Samsung SMART Signage
Samsung SMART Signage
QMR Series
QHR Series
Display any content in ultra-high defi nition with incredibly rich color on slim, effi cient signage.
Through intelligent UHD upscaling technology, Samsung’s QHR series performs edge restoration and noise
reduction to deliver UHD picture quality even with lower resolution content. As an added bene t, the QHR
series also features reliable, non-glare panels that provide better visibility from all angles. Backed by Tizen 4.0,
the QHR series provides reinforced capability with multiple web formats and secured protection. Additionally,
its new slim design simpli es wall mounting and ensures seamless installation.
Highlights
• Engage audiences with eye-catching 700 nit brightness and ultra-high-de nition resolution.
• Deliver UHD-level picture quality even with lower resolution content through innovative UHD upscaling
technology and unique picture-enhancing features.
• Dynamic Crystal Color allows viewers to enjoy a wider spectrum of colors, up to one billion shades.
• New symmetrical, slim design simpli es installation and complements any environment.
• Secure, PC-free operation through Knox and rigid three-layer protection.
• Reliable, non-glare panels provide better visibility from all angles, anytime of day allowing businesses to deliver
accurate information 24/7.
Page 2
Industry trend
700
nit
With visual display technology improving across devices, viewers have developed an ever-growing expectation for better picture quality. Additionally, the market has been fl ooded with a wide variety of color techologies and it’s becoming increasingly
important for businesses to have rich and vivid display capabilities. As UHD resolution continues to grow in popularity, it is essential for businesses to deliver superb picture quality for their customers. Low quality displays and signage can create negative
perceptions of a business. While much content is still being produced at a lower resolution, through Intelligent UHD upscaling
technology, Samsung’s QHR series is able to upscale the low resolution content to UHD picture quality.
UHD resolution is must-have feature in the future UHD sales forecasted to exceed FHD in 2019
2,809
2,94 3
77%
UHD digital signage portion
20%
20212017
* Source : IHS ‘18.2Q Final+Forecast($)] * Source : IHS ‘18.2Q Final+Forecast
* Note : Standalone digital signage only
Consumer TVs, along with Commercial Lite and Hospitality TVs used for signage are excluded.
344
45
2,227
2016
UHD(Kunit) FHD(Kunit) UHD(M$) FHD(M$)
835
197
2,468
2017 2018 2019 2020
2,032
1,459
461
2,311
1,969
1,654
576
2,348
2,481
1,425
1,099
1,92 5
Why Samsung’s QHR series?
Samsung’s superior visual display technology has positioned them as an industry leader in the digital signage market for a decade.
Samsung has also been the top selling TV brand for 12 consecutive years according to IHS Markit. As the leader in the visual
display industry, Samsung delivers best-in-class picture quality and the QHR series is no exception. The displays provide 700 nit
brightness, rich and fl awless colors, sleek and durable design, powerful performance through SSSP 6 and secure protection. Its
reliable, non-glare panels provide better visibility from all angles, allowing businesses to deliver important information 24/7.
Samsung’s QHR series is also able to upscale low-resolution content to UHD quality. For commercial displays, this technology
advancement means highly visible signage with unmatched accuracy to help capture the attention of potential customers. It
also means savings both in cost and time, as businesses can produce content at a lower cost and resolution and still display it in
stunning UHD quality.
1 Results based on IHS Technology report “Public Displays Market Tracker”, 2009 – 2018.
Information is not an endorsement of Samsung. Any reliance on these results is at the third party’s own risk.
2 Results based on IHS Markit, Technology Group, TV Sets Intelligence Service – Premium, Annual Unit and Annual Revenue Basis, 2006 – 2017.
Information is not an endorsement of Samsung. Any reliance on these results is at the third party’s own risk. Visit www.technology.ihs.com for more details.
High brightness
Intelligent UHD
upscaling
Slim & Flat back
design
SSSP 6
2
Page 3
Key features
24/7
FHD panel UHD panel
2M pixels 8M pixels
Conventional QHR Series
24/7
Incredible 4K picture quality
Samsung’s new QHR series is able to capture customer attention by
providing an incredibly clear picture, showcasing lifelike images and
intricate details better than ever before thanks to ultra high-de nition 4K resolution.
High Brightness
Non-glare
High visibility with eye-catching brightness
Samsung’s QHR series features brilliant image presentation with an
impressive 700 nit brightness allowing businesses to deliver clear information 24/7. The display’s non-glare panels provide better visibility regardless of ambient light, ensuring critical information is always
24/7 Operation
visible.
