Samsung BN59-00977A-00 User Manual

SyncMaster 230TSN/230MXN

LCD Display

User Manual

Safety Instructions

Note

These safety instructions must be followed to ensure your safety and prevent property dam­age.

Make sure to read the instructions carefully and use the product in the correct manner.

Warning / Caution

Failure to follow directions noted by this symbol could result in bodily
harm or damage to the equipment.

Note

Power

Prohibited

Do not disassemble

Do not touch

When not used for extended period of time, set your computer to DPM.

If using a screen saver, set it to active screen mode.

The images here are for reference only, and are not applicable in all cases
(or countries).

Shortcut to Anti-Afterimage Instructions

Do not use a damaged power cord or plug or a damaged or

loose power outlet.

• Otherwise, this may result in electric shock or fire.

Important to read and under­stand at all times

Disconnect the plug from the
outlet

Ground to prevent an electric
shock

Do not touch the power plug with wet hands when removing or

plugging the plug into the outlet.

• Otherwise, this may result in electric shock.

Make sure to connect the power cord to a grounded power out-

let.

• Otherwise, it may result in electric shock or personal injury.

Ensure that the power plug is plugged into the power outlet

firmly and correctly.

• Otherwise, this may result in fire.

Safety Instructions

Do not forcefully bend or pull the power plug and do not place

any heavy material on it.

• Otherwise, this may result in fire.

Do not connect multiple appliances to the same power outlet.

• Otherwise, this may cause fire due to overheating.

Do not disconnect the power cord while using the product.

• Otherwise, this may result in damage to the product due to
electric shock.

To disconnect the apparatus from the mains, the plug must be
pulled out from the mains socket, therefore the mains plug shall
be readily operable.

• Otherwise, this may cause electric shock or fire.

Use only the power cord provided by our company. Do not use
the provided power cord of another product.

Installation

• Otherwise, this may result in fire or electric shock.

Be sure to contact an authorized Service Center when installing your
monitor in a location with heavy dust, high or low temperatures, high hu­midity, and exposed to chemical substances and where it operates for 24
hours such as at airports, train stations etc.

Failure to do so may cause serious damage to your monitor.

Do not drop the monitor when moving it.

• This may cause damage to the product or the person carrying

it.

When installing the product in a cabinet or rack, make sure that
the front end of the bottom of the product does not project out.

• Otherwise, it may fall or cause personal injury.

• Use a cabinet or rack of a size appropriate to the product.

DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIG­ARETTES AND ANY HEATING APPLIANCES NEAR THE
PRODUCT.

• Otherwise, this may result in fire.

Keep heating appliances as far away from the power cord or the
product as possible.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

Do not install it in a badly ventilated location such as a bookcase
or closet.

• Otherwise, this may result in fire due to an increase in the in-

ternal temperature.

When putting the product down, make sure to put it down softly.

• Otherwise, this may result in damage to the screen display.

Do not place the front of the product on the floor.

• Otherwise, this may result in damage to the screen display.

Ensure that an authorized installation company installs the wall
mount.

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Install your product in a well ventilated location. Ensure that
there is a clearance of more than 4 inches (10 cm) from the wall.

Clean

• Otherwise, it may result in fire due to an increase in the internal

temperature.

Ensure that the packaging vinyl is kept away from children.

• Otherwise, it may result in serious harm (suffocation) if children

play with it.

If the height of your monitor is adjustable, do not place any ob­ject or part of your body on the stand when lowering it.

• This may cause damage to the product or the person carrying

it.

When cleaning the monitor case or the surface of the TFT-LCD screen,
wipe with a slightly moistened, soft fabric.

Do not spray cleaner directly onto the surface of the product.

• Otherwise, this may result in the discoloration and distortion of

the structure and the screen surface may peel off.

Clean the product using a soft cloth with a monitor cleaner only.
If you must use a cleaner other than the monitor cleaner, dilute it
with water at a ratio of 1:10.

When cleaning the power plug pins or dusting the power outlet,
clean it with a dry cloth.

• Otherwise, it may result in fire.

Safety Instructions

When cleaning the product, make sure to disconnect the power
cord.

• Otherwise, it may result in electric shock or fire.

When cleaning the product, disconnect the power cord and
clean it softly with a dry cloth.

• (Do not use chemicals such as wax, benzene, alcohol, thinner,

mosquito repellant, lubricant, or cleaner.) These may change
the appearance of the product surface and peel off the indica­tion labels on the product.

Since the product housing is easily scratched, make sure to use
the specified cloth only.

• Use the specified cloth adding only a little water. As the product

may be scratched if there is any foreign material on the cloth,
make sure to shake it thoroughly before using it.

When cleaning the product, do not spray water directly onto the
main body of the product.

Others

• Ensure that water does not enter the product and that it is not

wet.

• Otherwise, this may result in electric shock, fire or a malfunc-

tion.

The product is a high voltage product. Do not disassemble, re­pair or modify the product yourself.

• Otherwise, this may result in electric shock or fire. If the product

needs to be repaired, contact a Service Center.

If there is a strange smell or a strange sound or smoke is coming
from the product, disconnect the power plug immediately and con­tact a Service Center.

• Otherwise, this may result in electric shock or fire.

Do not place this product in a location exposed to moisture, dust,
smoke, water, or in a car.

• Otherwise, this may result in electric shock or fire.

When you drop the product or the case is broken, turn the power
off and disconnect the power cord. Contact a Service Center.

• Otherwise, this may result in electric shock or fire.

If thunder or lightning is occurring, do not touch the power cord
or antenna cable.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

Do not try to move the monitor by pulling only the wire or the
signal cable.

• Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Do not lift or move the product back and forwards or right and
left while only holding the power cord or signal cables.

• Otherwise, it may fall and result in electric shock, damage to

the product or fire due to damage to the cable.

Make sure that the ventilating opening is not blocked by a table
or curtain.

• Otherwise, it may result in fire due to an increase in the internal

temperature.

Do not place any containers containing water, vases, flower­pots, medicines as well as any metal on the product.

• If water or a foreign material enters the product, disconnect the

power cord and contact a Service Center.

• This may result in a product malfunction, electric shock, or fire.

Do not use or keep combustible spray or flammable material
near the product.

• Otherwise, this may result in an explosion or fire.

Do not insert any metal, such as chopsticks, coins, pins and
steel, or flammable objects, such as matches or paper, inside the
product (through the ventilating openings, input and output termi­nals, etc).

• If water or foreign material enters the product, disconnect the

power cord and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

When using a fixed screen for a long time, an afterimage or stain
may occur.

• If you are not using your product for a long period of time, put

it into sleep mode or use a moving screen saver.

Set a resolution and frequency appropriate to the product.

• Otherwise, your eyesight may be damaged.

When using headphones or earphones, do not turn the volume
too high.

• Having the sound too loud may damage your hearing.

To avoid eyestrain, do not sit too close to the product.

Safety Instructions

Take a rest for at least five (5) minutes after using the monitor
for one (1) hour.

This reduces eye fatigue.

Do not install it in an unstable location such as an unstable rack
or uneven surface or a location exposed to vibrations.

• Otherwise, it may fall and cause personal injury and/or damage

the product.

• If you use the product in a location exposed to vibrations, it may

damage the product and result in fire.

When moving the product, turn the power off and disconnect
the power plug, antenna cable, and all the cables connected to the
product.

• Otherwise, it may result in electric shock or fire.

Ensure that children do not hang onto the product or climb up
onto the product.

• The product may fall and cause personal injury or death.

If you do not use the product for a long period of time, disconnect
the power cord from the power outlet.

• Otherwise, this may result in overheating or fire due to dust,

and may result in fire due to electric shock or leakage.

Do not place any heavy items or toys or confectionery, such as
cookies etc. that may attract the attention of children and to the
product.

• Your children may hang onto the product causing it to fall and

this may result in personal injury or death.

Be careful that children do not place the battery in their mouths
when removed from the remote control. Place the battery in a lo­cation that children or infants cannot reach.

• If children have had the battery in their mouths, consult your

doctor immediately.

When replacing the battery, insert it with the right polarity (+, -).

• Otherwise, the battery may become damaged or it may cause

fire, personal injury or damage due to leakage of the internal
liquid.

Use only the specified standardized batteries, and do not use a
new battery and a used battery at the same time.

• Otherwise, the batteries may be damaged or cause fire, per-

sonal injury or damage due to a leakage of the internal liquid.

The batteries (and rechargeable batteries) are not ordinary re­fuse and must be returned for recycling purposes. The customer
is responsible for returning the used or rechargeable batteries for
recycling.

Safety Instructions

• The customer can return used or rechargeable batteries to a

nearby public recycling center or to a store selling the same
type of the battery or rechargeable battery.

Do not place the product in a location exposed to direct sunlight
or near any heat such as a fire or heater.

• This may reduce the lifetime of the product, and may result in

fire.

Do not drop any objects onto the product or cause any impact
to the product.

• Otherwise, this may result in electric shock or fire.

Do not use a humidifier near the product.

• Otherwise, this may result in electric shock or fire.

When there is a gas leak, do not touch the product or the power
plug; ventilate immediately.

• If a spark occurs, it may cause an explosion or fire.

If the product has been turned on for a long time, the display
panel becomes hot. Do not touch it.

• Keep the small accessories in a location out of the reach of

children.

Be careful when adjusting the angle of the product or the height
of the stand.

• This may result in personal injury as your hand or fingers may

become caught.

• Also, if you tilt the product too far, it may fall and cause personal

injury.

Do not install the product in a location low enough for children
to reach.

• Otherwise, it may fall and result in personal injury.

• Since the front part of the product is heavy, install the product

on a level and stable surface.

Do not put any heavy objects on the product.

• This may result in personal injury and/or damage to the prod-

uct.

Good Postures When Using the Monitor

Safety Instructions

Maintain the correct posture when using this prod-

uct.

• Straighten your back.

• Keep a distance of 45~50 cm(18~ 20inches) from
your eyes to the screen. Look down at the screen
and face the screen forwards.

• Maintain the correct posture when using this prod­uct.

• Adjust the angle of the product so that light is not
reflected onto the screen.

• Keep your elbow at a right angle and keep your arm
level with the back of your hand.

• Keep your elbow at a right angle.

• Place your heels flat on the ground while keeping
your knees at an angle of 90 degrees or higher and
maintain the position of your arm so that your arm
is below your heart.

Introduction

Package Contents

Note

Please make sure the following items are included with your LCD Display.

