Samsung HT-XQ100G User Manual
5.1Ch Stylish Home
Theater System
HT-XQ100G
Instruction Manual
AH68-01852X
COMPACT
DIGITAL AUDIO
SAMSUNG ELECTRONICS AMERICA, INC.
SERVICE DIVISION
400 Valley Road, Suite 201
Mount Arlington, NJ 07856
1-800-SAMSUNG (1-800-726-7864)
www.samsung.com
ENG
12
Safety Warnings Precautions
Ensure that the AC power supply in your house complies with the identification sticker located on the back of your player. Install your
player horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4inches). Make sure the ventilation
slots are not covered. Do not stack anything on top of the player. Do not place the player on amplifiers or other equipment which may
become hot. Before moving the player, ensure the Disc Insert Hole is empty. This player is designed for continuous use. Switching off
the Home Theater to the stand-by mode does not disconnect the electrical supply. In order to disconnect the player completely from the
power supply, remove the main plug from the wall outlet, especially when left unused for a long period of time.
Protect the player from moisture(i.e. vases) , and excess heat
(e.g.fireplace) or equipment creating strong magnetic or electric fields
(i.e.speakers...). Disconnect the power cable from the AC supply if the
player malfunctions. Your player is not intended for industrial use.
Use of this product is for personal use only.
Condensation may occur if your player or disc has been stored in cold
temperatures.
If transporting the player during the winter, wait approximately 2 hours
until the unit has reached room temperature before using.
Phones
During thunderstorms, disconnect AC main plug from the
wall outlet.
Voltage peaks due to lightning could damage the unit.
Do not expose the unit to direct sunlight or other heat
sources.
This could lead to overheating and malfunction of the unit.
The batteries used with this product contain chemicals
that are harmful to the environment.
Do not dispose of batteries in the general household
trash.
PREPARATION
CLASS 1 LASER PRODUCT
This Compact Disc player is classified as a CLASS 1
LASER product.
Use of controls, adjustments or performance of
procedures other than those specified herein may result
in hazardous radiation exposure.
CAUTION-INVISIBLE LASER RADIATION WHEN OPEN
AND INTERLOCKS DEFEATED, AVOID
EXPOSURE TO BEAM.
This symbol indicates that dangerous voltage which can cause electric shock is present inside
this unit.
This symbol alerts you to important operating and maintenance instructions accompanying
the unit.
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LASER CLASE 1
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE REAR COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
Note to CATV system installer :
This reminder is provided to call the CATV system
installer’s attention to Section 820~40 of the NEC
which provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical
ENG
43
READ INSTRUCTIONS
All the safety and operating instructions should be
read before the appliance is operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be
retained for future reference.
HEED WARNINGS
All warnings on the appliance and in the operating
instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and use instructions should be
followed.
WATER AND MOISTURE
Do not use this video product near waterfor example, near a bathtub, wash bowl,
kitchen sink, or laundry tub, in a wet basement,
or near a swimming pool, and the like.
OVERLOADING
Do not overload wall outlets and extension cords as
this can result in the risk of fire
or electric shock.
VENTILATION
Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of the
video product and to protect it from overheating
these openings must not be blocked or covered.
The openings should never be blocked
by placing the video product on a bed, sofa, rug, or
other similar surface. This video product
should never be placed near or over a radiator or
heat register.
This video product should not be placed
in a built-in installation such as a bookcase
or rack unless proper ventilation is provided
or the manufacturer's instructions have been followed.
POWER CORD PROTECTION
Power-supply cords should be routed so that
they are not likely to be walked on or pinched
by items placed upon or against them paying
particular attention to cords at plugs,
convenience receptacles, and the point where
they exit from the appliance.
CLEANING
Unplug this video product from the wall outlet
before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.
LIGHTNING
For added protection of this video product
receiver during a lightning storm, or when
it is left unattended and unused for long
periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system.
This will prevent damage to the video product
due to lightning and power-line surges.
OBJECT AND LIQUID ENTRY
Never push objects of any kind into this
product through openings as they may touch
dangerous voltage points or short-out parts
that could result in a fire or electric shock.