Conventional Conventional ConventionalQHR Series QHR Series QHR Series
UHD
UHD Processor Noise Reduction Edge Restoration
Intelligent UHD upscaling
Samsung’s global leadership in display technology and picture quality spans more than a decade. Thanks to superior semi-conductor technology, Samsung has developed the powerful video processor available. Additionally, intelligent UHD upscaling technology is a cutting-edge solution based on Samsung’s proprietary UHD Processor that allows content developed at a lower resolution to be elevated to UHD-level quality. It
also performs edge restoration and noise reduction to optimize on-screen text and imagery with crisp edges and ne detail.
Amplifi ed colorsReduced colors
affect RGB clarity
ensure accuate RGB
expression
1 Billion Color Wide Color Gamut
Dynamic Crystal Color
Dynamic Crystal Color is what brings the incredible, lifelike color to Samsung displays. Using 10-bit processing, the displays are able to showcase a wider spectrum of colors — up to a billion different shades — capturing subtle differences for fl awless color expression, critical to businesses in ensuring brand consistency across communication channels. The QHR series also features HDR+ functionality that converts standard
de nition (SDR) content to HDR quality for sharper contrast and more vivid colors.
3
Page 4
Key features
Side power inlet for
no depth extension
Symmetric
Slim Depth
Narrow Bezel
Long Life Cycle
Slim and symmetrical design
The all-new slim and symmetrical design of the QHR series signi cantly simpli es wall mounting the display and ensures installation
is a seamless process. The display’s power inlet direction has been redesigned to sit fl ush against the wall. The new design sets guarantees
a long life cycle ensuring the QHR series will stand the test of time.
Saving TCO
PC-less
Solution
Enhanced
Security
Any PC
Offi ce 365
VMware Horizon
Samsung Workspace secured by Knox
Samsung Workspace is a powerful new feature forti ed by proprietary
Knox security technology allowing users to create an enhanced virtual
collaboration workspace without needing a PC in the room, or any physical connection. Simply connect a keyboard and mouse to the display
and immediately get to work accessing a PC remotely or web-based
cloud services such as Microsoft Of ce 365 and VMWare Horizon.
* Samsung Workspace feature support may vary by region and market conditions.
* The scheduled availability of this feature varies by model.
Clean cable management
In a corporate or retail environment, the back of a display is often visible to customers. With the QHR series’ new cable guide feature retailers can tuck messy cables away from view. This allows for a clean
and more visually-appealing customer shopping experience.
Easy Development Reinforced Compatibility High Expandability Secured Protection
Powerful, all-in-one solution
The Samsung SMART Signage Platform (SSSP) is an open-source,
all-in-one solution embedded in Samsung SMART signage that simpli es installation and maintenance. With SSSP, there is no need for
any external devices to communicate with the server or play digital
media enjoying easy development, reinforced capability with multiple web formats, and secured protection.
Wi-Fi and Bluetooth built-in
The QHR series features a nearly endless range of business use-cases thanks to built-in Wi-Fi and Bluetooth. Wireless connectivity allows for personalized and interactive services including enabling
integration with beacon technology in store, while also simplifying
how businesses showcase content.
* Image is for illustrative purposes only, speci c application or program may have to be developed for
the depicted usage scenario.
4
EMC Class B IP5x Rating
Industry standard certifi ed
QHR displays are EMC class B compliant, providing a safe and
healthy viewing environment by meeting strict standards of electromagnetic wave emission and assuring reliable operation even near
other electronic equipment. Additionally, IP5x rating ensures durable performance even in dusty environments.
Page 5
Specif ications
Model QH43R QH49R QH55R QH65R QH75R
Diagonal Size
Type
Resolution
Pixel Pitch (mm)
Active Display Area
Panel
Display
Sound Speaker Type
Connectivity
Power
Mechanical
Spec
Operation
Feature
Certication
Accessories
Brightness(Typ.)
Contrast Ratio (Typ.)