If any items are missing, contact your dealer.

Contact a local dealer to buy optional items.

Unpacking

Manuals

LCD Display

Quick Setup Guide Warranty Card

(Not available in all loca-

tions)

Cables

Power Cord

Others

User's Guide, MagicInfo
Software CD, MagicInfo

Manual CD

Introduction

Others

Remote Control Batteries (AAA X 2)

(Not available in all loca-

tions)

Sold separately

Wall Mount KIT D-Sub Cable LAN Cable

USB Cable HDMI Cable RS232C Cable

Ferrite Core for LAN cable

Ferrite Core

• The ferrite cores are used to shield the cables from interfer­ence.

Installing a Wall Mount

This product provides a wall mount of 100 mm x 100 mm that complies with the VESA spec­ifications.

100 mm x 100 mm

A. Wall Mount Base

B. Wall Mount Kit (Optional)

• When connecting a cable, open the ferrite core and clip it
around the cable near the plug.

1. Turn the product off and unplug the power cord from the wall outlet.

2. Place a soft cloth or cushion on a flat surface to protect the panel and place the product
face down.

3. Separate the stand.

4. Align the groove of the Monitor's wall mount base with the groove in the wall mount ki
and firmly fix the wall mount kit by fastening the screws.

Introduction

Note

• If you use a screw that is longer than the standard specifications, the inside of the product

may be damaged.

• For wall mounts that are not compatible with the standard VESA specifications, the length

of the screw may differ depending on the corresponding specifications.

• Do not use screws that are incompatible with the standard VESA specifications and do

not assemble them using excessive force.

This may result in damage to the product or injury due to the product falling. Samsung
shall not be held liable for any damage or injury.

• Samsung shall not be held liable for any damage to the product or injury caused by using

a stand that is not compatible with the specified specifications or due to an installation not
performed by an authorized installation engineer.

• When installing the product using a wall mount, purchase a wall mount that provides at

least 4 inches (10 cm) of space from the wall.

• Samsung shall not be held liable for any problems caused by using a stand that is not

compatible with the specified specifications.

• Use a wall mount according to specifications of your country.

Your LCD Display

Front

SOURCE/[ ] button

Switches from PC mode to Video mode. Selects the input source that an
external device is connected to.

[PC] → [HDMI] → [MagicInfo]

Activates a highlighted menu item.

MENU button [MENU]

Opens the on-screen menu and exits from the menu. Also use to exit the
OSD menu or return to the previous menu.

- VOL +

Moves from one menu item to another horizontally or adjusts selected
menu values. When OSD is not on the screen, press the button to adjust
volume.

SEL

Introduction

Moves from one menu item to another vertically or adjusts selected menu
values.

Power button [ ]

Use this button for turning the LCD Display on and off.

Brightness Sensor

Automatically detects the surrounding brightness it accordingly.

Power indicator

Shows PowerSaver mode by blinking green

Note

See PowerSaver described in the manual for further information regarding
power saving functions. For energy conservation, turn your LCD Display
OFF when it is not needed or when leaving it unattended for long periods.

Remote Control Sensor

Aim the remote control towards this spot on the LCD Display.

Rear

Note

For detailed information concerning cable connections, refer to Connecting Cables under
Setup. The LCD Display 's configuration at the back may vary slightly depending on the model.

POWER S/W ON [ │ ] / OFF [O]

Switches the LCD Display On/Off.

POWER

The power cord plugs into the LCD Display
and the wall outlet.

Introduction

RGB IN

Connect the RGB IN terminal at the back of
your product to your computer.

VIDEO OUT

Connect between the [VIDEO OUT] port on
the product and the D-Sub port on your mon­itor using a D-Sub cable.

HDMI IN

Connect the HDMI terminal at the back of
your LCD Display to the HDMI terminal of
your digital output device using a HDMI ca­ble.

Connect your headphones to the Head­phone connection terminal.

LAN

LAN Connection Terminal

Keyboard / Mouse, Mass Storage Device
Compatible.

AUDIO IN

Connect the audio cable for your product to
the audio port on the back of your computer.

RS232C IN

MDC(Multiple Display Control) Program Port

Introduction

Kensington Lock

The Kensington Lock is a device used to
physically fix the system when using it in a
public place. The locking device has to be
purchased separately. The appearance and
locking method may differ from the illustra­tion depending on the manufacturer. Refer to
the manual provided with the Kensington
Lock for proper use. The locking device has
to be purchased separately.

Note

The location of the Kensington Lock may be
different depending on the model.

Using the Anti-Theft Kensington Lock

1. Insert the locking device into the Ken-

Note

See Connecting Cables for further information regarding cable connections.

Remote Control

Note

The performance of the remote control may be affected by a TV or other electronic device
operating near the LCD Display , causing a malfunction due to interference with the frequen­cy.

sington slot on the Monitor and turn

it in the locking direction .

2. Connect the Kensington Lock cable.

3. Fix the Kensington Lock to a desk or a
heavy stationary object.

Introduction

POWER

OFF

Number Buttons

DEL / GUIDE button

+ VOL -

SOURCE

D.MENU

TOOLS

Up-Down Left-Right buttons

INFO

COLOR BUTTONS

TTX/MIX

MTS/DUAL

ENTER/PRE-CH

MUTE

CH/P

TV

MENU

RETURN

EXIT

MagicInfo

1. POWER

OFF

2.

3. Number Buttons Used to enter the password during the OSD adjustment or

4. DEL / GUIDE but­ton

Turns the product On.

Turns the product Off.

to use MagicInfo.

The "-" button is used to select Digital channels.

Electronic Program Guide (EPG) display.

- This function does not work for this LCD Display.

5. + VOL - Adjusts the audio volume.

6. SOURCE

7.

D.MENU DTV menu display

8. TOOLS Use to quickly select frequently used functions.

Press the button to change the input signal SOURCE.

Changing the SOURCE is only allowed for external devices
that are connected to the LCD Display at the time.

- This function does not work for this LCD Display.

Introduction

- This function does not work for this LCD Display.

9. Up-Down Left-Right but­tons

10. INFO

11. COLOR BUTTONS Press to add or delete channels and to store channels to the

12.

13. MTS/DUAL - This function does not work for this LCD Display.

TTX/MIX

Moves from one menu item to another horizontally, vertically
or adjusts selected menu values.

Current picture information is displayed on the upper left
corner of the screen.

favorite channel list in the “Channel List” menu.

- This function does not work for this LCD Display.

TV channels provide written information services via tele­text.

- Teletext Buttons

- This function does not work for this LCD Display.

MTS-

You can select MTS (Multichannel Television Stereo) mode.

Audio Type MTS/S_Mode Default

FM Stereo Mono Mono Manual

Stereo Mono ↔ Stereo

SAP Mono ↔ SAP Mono

DUAL-

STEREO/MONO, DUAL l / DUAL ll and MONO/NICAM
MONO/NICAM STEREO can be operated depending on the
broadcasting type by using the DUAL button on the remote
control while watching TV.

14. ENTER/PRE-CH

MUTE

15.

16. CH/P In TV mode, selects TV channels.

This button is used to return to the immediately previous
channel.

- This function does not work for this LCD Display.

Pauses (mutes) the audio output temporarily. The audio
comes back on if MUTE or - VOL + is pressed in the Mute
mode.

- This function does not work for this LCD Display.

Change

17. TV Selects the TV mode directly.

- This function does not work for this LCD Display.

MENU Opens the on-screen menu and exits from the menu or

18.
closes the adjustment menu.

Introduction

19. RETURN

20. EXIT

21. MagicInfo MagicInfo Quick Launch Button.

Returns to the previous menu.

Exits from the menu screen.

Connections

Connecting a Computer

Connect the power cord for your LCD Display to the power port on the back
of the LCD Display. Turn on the power switch.

Connect the D-sub to the 15-pin, RGB port on the back of your LCD Display
and the 15 pin D-sub Port on the computer.

Connect the audio cable for your LCD Display to the audio port on the back
of your computer.

Note

• Turn on both your computer and the LCD Display.

• Contact a local SAMSUNG Electronics Service Center to buy optional items.

Connecting to Other devices

Note

AV input devices such as DVD players, VCRs or camcorders as well as your computer can
be connected to the LCD Display. For detailed information on connecting AV input devices,
refer to the contents under Adjusting Your LCD Display.

Connecting Using a HDMI Cable

Note

Connections

• Connect

Display using an HDMI cable.

• You cannot connect a PC to the HDMI terminal.

input devices such as a Blu-Ray/DVD player to the HDMI IN terminal of the LCD

Connecting Using a DVI to HDMI Cable

Note

• Connect

Display using a DVI to HDMI cable.

• Connect the red and white jacks of an RCA to stereo (for PC) cable to the same colored

audio output terminals of the digital output device, and connect the opposite jack to the
AUDIO IN terminal of the LCD Display.

the DVI output terminal of a digital output device to the HDMI terminal of the LCD

Connecting to another Monitor

Connect between the [VIDEO OUT]port on the product and the D-Sub port on your monitor
using a D-Sub cable.

Connections

Note

• Connect to the [VIDEO OUT] port to display the same picture on another monitor.

(For presentation purposes)

Connecting a LAN Cable

Note

Connect the LAN cable.

Connecting a USB device

You can connect USB devices such as a mouse or keyboard.

Connections

Using the Software

Monitor Driver

Note

When prompted by the operating system for the monitor driver, insert the CD­ROM included with this monitor. Driver installation is slightly different from one
operating system to another. Follow the directions appropriate for the oper­ating system you have.

Prepare a blank disk and download the driver program file at the Internet web
site shown here.
Internet web site :

http://www.samsung.com/

Installing the Monitor Driver (Automatic)

1. Insert CD into the CD-ROM drive.

2. Click "Windows".

3. Choose your monitor model in the model list, then click the "OK" button.

4. If you can see following message window, then click the "Continue Anyway" button. Then

click "OK" button (Microsoft® Windows® XP/2000 Operating System).

Using the Software

Note

This monitor driver is certified by Microsoft, and installing it will not damage your system.

The certified driver will be posted on Samsung Monitor homepage.

http://www.samsung.com/

Installing the Monitor Driver (Manual)

Microsoft® Windows Vista™‚ Operating System

1. Insert your Manual CD into your CD-ROM drive.

2.

Click
ization".

