the S Pen over the screen.

In most cases, general air commands appear on the screen when pressing the S Pen button.

Use the following actions:

•

Action Memo

•

Scrap booker

image into Scrapbook.

•

Screen Write

•

S Finder

•

Pen Window

the screen.

: Launch action memo. : Select and capture an image, and then save the

: Capture a screenshot and edit it with the S Pen.

: Launch S Finder.

: Launch multiple applications in specified areas on

Some items have contextual menus that make the S Pen pointer glow. Press the S Pen button to display the menu while hovering the S Pen over the item.

Air View

Use this feature to perform various functions while the S Pen is hovering over the screen.

1. From a Home screen, touch

➔

Controls

tab ➔

S Pen

OFF/ON

2. Touc h th e

Point at an item with the S Pen to preview content or view information in a pop-up window.

You can scroll through panels or lists by moving the S Pen pointer to an edge (top/bottom/left/right) of the screen.

For more information, refer to “S Pen” on page 31.

button to turn Air view ON .

Understanding Your Device 35

➔

Apps

Air view

➔ Settings

Samsung Smart Pause

Use this feature to pause videos when you look away from the screen.

Apps

1. From a Home screen, touch

➔

Controls

tab ➔

Smart screen

2. Touch

During video playback, look away from the screen to pause the video. To resume playback, look at the screen again.

Smart pause

to enable it.

➔ Settings

Samsung Smart Scroll

Use this feature to scroll the screen up or down by tilting your head or the device.

1. From a Home screen, touch

➔

Controls

tab ➔

Smart screen

OFF/ON

2. Touch the ON

3. Tou ch

When you are viewing email or webpages, the scroll type icon ( for head orientation or for tilting the device) that shows the recognition status for movements appears in blue.

Smart scroll

button to turn Smart scroll

and select a scroll type.

Apps

➔

➔ Settings

Smart scroll

When the device recognizes your head or device’s movements, the icon turns green. Tilt your head downward or upward, or tilt the device forward or backward to scroll in that direction.

Activating Multi Window

Use this feature to run two applications on the screen at the same time.

Notes:

•

Only applications on the Multi Window panel can run.

•

When launching applications that contain multimedia files, such

as music or videos, sound from both files will be played.

•

This feature may not be available depending on the region or

service provider.

To use Multi Window:

Apps

1. From a Home screen, touch

➔

Device

tab.

OFF/ON

2. Touc h th e ON

button to turn Multi window

➔ Settings

Using the Multi Window Panel

To show the Multi Window panel:

1. Touch and hold The Multi Window panel appears on the left side of the

screen.

2. Select one application, and then drag another application to a new location.

You can launch the same application on the two windows at the same time.

Back

Understanding Your Device 37

To hide the Multi Window panel:



Touch and hold Back

Drag the circle between the application panels left or right to adjust the size of the panels.

Touch the panel handle to hide or show the panel. When a panel is open, touch and hold the handle and drag it to the left or right edge of the screen to move the panel. When a panel is hidden, touch and hold the handle and drag it up or down to move the handle.

again.

Using Multi Window Applications

While using Multi Window applications, select an application panel, touch the circle between the application panels, and then use one of the following:

Switch app to compact screen.

Switch locations between Multi Window applications.

Share items between the application windows. Drag an item to share from one window to another. Some applications may not support this feature.

Close the application.

Sharing Files

Drag an item you want to share to the other window to share the item from one window to another.

Creating a Paired Window

Use this feature to save the combination of current running Multi Window applications.

On the Multi Window panel:

1. Touch ➔

2. Enter a title and then touch

Create

Notifications

Notification icons appear on the status bar at the top of the screen to report new messages, calendar events, device status, and more. Drag down from the status bar to open the notifications panel. Scroll the list to see additional alerts. To close the notifications panel, drag up the bar that is at the bottom of the screen.

Notifications Panel

From the notifications panel, you can view your device’s current settings. Drag down from the status bar, touch to open the notifications panel, and then use the following options:

•

Wi-Fi

: Activate or deactivate the Wi-Fi feature.

•

GPS

: Activate or deactivate the GPS feature.

•

Sound

: Activate or deactivate silent mode. You can vibrate or

mute your device in silent mode.

•

Screen rotation

when you rotate the device.

•

Bluetooth

•

Reading mode

optimizes the screen for reading.

•

Blocking mode

blocking mode, the device will block notifications. To select which notifications will be blocked:

–

From a Home screen, touch

Device

: Allow or prevent the interface from rotating

: Activate or deactivate the Bluetooth feature.

: Activate or deactivate reading mode, which

: Activate or deactivate blocking mode. In

Apps ➔ Settings ➔

tab ➔ Blocking mode

Understanding Your Device 39

•

Power saving

•

Multi window

•

Screen Mirroring

feature.

•

Air view

•

Smart stay

•

Smart pause

•

Smart scroll

•

Sync

•

Airplane mode

Note:

The available options may vary depending on the region

or service provider.

To rearrange the options on the notifications panel:

1. Open the notifications panel and touch .

2. Touch and hold an item, and then drag the item to

: Activate or deactivate power-saving mode. : Set to use Multi Window.

: Activate or deactivate the screen mirroring

: Activate or deactivate the air view feature.

: Activate or deactivate the smart stay feature.

: Activate or deactivate the smart pause feature.

: Activate or deactivate the smart scroll feature.

: Activate or deactivate auto-syncing of applications.

: Activate or deactivate airplane mode.

another location.

To open the Settings application:



Tou ch Settings “Settings” on page 133.

To set brightness options:



Touch the brightness or touch brightness automatically based on available light and battery charge status. For more information, refer to “Display” on page 140.

Notifications

To close the Notification Panel:

displays system notifications.



Touch a notification entry to display the details. Touch

Clear

to remove Notification Icons from the System Bar.

For more information, refer to “Notifications” on page 39.



Touch

. For more information, refer to

Brightness

slider and drag it to set the

Auto

to allow the device to set

Home,

Back

, or swipe up.

Indicator Icons

The icons displayed at the top of the screen provide information about the status of the device. The icons listed in the table below are most common.

Alarm activated

S Pen removed

Wi-Fi connected

Bluetooth feature activated

GPS activated

Air gesture feature activated

Smart screen feature activated

Synced with the web

Connected to computer

Silent mode activated

Vibration mode activated

Airplane mode activated

Error occurred or caution required

Battery power level

Understanding Your Device 41

Primary Shortcuts

Primary Shortcuts display at the bottom of the Home screens.

Tip:

The main Home screen is usually the center Home screen.

The default Primary Shortcuts are: S Note, Calendar, Internet, Email, Gallery, Scrapbook, Dropbox, Play Store.

Other App Shortcuts

There are also other application shortcuts on the Home screens, such as Dropbox, Samsung Apps, and Play Store.

For more information, refer to “More Application Information” on page 46.

Application shortcuts can be added to any Home screen. For more information, refer to “App Shortcuts” on page 43.

Widgets

When you first turn on your tablet, there are various widgets on the center Home screen. They can also appear on the Home screens to the left and right of the center Home screen.

Widgets are self-contained applications that you can place on the Home screens to access your favorite features.

For more information, refer to “Applications” on page 107.

Adding Widgets to a Home screen

1. Navigate to the Home screen on which you want to Apps

place the Widget and touch

Widgets

2. Touch the

Note:

Swipe across the screen horizontally to view all Widgets.

3. Touch and hold the widget’s icon until the Home screen

displays, then slide your finger where you want to place the icon and release it.

Note:

There must be room on the screen where you want to place the widget, otherwise the widget will not add to the Home screen.

tab.

Removing Widgets



Touch and hold the Widget until the displays, then drag the widget to the

Note:

This action does not actually delete the Widget, it just

removes it from the current Home screen.

Remove

App Shortcuts

Use App Shortcuts for quick access to applications or features, such as Email or other applications.

1. Navigate to the Home screen on which you want to

place the App Shortcut.

2. From a Home screen, touch

– or – Touch and hold on the screen until the

options pop-up displays and then touch

widgets

Apps

3. Touch the

tab.

Apps

Home screen

Apps and

icon

icon.

4. Touch and hold the application icon until the Home

screen displays, then slide your finger where you want to place the icon and release it.

