Samsung MX-J630/ZA User Manual

MX-J630

MiNi Hi-Fi Component Audio

System

MP3-CD/WMA-CD/CD-R/RW Playback

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service,

please register your product at

www.samsung.com/register

This Nanum Gothic Eco font is provided by NAVER.

English 3

Safety Warnings

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER­SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OPEN

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT AND INSERT FULLY.

WARNING

To reduce the risk of fire or electric shock, do

•

not expose this appliance to rain or moisture.

TO PREVENT THE SPREAD OF

•

FIRE, KEEP CANDLES AND
OTHER ITEMS WITH OPEN
FLAMES AWAY FROM THIS
PRODUCT AT ALL TIMES.

This product contains chemicals known to

•

the State of California to cause cancer and
reproductive toxicity.

FCC NOTES (for U.S.A)

This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable
protection against harmful interference in
a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on.
If interference is present, the user is encouraged
to try to correct the interference by one or more
of the following measures:

Reorienting or relocating the receiving

•

antenna.
Increasing the separation between the

•

equipment and receiver.
Connecting this equipment to an outlet that

•

is on a different circuit than the one the
receiver is connected to.

Consulting the dealer or an experienced

•

radio/TV technician for help.

This symbol indicates “dangerous
voltage” inside the product that presents
a risk of electric shock or personal
injury.

This symbol indicates important
instructions accompanying the product.

This class B digital product meets all
requirements of the Canadian Interference ­Causing Equipment Regulations.

CLASS 1 LASER PRODUCT

This Compact Disc player is classified as a CLASS
1 LASER product. Use of controls, adjustments
or performance of procedures other than
those specified herein may result in hazardous
radiation exposure.

Complies with 21CFR 1040.10 except for
deviations pursuant to Laser Notice No. 50,
dated June 24, 2007.

DANGER :

VISIBLE AND INVISIBLE LASER RADIATION

•

WHEN OPEN. AVOID DIRECT EXPOSURE TO
BEAM. (FDA 21 CFR)

CAUTION :

CLASS 3B VISIBLE AND INVISIBLE LASER

•

RADIATION WHEN OPEN. AVOID EXPOSURE
TO THE BEAM. (IEC 60825-1)

THIS PRODUCT UTILIZES A LASER. USE

•

OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE. DO
NOT OPEN THE COVER AND DO NOT REPAIR
YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.

CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LÁSER CLASE 1

2 English

Important Safety Instructions

Read these operating instructions carefully before
using the unit. Follow all the safety instructions
listed below. Keep these operating instructions
handy for future reference.

1.

Read these instructions.

2.

Keep these Instructions.

3.

Heed all warnings.

4.

Follow all instructions.

5.

Do not use this apparatus near water.

6.

Clean only with a dry cloth.

7.

Do not block any ventilation openings.

Install in accordance with the manufacturer's
instructions.

8.

Do not install near any heat sources such

as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.

9.

Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement of
the obsolete outlet.

10.

Protect the power cord from being walked

on or pinched particularly at plugs, near wall
outlets, and the point where they exit from the
apparatus.

11.

Only use attachments and accessories specified

by the manufacturer.

12.

Use only with the cart,

stand, tripod, bracket,
or table specified by the
manufacturer, or sold with
the apparatus. When a cart
is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

13.

Unplug this apparatus during lightning storms

or when unused for long periods of time.

14.

Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has
been damaged in any way, such as when the
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.

Precautions

Ensure that the AC power in your house

•

matches the requirements listed on the
identification sticker located on the back of
your product.
Install your product horizontally, on a suitable

•

base (furniture), with enough space around it
for ventilation (3 - 4 inches/7.5 - 10 cm).
Do not place the product on amplifiers or other

•

equipment which may become hot. Make sure
the ventilation slots are not covered.
Do not stack anything on top of the product.