3. Click "Personalization" and then "Display Settings".

(Start) and "Control Panel". Then, double-click on "Appearance and Personal-

4. Click "Advanced Settings...".

5. Click "Properties" in the "Monitor" tab. If the "Properties" button is deactivated, it means

the configuration for your monitor is completed. The monitor can be used as is.

Using the Software

If the message "Windows needs..." is displayed, as shown in the figure below, click
"Continue".

Note

This monitor driver is under certifying MS logo, and this installation will not damage your
system.

The certified driver will be posted on Samsung Monitor homepage.

6. Click "Update Driver..." in the "Driver" tab.

7. Check the "Browse my computer for driver software" checkbox and click "Let me pick

from a list of device drivers on my computer".

8. Click "Have Disk...” and select the folder (for example, D:\Drive) where the driver setup

file is located, and click "OK".

Using the Software

9. Select the model that matches your monitor from the list of monitor models on the screen,

and click "Next".

10. Click "Close" → "Close" → "OK" → "OK" on the following screens displayed in sequence.

Microsoft® Windows® XP Operating System

Using the Software

1. Insert CD into the CD-ROM drive.

2. Click "Start" → "Control Panel" then click the "Appearance and Themes" icon.

3. Click "Display" icon and choose the "Settings" tab then click "Advanced...".

4. Click the "Properties" button on the "Monitor" tab and select "Driver" tab.

5. Click "Update Driver..." and select "Install from a list or..." then click "Next" button.

6. Select "Don't search, I will...", then click "Next" and then click "Have disk".

Using the Software

7. Click the "Browse" button then choose A:(D:\Driver) and choose your monitor model in

the model list and click the "Next" button.

8. If you can see following message window, click the "Continue Anyway" button. Then click

"OK" button.

Note

This monitor driver is under certifying MS logo, and this installation will not damage your
system.

The certified driver will be posted on Samsung Monitor homepage.

http://www.samsung.com/

9. Click the "Close" button, then click the "OK" button continually.

Using the Software

10. Monitor driver installation is completed.

Microsoft® Windows® 2000 Operating System

When you can see "Digital Signature Not Found" on your monitor, follow these steps.

1. Choose "OK" button on the "Insert disk" window.

2. Click the "Browse" button on the "File Needed" window.

3. Choose A:(D:\Driver), then click the "Open" button and then click "OK" button.

How to install

1. Click "Start", "Setting", "Control Panel".

2. Double click the "Display" icon.

3. Select the "Settings" tab and click "Advanced Properties" button.

4. Choose "Monitor".

Case1 : If the "Properties" button is inactive, it means your monitor is properly configured.
Please stop installation.

Case2 : If the "Properties" button is active, click the "Properties" button, then follow the
next steps.

5. Click "Driver" and then click on "Update Driver..." then click on the "Next" button.

6. Choose "Display a list of the known drivers for this device so that I can choose a specific

driver" , then click "Next" and then click "Have disk".

7. Click the "Browse" button, then choose A:(D:\Driver).

8. Click the "Open" button, then click "OK" button.

9. Choose your monitor model and click the "Next" button. Then click "Next" button.

10. Click the "Finish" button, then the "Close" button.

If you can see the "Digital Signature Not Found" window, click the "Yes" button. Then
click the "Finish" button and the "Close" button.

Microsoft® Windows® Millennium Operating System

1. Click "Start", "Setting", "Control Panel".

2. Double click the "Display" icon.

3. Select the "Settings" tab and click "Advanced Properties" button.

Using the Software

4. Select the "Monitor" tab.

5. Click the "Change" button in the "Monitor Type" area.

6. Choose "Specify the location of the driver".

7. Choose "Display a list of all the driver in a specific location...", then click "Next" button.

8. Click the "Have Disk" button.

9. Specify A:\(D:\driver), then click "OK" button.

10. Select "Show all devices" and choose the monitor that corresponds to the one you con-

nected to your computer and click "OK".

11. Continue choosing "Close" button and "OK" button until you close the Display Properties

dialogue box.

Microsoft® Windows® NT Operating System

1. Click "Start", "Settings", "Control Panel", and then double-click "Display" icon.

2. In Display Registration Information window, click Settings Tab and then click "All Display

Modes".

3. Select a mode that you wish to use (Resolution, Number of colors and Vertical frequency)

and then click "OK".

4. Click "Apply" button if you see the screen working normally after clicking "Test". If the

screen is not normal, change to a different mode (lower mode of resolution, colors or
frequency).

Note

If there is no Mode at All Display Modes, select the level of resolution and vertical frequency
by referring to the Preset Timing Modes in the user guide.

Linux Operating System

To execute X-Window, you need to make the X86Config file, which is a type of system setting
file.

1. Press "Enter" at the first and the second screen after executing the X86Config file.

2. The third screen is for setting your mouse.

3. Set a mouse for your computer.

4. The next screen is for selecting a keyboard.

5. Set a Keyboard for your computer.

6. The next screen is for setting your monitor.

7. First of all, set a horizontal frequency for your monitor. (You can enter the frequency

directly.)

8. Set a vertical frequency for your monitor. (You can enter the frequency directly.)

9. Enter the model name of your monitor. This information will not affect the actual execution

of X-Window.

10. You have finished setting up your monitor. Execute X-Window after setting other re-

quested hardware.

MDC (Multi-Display Channel)

Installation

1. Insert the installation CD into the CD-ROM drive.

Using the Software

2. Click the MDC installation file.

Note

If the popup window to install the software for the main screen is not displayed, proceed
with the installation using the MDC executable file on the CD.

3. When the Installation Shield Wizard window appears, click "Next".

4. Select "I agree to the terms of the license agreement" to accept the terms of use.

5. Click "Install".

6. The "Installation Status" window appears.

7. Click "Finish".

8. When the installation is complete, the MDC executable icon appears on your desktop.

Double-click the icon to start the program.

MDC execution icon may not appear depending on specification of computer sys­tem or monitor. If that happens, press F5 Key.

Installation Problems

The installation of MDC can be affected by such factors as the video card, motherboard and
the network environment.

Uninstall

The MDC program can be removed only by using the "Add or Remove Programs" option of
the Windows® Control Panel.

Perform the following steps remove MDC.

Select "Setting/Control Panel" on the "Start" menu and then double-click "Add/Delete a pro­gram".

Select MDC from the list and then click the "Add/Delete" button.

Using MDC

Using the Software

Introduction

A Multiple Display Control (MDC) is an application allowing various displays to be easily and simultaneously
operated on a PC. RS-232C, a standard of serial communication, is used for the communication between a PC and
a display. Therefore, a serial cable should be connected between the serial port on a PC and the serial port on a
display.

Main Screen

Click Start > Program > Samsung > MDC System to start the program.

Select a set to see the volume of the selected set within the slider.

Main Icons Select Button
Remocon Info Grid
Safety Lock Display Selection
Port Selection Control Tools

1. Use the main icons to switch into each screen.

2. Allows you to enable or disable the remote control signal receiving function of the display unit.

3. Set the Safety Lock function.
When setting the Lock function, you can only operate power and lock buttons on the remote control and set.

4. The setting for the PC Serial Port can change. The original value is COM1.

5. Click Select all or Clear to select or clear all displays.

6. Use Grid to view brief information on selected display.

7. Select a display from Display Selection.

8. Use Control Tools to control displays.

<Note> The remote control Enable/Disable function operates whether or not the power is On/Off, and this

applies to all displays connected to the MDC. However, regardless of the status at the time the MDC is
shut down, the remote control signal receiving function of all displays is initialized to Enable when the
MDC is closed.

Port Selection

1. The Multiple Display Control is originally set to COM1.

2. If any port other than COM1 is used, COM1 through COM4 can be selected in the Port Selection Menu.

3. If the exact port name that is connected to the LCD Display using a serial cable is not selected, communication will
be unavailable.

4. The selected port is stored in the program and used for the next program as well.

Power Control

1. Click Power Control of the main icons and the Power Control screen appears.

Info Grid shows some basic information necessary to Power Control.

1) (Power Status)

2) Input

3) Image Size

4) On Timer

5) Off Timer

2. Use the Select All button or Check Box to choose a display to control.

Power Control allows controlling some of the functions of the selected display.

g

1) Power On/Off

- Turns the power of the selected display On/Off.

2) Volume

- Controls the volume level of the selected display.
It receives the volume value of the selected display from the sets and displays it in the slider.
(When you cancel the selection or choose Select All, the value returns to the default value 10)

3)

(Mute On/Off)

- Turns on/off the Mute function of the selected display.
When selecting one set at a time, turn on the Mute function for the selected set.
The Mute function is disabled automatically when you adjust the volume level.
(The values return to the default settin

The Power Control feature is available for all displays.
The Volume Control and Mute features are available only for the displays whose power status is ON.

s when you undo the selections or choose "Select All".)

Input Source

1. Click Input Source of the main icons and the Input Source control screen appears.
Click Select All or use Check Box to select a display to control.

• TV Mode

• PC Mode

Info Grid shows some basic information necessary to Input Source Control.

g

g

g

g

g

g

1) PC

- Changes the Input Source of the selected display to PC.

2) BNC

- Changes the Input Source of the selected display to BNC.

3) DVI

- Changes the Input Source of the selected display to DVI.

4) TV

-Chan

es the Input Source of the selected display to TV.

5) DTV

-Chan

es the Input Source of the selected display to DTV.

6) AV

-Chan

es the Input Source of the selected display to AV.

7) S-Video

- Changes the Input Source of the selected display to S-Video.

8) Component

-Chan

es the Input Source of the selected display to Component.

9) MagicInfo

- The Input source of Ma

icInfo works only on MagicInfo model.

10) HDMI

-Chan

es the Input Source of the selected display to HDMI.

11) Channel

- Channel arrow appears when the Input Source is TV.

TV Source can be selected only in products with TV and controlling channels is allowed only when
Input Source is TV.

The Input Source Control feature is available only for the displays whose power status is ON.

Image Size

PC, BNC, DVI

1. Click Image Size of the main icons and the Image Size control screen appears.

Info Grid shows some basic information necessary to Image Size Control.

1)

( Power Status)

- Shows the power status of the current display.

2) Image Size

- Shows the current Image Size of the display in use.

3) Input

- Info Grid displays only the displays whose Input Source is PC, BNC, DVI.

4) PC Source

- When you click Image Size, the PC Source tab first appear.

- The Image Size Control button controls Image Size available for PC, BNC, DVI.

5) Video Source

- Click the Video Source tab to control Image Size for respective Input Source.