For more information, refer to “Apps Screen” on page 45.

5. Touch and hold the App Shortcut and then drag the

application icon to reposition it on the Home screen.

Removing App Shortcuts



Touch and hold the App Shortcut until displays, then drag the App Shortcut to the

Remove

icon.

Understanding Your Device 43

Folder s

Place Folders on a Home screen to organize items together.

Adding Folders

To create a folder on a Home page:

1. Navigate to the desired Home screen.

Folder

Home screen

2. Touch and hold on the screen until the

pop-up displays and then touch The Create folder pop-up displays.

3. Touch the

Enter folder name

enter a name for the folder, and touch A new folder displays on the Home screen.

field, use the keyboard to

Managing Folders

To rename a folder:



Touch the folder, touch the current name, and use the keyboard to enter a new name for the folder.

To add an App shortcut to a folder:

1. Add the App shortcut to the Home screen that the

2. Touch and hold the App shortcut, drag it to the folder,

To remove an App shortcut from a folder:

1. Touch the folder to view the contents.

2. Touch the App shortcut, drag it out of the folder, and

Removing a Folder



Note:

folder is on.

and drop it.

drop it on the Home screen.

Touch and hold the folder until the displays, then drag the folder to the

Any App shortcuts in the folder are also removed.

Remove

icon.

icon

Wallpapers

You can choose a picture to display on the Home Screen, Lock screen, or on both the Home and Lock screens. Choose from preloaded wallpaper images or select a photo you have downloaded or taken with the Camera.

1. From a Home screen, touch and hold on the screen.

The

Home screen

2. Touch

3. Touch

Set wallpaper

The Set wallpaper pop-up displays.

Home screen, Lock screen

screens

Select wallpaper from

The following options:

•Gallery

select it. Crop and resize the picture, if desired. Touch save the picture as wallpaper. Touch

• Live wallpapers

wallpapers. Touch a wallpaper to see an example. If available, touch

wallpaper

the Live wallpapers menu.

options pop-up displays.

, or

Home and lock

pop-up displays the

: Access the Gallery to select a photo. Touch a photo to

Done

Cancel

to cancel.

: Choose from pre-loaded interactive animated

Settings

to view options for the selection. Touch

to save your choice. Touch Back

Set

to return to

• Wallpapers

Note:

Live wallpapers is not available for the Lock screen.

: Choose from pre-loaded wallpaper images. Touch an image to view it. Touch wallpaper. Touch

Set wallpaper

Back

to return to the Home screen.

Apps Screen

The

Apps

screen displays all applications installed on your wireless device. Applications that you download and install from Google Play or from the web are also added to a Home screen.

The Apps icons are arranged in a customizable grid. To arrange the Apps icons in alphabetical order:

1. From a Home screen, touch Menu

2. To uch

3. To uch

Alphabetical grid

➔ View type

Understanding Your Device 45

Apps

to save it as

To manually change the order of the icons on the Apps screen:

1. From a Home screen, touch Menu

2. Touch

3. Touch and hold an icon and drag it to a new position.

4. Touch

You can place shortcuts to applications on the Home screen for quick access to the application. For more information, refer to “App Shortcuts” on page 43.

To view your downloaded applications:

1. From a Home screen, touch

2. Touch

3. Touch an icon on the

Save

to launch the application. – or –

Add an App Shortcut to a Home screen by dragging the App icon onto the Home Screen. For more information, refer to “App Shortcuts” on page 43.

➔ Edit

to save the changes.

Download

to view downloaded apps.

Downloaded applications

Apps

screen

Application Information

To view information about an App, such as the amount of storage it uses, force the App to stop, uninstall updates, and clear data:

1. From a Home screen, touch

➔

General

tab ➔

Application manager

All

2. Touch the

touch the app to open a screen with details about the App.

tab, scroll through the apps list, and

Apps

➔ Settings

More Application Information

For more information, refer to “Applications” on page 107. In that section, each application that is available on the

Applications screen is listed and described. If the application is also described in another section of this user manual, then a cross reference to that particular section is provided. Various widgets are also described.

Help

Access help information to learn how to use the device and applications or configure important settings.

Apps

➔

1. From a Home screen, touch

Help

2. Select a category to view tips.

To sort categories by an alphabetical order, touch . To search for keywords, touch .

Entering Text

Use the Samsung keyboard or the voice input feature to enter text.

Note:

Text entry is not supported in some languages. To enter text, you must change the input language to one of the supported languages.

Using the Keyboard

Touch any text field, open the notifications panel, touch

Select input method

to use.

2 3 4 5

1. Enter uppercase.

2. Enter punctuation marks.

3. Touch for Voice input. Touch and hold to use

Handwriting, display keyboard settings, or change the keyboard type.

4. Enter a space.

5. Add an item from the clipboard.

6. Break to the next line.

7. Delete a preceding character.

, and then select the type of keyboard

Understanding Your Device 47

Entering Uppercase

Touch before entering a character. For all caps, touch it twice.

Changing the keyboard type

Touch and hold , and then touch to change the keyboard type.

Changing language keyboards

Add languages to the keyboard, and then slide the space key left or right to change language keyboards.

Handwriting

Touch and hold ➔ , and then write a word with a finger or the S Pen. Suggested words appear as characters are entered. Select a suggested word.

Use handwriting gestures to perform actions, such as editing or deleting characters and inserting spaces. To view the gesture guides, touch and hold , and then touch

Settings

➔

Help

➔

Keyboard

➔

Use handwriting

gestures

Direct Pen Input

1. From a Home screen, touch

➔

Controls

tab ➔

S Pen

OFF/ON

2. Touch the ON

button to turn Direct pen input

Apps

➔

Direct pen input

➔ Settings

When hovering the S Pen over a text field, the icon appears at the upper left corner of the text field. Touch to write with the S Pen.

To make simple corrections, change input languages, or enter a space between characters, touch each correction tool displayed on the handwriting pad.

When this feature is enabled, you can do the following actions:

•

Send a handwritten message.

•

Set an alarm just by writing numbers.

Entering Text By Voice

Activate the voice input feature and then speak into the microphone. The device displays what you speak.

If the device does not recognise your words, touch the underlined text and select an alternative word or phrase from the dropdown list.

To change the language or add languages for voice recognition, touch the current language.

Copying and Pasting

Touch and hold over text, drag or to select more or less text, and then touch text is copied to the clipboard.

To paste it into a text entry field, touch and hold at the point where it should be inserted, and then touch

COPY

to copy or

Understanding Your Device 49

CUT

to cut. The selected

PAS TE

Connecting to a Wi-Fi Network

Connect the device to a Wi-Fi network to use the Internet or share media files with other devices. For more information, refer to “Wi-Fi” on page 97.

Turning Wi-Fi On and Off

Open the notifications panel, and then touch Wi-Fi to turn it on or off.

Note:

Your device uses a non-harmonized frequency and is intended for use in all European countries. The WLAN can be operated in the EU without restriction indoors, but cannot be operated outdoors.

Turn off Wi-Fi to save the battery when not in use.

Joining Wi-Fi networks

1. From a Home screen, touch Connections

➔

2. Touch the

3. Select a network from the list of detected Wi-Fi

networks, enter a password if necessary, and then touch

Networks that require a password appear with a lock icon. After the device connects to a Wi-Fi network, the device will automatically connect to it any time it is available.

OFF/ON

Connect

tab ➔

button to turn Wi-Fi

Wi-Fi

Apps

➔ Settings

Adding Wi-Fi Networks

If the desired network does not appear in the networks list, touch

Add Wi-Fi network

Enter the network name in type and enter the password if it is not an open network, and then touch

Connect

at the bottom of the networks list.

Network SSID

, select the security

Forgetting Wi-Fi Networks

Any network that has ever been used, including the current network, can be forgotten so the device will not automatically connect to it. Select the network in the networks list, and then touch

Forget

Setting Up Accounts

Google applications, such as Play Store, require a Google account. Samsung Apps requires a Samsung account. Create Google and Samsung accounts to have the best experience with the device.

Adding Accounts

Follow the instructions that appear when opening a Google application without signing in to set up a Google account.