Viewing Angle(H/V)
Response Time (G to G)
Display Colors
Color Gamut
Operation Hour
Haze
Dynamic C/R
H-Scanning Frequency
V-Scanning Frequency
Maximum Pixel Frequency
INPUT
OUTPUT
EXTERNAL CONTROL
EXTERNAL SENSOR
Tuner
Type
Power Supply
Power Consumption
Dimension(mm)
Weight (kg)
VESA Mount
Protection Glass
Stand Type
Bezel Width (Top/Side/Bot) (mm)
Operating Temperature
Humidity
Key
Special
Internal Player
(Embedded H/W)
Safety
EMC
Environment
Included
Optional
Class
Measured
RGB
VIDEO
HDCP
AUDIO
USB
RGB
VIDEO
AUDIO
Power Out
USB
Max[W/h]
Typical[W/h]
Rating[W/h]
BTU(Max)
Sleep mode
Off mode
Set
Package
Set
Package
H/W
S/W
Processor
On-Chip
Cache
Memory
Clock Speed
Main
Memory
Interface
Graphics
Storage
(FDM)
Multimedia
IO Ports
Operating
System
Stand
Mount
Specialty
Media Player
43 49 55 65 75
42.5 48.5 54.6 64.5 74.5
Edge LED BLU Edge LED BLU Edge LED BLU Edge LED BLU Edge LED BLU
UHD (3840 x 2160) UHD (3840 x 2160) UHD (3840 x 2160) UHD (3840 x 2160) UHD (3840 x 2160)
0.2451 x 0.2451 0.279 x 0.279 0.315 x 0.315 0.372 x 0.372 0.42975 x 0.42975
941.184 (H) x 529.416 (V) 1073.78(H) x 604.00(V) 1209.6(H) x 680.4(V) 1428.48 (H) x 803.52 (V) 1650.24 (H) x 928.26 (V)
700 700 700 700 700
4000:1 4000:1 4000:1 4000:1 4000:1
178/178 178/178 178/178 178/178 178/178
8ms(Typ.) 8ms(Typ.) 8ms(Typ.) 8ms(Typ.) 8ms(Typ.)
16.7M(True Display)
1.07B(Ditherd 10bit)
92% (DCI-P3, CIE 1976) 92% (DCI-P3, CIE 1976) 92% (DCI-P3, CIE 1976) 92% (DCI-P3, CIE 1976) 92% (DCI-P3, CIE 1976)
24/7 24/ 7 24/7 24/7 24/ 7
44% 25% 25% 25% 44%
MEGA MEGA MEGA MEGA MEGA
30 ~ 81kHZ 30 ~ 81kHZ 30 ~ 81kHZ 30 ~ 81kHZ 30 ~ 81kHZ
48 ~ 75HZ 48 ~ 75HZ 48 ~ 75HZ 48 ~ 75HZ 48 ~ 75HZ
594MHz 594MHz 594MHz 594MHz 594MHz
Built in Speaker(10W + 10W) Built in Speaker(10W + 10W) Built in Speaker(10W + 10W) Built in Speaker(10W + 10W) Built in Speaker(10W + 10W)
DVI-D, Display Port 1.2 (1) DVI-D, Display Port 1.2 (1) DVI-D, Display Port 1.2 (1) DVI-D, Display Port 1.2 (1) DVI-D, Display Port 1.2 (1)
HDMI 2.0 (2) HDMI 2.0 (2) HDMI 2.0 (2) HDMI 2.0 (2) HDMI 2.0 (2)
HDCP2.2 HDCP2.2 HDCP2.2 HDCP2.2 HDCP2.2
Stereo mini Jack, DVI, HDMI Stereo mini Jack, DVI, HDMI Stereo mini Jack, DVI, HDMI Stereo mini Jack, DVI, HDMI Stereo mini Jack, DVI, HDMI
USB 2.0 x 2 USB 2.0 x 2 USB 2.0 x 2 USB 2.0 x 2 USB 2.0 x 2
HDMI 2.0 (Loop-out) HDMI 2.0 (Loop-out) HDMI 2.0 (Loop-out) HDMI 2.0 (Loop-out) HDMI 2.0 (Loop-out)
N/A N /A N/A N/A N /A
Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack
N/A N /A N/A N/A N /A
RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Temperature Sensor,Pivot Display,
Clock Battery(168hrs Clock Keeping),
Wall Daisy Chain(HDCP2.2:4EA,HD-
Auto Source Switching & Recovery,
LFD Home UI, Button Lock, Hot key
Cortex A72 1.7GHz Quad-Core CPU Cortex A72 1.7GHz Quad-Core CPU Cortex A72 1.7GHz Quad-Core CPU Cortex A72 1.7GHz Quad-Core CPU Cortex A72 1.7GHz Quad-Core CPU
Output resolution : 3840x2160 (Scale
up from graphic processing result.)