The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
Image Size Control is available only for the displays for which power status is ON.

Image Size

TV, AV, S-Video, Component, DVI(HDCP), HDMI, DTV

1. Click Image Size of the main icons and the Image Size control screen appears.

Info Grid shows some basic information necessary to Image Size Control.

1) Click the Video Source tab to adjust Image Size for TV, AV, S-Video, Component, DVI(HDCP), HDMI, DTV.
Click Select All or use Check Box to select a display to control.

2) Info Grid displays only the display having TV, AV, S-Video, Component or DVI(HDCP) as input source.

3) Switch Image Size of the selected display randomly.

Note: Auto Wide, Zoom1 and Zoom2 are not available for selection when the input signal type for
Component and DVI (HDCP) is 720p or 1080i.
(The Auto Wide mode is available only for TV, AV, and S-Video.)

4) The screen modes can only be adjusted when a TV (PAL only) is connected and the Image Size item is set to Auto
Wide.

The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
The Image Size Control feature is available only for the displays whose power status is ON.

Time

1. Click Time of the main icons and the Time Control screen appears.

Info Grid shows some basic information necessary to Time Control.

1) Current Time

- Set the current time for the selected display (PC Time).

- To change the current time, first change the PC Time.

2) On Time Setup

- Set the Hour, Minute, AM/PM of On Time Setup, Status, Source, Volume of the selected display.

3) Off Time Setup

- Set the Hour, Minute, and AM/PM, Status for Off Time Setup of the selected display.

4) Shows the On Time settings.

5) Shows the Off Time settings.

The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
Time Control is available only for the displays for which the power status is ON.
At On Time Setup, TV Source functions only for TV Model.
At On Time Setup, MagicInfo Source functions only for MagicInfo Model.

PIP

PIP Size

1. Click PIP of the main icons and the PIP control screen appears.
Click Select All or use Check Box to select a display to control.

Info Grid shows some basic information necessary to PIP Size Control.

1) PIP Size

- Shows the current PIP Size of the display in use.

2) OFF

- Turns off the PIP of the selected display.

3) Large

- Turns on the PIP of the selected display and changes the size to Large.

4) Small

- Turns on the PIP of the selected display and changes the size to Small.

5) Double 1

- Turns on the PIP of the selected display and changes the size to Double 1.

6) Double 2

- Turns on the PIP of the selected display and changes the size to Double 2.

7) Double 3 (Picture By Picture)

- Turns on the PBP of the selected display and changes the size to Double 3.

The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
PIP Size can be controlled with turning on the LCD Display power.

PIP

PIP Source

1. Click PIP of the main icons and the PIP control screen appears.

Info Grid shows some basic information necessary to PIP Source Control.

1) PIP Source

- PIP Source can be controlled with turning on the LCD Display power.

2) PC

- Changes the source of the PIP of the selected display to PC.

3) BNC

- Changes the source of the PIP of the selected display to BNC.

4) DVI

- Changes the source of the PIP of the selected display to DVI.

5) AV

- Changes the source of the PIP of the selected display to AV.

6) S-Video

- Changes the source of the PIP of the selected display to S-Video.

7) Component

- Changes the source of the PIP of the selected display to Component.

8) HDMI

- Changes the source of the PIP of the selected display to HDMI.

Note: Some of the PIP Sources may not be available for selection, depending on the input source type
of the Main Screen.

The Input source of MagicInfo works only on MagicInfo model.
The PIP Control feature is available only for the displays whose power status is ON and the PIP

function is set to ON.

j

j

j

Settings


1. Click Settings of the main icons and the Settings Control screen appears.

Info Grid shows some basic information necessary to Settings Control.
When each function is selected, the set value of the selected function is displayed in the slide.When selected, each
function fetches the value for the set and displays it on the slide bar. When "Select All" is chosen, the default value
is displayed. Changing a value in this screen will automatically change the mode to "CUSTOM."

1) Picture

- Available only for TV, AV, S-Video, Component, HDMI, DTV.

2) Contrast

-Ad

usts Contrast of the selected display.

3) Brightness

- Adjusts Brightness of the selected display.

4) Sharpness

-Ad

usts Sharpness of the selected display.

5) Color

-Ad

usts Color of the selected display.

6) Tint

- Adjusts Tint of the selected display.

- Available only for NT.

Color Tone

7)

-Ad

j

j

j

j

usts the Color Tone for the selected display.

8) Color Temp

-Ad

usts the Color Temp for the selected display.

9) Brightness Sensor

-Ad

usts the Brightness Sensor for the selected display.

10) Dynamic Contrast

-Ad

usts the Dynamic Contrast for the selected display.

The Input source of MagicInfo works only on MagicInfo model.
Color Temp is only enabled if the Color Tone is set to Off.
The Input source of TV works only on TV model.
This feature is available only for the displays whose power status is ON and if no selection is made, the

factory default is displayed.

Settings

Picture PC

1. Click Settings of the main icons and the Settings Control screen appears.

Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value
of the selected function is displayed in the slide. When selected, each function fetches the value for the set and
displays it on the slide bar. When "Select All" is chosen, the default value is displayed. Changing a value in this
screen will automatically change the mode to "CUSTOM."

1) Picture PC

- Available only for PC, BNC, DVI.

2) Contrast

j

j

j

j

j

j

j

j

j

-Ad

usts Contrast of the selected display.

3) Brightness

-Ad

usts Brightness for the selected display.

4) Red

-Ad

usts red Color of the selected display.

- Available only for NT.

5) Green

-Ad

usts green Color of the selected display.

- Available only for NT.

6) Blue

-Ad

usts blue Color of the selected display.

- Available only for NT.

7) Color Tone

-Ad

usts the Color Tone for the selected display.

8) Color Temp

-Ad

usts the Color Temp for the selected display.

9) Brightness Sensor

-Ad

usts the Brightness Sensor for the selected display.

10) Dynamic Contrast

-Ad

usts the Dynamic Contrast for the selected display.

The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
Color Temp is only enabled if the Color Tone is set to Off.
This feature is available only for the displays whose power status is ON and if no selection is made, the

factory default is displayed.

Settings

Audio

1. Click Settings of the main icons and the Settings Control screen appears.

Info Grid shows some basic information necessary to Settings Control. When each function is selected, the set value

j

j

j

of the selected function is displayed in the slide. When selected, each function fetches the value for the set and
displays it on the slide bar. When "Select All" is chosen, the default value is displayed. Changing a value in this
screen will automatically change the mode to "CUSTOM."

1) Audio

- Controls audio settings for all input sources.

2) Bass

-Ad

usts Bass of the selected display.

3) Treble

-Ad

usts Treble of the selected display.

4) Balance

-Ad

usts Balance of the selected display.

5) SRS TS XT

- SRS TS XT Sound ON/OFF of the selected display.

6) Sound Select

- Select either Main or Sub when PIP is On.

The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
This feature is available only for the displays whose power status is ON and if no selection is made, the

factory default is displayed.

Settings

Image Lock

1. Click Settings of the main icons and the Settings Control screen appears.

Info Grid shows some basic information necessary to Settings Control.

1) Image Lock

- Available only for PC, BNC.

2) Coarse

- Adjusts Coarse of the selected display.

3) Fine

- Adjusts Fine of the selected display.

4) Position

- Adjusts Position of the selected display.

5) Auto Adjustment

- Self-Adjust to the incoming PC signal.

The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
Settings Control is available only for the displays for which the power status is ON.

Maintenance

Lamp Control

1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen.

An "Info Grid" showing several basic data items appears.

j

j

1) Maintenance

- Allows the Maintenance Control function for all input sources.

2) Auto Lamp Control

- Automatically adjusts the backlight of the selected display at a specified time.
The Manual Lamp Control automatically turns off if you ad

3) Manual Lamp Control

- Allows you to adjust the backlight of the selected display regardless of the time.
The Auto Lamp Control automatically turns off if you ad

The Maintenance Control feature is available only for the displays whose power status is ON.
The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.

ust using the Auto Lamp Control.

ust using the Manual Lamp Control.

Maintenance

Scroll

1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen.

1) Scroll

- This function is used to remove the afterimages that occur when a still screen is displayed on the selected
display
for a long time.

2) Pixel Shift

- This allows the screen to be moved finely at the specified time interval.

3) Safety Screen

- The Safety Screen function is used to prevent afterimages from occurring when a still screen is displayed on the
monitor for a long time. The Interval item is used to set the repetition cycle in hour units and the Time item is
used to set the time when the Safety Screen function must be performed.
The Type item can be set to Scroll, Pixel, Bar, Eraser, All White, or Pattern.

4) Safety Screen2

- This function is used to prevent afterimages from occurring. There are five (5) types that you can select and
control with this function.

For the Scroll type, the Time item can be set to 1, 2, 3, 4 or 5. For the Bar and Eraser types, it can be set
to 10, 20, 30, 40 or 50. For the All White and Pattern type, it can be set to 1, 5, 10, 20 or 30.

The Input source of MagicInfo works only on MagicInfo model.
The Input source of TV works only on TV model.
The Maintenance Control feature is available only for the displays whose power status is ON.

Maintenance

Video Wall

1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen.

1) Video Wall

- A Video Wall is a set of video screens that are connected together, so that each screen shows a part of the whole
picture or so that the same picture is repeated on each screen.

2) Video Wall (Screen divider)

- The screen can be divided into.
You can select a number of screens with a different layout when dividing.

z Select a mode from Screen divider.
z Select a display from Display Selection.
z The place will be set up by pressing a number in the selected mode.
z The MDC program supplied by Samsung supports up to 5x5 LCD Displayes.

3) On / Off

- Turns on/off the Video Wall function of the selected display.

4)

Format

- The format can be selected to see a divided screen.

z Full

z Natural

You may not operate this function in MagicInfo.
The Input source of TV works only on TV model.
The Maintenance Control function is available only for the displays where the power status is ON.

Troubleshooting

1. The display you wish to control does not appear on the Power Control Info Grid

- Check the connection of RS232C. (Check if it is properly connected to the Com1 port)

- Check the displays to see if any of the other displays connected have the same ID. If more than one displays have
the same ID, those displays are not properly detected by the program due to data conflict.

- Check if the Display Set ID is a number between 0 and 25. (Adjust using the Display menu)

Note : A Display Set ID must be a value between 0 and 25 .

2. The display you wish to control does not appear on the other Control Info Grids

- Check to see if the display power is ON. (You can check this in Power Control Info Grid)

- Check if you can change the input source of the display.

