Samsung MX-HS6000, MX-HS7000, MX-HS6800 User Manual

PREMIUM HI-FI Component System

(MP3/WMA/CD-DA Playback with CD/USB)

user's manual

MX-HS6000
MX-HS7000

imagine the possibilities

Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at

www.samsung.com/register

02680B-MX-HS6000-XY-ENG-20140227.indd 1 2014/4/25 8:36:28

Safety Information

• An administration fee may be charged if either
an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user's manual).
you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user's manual).

• The amount of such administration charge will be advised to you before any work or home visit is
carried out.

2 English

Warning

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

This symbol indicates “dangerous
voltage” inside the product that presents
a risk of electric shock or personal injury.

This symbol indicates important
instructions accompanying the product.

WARNING

• To reduce the risk of fire or electric shock, do
not expose this appliance to rain or moisture.

CLASS 1 LASER PRODUCT

This Compact Disc player is classified as a CLASS
1 LASER product. Use of controls, adjustments
or performance of procedures other than those
specified herein may result in hazardous radiation
exposure.

Complies with 21CFR 1040.10 except for
deviations pursuant to Laser Notice No. 50, dated
June 24, 2007.

DANGER :

• VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN. AVOID DIRECT EXPOSURE TO
BEAM. (FDA 21 CFR)

CAUTION :

• CLASS 3B VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN. AVOID EXPOSURE
TO THE BEAM. (IEC 60825-1)

• THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN THE COVER
AND DO NOT REPAIR YOURSELF. REFER
SERVICING TO QUALIFIED PERSONNEL.

CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LÁSER CLASE 1

02680B-MX-HS6000-XY-ENG-20140227.indd 2 2014/4/25 8:36:29

01 Safety Information

3 English

Precautions

• Ensure that the AC power supply in your house
complies with the identification sticker located
on the back of your product.

• Install your product horizontally, on a suitable
base (furniture), with enough space around it for
ventilation (7.5~10cm).

• Do not place the product on amplifiers or other
equipment which may become hot. Make sure
the ventilation slots are not covered.

• Do not stack anything on top of the product.

• Before moving the product, ensure the Disc

Insert Slot is empty.

• During thunderstorms, disconnect the AC
plug from the wall outlet. Voltage peaks due to
lightning could damage the product.

• Do not expose the product to direct sunlight
or other heat sources. This could cause the
product to overheat and malfunction.

• when the mains plug or appliance coupler shall
remain readily operable.

• Protect the product from moisture, and excess
heat or equipment creating strong magnetic or
electric fields (i.e. speakers.).

• Disconnect the power cable from the AC supply
if the product malfunctions.

• Your product is not intended for industrial use. It
is for personal use only.

• Condensation may occur if your product or
disc has been stored in cold temperatures. If
transporting the product during the winter, wait
approximately 2 hours until the product has
reached room temperature before using.

• The batteries used with this product contain
chemicals that are harmful to the environment.
Do not dispose of batteries in the general
household trash.

• Place the loudspeakers at a reasonable distance
on either side of the system to ensure good
stereo sound.

• Direct the loudspeakers towards the listening
area.

•Do not expose this apparatus to dripping
or splashing. Do not place objects filled

with liquids, such as vases, on the
apparatus.

•To turn this apparatus off completely, you
must disconnect it from the wall outlet.
Consequently, the wall outlet and power
plug must be readily accessible at all
times.

•Use only a properly grounded plug and
receptacle.

- An improper ground may cause electric shock
or equipment damage. (Class l Equipment
only.)

Disc Storage & Management

• Holding Discs

- Fingerprints or scratches on a disc may
reduce sound and picture quality or cause
skipping.

- Avoid touching the surface of a disc where
data has been recorded.

- Hold the disc by the edges so
that fingerprints will not get on
the surface.

- Do not stick paper or tape on the disc.

• Cleaning Discs

- If you get fingerprints or dirt on a disc, clean
it with a mild detergent diluted in water and
wipe with a soft cloth.

- When cleaning, wipe gently from
the inside to the outside of the
disc.

• Disc Storage
`Do not keep in direct sunlight.
`Keep in a cool ventilated area.
`Keep in a clean, protective jacket and store

vertically.

02680B-MX-HS6000-XY-ENG-20140227.indd 3 2014/4/25 8:36:29

Safety Information

4 English

• Condensation may form if warm air comes
into contact with cold parts inside the product.
When condensation forms inside the product, it
may not operate correctly. If this occurs, remove
the disc and let the product stand for 1 or 2
hours with the power on.

Disc and Format Compatibility

This product does not support Secure (DRM)
Media files.

CD-R Discs

• Some CD-R discs may not be playable
depending on the disc recording device (CD­Recorder or PC) and the condition of the disc.

• Use 650MB/74 minute CD-R discs.
Do not use CD-R discs over 700MB/80 minutes
as they may not be played back.

• Some CD-RW (Rewritable) media may not be
playable.