To sign in with or sign up for a Google account:

1. From a Home screen, touch General

tab ➔

➔

2. Touch

More than one Google account can be used on the device. Set up a Samsung account as well.

New

follow on-screen instructions to complete the account setup.

Accounts

to sign up, or touch

Apps

➔

Add account

Existing

➔ Settings

➔

Google

, and then

Removing Accounts

1. From a Home screen, touch General

tab ➔

➔

2. Select an account name and select the account to

remove.

3. To uch

Remove account

Accounts

Apps

Transferring Files

Move audio, video, image, or other types of files from the device to the computer, or vice versa.

Note:

The following file formats are supported by some applications. Some file formats are not supported depending on the version of the device’s software or the computer operating system.

•

Music

: mp3, m4a, mp4, 3gp, 3ga, wma, ogg, oga, aac, and flac

•


: bmp, gif, jpg, and png

•

Video

: avi, wmv, asf, flv, mkv, mp4, 3gp, webm, and ts

•

Document

: doc, docx, xls, xlsx, ppt, pptx, pdf, and txt

Understanding Your Device 51

➔ Settings

Connecting with Samsung Kies

Samsung Kies is a computer application that manages media contents and personal information with Samsung devices. Download the latest Samsung Kies from the Samsung website.

1. Connect the device to the computer using the

USB cable. Samsung Kies launches on the computer

automatically. If Samsung Kies does not launch, double-click the Samsung Kies icon on the computer.

2. Transfer files between your device and the computer.

Refer to the Samsung Kies help for more information.

Connecting with Windows Media Player

Ensure that Windows Media Player is installed on the computer.

1. Connect the device to the computer using the

USB cable.

2. Open Windows Media Player and sync music files.

Connecting as a Media Device

1. Connect the device to the computer using the

USB cable.

2. Open the notifications panel, and then touch Connected as a media device ➔ Media device (MTP)

Camera (PTP)

Tou ch Media Transfer Protocol (MTP) or not have any appropriate driver installed.

3. Transfer files between your device and the computer.

if your computer does not support

Upgrading the Device

The device can be upgraded to the latest software.

Note:

This feature may not be available depending on the

region or service provider.

Upgrading with Samsung Kies

Launch Samsung Kies and connect the device to the computer. Samsung Kies automatically recognizes the device and shows available updates in a dialogue box, if any. Click the Update button in the dialogue box to start upgrading. Refer to the Samsung Kies help for details on how to upgrade.

Caution!

Do not turn off the computer or disconnect the USB cable while the device is upgrading.

While upgrading the device, do not connect other media devices to the computer. Doing so may interfere with the update process.

Upgrading Over the Air

The device can be directly upgraded to the latest software by the firmware over-the-air (FOTA) service.

1. From a Home screen, touch

➔

General

tab ➔

About device ➔ Software update

➔

Update

Understanding Your Device 53

Apps

➔ Settings

Section 3: Accounts and Contacts

This section explains how to manage accounts and contacts.

Accounts

Your device can synchronize with a variety of accounts. With synchronization, information on your device is updated with any information that changes in your accounts.

•

Samsung Account

•

ChatON

•

Dropbox

•

: Add an Email Account to sync Contacts.

•

Evernote

•

Google

: Add your Google Account to sync your Contacts, Calendar,

and Gmail.

•

LDAP

: Add an LDAP Account to find entries in an LDAP directory

server.

•

Microsoft Exchange ActiveSync

sync Contacts, Calendar, and Email.

•

Server

: Add a Server to sync and access your data.

•

Facebook

•

Twitter

: Add a Twitter Account.

: Add your Samsung Account.

: Add your ChatON Account.

: Add your Dropbox Account.

: Add an Evernote Account.

: Add your Exchange Account to

: Add a Facebook Account to sync apps.

Setting Up Accounts

Set up and manage your synchronized accounts with the

Accounts

setting.

1. From a Home screen, touch

➔ General

2. Touch the account type.

3. Follow the prompts to enter your account credentials to

complete the set up process. Your tablet communicates with the appropriate account

servers to set up your account. When complete, your account displays in the screen.

tab ➔

Accounts ➔ Add account

Accounts

Apps

➔ Settings

area of the Settings

Your Google Account

In order to utilize your device to the fullest extent, you will need to create a Google Account when you first use your device. With a Google Account, Google applications will always be in sync between your tablet and computer.

If you need to create a Google account, follow these steps:

1. From a Home screen, touch

➔ General

2. Follow the prompts to sign into your existing account or

create a new account.

tab ➔ Accounts

Apps

➔

Add account

➔ Settings

➔ Google

Your Samsung Account

Create a Samsung Account for access to Samsung apps and services, such as Samsung Hub, Samsung Apps, Samsung Link, and much more.

1. From a Home screen, touch

➔ General

Samsung account

2. Follow the prompts to sign into your existing account or

create a new account.

tab ➔ Accounts

Apps

➔

Add account

➔ Settings

➔

Contacts

Store contact information for your friends, family, and colleagues to quickly access information or to send a message.

To ac c e s s Contacts:



From a Home screen, touch

Add a Contact

1. Touc h

pop-up displays.

2. To choose where the contact is stored, touch

an account. – or –

To uch more information, refer to “Setting Up Accounts” on page 54.

Contacts

➔

Add new account

to add a different account. For

Accounts and Contacts 55

Apps

➔

Create

. The Save contact to

Contacts

Device

3. Touch each field to enter information. Touch to

add another entry, or to remove an entry. Touch to choose a label.

•Picture

: Touch the picture icon to assign a picture to the new

contact.

•Name

: Enter the name. Touch to display additional name

fields.

• Phone

: Enter a phone number.

•Email

: Enter an email address.

•Groups

: Assign the contact to a group.

• Add another field

4. Touch

Save

: Add additional fields for the contact.

Updating Contacts

1. Touch

2. Touch a contact in the Contacts list to display it.

3. Touch

4. Touch any field to edit. For more information, refer to

“Add a Contact” on page 55.

Contacts

Edit

Deleting Contacts

1. Touch

2. Touch a contact in the Contacts list to display it.

3. Tou ch

Contacts

Delete

Contacts Display Options

There are various ways to display your contacts.

1. Touch

2. Touch the

view contacts in various ways:

•Groups

•Favorites

•Contacts

Contacts

Groups

tab,

Favorites

tab, or

Contacts

: Display contacts sorted into groups—such as Not assigned, Co-workers, Family, Friends, etc. The number of contacts in each group is displayed next to the group name. Touch a group name to show only contacts in that group. For more information, refer to page 59.

: Show only your favorite (or starred), contacts. For

more information, refer to

: Show all your contacts. Touch the

enter a keyword to list contacts that contain that keyword.

“Create a New Group”

“Favorites”

on page 61.

tab to

field and

3. While viewing

4. While viewing the Settings

Groups, Favorites

for options.

Contacts

for Contact settings.

, or

tab, touch

Contacts

, touch

Linked Contacts

Your device can synchronize with multiple accounts, including Google, Corporate Exchange, and other email providers. When you synchronize contacts from these accounts with your device, you may have multiple contacts for the same person.

Linking, or joining, imported contact records allows you to see all of a contact’s numbers and addresses together in a single contact entry. Linking also helps you keep your contacts updated, because any changes that your contacts make to their information in the respective accounts are automatically updated the next time you synchronize with that account.

➔

Linking Contacts

1. Touc h

2. Touch a contact in the Contacts list to display it.

3. To uch

4. Touch the contact you want to link. The linked contact’s

information is displayed with the original contact’s information.

5. Repeat Steps 3 and 4 to link other contacts.

Separating Contacts

1. Touc h

2. Touch a contact in the Contacts list to display it.

3. To uch

contacts is displayed.

4. To uch

Contacts

➔

Link contact.

Contacts

➔

Separate contact.

to separate a linked contact.

Accounts and Contacts 57

A list of linked

Sharing Contact Information

You can send a contact’s information using Bluetooth to other Bluetooth devices, or in an Email or Gmail as an attachment.

Note:

Not all Bluetooth devices accept contacts and not all devices support transfers of multiple contacts. Check the target device’s documentation.