Never spill liquid of any kind on the video
product.
ACCESSORIES
Do not place this video product on an unstable cart,
stand, tripod, bracket, or table.
The video product may fall, causing serious injury to
a child or adult, and serious damage
to the appliance.
Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer,
or sold with the video product. Any mounting
of the appliance should follow the manufacturer's
instructions and should use a mounting accessory
recommended by the manufacturer.
CART
An appliance and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart combination to overturn.
POWER SOURCES
This video product should be operated only from the
type of power source indicated
on the marking label. If you are not sure
of the type of supply to your home, consult your
appliance dealer or local power company.
For video products intended to be operated from battery power, or other sources, refer
to the operating instructions.
POWER LINES
An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits,
or where it can fall into such power lines
or circuits. When installing an outside antenna
system, extreme care should be taken to keep from
touching such power lines or circuits as contact with
them might be fatal.
POLARIZATION
This video product is equipped with a polarized
alternating current line plug (a plug having one
blade wider than the other.) This plug will fit into the
power outlet only one way.
This is a safety feature. If you are unable
to insert the plug fully into the outlet, try reversing
the
plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
OUTDOOR ANTENNA GROUNDING
•
If an outside antenna is connected to the
antenna terminal, be sure the antenna system
is grounded so as to provide some protection
against voltage surges and built-up static
charges.
•
In the U.S.A section 810 of the National
Electrical Code, ANSI/NFPA No. 70-1984,
provides information with respect to proper
grounding of the mast and supporting
structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
See the figure below.
ATTACHMENTS
Do not use attachments not recommended
by the video product manufacturer as they may
cause hazards.
SERVICING
•
Do not attempt to service this product yourself
as opening or removing covers may expose
you to dangerous voltage or other hazards.
•
Refer all servicing to qualified service personnel.
REPLACEMENT PARTS
When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer or having the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or
other hazards.
SAFETY CHECK
Upon completion of any service or repairs
to this video product, ask the service technician to
perform safety checks to determine that the video
product is in proper operating condition.
DAMAGE REQUIRING SERVICE
Unplug this video product from the wall outlet
and
refer servicing to qualified service personnel
under
the following conditions.
a.
When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have
fallen into the video product.
c. If the video product has been exposed to rain
or water
d.
If the video product does not operate normally
by following the operating instructions.
Adjust only those controls that are covered
by the operating instructions as an improper
adjustment of other controls may result
in damage and will often require extensive
work by a qualified technician to restore
the video product to its normal operation.
e. If the video product has been dropped
or the cabinet has been damaged.
f. When the video product exhibits a distinct
change in performance - this indicates
a need for service.
HEAT
This video unit should be situated away from heat
sources such as radiators, stoves, or other products
(including amplifiers) that produce heat.
ANTENNA
LEAD IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION. 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
PREPARATION
Safety Instructions
PREPARATION
Safety Warnings .................................................................1
Precautions.........................................................................2
Safety Instructions..............................................................3
Features .............................................................................5
Notes on Discs ...................................................................7
Description..........................................................................9
CONNECTIONS
Before Connecting the Speakers .......................................13
Installing the DVD player....................................................15
Connecting the Video Out to TV ........................................16
P.SCAN(Progressive Scan) Function .................................17
Connecting External Components......................................18
Connecting the FM Antenna...............................................19
OPERATION
Before Using Your Home Theater ......................................20
Disc Playback.....................................................................22
MP3/WMA-CD Playback ....................................................23
Displaying Disc Information................................................24
JPEG File Playback............................................................25
DivX Playback ....................................................................27
Checking the Remaining Time ...........................................29
Fast/Slow Playback ............................................................30
Skipping Scenes/Songs......................................................30
Repeat Playback ................................................................31