• Only CD-Rs that are properly "closed" can be
fully played. If the session is closed, but the disc
is left open, you may not be able to fully play the
disc.

MP3-CD Discs

• Only CD-R discs with MP3 files in ISO 9660 or
Joliet format can be played.

• MP3 file names should contain no blank spaces
or special characters (. / = +).

• Use discs recorded with a compression/
decompression data rate greater than 128Kbps.

• Only a consecutively written multisession disc
can be played. If there is a blank segment in the
Multisession disc, the disc can be played only
up to the blank segment.

• If the disc is not closed, it will take longer to
begin playback and not all of the recorded files
may play.

• For files encoded in the Variable Bit Rate (VBR)
format,( i.e. files encoded in both low bit rate
and high bit rate - 32Kbps ~ 320Kbps), the
sound may skip during playback.

• A maximum of 999 files can be played per CD.

Supported Audio Formats

File

Extension

Audio

Codec

Sampling

Rate

Bit Rate

*.mp3

MPEG 1 Layer3

16KHz ~

48KHz

80Kbps ~

320Kbps

MPEG 2 Layer3

16KHz ~

48KHz

80Kbps ~

320Kbps

MPEG 2.5 Layer3

16KHz ~

48KHz

80Kbps ~

320Kbps

*.wma

Wave_Format_

MSAudio1

16KHz ~

48KHz

56Kbps ~

128Kbps

Wave_Format_

MSAudio2

16KHz ~

48KHz

56Kbps ~

128Kbps

| NOTES |

✎Does not support WMA Professional codec.
✎The above table shows supported sampling

rates and bit rates. Files of not supported
formats may not be played properly.

02680B-MX-HS6000-XY-ENG-20140227.indd 4 2014/4/25 8:36:30

Contents

Contents

5 English

SAFETY INFORMATION

2 Warning
3 Precautions
3 Disc Storage & Management
4 Disc And Format Compatibility

GETTING STARTED

6 Front Panel
7 Rear Panel
8 Remote Control
9 Accessories
9 Connecting the Speakers

FUNCTIONS

10 The Display function
10 Playing a CD
10 Loading a Compact Disc
10 CD/MP3/CD-R Playback
11 Selecting a Track
11 Searching for a Specific Music Passage on

a CD
11 Repeat One or All Tracks on a CD
12 Playing USB Devices
12 USB Device Playback
12 To Select a File from a USB Device
13 To Use High Speed Search
13 To Delete a File
13 To Move to the Next/Previous Folder
13 To safely remove a USB device
13 Read Before Connecting USB Storage

Devices
14 Searching for a Track Quickly
14 Using the Program Function
14 Viewing or Editing Programmed Tracks
15 Bluetooth
15 What is Bluetooth?
15 To connect the Hi-Fi Component to a

Bluetooth device

16 To disconnect the Bluetooth device from

the Hi-Fi Component

16 To disconnect the Hi-Fi Component from

the Bluetooth device
16 Using the Bluetooth Power On
17 TV SoundConnect
17 To connect the Hi-Fi Component to a

SoundConnect Compatible Samsung TV
17 To disconnect the TV from the Hi-Fi

Component
17 To disconnect the Hi-Fi Component from

the TV
18 Using My Karaoke
18 Auto Change Function
18 Listening to the Radio
18 To Store the Stations You Want
19 Selecting a Stored Station
19 Timer Function
19 Setting the Clock
19 Setting the Timer
21 Cancelling the Timer
21 The Recording Function
21 Basic Recording
22 Recording Speed
23 Special Sound Effect
23 Selecting EQ Mode
23 FOOTBALL MODE function
23 GOAL Function
24 GIGA SOUND Function
24 BEAT WAVING Function
24 DJ BEAT Function
25 +PANNING Function
25 NON-STOP MUSIC RELAY Function
25 DANCE TIME Function
25 TEMPO Function
25 Booting Sound Function

APPENDIX

26 Troubleshooting
27 Specifications

02680B-MX-HS6000-XY-ENG-20140227.indd 5 2014/4/25 8:36:30

j

k 56c7

&

1 43

*d (

2m n

g

l

$^

%

)

e

b

f

@

8a9

0

!

#

i

h

Front Panel

1

REMOTE CONTROL SENSOR

2

FORWARD SEARCH/SKIP button

3

PLAY/PAUSE button

4

TUNER/AUX button

5

DISPLAY / DEMO button

6

TV SOUND CONNECT button

7

EQ button

8

FOOTBALL MODE button

9

GIGA SOUND BEAT button

0

POWER button

• Press this button to switch your product
on or off.

!

REPEAT button

@

SEARCH button

#

VOLUME / SEARCH JOG

$

OPEN/CLOSE button

%

ENTER button

^

PROGRAM button

&

DISC slot

*

Display Panel

(

BEAT WAVING button

)

MIC jack

a

AUX IN 1 jack
Connecting an external device such as an

MP3 player.