Contacts

1. Touch

2. Touch

3. Touch

4. Touch a sending method, such as Bluetooth or email.

5. Follow the prompts to send the contact information.

Selected contact

contact, or touch

➔

Multiple contacts

Share namecard via

so share only the displayed

Importing and Exporting Contacts

To back up and restore your contacts, you can export your contacts list to a storage device (such as a PC), or import your contacts list from a storage device.

1. Use the USB cable to connect your device to the

storage device.

2. Touch

3. Tou ch

4. Touch an option and then follow the prompts.

Contacts

➔

Import/Export

Groups

Assign contacts to Groups to make searching for contacts faster or to quickly send messages to group members.

Create a New Group

Create a new group when you add or edit a contact.

1. Touch

2. Touch the

3. Tou ch

4. Touch the

5. Touch

touch selected contacts to the group.

6. Touch

Tip:

Contacts can belong to more than one group. While editing the contact, touch the additional groups.

Once you create a new group, the Contacts List can be set to display only the contacts in that group. For more information, refer to “Contacts Display Options” on page 56.

Contacts

Groups

Group name

Add member

Select all

Save

tab.

➔

Create

field enter a name.

. Touch individual contacts or

, then touch

Groups

Done

field to add

to add the

Adding Group Members

To add a contact to a group, just Edit a contact’s Group field. For more information, refer to “Updating Contacts” on page 56.

To add multiple contacts to a group:

Contacts

1. Touc h

2. To uch

3. To uch

4. To uch

5. Touc h Done to add the contacts to the group.

Groups

want to add members.

Add member

The contacts that can be added display.

Select all

and then touch the group to which you

or the name of each contact to add.

Accounts and Contacts 59

Removing Group Members

To remove contacts from a group:

1. Touch

2. Touch

want to remove members.

3. Tou ch

4. Touch

5. Touch Done to remove the contacts.

Contacts are removed from the group and the group name is removed from each contact’s

Contacts

Groups

and then touch the group from which you

Select all

➔

Remove member

or the name of each contact to remove.

Renaming a Group

1. Touch

2. Touch the

rename.

3. Tou ch

4. Touch the

5. Touch

Contacts

Groups

Group name

Save

tab and touch the group you want to

➔

Edit

field and enter a new name.

Group

field.

Deleting Groups

1. Touch

2. Touch individual groups or touch

3. Tou ch Group only (to delete only the group) or Group and group members (to delete both the group and the

group’s members).

Delete

Contacts

➔

Groups

tab ➔

Select all

Delete

, then touch

Favorites

Mark contact records with a gold star to identify them as favorites.

Mark a Contact as a Favorite

1. Touch

2. Touch a contact in the Contacts list to display it.

3. Touch the

Tip:

You do not have to edit the contact to mark it as a favorite.

View Favorites

There are two ways to view your favorites.

1. Touch

2. Touch the

displayed. – or –

Touch the list only your starred contacts that are being saved to your Google account.

Contacts

Star

so that it turns gold .

Contacts

Favorites

tab. Only your starred contacts are

Groups

tab, then touch

Starred in Android

Remove Favorites

Note:

1. Touc h

2. To uch

3. Touch individual contacts or touch

To remove the currently displayed contact your favorites list, touch the that it is no longer gold .

Done

to remove.

Contacts

➔

Favorites

tab.

➔

Remove from favorites

Select all

Star

next to the contact’s name so

Accounts and Contacts 61

. , then touch

Section 4: Messaging

This section describes how to send and receive messages and other features associated with messaging.

Types of Messages

Your device supports these types of messages:

•

Gmail

•

Hangouts

•

Google+

•

Google Messenger

•

ChatON

•

Twi tt er

Note:

Your Wi-Fi-only device does NOT support voice calling and messaging services. Please disregard any “dial” and “message” related menus because some Gmail options are identically set in all Android devices.

Gmail

Send and receive email with Gmail, Google’s web-based email service.



From a Home screen, touch

Google

folder ➔

Setting Up Your Gmail Account

If you did not set up a Google account during the initial configuration, the first time you launch Gmail, your device prompts you to set up your Google account.

1. Touch

2. Follow the prompts to sign in or create a new account.

The device communicates with the Google server to set up your account and synchronize your email. When complete, your Gmail displays in the Inbox.

Note:

You can use more than one Google account on your

device. To add another account, touch

➔

Gmail

Settings ➔ General

tab ➔

Gmail

Accounts

Apps

➔

Add account

Refreshing Your Gmail Account

Refresh your account to update your device from the Gmail servers.

1. Touch

2. While viewing your Inbox, drag your finger downward

across your messages.

Gmail

Gmail Settings

Use the Gmail Settings to configure your Gmail preferences.

1. Touch

2. Touch

Tip:

To uch

Gmail

➔ Settings

➔ Help

for more information.

for settings.

Composing and Sending Gmail

1. Touch

2. Tou ch

the message. While composing a message, touch

3. Touch

– or –

Gmail

Compose

for options.

SEND

to send this message.

, then touch fields to compose

To uch message.

➔ Save draft

to save a draft of this

Email

Use Email to view and manage all your email accounts in one application.



From a Home screen, touch

Configuring Email Accounts

You can configure Email for most accounts in just a few steps.

1. Touc h

2. The first time you set up an email account, at the Set

up email screen, enter an then touch – or –

For additional accounts, touch ➔

3. Follow the on-screen instructions to set up your email

account.

Add account

Apps

Email address

Messaging 63

➔

and

Password

➔ Settings

4. Touch

go to the Apps screen.

Note:

For Exchange ActiveSync accounts, the Activate device administrator? screen may appear. Read the information and touch

5. Enter an account name and Your name, if required.

6. Touch

The device communicates with the appropriate server to set up your account and synchronize your email. When complete, your email appears in the Inbox for the account.

Note:

To configure email account settings at any time, use

Account settings.

to go to the next screen or touch

Activate

to continue.

Done

Menu ➔ Settings

. Touch the account to display

Managing Your Email Accounts

You can view email you receive for all accounts in the

Combined view

individually.

1. Touch

2. Touch the

screen or you can view email accounts

drop-down menu at the top left of the

screen to select:

• Combined view

•<Account Name

: View all email in a combined inbox.

>: View email for the account.

Refreshing Your Email Account

Refresh your account to update your device from the Email servers.

1. Touch

2. In the Application Bar, touch

Refresh

Deleting Email Accounts

To delete an Email account:

1. Touch

2. Touch

Email Menu

➔ Settings

➔

Delete account

Email Settings

Use the Email Settings to configure your Email preferences.

Note:

Available settings depend on the email provider.

1. Touch Menu

2. Tou ch

General settings

•Display

open them.

• Composing and sending

while composing and sending email.

• Auto-advance

message. Choices are: Next email, Previous email, or Email list.

• Confirm deletions

•Priority senders

as a priority.

➔

Settings

, then touch

. The following options display:

: Set how email is shown in the email list and when you

: Set what functions are available

: Set the screen to show after deleting a

: Ask for confirmation before deleting email.

: Enter email addresses that you want treated

• Spam addresses

• Rules for filtering

names, address, or subject.

3. Touch an account to configure specific settings.

Available options depend on the account.

: Manage your spam address list.

: Create rules for filtering email based on

Composing and Sending Email

1. Touc h

2. If you have multiple accounts set up, choose an

account from the menu at the top of the screen.

3. To uch

recipients and the email text.

4. While composing a message:

•

5. Touch the body of the email to enter the text of your

email. Touch the text option buttons to edit and format your message text.

Compose

, then touch fields to enter

Touch displayed buttons to set Priority, Tracking options, Security options, and so on.

Touch

Attach

to add a file to the message.

Available options depend on the type of email account.

Messaging 65

Send

6. Touch

– or – Touch

to send the message.

Save

to save the email to the Drafts folder.

Hangouts

Previously known as Google Talk, Hangouts is an online place to meet friends and family, share photos, and host video calls. Conversation logs are automatically saved to a Chats area in your Gmail account.



From a Home screen, touch

Google

folder ➔

Apps

Hangouts

➔

Google+

Google+ makes messaging and sharing with your friends a lot easier. You can set up Circles of friends, visit the Stream to get updates from your Circles, use Messenger for fast messaging with everyone in your Circles, or use Instant Upload to automatically upload videos and photos to your own private album on Google+.