A-B Repeat Playback .........................................................32
Step Function .....................................................................33
Zoom (Screen Enlarge) Function .......................................34
EZ VIEW Function..............................................................34
Bonus Group / Navigating Pages.......................................35
Selecting Audio/Subtitle Language.....................................36
Moving Directly to a Scene/Song .......................................37
Using Disc Menu ................................................................38
Using the Title Menu...........................................................38
SETUP
Setting the Language .........................................................39
Setting TV Screen type ......................................................41
Setting Parental Controls (Rating Level)............................43
Setting the Password .........................................................44
Setting the Wallpaper .........................................................45
DVD Playback Mode ..........................................................47
Setting the Speaker Mode..................................................48
Setting the Delay Time.......................................................49
Setting the Test Tone..........................................................51
Setting the DRC (Dynamic Range Compression)..............52
Setting the Audio ...............................................................53
AV SYNC Setup .................................................................55
Sound Field (DSP)/EQ Function ........................................56
Dolby Pro Logic II Mode.....................................................57
Dolby Pro Logic II Effect.....................................................58
RADIO OPERATION
Listening to Radio...............................................................59
Presetting Stations .............................................................60
MISCELLANEOUS
Convenient Functions.........................................................61
Operating a TV with the Remote Control ...........................63
Before Calling for Service...................................................65
Cautions on Handling and Storing Discs............................67
Language Code List ...........................................................68
Specifications .....................................................................69
65
Multi-Disc Playback & FM Tuner
The HT-XQ100G combines the convenience of multi-disc playback capability, including
DVD-AUDIO, DVD-VIDEO, CD, MP3-CD, WMA-CD, DivX, CD-R/RW, and DVD-R/RW,
with a sophisticated FM tuner, all in a single player.
Dolby Pro Logic II
Dolby Pro Logic II is a new form of multi-channel audio signal decoding technology
that improves upon existing Dolby Pro Logic.
Power Saving Function
The HT-XQ100G automatically shuts itself off after 20 minutes in stop mode.
TV Screen Saver Function
The HT-XQ100G automatically brightens and darkens your TV screen
after 3 minutes in the stop mode.
The HT-XQ100G automatically switches itself into the power saving mode
after 20 minutes in the screen saver mode.
Customized TV Screen Display
The HT-XQ100G allows you to select your favorite image during JPEG and DVD
playback and set it as your background wallpaper.
PREPARATION
Features
Contents
ENG
DVD-Audio compatible
Experience the super high-quality audio performance of DVD-Audio.
The on-board 24-bit/192kHz DAC enables this player to deliver exceptional sound quality in
terms of dynamic range, low-level resolution and high-frequency detail.
AV SYNC Function
Video may lag behind the audio if the unit is connected to a digital TV.
To compensate for this, you can adjust the audio delay time to sync up with the video.
ENG
87
PREPARATION
CD-R Discs
•
Some CD-R discs may not be playable depending on the disc recording device (CD-Recorder or PC) and the
condition of the disc.
•
Use a 650MB/74 minute CD-R disc.
Do not use CD-R disc over 700MB/80 minute as it may not be play back.
•
Some CD-RW (Rewritable) media, may not be playable.
•
Only CD-Rs that are properly "closed" can be fully played. If the session is closed but the disc is left open, you
may not be able to fully play the disc.
CD-R JPEG Discs
•
Only files with the ".jpeg" and ".JPEG" extensions can be played.
•
If the disc is not closed, it will take longer to start playing and not all of the recorded files may be played.
•
Only CD-R discs with JPEG files in ISO 9660 or Joliet format can be played.
•
JPEG file names should be 8 characters or less in length and contain no blank spaces or special characters (. / = +).
•
Only a consecutively written multisession disc can be played. If there is a blank segment in the multisession disc, the
disc can be played only up to the blank segment.
•
A maximum of 9,999 images can be stored on a single CD.
•
When playing a Kodak/Fuji Picture CD, only the JPEG files in the picture folder can be played.
•
Picture discs other than Kodak/Fuji Picture CDs may take longer to start playing or may not play at all.
Disc Recording Format
CD-R MP3 Discs
•
Only CD-R discs with MP3 files in ISO 9660 or Joliet format can be played.
•
MP3 file names should be 8 characters or less in length and contain no blank spaces or special characters (. / = +).
•
Use discs recorded with a compression/decompression data rate greater than 128Kbps.
•
Only files with the ".mp3" and ".MP3" extensions can be played.