3. The dialogue box appears repeatedly.

- Check to see if the display you wish to control is selected.

4. Both On Timer and Off Timer have been set but different time is showing.

- Apply current time to synchronize the display clocks.

5. The remote may not function properly when you turn off the remote Function, disconnect the RS-232C cable, or exit
the program in an Irregular manner. Rerun the program and turn the remote function again to Restore normal
functions.

<Note> This program may malfunction due to problems in communication circuits or interference from electronic

appliances nearby.

Settings Value Display In Multiple Display Mode

When there are more than one displays connected, the settings values are displayed as follows.

1. No selection: Displays the Factory Default Value.

2. Selected one display: Fetches and displays the settings value for the selected display.

3. Selected one display (ID1) and add another display (ID3): The program, which was displaying the settings value of
ID 1, fetches and displays the value of ID3.

4. Selected all sets using Select All: Returns to the Factory Default Value.

Adjusting the LCD Display

Input

Available Modes

•

PC

•

HDMI

•

MagicInfo

Source List

MENU → ENTER → → ENTER →

→ , → ENTER

Use to select PC, DVI or other external input sources connected to the LCD Display. Use to
select the screen of your choice.

1. PC

2. HDMI

3. MagicInfo

• The direct button on the remote control is the 'SOURCE' button.

Edit Name

MENU → ENTER → → → ENTER →

Note

→ , → ENTER

Name the input device connected to the input jacks to make your input source selection
easier.

1. PC

2. HDMI

Picture [PC / MagicInfo Mode]

Available Modes

•

PC

•

HDMI

•

MagicInfo

MagicBright

MENU → → ENTER → → ENTER →

Adjusting the LCD Display

→ , → ENTER

MagicBright is a feature providing the optimum viewing environment depending on the con­tents of the image you are watching. Currently four different modes are available: Entertain,
Internet, Text and Custom. Each mode has its own pre-configured brightness value.

(Not available when Dynamic Contrast mode is set to On.)

1. Entertain

High brightness

For watching motion pictures such as from a DVD or VCR.

2. Internet

Medium brightness

For working with a mixture of images such as texts and graphics.

3. Text

Normal brightness

For documents or works involving heavy text.

4. Custom

Although the values are carefully chosen by our engineers, the pre-configured values
may not be comfortable to your eyes depending on your taste.

If this is the case, adjust the brightness and contrast by using the OSD menu.

Custom

Contrast

Adjusting the LCD Display

By using the on-screen menus, the contrast and brightness can be changed to your personal
preference.

MENU → → ENTER → → → ENTER →

(Not available when Dynamic Contrast mode is set to On.)

Note

By adjusting the picture using the Custom function, MagicBright will change to Custom mode.

MENU →

→ , → ENTER

Adjusts the Contrast.

Brightness

MENU →

→ , → ENTER

Adjusts the Brightness.

Sharpness

MENU →

→ ENTER → → → ENTER → → ENTER→

→ ENTER → → → ENTER → → → ENTER →

→ ENTER → → → ENTER → → → → ENTER →

→ , → ENTER

Adjusts the Sharpness.

Color Tone

MENU → → ENTER → → → →ENTER →

Adjusting the LCD Display

→ , → ENTER

The color tones can be changed.

(Not available when Dynamic Contrast mode is set to On.)

1. Off

2. Cool

3. Normal

4. Warm

5. Custom

Note

If you set the Color Tone to Cool, Normal, Warm, or Custom, the Color Temp function is
disabled.

If you set the Color Tone to Off, the Color Control function is disabled

Color Control

Adjusts individual Red, Green, Blue color balance.

MENU → → ENTER → → → → → ENTER →

(Not available when Dynamic Contrast mode is set to On.)

Note

If you adjust the picture by using the Color Control function, Color Tone will turn to the Cus­tom mode.

Red

MENU →

→ , → ENTER

Green

MENU → → ENTER → → → → → ENTER → → → ENTER

→

→ ENTER → → → → → ENTER → → ENTER →

Blue

→ , → ENTER

MENU → → ENTER → → → → → ENTER → → → →
ENTER →

→ , → ENTER

Color Temp.

MENU → → ENTER → → → → → ENTER →

→ , → ENTER

Color Temp is a measure of the 'warmth' of the image colors.

(Not available when Dynamic Contrast mode is set to On.)

This function is only enabled if the Color Tone is set to Off.

Adjusting the LCD Display

Note

Image Lock

Image Lock is used to fine-tune and get the best image by removing noise that creates un­stable images with jitters and shakiness. If satisfactory results are not obtained using the Fine
adjustment, use the Coarse adjustment and then use Fine again.

(Available in PC mode only)

(Not available when Dynamic Contrast mode is set to On.)

MENU →

Coarse

MENU → → ENTER → → → → → → ENTER → → ENTER

→

→ , → ENTER

Removes noise such as vertical stripes. Coarse adjustment may move the screen image
area. You may relocate it to the center using the horizontal control menu.

→ ENTER → → → → → → ENTER →

Fine

MENU →
ENTER →

→ , → ENTER

Removes noise such as horizontal stripes. If the noise persists even after Fine tuning, repeat
it after adjusting the frequency (clock speed).

→ ENTER → → → → → → ENTER → → →

H-Position

V-Position

Adjusting the LCD Display

MENU → → ENTER → → → → → → ENTER → → →

→ ENTER →

→ , → ENTER

Adjusts the screen location horizontally.

MENU → → ENTER → → → → → → ENTER → → → →

→ ENTER →

→ , → ENTER

Adjusts the screen location vertically.

Auto Adjustment

MENU → → ENTER → → → → → → → ENTER →

The values of Fine, Coarse, Position are adjusted automatically. By changing the resolution
in the control panel, the auto function is performed.

(Available in PC mode only)

(Not available when Dynamic Contrast mode is set to On.)

Note

The direct button on the remote control is the 'AUTO' button.

Signal Balance

This is used to make up for the weak RGB signal transmitted by a long signal cable.

MENU → → ENTER → → → → → → → → ENTER →

(Available in PC mode only)

(Not available when Dynamic Contrast mode is set to On.)

Signal Balance

MENU → → ENTER → → → → → → → → ENTER →

→ ENTER →

→ , → ENTER

Selects either On or Off with the signal control.

Signal Control

MENU → → ENTER → → → → → → → → ENTER →
→ ENTER → →

1. R-Gain

Adjusting the LCD Display

MENU → → ENTER → → → → → → → → ENTER →

→ ENTER → → → ENTER → → ENTER

→ , → ENTER

2. G-Gain

MENU → → ENTER → → → → → → → → ENTER →

→ ENTER → → → → ENTER→ → EN-

TER

→ , → ENTER

3. B-Gain

MENU → → ENTER → → → → → → → → ENTER →

→ ENTER → → → → → ENTER→ →

ENTER

→ , → ENTER

4. R-Offset

MENU →

→ ENTER → → → → → → → → ENTER →

→ ENTER → → → → → → ENTER→

→ ENTER

→ , → ENTER

5. G-Offset

Adjusting the LCD Display

Size

MENU →

→ , → ENTER

6. B-Offset

MENU → → ENTER → → → → → → → → ENTER →

→ , → ENTER

MENU → → ENTER → → → → → → → → → ENTER →

→ ENTER → → → → → → → → ENTER →

→ ENTER → → → → → → → ENTER→

→ ENTER

→ ENTER → → → → → → → → ENTER →

→ ENTER

→ , → ENTER

The Size can be switched.

(Not available when Dynamic Contrast mode is set to On.)

1. 16:9

2. 4:3

Dynamic Contrast

MENU → → ENTER → → → → → → → → → → ENTER →

→ , → ENTER

Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to
create an optimum contrast.

1. Off

2. On

Brightness Sensor

MENU → → ENTER → → → → → → → → → → → ENTER →

→ , → ENTER

Brightness Sensor automatically detects distribution of the inputted visual signal and adjusts
to create optimum brightness.

Adjusting the LCD Display

1. Off

2. On

Picture [ HDMI Mode]

Available Modes

•

PC

•

HDMI

•

MagicInfo

Mode

MENU → → ENTER → → ENTER →

→ , → ENTER

The LCD Display has four automatic picture settings ("Dynamic", "Standard", "Movie" and
"Custom") that are preset at the factory.

Dynamic, Standard, Movie, or Custom can be activated.

(Not available when Dynamic Contrast mode is set to On.)

Custom

Contrast

Adjusting the LCD Display

1. Dynamic

2. Standard

3. Movie

4. Custom

By using the on-screen menus, the contrast and brightness can be changed to your personal
preference.

MENU → → ENTER → → → ENTER →

(Not available when Dynamic Contrast mode is set to On.)

MENU →

→ , → ENTER

Adjusts the Contrast.

Brightness

MENU →

→ , → ENTER

Adjusts the Brightness.

Sharpness

MENU →

→ ENTER → → → ENTER → → ENTER→

→ ENTER → → → ENTER → → → ENTER →

→ ENTER → → → ENTER → → → → ENTER →

Color

→ , → ENTER

Adjusts the picture Sharpness.

MENU →

→ , → ENTER

→ ENTER → → → ENTER → → → → → ENTER →

Tint

Adjusting the LCD Display

Adjusts the picture Color.

MENU →

→

→ , → ENTER

Adds a natural tone to the display.

Color Tone

MENU → → ENTER → → → → ENTER →

→ , → ENTER

→ ENTER → → → ENTER → → → → → → ENTER

The color tones can be changed. The individual Color components are also user adjustable.

(Not available when Dynamic Contrast mode is set to On.)

1. Off

2. Cool2

3. Cool1

4. Normal

5. Warm1

6. Warm2

If you set the Color Tone to Cool2, Cool1, Normal, Warm1, or Warm2, the Color Temp function
is disabled.

Color Temp.

MENU → → ENTER → → → → → ENTER →

Note

→ , → ENTER

Color temp. is a measure of the 'warmth' of the image colors.

Size

Adjusting the LCD Display

(Not available when Dynamic Contrast mode is set to On.)

Note

This function is only enabled if the Color Tone is set to Off.

MENU → → ENTER → → → → → → ENTER →

→ , → ENTER

The Size can be switched.

1. 16:9

2. Zoom 1

3. Zoom 2

4. 4:3

5. Just Scan

Note

The Zoom1, Zoom2 are unavailable in HDMI mode.