From a Home screen, touch

Google

folder ➔

Google+

Apps

➔

Messenger

With Google Messenger, you can bring groups of friends together into a simple group conversation, putting everyone on the same page. When you get a new conversation in Messenger, Google+ sends an update to your device.



From a Home screen, touch

Google

folder ➔ Messenger

Apps

➔

ChatON

A smart-messaging app that gives you a host of innovative ways to stay connected with all your friends and family, regardless of their device or platform. Use ChatON to send and receive instant messages from any device that has a mobile phone number.

1. From a Home screen, touch

If you are launching this application for the first time, follow the on-screen instructions to complete the account setup.

2. Enter and send your message.

Apps

➔

ChatON

Section 5: Multimedia

This section explains how to use the music features of your device including the Music app and the Music Player. Story Album, Flipboard, SketchBook for Galaxy, and WatchON are also described.

Listening to Music

You can listen to music by using your device’s built-in speakers, through a wired headset, or through a wireless Bluetooth stereo headset.

For more information, refer to “Bluetooth” on page 101.

Volume Key

Press the screen volume control, then touch and drag on the scale to set volume. You can also press the Volume Key to adjust playback volume.

on the side of the device to activate on-

Play Music

The Play Music contains a music player that plays other audio files that you copy from your computer or store online.

Note:

Some options described in this manual may not be

available until you sign in to your Google account.

music and

Google Play Music

Google Play Music is a Google service that gives you instant access to your personal music collection on the Internet and your compatible Android devices without the hassle of wires or syncing. For more information, visit

music.google.com

Accessing the Music App



From a Home screen, touch

Google

folder ➔

The Play Music app searches your online library and your device’s internal storage for music and playlists. This can take from a few seconds to several minutes, depending on the amount of new music added since you last opened the application.

Apps

Play Music

➔

Multimedia 67

Changing Library View

You can change the way you view the contents of your library.

1. Tou ch

2. Near the top-left of the Application bar, touch and

then touch

3. Touch and then touch an option to set whether to

view

4. On the My Library screen, touch an option to set how

you view your library. The choices are:

Play Music

Listen Now, My Library

All music or On device

GENRES, ARTISTS, ALBUMS

, or

Playlists

, or

Play Music Menu

While viewing a Play Music main screen:



To uch instructions to use the following options:

• Settings

•Help

and follow the on-screen

: Configure Play Music settings.

: Get more information about the Play Music app.

SONGS

Play Music Options

Options are available for playing songs, albums, or playlists:

1. Tou ch

Play Music

2. Touch an album or song.

3. Touch the

Options display depending on the item view.

To play a song:

1. Tou ch

2. Touch a song in your library to listen to it.

– or – While viewing a list of songs, touch

song and touch – or –

While viewing a list of albums, artists, playlists, or genres, touch

Add to queue

Play Music

Options

for an item to display options.

Add to queue

Options

for an item and touch

Options

for a

Shopping for Music at the Play Store

To visit the Google Play Store where you can find and buy music:

1. From a Home screen, touch

➔

Play Store

Music

2. Touch

The Google Play Store music section displays.

To view information about finding and buying music:

1. Touch

2. Touch

The Google Play Music help screen displays.

Play Music

➔

Help

Apps

Making Online Music Available Offline

In addition to playing the music that you add to your online library, you can play music stored on your device’s internal storage. Then you can listen to music when you have no Internet connection. To do this, make some of your online music available offline.

Tip:

You can also copy music directly from your computer to your device. For more information, refer to “Synchronizing with Windows Media Player” on page 106.

To make your online music available offline on your device:

Play Music

➔

1. Touc h

2. Change your library view to Albums, Artists, or

Playlists. For more information, refer to “Changing Library View” on page 68.

3. If you have signed in to your Google account, touch

information about listening to music offline.

Help ➔ Listen to music offline

Multimedia 69

to view

Music Player

Music Player plays songs stored on your tablet or an installed memory card.

To access Music Player:

Apps

➔

1. From a Home screen, touch

The Music Player application searches your device’s internal storage or on an installed memory card for music and playlists. This can take from a few seconds to several minutes, depending on the amount of new music added since you last opened the application. It then displays your music in several ways.

2. Touch a tab, such as

on, to change the way you view the contents of your library.

3. Touch the Music application icon at the top-left of

the Application bar to return to the previous Music screen.

Songs, Playlists, Albums

Searching for Music

To find music in your library:

1. Tou ch

2. Touch

name of an artist, album, or song.

Music

and use the keyboard to type the

Music

, and so

Music Player Options and Settings

To use Music Player options and configure settings:

1. Tou ch

2. Tou ch

• List view / Thumbnail view

•Delete

• Scan for nearby devices

• Settings

•End

Music

to display the following options:

thumbnail format.

: Delete a song, an album, or every song or album.

nearby devices.

: The following settings display:

–

SoundAlive

–

Adapt Sound

–

Play speed

–

Smart volume

–

Voice control

–

Lyr ics

–

Music auto off

automatically by touching one of the time values.

: Configure SoundAlive.

: Enhance sound quality.

: Decrease or increase play speed.

: Automatically adjust volume to surroundings.

: Use voice commands to control playback.

: Display the lyrics of the song, if available.

: Set the option Off or set your music to turn off

: Close the Music Player app.

: View your music in a list or

: Discover and connect directly to

Managing Playlists

To create, manage, or delete a playlist:



Tou ch

Creating a Playlist



Tou ch enter a name for the playlist.

Renaming a Playlist

1. Touch the

2. Touch a playlist, touch

the keyboard to enter a new name for the playlist.

Music

Create playlist

Playlists

tab.

and use the keyboard to

➔ Edit title

and use

Adding Songs to or Removing Songs from Playlists

1. To uch

– or – To uch

All songs are displayed.

2. To uch Add all

– or – To uch

3. Touc h

Changing the Order of a Playlist

1. Touc h th e

2. Touc h

3. Touch the grid for an entry and drag the entry to a

new position in the list.

4. To uch

Create playlist

Playlists

Add music

next to each song you want to add or next to

to add all songs to the playlist.

to remove a song from the playlist.

Done

Playlists

Change order

Done

to change the order and save the playlist.

and touch a playlist.

, touch a playlist, and then touch .

to save the playlist.

tab and touch a playlist.

Multimedia 71

Playing a Playlist

1. Touch the

2. Touch

3. Touch a song to start playing the playlist at that song.

Deleting a Playlist

1. Touch the

2. Touch

3. Touch the box next to

Playlists

tab.

Favorites, Most played, Recently played

Recently added

created.

then touch

, or touch a playlist title that you

Playlists

tab and touch a playlist.

Menu ➔ Remove

Select all

, touch

Remove

Playing Music

To play a song:

Music

1. Tou ch

2. Touch a song or touch an album or genre and then

touch a song in the list of songs on the album. The song you touch starts to play. The tracks in the

current list play in order until you reach the end of the list (unless you choose a repeat option). Otherwise, playback stops only if you stop it, even when you switch applications.

, or

, and

Accessing the Music Player

If you navigate away from the Music Player application and music is playing, the Music notification icon is displayed in the System Bar.

You can change songs or easily return to the Music Player:

1. Touch the top of the screen and swipe downward.

The Notification Panel displays.

2. Touch the song thumbnail to display the Music Player.

You can also pause and resume playback and skip to the next or previous song in the panel. For more information, refer to “Notifications” on page 39.

Music Player Controls

When a song is playing, the Music Player screen displays various controls are available.

1. Tou ch

2. Touch a song or playlist to begin playback.

The music player displays below (portrait mode) or to the right (landscape mode) of the music listing.

3. Touch the song thumbnail to enlarge the music player.

Music

and

Music Player Controls

7 8 9 10 11

During playback, use the sound and playlist controls:

1. Scan DLNA-enabled devices.

2. Touch to display the volume control, then touch and

drag on the scale to set volume. You can also press the Volume Key on the side of the device to adjust playback volume.

3. Touch to view and set SoundAlive options.

4. Set the file as your favorite song.

5. Turn on shuffle.

6. Change the repeat mode.

7. Hide the music player screen.

8. Restart the currently-playing song or skip to the

previous song. Touch and hold to move backwards quickly.