•
Only a consecutively written Multisession disc can be played. If there is a blank segment in the Multisession disc,
the disc can be played only up to the blank segment.
•
If the disc is not closed, it will take longer to begin playback and not all of the recorded files may be played.
•
For files encoded in Variable Bit Rate (VBR) format, i.e. files encoded in both low bit rate and high bit rate
(e.g., 32Kbps ~ 320Kbps), the sound may skip during playback.
•
Amaximum of 500 tracks can be played per CD.
•
A maximum of 300 folders can be played per CD.
DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital
surround sound and MPEG-2 video compression technology. Now you can enjoy these realistic effects in the home, as if you were in a movie theater or concert hall.
DVD players and the discs are coded by region. These regional codes must match in order
for the disc to play. If the codes do not match, the disc will not play.
The Region Number for this player is given on the rear panel of the player.
(Your DVD player will only play DVDs that are labeled with identical region codes.)
1 6
~
•
LD, CD-G, CD-I, CD-ROM and DVD-ROM discs cannot be played on this player.
If such discs are played, a "WRONG DISC FORMAT" message appears on the TV screen.
•
DVD discs purchased abroad may not play on this player.
If such discs are played, a "WRONG REGION CODE" message appears on the TV screen.
Do not use the following types of disc!
•
Many DVD discs are encoded with copy protection. Because of this, you should only connect
your DVD player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted
picture from copy-protected DVD discs.
•
This product incorporates copyright protection technology that is protected by methods claims of certain
U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be authorized by Macrovision Corporation,
and is intended for home and other limited viewing uses only unless otherwise authorized by
Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Copy Protection
Notes on Discs
Playable Discs
CD-R/RW DivX Discs
•
Since this product only provides encoding formats authorized by DivX Networks, Inc., a DivX file created by the user
might not be played.
•
Software update for unsupported formats is not supported.
(Example: QPEL, GMC, resolution higher than 720 x 480 pixels, etc.)
•
Sections with high frame rate might not be played while playing a DivX file.
•
For more information about the formats authorized by DivX Networks, Inc., visit "www.divxnetworks.net".
COMPACT
DIGITAL AUDIO
Mark (Logo)
Audio + Video
DVD
AUDIO-CD
5"
Approx. 240 min. (single-sided)
Approx. 480 min. (double-sided)
Approx. 80 min. (single-sided)
Approx. 160 min. (double-sided)
74 min.
20 min.
74 min.
20 min.
3 1/2"
5"
3 1/2"
Audio
Recorded Signals
Disc Type Disc Size Max. Playing Time
DivX
5"
3 1/2"
MPEG4
MP3
This product does not support Secure (DRM) Media files.
ENG
9
PREPARATION
10
Description
—Rear Panel—
—Side Panel—
Video Cable
(AH39-40001V)
Remote Control
(AH59-01643H)
FM Antenna
(AH42-00017A)
Accessories
User's Manual
(AH68-01852X)
FM Antenna Connector
External Audio
Input Connectors
5.1 Channel Speaker
Output Terminals
External Digital Optical
Input Connector
Use this to connect external equipment
capable of digital output.
Cooling Fan
Headphone Jack
Component Video Output
Connectors
Connect a TV with component video
inputs to these jacks.
Video Output Connector
Connect the TV's video input jacks
(VIDEO IN) to the VIDEO OUT connector.
—Front Panel—
Power ( ) button
Volume control
button
button
Function button
Display
Cooling Fan
Eject button
Disc Insert Hole
Tuning up & Skip ( ) button
Tuning down & Skip ( ) button
Play/Pause ( ) button
Stop ( ) button
ENG
12
PREPARATION
11
Insert Remote Batteries
The remote control can be used up to approximately 23 feet/7 meters in a straight line. It can also be
operated at a horizontal angle of up to 30° from the remote control sensor.
Range of Operation of the Remote Control
Caution
Description
Remove the battery
cover in the direction of
the arrow.
1
Insert two 1.5V AAA
batteries, paying attention to the correct
polarities (+ and –).
2
Replace the battery
cover.
3
Follow these precautions to avoid leaking or cracking cells:
•
Place batteries in the remote control so they match the polarity:(+) to (+)and (–)to (–).