*Video Decoder : MPEG-1/2/4, H.263,
H.264/AVC, UHD H.264/AVC, VC-1,
AVS+, HEVC, JPEG, PNG, VP8, VP9 *Au-
Quick Setup Guide, Warranty Card,
N/A N /A N/A N/A N /A
IR IR IR IR IR
N/A N /A N/A N/A N /A
Internal Internal Internal Internal Internal
138 143 160 204 314
96 99 118 150 247
125 130 145 185 285
470.6 487.6 545.6 695.6 1070.7
0.5 0.5 0.5 0.5 0.5
N/A N /A N/A N/A N /A
967.5 x 557.7 x 48.3 1099.2 x 631.5 x 46.3 1235.1 x 707.9 x 46.3 1453.9 x 831.0 x 46.3 1681.1 x 960.1 x 49.7
1095 x 676 x 151 1247 x 772 x 152 1402 x 858 x 163 1611 x 973 x 185 1871 x 1127 x 223
10 13.5 18.1 24.9 38.3
13.3 18 23.6 33.3 49
200 X 200 200 X 200 200 X 200 400 X 400 400 X 400
N/A N /A N/A N/A N /A
Foot Stand (Optional) Foot Stand (Optional) Foot Stand (Optional) No No
9.2mm(U/L/R), 11.2mm(B) 9.2mm(U/L/R), 11.2mm(B) 9.2mm(U/L/R), 11.2mm(B) 9.2mm(U/L/R), 11.2mm(B) 11.5mm(U/L/R), 12.5mm(B)
0℃~ 40℃ 0℃~ 40℃ 0℃~ 40℃ 0℃~ 40℃ 0℃~ 40℃
10~80% 10~80% 10~80% 10~80% 10~80%
UHD Signage Display
Slim & Light Signage with
Built-in MagicInfo S6, SSSP 6.0
Built in Speaker(10W 2ch), Video
CP1.4:7EA), IP5x Rating, Wi-Fi/BT
option, Plug&Play (Initial Setting)
L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB
1.7GHz 1.7GHz 1.7GHz 1.7GHz 1.7GHz
2.5GB
LPDDR4 1.5GHz 64bit
Graphic resolution : 1920x1080
8GB (3.88GB Occupied by O/S,
4.12GB Available)
dio Decoder : AC3 (DD), MPEG
USB 2.0 USB 2.0 USB 2.0 USB 2.0 USB 2.0
Tizen 4.0 (VDLinux) Tizen 4.0 (VDLinux) Tizen 4.0 (VDLinux) Tizen 4.0 (VDLinux) Tizen 4.0 (VDLinux)
60950-1 60950-1 60950-1 60950-1 60950-1
Class B Class B Class B Class B Class B
N/A ENERGY STAR 8.0, Epeat ENERGY STAR 8.0, Epeat ENERGY STAR 8.0, Epeat N/A
Power Cord, Remote Controller,
Batteries
STN-L4355F STN-L4355F STN-L4355F No No
WMN4070SE WMN4070SE WMN4070SE WMN4277SE
CML400XK CML400XK CML400XK CLM450K CLM450K
N/A N /A N/A N/A N /A
16.7M(True Display)
1.07B(Ditherd 10bit)
UHD Signage Display
Slim & Light Signage with
Built-in MagicInfo S6, SSSP 6.0
Temperature Sensor,Pivot Display,
Clock Battery(168hrs Clock Keeping),
Built in Speaker(10W 2ch), Video
Wall Daisy Chain(HDCP2.2:4EA,HD-
CP1.4:7EA), IP5x Rating, Wi-Fi/BT
Auto Source Switching & Recovery,
LFD Home UI, Button Lock, Hot key
option, Plug&Play (Initial Setting)
L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB
2.5GB
LPDDR4 1.5GHz 64bit
Graphic resolution : 1920x1080
Output resolution : 3840x2160 (Scale
up from graphic processing result.)
8GB (3.88GB Occupied by O/S,
4.12GB Available)
*Video Decoder : MPEG-1/2/4, H.263,
H.264/AVC, UHD H.264/AVC, VC-1,
AVS+, HEVC, JPEG, PNG, VP8, VP9 *Au-
dio Decoder : AC3 (DD), MPEG
Quick Setup Guide, Warranty Card,
Power Cord, Remote Controller,
Batteries
16.7M(True Display)
1.07B(Ditherd 10bit)
UHD Signage Display
Slim & Light Signage with
Built-in MagicInfo S6, SSSP 6.0
Temperature Sensor,Pivot Display,
Clock Battery(168hrs Clock Keeping),
Built in Speaker(10W 2ch), Video
Wall Daisy Chain(HDCP2.2:4EA,HD-
CP1.4:7EA), IP5x Rating, Wi-Fi/BT
Auto Source Switching & Recovery,
LFD Home UI, Button Lock, Hot key
option, Plug&Play (Initial Setting)
L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB
2.5GB
LPDDR4 1.5GHz 64bit
Graphic resolution : 1920x1080
Output resolution : 3840x2160 (Scale
up from graphic processing result.)