9. Pause and resume playback.

10. Skip to the next song. Tap and hold to move forwards

quickly.

11. Open the playlist.

Multimedia 73

Options While Playing a Song

There are various options and controls available while a song is playing:

1. Tou ch

a song.

2. Touch the music player to enlarge it.

3. Touch

• Add to playlist

• Via Bluetooth

• Play via Group Play

• Scan for nearby devices

Music

playlist.

device.

Group Play.

nearby devices.

, touch a song or an album, and then

to display the following options:

: Add the song to a new playlist or an existing

: Play the current song by using a Bluetooth

: Share the current song by using

: Discover and connect directly to

•Details

: View song details.

• Set as alarm tone

• Settings

refer to page 70.

•End

: This option returns you to the home screen.

: Use the current song as an alarm tone.

: Displays Music Player settings. For more information,

“Music Player Options and Settings”

Playing Music by Mood

Play music grouped by mood. The playlist is automatically created by the device. When a new song is added:

1. Touch

2. Tou ch

multiple cells by dragging your finger.

Music

Library update

Music square

➔

Music square

and select a cell of mood. Or select

➔

Story Album

Use this application to create your own digital album to keep your stories by organizing the images neatly and automatically.

Note:

The Story Album app must be installed before you can use it. Touch OK on the pop-up and follow the on-screen instructions.

To a ccess St ory Album :

1. From a Home screen, touch Samsung

folder ➔

2. Touch

Story Album.

Menu ➔ Help

Apps

➔

Story Album

to learn more about

Creating Story Albums

Create story albums by selecting images from Gallery or images sorted by tag information.

To create a story album manually:

1. Touch Create album.

The Create album screen displays.

2. To uch From Gallery to add pictures from the Gallery.

– or – To uch By tag information to create the story album

automatically. Select criteria, and then touch Find pictures. Enter a title for the album, select a theme, and then touch Create album.

Multimedia 75

Creating Recommended Albums

When you take photos at one location, the device automatically sorts your photos into albums based on your specified criteria and suggests making the new albums.



To uch

➔ Settings ➔ Home city, and then

set a method for recognizing your location. Select an album type and set a minimum number of photos.

Viewing Story Albums

1. Select a story album. The cover image appears on the

first page. Scroll left or right to view images in the story album.

2. On a page of the album, touch

following functions. The available options vary depending on the page.

• Edit title

: Rename the album.

• Change theme

•Change cover image

: Change the theme for the album.

: Change the cover image of the album.

and use the

•Slideshow

: Start a slideshow with the images in the

current album.

•Share via

•Print

: Send the album to others.

: Print the album via a USB or Wi-Fi connection. Some

printers may not be compatible with the device.

• Order photo book

• Export Album

• Add content

• Remove content

•Edit

: Change the layout of the current page.

• Delete page

: Place an order for a printed album.

: Export the album to other storage locations.

: Add more content to the current page.

: Delete content on the current page.

: Delete the current page.

Managing Story Albums

1. Touch and hold a story album.

2. Touch one or more story albums or touch the

# selected

selected

tab ➔

Select all

Share via

3. Touch

Album file (.scc).

4. Touch

to create a PDF file or a Story

Delete

to delete the selected story albums.

Editing Images

1. Touch the image of the page in an album.

The following options are available:

Add a caption.

Send the image to others.

Delete the image.

Select among various effects that are available.

2. Touch

functions:

•Slideshow

settings.

• Set as cover

•Rotate left

•Rotate right

, and then use the following

: Start a slideshow or change the slideshow

: Set the image as an album cover image.

: Rotate the image counter-clockwise.

: Rotate the image clockwise.

Flipboard

Use this application to access your personalized magazines.

1. From a Home screen, touch Galaxy Plus

2. To uch

account information or your Flipboard account to view your content and social networks. – or –

To start your Flipboard, touch and swipe to the left, select news topics, and then

Build Your Flipboard

touch

3. Select a cover story or a topic, flick through the

Flipboard pages, and then select an article to read. While reading an article, use the following icons:

➔

Tap to sign in

Go to the previous page.

Share the article with others.

Set the article as your likes in Flipboard.

Create an account for Filpboard to make your own magazine.

to sign in with your Facebook

Flipboard

FLIP

Apps

➔

on the greeting page

Multimedia 77

SketchBook for Galaxy

Use this application to create a quick concept or sketch out your idea for a project.

Note:

The SketchBook app must be installed before you can use it. Touch OK on the pop-up and follow the on-screen instructions.

Apps

1. From a Home screen, touch Galaxy Plus

folder ➔

2. Use artistic tools to draw and paint your digital art. The

image is saved in Gallery.

➔

SketchBook for Galaxy

1. Create and save a sketchbook.

2. Display SketchBook information and settings.

3. Undo the last action.

4. Redo the last action.

5. Use SketchBook tools.

6. Change the brush types and settings.

7. Change a brush color.

8. Add or delete layers.

9. Register the frequently-used tools.

WatchON

Enjoy all of your favorite movies and TV shows with WatchON.

Important!

Before you use WatchON, verify that you have an active Internet connection available. For more information, refer to “Wi-Fi” on page 97.

Notes

1. Before beginning your initial WatchON application

setup, make sure that your TV is turned off.

2. Sign into your Samsung account before using

WatchON. For more information, refer to “Your Samsung Account” on page 55.

Initial Configuration

1. From a Home screen, touch

The Privacy policy displays.

2. Read the Privacy policy, check the accept the terms of the above privacy policy

touch

Confirm

The Set up WatchON screen displays.

3. To uch

4. Follow the on-screen instructions.

Set up WatchON

WatchON Menu

1. From a Home screen, touch

2. To uch

• Sign in

WatchON experience.

•Settings

on-screen instructions.

•Help

: Displays Samsung WatchON help information and a

for the following options.

: Sign in to your Samsung account to improve your

: Configure Samsung WatchON settings. Follow the

Apps

➔

WatchON

I have read and

box, and

Apps

➔

WatchON

Multimedia 79

Section 6: Internet and Social Networking

This section describes the various Internet and social networking applications available on your device such as Google and Voice Search, Google+, Internet, Local, Maps, Navigation, Google Play Books, Play Magazines, and YouTube.

Google Search

Search the internet using the Google search engine.

1. From the main Home screen, touch .

– or –

Apps

From a Home screen, touch

Google

folder ➔

2. Use the keyboard to enter search criteria to display

matching searches. – or –

Touch and speak the search criteria slowly and clearly. Google searches for the information and displays results.

Suggestions display below the text entry area.

Google

➔

3. Touch a suggestion to search for that term.

– or – Touch on the keyboard to start the search. A browser window displays the search results.

To use Voice Search directly:

Apps

1. From a Home screen, touch Google

folder ➔

2. Speak the search criteria slowly and clearly. Google

searches for the information and displays results. If criteria is not understood, it displays

to retry speaking the search words.

Voice Search

➔

Retry

. Touch the

Internet

Your device is equipped with a full HTML browser that allows you to access the Internet.



From a Home screen, touch

Navigating the Internet

The following options are available for Internet navigation.

Command Keys



Tou ch



Touch and hold



Tou ch



Tou ch

Touching and Dragging

•

Touch and drag your finger on the screen to navigate pages and

to reposition pages within the screen.

Entering Text in a Field

•

While browsing, touch a text field to display the virtual QWERTY

keyboard to enter text.

Back

or to return to the previous page.

Back

Forward

to go forward to a recent page.

Refresh

to reload the current page.

Apps

➔

Internet

display browser History.

Zoom

•

Touch the screen twice to zoom in or out.

•

Use two fingers, such as your index finger and

thumb, to zoom out by making an inward pinch motion on the screen. To zoom in, make an outward motion by sweeping your fingers out.

Tip:

For convenient browsing, you can rotate the device to landscape mode.

Selecting Items On a Page

While browsing, use gestures and menus to navigate:

•

Touch an item to select it.

•

Touch a hyperlink to follow the link.

•

Touch and hold on a hyperlink or an image for options.

Internet and Social Networking 81

Using Browser Windows

You can have multiple windows open at one time and easily switch between windows.

1. Tou ch

2. To open a new window, touch at the top of the

screen.

3. To switch to another open window, touch its tab at the

top of the screen.