Digital NR (Digital Noise Reduction)

MENU → → ENTER → → → → → → → ENTER →

→ , → ENTER

Turns the Digital Noise Reduction feature Off/On. The Digital Noise Reduction feature allows
you to enjoy clearer and crisper images.

1. Off

2. On

Digital NR function is not available for all resolutions.

Film Mode

MENU → → ENTER → → → → → → → → ENTER →

→ , → ENTER

The Film Mode feature offers you a theater-quality viewing experience.

(In HDMI mode, this function is available when the input signal is interlaced scan; it is not
available in progressive scan.)

Adjusting the LCD Display

Note

1. Off

2. On

Dynamic Contrast

MENU → → ENTER → → → → → → → → → ENTER →

→ , → ENTER

Dynamic Contrast automatically detects the distribution of the visual signal and adjusts to
create an optimum contrast.

1. Off

2. On

Brightness Sensor

MENU → → ENTER → → → → → → → → → → → ENTER →

Sound

Mode

Adjusting the LCD Display

→ , → ENTER

Brightness Sensor automatically detects distribution of the inputted visual signal and adjusts
to create optimum brightness.

1. Off

2. On

Available Modes

•

PC

•

HDMI

•

MagicInfo

MENU → → → ENTER → → ENTER →

Custom

→ , → ENTER

The LCD Display has a built-in high fidelity stereo amplifier.

1. Standard

Selects Standard for the standard factory settings.

2. Music

Selects Music when watching music videos or concerts.

3. Movie

Selects Movie when viewing movies.

4. Speech

Selects Speech when watching a show that is mostly dialog (i.e., news).

5. Custom

Selects Custom if you want to adjust the settings according to your personal preferences.

The sound settings can be adjusted to suit your personal preferences.

MENU → → → ENTER → → → ENTER →

Bass

Adjusting the LCD Display

Note

• You can hear the sound even when sound value is set to 0.

• If you adjust sound using Custom function, Mode will turn to Custom mode.

Treble

Balance

MENU →

→ , → ENTER

Emphasizes low frequency audio.

MENU →

→ , → ENTER

Emphasizes high frequency audio.

MENU → → → ENTER → → → ENTER → → → → ENTER →

→ → ENTER → → → ENTER → →ENTER→

→ → ENTER → → → ENTER → → → ENTER →

→ , → ENTER

Allows you to Adjusts the sound balance between the left and right speakers.

Auto Volume

MENU → → → ENTER → → → → ENTER →

→ , → ENTER

Reduces the difference in volume control between broadcasters.

1. Off

2. On

SRS TS XT

MENU → → → ENTER → → → → → ENTER →

→ , → ENTER

SRS TS XT is a patented SRS technology that solves the problem of playing 5.1 multichannel
content over two speakers. TruSurround delivers a compelling, virtual surround sound ex­perience through any two-speaker playback system, including internal television speakers. It
is fully compatible with all multichannel formats.

Adjusting the LCD Display

1. Off

2. On

The direct button on the remote control is the 'SRS' button.

Setup

Available Modes

•

•

•

Language

MENU → → → → ENTER → → ENTER →

Note

PC

HDMI

MagicInfo

→ , → ENTER

You can choose one of 13 languages.

Time

Adjusting the LCD Display

Note

The language chosen affects only the language of the OSD. It has no effect on any software
running on the computer.

Selects from one of 4 time settings, Clock Set, Sleep Timer, On Timer, and Off Timer.

MENU →

Clock Set

MENU → → → → ENTER → → → ENTER → → ENTER→

→ , / , → ENTER

Current Time Setting.

Sleep Timer

MENU → → → → ENTER → → → ENTER → → → ENTER→

→ → → ENTER → → → ENTER →

→ , → ENTER

Turns the LCD Display off automatically at certain times.

1. Off

2. 30

3. 60

4. 90

5. 120

6. 150

On Timer

Adjusting the LCD Display

7. 180

Off Timer

MENU →

→ , / , → ENTER

Turns the LCD Display on automatically at a preset time. Controls the mode and the volume
level at the time the LCD Display turns on automatically.

MENU →

→

→ → → ENTER → → → ENTER → → → → ENTER→

→ → → ENTER → → → ENTER → → → → → ENTER

→ , / , → ENTER

Turns the LCD Display off automatically at a preset time.

Menu Transparency

MENU → → → → ENTER → → → → ENTER →

→ , → ENTER

Change the transparency of the background of the OSD.

1. High

2. Medium

3. Low

4. Opaque

Safety Lock

Change PIN

MENU → → → → ENTER → → → → → ENTER → [Safety Lock ]→ EN­TER→ [Change PIN]

Adjusting the LCD Display

→ [0~9]→ [0~9]→ [0~9]→ [0~9]

The password can be changed.

Lock On

MENU →
TER→ → ENTER→[Lock On]

→ [0~9]→ [0~9]→ [0~9]→ [0~9]

Turns Off/On the Video Wall function of the selected display Off/On.

Energy Saving

MENU → → → → ENTER → → → → → → ENTER →

→ → → ENTER → → → → → ENTER → [Safety Lock ]→ EN-

→ , → ENTER

This feature adjusts the power consumption of the unit in order to save energy.

1. Off

2. On

HDMI Black Level

MENU → → → → ENTER → → → → → → → ENTER →

→ , → ENTER

When a DVD or set-top box is connected to your TV via HDMI, it may cause a degradation
in the screen quality, such as an increase in the black level, a low contrast, or discoloration,
etc., depending on the external device connected. In this case, adjust the screen quality of
your TV by configuring the HDMI black level.

Adjusting the LCD Display

1. Normal

2. Low

Video Wall

A Video Wall is a set of video screens connected together, so that each screen shows a part
of the whole picture or where the same picture is repeated on each screen.

When the Video Wall is on, you can adjust the Video Wall screen setting.

MENU → → → → ENTER → → → → → → → → ENTER →

When Video Wall is running, the Auto Adjustment, Image Lock, and Size functions are not
available. Video Wall does not operate in MagicInfo mode.

Video Wall

MENU → → → → ENTER → → → → → → → → ENTER →
→ ENTER →

Note

→ , → ENTER

Format

Adjusting the LCD Display

Turns Off/On the Video Wall function of the selected display Off/On.

1. Off

2. On

MENU →

→ → ENTER →

→ , → ENTER

The Format can be selected to see a divided screen.

1. Full

2. Natural

→ → → ENTER → → → → → → → → ENTER →

Provides a full screen without any margins.

Displays a natural image with the original aspect ratio intact.

Horizontal

Vertical

MENU →

→ → → ENTER →

→ , → ENTER

Sets how many parts the screen should be divided horizontally.

Five adjustment levels: 1, 2, 3, 4, and 5.

MENU → → → → ENTER → → → → → → → → ENTER →

→ → → → ENTER →

→ → → ENTER → → → → → → → → ENTER →

→ , → ENTER

Sets how many parts the screen should be divided vertically.

Five adjustment levels: 1, 2, 3, 4, and 5.

Screen Divider

MENU → → → → ENTER → → → → → → → → ENTER →
→ → → → → ENTER →

Adjusting the LCD Display

The screen can be divided into several images. A number of screens can be selected with a
different layout when dividing.

• Select a mode in Screen Divider.

• Select a display in Display Selection.

• The selection will be set up by pressing a number in the selected mode.

Safety Screen

The Safety Screen function is used to prevent afterimages that may appear when a still picture
is displayed on the screen over a long time.

• The Safety Screen function scrolls the screen for the specified period of time.

• This function is not available when the power is turned off.

MENU → → → → ENTER → → → → → → → → → ENTER →

Pixel Shift

Pixel Shift

MENU → → → → ENTER → → → → → → → → → ENTER →

→ ENTER → → ENTER → → , → ENTER

Adjusting the LCD Display

To prevent after-images on the screen you can use this function have pixels move on the
LCD in the horizontal or vertical direction.

1. Off

2. On

Note

The Pixel Shift is not available when Video Wall is On.

Horizontal Dot

MENU → → → → ENTER → → → → → → → → → ENTER →

TER

Sets how many pixels the screen moves horizontally.

Five adjustment levels: 0, 1, 2, 3, and 4.

Vertical Line

MENU → → → → ENTER → → → → → → → → → ENTER →

ENTER

→ ENTER → → → ENTER → → , → EN-

→ ENTER → → → → ENTER → → , →

Sets how many pixels the screen moves vertically.

Five adjustment levels: 0, 1, 2, 3, and 4.

Time

Timer

Timer

Adjusting the LCD Display

MENU → → → → ENTER → → → → → → → → → ENTER →

→ ENTER → → → → → ENTER → → , → ENTER

Set the time interval for performing the horizontal or vertical movement, respectively.

MENU → → → → ENTER → → → → → → → → → ENTER →

→ → ENTER → → ENTER → → , → ENTER

Mode

You can set the timer for Screen Burn Protection.

If you start the operation to erase any residual image, the operation will be performed for the
set period of time and then automatically finish.

1. Off

2. On

MENU → → → → ENTER → → → → → → → → → ENTER →

→ → ENTER → → → ENTER → → , → ENTER

You can change the Safety Screen Type.

1. Scroll

Period

Time

Adjusting the LCD Display

2. Bar

3. Eraser

MENU → → → → ENTER → → → → → → → → → ENTER →

→ → ENTER → → → → ENTER → → , → ENTER

Use this function to set the execution period for each mode set in the timer.

Scroll

MENU →

Within the set period of time specify a time for execution.

• Mode-Scroll : 1~5 sec

• Mode-Bar, Eraser : 10~50 sec

MENU →

→ → → ENTER → → → → → → → → → ENTER →

→ → ENTER → → → → → ENTER → → , → ENTER

→ → → ENTER → → → → → → → → → ENTER →

→ → → ENTER →

This function helps to remove after-images on the screen by moving all the pixels on the LCD
according to a pattern.

Use this function when there are remaining after-images or symbols on the screen, especially
when you displayed a still image on the screen for a long time.

Bar

Eraser

Adjusting the LCD Display

MENU → → → → ENTER → → → → → → → → → ENTER →

→ → → →ENTER →

This function prevents after-images on the screen by moving long black and white vertical
lines.

MENU →

This function prevents after-images on the screen by moving a rectangular pattern.