8GB (3.88GB Occupied by O/S,
4.12GB Available)
*Video Decoder : MPEG-1/2/4, H.263,
H.264/AVC, UHD H.264/AVC, VC-1,
AVS+, HEVC, JPEG, PNG, VP8, VP9 *Au-
dio Decoder : AC3 (DD), MPEG
Quick Setup Guide, Warranty Card,
Power Cord, Remote Controller,
Batteries
16.7M(True Display)
1.07B(Ditherd 10bit)
UHD Signage Display
Slim & Light Signage with
Built-in MagicInfo S6, SSSP 6.0
Temperature Sensor,Pivot Display,
Clock Battery(168hrs Clock Keeping),
Built in Speaker(10W 2ch), Video
Wall Daisy Chain(HDCP2.2:4EA,HD-
CP1.4:7EA), IP5x Rating, Wi-Fi/BT
Auto Source Switching & Recovery,
LFD Home UI, Button Lock, Hot key
option, Plug&Play (Initial Setting)
L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB
2.5GB
LPDDR4 1.5GHz 64bit
Graphic resolution : 1920x1080
Output resolution : 3840x2160 (Scale
up from graphic processing result.)
8GB (3.88GB Occupied by O/S,
4.12GB Available)
*Video Decoder : MPEG-1/2/4, H.263,
H.264/AVC, UHD H.264/AVC, VC-1,
AVS+, HEVC, JPEG, PNG, VP8, VP9 *Au-
dio Decoder : AC3 (DD), MPEG
Quick Setup Guide, Warranty Card,
Power Cord, Remote Controller,
Batteries
16.7M(True Display)
1.07B(Ditherd 10bit)
UHD Signage Display
Slim & Light Signage with
Built-in MagicInfo S6, SSSP 6.0
Temperature Sensor,Pivot Display,
Clock Battery(168hrs Clock Keeping),
Built in Speaker(10W 2ch), Video
Wall Daisy Chain(HDCP2.2:4EA,HD-
CP1.4:7EA), IP5x Rating, Wi-Fi/BT
Auto Source Switching & Recovery,
LFD Home UI, Button Lock, Hot key
option, Plug&Play (Initial Setting)
L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB
2.5GB
LPDDR4 1.5GHz 64bit
Graphic resolution : 1920x1080
Output resolution : 3840x2160 (Scale
up from graphic processing result.)
8GB (3.88GB Occupied by O/S, 4.12GB
Available)
*Video Decoder : MPEG-1/2/4, H.263,
H.264/AVC, UHD H.264/AVC, VC-1,
AVS+, HEVC, JPEG, PNG, VP8, VP9 *Au-
dio Decoder : AC3 (DD), MPEG
Quick Setup Guide, Warranty Card,
Power Cord, Remote Controller,
Batteries
WMN4277SE
WMN6575SE
5
Page 6
About Samsung Electronics Co., Ltd.
Samsung Electronics Co., Ltd. inspires the world and shapes the future with transformative ideas and technologies. The company is redening
the worlds of TVs, smartphones, wearable devices, tablets, cameras, digital appliances, medical equipment, network systems, and semiconductor and LED solutions. For the latest news, please visit the Samsung Newsroom at news.samsung.com.
SMART Signage
For more information about Samsung SMART Signage QHR Series Displays, visit
www.samsung.com/business or www.samsung.com/displaysolutions
Copyright © 2019 Samsung Electronics Co. Ltd. All rights reserved. Samsung is a registered trademark of Samsung Electronics Co. Ltd. Specications and designs are subject to change without notice. Non-metric weights and measurements are approximate. All data were deemed
correct at time of creation. Samsung is not liable for errors or omissions. All brand, product, service names and logos are trademarks and/or
registered trademarks of their respective owners and are hereby recognized and acknowledged.
Samsung Electronics Co., Ltd.
416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do 443-772, Korea
2019-10
Loading...