4. To delete an open window, touch the tab at the top of

the screen, and then touch .

Internet

Entering a URL

Access a website quickly by entering the URL.

Internet

1. Tou ch

2. Touch the

the URL using the virtual QWERTY keyboard. As you enter characters, potential matches display.

Note:

Use the

necessary.

URL

field at the top of the screen, then enter

Delete

key to clear the URL field, if

3. Touch a match to complete the URL.

– or –

Continue entering characters and touch the load the page.

key to

Creating Bookmarks

While browsing, bookmark a site to quickly access it later.

1. Touch

2. Browse to a website, touch

the required information, and touch A gold star displays on the Bookmarked page.

Internet

Add bookmark

Save

, enter

Internet Menu

While viewing a webpage:



Tou ch

To configure web settings:



Tou ch Follow the on-screen instructions.

for options.

Menu ➔ Settings

Section 7: Camera and Video

Camera

Use this application to take photos or videos.

Gallery

Use camera.

Note:

Camera Etiquette

•

to view photos and videos taken with the device’s



From a Home screen, touch

The camera automatically shuts off when unused.

Make sure that the lens is clean. Otherwise, the device may not work properly in some modes that require high resolutions.

Do not take photos or videos of other people without their

permission.

Do not take photos or videos where legally prohibited. Do not take photos or videos in places where you may violate

other people’s privacy.

Apps

➔

Camera

Using the Camera

To access the Camera:

1. Touc h

2. To uch

Camera

If a memory card is inserted, the Storage location pop-up displays.

to change the storage location to memory card. – or –

Cancel

To uch pictures and videos.

The Camera screen displays.

to use the device storage for storing

Camera and Video 83

1. Switch between the front and rear camera.

2. Switch to dual camera mode.

3. View more options.

4. Display current mode.

5. Record video button.

6. Camera button.

7. Shooting mode.

8. Open Gallery to view photos and videos.

9. Select an available effect.

Taking Photos

1. Touch the image on the preview screen where the

camera should focus. When the subject is in focus, the focus frame turns

green.

2. Touch to take the photo.

Shooting Mode

Several photo effects are available.



Tou ch

MODE

, and then scroll up or down the screen at

the right side of the screen.

•Auto

: Use this to allow the camera to evaluate the surroundings

and determine the ideal mode for the photo.

• Beauty face

: Take a photo with lightened faces for gentler

images.

•Best photo

: Take a series of photos, and then save the

best one.

• Best face

• Sound & shot

Note:

While taking photos in this mode, sound is recorded by

the internal microphone.

•Drama

: Use this to take multiple group shots at the same

time and combine them to create the best possible image.

–

Touch to take multiple photos. To get the best shot, hold the camera steady and remain still while taking photos. When

Gallery

opens, touch the yellow frame on each face, and

choose the best individual pose for the subject. After choosing a

Save

pose for each individual, touch single photo, and save it.

: Use this to take a photo with sound.

–

Touch to take a photo. The device records a few seconds of audio after taking a photo.

: Use this to take a series of photos and combine them to create an image that shows trails of the movement. To get the best shot, follow these tips. The device may not take

photos properly in other shooting conditions.

–

Hold the camera steady and remain still while taking photos.

–

Take photos of a subject that is moving in one direction.

to merge the images into a

–

Take photos with backgrounds that are free of moving objects.

–

Avoid taking photos of a subject and background with similar colors.

–

Avoid taking photos of a subject that is too close or too far away to fit within the viewfinder or that is too long such as a bus or a train.

• Rich tone (HDR)

in bright and dark areas.

•Eraser

the background.

–

Touch to take a series of photos. The device erases traces of movement from a moving subject. To restore the original photo, touch Show moving objects, and then touch the highlighted area.

To get the best shot, follow these tips:

–

Hold the camera steady and remain still while taking photos.

–

Avoid taking photos of a subject and background with similar colors.

: Use this to take photos without losing details

: Use this to erase the movements of moving subjects in

Camera and Video 85

–

When taking photos of a subject that is moving very little or moving a great deal, the camera may not recognise all of the movements.

–

If there are multiple subjects moving in the background, the camera may not recognise all of the movement.

• Panorama

•Sports

•Night

: Take a photo composed of many photos strung

together.

To get the best shot, follow these tips:

–

Move the camera slowly in one direction.

–

Keep the camera’s viewfinder within the guide frame.

–

Avoid taking photos of a subject in front of unrecognizable backgrounds, such as empty skies or plain walls.

: Use this setting for fast-moving subjects.

: Use this setting for images taken in darker conditions.

Panoramic Photos

A panoramic photo is a wide landscape image consisting of multiple shots.

1. Tou ch

2. Touch and move the camera in one direction.

Applying Filter Effects

Use the filter effects to take unique photos or videos.



MODE

➔

Panorama

When the blue frame aligns with the viewfinder, the camera automatically takes another shot in a panoramic sequence. To stop shooting, touch . If the viewfinder is out of the direction, the device stops shooting.

Touch and select a filter effect. The available options vary by mode.

Recording Videos

To r ecord a v ideo:



Touch to take a video. To pause recording, touch

. To stop recording, touch .

While recording, use the following actions:



To change the focus, touch where you want to focus. To focus on the centre of the screen, touch .



To capture an image from the video while recording, touch .

Recording Mode



Tou ch the recording mode.

•Normal

• Limit for email

• Fast motion

Options

➔

: Use this mode for normal quality.

: Use this mode to lower quality for sending via

messages.

: Use this mode when recording action scenes.

Recording mode

to change

Zooming In and Out

Use one of the following methods:



Use the

Volume

button to zoom in or out.



Spread two fingers apart on the screen to zoom in, and pinch to zoom out.

Note:

The zoom in and out effect is available when using the

zoom feature while shooting video.

Camera and Video 87

Dual Camera Mode

OFF

When you take a landscape photo with the rear camera, the photo or video captured by the front camera appears in an inset window, or vice versa. Use this feature to take a beautiful landscape photo and a self-portrait simultaneously.



Touch to switch to dual camera mode. Touch

to take a photo or touch to take a video.

1. Tap to resize it or move the location.

Note:

You can record videos in dual camera mode for up to 5 minutes in Full HD and up to 10 minutes in HD. While taking videos in this mode, sound is recorded by the internal microphone.

Share Shot



Touch following:

•Share shot

• Buddy photo share

• ChatON photo share

• Remote viewfinder

Options

➔ , and then select one of the

: Send a photo directly to another device via Wi-Fi

Direct.

: Set the device to recognise a person’s

face that you have tagged in a photo and send it to that person.

: Send a photo to another device via

ChatON.

: Set a device to control the camera

remotely.

Controlling the Camera Remotely

OFF

Set a device as a viewfinder to control the camera remotely. Touch

➔ ➔

Remote viewfinder

Options

connect the device and the camera using Wi-Fi Direct. Touch to take a photo remotely using the device as a viewfinder.

Configuring Settings for Camera



Tou ch ➔ to configure settings for Camera. Not all of the following options are available in both still camera and video camera modes. The available options vary depending on the mode used.

• Photo size/ Video size

resolution for higher quality. But it takes up more memory.

• Burst shot

: Take a series of photos of moving subjects.

• Tap to take pics

take photos.

• Face detection

help you take photos of them.

: Select a resolution. Use higher

: Touch the image on the preview screen to

: Set the device to recognise people’s faces and

, and then

• Metering

: Select a metering method. This determines how light values are calculated. Centre-weighted measures background light in the centre of the scene. Spot measures the light value at a specific location. Matrix averages the entire scene.

•ISO

: Select an ISO value. This controls camera light sensitivity. It is measured in film-camera equivalents. Low values are for stationary or brightly-lit objects. Higher values are for fastmoving or poorly-lit objects.

• Video stabilization

: Activate or deactivate anti-shake. Anti-

shake helps focus when the camera is moving.

• Auto night detection

: Set the device to automatically detect darker conditions and adjust the brightness of the photo without the flash.

•Save as

: Set the device to delete the original photo when

taking photos with rich tone mode.

Camera and Video 89

•Location tag

Note:

To improve GPS signals, avoid shooting in locations where the signal may be obstructed, such as between buildings or in low-lying areas, or in poor weather conditions.