•

Before moving the product, ensure the Disc

•

Insert Slot is empty.
To turn off the product completely, disconnect

•

the AC plug from the wall outlet. Disconnect
the AC plug from the wall outlet if you will be
leaving the device unused for a long period of
time.
During thunderstorms, disconnect the AC plug

•

from the wall outlet. Voltage peaks due to
lightning could damage the product.
Do not expose the product to direct sunlight

•

or other heat sources. This could cause the
product to overheat and malfunction.
Protect the product from moisture and excess

•

heat and equipment creating strong magnetic
or electric fields (i.e. speakers.).
Disconnect the power cable from the AC wall

•

outlet if the product malfunctions.
This product is for personal use only. It is not

•

intended for industrial use.
Condensation may occur if your product or a

•

disc has been stored in cold temperatures. If
transporting the product during the winter,
wait approximately 2 hours until the product
has reached room temperature before using.
The batteries used with this product contain

•

chemicals that are harmful to the environment.
Do not dispose of batteries in the general
household trash.
Place the loudspeakers at a reasonable distance

•

on either side of the system to ensure good
stereo sound.
Direct the loudspeakers towards the listening

•

area.
Do not expose this apparatus to dripping or

•

splashing. Do not place objects filled with
liquids, such as vases, on the apparatus.
To turn this apparatus off completely, you

•

must disconnect it from the wall outlet.
Consequently, the wall outlet and power plug
must be readily accessible at all times.
Use only a properly grounded plug and

•

receptacle.

- An improper ground may cause electric shock
or equipment damage. (Class l Equipment
only.)

English 3

English 5

Disc Storage & Management

Holding Discs

•

- Fingerprints or scratches on
a disc may reduce sound
and picture quality or cause
skipping.

- Avoid touching the surface of a disc where
data has been recorded.

- Hold the disc by the edges so that
fingerprints will not get on the surface.

- Do not stick paper or tape on the disc.

Cleaning Discs

•

- If you get fingerprints or dirt
on a disc, clean it with a mild
detergent diluted in water and
wipe with a soft cloth.

- When cleaning, wipe gently from the inside
to the outside of the disc.

Disc Storage

•

- Do not keep in direct sunlight.

- Keep in a cool, ventilated area.

- Keep in a clean, protective jacket and store
vertically.

Condensation may form if warm air comes

•

into contact with cold parts inside the
product. When condensation forms inside the
product, it may not operate correctly. If this
occurs, remove the disc and let the product
stand for 1 or 2 hours with the power on.

Disc and Format Compatibility

This product does not support Secure (DRM)
Media files.

CD-R Discs

Some CD-R discs may not be playable

•

depending on the disc recording device (CD­Recorder or PC) used to burn music onto the
disc and the condition of the disc.

Use 650MB/74 minute CD-R discs.

•

Do not use CD-R discs over 700MB/80
minutes as they may not be played back.

Some CD-RW (Rewritable) media may not be

•

playable.
Only CD-Rs that are properly "closed" can be

•

fully played. If the session is closed, but the
disc is left open, the product may not be able
to fully play the disc.

MP3-CD Discs

Only CD-R discs with MP3 files in ISO 9660 or

•

Joliet format can be played.
MP3 file names should contain no blank

•

spaces or special characters (for example, /, =,
+).

Use discs recorded with a compression/

•

decompression data rate greater than
128Kbps.

Only consecutively written multisession discs

•

can be played. If there is a blank segment in a
Multisession disc, the disc can be played only
up to the blank segment.

If a disc is not closed, it will take longer to

•

begin playback and not all of the recorded
files may play.

If a file is encoded in the Variable Bit Rate

•

(VBR) format,( i.e. files encoded in both
low bit rate and high bit rate - 32Kbps
~ 320Kbps), the sound may skip during
playback.

A maximum of 999 files can be played per

•

CD.

Supported Audio Formats

File

Extension

*.mp3

*.wma

Does not support the WMA Professional

➣

codec.

The table above shows supported formats,

➣

sampling rates, and bit rates. Files recorded in
formats that are not supported may not be
played properly.

Audio
Codec

MPEG 1

Layer3

MPEG 2

Layer3

MPEG 2.5

Layer3

Wave_Format_

MSAudio1

Wave_Format_

MSAudio2

Sampling

Rate

16KHz ~

48KHz

16KHz ~

48KHz

16KHz ~

48KHz

16KHz ~

48KHz

16KHz ~

48KHz

Bit Rate

80Kbps ~

320Kbps

80Kbps ~

320Kbps

80Kbps ~

320Kbps

56Kbps ~

128Kbps

56Kbps ~

128Kbps

4 English

Contents

Thank you for buying this SAMSUNG MiNi Hi-Fi Component Audio system.
Please take time to read these instructions.
They will allow you how to operate your system and take full advantage of its features.