Resolution Select

MENU → → → → ENTER → → → → → → → → → →ENTER →

→ → → ENTER → → → → → → → → → ENTER →

→ → → → →ENTER →

→ , → ENTER

When the picture is not displayed properly on the screen when setting the graphics card
resolution of the computer to 1024 x 768 @ 60Hz, 1280 x 768 @ 60Hz, 1360 x 768 @ 60Hz
or 1366 x 768 @ 60Hz, by using this function(Resolution Select), you can have the picture
displayed on the screen in the specified resolution.

Note

Available in PC mode only

1. Off

2. 1024 x 768

3. 1280 x 768

4. 1360 x 768

5. 1366 x 768

Note

Selecting the menu is only allowed when the graphics resolution is set to 1024 x 768 @ 60Hz,
1280 x 768 @ 60Hz, 1360 x 768 @ 60Hz or 1366 x 768 @ 60Hz.

Power On Adjustment

MENU → → → → ENTER → → → → → → → → → → → ENTER

→

Adjusting the LCD Display

→ , → ENTER

Adjusts the Power On time for the screen.

Side Gray

MENU → → → → ENTER → → → → → → → → → → → →
ENTER →

→ , → ENTER

Select the brightness of the grey for the screen background.

1. Off

2. Light

3. Dark

Reset

Reverts the product settings to factory defaults. The Reset function is only available when
PC / DVI is being used.

MENU → → → → ENTER → → → → → → → → → → → →
→ ENTER →

Image Reset

MENU → → → → ENTER → → → → → → → → → → → →

→ ENTER → → ENTER →

→ , → ENTER

Note

Available in PC mode only

Adjusting the LCD Display

Note

The Reset function is not available when Video Wall is On.

Color Reset

MENU → → → → ENTER → → → → → → → → → → → →

→ ENTER → → → ENTER →

→ , → ENTER

OSD Rotation

MENU → → → → ENTER → → → → → → → → → → → → →

→ → ENTER →

→ , → ENTER

OSD Rotate

1. Landscape

2. Portrait

Lamp Control

MENU → → → → ENTER → → → → → → → → → → → → →

→ ENTER →

→ , → ENTER

Adjusts the inverter lamp in order to reduce energy consumption.

Note

Not available when Dynamic Contrast mode is set to On.

Multi Control

Available Modes

•

Adjusting the LCD Display

PC

•

•

Multi Control

Assigns an individual ID to the SET.

MENU → → → → → ENTER → → ENTER

→ , → [0~9]

• ID Setup

HDMI

MagicInfo

Assigns distinctive IDs to the SET.

MagicInfo

• ID Input

Use to select the transmitter functions of the individual SET. Only a SET where the ID
corresponds to the transmitter setting becomes activated.

Available Modes

•

PC

•

HDMI

Adjusting the LCD Display

•

MagicInfo

Note

• The remote control can be used to select MagicInfo. However, it is recommended to use
a separate USB keyboard to utilize MagicInfo fully.

• For MagicInfo in Device mode, moving external devices while booting may cause errors.
Set up external devices only if the LCD Display turns on.

• Do not unplug the LAN cable used for the network (ex: video display). Otherwise, the
program (MagicInfo) may stop. If you do unplug the cable, restart the system.

• Do not unplug the LAN cable used by an USB device (ex: video display). Otherwise, the
program (MagicInfo) may stop.

• To access other sources, press the SOURCE button in MagicInfo.

• The preset password for the LCD Display is "000000".

• The server program's Power-On option works only if the LCD Display's power is com­pletely shut off.

Please make sure not to use the Power-On option when the LCD Display is in the process
of shutting down since this may cause system errors on the LCD Display.

• In the OSD image of MagicInfo, Network mode is the same as Device.

• When using MagicInfo with the MagicInfo Server Program: perform Network mode.

• When using MagicInfo with the device directly connected to LCD Display : execute Device
mode.

• Press ALT + F12 to directly go to the MagicInfo Window screen.

• To setup MagicInfo on a Windows screen, a keyboard and mouse are required.

• To setup MagicInfo on a Windows screen, refer to the MagicInfo Server Help.

It is highly recommended not to turn off the AC power during an operation.

• For pivoted LCD Displays, ticker transparency is not supported.

• For pivoted LCD Displays, a screen resolution of up to 720*480(SD) is supported for
movies.

• For drive D:, EWF is not applied.

MagicInfo

• To save Setup contents that have been changed when EWF is in the Enable state, you
must Commit them.

• By selecting Disable, Enable or Commit, the system is restarted.

1. Select Application - step 1

Adjusting the LCD Display

You can select an Application to be executed in your computer when Windows starts.

2. Select TCP/IP - step 2

In step 2 of MagicInfo Setup Wizard, you don’t have to go to Network Setting on the desktop
to make your settings for TCP/IP. You just do that at step 2 of MagicInfo installation.

3. Select Language - step 3

Adjusting the LCD Display

When using multiple languages, you can choose and set a specific language among them.

4. Select Screen Type - step 4

You can select which rotation type will be applied to your device.

5. Setup Information

Adjusting the LCD Display

Shows the settings that have been selected by the user.

Note

If the MagicInfo icon is not displayed on the notification area, double click the MagicInfo icon
on the window desktop. The icon will appear.

Troubleshooting

Self-Test Feature Check

Note

Check the following items yourself before calling for assistance. Contact a Service Center for
problems that you cannot solve by yourself.

Self-Test Feature Check

1. Turn off both your computer and the LCD Display.

2. Unplug the video cable from the back of the computer.

3. Turn on the LCD Display.

The figure shown below ("Check Signal Cable") appears on a black background when
the LCD Display is working normally even though no video signal is detected: While in
the Self-Test mode, the LED power indicator remains green and the figure moves around
on the screen.

4. Turn off your LCD Display and reconnect the video cable; then turn on both your com-

puter and the LCD Display

If your LCD Display screen remains blank after using the previous procedure, check your
video controller and computer system; your LCD Display is functioning properly.

Warning Messages

You can even view the screen at a resolution of 1920 x 1080. However, you will receive the
following message for a minute; You can choose to change the screen resolution or stay in
the current mode during that time. If the resolution is more than 85Hz, you will see the black
screen because the LCD Display does not support over 85Hz.

Note

Refer to Specifications > Preset Timing Modes for the resolutions or frequencies supported
by the LCD Display.

Maintenance and Cleaning

1) Maintaining the LCD Display Case.

Clean with a soft cloth after disconnecting the power cord.

Troubleshooting

• Do not use benzene, thinner or other flammable sub­stances.

2) Maintaining the Flat Panel Display Screen.

Clean with a soft cloth (cotton flannel).

• Never use acetone, benzene or thinner.

(They may cause flaws or deformation of the screen
surface.)

• The user is responsible for any damage caused by
using these substances.

Symptoms and Recommended Actions

Note

A LCD Display recreates visual signals received from the computer. Therefore, if there is a
problem with the computer or the video card, this can cause the LCD Display to become
blank, have poor coloring, become noisy, etc. In this case, first check the source of the prob­lem, and then contact a Service Center or your dealer.

1. Check if the power cord and the video cables are properly connected to the computer.

2. Check if the computer beeps more than 3 times when booting.

3. If you installed a new video card or if you assembled the PC, check if you installed the

4. Check if the scanning ratio of the video screen is set to between 50 Hz ~ 85 Hz.

5. If you have problems in installing the Adaptor (video) driver, boot the computer in Safe

Check List

• The following table lists possible problems and their solutions. Before calling for assis-

(If it does, request service.)

Adaptor(video).

(Do not exceed 60Hz when using the maximum resolution.)

Mode, remove the Display Adaptor in the "Control Panel −> System −> Device Admin­istrator" and then reboot the computer to reinstall the Adaptor (video) driver.

Note

tance, check the information in this section to see if you can remedy any problems for
yourself. If you do need assistance, please call the phone number on the Information
section or contact your dealer.

• For more network-related information, refer to the MagicInfo Troubleshooting section.

Problems related to the Installation (PC Mode)

Note

Problems related to the LCD Display installation and their solutions are listed.

Q: The LCD Display screen flickers.

A: Check if the signal cable between the computer and the LCD Display is securely con-

nected.

(Refer to Connecting a Computer)

Problems related to the Screen

Note

Problems related to the LCD Display screen and their solutions are listed.

Q: The screen is blank and the power indicator is off.

A: Ensure that the power cord is firmly connected and the LCD Display is on.

(Refer to the Connecting a Computer)

Q: "Check Signal Cable" message.

A: Ensure that the signal cable is firmly connected to the PC or video sources.

(Refer to the Connecting a Computer)

Troubleshooting

A: Ensure that the PC or video sources are turned on.

Q: "Not Optimum Mode" message.

A: Check the maximum resolution and the frequency of the video adaptor.

A: Compare these values with the data in the Preset Timing Modes Chart.

Q: The picture rolls vertically.

A: Check if the signal cable is securely connected. Re-connect it, if necessary.

(Refer to Connecting a Computer)

Q: The image is not clear; picture is blurred.

A: Run Frequency Coarse and Fine tuning.

A: Turn on again after removing all accessories (video extension cable, etc.)

A: Set the resolution and frequency to the recommended ranges.

Q: The picture image is unstable and shakes.

A: Check if the resolution and frequency set for the computer video card falls in the range

supported by the LCD Display. If not, reset them referring to the current Information
under the LCD Display menu and Preset Timing Modes

Q: Ghost images are shown in the picture.

A: Check if the resolution and frequency set for the computer video card falls in the range

supported by the LCD Display. If not, reset them referring to the current Information
under the LCD Display menu and Preset Timing Modes

Q: The image is too light or too dark.

A: Adjust the brightness and contrast.

(Refer to the Brightness, Contrast)

Troubleshooting

Q: The screen color is inconsistent.

A: Adjust color using Custom under OSD Color Adjustment menu.

Q: The color image is distorted by dark shadows.

A: Adjust color using Custom under OSD Color Adjustment menu.

Q: The color white is poor.

A: Adjust color using Custom under OSD Color Adjustment menu.

Q: The Power Indicator blinks.

A: The LCD Display is currently saving the changes made in the settings to the OSD

memory.

Q: The screen is blank and the power indicator light blinks every 0.5 or 1 seconds.

A: The LCD Display is using its power management system.

A: Press any key on the keyboard.

Q: The screen is blank and it is blinking.

A: If you see the "TEST GOOD" message on the screen when you pressing the MENU

button, check the cable connection between the LCD Display and the computer to en­sure that the connector is properly connected.

Problems related to Audio

Note

Problems related to audio signals and their solutions are listed below.

Q: No sound.