Tip:

Your location may appear on your photos when you upload

them to the Internet. To avoid this, deactivate the GPS tag setting.

•Review

•Volume key

the shutter or zoom function.

•Timer

• White balance

images have a true-to-life color range. The settings are designed for specific lighting situations. These settings are similar to the heat range for white-balance exposure in professional cameras.

: Attach a GPS location tag to the photo.

: Briefly display photos taken.

: Set the device to use the Volume button to control

: Use this for delayed-time shots.

: Select an appropriate white balance, so

•Exposure value

how much light the camera’s sensor receives. For low light situations, use a higher exposure.

• Guidelines

when selecting subjects.

•Flash

• Voice control

commands.

• Contextual filename

tags. Activate this to use Tag Buddy in Gallery and Story Album.

• Save as flipped

the original scene.

•Storage

• Reset

: Change the exposure value. This determines

: Display viewfinder guides to help composition

: Activate or deactivate the flash.

: Set the camera to take photos with voice

: Set the camera to display contextual

: Invert the image to create a mirror-image of

: Select the memory location for storage.

: Reset the camera settings.

Shortcuts

Reorganize shortcuts for easy access to the camera’s various options.

1. Touch

2. Touch and hold an option and drag it to a slot at the top

of the screen. The other icons can be moved within the list by touching and dragging them.

➔

Edit

quick settings

Gallery

Use this application to view images and videos.



From a Home screen, touch

Note:

Some file formats are not supported depending on the software installed on the device. Some files may not play properly depending on the encoding method used.

Apps

➔

Gallery

Viewing Images

Launching Gallery displays images by creation date.



To sort images by location, people, or other categories, touch

Time

and select a category. Albums displays

images by folder.



In a folder, images are displayed by creation date. Select an image to view it in full screen.



Scroll left or right to view the next or previous image.

Zooming In and Out

Use one of the following methods to zoom in an image:



Double-touch anywhere to zoom in.



Spread two fingers apart on any place to zoom in. Pinch to zoom out, or double-tap to return.

Camera and Video 91

Viewing Images Using the Motion Feature

Use the motion feature to execute a function with particular motion.

1. On the Applications screen, touch Controls

tab ➔

Motions

, drag the

right, and then turn on the switch for each feature.

2. To stop using a motion feature, drag the to the left.

Settings

Motions

➔

switch to the

Motions

switch

Playing Videos

Video files show the icon on the preview.



Select a video to watch it and touch .

Trimming Segments of a Video

1. Select a video, and then touch .

2. Move the start bracket to the desired starting point,

move the end bracket to the desired ending point, and then save the video.

Editing Images



When viewing an image, touch following functions:

•Edit

: Use Photo Editor to edit your photo.

•Favorite

: Add to the favorites list.

•Slideshow

• Photo frame

• Photo note

•Copy to clipboard

•Print

•Rename

: Start a slideshow with the images in the current

folder.

: Use this to add a frame and a note to an image.

The edited image is saved in the Photo frame folder.

: Use this to write a note on the back of the image.

Touch to edit the note.

: Copy to clipboard.

: Print the image via a USB or Wi-Fi connection. Some

printers may not be compatible with the device.

: Rename the file.

and use the

• Buddy photo share

tagged in the image.

•Rotate left

•Rotate right

•Crop

•Set as

•Details

•Settings

: Rotate counter-clockwise.

: Rotate clockwise.

: Resize the blue frame to crop and save the image in it.

: Set the image as wallpaper or a contact image.

: View image details.

: Change the Gallery settings.

Modifying Images



When viewing an image, touch use the following functions:

•Rotate

: Rotate the image.

•Crop

: Crop the image.

•Color

: Adjust the saturation or brightness of the image.

• Effect

: Apply effects to the image.

• Sticker

: Attach stickers.

•Drawing

: Draw on the image.

•Frame

: Apply frames to the image.

: Send the image to a person whose face is

➔

Edit

and

Favorite Images



When viewing an image, touch to add the image to the favorites list.

Deleting Images

Use one of the following methods:



In a folder, touch images by ticking, and then touch



When viewing an image, touch

➔

Select item

Delete

Sharing Images

Use one of the following methods:



In a folder, touch images by ticking, and then touch to send them to others or share them via social network services.



When viewing an image, touch to send it to others or share it via social network services.

➔

Select item

Camera and Video 93

➔

Delete

Favorite

, select

Setting as Wallpaper



When viewing an image, touch set the image as wallpaper or to assign it to a contact.

➔

Set as

Tagging Faces

1. Touch yellow frame appears around the recognized face.

2. Touch the face, touch a contact.

3. When the face tag appears on an image, touch the face tag and use available options, such as sending messages.

Note:

Face recognition may fail depending on the face angle, face size, skin color, facial expression, light conditions, or accessories the subject is wearing.

➔

Settings ➔ Tags ➔ Face tag

Add name

, and then select or add

. A

Using Tag Buddy

Video

Use this application to play video files.

Note:



Tou ch and then drag the Tag buddy switch to the right to display a contextual tag (weather, location, date, and person’s name) when opening an image.



From a Home screen, touch

Some file formats are not supported depending on the device's software. Some files may not play properly depending on the encoding method used.

➔

Settings ➔ Tags ➔ Tag buddy

Apps

➔

Video

Playing Videos

Select a video to play.

4 5 6 7 8

1. Scan DLNA-enabled devices.

2. Adjust the volume.

3. Move forwards or backwards by dragging the bar.

4. Change screen ratio.

5. Restart the current video or skip to the previous video.

Touch and hold to move backwards quickly.

6. Pause and resume playback.

7. Skip to the next video. Tap and hold to move forwards

quickly.

8. Switch to floating screen mode.

Deleting Videos



Tou ch

and then touch

➔

Delete

, select videos by ticking,

Sharing Videos

To uch touch

➔

Share via

, select videos by ticking,

Done

, and then select a sharing method.

Using Popup Video Player

Use this feature to use other applications without closing the video player.



While watching videos, touch to use the pop-up player.



Spread two fingers apart on the screen to enlarge the player or pinch to reduce it.



To move the player, drag the player to another location.

Purchasing Videos

Scroll the screen to the left or right, and then select a video.

Camera and Video 95

YouTube

Use this application to watch videos from the YouTube website.



From a Home screen, touch

Watching Videos

Touch the returned search results to watch a video.

Touch to display full screen.

, and then enter a keyword. Select one of

Apps

➔

YouTube

1. Add the video to the playlist.

2. Send the URL to others.

3. Search for videos.

4. Pause or resume playback.

5. Change display quality.

6. Move forwards or backwards by dragging the bar.

7. Exit full screen.

Sharing Videos



Select the video to view, touch , and then select a sharing method.

Uploading Videos



Select your account, touch , select a video, enter information for the video, and then touch

UPLOAD

5 6

Samsung Note 10.1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Section 1: Getting Started

Understanding This User Manual

Battery

Turning Your Device On and Off

Setting Up Your Device

Task Manager

Memory Card

Galaxy Tab Accessories

Securing Your Device

Holding the Device

Adjusting the Volume

Switching to Silent Mode

Troubleshooting

Section 2: Understanding Your Device

Features

Front and Sides

Home Screen

Navigating Your Device

Using the Touch Screen

SPen

Samsung Smart Pause

Samsung Smart Scroll

Activating Multi Window

Notifications

Notifications Panel

Indicator Icons

Primary Shortcuts

Other App Shortcuts

Widgets

App Shortcuts

Folder s

Wallpapers

Apps Screen

Help

Entering Text

Connecting to a Wi-Fi Network

Setting Up Accounts

Transferring Files

Upgrading the Device

Section 3: Accounts and Contacts

Accounts

Your Google Account

Your Samsung Account

Contacts

Groups

Favorites

Section 4: Messaging

Types of Messages

Gmail

Email

Hangouts

Google+

Messenger

ChatON

Section 5: Multimedia

Listening to Music

Play Music

Music Player

Story Album

Flipboard

SketchBook for Galaxy

WatchON

Section 6: Internet and Social Networking

Google Search

Internet

Section 7: Camera and Video

Camera

Zooming In and Out

Gallery

Video

YouTube