•
Use the correct type of batteries.Batteries that look similar may differ in voltage.
•
Always replace both batteries at the same time.
•
Do not expose batteries to heat or flame.
PL II MODE button
VOLUME button
MENU button
POWER button
TV button
DVD Receiver button
CANCEL button
REPEAT button
Number(0~9) buttons
TV/VIDEO button
EJECT button
Cursor/Enter button
DSP/EQ button
DIGEST button
EZ VIEW button
SLIDE MODE button
LOGO button
RETURN button
SOUND EDIT button
TEST TONE button
AUDIO button
MUTE button
INFO button
TUNING/CH button
ZOOM button
TUNER MEMORY, P.SCAN button
SLOW, MO/ST button
DIMMER button
REMAIN button
STEP button
SEARCH buttons
SUB TITLE button
PL II EFFECT button
—Remote Control—
Play/Pause button
Tuning Preset/CD Skip button
Stop button
DVD button
TUNER button
AUX button
D.IN button
SLEEP button
ENG
1413
CONNECTIONS
Speaker Accessories
Before Connecting the Speakers
Please confirm that all the following contents are included in the package.
Front Speaker (2EA)
Front Stand (2EA)
Rear Speaker (2EA) Subwoofer Speaker Center Speaker Speaker Cable (6EA)
Assembling the Speakers
Speaker Packages
Set the front speaker on the front stand.
To mount the speakers on the wall
Drive a screw into the wall for each speaker and
then hook the front speaker over them.
Hook the speakers so
that the screws are in the
position of the figure.
Center Speaker
Front Speaker (L)
Front Speaker (R)
Rear Speaker (R)
Rear Speaker (L)
Subwoofer
Connecting the Speakers
Black
Press down the terminal
tab on the back of the
speaker.
1
Insert the black wire into the
black terminal (–) and the red
wire into the red (+) terminal,
and then release the tab.
2
Connect the connecting plugs to the back
of the Home Theater.
•
Make sure the colors of the speaker terminals
match the colors of the connecting plugs.
3
Red
•
Do not let children play with or near the speakers.
They could get hurt if a speaker falls.
•
When connecting the speaker wires to the speakers,
make sure that the polarity (+/–) is correct.
Caution
•
If you place a speaker near your TV set,
screen color may be distorted because of
the magnetic field generated by the
speaker. If this occurs, place the speaker
away from your TV set.
Note
or
ENG
1615
CONNECTIONS
Choose one of the two methods for connecting to a TV.
Connecting the Video Out to TV
- Connect the supplied video cable from the VIDEO OUT jack on the side panel of the system
to the VIDEO IN jack on your TV.
Composite Video
.......
(Good Quality)
METHOD 1
- If your television is equipped with Component Video inputs, connect a component video cable
(not supplied) from the Pr, Pb and Y jacks on the side panel of the system to the corresponding
jacks on your TV.
Component
.......
(Best Quality)
METHOD 2
•
When the Progressive scan mode is selected, the VIDEO output (Yellow) does not output
any signal.
Note
TV
METHOD2
(supplied)
METHOD 1
Installing the DVD player
1
Separate the rear cover(A).
2
3
4
5
6
Close the rear cover(A).
Fasten the 1 screw on the cover(B).
Put the cables connected to the Video OUT,
Component OUT and Audio IN ports into
the right groove.
Put the speaker cable connected to the
Speaker OUT port into the left groove.
Remove the 1 screw of the cover(B).
cover(A)
cover(B)
Audio Cable
(not supplied)
If the external analog
component has only one
Audio Out, connect either left
17
ENG
18
CONNECTIONS
Optical Cable
(not supplied)
Connecting External Components
Press AUX on the remote control to select ‘D.IN / AUX’ input.
•
Each time the button is pressed, the selection changes as follows: D.IN ➝ AUX
•
You can also use the FUNCTION button on the main unit.
The mode switches as follows: DVD ➝ D.IN ➝ AUX ➝ FM.
3
Connect the Digital In (OPTICAL) on the main unit to the Digital Output on the external
digital component.