• Connect AUX IN 1 on the front panel
of the product to the Audio Out of an
external device/MP3 player.

• Press the TUNER/AUX button to select
AUX1.

b

USB REC button

c

USB button

d

USB 2 jack for Playing and USB Recording

e

USB 1 jack for Playback only.

f

TEMPO button

g

NON-STOP MUSIC RELAY button

h

DANCE TIME button

i

DJ JOG

j

+PANNING button

k

DJ BEAT button

l

CD/ Bluetooth button

m

STOP button

n

BACKWARD SEARCH/SKIP button

Getting Started

6 English

02680B-MX-HS6000-XY-ENG-20140227.indd 6 2014/4/25 8:36:31

02 Getting Started

2
3

4

5

6

7

1

MX-HS6000

2
3

4

5

6

7

1

MX-HS7000

1

Cooling fan

• The fan operates while the unit is powered on.
If you set the unit to the minimum volume, the
fan won't operate.
Secure a minimum 10 cm of clear space from
all sides of the fan when installing the product.

2

AUX IN 2 Terminals

1.

Use an Audio Cable (not supplied) to connect
AUX IN 2 on the product to Audio Out on the
external analog output device.

• Be sure to match connector colors.

•

If the external analog output device has only
one Audio Out jack, connect either left or right
terminal.

•

Press the TUNER/AUX button to select the AUX 2.

•

If no button actions for more than 8 hours in AUX
mode, the power will automatically turn off.

3

FM Antenna Terminals

1.

Connect the FM antenna (supplied) to the FM
Antenna jack.

2.

Slowly move the antenna wire until you find a
location where reception is good, then fasten
it to a wall or other rigid surface.

3.

If reception is poor, you may need to install
an outdoor antenna. To do so, connect an
outdoor FM antenna to FM antenna jack on
the rear of the system using a 75Ω coaxial
cable (not supplied).

4

LED Terminals for Speaker Beat Waving.

5

ONLY FOR SERVICE

• This jack is just for testing, please don't use it.

6

POWER

• Insert only provided power cable.

7

2.1 CH Speaker Terminals (MX-HS6000)

2.2 CH Speaker Terminals (MX-HS7000)

1.

To achieve the correct sound quality, when
you connect the speakers, match the color
of the speaker plugs to the color of the
speaker jacks. See below.

• LEFT channel (marked ).

• RIGHT channel (marked ).

• Don't force the Purple SUBWOOFER

connector into the White or Red speaker jack.

Rear Panel

7 English

02680B-MX-HS6000-XY-ENG-20140227.indd 7 2014/4/25 8:36:32

Installing Batteries In The Remote Control

• Place batteries in the remote control so they
match the of the illustrations in the battery
compartment. : (+) to (+) and (–) to (–).

• Do not dispose of batteries in a fire.

• Do not short circuit, disassemble, or overheat

the batteries.

• Danger of explosion if the battery is replaced
with the wrong battery type. Replace only with
the same or equivalent type.

• The remote control can be used up to
approximately 23 feet (7 meters) in a straight
line from the system.

Power

Bluetooth

TUNING MODE

PLAY/PAUSE

TIMER SET

MY KARAOKE

CD

USB

TUNER/AUX

NON-STOP MUSIC RELAY

TEMPO

STOP

FOOTBALL

EQ

PROGRAM

TIMER ON/OFF

DISPLAY

MIC VOLUME –, +

AUTO CHANGE

BEAT WAVING

TV SoundConnect

REC SPEED

MO/ST

DJ BEAT

EFFECT LEVEL

REPEAT

GOAL

DANCE TIME

DELETE

SLEEP (Set a sleep time to shut off the
product.)

TUNING/ALBUM ,,

.

SEARCH

USB REC

+PANNING

GIGA SOUND BEAT

MUTE (Turn off the sound temporarily. Press
again to turn the sound back on.)

SKIP

VOLUME (–, +)

Remote Control

Getting Started

8 English

02680B-MX-HS6000-XY-ENG-20140227.indd 8 2014/4/25 8:36:33

02 Getting Started

Accessories

Check for the supplied accessories below.

User Manual

Remote Control /

Batteries

Power Cable Rubber Foot (8ea) FM Antenna

• Figures and illustrations in this user's manual are provided for reference only and may differ from actual
product appearance.

Connecting the Speakers

Recommended speaker setup.

| IMPORTANT |

✎The product may not operate properly if it is subject to shaking or

external shocks or if the speakers are not installed as recommended.
✎Do not stretch the speaker wires or place a heavy object on them.
✎Please place these subwoofers separately and keep a distance at

least 5cm for each other.(only for MX-HS7000)

Attaching the speaker foot

Attach the supplied speaker feet to the bottom rear corners of each speaker as shown in the illustration
to stabilize the speakers and prevent them from slipping.

(MX-HS7000)

(MX-HS6000)

Rubber Foot

9 English

02680B-MX-HS6000-XY-ENG-20140227.indd 9 2014/4/25 8:36:35