A: Ensure that the audio cable is firmly connected to both the audio-in port on your LCD

Display and the audio-out port on your sound card.

(Refer to the Connecting a Computer)

A: Check the volume level.

Q: The sound level is too low.

A: Check the volume level.

A: If the volume is still too low after turning the control to its maximum, check the volume

control on the computer sound card or software program.

Q: The sound is too high or too low.

A: Adjusts the Treble and Bass to the appropriate levels.

Problems related to the Remote Control

Note

Problems related to the remote control and their solutions are listed.

Q: The remote control buttons do not respond.

Q & A

Troubleshooting

A: Check the polarities (+/-) of the batteries.

A: Check if the batteries are empty.

A: Check if the power is on.

A: Check if the power cord is securely connected.

A: Check if a special fluorescent or neon lamp is on in the vicinity.

Q: How can I change the frequency?

A: The frequency can be changed by reconfiguring the video card.

Note

That video card support can vary, depending on the version of the driver used. (Refer
to the computer or the video card manual for details.)

Q: How can I adjust the resolution?

A: Windows XP:

Set the resolution in the Control Panel → Appearance and Themes → Display → Set­tings.

A: Windows ME/2000:

Set the resolution in the Control Panel → Display → Settings.

* Contact the video card manufacturer for details.

Q: How can I set the Power Saving function?

A: Windows XP:

Set the resolution in the Control Panel → Appearance and Themes → Display → Screen
Saver.

Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer
Manual).

A: Windows ME/2000:

Set the resolution at the Control Panel → Display → Screen Saver.

Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer
Manual).

Q: How can I clean the outer case/LCD Panel?

A: Disconnect the power cord and then clean the LCD Display with a soft cloth, using either

a cleaning solution or plain water.

Do not leave any detergent or scratches on the case. Do not let any water enter the
LCD Display.

Q: How can I play the video?

Troubleshooting

A: The video supports the MPEG1 and WMV codecs only. Install the corresponding codec

to play the video. Note that some of the codecs can be incompatible.

Note

Before calling for assistance, check the information in this section to see if you can remedy
any problems yourself. If you do need assistance, please call the phone number on the In­formation section or contact your dealer.

Specifications

General

General

Model Name SyncMaster 230TSN, 230MXN

LCD Panel

Size 23 inch (58 cm)

Display area 509.76 mm (H) x 286.74 mm (V)

Pixel Pitch 0.2655 mm (H) x 0.2655 mm (V)

Synchronization

Horizontal 31 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7 M

Synchronization

Optimum resolution 1920 x 1080 @ 60 Hz

Maximum resolution 1920 x 1080 @ 60 Hz

Input Signal, Terminated

1 RGB Analog, HDMI

0.7 Vp-p ±5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

Maximum Pixel Clock

164MHz (Analog,Digital)

Power Supply

This product supports 100 – 240 V.

Since the standard voltage may differ from country to country, please check the
label on the back of the product.

Less than 30Ap-p at AC 120V or 50Ap-p at AC 220V

Signal Connectors

D-sub, HDMI, RS232C In, PC Audio(Stereo) In, Audio Out, LAN, USB(4port), VGA
OUT(Network)

Dimensions (W x H x D) / Weight

SyncMaster 230TSn 557.5 x 339.0 x 79.2 mm / 21.9 x 13.3 x 3.1 inches / 8.35

kg / 18.4 lb

Specifications

Dimensions (W x H x D) / Weight

SyncMaster 230MXn 557.5 x 339.0 x 73.9 mm / 21.9 x 13.3 x 2.9 inches / 7 kg /

15.4 lb

VESA Mounting Interface

100 x 100mm

Environmental con­siderations

Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Plug and Play Capability

This LCD Display can be installed on any Plug & Play compatible system. The
interaction of the LCD Display and the computer systems will provide the best op­erating conditions and LCD Display settings. In most cases, the LCD Display
installation will proceed automatically, unless the user wishes to select alternate
settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with
precision of 1ppm (one millionth) above are used for this product. But the pixels of
RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some
black pixels may be seen. This is not from bad quality and you can use it without
any problems.

Humidity : 10 % ~ 80 %, non-condensing

Humidity : 5 % ~ 95 %, non-condensing

For example, the number of TFT-LCD sub pixels contained in this product are
6,220,800.

Design and specifications are subject to change without prior notice.

This product complies with the Electromagnetic Compatibility Directives for residential use
and can be used in all areas including common residential areas. (Class B equipment emits
less electromagnetic waves than Class A equipment.)

PowerSaver

This LCD Display has a built-in power management system called PowerSaver. This system
saves energy by switching your LCD Display to low-power mode when it has not been used
for a certain amount of time. The LCD Display automatically returns to normal operation when
you press a key on the keyboard. For energy conservation, turn your LCD Display OFF when
it is not needed, or when leaving it unattended for long periods. The PowerSaver system
operates with a VESA DPM compliant video card installed in your computer. Use the software
utility installed on your computer to set up this feature.

Note

Class B Equipment (Information Communication equipment for residential use)

Specifications

State Normal Opera-

Power Indicator On Blinking Off

Power Consumption 80 watts 5 watts 0 watts

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes,
the screen will be adjusted automatically. However, if the signal differs, the screen may go
blank while the power LED is on. Refer to the video card manual and adjusts the screen as
follows.

Display Mode Horizontal

IBM, 640 x 350 31.469 70.086 25.175 +/-

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

VESA, 640 x 480 31.469 59.940 25.175 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 x 800 49.702 59.810 83.500 -/+

VESA, 1280 x 800 62.795 74.934 106.500 -/+

VESA, 1280 x 960 60.000 60.000 108.000 +/+

VESA, 1280 x 1024 63.981 60.020 108.000 +/+

VESA,1440 x 900 55.935 59.887 106.500 -/+

VESA,1440 x 900 70.635 74.984 136.750 -/+

VESA,1600 x 1200 75.000 60.000 162.000 +/+

VESA,1680 x 1050 65.290 59.954 146.250 -/+

VESA,1920 x 1080 67.500 60.000 148.500 +/+

tion

Frequency

(kHz)

Power saving

Vertical Fre­quency (Hz)

mode

Pixel Clock

(MHz)

Power off

Sync Polarity

(H/V)

Horizontal Frequency

The time to scan one line connecting the right edge
to the left edge of the screen horizontally is called the
Horizontal Cycle and the inverse number of the Hor­izontal Cycle is called the Horizontal Frequency.
Unit: kHz

Vertical Frequency

Specifications

Like a fluorescent lamp, the screen has to repeat the
same image many times per second to display an
image to the user. The frequency of this repetition is
called the Vertical Frequency or Refresh Rate. Unit:
Hz

Information

For Better Display

Adjust the computer resolution and screen injection rate (refresh rate) on the
computer as described below to enjoy the best picture quality. You can have an
uneven picture quality on screen if the best picture quality is not provided for TFT­LCD.

• Resolution: 1920 X 1080

• Vertical frequency (refresh rate): 60 Hz

TFT-LCD panels manufactured by using advanced semiconductor technology
with a precision of 1ppm (one millionth) and above is used for this product. But the
pixels of RED, GREEN, BLUE and WHITE color seem to be bright sometimes or
some of black pixels could be seen. This is not from bad quality and you can use
it without any problems.

• For example, the number of TFT-LCD sub pixels contained in this product are

6,220,800.

When cleaning the monitor and the panel outside, please apply the recom­mended small amount of cleaner by using a soft cloth to polish. Rub softly when
cleaning the LCD area. If excessive force is applied, you may stain it.

If you are not satisfied with the picture quality, you can get better quality of
picture by performing the "Auto Adjustment function" in display screen that is ap­peared as window termination button is pressed. If there's still noise after the
automatic adjustment, use the Fine/Coarse adjustment function.

When viewing a fixed screen for an extended period of time, a residual image
or blurriness may appear. Change the mode to energy save or set a screensaver
to move the picture when you need to be away from the monitor for an extended
period of time.

PRODUCT INFORMATION (Image Retention Free)

LCD Monitors and TVs may have image retention when switching from one image to another
especially after displaying a stationary image for a long time.

This guide is to demonstrate correct usage of LCD products in order to protect them from
Image retention.

Warranty

Warranty does not cover any damage caused by image retention.

Burn-in is not covered by the warranty.

What is Image retention ?

During normal operation of a LCD panel, pixel image retention doesn't occur. How­ever, if the same image is displayed for a long time, a slight difference in electric
charge accumulates between the two electrodes which encase the liquid crystal.
This may cause the liquid crystal to build up in a certain areas of the display. Thus,
the previous image is retained when switching to a new video image. All display

Information

products, including LCD, are subject to image retention. This is not a product de­fect.

Please follow the suggestions below to protect your LCD from image retention.

Power Off, Screen Saver, or Power Save Mode

Ex)

• Turn the power off when using a stationary pattern.

• Turn the power off for 4 hours after 20 hours in use

• Turn the power off for 2 hours after 12 hours in use

• Use a Screen saver if possible

• Screen saver in one color or a moving image is recommended.

• Set the Monitor to power off with the PC Display Properties Power Scheme.

Suggestions for specific applications

Ex) Airports, Transit Stations, Stock Markets, Banks, and Controlling Systems We
recommend that you follow set up of your display system program as below:

Display Information together with Logo or Moving image cycle.

Ex) Cycle : Display Information for 1 hour followed by a Display Logo or moving
image for 1 minute.

Change the Color Information periodically (Use 2 different colors).

Ex) Rotate the Color Information with 2 colors every 30 minutes.

Avoid using a combination of characters and background color with large difference
in luminance.

Avoid using Grey colors, which can cause Image retention easily.

• Avoid: Colors with big difference in luminance (Black & White, Grey)

Ex)

• Recommended settings: Bright colors with little difference in luminance

• Change the characters color and background color every 30 minutes

Information

Ex)

• Every 30 minutes, change the characters with movement.

Ex)

The best way to protect your monitor from Image retention is to set your PC or

System to operate a Screen Saver program when you are not using it.

Image retention may not occur when a LCD panel is operated under normal con­ditions.

Normal conditions are defined as continuously changing video patterns. When the
LCD panel is operated for a long time with a fixed pattern (-over 12 hours-), there
may be slight difference in voltage between electrodes that work the liquid crystal
(LC) in a pixel. The voltage difference between electrodes increases with time,
forcing the liquid crystal to lean. When this occurs, the previous image may be seen
when the pattern is changed.

To prevent this, the accumulated voltage difference must be decreased.