1
Connect AUX (Audio) In on the Home Theater to Audio Out on the external analog
component.
•
Be sure to match connector colors.
2
Example: Digital signal components such as a Set-top Box or CD Recorder.
Connecting an External Digital Component
•
You can connect the Video Output jack on your VCR to the TV, and connect the Audio
Output jacks on the VCR to this product.
Note
Press STOP button.
•
If playing a disc, press the STOP button twice so that “STOP”, appears on the display.
Press and hold P.SCAN button on the remote control for over 5 seconds.
•
Pressing and holding the button for over 5 seconds will select "Progressive Scan" and "Interlace Scan"
alternately.
•
When you select P.SCAN, "P.SCAN" will appear on the display.
•
To set P.Scan mode for DivX discs, press the P.SCAN button on the remote control for more than
5 seconds with no disc in the unit (“'NO DISC" on the display), then load the DivX disc and play.
In interlaced-scan video, a frame consists of two
interlaced fields (odd and even), where each field
contains every other horizontal line in the frame.
The odd field of alternating lines is displayed first, and
then the even field is displayed to fill in the alternating
gaps left by the odd field to form a single frame.
One frame, displayed every 1/30th of a second, contains
two interfaced fields, thus a total of 60 fields are
displayed every 1/60th of a second.
The interlaced scanning method is intended for capturing
a still object.
Interlaced Scan (1 FRAME = 2 FIELDS)
The progressive scanning method scans one full frame of
video consecutively down the screen, line by line.
An entire image is drawn at one time, as opposed to the
interlaced scanning process by which a video image is
drawn in a series of passes.
The progressive scanning method is desirable for dealing
with moving objects.
Progressive Scan (FULL FRAME)
What is Progressive (or Non-Interlaced) Scanning?
•
This function works only on TVs equipped with component video inputs (Y, Pr, Pb) that support
Progressive Video. (It does not work on TVs with conventional component inputs, i.e., non-progressive
scan TVs.)
•
Depending on the capabilities of your TV, this function may not work.
Note
1
2
Unlike regular Interlace Scan, in which two fields of picture information alternate to create the entire
picture (odd scan lines, then even scan lines), Progressive Scan uses one field of information
(all lines displayed in one pass) to create a clear and detailed picture without visible scan lines.
P.SCAN(Progressive Scan) Function
•
Buttons Enabled for TV Operation: POWER, CHANNEL, VOLUME, TV/VIDEO, and Numeric (0-9) buttons.
•
By default, the remote control is set to work with Samsung TVs.
See page 63 for more information about remote control operation with other manufacturer's TVs.
19
2
3
Press TV button to
set the remote to
TV mode.
Press the POWER
button to turn on
your Samsung TV
with this remote.
56
Press FUNCTION button
on the main unit or DVD
button on the remote to
enable DVD/CD playback.
1
Plug the main unit's
power cord into the
AC power supply.
4
Press DVD RECEIVER
button to switch to
DVD RECEIVER
mode.
Note
Your Home Theater is capable of playing DVD, CD, MP3/WMA and JPEG discs.Depending on the disc you are
using, these instructions may vary slightly. Read the instructions carefully before using.
Before Using Your Home Theater
To Operate your Samsung TV and the Home Theater with the HT-XQ100G's Remote Control
Press TV/VIDEO
button to select
VIDEO mode on
your TV.
ENG
20
VIDEO
OPERATION
Connecting the FM Antenna
The cooling fan supplies cool air to the unit to prevent overheating.
Please observe the following cautions for your safety.
•
Make sure the unit is well-ventilated. If the unit has poor ventilation, the temperature inside the unit could rise
and may damage it.
•
Do not obstruct the cooling fan or ventilation holes. (If the cooling fan or ventilation holes are covered with a
newspaper or cloth, heat may build up inside the unit and fire may result.)
Cooling Fan
Connect the FM antenna supplied to the FM 75Ω COAXIAL terminal.
Slowly move the antenna wire around until you find a location where reception is good,
then fasten it to a wall or other rigid surface.
FM Antenna (supplied)
1
2
•
This unit does not receive AM broadcasts.
Notes
Loading...