Safety Warnings .................................... 2

Important Safety Instructions ................ 3

Precautions ........................................... 3

Disc Storage & Management ................ 4

Disc and Format Compatibility...............4

Supported Audio Formats ..................... 4

Contents............................................... 5

Accessories ........................................... 5

Description ........................................... 6

Front Panel ...................................... 6

Rear Panel ....................................... 7

Remote Control ............................... 8

Display Function ................................... 8

CD/MP3/WMA-CD Playback ................. 9

Selecting a Track ................................... 9

Searching for a Specific Music

Passage on a CD ................................... 9

Repeat One or All Tracks on a

Compact Disc ....................................... 9

Playing a USB Device ........................... 10

To Select a Track from

a USB Device ................................. 10

To Search a Folder Quickly .............. 10

To Use High Speed Search .............. 10

To Repeat one or all Tracks ............10

To Delete a File .............................. 10

Searching for a Track Quickly ......... 11

CD/USB My List Function .................... 11

Checking or Editing the track of the

My List ................................................ 11

Using Bluetooth .................................. 12

Using the Samsung Audio Remote

App .................................................... 13

TV SoundConnect ............................... 14

Setting the Clock ................................ 15

Timer Function .................................... 15

Cancelling the Timer ........................... 16

Listening to Radio ............................... 16

Recording Function............................. 17

Recording Speed ................................ 18

Selecting PRESET EQ Mode ................ 18

Selecting USER EQ Mode ................... 18

Selecting MY KARAOKE Mode .......... 18

Using the FOOTBALL MODE ............... 18

Using the GIGA SOUND Function ....... 18

Using the NON-STOP RELAY

Function ............................................. 19

Auto Change Function........................ 19

Software update ................................. 19

Troubleshooting ................................. 20

Specifications......................................21

Accessories

Check for the supplied accessories below.

FM Antenna

(AH42-00021A)

• Figures and illustrations in this User Manual are provided for reference only and may differ from actual
product appearance.

Symbols

User's Manual

(AH68-02791J)

Important

Remote Control/Batteries

(AH59-02694B/4301-000116)

Note

English 5

English 7

Description

Front Panel

1
2
3

21

4

5

6

7

8
9

10
11

12

1. Window Display

2. FOOTBALL MODE button

3. GIGA SOUND BLAST button

4. CD/ Bluetooth button

5. STOP/Tuning Mode button

6. Search/Skip button

7. TV SOUND CONNECT button

8. USB 1, 2 button

9. PRESET EQ button

10. USB REC button

11. USB 1 jack for Playback only

12. Disc Tray

13. USB 2 REC jack for Playing and USB Recording

14. USER EQ button

20

19

18

17

16

15
14

13

15. OPEN/CLOSE button

16. AUTO CHANGE button

17. Search/Skip button

18. VOLUME/JOG Control

19. PLAY/PAUSE button

20. TUNER/AUX button

21. POWER button

• Press this button to switch your MiNi Hi-Fi
Component Audio system on and off.

6 English

Rear Panel

1

2

3
4

1.

2.0 CH Speaker Connector Terminals

The speaker connector terminals are located
on the rear of the system.

1.

To ac

hieve the correct sound quality, insert
the speaker connector cables identified below
into the correct speaker terminals on the back
of the system.

• Left speaker (marked L).

• Right speaker (marked R).

2.

ONLY FOR SERVICE

• This jack is for service only. Please do not
use.

3.

AUX IN Terminals

1.

Use an Audio Cable (not supplied) to connect
AUX IN on the product to Audio Out on an
external analog component.

• Be sure to match connector colors.

• If the external analog component has only
one Audio Out jack, connect to either the
left or right terminal.

• Press the TUNER/AUX button on the
main unit or press the AUX button on the
remote control to select the AUX input.

• When the unit is in AUX mode, if none of
the buttons are pushed for more than 8
hours, the power will automatically turn
off.

4.

FM Antenna Connector Terminal

1.

Connect the FM antenna (supplied) to the FM
Antenna jack.

2.

Slowly move the antenna wire until you find a
location where reception is good, then fasten it
to a wall or other rigid surface.

3.

If reception is poor, you may need to install an
outdoor antenna. To do so, connect an outdoor
FM antenna to FM antenna jack on the rear
of the system using a 75Ω coaxial cable (not
supplied).

English 7
